Escondido Union High School District

Welding and Fabrication 3

EUHSD Board Approval Date: 4/17/18

1

The EUHSD Welding and 3 curriculum document identifies what students should be able to know by grade level in a comprehensive standards-based course of study. The curriculum document is updated annually based on student academic achievement data, research and best practices, and input from stakeholders. The EUHSD curriculum document contains the following documents and/or information: A. Course Description B. Course Guidelines/Requirements - graduation credit information, transcript information, adopted materials, adopted , assessment outline C. Instructional Materials References D. Scope and Sequence Map with Essential Standards outlined by Unit E. References to key essential design and implementation documents

A comprehensive course of study and/or program is designed so that all students have access to the rigorous curriculum necessary to graduate high school demonstrating college and career readiness skills. Student-Centered learning provides opportunity for collaboration, , and a robust learning environment and provides opportunities for all students to meet the goals of the district’s Instructional Focus at the time of this writing: “All students communicate their thinking, ideas and understanding by effectively using oral, written and/or non-verbal expression.”

A key design consideration in the transition to the new California State Standards is a focus on changes to pedagogy. The English Language Arts instructional shifts guide classroom teaching and learning and the foundation of curriculum and instructional design. Key considerations of the ELA Instructional shifts can be found by visiting the following URL: http://www.corestandards.org/other-resources/key-shifts- in-english-language-arts/

The curriculum document is aligned to the California Model Career Technical Education Standards and reflects learning outcomes from both the anchor and pathway standards.

2

Welding and Metal Fabrication 3 Course Description Welding and Metal Fabrication 3 is a two-semester third year class and the “capstone” course of the Manufacturing and Product Development Career Pathway. Students who complete this course have completed the pathway requirements and have attained practical, marketable skills and certifications making them uniquely prepared to enter post-secondary welding and metal fabrication preparation programs and jobs. Students at this level don’t just follow industry practices but lead other students by demonstrating their exemplary understanding of workplace safety and collaboration in a functional lab-based instructional setting. In addition to welding and metal fabrication skills and content knowledge, this course continues to provide project-based experiences that develop the unique leadership and critical thinking skills that jobs in this competitive industry require. Students add to their understanding regarding the history of welding and fabrication and develop a practical understanding of today's processes in order to look forward to emerging and applications in the field. Students complete sophisticated projects using advanced techniques that require the use of equipment such as gas, arc, MIG and TIG welding as well as and oxyacetylene cutting equipment; they then apply advanced tests on their products and respond to feedback by revising their work to meet industry specific standards to receive certifications. The course culminates with students describing in detail their portfolio of work and presenting it along with samples to real audiences and for real purposes such as local fairs and trade shows.

Course Requirements Course Length: Year Long Grade Level: 11-12 UC/CSU Requirement: Meets UC/CSU “g” requirement Graduation Requirement: EUHSD Elective Credit or CTE Requirement Course Number (Semester A): 6364 Transcript Abbreviation (Semester A): WELD MTL FAB 3 P A Course Number (Semester B): 6365 Transcript Abbreviation (Semester B): WELD MTL FAB 3 P B Credits (Semester A): 5 Elective or CTE Credits (Semester B): 5 Elective or CTE Required Prerequisite/s: Welding and Metal Fabrication 2 with grade of “C” or better Recommended Prerequisite/s: None Industry Sector: Manufacturing and Product Development Career Pathway: Welding and Materials Joining Board Approval Date (Curriculum): 4/17/18 Board Approval Date (Materials): Instructional Material/s: Supplemental Instructional Material/s: • GMAW, & FCAW (DVDs, Instructor Guides, Technical Guides, Student Workbook, Written Tests) • Gas Metal Handbook, W. Minnick. Goodheart-Willcox Publisher • Welding and Metal Fabrication, by Larry Jeffus, Cengage Learning • Shielded Metal Arc Welding, Walker/Polanin. G-W Publisher • Modern Welding, 11th Edition by Andrew D. Althouse and Carl H. Turnquist, 2013 • Oxyfuel Gas Welding, Bowditch/Bowditch. G-W Publisher • S/P2 Welding Safety Course • Cored Arc Welding Handbook, W. Minnick. G-W Publisher • Gas Arc Welding Handbook, Minnick/Prosser. G-W Publisher

Technology Resource/s: Students utilize a variety of technical equipment in the work/lab space including a variety of safety apparatus, welding and metal working and machines, and occasional access to computer workstations loaded with content specific software. Assessments: The course is designed as a project-based curriculum and includes a variety of formative and summative assessments. Each unit outlines specific skills and/or long-term projects, which serve as unit and course assessments. Meeting the Needs of ELs: Our student information system is used by site leaders and instructors to acquire the language levels of EUHSD English Learners to ensure they are identified and their specific needs are met. Our approach to supporting English learners in based on the CA Department of Education (CDE) adopted language level proficiency descriptors and updated ELD Learning Standards. Visit the following website to learn more about those new descriptors and corresponding standards: http://www.cde.ca.gov/sp/el/er/documents/eldstndspublication14.pdf EUHSD uses the ELA-ELD Framework to inform pedagogical practices related to supporting English Learners. Visit the following URL to learn more about the new frameworks which describe in detail specific research-based best practices used to support English Learners: http://www.cde.ca.gov/ci/rl/cf/documents/elaeldfwchapter11.pdf

3

Instructional Resources: Instructional Strategies:

• Machinery’s Handbook • Teacher led modeling and direct instruction • https://sp2.org/site/ • Industry guest presentation • www.osha.gov • Industry fieldtrips and open-houses • www.youtube.com • Video demonstrations • Safety Manual • Group work and/or pair work • Precision Technology, Section4:" Press" • Differentiate vocabulary or use of glossary • http://www.globalclassroom.org/rulergame200/ • Teacher led demonstrations on all equipment prior to safety tests • A variety of intermediate digital and print texts including instructional and modeling videos • Use of instructional notebooks and digital and physical portfolios

4

Scope and Sequence Guide

The Scope and Sequence Guide for this course is informed by the California Learning Standards and delineates the concepts and skills students are expected to acquire in order to meet College and Career Readiness expectations set for by the state and local board approved guidelines. Each unit of study is designed to build upon the previous unit and/or prerequisite coursework in support of student mastery of specific standards based skills. This Scope and Sequence document provides guidelines for instructors to ensure they have the necessary information related to content and pedagogy to guarantee students can meet the learning objectives of the course. The document is updated as needed based on input from all stakeholders to ensure it meets the needs of students.

All Career Technical Education coursework in the EUHSD is based on a series of state-adopted CTE standards which include the CTE Knowledge and Performance Anchor Standards, the California Standards for Career Ready Practice, and the CTE Model Curriculum Pathway Specific Standards. Not every standard and its related learning objective is included in the Scope and Sequence Guide since this document provides the essential pathway focus standards and key learning objectives for each unit with the related assignments and assessments. However, all of the CTE model Curriculum Pathway Standards are imbued in the student tasks throughout the course with specific standards emphasized in particular units in order to ensure students build the skills to ensure their success.

The CTE Standards for Career Ready Practice and CTE Model Curriculum Pathway Specific Standards below are integrated throughout the units and describe the fundamental knowledge and skills that a career ready student needs in order to prepare for transition to postsecondary education, career training, or the workforce. These standards are not exclusive to a career pathway, a CTE program of study, a particular discipline, or level of education. Standards for Career Ready Practice are taught and reinforced in all career exploration and preparation programs with increasingly higher levels of complexity and expectation as a student advances through a given pathway/program of study. CTE Standards for Career Ready Practice CTE Model Curriculum Pathway Specific Standards 1. Apply appropriate technical skills and academic knowledge. 1. Academics: Analyze and apply appropriate academic standards… 2. Communicate clearly, effectively, and with reason [both in writing and verbally] 2. : Acquire and accurately use general academic and domain specific words… 3. Develop an education and career plan aligned with personal goals. 3. Career Planning and Management: Integrate multiple sources of information… 4. Apply technology to enhance productivity 4. Technology: Use technology, including the Internet, to produce, publish, and update writing… 5. Utilize critical thinking to make sense of problems and persevere in solving them. 5. Problem Solving and Critical Thinking: Conduct short as well as more sustained research… 6. Practice personal health and understand financial literacy. 6. Health and Safety: Determine the meaning of symbols, key words [related to health and safety…] 7. Act as a responsible citizen in the workplace and the community 7. Responsibility and Flexibility: Initiate and participate in a range of collaborative discussions… 8. Model integrity, ethical leadership, and effective management. 8. Ethics and Legal Responsibilities: Respond thoughtfully to diverse perspectives… 9. Work productively in teams while integrating cultural and global competence. 9. Leadership and Teamwork: Work with peers…[to] set clear goals,...establish individual roles… 10. Demonstrate creativity and innovation 10. Technical Knowledge and Skills: Use technology…to produce, publish, and update…products… 11. Employ valid and reliable research strategies. 11. Demonstration and Application: Demonstrate and apply the knowledge and skills contained in the 12. Understand the environmental, social, and economic impacts of decisions industry-sector anchor standards, pathway standards, and performance indicators…

5

Welding and Metal Fabrication 3 Scope and Sequence Unit 1 – Review Workshop Safety Length: 1 Week and Ongoing Unit Description: Unit 1 is repeated again to ensure student safety and well-being and to reinforce workshop environmental safety and lab hygiene. Students re-examine and create specific safety policies, procedures, and practices. They also examine sample workspaces for safety and/or health concerns and demonstrate a variety of safety practices through various classroom assignments and activities and will demonstrate their understanding through completion of a required safety assessments but this time at a higher level which includes instructing and re-teaching peers and others to demonstrate safety leadership and communication skills. All the skills and procedures acquired in this unit are used throughout the remainder of the course. Year three students are encouraged to be exemplary in their adherence to best practices related to safety and safety leadership and management. Focus Unit Standards: Learning Objectives: Key Unit Assignments and Assessments:

Manufacturing and Product Development Anchor Standards: Students will… • Year 3 students provide safety demonstrations to their peers 6.1 Locate, and adhere to, Material Safety Data Sheet (MSDS) instructions. • Create and/or describe in detail the Material and year 1 and 2 students. 6.2 Interpret policies, procedures, and regulations for the workplace Safety Data Sheet including what it is, its • In order to demonstrate their ability to work safely in the environment, including employer and employee responsibilities. features, where to access it, and how to apply its shop environment, all students in course 3 shall re-take a 6.3 Use health and safety practices for storing, cleaning, and maintaining information to enhance personal safety. Students multiple choice safety and measurement assessment and tools, equipment, and supplies. may be asked to create documents and safety pass the test with 100% accuracy prior to utilizing 6.4 Set up a work area, or shop, to avoid potential health concerns and safety related materials for students in the entry-level equipment and/or working in the shop area. hazards including but not limited to ergonomics, electrical (shock), wires course. • Students will review, revise and/or develop a (tripping), fumes (lung health), noise (hearing loss), fire (), and so forth, • Review and present a workshop protocol housekeeping/clean-up plan for each shop based on incorporating ergonomics. document to demonstrate that they understand photographs and videos of the workshops as they appear 6.5 Practice personal safety when lifting, bending, or moving equipment and what they are responsible for in the workshop. during actual work. The plan will be in a spreadsheet supplies. • Show their understanding of how to properly format, identifying potential hazards and ways to mitigate 6.6 Demonstrate how to prevent and respond to work-related accidents or store, clean and maintain tools, equipment and those hazards so they do not result in injuries. injuries and emergencies. supplies through writing and application. • Students complete a series of measurement tests designed 6.7 Maintain a safe and healthful working environment. • Safely set up their work areas to avoid health to assess their understanding and mastery of basic 6.8 Be informed of laws/acts pertaining to the Occupational Safety and Health hazards and injuries. measurements utilized throughout the course. This may be Administration (OSHA). • Demonstrate safe and proper techniques when either a hands on and/or paper demonstration of moving equipment and supplies. understanding. (fraction, inch, decimal inch, dial caliper, Manufacturing and Product Development Pathway Standards: • Demonstrate how to prevent and respond to work , etc.). C9.1 Know how scheduling, quality control, accident prevention, and related accidents, injuries and emergencies. • Students complete a formal evaluation of safety posters inventory control are used efficiently and appropriately in a welding • Maintain a safe and healthful work environment. determining accuracy and relevance. production management system. • Describe and apply 2-3 OSHA laws to various scenarios and projects in the lab.

6

Welding and Metal Fabrication 3 Scope and Sequence Unit 2 – Advanced Welding and Cutting Processes Length: Ongoing (these skills and concepts in are reinforced and refined throughout the school year) Unit Description: In Unit 2, after receiving comprehensive instruction on the various machines, students will use various welding and cutting processes (GMAW, FCAW, SMAW, GTAW, OFW, and OFC) and machinery to produce components, which will be jointed, resulting in fabricated projects. Focus Unit Standards: Learning Objectives: Key Unit Assignments and Assessments:

Manufacturing and Product Development Pathway Standards: Students will… Select tasks below will be part of the student’s certification process. C2.0 Understand and demonstrate how materials can be processed • Use cutting and grinding tools to prepare various Students will spend a significant amount of time throughout the school through the use of welding tools and equipment. welded joints. year practicing the concepts and skills integrated in these project-based C2.2 Use standard and new emerging welding tools and equipment, • Properly install the major components, set up tasks. such as fuel cutting (OFC), plasma arc cutting (PAC), and control parameters, and install appropriate carbon arc cutting (CAC) to cut materials for the purpose of completing consumables for the GTAW, FCAW, SMAW, Students will, through written, verbal and demonstration methods, complete a finished product that meets the standards of the AWS or a similar GTAW, OFW, and OFC processes. the following at an advanced level: industry standard. • Troubleshoot any of the above processes when • Select welding processes as well as the appropriate procedures for C2.3 Use welding tools and equipment such as oxy fuel welding they are not producing quality welds or cut preparing the following welding joints: Single-V-Groove, Double- (OFW), shielded metal arc welding (SMAW), surfaces, and take corrective action to have the Bevel-Groove, and Double-U-Fillet. (GMAW), flux-cored arc welding (FCAW), and/or its settings produce acceptable • Completely set up and adjust the three machines for each of the (GTAW), , and furnace to combine or join manufactured parts results. welding processes for the above assessment. and products resulting in a finished product that meets the standards of • Select the appropriate torch tip and achieve the • Demonstrate and list procedures and techniques for welding the above the AWS or a similar industry standard. correct gas in preparation for cutting a welding joints and then weld them using three different welding C3.1 Use welding tools such as OFW, SMAW, GMAW, FCAW, given thickness of metal using oxy-fuel cutting processes to acceptable workmanship standards on 3/8” mild GTAW, forge, and furnace and the equipment and assembly processes equipment. plate. appropriate to the design criteria of a specific product to result in a • Posit and defend why any of the above welding • Demonstrate/list procedures for making straight cuts on 3” mild steel finished part or product that meets the standards of the AWS or similar processes would be the preferred method of plate using a -burner. industry welding standards. welding or cutting for a particular fabricated part • Receive a passing result of a macro etch test on the above Single-V- C6.1 Select and use appropriate welding tools, equipment, and (argumentative thinking and writing). Groove weld. inspection devices to manufacture parts or products. • Receive a passing result of a macro etch test on the above Double- C6.3 Research new and emerging welding systems and their effects on Bevel-Groove weld. the standard hand and machine manufacturing industry. • Receive a passing result of a macro etch test on the above Double-U- C8.1 Recognize the importance of base metal preparation and joint fit- Fillet weld. up and alignment. • Receive a passing evaluation of cut edges by instructor. C8.2 Analyze and be able to defend various welding processes used to • Pass final exams to test overall knowledge of the various preparations complete a fabrication, an assembly, or a repair. C8.3 Produce a completed fabrication, an assembly, or a repair by and knowledge of welding machines, hand tools, power tools and using appropriate joining and mechanical fastening techniques and fabricating machines. processes.

7

Welding and Metal Fabrication 3 Scope and Sequence Unit 3 – Fabrication Tools and Machines Advanced Projects Continued Length: Skills in Unit 3 are reinforced and refined throughout the school year Unit Description: In Unit 3, after receiving reintroduction about various tools, metalworking machines, and welding machines, students are trained in the safe operation of each machine and through written, verbal and demonstration methods, demonstrate/list procedures for each of those tools. Various tools are used in support of completing the major projects for this course. Focus Unit Standards: Learning Objectives: Key Unit Assignments and Assessments:

Manufacturing and Product Development Pathway Standards: Students will… • Students will complete a series of B1.0 Validate that a provided part meets specifications from its engineering by • Safely use a variety of metalworking and measurement tests on various projects and comparing specifications (geometric dimensioning and tolerancing) and by demonstrating proper finishing tools (machine tools, portable electric hypothetical tasks in order to verify their technique using appropriate precision measuring tools. tools, pneumatic tools, layout tools, hand tools, understanding and mastery of basic, B1.2 Demonstrate the correct use of precision measuring tools such as vernier and dial etc.) in order to complete required projects. intermediate and advanced measurement and height gages, utilizing both English and Metric systems. • Use measuring tools to verify conformance of practices and applications, which are utilized B2.4 Use a , surface gage, height gage, prick and center punches, , layout parts according to technical drawings. throughout the course. This may be either a dye, and other appropriate tools to locate hole centers, radii, and locations matching the • Use measuring tools to accurately create layout hands on and/or paper demonstration of specifications provided. lines for the purposes of cutting out material or understanding. (fraction, inch, decimal inch, B4.0 Demonstrate a cutoff operation(s) to produce a length of bar stock to specification. outlining parts edges. dial caliper, micrometer, etc.) depending on the B4.1 Using a length of bar stock and a process specification or drawing, cut a length of bar stock • Explain the major parts and functions of a twist needs of the individual students as well as matching the cut list and demonstrate no sharp edges. . which artifacts and projects they are working B5.2 Describe and demonstrate the care and use of the common which can be used to form • Set up and use various -holding and work- on and cataloging in their portfolios. radii on a variety of commercially available or those that have been casted or forged. holding devices on the drill press. • Students will perform measurements and B5.9 Complete a layout project using a detailed set of sequential instructions to manufacture the • Set up and safely operate a drill press. inspections to ensure that their projects are project to plan specifications. • Calculate the appropriate RPM for a given made to specification in order to evaluate their B7.1 Set up and safely operate a drill press. work piece. own, as well as their peers' projects. B7.3 Drill, tap, or ream holes according to specifications. • Students use the Welding Machine Setup and • Perform drill press operations such as , B7.4 Research the proper material machinability and tooling recommendations from trade Operation Observation checklists as they reaming, countersinking, counter boring, resources such as ‘Machinery’s Handbook’; choose the correct tool and holder; and calculate the complete and prepare for their projects. tapping, and deburring. spindle rpm and the feed rate for holes. • Set up and safely operate the oxygen fuel- B7.5 Perform secondary operations on each hole to specification including reaming, counter- cutting torch and the plasma arc-cutting torch. Unit 4 Project Preparation: , counter boring, tapping, and deburring. • Students are introduced to the choices for C2.0 Understand and demonstrate how materials can be processed through the use of welding • Select which welding process would be best suited for a particular project based on part projects (see Unit 4 Key Assessments) and tools and equipment. begin the preparation and outlining of these C2.2 Use standard and new emerging welding tools and equipment, such as oxygen fuel cutting function, application, installed location, and desired aesthetics. projects. They apply the skills and concepts of (OFC), plasma arc cutting (PAC), and carbon arc cutting (CAC) to cut materials for the purpose this unit to their plans. of completing a finished product that meets the standards of the AWS or a similar industry standard. C6.0 Explore and understand various welding systems that require standard hand and machine tools.

8

C6.1 Select and use appropriate welding tools, equipment, and inspection devices to manufacture parts or products. C8.0 Understand various joining or combining processes, including welding processes used in manufacturing, maintenance, and repair. C8.2 Analyze and be able to defend various welding processes used to complete a fabrication, an assembly, or a repair.

9

Welding and Metal Fabrication 3 Scope and Sequence Unit 4 – Fabrication Techniques and Advanced Shop Leadership & Management Extension Length: Skills in Unit 4 are reinforced and refined throughout the school year; initial instruction time is approximately 4 weeks. Unit Description: In Unit 4, students interpret and demonstrate the planning and layout operations used in the welding process and prepare and begin planning to create their cumulative projects. In this unit and for the remainder of the course, student apply current information technology ideation and design process systems in the manufacturing of welded parts and products. In addition, students re-define, continue applying, and seek to exemplify the leadership responsibilities, competencies, and behaviors of successful leaders in this industry that will make them employable and teachable in post-secondary opportunities. Focus Unit Standards: Learning Objectives: Key Unit Assignments and Assessments:

Manufacturing and Product Development Anchor Standards: Students will… • Students will, through written, verbal and 7.4 Practice time management and efficiency to fulfill responsibilities. • Regularly exemplify the traits of demonstration methods, demonstrate/list 7.7 Demonstrate the qualities and behaviors that constitute a positive and professional work demeanor, responsible and capable employees employee traits and skills, check for including appropriate attire for the profession. (such as punctuality, integrity, showing workmanship and accuracy against the 8.4 Explain the importance of personal integrity, confidentiality, and ethical behavior in the workplace. initiative, having a safe attitude, and products’ technical drawings and dimensions. 9.1 Define leadership and identify the responsibilities, competencies, and behaviors of successful leaders. maintaining a commitment to 9.2 Identify the characteristics of successful teams, including leadership, cooperation, collaboration, and excellence). Course 4 Final Project-Based Learning Task: effective decision-making skills as applied in groups, teams, and career technical student organization • Interpret weld symbols on drawings and (continued in Unit 5) activities. locate dimension, tolerance, process, • Students will cut out raw stock, perform 9.3 Understand the characteristics and benefits of teamwork, leadership, and citizenship in the school, and finishing information. deburring operations, layout dimension and community, and workplace setting. • Interpret and demonstrate the planning feature lines, and remove excess metal to 9.4 Explain how professional associations and organizations and associated leadership development and and layout operations used in the produce parts to specific dimensions, which competitive career development activities enhance academic preparation, promote career choices, and welding processes. are with tolerance, and perform finishing contribute to employment opportunities. • Use current information technology techniques to produce these capstone projects: 9.6 Respect individual and cultural differences and recognize the importance of diversity in the workplace. ideation and design process systems in o barbeque/smoker the manufacturing of welded parts and o Steel Bookshelf Manufacturing and Product Development Pathway Standards: products. • Students will collaborate to build a C1.0 Interpret and demonstrate the planning and layout operations used in the welding processes. • Interpret scaled welding blueprints; functioning mini-bike, taking the project from C1.1 Use current information technology ideation and design process systems in the manufacturing of gather design and materials ideation/conceptualization to engineering welded parts and products. information; perform calculations; and drawing. C1.2 Interpret scaled welding blueprints; gather design and materials information; perform calculations; and use the detail to plan, lay out, and • After students develop a plan of procedure, use the detail to plan, lay out, and produce parts or finished products. produce parts or finished products. they will deliberate about what tools, C1.3 Analyze welding symbols on drawings, specifications, and welding procedure specifications. • Create isometric and orthographic machines, and welding processes are most C1.4 Critique the design parameters across welding processes to produce a welded part or product. drawings from a representative object. fitting to build their project. After the project C2.2 Use standard and new emerging welding tools and equipment, such as oxygen fuel cutting (OFC), • Solve basic welding fabrication math is complete, they will share their design and plasma arc cutting (PAC), and carbon arc cutting (CAC) to cut materials for the purpose of completing a problems. construction process with the class to allow finished product that meets the standards of the AWS or a similar industry standard. • Round numbers, convert mixed units; for questioning, feedback, and ideas about C2.4 Compare and contrast the physical qualities of various industrial materials and how these qualities reduce fractions and decimal fractions how to improve the overall process based on affect the ability of the materials to be processed to produce useful welded parts and products. in the application of welding and metal achieving the desired outcome, keeping work fabrication (mathematics application). time and cost as low as possible. 10

C3.1 Use welding tools such as OFW, SMAW, GMAW, FCAW, GTAW, forge, and furnace and the • Students will select an appropriate finishing equipment and assembly processes appropriate to the design criteria of a specific product to result in a process to meet the design criteria of a finished part or product that meets the standards of the AWS or similar industry welding standards. specific welded product, and apply the C4.0 Understand finishing processes and the differences between various types of finishing materials used process to their fabricated parts. in the manufacture of welded parts and products. • Students will present at least two projects of C4.1 Employ and explain the steps to be taken, and the choices to be made, in finishing welded materials. their choice to the class along with an C4.2 Apply the processes used for finishing welded materials. engineering drawing, plan of procedure, C4.3 Assess how to select an appropriate finishing process to meet the design criteria of a specific welded welding process and assembly overview, product. finishing techniques, and a critical critique by C6.2 Compare and contrast the various welding systems used in conventional manufacturing industries in both the fabricator and the audience. order to select and use appropriate tools, equipment, and inspection devices. • At least one project entered into the San Diego C8.0 Understand various joining or combining processes, including welding processes used in County Fair along with a measured blueprint manufacturing, maintenance, and repair. and bio to go on display with their C8.1 Recognize the importance of base metal preparation and joint fit-up and alignment. project.

11

Welding and Metal Fabrication 3 Scope and Sequence Unit 5 – Weld Inspection, Testing, and Certification Length: 8 Weeks Unit Description: In Unit 5, students continue working on their final projects in preparation to complete all course and pathway requirements. This unit also focuses on reviewing and applying advanced semi- precision measurements in order to measure weld dimensions in accordance with typical American Welding Society inspection techniques. Students will complete a weld sample as part of their cumulative project that is designed to demonstrate their advanced level of understanding regarding quality assurance and how it is used to produce parts that are within workmanship acceptability. After completing a welding sample, the welded piece will be inspected by the student and the instructor and then tested with both non-destructive and destructive testing methods. Upon passing the test, students will be issued welding certifications from the American Welding Society (AWS) for (D1.1). The course culminates with students presenting their portfolio of work and includes the task of presenting finished products both digitally and in person to audiences of both peers and industry representatives. Focus Unit Standards: Learning Objectives: Key Unit Assignments and Assessments:

Manufacturing and Product Development Pathway Students will… • Working in groups of four, students will inspect a section of a welded structural steel Standards: • Identify common weld discontinuities, member. Students will determine whether or not the section has sound welds. After using C4.0 Understand finishing processes and the differences what causes them, and then take the appropriate welding quality criteria and common welding inspection tools, students will between various types of finishing materials used in the corrective action to prevent them. present their findings to a committee (several of their classmates). manufacture of welded parts and products. • Explain the difference between • The presentation will culminate with a professional training plan outlining how to train the C4.1 Employ and explain the steps to be taken, and the destructive and non-destructive testing welder in proper welding techniques to be successful in welding similar pieces in the future. choices to be made, in finishing welded materials. methods, and when each would best be C4.2 Apply the processes used for finishing welded used. Using proper preparation, fabrication, and welding techniques, students will complete the following materials. • Explain and demonstrate how base metal welding certification performance weldments and successfully pass a destructive bend test and/or C4.3 Assess how to select an appropriate finishing process is prepared before welding and know the macro-etch inspection of a cross-section of their welded piece in accordance to AWS D1.1 structural to meet the design criteria of a specific welded product. principles of good joint fit-up. steel: C5.1 Identify and explain weld imperfections and their • Use common welding inspection ✓ 3G SMAW Unlimited Thickness causes. measuring devices such as gauges, ✓ 4G SMAW Unlimited Thickness C5.2 Identify and explain destructive and nondestructive calipers, and rules to verify a weldment’s ✓ 3G FCAW Unlimited Thickness examination practices. conformance to acceptability criteria as ✓ 4G FCAW Unlimited Thickness C5.3 Describe the reasons for inspection and quality set forth in the AWS’ structural steel control in the manufacturing of welded parts. codebook (D1.1). Final Project Presentations and Course Completion Events: C5.4 Analyze and identify the steps to check for distortion, • Examine welding samples with common (per instructions in Key Assessments in Unit 4) joint misalignment, and poor fit-up before and after weld discontinuities to determine if the • Students will present at least two completed projects of their choice to the class along with welding. welds are defective or if the an engineering drawing, plan of procedure, welding process and assembly overview, C5.5 Perform continuous online quality control discontinuities fall within the ranges of finishing techniques, and a critical critique by both the fabricator and the audience. inspections of welded parts. acceptability set forth in the D1.1 • At least one project entered into the San Diego County Fair along with a measured blueprint C8.1 Recognize the importance of base metal preparation codebook. and welder bio to go on display with their project. and joint fit-up and alignment. • Achieve AWS D1.1 certification in C8.3 Produce a completed fabrication, an assembly, or a • Students present their portfolio of work along with their key work samples. They receive a FCAW and SMAW in 3/8” steel in the certificate of completion as well as evidence of any completed certification repair by using appropriate joining and mechanical flat position. fastening techniques and processes. coursework/tasks.
