Intel® Quark™ Microcontroller Software Interface (Intel® QMSI)
Malcolm Prinn,
October 2016 Intel® QMSI quick facts
. Hardware Abstraction Layer written in C
. ~100k LoC
. Supports most Intel® Quark™ MCU SoCs
. Small code size / stack usage
. Low power functionality
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 2 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ Microcontrollers (MCUs) D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 3 *Other names and brands may be claimed as the property of others. Intel® Quark™ MCU family
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 4 *Other names and brands may be claimed as the property of others. Intel® Quark™ microcontroller D2000 Intel® Quark™ SoC Peripheral Power Lakemont- ULP @32MHz Interfaces Subsystem . Ultra low power, Entry Level UART PWM / Timer 8k SRAM Pwr. Supply & Distr. . 32MHz, 32-bit x86 Microcontroller, 32kB Flash, 8kB SRAM I2C SPI (M/S) 8k OTP Battery Mgmt. GPIO . Scalable Software Development Kit, with ADC sample apps and libraries 32k Intg. Power Mgmt. Flash Comparator RTC
. Pre-validated comms and sensor modules Memory Memory Subsystem 2 ch DMA WDT JTAG & Debug Support
. Full Intel® x86 instruction set architecture for compatibility and scalability
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 5 *Other names and brands may be claimed as the property of others. InteL® Quark™ SE microcontroller C1000 Intel® Quark™ SoC Peripheral Interfaces Power Lakemont- ULP UART Pattern Matching Engine Subsystem . High-efficiency power consumption @32MHz ARC PWM / I2C (M/S) GPIO Pwr. Supply & Distr. . 32MHz, 32-bit x86 Microcontroller @32MHz Timer . 384Kb Flash, 80kB SRAM SPI (M/S) I2S Mailbox 80k SRAM Battery Mgmt. . Scalable Software Development Kit, with sample apps and libraries WDT RTC AON GPIO 8k OTP Power Mgmt. . Pre-validated comms and sensor modules USB 1.1 Comparator 2x 192kB Intg. Flash Sensor SubSystem . Full Intel® x86 instruction set architecture Peripherals for compatibility and scalability
Memory Memory Subsystem 8 ch DMA ADC GPIO I2C SPI JTAG & Debug Support
. Always sensing: always-listening Internal Sensor Hub
. Intelligent: Pattern Matching Engine
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 6 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 7 *Other names and brands may be claimed as the property of others. Intel® Quark™ Microcontroller Software Interface
. Intel® Quark™ Microcontrollers Hardware Abstraction Layer (HAL)
. APIs provide a standard interface to all functionality in Intel® Quark™ microcontrollers.
. APIs are consistent across the Intel® Quark™ microcontroller family of devices.
. Included with this API are a collection of sample applications to enable users to get started quickly.
. Embedded devices with a limited amount of memory, . Object code size & stack size minimization is a primary design objective. . Everything accessed as MMIO. . Nothing is dynamic, all the heavy work is done at compile time. . Garbage collection on unused functionality.
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 8 *Other names and brands may be claimed as the property of others. Intel® QMSI
Firmware Mailbox DMA ADC RTC Upgrade
InterruptInterrupt Boot loader AON Counter Pin muxing WDT managementmanagement
AONAON Periodic ARC support Power states I2C GPIO Timer
X86 support Flash Comparators SPI Timers
Memory SoC support IdentificationIdentification UART PWM protection
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 9 *Other names and brands may be claimed as the property of others. Bootloader / ROM
. Bootstrap
. TRIM code calculation
. Firmware update management . Host tools also provided (fork of DFU utils)
. Un-brick me
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 10 *Other names and brands may be claimed as the property of others. Boot flow Reset
Assembly Start-up
Primary peripherals
Un-brick me
Secondary Flash Start ARC peripherals controllers
Start Sanitize Lakemont bootloader
Power Firmware down mgmt.
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 11 *Other names and brands may be claimed as the property of others. Clocking Crystal Oscillator 32 MHz Crystal determines I2C Enable accuracy ~4mA
Silicon Oscillator Selector Prescaler I2C 4/8/16/32 MHz System clock +/- 20000ppm accuracy source 450uA@32MHz Prescaler SPI
RTC oscillator Prescaler RTC 32768 Hz AON Periodic Prescaler Timer RTC clock source Prescaler WDT
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 12 *Other names and brands may be claimed as the property of others. Power states - D2000
RST_N
Active Wake Event Wake
Halt Deep Sleep
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 13 *Other names and brands may be claimed as the property of others. Power states - C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 14 *Other names and brands may be claimed as the property of others. Sample Real Time Clock driver usage
RTC configuration structure
Register / request interrupt
Enable clocking to RTC
Set configuration and start RTC
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 15 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 16 *Other names and brands may be claimed as the property of others. Newlib syscalls
. Pico printf . Modular, support for formats can be disabled at compile time . Supports ‘d’, ‘u’, ‘x’, ‘X’ and ‘s’
. Puts
. Malloc / free
. Assert
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 17 *Other names and brands may be claimed as the property of others. Toolchain
GDB
OpenOCD based GCC ARC GCC JTAG
Bare metal / RTOS code
Intel® Quark™ microcontroller-based systems
https://software.intel.com/en-us/articles/issm-toolchain-only-download
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 18 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 19 *Other names and brands may be claimed as the property of others. TinyCrypt Library
. The TinyCrypt Library provides an implementation for constrained devices of a minimal set of standard cryptography primitives.
TinyCrypt HMAC- SHA-256 AES-128 ECC-DH SHA256
HMAC- AES-CBC AES-CTR ECC-DSA PRNG mode mode
AES- CMAC AES-CCM CTR- mode mode PRNG
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 20 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 21 *Other names and brands may be claimed as the property of others. Intel® Performance Primitives for Microcontrollers
. Supported data types Functional Groups . Fixed point: q15, q31 . Floating point: 32f (using Basic floating point simulation) Fast Math Complex Math Math . Optimization criteria . Size (~1 KB per function) . Performance Statistical Filtering Transform . Accuracy Functions Functions Functions . Power consumption
Interpolatio Matrix Controllers n Functions Functions Functions
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 22 *Other names and brands may be claimed as the property of others. Floating Point Library
. Only applicable to Intel® Quark™ Lakemont processor cores
. Floating Point . The Floating Point Library emulates basic floating point operations with hardware integer instructions. . Compatible with the Intel® MCU Architecture ; supports Intel® Pentium® processor instruction set minus instructions for x87 floating point unit. . Fixed point data format . Intel® IPP for Microcontrollers functions operate on fixed-point data in Qn format. . Example : X in the Q15 format is X*2-15, with the range of supported values for the Ipp16s data type equal to [-1, 1-2-15].
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 23 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 24 *Other names and brands may be claimed as the property of others. Zephyr Applications
CoAP, MQTT, HTTP, LWM2M
DTLS, TLS, ..
UDP, TCP Bluetooth Low Energy
IPv4, IPv6 6LowPAN
Power Management Device Management
Device Drivers
QMSI
Microkernel
Nanokernel
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 25 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (Comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 26 *Other names and brands may be claimed as the property of others. Intel® System Studio for Microcontrollers
. Bundles components into a Software Development Kit (SDK) . Integrated Development Environment (IDE) . Based on Eclipse . Intel® System Studio for Microcontrollers plugins . SoC debugger integration . Windows USB Driver for: . Intel® Quark™ Microcontroller D2000 Development Board . Intel® Quark™ SE C1000 Development Board
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 27 *Other names and brands may be claimed as the property of others. Intel® system studio for Microcontrollers in action
Disassembly Code
Registers
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 28 *Other names and brands may be claimed as the property of others. Customer Apps
Intel® system studio for Microcontrollers
Zephyr OS (comms. Stacks)
Libs TinyCrypt IPPM
Intel® QMSI
Intel® Quark™ MCUs D2000 C1000
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 29 *Other names and brands may be claimed as the property of others. Build upon already existing example applications
Accelerometer CryptographyMailbox DMA PWMADC VersionRTC
Always-on Interrupt DMA AON I2CCounter Pin RTCmuxing GroveWDT Shields Counters management
AON Periodic Blinky PowerFlash Access states Identifaction I2CSPI D2000GPIO Power Timer
Clib FlashGPIO Mailbox TimersSPI C1000Timers Power
Clock Memory Hello World IdentificationPIC Timer UART GyroscopePWM Divisors protection
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 30 *Other names and brands may be claimed as the property of others. Where to get Intel® QMSI™
Intel® Developer Zone: https://software.intel.com/en-us/intel-system-studio-microcontrollers
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 31 *Other names and brands may be claimed as the property of others. Github.com/quark-mcu
Optimization Notice Copyright © 2016, Intel Corporation. All rights reserved. 32 *Other names and brands may be claimed as the property of others. Intel® Community
Intel® Quark™ Microcontroller Forum: https://communities.intel.com/community/tech/microcontrollers
