Creation and maintaining a Web based Protection Database and Desktop based Protection setting calculation tool for Eastern Regional Grid

Eastern Regional Power Committee 14 Golf Club Road, Tollygunge, Kolkata, West Bengal 700033

OPERATIONAL LOAD FLOW STUDIES UNDER SUMMER PEAK LOADING CONDITIONS

September 2017

Power Research and Development Consultants Private Limited # 5, 11th cross, 2nd stage, west of chord road, Bangalore - 560 086, Karnataka Tel: +91- 80-23192159 / 23192168 E-mail – [email protected] Web site: www.prdcinfotech.com

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Document reference details:

LOA No : ERPC/PR_DBASE/2016/3567 Document reference No : PRDC/2017-2018/ERPC-WB/937

Revision Index

Revision Description Date Remarks

Summer-Peak 1.0 19.09.2017 Initial version Load Flow Report

Based on the comments given by 1.1 Modification 20.09.2017 Mrs. Debarati Basu

2.0 Approved 20.09.2017 Approved

Internal Approval

Ms. Suman Kumari

Prepared by 19.09.2017 Mr. Anirban Banerjee

Reviewed by Mrs. Debarati Basu 20.09.2017

Approved by Dr. Nagaraja Ramappa 20.09.2017

2 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

TABLE OF CONTENTS

1 INTRODUCTION ...... 12

2 PROJECT SCOPE ...... 13

2.1 Database Building Activities for Operational Studies ...... 14

3 SYSTEM OPERATIONAL DATA ...... 15

3.1 Methodology adopted for performing the load flow analysis ...... 17 3.1.1 Data Collection Procedure ...... 17 3.2 May 04, 2017 Peak system demand condition ...... 19 3.3 Salient points of CEA planning criteria referred for network modelling and analysis of study results ...... 19 3.3.1 Transmission line parameters ...... 19 3.4 Transformer parameters ...... 21 3.4.1 Voltage limits ...... 21 3.5 Network element statistics for ER Grid ...... 21 3.5.1 Substation details ...... 21 3.5.2 Transmission line details ...... 22 3.5.3 Transformer details ...... 22 3.5.4 Generation details...... 23 3.5.5 HVDC details ...... 23 3.5.6 Reactor details ...... 24 3.5.7 Load details ...... 24 3.6 Generation schedule details for operational load flow ...... 24

4 OPERATIONAL LOAD FLOW STUDY ...... 27

4.1 Introduction to Load flow analysis ...... 27 4.2 Load Generation Balance from the results of operational load flow analysis ...... 29 4.3 Line loading conditions ...... 33 4.4 Transformer loading conditions...... 35 4.5 Voltage profile ...... 38 4.6 Analysis of the load flow study results ...... 43

5 SHORT CIRCUIT STUDIES ...... 44

5.1 Short circuit study result analysis...... 45

6 CONCLUSION ...... 47

3 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

LIST OF FIGURES

Figure 3.1: Constituents of Eastern Regional grid ...... 16 Figure 3.2: Scheduled generation, Import and Export of Eastern Regional grid ...... 26 Figure 4.1: Block diagram of load generation balance of ER ...... 32

4 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

LIST OF TABLES

Table 3.1: Data availability status ...... 17 Table 3.2: ER loading details ...... 19 Table 3.3: Source of the data considered for the study ...... 19 Table 3.4: Details of transmission line parameters ...... 20 Table 3.5: Details of transformer parameters ...... 21 Table 3.6: Voltage limits at different voltage levels prescribed in CEA’s “Transmission ...... 21 Planning Criteria” ...... 21 Table 3.7: Existing number of sub-station in the ER ...... 21 Table 3.8: Summary of transmission line data in the ER ...... 22 Table 3.9: Summary of transformers capacity in the ER ...... 22 Table 3.10: Summary of Generator installed capacity in the ER ...... 23 Table 3.11: HVDC Back to Back in the ER ...... 23 Table 3.12: HVDC Link in the ER ...... 23 Table 3.13: Load Details of ER ...... 24 Table 3.14: Generation schedule Details of ER ...... 24 Table 4.1: Load generation balance Details of ER...... 29 Table 4.2: Load generation balance details of Bihar ...... 29 Table 4.3: Load generation balance details of Jharkhand ...... 29 Table 4.4: Load generation balance details of Odisha ...... 30 Table 4.5: Load generation balance details of Sikkim ...... 30 Table 4.6: Load generation balance details of West Bengal ...... 30 Table 4.7: Load generation balance details of DVC ...... 31 Table 4.8: Load generation balance details of CESC ...... 31 Table 4.9: Load generation balance details of DPL ...... 31 Table 4.10: Percentage loading details of lines of Eastern Region ...... 33 Table 4.11: Percentage loading details of lines of Bihar ...... 33 Table 4.12: Percentage loading details of lines of Jharkhand ...... 33 Table 4.13: Percentage loading details of lines of Odisha ...... 34 Table 4.14: Percentage loading details of lines of Sikkim ...... 34 Table 4.15: Percentage loading details of lines of West Bengal ...... 34 Table 4.16: Percentage loading details of lines of DVC ...... 34 Table 4.17: Percentage loading details of lines of CESC ...... 35 Table 4.18: Percentage loading details of lines of DPL ...... 35 Table 4.19: Percentage loading details of Transformers of Eastern Region ...... 35 Table 4.20: Percentage loading details of Transformers of Bihar ...... 36 Table 4.21: Percentage loading details of Transformers of Jharkhand ...... 36 Table 4.22: Percentage loading details of Transformers of Odisha ...... 36 Table 4.23: Percentage loading details of Transformers of Sikkim...... 36

5 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 4.24: Percentage loading details of Transformers of West Bengal ...... 37 Table 4.25: Percentage loading details of Transformers of DVC ...... 37 Table 4.26: Percentage loading details of Transformers of CESC ...... 37 Table 4.27: Percentage loading details of Transformers of DPL ...... 37 Table 4.28: Bus Voltage Profile for Eastern Region ...... 38 Table 4.29: 765 kV and 400 kV Bus Voltage of Eastern Region grid ...... 39 Table 5.1: 3-Ph fault levels > 80% of breaker rating ...... 45 Table 5.2: SLG fault levels > 80% of breaker rating ...... 45

6 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

EXECUTIVE SUMMARY

ERPC secretariat has taken up a project of “Creation and maintaining a Web based Protection Database and a Desktop based Protection Setting Calculation Tool for Eastern Regional Grid”.

M/s PRDC has been awarded with the order by ERPC to implement the project in its entirety including creation of database and supply of software and hardware along with necessary power system analysis relevant for the project.

Eastern Regional Grid comprises of the electrical system of the states of Bihar, Jharkhand, West Bengal, Odisha, Sikkim under different transmission utilities. The major constituents of ER grid are the Transmission and Distribution Utilities of States and UT, Central Transmission Utility, State and Central sector Generating Companies, DVC, CESC, DPL, IPP’s and Private sector Transmission and Distribution Utilities. The ER covers a geographical area of 425432 sq km with an installed capacity of 37871 MW. In addition to this the region has an installed capacity of 7840 MW in the form of CPP’s. Eastern Regional Power Committee (ERPC) formed by Ministry of Power is entrusted for facilitating the integrated operation of the power system in the region. As a prerequisite of building the protection management system the first step as envisaged is the electrical modeling of the entire network data under ER system from 765 kV to 132 kV and 66 kV for Sikkim and carrying out the base case operational load flow analysis and short circuit studies for peak and off peak load conditions. The Load flow and Short Circuit studies of Eastern Grid was carried out for summer peak 2016, summer off peak 2016, winter off peak 2016 and summer peak 2017 loading conditions of ER. The network was updated till 31st May 2016, 31st August 2016, 31st December 2016 and 30th April 2017 for summer peak 2016, summer off peak 2016, winter off peak 2016 and summer peak 2017 loading condition respectively and report was submitted with study results on 27th July 2016 for summer peak loading, 6th January 2017 for summer off peak loading and 3rd April 2017 for winter off peak loading and 21st September 2017 for summer peak case. As a next phase of the power system studies, the summer peak scenario of ER grid is studied for Load flow and Short Circuit analysis. The data and electrical parameters of the EHV network elements as updated till 30th April 2017 by collecting data from the respective constituents of ER grid and updated network is modeled in power system analysis software MiP-PSCT.

7 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

It was decided in the 132th OCC meeting that the operational Load Flow study for ER grid is carried out for a load generation condition during summer peak condition on an updated network data till April 2017. The load generation condition was selected for two time steps are collected for 4th & 5th May 2017 at 19:00 hours and 20:00 hours respectively. In 133rd OCC meeting, it was decided that the summer peak load flow study will be carried out with load generation scenario of 4th May 2017 at 20:00 hrs as per the load generation scenario data given by ERLDC. A comparison of loading details of 26th May 2016 peak hours, 27th August 2016 off peak hours, 29th December 2106 off peak hours and 4th May 2017 peak hours of ER grid is presented below.

Load (MW) Sl. No. Constituents 4th May-17, 29th Dec-16, 27th Aug-16, 26th May-16, 20:00 hrs 02:00 hrs 13:00 hrs 20:00 hrs 1 Bihar 3362 2321 2716 3044 2 Jharkhand 1014 914 799 991 3 Odisha 3666 2236 2872 3354 4 Sikkim 57 36 43 75 5 W. Bengal 5854 3176 4858 5460 6 DVC 2494.5 2330 2426 2621 7 CESC 1675.8 558 1507 1441 8 DPL 231 181 217 217 Total Load 18354 11753 15438 17203 loss 749 389 671 762 Total Demand 19103 12142 16109 17965

Load flow analysis and short circuit studies are conducted under summer peak loading scenario and the observations on the results are detailed in subsequent sections of the report. Constituent’s wise demand for ER grid id presented below.

Sl. No. Constituents Demand MW) 1 Bihar 3362 2 Jharkhand 1014 3 Odisha 3666 4 Sikkim 57 5 W. Bengal 5854 6 DVC 2495 7 CESC 1676 8 DPL 231

8 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Summarized particulars of network data for ER as on 30st April 2017 collected during the studies are given below: EHV Transmission Grid Substations: The total count is 501 with a voltage grade wise population mix as, o 765 kV: Number of substations is 5 with installed capacity of 18000 MVA o 400 kV: Number of substation is 47 with an installed capacity of 36390 MVA o 220 kV: Number of substation is 105 with an installed capacity of 39140 MVA o 132 kV: Number of substation is 348 with an installed capacity of 38254 MVA o 66 kV: Number of substation is 19 with an installed capacity of 213 MVA ER generating units under state, central sector and integrated utilities: Aggregated generation capacity of 28403 MW with a hydro thermal mix of 5.5 : 22.8.The break up is given as, o Total number of hydro generating units is 91 with an installed capacity of 5598 MW o Total number of thermal generating units is 105 with an installed capacity of 22805 MW ER generating units under IPPs: Aggregated generation capacity of 9468 MW with a hydro thermal mix of 2.06: 92.62.The break up is given as,

o Total no. of hydro generating units is 4 with an installed capacity of 206 MW o Total number of thermal generating units 31 with an installed capacity of 9262 MW CPP generation capacity: 7840 MW. ER EHV and HV Transmission Lines (132 kV and above and 66 kV in Sikkim): 85144 ckm The node wise load and generation data, recorded are collected from the respective system owners and are matched with the demand, generation and exchange recorded by ERLDC, SCADA for the selected time instant.

The consolidated observations from load flow analysis are: Load Generation Balance Peak Scenario:

o System input ( Generation & Import ): 25390 MW o System Demand including losses in ER network : 19103 MW o Consolidated Export from ER bus : 6287 MW

9 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Generation Scheduling: Generators are scheduled as per SCADA records of ERLDC. Voltage Profile: Bus bar voltages at all voltage levels are within the stipulated range of grid code of CEA Transformer loading: In the entire population overloading of 1 transformer is observed. 76 number of transformers are loaded beyond 80% and 265 numbers are loaded below 20%. Line loading: Number of lines loaded beyond 100% of thermal capacity is 8 in 220 kV and 132 kV voltage level. Number of lines loaded between 80 to 100% of thermal capacity is 49 predominantly in 220 kV and 132 kV level. Number of lines loaded below 5% thermal capacity is 126 and the percentage is predominant at 132 kV level. Short Circuit studies are conducted on the network topology and generation scheduling of the load flow modeling for both three phase symmetrical faults and single line to ground fault conditions at every bus up to 66 kV level by considering sub transient reactance’s of the generators and closed bus operation at all 765, 400 and 220 kV bus. It is observed that short circuit levels are critical at some of the substations but within the breaker rated capacity.

Detailed analysis of data and study results under summer peak condition for load flow and short circuit studies are elaborated in subsequent sections of the report.

10 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

ABBREVIATIONS AND ACRONYMS

Acronym Full form CEA Central Electricity Authority CGP/CPP Captive generating plant CTU Central Transmission Utility DB Data Base DPR Detailed Project Report DTR Distribution Transformer EHV Extra High Voltage ER Eastern Region ERLDC Eastern Regional Load Dispatch Centre ERPC Eastern Regional Power Committee GoI Government of India GS Generating Station GUI Graphical User interface HV High Voltage IPP Independent Power Producer MiP-PSCT Protection Setting Calculation Tool NR Northern region PRDC Power Research & Development Consultants Pvt. Ltd. PSS Power System Study SCADA Supervisory control and data acquisition SLD Single Line Diagram SLDC State Load Dispatch Centre SS Substation STU State Transmission Utility

11 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

1 INTRODUCTION

Eastern Regional Grid comprises of the electrical transmission system of the states of Bihar, Jharkhand, West Bengal, Odisha, Sikkim and supply area under DVC. The major constituents of ER grid are the State/UT Transmission and Distribution Utilities, Central Transmission Utility, State and Central sector Generating Companies, DVC, CESC, DPL, IPP’s and Private sector Transmission and Distribution Utilities. The ER covers a geographical area of 425,432 sq. km which is about 13% of the total area of the country with an installed capacity of 37871 MW. Keeping in view the criticality of safe and reliable operation of this vast and complex system of ER, M/s. ERPC has awarded the project for implementation of a software based protection management system that includes building up a comprehensive web based protection database for the ER grid to M/s PRDC, a pioneer consultant in the field of power engineering on 31st March 2016. As a fundamental prerequisite of building the protection management system and as base work for protection system simulation and studies the entire existing network data under ER system is modeled from 765 kV level to 33 kV buses of 132/33 kV substations for all states other than Sikkim where the network is modeled up to 11 kV buses of 66/11 kV substations. The network model in its entirety encompasses each of the individual power system elements including generators (hydro, thermal, pump storage), substations/switching station equipment, transmission lines, HVDC system, reactors, capacitors and load. This report presents the results of the base case load flow studies for the modeled EHV transmission network of the ER grid for a selected scenario of summer peak load condition. With reference to the discussions with M/s ERPC and its constituents, 4th May 2017 is identified as a typical day with evening peak load at 20:00 hours. The load flow analysis is carried out with the load generation scenario for the selected instant and the parameters are crosschecked with the SCADA results to authenticate the correctness of the modeling. Between the two selected time step, ER network is modeled for 4th May 2017 20:00 hours, wherein a demand recorded 19103 MW for the ER grid. This volume of the report presents the details of existing Eastern region transmission network data, load generation balance along with operational load flow and short circuit study results under summer peak scenario.

12 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

2 PROJECT SCOPE

The scope of work envisaged in tender document is elaborated in detailed here. As per scope M/s PRDC should supply Protection Analysis Software Package with following requirements but not limited to the following modules for the supply of Software and Database building activities, M/s PRDC should develop and maintain a hardware setup and software package capable of meeting the following objectives; but not limited to:  Classified database of all bay equipment and the protection system details of all bays 132 kV and above, for Eastern Regional power system.  A user friendly interface for browsing and editing the contents of the database.

 Tool for simulating the performance/ behavior of the protection system under all possible normal and abnormal operating conditions of the power system, including effect of changing one or more parameter setting of the relays.  Diagnostics for verifying proper coordination among various protective relays.  Generation of useful reports. The detailed scope of work is elaborated in Volume-1 of the DPR and submitted on 27.04.2016. A consolidated view on Network Modeling and database building activity for operational load flow involve “Creation and maintaining a Web based Protection Database and Desktop based Protection setting calculation tool for Eastern Regional Grid” is presented below.

13 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

2.1 Database Building Activities for Operational Studies

 One time power system network model building for the Load flow, Short circuit and dynamic simulations of entire Eastern region with Indian national grid transmission network model.  Data collected from respective substations to be validated before populating the same in the database.  Complete modeling of ER transmission network for 132 kV and above including HVDC systems connected with ER, with relevant system parameters of transmission lines, generators, transformers, reactors for all existing substations. However, for Sikkim 66 kV system along with 66 kV interconnections are to be considered.

 Prepared network is made ready for base case load flow analysis and the same has to be verified with field engineers of ER constituents. Both MW and MVAr flow are computed and Voltage Level at different Buses is ascertained along with suggestive conditions to reduce or enhance Bus voltage.  Short circuit, studies to be simulated and the results to be demonstrated to the ER constituents for approval. This report includes operational load flow and short circuit study of existing ER grid under summer peak loading condition.

14 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3 SYSTEM OPERATIONAL DATA

As increasing electricity demand, electrical transmission and distribution system is expanding at very fast pace. To meet future expected demand with reliable manner there is a need of great integration among electricity generating, transmission and distribution agencies. With an objective to facilitate integrated operation of power system in Eastern Region, Govt. of India had established Eastern Regional Power Committee comprising the states of Bihar, Jharkhand, Orissa, West Bengal and Sikkim along with area under DVC. The major constituents of ER grid are the State/UT Transmission and Distribution Utilities, Central Transmission Utility, State and Central sector Generating Companies, DVC, CESC, DPL, IPP’s and Private sector Transmission and Distribution Utilities. Figure 3.1 depicts constituents of Eastern Regional grid.

15 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Figure 3.1: Constituents of Eastern Regional grid

16 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3.1 Methodology adopted for performing the load flow analysis

3.1.1 Data Collection Procedure  In 132th OCC meeting, it was decided that operational load flow study under summer peak loading scenario will be carried out for load conditions of 04.05.2017 and 05.05.2017 at 19.00 hrs and 20.00 hrs respectively.  To collect the Eastern grid network data for operational load flow under peak scenario a standard data collection format was prepared and forwarded to ERPC.  Load generation data collection format was finalized by M/s PRDC and uploaded in ERPC portal.  M/s PRDC has received the network data from most of the constituents in agreed format and remaining is collected from field survey in coordination with ERLDC and SLDC’s. Network data for all the utilities under Eastern region were collected in co-ordination with ERPC and its constituents. The complete Eastern Region Network from 765 kV level to 33 kV buses of 132/33 kV S/S (with the exception where generator is connected to a lower voltage network) is considered in the studies. However, for Sikkim 66 kV system along with 66 kV interconnections are considered. Inter-regional 765 kV, 400 kV, 220 kV and 132 kV transmission lines with Northern, Western, Southern and North-Eastern region is also considered in the studies. Network update of ER constituent has been done based on monthly report of CEA and OCC meeting and verified with the data received from concerned utilities. Table 3.1 present the collected/received data status from ERPC and its constituents.

Table 3.1: Data availability status

State wise Data received* Constituent of ERPC Network augmentation Data Load data (%) (%) Bihar 91 0 Jharkhand 74 0 Odisha 62 0 Sikkim 8 0 West Bengal 91 0 Note: Network data includes CTU and STU network details as per state wise location while DVC network details are allocated in Jharkhand and West Bengal as per physical location.

17 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

*Utility owners have furnished network data for all elements but the line and transformer parameter data is furnished for 70% elements.

* SCADA record of 765 & 400 and 220kV line flow and Generation schedule from ERLDC is collected. The methodology adopted by the study team for performing the load flow analysis is as given below.

 Configuring the entire Eastern Regional Grid electrical network down to 33 kV (up to 11 kV bus of 66/11 kV S/S in Sikkim) banks of the transmission substations. i.e. transmission system comprising of 765 kV, 400 kV, 220 kV and 132 kV (66 kV S/S in Sikkim) substation buses up to the 33 kV buses at the substations.  Represented the collective load of the substations at 33 kV buses for Bihar, Jharkhand, Odisha and West Bengal and at 11 kV buses in Sikkim.  Import form generation located outside the region is considered as a bulk import.  Railway loads are modeled by considering radially link with grid.

 Slack bus is considered outside the region at the point having a maximum power exchange from eastern grid.  Generation scheduling is matched with ERLDC’s SCADA record.  Allocation of load to the substations is finally done to match the state wise system demand as per ERLDC’s SCADA record.  Simulation of load flow analysis under peak scenario is done on the integrated Grid transmission network of Eastern Region.  Geographical drawings for entire Eastern Regional Grid transmission network along with separate maps of eastern grid constituent states.

 Eastern regional transmission network is simulated under summer peak scenario by taking load demand of 04.05.2017 at 20.00 hrs. Currently, the modeled Eastern grid network has been simulated for the loading conditions which are given in Table 3.2.

18 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 3.2: ER loading details

Date & Time 4h May 2017, 20:00 hrs. System Demand Met 19103 MW Total Load 18354 MW System Loss 749 MW Percentage Loss 2.95%

 Software used : MiP-PSCT

3.2 May 04, 2017 Peak system demand condition

The study team has received substation wise load data and SCADA records from the ERLDC and SLDC’s of eastern region. The data considered for modeling the transmission network and its sources are given in Table 3.3.

Table 3.3: Source of the data considered for the study Sl Data Source No 1 Transformers Field data and CEA planning criteria Field data and network data received from 2 Transmission lines / UG cable types CTU, STU and other constituents Data received from CTU, STU and other 3 Lines / UG cable parameters constituents and CEA planning criteria SCADA recordings and Load data received 4 Loads and Generation from SLDC’s Note: Transmission lines and Transformers parameters, which are not furnished by CTU’s and STU’s, is considered as per CEA transmissions planning criteria. This section of the report presents the basic data considered for the system studies.

3.3 Salient points of CEA planning criteria referred for network modelling and analysis of study results

3.3.1 Transmission line parameters Table 3.4 provides the transmission line parameters and the thermal loading limit of the transmission lines at various voltage levels considered for the studies.

19 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 3.4: Details of transmission line parameters Positive Zero Positive Positive Zero Zero Sequence Sequence Thermal Voltage Sequence Sequence Sequence Sequence Conductor Type Susceptance Susceptance Rating (kV) Resistance Reactance Resistance Reactance , B/2 , B/2 (MVA) (ohm/km/ckt) (ohm/km/ckt) (ohm/km/ckt) (ohm/km/ckt) (mho/km/ckt) (mho/km/ckt) ACSR Quad Bersimis 765 0.0114 0.2856 2.01E-06 0.2634 1.0534 1.20E-06 3880 ACSR Hexa Zebra 765 0.0123 0.2552 2.27E-06 0.2247 0.9223 1.38E-06 4452 ACSR Quad Moose 400 0.0147 0.2528 2.29E-06 0.2480 1.0000 1.32E-06 1749 ACSR Twin Moose 400 0.0298 0.3320 1.73E-06 0.1619 1.2400 1.12E-06 874 AAAC Twin Moose 400 0.0309 0.3304 1.77E-06 0.1682 1.2368 1.14E-06 840 ACSR Zebra 220 0.0697 0.3978 1.46E-06 0.2048 1.3344 9.14E-07 213 ACSR MOOSE 220 0.0749 0.3993 1.47E-06 0.2200 1.3392 9.20E-07 240 AAAC Zebra 220 0.0749 0.3993 1.47E-06 0.2200 1.3392 9.20E-07 212 800sqmm XLPE Cable 220 0.0321 0.1260 3.23E-05 0.1400 0.0680 3.00E-05 266 ACSR Panther 132 0.1622 0.3861 1.46E-06 0.4056 1.6222 8.99E-07 83 LARK 132 0.1622 0.3861 1.46E-06 0.4056 1.6222 8.99E-07 94 T Snowbird 132 0.0223 0.2900 1.96E-06 0.2840 0.9784 1.36E-06 432 161 sqmm G.F Cable 132 0.1400 0.1873 4.25E-05 0.2700 0.0519 4.25E-05 50 260 sqmm G.F Cable 132 0.0876 0.2167 4.55E-05 0.1695 0.0600 4.55E-05 70 400 sqmm XLPE Cable 220 0.0617 0.1360 2.20E-05 0.2040 0.0830 2.19E-05 100 630 sqmm XLPE Cable 132 0.0391 0.1267 2.27E-05 0.1120 0.0840 2.24E-05 130 800 Sqmm XLPE Cable 132 0.0321 0.1260 3.23E-05 0.1300 0.0680 3.00E-05 160 ACSR DOG 66 0.3274 0.4267 1.36E-06 0.5578 1.3688 9.84E-07 50 Note: Transmission lines parameters, which are not furnished by CTU and STU’s, is consider as per CEA transmissions planning criteria.

20 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3.4 Transformer parameters

Actual transformer parameters wherever provided by CTU and STU’s is used. In cases where data is not furnished standard data as per CEA transmissions planning criteria given in Table 3.5 is considered.

Table 3.5: Details of transformer parameters Transformer reactance Xt Type of Transformer (at its own base MVA) Generator transformer (GT) 14 – 15 % Inter-Connecting Transformer (ICT) 12.50%

3.4.1 Voltage limits The steady-state voltage limits prescribed in CEA’s “Transmission Planning Criteria” at different voltage levels are presented in Table 3.6.

Table 3.6: Voltage limits at different voltage levels prescribed in CEA’s “Transmission

Planning Criteria”

Normal rating Emergency rating Nominal Maximum Minimum Maximum Minimum Voltage (kV) kV pu kV pu kV pu kV pu 765 800 1.05 728 0.95 800 1.05 713 0.93 400 420 1.05 380 0.95 420 1.05 372 0.93 220 245 1.11 198 0.90 245 1.11 194 0.88 132 145 1.10 122 0.92 145 1.10 119 0.90 66 72.5 1.10 60 0.91 72.5 1.10 59 0.89

3.5 Network element statistics for ER Grid

3.5.1 Substation details The summary of the number of substations present in the Eastern region state wise is presented in Table 3.7 and the complete list of substations along with load considered at each substation is given in Table A of Annexure-I.

Table 3.7: Existing number of sub-station in the ER

State Sl. No. Substation* Bihar Jharkhand Odisha Sikkim W. Bengal 1 765 kV 2 1 2 - - 2 400 kV 12 7 13 1 14

21 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

State Sl. No. Substation* Bihar Jharkhand Odisha Sikkim W. Bengal 3 220 kV 24 16 26 - 39 4 132 kV 100 47 86 4 111 5 66 kV - - - 19 - Total No. of S/S in ER 524 Note: If 765/400/220 kV substation has 400/220 kV transformation level also, in that case 765/400/220 kV substation is counted as single 765 kV substation.

*Above listed substation number excludes switching stations and generating stations.

3.5.2 Transmission line details The summary of Transmission line data present in the Eastern region is presented in Table 3.8 and the complete list of transmission lines state wise is given in Table B of Annexure-I.

Table 3.8: Summary of transmission line data in the ER

Sl. No. Voltage (kV) Line Length (ckm) 1 765 3014 2 400 34382 3 220 19202 4 132 29225 5 66 295

3.5.3 Transformer details The summary of Transformer data present in the Eastern region is presented below in Table 3.9 and the complete list of substation and their transformation capacity for each constituent state of ER Grid is given in Table A of Annexure-I.

Table 3.9: Summary of transformers capacity in the ER

Sl. No Voltage Ratio (kV) Installed Capacity (MVA) 1 765 18000 2 400 36390 3 220 39140 4 132 38254 5 66 213

22 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3.5.4 Generation details The summary of generator installed capacity present in the Eastern region state wise is presented in Table 3.10 and the complete list of generators is given in Table C of Annexure-I.

Table 3.10: Summary of Generator installed capacity in the ER

Installed capacity (MW)* Sl. No. State Thermal Hydro 1 Bihar 4545 35 2 Jharkhand 5251 289 3 Odisha 15956 2143 4 Sikkim 0 2072 5 West Bengal 14155 1265 39907 5804 Total ER 45711 *Note: Installed capacity includes central, state, IPP and CPP generations

3.5.5 HVDC details The details of the existing converter stations used for HVDC transmission and HVDC Back to Back, considered in the studies are given in Table 3.11 and Table 3.12.

Table 3.11: HVDC Back to Back in the ER

Sl. No. Parameter Sasaram B2B Gazuwaka B2B 1 Power Rating 1 X 500 MW 1 X 500 MW 1 X 500 MW 2 Number of blocks 1 Block 1 Block 2 3 AC voltage 400 kV 400 kV 400 kV 4 DC voltage 205 kV 205 kV 177 kV Converter transformer 5 6 X 234 MVA 6 X 234 MVA 6 X 201.2 MVA (Inverter/Rectifier)

Table 3.12: HVDC Link in the ER

Sl. No. Parameter Talcher to Kolar 1 Power Rating 2000 MW 2 Number of Poles 2 3 AC voltage 400 kV 4 DC voltage ± 500 kV 5 Converter transformer (Inverter) 6 X 398 MVA 6 Converter transformer (Rectifier) 6 X 398 MVA

23 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3.5.6 Reactor details The complete list of state wise Series and shunt reactors installed in the Eastern region is presented in Table D and E of Annexure-I respectively.

3.5.7 Load details The state wise summary of load data considered for the study is given in Table 3.13. Substation wise loading details considered for operational load flow is presented in Table F of Annexure-I.

Table 3.13: Load Details of ER

Sl. No. Constituents Load* 1 Bihar 3362 2 Jharkhand 1014 3 Odisha 3666 4 Sikkim 57 5 West Bengal 5854 6 DVC 2495 7 CESC 1676 8 DPL 231 *Note: 18354 MW (summation of recorded loads in S/S) on 04.05.2017 at 20:00 hrs in ER grid 3.6 Generation schedule details for operational load flow

The generation schedule considered was based on the information obtained from the ERLDC and other constituents of ER grid. Power plant wise generation allocation is given in Table 3.14 and graphically represented in figure 3.2.

Table 3.14: Generation schedule Details of ER Scheduled Sl.no. State Station Name Owned By Generation (MW) Joint venture of NTPC & 1 Muzaffarpur 90.0 BSEB 2 Bihar Baruni TPS BSEB 70.0 3 Kahalgaon 1710.0 NTPC 4 Barh 636.0 5 Patratu Thermal 50.0 6 Tenughat Thermal JVNL 124.0 7 Sikidiri Gen 45.0 8 Koderma Thermal 456.4 Jharkhand 9 Chandrapura Thermal 640.0 DVC 10 Maithon Dam 34.1 11 Bokaro Thermal 625.0 12 Adhunik Thermal APNRL 488.0 24 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Scheduled Sl.no. State Station Name Owned By Generation (MW) 13 Maithon RB Thermal MPL 513.0 14 Inland Power 62.1 15 ABCIL 24.0 16 Upper Kolab 240.0 17 indravati 566.0 18 Rengali OHPC 187.4 19 Hirakud 95.7 20 Chiplima 22.7 21 Talcher Thermal NTPC 432.0 22 IB Thermal OPGC 258.0 23 Odisha Balimela 326.0 OHPC 24 Machkund 47.1 25 Talcher Super Thermal NTPC 1669.0 26 Meenakshi Power 20.0 27 GMR GMR Kamalanga Energy 997.0 28 Jindal Thermal JITPL 456.0 29 Sterlite Energy Vedanta Ltd. 0.0 30 Net CPP Injection to Grid 591.0 31 Rangeet Hydro 57.0 NHPC 32 Teesta 5 Hydro 528.0 33 Teesta 3 714.0 34 Lagit Hydro 0.0 Sikkim 35 Meyong Hydro Sikkim Gov. 0.0 36 Rongli Hydro 0.0 37 Chuzachen Gati Infrastructure Pvt. Ltd 72.0 38 Jorethang DANS Energy Pvt. Ltd. 54.8 39 Bandel Thermal 322.1 40 Santaldih Thermal 467.0 41 Kolaghat Thermal WBPDCL 544.5 42 Bakreswar Thermal 955.0 43 Sagardighi Thermal 852.0 44 TCF 6.1 Purulia Pump Storage 45 342.8 Hydro WBSEDCL 46 Jaldhaka Hydro 27.0 47 Rammam Hydro 12.2 48 West Teesta Load Dam Hydro NHPC 212.0 49 Bengal Farakka Super Thermal NTPC 1519.9 50 Mejia 1682.0 51 DTPS 197.5 DVC 52 Raghunathpur 349.8 53 Durgapur Steel Thermal 935.0 54 DPL Thermal DPL 450.0 55 Budge Budge 690.0 56 SRS 87.0 CESC 57 TRS 0.0 58 Haldia Thermal 552.0 59 Net CPP Injection to Grid 124.4

25 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Figure 3.2: Scheduled generation, Import and Export of Eastern Regional grid

26 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

4 OPERATIONAL LOAD FLOW STUDY

4.1 Introduction to Load flow analysis

One of the most common computational procedures used in power system analysis is the load flow calculation. The planning, design and operation of power systems require such calculations to analyze the steady state performance of power system under various operating conditions and to study the effects of changes in network configuration. These load flow solutions are performed using computer programs designed specifically for this purpose. The basic question in the load flow analysis is: “Given the demand at all buses of a known electric power system configuration and the power production at each generator, find the power flow in each line and transformer of the interconnecting network and the voltage magnitude with phase angle at each bus.“ Analyzing the solution of load flow analysis for numerous conditions helps ensure that the power system is designed to satisfy its performance criteria while incurring the most favorable investment and operation costs. Some examples of the uses of load flow studies are to determine,  Component or circuit loading.  Steady state bus voltages.

 Active and Reactive power flows.  Transformers tap settings.  System losses.  Performance under emergency conditions. Modern systems are complex and have many paths or branches over which power can flow. Such systems form networks of series and parallel paths. Electric power flow in these networks divides among the branches until a balance is reached in accordance with established circuit theory. Computer programs to solve load flows are divided into two type’s static (offline) and dynamic (real time). Most load flow studies for system analysis are based on static network models. Real time load flows (online) that incorporate data input from the actual networks are typically used by utilities in Supervisory Control and Data Acquisition (SCADA) systems. Such systems are used primarily as operating tools for optimization of generation, VAr control, dispatch, losses, and tie line flow control. This discussion is concerned with only static network models and their analysis.

27 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

A load flow calculation determines the state of the power system with respect to a given load and generation schedule. It represents a steady state condition which is assumed to remain fixed for some time. In reality, line flows and bus voltages fluctuate in small amounts because load changes due to lights, motors, and other loads being turned on or off in the system. However, these small fluctuations are ignored in calculating the steady state effects on system equipment. As the load distribution, and hence power flow in the network vary considerably during different time periods, it may be necessary to obtain load flow solutions representing different system conditions such as peak load, average load or light load. Generally, these solutions provide,  Optimum operating modes for normal conditions, such as proper setting of voltage control devices, or how the system will respond to abnormal conditions, such as outage of transformers or lines.  When the new equipment additions are needed.  Effectiveness of new alternatives to solve present deficiencies and meet future requirements. The load flow model is also the basis for several other types of studies such as short circuit, stability, motor starting, and harmonic studies. The load flow model supplies the network data and an initial steady state condition for these studies. The present study is carried out to determine the power flows at different lines/transformers and to compute the voltage profile at different buses of the existing system. The system configuration considered for the study and simulation results are explained in the subsequent sections.

28 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

4.2 Load Generation Balance from the results of operational load flow analysis

The detail of load generation balance of ER is given in Table 4.1 and state wise load generation balance is presented in Table 4.2, 4.3, 4.4, 4.5, 4.6, 4.7 and 4.8. The detailed load and generation data is given in Annexure-I.

Table 4.1: Load generation balance Details of ER

Sl. No. Description Quantity (MW) 1 Generation 23326 2 Import 2064 Total (Generation + Import) 25390 3 Loss 749*(2.95%) 4 Load 18354 Demand Met (Load + Loss) 19103 5 Export 6287 Total System (Load + Export + Loss) 25390 *Note: Only for 765 kV, 400 kV, 220 kV, 132 kV and 66 kV transmission network.

Table 4.2: Load generation balance details of Bihar

Sl. No. Description Quantity (MW) 1 Generation 2505 2 Import 3789.6 Total Total(Generation + Import) 6295 3 Loss 134* (2.12%) 4 Load 3362 Demand Met (Load + Loss) 3496 5 Export 2799 Total (Load + Export + Loss) 6295 *Note: Only for 765 kV, 400 kV, 220 kV and 132 kV transmission network

Table 4.3: Load generation balance details of Jharkhand

Sl. No. Description Quantity (MW) 1 Generation 1306 2 Import 3202 Total (Generation + Import) 4508 3 Loss 38*(0.84%) 4 Load 1014 Demand Met (Load + Loss) 1052 29 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Sl. No. Description Quantity (MW) 5 Export 3456 Total (Load + Export + Loss) 4508 *Note: Only for 765 kV, 400 kV, 220 kV and 132 kV transmission network

Table 4.4: Load generation balance details of Odisha

Sl. No. Description Quantity (MW) 1 Generation 5908 2 Import 1396 Total (Generation + Import) 7304 3 Loss 155*(2.12%) 4 Load 3666 Demand Met (Load + Loss) 3822 5 Export 3482 Total (Load + Export + Loss) 7304 *Note: Only for 765 kV, 400 kV, 220 kV and 132 kV transmission network

Table 4.5: Load generation balance details of Sikkim

Sl. No. Description Quantity (MW) 1 Generation 1426 2 Import 0 Total (Generation + Import) 1426 3 Loss 14*(0.98%) 4 Load 57 Demand Met (Load + Loss) 71 5 Export 1355 Total (Load + Export + Loss) 1426 *Note: Only for 400 kV, 132 kV and 66 kV transmission network

Table 4.6: Load generation balance details of West Bengal

Sl. No. Description Quantity (MW) 1 Generation 5930 2 Import 3667 Total (Generation + Import) 9597 3 Loss 321*(3.35%) 4 Load 5854 Demand Met (Load + Loss) 6175 5 Export 3422 Total (Load + Export + Loss) 9597 30 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

*Note: Only for 400 kV, 220 kV and 132 kV transmission network

Table 4.7: Load generation balance details of DVC

Sl. No. Description Quantity (MW) 1 Generation 5024 2 Import 702 Total (Generation + Import) 5726 3 Loss 68*(1.19%) 4 Load 2495 Demand Met (Load + Loss) 2563 5 Export 3164 Total (Load + Export + Loss) 5727 *Note: Only for 400 kV, 220 kV and 132 kV transmission network

Table 4.8: Load generation balance details of CESC

Sl. No. Description Quantity (MW) 1 Generation 777 2 Import 913 Total (Generation + Import) 1690 3 Loss 14*(0.82%) 4 Load 1676 Demand Met (Load + Loss) 1690 5 Export 0 Total (Load + Export + Loss) 1690 *Note: Only for 220 kV and 132 kV transmission network

Table 4.9: Load generation balance details of DPL

Sl. No. Description Quantity (MW) 1 Generation 450 2 Import 0 Total (Generation + Import) 450 3 Loss 5*(1.02%) 4 Load 231 Demand Met (Load + Loss) 236 5 Export 214 Total (Load + Export + Loss) 450 *Note: Only for 220 kV and 132 kV transmission network. A block diagram illustrating the interstate and inter regional power exchange of ER is presented in figure 4.1 31 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Figure 4.1: Block diagram of load generation balance of ER

Note: Inter regional exchange is shown as net exchange 32 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

4.3 Line loading conditions

Under operational load flow study, number of lines whose loading is below 5% and above 80% is presented in Table 4.10 for complete ER grid and Table 4.11 to 4.18 for constituent state of ER grid.

Table 4.10: Percentage loading details of lines of Eastern Region Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 765 14.50 4.00 7.00 0 0 3 2 400 81.60 2.10 19.68 0 1 8 3 220 105.00 0.20 30.81 2 7 20 4 132 125.90 0.10 32.09 5 42 89 5 66 26.90 1.30 12.19 0 0 6

Table 4.11: Percentage loading details of lines of Bihar

Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 765 11.20 4.70 7.95 0 0 1 2 400 51.60 6.70 21.16 0 0 0 3 220 98.60 13.60 45.92 0 3 0 4 132 99.20 0.10 35.20 0 18 18

Table 4.12: Percentage loading details of lines of Jharkhand

Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 765 10.40 5.60 8.00 0 0 0 2 400 38.60 2.10 17.28 0 0 3 3 220 62.30 2.20 21.70 0 0 4 4 132 85.90 0.30 25.07 0 1 11

33 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 4.13: Percentage loading details of lines of Odisha Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 765 6.50 4.00 5.20 0 0 2 2 400 56.80 4.00 18.15 0 0 3 3 220 82.50 0.30 25.46 0 1 10 4 132 118.60 0.10 28.22 1 8 34

Table 4.14: Percentage loading details of lines of Sikkim Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 400 81.60 9.60 48.27 0 1 0 2 220 11.90 9.10 10.60 0 0 0 3 132 77.5 3.6 38.22 0 0 1 4 66 44.70 0.10 9.77 0 0 10

Table 4.15: Percentage loading details of lines of West Bengal Loading Percentage

Voltage No of No of Sl.No Grade No of lines Lines Max Min Avg lines Over (kV) Over 100% less than 80% 5%

1 400 43.10 4.00 20.33 0 0 1 2 220 105.00 0.20 34.00 2 2 3 3 132 125.90 0.40 36.29 4 15 16 4 66 26.90 26.80 26.85 0 0 0

Table 4.16: Percentage loading details of lines of DVC Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 400 39.6 6.7 25.4 0 0 0 2 220 72.7 1.6 24.35 0 0 3

34 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

3 132 84.8 0.5 25.25 0 2 13

Table 4.17: Percentage loading details of lines of CESC Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

2 220 87.2 47.7 56.24 0 1 0 3 132 102.7 2.5 43.94 1 2 3

Table 4.18: Percentage loading details of lines of DPL

Loading Percentage Voltage No of Sl.No Grade No of lines No of lines Max Min Avg Lines less (kV) Over 100% Over 80% than 5%

1 132 67.70 11.90 29.92 0 0 0

4.4 Transformer loading conditions

Under operational load flow study, number of transformers whose loading is below 20% and above 80% is presented in Table 4.19 for complete ER grid and Table 4.20 to 4.27 for constituent state of ER grid.

Table 4.19: Percentage loading details of Transformers of Eastern Region Loading Percentage Voltage No of No of No of Sl.No Grade Transformers Max Min Avg Transformers Transformers (kV) less than Over 100% Over 80% 20% 1 765 14.6 3.9 6.98 0 0 13 2 400 94.5 1.4 47.26 0 8 23 3 220 98.4 1.8 43.84 0 16 80 4 132 101.9 1.1 44.12 1 52 145 5 66 55.9 19.8 30.43 0 0 4

35 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 4.20: Percentage loading details of Transformers of Bihar Loading Percentage Voltage Sl.No Grade No of No of No of (kV) Max Min Avg Transformers Transformers Transformers Over 100% Over 80% less than 20%

1 765 14.6 3.9 7.47 0 0 5 2 400 75.8 17.6 51.48 0 0 2 3 220 75.8 13.8 47.13 0 0 6 4 132 99.2 4.1 42.83 0 8 32

Table 4.21: Percentage loading details of Transformers of Jharkhand Loading Percentage Voltage Sl.No Grade No of No of No of (kV) Max Min Avg Transformers Transformers Transformers Over 100% Over 80% less than 20%

1 765 9 9 9.00 0 0 2 2 400 77.6 1.4 44.56 0 0 2 3 220 52.8 3.1 33.03 0 0 4 4 132 88.5 1.8 36.60 0 1 23

Table 4.22: Percentage loading details of Transformers of Odisha Loading Percentage Voltage No of No of No of Sl.No Grade Transformers Max Min Avg Transformers Transformers (kV) loaded 80% Over 100% less than 20% and above 1 765 7.2 5 5.88 0 0 6 2 400 79.9 7.8 36.73 0 0 10 3 220 98.4 1.8 37.13 0 5 50 4 132 83.7 1.1 41.17 0 5 43

Table 4.23: Percentage loading details of Transformers of Sikkim Loading Percentage Voltage No of No of No of Sl.No Grade Transformers Max Min Avg Transformers Transformers (kV) loaded 80% Over 100% less than 20% and above 1 400 87.6 2.4 46.03 0 3 5 2 220 31.6 2.4 25.00 0 0 5 3 132 93 10.9 37.87 0 2 2 4 66 53 19.8 29.27 0 0 4

36 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 4.24: Percentage loading details of Transformers of West Bengal Loading Percentage Voltage No of No of No of Sl.No Grade Transformers Transformers Max Min Avg Transformers (kV) loaded 80% less than Over 100% and above 20% 1 400 94.5 4.5 53.04 0 5 2 2 220 94.5 4.5 49.36 0 9 8 3 132 101.9 3 50.45 1 27 25 4 66 55.9 55.9 55.90 0 0 0

Table 4.25: Percentage loading details of Transformers of DVC Loading Percentage Voltage Sl.No Grade No of No of No of (kV) Max Min Avg Transformers Transformers Transformers Over 100% Over 80% less than 20%

1 400 55.3 55.3 55.3 0 0 0 2 220 80.2 2.2 43.76 0 1 5 3 132 91.7 2.9 42.97 0 3 16

Table 4.26: Percentage loading details of Transformers of CESC Loading Percentage Voltage Sl.No Grade No of No of No of (kV) Max Min Avg Transformers Transformers Transformers Over 100% Over 80% less than 20%

1 220 79.3 8.5 57.81 0 0 2 2 132 85.5 8.5 50.00 0 6 4

Table 4.27: Percentage loading details of Transformers of DPL Loading Percentage Voltage Sl.No Grade No of No of No of (kV) Max Min Avg Transformers Transformers Transformers Over 100% Over 80% less than 20%

1 220 81.3 60.5 66.74 0 1 0 2 132 64.6 6.7 35.83 0 0 7

37 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

4.5 Voltage profile

Bus Voltage Profile for Eastern Region grid is presented in Table 4.28

Table 4.28: Bus Voltage Profile for Eastern Region

Voltage Bus Voltage In pu Sl.No Grade (kV) Max Bus name Min Bus name Average 1 765 1.009 Jharsuguda 0.988 Gaya 0.998 2 400 1.031 DSTPS 0.987 Jeerat 1.009 3 220 1.031 Arrah 0.946 Balimela 0.992 4 132 1.026 Machkund 0.902 Buxar 0.967 5 66 1.011 Rangit 0.969 Chalsa 0.991 Note: As observed in operational load flow study that bus voltage of ER grid is within the acceptable limit (as per CEA grid code). Comparison of SCADA record with simulated result for 765 kV and 400 kV Bus Voltage of Eastern Region grid is presented in Table 4.29

38 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table 4.29: 765 kV and 400 kV Bus Voltage of Eastern Region grid

Voltage level Voltage in pu SI.No Name of the SubStation (kV) Difference % Difference Nominal Recorded Simulated Bihar 765 0.986 0.995 0.009 0.911% 1 Sasaram 400 0.983 0.996 0.013 1.333% 765 0.986 0.988 0.003 0.272% 2 Gaya 400 0.995 0.995 0.001 0.060% 3 Banka 400 1.018 1.012 -0.006 -0.560% 4 Barh 400 1.025 1.013 -0.012 -1.132% 5 Biharsharif 400 0.995 1.014 0.019 1.859% 6 Kahalgaon 400 1.018 1.018 0.001 0.088% 7 Muzaffarpur 400 0.993 1.001 0.008 0.856% 8 New Purnea 400 0.993 1.011 0.019 1.904% 9 Patna 400 1.009 1.006 -0.003 -0.253% 10 Lakhisarai 400 1.008 1.007 0.000 -0.020% 11 Kishanganj 400 1.008 1.012 0.004 0.397% Jharkand 765 1.016 1.006 -0.010 -0.993% 1 Ranchi New 400 1.028 1.008 -0.020 -1.927% 2 Jamshedpur 400 1.025 1.020 -0.005 -0.459% 3 Maithon 400 1.018 1.014 -0.004 -0.344% 4 Ranchi 400 1.020 1.016 -0.004 -0.392%

39 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Voltage level Voltage in pu SI.No Name of the SubStation (kV) Difference % Difference Nominal Recorded Simulated 5 Chaibasa 400 1.025 1.015 -0.010 -0.966% 6 Koderma (KTPS) 400 1.018 1.013 -0.004 -0.423% 7 BTPS-A (Bokaro) 400 1.028 1.019 -0.009 -0.847% 8 TISCO 400 1.010 1.017 0.007 0.703% 9 Chandwa 400 1.005 0.999 -0.006 -0.577% Odisha 765 1.009 1.009 0.000 0.025% 1 Jharsuguda 400 1.028 1.018 -0.010 -0.934% 765 1.018 1.004 -0.015 -1.424% 2 Angul 400 1.010 1.007 -0.003 -0.277% 3 Bisra 400 1.010 1.013 0.003 0.297% 4 Bolangir 400 0.994 1.008 0.014 1.406% 5 Indravati 400 0.995 0.994 -0.001 -0.060% 6 Jaypore 400 0.988 0.994 0.006 0.618% 7 Kaniha 400 0.993 1.002 0.010 0.997% 8 Keonjhar 400 1.018 1.006 -0.012 -1.170% 9 Kuchei/Baripada 400 1.005 1.008 0.003 0.328% 10 Mendhasal 400 0.995 0.999 0.004 0.412% 11 Meramundali 400 1.013 1.009 -0.003 -0.326% 12 Rengali 400 0.995 1.004 0.009 0.935% 13 New Duburi 400 1.008 1.005 -0.003 -0.258% 14 Sterlite 400 1.025 1.015 -0.010 -0.976% 15 Pandiabil 400 0.999 0.999 0.000 -0.043%

40 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Voltage level Voltage in pu SI.No Name of the SubStation (kV) Difference % Difference Nominal Recorded Simulated 16 JITPL 400 1.022 1.020 -0.002 -0.225% 17 GMR 400 1.009 1.009 0.000 0.050% 18 JSPL 400 0.995 1.008 0.013 1.276% Sikkim 1 Rangpo 400 1.000 0.999 -0.002 -0.155% 2 Teesta V 400 0.998 1.000 0.002 0.201% West Bengal 1 Arambagh 400 1.028 1.002 -0.026 -2.511% 2 Jeerat 400 0.983 0.987 0.005 0.499% 3 Bidhannagar (WBSETCL) 400 1.015 1.010 -0.005 -0.502% 4 Kharagpur 400 1.007 1.006 -0.001 -0.070% 5 Bakreswar 400 0.990 0.991 0.001 0.111% 6 Kolaghat TPS 400 1.000 1.001 0.001 0.100% 7 Sagardighi 400 1.023 1.019 -0.003 -0.303% 8 Binaguri 400 1.008 1.006 -0.002 -0.169% 9 Malda 400 1.025 1.021 -0.004 -0.390% 10 Parulia (Durgapur PG) 400 1.023 1.010 -0.012 -1.193% 11 Farakka 400 1.033 1.024 -0.009 -0.862% 12 Subhashgram 400 0.998 0.989 -0.009 -0.852% 13 Raghunathpur DSTPS 400 1.037 1.031 -0.007 -0.646% 14 Mejia 400 1.028 1.028 0.000 0.019% 15 PPSP 400 1.030 1.021 -0.009 -0.893% 16 Berhampore 400 1.022175 1.016 -0.006 -0.624%

41 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Voltage level Voltage in pu SI.No Name of the SubStation (kV) Difference % Difference Nominal Recorded Simulated 17 Alipurduar 400 1.0225 1.022 -0.001 -0.098% 18 Haldia 400 1.005 1.007 0.002 0.229%

42 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

4.6 Analysis of the load flow study results

 Power map of ER grid along with separate power map of constituent states (Bihar, Jharkhand, Odisha, Sikkim and West Bengal) for operational load flow study is presented in Annexure-II.  Line loading details are presented in Table G of Annexure-II.  All the bus Voltages (765 kV, 400 kV, 220 kV, 132 kV and 66 kV) were within the standard tolerance limits (as per CEA grid code).  Total nine numbers of line/Transformers loaded beyond 100%, rest of the network elements were loaded within the rated capacity under summer-peak operating condition of 4th May 2017 at 20.00 hrs.

 Maximum inter regional power exchange is 3122 MW to SR.

43 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

5 SHORT CIRCUIT STUDIES

Even the most carefully designed power systems may be subjected to damaging arc blast or overheating and the explosive magnetic forces associated with high magnitude currents flowing during a short circuit. To ensure that circuit’s protective equipment can isolate faults quickly and minimize system component damage, personal hazard and outage severity, it is essential that a short circuit study be included in the electrical design of new industrial and commercial power systems, and for modifications to existing system. There are five possibilities for a short circuit in three-phase system.

 3-phase to ground fault.  Single line to ground fault.  Line to line fault.  Double line to ground fault.  Open conductor fault. If a short circuit of one type is not interrupted promptly, it often progresses to another type, which generally results in more severe damage. For example in a solidly grounded system, a single line to ground fault, if not interrupted, can quickly escalate to a double line to ground or a three phase to ground fault. The choice of study that is required for a particular system is a matter of engineering judgment based on an analysis of the basic single line diagram and determination of the specific purpose of the study. For the three-phase industrial and commercial power systems, the most common study is the calculation of three-phase (balanced) short circuit current which is more severe compared to other faults, specifically for comparison with switching equipment capability. The short circuit current determined from this type of study generally represents the highest value at a particular location in the system. It is important to realize that single line to ground or double line to ground short circuit current magnitude can exceed three-phase short circuit current under certain conditions. This condition may arise near,  Solidly grounded synchronous machines.  Solidly grounded star connection of a delta-star transformer of the three- phase core design.  Grounded star-delta tertiary autotransformers.

44 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

 Grounded star-delta tertiary three winding transformers. In system where any of these machines or transformer connections exists, it may be necessary to conduct a single line to ground short circuit study. Medium and high voltage circuit breakers have 15% higher interrupting capability for single line to ground short circuits than for phase to phase or three phase short circuits. This difference must be taken into account when comparing short circuit duty with equipment ratings. Further, future network growth (about 20% increases in result obtained through study) has to be accounted while considering the fault levels for equipment ratings.

5.1 Short circuit study result analysis

The detailed results of the Short circuit study for the three phases to ground fault and single line to ground faults are tabulated in Table H and presented in Annexure-III. Based on the detailed analysis, it is observed that  For 400 kV 220 kV and 132 kV voltages, 3-phase fault level & SLG fault level at some of the substations are at the critical level. Fault levels which are more than 80% of breaker rating are listed in Table 5.1 and Table 5.2.  For 765 kV & 66 kV voltage level, there are no violation in the fault level.

Table 5.1: 3-Ph fault levels > 80% of breaker rating Fault Rated 3-Phase Sl.No. Substation Name Current Voltage (kV) fault (MVA) (kA) 1 CTPS-A 132 5765.10 25.22 2 CTPS-B 132 5765.89 25.22 3 Angul 400 36101.97 52.11 4 Meramandali 220 13069.98 34.3 5 Budhipadar 220 14262.63 37.43

Table 5.2: SLG fault levels > 80% of breaker rating Fault Rated SLG fault Sl.No. Substation Name Current Voltage (kV) (MVA) (kA) CTPS-A 132 6035.999 26.401 1 CTPS-B 132 6034.305 26.393 2 Meramandali 220 13003.502 34.125 3 Budhipadar 220 13967.8 36.656 4 Vedanta 220 12652.203 33.203 5 NALCO 220 12347.226 32.403 6 Mejia 220 12840.489 33.698 7 BTPS132 132 6114.185 26.743

45 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Note: In some of the Generating stations the SLG fault rating is exceeding 80% while the three phase fault rating is within 80% of breaker capacity.

46 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

6 CONCLUSION

Based on the operational load flow studies carried out for said condition following observation are made,  The voltages at all the bus bars (765 kV, 400 kV, 220 kV, 132 kV and 66 kV) were within the standard tolerance limits (as per CEA grid code).  Number of line/Transformers were loaded beyond 100% is 9, rest of line/Transformers loaded within the rated capacity under summer-peak operating condition of 4th May 2017 at 20.00 hrs.  Maximum inter regional power exchange is 3122 MW to SR.

 It is observed that short circuit levels are critical at some of the substations but within the breaker rated capacity. Such cases are listed above in section 5.1. The network modeling for operational load flow and short circuit study and the results will provide the base for the subsequent protection system analysis and calculation. This will also provide the base for transient studies and tripping analysis.

47 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

ANNEXURE-1 EXISTING EASTERN REGION TRANSMISSION NETWORK AND LOAD DETAILS

48 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table A: State wise list of substation present in the eastern region grid

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) Bihar 765kV Level 765/400 1 1500 1500 1 315 315 1 Sasaram 400/220 PGCIL 1 500 500 132/33 2 10 20 765/400 3 1500 4500 2 Gaya 1 315 315 PGCIL 400/220 1 500 500 400kV Level 1 Banka 400/132 2 200 400 PGCIL 2 Barh 400/132 2 200 400 NTPC 3 Biharsharif 400/220 3 315 945 PGCIL 4 Kahalgaon 400/132 2 200 400 NTPC 2 315 630 400/220 5 Muzaffarpur 1 500 500 220/132 1 100 100 1 315 315 6 New Purnea 400/220 1 500 500 PGCIL 7 Patna 400/220 2 315 630 8 Lakhisarai 400/132 2 200 400 400/(93/√3)/ 234/117/1 9 Sasaram B2B 3 1350 93 17 10 Kishanganj 400/220 2 500 1000 11 Nabinagar RLY 400/132 2 200 400 Railway Darbhanga 12 400/220 2 160 320 DMTCL (DMTCL) 220kV Level 1 Purnea 220/132 3 160 480 1 160 160 PGCIL 2 Arrah 220/132 2 100 200 Amnour 3 220/132 2 100 200 (Chhapra) 220/132 3 150 450 4 Biharshariff 132/33 1 20 20 220/132 4 150 600 5 Bodhgaya 220/132 1 160 160 BSPTCL 132/33 3 50 150 6 Darbhanga new 220/132 2 160 320 220/132 4 100 400 7 Dehri 132/33 2 50 100 220/132 5 100 500 8 Fatuha 132/33 3 50 150

49 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 220/132 3 100 300 9 Gopalganj 132/33 3 50 150 220/132 4 100 400 10 Khagaul 132/33 5 50 250 220/132 4 100 400 11 Begusarai 132/33 3 50 150 220/132 2 150 300 12 Sipara 220/132 1 160 160 132/33 2 50 100 13 Hazipur New 220/132 2 100 200 220/132 3 100 300 14 Madhepura 132/33 2 20 40 220/132 2 150 300 15 Pusauli New 132/33 2 50 100 220/132 2 160 320 16 Sonenagar 132/33 2 50 100 Muzaffarpur 17 220/132 3 100 300 (MTPS) 18 Kishanganj _New 220/132 2 160 320 Muzzafarpur_BS 220/132 2 160 320 19 PTCL 132/33 3 50 150 Musahari_BSPT 220/132 2 160 320 20 CL 132/33 3 50 150 220/132 2 160 320 21 Samastipur_New 132/33 2 50 100 220/132 2 160 320 22 Sonenagar_New 132/33 2 50 100 220/132 2 160 320 23 Mushahri 132/33 3 50 150 220/132 2 160 320 24 Motipur 132/33 3 50 150 132kV Level 1 20 20 1 Arrah 132/33 3 50 150 2 Ataula (Arwal) 132/33 2 20 40 132/33 1 20 20 3 Aurangabad 132/33 1 50 50 4 Banjari 132/33 3 20 60 5 Banka 132/33 3 20 60 BSPTCL 6 Banmakhi 132/33 2 20 40 1 50 50 7 Barauni TPS 132/33 2 20 40 1 20 20 8 Barh 132/33 1 50 50 9 Baripahari 132/33 3 50 150

50 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 10 Belaganj 132/33 2 20 40 11 BENIPATTI 132/33 2 20 40 12 Belsand 132/33 2 10 20 2 20 40 13 Bettiah 132/33 1 50 50 14 Bihta 132/33 3 50 150 2 20 40 15 Bikramganj 132/33 1 50 50 2 20 40 16 Buxar 132/33 1 50 50 Chandauti 132/33 2 50 100 17 (Gaya) 132/25 2 13.35 26.7 2 20 40 18 Chhapra 132/33 1 50 50 19 Darbhanga (old) 132/33 2 50 100 20 Dhaka 132/33 3 20 60 132/33 2 20 40 21 Dalsingsarai 132/33 1 50 50 22 Digha 132/33 3 50 150 1 20 20 23 Dumraon 132/33 1 50 50 24 Ekma 132/33 1 20 20 Ekanga Sarai 25 132/33 3 20 60 (Ekanagar) 2 20 40 26 Forbeshganj 132/33 1 50 50 27 Goh 132/33 2 20 40 28 Gangwara 132/33 2 50 100 29 Gaighat 132/33 2 50 100 30 Hazipur 132/33 3 50 150 31 Hulasganj 132/33 2 20 40 32 Harnaut 132/33 2 20 40 33 Hathidah 132/33 3 20 60 34 Hathua 132/33 2 20 40 35 Imamganj 132/33 2 20 40 36 Jagdishpur 132/33 2 20 40 37 Jandaha 132/33 2 20 40 38 Jainagar 132/33 3 20 60 4 50 200 39 Jakkanpur 132/33 1 20 20 40 Jamalpur 132/33 2 50 100 2 20 40 41 Jamui 132/33 1 50 50 42 Jehanabad 132/33 2 20 40 2 20 40 43 Kahalgaon 132/33 2 50 100

51 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 2 50 100 132/33 1 20 20 44 Karmnasa 1 21.6 21.6 132/25 1 20 20 132/33 2 20 40 45 Kataiya 132/33 1 50 50 3 20 60 46 Katihar 132/33 1 50 50 47 Katra 132/33 3 50 150 Kusheshwarstha 48 132/33 2 20 40 n 49 Kochas 132/33 2 20 40 50 Karbigahiya 132/33 4 50 200 51 Kudra 132/33 2 20 40 2 20 40 52 Khagaria 132/33 1 50 50 2 50 100 53 Kishanganj 132/33 1 20 20 54 Lakhisarai 132/33 3 20 60 55 Madhubani 132/33 2 20 40 56 Manjhaul

57 Masaurhi 132/33 3 20 60 58 Mahanar 132/33 2 20 40 59 Mithapur 132/33 2 50 100 1 50 50 60 Mohania 132/33 1 20 20 1 20 20 61 Motihari 132/33 1 50 50 62 Masrakh 132/33 2 20 40 63 Muzaffarpur 132/33 3 50 150 64 Nalanda 132/33 2 20 40 65 Narkatyagaunj 132/33 2 20 40 66 Naugachhia 132/33 3 20 60 1 20 20 67 Nawada 132/33 3 50 150 2 20 40 68 Pandaul 132/33 1 50 50 69 Phulparas 132/33 2 20 40 70 Pupri 132/33 2 20 40 1 20 20 71 Purnea 132/33 2 50 100 1 50 50 72 Rafiganj 132/33 1 20 20 73 Rajgir 132/33 2 20 40 74 Ramnagar 132/33 2 20 40

52 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 132/33 1 50 50 75 Raxaul 132/33 2 20 40 Remi nagar 76 132/33 2 20 40 (Runni Saidpur) 77 Sherghati 132/33 2 20 40 78 SKMCH 132/33 2 50 100 79 Sonebarsa 132/33 2 20 40 80 Sabour 132/33 3 50 150 81 Saharsa 132/33 1 20 20 82 Samastipur 132/33 2 20 40 83 Sasaram 132/33 2 50 100 84 Shekhpura 132/33 2 20 40 85 Sheohar 132/33 2 50 100 86 Sherghati 132/33 2 20 40 87 Sheetalpur 132/33 2 20 40 88 Sitamarhi 132/33 3 50 150 1 20 20 89 Siwan 132/33 2 50 100 1 50 50 132/33 1 20 20 90 Sonenagar 1 21.6 21.6 132/25 1 20 20 2 20 40 91 Sultanganj 132/33 2 50 100 92 Supaul 132/33 3 20 60 93 Tarapur 132/33 2 20 40 94 Tehta 132/33 2 20 40 95 Tekari 132/33 2 20 40 96 Triveniganj 132/33 2 20 40 97 Udaikishanganj 132/33 2 20 40 98 Vaishali 132/33 2 20 40 99 Valmikinagar 132/33 1 10 10 100 Wazirganj 132/33 2 20 40 Jharkhand 765kV Level 1 Ranchi New 765/400 2 1500 3000 PGCIL 400kV Level Jamshedpur 1 400/220 2 315 630 (3*315) 2 Maithon 400/220 2 315 630 PGCIL 3 Ranchi 400/220 2 315 630 4 Chaibasa 400/220 2 315 630 400/220 2 315 630 5 Koderma (KTPS) 220/132 2 150 300 DVC 6 BTPS-A (Bokaro) 400/220/33 2 315 630

53 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 7 TISCO 400/220 2 315 630

220kV Level 1 Chandil 220/132 4 100 400 220/132 2 150 300 2 Chaibasa 132/33 2 50 100 3 Hatia New 220/132 3 150 450 220/132 1 100 100 4 Lalmatiya 1 20 20 JUSNL 132/33 2 50 100 5 PTPS 220/132 2 150 300 6 Ramachandrapur 220/132 3 150 450 7 TTPS 220/132 2 250 500 8 Dumka (New) 220/132 2 150 300 220/132 2 150 300 9 BTPS-B (Bokaro) 132/33 2 50 100 220/132/11 3 150 450 10 CTPS 132/33 2 80 160 220/132/33 2 150 300 11 Giridhi 220/33 2 80 160 132/33 3 80 240 220/132/33 2 150 300 12 Jamshedpur 132/33 3 50 150 DVC 220/132 2 150 300 13 Ramgarh 2 80 160 132/33 1 50 50 220/33 2 80 160 14 Dhanbad 220/132 1 150 150 15 Ramkanali 132/33 2 25 50 220/132/33 2 150 300 16 Kalyanswari 220/132/33 1 160 160 132/33 2 50 100 132kV Level 1 Maniqui 132/33 2 50 100 2 Adityapur 132/33 4 50 200 3 Chakradharpur 132/33 2 20 40 4 Dalbhumgarh 132/33 3 50 150 5 Chaibasa 132/33 1 25 25 6 Manoharpur 132/33 2 50 100 7 Deogarh 132/33 3 50 150 JUSNL 8 Dumka 132/33 2 50 100 1 50 50 9 Garhwa Road 132/33 1 20 20 10 Goielkara 132/33 1 20 20 11 Golmuri 132/33 2 50 100 12 Gumla 132/33 2 20 40

54 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 13 Hatia old 132/33 4 50 200 14 Tamar 132/33 2 50 100 15 Madhupur 132/33 2 50 100 16 Sikidri 132/33 2 20 40 2 20 40 17 Jadugoda 132/33 1 50 50 1 50 50 18 Jamtara 132/33 1 20 20 19 Japla 132/33 2 20 40 2 20 40 20 Kamdara 132/33 1 50 50 21 Kanke 132/33 2 50 100 1 20 20 22 Kendposi 132/33 1 50 50 23 Latehar 132/33 2 50 100 24 Lohardaga 132/33 2 50 100 25 Namkum 132/33 3 50 150 26 Nowamundi 132/33 1 50 50 27 Pakur 132/33 2 50 100 1 20 20 28 Rajkharsawan 132/33 1 50 50 29 Sahebgunj 132/33 2 50 100 30 Daltonganj 132/33 2 50 100 1 80 80 132/33 31 Koderma 1 50 50 132/25 1 25 25 132/33 2 31.5 63 32 Nimiaghat 132/25 2 25 50 33 North Karnapura 132/33 2 50 100 34 Pradhankanta 132/33 No Load

132/33 2 80 160 35 Patherdhi 132/33 1 50 50 132/25 2 12.5 25 36 Patratu (DVC) 132/33 1 31.5 31.5 DVC 37 Putki 132/33 3 80 240 132/33 1 50 50 38 Barhi 132/33 1 31.5 31.5 132/33 1 31.5 31.5 39 Gola 132/33 1 20 20 40 Hazaribag Road 132/33 No load

41 Hazaribagh 132/33 2 50 100 2 50 100 132/33 42 Kumardhubi 1 80 80 132/25 2 25 50 43 Konar 132/33 1 20 20

55 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 132/33 1 31.5 31.5 44 Mosabani 132/33 1 20 20 45 Biada 132/33 2 80 160 46 MHS-Right bank 132/33 2 50 100 47 Panchet 132/33 1 50 50 Odisha

765 kV Level 1 Jharsuguda 765/400/33 2 1500 3000 PGCIL 2 Angul 765/400 4 1500 6000 400 kV Level 1 Bisra 400/220 2 315 630 2 Bolangir 400/220/33 2 315 630 3 Indravati 400/220/33 2 315 630 4 Jaypore 400/220/33 2 315 630 5 Kaniha 400/220 2 315 630 PGCIL 6 Keonjhar 400/220/33 2 315 630 400/220 2 315 630 7 Kuchei/Baripada 400/220 1 500 500 220/132 2 160 320 400/220 2 315 630 8 Mendhasal 220/132 2 100 200 OPTCL 220/33 1 20 20 400/220 2 315 630 PGCIL 9 Meramundali 220/132 3 100 300 OPTCL 132/33 1 12.5 12.5 10 Rengali 400/220 2 315 630 PGCIL 11 New Duburi 400/220 2 315 630 OPTCL 12 Sterlite 400/220 2 315 630 SEL 13 Pandiabil 400/220 2 500 1000 PGCIL 220 kV Level 1 Atri 220/132 2 160 320 220/132 2 160 320 2 Balasore 132/33 2 63 126 132/33 1 40 40 220/132 3 100 300 3 Bhadrak 132/33 2 63 126 132/33 1 40 40 OPTCL 220/132 1 160 160 220/132 2 100 200 4 Bidanasi 132/33 2 63 126 132/33 1 40 40 220/132 2 160 320 5 Bolangir new 132/33 1 12.5 12.5

56 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 220/132 2 160 320 6 Budhipadar 132/33 1 20 20 132/33 1 12.5 12.5 220/132 2 100 200 220/132 2 160 320 7 Chandaka 132/33 2 63 126 132/33 1 40 40 220/132 3 100 300 8 Duburi 220/33 2 40 80 132/33 1 5 5 220/132 2 160 320 9 Jayanagar 132/33 2 20 40 132/33 1 12.5 12.5 220/132 3 100 300 10 Joda 132/33 3 20 60 132/33 1 40 40 220/132 1 160 160 220/132 2 100 200 11 Katapalli 132/33 1 40 40 132/33 2 20 40 12 Lapanga 220/132 2 160 320 13 Mendhasal 220/132 2 100 200 220/132 1 100 100 220/132 2 160 320 14 Narendrapur 132/33 2 40 80 132/33 1 20 20 220/132 1 160 160 220/132 1 50 50 15 Paradip 220/132 1 100 100 132/33 2 20 40 132/33 1 12.5 12.5 16 Talcher (TTPS) 220/132 2 160 320 17 Tarkera 220/132 4 100 400 220/132 2 100 200 18 Theruvali 132/33 2 12.5 25 19 Bhanjanagar 220/132 2 160 320 Puri 220/132 1 160 160 20 (Samangara) 132/33 2 20 40 220/33 1 20 20 21 Balimela 220/33 1 40 40 22 Barkote 220/33 2 40 80 220/33 1 40 40 23 Nayagarh 220/33 2 20 40

57 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 24 Laxmipur 220/33 1 20 20 25 Rengali 220/33 2 20 40 Cuttack(POPAR 26 220/132 1 160 160 DA) 132 kV Level 1 Akhusingh 132/33 2 12.5 25 132/33 2 12.5 25 2 Anandapur 132/33 1 20 20 132/33 2 40 80 3 Angul 132/33 1 20 20 132/33 2 40 80 4 Argul 132/33 1 20 20 5 Atri 132/33 1 34 34 6 Aska 132/33 3 40 120 132/33 1 40 40 7 Balugaon 132/33 1 20 20 132/33 1 12.5 12.5 8 Banki 132/33 2 20 40 9 Barbil 132/33 2 12.5 25 10 Baragarh 132/33 3 40 120 11 Baripada 132/33 3 40 120 132/33 1 20 20 12 Barpalli 132/33 1 40 40 132/33 2 40 80 13 Berhampore OPTCL 132/33 1 20 20 132/33 1 12.5 12.5 14 Basta 132/33 1 20 20 132/33 2 40 80 15 Bhanjanagar 132/33 1 16 16 16 Bhawanipatna 132/33 2 12.5 25 17 Bhubaneswar 132/33 3 63 189 132/33 1 20 20 18 Boinda 132/33 2 12.5 25 19 Boudh 132/33 1 20 20 132/33 2 40 80 20 Bolangir 132/33 1 12.5 12.5 132/33 1 40 40 21 Brajrajnagar 132/33 3 20 60 132/33 1 12.5 12.5 132/33 2 40 80 22 Chainpal 132/33 1 20 20 23 Chandikhole 132/33 3 20 60 24 Chhandpur 132/33 2 12.5 25

58 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 25 Chhatrapur 132/33 3 20 60 26 Chhend 132/33 3 40 120 132/33 1 20 20 27 Choudwar 132/33 2 40 80 28 Cuttack 132/33 3 40 120 29 Dabugaon 132/33 2 12.5 25 30 Dhenkanal 132/33 3 40 120 132/33 2 20 40 31 Digapahandi 132/33 1 12.5 12.5 32 Ganjam 132/33 2 12.5 25 132/33 2 20 40 33 Jagatsinghpur 132/33 1 40 40 132/33 2 40 80 34 Jajpur road 132/33 1 20 20 132/33 2 40 80 35 Jajpur town 132/33 1 20 20 132/33 2 31.5 63 36 Jaleswar 132/33 1 12.5 12.5 37 Jharsuguda 132/33 1 40 40 38 Junagarh 132/33 3 20 60 132/33 2 12.5 25 39 Kalarangi 132/33 1 20 20 40 Kalugaon 132/33 2 40 80 132/33 1 20 20 41 Kamakshyanagar 132/33 2 12.5 25 132/33 2 12.5 25 42 Karanjia 132/33 1 20 20 132/33 2 40 80 43 Kendrapara 132/33 1 12.5 12.5 132/33 1 40 40 44 Kesinga 132/33 2 20 40 Kesura/Badagad 132/33 1 63 63 45 a 132/33 1 40 40 46 Khariar 132/33 2 40 80 47 Khurda 132/33 3 40 120 48 Konark 132/33 2 20 40 49 Kuchinda 132/33 2 20 40 50 Lapanaga 132/33 1 20 20 51 Mania 132/33 1 12.5 12.5 52 Marshaghai 132/33 2 20 40 53 Mohana 132/33 2 12.5 25 2 40 80 54 Nimapara 132/33 1 12.5 12.5

59 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 55 Nuapara 132/33 2 20 40 132/33 1 40 40 56 Nuapatna 132/33 1 20 20 132/33 1 12.5 12.5 57 Padampur 132/33 1 20 20 58 Parlakhemundi 132/33 3 12.5 37.5 132/33 1 40 40 59 Patnagarh 132/33 2 20 40 132/33 2 20 40 60 Pattamundai 132/33 1 12.5 12.5 132/33 2 12.5 25 61 Phulbani 132/33 1 40 40 62 Phulnakhara 132/33 2 20 40 132/33 1 40 40 63 Polasapanga 132/33 2 20 40 64 Puri 132/33 3 40 120 65 Purusottampur 132/33 2 12.5 25 66 Rairakhole 132/33 2 12.5 25 132/33 2 20 40 67 Rairangpur 132/33 1 12.5 12.5 68 Rajgangpur 132/33 3 40 120 132/33 2 63 126 69 Ranasinghpur 132/33 1 40 40 70 Rayagada 132/33 2 12.5 25 132/33 4 35 140 71 Rourkela 132/25 1 12.5 12.5 132/33 1 10 10 72 Saintala 132/33 1 12.5 12.5 132/33 2 20 40 73 Salipur 132/33 1 12.5 12.5 132/33 2 31.5 63 74 Sambalpur 132/33 1 40 40 75 Shamuka 132/33 2 31.5 63 76 Somnathpur 132/33 1 12.5 12.5 132/33 60 77 Sonepur 3 20 132/33 0 132/33 1 40 40 78 Soro 132/33 2 20 40 79 Sunabeda 132/33 3 12.5 37.5 132/33 1 40 40 80 Sundargarh 132/33 1 20 20 132/33 1 20 20 81 Tentulikhunti 132/33 2 12.5 25

60 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 82 Tarkera 132/33 1 12.5 12.5 83 Umerkote 132/33 2 20 40 84 Bolani 132/11 2 10 20 85 Brajrajnagar 132/11 1 12.5 12.5 132/11 1 20 20 86 Jharsuguda 132/11 1 12.5 12.5 Sikkim

400kV Level 440/220 5 315 1575 1 Rangpo PGCIL 220/132 3 100 300 132kV Level 1 Gangtok 132/66 2 50 100 PGCIL 2 Melli 132/66 2 50 100 Sikkim 3 Geyzing 132/66 1 20 20 Gov 4 Rangit 132/66 1 20 20 66kV Level 1 5 5 1 Phodong 66/11 1 2.5 2.5 2 Bulbuley 66/11 2 10 20 2 10 20 3 Sichey 66/11 1 5 5 4 Tadong 66/11 3 5 15 5 Rongly 66/11 2 2.5 5 1 10 10 6 Mamring 66/11 1 7.5 7.5 1 15 15 7 Melli 66/11 2 5 10 8 Namchi 66/11 2 2.5 5 Sikkim 9 Rabangla 66/11 1 5 5 Gov 10 Rothak 66/11 2 2.5 5 11 Soreng 66/11 2 2.5 5 12 Geyzing 66/11 2 2.5 5 13 Purano Namchi 66/11 2 7.5 15 14 Pakyong 66/11 1 10 10 15 Pelling 66/11 1 5 5 16 Rhenock 66/11 1 5 5 17 Mangan 66/11 2 5 10 18 Ranipool 66/11 2 7.5 15 66/11 1 7.5 7.5 19 Topakhani 66/11 1 5 5

West Bengal

400 kV Level 1 Arambagh 400/220 4 315 1260 WBSETC

61 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 220/132 3 160 480 L 132/33 3 50 150 400/220 4 315 1260 2 Jeerat 220/132/33 3 160 480 Bidhannagar 3 (Durgapur 400/220 2 315 630 WBSETCL) 400/220 3 315 945 4 Kharagpur 220/132 2 160 320 400/220 2 315 630 WBPDCL 5 Bakreswar WBSETC 220/33 1 50 50 L 6 Kolaghat TPS 400/220 2 315 630 WBPDCL 7 Sagardighi 400/220 2 315 630 8 Binaguri 400/220 2 315 630 9 Malda 400/220 2 315 630 PGCIL Parulia 10 400/220 2 315 630 (Durgapur PG) 11 Farakka 400/220 2 315 630 NTPC 4 315 1260 12 Subhashgram 400/220 PGCIL 1 500 500 Alipurduar_ 13 400/220 2 315 630 PGCIL HVDC WBSETC 14 Gokarna 400/220 2 315 630 L 220 kV Level 1 160 160 220/132 1 Asansol 1 160 160 132/33 3 50 150 220/132 3 160 480 2 New Bishnupur 132/33 2 31.5 63 220/132 2 160 320 3 Dalkhola 1 31.5 31.5 132/33 2 20 40 220/132 2 160 320 4 Dharampur 132/33 2 50 100 WBSETC 2 160 320 L 220/132 5 Domjur 1 100 100 132/33 3 50 150 220/132 4 160 640 6 Gokarna 132/33 3 50 150 3 160 480 220/132 7 Howrah 1 150 150 132/25 2 20 40 2 150 300 8 Kasba 220/132 2 160 320

62 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 220/132/33 2 160 320 9 Krishnagar 2 50 100 132/33 1 31.5 31.5 220/132 3 160 480 1 31.5 31.5 10 Laxmikantpur 132/33 2 50 100 132/25 2 12.5 25 220/132 2 160 320 11 New Haldia 132/33 2 50 100 220/132 2 160 320 12 New Jalpaiguri 132/33 2 50 100 New town action 220/132 2 160 320 13 area-III 220/33 2 50 100 220/132 3 160 480 14 Rishra 132/33 4 50 200 220/132 2 160 320 15 Satgachia 2 50 100 132/33 1 31.5 31.5 220/132 2 160 320 16 Subhashgram 132/33 2 31.5 63 1 160 160 17 KTPS 400 kV 220/132 WBPDCL 2 150 300 STPS 1 130 130 18 220/132 WBPDCL (Santhaldih) 1 100 100 19 Birpara 220/132 2 160 320 1 50 370 20 Malda 220/132 PGCIL 2 160 640 21 Siliguri 220/132 2 160 320 2 160 320 22 DPL 220/132 DPL 1 100 100 Bidhannagar(Dur 23 220/132 3 200 600 gapur) 220/132 2 160 320 24 Hura 132/33 2 50 100 220/132/33 2 160 320 25 Foundry park 132/33 2 50 100 220/132 3 160 480 26 Midnapur WBSETC 132/33 2 50 100 L Kolkata leather 220/132 2 160 320 27 complex(CLC) 132/33 3 50 150 220/132 2 160 320 28 Vidyasagar Park 132/33 2 50 100 29 Sadaipur 220/132/33 2 160 320 30 Egra 200/132/33 2 160 320 31 EMSS 220/132 /33 5 160 800 CESC 32 BBGS 220/132 /33 2 160 320

63 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 33 NCSS 220/132 /33 2 160 320 220/132/33 3 150 450 34 Waria (DTPS) 132/33 3 50 150 132/25 2 25 50 Durgapur/ 2 80 160 35 220/33 Muchipara 1 50 50 220/33 2 80 160 36 Parulia 132/33 1 50 50 DVC 220/132 2 150 300 1 100 100 37 Barjora 220/33 1 80 80 1 50 50 38 Mejia 220/33 2 35 70 39 Burnpur 220/33 2 50 100 132 kV Level 132/33 3 50 150 1 Adisapthagram 132/25 2 20 40 2 16 32 132/66 2 Alipurduar 1 20 20 132/33 2 31.5 63 1 31.5 31.5 3 Amtala 132/33 1 50 50 132/33 3 50 150 4 Asoknagar 132/25 2 7.5 15 5 Bagnan GIS 132/33 2 50 100 6 Bagmundi 132/33 2 20 40 7 Balurghat 132/33 4 12.5 50 8 Bankura 132/33 2 50 100 9 Barasat 132/33 3 50 150 10 Behala/Joka 132/33 3 50 150 WBSETC 11 Basirhat 132/33 2 50 100 L 12 Belmuri 132/33 2 31.5 63 13 Berhampore 132/33 3 50 150 14 Bighati 132/33 2 50 100 15 Birsingha 132/33 2 50 100 132/33 1 50 50 16 Bishnupur (Old) 132/33 1 31.5 31.5 17 Bolpur 132/33 3 50 150 18 Bongaon 132/33 3 31.5 94.5 19 Barjora 132/33 2 31.5 63 20 Chanditala 132/33 2 50 100 Chandrakora 1 50 50 21 132/33 road 1 31.5 31.5 22 Contai 132/33 2 50 100 23 Coochbehar 132/33 3 50 150

64 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 24 Darjeeling 132/33 3 10 30 1 20 20 25 Debogram 132/33 1 31.5 31.5 1 50 50 26 Dhulian 132/33 2 31.5 63 27 Egra 132/33 3 50 150 2 31.5 63 28 Falta 132/33 1 50 50 3 20 60 29 Gangarampur 132/33 1 12.5 12.5 1 50 50 132/33 30 Haldia 1 31.5 31.5 132/25 2 30.24 60.48 31 Haldia NIZ 132/33 2 31.5 63 132/33 2 50 100 32 Hizli 132/25 2 10 20 33 Jangipara 132/33 2 31.5 63 1 31.5 31.5 34 Jhargram 132/33 1 50 50 35 Kurseong 132/33 3 10 30 36 Kakdwip 132/33 2 31.5 63 MVA rating not 37 Kalingpong 132/66 given 38 Kalan 132/33 2 31.5 63 1 31.5 81.5 39 Kalyani 132/33 1 50 150 40 Khatra 132/33 2 50 100 1 31.5 31.5 41 Katwa 132/33 2 50 100 42 Khanyan 132/33 2 31.5 63 Kharagpur 43 132/33 2 31.5 63 WBIIDC 44 Khejuria GIS 132/33 2 50 100 132/33 3 50 150 45 Kolaghat 132/25 2 12.5 25 46 Lalgola 132/33 2 31.5 63 132/33 3 50 150 47 Lilooah 132/25 2 20 40 1 31.5 31.5 48 Mahachanda 132/33 2 50 100 1 50 50 49 Mathabhanga 132/33 1 31.5 31.5 50 Malda 132/33 3 50 150 51 Mankar 132/33 3 31.5 94.5 1 31.5 31.5 52 Maynaguri 132/33 1 50 50

65 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 2 30 60 North Bengal 2 31.5 63 53 132/33 university (NBU) 1 50 50 54 Najirpur 132/33 2 31.5 63 55 New town AA 1 132/33 2 50 100 56 Pingla 132/33 3 50 150 2 31.5 63 132/33 57 Purulia (WB) 1 20 20 132/25 2 12.5 25 2 31.5 63 58 Raghunathganj 132/33 2 50 100 59 Raghunathpur 132/33 2 31.5 63 1 31.5 31.5 60 Raigunj 132/33 2 20 40 2 12.5 25 61 Raina 132/33 3 50 150 62 Rampurhat 132/33 2 50 100 132/33 2 50 100 132/66 2 31.5 63 63 Ranaghat 1 12.5 12.5 132/25 1 10 10 64 Sainthia 132/33 2 50 100 65 Salt lake 132/33 3 50 150 66 Salt lake GIS 132/33 2 50 100 2 31.5 63 67 Samsi 132/33 1 50 50 68 Siliguri 132/33 2 50 100 132/33 3 31.5 94.5 69 Sonarpur 132/25 2 20 40 70 Serakol 132/33 2 50 100 71 Tamluk 132/33 2 50 100 1 31.5 31.5 72 Tarakeswar 132/33 1 50 50 132/33 3 50 150 73 Titagarh 132/25 2 20 40 74 Ukhra 132/33 2 50 100 75 Uluberia 132/33 3 50 150 76 Kuli 132/33 2 50 100 77 Birpara 132/66 3 20 60 1 20 20 132/66 78 Chalsa 1 10 10 132/33 2 20 40 79 Bajkul 132/33 2 50 100 80 Food Park 132/33 2 50 100 81 Belur 132/33 3 50 150 CESC

66 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 82 BT Road 132/33 2 75 150 1 50 50 83 B.Garden 132/33 1 100 100 84 Titagarh (TRS) 132/33 5 50 250 85 Dum Dum 132/33 2 75 150 1 75 75 86 Park lane 132/33 1 50 50 87 Jadavpore 132/33 3 75 225 88 Chakmir 132/33 2 55 110 2 75 150 89 Majerhat 132/33 1 50 50 1 68 68 90 BBD Bag 132/33 1 69 69 1 50 50 91 PRS 132/33 1 75 75 1 100 100 92 East Calcutta 132/33 3 75 225 1 50 50 93 NCSS 132/33 1 75 75 2 55 110 94 SRS 132/33 1 75 75 95 Patuli 132/33 2 75 150 96 Park Circus 132/33 2 75 150 97 WBRS 132/33 2 75 150 132/11 1 20 20 132/11 1 31.5 31.5 98 A Zone 132/33 1 31.5 31.5 132/33 1 50 50 132/11 5 31.5 157.5 99 B Zone 132/33 1 31.5 31.5 132/33 1 50 50 100 AB Zone 132/33 1 50 50 DPL 1 31.5 31.5 132/11 2 20 40 101 C Zone 1 31.5 31.5 132/33 1 50 50 132/11 2 31.5 63 102 C1 Zone 132/33 2 50 100 103 Bamunara SS 132/33 2 50 100 132/33 1 50 50 104 Kalipahari 132/33 2 80 160 105 Kharagpur 132/11 1 7.5 7.5 DVC 2 50 100 106 Burdwan 132/33 1 80 80 107 Belmuri 132/33 1 50 50

67 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Substation details Capacity Name of the Voltage Total Owned SI.No of each Substation level (kV) No. of units capacity By unit (MVA) (MVA) 1 31.5 31.5 132/25 2 25 50 108 Purulia 132/33/11 1 50 50 132/33/11 2 50 100 109 ASP 132/33 2 50 100 110 Jamuria 132/33 2 50 100 111 Howrah 132/33 3 50 150

68 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table B: State wise list of transmission lines present in eastern region grid

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type Bihar 765 kV 1 Gaya to Varanasi D/C 341.0 Quad-Bersimis 2 Sasaram to Fatehpur line I S/C 61.3 Quad-Bersimis PGCIL 3 Gaya to Ballia S/C 228.0 Quad-Bersimis 400 kV 1 Gaya to Koderma D/C 126.0 Twin-Moose 2 Gaya to Maithon D/C 272.0 Quad-Moose 3 Sasaram to Sarnath S/C 76.0 Twin-Moose 4 Sasaram to Allahbad D/C 215.0 Twin-Moose 5 Sasaram to Nabinagar D/C 81.0 Twin-Moose 6 Biharshariff to Sasaram S/C 192.0 Twin-Moose 7 Biharshariff to Sasaram S/C 203.5 Twin-Moose 8 Kahalgaon to Farakka I & II D/C 95.0 Twin-Moose 9 Kahalgaon to Farakka III & IV D/C 95.0 Twin-Moose 10 Kahalgaon to Maithon D/C 172.0 Twin-Moose 11 Biharshariff to Lakhisarai S/C 89.0 Twin-Moose 12 Biharshariff to Lakhisarai S/C 102.5 Twin-Moose 13 Lakhisarai to Kahalgaon D/C 145.0 Twin-Moose PGCIL 14 Kahalgaon to Banka D/C 48.0 Twin-Moose 15 Kahalgaon to Barh D/C 217.0 Quad-Moose 16 Biharshariff to Koderma D/C 111.0 Quad-Moose 17 Biharshariff to Banka D/C 184.0 Twin-Moose 18 Biharshariff to Balia D/C 242.0 Quad-Moose 19 Biharshariff to Muzaffarpur D/C 132.0 Twin-Moose 20 Biharshariff to Varanasi D/C 321.0 Quad-Moose 21 Biharshariff to Purnea D/C 232.0 Quad-Moose 22 Barh to Patna I & II D/C 93.0 Quad-Moose 23 Barh to Patna III &IV D/C 69.0 Quad-Moose 24 Patna to Balia D/C 195.0 Quad-Moose 25 Patna to Balia D/C 180.0 Quad-Moose 26 Patna to Kishanganj D/C 347.0 Quad-Moose 27 Muzaffarpur to Gorakhpur D/C 261.0 Quad-Moose Power Links 28 Purnea to Muzaffarpur D/C 240.0 Quad-Moose 29 Malda to Purnea D/C 167.0 Twin-Moose 30 Purnea to Binaguri I & II D/C 168.0 Twin-Moose 31 Purnea to Kishanganj D/C 72.0 Quad-Moose PGCIL 32 Kishanganj to Binaguri D/C 98.0 Quad-Moose 33 Barh II to Gorakhpur D/C 349.0 Quad-Moose 34 Muzaffarpur to DMTCL D/C 63.3 Twin-Moose DMTCL 220 kV 1 Patna PG to Sipara D/C 0.5 Zebra BSPHCL BSPHCL & 2 Dehri to Pusauli S/C 65.0 Zebra PG 3 Pusauli to Sahupuri (UP) S/C 71.0 Zebra 4 Arrah to Khagaul D/C 50.0 Zebra PGCIL

69 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

BSPHCL 5 Patratu to Bodhgaya T/C 136.0 Zebra & JSEB 6 Patna PG to Khagaul S/C 30.5 Zebra BSPHCL BSPHCL & 7 Tenughat to Biharshariff S/C 182.0 Twin-Moose JSEB Biharshariff (PG) to Biharhariff 8 T/C 1.7 Zebra BSPTCL (BSPHCL) POWER 9 Muzaffarpur to MTPS (Kanti) D/C 24.0 Zebra LINKS 10 Dehri to Gaya (PG) D/C 95.0 Zebra BSPHCL & 11 Bodhgaya to Gaya (PG) D/C 17.0 Zebra PG 12 Muzaffarpur to Hazipur - I & II D/C 53.0 Zebra 13 Biharshariff to Fatua D/C 40.0 Zebra BSPTCL 14 Biharshariff to Bodhgaya D/C 80.0 Zebra 15 Purnea to Dalkhola (WB) D/C 41.0 Zebra PGCIL 16 Sipara to Khagaul S/C 39.0 Zebra 17 MTPS (Kanti) to Gopalganj D/C 101.4 Zebra 18 MTPS (kanti) to Darbhanga S/C 68.5 Zebra 19 Purnea (PG) to Madhepura D/C 100.1 Zebra 20 Biharsariff to Begusarai D/C 75.0 Zebra 21 MTPS to Begusarai D/C 152.0 Zebra 22 Amnour(Chhapra) to Hajipur D/C 50.0 Zebra BSPTCL 23 Patna (PG) to Fatuha S/C 27.6 Zebra 24 MTPS to Motipur D/C 56.8 Zebra 25 Motipur to Mushahri D/C 88.7 Zebra 26 Motipur to DMTCL D/C 68.5 Zebra 27 Mushahri to Darbhanga D/C 57.9 Zebra 28 Sipara to Fatuha S/C 26.0 Zebra 29 Pusauli (PG) to Pusauli new S/C 1.7 Zebra 30 Pusauli new to Ara (PG) S/C 116.0 Zebra 31 Pusauli (PG) to Ara (PG) S/C 112.0 Zebra PGCIL 32 Purnea (PG) to Purnea old D/C 2.0 Zebra 33 Kishanganj to Siliguri D/C 108.0 Zebra 34 Kishanganj to Dalkhola PG D/C 31.0 Zebra 132 kV 1 Kahalgao to KhSTPP S/C 6.0 Panther PGCIL 2 KhSTPP to lalmatya S/C 47.0 Panther 3 Arrah (PG) to Arrah BS S/C 2.1 Panther 4 Arrah (PG) to Dumraon S/C 61.5 Panther BSPTCL 5 Purnea (PG) to Purnea (BS) T/C 1.3 Panther 6 Purnea (OLD) to Kishanganj S/C 70.0 Panther 7 Karmansa to Sahupuri S/C 131.0 Panther BSPHCL & 8 Karmansa to Chandauli S/C 25.0 Panther UPPCL 9 Sonenagar to Rihand S/C 188.0 Panther 10 Japla to Sonenagar S/C 56.0 Panther BSPTCL 11 Kahalgao to Sabour S/C 19.0 Panther PGCIL 12 Kahalgao to Lalmatia S/C 60.0 Panther NTPC

70 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

13 Banka to Sabour S/C 40.7 Panther 14 Banka (PG) to Banka (New) S/C 12.5 Panther 15 Chandauti to Sipara S/C 90.0 Panther 16 Chandauti to Belaganj S/C 20.0 Panther 17 Belaganj to Jehanabad S/C 30.0 Panther 18 Jehanabad to Masaudhi S/C 30.0 Panther 19 Masaudhi to Sipara S/C 24.0 Panther 20 Jehanabad to Ataula S/C 28.0 Panther 21 Chandauti to Sonenagar (L - 30) S/C 76.0 Panther 22 Chandauti to Rafiganj (L - 31) S/C 41.0 Panther 23 Rafiganj to Sonenagar (L - 31) S/C 35.0 Panther 24 Chandauti to Tekari S/C 28.9 Panther Bodhgaya to Chandauti 25 D/C 16.0 Panther (Gaya)(Line - I) Bodhgaya to Chandauti (Gaya) 26 D/C 14.0 Panther (Line - II) 27 Tekari to Goh S/C 22.0 Panther 28 Bodhgaya to Wazirganj S/C 30.0 Panther 29 Wazirganj to Nawada S/C 26.0 Panther 30 Bodhgaya to Sherghati S/C 27.0 Panther 31 Bodhgaya to Imamganj S/C 56.0 Panther 32 Dehri to Banjari S/C 38.0 Panther 33 Dehri to Sasaram Ckt. - I S/C 20.0 Panther BSPTCL 34 Sasaram to Kudra Ckt. - I S/C 13.0 Panther 35 Kudra to Karamnasa Ckt.- I S/C 10.0 Panther 36 Dehri to Pusauli PG Ckt - II S/C 26.0 Panther 37 Pusouli PG to Mohania Ckt. - II S/C 10.0 Panther 38 Mohania to Pusauli BS S/C 15.0 Panther 39 Mohania to Karmnasa Ckt. - II S/C 11.0 Panther 40 Dehri to Bikramganj Ckt. - II S/C 45.0 Panther 41 Bikramganj to Dumroan Ckt. - II S/C 35.0 Panther 42 Dumroan to Buxar S/C 16.1 Panther 43 Ara (PG) to Jagdishpur S/C 26.3 Panther 44 Fatuha to Sipara S/C 26.0 Panther 45 Sipara to Mithapur S/C 16.0 Panther 46 Mithapur to Jakkanpur S/C 1.0 Panther 47 Gaighat to Mithapur S/C 5.0 Panther 48 Fatuha to Gaighat S/C 23.0 Panther 49 Fatuha to Katra S/C 17.0 Panther 50 Biharsarif (SG) to Barh Ckt. - I S/C 25.0 Panther 51 Barh to Hathidah Ckt. - I S/C 20.0 Panther Biharsarif (SG) to Hathidah Ckt. - 52 S/C 32.5 Panther II 53 Biharsarif (SG) to Ekangarsarai S/C 30.0 Panther 54 Ekangarsarai to Hulasgarh S/C 14.5 Panther 55 Baripahari to Harnaut S/C 26.0 Panther 56 Motipur to motihari S/C 45.0 Panther

71 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Panther 57 Motipur to MTPS S/C 24.2

Panther 58 Harnaut to Fatuha S/C 45.0

Biharsarif (SG) to Barhi (DVC) (L - BSPTCL & 59 S/C 142.0 Panther 28) DVC 60 Barhi (DVC) to Rajgir (L - 29) S/C 16.0 Panther 61 Rajgir to Biharsarif (L - 29) S/C 126.0 Panther 62 Biharsarif (SG) to Nawada S/C 41.0 Panther 63 Hathidah to Lakhisarai S/C 28.0 Panther 64 Hathidah to Shekhpura S/C 28.0 Panther 65 Lakhisarai to Jamui S/C 35.0 Panther 66 Biharsarif (SG) to Shekhpura S/C 39.5 Panther 67 Shekhpura to Jamui S/C 49.0 Panther 68 Lakhisarai to Jamalpur S/C 45.0 Panther 69 Sultanganj to Jamalpur S/C 38.0 Panther 70 Sultanganj to Tarapur S/C 19.7 Panther 71 Sabour to Sultanganj Ckt I S/C 30.0 Panther 72 Sabour to Sultanganj Ckt II S/C 31.0 Panther 73 Sultanganj to Deoghar S/C 105.0 Panther 74 KhSTPP to Sabour S/C 25.0 Panther 75 Purnia(bs) to Naugachia (L - 16) S/C 70.0 Panther 76 Naugachia to BTPS (L- 16) S/C 136.0 Panther 77 Purnia(bs) to Khagaria (L - 23) S/C 150.0 Panther 78 Khagaria to BTPS (L - 23) S/C 60.0 Panther 79 Purnia(BS) to Katihar S/C 29.0 Panther 80 Purnia(BS) to Saharsa S/C 101.2 Panther BSPTCL 81 Purnia (BS) to Farbisganj S/C 85.0 Panther 82 Kishanganj to Dalkola (WB) S/C 26.0 Panther 83 Kishanganj to Farbisganj S/C 88.6 Panther Farbisganj to Kataya (Kosi) Ckt. - 84 S/C 50.9 Panther II (Old) 85 Madhepura to Saharsa S/C 50.0 Panther 86 Madhepura to Sonebarsa S/C 50.0 Panther 87 Saharsa to UdaKishanganj S/C 50.4 Panther 88 Begusarai to Samastipur (L - 9) S/C 57.0 Panther 89 Begusarai to Dalsingsarai (L - 10) S/C 34.0 Panther Dalsingsarai to Samastipur (L - 90 S/C 23.0 Panther 10) 91 KBUNL to Muzaffarpur Ckt - I S/C 15.5 Panther 92 KBUNL to Muzaffarpur Ckt - II S/C 16.7 Panther 93 KBUNL to SKMSH S/C 14.1 Panther 94 Samastipur to Darbhanga S/C 40.0 Panther Samastipur to Hazipur LILO at 95 S/C 92.0 Panther Jandaha 96 Hazipur to Sheetalpur S/C 30.0 Panther 97 Chapra to Sheetalpur S/C 40.0 Panther 98 Muzaffarpur to Vaishali D/C 30.1 Panther 99 Chapra to Siwan S/C 70.0 Panther

72 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Panther 100 Chapra/Siwan to Ekma S/C 0.6

101 Gopalganj to Hathua S/C 25.0 Panther 102 Hathua to Siwan S/C 40.0 Panther Panther 103 Gopalganj to Siwan S/C 40.0

104 Gopalganj to Masrakh to Siwan S/C 74.9 Panther 105 Gopalganj to Bettia D/C 60.8 Panther Gopalganj/Bettia Ckt- I LILO at 106 S/C 12.0 Panther Sidhwalia SM 107 Betiya to narkatiyaganj S/C 35.5 Panther 108 MTPS to Motihari S/C 70.0 Panther 109 Bettia to Motihari S/C 45.0 Panther 110 Bettia to Ramnagar S/C 41.5 Panther 111 Bettia to Raxaul D/C 37.1 Panther 112 Ramnagar to BHPC, Valmikinagar S/C 77.8 Panther BHPC, Valmikinagar to Nepal 113 S/C 7.2 Panther (Surajpura) 114 Motihari to Dhaka S/C 24.0 Panther 115 Mushahri to Sitamarhi D/C 63.0 Panther 116 Mushahri to SkMCH S/C 21.0 Panther 117 Dhaka to Sitamarhi S/C 52.0 Panther Sitamarhi to 118 S/C 21.0 Panther Runisaidpur(Reminagar) 119 Runisaidpur to SKMCH S/C 35.0 Panther 120 SKMCH to Muzaffarpur S/C 15.0 Panther Darbhanga (220 kV) to 121 S/C 1.0 Panther Darbhanga (132 kV) 122 Darbhanga to Phoolparas S/C 71.8 Panther 123 Pandaul to Madhubani S/C 16.0 Panther 124 Madhubani to Jainagar S/C 40.0 Panther 125 Jainagar to Phoolparas S/C 55.0 Panther Barauni TPS to Begusarai (L - 9 & 126 D/C 10.0 Panther L - 10) BHPC Kosi (Kataiya) to Duhabi 127 D/C 3.5 Panther (Nepal) 128 Biharshariff (BSEB) to Baripahari D/C 5.0 Panther 129 Dehri to Sonenagar D/C 14.5 Panther 130 Khagaul to Bihta D/C 14.5 Panther 131 Khagaul to Digha D/C 16.0 Panther 132 Samastipur to MTPS (Kanti) D/C 85.2 Panther 133 Sheetalpur to Vaishali D/C 30.2 Panther 134 Sonenagar to Aurangabad D/C 21.0 Panther 135 Supaul to Phulparas D/C 31.9 Panther 136 Madhepura to Supaul D/C 30.0 Panther 137 Biharshariff to Hullasgarh S/C 40.0 Panther 138 Ara to Ara TSS S/C 4.0 Panther 139 Dumroan to Dumroan TSS S/C 2.0 Panther 140 Rafiganj to Rafiganj TSS S/C 4.6 Panther

73 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type Panther Barh/Hathidah line to Mokama 141 S/C 6.0 TSS

142 Lakhisaai to Lakhisarai TSS S/C 6.0 Panther 143 Khagaul to Khagaul TSS S/C 1.0 Panther 144 Fatuha to Khusrupur TSS S/C 7.2 Panther Panther 145 Chapra to Chapra TSS S/C 1.0

146 Hazipur to Hazipur TSS S/C 2.0 Panther Lakhisari PG to Lakhisarai 147 D/C 15.3 Panther BSPTCL 148 Chandauti to Tehta D/C 15.0 Panther 149 Tehta to Jehanabad D/C 40.0 Panther 150 Sipara to Jakkanpur D/C 18.0 Panther Farbisganj to Kataya Ckt. - I 151 D/C 39.7 Panther (New) 152 Supaul to Kataya D/C 59.6 Panther 153 Samastipur to Hazipur (220 kV) D/C 70.0 Panther 154 Bodhgaya to Paharpur TSS D/C 35.0 Panther 155 Jamui to Jhajha TSS D/C 31.0 Panther 156 Lakhisari PG to Jamui D/C 25.3 Panther 157 Dehri to Kudra S/C 46.0 Panther 158 kudra to Pusauli S/C 25.0 Panther 159 Kudra to kochas S/C 27.0 Panther 160 Banjari to KCL S/C 1.0 Panther 161 Khagaul to Fatuha S/C 35.0 Panther 162 Begusarai to Khusweshthan S/C 65.5 Panther 163 Fatuha to Birpahari S/C 42.0 Panther 164 Nalanda to (L - 28) LILO Point D/C 2.0 Panther (L - 28) Line to Rajgir grid (T - 165 S/C 6.0 Panther Connection) 166 Muzaffarpur to SKMCH S/C 16.7 Panther 167 Sasaram to Banjari S/C 47.5 Panther 168 Tehata to Belaganj S/C 22.0 Panther 169 Aurangabad to Shree Cement S/C 0.8 Panther Kahalgaon (BSPTCL) to 170 D/C 63.5 Panther Sultangunj 171 Darbhanga to Gangwara GSS Panther D/C 7.3 172 Gangwara GSS to Pandaul Panther 173 Kisanganj to Forbesganj Circuit- 2 S/C 88.4 Panther 174 Forbesganj to Kataiya Circuit- 3 S/C 39.8 Panther 175 Mithapur to Karbighaia S/C 2.5 Panther 176 Dehri to Kochas S/C Panther 31.6 177 Kochas to Dumraon Circuit- 1 S/C Panther 178 Banka (PG) to Sultanganj D/C 46.0 Panther Jharkhand 765 kV 1 Ranchi (New) to Dharamjaygarh S/C 301.0 Qd Bermis PGCIL

74 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type Qd Bermis 2 Ranchi (New) to Dharamjaygarh S/C 344.6

400 kV 1 Chaibasa to Bisra (Rourkela) S/C 131.0 Twin-Moose 2 Jamshedpur to Chaibasa S/C 46.0 Twin-Moose 3 Jamshedpur to Bisra S/C 182.0 Twin-Moose 4 Jamshedpur to Mejia B S/C 168.0 Twin-Moose PGCIL 5 Jamshedpur to Maithon S/C 153.0 Twin-Moose 6 Maithon to Mejia B S/C 97.0 Twin-Moose Twin-Moose 7 Jamshedpur to DTPS D/C 156.0

8 Jamshedpur to Adhunik D/C 0.3 Quad-Moose APNRL 9 Jamshedpur to Parulia S/C 177.0 Twin-Moose 10 Jamshedpur to Baripada S/C 141.0 Twin-Moose 11 Jamshedpur to TISCO S/C 39.0 Twin-Moose 12 TISCO to Baripada S/C 116.0 Twin-Moose 13 Maithon to Maithon RB D/C 31.0 Twin-Moose 14 Maithon to Kahalgaon D/C 172.0 Twin-Moose 15 Maithon to Mejia B D/C 84.0 Twin-Moose 16 Maithon to Gaya D/C 277.0 Quad-Moose 17 Maithon to Durgapur D/C 70.7 Lapwing 18 Ranchi to Maithon RB D/C 188.0 Twin-Moose 19 Ranchi to Maithon S/C 200.0 Twin-Moose PGCIL 20 Ragunathpur to Maithon S/C 52.9 Twin-Moose 21 Ranchi to Raghunathpur S/C 169.2 Twin-Moose 22 Ranchi to Sipat D/C 405.0 Twin-Moose 23 Ranchi to Rourkela D/C 145.0 Twin-Moose 24 Ranchi to Ranchi (New) 2XD/C 78.6 Quad-Moose Ranchi (New) to Chandwa (JK 25 D/C 69.0 Quad-Moose Pool) 26 Koderma to Gaya D/C 82.0 Quad-Moose 27 Koderma to Biharshariff D/C 111.0 Quad-Moose 28 Koderma to BTPS D/C 100.0 Twin-Moose Jharkhand pooling station 29 D/C 117.0 Quad-Moose (Chandwa) to Gaya 220 kV 1 Farakka to Lalmatia S/C 79.0 Zebra PGCIL OPTCL & 2 Ramchandrapur to Joda S/C 130.0 Zebra JSEB WBSETCL 3 Chandil to Santadih (STPS) S/C 98.0 Zebra & JSEB Jamshedpur PG to 4 D/C 0.1 Zebra Ramchandrapur 5 Ramchandrapur to Chandil S/C 30.0 Zebra 6 Chandil to Ranchi PG S/C 78.4 Zebra 7 Tenughat to Patratu S/C 64.0 Double Moose JUSNL 8 Tenughat to Biharsharif S/C 180.0 Double Moose 9 Ranchi PG to Hatia new D/C 35.0 Zebra Zebra 10 PTPS to Hatia new D/C 42.0

75 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Dumka to Rupnarayanpur PG 11 D/C 74.0 Zebra (Maithon PG)

12 Chaibasa PG to Chaibasa D/C 0.7 Zebra BSPHCL & 13 PTPS to Bodhgaya T/C 136.0 Zebra JSEB 14 BTPS (DVC) to Ramgarh D/C 54.6 Zebra 15 BTPS to CTPS Old D/C 31.8 Zebra 16 CTPS B (New) to Dhanbad D/C 45.6 AAAC Zebra 17 Jamshedpur DVC to BTPS D/C 150.0 Zebra 18 Dhanbad to Kalyanaswari D/C 79.2 Zebra Zebra DVC 19 CTPS A (Old) to Kalyanaswari D/C 141.8

20 Dhanbad to Giridih D/C 44.4 AAAC Zebra 21 Jamshedpur DVC to Jindal (Joda) S/C 135.0 Zebra 22 CTPS A (Old) to CTPS B (New) D/C 2.6 AAAC Zebra 23 Giridhi to Koderma D/C 100.9 AAAC Zebra 24 Dhanbad to Electro Steel D/C 58.6 AAAC Zebra PGCIL 25 BSL to CTPS A D/C 9.0 AAAC Zebra DVC 132 kV 1 ABCIL to Garhwa S/C 2.0 Panther 2 Adityapur to Ramchandrapur D/C 8.3 Panther 3 Chakradharpur to Rajkharsawan D/C 22.0 Panther 4 Chandil 220 kV to Rajkharsawan S/C 34.5 Panther Rajkharsawan to Chaibasa 132 5 S/C 20.0 Panther kV 6 Chandil 220 kV to Adityapur S/C 16.0 Panther 7 Chandil 220 kV to Golmuri D/C 30.0 Panther 8 Chandil 220 kV to Chandil 132 kV S/C 1.0 Panther 9 Deoghar to Sultanganj S/C 92.0 Panther 10 Deogarh to Jamtara D/C 75.0 Panther 11 Jamtara to Madupur D/C 54.0 Panther 12 Deoghar to Shankarpur Rly S/C 11.0 Panther JUSNL 13 Deoghar to Dumka 220 kV D/C 68.0 Panther 14 Dumka 132 kV to Lalmatiya D/C 96.0 Panther 15 Goielkera to Goielkera Rly S/C 0.5 Panther 16 Goielkera to Rajkharsawan S/C 55.0 Panther 17 Gumla to Kamdara S/C 62.0 Panther 18 Kamdara to Hatia Old S/C 61.0 Panther 19 Garhwa to Japla S/C 50.0 Panther 20 Hatia old to Sikadari S/C 46.0 Panther 21 Hatia old to HEC D/C 8.0 Panther 22 Hatia New to Lohardanga D/C 62.0 Zebra 23 Chaibasa 132 kV to Kendposi S/C 30.0 Panther 24 Jadugoda to Golmuri S/C 22.0 Panther POWERGRI 25 Lalmatia to Kahalgaon TPP S/C 47.0 Panther D 26 Kendposi to Noamndi S/C 28.0 Panther JSEB

76 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

JUSNL & 27 Kendposi to Joda S/C 42.0 Panther OPTCL 28 Lalmatia to Sahebgunj S/C 49.0 Panther 29 Lohardanga to Latehar D/C 56.0 Zebra JUSNL 30 Latehar to Daltonganj D/C 64.0 Zebra DVC & 31 Maithon DVC 132 kV to Jamtara S/C 25.0 Panther JSEB 32 PTPS to Hatia Old S/C 44.0 Zebra 33 Hatia old to Kanke S/C 28.0 Zebra 34 Kanke to PTPS S/C 28.0 Zebra 35 Rajkharsawan to Adityapur S/C 36.0 Panther 36 Saljhagiri Rly to Golmuri S/C 4.0 Panther Panther Sikkidri (pooling point of SHPS) to 37 S/C 34.0 Namkum

38 Namkum to Hatia new S/C 27.0 Panther JUSNL 39 Sonenagar to Japla S/C 49.6 Panther 40 Tolra Rly to Garhwa S/C 8.0 Panther 41 UMI to Adityapur D/C 3.5 Panther 42 Gumla to Lohardaga D/C 71.0 Zebra 43 Dumka to Pakur S/C 85.0 Panther Ramchanderpur to APL (Odisha 44 S/C 4.0 Panther minerals) 45 DVM to DVM Railway D/C 0.5 Panther JSEB & 46 PTPS to Patratu DVC D/C 6.4 Panther DVC 47 Chandil 220 kV to Tamar S/C 50.0 Panther JUSNL JSEB & 48 Garwa to Rihand S/C 106.0 Panther UPPCL 49 Hatia New to Hatia Old D/C 0.5 Panther 50 Kamdara to Bakaspur Rly S/C 15.0 Panther 51 Kamdara to Bano Rly S/C 35.0 Panther 52 Kendiposi FD Stn to Kendiposi D/C - Panther 53 Lodhma Rly to Hatia Old D/C 15.0 Panther 54 Namkum to Tatisiloi Rly D/C 15.0 Panther 55 Noamundi to Kendiposi FD STN S/C - Panther JUSNL 56 Goelkera to Manoharpur S/C 10.0 Panther Sikkidri (Pooling point of SHPS) to 57 S/C 1.0 Panther SHPS - 1 Sikkidri (pooling point of SHPS) to 58 S/C 7.0 Panther SHPS - 2 59 Dumka 220 kV to Dumka 132 kV D/C 2.0 Panther BSPHCL & 60 Lalmatia to Sabour S/C 46.6 Panther JSEB 61 Chandil to Manique (JSEB) D/C 1.0 Panther JSEB/DVC 62 Chandil to JUSCO No details available 63 Maithon (MHS) to Jamtara S/C 30.0 Lark DVC/JSEB 64 Barhi to Rajgir S/C 149.0 Lark Lark DVC 65 Barhi to Nalanda S/C 138.0

77 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

66 PTPS to Patratu DVC D/C 12.5 Lark 67 Patratu to JSPL No details available

68 Barhi to Hazaribhag D/C 36.5 Lark 69 Barhi to KTPP D/C 20.1 Lark 70 BTPS B to ECR Gomia D/C 6.9 AAAC Panther 71 BTPS B to Barhi D/C 82.0 Panther 72 BTPS B to Konar S/C 23.0 Lark 73 Barhi to Konar S/C 61.0 Panther 74 CTPS A to Gola D/C 36.0 Lark D/C 29.0 Lark 75 CTPS B to Putki D/C 30.0 Lark DVC 76 CTPS A to Purulia DVC D/C 59.6 Lark 77 CTPS A to Ramkanali S/C 60.0 Lark AAAC Panther 78 Ramkanali to DTPS S/C 73.0

79 BSL to CTPS A D/C 10.0 Lark 80 BSL (MSDS) to CTPS A D/C 10.0 Lark 81 Gola to Manique (DVC) D/C 86.1 Lark 82 Jamshedpur to Chandil D/C 43.7 Lark 83 Jamshedpur (DVC) to Mosabani D/C 39.6 Lark DVC 84 Jamshedpur to TISCO No details available

85 KTPP to Koderma D/C 18.3 Lark 86 Koderma JSEB to Koderma DVC D/C 18.3 ACSR Panther 87 Konar to Hazaribhag Road D/C 35.0 Lark DVC 88 Nimiaghat to Putki D/C 45.0 AAAC Panther 89 Nimiaghat to Giridhi (New) D/C 43.6 AAAC Panther 90 Giiridhi (New) to Giridhi (Old) No proper data available

91 Patherdhi to Putki D/C 22.6 Lark 92 Patherdhi to Sindri D/C 3.2 Lark 93 Pradhankhanda to Sindri D/C 20.0 Lark 94 Patherdhi to Maithon (MHS) D/C 41.0 AAAC Panther 95 Ramgarh to Gola D/C 25.3 Lark 96 Gola to SER Muri D/C 30.3 Lark 97 Ramkanali to Panchet D/C 14.5 Lark Jamshedpur (DVC) to Purulia 98 D/C 87.0 Lark DVC 99 Kalipahari to Kalyanswari D/C 28.8 Lark DVC Kalyanswari to MAL IMPEX 100 S/C 1.5 AAAC Panther FERRO Mosabani to JSEB 101 D/C 10.7 Lark (Dhalbhumgarh) 102 Maithon (MHS) to Kumardubi S/C 4.9 Lark 103 Kumardubi to Panchet S/C 9.6 Lark 104 Ramgarh to ECR Barkakana S/C 10.0 Panther 105 Dhanbad to Govindpur D/C 24.0 AAAC Panther 106 Ramgarh to Patratu S/C 30.4 Lark 107 Ramgarh to Patratu S/C 28.0 Lark

78 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

108 North Karnpura to Patratu D/C 32.0 Lark 109 North Karnpura to E.C.Rly D/C 4.5 Lark 110 Putki to Balihari 132 kV S/C 0.5 Lark 111 Patherdih to Balihari S/C 24.0 Lark 112 CTPS B to Biada R/S D/C 12.1 AAAC Panther 113 CTPS A to Rajabera D/C 4.9 Lark 114 CTPS B to Jamuria S/C 119.2 Lark 115 Maithon (MHS) to Panchet S/C 14.5 Lark 116 Maithon (MHS) to Kalyanaswari D/C 1.6 Lark Odisha 765 kV Jharsuguda pooling station to ACSR Hexa- 1 D/C 151.0 Dharamjaygarh ZEBRA ACSR Quad 2 Angul to Srikakulam D/C 276.0 PGCIL Bersimis Angul to Jharsuguda pooling ACSR Quad 3 D/C 272.0 station Bersimis 400 kV ACSR Moose 1 Jaypore to Bolangir PGCIL S/C 287.7

PGCIL 2 Bolangir PGCIL to Angul S/C 198.0 Twin Moose 3 Angul to Meramundali - I S/C 25.0 Twin Moose 4 JITPL to Angul D/C 68.0 Twin Moose Jindal 5 TSTPS to Angul S/C 68.0 Twin Moose 6 Angul to Meramundali - II S/C 18.0 Twin Moose PGCIL 7 TSTPS to Meramundali S/C 52.3 Twin Moose 8 GMR to Angul D/C 30.0 Quad Moose GMR 9 Meramundali to JSPL D/C 37.9 Twin Moose OPTCL 10 Meramundali to Vedanta (Sterlite) D/C 222.0 Twin Moose PGCIL 11 GMR to Meramundali S/C 8.5 Twin Moose 12 Meramundali to Mendhasal S/C 106.0 Twin Moose OPTCL 13 Meramundali to New Duburi D/C 97.0 Twin Moose 14 TSTPS to Rengali D/C 24.0 Twin Moose PGCIL 15 Baripada to Keonjhar S/C 156.3 ACSR Moose OPTCL 16 Keonjhar PGCIL to Rengali S/C 100.3 Twin Moose OPTCL WBSETCL 17 Baripada to Kharagpur S/C 100.3 ACSR Moose & OPTCL 18 Baripada to Jamshedpur S/C 141.0 ACSR Moose 19 Baripada to TISCO (DVC) S/C 115.0 ACSR Moose PGCIL Baripada to Pandiabil 295.0 20 S/C ACSR Moose Pandiabil to Mendhasal 25.0 21 Baripada to Duburi S/C 190.3 ACSR Moose Dubri to Pandiabil 130.0 OPTCL 22 S/C Twin Moose Pandiabil to Mendhasal 25.0 23 Bisra to TSTPS D/C 171.0 Twin Moose 24 Bisra to Ranchi D/C 145.0 ACSR Moose PGCIL ACSR Moose 25 Bisra to Chaibasa S/C 131.5

79 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

26 Bisra to Sterlite S/C 135.0 ACSR Moose PGCIL& 27 Sterlite to Raigarh S/C 147.0 Twin Moose Sterlite 28 Bisra to Raigarh S/C 230.4 ACSR Moose ACSR Twin 29 Bisra to Jharsuguda D/C 145.3 Moose ACSR Twin 30 Jharsuguda to Raigarh S/C 110.0 Moose ACSR Twin PGCIL 31 Jharsugud to Indbarath S/C 62.6 Moose 32 Ind Bharath to Raigarh S/C 91.0 Twin Moose 33 Indravati PG to Rengali S/C 356.0 ACSR Moose 34 Indravati PG to Jaypore S/C 72.0 ACSR Moose 35 Indravati PG to Indravati OHPC S/C 4.0 ACSR Moose OPTCL 36 Jaypore to Gazuwaka D/C 225.0 AAAC Double 37 TSTPS to Kolar 1450.0 HVDC PGCIL pole 38 Bishra to Jamshedpur S/C 181.4 ACSR Moose 220 kV LILO of Balasore to Duburi new 1.4 S/C line at Bhadrak 70.0 1 Zebra Balasore to Bhadrak S/C

Bhadrak to New Duburi S/C 70.0 OPTCL 2 Balasore to Baripada D/C 77.0 Zebra 3 Budhipadar to Raigarh S/C 81.0 Zebra 4 Budhipadar to Korba D/C 183.0 Zebra 5 Budhipadar to ITPS D/C 25.3 AAAC MOOSE 6 Budhipadar to ITPS D/C 25.3 AAAC MOOSE 7 Budhipadar to Vedanta D/C 16.8 ACSR MOOSE Vedanta 8 Budhipadar to Bhusan D/C 14.9 Zebra 9 Budhipadar to SPS D/C 7.1 Zebra 10 Budhipadar to Basundhara S/C 35.8

Budhipadar to Lapanga D/C 25.0 11 Zebra Lapanga to Katapalli D/C 51.0 12 Budhipadar to Tarkera D/C 102.0 Zebra OPTCL 13 Budhipadar to Aditya Aluminum D/C 20.5 Zebra 14 Balimela to Upper Silleru S/C 24.7 Zebra 15 Balimela to Balimela SC S/C 0.2 Zebra 16 Duburi to New Duburi D/C 6.4 Zebra 17 Duburi to NINL (Nilachal) S/C 5.5 Zebra 18 New Duburi to Paradeep D/C 113.3 ACSR+AAAC 19 New Duburi to JSL D/C 4.8 Zebra JSL New Duburi to Maithan Ispat 20 S/C 4.8 Zebra MINL Nigam Limited 21 New Duburi to Rohit S/C 4.8 Zebra Rohit 22 New Duburi to Balasore S/C 137.9 Zebra OPTCL 23 New Duburi to Visa S/C 10.5 Zebra Visa 24 New Duburi to Tata steel D/C 4.0 Zebra

80 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

25 Meramundali to Dubri D/C 95.6 ACSR Zebra 26 Meramundali to TSTPS D/C 42.0 ACSR Zebra 27 Meramundali to TTPS D/C 11.2 ACSR Zebra 28 Meramundali to NALCO D/C 11.5 ACSR Zebra 29 Meramundali to Bhusan steel D/C 2.4 ACSR Zebra 30 Meramundali to Bhanja nagar D/C 139.0 ACSR Zebra Mendhasal to Bhanja nagar S/C 135.0 31 Mendhasal to Nayagarh S/C 69.0 Zebra Nayagarh to Bhanja nagar S/C 68.6 6.04 & 32 Mendhasal to Chandaka 4 ACSR Zebra 7.26 33 Meramundali to Bidanasi S/C 92.3 Twin Moose 34 Bidanasi to Mendhasal S/C 31.1 Mendhasal to Atri D/C 16.0 Zebra 35 Atri to Narendrapur S/C 120.0 Zebra 36 Theruvali to Bhanja nagar D/C 171.5 Zebra 37 Theruvali to Narendrapur D/C 196.0 Zebra 38 Theruvali to Indravati D/C 86.0 AAAC Zebra 39 Theruvali to Indravati D/C 91.0 AAAC Zebra Zebra

40 Theruvali to Upper Kolab S/C 123.0

Jaynagar to Laxmi pur S/C 53.5 41 Laxmi pur to Theruvali S/C 70.0 Zebra OPTCL Theruvali to Jaynagar S/C 123.0 42 Jaya nagar to Upper Kolab D/C 6.0 Zebra Jaya nagar to Jaya nagar PGCIL 43 D/C 7.7 Zebra (Jaypore) 44 Jaya nagar to Balimela S/C 92.0 Zebra 45 Jaya nagar to Balimela D/C 93.0 Zebra 46 Joda to TTPS D/C 154.0 Zebra 47 Joda to chaibasa S/C 90.0 Zebra Joda to JSPL S/C 12.0 48 Zebra JSPL to Jamshedpur (DVC) S/C 126.0 49 Joda to TSIL S/C 7.3 Zebra 50 Joda to Ramchandrapur S/C 130.0 Zebra Katapalli to Bolangir D/C 117.8 51 Zebra Bolangir to Bolangir PG S/C 3.0 52 Laxmi pur to Aditya Alumina D/C 16.9 Zebra 53 Laxmi pur to Utkal Alumina D/C 14.1 Zebra 54 Paradeep to Essar steel D/C 9.0 Zebra 55 Paradeep to IOCL S/C 6.2 Zebra 56 Rengali PH to TSTPS S/C 29.5 Zebra 57 TSTPS to TTPS S/C 34.5 Zebra Rengali PH to TTPS S/C 70.0 Zebra 58 Rengali PH to NALCO S/C 62.7

NALCO to TTPS S/C 8.6

81 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Rengali Switching Station to 59 D/C 1.0 Zebra Rengali PG Rengali Switching Station to 60 D/C 5.0 Zebra Rengali PH Rengali Switching Station to S/C 34.7 61 Barkot Zebra Barkot to Tarkera S/C 115.0 Rengali Switching Station to S/C 102.0 62 Chandiposh Zebra Chandiposh to Tarkera S/C 30.0 63 Tarkera to Bisra PG D/C 15.0 Zebra 64 Tarkera to RSP D/C 10.0 Zebra 65 Vedanta to SEL D/C 6.0 Zebra Atri to Pandiabil (Uttara) D/C 22.0 Zebra 66 Pandiabil (Uttara) to Samangara D/C 45.9 Zebra 67 Cuttack to Bidanasi D/C 7.4 Zebra 132 kV 1 Angul to MCL Nandira D/C 10.8 Panther 2 Angul to Boinda S/C 38.5 Panther 3 Angul to Chainpal S/C 14.9 Panther Panther

4 Angul to TTPS S/C 16.0

LILO of TTPS to Duburi S/C line at Jambay 0.7 Ferro Alloys 5 TTPS to Jambay Ferro Alloys 45.0 Panther S/C Jambay Ferro Alloys Duburi 8.0

LILO of ICCL to Salipur S/C line at OCL 25.8 ICCL to Mania 22. 6 Panther OPTCL Mania to OCL S/C 5.0 OCL to Salipur 35.0 LILO at Kamakhyanagar 1.0

LILO at Kalarangi 13.0

LILO at OPCL 23.0

7 TTPS to OPCL 24.0 Panther Kamakshya Nagar to OPCL 40.0 S/C Kalarangi to Kamakhyanagar 36.0 Duburi to Kalarangi 20.0 8 Chainpal to FCI D/C 7.0 Panther 9 Chainpal to Meramundali D/C 7.8 Panther 10 Chainpal to TTPS 3 3.0 Panther LILO of Chandaka to Choudwar S/C line at 6.8 11 Bidanasi Panther Choudwar to Bidanasi S/C 8.6

82 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Bidanasi to BPPL 35.0 BPPL to Chandaka 10.0 Choudwar to Kendrapara Road 12 S/C 4.6 Panther (Traction) LILO at Rawmeet 8.8 LILO at Nuapatna Tap - LILO at Arati steel 11.0 13 Meramundali to Arati steel 66.0 Panther Nuapatna Tap Arti Steel 20.0 S/C Arti Steel to Rawmet 22.3 Choudwar to Rawmet 27.5 LILO at Maheswari 4.9 LILO at ICCL - Dhenkanal to Maheswari 28.0 14 Panther Maheswari to ICCL 23.5 S/C ICCL to Grid Steel (GSAL) 2.0 Grid Steel (GSAL) to Choudwar 1.9 15 Dhenkanal to Meramundali S/C 43.8 Panther 16 Dhenkanal to Joranda traction S/C 19.4 Panther LILO at Ranasinghpur 1.3 LILO at Kesura - Chandaka to Ranasinghpur 23.6 17 Panther 26.4 Ranasinghpur to Kesura S/C

Kesura to Nimpara 43.2 18 Chandaka to Nimpara S/C 62.0 Panther Chandaka to Mendhasal S/C 36.5 Panther 19 Mendhasal to Khurda S/C 36.5 Panther 20 Chandaka to Bhubaneswar D/C 5.5 Panther LILO of Bhubaneswar to Cuttack S/C line at - Phulnakhara 21 Panther Bhubaneswar to Phulnakhara 23.5 S/C Phulnakhara to Cuttack 20.0 22 Cuttack to Jagatsinghpur S/C 35.2 Panther 23 Jagatsingpur to Paradeep S/C 56.1 Panther Jagatsingpur to Gorakhnath 24 S/C 16.2 Panther (Traction) 25 Nimpara to Konark S/C 20.3 Panther 26 Puri to Nimpara S/C 30.0 Panther Puri to Samangara S/C 15.0 27 Panther Samangara to Nimpara S/C 20.0 Khurda to Arugul Tap S/C 15.0 Arugul Tap to Arugul S/C 3.9 28 Panther Arugul Tap to Shamukh S/C 35.6 Shamukh to Puri S/C 18.6 29 Khurda to Kaipadar traction S/C 11.5 Panther

83 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type LILO at Balugaon 9.1 LILO at Chandpur 2.3 Khurda to Balugaon T 68.6 Panther Balugaon T to Chandapur 5.0 30 Chandapur to Balugaon 30.0 Balugaon to Chatrapur S/C 54.2 Balugaon T to Atri 18.0 Argul to Atri 19.4 Atri to Baki 19.6 31 Balugaon T to Narendrapur S/C 86.0 Panther 32 Balugaon to Solari Rly S/C 15.0 Panther 33 Chatrapur to Ganjam S/C 12.0 Panther 34 Chatrapur to IRE D/C 5.8 Panther 35 Chatrapur to Narendrapur D/C 13.9 Panther Panther 36 Chatrapur to Rambha Traction S/C 28.9

37 Chatrapur to Aska S/C 43.8 Panther LILO of Aska to Chatrapur S/C line at 2.5 Purusottampur 38 Panther Chatrapur to Purusottampur 22.0 S/C Purusottampur to Aska 24.0 39 Aska to Bhanja nagar D/C 33.0 Panther 40 Bhanja nagar to Phulbani S/C 86.6 Panther 41 Aska to Berhampur S/C 34.0 Panther Panther

42 Berhampur to Narendrapur D/C 11.0

LILO of Berhampur to Mohanan S/C at 1.9 Digapahandi 43 Panther Berhampur to Digapahandi 39.0 S/C Digapahandi to Mohanan 19.0 Narendrapur to Jagannathpur 44 S/C 0.5 Panther traction LILO of Rayagada to Mohana S/C line at - Akhusinghi 45 Panther Rayagada to Akhusinghi 65.0 S/C Akhusinghi to Mohana 55.0 46 Akhusinghi to Parlakemundi S/C 76.9 Panther 47 Rayagada to VVC Ferro (JESCO) S/C 0.3 Panther 48 Rayagada to Jayanagar S/C 108.0 Panther 49 Rayagada to Theruvali S/C 20.0 Panther 50 Theruvali to IMFA S/C 2.0 Panther 51 Theruvali to J.K. paper S/C 9.7 Panther LILO of Kesingh to Theruvali S/C line at 12.4 Vedanta Aluminum 52 Panther Theruvali to Vedanta Aluminum 63.7 S/C Vedanta Aluminum to Kesingh 59.4

84 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 53 Jayanagar to Tentulikhunti S/C 54.6 Panther 54 Jayanagar to Meenakshi S/C 53.2 Panther 55 Jayanagar to Machukhand S/C 43.0 Panther Jayanagar to Machukhand (RE 148.0 line) Jayanagar to Jayanagar Traction 0.5 Jayanagar Traction to Maliguda 12.0 traction 56 S/C Panther Maliguda traction to Manbar 17.7 traction Manbar traction to Machukhand 37.0 road Machukhand road to Machukhand 50.0 Jayanagar to Damanjodi 45.0 57 S/C Panther Damanjodi to Sundarbeda 13.0 58 Jayanagar to Sunabeda S/C 40.0 Panther Panther Jayanagar Traction to Ch Kusumi 59 S/C 20.0 Traction

60 Sunabeda to HAL S/C 0.7 Panther 61 Machukhand to Vizag D/C 45(160) Lark Machukhand road to Padwa 62 S/C 20.0 Panther Traction 63 Dabugaon to Tentulikhunti S/C 43.2 Panther 64 Dabugaon to Umerkote S/C 45.9

LILO of Kesinga to Junagarh S/C line at 6.6 Bhawanipatna 65 Panther Kesinga to Bhawanipatna 43.0 S/C Bhawanipatna to Junagarh 37.4 66 Kesinga to Khariar S/C 58.5 Panther Panther 67 Kesinga to Powmax (Turla) S/C 14.5

Kesinga to Saintala S/C 40.0 Panther 68 Saintala to Bloangir Old S/C 33.0 Panther 69 Khariara to Naupara S/C 77.2

LILO of Bolangir to Patnagarh S/C line at 0.5 New Bolangir 70 Panther Bolangir to New Bolangir 3.0 S/C New Bolangir to Patnagarh 39.8 71 Bolangir to Bolangir New S/C 3.0 Panther LILO of New Bolangir to Bargarh S/C line at Barpali 72 Barpali to Bargarh 26.0 Panther S/C New Bolangir to Barpali 60.0 Panther 73 Bolangir to Sonepur S/C 54.0 Panther 74 Sonepur to Boudh S/C 51.1 Panther 75 Patnagarh to Padampur S/C 44.6 Panther 76 Baragarh to ACC S/C 3.0 Panther LILO of Chiplima to Bargarh S/C line at 12.7 77 Katapali Panther Chiplima to Katapali S/C 16.4

85 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type

Katapali to Bargarh 38.5 78 Burla to Chiplima D/C 20.0 Panther LILO at Katapali 8.5 LILO at Rairakhole 0.5 Burla to Katapali 11.1 79 Katapali to Rairakhole Tap 85.2 Panther Rairakhole Tap to Sambalpur S/C 0.4 Rairakhole Tap to Rairakhole 65.3 Rairakhole to Boinda 89.9 80 Burla to Hindalco D/C 8.3 Panther LILO at Sambhalpur 0.5 LILO at Shyam DRI 29.4 LILO at Aryan ispat 6.9 81 Burla to Sambalpur 19.9 Panther Sambalpur to Shyam DRI 33.0 S/C 10.0 Shyam DRI to Aryan Steel

82 Aryan Steel to Lapanga S/C 5.0

Lapanga to SMC 12.0 Panther

SMC to Kuchinda 53.3 Panther

Kuchinda to Rajgangpur 100.7 Panther

83 Burla to Rajganpur Tap to Bamra S/C 5.0 Panther traction Rajgangpur to Trakera 28.4 Panther

Trakera to Raurkela 3.0 Panther

Lapanga to Burla D/C 57.3 Panther 84 Bhudipadar to Lapanga D/C 16.4 Panther 85 Bhudipadar to Sundargarh D/C 29.9 Panther 86 Bhudipadar to Brajaraj Nagar S/C 11.7 Panther Panther 87 Bhudipadar to MSP S/C 0.6

88 Bhudipadar to Jharsuguda S/C 7.0 Panther LILO of Bhudipadar to Tarkera S/C Line at 1.2 Rajgangpur 89 Panther Bhudipadar to Rajgangpur 81.0 S/C Rajgangpur to Tarkera 29.0 Bhudipadar to Kalugaon S/C 95.0 Panther 90 OPTCL Kalugaon to Tarkera S/C 15.0

91 Bhudipadar to MCL D/C 23.0 Panther Jharsuguda to Jharsuguda 92 S/C 0.2 Panther Traction 93 Jharsuguda to Action ispat S/C 1.6 Panther 94 Jharsuguda to L&T D/C 15.7 Panther 95 Rajgangpur to OCL S/C 0.5 Panther Rajgangpur to Rajgangpur 96 D/C 2.1 Panther Traction 97 Tarkera to Rourkela D/C 3.0 Panther 98 Tarkera to RSP 3 11.0 Panther

86 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 99 Tarkera to Chhend D/C 6.2 Panther 100 Chhend to NugaonTraction S/C 36.0 Panther 101 Chhend to Adhunik S/C 21.0 Panther 102 Adhunik to Sriganesh S/C 2.0 Panther LILO at Barbil 1.4 LILO at Arya 0.5 LILO at Beekey 2.4 LILO at Bolain 7.9 Rourkela to Bhalulata Tap 27.0 Bhalulata Tap to Beekay Steels 14.0 Beekay Steels to Nalda 103 14.0 Panther Nalda to Nalda Traction Nalda to Barbil 8.0 S/C Barbil to Arya Iron 10.0 Arya Iron to Bolani 12.0 Bolani to Joda 25.0 3.7 Bhalulata top to Bhalulata traction

104 Joda to Kenduposi S/C 50.0 Panther 105 Joda to Bansapani S/C 3.0 Panther 106 Joda to FAP Joda S/C 1.0 Panther 107 Arya iron to BRPL S/C 9.0

LILO at Karanjia 23.5 LILO at Polasapanga 18.0 108 Karenjia to Rairangpur 72.5 Panther Polasapanga to Karenjia S/C 90.0 Joda to Polasapanga 55.0 OPTCL 109 Polasapanga to Keonjhargarh S/C 19.4 Panther 110 Rairangpur to Kuchei S/C 66.1 Panther 111 Kuchei to Baripada S/C 11.0 Panther 112 Baripada to Balasore S/C 57.3 Panther 113 Balasore to Birla Tyre S/C 3.0 Panther Panther Balasore to Somanthpur S/C 3.0 114 Somanthpur to Emami S/C 1.5 Panther 115 Balasore to Balasore Traction S/C 3.6 Panther 116 Balasore to Balasore Alloys S/C 6.0 Panther LILO of Balasore to Jaleswar S/C line at 0.5 Basta 117 Panther Balasore to Basta 24.5 S/C Basta to Jaleswar 32.5 LILO of Balasore to Bhadrak S/C line at 1.0 Soro 118 Panther Balasore to Soro 34.8 S/C Soro to Bhadrak 40.3 119 Jaleswar to Jaleswar Traction S/C 2.0 Panther 120 Bhadrak to Dhamara Traction S/C 36.0 Panther 121 Bhadrak to Dhamara Port S/C 65.0 Panther

87 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 122 Bhadrak to FACOR S/C 4.6 Panther 123 Bhadrak to Bhadrak Traction S/C 8.5 Panther LILO of Bhadrak to Jajpur road S/C at 10.5 Jajpur Town 124 Panther Jajpur road to Jajpur Town 28.0 S/C Jajpur Town to Bhadrak 38.0 125 Jajpur Road to Anadapur S/C 29.4 Panther 126 Jajpur Road to Kendrapara S/C 63.0 Panther LILO of Jajpur Road to Kendrapara S/C line 1.6 at Chandikhole 127 Panther Jajpur Road to Chandikhole 32.0 S/C Chandikhole to Kendrapara 34.1 128 Jajpur Road to Duburi D/C 13.0 Panther 129 Kendrapara to Pattamundai S/C 19.5 Panther 130 Kendrapara to Paradeep S/C 34.8 Panther Kendrapara to Marshghai 12.0 Panther 131 S/C 31.5 Marshghai to Paradeep Panther

132 Paradip to IFFCO D/C 7.2 Panther 133 Paradip to PPT D/C 7.7 Panther 134 Paradip to PPL D/C 6.2 Panther 135 Duburi to MISRILAL (MSL) S/C 9.0 Panther 136 Duburi to MESCO S/C 5.0 Panther LILO of Duburi to MESCO S/C line at BRPL 2.8 137 Duburi to BRPL 4.0 Panther S/C BRPL to MESCO 6.5 138 Duburi to Jakhpur Traction S/C 13.2 Panther LILO of Duburi -TISCO (Bamanipal) S/C Line at B.C.Mohanty 139 Duburi to B.C. Mohanty 8.0 Panther B.C. Mohanty to TISCO S/C 13.0 (Bamanipal) 140 B.C. Mohanty to Tomaka traction S/C 11.9 Panther 141 Meramundali to ML Rungta S/C 7.5 Panther 142 Meramundali to BRG S/C 3.6 Panther Panther 143 Nuapatna Tap to Nuapatna S/C 37.1

144 Nuapatna Tap to Dhenkanal S/C 37.1 Panther 145 Kharagprasad to Meramundali D/C 5.5 Panther 146 Kharagprasad to Nabbharat D/C 0.6 Panther 147 Kharagprasad to Salibahan S/C 7.0 Panther 148 Kharagprasad to Hind Metal S/C 0.5 Panther 149 Kharagprasad to Samal Metal S/C 1.0 Panther 150 Kharagprasad to Traction S/C 1.2 Panther Sikkim 400 kV Lilo of Teesta to V to Binaguri D/C line 1 - Twin Moose PGCIL (115km) at Rangpo

88 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type Teesta V to Rangpo D/C 12.3 Rangpo to Binaguri D/C 110.0 2 Teesta 3 to Rangpo S/C 47.0 3 Rangpo to Kishanganj D/C 148.0 220kV 1 Jorethang loop to Rangpo S/C 25.0 Zebra LILO of one circuit of 220kV D/C from Zebra 2 Jorethang loop to new melli at Rangpo PGCIL Jorethang loop to New Melli S/C 10.0 Zebra 3 Jorethang loop to New Melli S/C 11.5 Zebra 4 Rangpo to new melli S/C 26.0 Zebra 132 kV 1 Rangit to Rammam S/C 27.0 Panther PGCIL 2 Rangit to Rangpo S/C 54.2 Panther PGCIL 3 Rangeet HEP to Sagbari S/C 0.3 Panther NHPC 4 Sagbari to Melli S/C 32.0 Panther - Panther 5 Sagbari to Geyzing S/C 15.5

LILO of Gangtok to Melli at Rangpo and - - - Chuzachen 6 Rangpo to Gangtok 26.0 - - Rangpo to Chuzachen S/C 21.0 Panther Gati infra Gangtok to Chuzachen 48.6 Panther+Zebra Sikkim 7 Melli to NJP S/C 90.0 Panther 8 Melli to Rangpo S/C 16.6 Panther PGCIL 9 Rangit to Kurseong S/C 68.0 Panther 66 kV 1 LLHP G/T to Ranipool D/C 0.2 Dog 2 Ranipool to Gangtok PGCIL S/C 0.7 Dog 3 Ranipool to Pakyong S/C 12.0 Dog 4 Pakyong to Rongli S/C 21.0 Dog 5 Ranipool to Topakhani S/C 15.0 Dog 6 Tadong to Gangatok PGCIL S/C 8.0 Dog 7 Tadong to Sichey S/C 5.0 Dog 8 Tadong to Phudong S/C 18.0 Dog 9 Sichey to Bulbuley S/C 4.0 Dog Dog 10 Bulbuley to Gangatok PGCIL S/C 10.0 Sikkim Gov 11 Mangan to Meyong HEP S/C 12.0 Dog 12 Mangan to Phudong S/C 20.0 Dog 13 Rongli HEP to Rongli S/C 4.9 Dog 14 Rongali to Rhenock S/C 12.0 Dog 15 Geyzing 132kV to Geyzing 66kV S/C 0.2 Dog 16 Geyzing 132kV to Pelling S/C 2.1 Dog 17 Geyzing to Namchi S/C 25.0 Dog 18 Melli 132kV to Melli 66kV S/C 0.1 Dog 19 Melli 66kV to Purano Namchi S/C 22.0 Dog 20 Melli 66kV to Namchi S/C 22.0 Dog

89 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 21 Melli 66kV to Mamring S/C 18.0 Dog 22 Melli 66kV To Kalingpong D/C 15.0 Dog 23 Rangit HEP to Ravangla S/C 13.0 Dog 24 Purno Namchi to Rohatak S/C 9.0 Dog 25 Rohtak to Soreng S/C 11.0 Dog West Bengal 400 kV 1 Jeerat to KTPS S/C 136.0 Twin Moose WBSETCL 2 Jeerat to Bakreswar S/C 163.0 Twin Moose 3 Jeerat to Behrampur S/C 200.0 Twin Moose 4 Jeerat to Subhashgram S/C 80.0 Twin Moose 5 Farakka (NTPC) to Behrampur S/C 73.0 Twin Moose PGCIL 6 Sagardighi to Behrampur D/C 26.0 HTLS Behrampur to Behramara 7 D/C 71* Twin Moose (Bangladesh) 8 Subhashgram to Haldia D/C 90.0 Twin Moose CESC PGCIL 9 Sagardighi to Subhashgram S/C 246.0 Twin Moose

10 Farakka (NTPC) to Sagardighi S/C 67.0 Twin Moose Farakka (NTPC) to Kahalgaon I, 11 4 95.0 Twin Moose II, III & IV PGCIL 12 Farakka (NTPC) to Malda D/C 40.0 Twin Moose 13 Farakka (NTPC) to Gokarna D/C 94.6 Twin Moose 14 Sagardighi to Parulia (PGCIL) D/C 171.0 Twin Moose 15 Arambag to KTPS S/C 78.0 Twin Moose WBSETCL 16 KTPS to Kharagpur S/C 95.0 Twin Moose 17 KTPS to Kharagpur S/C 91.0 Twin Moose WBSETCL 18 Kharagpur to Baripada S/C 98.0 Twin Moose & OPTCL 19 PPSP to Arambag D/C 210.0 Twin Moose 20 PPSP to Bidhanagar D/C 183.5 Twin Moose 21 PPSP to New ranchi S/C 85.0 Twin Moose WBSETCL Parulia (PGCIL) to Bidhanagar 22 D/C 11.0 Twin Moose (Durgapur) 23 Parulia (PGCIL) to Jamshedpur S/C 177.0 Twin Moose PGCIL DVC Durgapur (DSTPS) to 24 D/C 70.5 Twin Moose Raghunathpur (RTPS)

Maithon to Raghunathpur (RTPS) 52.9 Twin Moose DVC & 25 S/C Raghunathpur (RTPS) to Ranchi 169.0 PGCIL 26 Raghunathpur (RTPS) to Ranchi D/C 155.0 Quard Moose DVC Durgapur (DSTPS) to DVC & 27 D/C 161.0 Twin Moose Jamshedpur PG PGCIL Maithon to Mejia B 84.0 28 S/C Twin Moose Mejia B to Jamshedpur 168.0 PGCIL 29 Maithon to Mejia B D/C 59.0 Twin Moose 30 Malda (PGCIL) to Purnea D/C 167.0 Twin Moose

90 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 31 Binaguri (PGCIL) to Purnia I & II D/C 168.0 Twin Moose 32 Binaguri (PGCIL) to Purnia III & IV D/C 160.0 Quad Moose 33 Binaguri (PGCIL) to Malbase S/C 121* Twin Moose 34 Binaguri (PGCIL) to Rangpo - I S/C 110.0 Twin Moose 35 Binaguri (PGCIL) to Rangpo - II S/C 110.0 Twin Moose 36 Binaguri (PGCIL) to Bongaigaon D/C 217.0 Twin Moose 37 Binaguri (PGCIL) to Alipurduar D/C 114.0 Quad Moose 38 Alipurduar to Bongaigaon D/C 122.4 Quad Moose 39 Binaguri (PGCIL) to Tala IV S/C 98* Twin Moose 40 Binaguri (PGCIL) to Tala I & II D/C 115* Twin Moose Farakka (NTPC) to Parulia 41 D/C 150.0 Twin Moose (PGCIL) 42 Arambag to Bakreswar S/C 130.0 Twin Moose WBSETCL 43 Maithon to Parulia (PGCIL) D/C 70.7 Twin Moose 44 Bidhannagar to Arambag S/C 115.0 Twin Moose 45 Ranchi to Arambag S/C 111.5 Twin Moose PGCIL 46 KTPS to Chaibasa S/C 70.0 Twin Moose 47 Kharagpur to Chaibasa S/C 161.0 Twin Moose 220 kV 1 Bakreswar to Bidhanagar D/C 40.0 Zebra WBSETCL 2 Bidhanagar to Waria (DTPS) D/C 17.2 ACSR DEER DVC 3 Bidhanagar to DPL D/C 10.0 Zebra 4 Gokarna to Sadaipur D/C 75.0 Zebra 5 Sadaipur to Bakreswar D/C 6.0 Zebra WBSETCL 6 Jeerat to New Town D/C 40.0 Zebra 7 KTPS to Howrah D/C 71.0 Zebra 8 NJP (WB) to Binaguri D/C 6.0 Zebra PGCIL 9 J K nagar to Bidhanagar S/C 40.5 Deer+Zebra WBSETCL/I 10 J K Nagar to STPS S/C 89.9 Deer+Zebra PCL 11 STPS to New Bishnupur S/C 145.5 Zebra Subhasgram (WB) to Subhasgram 12 D/C 0.6 Moose WBSETCL (PG) 13 Kharagpur to Midnapur D/C 45.6 Zebra 14 Dalkhola to Dalkhola (PG) D/C 1.0 Zebra Dalkhola PG to Kishanganj D/C 31.0 Zebra 15 Kishanganj to Siliguri (PG) D/C 108.0 Zebra 16 Dalkhola PG to Purnea D/C 41.0 Zebra 17 Dalkhola PG to Malda D/C 116.0 Zebra PGCIL 18 Binaguri to Siliguri (PG) D/C 6.0 Zebra 19 Binaguri to Birpara D/C 80.0 Zebra 20 Birpara to Salakati (NER) D/C 160.0 Zebra 21 Birpara to Malbase S/C 40.0 Zebra 22 Birpara to Chukha D/C 38.0 Zebra PGCIL 23 Gokarna to Sagardighi D/C 40.0 Zebra WBSETCL 24 Farakka to Lalmatia S/C 79.0 Zebra PGCIL

Zebra WBSETCL 25 STPS to Chandil S/C 98.0 & JSEB

91 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type Subhashgram (PG) to Newtown Zebra 26 S/C 24.0 WBSETCL (WBSETCL) Single Core 27 Kasba to EMSS S/C 1.0 XLPE Subhasgram (PG) to EMSS 28 D/C 23.2 ACSR Moose (CESC) D/C 85.0 Moose CESC EMSS to Budge Budge G.S 29 800 sqmm, (BBGS) D/C 2.5 XLPE 800 sqmm, 30 NCGS to EMSS D/C 19.0 XLPE 31 Arambagh to Midnapore D/C 71.0 Zebra 32 Arambagh to Rishra S/C 73.0 Zebra 33 Arambag to New Bishnupur D/C 49.0 Zebra 34 Bakreswar to Satgachia D/C 132.0 Zebra 35 Domjur to Arambagh D/C 58.0 Zebra 36 Howrah to Foundry Park D/C 34.0 Zebra 37 Foundry Park to Domjur D/C 14.5 Zebra 38 Jeerat to Satgachia D/C 78.0 Zebra 39 Kasba to Jeerat D/C 55.0 Zebra 40 Kasba to Subhasgram (WB) D/C 22.0 Zebra 41 Krishnanagar to Satgachia D/C 52.0 Zebra 42 NJP (WB) to TLDP‐III S/C 80.8 Zebra WBSETCL 43 NJP (WB) to TLDP‐IV D/C 145.0 Zebra 44 New Haldia to KTPS D/C 56.0 Zebra 45 Bidhanagar to Asansol S/C 114.0 Zebra 46 STPS to Asansol S/C 62.0 Zebra 47 STPS to Hura S/C 45.3 Zebra 48 Hura to New Bishnupur S/C 131.8 Zebra Subhasgram (WB) to 49 D/C 43.0 Zebra Lakshmikantapur 50 Jeerat to Rishra S/C 70.0 Zebra 51 Jeerat to Dharampur S/C 32.5 Zebra 52 Dharampur to Rishra S/C 32.5 Zebra 53 Malbase to Chukha S/C 36.0 Zebra PGCIL Subhasgram (PG) to Bantala - 54 S/C 20.7 Zebra CLC (WB) WBSETCL 55 Bantala (CLC) to New town S/C 20.0 Zebra Kalyanisweri to Maithon 56 D/C 7.6 Zebra (Pithakari) PGCIL PGCIL 57 Maithon(Pithakari) to Dhanbad D/C 52.0 Zebra ACSR Zebra 58 Mejia to Borjora D/C 8.5

59 Mejia to Muchipara (Durgapur) D/C 31.5 Zebra Muchipara (Durgapur) to Parulia 60 D/C 14.8 Zebra (DVC) DVC 61 Parulia (DVC) to Tumla 3 6.0 Zebra 62 Burnpur to IISCO D/C 1.2 AAAC ZEBRA Mejia (DVC) to Waria DTPS 63 D/C 42.0 Zebra (DVC) 64 Waria (DTPS) to Parulia (DVC) D/C 22.0 Zebra

92 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 65 Parulia (DVC) to Parulia (PG) D/C 1.0 Zebra 66 Mejia to Kalyanswari S/C 54.9 Zebra 67 Mejia to Burnpur S/C 58.2 Zebra 68 Burnpur to Kalyanswari S/C 22.0 Zebra DVC 69 Gokarna to Krishnanagar D/C 105.0 Zebra 70 Kharagpur to Egra D/C 53.5 Zebra WBSETCL 71 Kharagpur to Vidyasagar Park D/C 100.0 Zebra 132 kV 1 Adisaptagram to Belmuri D/C 32.0 Panther 2 Adisaptagram to BTPS D/C 10.0 Panther 3 Alipurduar to Coochbehar S/C 19.0 Panther 4 Amtala to Debagram D/C 40.5 Panther 5 Arambag to Birsingha D/C 24.0 Panther 6 Arambag to Raina D/C 32.0 Panther 7 Arambag to Tarakeswar D/C 34.0 Panther 8 Ashoknagar to Basirhat D/C 39.0 Panther 9 Bagmundi to Purulia (WB) S/C 69.0 Panther 10 Balichak TSS to Pingla S/C 18.0 Panther 11 Bankura to Bankura TSS S/C 0.6 Panther 12 Bankura to Bishnupur New D/C 36.2 Panther 13 Bankura to Bengal Concast S/C 3.8 Panther 14 Bankura to Raghunathpur D/C 59.6 Panther 15 Barasat to New Town AA‐III D/C 35.0 Panther 16 Barasat to Barasat TSS S/C 3.0 Panther 17 Berhampore to Amtala D/C 47.3 Panther Berhampore to Cossimbazar 18 S/C 13.0 Panther traction 19 Bighati to Rishra D/C 10.0 Panther WBSETCL 20 Birpara to Alipurduar S/C 54.0 Panther 21 Birpara to Coochbehar S/C 67.0 Panther 22 Birpara to Birpara (PG) D/C 0.5 Panther Bishnupur to (Chandrakonaroad) 23 S/C 48.0 Panther CK Road Chandrakonaroad (CK Road) to 24 S/C 5.0 Panther CK Road Rail 25 Bishnupur to Midnapur S/C 88.0 Panther Bishnupur to Modern/ Gaytri 26 S/C 4.0 Panther (load) 27 Bishnupur to New Bishnupur D/C 5.5 Panther 28 Bishnupur to New Bishnupur S/C 3.0 Panther 29 Bishnupur to Rohit Ferro S/C 2.8 Panther Panther 30 New Bishnupur to Borjora D/C 44.5

31 Borjora to Durgapur (Bidhanagar) D/C 27.0 Panther 32 Bolpur to Durgapur (Bidhanagar) D/C 71.0 Panther 33 Bolpur to Sainthia D/C 40.0 Panther 34 BTPS to Dharampur 3 26.0 Panther 35 BTPS to Bighati D/C 25.0 Panther

93 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 36 BTPS to Kalyani S/C 22.0 Panther 37 BTPS to Khanyan S/C 18.0 Panther 38 BTPS to Satgachia S/C 55.0 Panther 39 Chanditala to Rishra D/C 6.0 Panther 40 CK Road to Ck Road Traction S/C 5.0 Panther 41 Contai to Egra S/C 32.0 Panther 42 Contai to Bajkul S/C 33.0 Panther 43 Egra to Bajkul S/C 65.0 Panther 44 Contai to New Haldia S/C 77.0 Panther 45 Dalkhola to Raigaunj D/C 51.0 Panther 46 Dalkhola to TCF PS ‐ III D/C 95.0 Panther 47 Dankuni to Hind Motor S/C 7.0 Panther 48 Dankuni to Liluah S/C 8.0 Panther 49 Debagram to Debagram TSS S/C 6.0 Panther 50 Debagram to Katwa D/C 35.0 Panther 51 Dharampur to Kalyani S/C 10.0 Panther Panther 52 Dharampur to Ranaghat D/C 26.0

53 Dharampur to Titagarh D/C 29.0 Panther 54 Dhulian to Farakka S/C 22.0 Panther 55 Domjur to Jangipara D/C 17.0 Panther 56 Domjur to Chanditola D/C 25.0 Panther 57 Domjur to Uluberia D/C 27.0 Panther 58 Durgapur (Bidhanagar) to DPL D/C 10.0 Panther 59 Durgapur (Bidhanagar) to Mankar D/C 30.0 Panther 60 Durgapur (Bidhanagar) to Ukhra D/C 22.5 Panther 61 Egra to New Haldia S/C 100.0 Panther 62 Gangarampur to Balurghat S/C 35.0 Panther 63 Gokarna to Katwa D/C 57.0 Panther 64 Gokarna to Berhampore D/C 18.0 Panther 65 Gokarna to Lalgola S/C 46.8 Panther 66 Gokarna to Lalgola S/C 67.0 Panther 67 Lalgola to Raghunathganj S/C 27.0 Panther 68 Gokarna to Raghunathganj S/C 42.0 Panther 69 Gokarna to Rampurhat S/C 63.0 Panther 70 Gokarna to Kuli S/C 23.6 Panther 71 Haldia to Haldia NIZ D/C 22.0 Panther 72 Haldia NIZ to Rohit Ferro S/C 2.0 Panther 73 Haldia to TATA Power D/C 6.5 Panther 74 Haldia to New Haldia S/C 2.0 Panther 75 New Haldia to Bajkul D/C 45.0 Panther Panther

76 Haldia NIZ to Maniksia S/C 1.0

77 Hizli to Midnapur D/C 25.5 Panther 78 Egra to Bengal Energy (BEL) S/C 50.1 Panther 79 Bengal Energy (BEL) to Hizli S/C 22.7 Panther

94 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 80 Hind Motor (HM) to Rishra S/C 13.0 Panther 81 Howrah to Liluah I&II D/C 14.0 Panther 82 Howrah to Liluah III S/C 18.0 Panther 83 Howrah to Liluah IV S/C 24.0 Panther 84 HPCL to Haldia S/C 3.0 Panther 85 HPCL to New Haldia S/C 2.0 Panther 86 Jeerat to Ashoknagar D/C 15.0 Panther 87 Jeerat to Mahispota D/C 27.7 Panther 88 Jeerat to Barasat D/C 24.5 Panther 89 Jeerat to Bongaon D/C 36.0 Panther 90 Jeerat to Dharampur D/C 14.0 Panther 91 Kalna to Satgachia D/C 18.8 Panther 92 Kasba to Salt Lake S/C 21.0 Panther 93 Kasba to KLC S/C 13.0 Panther 94 KLC to Salt Lake S/C 13.0 Panther 95 Kasba to Sonarpur S/C 12.0 Panther 96 Katwa to Katwa TSS S/C 2.4 Panther 97 Katwa to Satgachia D/C 45.0 Panther 98 Khanyan to Satgachia S/C 42.0 Panther Kharagpur (DVC) to Kharagpur 99 S/C 1.0 Panther (WB) Khargapur (WBIDC) to TATA 100 S/C 5.0 Panther Metalic 101 Khatra to Bishnupur Old D/C 66.5 Panther 102 Khejuria to Farakka (Cable) D/C 2.6 Panther 103 Kolaghat to KTPS D/C 4.0 Panther DVC 104 Kolaghat to Madras Cement S/C 5.0 Panther 105 Krishnanagar to Bongaon D/C 53.0 Panther 106 Krishnanagar to Debagram D/C 46.0 Panther 107 Krishnanagar to Ranaghat D/C 33.4 Panther 108 Tamluk TO Tamluk rail S/C 10.0 Panther 109 KTPS to Tamluk D/C 19.0 Panther KTPS to Uluberia 29.0 110 KTPS to Bagnan S/C 16.0 Panther Bagnan to Uluberia 21.0 111 Kuli to Sainthia S/C 35.6 Panther 112 Laxmikantapur to Falta D/C 34.0 Panther 113 Laxshmikantapur to Kakdwip D/C 53.5 Panther WBSETCL 114 Liluah to BTPS S/C 58.0 Panther 115 Liluah to Rishra S/C 19.5 Panther 116 Liluah to Rishra S/C 36.0 Panther 117 Mahachanda to Mankar D/C 43.0 Panther 118 Mahachanda to Satgachia D/C 54.0 Panther 119 Malda to Balurghat Tap point S/C 98.4 Panther Panther 120 Malda to Khejuriaghat D/C 35.0

121 Malda to Malda (PG) D/C 7.0 Panther 122 Malda to Raigaunj S/C 85.0 Panther 123 Malda to Samsi S/C 55.0 Panther

95 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 124 Midnapur to Khargapur (WBIDC) S/C 18.0 Panther 125 Midnapur to Balichak TSS S/C 26.0 Panther Midnapur to Chandrakonaroad 126 S/C 46.0 Panther (CK Road) 127 Midnapur to Jhargram D/C 48.0 Panther 128 Midnapur to Pingla S/C 41.0 Panther 129 Moinaguri to Birpara S/C 43.0 Panther 130 Moinaguri to Mathabhanga S/C 50.0 Panther 131 Mathabhanga to Birpara S/C 83.8 Panther 132 Moinaguri to Chalsa S/C 43.0 Panther 133 Gokarna to Sonar Bangla S/C 47.2 Panther 134 Sonar Bangla to Lalgola S/C 28.4 Panther New Town AA‐III to New Town 135 S/C 8.3 Panther AA‐I 136 New Town AA‐III to Salt Lake GIS S/C 15.0 Panther New Town AA‐I to Salt Lake GIS 137 D/C 11.1 Panther S/C 138 New Town AA‐I to CLC S/C 12.1 Panther 139 NBU to Lebong S/C 66.0 Panther 140 NBU to NJP (PG) S/C 15.0 Panther 141 NBU to Rammam S/C 69.0 Panther 142 NBU to TCF PS ‐ I S/C 18.0 Panther 143 NJP (WB) to Chalsa S/C 78.0 Panther 144 NJP (WB) to Moinaguri S/C 41.0 Panther 145 NJP (WB) to TCF PS ‐ I S/C 16.0 Panther 146 Purulia (WB) to STPS D/C 35.0 Panther 147 Raghunathganj to Dhulian S/C 22.0 Panther 148 Raghunathganj to Farakka S/C 44.0 Panther 149 Raigaunj to Gangarampur S/C 75.0 Panther 150 Rampurhat to Sainthia S/C 38.0 Panther 151 Reshmi to TATA Metalic S/C 6.0 Panther 152 Samsi to Raigaunj S/C 68.0 Panther 153 Satgachia to Debagram TSS S/C 18.0 Panther 154 Siliguri to NJP (WB) D/C 16.0 Panther 155 Tamluk to Haldia NIZ D/C 46.0 Panther 156 Tarakeswar to Belmuri D/C 18.0 Panther 157 TCF PS ‐ I to TCF PS ‐ II S/C 16.0 Panther 158 TCF PS ‐ I to TCF PS ‐ III S/C 34.0 Panther 159 TCF PS ‐ II to TCF PS ‐ III S/C 20.0 Panther 160 Hura to Purulia(WB) D/C 15.9 Panther 161 Howrah to Foodpark S/C 20.0 Panther 162 Foodpark to Kolaghat S/C 37.0 Panther 163 Vidyasagarpark to Hizli TSS S/C 90.0 Panther 164 Vidyasagarpark to Hizli S/C 80.0 Panther Panther 165 Hizli to Hizli TSS S/C 1.1

166 Midnapur to BRG steel Tap S/C 2.5 Panther 167 BRG steel Tap to BRG S/C 8.4 Panther 168 BRG steel Tap to Vidyasagarpark S/C 87.5 Panther

96 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type 169 New Town AA-1 to Salt Lake GIS D/C 11.1 Panther 170 NJP (WB) to NJP (PG) S/C 10.0 Panther 171 NJP (PG) to Melli S/C 90.0 Panther 172 NJP (PG) to Kurseong S/C 31.3 Panther PGCIL 173 Kurseong to Rangit S/C 68.0 Panther 174 NJP (WB) to NBU S/C 10.0 Panther Raghunathganj to farakka Ambuja 175 D/C 5.0 Panther Cement 176 NBU to Siliguri ( Ujanoo) S/C 10.0 Panther 177 Midnapur to Rashmi S/C 10.0 Panther 178 Crescent power to Asansol D/C 20.0 Panther WBSETCL 179 Raghunathpur to Hura D/C 33.4 Zebra 180 Joka to Falta D/C 28.8 Panther 181 Joka to Sonarpur S/C 18.0 Panther 182 Kasba to Joka S/C 27.0 Panther 183 Kolagat (WB) to Kolagat (DVC) D/C 5.0 Panther 184 Waria (DTPS) to ASP D/C 5.0 Lark 185 Wariac (DTPS) to Kalipahari D/C 39.7 Lark 186 Waria to Burdwan D/C 69.2 Lark 187 Belmuri to Burdwan D/C 51.5 Lark 188 Belmuri to Howrah D/C 49.3 Lark DVC 189 Howrah to Kolaghat D/C 57.3 Lark 190 Kolaghat to kharagpur D/C 69.2 Lark 191 Waria (DTPS) to Jamuria S/C 33.0 AAAC Panther 192 Borjora to Sonic Thermal S/C 1.8 AAAC Panther 193 Mosabani to Kharagpur D/C 95.2 ACSR LARK Kolaghat to Badrinarayan alloy 194 No proper details available steel 195 DTPS to DPL D/C 11.0 Lark DVC/DPL 196 Joka to Sirakol S/C 17.0 Panther 197 Amtala to Najirpur D/C 13.4 Panther 198 Rammam to Rangit S/C 27.0 Panther 199 Laxmikantapur to Sirakol D/C 35.2 Panther WBSETCL 200 Siliguri to Siliguri ( Ujanoo) S/C 10.0 Panther 201 Dalkhola to Kishengunj S/C 26.0 Panther 202 Lebong (Darjeling) to Rammam S/C 20.0 Panther 203 DPPS to B Zone D/C 1.6 Panther 204 DPPS to A Zone S/C 6.4 Panther 205 DPPS to C Zone D/C 4.8 Bison DPL 206 DPPS to C1 Zone D/C 5.5 Panther 207 DPPS to AB Zone D/C 1.2 Panther 208 A Zone to Bamunara D/C 3.6 Panther 209 BBGS to Chakmir D/C 20.1 ACSR Moose 210 BBGS to Chakmir D/C 18.7 ACSR Moose XLPE 630 CESC 211 Chakmir to Majerhat D/C 6.1 sqmm XLPE 630 212 Chakmir to Taratala D/C 5.4 sqmm

97 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type XLPE 630 213 Taratala to BBD Bag S/C 10.4 sqmm XLPE 630 214 Taratala to PRS S/C 11.0 sqmm XLPE 630 215 Majerhat to Taratala S/C 0.9 sqmm XLPE 630 216 Jadavpore to Majerhat S/C 5.6 sqmm XLPE 400 217 Majerhat to Southern D/C 6.4 sqmm XLPE 400 218 Majerhat to PRS S/C 9.0 sqmm 219 WBSETCL (Howrah) to Southern S/C 3.0 GF 161 sqmm XLPE 800 sq.mm( 1st circuit) 2 x GF 220 Botanical Garden to Southern D/C 2.2 161 sq.mm. Cu.( 2nd circuit) XLPE 630 sq.mm( 1st circuit) 2 x GF 221 WBSETCL (Howrah) to B.Garden D/C 1.1 161 sq.mm. Cu.( 2nd circuit) XLPE 630 222 BBD Bag to PRS D/C 1.4 sqmm XLPE 630 223 East Calcutta to PRS S/C 6.6 sqmm XLPE 800 224 PRS to Park lane S/C 2.1 sqmm XLPE 630 225 East Calcutta to Chitpur railway S/C 7.4 sqmm XLPE 630 226 Chitpur railway to Btroad S/C 5.6 sqmm GF 260 sq. 227 BT road to NCGS S/C 1.5 mm. Cu XLPE 800 228 BT road to NCGS S/C 2.5 sqmm XLPE 800 229 BT road to Titagarh S/C 9.3 sqmm XLPE 800 230 Dum dum to BT road S/C 7.5 sqmm XLPE 400 231 NCGS to Titagarh S/C 13.4 sqmm GF 225 sq. 232 WBSETCL (Titagarh) to Titagarh D/C 0.5 mm. Al. GF 161 sq.mm. 233 WBSETCL (Lilooah) to Belur T/C 4.4 Cu XLPE 800 234 WBSETCL (Rishra) to Rishra D/C 6.4 sqmm XLPE 800 235 EMSS to East Calcutta S/C 7.8 sqmm 236 EMSS to PRS S/C 9.8 XLPE 800

98 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Ckt Distance Conductor Sl.No Transmission line Owned By type (km) Type sqmm XLPE 800 237 WBSETCL (Kasba) to EMSS T/C 0.4 sqmm XLPE 630 238 EMSS to Jadavpore S/C 11.0 sqmm XLPE 800 239 EMSS to Park lane S/C 7.0 sqmm XLPE 800 240 EMSS to Patuli S/C 7.0 sqmm XLPE 800 241 East calcutta to DDSS S/C 11.0 sqmm XLPE 800 242 EMSS to DDSS S/C 17.3 sqmm

99 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table C: State wise list of generators present in the eastern region grid

Power station details Capacity Total Sl.No Name of the power station No. of Owned By of each capacity units unit (MW) (MW) Bihar State Sector 1 Barauni (BTPS) 2 110 220 BSPGCL 2 110 220 Joint venture 2 Muzaffarpur (Kanti) of NTPC & 1 195 195 BSEB Eastern gandak canal HEP 3 3 5 15 BSHPGCL (Valmikinagar) Central sector 4 210 1 Khalgoan 2340 3 500 NTPC 2 Barh STPP, St-II 2 660 1320 Jharkhand State Sector 1 PTPS 1 110 110

2 TTPS 2 210 420

3 Subernrekha (SHPS) 2 65 130

DVC 3 210 630 1 Bokaro 'B' DVC 1 500 500 3 140 2 Chandrapur 920 DVC 2 250 3 Koderma TPS 2 500 1000 DVC 4 Tiliya 2 2 4 DVC 1 23.2 5 Maithon dam 63.2 DVC 2 20 6 Panchet 2 40 80 DVC 7 MGT gen (Gas based) 3 27.5 82.5 DVC CPP 3 120 1 Jojobera 427.5 Tata Steel 1 67.5 2 Inland Power 1 70 70

3 30 3 Usha Martin Ltd. (Adityapur) 1 25 130

1 15 4 Usha Martin Ltd. (Ranchi) 2 10 20

5 Rungta mines 2 20 40

6 ABCIL 2 30 60

IPP 1 Adhunik Power Co. Ltd. 2 270 540

Joint venture 2 Maithon RB (MPL) 2 525 1050 of DVC & TATA

100 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Power station details Capacity Total Sl.No Name of the power station No. of Owned By of each capacity units unit (MW) (MW)

Odisha State sector 2 49.5 1 Burla power house (Hirakud-I) 2 32 275.5 OHPC 3 37.5 Chiplima power house (Hirakud- 2 3 24 72 OHPC II) 6 60 3 Balimela power house (HPS) 510 OHPC 2 75 4 Rengali power house (HPS) 5 50 250 OHPC 5 Upper Kolab power house (HPS) 4 80 320 OHPC Upper Indravati hydro electric 6 4 150 600 OHPC (HPS) 3 17 7 Machhkund power house (HPS) 115.5 OHPC 3 21.5 8 IB thermal power station 2 210 420 OPGC 4 60 9 TTPS (NTPC- State dedicated) 460 NTPC 2 110 Central sector Talcher super thermal power-I 2 500 1 3000 NTPC Talcher super thermal power-II 4 500 CPP 1 NALCO (Angul) 10 120 1200

2 60 2 RSP (Rourkela) 220 4 25 2 54 3 ICCL (IMFA), (Choudwara) 2 60 258

1 30 1 67.5 4 HPCL(HINDALCO), (Hirakud) 467.5 4 100 1 24 5 KMCL (NINL), (Duburi) 62.5 2 19.25 1 30 6 NBVL (Meramundali) 94 1 64 1 60 Bhusan Power & Steel, 1 40 7 506 Jharsuguda 3 130 2 8 8 Vedanta (Lanjigarh) 3 30 90

1 18.5 9 Tata sponge iron (Joda) 26 1 7.5 10 Shyam DRI (Pandoli, Sambalpur) 1 33 33

11 Aarti steel (Ghantikhal, Cuttak) 1 40 40

101 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Power station details Capacity Total Sl.No Name of the power station No. of Owned By of each capacity units unit (MW) (MW) 1 33 Bhusan steel and strips 12 1 77 410 (Meramundali) 2 150 2 125 13 Jindal stainless Ltd. (Duburi) 263 1 13 14 Vedanta (Jharsuguda) 9 135 1215

15 Visa steel (New Duburi) 3 25 75

16 IFFCO (Paradeep) 2 55 110

1 8 17 SMC power generation Ltd. 33 1 25 1 12 18 Action ispat and power Ltd. 1 25 123

2 43 19 Aryan ispat and power Ltd. 1 18 18

1 15 20 EMAMI 20 1 5 21 Shree Ganesh 1 32 32

22 ACC ( Baragarh) 1 30 30

Jindal steel and power Ltd. 23 6 135 810 (Angul) Maithan ispat nigam Ltd. (Jajpur 24 1 30 30 road) 25 MSP mettallics Ltd. 1 25 25

26 OCL India Ltd. 2 27 54

1 45 45 27 FACOR 1 55 55

28 HINDALCO (AAL) (Budhipadar) 4 150 600

29 Maheswari Ispat Pvt Ltd 2 12 24

IPP 3 4 1 Meenakshi power (Jayanagar) 37 2 12.5 Odisha power consortium Ltd. 2 4 5 20 (Samal) 3 Aarati steel (Ghantikhal) 1 50 50

4 Sterlite energy Ltd. (Jharsuguda) 4 600 2400

5 GMR Kamalanga 3 350 1050

6 JITPL (Derang) 2 600 1200

7 Ind-Barath 1 350 350

Sikkim State Sector 1 LLHP 2 6 12 2 Meyonchu 2 2 4 Sikkim Gov. 3 Rongali HEP 2 3.125 6.25 Central sector 1 Teesta-V 3 170 510 NHPC 2 Rangeet -III 3 20 60 NHPC

102 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Power station details Capacity Total Sl.No Name of the power station No. of Owned By of each capacity units unit (MW) (MW) Teesta Urga 3 Teesta-III 6 200 1200 ltd. 4 Dikchu 2 48 96 IPP 1 Chuzachen 2 55 110

2 Jortheang loop 2 48 96

West Bengal State Sector 1 Bakreswar TPS 5 210 1050 WBPDCL 4 60 2 Bandel TPS 450 WBPDCL 1 210 3 210 630 3 Kolaghat TPS WBPDCL 3 210 630 2 300 4 Sagardighi TPS 1600 WBPDCL 2 500 5 Santaldih TPS 2 250 500 WBPDCL 6 Rammam II hydro 4 12.75 51 WBSEDCL 7 Purulia pumped storage 4 225 900 WBSEDCL 8 Jaldhaka hydro 1 3 9 27 WBSEDCL 9 Teesta canal fall hydro 1 3 7.5 22.5 WBSEDCL 10 Teesta canal fall hydro 2 3 7.5 22.5 WBSEDCL 11 Teesta canal fall hydro 3 3 7.5 22.5 WBSEDCL Central sector 3 200 1 Farakka 2100 NTPC 3 500 2 Chuka Bhutan, Hydro 4 84 336 Bhutan 3 Tala Bhutan, Hydro 6 170 1020 Bhutan 4 Teesta low dam 3 4 33 132 NHPC 5 Teesta low dam 4 2 40 220 NHPC Private Sector and DVC 1 110 1 DPL 1 250 DPL

1 300 4 210 2 Mejia 1340 DVC 2 250 1 140 3 Waria TPS (DTPS) 350 DVC 1 210 4 Mejia TPS phase-II 2 500 1000 DVC 5 Durgapur steel TPS 2 500 1000 DVC 2 250 500 6 Budge Budge CESC 1 250 250 7 Southern generating station 2 67.5 135 CESC 8 Haldia TPP 2 300 600 CESC 9 Raghunathpur TPS 2 600 1200 DVC CPP

103 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Power station details Capacity Total Sl.No Name of the power station No. of Owned By of each capacity units unit (MW) (MW) 2 45 1 Tata power 120 1 30 2 Crescent power 2 20 40

104 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table D: State wise list of Bus reactors present in the eastern region grid

Existing reactor details Sl. Voltage level capacity of Total Name of the substaion no of No (kV) each unit capacity units (MVAr) (MVAr)

Bihar 765 2 240 480 1 Gaya 400 2 125 250 400 1 125 125 2 Biharshariff 400 1 50 50 400 1 80 80 3 Kahalgaon 400 3 50 100 4 Muzaffarpur 400 2 125 250 400 1 80 80 5 Patna 400 2 125 250 6 New Purnea 400 2 125 250 7 Barh 400 1 80 80 8 Banka 400 1 80 80 9 Lakhisarai 400 1 80 80 765 1 330 330 10 Pusauli 400 2 125 250 11 Kishanganj 400 2 125 125 Jharkhand 400 2 125 250 1 Ranchi (New) 765 2 240 480 2 Maithon 400 1 50 50 3 Maithon RB (MPL I & II) 400 2 125 100 4 Jamshedpur 400 2 50 100 400 1 80 80 5 Ranchi 400 1 125 125 6 Koderma 400 2 50 100 7 Chaibasa 400 1 80 80 Chandwa 8 400 2 125 250 (Jharkhand Pooling ) Odisha 765 2 330 660 1 Angul 400 3 125 330 1 240 240 2 Jharsuguda 765 1 240 240 3 Bolangir 400 1 80 80 1 50 50 4 Rourkela 400 1 125 125 5 Rengali 33 1 31.5 31.5 33 1 31.5 31.5 6 Jeypore 400 1 125 125 400 1 63 63 7 Keonjhar 400 1 80 80

105 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Existing reactor details Sl. Voltage level capacity of Total Name of the substaion no of No (kV) each unit capacity units (MVAr) (MVAr) 8 Jharsuguda 400 2 125 250 9 Indravati 400 1 125 125 10 Duburi 400 1 80 80 11 JITPL 400 2 50 100 1 80 80 12 Pandiaballi 400 1 63 63 13 Baripada 400 1 125 125 Sikkim 1 Rangpo 400 2 80 160 2 New Melli 220 1 63 63 West Bengal 1 Farakka 400 2 50 100 2 Parulia 400 3 16.77 50.31 3 Bidhannagar 400 1 50 50 4 Bakreswar 400 1 50 50 5 Jeerat 400 1 50 50 6 Arambagh 400 1 50 50 7 Ragunathpur 400 2 50 100 8 Kharagpur 400 1 80 80 9 Binaguri 400 2 125 250 10 Behrampur 400 1 80 80 11 KTPS 400 2 50 100 12 Durgapur 400 1 50 50 13 Alipurduar 400 2 125 250

106 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table E: State wise list of line reactor present in the eastern region grid

Existing reactor details

Voltag capacity Sl Name of the No. Total e level of each Remarks No transmission line of capacity End (kV) unit units (MVAr) (MVAr)

Bihar 400 2 50 100 Gaya Switchable 1 Maithon to Gaya I & II 400 2 50 100 Maithon Switchable 2 Purnea to Kishanganj-I 400 1 63 63 Purnea - 3 Purnea to Binaguri-III 400 1 63 63 Purnea - 400 2 63 126 Purnea Purnea to Muzaffarpur I & 4 Muzaffarpu Switchable II 400 2 63 126 r Muzaffarpur to Gorakhpur Muzaffarpu 5 400 1 63 63 Switchable I r Muzaffarpur to Gorakhpur Muzaffarpu 6 400 1 50 50 Switchable II r 7 Biharshariff to Balia I & II 400 2 50 100 Balia - 765 1 310 240 Pasuali - 8 Pasuali-Fatehpur 765 1 330 330 Fatehpur - 9 Banka to Biharshariff I & II 400 2 50 100 Banka - Biharshariff to Purnea I & 10 400 2 80 160 Biharshariff - II Lakhisarai to Biharshariff I 11 400 2 50 100 Biharshariff - & II 12 Barh to Patna I & II 400 2 63 100 Patna - Lakhisarai to Kahalgaon I 13 400 2 50 100 Lakhisarai - & II 14 Biharshariff to Tenughat 220 1 50 50 Tenughat - 15 Biharshariff to Pusauli I 400 1 50 50 Biharshariff Switchable 16 Pasauli to Allahabad 400 1 63 63 Pasauli Switchable 17 Pasauli to Sarnath 400 1 63 63 Pasauli Switchable 18 Patna to Balia III & IV 400 2 50 126 Balia - Pasauli to Biharshariff I & 19 400 2 63 126 Pasauli - II 1 63 63 Patna Switchable 20 Patna to Krishanganj I & II 400 1 63 63 Patna Switchable Kishangau 1 63 63 nj 21 Patna to Krishanganj I & II 400 Kishangau 1 63 63 nj Biharshariff to Varanasi I 22 400 2 50 100 Biharshariff Switchable & II 1 240 240 Gaya Switchable 23 Gaya to Balia 765 1 330 330 Balia - 24 Gaya to Varanasi-I 765 1 240 240 Gaya Switchable

107 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Existing reactor details

Voltag capacity Sl Name of the No. Total e level of each Remarks No transmission line of capacity End (kV) unit units (MVAr) (MVAr)

25 Gaya to Varanasi-II 765 2 240 480 Gaya Switchable Jharkhand 1 240 240 Ranchi Switchable Ranchi (New) to 26 Dharamjay Dharmjaygarh I 1 330 330 - garh 765 1 240 240 Ranchi Switchable Ranchi (New) to 27 Dharamjay Dharmjaygarh II 1 330 330 - garh 2 80 160 Ranchi - 28 Ranchi to Sipat-I & II 400 2 80 160 Sipat - Maithon RB (MPL) to 2 50 100 MPL 29 400 - Ranchi I & II 2 50 100 Ranchi Maithon to Kahalgaon-I & 30 400 2 50 100 Maithon - II 31 Maithon to Mejia I 400 1 50 50 Maithon Switchable 32 Kharagpur to Chaibasa 400 1 63 63 Chaibasa

Odisha Jharsugud 2 240 480 Switchable 33 Jharsuguda to Angul-I & II 765 a 2 240 480 Angul - Jeypore to Gajuwaka I & 34 400 2 80 160 Gajuwaka Switchable II Pandiabill to Mendhasal 400 1 63 63 Mendasal 35 - Baripada to Pandiabill 400 1 63 63 Baripada 36 Rourkel to Jharsuguda I 400 1 63 63 Rourkela - 37 Rourkel to Sterlite I 400 1 63 63 Rourkela - Meramund Meramundali to Angul I 400 1 80 80 - ali 38 Meramund Meramundali to Vedanta 400 2 50 100 ali 39 Angul to Bolangir 400 1 50 50 Bolangir - 400 1 50 50 Bolangir 40 Bolangir to Jeypore - 400 1 80 80 Jeypore 41 Rourkela to Talcher I & II 400 2 50 100 TSTPP - 42 Keonjhar to Rengali 400 1 63 63 Rengali - 400 2 50 100 Rengali 43 Rengali to Indravati - 1 50 50 Indravati

44 Rourkela to Chaibasa-I 400 1 50 50 Rourkela Switchable 45 Baripada to Duburi 400 1 63 63 Baripada - Rourkela to Jamshedpur 46 400 1 50 50 Rourkela Switchable II

108 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Existing reactor details

Voltag capacity Sl Name of the No. Total e level of each Remarks No transmission line of capacity End (kV) unit units (MVAr) (MVAr)

47 Baripada to Keonjhar 400 3 16.67 50.01 Baripada - Jharsuguda to Dharamjay 48 765 1 330 330 - Dharamjaygarh-I garh Jharsuguda to Dharamjay 49 765 1 330 330 - Dharamjaygarh-II garh West Bengal 50 Behrampur to Jeerat-I 400 1 50 50 Jeerat - 3 21 63 Sagardighi Sagardighi to 51 400 Subashgra - Subashgram 1 50 50 m 52 Farakka to Parulia-I 400 1 50 50 Farakka - 53 Bidhannagar to Parulia-I 400 3 16.7 50.01 Parilia - 54 Bakreswar to Arambagh 400 1 63 63 Bakreswar - 55 Bakreswar to Jeerat 400 1 63 63 Jeerat - 56 Malda to Purnea I & II 400 2 63 126 Malda - Binaguri to Bongaigaon- I Bongaigoa 57 400 2 63 126 & II n 58 Binaguri to Tala I & II 400 2 63 126 Binaguri - 59 Binaguri to Tala IV 400 1 63 63 Binagiri - Binaguri to Bongaigaon III 60 400 2 80 160 Binagiri Switchable & IV 61 Ragunathpur to Ranchi 400 1 60 60 Ranchi_PG - 62 Ragunathpur to Ranchi 400 1 60 60 Ranchi_PG -

109 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table F: State wise list of load data considered for the study present in the eastern region grid

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) Bihar 1 20 20 1 Arrah 132/33 50.81 16.70 3 50 150 2 Ataula (Arwal)(Karpi) 132/33 2 20 40 16.09 4.99 3 Aurangabad 132/33 2 20 40 31.75 13.86 4 Banjari 132/33 3 20 60 12.70 6.35 5 Banka 132/33 3 20 60 31.75 10.44 1 50 50 6 Barauni TPS 132/33 12.70 6.35 2 20 40 1 20 20 7 Barh 132/33 33.87 11.14 1 50 50 8 Baripahari 132/33 2 50 100 64.56 21.22 9 Belaganj 132/33 2 20 40 8.47 2.75 2 20 40 10 Bettiah 132/33 22.99 7.56 1 50 50 11 Bihta 132/33 3 50 150 88.91 29.15 2 20 40 12 Bikramganj 132/33 23.38 1.34 1 50 50 2 20 40 13 Buxar 132/33 28.19 10.64 1 50 50 132/33 2 50 100 63.51 25.50 14 Chandauti (Gaya) 132/25 2 13.35 26.7 1.06 0.41 2 20 40 15 Chhapra 132/33 40.22 13.22 1 50 50 16 Darbhanga (old) 132/33 2 50 100 21.17 6.95 17 Dhaka 132/33 3 20 60 15.88 4.85 18 Dalsingsarai 132/33 2 20 40 22.97 6.25 19 Digha 132/33 3 50 150 55.03 18.07 1 20 20 20 Dumraon 132/33 28.58 4.80 1 50 50 21 Ekma 132/33 1 20 20 6.35 1.91 22 Ekanga Sarai (Ekanagar) 132/33 3 20 60 21.17 4.23 1 20 20 23 Forbeshganj 132/33 42.34 1.63 1 50 50 24 Goh 132/33 2 20 40 11.93 3.87 25 Gangwara 132/33 2 50 100 44.03 5.73 26 Gaighat 132/33 2 50 100 66.69 15.12 27 Hazipur 132/33 3 50 150 57.16 18.34 28 Hulasganj 132/33 2 20 40 19.71 4.55 29 Harnaut 132/33 2 20 40 19.55 12.12 30 Hathidah 132/33 3 20 60 23.50 7.65

110 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 31 Imamganj 132/33 2 20 40 13.34 4.10 32 Jagdishpur 132/33 2 20 40 19.37 5.29 33 Jandaha 132/33 2 20 40 16.09 3.39 34 Jainagar 132/33 3 20 60 12.91 4.21 35 4 50 200 95.17 30.01 Jakkanpur 132/33 36 1 20 20

37 Jamalpur 132/33 2 50 100 30.48 9.95 38 Jamui 132/33 2 20 40 31.75 10.36 39 Jehanabad 132/33 2 20 40 21.22 4.27 2 20 40 40 Kahalgaon 132/33 29.64 14.82 2 50 100 2 50 100 6.59 41 132/33 23.82 1 20 20 Karmnasa 1 21.6 21.6 42 132/25 0.26 0.77 1 20 20 43 Kataiya 132/33 3 20 60 30.38 7.11 3 20 60 44 Katihar 132/33 25.93 8.46 1 50 50 45 Katra 132/33 3 50 150 74.73 11.54 46 Kusheshwarsthan 132/33 2 20 40 12.92 4.23 47 Kochas 132/33 2 20 40 12.82 2.45 48 Karbigahiya 132/33 4 50 200 58.75 19.02 49 Kudra 132/33 2 20 40 13.89 3.90 2 20 40 50 Khagaria 132/33 14.07 2.29 1 50 50 1 50 50 51 Kishanganj 132/33 21.17 6.29 1 20 20 52 Lakhisarai 132/33 3 20 60 38.11 12.44 53 Madhubani 132/33 2 20 40 8.47 2.76 54 Masaurhi 132/33 2 20 40 15.88 16.91 55 Mithapur 132/33 2 50 100 46.57 15.08 1 50 50 56 Mohania 132/33 32.04 9.26 1 20 20 1 20 20 57 Motihari 132/33 45.38 14.51 1 50 50 58 Masrakh 132/33 2 20 40 15.88 3.28 59 Muzaffarpur 132/33 3 50 150 65.63 21.42 60 Nalanda 132/33 2 20 40 26.67 8.76 61 Naugachhia 132/33 3 20 60 20.64 5.40 1 20 20 62 Nawada 132/33 41.81 8.19 3 50 150 2 20 40 63 Pandaul 132/33 22.79 2.22 1 50 50 64 Phulparas 132/33 2 20 40 25.40 8.35

111 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 1 20 20 55.04 18.09 65 Purnea 132/33 2 50 100

1 50 50 15.88 5.19 66 Rafiganj 132/33 1 20 20

67 Rajgir 132/33 2 20 40 26.57 8.66 68 Ramnagar 132/33 2 20 40 28.52 9.29 69 Raxaul 132/33 2 20 40 7.30 2.40 Remi nagar (Runni 70 132/33 2 20 40 7.62 2.48 Saidpur) 71 Sherghati 132/33 2 20 40 23.96 6.18 72 SKMCH 132/33 2 50 100 65.28 21.30 73 Sonebarsa 132/33 2 20 40 10.62 3.72 74 Sabour 132/33 3 50 150 66.69 21.76 75 Saharsa 132/33 1 20 20 25.40 9.54 76 Samastipur 132/33 2 20 40 28.79 8.90 77 Sasaram 132/33 2 50 100 31.75 3.04 78 Shekhpura 132/33 2 20 40 28.05 9.15 79 Sheetalpur 132/33 2 20 40 10.58 4.77 80 Sitamarhi 132/33 3 50 150 30.59 9.97 1 20 20 81 Siwan 132/33 47.63 15.66 2 50 100 1 50 50 82 132/33 40.49 13.38 1 20 20 Sonenagar 1 21.6 21.6 83 132/25 10.58 2.83 1 20 20 2 20 40 84 Sultanganj 132/33 16.63 4.57 2 50 100 85 Supaul 132/33 3 20 60 25.40 5.09 86 Tehta 132/33 2 20 40 6.35 0.86 87 Tekari 132/33 2 20 40 12.55 2.95 88 Udaikishanganj 132/33 2 20 40 9.31 2.01 89 Vaishali 132/33 2 20 40 16.94 5.94 90 Wazirganj 132/33 2 20 40 12.62 5.45 91 BodhGaya 132/33 1 50 50 54.49 4.32 92 Dehri 132/33 2 50 100 24.87 8.12 93 GopalGanj 132/33 2 50 100 42.13 13.27 94 Begusarai 132/33 3 50 150 61.39 54.12 120.6 95 Khagaul 132/33 5 50 250 39.65 7 96 Sipar 132/33 2 50 100 35.25 9.63 97 Fatuha 132/33 3 50 150 61.39 16.24 98 Bihar Sarif 132/33 1 20 20 0.00 0.00 2 20 40 31.42 9.38 99 Madhepura 132/33 1 100 100

100 Pussori New 132/33 1 50 50 97.00 21.05

112 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 101 Benipatti 132/33 2 20 40 4.93 0.13 102 Belsand 132/33 1 10 10 6.51 2.14 103 Mahanar3 132/33 2 20 40 6.12 1.99 104 Sheohar 132/33 2 50 100 9.02 2.93 105 Kishanganj New 132/33 1 50 50 9.38 1.19 106 Banmakhi 132/33 2 20 40 6.13 1.30 107 Hathua 132/33 2 20 40 10.58 3.48 108 Narkatiyaganj 132/33 2 20 40 3.75 1.23 109 Pupri 132/33 2 20 40 1.52 0.50 110 Tarapur 132/33 2 20 40 15.88 4.13 111 Trivenigaunj 132/33 2 20 40 4.39 0.54 112 SamastipurN 132/33 2 50 100 5.48 0.75 113 motipur 132/33 3 50 150 9.18 2.17 Traction 114 Arrah Rly 132/25 7.41 2.40

115 LakhisR 132/25 4.00 1.29

116 RafignR 132/25 3.40 1.10

117 DumarnR 132/25 3.00 0.54

118 HajiR 132/25 0.86 0.69

119 ChprR 132/25 6.49 2.10

120 KudraR 132/25 3.80 1.23

121 Mokama Rly 132/25 7.00 2.27

122 Railfactory Rly 132/25 10.00 2.97

123 Khsurupur Rly 132/25 6.00 1.97

124 Paharpur Rly 132/25 2.90 1.86

125 KCL Rly 132/25 0.80 2.00

126 JHAJA Rly 132/25 10.00 3.28

127 Khagaul Rly 133/25 4.00 1.34

128 Jehanabad_Railway 132 3.83 0.23

129 Dalsingsarai_R 132 2.70 0.18

130 Arrah RLY 132 5.00 1.61

Bihar Industry

131 Ordinance Factory( Rajgir) 132 0.40 0.13

132 Samastipur Trac 132 3.80 0.15

133 RailLoacal Plant (vaisali) 132 3.02 1.50

134 Shree Cement 132 18.00 2.91

135 Surajpur 132 21.76 7.16

136 Chandauli 132 0.00 0.00

137 BharatSM_Gen 132 0.00 0.00

113 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 138 Hasanpur SMG 132 0.00 0.00

139 SUGAULI 132 0.07 0.02

140 LAURIYA 132 0.07 0.02

141 Swdesi Sugarmill Gen 132 0.00 0.00

142 Narinagar SugerMill 132 0.60 0.20

Jharkhand 1 Chaibasa 132/33 2 50 100 8.79 2.89 1 20 2 Lalmatiya 132/33 120 25.00 8.21 2 50 3 Adityapur 132/33 4 50 200 89.43 -13.30 4 Chakradharpur 132/33 1 20 20 8.00 6.62 132/33 37.20 23.17 5 Dalbhumgarh Railway 2 50 100 6.00 2.03 feeder 6 Chaibasa 132/33 1 25 25 6.00 1.98 7 Chandil II/ Maniq 132/33 2 51.00 16.33

8 Deogarh 132/33 3 50 150 30.00 8.10 9 Dumka(Maharo) 132/33 2 50 100 20.00 5.78 1 50 10 Garhwa Rd 132/33 70 42.00 5.98 1 20 132/33 1 20 20 12.00 3.94 11 Goielkara Railway 3.00 0.99 feeder 12 Golmuri 132/33 2 50 100 34.00 11.17 13 Gumla 132/33 2 20 40 17.57 5.77 105.0 14 Hatia old 132/33 4 50 200 34.51 0 15 Tamar 132/33 2 50 100 13.00 0.33 16 Madhupur 132/33 2 50 100 16.40 3.40 2 20 17 Jadugoda 132/33 90 21.00 6.90 1 50 1 50 132/33 70 25.20 4.42 1 20 18 Jamtara Railway 8.00 1.40 feeder 19 Japla 132/33 2 20 40 16.00 2.28 2 20 20 Kamdara 132/33 60 30.50 10.50 1 20 21 Kanke 132/33 2 50 100 33.10 9.42 2 20 132/33 90 28.00 9.19 1 50 22 Kendposi Railway 6.00 1.97 feeder 23 Latehar 132/33 2 50 100 1.60 0.53 24 Lohardaga 132/33 2 50 100 31.70 10.42

114 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 25 Namkum 132/33 4 50 200 93.20 39.25 26 Nowamundi 132/33 1 50 50 0.00 0.00 27 Nowamundi Tata Steel 132 0.00 0.00

28 Pakur 132/33 2 50 100 23.07 6.69 132/33 2 50 100 0.00 0.00 29 Rajkharsawan Railway 8.30 3.16 feeder 30 Sahebgunj 132/33 2 50 100 10.53 3.61 31 Daltonganj 132/33 2 50 100 43.00 14.14 32 Manoharpur_JUSNL 132/33 4.00 5.95

33 Sikidri_JUSNL 132/33 9.50 8.00

34 Saljagiri RLY 132/25 - - - 0.00 0.00 35 Shankarpur RLY_deogarh 132/25 - - - 3.00 0.65 36 Tatisiloi RLY 132/25 - - - 10.80 5.23 37 Tolra RLY 132/25 - - - 16.00 2.28 38 Lodhma RLY 132/25 - - - 2.63 0.25 39 Bakaspur RLY 132/25 - - - 3.00 0.99 40 Chakradharpur RLY 132/25 - - - 9.36 3.10 41 Bano RLY 132/25 - - - 0.00 0.00

42 Umi Rly 132/25 - - - 2.90 2.08

43 Pakur Rly 132 0.02 0.22

DVC 2 80 160 132/33 46.64 24.84 44 Patherdih 1 50 50 132/25 9.67 4.92

45 Pattratu (DVC) 132/33 1 31.5 31.5 4.50 2.23 46 Gola 132/33 2 50 100 5.80 1.73 2 50 100 132/33 38.99 18.85 47 K'Dubi 1 80 80 132/25 8.55 8.55

132/33 1 20 20 11.15 2.97 48 Konar 132/25 5.30 1.67

49 Biada 132/33 2 80 160 30.00 8.54 50 BTPS'B 220 37.91 27.96

51 Dhanbad 220/33 2 80 160 21.70 4.99 52 Jamshedpur 132/33 3 45 135 13.80 2.55 1 80 80 78.19 24.65 53 Koderma 132/33 1 50 50 15.15 3.80 132/33 2 80 160 95.71 25.30 54 Ramgarh 132/33 1 50 50

55 Mosabani 132/33 2 20 40 21.21 7.05 56 Ramgarh_33 220/33 2 50 100 37.95 16.13 JUSNL Industry 1 HEC Hatia 132 9.41 3.84

115 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 2 Ushamartin 132 18.60 6.11

3 APL Ramchandrapur 132 16.22 12.91

4 ECL_Lalmatya_JUSNL 132 5.00 1.64

DVC industry 132/33 93.54 28.31 1 GIRDHI 220/33 27.35 11.94

2 North Karanpura 132/33 9.91 3.01

3 Govindpur 132 50.60 3.00

4 Hazaribag 132/33 47.23 15.60

5 Nimghat 132/33 33.00 10.40

145.5 6 Putki 132/33 65.50 0 7 Barhi DVC 132/33 47.00 22.00

8 CTPS 132/33 89.54 27.24

9 MHS-RB3 132/33 12.35 3.54

10 Panchet 132/33 11.90 0.59

11 Maniq Railway 132 2.09 0.65

12 Jamshedpur 220/132 17.50 52.91

13 JSPL 132 19.73 3.89

253.0 14 TISCO 400/132 17.43 0 15 Maniq DVC 132 11.50 -2.42

16 PDIL 132 0.19 0.62

130.0 17 BSL_DVC 220 68.00 0 Traction 1 ECRBR-D 132 0.00 0.00

ECRly North Karanpura 2 132 9.84 2.84 DVC 3 BSL-DVC 132 0.00 0.00

4 ElctrDVC /Dhanbad 220 32.30 29.10

5 Nimiaghat Railway 132/25 5.00 1.84

6 ECR Gomia 132 0.29 -0.14

7 MAL-Impex 132 36.00 4.00

8 Sermuri DVC 132 4.21 2.22

9 Pradhankant 132 3.50 2.50

10 BSLGD 132 0.00 0.00

11 Rajbera DVC 132 9.50 4.41

12 E C RLY(from sindri DVC) 132 6.48 0.90

Odisha 1 Mendhasal 220/33 1 20 20 15.00 0.78 2 63 132/33 73.39 22.84 2 Balasore 1 40 166 Railway Feeder 2.50 0.06

116 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 2 63 54.31 15.62 132/33 3 Bhadrak 1 40 166

Railway Feeder 5.73 0.53 2 63 74.70 30.40 4 Bidanasi 132/33 166 1 40

5 Budhipadar 132/33 1 20 20 6.20 0.67 2 63 6 Chandaka 132/33 166 91.00 31.38 1 40 2 20 132/33 34.80 23.40 1 12.5 52.5 7 Jayanagar Railway trac 2.80 -12.50 ChakusTr 0.00 0.00

3 20 8 Joda 132/33 100 18.75 5.65 1 40 1 100 220/132 2 160 9 520 27.80 8.90 Narendrapur 2 40 132/33 1 20 10 Railway (JagnathTr) 4.32 7.34

2 20 11 Paradip 132/33 52.5 28.50 7.20 1 12.5 12 Theruvali 132/33 2 12.5 25 12.00 2.22 1 20 13 Balimela 220/33 60 14.40 1.91 1 40 14 Barkote 220/33 2 40 80 15.00 3.92 1 40 15 Nayagarh 220/33 80 75.90 23.90 2 20 16 Duburi 220/33 2 40 80 9.92 3.00 17 Akhusingh 132/33 2 12.5 25 10.00 2.50 2 12.5 18 Anandapur 132/33 45 16.54 4.63 1 20 2 40 19 Angul 132/33 100 30.40 10.17 1 20 1 40 20 Argul 132/33 60 1.20 -0.80 1 20 21 Atri 132/33 1 20 20 0.00 0.00 22 Aska 132/33 3 40 120 27.00 13.76 1 40 132/33 1 20 30.15 7.92 23 Balugaon 72.5 1 12.5 Railway feeder (Solar trac) 4.41 1.20 24 Banki 132/33 2 20 40 10.80 2.20 132/33 2 12.5 25 7.44 2.90 25 Barbil traction 2.40 7.75

26 Baragarh 132/33 3 40 120 53.05 25.69

117 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 27 Baripada 132/33 3 40 120 69.00 24.00 1 20 28 Barpalli 132/33 60 32.18 13.48 1 40 2 40 29 Berhampore 132/33 100 44.81 15.63 1 20 1 12.5 30 Basta 132/33 32.5 13.00 3.42 1 20 2 40 31 Bhanjanagar 132/33 96 23.76 5.34 1 16 32 Bhawanipatna 132/33 2 12.5 25 6.66 2.59 33 Bhubaneswar (BBSR) 132/33 3 63 189 94.00 28.53 1 20 34 Boinda 132/33 45 18.40 4.20 2 12.5 35 Boudh 132/33 1 20 20 4.90 1.34 2 40 36 Bolangir 132/33 92.5 61.10 17.98 1 12.5 1 40 37 132/33 100 43.45 15.87 Brajrajnagar 3 20 38 132/11 1 12.5 12.5 3.72 1.26 2 40 39 Chainpal 132/33 100 49.23 14.94 1 20 40 Chandikhole 132/33 3 20 60 34.30 8.60 41 Chhandpur 132/33 2 12.5 25 9.40 2.00 132/33 3 20 33.73 14.46 42 Chhatrapur Railway Traction Feeder ( Ramba 60 2.33 2.28 trac ) 132/33 3 40 60.02 18.60 43 Chhend Railway Traction Feeder ( 120 0.07 4.27 Naugaon trac. ) 1 20 44 132/33 26.98 9.07 2 40 Choudwar 100 Railway Traction Feeder ( 45 7.30 1.70 Kendpur trac. ) 46 Cuttack 132/33 3 40 120 40.00 10.16 47 Dabugaon 132/33 2 12.5 25 6.50 0.72 48 132/33 3 40 120 57.39 21.54 Dhenkanal 49 traction (JorndaTr) 4.71 3.51

2 20 50 Digapahandi 132/33 52.5 32.75 10.12 1 12.5 51 Ganjam 132/33 2 12.5 25 7.43 2.53 52 Ganjam_132 132 10.30 1.26

2 20 132/33 80 32.20 8.48 1 40 53 Jagatsinghpur Railway Traction Feeder 7.80 2.70 (Goreknath Trac.) 55 Jajpur road 132/33 2 40 100 37.84 16.34

118 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 1 20 2 40 56 Jajpur town 132/33 100 47.97 16.07 1 20 2 31.5 132/33 20.41 7.22 57 Jaleswar 1 12.5 75.5 Railway Traction Feeder 9.53 1.08 132/33 1 40 40 9.50 3.22 1 20 20 58 Jharsuguda 132/11 0.00 0.00 1 12.5 12.5 Railway Traction Feeder 10.40 3.20

59 Junagarh 132/33 3 20 60 18.44 2.58 2 12.5 60 Kalarangi 132/33 45 27.81 7.43 1 20 61 Kalunga 132/33 2 40 80 31.00 10.24 1 20 62 Kamakshyanagar 132/33 45 17.65 4.17 2 12.5 2 12.5 63 Karanjia 132/33 45 7.32 2.03 1 20 2 40 64 Kendrapara 132/33 92.5 21.07 6.36 1 12.5 1 40 65 Kesinga 132/33 80 27.77 5.90 2 20 1 63 66 Kesura/Badagada 132/33 103 22.00 8.26 1 40 67 Khariar 132/33 2 40 80 38.07 9.11 132/33 3 40 120 68.99 8.52 68 Khurda Railway Traction Feeder ( Kaipad 11.87 2.89 trac ) 69 Konark 132/33 2 20 40 5.80 1.54 70 Kuchinda 132/33 2 20 40 18.71 5.35 71 Lapanaga 132/33 1 20 20 0.20 0.07 73 Mania 132/33 1 12.5 12.5 0.00 0.00 74 Marshaghai 132/33 2 20 40 3.96 1.52 75 Mohana 132/33 2 12.5 25 4.60 0.31 2 40 76 Nimapara 132/33 92.5 42.85 5.66 1 12.5 77 Nuapara 132/33 2 20 40 11.60 3.90 1 40 78 Nuapatna 132/33 1 20 72.5 36.89 11.56 1 12.5 79 Padampur 132/33 1 20 20 7.32 0.79 80 Parlakhemundi 132/33 3 12.5 37.5 8.23 4.47 1 40 6.08 81 Patnagarh 132/33 80 24.12 2 20

82 Pattamundai 132/33 2 20 52.5 30.72 7.06

119 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 1 12.5 2 12.5 83 Phulbani 132/33 65 20.45 4.05 1 40 84 Phulnakhara 132/33 2 20 40 14.22 4.21 1 40 85 Polasapanga 132/33 80 36.40 8.90 2 20 86 Polasapanga_132 11.20 0.69

87 Puri 132/33 3 40 120 36.00 10.20 88 Purusottampur 132/33 2 12.5 25 12.20 3.30 89 Rairakhole 132/33 2 12.5 25 11.75 2.82 2 20 90 Rairangpur 132/33 52.5 6.50 0.80 1 12.5 91 132/33 3 40 120 52.72 10.10 Rajgangpur 92 Railway Traction Feeder 2.68 2.45

2 63 93 Ranasinghpur 132/33 166 72.00 12.00 1 40 94 Rayagada 132/33 2 12.5 25 6.45 2.30 95 132/33 4 35 140 36.60 9.30 Rourkela 132/25 1 1.60 2.39 Railway Tr 1 10 96 Saintala 132/33 22.5 2.80 0.14 1 12.5 2 20 97 Salipur 132/33 52.5 29.80 9.30 1 12.5 2 31.5 98 Sambalpur 132/33 103 75.40 18.65 1 40 99 Shamuka 132/33 2 31.5 63 9.52 1.00 Sijua 132/33 3

100 Somnathpur 132/33 1 12.5 12.5 5.29 1.75 101 Sonepur 132/33 3 20 60 25.08 7.51 1 40 102 Soro 132/33 80 39.19 11.99 2 20 103 Sunabeda 132/33 3 12.5 37.5 23.60 5.00 1 40 104 Sundargarh 132/33 60 32.00 7.00 1 20 1 20 105 Tentulikhunti 132/33 32.5 15.74 4.16 1 12.5 106 Tarkera 132/33 1 12.5 12.5 0.00 0.00 107 Umerkote 132/33 2 20 40 16.20 5.10 108 Bolani 132/11 2 10 20 2.22 0.40 109 REN 220/33 2 20 40 5.05 1.08 110 Laksmi 220/33 1 20 20 6.98 1.40 132/33 2 20 111 Katpali 60 37.20 13.80 132/33 1 40

120 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 112 Bolangir_New 132/33 1 12.5 12.5 1.90 0.13 113 Rengli 132/33 2 20 40 14.00 3.06 114 Smangara 132/33 2 20 40 10.70 14.30 115 Rajgangpur 132/33 3 40 120 0.02 -0.54 Traction Load 1 BhultaTraction 132 5.48 1.80

2 Meramandali TR 132 7.40 1.90

3 Jakhpur Traction ( Dubri ) 132 16.00 8.00

4 Dharma Traction 132 2.60 1.01

5 Tomka Trac 132 0.00 0.00

6 Padwa Tr 132 5.00 1.64

7 Manbar Trac. 132 5.00 1.64

8 Maling Tr 132 5.00 1.64

9 KeonjharTr 132 4.20 2.79

Railwa 10 Talcher_R 132 4.20 1.10 y 11 Bamra Tr 132 0.00 0.00

Bulk Load 1 IMFA1 132 44.00 14.66

2 Damanjod 132 43.41 -30.10

3 IRE 132 6.05 1.83

4 FCI 132 0.40 0.19

5 Baminpl 132 9.92 0.50

6 Balasore Alloy 132 44.78 3.17

7 BirlaTyr 132 3.66 0.24

8 PPL 132 10.00 0.96

9 L&T Cem co 132 1.79 0.50

10 Power Max 132 0.69 0.23

11 MCL 132 17.00 3.00

12 Chandiposh 220 3.00 0.08

13 J K Paper 132 0.02 0.55

14 FAP-Joda 132 15.94 1.13

15 HAL 132 3.42 0.57

16 BRG 132 12.50 5.60

17 M L Rungta 132 0.01 0.30

18 PPT 132 12.00 4.74

19 RAW MET 132 11.09 -4.44

20 Hind Metalic 132 0.00 0.00

21 MESCO 132 3.56 1.18

22 ROHIT 220 30.75 2.00

23 Adhunik 132 19.27 6.39

24 Dahmra Prt 132 2.94 0.69

25 OCL_TA 132 7.78 2.58

26 Saliban (Bhuvi Profile) 132 1.49 0.50

27 ESSAR 220 4.00 2.09

121 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 28 IOCL 220 0.50 0.48

29 Jabamaye Fe 132 2.63 0.87

30 Beekay Steels 132 7.78 2.58

31 Arya 132 6.48 2.15

32 Bansapani 132 2.26 0.93

33 BC-monty 132 9.92 0.50

34 Saintla 132 3.63 0.16

134.8 35 Tata Steel 220 10.00 9 36 BRPL 132 7.35 2.44

37 MSL 132 3.23 0.83

38 VVC 132 0.00 0.00

39 JSPL 220 44.00 14.50

40 Greed Steel 132 0.00 0.00

41 BRP-St 132 3.47 1.15

42 Basundra 220 2.00 0.57

43 Utkal Aluminum 220 0.00 0.00

44 Adity Aluminum 220 0.00 0.00

45 Salibani 132 16.57 2.93

46 SPS 220 0.99 -1.00

47 Nandira 132 24.70 2.80

48 Sterling 400 0.00 0.00

49 Chiplma 132 19.00 6.30

50 Remja Load ( Budhipadar) 132 43.00 16.00

51 Joda_SMPL( Joda) 132 0.31 0.20

52 RSP_220 220 54.39 27.12

53 CTC_Feeder(BBSR) 132 20.83 9.18

CGP 1 Vedanta 132 0.00 0.00

2 FACOR 132 0.00 0.00

3 RSP 132 0.00 0.00

4 ACC 132 26.54 8.98

5 Bhusan#1G 220/11 34.30 11.60

6 Bhusan#2G 220/11 51.50 17.41

7 NBVL 132 55.80 18.86

8 IFFCO 132 5.00 1.64

9 NINL2 220 0.00 0.00

10 Maheswri 132 0.00 0.00

11 Shyam DRI 132 0.00 0.00

115.0 12 JINDAL 220 38.88 0 13 KMCLG 33/11 24.86 8.64

14 ICCL#1G 132/11 58.22 19.67

15 RSP#1G 132/11 43.00 14.50

122 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 16 RSP#2G 132/11 43.00 14.50

17 RSP#G3-7 132/11 68.00 22.90

884.0 290.5 18 NALCO#1G 220/10.5 0 5 706.0 238.7 19 Veda_135 220 0 2 20 MSP 132 0.00 0.00

21 AryanISt 132 2.62 -3.00

22 Bhusan2 220 66.00 21.69

23 EMAMI 132 0.00 0.00

24 maithan2 220 0.00 0.00

25 SMC1 132 0.00 0.00

26 OPCL 132 9.60 3.24

27 MERAMDL3 132 0.00 0.00

649.0 219.4 28 JSPLG 132 0 4 311.0 105.1 29 HinlcoG 132 0 6 30 BSSL 220 0.00 0.00

31 ICCL1 132 0.00 0.00

32 ICCL#3G 132 20.39 6.90

33 AryaIspt 132 14.57 4.93

34 SDRI_GEN 132 24.96 8.44

120.0 35 BHU3G 132 40.60 0 36 BHU5G 132 9.60 3.25

37 EMAMIG 132 10.75 3.63

38 EMAM2G 132 2.50 0.84

39 ICCL#2G 132 41.25 13.95

40 maheIsG 132 6.51 2.20

41 IFFCOG 132 24.43 8.26

42 VEDNT_GN 132 74.89 25.32

43 RathiG 132 0.00 0.00

44 visastlG 132 64.20 22.37

45 MAITHN 132 16.00 5.41

46 MSPG 132 9.50 3.21

47 INDAL#1G 132 55.36 18.72

216.3 48 INDAL#2G 132 73.14 0 49 AARTI#1 132 48.81 16.50

50 OCL-Raj 132 36.43 12.32

51 BSSL2G 132 38.77 13.10

52 BSSL1 132 11.87 4.01

53 Facor 132 32.58 11.02

54 NINL 132 15.00 5.06

55 SMCG 132 4.00 1.34

123 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 56 SMCG2 132 17.10 5.78

57 SrigaG 132 14.57 4.93

58 ActIspG2 132 16.61 5.62

59 ActnIsG 132 10.00 3.38

60 JSPL_4 132 0.00 0.00

61 BSSP3G 132 23.07 7.79

62 ActIspG3 132 62.16 21.00

289.0 63 Sterlite 132 41.89 0 125.0 64 BPPLGEN 132 18.33 0 125.0 65 BPPLGEN2 132 18.33 0 66 TSAlloy 132 0.00 0.00

Sikkim 1 5 5 1 Phodong 66/11 1.42 0.36 1 2.5 2.5 2 Bulbuley 66/11 2 10 20 4.99 1.25 2 10 20 3 Sichey 66/11 8.55 2.14 1 5 5 4 Tadong 66/11 3 5 15 4.99 1.25 5 Rongly 66/11 2 2.5 5 1.07 0.27 1 10 10 6 Mamring 66/11 1 7.5 7.5 6.77 1.73 1 15 15 7 Melli 66/11 2 5 10 2.14 0.55 8 Namchi 66/11 2 2.5 5 1.07 0.27 9 Rabangla 66/11 1 5 5 2.14 0.55 10 Rothak 66/11 2 2.5 5 1.07 0.27 11 Soreng 66/11 2 2.5 5 1.07 0.27 12 Geyzing 66/11 2 2.5 5 1.07 0.27 13 Purano Namchi 66/11 2 7.5 15 2.85 0.73 14 Pakyong 66/11 1 10 10 4.99 1.25 15 Pelling 66/11 1 5 5 2.14 0.55 16 Rhenock 66/11 1 5 5 2.14 0.55 17 Mangan 66/11 2 5 10 2.85 0.73 18 Ranipool 66/11 2 7.5 15 2.85 0.73 66/11 1 7.5 7.5 19 Topakhani 2.85 0.73 66/11 1 5 5 West Bengal 1 Arambagh 132/33 3 50 150 66.00 12.00 2 Bakreswar 220/33 1 50 50 30.00 10.00 104.4 3 Asansol 132/33 3 50 150 41.42 0 4 New_Bishnupur 132/33 2 31.5 63 16.00 6.00

124 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 5 Dalkhola 132/33 3 20 60 26.50 8.46 6 Dharampur 132/33 2 50 100 80.30 14.38 7 Domjur 132/33 3 50 150 79.00 17.03 8 Gokarna 132/33 3 50 150 63.80 21.12 9 Howrah 132/25 2 20 40 8.00 2.33 2 50 100 10 Krishnagar 132/33 93.00 30.56 1 31.5 31.5 1 31.5 Laxmikantpur 132/33 81.5 77.86 25.81 11 1 50 Laxmikantpur_railway 132/25 2 12.5 25 14.13 3.36 132/33 1 31.5 31.5 12 New Haldia 44.00 14.46 132/33 1 50 50 13 New Jalpaiguri 132/33 2 50 100 54.00 17.75 14 New town action area-III 220/33 2 50 100 48.00 8.00 15 Rishra 132/33 3 50 150 71.02 23.34 2 50 16 Satgachia 132/33 131.5 48.00 15.77 1 31.5 17 Subhashgram 132/33 2 31.5 63 60.92 8.68 18 Hura 132/33 2 50 100 17.80 5.85 19 Foundry park 132/33 2 50 100 26.00 8.50 20 Midnapur 132/33 2 50 100 64.50 21.20 Kolkata leather complex 21 132/33 3 50 150 66.50 8.00 (KLC) 2 50 132/33 131.5 87.79 10.57 22 Adisapthagram 1 31.5 Railway 2 20 40 15.28 8.73 2 16 132/66 52 13.38 6.30 23 Alipurduar 1 20 132/33 1 31.5 31.5 4.02 0.21 1 31.5 31.5 24 Amtala 132/33 59.00 19.55 1 50 50 132/33 2 50 100 70.50 11.68 25 Asoknagar 132/25 2 7.5 15 0.40 0.13 26 Bagnan GIS 132/33 2 50 100 48.80 16.03 27 Bagmundi 132/33 1 20 20 4.40 4.30 28 Balurghat 132/33 4 12.5 50 26.20 5.71 132/33 2 50 100 50.40 7.20 29 Bankura Railway 7.50 3.20

120.0 132/33 3 50 150 30.07 30 Barasat 0 Railway 4.00 1.31

110.8 31 Behala/ joka 132/33 3 50 150 25.77 6 32 Basirhat 132/33 2 50 100 88.00 15.59 33 Belmuri 132/33 2 31.5 63 24.00 2.67 34 Berhampore 132/33 3 50 150 98.50 29.40

125 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 35 Bighati 132/33 2 50 100 30.00 4.00 36 Birsingha 132/33 2 50 100 54.31 16.87 132/33 1 50 50 37 Bishnupur (old) 47.90 14.50 132/33 1 31.5 31.5 Bolpur 132/33 3 50 150 69.50 6.80 38 Bolpur_Prantik TSS 132/25 2.00 3.80

39 Bongaon 132/33 3 31.5 94.5 61.50 20.40 40 Barjora 132/33 2 31.5 63 20.00 2.00 41 Chanditala 132/33 2 50 100 40.00 2.66 1 50 132/33 81.5 47.90 18.50 42 Chandrakora road 1 31.5 Railway 1.80 1.80

132/33 2 50 100 74.50 20.50 43 Contai Railway 1.10 0.36

44 Coochbehar 132/33 3 50 150 58.50 19.39 45 Darjeeling 132/33 3 10 30 12.42 0.50 1 20 132/33 1 31.5 101.5 37.25 5.35 46 Debogram 1 50 Railway 2.76 0.63

47 Dhulian 132/33 2 31.5 63 26.00 2.20 121.0 48 Egra 132/33 3 50 150 6.51 0 2 31.5 63 49 Falta 132/33 70.00 23.19 1 50 50 3 20 50 Gangarampur 132/33 72.5 40.45 18.60 1 12.5 1 50 132/33 81.5 20.40 6.75 1 31.5 51 Haldia 1 10 132/25 22.5 0.96 0.32 1 12.5 52 Haldia NIZ 132/33 2 31.5 63 18.68 6.15 1 31.5 132/33 81.5 58.00 13.57 53 Hizli 1 50 132/25 2 10 20 11.20 2.20 54 Jangipara 132/33 2 31.5 63 20.00 2.00 1 31.5 31.5 55 Jhargram 132/33 46.62 13.05 1 50 50 56 Kurseong 132/33 3 10 30 7.40 1.70 57 Kakdwip 132/33 2 31.5 63 44.40 15.00 58 Kalan 132/33 2 31.5 63 42.00 15.40 1 31.5 59 Kalyani 132/33 81.5 60.16 21.73 1 50 60 Khatra 132/33 2 50 100 26.80 1.48 61 Katwa 132/33 2 31.5 63 58.26 34.57

126 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 1 50 50 Railway 0.30 0.17

62 Khanyan 132/33 2 31.5 63 32.00 10.50 132/33 3 50 150 51.00 16.89 63 Kolaghat 132/25 2 12.5 25 11.60 5.60 64 Lalgola 132/33 2 31.5 63 30.00 16.00 132/33 3 50 150 83.00 27.50 65 Lilooah 132/25 2 20 40 18.00 5.92 2 31.5 63 66 Mahachanda 132/33 48.03 13.10 1 50 50 1 50 50 67 Mathabhanga 132/33 30.50 10.02 1 31.5 31.5 68 Malda 132/33 3 50 150 95.00 41.67 69 Mahishpota 132/33 2 31.5 63 48.00 18.00

70 Mankar 132/33 3 31.5 94.5 48.60 18.00

1 31.5

71 Maynaguri 132/33 1 50 141.5 62.99 7.55

2 30 72 Nazirpur 132/33 2 31.5 63 30.00 9.86 North Bengal university 2 31.5 73 132/33 113 46.00 15.12 (NBU) 1 50 74 New town AA 1 132/33 2 50 100 63.60 20.90 75 Pingla 132/33 3 50 150 54.00 17.74 2 31.5 132/33 83 44.00 14.46 76 Purulia(WB) 1 20 132/25 2 12.5 25 4.30 1.41 1 31.5 77 Raghunathganj 132/33 1 20 101.5 67.00 22.02 1 50 78 Raghunathpur 132/33 2 31.5 63 22.98 5.33 1 31.5

79 Raigunj 132/33 2 20 96.5 53.00 17.42

2 12.5 80 Raina 132/33 2 50 100 80.10 26.32 81 Rampurhat 132/33 2 50 100 72.88 24.05 82 Rampurhat_railway 132 4.10 1.35

132/33 2 50 100 82.31 23.18 132/66 2 31.5 63 13.80 1.16 83 Ranaghat 1 12.5 132/25 22.5 3.07 0.77 1 10 84 Sainthia 132/33 2 50 100 44.20 14.52

127 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 85 Salt lake 132/33 3 50 150 78.30 25.73 86 Salt lake GIS 132/33 2 50 100 49.87 16.39 87 Samsi 132/33 3 31.5 94.5 67.40 22.15 88 Siliguri 132/33 2 50 100 41.90 9.92 132/33 3 31.5 94.5 62.20 20.44 89 Sonarpur 132/25 2 20 40 8.00 2.62 Tamluk 132/33 2 50 100 60.70 18.70 90 Tamluk Railway 3.70 2.30

1 31.5 91 Tarakeswar 132/33 81.5 41.80 13.85 1 50 Titagarh 132/33 3 50 150 84.00 27.60 92 Titagarh_railway 132/25 2 20 40 13.50 4.43 93 Ujaano (NBU _ NEW ) 132/33 2 31.5 63 20.80 6.90 94 Ukhra 132/33 2 50 100 64.20 12.90 95 Uluberia 132/33 3 50 150 91.00 19.20 96 Kuli 132/33 2 50 100 33.00 6.70 97 Food Park 132/33 2 50 100 9.60 2.99

98 Birpara 132/66 3 20 60 16.20 5.32

1 20 Chalsa_66 132/66 30 36.97 8.23 99 1 10 Chalsa_33 132/33 2 20 40 8.05 1.52 100 Serakol 132/33 2 50 100 32.84 10.79 101 Cossipur traction 132 5.00 1.50

102 Balichak 132 13.00 4.20

103 Dhatrigram Traction 132 4.00 0.00

104 Kalingpong 66/33 6.75 0.80

105 WBIDC_33 132/33 2 31.5 63 32.26 10.28 106 KhjrGIS3 132/33 2 50 100 6.60 2.35 107 Vidyasagar Park_33 220/33 2 50 100 17.00 5.58 108 TCF 132/33 2 20 40 32.00 10.50 109 Bajkul 132/33 2 50 100 32.00 10.73 DPL substations in West Bengal 132/11 1 20 20 28.91 9.51 1 A Zone 132/11 2 31.5 63 132/33 1 50 50 0.00 0.00 132/11 5 31.5 157.5 63.74 20.95 2 B Zone 132/33 1 31.5 31.5 1.08 3.28 132/33 1 50 50

3 AB Zone 132/33 1 50 50 1.63 0.27 132/11 3 31.5 94.5 17.48 7.25 4 C Zone 132/33 1 50 50 5.23 4.52 132/11 2 31.5 63 3.72 1.50 5 C1 Zone 132/33 2 50 100 18.61 4.42 6 Bamunara SS 132/34 2 50 100 20.03 3.83

128 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 7 Shayam Stl (DPL_C) 132 18.61 6.12

8 PCBL (DPL_AB) 132 16.43 10.14

9 Shayam Ferro(DPL_C1) 132 33.71 4.79

West Bengal DVC substations 1 Burnpur 220/33 2 50 100 0.90 0.60 2 Purulia 132/33 1 50 50 17.43 2.61 3 ASP 132 4 50 200 36.18 14.52 4 Jamuria 132/33 2 50 100 70.90 5.40 5 Kalipahari 132/33 2 80 160 57.66 18.55 6 Kalyaneswari 132/33 85.00 18.00

7 Mejia TPS 220/33 2 80 160 48.00 13.70 220/33 1 100 100 8 Barjora 220/33 1 80 80 81.37 5.53 220/33 1 50 50 220/33 1 50 50 126.0 9 Durgapur 8.00 220/33 2 80 160 0 10 DTPS_Waria 132/33 13.40 2.16

11 DTPS_Waria_railway 132/25 8.32 2.62

12 Belmuri_DVC 132/33 0.70 0.85

13 Belmuri_DVC_railway 132/25 17.81 5.85

14 Burdwan_DVC 132/33 74.00 11.82

15 Burdwan_trac_railway 132/25 3.00 6.00

16 Rumkanali_traction 132/25 4.00 1.09

17 Tamla traction 220 31.00 9.00

111.2 18 IISCOD 220 4.41 0 19 Sonic thermal-DVC 132 51.71 1.57

20 Badrinarayan Alloy 132 8.60 2.70

21 Parulia 220/33 56.00 4.32

22 Howrah_DVC_33 132/33 0.00 0.00

23 KGP_Traction_11 132/25 0.06 0.20

CESC 18.63 1 EMSS 38.5 8549 2 EMS-ter1 37.3 18.05 3 EMS-ter2 220/132 /33 5 160 800 37.3 18.05 4 EMS-ter3 37.3 18.05 18.63 5 EMSS_T5 38.5 8549 6 3 50 150 118 0.9 Belur 132/33 7 0 0

8 2 75 150 81 35 BT Road 132/33 9 0 0

10 B.Garden 132/33 2 50 100 108 49

129 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 9.774 11 132/33 5 50 250 39 321 9.499 12 Titagarh(trs) 57 973 8.209 13 53 934 14 Dum Dum 132/33 2 75 150 33 13.2 0.439 15 2 75 150 31.9 Park lane 132/33 742 16 0 0

Jadavpore 2 50 100 70 27 17 132/33 Jadavpore_2 1 55 55 35 6.3 18 Chakmir 132/33 2 55 110 73 30 19 Majerhat 132/33 2 75 150 101 14.8 1 68 35 4 20 BBD Bag 132/33 136 1 68 23 3.8 132/33 2 50 175 0 0 12.14 132/33 37 21 PRS 0686 3.452 132/33 1 75 82 144 16.35 39 22 East Calcutta 132/33 2 50 100 4884 70 24.5 2 50 100 39 35 23 NCGS 132/33 1 75 31.22 75 95 2 50 0607 19.65 24 SRS 132/33 2 55 110 129 7472 4.199 25 SRS_33 21 1 75 75 964

26 Patuli 132/33 2 75 150 32 8.7 27 WBRS 132/33 2 75 150 64 7.9 28 Park Circus 132/33 1 75 75 21 8.9 West Bengal Bulk Load 29 Resmi Bulk 15.00 4.96

30 Tata Metalic 15.00 4.96

31 SonarLal 10.01 1.32

32 HNIZ MICL 24.00 3.00

33 Ambuja Frakka 10.00 3.31

34 Dankuni 6.00 1.97

35 HPCL 7.70 13.80

36 Madras Cement 4.00 1.00

37 Rohit Ferro1 0.00 0.00

38 Manaksia 2.00 2.00

39 Bencon 0.25 2.06

130 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

33KV lump Substation details load SI. Voltage Capacity Name of the Sub-Station Total No level (kV) No. of of each capacity MW MVAr units unit (MVA) (MVA) 40 Rohit Ferro 0.00 0.00

41 Modern 9.10 0.38

42 BEL 15.40 5.06

43 OCL_Midnapore 1.00 0.00

44 Emami Cement 0.80 0.60

Jayshree ( from 45 10.43 3.45 liluahh_WB) 46 BRGSteeel 1.30 0.50

47 MCCPT 21.00 4.00

West Bengal IPCL Load 1 JK Nagar 220/33 2 100 200 45.00 9.14

131 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

ANNEXURE-II POWER MAP OF ER GRID AND ITS CONSTITUENTS STATES AND LINE LOADING DETAILS

132 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table G: 765 kV, 400 kV, 220 kV, 132 kV and 66 kV line flow (simulated result) of eastern region grid

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING Bihar line loading 765 kV

1 1 Fathepur Sasaram 112.00 -534.18 14.5 2 1 Balia Gaya -286.00 -32.78 7.6 PGCIL 3 1 Gaya Varanasi -163.70 150.62 5.8 4 1 Gaya Varanasi 163.49 -167.01 11.2 400 kV 5 1 Varanasi Biharshariff 3.52 -50.00 7.5 6 1 Varanasi Biharshariff 8.48 -58.92 4.8 7 1 Banka Biharshariff 243.95 -16.29 27.6 8 1 Banka Biharshariff 243.95 -16.29 27.6 9 1 Biharshariff Muzaffarpur 65.05 -2.99 10.9 10 1 Biharshariff Muzaffarpur 65.05 -2.99 10.9 11 1 Biharshariff Purnea LINE IS 0 12 1 Biharshariff Purnea LINE IS 0 13 1 Biharshariff Lakhisarai -172.76 73.71 21.2 14 1 Biharshariff Lakhisarai -172.76 73.71 21.2 15 1 Biharshariff Balia 83.48 -85.15 6.7 16 1 Balia Biharshariff -76.67 -43.14 6.7 17 1 Sasaram Biharshariff -270.65 -58.97 31.8 18 1 Sasaram Biharshariff -270.65 -58.97 31.8 19 1 Barh Kahalgaon -329.44 -58.84 19 20 1 Barh Kahalgaon -329.44 -58.84 19 21 1 Kahalgaon Banka 311.32 24.29 35.4 22 1 Kahalgaon Banka 311.32 24.29 35.4 23 1 Farraka Kahalgaon 1.42 2.27 6.4 PGCIL 24 1 Farraka Kahalgaon 1.42 2.27 6.4 25 1 Farraka Kahalgaon 38.67 -3.67 7.2 26 1 Farraka Kahalgaon 38.67 -3.67 7.2 27 1 Lakhisarai Kahalgaon -271.42 3.36 30.8 28 1 Lakhisarai Kahalgaon -271.42 3.36 30.8 29 2 Patna Kishanganj LINE IS 0 30 2 Patna Kishanganj LINE IS 0 31 1 Patna Barh -200.63 -69.54 12.1 32 1 Patna Barh -200.63 -69.54 12.1 33 1 Patna Barh -200.63 -69.54 12.1 34 1 Patna Barh -200.63 -69.54 12.1 35 1 Balia Patna -100.62 -38.74 6.6 36 1 Balia Patna -100.62 -38.74 6.6 37 1 Balia Patna -100.62 -38.74 6.6 38 1 Balia Patna -100.62 -38.74 6.6 39 1 Balia2 Brshrf-I -76.67 -43.14 6.7 40 1 Barh Gorakhpur 174.05 -13.07 13.9 41 1 Barh Gorakhpur 174.05 -13.07 13.9

133 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 42 1 Sarnath Sasaram -127.00 -43.05 16.2 43 1 NabinagarRly Sasaram LINE IS 0 44 1 NabinagarRly Sasaram LINE IS 0 45 1 Allhabad Sasaram -15.00 -2.14 7.2 46 1 Muzaffarpur Gorakhpur 170.83 35.61 13.4 47 1 Muzaffarpur Gorakhpur 170.83 28.45 13.4 Power link 48 1 Muzaffarpur Purnea -515.23 26.48 29.5 49 1 Muzaffarpur Purnea -515.23 26.48 29.5 50 2 Kishanganj Purnea 317.30 -38.65 18.1

51 2 Kishanganj Purnea 317.30 -38.65 18.1 52 1 Kishanganj Binaguri -431.78 40.19 25.1 53 1 Kishanganj Binaguri -431.78 40.19 25.1 54 1 Malda Purnea 47.16 35.52 9.6 55 1 Malda Purnea 47.16 35.52 9.6 56 1 Binaguri Purnea 294.11 -74.58 34.5 PGCIL 57 1 Binaguri Purnea 294.11 -74.58 34.5 58 1 Gaya Mathn-I -220.02 -74.43 13.3 59 1 Gaya Mathn-I -220.02 -74.43 13.3 60 1 Gaya Koderma -116.57 -127.82 9.9 61 1 Gaya Koderma -116.57 -127.82 9.9 220kv line 62 1 Bodhgaya Biharshariff LINE IS 0.00 63 1 Bodhgaya Biharshariff LINE IS 0.00 BSPTCL 64 1 MTPS Gopalganj 160.62 -21.88 38.40 65 1 MTPS Muzaffarpur -131.65 9.76 62.70 Power link 66 1 MTPS Muzaffarpur -131.65 9.76 62.70 67 1 Purnea Madhepura 62.64 -2.23 29.50 PGCIL 68 1 Purnea Madhepura 62.64 -2.23 29.50 69 1 Biharshariff Biharshariff 144.53 42.31 71.30 70 1 Biharshariff Biharshariff 144.53 42.31 71.30 BSPTCL 71 1 Biharshariff Biharshariff 144.53 42.31 71.30 72 1 Patna Khagaul 154.87 47.63 77.80 BSPHCL 73 1 Pusauli new Pusauli -119.91 -10.98 57.10 PGCIL 74 1 Pusauli Dehri -71.35 13.52 35.40 BSPHCL & PG 75 1 Arrah Pusauli -146.31 -15.80 72.10 PGCIL 76 1 Hajipur Muzaffarpur 87.81 4.80 41.60 77 1 Hajipur Muzaffarpur 87.81 4.80 41.60 BSPTCL 78 1 MTPS Darbhanga LINE IS 0.00 79 1 Gaya Dehri 84.31 -17.53 40.90 80 1 Gaya Dehri 84.31 -17.53 40.90 81 1 Gaya Bodhgaya 124.50 19.89 59.90 82 1 Gaya Bodhgaya 124.50 19.89 59.90 83 1 Patna Sipara 365.02 101.95 91.00 BSPHCL & PG 84 1 Patna Fatua LINE IS 0.00 85 1 Sipara Khagaul 118.76 35.47 59.50 86 1 Sipara Fatua LINE IS 0.00 87 1 Arraha PusaliNew LINE IS 0.00 88 1 Pusali Sahupura 229.11 -48.84 98.60

134 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 89 1 Samastipur Begusarai LINE IS 0 90 1 Samastipur Begusarai LINE IS 0 91 1 Hajipur Amnour 55.81 -6.38 26.80 92 1 Hajipur Amnour LINE IS

93 1 Begusarai Purnea_PG LINE IS 0 94 1 Begusarai Purnea_PG LINE IS 0 95 1 Purnea_PG Purnea_BS 71.17 7.56 33.3 96 1 Purnea_PG Purnea_BS 71.17 7.56 33.3 97 1 Gaya_PG Sonenagar New 160.34 -8.89 38.2 98 1 MTPS_Kanti Samastipur LINE IS 0 BSPTCL 99 1 MTPS_Kanti Samastipur LINE IS 0 100 1 Biharsarif TTPS -89.06 -8.76 18.9 101 1 Arrah Khagaul LINE IS 0 102 1 Fatua Biharsarif -125.71 -22.32 61 103 1 Fatua Biharsarif -125.71 -22.32 61 104 1 Biharsarif Begusarai 24.41 4.81 13.6 105 1 Arrah Khagaul LINE IS 0 106 1 Purnia_PG Purnea_BS 71.17 7.56 33.3 107 1 Purnia_PG Purnea_BS 71.17 7.56 33.3 108 1 Biharsarif Begusarai 24.41 4.81 13.6 132KV line BSPHCL & 109 1 Chandauti Karamnasa LINE IS 0.00 UPPCL 110 1 Bodhgaya Wajirganj 12.71 4.59 17.40 111 1 Sonenagar Japla 42.22 -11.51 54.20 112 1 Sonenagar Aurangabad 25.12 9.01 33.50 113 1 Sonenagar Aurangabad 25.12 9.01 33.50 114 1 Jehanabad Arwal 16.22 -2.51 21.20 115 1 Rafiganj Sonenagar LINE IS 0.00 116 1 Rafiganj Rafiganj_R 3.40 0.64 2.20 BSPTCL 117 1 Dehri Banjari 13.63 7.07 19.90 118 1 KCL Banjari -0.80 -1.97 2.60 119 1 Dehri Sasaram LINE IS 0.00 120 1 Dehri Sonenagar LINE IS 0.00 121 1 Dehri Sonenagar LINE IS 0.00 122 1 Dehri Bikramganj 23.68 0.73 28.90 123 1 Biharshariff Rajgir 28.12 -7.78 36.30 BSPTCL & 124 1 Biharshariff Barh LINE IS 0.00 DVC 125 1 Biharshariff Hathidah -5.59 22.83 31.10 126 1 Biharshariff Nalanda 27.93 0.33 34.80 127 1 Biharshariff Ekangasarai 41.63 10.36 53.40 128 1 Biharshariff Nawada 42.69 9.52 54.50 129 1 Biharshariff Sheikhpura LINE IS 0.00 BSPTCL 130 1 Hathidah Sheikhpura LINE IS 0.00 131 1 Hathidah Lakhisarai -70.70 0.18 89.50 132 2 Lakhisarai Jamui 71.16 13.80 44.20 133 2 Jamui Jhajha_R 10.02 0.26 6.50

135 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 134 1 Lakhisarai Lakhisarai_R 4.00 0.98 5.20 135 1 Jamui Sheikhpura 28.67 10.62 38.90 136 1 Rajgir Barhi LINE IS 0.00 137 1 Jamalpur Tarapur 0.00 0.00 0.10 138 1 Tarapur Sultanganj 15.93 4.84 20.30 139 1 Sultanganj Sabour LINE IS 0.00 140 1 Sultanganj Sabour LINE IS 0.00 141 1 Jamalpur Lakhisarai -30.56 -10.95 40.40 142 2 Lakhisarai Lakhisarai -145.48 -28.57 91.70 143 1 Lakhisarai Jamui LINE IS 0.00 144 1 Sabour Kahalgaon LINE IS 0.00 PGCIL 145 1 Dumraon Arrah -60.30 5.83 80.70 146 1 Dumraon Dumraon_R 3.00 0.42 4.00 147 1 Dumraon Buxar 28.46 -1.45 37.90 148 1 Arrah_PG Arrah_BSEB 63.49 8.91 82.30 149 1 Arrah_PG Jagdishpur 19.53 0.89 25.10 150 1 Purnea_BSEB Banmakhi 69.76 -3.29 84.20 151 1 Banmakhi Saharsa 63.57 -4.89 76.90 152 1 Purnea_BSEB Trivenigaunj 22.63 -6.68 28.40 153 1 Trivenigaunj Forbesganj 18.03 -5.83 22.90 154 1 Saharsa Udakishanganj LINE IS 0.00 155 1 Saharsa Madhepura 38.09 -7.07 46.70 156 1 Khagaul Purnea LINE IS 0.00 157 1 Muzaffarpur SKMCH LINE IS 0.00 158 1 Samastipur Begusarai LINE IS 0.00 159 1 Samastipur Hajipur LINE IS 0.00 160 1 Pandauli Madhubani 0.00 0.00 1.00 161 1 Hajipur Hajipur 0.86 0.57 1.40 162 1 Gopalganj Mashrakh 16.21 -15.36 27.30 163 1 Chhapra Chhapra 6.49 1.94 8.80 BSPTCL 164 1 Siwan Mushark 0.00 0.00 0.10 165 1 Mushark Gopalganj 16.21 -15.36 27.30 166 1 Ekma Ekma 6.38 -5.90 10.90 167 1 Motihari Dhaka 16.00 4.70 22.00 168 1 Bettiah Motihari LINE IS 0.00 169 1 Bettiah Gopalganj -43.39 4.86 54.90 170 1 Bettiah Gopalganj -43.39 4.86 54.90 171 1 Ramnagar Bettiah -51.48 -1.04 65.70 172 1 Ramnagar Swadesi_G LINE IS 0.00 173 1 Darbhanga Darbhanga -80.71 9.90 99.20 174 1 Darbhanga Samastipur 1.64 -2.68 3.80 175 1 Kahalgaon Sabour LINE IS 0.00 176 1 Kahalgaon Lalmatia 26.07 -7.19 32.10 177 1 Kahalgaon Lalmatia 15.77 -7.19 20.60 178 1 Belaganj Chandauli -8.48 4.86 12.90 179 1 Belaganj Hjehanabad LINE IS 0.00 180 1 MTPS Samastipur -4.76 -6.44 9.90 181 1 MTPS Samastipur -4.76 -6.44 9.90

136 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 182 1 Sitalpur Chhapra 47.91 5.63 60.90 183 1 Jainagar Pulparas -37.74 21.76 55.00 184 1 Pulparas Supaul -3.79 0.09 5.10 185 1 Pulparas Supaul -3.79 0.09 5.10 186 1 Supaul Katiya 8.94 -1.31 11.20 187 1 Supaul Katiya 8.94 -1.31 11.20 188 1 Mohania Karmansa LINE IS 0.00 189 1 Dehri Kochas LINE IS 0.00 190 1 Bikranganj Dumraon LINE IS 0.00 191 1 Forbesganj Katiya 83.93 3.82 51.20 192 2 Forbesganj Katiya 83.93 3.82 51.20 193 1 Barh Hathidah_R -34.01 -13.16 46.70 194 1 Pusauli Sasaram 31.94 -12.15 41.80 195 1 Katiya Duhabi 102.16 14.62 49.90 196 1 BarauniTPS Khagaul 14.23 -8.12 20.10 197 1 BarauniTPS Begusarai 26.14 14.29 36.80 198 1 BarauniTPS Begusarai 26.14 14.29 36.80 199 1 Surjapur Balmikinagar -21.77 1.85 28.30 200 1 MTPS Muzaffarpur 57.42 2.95 70.90 201 1 MTPS Muzaffarpur 57.42 2.95 70.90 202 2 MTPS Vaisali 52.33 -4.52 32.70 203 1 MTPS SKMCH 80.34 17.83 50.70 204 1 Kudra_R Karmansa 24.17 -5.05 30.30 205 2 Mithapur Karbigahia 27.64 6.92 19.40 206 1 Kudra new Dehri -31.87 11.01 42.20 207 1 Pusauli Kudra -5.02 7.91 12.70 208 1 Kudra Kochas 12.90 -6.42 17.60 209 1 Chandauli Bodhgaya LINE IS 0.00 210 1 Chandauli Bodhgaya LINE IS 0.00 211 1 Chandauli Bodhgaya LINE IS 0.00 212 1 chandauli Bodhgaya LINE IS 0.00 213 2 Bodhgaya Paharpur 2.90 -1.55 2.10 214 1 chandauli Tekari 24.75 -1.91 31.10 215 1 Balmikinagar Ramnagar -21.80 2.08 29.00 216 1 Purnea Katihar 26.25 9.28 34.20 217 1 Purnea_PG Kishanganj -8.44 -4.22 11.40 218 1 Purnea_PG Purnea 68.30 5.95 26.80 219 1 Purnea_PG Purnea 68.30 5.95 26.80 220 1 Purnea_PG Purnea 68.30 5.95 26.80 221 1 Masaurhi Jehanabad 41.91 -3.84 53.90 222 1 Masaurhi Sipara -57.83 -5.99 74.30 223 1 Pusauli Mohania 70.61 -9.10 86.80 224 1 Kahalgaon TPP Kahalgaon 45.59 8.81 55.10 PGCIL 225 1 Hathidah_R Mokama_R 7.00 1.92 9.40 226 1 Hathidah_R Hathidah -41.15 -14.96 55.70 227 1 Nalanda Rajgir LINE IS 0.00 BSPTCL 228 1 Raxaul Bettiah -7.32 2.17 10.40 229 1 Runisaudpur Sitamarhi LINE IS 0.00

137 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 230 1 Tekari Goh 11.99 -4.40 16.10 231 1 Wazirganj Nawada LINE IS 0.00 232 1 Ekangasarai Hulasganj 19.85 5.29 26.30 233 1 Biharshariff Hulasganj LINE IS 0.00 234 1 Gangwara Pandauli 0.00 -1.34 1.60 235 1 Madhepura Supaul 54.74 -5.10 67.00 236 1 Madhepura Supaul 54.74 -5.10 67.00 237 1 Madhepura Sonbhadra 20.20 2.95 25.50 238 1 Mashrakh Siwan LINE IS 0.00 239 1 Dalsingsarai Siwan LINE IS 0.00 240 2 Jehanabad Tehta LINE IS 0.00 241 1 Begusarai Dalsingsarai 25.97 -1.76 32.10 242 1 Jandaha Samastipur LINE IS 0.00 243 1 Hazipur Jandaha 22.54 -6.68 29.40 244 1 Begusarai Kuswesthan 13.07 1.85 17.20 245 1 Sherghati Bodhgaya -24.08 -8.08 32.10 246 1 Immamganj Bodhgaya -13.37 -4.62 17.70 247 1 Purnea naughat 30.83 -2.94 37.30 248 1 Railfactory Sitalpur -10.00 -2.87 13.20 249 1 Muzaffarpur Dhalkera 133.86 32.07 33.10 250 1 Khagul Bihta 90.07 23.77 59.60 251 1 Khagul Fatua LINE IS 0.00 252 1 Digha Khagul -55.21 -6.43 35.60 253 1 Khagul Khagaul Rail 4.00 1.26 5.40 254 1 Mithapur Gaighat LINE IS 0.00 255 1 Katra Fatua -75.05 -10.10 95.90 256 1 Sipara Mithapur 75.34 12.09 96.00 Jakkanpur 257 1 Mithapur LINE IS 0.00 (Patna) Jakkanpur 258 1 Sipara -126.88 -20.07 82.00 (Patna) 259 1 Khusrupur RLY Fatua -6.00 -1.92 7.90 260 1 Fatua Harnuth LINE IS 0.00 261 1 Fatua Sipara 39.00 -2.31 48.70 262 1 Harnuth Baripahari -19.62 -5.78 25.80 263 1 Baripahari Biharshariff -84.55 -30.31 56.10 264 1 Baripahari Fatua LINE IS 0.00 265 1 Sabour BankaPG -67.00 -27.07 43.90 266 1 Rafiganj Chandauti (Gaya) -19.30 1.53 24.70 267 1 Karmnasa Sahupura LINE IS 0.00 268 1 Fatua Gaighat 68.15 9.08 85.70 269 1 Naugachhia BaruniTPS 9.53 -7.05 14.50 270 1 Sitamarahi Dhaka LINE IS 0.00 271 1 Hazipur Sheetalpur 37.22 -2.57 46.70 272 1 Hazipur Hazipur New -95.41 -18.99 60.80 273 1 Chapra Ekma Tap LINE IS 0.00 274 1 Motihari Motipur 63.53 16.60 81.10 275 1 Motipur MTPS -1.52 -2.26 3.40

138 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 276 1 Vaishali Sheetalpur 31.90 4.91 20.60 277 1 Banka Banka PG -31.85 -12.15 20.70 278 1 Kishanganj Dalkhola LINE IS 0.00 Chandauti 279 1 Sipara 14.00 -6.34 9.60 (Gaya) 280 1 Sultanganj Kahalgaon LINE IS 0.00 281 1 Ekma Traction Siwan -6.38 5.90 12.40 282 1 Banka PG Sultanganj 32.81 0.33 20.00 283 1 Kochas Dumaraon LINE IS 0.00 284 1 Pusali Kudra Rail 28.05 -4.14 34.70 285 1 Karbigahiya Jakkanpur(Patna) -31.28 2.32 40.10 286 1 Naugachhia Begusarai LINE IS 0.00 287 1 Sonebarsha Udakishanganj 9.36 0.88 11.90 Jehanabad 288 1 Jehanabad 3.83 0.19 5.00 Traction 289 1 Rihand Sonenagar -13.78 5.72 24.50 290 1 Dehri Karamnasa LINE IS 0.00 291 1 Dehri Karamnasa LINE IS 0.00 292 1 Kishanganj New Kishangaunj 92.82 -0.88 21.60 293 1 Kishanganj New Kishangaunj 92.82 -0.88 21.60 294 1 Sonenagar New Sonenagar 79.05 -2.07 97.80 295 1 Dalsingarai Kusheswar LINE IS 0.00 296 1 Dalsingarai Kusheswar LINE IS 0.00 297 1 Arrah Arrah Rail 7.41 2.12 10.00 298 1 Madhubani Phulparas LINE IS 0.00 299 1 Benpatti Tap Jainagar -24.69 17.88 37.70 300 1 Kishanganj New Forbesganj 73.55 -10.94 44.30 301 1 Darbhanga Gangawara 44.36 -1.20 54.10 302 1 Bharti Gen Gopalgaunj LINE IS 0.00 303 1 SKMCH Belsand 14.21 -1.25 17.80 304 1 Sherghati Bodhgaya -24.08 -8.08 32.10 305 1 Imamgaunj Bodhgaya -13.37 -4.62 17.70 306 1 Hari Sugar Mill Ramnagar -0.60 -0.19 0.80 307 1 Tetha Chandauti (Gaya) -6.36 -0.97 8.10 308 1 Tetha Chandauti (Gaya) -6.36 -0.97 8.10 309 1 HasnpSM Dalsingarai LINE IS 0.00 310 1 SUGAULI Mothihari -0.07 -0.02 0.60 311 1 LAURIYA Ramnagar -0.07 -0.02 0.6* 312 1 Sasaram1 Banjari LINE IS 0.00 313 1 Madhubani Benpatti Tap -18.06 17.52 31.70 314 1 Aurangabad Shree Cement 18.01 2.75 22.80 315 1 Arrah BS Arrah RLY 5.00 1.47 6.70 316 1 Belsand Runisaidpur 7.64 -2.88 10.20 317 1 Dhaka Sheohar LINE IS 0.00 318 1 Sitamari Sheohar 9.05 1.95 12.40 319 1 Gaighat Katra LINE IS 0.00 320 1 Jandha Mahanar 6.16 -1.59 8.20 321 1 Samstipur Samasti Trac 3.80 0.10 4.60

139 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 322 1 Kishanganj New Kishngaunj 102.13 -3.09 60.90 323 1 Benipatti Tap Benipati 6.47 0.59 8.00 324 1 Darbhanga Pandaul 23.00 -5.59 28.90 325 1 Phulparas Pandaul 0.00 -2.28 2.80 326 1 Madhubani Darbhanga 9.55 -2.71 12.10 Jharkhand line loading 765 kV 1 1 Ranchi New Dharamjaygarh -140.80 -164.89 5.6 PGCIL 2 1 Ranchi New Dharamjaygarh -140.80 -164.89 5.6 400 kV 3 1 Aadhunik Jamshedpur 242.76 -1.98 13.6 APNRL 4 1 Aadhunik Jamshedpur 242.76 -1.98 13.6 5 1 Maithon Jamshedpur -21.68 -61.67 7.4 Durgapur 6 1 Jamshedpur -326.62 -31.93 36.7 (DSTPS) Durgapur 7 1 Jamshedpur -326.62 -31.93 36.7 (DSTPS) PGCIL 8 1 Jamshedpur Mejia B -154.46 -52.53 18.3 9 1 Chaibasa Jamshedpur -240.66 -44.52 27.6 10 1 Chaibasa Jamshedpur -240.66 -44.52 27.6 11 1 TISCO Jamshedpur -343.13 -16.01 38.6 DVC 12 1 Parulia (PGCIL) Jamshedpur 78.65 -61.90 11.2 13 1 MPL Ranchi 152.26 6.90 17 14 1 MPL Ranchi 152.26 6.90 17 15 1 Ranchi RanchiP 180.54 29.86 11.3 16 1 Ranchi RanchiP 180.54 29.86 11.3 17 1 Ranchi RanchiP 180.54 29.86 11.3 18 1 Ranchi RanchiP 180.54 29.86 11.3 19 1 Ranchi Maithon -126.48 -62.77 15.9 20 2 Ranchi Chandwa 523.98 81.65 15.7 21 1 Ranchi Sipat -196.11 -75.32 23.7 22 1 Ranchi Sipat -196.11 -75.32 23.7 23 1 Raghunathpur Ranchi 262.24 -23.08 29.9 24 1 Raghunathpur Ranchi 262.24 -23.08 29.9 25 1 Gaya Maithon -220.02 -74.43 13.30 PGCIL 26 1 Gaya Maithon -220.02 -74.43 13.30 27 1 Maithon Mejia B -14.79 2.60 2.10 28 1 Mejia B Maithon 348.40 34.86 39.70 29 1 Mejia B Maithon 348.40 34.86 39.70 30 1 Maithon Kahalgaon 152.38 -43.11 17.90 31 1 Maithon Kahalgaon -29.82 -10.50 5.70 32 1 Maithon MPL -103.45 -11.47 11.60 33 1 Maithon MPL -103.45 -11.47 11.60 34 1 Maithon Parulia (PGCIL) 148.71 7.42 17.40 35 1 Maithon Parulia (PGCIL) 148.71 7.42 17.40 36 1 Raghunathpur Maithon 356.36 6.24 39.60 37 1 Gaya Koderma -116.57 -127.82 9.90 38 1 Gaya Koderma -116.57 -127.82 9.90

140 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 39 1 Koderma Biharshariff 219.36 -52.48 12.70 40 1 Koderma Biharshariff 219.36 -52.48 12.70 41 1 Koderma Bokaro (BTPS) -172.62 -37.41 19.90 42 1 Koderma Bokaro (BTPS) -172.62 -37.41 19.90 43 2 Chandwa Gaya 523.07 -58.74 15.20 44 1 Chaibasa Bisra -12.78 -28.78 3.50 45 1 Chaibasa Bisra -12.78 -28.78 3.50 46 1 Ranchi PG PPSP 128.84 -62.82 16.10 47 1 Ranchi PG PPSP 128.84 -62.82 16.10 220kV 48 1 Kalyaneshwari Mejia-D -95.89 9.07 45.9 49 1 Kalyaneshwari Mejia-D -95.89 9.07 45.9 50 1 Kalyaneshwari Mejia-D -95.89 9.07 45.9 51 1 CTPS-new BTPS-B 42.83 -28.37 24.5 52 1 CTPS-new BTPS-B 42.83 -28.37 24.5 53 1 CTPS-old Kalyaneshwari -24.21 -14.00 13.4 54 1 CTPS-old Kalyaneshwari -24.21 -14.00 13.4 55 1 CTPS-New Dhanbad 35.82 -7.20 17.4 56 1 Kalyaneshwari Maithon -30.68 -55.27 29.9 57 1 Kalyaneshwari Maithon -30.68 -55.27 29.9 58 1 BTPS-B Jamshedpur 44.61 -1.97 22.7 59 1 BTPS-B Jamshedpur 44.61 -1.97 22.7 DVC 60 1 Giridhi Dhanbad -77.92 -7.48 37.4 61 1 Giridhi Dhanbad -77.92 -7.48 37.4 62 1 Maithon Dhanbad 191.73 26.27 45.5 63 2 Ramgarh BTPS-B -161.88 -30.82 39.6 64 1 CTPS-old CTPS-New -147.50 -43.71 72.7 65 1 CTPS-old CTPS-New -147.50 -43.71 72.7 66 1 Kalyaneshwari Maithon -30.68 -55.27 29.9 67 1 Kalyaneshwari Maithon -30.68 -55.27 29.9 68 2 BSL CTPS-New -130.00 -66.88 35.1 69 1 CTPS-New Dhanbad 35.82 -7.20 17.4 70 1 Ramchandapur Jamshedpur -133.88 -11.01 62.3 71 1 Ramchandapur Jamshedpur -133.88 -11.01 62.3 72 1 PTPS-TPS Hatia 6.26 0.19 4.1 73 1 PTPS-TPS Hatia 6.26 0.19 4.1 74 1 PTPS-TPS TTPS -33.78 -15.24 7.8 75 1 KTPP Giridhi -5.99 1.46 7.8 76 1 KTPP Giridhi -5.99 1.46 7.8 JUSNL 77 1 RanchiTG Chandil 30.52 -11.06 15.2 78 1 Maithon Dumka 24.10 -20.37 6.6 79 1 Maithon Dumka 24.10 -20.37 6.6 80 2 RanchiTG Hatia 212.83 50.95 51.1 81 1 Chandil Ramchandapur -74.27 -16.87 35.6 82 2 Chaibasa Chaibasa 8.80 2.83 2.2 83 2 Maithon Dhanbad 191.73 26.27 45.5

141 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING BSPHCL & 84 2 PTPS-TPS Bodhgaya LINE IS 0 JSEB BSPHCL & 85 1 PTPS-TPS Bodhgaya LINE IS 0 JSEB WBSETCL & 86 1 Chandil STPS -40.45 14.74 23 JSEB 87 2 Dhanbad Elctro SteelD 32.37 13.12 10.4 PGCIL 88 1 CTPS-New BTPS-B2 42.83 -28.37 24.5 89 1 CTPS-New BTPS-B2 42.83 -28.37 24.5 DVC 90 1 Ramghar Gola 0.00 -6.81 1.6 132kV 91 2 ManiqueD GolaD -36.94 -10.62 24.6 92 2 ManiqueD Jamshedpur -27.90 -0.73 18 93 1 CTPS-B Putki 41.09 16.21 48.6 94 1 CTPS-B Putki 41.09 16.21 48.6 95 1 CTPS-B Putki 41.09 16.21 48.6 96 1 CTPS-B Putki 41.09 16.21 48.6 97 1 BTPS-B-D ECR-GomD 0.15 -0.40 0.5 98 1 BTPS-B-D ECR-GomD 0.15 -0.40 0.5 99 1 CTPS-A PuruliaD 20.03 -1.70 22.1 100 1 CTPS-A PuruliaD 20.03 -1.70 22.1 101 1 Jamshedpur MosabaniD 35.41 1.82 39.9 102 1 Jamshedpur MosabaniD 35.41 1.82 39.9 103 1 CTPS-A GolaD 32.75 -9.28 37.4 104 1 CTPS-A GolaD 32.75 -9.28 37.4 105 1 Ramgarh GolaD -8.49 10.09 15.5 106 1 Ramgarh GolaD -8.49 10.09 15.5 107 1 PatratuD North karnpuraD 9.92 -2.58 12.8 108 1 PatratuD Ramgarh -22.94 3.61 25.9 109 1 PatratuD Ramgarh -22.94 3.61 25.9 DVC 110 1 PatratuD North karnpuraD 9.92 -2.58 12.8 111 2 PatratuD JSPL 19.73 -3.92 22.2 112 1 MaithonD KumardubiD 41.14 22.47 58.4 113 1 Klyaneshwari MaithonD 75.21 17.54 84.8 114 1 MaithonD Panchet 9.48 3.52 12.9 115 1 KumardubiD Panchet -6.61 -5.81 11 116 1 MaithonD PatherdhiD 35.32 10.17 45.8 117 1 MaithonD PatherdhiD 35.32 10.17 45.8 118 1 PatherdhiD SindriD 5.09 0.49 6.6 119 1 PatherdhiD SindriD 5.09 0.49 6.6 120 1 PatherdhiD Putki 0.99 -3.52 4.1 121 1 PatherdhiD Putki 0.99 -3.52 4.1 122 1 Putki Nimiaghat 7.98 -10.21 16.5 123 1 Putki Nimiaghat 7.98 -10.21 16.5 124 1 Nimiaghat GiridhiD -11.15 -7.95 17.3 125 1 Nimiaghat GiridhiD -11.15 -7.95 17.3 126 1 BarhiD BTPS-B-D -28.65 -2.95 36.4 127 1 BarhiD Konar -23.53 -2.56 29.9

142 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 128 1 BarhiD KTPP -21.47 -10.70 30.5 129 1 BarhiD Hazaribhag 23.96 8.11 32.9 130 1 BarhiD Hazaribhag 23.96 8.11 32.9 131 1 BarhiD KTPP -21.47 -10.70 30.5 132 1 Konar BTPS-B-D -40.38 -2.68 50.6 133 2 RamkanaliD Panchet 9.08 0.79 5.8 134 1 CTPS-B RamkanaliD LINE IS 0 135 1 CTPS-B Jamuria 0.01 -5.71 6.3 136 2 MosabaniD KharagpurD 5.12 -10.64 6.8 137 2 KodermD1 KTPP -93.82 -36.17 64.1 138 1 SindriD Pradhankhanda 1.75 0.30 2.7 139 1 SindriD Pradhankhanda 1.75 0.30 2.7 140 2 DHANBAD1 GovndrD 50.90 1.33 31.3 141 1 CTPS-A BSL-DVC LINE IS 0 142 1 CTPS-A BSL-DVC LINE IS 0 143 1 CTPS-A Rajbera_DVC 9.50 4.09 11.5 144 2 CTPS-B BiadaDVC 30.14 8.90 17.5 145 2 Putki BalhrDVC -0.91 2.22 2.7 146 1 Ramgarh ECR Barkakana LINE IS 0 147 2 ECRlyDVC North karnpuraD -9.84 -2.77 5.7 148 1 Klyaneshwari MaithonD 75.21 17.54 84.8 149 1 CTPS-A CTPS-B -20.68 28.90 17.3 150 1 BSLGD CTPS-B LINE IS 0 151 1 PatherdhiD BalhrDVC 0.91 -3.33 3.9 152 2 GolaD SER Muri 4.21 -0.70 2.6 153 2 Klyaneshwari MAL-Impex ferro 36.02 3.89 45 154 1 ManiqueD Manique R 2.09 0.44 2.8 155 1 CTPS-A Rajbera_DVC 9.50 4.09 11.5 156 1 Garhwa Japla -24.74 12.80 36 157 2 Dhalbhumgarh DhalbhumgarhRL 6.00 1.75 4.1 158 1 Lohardaga Gumla 5.33 0.94 8.6 159 1 Lohardaga Gumla 5.33 0.94 8.6 160 1 Kamdara Gumla 7.06 -4.51 10.6 161 1 Hatia Old Sikadari -27.59 4.58 35.1 162 1 Hatia New Namkum 40.61 21.11 56.6 163 1 Hatia Old Kamdara 41.71 0.12 51.6 164 1 Kamdara Bakaspur R 3.00 0.27 4 165 1 Kamdara Bano R LINE IS 0 JUSNL 166 1 Hatia Old Hatia New -47.04 -11.50 59.9 167 1 Hatia Old Hatia New -47.04 -11.50 59.9 168 1 Namkum Sikadari -67.40 -8.62 85.9 169 1 PTPS Kanke 40.57 9.58 33 170 1 PTPS Hatia Old 30.45 5.44 24.9 171 1 Deoghar Sultanganj 0.00 0.00 6.4 172 1 Deoghar Jamtara LINE IS 0 173 1 Deoghar Shankarpur R 3.00 0.08 3.7 174 1 Deoghar Dumka -16.53 5.78 22.6 175 1 Deoghar Dumka -16.53 5.78 22.6

143 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 176 1 Dumka Lalmtiya -14.49 3.16 19.7 177 1 Dumka Lalmtiya -14.49 3.16 19.7 178 1 Dumka Pakur 23.56 -4.09 28.5 179 2 Dumka Dumka 24.51 -13.64 16.7 180 1 Kendposi Chaibasa -26.13 -0.99 32.2 181 2 Kendposi Kendposi 6.00 1.55 3.9 182 1 Manique Chandil LINE IS 0 183 1 Adityapur Ushamartin 9.30 2.89 11.8 184 1 Adityapur Ushamartin 9.30 2.89 11.8 185 1 Golmuri Jharsuguda 21.14 -1.26 25.6 186 1 Golmuri Saljhagiri R LINE IS 0 187 1 Rajkharsawan Chandil -46.63 -8.14 37.1 188 1 Goelkera Rajkharsawan -19.02 -10.19 26.8 189 1 Rajkharsawan CKPR 9.37 0.90 6 190 1 Goelkera Manoharpur 4.01 5.39 8.8 191 1 Ramchandapur APL 16.24 12.79 24.9 192 1 Nowamundi Kendposi LINE IS 0 193 1 Sikadari PH1 -44.82 -8.21 56 194 1 Sikadari PH2 LINE IS 0 195 1 Chandil Adityapur 29.22 -10.74 37.4 196 1 Adityapur Ramchandapur -55.28 4.34 66.6 197 1 Adityapur Ramchandapur -55.28 4.34 66.6 198 1 Dhalbhumgarh MosabaniD -21.64 -4.06 28.6 199 1 Dhalbhumgarh MosabaniD -21.64 -4.06 28.6 200 1 Kanke Hatia Old 7.19 -0.88 5.8 201 1 Lathehar Lohardaga -22.50 -2.64 18.6 202 1 Lathehar Lohardaga -22.50 -2.64 18.6 203 1 Lathehar Daltanganj 21.70 2.38 18.3 204 1 Lathehar Daltanganj 21.70 2.38 18.3 205 1 Garhwa Tolrah R 16.02 1.90 20.1 206 1 Lalmtiya Sahebganj 10.59 1.38 13.4 207 1 Hatia New Lohardaga 44.37 3.86 35.7 208 1 Hatia New Lohardaga 44.37 3.86 35.7 209 1 Namkum Tatisiloi R 10.82 4.40 15.2 210 1 Namkum Tatisiloi R 10.82 4.40 15.2 211 1 Namkum UMIRa 2.90 1.78 4.5 212 1 Hatia Old LodhmaR 2.63 -0.48 3.3 213 1 Hatia Old LodhmaR 2.63 -0.48 3.3 214 1 Adityapur Rajkharsawan 31.19 1.81 37.5 215 1 Golmuri Chandil -27.61 -1.75 33.4 216 1 Golmuri Chandil -27.61 -1.75 33.4 217 1 Rajkharsawan Chakradharpur 8.02 -2.49 10.2 218 1 Rajkharsawan Chakradharpur 8.02 -2.49 10.2 219 1 Hazaribhag Rd Konar -2.65 -0.81 3.5 220 1 Hazaribhag Rd Konar -2.65 -0.81 3.5 221 1 Tamar Chandil -13.01 -0.57 15.9 222 1 Hatia Old HEC 9.42 3.40 12.6 223 2 Jamtara Madhupur 16.51 -0.97 10.7

144 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 224 1 Chaibasa Rajkharsawan -32.34 -2.14 39.6 225 1 Manique ManiqueD -51.24 -13.21 67.8 226 1 ABCILG Garhwa 23.93 14.80 35 227 1 Jamtara Jamtara R 8.00 1.14 10.3 228 1 Rajkharsawan RKSNR 8.30 2.90 10.8 229 1 Hatia Old HEC 9.42 3.40 12.6 230 1 Deoghar Jamtara LINE IS 0 231 1 Goelkera GoelkeraT 12.00 3.77 15.7 232 1 MaithonD Jamtara 50.53 -1.58 63 DVC & JSEB 233 1 Kendposi Nowamundi LINE IS 0 JSEB 234 2 PatratuD PTPS LINE IS 0 JSEB & DVC JSEB & 235 1 Garhwa Rihand -9.66 -7.00 14.8 UPPCL 236 1 Inland P Sikidiri 30.89 2.31 38 JSEB 237 1 Inland P Sikidiri 30.89 2.31 38 238 1 Sindri DVC ECRLY DVC 6.49 0.07 8.4 DVC Odisha line loading 765 kV 1 1 Jharsuguda Dharamjaygarh -169.29 -51.24 4 2 1 Jharsuguda Dharamjaygarh -169.29 -51.24 4 3 1 Jharsuguda Angul 140.27 -65.78 5.1 PGCIL 4 1 Jharsuguda Angul 140.27 -65.78 5.1 5 1 ANGUL PG Srikakulam 17.11 -251.50 6.5 6 1 ANGUL PG Srikakulam 17.11 -251.50 6.5 400 kV 7 1 Jaypore Bolangir -39.93 -26.47 8.3 8 1 Jaypore Gazuwaka 296.79 -25.74 34.3 PGCIL 9 1 Jaypore Gazuwaka 296.79 -25.74 34.3 10 1 Indravati PG Jaypore 268.21 -32.83 31.1 11 1 Indravati OHPC Indravati PG 259.35 12.35 29.9 OPTCL 12 1 Rengali Indravati PG 8.93 -41.26 7.6 PGCIL 13 1 Bolangir Angul -173.12 -33.00 21.2 14 1 Angul JITPL -226.78 -85.08 27.5 Jindal 15 1 Angul JITPL -226.78 -85.08 27.5 16 1 Angul Meramundali 353.01 -74.73 41 17 1 Angul Meramundali 353.01 -74.73 41 PGCIL 18 2 TSTPS Angul -338.76 -14.38 38.7 19 1 Angul GMR -329.09 6.60 18.7 GMR 20 1 Angul GMR -329.09 6.60 18.7 21 1 Sterlite Meramundali -6.17 -50.19 8.6 PGCIL 22 1 Sterlite Meramundali -6.17 -50.19 8.6 23 1 JSPL Meramundali 22.88 -32.51 4.5 OPTCL 24 1 JSPL Meramundali 22.88 -32.51 4.5 25 1 GMR Meramundali 333.35 -30.60 38 OPTCL 26 2 Duburi Meramundali -412.95 -51.61 23.6 OPTCL 27 1 TSTPS Meramundali -274.23 -48.76 31.8

28 1 Meramundali Mendhasal 289.62 -0.65 33.3 OPTCL

145 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING OPTCL & 29 2 Pandibl D/C Mendhasal 99.28 -39.69 6.1 PGCIL 30 1 DUBURI4 Pandibl4 72.21 -18.95 8.5 PGCIL 31 1 Duburi Baripada 7.31 -62.44 7.2 OPTCL 32 1 Pandibl4 Baripada -27.20 -37.68 8.5 PGCIL 33 1 Baripada Jamshedpur -253.60 -49.35 29.3 PGCIL 34 1 Baripada TISCO -193.94 -47.93 22.7 PGCIL OPTCL & 35 1 Baripada Kharagpur 156.68 -28.02 18.1 WBSETCL 36 1 Baripada Keonjhar -28.11 12.92 7 OPTCL 37 1 Rengali Keonjhar 28.15 20.83 4 OPTCL 38 1 TSTPS Rengali -6.35 -44.83 5.2 39 1 TSTPS Rengali -6.35 -44.83 5.2 40 1 Bisra TSTPS 112.22 -26.24 13 41 1 Bisra TSTPS 112.22 -26.24 13 42 1 Bisra Jamshedpur LINE IS 0 PGCIL 43 1 Chaibasa Bisra -12.78 -28.78 3.5 44 1 Bisra Ranchi -57.79 -45.61 8.3 45 1 Bisra Ranchi -57.79 -45.61 8.3 46 1 Bisra Raigarh -117.13 18.68 21 PGCIL& 47 1 Bisra Sterlite 45.78 9.49 6 Sterlite 48 1 Jharsuguda Bisra 101.84 -32.95 12 49 1 Jharsuguda Bisra 101.84 -32.95 12 50 1 Ind-Bharath Jharsuguda LINE IS 0 PGCIL 51 1 Jharsuguda Raigarh -145.72 -145.59 11.6 52 1 Ind-Bharath Raigarh 0.00 0.00 0 PGCIL& 53 1 Sterlite Raigarh 57.13 -79.89 11.1 Sterlite 220KV line

54 1 Balimela Upper Silleru -1.12 -49.44 22.5 55 1 Budhipadar Bhusan 33.04 17.56 17.9 56 1 Budhipadar Bhusan 33.04 17.56 17.9 57 1 UPPER KOLAB JAYA NAGAR 112.47 -6.26 52.4 58 1 Theruvali BHANJANAGAR 41.87 -23.48 22.5 59 1 Theruvali Narendrapur 103.47 4.77 48.4 60 1 BHANJANAGAR MENDHASAL 34.27 1.55 18.5 61 1 BHANJANAGAR NAYAGARH 72.29 11.65 34.9 62 1 NAYAGARH MENDHASAL -4.63 0.83 5.4 OPTCL 63 1 Rengali PH TSTPS 58.73 -8.59 27.4 Rengali 64 1 Rengali PH 43.48 21.75 22.6 Switching Station Rengali 65 1 BARKOT 16.63 0.00 8 Switching Station 66 1 TSTPS TTPS 22.57 -15.60 12.7 67 1 NEW DUBURI BHADRAK 88.07 -3.54 41.7 68 1 ITPS Budhipadar 64.29 9.72 27 69 1 TARKERA BISRA -67.67 -13.35 28.6

146 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING Jaya nagar 70 1 JAYA NAGAR 143.85 27.50 68.2 PGCIL (Jaypore) Jaya nagar 71 1 JAYA NAGAR 143.85 27.50 68.2 PGCIL (Jaypore) Rengali 72 1 Rengali PG 24.93 21.05 15.3 Switching Station 73 1 MERAMAUNDLI TSTPS -23.11 21.29 16.5 74 1 Budhipadar RAIGARH 87.39 5.43 40.7 75 1 Balimela JAYA NAGAR 103.53 8.45 47.3 76 1 JAYA NAGAR Balimela -103.18 -14.21 47.8 77 1 JAYA NAGAR Balimela -103.18 -14.21 47.8 Rengali 78 1 Chandiposh 6.42 -1.06 7 Switching Station 79 1 TARKERA Chandiposh -3.40 -17.71 8.4 80 1 UPPER KOLAB JAYA NAGAR 14.22 -5.71 7.1 81 1 JAYA NAGAR Theruvali 50.91 -3.24 23.7 82 1 DUBURI NINL -2.83 -3.75 2.2 83 1 BIDANASI MERAMAUNDLI -173.10 -18.93 35.9 84 1 MENDHASAL CHANDAKA 68.05 6.83 32.4 85 1 TTPS MERAMAUNDLI 80.14 23.47 38.8 86 1 TTPS MERAMAUNDLI 80.14 23.47 38.8 87 1 MERAMAUNDLI BHANJANAGAR 54.62 -9.11 25.5 88 1 MERAMAUNDLI BHANJANAGAR 54.62 -9.11 25.5 89 1 Indravati Theruvali 77.98 -21.53 37.9 90 1 ITPS Budhipadar 64.29 9.72 27 91 1 Budhipadar TARKERA 44.48 -7.09 20.9 92 1 Budhipadar SPS 0.99 -2.03 1 93 1 TSIL JODA 10.48 0.35 5 94 1 DUBURI NEW DUBURI 46.79 4.41 22.3 95 1 ITPS Budhipadar 64.29 9.72 27 96 1 Budhipadar SPS 0.99 -2.03 1 97 1 BALASORE KUCHEI -102.33 -12.29 48.7 98 1 Indravati Theruvali 77.98 -21.53 37.9 99 1 KATAPALI BOLANGIR 45.93 -11.79 22.1 100 1 MENDHASAL CHANDAKA 68.05 6.83 32.4 101 1 BALASORE NEW DUBURI -30.97 -11.14 15.7 102 2 NEW DUBURI PARADEEP 196.72 25.29 41.6 103 2 PARADEEP ESSAR 4.00 -0.31 1.1 104 1 UPPER KOLAB JAYA NAGAR 112.47 -6.26 52.4 105 1 Theruvali BHANJANAGAR 41.87 -23.48 22.5 106 1 Theruvali Narendrapur 103.47 4.77 48.4 Rengali 107 1 Rengali PH 43.48 21.75 22.6 Switching Station 108 1 ITPS Budhipadar 64.29 9.72 27 109 1 TARKERA BISRA -67.67 -13.35 28.6 Rengali 110 1 Rengali PG 24.93 21.05 15.3 Switching Station 111 1 MERAMAUNDLI TSTPS -23.11 21.29 16.5

147 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 112 1 Budhipadar Korba -82.18 -29.86 40.6 113 1 Budhipadar Korba -82.18 -29.86 40.6 114 1 Indravati Theruvali 77.98 -21.53 37.9 115 1 Indravati Theruvali 77.98 -21.53 37.9 116 1 MERAMAUNDLI DUBURI 74.95 8.38 36 117 1 MERAMAUNDLI DUBURI 74.95 8.38 36 118 1 Budhipadar TARKERA 44.48 -7.09 20.9 119 1 DUBURI NEW DUBURI 46.79 4.41 22.3 120 1 BALASORE KUCHEI -102.33 -12.29 48.7 121 1 KATAPALI BOLANGIR 45.93 -11.79 22.1 122 1 MENDHASAL CHANDAKA 68.05 6.83 32.4 123 1 MENDHASAL CHANDAKA 68.05 6.83 32.4 124 1 NEW DUBURI JINDAL -29.49 16.08 16 JSL 125 1 NEW DUBURI JINDAL -29.49 16.08 16 126 1 NEW DUBURI VISA 0.00 -6.76 3.2 VISA 127 1 NEW DUBURI ROHIT 30.75 1.36 14.6 Rohit 128 1 Budhipadar VEDANTA -81.66 14.97 34.4 VEDANTA 129 1 Budhipadar VEDANTA -81.66 14.97 34.4 130 1 DubriNew Maithan2 3.20 -2.48 1.9 131 1 Mendha BIDANASI LINE IS 0 132 1 Bhadrak Balasore -26.18 0.87 13.4 133 1 BALIMELA Balimela Splt 14.42 2.33 6.7 134 1 THERUVALI Lakshmipur -51.51 -16.02 12.6 135 1 Lakshmipur JAYANAGAR -58.64 1.47 14.2 136 1 THERUVALI JAYANAGAR LINE IS 0 137 1 Narendrapur Aatri LINE IS 0 138 1 Mendhasal Aatri 68.91 -9.26 16.4 139 1 TARKERA BARKOTE -1.58 -17.04 8 140 1 Rengali Hydro TTPS 35.97 -14.11 17.9 141 1 JSPL Jamshedpur 20.48 8.24 15.4 142 1 JODA Ramchandrapur -64.86 -11.21 31 BOLANGIR- 143 1 Bolagir 175.17 18.95 82.5 NEW OPTCL 144 1 NALCO Meramundali 113.93 52.60 29.1 145 1 BSSL Meramundali 15.66 30.66 8.1 146 1 JODA JSPL 64.56 21.45 32.3 147 1 Paradeep IOCL 0.50 -0.34 0.3 148 1 Basundhora BUDHIPADAR -2.00 -0.57 2.3 149 1 Lakshmipur Utkal Aluminium LINE IS 0 150 1 Atri Pandibil LINE IS 0 151 1 Pandibil Samangara LINE IS 0 152 1 Lakshmipur Aditya Aluminium LINE IS 0 JAYA NAGAR 153 1 Jayanagar -36.72 6.47 17.4 Traction 154 1 JODA TTPS2 -42.59 -19.12 22 155 1 JODA TTPS2 -42.59 -19.12 22 156 1 BUDHIPADAR Lapanga 110.50 -6.27 51.5 157 1 BUDHIPADAR Lapanga 110.50 -6.27 51.5

148 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 158 1 VEDANT Veda_135 0.00 0.00 0.4 159 1 VEDANT Veda_135 0.00 0.00 0.4 160 1 Lapanga KATAPALI 65.59 -9.41 30.9 161 1 Lapanga KATAPALI 65.59 -9.41 30.9 162 1 TARKERA RSP_220 27.21 12.24 14.2 163 1 TARKERA RSP_220 27.21 12.24 14.2 164 1 DubriNew Tata Steel 67.47 4.57 32 165 1 DubriNew Tata Steel 67.47 4.57 32 166 1 KATAPALI BOLANGIR-New 42.57 -12.35 20.7 132KV lines

167 1 Balimela Upper Silleru -1.12 -49.44 22.5 168 1 Theruvali Rayagada LINE IS 0 169 1 Jayanagar Damanjodi 44.58 -30.08 64.3 170 1 Theruvali IMFA 44.04 14.63 56 171 1 Vedanta Kesinga 55.50 -0.51 67.1 172 1 RyagdSp Akhusinghi 40.90 -5.13 51.5 173 1 Digha Berhampore -16.41 2.99 21.8 174 1 BHANJANAGAR Aska 19.78 -1.09 23.6 175 1 BHANJANAGAR PHULBNI 20.86 -7.13 26.3 176 1 Aska Berhampore LINE IS 0 177 1 Aska Chatrapur LINE IS 0 178 1 Chatrapur Ganjam 17.79 -4.02 23.3 179 1 Chatrapur IRE 3.03 0.62 4 180 1 Chatrapur Balugaon 45.35 -1.79 58.1 181 1 MENDHASAL1 Chandaka LINE IS 0 182 1 Chandaka Bhubaneswar 115.51 20.11 71.8 183 1 ChandSpl Bhubaneswar -2.60 -9.24 11.7 184 1 Phulnakhara Bhubaneswar 2.62 7.84 11.4 185 1 Chandaka Ranasinghpur 96.60 6.74 118.6 OPTCL 186 2 TTPS Chainpal 45.16 5.01 53.6 187 1 TTPS Angul 42.31 8.83 51 188 1 Angul NANDIRA 24.76 2.40 29.6 189 1 Chainpal FCI 0.40 -0.18 0.5 190 1 MERAMAUNDLI Dhenkanal 73.56 8.05 88.5 191 1 Kamakhyanagar OPCL -38.76 -4.24 47.1 192 1 Dhenkanal Nuapatna Tap LINE IS 0 193 1 ICCL Maheswari -9.03 22.94 31.2 Grid Steel 194 1 Choudwar 14.37 18.54 28.6 (GSAL) 195 1 Choudwar BIDANASI -7.19 4.43 10.5 196 1 BPPL BIDANASI 4.61 1.40 6.8 197 1 Cuttack Jagatsinghpur 0.00 -1.78 2.2 198 1 Duburi Jambay Ferro -64.69 -4.20 79.6 TISCO 199 1 B.C. Mohanty 9.93 -0.11 12.2 (Bamanipal) 200 1 Duburi Jajpur Road 27.39 6.00 34.4 201 1 Chandikhole Kendapra -34.45 -4.30 45.6 202 1 Kendapra Ptamundi 31.06 2.06 40.4

149 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 203 1 Nuapatna Tap ARATI STEEL -37.62 -13.58 48.8 204 1 Paradip PPL LINE IS 0 205 1 Jajpur Road Jajpur Town LINE IS 0 206 1 Bhadrak Soro LINE IS 0 207 1 Balasore Soro 39.98 14.30 53 208 1 Balasore Basta 43.80 -3.16 54.8 209 1 Balasore BIRLA TYRE 3.66 0.09 4.6 210 1 Balasore Balasore Alloys 44.90 3.09 56.2 211 1 Bhadrak FACOR -1.60 -15.42 9.5 212 1 Joda Polasapanga 42.62 -7.26 53 213 1 Polasapanga Karenjia -7.01 -4.97 10.7 214 1 Budhipadar Kuchei -69.31 -29.25 92.6 215 1 Burla Samblpur 51.43 0.24 61.8 216 1 Hindalco Burla 4.42 -4.45 7.5 217 1 Budhipadar Brajaraj Nagar 47.68 20.90 62.9 218 1 Jharsuguda L0TCemco 0.89 -0.54 1.3 219 1 Rajgangpur Tarkera -11.20 -2.01 13.9 220 1 Tarkera Rourkela 22.33 0.87 27.3 221 1 Tarkera Rourkela 22.33 0.87 27.3 222 1 Tarkera RSP LINE IS 0 223 1 Rourkela Bhalulata Tap LINE IS 0 224 1 Burla Chiplima 6.02 -0.84 7.3 225 1 Burla Chiplima 6.02 -0.84 7.3 226 1 Bolangir Old Saintala 60.56 -7.76 74.3 227 1 Saintala Kesinga 52.97 -9.30 66.2 228 1 Kesinga Khariar 51.49 -1.36 64.2 229 1 Kesinga PowerMax 0.69 -0.47 1 230 2 Budhipadar MCL 17.03 0.74 10.5 231 1 Tarkera Chhend 34.33 12.93 44.8 232 1 Jaleswar Jaleswar traction 9.53 0.95 12.2 233 1 Chhend Adhunik 8.19 1.12 10.4 234 1 Chhend NugaonTraction 0.07 2.45 5.2 235 1 Tarkera Chhend 34.33 12.93 44.8 236 1 Nalda Traction BEEKAY 13.29 2.87 17.5 237 1 Nalda Traction Barbil -15.69 -10.34 23.9 238 1 Kesinga Bhawanipatna 25.60 -9.15 33.9 239 1 Jajpur Road Kendapra LINE IS 0 240 1 Jajpur Town Bhadrak -48.14 -11.47 61.9 241 1 Kuchinda SMC -23.80 -3.60 29.1 242 1 Rajgangpur Rourkela LINE IS 0 243 1 Joda Kendposi 7.97 0.63 10.5 244 1 Chatrapur Narendra Pur -52.70 0.82 67.4 245 1 Berhampore Narendra Pur -30.74 -3.12 39.4 246 1 Berhampore Narendra Pur -30.74 -3.12 39.4 247 1 Puri Nimpara LINE IS 0 248 1 Sunabeda Damanjodi LINE IS 0 249 1 Jayanagar Tentulik 39.76 7.81 48.5 250 1 Burla Katapali 44.52 7.01 27.2

150 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 251 1 Theruvali JK Paper 0.02 0.06 0.7 252 1 Rajgangpur OCL -9.55 -9.71 16.7 Rajgangpur 253 2 Rajgangpur 2.68 2.22 2.2 Traction 254 1 Paradip IFFCO LINE IS 0 255 1 Boinda Rairakhole 4.23 0.28 7.7 256 1 Mohana Akhusinghi -21.17 7.14 29.6 257 1 Akhusinghi Parlakemundi 8.31 1.24 12.2 258 1 Bolangir Old Sonepur 30.60 -10.04 39.2 259 1 Bolangir New Patnagarh 31.93 4.97 39.2 260 1 Patnagarh Padamapur 7.36 -0.97 9.2 261 1 Khurdah Balugaon T LINE IS 0 262 1 Balugaon T Narendra Pur LINE IS 0 263 1 Tarkera Rajgangpur 10.99 0.64 13.6 264 1 NUAPATNA Nuapatna Tap -37.04 -13.95 49.2 265 1 OPCL TTPS -39.36 -7.27 47.5 266 1 Chainpal Angul 36.24 8.38 43.9 267 2 Machkhnd Vizag LINE IS 0 268 1 Joda FAP-Joda 15.94 1.09 19.6 269 1 Chatrapur Rambha Traction 2.33 0.89 4.1 270 1 Digha Mohana -16.49 -0.85 21.1 271 1 Budhipadar Sundargarh 16.15 3.46 20.4 272 1 Boinda Angul -22.68 -5.46 28.1 273 1 Kurdsplt Kaipadar traction 11.89 2.32 15.1 274 1 Balugaon Solari Rly 4.41 0.50 6 275 1 Jajpur Road Chandikhole LINE IS 0 276 1 HMSwitch HindMtl 0.00 -0.02 0 277 1 Sunabeda HAL 3.42 0.53 4.2 278 1 Rayagada VVC LINE IS 0 279 1 Paradip PPT LINE IS 0 280 1 Duburi Jakhpur Traction 16.04 7.32 22 281 1 Duburi MESCO LINE IS 0 282 1 Bhadrak Bhdrak Traction 5.73 0.11 7.1 283 1 Balasore Balsore Traction 2.50 -0.11 3.1 284 1 Balasore Somanthpur LINE IS 0 285 1 Bhalulata Tap Bhulta Traction 5.48 1.58 7.3 Jharsuguda 286 1 Jharsuguda 10.40 3.18 13.2 Traction 287 1 Vedanta Theruvali -53.31 21.58 70.9 Kendrapara 288 1 Choudwar 7.30 1.46 9.1 Road(Traction) 289 1 Dhenkanal Joranda traction 4.72 2.52 7.2 290 1 ICCL Mania 38.39 4.93 47 291 1 MERAMAUNDLI ML Rungta 0.01 -0.09 0.4 292 1 MERAMAUNDLI BRG 12.50 5.46 16.4 Meramaundali 293 1 HMSwitch 7.40 1.77 9.8 Traction

151 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING Jagannathpur 294 1 Narendra Pur 4.32 7.06 10.5 traction Jayanagar 295 1 Jayanagar 17.86 -13.01 26.4 Traction 296 1 JayaSplt Machkhnd -46.17 0.17 55.2 297 1 Machkhnd MackndRd LINE IS 0 298 1 MackndRd Padwa traction 5.01 0.63 6.3 299 1 MERAMAUNDLI Chainpal LINE IS 0 300 1 MERAMAUNDLI Chainpal LINE IS 0 301 1 Dhenkanal Maheswari 9.03 -22.59 30.2 302 1 RAWMET Choudwar 12.83 -4.01 16.3 303 1 MackndRd Manbar Traction -5.01 -0.63 6.2 304 1 Manbar traction Maliguda traction -10.01 -0.40 12 Jayanagar 305 1 Maliguda traction 15.06 0.61 18.1 Traction Jayanagar Ch Kusumi 306 1 0.00 -1.04 1.2 Traction Traction 307 1 Chiplima Katapali 15.47 5.06 10.2 308 1 Barpali Bolangir New -32.29 0.18 40 309 1 Rajgangpur Budhipadar -18.86 -0.78 23.4 310 1 Rairakhole Rairakhole Tap -7.58 1.25 10.7 311 1 Samblpur Rairakhole Tap -1.41 -6.04 7.5 312 1 Kendapra Paradip -64.24 -9.70 41.9 313 1 Rairakhole Tap Katapali -9.03 -1.59 11.4 314 1 Budhipadar Budhipadar 140.01 44.53 73.7 315 1 Bolangir New Bolangir Old 76.46 -0.52 92.8 316 1 Phulnakhara Cuttack -16.88 -4.45 21.2 317 1 Arya Bolani -33.20 -15.66 45.9 318 1 Karenjia Rairangpur -14.39 1.96 18.9 319 1 Jayanagar Meenakshi -19.74 -4.98 24.3 320 1 DhmraPrt Bhadrak -2.94 -0.68 4.7 321 1 Budhipadar MSP LINE IS 0 322 1 OCL Salipur 30.23 2.81 37.3 323 1 Jajpur Road Anandpr 16.62 -5.31 10.8 324 1 Basta Jaleswar 30.29 0.53 38.2 325 1 Samblpur ShyamDRI -23.41 -3.56 28.5 326 1 BHANJANAGAR Aska 19.78 -1.09 23.6 327 1 Chatrapur IRE 3.03 0.62 4 328 1 TTPS Chainpal 45.16 5.01 53.6 329 1 Angul NANDIRA 24.76 2.40 29.6 330 1 Chainpal FCI 0.40 -0.18 0.5 331 1 Tarkera RSP LINE IS 0 332 1 Tarkera RSP LINE IS 0 333 1 Chatrapur Narendra Pur -52.70 0.82 67.4 334 1 Paradip IFFCO LINE IS 0 335 1 NBVL HMSwitch 25.47 4.58 33.2 336 1 NBVL HMSwitch 25.47 4.58 33.2 337 1 Budhipadar Sundargarh 16.15 3.46 20.4

152 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 338 2 MERAMAUNDLI HMSwitch LINE IS 0 339 1 Paradip PPT LINE IS 0 340 1 Duburi BRPL 10.92 3.07 14 341 1 MESCO BRPL -3.56 -1.16 4.6 342 1 Bolangir New Bolangir Old 76.46 -0.52 92.8 343 1 Duburi Jajpur Road 27.39 6.00 34.4 344 1 Paradip PPL LINE IS 0 345 1 Hindalco Burla 4.42 -4.45 7.5 346 1 Jharsuguda L&TCemco 0.89 -0.54 1.3 347 1 Tarkera Rourkela 22.33 0.87 27.3 348 1 SMC Lapanga -21.30 -1.77 25.7 349 1 Lapanga Budhipadar 38.38 17.18 25.7 350 1 Jayambee Ferro TTPS -67.64 -5.44 82.6 351 1 BEEKAY Steel Bhulta Tap 5.49 0.96 7.3 352 1 Chandaka Nimpara 50.32 -6.03 62.1 353 1 Joda Bansapani 2.26 0.77 3 354 1 Barbil Arya -23.18 -13.17 33.8 355 1 Saliban HMSwitch -1.49 -0.48 2 GOREKNATH 356 1 Jagatsingpur TRACTION 7.81 1.88 10.9 357 1 Paradip Jagatsingpur 41.19 6.10 53.2 358 1 Aska Purusattampur 12.28 -5.63 16.2 359 1 Chatrapur Purusattampur LINE IS 0 360 1 Balugaon Chandpur 9.46 -6.34 14.9 361 1 Chandpur Balugaon Tap 0.00 -0.22 0.3 362 1 Balugaon Tap Atri LINE IS 0 363 1 Arati Steel RAWMET 24.06 -9.22 31.3 364 1 Nimapara Konark 5.81 0.67 7.5 365 1 Nimapara Kesura LINE IS 0 366 1 Nimapara Samangara LINE IS 0 367 1 Khariar Nuapara 11.75 1.07 16.1 368 1 Argul Tap Shamuka LINE IS 0 369 1 Sonepur Boudh 4.92 -1.01 6.3 370 1 JUNAGRH Bhawanipatna -18.48 4.45 24.4 371 1 Shamuka Puri -9.54 6.99 15.1 372 1 Puri Samangara -45.63 10.98 57.6 373 1 Dabugaon Tentulikhunti -22.91 -5.24 29.4 374 1 Dabugaon Umerkote 16.39 4.07 21.9 375 1 Joda Bolani 35.96 15.63 48.1 376 1 Jayanagar Sunabeda 27.39 5.55 34 377 1 Polasponga Keonjhar Traction 4.20 1.81 6.2 378 1 KATAPALI Bargarh 55.39 15.28 69.3 379 1 Bargarh Barpalli LINE IS 0 380 1 Bargarh ACC 0.97 1.09 2 381 1 Budhipadar Kahalgaon 15.44 -1.87 18.8 Burla-Rajganpur 382 1 Kuchinda Tap LINE IS 0 383 1 Aryan Steel ShyamDRI 22.91 -6.78 28.7

153 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 384 1 Baripada Balasore LINE IS 0 385 1 Kendrapra Marshghai -22.84 -3.16 29.8 386 1 Arati Steel Meramundali -43.03 8.14 53.9 387 1 BC Mohanty Duburi -19.85 0.20 24.4 388 1 Budhipadar Jharsuguda 19.10 -1.23 23.1 389 1 Khurdah Split Argul Tap LINE IS 0 390 1 Argul Tap Argul LINE IS 0 391 1 Rayagarh Split Jayangr splt -47.36 2.72 59.6 392 1 Action Ishpat Jharsiguda 2.63 6.38 4.3 393 1 Rathi CHIPLMA 0.00 0.00 0.3 394 1 Adhunik Sri ganesh -11.10 -4.19 14.6 395 1 Kesura Ranasinghpur -22.05 -1.59 27.9 396 1 Grid Steel ICCL -14.37 -18.54 28.5 397 1 Mania OCL TAP 38.08 5.28 47.1 398 1 BPPL Chandaka Split 65.29 10.46 80.2 399 1 Kurda split Mendhasal -17.33 -2.39 21.6 400 1 Aryan Steel Lapanga -25.10 9.32 32.3 Burla-Rajganpur 401 1 Rajganpur Tap LINE IS 0 Burla-Rajganpur 402 1 Bamra Traction Tap 0.00 0.00 0 403 1 Kalugaon Tarkera -15.86 -9.39 22.6 404 1 Somnathpur EMAMI -5.30 -2.04 6.9 405 1 Bhadrak Dhamra Traction 2.60 -0.77 3.4 406 1 Marshghai PARADEEP -26.87 -4.30 34.9 407 1 Duburi MSL 3.23 0.38 4.1 408 1 BC Mohanty Tomka Traction 0.00 -0.58 0.7 409 1 HMSwitch Samal Metalics 0.00 -0.05 0.1 410 1 Arya BRP-St 3.47 0.70 4.6 411 1 Argul Atri -0.60 0.39 1.8 412 1 Atri Baki 10.84 -3.35 13.7 413 1 Rajganpur Kuchinda -5.01 -0.25 7.1 414 1 Duburi Kamakhyanagar -20.85 -1.24 25.6 415 1 Polasponga MSP -3.26 -7.69 10.4 416 1 HMSwitch SGEL 16.58 2.73 21.6 417 1 Lapanga Jharsiguda LINE IS 0 418 1 Lapanga Burla LINE IS 0 419 2 Lapanga Burla LINE IS 0 420 1 Kalarangi Duburi -28.05 -9.36 36.8 421 1 Kalarangi Kmakhyanagar LINE IS 0 422 1 Kuchai Bangaripusi 21.39 -7.08 27.4 423 1 Khurda Kurda splt -5.45 -0.12 6.7 424 1 Chandka Chandka Splt -67.41 -19.12 85.8 425 1 Rayagda Rayagda Sp -6.46 -2.48 8.6 426 1 Kesinga Splt Kesinga 0.35 -8.68 10.8 427 1 Joda Rourkela -28.10 7.93 37.1 428 1 Kalarangi Tap Kalarangi 28.05 9.36 37 429 1 Bhubaneswar CTC 20.83 9.01 27.9

154 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 430 1 Bangaripusi Rairangpur 21.21 -5.64 26.8 431 1 Chandaka Bidansi -37.94 -3.47 46.6 Sikkim line loading 400 kV 1 1 Teesta-5 Rangpo 262.39 15.05 30.1 2 1 Teesta-5 Rangpo 262.39 15.05 30.1 PGCIL 3 1 Malbase TALA LINE IS 0 220kV 4 1 New Melli Jorthang -16.83 -18.76 11.9 5 1 New Melli Rangpo 31.46 -22.17 9.1 PGCIL 6 1 Rangpo Jorthang -23.11 0.74 11 132kV 7 1 Rangit Ramam 63.52 -14.96 77.5 PGCIL 8 1 Rangit Sagbari -14.68 8.80 20.3 NHPC 9 1 Melli NJPPG 47.74 -14.46 59.3 PGCIL 10 1 Rangit Kurseong 39.83 -10.44 48.9 PGCIL 11 1 Rangpo Chuzechan -45.94 -4.45 35.5 Gati infra 12 1 Gantok Chuzechan -25.55 -6.44 20.4 Sikkim 13 1 Rangpo Melli 88.19 -18.24 69.5 14 1 Gantok Rangpo -11.63 -4.72 15 15 1 Rangpo Rangit 34.91 -17.35 46.4 PGCIL 16 1 Sagbari Melli -17.51 8.43 24 17 1 Sagbari Geyzing 2.83 0.38 3.6 66kV 18 1 Mangan Phudong -2.86 -0.67 6.1 19 1 Geyzing Namchi -0.39 0.22 1.3 20 1 Bulbuley Sichey 5.05 1.29 10.6 21 1 Bulbuley Gangtok -10.04 -2.66 21.1 22 2 Ranipool LLHP 0.00 -0.01 0 23 1 Rongli Pakyong -3.22 -0.75 6.8 24 1 Mamring Melli -6.78 -1.91 14 25 1 Rangit Rabangla 2.15 0.50 4.4 26 1 Ranipool Pakyong 8.27 1.97 9.1 27 1 Melli Namchi 1.46 -0.48 3.1 28 1 Pelling6 Geyzing -2.14 -0.65 4.5 29 1 PNamchi6 Rothak 2.14 0.35 4.4 Sikkim Gov 30 1 Rothak Soreng 1.07 0.16 2.2 31 2 Melli Kalingpong 6.78 0.47 6.8 32 1 Melli6 Melli 22.27 3.31 44.7 33 1 Melli PNamchi6 5.04 0.93 10.2 34 1 Gangtok Tadong 12.97 3.27 27 35 1 Ranipool Gangtok -13.99 -3.37 29 36 1 Tadong Sichey 3.54 1.13 7.6 37 1 Tadong Phudong 4.32 0.68 9 38 1 Rongli Rhenock 2.15 0.52 4.6 39 1 Geyzing Geyzing 0.68 0.51 1.7 40 1 Ranipool Topakhani 2.86 0.63 6 41 1 Mangan Meyong HEP 0.00 -0.13 0.3

155 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 42 1 Rongli RongliH 0.00 -0.06 0.1 West Bengal line loading 400 kV 1 1 Malbase Binaguri LINE IS 0 2 1 Rangpo Binaguri 598.57 -74.82 69.1 3 1 Rangpo Binaguri 598.57 -74.82 69.1 4 1 TALA Binaguri 95.24 -29.97 11.5 5 1 TALA Binaguri 95.24 -29.97 11.5 6 1 TALA Binaguri 95.24 -29.97 11.5 Bongaigaon 7 1 Binaguri LINE IS 0 (NER) Bongaigaon 8 1 Binaguri LINE IS 0 (NER) PGCIL 9 1 Farraka MaldaPG 161.80 7.54 18.4 10 1 Farraka MaldaPG 161.80 7.54 18.4 11 1 Farraka Parulia (PGCIL) -79.75 29.00 11.7 12 1 Farraka Parulia (PGCIL) 158.72 -10.47 19.5 13 1 Farraka Behrampur 347.22 8.96 38.8 14 1 Farraka Sagardighi 282.19 -8.70 31.6 15 1 Sagrdghi Behrampur 248.64 39.95 28.6 16 1 Sagrdghi Behrampur 248.64 39.95 28.6 17 1 Sagrdghi Parulia (PGCIL) 29.45 -25.66 8.8 WBSETCL 18 1 Sagrdghi Parulia (PGCIL) 29.45 -25.66 8.8 WBSETCL 19 1 Subhashgram Sagardighi -374.49 -56.06 43.1 Behramara 20 1 Behrampur 240.25 2.01 27.4 (Bangladesh) PGCIL Behramara 21 1 Behrampur 240.25 2.01 27.4 (Bangladesh) 22 1 Behrampur Jeerat 361.83 6.18 42 23 1 Haldia Subhashgram 274.47 55.37 33.3 CESC 24 1 Haldia Subhashgram 274.47 55.37 33.3 25 1 Jeerat Subhashgram 178.11 -44.51 21.3 PGCIL 26 1 Jeerat Bakreswar -362.26 0.83 42.6 27 1 Jeerat KTPS 272.19 -3.79 31.8 WBSETCL 28 1 KTPS Kharagpur -147.38 -88.05 9.8 29 1 KTPS Kharagpur -147.38 -88.05 9.8 30 1 Arambag KTPS 114.17 -26.33 13.4 31 1 Arambag Bidhannagar -224.44 -40.42 26 32 1 Arambag Bakreswar -111.39 14.92 13.3 33 1 PPSP Arambag 126.60 -24.13 17.5 34 1 PPSP Arambag 126.60 -24.13 17.5 WBSETCL 35 1 PPSP Bidhannagar 2.02 -24.06 9.1 36 1 PPSP Bidhannagar 2.02 -24.06 9.1 37 1 Parulia (PGCIL) Bidhannagar 134.65 54.03 16.4 38 1 Parulia (PGCIL) Bidhannagar 134.65 54.03 16.4 39 1 Khargpr4 Chaibasa -249.35 -40.36 28.5 PGCIL 40 1 Khargpr4 Chaibasa -249.35 -40.36 28.5 PGCIL

156 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING Durgapur 41 1 Raghunathpur 135.35 -21.21 15.2 DVC (DSTPS) Durgapur 42 1 Raghunathpur 135.35 -21.21 15.2 DVC (DSTPS) 43 1 Binaguri Purnea PG 294.11 -74.58 34.5 44 1 Binaguri Purnea PG 294.11 -74.58 34.5 45 1 MaldaPG Purnea PG 47.16 35.52 9.6 46 1 MaldaPG Purnea PG 47.16 35.52 9.6 47 1 Farraka Khalgaon-I 1.42 2.27 6.4 48 1 Farraka Khalgaon-I 1.42 2.27 6.4 49 1 Farraka Khalgaon-II 38.67 -3.67 7.2 50 1 Farraka Khalgaon-II 38.67 -3.67 7.2 PGCIL 51 1 MejiaB4 Maithan-I 348.40 34.86 39.7 52 1 MejiaB4 Maithan-I 348.40 34.86 39.7 53 1 Raghunathpur Ranchi 262.24 -23.08 29.9 54 1 Raghunathpur Ranchi 262.24 -23.08 29.9 55 1 Binaguri Alipurduar PG -47.52 -53.08 4 56 1 Binaguri Alipurduar PG -47.52 -53.08 4 57 1 AlipurDP Bongaigaon -80.39 -110.32 7.6 58 1 AlipurDP Bongaigaon -80.39 -110.32 7.6 220kV 59 1 STPS Asansol 61.16 15.04 30.9 60 1 SubhasgramPG CLC 80.19 21.77 40.5 61 1 Kasba SubhasgramW -29.71 -5.21 14.6 62 1 Jeerat Satgachia 0.00 0.00 5 63 1 Arambag Domjur 153.48 21.95 74.1 64 1 Arambag Domjur 153.48 21.95 74.1 65 1 Arambag Midnapur 41.17 -2.92 19.9 66 1 Arambag Midnapur 41.17 -2.92 19.9 67 1 Bakreshwar Bidhanagar 23.20 13.72 14.3 68 1 Bakreshwar Bidhanagar 23.20 13.72 14.3 69 1 Bidhanagar DPL -106.73 90.87 67.4 70 1 Bidhanagar DPL -106.73 90.87 67.4 71 1 Howrah KTPS -90.59 -17.36 44.7 72 1 Howrah KTPS -90.59 -17.36 44.7 WBSETCL 73 1 Jeerat Kasba 92.93 -11.44 45.2 74 1 Jeerat Kasba 92.93 -11.44 45.2 75 1 ParuliaW ParuliaD 42.39 41.18 27.9 76 1 ParuliaW ParuliaD 42.92 41.20 28.1 77 1 Bidhanagar DTPS-D LINE IS 0 78 1 Bidhanagar DTPS-D LINE IS 0 79 1 STPS Hura 162.93 -15.03 77.3 80 1 BishnupurNew Arambag 22.93 -9.60 11.9 81 1 BishnupurNew Arambag 22.93 -9.60 11.9 82 1 Laxmikantapur SubhasgramW -179.89 -19.95 88.9 83 1 Laxmikantapur SubhasgramW -179.89 -19.95 88.9 84 1 Bakreshwar Satgachia 123.93 0.81 58.8 85 1 Bakreshwar Satgachia 123.93 0.81 58.8

157 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 86 1 SubhasgramPG SubhasgramW 242.63 35.28 105 87 1 SubhasgramPG SubhasgramW 242.63 35.28 105 88 1 Kasba SubhasgramW -29.71 -5.21 14.6 89 1 Kharagpur Midnapur 88.03 17.45 43.2 90 1 Kharagpur Midnapur 88.03 17.45 43.2 91 1 SubhasgramPG NTAA 27.25 27.75 19.9 92 1 NTAA Jeerat -122.62 -1.37 59.6 93 1 TLD NJP 131.24 -6.05 60.3 94 1 NJP TLD -39.45 -16.11 19.8 95 1 NJP TLD -39.45 -16.11 19.8 96 1 Gokarna Sadaipur -72.91 7.31 35.5 97 1 Gokarna Sadaipur -72.91 7.31 35.5 98 1 Sadaipur Bakreshwar -73.51 14.18 35.6 99 1 Gokarna Sagardighi -73.51 14.18 35.6 100 1 Gokarna Sagardighi -95.02 -35.08 48.1 101 1 Foundry Park Domjur -66.25 -7.97 32.7 102 1 Foundry Park Domjur -66.25 -7.97 32.7 103 1 Howrah Foundry Park -53.06 -6.52 26.3 104 1 Howrah Foundry Park -53.06 -6.52 26.3 105 1 Krishnanagar Satgachia -13.91 -7.97 7.8 106 1 Krishnanagar Satgachia -13.91 -7.97 7.8 107 1 Asansol Bidhanagar -7.67 -9.34 5.8 108 1 NTAA CLC 49.89 -12.72 25 109 1 Bishnupr New STPS -106.94 5.46 52 110 1 New Haldia KTPS -52.09 -6.68 25.5 111 1 New Haldia KTPS -52.09 -6.68 25.5 112 1 Bishnupr New Hura -63.84 -3.44 31 113 1 Sadaipur Bakreshwar -73.51 14.18 35.6 114 1 SubhasgramPG EMSS 250.67 11.45 49.4 115 1 SubhasgramPG EMSS 250.67 11.45 49.4 116 1 NTAA Jeerat -122.62 -1.37 59.6 117 1 Jeerat Satgach2 0.00 0.00 5 118 1 Jeerat Dharampur 81.33 33.75 22.1 119 1 Arambag2 Rishra 156.78 7.05 75 120 1 Dharampur Rishra2 9.32 20.11 7.3 121 2 Gokarna Kishnanagar 213.29 20.35 50.9 122 2 VidyasagarW Kharagpur -60.52 -11.44 29.6 123 2 New Haldia IPCLG 0.00 -0.84 0.2 124 1 Parulia Parulia -94.95 -4.46 44.8 125 1 Kharagpur Egra 103.72 22.31 50.3 126 2 Kharagpur Egra 103.72 22.31 50.3 127 1 Khargpur Vidysagar Park 61.08 1.00 29.6 128 1 STPS JK nagar 36.47 2.21 18.2 WBSETCL/IPC 129 1 JK Nagar Bidhanagar -8.80 5.00 5.8 L 130 1 DalkholaPG MaldaPG 4.38 -10.44 5.3 131 1 DalkholaPG MaldaPG 4.38 -10.44 5.3 PGCIL 132 1 Binaguri BirparaPG 8.67 -6.76 5.1 133 1 Binaguri BirparaPG 8.67 -6.76 5.1

158 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 134 1 Binaguri SliguriPG 82.46 -9.31 38.5 135 1 Binaguri SligurPG 82.46 -9.31 38.5 136 1 NJP Binaguri 51.55 -6.92 24.1 137 1 NJP Binaguri 51.55 -6.92 24.1 138 1 BirparaPG Malbase 6.00 -5.75 3.9 139 1 BirparaPG Chukha -35.87 9.63 18.1 140 1 BirparaPG Chukha -35.87 9.63 18.1 141 1 DalkholaPG Purnea 27.36 -1.54 12.9 142 1 DalkholaPG Purnea 27.36 -1.54 12.9 143 1 DalkholaPG DkholaW 62.40 1.27 29 144 1 DalkholaPG DkholaW 62.40 1.27 29 145 1 Farakka Lalmatiya 28.78 -3.67 13.6 146 1 SiliguriP Krishanganj 74.02 -18.32 35.4 147 1 SiliguriP Krishanganj 74.02 -18.32 35.4 148 2 DalkholaP Krishanganj -188.26 21.41 44.3 149 1 BirpraP2 ALIPURDUAR -28.59 -4.85 13.6 150 1 BirpraP2 ALIPURDUAR -28.59 -4.85 13.6 151 1 ALIPURDU Salakati_NER 4.05 14.29 12.2 152 1 ALIPURDU Salakati_NER 4.05 14.29 12.2 153 1 JK Nagar JK Nagar 36.32 11.66 18.5 IPCL 154 1 JK Nagar JK Nagar -8.80 2.93 4.8 155 1 BurnpurD Mejia-D -96.20 5.22 45.9 156 1 BurnpurD Kalyaneshwari -15.91 -9.76 8.8 157 2 Mejia Durgapur 133.95 -15.14 31.8 158 2 ParuliaD Durgapur -6.97 23.77 6.8 159 2 Barjora Mejia -133.45 -13.59 31.6 160 1 DTPS-D Mejia -52.47 -6.08 25 DVC 161 1 DTPS-D Mejia -52.47 -6.08 25 162 1 Parulia-D TamlaD 10.33 2.16 5.1 163 1 Parulia-D TamlaD 10.33 2.16 5.1 164 1 Parulia-D Tamla 10.33 2.16 5.1 165 2 DTPS-D Parulia-D -5.07 -51.14 12.2 166 2 IISCOD BurnpurD -111.20 -4.38 26.3 167 1 EMSS NCGS LINE IS 0 168 1 EMSS NCGS LINE IS 0 169 1 EMSS EMSS LINE IS 0 170 1 BBGS BBG 123.14 12.53 49.3 171 1 BBGS BBG 123.14 12.53 49.3 CESC 172 1 BBG EMSS 122.33 17.75 47.7 173 1 BBG EMSS 122.33 17.75 47.7 174 1 EMSS Kasba LINE IS 0 175 1 EMSS EMSS LINE IS 0 132kV 176 1 Howrah B. Garden 41.70 3.32 89.1 177 1 Howrah B. Garden 41.70 3.32 89.1 178 1 Howrah SRS LINE IS 0 WBSETCL 179 1 Lilooah Belur 39.56 -0.77 85.2 180 1 Lilooah Belur 39.56 -0.77 85.2

159 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 181 1 Lilooah Belur 39.56 -0.77 85.2 182 1 Titagarh Titagarh 39.15 1.31 85.5 183 1 Titagarh Titagarh 39.15 1.31 85.5 184 1 Kasba EMSS 28.68 -20.53 22.7 185 1 Kasba EMSS 28.68 -20.53 22.7 186 1 Howrah B. Garden 41.70 3.32 89.1 187 1 Rishra Rishra 32.06 -0.59 21.4 188 1 Rishra Rishra 32.06 -0.59 21.4 189 1 Alipurduar Birpara -37.02 15.81 49.4 190 1 Midnapur Balichauk 35.58 4.88 45 191 1 Pingla Balichauk -22.15 -1.69 28.2 192 1 CK Road Midnapur -49.90 -2.42 64.1 193 1 Leobong NBU 25.84 -7.45 32.3 194 1 Leobong Ramam -38.30 6.30 46.8 195 1 Dharampur Kalyani 4.91 -0.46 6.3 196 1 Dhulian Farakka -26.07 4.45 32.7 197 1 Joka Sonarpur LINE IS 0 198 1 Lalgola Raghunathpur 23.68 6.74 31.9 199 1 Gokarna Rampurhat 52.44 7.22 66.4 200 1 Gokarna KuliGIS 58.07 13.47 74.7 201 1 HM Dankuni LINE IS 0 202 1 Dankuni Lilooah -6.00 -1.97 8.1 203 1 HM Rishra LINE IS 0 204 1 Khanyan Satgachia -32.58 16.94 47.3 205 1 Malda Samsi 70.35 10.03 86.6 206 1 Satgachia DhatriT 4.00 -0.83 5.2 207 1 NBU TCF-1 14.31 0.26 17.3 208 1 NJP TCF-1 11.88 8.91 18.5 209 1 Samsi Raigunj LINE IS 0 210 1 Saintia Rampurhat 27.04 -1.03 35.1 211 1 TCF-1 TCF-2 0.00 -0.81 1 212 1 TCF-1 TCF-3 0.00 -1.72 2.1 213 1 TCF-2 TCF-3 LINE IS 0 214 1 NBU NJP 6.83 -13.89 18.7 215 1 New Haldia Haldia 3.36 -19.11 24.4 216 1 New Haldia HPCL 5.96 0.54 7.5 217 1 Haldia HPCL 1.74 13.04 16.7 218 2 Rishra CTOLA 3.88 20.70 13.7 219 1 Raigunj Gangarampur 40.35 0.57 49.3 220 1 Cooch Bihar Alipurduar -19.50 4.28 24.2 221 1 Chalsa Maynaguri 3.05 -1.06 3.9 222 1 Chalsa NJP -22.32 5.58 29.3 223 1 Contai Egra -48.51 -9.84 63.9 224 1 Gokarna Raghunathpur 44.63 12.19 58 225 1 CLC Kasba -40.01 -18.97 55.3 226 1 Kasba Joka LINE IS 0 227 1 TMBLK RMBLK -23.84 -9.75 32.5 228 1 CK Road Bishnupur Old LINE IS 0

160 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 229 1 Basirhat Ashoknagar -44.30 -2.73 58.3 230 1 Basirhat Ashoknagar -44.30 -2.73 58.3 231 1 Arambag Raina 40.87 16.84 55.5 232 1 Arambag Raina 40.87 16.84 55.5 233 1 Arambag Tarakeshwar 47.75 -4.13 60.1 234 1 Arambag Tarakeshwar 47.75 -4.13 60.1 235 1 Ashoknagar Jeeerat -80.72 -7.86 104.5 236 1 Ashoknagar Jeeerat -80.72 -7.86 104.5 237 1 Bankura Bishnupur New -2.07 -5.83 7.7 238 1 Bankura Bishnupur New -2.07 -5.83 7.7 239 1 Barasat Jeeerat LINE IS 0 240 1 Barasat Jeeerat LINE IS 0 241 1 Birpara BRPPG -69.91 0.97 83.6 242 1 Birpara BRPPG -69.91 0.97 83.6 243 1 Birpara Maynaguri 14.72 6.20 20.3 244 1 Birpara Mathabhanga 31.45 9.29 39.2 245 1 Bolpur Saintia 24.01 -2.18 31 246 1 Bolpur Saintia 24.01 -2.18 31 247 1 Bongaon Krishnanagar LINE IS 0 248 1 Bongaon Krishnanagar LINE IS 0 249 1 Dlkhola Raigunj 48.97 -2.33 54.1 250 1 Dlkhola Raigunj 48.97 -2.33 54.1 251 1 Debagram Katwa LINE IS 0 252 1 Debagram Katwa LINE IS 0 253 1 Debagram DebagramTSS 2.76 0.36 3.7 254 1 Dharampur Titagarh 70.07 12.42 90.7 255 1 Dharampur Titagarh 70.07 12.42 90.7 256 1 Domjour Uluberia 16.88 10.49 26 257 1 Domjour Uluberia 16.88 10.49 26 258 1 Bidhannagar DPL LINE IS 0 259 1 Bidhannagar DPL LINE IS 0 260 1 Bidhannagar Mankar 49.93 -4.74 61.7 261 1 Bidhannagar Mankar 49.93 -4.74 61.7 262 1 Falta Laxmikantapur -59.87 1.03 78.4 263 1 Falta Laxmikantapur -59.87 1.03 78.4 264 1 Gokarna Katwa 0.00 -2.69 3.4 265 1 Gokarna Katwa 0.00 -2.69 3.4 266 1 Joka Sirkl -62.46 1.36 82.3 267 1 Jeeerat Bongaon 31.28 5.56 40.3 268 1 Jeeerat Bongaon 31.28 5.56 40.3 269 1 Kasba SaltLak 45.81 16.81 60.6 270 1 Katwa Satgachia -29.38 -9.02 39 271 1 Katwa Satgachia -29.38 -9.02 39 272 1 KTPS KolaghatW 33.45 13.52 45.7 273 1 KTPS KolaghatW 33.45 13.52 45.7 274 1 KTPS TMLK 32.34 7.16 41.9 275 1 KTPS TMLK 32.34 7.16 41.9 276 1 KTPS Uluberia 36.06 2.58 45.8

161 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 277 1 KTPS Bagnan 71.74 5.67 45.5 278 1 Lilooah Rishra LINE IS 0 279 1 Lilooah Howrah -29.25 1.05 37.8 280 1 NJP Siliguri 17.57 2.99 21.7 281 1 NJP Siliguri 17.57 2.99 21.7 282 1 STPS PuruliaW 26.68 2.55 32.6 283 1 STPS PuruliaW 26.68 2.55 32.6 284 1 NJP PG Kurseong -31.08 10.42 40 285 1 Domjour Jangipara 10.04 -3.08 13.3 286 1 Domjour Jangipara 10.04 -3.08 13.3 287 1 Arambag Birsingha 27.46 6.40 35.4 288 1 Arambag Birsingha 27.46 6.40 35.4 289 1 Tarakeshwar Belmuri 25.98 -13.11 37 290 1 Tarakeshwar Belmuri 25.98 -13.11 37 291 1 Bishnupur New Borjora 10.07 -0.61 12.6 292 1 Bishnupur New Borjora 10.07 -0.61 12.6 293 1 Borjora Bidhannagar LINE IS 0 294 1 Borjora Bidhannagar LINE IS 0 295 1 RGP Bankura 27.53 0.19 33.6 296 1 RGP Bankura 27.53 0.19 33.6 297 1 Mankar Mahachanda 24.37 -9.42 32.5 298 1 Mankar Mahachanda 24.37 -9.42 32.5 299 1 Mahachanda Satgachia LINE IS 0 300 1 Mahachanda Satgachia LINE IS 0 301 1 TATA Power Haldia 43.43 22.43 61 302 1 TATA Power Haldia 43.43 22.43 61 303 1 Cresent Asansol 18.40 8.02 25.3 304 1 Cresent Asansol 18.40 8.02 25.3 305 1 Krishnanagar Ranaghat 51.13 -2.35 65.4 306 1 Krishnanagar Ranaghat 51.13 -2.35 65.4 307 1 Debagram Amtala LINE IS 0 308 1 Debagram Amtala LINE IS 0 309 1 Berhampur Amtala 45.80 -1.85 58.8 310 1 Berhampur Amtala 45.80 -1.85 58.8 311 1 Hizli Midnapur LINE IS 0 312 1 Hizli Midnapur LINE IS 0 313 1 Midnapur Pingla 32.43 3.39 40.8 314 1 Jhargram Midnapur -23.41 -4.91 30 315 1 Jhargram Midnapur -23.41 -4.91 30 316 2 NTAAIII Barasat 127.79 22.98 82.3 317 1 Ukhra Bidhannagar -32.19 -0.51 39.9 318 1 Ukhra Bidhannagar -32.19 -0.51 39.9 319 1 TCF-3 Dlkhola LINE IS 0 320 1 TCF-3 Dlkhola LINE IS 0 321 1 Rishra Bighati 6.68 -10.19 15.4 322 1 Rishra Bighati 6.68 -10.19 15.4 323 1 Bishnupur New Bishnupur Old 22.02 1.85 27.3 324 1 Bishnupur New Bishnupur Old 22.02 1.85 27.3

162 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 325 1 Bishnupur New Bishnupur Old 22.02 1.85 27.3 326 1 Howrah Lilooah 50.52 -2.15 64.7 327 1 Howrah Lilooah 50.52 -2.15 64.7 328 1 Howrah Lilooah 50.52 -2.15 64.7 329 1 Khejuria GIS Malda -21.43 4.06 27.1 330 1 Bishnupur Old Khatra 13.54 -1.68 16.9 331 1 Bishnupur Old Khatra 13.54 -1.68 16.9 332 1 Satgachia Kalna 21.19 1.72 26.8 333 1 Satgachia Kalna 21.19 1.72 26.8 334 1 Laxmikantapur Kakdwip 22.60 -2.79 29.2 335 1 Laxmikantapur Kakdwip 22.60 -2.79 29.2 336 1 Dharampur Jeeerat -9.17 -11.40 18.7 337 1 Dharampur Jeeerat -9.17 -11.40 18.7 338 1 Hura PuruliaW LINE IS 0 339 1 Hura PuruliaW LINE IS 0 340 2 Hura RGP 78.50 -2.25 18.6 341 1 Bagnan Uluberia 22.34 1.24 28.5 342 1 Krgpr132 Hizli LINE IS 0 343 1 Saintia KuliGIS -23.86 -4.23 31.1 344 1 Malda Khejuria GIS 21.59 -5.42 27.1 345 1 Bengal Energy Egra -23.30 -0.28 29.9 346 1 SonarLal Lalgola 9.85 3.62 14 347 1 Raghunathpur Dhulian LINE IS 0 348 1 MaldaPG Malda 118.09 14.51 56.2 349 1 MaldaPG Malda 118.09 14.51 56.2 350 1 Berhampur Gokarna -97.79 -9.43 125.9 351 1 Berhampur Gokarna -97.79 -9.43 125.9 Cossim 352 1 Berhampur 5.00 0.93 6.7 bazarTSS 353 1 Ranaghat Dharampur 0.69 -27.69 36 354 1 Ranaghat Dharampur 0.69 -27.69 36 355 1 NTAAIII NTAA 70.29 8.35 89.7 356 1 Bidhannagar Bolpur 62.58 1.16 77 357 1 Bidhannagar Bolpur 62.58 1.16 77 358 1 Ujanoo NBU -27.79 4.55 34.2 359 1 NJP PG NBU 34.63 2.90 41.7 360 1 Ujanoo Siliguri 6.97 -3.80 9.6 361 1 Adisaptagram BTPS -38.09 -23.67 56.3 362 1 Adisaptagram BTPS -38.09 -23.67 56.3 363 1 Lilooah Rishra LINE IS 0 364 1 NJP PG NJP 58.97 -8.97 71.6 365 1 NJP Maynaguri 46.45 -13.40 58.2 366 1 Balurghat BalurghatTP -27.73 -3.65 34.8 367 1 Balurghat Gangarampur 1.43 -4.06 5.4 368 1 Gokarna SonarLal 20.06 3.22 26 369 1 Debagram Krishnanagar -20.06 -3.89 26.5 370 1 Debagram Krishnanagar -20.06 -3.89 26.5 371 1 Haldia Hizil 33.38 8.62 43.3

163 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 372 1 Haldia Hizil 33.38 8.62 43.3 373 1 TMLK Hizil -0.23 -5.88 7.5 374 1 TMLK Hizil -0.23 -5.88 7.5 375 1 Falta Joka 24.71 -1.93 32.4 376 1 Falta Joka 24.71 -1.93 32.4 377 1 Ramam NBU 36.10 -8.65 44.4 378 1 Sonarpur Kasba -70.50 -6.33 88.7 379 1 New Haldia Bajkul 50.48 10.62 33 380 1 Bajkul Egra -10.02 -3.59 13.6 381 1 Bengal Energy Hizli 7.87 2.03 10.8 382 1 Raigunj BalurghatTP 2.15 -2.27 3.8 383 1 Lalgola Gokarna -18.08 -5.92 24.3 384 1 Lalgola Gokarna -18.08 -5.92 24.3 385 1 PuruliaW Bagmundi 4.42 -3.71 7.1 386 1 Belmuri Adisaptagram 13.79 -14.65 25.5 387 1 Belmuri Adisaptagram 13.79 -14.65 25.5 388 1 BalurghatTP Malda -26.36 0.68 32.2 389 2 Hizil Rohit Ferro LINE IS 0 390 1 Hizil Mankar 2.00 1.90 3.5 391 1 CK Road CK Road-Tr 1.80 1.50 3.2 392 2 Sirkl Laxmikantapur -96.12 2.69 62.7 393 1 Maynaguri Mathabhanga LINE IS 0 394 2 Amtala Najirpur 30.18 -2.22 19.8 395 1 SaltLak CLC -33.30 -8.19 43.2 396 1 Bankura Bengal concast 0.25 1.88 2.6 397 1 Cooch Bihar Birpara -39.15 5.80 18.7 398 1 Katwa KatwaTss 0.30 0.06 0.4* 399 1 Bankura BankuraT 7.50 3.17 10.1 400 1 Bishnupur Old Modern 9.10 0.19 11.3 401 1 Bishnupur Old Rohit Ferro LINE IS 0 402 1 Midnapur WBIDC 23.70 7.33 31.4 403 1 Barasat BarsatT 4.00 1.18 5.5 404 1 KolaghatW Madras cement 4.00 0.77 5.2 405 1 TMBLK WBIDC 8.84 4.79 12.8 406 1 Bolpur Bolpur Trac 2.00 3.58 5.3 407 1 Rishra Jayshree 10.43 3.25 13.8 Foundry Park 408 1 HOWRH DVC 7.58 -0.98 9.9 Tap Foundry Park 409 1 Kolaghat DVC -2.05 -3.02 4.7 Tap 410 1 Vidyasagar Park BRG Steel Tap 1.31 -4.07 5.3 411 1 BRG Steel Tap BRG Steel 1.30 0.09 1.7 412 1 BRG Steel Tap Midnapur LINE IS 0 413 1 Vidyasagar Park Hizli 33.66 0.46 42 414 1 Vidyasagar Park HIZLI TSS 29.69 -0.04 37.1 415 1 HIZLI TSS Hizli 17.65 -0.95 22.7 Farakka 416 1 Khejuria GIS 36.25 -2.44 22.2 Switching

164 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING Farakka Ambuja Cement 417 1 10.01 2.96 12.9 Switching Tap Ambuja Cement 418 1 Raghunathganj LINE IS 0 Tap Ambuja Cement 419 1 Ambuja Cement 10.00 3.24 12.9 Tap Kharagpur 420 1 Kharagpur DVC LINE IS 0 Traction Foundry Park 421 1 Food Park 9.61 2.90 13 Tap 422 1 New Haldia Bajkul 50.48 10.62 33 Resmi Metalic 423 1 Vidyasagar -38.88 -14.53 52 BLK NewTown Action 424 1 SALTLAKE GIS 50.20 5.57 32.3 area-I 425 1 Bishnupur Old OCL Bishnupur LINE IS 0 426 1 Chanditala Domjour -36.25 16.31 25.8 427 1 Bajkul CONTAI 27.79 5.06 36.2 428 1 OCL Bishnupur Midnapur -1.00 0.00 5.3 429 1 Mankar Emami Cement 0.80 0.54 1.2 430 1 BTPS Kalyani 56.34 15.13 72.9 431 1 BTPS Lilooah 58.66 16.21 38 432 1 BTPS Khanyan -0.44 13.60 18.1 433 1 BTPS Satgachia -25.14 17.12 39.9 434 1 BTPS Bighati 8.42 11.35 18.9 435 1 BTPS Bighati 8.42 11.35 18.9 436 3 BTPS Dharampur 137.25 38.01 59.3 437 1 KolaghatD KolaghatW LINE IS 0 438 1 KolaghatD KolaghatW LINE IS 0 439 1 DTPS-D ASP 18.16 7.86 21.7 440 1 DTPS-D Kalipahari 23.50 2.49 25.8 441 1 DTPS-D Kalipahari 23.50 2.49 25.8 442 1 DTPS-D ASP 18.16 7.86 21.7 443 1 KharagpurD KolaghatD 2.51 -1.24 3.5 DVC 444 1 KharagpurD KolaghatD 2.51 -1.24 3.5 445 1 KolaghatD KolaghatT 4.29 1.91 5.8 446 1 KolaghatD HowrahD -1.32 0.36 3.6 447 1 HowrahD BelmuriD -6.62 2.96 9.6 448 1 HowrahD BelmuriD -6.62 2.96 9.6 449 1 BelmuriD Burdwan -15.94 1.08 18.6 450 1 BelmuriD Burdwan -15.94 1.08 18.6 451 1 Burdwan DTPS-D -54.69 -0.50 62.1 452 1 Burdwan DTPS-D -54.69 -0.50 62.1 453 1 Kalipahari Klyaneshwari -5.63 -6.64 10.9 454 1 Kalipahari Klyaneshwari -5.63 -6.64 10.9 455 2 PuruliaD Jamshedpur 22.12 -2.28 14.3 456 1 Jamur1 DTPS-D -71.25 2.94 79.6 457 1 DTPS-D RamkanaliD 13.21 -1.25 16.4

165 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 458 1 SonicTD Barjora -51.71 -1.56 55.6 459 1 KolaghatT HowrahD -4.32 0.42 5.5 460 1 KolaghatT Badrinarayan AS 8.61 2.36 10.3 461 2 DPL DTPS-D LINE IS 0 DVC/DPL 462 1 B. Garden SRS LINE IS 0 463 1 B. Garden SRS LINE IS 0 464 1 SRS Majerhat LINE IS 0 465 1 SRS Majerhat -21.02 -5.00 21.9 466 1 Majerhat Taratala -2.99 9.84 8.5 467 1 Majerhat Chakmir -116.84 -5.98 91.2 468 1 Majerhat Chakmir -116.84 -5.98 91.2 469 1 Majerhat Jadavpur 35.07 4.31 28.2 470 1 PRS PLN LINE IS 0 471 1 Taratala Chakmir LINE IS 0 472 1 Taratala Chakmir LINE IS 0 473 1 Taratala PRS 62.69 8.88 50.7 474 1 Taratala BBD Bag 65.82 9.42 53.1 475 1 Chakmir BBGS -105.85 0.60 59.5 476 1 Chakmir BBGS -105.85 0.60 59.5 477 1 Chakmir BBGS -105.85 0.60 59.5 478 1 Chakmir BBGS -105.85 0.60 59.5 479 1 EMSS PKL 32.05 -4.07 20.9 480 1 Jadavpur EMSS -70.10 -3.36 55.8 481 1 BBD Bag PRS 3.81 2.88 4.3 482 1 BBD Bag PRS 3.81 2.88 4.4 483 1 Titagarh Gen BT Road -72.24 -19.55 48.5 CESC 484 1 Titagarh NCGS -38.02 -6.80 40 485 1 NCGS BT Road 81.22 -3.44 54.1 486 1 Chitpur Tr East Calcutta 60.61 -5.13 49.8 487 1 PRS PRS LINE IS 0 488 1 East Calcutta EMSS -102.68 1.41 66.5 489 1 Chitpur Tr BT Road -60.49 -4.08 48.2 490 1 East Calcutta PRS -70.12 -29.52 59.7 491 1 EMSS Kasba -28.68 20.11 22.7 492 1 Park Circus PRS 82.23 1.98 53.5 493 1 SRS SRS LINE IS 0 494 1 B. Garden SRS LINE IS 0 495 1 BT Road Dumdum -49.95 -1.28 32.5 496 1 Park Circus EMSS -103.24 -11.36 67.3 497 1 EMSS Patuli 32.04 2.42 21.7 498 1 NCGS BT Road -38.10 2.60 49.6 499 1 NCGS NCGS LINE IS 0 500 1 BBD Bag BBD Bag 26.83 7.71 12.4 501 1 Titagarh Titagarh LINE IS 0 502 1 EMSS EMSS LINE IS 0 503 1 East Calcutta EMSS -80.09 -0.97 52 504 1 EMSS Dumdum LINE IS 0 505 1 EMSS Dumdum LINE IS 0

166 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

No. FORWARD Sl. of From Station To Station % OWNER No MW MVAr ckts LOADING 506 1 BT Road BT Road LINE IS 0 507 1 PRS Majerhat -37.06 10.28 41.4 508 1 Majerhat Majerhat -79.39 24.15 36.8 509 1 PLN PKL -32.04 -3.22 9.5 510 1 East Calcutta East Calcutta LINE IS 0 511 1 Jadavpur Jadavpur LINE IS 0 512 1 EMSS EMSS 87.02 46.89 2.5 513 1 PRS PRS LINE IS 0 514 1 EMSS PRS LINE IS 0 515 1 Titagarh Titagarh Gen -19.12 -7.35 9.3 516 1 BT Road Titagarh LINE IS 0 517 1 SRS Majerhat LINE IS 0 518 1 PRS PRS LINE IS 0 519 1 ECAL PRS -70.12 -29.52 59.7 520 1 ECAL EMSS -80.09 -0.97 52 521 1 ECAL DUMDUM 83.10 4.43 68.4 522 2 DPL DPLB 100.39 36.34 67.7 523 1 DPL DPLA 16.15 5.47 21.8 524 2 DPL DPLC 41.44 18.14 28.8 DPL 525 2 DPL DPLC 56.17 10.57 36.3 526 2 DPL DPLAB 18.08 -5.26 11.9 527 2 DPLA DPL-Bamunara 20.07 3.95 13 66 kV lines 528 1 JALI JALI 13.45 -0.94 26.9 529 1 JALI JALI 13.45 -0.94 26.9 WBSETCL 530 1 JALI Chalsa 13.40 -0.96 26.8 531 1 JALI Chalsa 13.40 -0.96 26.8

167 PRDC Bangalore September 2017

Geographical Diagram of existing Eastern Region network (May-17)

Dikchu Teesta 5 0.00 1.00 SIKKIM Teesta 3 TEESTA-5

1 ) 52

6.8k 1.00 8 8 3X170 MW TALA m 2

1 - (9

(15) ( 3) 6X170 MW

m

5

k

2 2

-7 5 4 -

1 1 2 7k TEESTA-3 ( m

3 ) Malbase 9 4

) 9

2 Rangpo

6X200 MW 3 0.00

( 5 1.00 0 (0 258

) (-90) 0 (0) Darbhanga 1 -1 50km (-1) 1 1 Tala 0 9 (0) m (DMTCL) k 9( k 1.01 m 1 1 5 0 15 ) 1.00 E , 2 1 m T ) , 9 2 S 8 9 k w ( 4 9 8 Alipurduar_PG 2 O in 5 6 8 ) 2 3 (1 4 O M - . 8 121km 3 1.02 3 1 M o 9 ) - 161 (234) 4 o 1 (0) ( k Kishanganj N s 1 7 114 km, Quad Moose m (85) I (e 8 5 114 km Gorakhpur -1 4 2 , W 9 (183)

Q 0 1.01 -0 T 4 83 Bongaigaon u -2 Moose ) 261 a 4 72 km, Quad -83 (-88) km d 2 (NER) , M ( 0 Qu o 4 -864 (168) ) ad o 9 (0) 861 (-79) 9 0 (0) 217 km, Twin Moose Mo s ) (14 os e Muzaffarpur e ) 87 e os 8 -5 Binaguri Mo 3 34 -17 1.00 ad ( 1.01 9 1( BIHAR Qu 7 e km -28) km, 1 os , Q - 47 m -3 Mo u 171 1031 3 Purnea k n ad (-35 2 wi M ) e 240 km, Qua 7 , T Balia oo ) s d Moose 1.01 km 1 s 8 o (-53) 7 8 8 e 3 m -1043 6 0 o 1 1 km 1 k 3 , ( M ) Qu 9 2 (5 a 2 3 n 0) 2X660 MW (-27) ) 1 d 1 i ( 36 95 Mo 1 (-1 km os w 0 6 Barh 2 , Q e T 3 (0) 58 ua -20 -348 (85 6 ) 1.01 0 d M 2 ) 7 9 o (1 3 e 5 os 13) ( oos e d Moose 6 M ( Saranath 321 3,69 km, Qua 58 uad 4X210 MW+3X500 MW 1 km, Q 2 9 ( , Q 1 4 uad M 2 -21 5 km Kahalgaon 6 0 (Varnasi) oose 8 8( -71) 9) 32 7 ) 3 k 99) -942 ( 2 41 m (285) 1.02 0 k km Q Patna 941 -662(137) 71 m , u 1 , 76 Q a T -9 k ua d 1.01 -1 217 km, Quad Moose 229) w m d -1 2 (- 5 Allahabad , T B B 60 (1 (8 9 ) in w er e 74 (0 ( in si r ) ) Twin Moose M -6 215 M m s 0 89, 102.5 km 145 km, 8 9 km, T o iri im 1 -3 2 o ) Malda_PGCIL win Mo os -1 s Sasaram r 2 (21 28 (36) o ose e 27 is 8) 547 (-8) -551 ( s 1.00 /1.00 -551 327 (-138) (142 21 e 1.02 -1 (-6 Moose ) 4 6 5 (61) 4) 2 km, Twin 2 95 ) (58) 19 Lakhisarai ) ) 545 (45) 485 -6 7 (48) k -4 m -8 m 4 FARAKKA (3 (41) 356 km, Quad Bersimiris 112 (-31) 9) 1.01 ( , 2 k 5

450 T ( Fathepur -2 18 m w (3 4 153 3 0

(45) k ) 0 8 m k in 1 3X500 MW 6 , T 5 ( 4 4 0 win -29 M 1 8 - ( Mo o 2 ) 1 - Biharshariff os e o 3X200 MW 6 2 Gaya e 4 - ) s 3 5) 3 4 4 s e 8 8 ( ) 1.01 8 3 (2

1 1 0.99 /1.00 9 o 6 ( 8 (

k 7 3 o )

3 m

m ) 2 9

) M k - Farakka

437 (148) 2 6 2 3

, 2 - 6 n 7 1.02

T 111km ( 4 7 w -1 2 i

6 2 7 Banka 7 k 4 2 1

i (73 2 km w n 0 ) , m 2 Q ( (

u 1.01 T 0 a - 8 Moose Quad d M 5 ( 1 2 M 8 9 0 77 o ) 5 ( 2 km o 1 2 s o ) 6 e )

) 5 0 )

o Nabinagar 7 4 k 2X300 MW m ) 1

) 0 9 ( 2 92

s ( 2 5 Q 3 8

e 0.00 456 1 4 ) ( 8 0 4

(104) 1 - 4 .

// 1 u - -451 Sagardighi

6 2 2X500 MW 4 ( 5 1 2 7) ) ( a 1 3 1 Bakreshwar k

1 2( - ( 1 7 3 9 - d 9 1.02 1 5 4 m -4

) 2 2X210 MW 9 Maithon-RB ( -153 6 7 7 ( 2 e M 1 7 2X525 MW - (-8 9 0 4 s 3 0 k 0 ) 5 ) ) o Koderma 13 1.03 0.99 ( 8 m k 6 o - o m 7 8 5 1 Behrampur 1.01 ) o 26 4 s , (1 3 5 9 Q - 2X500 MW 26 Maithon 2 - 1 km 7( ) M ) 1 1.02 e u 3 -2 3 ) 0 0 e a 4 8 ( 3 d 7 (12 1 ) s ) n ( 1.02 5 2 4 i M 8 5 30 ( o Chandawa o ) 6 - 31 -48 o 4 km -3 w 345 0 (-4 JHARKHAND o ) 3) 73 km ) 1.00 s 3 -1 708 -298 - 6 T 9 e ( ( ( ( 1 6 (34) 519 , M 6) -1 2 364 ) e 4 ) 1 (166) s 27( 24 5 6 6 7 o 1 ( ) 2 m m - 1k d - o 5 (122) ) ( m Bheramara (66) k -I Bokaro M 5 7 k nd a ose 3 ( i o m, Twin M n m 0 4 1 (127) 2 an 69km 85 k i k 2X500 3 6 po u ) 1.02 w e 3 .7 ) 0 7 rti // 24 , T s 5 -3 on (Bangladesh) (- o k 5 1 1.01 Q 3 m Mo m 3 k MW 1 8 in 5) ) 2

3 (-6)

- ) 6 (61) 8 w (2 m Gokarna 2 1 T 5 3 4

-520 (-79) 0(6 , // -81 2 k ) 3 / 3 -1 km -26 ) 2 4 2 6

) 7 9 0 8 5 0 m 21 9 1 0

2 0 k -357 270 (36) ( ( k ( 2 9 9 7 6 1 0

(165) , m 141 71 2 6 350 ( 6

9( 30 ,1 (

3 4 k 5 m 3 5 9 7 3

7) 1 DSTPS m , 8 8 ) 70.5 km k 0 5 k T -7 (63 (-172) 5 m 20 6 3 (55) 1.03 ) 1 , w 141 (165) (-1 12 9 , T 18 129 5 65

7 ) Raghunathpur - T w in 8 (-64) 1 -71 1 w .6 55) -79 Parullia km 1 ( m i in M Ranchi new 26 4X225 MW 1.03 k 2X500 (62) 1 n 1 - ) 6 1 1.02 M o is (151 PPSP 1 e 2 M m k o ir 1.01 / 1.01 392 34 ) k os (- MW 6 o o 5 m 3 4 ( o s rm 1.02 6 7 o 7 8 o ) Ranchi ( 7 M ) - s e e 5 B is (72 3 1 in 55 871 e s r - -1 7 e ad i 1.02 (76) 5 (48) 65 8 Tw u rm 17 7 (105) ) Q e e -1 8) (37) Bidhanagar , B s Adhunik -25 (3 Mejia m d o 3( ( - 362 4 7 k a e 8 2 1.01 ) 6 u os o ) 1.03 5 1 o 2 ( 5 .// Q M 2 - 3 4 , in 2X270 MW Jamshedpur 185 5 1 4 w M km, Tw ) 3 6 m T in Mo 1) 1 1 3 k , ose 16 ) ( km n 1.02 ( 1 3 1 05 i 1.02 0 4 3 5 0 3 w 488 486 6) 3 (2 km k k 8 8 T -21 155 16 1 21 (1 m m -178 , 0 km 5 Jeerat 0 (46) (53) , ) (40) ) k m 0.3km (-4) - ( - Tw 2 3 0.99 e - i 224 0 3 n (44) m k 4 M 1 s 5 ) 5 ) oos 1 o ( 4 e ) 6 5 5 1 3 25 5 o 0 4 Chaibasa ( 2 1 7 5 - M ( 1 m 1 9 (1 ( 2 k 7 4 WEST BENGAL ) k 3 343 TISCO 6) in 8 1.02 6 m 7

482 7 4 )1 7 w - ) 3 4 ( Arambagh T 1 ( 7 2 16) (DVC) 30 1 7 , 1 9 90km 1 ( (89) 1.00 - 8 m k 1.02 1 km k k (-1) 8 m -195 (9) 1 9 m 6 ) (45) -502 , 4 3 546 (180) Subashgram -30 T 1 1 1 e 2 ( 9 s m 1 oo 02 k 1 w 1 2 2 0.99

1 6 4 M e 7 ) 1 n 3 s 1 6 6 wi 1 o (-57) i 4 - T o . 2 5 , (3 M 5 n k 91km ) - ( ( m 6 k - 0 k ) win m m (81) 12 (39) T M 499 -148 147 Haldia 151 km, Hexa Zebra 337 3 Sipat Dharmjayagarh Tw o // 0 9) i o 6 1.01 ) n 2 -1 m 15 (11) (88) 5 - ) ( s ) 7 ) 2 Bisra 1 ( (102) (146 1 0 oo m ) 1 5 6 1 e 9 k 1 5 s ) Twin moose 46 (- e 4 0 3 5 2 7 2 ( 1 6 2 (4 0 (2 4 0 ( 6 5 8 1 5 1 2 4 5 1.01 ) 7 Kharagpur ( - 4(4 5 )

2 1

ose 0 9) - e Mo km 2 ) 1.01 KTPS 2X300 MW - 8 win 5 s (2

, T 3 Keonjhar 28 ) 1.00 o m e 1 )

0 k os 0) e 4

o ( o s 1 0 Baripada

1 M oo 3) 1 3X210 MW

in (PGCIL) M (-1 -

w 7 M

, T Jharsuguda in ( m - Tw ( 1 k 2 , (Kuchei)

9 n 1.01 km - i

5 7) 8 1.01 1.02 Rengali 156

se 0 7 1.01 oo (2 7

M ( 7 w 8

, Twin 8 -2

km 2 T

30.4 0 6 1.00

2 -

m ) ( , 19 Raigarh ) 4 1 8 ( (54) k ) 2

se 3 (-21 o m 8 in Mo 5 -2 m, Tw . 2

147 k k -9 0km ) 0

2 ) 2 1 6 Sterlite 1 6 9 7 8 4 2X600 MW (41) m

2 1 2 7 TSTPS

- 1.01 24km 6X500 MW k ( JITPL 1 ) ) ) k 2

0

0 m 0 1.02 1.00 2X350 MW 9

( 4 9 0 56 2 1 , 2 ( Duburi 1 Q

3X600 MW ( 4 9 62 e 0 u (2 6 GMR 6 1.00 2 ( s 3 3 1X600 MW a ) 4 16 ) o

0 1 ) 2 d 0) 1.01 7 1X350 MW 2 ) ) ( 1 0 ( o 1 B 8 (6

0) e 335 ( m JSPL 0 m 5 -7 r

0.00 1 s 5 2 9 (2) ) k - 2

1.01 7 5 5 - n GMR-3rd unit 5 i

im 4 ( 4 6 3( 72

- -

) 1 9 Ind-Bharath 9 ) )

( 8 4 w 1X350 MW i 1 ( 4 2 -4 r 3 4 4 3 1.01 1 e 6 m 9 ( 9 T i 3 5 s 3 1 ) 3 ) s ( k ( 69 3 o - 8 m 5 m o ) ( m e e 5 6 6 k 5 5 2 k s k M 1 ) . 7 o s ( m 9 8 3 o 0 n ) o 6 k k // M 3 i -2503 (-159)

m 8 Bolangir_PGCIL m n 1 o w k 5 i

. - 2 Tw T 6X135 MW 0 - m ) 2 8 , 3 ( 1.01 ) 3 7 4 6 7 ( 1

. 3 4 9 - 5 4 n m 0 km 2 - i 7 ) 1 k 5 3 73 7 8 1 (3 2 (4 w 3 ) 3 ) 4 6 ( 1 ) 5 ( 46 T 8 ) 3 (- 3 1 23) -2 (

0

0 1 6 98 k 340 ) ) 9 2 ) ( m - 3 0 8

4 , ( 5 Twi 8 1 1) 9 7 - 7 - n M - oose 2 ( ( (-165) 9k ( 2 8 41 m -1 65 8 74 ) 28 2) Pandiabil m 2 8 -1 , 25k 2 ( ( // (6 4) 8 5 4 6) (17 1 1 0 99 1.00

- 3 1 ) m -84 ( 25k e Angul

s

) Mendhasal

o 4 ORISSA 1.00 1.01 3 Meramundali o 3 0 - 1.00

M 5 1.01 (

n 9 i 5) LEGEND Existing w (6 Indravati T se Moo m (PGCIL) in s w i k ) 2 , T 3 km r 765 kV S/S 5 0.99 2 i 8 3 9 22 8 ( ( 4 2 1 m 8 4 k i m m 6 ) s k -2 r - 6 ( 2 e 400 kV S/S 5 7 - B m 1 9 Indravati 2 k 2 ) d 2 r 7 0.99 a

) u 765 kV line 6 (2 ) Q -4 0 ( 4 7 6 2 400 kV line -59 Jeypore 4 Thermal (5 0.99 1) generation Kolar Hydro 2 25 k m, T Srikakulam generation win M oose Pumped storage plant 58 6 Gazuwakka Display Notation (106) 0.97 Injection into the bus : +ve Drawl away from the bus : -ve Voltage Mag/(Ang) in pu /degree Flows in MW and (Mvar)

Power Research & Development Consultants Eastern Regional Power Committee Private Limited 14, Golf Club Road, Tollygunge, # 5, 11th cross, 2nd Stage, (Eastern Region existing network May-17) geographical map West of chord Road, Kolkata, West Bengal 700033 Bangalore-560086.INDIA R0 09/11/2017 Tel :+91-80-4245 5555 E-mail:[email protected]

TM APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REV DATE REMARKS LOA details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 DRAWN USING : MiP-PSCT DWG. NO. : Geographical Power Map\May-2017\ER N

SURAJPURA (HEP) (NEPAL) Geographical Diagram of Existing Bihar Network (May-17)

7 . 2

k m

P a n t h e r

- 2

2

( 2 )

)

7

KARBIGAHIYA 4 VALMIKI NAGAR HEP 6

22 (-2) 1 - 9 - 0.93 0.94 -5 GAIGHAT ( 0 95 ) 8) JAKKANPUR - 8 -1 0.95 67 (8 0) -2 ( ) 3 X 5 MW ( ( 2 ) 0.94 8 0 0 -31 ( (0) (9) 0 m

) ) 2 k KHAGAUL TSS e ( r l 0 e KATRA ) 5 b . h 1 2 0 t -75 0.94 8 a 2

(

2 0.95 ) n -4 3

KHAGAUL (0 C a 1 - (-11) 7 4 )

7 P

2

4 - ( 1 )

7 1 0

2

DIGHA 3 1 k 4

7 k 0.96 0.94 - m 5 m - 1

1

. m ( k

( 8 7 k (-1) (1 0.94 5 k

) MITHAPUR m m 16 km 55 P 0.94

a P r

n - a ) 0 1 e

t 5 n

h (6) 1

m 1 ( 5 h

k m t

t e 0 8 - 1 5

5 1 h

1 ( r k

1 8 3

) ( k ) n

3 - e

(0 7 m 6 9 5

5 a

) - r

1 2

P 4 (

a 4 0 -

PASCHIM CHAMPARAN r ) a 1 6 P

b n 2 e 7 Z th 8( km m (4 5 ) ( e -2

BALIA-PG k 0 r 2) P m

) a k 5 r Zebra

ARRAH-PG . e -119 n KISHANGANJ-PG 4 SIPARA th 7

1 h e 1 t r ) 4

( n 39 km (-35) )

2 - 2

1 a - 0.98 3 0.96 1

3 P 5 8 9 9

6 ) 2 - - 9 ( 7 1 1 RAMNAGAR 2 6 (

0 4 ( k ( ) m 1 2 6

9 ) ( k - Z ) 8

8 2 4 m 7 e 0 7 ( 6 FATUHA e - 0.94 ) 6 ) br - s 2 3 35 a - oo 2 2 km Pa 3 d M (5 ( nther (0 0.98 0.97 Qua ) ) km HARINAGAR -29 9 MASAURHI -61 347 -8 0. 6 ) 1 (-9) 7) BIHTA 3 5 -1 6 0 (0) SUGAR MILL - -2 0.5 km 0.94 -1 (-16) m 0 ( km Z ( 0 -942 8 k (0) 0.93 Z eb bra ) se 0.94 r eb ra -3 Ze (0 Quad Moo the ( SWADESHI ra 64 km 93 km BARH-NTPC 1 an 0 ) 0 1 ( 8 (0) P - ) 4 -1 2 0 .1 0 0 0) ( P 1 k SUGAR MILL - 2) ( an m 155 Pant (-71) r 5 t ( her 6 m h -4 - e ( 1 e 0 0.00 8) -6 k 1 r 1 h oose 7.2km KHUSRUPURRLY t ) ad M ( 0 m Qu (2) (-2) - n ( 69 k 0 1 4 0 (285) 0.97 a ) PATNA-PG 41 P ) 1 9 an P . Narkatiyaganj th 5 1.01 0.98 er CGP - P 0 k a 45 0 ) 0.97 0 k m ( 195 km Panther km 30 n m (0 0 - QUAD MOOSE -420 t ) HARNAUT ( 0 4 h -20 1 X 14.5 MW 2 P ) er 0.96 a k

) -7 m n (-12) 1 -4 ) t CGP ( 2 HFCL BIOFUEL h (- (-2) 180 km QUAD MOOSE (211) 0 e

) (-5) 4 7 ( r (-1) 1 X 10 MW 0 4 LAURIYA 1 RAXAUL - ) 26km

r 4 4

( r -20 e e Z 0 0.94 m 0.97 th h e k

t CGP k n b m a PATNA n r -65 BARIPAHARI 5 P

a a 1 X 14.5 MW . m

P - 5 k JAHANABAD 0.96

5 5 ) (-20) ( 3 .1 3 7 8 0 - m 2 3 k - 3

) ) 2 ( 4 5 5

( 0 2

k 7 9 - m (-45) BETTIAH 0.97 -23 ) BIHARSHARIF BSEB

0 (-7)

)

1

2

-

( ( 0 (0 NALANDA ) 4 6 7 5 k 1 - 8 m Pa nth er DHAKA

GORAKHAPUR-PG r ) 0.93

e

4

5

h

1 t 0 4 0

- - 6 Chaundathi (Gaya) n ( m 1 0 ( 24 k (0

a ) 16 ) P - 6) Panther ( 5 ) 6 ) 2 m MOTIHARI (-5 k 0 1 5 m k

- - P (0) ( a 8 n . 0.93 th Dhalkebar ) e 0 r 0 ) 6 r

( 4 0 e SITAMARHI (Nepal)

1 ( 0 h 0

( ) - t 0.92 n

2 a 9 (3) 6 0 P 40 (12) JAINAGAR (0) (-2) m SHEOHAR -9 k 1 0.99

2 3 ) Duhabi(nepal)

- r -13 6

0 ) 0 e 0.92 9 ( GOPALGANJ 1 1 - 3 ( h (-4) 8 k BELSAND t 0 - ( 0.98 m HFCL BIOFUEL ) n SITAMARHI 2 -2 0 0.97 a 5 , ( 3 r

P ) e

Q r d SUGAULI - r ( th 8 e i 1 u r

- n RUNNISAUDPUR m

) 9 a 4 e h b

) a 0 -9 (-3) k ( t ) P ( 0

h

2 0 d 0.93 3 w GOPALGANJ - ) ( t n

1 1 0.97 1 m Siliguri (PG) 1 o a ( M a k n r 3 4 - 2 n 5 5 Zeb a 8 9 P , BHARAT SUGAR ) o -7 S 5 . m 8 0 3 k - o P ( e k 08 ) - l m 2 1

1 ( m

0.00 s ) -2 SKMCHSHEOHAR -2) 0

MILL ) p r ( k

e m 1 0 i e P -

m 0 0 - k r )

k 3 a

2 h BINAGURI-PG 1 -11 - ( 0.97 T 5 5

t n

1 X 18 MW 0 8 6 1

4 n t -

(0) (-3) m h ( a a

Zebr -2) k e Kataiya

(0) 6 Hathua ( P r -30 CGP

)

-0 -1 1 6 2 m m 0 2 ) 5 1

k 5 2 0.98 8 1 0.97 3

1 5 (0) k

1 2 (-7) 9 1 X 20 MW 4

CGP (-0) ( km

0 k ) - (

5 -

) m 8 0 3 2 6 1 ( 1 1 MUSHRAKH 3 m ) ) ( -11 k ( 2 - 1 0 1 MADHUBANI 5 5 . -8 - 5 6 0 GANGWARA 0 ( 2 4 1.00 (-3) 6 Mushahri - PULPARAS ) 1 0 - k 3 . 3 - Motipur m 6 r PURBA CHAMPARAN ( 0.99 9 9 9 1 e P 0.99 (-3) ) . -16 24.2km -64 an ( 0.98 3 k 7 h (-17) 2 ( (0) th 0.97 0.97 m k t 0.98 0.98 er 18 0 3 m n -44 ) 8 - (-3) a (-17) (0) 1 P 3 2 x 110 MW ) 3 FORBESHGANI ) -0 (1 e P 8 ) -25 a (-6) ( s 0 0 MADHUBANI -41 n - (-2) 2 1 ) 0.99 o

( 1 - o

r (2) 27 km Pant 5 t

m 1 1 1 0 1 4 her - ) 0 ( e 1 ) 1 (-8) h -42 ) M

.3 - - 4

k h 5 k ( 6 2 0

t m ( 0 - e n

m 0 Z ) ( ( i

- - 1 1

n eb 0 0 1 ) 2 6 r ) w k r ) 3 ( NIRMALI - 4 a a ( ( km 16 9 4 1 4 (-2) T

88.73 km Zebra - (

0 8 8 ) ) (

P 2 4 , 2 0 , ) - r 7 0 (0) - - 16 (0) 1 (- e -8 KISHANGANJ-PG m 5 m 1 - - 1 1 5 k ( 1 1 4 0.98 2 ) 1 0 k 2) 0 1 57 0 ( 8 ) th ( 1 8 ( 9 9 2 2 .8 - 1.01 0 6 n ( 0

- - ( 2 1 PANDAUL ( 1 7 4 2 k 1 a - ( m 8 ) 1 ) 2 SIWAN 118 (5) 15.5km ) 1 (-19) ) Beniapatti T P 8 -190 1 0.99 )

MUZAFFARPUR 2 (0) k m m ) (26) 3 km Panther

0.96 -48 16.7km 6 2 3 k 9 0 (0) 31 km, Zebra

0 1

- 9 3 ( 3 1 4 3 Dalkhola (PG) 6

0.97 5 ( Darbhanga - 6 1

(-15) 2 ) - 5 0.99 .9 . k ARARIA ) 5 - 1 1 9 m 7 (2 ) k ( 0 ) 1 ( 0 9 5 6 5 ) 68 0.00 -6 TRIVENIGANJ 9

m 2 . m P

6 ) Z 5 e - k 8 ( 7

k -55 - 2 e m 1 - KISHANGANJ ( s 1.00 ( b Z - 7 -

1 4 ra eb (1) ) ( 5 o )

3 km ra a (6 88 ) 1 3 1 x 195 MW (3) o SUPAUL - .6 5 6 ) 2 n km 6

6 the 3 8 ( 7

M P

) MTPS KISHANGANJ 4 a 0 (

MUZAFFARPUR-PG 1 (-1) -4 nth 6

6 - - ( e - d 4 ) r 0 - 1 1 4

Ekma 6 r a 0.99 0.98 ( 1

6 9) 1 0.99 0.96 3 (1) u 6

0.97 (- 2) (-1) 93 (-0) 1.01 1.01

(-6) Q -134 5 ( 0 Amnour -342 )

) , (-32) 8 2 6 Beniapatti

2 1 ( 2 - m -

- 0.6 km (0 - - k DARBHANGA OLD 0.99

( m 5 9 ) 0.98 3 (-56) k

0 1 ) 9 SUPAUL (

.1 -242 MUZAFFARPUR(49) -81 - - - -1 54 4 k 24 2 2 0.99 4 7

Ekma Tap ) 2 4 ( ) 0.98 3 m - ) 1 0.98 11 9 e 1031 ) 2 ) m

)

- ) (9 ( ( 1 s 0.97 (-4) ( - 5

K 3

50km Zebra 8 (1 7 0 o 56 (-1) ( 8 2 -

9 - ) ) o -5 3 8 (-0) - 5 (

6 1 2 3 )

1 ) M (-6)

7 ( 1 5 ) r - 2 1 3 e ( n i 0 - ( DARBHANGA th -21 3 w 1 5 n P 9 e SIWAN a T PAHIYA KARKHANA 2 46 NEW(DMTCL) P 3 a k , s 70 k - 0 n m o 2 m, Z t m o 6 ebra m k h P k 0 km RAIL 0.95 (- 1.00 0.99 1.00 k m e M -72 (0) P 3 3 0 DARBHANGA r a 8 an 5 ) 4 nt 6 d th -20 MADHEPURA h 1 a 11) er k -10 e u ( m 8 1 SARAN 5. -5 2 ) r Q 2 3 P (-3) (-7) 40 9 , 4 k - - MADHEPURA 1.01 19 m km e 1 - a , ( BALIA-PG n ) ) P (-1) , Q os 0 BANMAKHI m 9 a u o k - )

t 3 5 n ad ( 1.00 0.99 Vaishali a t 9 h ( - h SAMASTIPUR M 1 DALKHOLA ( e Mo SAHARSA -6 8 1

e r o ad 1 1.00 ) -

br s 0 2

r r 0.96 ) e u ) 124 -1 9 ( DALKHOLA-PG e Q 3 1 PURNEA ( 1 e - New 1 (

(

2 3 m 1.00 (-6)

3 h Z k 37 t 7 2 7 0 km ) n 1 4 5 ) 70 1.00 (17

0.99 0.99 3 7) 100 km Zebra CHHAPRA TSS m ( 1 a k 4 -38 -

) 9 ) ther 0 k 2

- -25 n

5 P m Pa

3 k 0 -2 ) (-4) 3 r

0.93 - )

m 3 ) e 3 ( 3 4 (

m m VAISHALI - 7 h 5 ( , (-10) 8 k ( 5 5 t 6 T

Q k ) 2 ( 10 -

u - 9 1.2 km 1 n P 5

w anth ) 6 2 1 er a -6 2 - a

d 0 7 . 0 - - ( 7

8 0 ) i ( P

M 1 HAJIPUR - )

3 n 5 5 7 ) 2

o ( 7 ) 9 0 -

o (-2) 0 MAHNAR - 0 ( 9 m 1 .

s ) 0.96 M ( 3 ( k e ( 2 1 CHHAPRA -3 ( 5 2 0

k o 0 8 a ) -6

m er 7( 3 0.96 SAMASTIPUR ) k r 0 7 r h 4 m ) 5 t ) o e 5 3 b

0.93 2 ) an (0 ( e

7 - h 1 3 7 P s 6 (-2) 0.99 t 8 Z

( ( m -10 0 6 1 ) e 4 4 30 k - an 3 (-27) m

7 0 9 4 k -6 (-2) (5) 2 -2) ) 5 (2) P 6 )

1 3 ( (1 (19 (0) ) 2 1 41

)

- - 7 1 ) 0 ther (0 ( - 9 . 4 ) 0 - m 3 8 3 m ) Pan - ( 3 40 (-6) HAJIPUR TSS k 0 km 0 0 k ( 3 7 0 0 0 km 2 8 ) ) 0 - 1

P ) ( 5 1 an 7 2 5 ) k

4 - ther 1 k m ( 2

- ( 0.96 - 3 k 5 m ) 5 m - ) 0 9 0

1 ( - r

1 - 5 2 UDAKISHANGANJ 4

( (2) e

1 3 h (

SHEETALPUR ( - t SAMASTIPUR -11

-5 ( an SAHARSA (5 ) 6

) 1 ) m 0.97 ) 8 - -6 P 0 k Traction - -1 ( 1 9 0.95 HAJIPUR NEW ( (-4) 4 5 - 0 1 5 SAMASTIPUR3 0.99 0 -9 0.98 0.96 2 (- 9 ( ) ) ) (-1 22 (-5) SONEBARSA 1) 0 2 3 0 5) ARRAH -4 ) - ( ( 2 ( 0 km OLD PURNEA-PG 2 0.94 45 km (- 0.98 (2 1 4 3 0) ) r 3 2 Khuswesthan he - NEW PURNEA-PG 1.01 1.00 2 JANDAHA 0 - t ) an PURNIA 95 k - (0) P 1 1.01 m -51 9 0.96 -6 0.96 m (1 er (-16) Digha 5 ( 0 k 4 , nth DALSINGSARAI -13 15 0) Q Pa 0 U km (0 m 4 5 ) 0.97 5 0 (0) ) . 3 (-4)

A k 2 1 - ) 1

6 7 2 6

-7 6 1 - D -

3 5 2 BIHTA DUMRAON ( k ( BUXAR ) 3 (- ( (-6 M (-2) ) km 1 m 2 3 0 ) 9 0 ) 5 0.91 0.91 6 O Gaighat HASANPUR -0 k 2 6 P m 6 9 r r O - -28 16.1 km - 3 a 0 e P ( -28 ARRAH RLY e a 1 S ( SMG 4 n n 0 0 Khagul h KHAGARIA h ) (-0) k 4 ) t th KATIHAR E m t t 1 (0 e 28 (-1) Panther - 0.94 ) h n r (-10) (2) 29 0.94 MITHAPUR - BEGUSARAIn e

2 ) a 3 ) 0 CGP P a ) 0.99

5 - 0.94 r

( -6 P 0 a 4 r (

3 - ( JAKANPUR P e - ( n

) (-5) 8 t th ) 0 h m 0 n KHAGARIA m 1 - 1 X 10 MW e m a )

k ( 0 0 k 6 r k P 6 ARRAH-PG 8

( 2 ) ( 0 2 0.98 2 7 m - - 8 k 1 - 3 ) -2 6 7 ( , - 0 0 0 5 ( 0.95 0.94 5 6 6 6 T

0 r 1 e w -3 ( ) ( ) ) s 2 o

(1) e 6 r KATRA 2 -2 Mo i

2 e ) 0 (

h 4 ) d n

m 0 ( 136km Pan a t th u

8 1 m th ( Harnaut 3 er Q

(-1) k MASAURHI , M

m n

k n 2 x 660 MW 1 k

k - 2 a 5 a 23 o

m 3 PATNA -34 3 . o P P DUMRAON RLY 6 1 BEGUSARAI ) s , r (-10) MOKAMA RLY -61 2 0 1 e Q e k - 0.91 3 0.98 0.98 ( h 9 3 -7 0.94 m u 6 t 1 ) 6 (-51) a k 0 n 2 m d ) CHANDAULI ( ( 3 (8) 3 a a 2 -2 - ( ) 5 ) r P 1 14 B P b Sipara BS a 2 - 6 - BUXAR 0 e 9 n - e -1 34 (13) t ( KATIHAR

Z h - ( 1) r

( m - NAUGACHIA

1 e 2 (

0 s

r)

k PATNA - -

) m 5) 10 km Panther 4 8 9 1 JAGADISHPUR - 5

i k ( 3 0 (

m ) 1 5 6 4 7 6 5 ( ) 0.98

5 BARH-NTPC ( i 1 0.94 8 - BARAUNI KARMNASA s 1 1 1 ) (1 HATIDAH 3 7

) 3 0 1 ) 0 0.98

1 ( 0.99 KOCHAS 0 Fatuah Baripahari 1.01 0.94 8 0.95 ) -21 K ( BHOJPUR 0 ) 4 (27 m r 2 7 ) ) ( ) (- 0.99 e 6 ) 1 5 0 5 m - ( ) 1 0 2 X 110 MW 217 km, Q

0 ua h d M ( - oose

- 0 k

0 ( k t 0 - 4 4

( -2 m ) 4 x 210 MW 0 n

-13 k 5 ) r 7) ) a e - 2 0

0 (0) ( m - h 0 -6

0 - t 6 1

- 8 P ( 2 ( n 2 2 24 Kaimur BIKRAMGANJ KHUSRUPUR RLY 5 5 Pa (13 7 0 ) 2 0 ) 7 KAHALGAON-NTPC ) (- (-2) (- (- - 3 m 2 LAKHISARAI ) ) 7 3 x 500 MW 5 2 1 VARANASI FATEHPUR 5 0.98 4 3 ) - k 8 1 5 0 ) - 5 0 ( 3 ( 3 - 0 a ( (0) 0 8 er 1 ( - ) ) 5 3 br k 0.97 31 k 1 1.02 anth 0 2 ( Ze 8 r m 81

SAHUPURI 27km P (0 1 k 3 3 BIHARSHARIFF m m 3 ) anthe P SULTANGANJ SABOUR 9 ) k 2 P a m 1 ) ) MALDA

1 5 - 0 n 7 ) m )

) (-10) 7 1 k th 4

0 EKANGASARAI 5 2 4 4

) - e P 3 3

k 0 ( ) 0.99 0.97 9 ) 1

( -4 ( 5 - - r

1 - 6 Lakhisarai TSS (-10) 0.97 ( - a 1 31 m - - ( 4 2 r - - 1 ARWAL he

0 nt 9 ( n 4 a

Pusauli New - 1 P 0.99 82

( m ( 1

) 2 k ( m ( 0.95 30 (0)

3 - t - 0 0 h - (0) k ( 0 2 (0 e 2 0.93 1 ther 0 0.97 m JAMALPUR ) r 0.99 0.99 ) 0 4 -21 an ) ( m k 0 (0) 30/31 km ) 7 ) P 2 7 0 6 0 (0) 25km - 9 2 3 ) km 3 2 ) k TARAPUR 2 - 1 ( 1 (10) 40 4 -6 JAHANABAD 5 41 1 ) 7 -

4 r (

2 6 r (-4) 8 1

m ( LAKHISARAI-PG 0.95 2 - 0 Panther ( - 9 ) -16 0

5 e k

10 km ( e ( 2 4

a ) km 15 ( 6 ( 0 6

) 2 3 5 r 8 0 0.99

( ( ) (

- 7 (27)

h 0.93 - - k h

-32 9 -28 -16 ( .

-147 2 (4) 1 0 - t 1 3 b t 0 SHEIKHPUR 1.01 0.99

(-31) 1

0 - 4

3 1 1 ) ( m ( ) 1 - m r 6 - P (-4) 5 e 2 3 (

e 7 6 n 6 ) h n 0 6 nt ( 67 -

) Z k -16 0 1 a 9 a )

P 4

a (5) ) 1 (-9) 5 5 m a . 6 ALLAHABAD k 1 k ) - - k (3) (0 5 n ) 3.5 ) 4 8 ) 6 0 m m 7 2 Nalanda ( k

0 1 P P m m (- ( 1 t 0 P 5 9 ) 7 k h a 5

, k 26 2 4 k ( -71 (-14) (-4) nth (

Q MOHANIA m ) ) 2 4 ) e er 9 k

m m -0 m m , 1 m

2 7 m 0 ) ( )

m r

u 3

P 1 ( 1 k ,

k 89 km Twin Moose (36) 0

0

a ( k a k BIHARSHARIF-PG -551 (0) T

0.99 0

6 k k 0

n

d 2 win Moose w 2 3 2 km, T

) 145

t ( 6 m )

h 3 3 5 i

KUDRA 5 6

0 n k - ) 4

B e - . 1

4

r 1 2 0.99 5 ( 1.01 M

) 9 e - m 0 1 )

JAHANABAD 4 7 1 102.5 km Twin Moose

rs 7 22 0.99 1) ( 327 (-138) -328 (142) BHAGALPUR 4 (-4 o 1 1 2 ) o

k - - 7 0

im m 1 km ( ( 547 (-8) -6 1 ( KAHALGAON s ) e -14 P 2 NALANDA , Z 0 9

i eb 2 1 0 r - 4

s a k 0 27 a 2 0 SHEIKHPURA ) 5 - 5 k 7

2 ) 0 0.92 6 (

(-4) nt TEHTA 1 m r KUDRA TSS 1 0 (- ( ) - (BSEB) 1.01 3 - ( 5 4 m LEGEND ) 0

1 P - - e ) m 0 - 9 ) 5

( 4

) - 7 k he 2 5 0.95 9 0.99 ) a 7 - ) 5 5 (7 ) ) 7 4 h

SARNATH ( n 0.96 0 5 Panther Km 45 0 184 km, Twin Moose 0

2 ( 485 (39) t 5 4 2 (

t 1 1

( (

-2 - 6 h r - 6 n 3 29 -0 ( 8 - FARAKKA e -

) k ) 48 km, Twin Moose ( a (43 6 r 0 ( ) - m 4

- (0 ) 4

( r 0 ) 2 P ) 6 1 ( 8 HULASGANJ r

2 47km Panther

1 m 5 2 9 NTPC ( 1 8

- (-12) 7 1 k ( e 3 56 65km Zebra 2 2 - PARTICULARS SYMBOL 1 1 he k 1 ) ) - 1 - (

2 m 198 km, Twin Moose 6 h m ( 0.94 )

) t k

215 km, Twin Moose nt LAKHISARAI 6 n -15 (61) a

7 3 P 0

2 ) a - 8 . - 4 P 1 5 203 km, Twin Moose RAJGIR (2 r ) a P

545 (58) 5 k 281 (56) 7 2 BELAGANJ )

2 8 0 e ) - ( n - 3 (1 DEHRI 2 m 2 m 1 (-64) GOH 1 m r 4 MUNGER h -127 2 9 t ( 0.96 0.95 m t ) - k h 3 ) - k 0 e 4 - 3 ( ( k n P 3 ) 1 0 9 - - 0.99 0.99 0.96 e 1 -2 ( h ( 5 - 6 9 4 t a a ( k 76 km, Twin Moose 2 1 3 8 r

m 5 8

) ) 0 ) 2 - - - n -8 n P 765kV S.S

(-3) 4 3 SASARAM-PG ( ) 2 12(-3) 9

20 km Panther ) ) P 146 2 2 5 a t ( AURANGABAD 2 4

km 5 WAJIRGANJ ( a h 0 0 n 1

0.99 P ) - - m )

- t -

( e

1.00 1.00 8 )

e ( h 2 ) os o 8 ( 0 0 k ) ad M ( ) 9 8 0 (0) (19) , Qu 1 e r SASARAM -57 7 1 km ( 9 r ( 32 (33) 4 (-19) 0.97 m

0.99 0.99 - 2 ( 1 1 (

( 5 (- ) - m 1 TEKARI ) Chandauti 1 k

4

7 m

4 k 1 6 NAWADA 5 - )

k 1 (0) 5

- 3 1 0 1 3 0 e

- 0.96 2 0.96 (83) 0

RAFIGANJ TSS 8 0 s 5 4 - .

3 9 - 3 2 0.94 1

k ( 0 - 3 o 1

r . m - 1 ) 1 5 e 6

m e 1 SONENAGAR 0.96 (7) ) 0 3 -489 o

s 0 (

k h - ) k ( -16 Jamui 400kV S.S ( 0 - ( 1 0 (

t 3 1 ) ) ( 622 M m 1 o - ) (3 26 km 0 - 1 n ( 0.97 ) 19 0 ) o r - -1 3 ) n 8 a 0 he 1 0.97 ) ) (0) t ) 1 BANKA 8 i

-40 n 6 - a 0 M P ) 5

NABINAGAR RLY P ) 7 6 Panther (0) / 3 ( 6

m 0 6 2 w k 1 4 (-0) ( 1 2 1 0 ( 1 - n 79 35 4 T

m 4 3 - - (-13) km 4 Lalmatiya ) i (-2) Pa 0 (0) 9 0 r k ( - ( (

n 1 1 , 0.00 0 k ther 1 - m ( k 2 e m w ) 0 k 1

8 m 4 h m

a 1 0 T 4 - ) t r JUSNL 3 1 5 (0 (-2) BODHGAYA 0 eb P ) k ( RAFIGANGJ 3 n Z a 4 0 79 ) 6 a m k 1 1 ) k n 1 2 2 ( ) m 220kV S.S - - (-2) 0.96 1 (-5 P 80 t - 7 ) - 5 0.98 0.97 3 h ( 4 1 -1 BANKA-PG 1 - - , e 1 KCL 8 2 ( 0 (0) r 2 0 Q 1 ) 1 -6) 3 1.00 ( 1 1 ( - u 0.98 k 4 - 8

(0) -2 5 a

m 2 4 r m d BANKA NEW - k e k 132kV S.S

1 P 2 (

M - h m 1 7 4 km a 95 (- 8 ) t 0.99 ther r 1

n k o n 6 n 1 a ) m 2 , 32 P

1 X 250 MW e t 3 Z 0 m o

(2) 4 e 4 a k 9 h 1 k br T ( -32 2.5 ( h (2) m a ) 1 1 , s w 3

-1 t e Q ) - P u 3 ) ) 5 ) 2 1 4 (2) r ad ( e (1 n 0 i

- B 2 2

2 1 -79 5 ers - n (-10) a

1 m 765kV Line i 4 ) 4 r - -79 mi 8 (36) - 0 s -

( (-2) ( k

P ( e M 1

3 Jhaja TSS BANJARI 5 h JAMUI

9 9 o

r -13 k t e m ) -3 m o th 3 ) AURANGABAD 27 n k

n ( (-2) P 14 0.97 a 2 a s P 1 6 0.98 40) a

6

- - e P

0.96 n )

m ( 0 GAYA k 5 t 400kV Line ) he 8 3 8 1

- 1 3 r - 2

( 3 km SONENAGAR 1

SHERGHATI m 3

-

- k (

(

2 8

0.98 0.98 ) 7 ) 3

NEW 8

2

3 -3 0.95 1

1 ( GAYA-PG 220kV Line -24 Panther (-2) 0.99 1.00 0.99 2 Paharpur TSS ROHTAS 2 0.96 (-6) 2 0.97 ( NAWADA SHERGHATI 2 TENUGAT TPS 132kV Line Shreecement 5 43 4 7 (148) 23 km 23 TAP ) 6) (- 5 IMAMGANJ m 1 1 14 k ( 5 2 8 7 Load 0.96 5 6 5

k ) RIHAND -13 m (5) , 13 2 (-4) Q 11 72 km Q u 7 ua km d Moo CGP CGP a Qu se 159 91.5 km Zebra -160 d ad M TO DEOGHAR oo M se (6) o (9) o s Hydro Generation e

1 JAPLA 3 6 KODERMA

k m CHANDWA Thermal Generation ,

Z MAINTHAN e b r a Display Notation: BARAHI Injection into the bus : +ve Patratu Drawl away from the bus : -ve Voltage Mag in PU Flows in MW and (MVAr)

Power Research & Development Consultants Eastern Regional Power Committee Private Limited #5, 11th Cross, 2nd Stage, 14 Golf Club Road, Tollygunge, West of Chord Road, Bihar state existing network (May-17) geographical map Bangalore- 560086, INDIA Kolkata, West Bengal 700033 Ph : +91-080-4245 5555 R0 17/09/2016 E-mail : [email protected]

APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REV DATE REMARKS TM LOA details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 DRAWN IN : MiP-PSCT DWG. NO. : Geographical Power Map\ER\May-17\Bihar N TOWARDS TOWARDS KAHALGAON KAHALGAON

4 7 k m , P a SAHIBGANJ n 1.00 th e r 2 1 6 ) 1

5

8

- m 2 )

( k ( - (4 - 0 r ) 5 5 e 1 Geographical Diagram of Existing Jharkhand Network (May-17) ) 4

h 1 1 t -

- 6 -11 an ( (-4 P LALMATIA ) (-1)

1.02 1.01 9 2 2 9 - ) (7 5 ) R

I 1 (

G

J

A

R

TOWARDS S BIHARSHARIFF

D

R

A SAHIBGANJ 7 W 9

O k m

T TOWARDS , Z

e e b GAYA s ra

o

o

M TOWARDS

d

a SULTANGANJ e TOWARDS u s

o

Q

SONENAGAR o

,

M

m

n k i

1 w TOWARDS

1 T

1 , FARAKKA 5 m 6 r k GODDA k e m 2 h , 7 P 1 t a 2 1 n n 6

th k a e k m P r

r , , PAKUR a Q

m

L u

k , a 4 d 1.00

1 5 m M

9 23 ( k o

-11 o ) 9 s )

-16 e 3 4 7

PAKAUR (-1) 2 - 1 - 2 - ( (-2) ( 2 ) - 2 er

7 ) 4 5 th ) 4 an (1 1 KODERMA_D P JAPLA 0 , 5 5 1 m

4 k -2 ( 1.01 / 0.98 /0.96 0.97 KODERMA_D - 85 r 18.3 km SHANKARPUR e 0.94 456 KTPS th CGP n -15 94 Panther -95 1.01 TOWARDS a (117) 2X500 MW P (-4) (36) (-37) -3 DUMKA , 1 RIHAND 2 277 3 m 3 3 9 ) ) k k 4 ( m (-1) 105 km, Panther - 0 7 4 2 8 , 3 Q 1 0 2 6 (- u ( ) 4 1 7 - 3 1 2 ( ) a )

5 - d - 6 ) M k DUMKA - 1 ( 06 r GIRIDIH o m ( km e ose , P , Pan h a th t n 1.00 1.01 4 er 0 ) n th -2 ) (0) 1 a e 3 P r (2 DEOGARH ) 1 , KODERMA - er -33 (18) 4) 3 3 6 ( - 1 anth ( 4 m - m, P 1 10 (- ( 68 k -20 0 (7 k 0.9 0) ) 5 .1 2 k 2 0 m, DEOGHAR 33 (-12) (-6) -16 1 2 -47 Z 8 ) 6 eb 1.01 4 7 8 km ABCIL ) r ) a 6 -1 BARHI 3 ) 1 6 2 (-21) 3 -30 - (-2) ( 6 1 24 - ( (2) - 2X30MW 0.95 4 9 ( Pan ( CGP 1 (-8) ther -2) 2 - 0 r ( (

TOLRA_R (15) ) e 3 8 0 ) MADHUPUR 0 GARHWA h ) (

4 7 t 2 ) - GIRIDHI ( 1 0.97 2 0 1 - 2 1 ) 2 0.95 r m n 1 6 0 6

4 -

0.97 ( - - a 3 - e 0 0 k ( ( ( ) 0.98 4 P 5 ) h k 4 , t 5 m k

TILIYA Lark m n -94 m - 7 a , 2 , 1 k -2 7 PALAMU 2X2 MW T P CHATRA P r 1 e a ( ) w ) nth (-27) n 1 , a )

6 P 0 , 0 2 m ) t

i k 2 h ( 5

- 6 1 n 43. (- m - e ( 1 r -8 ) ( k M ) 1 5 -25 (16 8 22 5 6 5 o 1 . 182 km, Twin Moose ) (-4) (-1) ( o -33 6 ) s 3 7 NIMIAGHAT 0 1 e JAMTARA - 4 (-10) 1 BALIHARI_D 5 ) ( 6 2 4 -47 4 0.95 4 - DALTONGANJ 2 ( 5 0.94 ( 0.95 - -1 k 5 0.94 KONAR (-15) 7) m k HAZARIBAGHHAZARIBAGH8 , P m e 0.96 2 a s -43 RAJBERA_D n r o 43 k th e o -11 0.93 m BAIDA_D e PUTKI h M (-13) 0.97 r t (9 40 , -1 in ) 0.96 6 0.94 ) n (-3) P -30 2 JAMTARA w 1 a T (3) a - ( - P.KANTHA , 3 2 ( P

n 0 1

) (-8) m 4 , 9 ) )

t k 0.94 k

5 2 ) h 7 0 ) r 4

- - (-4) ( -146 (-2 3 m 3 7 ( 4 1

e 0

-9 a k

( ) ( (4

r 2 ) 3 L m ) 8 8 4 k 2 0 - ) 4 (-61) 5 4 CTPS , ( 3 3 0 - ) .9 1 - 4 r 3 5 ) 9 ( 1 k P 2 5 m e 9 1 ( 41 m . 3X140 MW r 1 k h - ( a 1 e 4 t MAITHON_B1 ( 9 GUMIA_R ) - ) , 2 2 L n k th 4 4 ) n 2

NORTH a 3 9 t n (6 2 1 2 a m - 1.02 h - P - ) ECR_R_D ) a r ( ( BTPS GEN k e KARANPUR 5 2 JSPL P ) 1 ) e - - r , - m s

0.96 7 3 k o ( 4 r SINDRI o MAITHON_B2 0.96 1X500 MW ( m ( ( e 6 ) M 0.96 - - 5 4 1 9 k km 22.6 h in (5) 0 t ) (-2) -20 8 0.94 k 10 32 km -10 20 32 km, Lark 0.5 km 20 0 - ) 0 ) 2 n Tw (23 1.01/ 1.00 4 - , m 3 4 1 3 0 4 6 m ) ( 1 ) , - 6 (- 0 (- -47 - Pa 70 k 7 ) 1 ) 5 ) 9 Z 2 BOKARO_D 0 5 3 4 MAITHON RB 3 ) ) e (3) Lark (-4) ( 2 2 5 (-2) 0 - ) 1 PATRATU_D 9 3 0 6 2 ( 4 6 b . 1 9 ) 1 - 0 ) 1.02 1 4 3 ) r 1 - 6 1.03 1 - - 2X525 MW ( 1 a ) ) BOKARO ( ) 2 2 0 21 ( ( ( - k 2 4 ( 0 6 ( - ) 7 8 0 ( 0.96 - - m ( 0 (-24) ( 0 ) 2 1 4 ( 4 3 -90 (-26) 1 2 - 8 , CTPS_OLD ) 513 2 - ( - 1 4 ) 7 3 ) L 5 ( -

0 9 - ( 1 9 PTPS 0 4 IPP a 5 2 1 5 ( ( k (126) 5 2 - - m 2 r 2 6 7 0.98 0.97 1 PATARDIHI , 0 P ) 1 k ( 3 - a 1 9 k ) BTPS B - n 2 2X100 4X50 1X110 (0) th 1 - r ) e ) ) 3 ( 5 r (-1 1 a 2 -

7 - 8 6 - 1 0.99 0.97 - 2 4 L - 4 8 0.94 30 4 1 ) 4 - 1 6 MW MW MW 4 2 9 3 1 1 ) 3 9 , ) - 3 - 5 5 4 - - (0 0 ( 5 ) ( - ( 8 4 -7 - 8 - 1 ( ( ( 6 m 9 60 1 -12 (-3) ( ( k 9 5 m 2 m (- 2 - 9 - ) 7 8 , L 20 ( ) 2 ) a ) - ) LATEHAR 5 k ) k ) rk (

) 0 - 1 1 0 ( - 5 5 BSLG 0 ( 2 3 -39 0.95 4 1 ) 3 r 6 0 . 162 .6 k 9 2 9 k MAITHON_D ) m m 8 0 . ( ( 2 -96 , ) 1 -41 e RANCHI 0 Zeb 6 (- BTPS 0.00 (1 6 -8 5 41.8 k -2 5 1 ra 4 m, 4 5 (31 k Ze r h ( ) 9 8 1 bra 0.97 (-18) ) m 3 e ( (-22) t 5 1 - 3X210 MW Z ) - - (NEW)_PG (-25) 7 163 0 e CTPS_N 0 h ) 4 9 ) (-22 6 t n (-1) ) - ( 0 ) b BSL ( 6 (6 ( n 7 4 ) K'DUBI 5 ( - 4 a 6 r 1 a ) 5 / PTPS RAMGARH_D 0 -2 16 (0) a 0.98 7 3 1 9 1.01 1.01 0 ( . 0 ) P ( 0 6 0.98 P 0 9 -0 , 0.99 / 0.99 )2 BSLT TOWARDS k 6 - )

, 5 k ) m 0.98 0.97 m 5 8 7 0.96 ) - m ) / m (4 (6) k ) k . 6 0 5 7 - 3 k 3 0.00 1 ( ) ) 0 PARULIA , ) 6 m 5 3 r 0 9 ) 4 . )

-

k 4 6 - Z k - 0 4 7 1 2 0 ( ( k a r ( ( 0 m 2 e -1 5 ( 5 1 ( 5 ( a ( 1 0 b - - 1 , 1X23.2 MW ( 1 L 5 - BSLG KALYANASWARI 5 ( ( 5 5 k r ) k L 9 0 L 1 4 7 CHANDWA_JHK_POOL , - . a m a ) ) m ) 7 0.96 e 8 ) 0 0 1 a -0 r 31 2X20 MW - - 1 X 31 MW m . 8 PANCHET 9 s r , k 84 3 9 -85 1 4 Z k km CTPS , - - - e - ( 0 1.00 o b SIKKIDIRI b 2 Z ) -12 e (-0) -0 (0) 7 ( ark o ra .0 2X250 MW e - - 0 , L a m Z - b ( 1 ) 4 k a 0.98 1 6 (-17) 4. (-1) M r ECRBR_D 124 1 1 (2) r 3 LOHARDAGA , 7 ECRGMD r 7 9 0 b TTPS a 5 ( 6 d b m ( - (- -4 0 e 1 0.00 2 (-2) 1 ) 1 9 a e k 2 - 6 1 ) ) Z 1.00 1

k ) ) u Z 6 ) (-1) 0 5 7 ) RAMKANALI , 1 - m 0 8 4 6 7 TVNL ( 8 , ) 1 - 4 ) 1 k ( 1 PANCHET Q 1 1 , 2 - 1 - 7 ( - m 3 0.97 3 5 Q 5 - ( m 8 , ( 4 SHPS GOLA ( 5 3 ) ( 7.6 km, Zebra m 2X210 MW 0 , - ( u 3 ) 2 1 k T ( - 4 - ) 2X38.4 MW

2 a 1 m k w 0.98 -6 DHANBAD 2X65 MW d - (12) i 0.96 2 ) 4 -32 ( k n M 2 -33 M 191 6

o 4 62 (-2) 0.98 0.98 52 km, Zebra 6 4 0 ) o

o . INLAND o r 1 2 )

(-10) s 8 (-9) s e (33) e

LOHARDANGA e 7 ) 1 ( CGP e

1 4 s

- 7 - 1

) 1X70 MW - h ) Kanke 6 ( 3 o TOWARDS

( ( 0. t 5 57 km, Lark DHANBAD o 0.96 9 2 n 8

-2 RANCHI_PG 8 9 . M 0.97 8 (25) 6 6

( 302 2 km SERMURI a n 9 JAMURIA - 119.2 km, Lark 2 i 7

- 3 , L P k 8 1 1.02 / 1.01 - a m w k 4 TOWARDS 8 r r , 3 T ) m 1 126 k ) , 2 , k - (63) 2 Z ) e 8 6 4 , m 4 (3 m ) e (2 m KALAPAHARI 2 9 ( T

8 a h b k m 188 km, Twi k ) 3 , n Moose ( -4 - 5 w ( t 2 1 r k r 3 ) 5 4 - a i T 6 - n ( 5 n w . 2 b 4 1 1 a 2 -36 M i 4 3( (3) e 3 (-2) n

-5 ) 4 ELECTROSTEEL_D o Z P 3 -51 M

1 260 20 o

- 2 , (52) 0 km, T (-4) TOWARDS m ) , w k 31( k in Moose 0.98 ) s o 1 1 m GOVINPUR_D e

2 9 MAL TOWARDS o 7

1 ( m 1 m ) ) s ther DSTPS 0 k , (-3) 3 2

1 n 3 k a 2 2 e P 3 0.97 - - 22 km, Zebra , 5 1 P 1 km 1 IMPEX FERRO BURNPUR r 6 ( 73 ) 7 2 - k 8 a 9 e 2 ( 2 ( m 5 4 2 1 4 2 n 9 h , ) 1 RANCHI 0.97 t 5 Z t 7 169 km, Tw 3 h 8.4 km, Z in Moose ( n 1 e ebra 7 - HATIA_N e 8 96 a ( b ) ) 1 (-9) ) ) r r 5 a 7 5 6 8

P 0 6 ( - 155 3 ) . k ( m - 7 , - , 62 km, Zeb 0.99 /0.97 ( 1 Qua -262( 23) ra d M ( 0 8 oose m 3 4 1 2 k 54 k .9 -89 k 0 e km m -4 27 os , Ze 1 1 27 km, Panther m in Mo bra 7 9 -0 (242) w ( 4 km, T (-8) 2 (- , 2.5 21 (36) 7 54. TOWARDS 3 ) P 0 9 km ) Tamar 5 , Zeb

a 3 ra MEJIA

-105 9) n 1.00 7 )

HATIA_O 40 ( 72 RAGHUNATHPUR t 1 (2 6 -1 1) h ( 1 ) 0.97 (-34) e -13 1.03 e 8 - -93 s GUMLA ( 9 r STPS oo r ) a RTPS M 42 ) 7 (-37) (-0) br n - e 2 5 e i 0.95 0 ( Z k - ) w - 3 1 ( 3 0 , T ) h ( ) 1X600 MW 0 m USHA - 2 1 m , 1 4 (- t ) ( 3 k k m 3 , er - - m 98 k - ( NAMKUM ( -18 7 n h 1 P MARTIN 3 nt ) , 153 r a a a P ( he n , P 0.95 a ADHUNIK IPP (-5) -2) t P t m n CHANDIL an h 0.95 k t 0 , 5 h 4 , P e ( e 2X270 MW r 0 30 r 1.01 1.00 ) m m 5 ose k 0 ) (-0 - (-1 Mo 62 61 k 9 ) 13 Adhunik TPP JAMSHEDPUR_PG ) win k 6 T ) ( 2 , m km 15 Panther ( 5 km , 5 ( 53 2 1.02 1.01 TOWARDS 40 P 0 4 km ) 1.02 1

1 a -7 1 ( ) 2 n ) - 4 ) th (5 1 0.3 km

) 3 e 5 DHARMAJAYAGARH 7 1 (53) 168 km, Twin Moose r CGP 1 488 155 (

) 1 1 3 MANIQUI Quad Moose ( HEC ( 0 74 BANO_R 35 km, Panther ) TATISILOI_R 1 km 0 LODHNA_R 4 USHA MARTIN 0.94

-56 ( 9 177 km, Twin Moose

- 1

r 0.97 MANIQUI_D 0) (-1) 7 (46) 78 (38) - ( ) the KAMDARA ( (-4) 486 ) 0.00 (0) an 0.97 2X10 MW 0.95 MANIQUI_R 0.94 km - 7 3 ) P ) 0.5 7 2 5 , 4 ) 8 TOWARDS 0.95 ) ) k m 4 9 m - 2 0 ) k 1 2 - ( ( 3 653 (64) 3 ) 8 , 6 0 1 1 ) 3 Z ) 1 0.94 1 - - 2 1 - 5 e 6 3 - (- 1 3 BAKASPUR_R 1 ( b ( - SIPAT 2 - 1 0 - ( 5 r 0 1 ) 8 ( 5 a - 3 1 ( - - - ) - (1) 4 - 5 156 km, Twin Moose (1 ) 4 km - 4 -16 ( 2 ( - a 0 1 - )

( 4 3 ) APL r 0.1 km 2 1 6 1 3 0.95 2 - -

2 - b k - 6

( 8 ( 2 k ) ( 1 (-13) e m m 2 ) 1.01 1 8 3 6 - ( 6 3 ) 74 ) Z 1 (1 , , 2 1 1 , ( - ) 3

- P P 3 - ( m ( 5 - m a 14 -1 k RAJKHARSAWAN_R a 5 ) ( 4 SARAIKELA k n RAMCHANDRAPUR n t 2 0.99 5 h - . t e ) ) 1.01 1.01 h 4 1 -8 r (3 8 1 LEGEND 43 e ( 3 r 1

6 km 8.3 (-3) 5 .74 -6 -

1 km km 29 ) , 1 9 8 Pa ) , ( - ADITYAPUR GOIELKERA 3) n P 1 USHA MARTIN th 0 a ( ( e - GENERATION ) ) n -1 r 0 0 ( t ) - 1.00 0.97 - 8 h 1 1 ( e 9 3X300 MW 3 - r - ( 7 (-6 4 -31 (-2) ) 9 1X25 MW

) 55 km, Panther 31 (3) 1 CGP - 19 -19 (-8) 6 ) 1 r -4 9 HYDRO anther 3 9 - 0 1X15 MW e , P 4 ( km 8 . (6 e 36 5 ) ) - 0 h (-5) (10) er 1 k ( s t h m nt ( CGP n , Pa , o km P 22 r an 0 o Pa (-1) e RAJKHARSAWAN t (0) USHA ) h h , -8 8 t ) e 0 2 n M THERMAL 4 a 2 e r CGP

- P - 0.99 MARTIN m 1 ( s e ( (-7) ,

- 5 n 5 (0) k m 3 o s TOWARDS i k ( 2 3 o 4) 1.00 0 2 - o 4 km, Panther -0 w 1 CHARADHARPUR M PARULIA o T n 2 0.99 i 2 , GOIELKERA_R SIMDEGA M GOLMURI 0 (0) (-0) THERMAL-CGP 9 w EAST k r T m CGP m 0.97 e , n

i ) , k -9 h 1.00 P SALGAJHARI_R 4 m ) t CHAIBASA 1 -12 (3 k w 4 a rk 5 n a ) 1 n L TOWARDS T 3 2 6 a 1.01 1.01 6 - t , - 1 0.00 4 m ( (-3) 4 ( h P , (- e 7 k 1 MANOHAR WEST (-4) , TISCO 0 r JADUGUDA 8 KTPS THERMAL-IPP SINGHBHUMm ) CHAKRADHARPUR_R m -9 -21 IPP 0.97 k k 1.02 1.01 0.99 0.99 0 9 (-7) ) 2 (-3) 3

6 KENDPOSI 343 (16)

4 - m TOWARDS

- ( SUB STATION SINGHBHUM 0.98 k

rk KHARAGPUR -28 1 -2 , La 30 8( .5 km 3 3 5

2 k ) ) 9 4

(-9) 6 m ) 22 -195 5

) 8 2 MOSABANI ) (9) ( 2

1 , 8 1

P - ( 2 ) 3 765 kV -

) a 9 ( 5) - - (

3 - n 5 (3 0.93 -5

t ( 8 2

( 2

9 6 h 0) 0 )

(

e ) - ( r 3 2 -71 (-4) (5) DALBHUMGARH_R

( 0 1 70 - - 7 8 2 2 JAMSED_D 2 6 -5 - (11) 1 4 4 ( 8 ) 0 - ) -6 3 0.93

( k 4 ) 0.97 0.95 39.6 km, Lark (- 0 ) m 57 CGP 7 ) - 8 1 400 kV 0 ( ) 2 0 CGP ) 0 ( ( , (-2) 1 IPP 7 )

)

- 0 1 . P - 7

( 7

(0) 2 ) 6 6 r 2 2

a - 5 -

-

JOJOBERA -

CHAIBASA 5 ( m e n RUNGTA 4 k ( k t 2 h ( 3 m t h 0.98 3X120 MW 1X67.5 MW 6 e 2X20 MW n ( 220 kV 2 r CHAIBASA 8 a (45) )

P 30 1.02 1.01 e s

0 ) DALBHUMGARH ) o

0 2 7 132 kV

NOA ( KEND FD STN o 0.93 2 3

0 -

-

e M

(

0.98

s

MUNDI 4 km, Panther (0) n

) i o

0

w

) o

- 0.00 T TRANSMISSION LINE 0 (

6

2

-

- M

- ,

(

n m

i

k

w

6 765 kV

T

1

r 1

e ,

h t m

n 400 kV

k

a P 1 , m 4

1 220 kV k ra 2 Zeb e 4 km, oos 130 in M 132 kV TOWARDS , Tw ROURKELA km 131 TOWARDS LOAD JODA TOWARDS TOWARDS TOWARDS BARIPADA JODA JSPL Load Eastern Regional Power Committee Power Research and Development Consultants Pvt. Ltd. #5, 11th Cross, 2nd Stage, 14, Golf Club Road, Tollygunge, West of Chord Road, Jharkhand state existing network (May-17) geographical map Bangalore- 560086, INDIA Kolkata, West Bengal 700033 Ph : +91-080-4245 5555 R0 12/9/2017 E-mail : [email protected]

APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REVISION DATE REMARKS TM LOA details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 DRAWN IN : MiP-PSCT DWG. NO. : Geographical Power Map\ER\May-2017\Jharkhand Geographical Diagram of Existing Sikkim Network (MAY-17)

North Sikkim

MEYONG HEP 2 X 2 MW PHODONG 0.97 0 0.97 (0) -0 ) -1 ( (-0 -0 1 MANGAN -3 (-0) ) 2 D k 0.97 og 4 TEESTA-3 o m m D ) Dikchu g 20 k (1 6X200 MW TEESTA-V 0 3 ( g PELLING 0.00 3X170 MW 0) o 1.00 (1) D SICHEY 1.01 -2 m (-1) 1.00 k 0.98 2 18 -9 (-2) -3 (-1) ( 2 1) 5 km 4 5 D k TADONG -4 4 m -4 D km o 1) BULBULEY g 0.98 - Dog (1) (1) og GEYZING 528 (93) ( (-1)

(0) 0.98 -2 1.01 1.01 -5 ( - -1 714 -5 8 1 -5 ) (-1) k 3 15.5 km Panther 25 m g (- o 10 (3) (-1) 3 RABANGLA 2 ( D 8 - - ) 3 71 ) m (1) 1.01 2 1 k 2 -10 10 LLHP -1 1 RANGEET-III -2 (3 .3 RANIPOOL 9) 4 2 ) 0 7 GANGTOK-PG -3) 2 X 6 MW (-0) (1 ( (-1) k k ( 0.99 -0 3X20 MW m m 0.7 -3 ) 2 T T km 1) 0.99 ) w w 1.01 0.99 Dog (- 0 GEYZING 1.02 (1 in i 1 -0 km n 2( 5 (0) 1.01 1.01 3 M M ) 14 (3) o - 1 o 8 o o (-0) se s 26 e (

-

) 15 km Dog (6 2

7 r ) (

7 e ) 5 2 - h 4 68 km Panther -39 (10) ) m t 9 0 k n k (- 6 a m 2 P Pa -63 (15) 34 (-16) 54 km Panther -34 nth 2 ( (-0) e 27 km Panther - 1 r 9 - ) 1 ) ) (17) 3 4 - RANGPO-PG (1 ( 0 TOPAKHANI 1 .3 -3 3 2 k 524 (39) 1.00/ 1.00 1.01 km PAKYONG m SAGBARI 0.99 D CHUZACHEN -1 o 25 ( 4 21 g 0.99 k 9 1.02 46 (4 8 2 X 55 MW

IPP m ) -3 (-1) (-1) ) k -2

) 23 -1 m (2 6

1 (

5 D ) P ) - 3 1 5

5 5 ( o 1 9 an -5 ) 1.02 g bra (- (1 9 t 1 5 km Ze 5 he JORTHANG 7 2 1 2 r (- 3 ) (-1) 72 -23 (4) 8) 2X48 MW - ebra 7 -3 (-4) (13) 1 Z (-1) -46 7 (- 6 km 8 ) IPP 1.00 17) 2 - 8 10 km (1 -15 (-15) KURSEONG 3 -3 (-1) NAMCHI OLD MAMRING -1 -31 (22) 2 1 km 1.00 (-0) P 22 km 1.00 East Dog Sikkim a n -2 km 21 (0) th 5 (1) Dog -7 SORENG e ) 11 NEW MELLI-PG r (-0 er (-2) RONGLI 0.99 km th 7 LEGEND g an ( Do 1.00 Do P 2) 0.98 g m NAMCHI m k - k 9 0 17 -1 3 -1 (1 1.01 RONGLI-HEP 2 ) (-0) (1) PARTICULARS SYMBOL (-0) 1 22 km e 5 2 X 3.125 MW -1 0) s k (0) -2 o 0 m ROTHAK (-0) Dog ( o -2 1) (0) 0.98 M - (-0) ( - n 0 1.00 1 7 - g i -1 (-0) 7 8 5 o -1 MELLI w 400 kV SS ( D T (0) 10 ) ( m RHENOK 0 ( k 1 ) - 1.01 m 2 1 8 k k ) 1 m 0 D 0.98 -22 ) 1 o 2 (-2 1 g MELLI - ( -7 (1) -2 4 -3) 220 kV SS RAMMAM 1.01 1.01 7 (-1) (1 -2 4 West Sikkim ) (-1)

-7 ) (-0 132 kV SS

e South Sikkim s o o M r 66 kV SS e n h i t w n T a P m k

m 8 k 4 0 1 9 400 kV Line

g o D m 220 kV Line k 15 TOWARDS 132 kV Line NJP

TOWARDS TOWARDS 66 kV Line KALIMPONG TOWARDS BINAGURI Kishanganj Load Hydro Generation IPP Hydro Generation IPP

Power Research and Development Consultants Pvt. Ltd. Eastern Regional Power Committee Sikkim state existing network 14, Golf Club Road, Tollygunge, #5, 11th Cross, 2nd Stage, (May-17) geographical map. Kolkata, West Bengal 700033 West of Chord Road, Bangalore- 560086, INDIA Ph : +91-080-4245 5555 E-mail : [email protected] R0 15/09/2016

TM APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REV. DATE REMARKS PO details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 DRAWN IN : MiP-PSCT DWG. NO. : Geographical Power Map\ ER\May-2017\Sikkim

West Bengal state existing network (May-17) geographical map

)

2

5 1 m ( 6) 27 k 9

1 9 1.01 (-

62 e 1 1

s -

- o 3 o 8

- m 3 (

7 n

6 i 12 ) ( w 9 Lebong ) T 4X12.75 MW (1 ) 2 0 ) 1.00 m m k (-6 r TLD 3 k

k m 38 e

1.02 5

0 h t 4 1 )

) n 4 1 Tala ) 2 132 (6

Kurseong (7 1 a 6 1

6 - 7

2 -

p - ( m 4X33 MW 1

- (9) Malbase -

TLD3 k 1 ) e 0

m 3 s 3 5 ( 1

k oo TLD4 5 ) 6 5 0 M -9

Melli ( 0

5

3 9 6 n ( i

. Ramam III Rangpo ) w 8 Labong 5 T

)

k m k

7 k m m 8 0 5

- 3 1

(

- 3X9 MW 1

DARJEELING 2X40 MW Z

) a

TLDP 4 9 0 e ( r 8

0 7 b Kerseong b

0 1.03 2 r

0 k e 8 a 1.01 . 2X4 MW m 8

38 (-9) -8 Z

k Siliguri Tala

2) P ( m m

1 - )

8 a 1 Malbase

1.00 (-2) k 6 )

0 n -3 Chalsa

Z - 0

-31 (11) ( 0

2 1 e

Ujanoo ( t

7 e s 4

- 7 o h

k - 4 o 7 (-3) ( 1.00 b 2 ( M )

e m 5 n 1.00 2 1 i 6 r r w

r a k T 3 a

) 9 )

66km 4 m r e m

( ) Banarhat 5 m k )

7 k T k

- ) h 1

50 50 km 8 b

( 4 2

w m t 6

2 1

7 a e

0 ( e s Z 9 n o r

4 ) o ) 69km 69km panther i

1 a - Z M

e 1 5 n ) - b

n 2 - P i 6

( 25

b w 2 - e 3 ( T

5 (-10) 2

M 31

4

- r m m m 5 r - 1 Z m k ( ( )

k 1 a

8 8

e

k 6 o 9 r ( k

7 -

2 Birpara(PG)

8 ( 2 1

o k h

r 5 5 - m - 8 - e

7 t

) ( e m ) 1 7 7 4

k s ) 5 h )

h e n 1.01

( t t

1 34 (6) 5 8 e

7 8 n P s a . JALPAIGURI - 2 n ) 1.01 3 a o ( - a

a 0 9 P

P n o ( P 8 e -6 (14) m - th

M 2 m k 3 s (9) (6) ALIPURDUAR e 7 2 7 34

) m 0 5 k NBU -1 r in o (37) 18km Panther - bra

4 0 9 9 -152 Ze k o 3 ( e 141

m (-2) ) k

- ( w 0 km 0.8 ) 1 8 1.00 (- 3 6 3 s 4 0 - 1 6 T M 8 5 ) ( . 0 o -16 (-6) 1 - . k ) 2 -16 5k 1 ) m ( m 1 n Z 8 ) i o e - 4 P m b 3 9 -864 r ra ( 1 a NJP (168 k - n 6 k M ) e (-5) 1 ( th 2 w h Birpara Alipurduar m t ) 6 e ( 3 5 - 1 1 T - r 1 n n

1.01 9 4 3 i a 1.01 4 3 2 - ) - 1.02 - P 4 - ( 4 ( 3 5 - 8 9) - 1.00 1 m w m 0 8 4 3 5 (- 2 k T k -35 -5 ( k (5) 1.02 ) ) 2 87( 14 1 83 (183) 3 1 ( 1 m (9 (9 5 9) 4 (1 4 7 7 -58 ) ) 3 ) SiliguriPG ) m 2 P

- ) 1 1 0 Panther ) k - 1 114km a

10 km -9 1 0 ( 6 TwinM n -35 -4 ( ) -4 r Binaguri oose t (5)

8 h 1.01 ) 2 4 5 e (-18)

1 ) e -42 (-44) 9 h

7 1 - 1 ( -0 3 r 3 t ( ( 8 2 1) ( 8

1.00 3 6 6 ( 1 0 (0) 1. Chalsa n ) 5 0 4

1 k

( 9 1 ) ( 161 -4 m (30) k a - 3 1 Z 1 5 (-18) e 4

( m - ( ) 21 br

- P 7km a 2 - ) T 1 er TCF I 4 winMoo 67 (-44)

5 8 Z m th 1 Moinaguri se -42 (234) Salakatti e n m k

1 ) b k a m 21 P k 7km

- r 6 m k Twin M 114k ) k 6 3X7.5 MW P (8) er oos m T a )

8 a 1.00 16 50km Panth m e winMoo 4 4 7 er Moinguri 1 n se -161 (30) 3 0 ) th 1.00 (-48) 9 -93 Pan e th 3 -17 1 1 ) ( km s e P 7 -1 - - 0 7 41 r ( 220 km ( ( ( 5 o 3 a - Qua 6 4 2 nt 1 d Moos 9 3 o 4 ) 0 (0) 6 e 8 bra 0 4 (-13 ) 0

80km Ze M k ( 4 r he (-7) Bongigaon(NER)

(1 1 Birpara(PGCIL) r 0 1

m ) 3X7.5 MW e Alipurduar 9 1 e 3

d ) r 0

) ) ) h

4 4 h (0) 1 a 6 3 ( t

- 8

( -7 P t r

- 1.01

- ) 5 u n e

8 9 a ( n 6 e a

(1 Q h

a n P s t

64 o t

8 114km Twin Moose m P n - 83 (183) h m

a o

Alipurduar k k a

r e M 0 3 )

) r m P b 8 9 2 9 14 6 4

( n k e i - 87 1 0 TCF III ( ( m Z -5 (0) -

Bongigaon(NER) w 8 6 k e Binaguri 0 (0) 217km Twin Moose T 1.00 . ) 9 9

m s 3 o m 1 1 k (-0) 0 8 o 1.01 k -0 )

e r -59 8 0 M 8 ( 3X7.5 MW )

s e ( 0) 0

1.01 6 1

d o h 1

1 a o t 1

0 ( n (-19)

u M Coochbehar

1 Q a

n 0

i 3 P 1.01 )

m 6 w

k T ( m 1 a 0

- 8 k r ) ( 6 m b

0 1 8

k e 5 1 8 Z 1 6 Mathabanga 1 m k 0.96 9 1 )

TCF I 1 0 Kishanganj 1 1

3 - Purnea - (

r e th n a P ) 9 m 7 k (- 5 1 9 6 ) 8 7 7 (- 2 8 Kishanganj 5 26 km Panther

1

(

UTTAR8 DINAJPUR - )

2 9 0 (0 1 (

) 0 ) 0

41km Zebra -56 (3) -125 (-2)

Purnia )

) 1.01

0

5

Dalkola (

4 1 km 125 (3) 1.01

1

8

( (PGCIL) Zebra 7 9

2 ) - ) 5 -

8

1.01 0 9 -

(

2

(

r

e

h 9

t -

n

a

P

m

k

1 5

)

5

-

( -53

6

9

a (-17) r

b -

e Raiganj 40 Z (

0.99 -1)

)

m

0

k (

6 -2

1 (2 1

0

e ) 7 s 5

k

o m

o P

M a

nt n h

i er

w

T

m

k

3

7 7 9( 6 5 1

k ) 1 m Kahalgaon P a Khlgaon split 3 68km Panther n th e r Gangarampur -40 7 ( 9 1 1 0.96 1 (-19) 4 ( (- 35 1 ) 2 k 0 ) m 2 p ) an the Samsi r Balurghat -1 2 (4

e 0.94 0 (0) ) 0.96

s (1

o -67 ) -28 -26 o 28 )

M -1 n (-22) 6 ( (-1) 98.4 km panther (4) (-6)

i 8 w 6

2 Balurghat_Tap T ( 6

)

m 0.99

k

e

5

s 9

o

o 5

M 5

n k

i m

w

T P r

a e

m n

) h

k t t

3 h n

5 a 1 e

9 ( r P m k 0 -7 1

Malda 9 0 ( PG - -1 (1) 23 0 -95 (-9) 6 ) 6 1.02 7k 2 MALDA m - 1.01 ) P 3X200 MW 4 (-2 ant -95 0.99 0.99 (5 9) her 4 (-42) 2 ) 3 1 3X500 MW e (1 s r o e 3 LALMATIYA ) o th -4

6 n

M a 8

( in P

- 6 3 ) w m

5 T k 7 9 5 ( 5 5 9 m 3 7 - 1 9 4 9 ( k k ) 0 m 4 - ) Z 7 ) -8 e 9 2 ( Khejuria b 1 3 r (7 - 4 a ) ( 0.99 4 2 -7 3 -29 (4) - (-2) m

k 6 -282 (8) . 2

Farakka nmooseTwi 67km 6 )

) 3 1.02 2 (-19) - 1 ( FKK-s 0.99

3

1.02 -

(

)

-347 (-9) -26 Ambuja

3

-78 0

-

5 1 (

(5) - 0.98

6 m

3 m

- k

k 6

-10 2 km Dhulian 2 1.5

-26 (-3)

r

0.98 r Ambuja Tap e e

0

h h

t

t 0.98

( n n

(-2) 0 a a

)

P P

m m

k k

2 8 2

3 Raghunath

gunj (20)

) 0

0 0.93 ( 2X300 MW e (0) s 24 281 o 0 (8 o ) 27

M k -67 4 m 2 Lalgola Bangladesh n 4 ( 9 ) i (-22) 1 5 4 2) 1 w (1 0.94 Bheramra

T Sagardighi -58 (51) m -30 (-16)

-497 )

k

1.02 5

) ( 0 94.6 km TwinMoose

6 -381 5 1.00 0 6 1 (-80)

1 0

- ) (

1

1

-

- 1 e -10 (-4) ( (-51) 9 s r 1 r o - e e h o t

7 h 20 (5) t n e M 3

a k n s n

m P a o SonarLal i

P o T w m 0.95 w T

k m m

i 8

. n a n k i

r m r m 6

2 e

4 k w b o h

4 t

o T e 1

s n

Z e a 7

m P

k m

3 m 6

k 6 ) k 2

4 0 6 7 4 ( 4 - 6 9 Rampurhat 1 ( ) 2 7 4 7 ( -

0.92 ) ) 1 ( ) 0 6 2 ) 0

3km 0 8 3

51 (6) Pa 1 3 47.2km Panther 7 - 4

nth - 6 ) - e ( ( Behrampur ) r ( 2 -

0 5 ) - 0 3

( 8 (- 9 4 0 1.02

- - -2 1 3 5 7 ( - 2 -1 -362(-6)

- 7 -4 Gokarna 2 8 2 (-7 345

3 k 4 1.01 )

m ) (-1) 146 - (34) 0.99 1 -9

e P a 99 Behrampur 2 ( Kalyaneshwari a 4

s 0.96 br ( ) ) o n - 0.94 9 4

e (-15) ) 2

o t Z ) - 1 7 h 2 ( - 1 6

3 4 5

m ) 1 ) 6 .3 n e m 1 2

i 1 - 6 (

k - 3 9 ) - k - ( r ( 1 w ( m 5 )13km T 8 ( 1 9 7 - 9 7 4 5 2 5 r 2 4 - ) m - e 1 9 Sainthia 2 0 8 -

h k - ( k - t 5 m ( ) ) P 2 1 ) Kuli n ( an t 5 11 (13) Kalyaneshwari 7 0.93 5 a he ) 47 (8) 1 (-1 ) P r - 3 ( 35 0.94 1 m 0 -5 .6k ( k - Amtala

m 7 9

m 5X210 MW 2 ( 0 Nazirpur

4 4) 5 2 8

r

k e 39.7 km LARK Maithan

e (-2) 0.92

)

Kalipahari s 2 4

- h 0.92

8 2

8 4 o 2 ( - t ) 8 3) 5 -30 1 30

5 o Cossim Bazar n 1

- 3 (

- 0.96 5 - ( 0

2 a

9 M ) 9 7 5 ( 4

) p TSS 0

1 n r ) ( i (-1) (-3) 3 k (2) Burnpur 71 m e

7 m

3 )

k w h Waria ) - m 0 ) 9 m - 0.94 t

8 ( 0

e 9 T ) k k

2 Z 3 9 8 1 (-10) 9 - n s IICSO 0.99 6 ( - - 6 0 Sadaipur - 2 33 km Panther . 7 e

a ( Jamuria Bakreswar - 1 1 o b 4 5

1 ) (DVC) m P (

0.99 ( r o 5 4 k 7 5 ) 0.99 a

-1 - - ) 0 -111 0.95 3 0.99 0.99 6 m ( Mejia M - 7 - k

( 2 4 k (134) -2 - 4 m

JK Nagar n 3 5 ) ( 2 (-4) i 8 . (-1) 1 7 6 CTPS-B1 8 6 p 0 0.98 7 4 ( 6 58.23 km 96 w a 4 Panchet 70.7k 77 -4 (- T m Tw inmoo (26) ( 2 n se 4 ) -71 3 t (-5) a h

6 Katwa r

m )

CTPS-B1 119.2 km LARK )

2X600 MW e ) e

5 4 k

) s b 2 4 2

- - r

(-5) - ( 2.4km o -112 TSS e 0 3

(

9 (-5) 3 1

o 4 0 (12) K 4

Z 1 36 e Parulia .

5 7 7 - - ) ) M k

s 5 6 3 - )

R k

( 0.93

)

- 4 n o m 0

6 7 m m 0

2X20 MW i (

(DVC) 0 A

( o Z 8

a Debagram TSS

a 2

e - k

0 w 8 ( ) -

r Ukhra b

r Asansol L ( T

37 -37 M r - T 5 (

5 a ( 0

2 5 b 1.00

b n 0 0 w

37 CTPS-A1 Raghunathpur ( 4 - 0.93 i 8

20 km -357 3 7 4 0 ) e

ZZCP0 3 0.97 0

e (-6) Asansol

m m ) i

0.98 -

4X120 MW 1 w ) ) n

Z Z k -

- k Bolpur -3

) T 1 0

5 7 M

( - (20) k 2 2 )

0.97 1 (DVC) -31 m ( -0 9 2 (

5 . m o

m 2 m ( ) 5 3

. -

) Crescent 2X250 MW - (1 k -58 (-1) ( k

4 4 0.94 5km o

k 6 m 3

k )

4 4 9

4

( 1.03 (-9)

1 0 Tamla P m s 1 5 ) 1 0.97 -20 8 - -70 k 9 9 -20 a 6 Debagram e 6 1 8

) 5 n

4 (143) )

- 4 1.00 (-35) - 5 t 8 8 (90)

- h 4 . . - 4 4 (

( e ) 270 (36) -271 (42) 0.4 2 r ( (-7) (0) 0 (0) 0 9 0 (2) (2) ) 9 2 ( 0 5 ) k - 7 m (-4) 0.93 0 65 k 8 0 4 Parulia -2 Katwa 8 ( 2 2 9

7 ( 2X500 MW 3 58 6 m 0 2 7 ) 297 1 r (8

2 4 6 9 4 1.02 e 2 70.5km Twin Moose 3 0.93 ( )

( - ) 5 - 1

23 ) th Bolpur TS 2( m n

8 1 ) 1.00

6 9 ( 2 a

2 k 0 (6 4

- - ZZCP0 79 - - (4)

114 km Zebra ) P )

( 0.94 6 62 km Zebra Bidhannagar 60 km LARK 0 (0) 3 1 2 k

DSTPS 1 5 1 km

2 1X140 MW ( m . 1

1 9 ( 1 km 7 (-15) 89.89 km Zebra 8 1.03 5 85 1 P

-61 1X210 MW ) 4 -2 5 a 1 3 k ) m ) n STPS (55) -659 ) 7 ) -37 (-2) 0 8 t - 2 1 ( h 13 73km 6 3 (0 ) -13 (1) 6 (-4) 3 e 8 ( 2 STPS - 2 4 r ) 4 ( - 62 km Zebra Ramkanali ) 4(-5 -8 -9 (1 5 k

1 (2) 16 -11 (6 8 6 5 5 ) - 2 m

-1 0 ) -36 6 ( 1 ) (8 -

e 0.99 9 3 1 ) ) 1 - k

3 s ) -

oo 7 k

( 0.97 m 0 Z

M ) 6 9

d 1 ( Bidhannagar m 1 5

a 0.99 2 0) u ( 1 ( e 3 1 - a 7 Q -23 ) k 1

1 r m

m 2 k ) Raghunathpur ( ASP b 0 Z 1.01 b

4 - e

5 - (-14) e b 5 ( ) 5 ra 6

1 - ( Z r P

2 - (

se 1 7 1 0 m -1 3 a 7 o 1 ( k

o ) ) (-5) m ( ) 0 0

0.97 a

in M 5 0.99 - 9 2k 5 1 0( 0.98 k 5 1 9

Tw 7 - 4 0 9 5 n m ) 5 - 1 ) m

9 k 2 - 0 (0) 6 ( -7 1 ( ( 4X210MW Waria DVC ) km 0.98 t r - 10 h

) 0 1 9 Mankar T r 4 2 1 e 3 ) 8 DPL - e

1 2X250MW 0.99 0 ( ) w e ) 3 - 2 ( 1

4 h A -

5 - 5 8 0

r 4

(-1 1 ) 1 0.97

t 4 3 k

- ( 0 i - h

5 0.98 0.95 21 m ) 0

a n

0.98 2 Dhatri T 6 1

t 0.95

n 9 (

r 8 5 -29 1 P m 1 Krishnagar

a 2 Sagardighi

r .

a n 0 ( 6 ( b 1

7 ( n -

) 4 ) )

t 8 2 1 - e B 9 o 0.95 a h e ) P 1 -

2 Bmn (-9) e ( 5

2 1

k - 0 ) 5 r o h IPP

Z 7 9 P ( 0.95 8 0.96 ( 8 0.95 ) ) t m 0.95 AB -

3

5 2 2 s -4 0 m 6 (

) Bakreswar

n 1 0.95 ( m 9 ) 1X110 MW 1X300 MW 2 e

m 4 0.95 5 k - 9 r

a 8 0.94

k Behrampur

5 5 4 4 Satgachia ( 0 8 k

- (-0) k . e (

1

1X250 MW 3X75 MW (-6)

P 5 ( 2

-20 0

3 -22 -

m -

1 . ) -23 (-4) Mahachanda

1 1 Muchipara 4 6 h Khanyan ( 6 )

3 ) 4 3 ) 2 1 ) (-14) t -67 2 ( 6 5 6 k . (-11) Z -48 -2

2 2 -155 (-21) m 8 - 1

(-0) 4 m 7 1 e 5 4 P n 2 ( -44 3 ) 0.97 1 ( 134 k 8 b (Durgapur) a 2 - k ( n r 6 - t a k 3 2 h 0 0 Purulia 1 a m e ( 6 3 ( r 3 m 2 9 0 2 P 3 (37) ) -134 (15) 31.5km

(-14) ) 8 (-9) ) (

4 ) 5 1 e - Barjora DVC 0.99 6 0.98 2 5 L ) 8 (

. )

3 6

8

1

s 0 0 m a ) 1 A 1 r

- 3 9 7 -

5 1 1 1.00 b

2 4 (

( ) Mejia o k e Ranchi - 7 ) k ( - 133 m Z 5 ( 9 0 (0) R

) 8 0 3 0

1 P -4 (4) 6 8 o m (- r 3 ) a - 4 k (0) 0.99 e - 0 ) ) h - n ) 2 0 t t 8 3

( 4 2 K h - - 5 1.03 n ( ( 5 BTPS

5 a 1 e ( (

0 - r - - (14) P M 1 - 1

6 0 m - 7 1 5 52 k 8 3 ) 7 ( -2 4

1 - 2 Kalna 3 0.96 -17 ( 1.00 8 n )

Bagmundi 15.9 km Panther (1 i 109 (1) 0 55 -56 (-15) 22km 1 (2) -20 (-6) (0) . 5 k ) 69km Panther 0 -3 18.75km 4 m 5

2X500MW 0

Hura ) 4 6 4 w 0.95 3

- ( 2

- Barjora ( e

) (-3) e 6 4 k )

s T k 1 0.98 o 5 2 s

-

) o ( 2

(-2) m 4 2 M -

n . 1 2 0.99 ) Sonic TD m ) 0 1 i

w 3 ) o

( -42 (-3) (

- T 5

-

0.97 Burdwan - 8

m - ( 6 -

Purulia DVC k 1 o

m 3

( 2 1 - P ) 3

2 5 k 3 )

. ) 0 7

83 Satgachia 2 (-

0.99 1 Bankura 2 - p 1 ) 1 38 1 k a M

20 (1) 2 0.99 0 3 0 5 2 )

6

m ( - )

0.96 0.94 26

) k - a 2 m ( 7 ( n n

PURULIYA PPSP ( P 5

4 2 1 an -48 t i 0 h ( 3 4 e 0.96 1 t r KLY

1 - n 4

0.97 k 6 0 4 h - (

-

-4 (-4) 9 P w

3 7 2 ( 7 1 ) (

5 m ) t e

4 -

7 T

1.02 ( - - 0.95 h 3

20 (1) 4) 5 a

1 0.94 ) r ( ( 4 (12) r

(48) 8 -

-5 (-16) ) e

1 n e

T m

3 k h

4 r 7 t 26km 26km Panther

1 t m k w ) . n

8 h 2 1 7 0

129 -22 (2) k - a 8

e i k P

m 36.2 km Panther Z 0 4X60MW Dharam 0

n

)

4

e 7 ) Z 2 r m

M 0 m

e 8 1 - b 0

2 - 1

( b ( k New Bishnupur (

(-64) 1X210 MW 3 r 2 r

-253 (48) 5 - - pur Bongaon

a 0 1 o a 6

3 - P 6 7 - 5 -

4 0 ) 8 ( 1 4 o 3 - ( ) k a

3 K 0.98 7 m m 7 ( s 0.97 1 ) n )

( 1 4 Z 6 R k - e Adisapthagram ( e t b 7 1 8 ) 0.98 r 0.94 h ( A e 07( 5 Ranaghat -3 0 a a s -5) ) 5 6 1 -9 -80 5 e r L o 1 0 (-20)

b 7 e o k r 0.95 21 . 0.93 ) 4X225 MW Z M 0k -46 (19) Raina 5 m m n m 3 (-1) ( (-14) m i Tw 64 k 3 9 0 -15 1

k 6

k w in (3) m 2 M ) 3 r

5 o -80 P ( ( k 7 T

o ) m e 0 - r

se 0.93 (-25)

- a Khanyan 7 h

1 8 1 1 T

m 6 e (-9) t

w a

) P r

e n 7 1 2 2 0

k r

s (-26) - in n

- e h 4

8 7 a

) ( m b 4 a 0.96 o ) t

t

6 - ( h o h e - ) 1

o -62 7 P

8 6 4 n o (

5 t 1 ) - s Z - n

2 - 4 e 2

M 7 9 t e ( n Bongaon m

( 1

3 h ) a - 3 )

n r 1 k

k r 2 m

i ) - ( a

4 ) m ( 8 4

e 2 1 ) k

w P 3

P ) e

(-20) 1

0.93 ) 36km Panther k 5

T r r 8 4 .

5.5km, 3km 5.5km, 1 2

3 1

1 0

r Z (63)

4 h m ) ( e 2 -

-

) h 2 e 3

e 8 t

t 1 Belmuri

m 1

2 8 ( m 3

( n 3 - m k a 6 2 -

b -

Bishnupur Old 5 (

P k h

7 1 n

-

( 2 ) 1 t r k 1 m ( 8 r 9

5k a 0.95 - 6 ( (

6 . a -

5 0 n 1 6 e 1 2 1

1 6 357

Khatra 0.97 h 2 a 2 3 8 4 r )

t - 7 e P 6 1 - ( ) 2 6 th 2 (-1 4 n 8 ) an P ( 63 -57 3 a m P -1) - 0.97 0 - 4 k m m Jeerat

0 ( P 2k m 4 2 Chandil 2 - (2 .2 3 k k

(-15) 46 2 -8 m ) ) 9) 35 0.99

5 8 -1

) 2 k 3 5 64 1 7 (0) ( (50) 2 (- 2 2 270 5 5

0 1 ( - Belmuri Belmuri k Ashoknagar 2 3 - - ( m

- ) 6 0.97 ( ) (-19) p 252 2 DVC DVC ant se (1 -18(-6) 5 0.95 her o 4 7 (5) Mo 0 6) 0.93 161 22 in 8 -157(-7) 73km Zebra ) -48 -0 ) ) 2 w k 3 T 111.5km TwinMoose - 5 ) 7 (- - 2 4 8 m 9 m 6 ( 0 .6 ) k (0) 1 2

(15) ( 4 ( 7 CK Road_R 331 (8 6 6 (1 - (-0) OCL ( 6) 7 3 BANKURA ) 1 -1 - 9 ) ( P k - 7 8 2 1 1 3 6 - 8 4 m 0 a 0 ) 1 1 0.94 2 0 7 7 ( 1 r - 0 7 p ( (-0) n - - ) a Arambag r ( 34 9 ( ra e 1 6

t 4 ) - 2 - n Jamshedpur e 4 k b e ) h -2 m (- 5 -157 (-7) e h t 6 9 m ) 1 1.00 h 4 P ) - -30 z s t h 1 ( ) OCL e a t ) k o e 1 nt km n 2 2 h o ( r r 8 Arambag 0 (0) 0.98 n e Bighati - 7 ) a (-2) r 7 1

6

3) - (0) 2 1 1 m - 0.97 a 6 73km Zebra P (-4) r 8 - n ( 6 0 0.96 - P ( i - 2 0.96 e Tarakeswar 4 m ( w m k ) T h 0 m k t ( 5 4 2 4 -48 (-17) k 0 k n - 0.95 ) ) m 9 1 1 m 4 a ) k 2 ) ( 1 2 4 0 2 - 6 1 P (- 4 1 2 3 p Birsingha - - ( ) 1 5 ( 9 Mahispota a 58 -48 5 1 3 (2 m n

k arambag 0.95 54 1 t

CK Road - 10 km Panther Titagarh WB h Rishra ( 7 5 0.94 k 1 (-19) ) 3 ) . e m 9 3X60MW 4 (-23) 1 0 r 5 ) 0.92 Chanditala 0.95 2 0.96 -71 2

0 7 Ze ( a ( 4 21)

CK Road 1 - ( 6.4 km ) r 8 2 0.95 -4 -84 (-28) 5 - -32 a b - ( HOWRAH b r r 0

8 ) (1) IPP e ( e 0.94 (21) th Panther

k a r -40 an b 7 4 Z r a P

0 e

m b Basirhat km -10 ) 32 8

6 0 0 -32 -14 ) Z

87km 87km Panther e (-1)

-88 (1) -39

HOWRAH (-3) Jhargram ( m k

P (-3) (6) 0

Z 2 0.91 r (

k e m

) 32 -124

a e (-4) m 1 4 s

m (-16) ) 10 0

3

n h k

(3)

46km Panther 7 (6) 0

6 6 o 0.5km

-

k 6 t T Jayashree (

t 3 1 5

( )

k 1 - 0 o (-31)

h n w ( (3) -64 -149 5 5

7 3 Barasat

m )

e ( 0.95 a 1

M i 6

n

r 9 P

9 k (-19) -1

) P 9 . n

M (-8) 0.92 m i TRS Basirhat 8 5

- Dumdum

3

(-7) a m

-47

- o r k w (4) m

P k

( n -10 (-3) e

0.97

)

o m k

39 km T 0.92

Rishra_CESC h

1 t a 3

) 3 t

5 m h s . Salt lake

39 (15) 1 4 nt

5 k n

(-0) 1

48 km panther P 1 9 -33 3 m e e

- ( m a

( 5 k a he 0.95 k BT road

-1 r 2 -6 (-2) P GIS 3 ) (20) 2 ) Kolaghart T . ) n

8 7 3 8 3 RM Bulk 6

t r

2 5 (1 ( m ) 0.94

h e

(4) - 0 Dankuni k 0.94

( 4

-36 (-5) -2 (0) 0 - 0

26km Panther 7 0 9 6 72 e s

3 -15 (

0.96 ) 0.93 3 5 - 2 8 3 Balichak Domjur r . m ) o

0 k

- (-1) 3 3 8 3 0.93 0 5 - 4 . ( 2 - Bagnan (- - 1 8 o ( ( (0) Hind 3 (-13) (-5) -3 Uluberia 0.96 ) 1 1.5km Panther - ) 7km ) 3 Panther 35km ) M 2 ( 4 1 ) 2 0 4 - Midnapur 1 ) -39 5 8 1 7 0 k ( 0 1 4 (-3) (10) - r m 5 7 0.95 0.94 3 -79 Motor 38 TM Bulk ) Jhargram 0.95 n 24 P 0 - -49 -50 (-16) -15 ( e 1 ) i a Kolaghat ( 0 ) n - 6 8km 1 6km h ( 0.98 t ( -22 21km ( 4 t h ( 6 0.00 0 er 0.95 (-17) (-35) w 0.96 2 n ) (DVC) ) 0 NCSS - ) (-16) (-1) (23 ) 2.5km Panther Salt lake T

(-5) a r 2 ) -9 (-5) 1 km 0 - 47 (10) 8 e ) 8 9 P 4 h m ( -81 (3) ) r 4 t 6 1 0.96 m 0 k m ( - 0.93 r n 1 1 - Kolaghat ( ) 5 0.95 e 9 Pingla e ) k Food Park 6 (4 (5) 6 a - ( 1 m -91 r Food Park 5 3 k (-19) WBIIDC h 2 (-13) ) ( a . ( 2 P r 0.97 0 3 5 t h 7 -32 k - 5 - 0.93 -6 (-2) 5 6 8 1 6 r - 0.95 n e e -78 t 0 - . 8 8 7 2 m 3 ( - a ( 5 km k h Tap 0.93 (6) b 0.95 1 5 P t h 5 n 40kmm Zebra Belur 8 1 9.2km ) 9 9 1 69.2km 6 2 n t 4

7 m e a (-10) ) ) ) Kolghat DVC 4 LILU 24 (8) 2 6 k a n 3 -133 10 (-26) ) - 6 0 50 - ( a Z 3 P - ) P (2) r e Jangipara -10 0.93 m CHPR_R (-2) -5 6 ( 1 b s a 95.2 km Panther 5 ) ) -119 (2) 7 - ) Ze o 2 216 (52) ) 1 0.94 - 5 1 ( o ( (4) 2 k -3 m M m P 1 0 7 7 ( 7 ( 4 - - ( 1k n (3) 9 . i r m ( 7 3 0 - ( 6 k (-3) 1 0.97 m 114 w e 1 1 Balichak ( - 6 T 0.95 5 15 ) ) 1 3 h k ( ) 7 6 3 k 0.93 0 - ) m t 2) k

m 3 7 (- k 8 3 - -1 -1 2 6 1 n 8 4.4km m - 1 ( 3 (-0) a 0 . 3

) 1 k 8 9 5 5 .

0.95 3 P 2 2 - r

8 ) BRG Steel m r 7 (-0) 2 (0) 6 - (

1 8 1 -34 a 35 -13 - k m e r 1 -83 (-4) 4 0 7 e

KTPS - ( 8 r k h e 1 1 (4) 5 t ( 1 r ( 9 -

-39 -30 e 2 h 4

(-14) b 0.97 n h )

t . 0

(-5) ) 2 t ( 4 2 (3) 3 a 1

19km s ( e (-0) 5 2 0.97 - 1.00

7 Howrah P - -64

e (5) -2 o n n ) ( 2

BRG Steel 1 ) (-4) ) East kolkata h

k -

0 2 )

0 a a 1 - o ( m Z 6 - ) (88) Howrah t

(0) 2 k -17 61 61 1 m 1

1 2 P 2 3

9 0.97 5 M 2 9 5 P 8 3 - (

0 3 0.97 n 147 Uluberia -

- ) ) 9 r - ) n 8 8

3 k Tap - ( 0.95 1 - 0 r ( e 2 m (-21)

m i ( m - ( m 2 5 - k 2 5 Kharagpur 4 h (dvc) ) 4 NTAA-I e

0.95 ) k 1 t 1 5 6 9 a k Falta ( w 5 - . h

5 k 8 n m 5 (4) k - . (11) ( m Tamluk_R - 1 4 -80 8 ( (11) 2 4 9 T a 6 m t

P

( k -

k 0 P 0.95 4

- ) n

5 0 ) Tamluk 4 0.93 ( 0.94 ) m 6 8

1 -148 91km TwinMoose - m 0 1 a

r

) P 0.92 m k -37 (-12)

Vidysagar ) 3

) e P P 4 4 1 2

k 5 2 Z 6 . -8 m )

a 0.94 KTPS

( 7 3 (

) ) 0 ( ) a

e 7 h

1 0.94 6 a 8

- n 3 - 1

k 33 m

b ( t ) 9 r

5 - 1 6 ) -

1 -

Park r - 3 8 n k (2) ( t n 1 (11) (

a - 3 - 7

h 1 -2 a 1 r 3 b - r ( (-2) m . a

WEST MEDINIPUR 2 b k 3 e t

( e BBD 1 .

( e 0 Z (2) 6 37 ) PRS - th h 8 e P

0 . 245

0.98 - Hizlee -4 0 1 7 0

m

1 ) -54 5 r ( k ) ( ( n ) (4 1 ) 7 a

) - 5 0.96 e 7

(0 2 2 . Z ) 3 7 P - 0 4 ) 4 3 (-1) 5 bag ) 2 m

1 (-7) 29 18 ) 1 -61 (2) 0.94 m ( ) m 1 8 m r

k 1 ( k 9 8

1 ) 2 1 k 3 7 0 ) k 0.97 4 -48 6X210 MW 3 3 0 (0) )

( 2 3 . ( m ( 1 (-1) - 1 7 2 4 7 8

Hizlee 9 0 5 1 m 7 k (-18) ) 1 0.98 3 . -1 2 k a (

(-1) Pingla 1 (

- r 6 4 Kharagpur 0 6 a . 7 3

1 - 4 m k

b 8 9.8km 6 -4 (-2) 0 r km 24.1 6 - ( ( 5 (0) 4

5 e -109 - ) 1 0 (-8)

TSS 1.1km m

(0) - ( Z ) ) b 1 0.95 k -32 2 8 6 3 Kolaghat 1 3

0 r (-19) )

m 6 Parklane . -40 3 e - ) ( ) e 1

1.01 91 km TwinMoose 6 k -108 6 9 ( 147 ) 1

-148 Botanical . 6 2 Z 3 h 4 2 NTAA-III

) (2) 0

0 6 ( 0 t 4 a 4 3 DVC 3 3 - 0.97 er r 3 - 1 1 3 1 13 km Panth 0 5 4 0 0.99 1 -98 2 ( n - 1 ( (

6 6 garden 2 m (-0) b

( KTPS 2 7 a ( m 1 ) 0.97 4 (88) k 2 (-49) 8 k e

5 9 ) (11) ( (1) P -45

(-2) k 1 9 - 9 (

m ( m 3 Kasba (-11)

k 4

0.99 Z 7 - ) 0 ) ) 1 2 5 Laxmikantpur

1 4 - 1

7 -106(-6) -

6 ) 0.94 m ) . 2 0 P ) P 0 ( 0.95

2 2 -11 1 a 80 k 0.97 m

3 km 4.3km

9 5

9

- 1 2

a 1 m n ( ) 1 0 k

- - 4 0 ( ( HPCL ( 0.95 ) 4 (0) n k t . 5

( 2 1.01 - h 0 0 4 t 2 1 ) 0 0 0.97 2 a ) . m e (

h -78 r P Circus 0 r 6 2 -67

0 0 2 k - e 1 3 9 0.96 b ( 6 ( (-22) m 1 r e

) 3 2 6 F PARK ) . 0.96 ( 5 -33 (-8) - 6 Z -

- 0 k - 2X300MW 0 7 )

9 ( 0 0 e 2 6 ) -8 0 (-26) 9 ) (-8) ) )

) - m 1

-

s South R S 8 7

a

(

3 0.96 k 0 0 m - ) o 552 ( 3

1 (1) r

k ) 1 ( o 1 (

- -189 0 3 (-14)

7 7 0 (0) 2 ( - b -104 . (

M 8 6 )

0.95 0.99 EMSS ( 2 4 1 ( IPP 4 CLC e n )

i 2 ( 3

-157 (28) 98km TwinMoose 2 (172) 21 (5) 0 0 1 - 0.96

Z w 5 ) ) ) (-91) 6

- ( 9 8 8

1

T 1 1 0.97 - - a Baripada ) 4 ( ( 4

2 -

) r

7 - HNIZ 9 3 6 0.97 2 m

m 6.4km 2 -21

- a ( 6 0.96 2 ) k New Haldia 6 6 2 - b

1 (-4) 1 (

k r

8 - 6 -9 ) r e - 0.95 - ( (

5 2 b

9 ( 8 e -

. z

7 (17) 1

(7) 3

1 mankar 8 h

-251 (-28) Haldia 6 ( -37 E - t ) e 3 - -

) ) -63

P n Z 7 L m 5 )

9 -

0.96 - 1 0.95 Taratala 3 X 0 a 0.96 - r Majerhat k

- -21(-0) Chaibasa 3 ( KTPS -42 r 1 P

( e 3 m ( m e 2 BEL CPP -15 -50 (1 m r 3 0.99 0 h

( h 1 0.99 q e k 161.5km TwinMoose ) t 2 m 2 -251 (-28) 1 t 3 0 ( s n 2 4 . - k h 0.94 (-11) 9 ) 86 1 0 a 3 2 - 1 0 t 3 (-5) 7 (-0) n Chakmir km 0 8 P ) 7 ) - 7 4 . ) -1 2 ) 3 -32 n ) a 5 6 8 2 - 8 ( m a ( ) 0 ( -4 m ( k 0

- ( 4 k k 0 7 P 3 ) P 0.99 m 1 m

4 2 2 0 2

BEL CPP 4 - 5 ) ) 2 5 . 7 1 (-9) ) ra - k . - )

( 3 Patuli

3 ) 5 0 m b

1 6 4 Z 6 5 m 1 4 4 ) k e 5 - . m 3 k 7

- 2

3 4 - - (1 5 7 e Z

( -73 (-30) ( 5 ) 5 -

0 ( k 4 r 2 b ( ( ( 0 4 ( 0.97 e m

. 5 23 km 9 1 r k . e - ) h a 4

1 1 t 0 (0) 8 ) 1 EAST MEDINIPUR

MCCPT s 6. n Sonarpur - 4 m 7 k 3 (-15) 5 2 2

a 7

o 1 ) -101 m k ) 0.95 5 o 4 P r 0 3 -2 3 - 1 ( e ) 1 (

) r 5 M 4 EJadavpur m 0.96 5 ) h

e 7 0 P 4 P k t 4 0 -21 (-4) h )

t 4 - C ) L 5 3 7 n ( ) 8

a / 2 - 8 8 2 n ( 0.97 2 a 2 3 3 - X -

da 0

aripa 87 (56) 3 - 2 ( B a - e P 3 - n D -

( s - ) ( ( 1 P ZZCP0 m ( ) 7

t BAJKUL ( 0 ) 2

Egra h o - ( m -

m 2

- m 10 k o m k 8 Tatapower 5 e 2 k q 8 -

9 M 6 5 50 s 0 1 - r 2X45 MW - 4 6 0.94 .0 0 ) ( ra (4) (13) 0 /C 0 0 b ( 0.97 2 8 -111 ( e 1 10 1X30MW 5 D Z ) - 3 m 9 m 1) Subhashgram-PGCIL 1.01 4 m k 0 6 k -7 5 ( ) ) - ) k 5 . Egra -1 -32 1X250MW 5 7 JOKA (-26) - 0 85 ( 2 1.00 . 8 4 - 1 8 - 0.99 SOUTH 24 PARAGANAS - 2 ) Sirakol r -28 (-10) ( ( 1 0.97 0.95 e 0.91 6 1 Subhashgram-WB -61 0.97

/ -121 - (180) 5 234 ) h IPP -2 ( 0.92 t (-5) 4 ( n -33 0.97 ) ) (-7) (72) -123 9 -63 4 (-9) a 6 (-13) 4 546 4 5 5 - 3 P -44 4 17km 0.97 - 2 4 2 Kakdip (0) ( 3 9 k 3 (-10) ( ( m 2X250MW 2) 9 5 - ) m 4 0 1 103 0 P k (3 6 . 6

1 0.93 a 5 1 ) 29km Panther 2 n (-15) ( e -3 t 2 3 s h 7 - k o - 3 o (24) e - 3 M r ( IPP m in 49 28 ) m Tw ra (1 Falta P 0 k Zeb 0) 9 a km a r 53.5 (6) 34 km Panther n ) b th 0 e Contai ) e (4 Z

) 1 (-11 r 0 m 2 9 k 4 0.93 -54 -9 6 2 8 3 3

0 - (2 4

(

1 )

- Haldia -122(-1) -78 (-22) -104 (-26) Kharagpur Laxmikantpur ) 6 r ( e h (DVC) 0.95 5 t -4 n

0.94 a ) P 4

3 1

-

-

) ( 2 m (- k .5 5 3 4 5 Kakdwip -44 (-15) 0.93

ZZGP0

400 kV S.S

220 kV S.S

132 kV S.S 400 kV Line 220 kV Line 132 kV Line Load Thermal Generation

Hydro Generation

IPP IPP

CGP ZZCP0 Display Notation Injection into the bus : +ve Drawl away from the bus : -ve Voltage Mag/(Ang) in Pu /degree Flows in MW and (Mvar) Eastern Regional Power Committee Power Research and Development Consultants Pvt. Ltd. 14, Golf Club Road, Tollygunge, #5, 11th Cross, 2nd Stage,WOC Road, West Bengal state existing network (May-17) geographical map Bangalore-560 086, INDIA. Kolkata, West Bengal 700033 Tel : +91-080-23192159,23192168, 15.09.2017 E-mail : [email protected]

APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REV. DATE REMARKS LOA details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 MiP-PSCT TM DWG. NO. : Geographical Power Map\ER\May-2017\West Bengal Ranchi Jamshedpur ) 42 6 6. 7 ) (1 . 6 7 6 9 9 . 8) TISCO . 6 .7 1 1 (28 1 1 69 - 2. 7 1 Chaibasa ( Jamshedpur - JHARKHAND e 1 s 9 e o e 4 s o m s .8 k o 141 M o 6( o 5 o 9 1 X 525 MW n T i w K . 4 M i 1 M n m 1 w 0 CGP n T n M i i oo ) w w 0 m s T T e 7 ) k . 5 .40-255 Nuagaon 2 Orissa state existing network (May-17) geographical map 5 5 . 8 m 2 9 1 1 16 km ( traction k 07 Kharagpur Sri -0. 1 0.98 3 156.14 1 Ganesh (-4.21) (12.58) -14.57 ) (23.25) 0.07 0.98 2 Twin oose M (4.21) Adhunik 6 2 X 30 MW 0 (-4.93) . ) r CGP .1 0 metallics 9 e - Bhalulata 1 0 ) 0 ( h 1 . 8 - t 3 .7 4 5 0.98 m - n 7 traction k ( . . 2 r a 2 e -60.02 (-18.07) 1 th 6 1 - n P 46.00 a P 1 9 0.94 9) ( (22.29) .7 1 -19.27 8.1 (-18 -5.48 (-1.73) 7 2 3 m Bhalulata tap 126 km Rairangpur ( 0 .1 k 2.1 km117 DVC-Jamshedpur JHARSUGUDA 5 (-6.31) 3) P 202.37 km Zebra SUNDARGARH 3 27 0.94 0.98 a WEST BENGAL n 5.48 th (35.56) 3.272km 21.05 e e 1 r Panther (1.73) 35 m s -45.9 Chhend 0 .5 k o 5 5 (-4.26) km o se 6 0.98 .4 . 0 win Moo ( -3 (-9.59) - 8 8 6 0 M 230 Km T -1 6 0 .5 ( - ) 1 2. .4 OCL . 0 Bisra 1 9 P n Kalugaon 32 3 ( 0 (2 .5 .7 an i 0.5km ) -0 0 6.09 1.01/ 1.01 8) 0 th w -31.00 ose 0.98 . ) (- e T Mo 0 -68.66 km r km Twin Rajgangpur -9.55 0 15.34 14 151 Km 168.51 (-9.97) 0.98 145 se Tarkera ) .00 35.63 km -168.67 in Moo 2 66.95 0 -1 (5.16) km Tw .1k(-9.67) P -21.21

135 0.98 2 m 1.00 0.99 -38.20 Rourkela an (-8.77) ) ) 3km (51.85) Hexa Zebra -15.91 (27.38 .6 the Bangiriposi

(51.12) 15.87 (9.39) 85 8 0.99 r 0

2 45. (2 8 Rajgangpur .36

4 4

) 88 2 4 Dharamjaygarh 2 2 .7 . . (-11.47) . 0.99

. 7 2 0.00 4

) 4 2 (5.64)

168.51 1) 9 5 2 4 - Beekay steels 8 151 Km .1 - . -168.67 5 .3 .0(0136 . 8 ) traction 2 7 - ) 21.21

44.18 (5.83) 18 (0.00) . ) -65.71 -14.55 -32.00 4 1 2 { 1 2 - 2 ) 0 7

Tarkera 0 5 - m RSP 7 8 Ramchandpur (-6.83) ( . 1 5 k 8 4

Hexa Zebra 0 3 8 ( a ( 0.95 - 4 . 0 km 3 (51.85) . 6 - r . . 13 7 9 se 6 0 ) . 3.38 (17.71) 0 - 3 (-5.64) k o 2 7 (47.96) (51.12) A win Mo . -9 -2 1 b 7 1.00 1.02 - 2 - 64.91 (2.71) m .5 R km T - 6 5 ( )0.98 e 9 9 5 - a -139.87 (65.81) B 147 ( 5 2 . ( ( Zebr 6 Korba ZE 2 4 Z .8 ( 4 P 5 Jharsuguda Sundargarh m Rajgangpur 9) . -2. 00 0 - 9 a -1 ) 0 0 K 9.8 Moose ( . (11.22) nt (49.38) 3 - (7 in ( ) 1 9 12 m Tw 0 a 0.00 .9 h 0 6 0 7. k r 1 -5 10 r -224.70 e . 8 r Raigarh 1 ) r e se 1 1.20 2 e 6 Nalda r . (52.38) 0 1.01 1.02 -139.87 (65.81) th oo .0 th (-8.77) e 8 / M 154.00 0 0.99 n Twin (2 n b 4km ) 2 a m ) a r 0 23.18 h k . 194.06 ( ( P 91 P e 1 Kenduposhi -2 er 4 bra 0 he 1 0.98 t

5 m th 1 e 8 .2 t -15.91 0.95 . Z Z .0 K m an 9 ) 11 km an r n -21.39 1 95 30k P 1 .61 7 8 P he (13.17) 1 2 m t a 145 Km 1 - ( . n ) 202.37 k 3 1.57 a 0 -15.72 -202.92 9 r . P 0 8 253.73 0 Arya k P 1 2 m m 3 e ( ) k m (7.07) m Chandiposh ) Bisra .9 2 5 k (66.08) Twin Moose 8 h 6 0 1 (-10.04) (35.56) k 6 r 1 } -8 t . steel 8km e 2 0 m 5 ) 0 8 -3.39 . th 0 n . ( n . 3 69km Bolani k 6 a 25 168.51 151 Km 1 Kuchei 9 8 P (51.12) a 8 CGP 0.96 1 se 4 ( 18. Km 5 (0. 5) (-13.49) JSPL 6 o 1 2 P 1 81 Mo 1 8 4. Panther a FMP 4 Km in 0.00 . 8) 91 Hexa Zebra (1 er 0.96 r . w 2 .7 . h Barbil 2 9 0.99 1.00 T 5 Dharamjaygarh 2 Z km 3 (0 -4 { nt 2 X 60MW+ 5 b 94 1.01 / 0.99 / E 0 a 5 e JODA . 6 B 1 ) . 5 7 )

R 1 9 P Z -1 9 A r 5 0.95 6 k 4 TSIL 5 .

(0.00) e -9. 168.51(51.12) m 4 X 25MW 10 6 .9 P 31 h ( k k 9 m - r m -33.36 a

t the 0 . 2 (2 0

n an 13 (13.57) 1 ) n .0 a P 4 Pa 5 -10.47 1.00 (- 9 9 P e km .4 nth 7 t .2 -6

os 81 er 3 m h 5 o -7 - m k 7 m 91.40 M 3 . e ) k ) n 2 k . r CGP i -3.00 .2 (-5.54) 7 a (-0.34) 4 3 7) 2 7 Tw 2 -18.75 1 r 23.0 ) .9 8 - b .0 1 3 (- . m 6.39 e 49.92 Km 3 9 k ) Z 8 - k .9 2 (1 Action ispat 30 1 Bamra traction (-0.08) (-2.77) ( m -0.00 -6 4 (36.41) 2 ose .6 (-0.39) Joda 2 0 ( .4 Mo (2 0.00 . Baripada 1 5 ) in -0.00 0.00 -42.62 (0 0 6 9 ) 0 Panther (-16.98) 0 4 2 1 0 w 1.00/ 0.98 (-0.63) 8 -207.12 (-0.00) . . 12 - . m T 4 -0.00 -7.95 .0 3 2 . 30 1.00 L&T CEMCO 5 k .1 (7.25) 1 0.98 Raigarh ( 7 -3 (7 (- 3 ) .8 230 9 . 0 5 7 5 (-0.00) 7 ) 9.7 .6 3 1.00 4 ) Raigarh -1 ) 2 Budhipadar 7 2 6. .38 B TAP -0.00 5 ) 4 7 0.00 28.09 01 57.00 . -88.77 - - (2 2.8km 5 4 m ( -1.79 Panther k / 4 6k r (-3.19) 0.00 m 9. 1.01 1.00 . e P 1 5 - 1 -9.50 (-0.00) a ( (3.60) 7 th 1.79 (-0.50) (0.00) n 7 -57.12 Km n m Jharsuguda t . 1 Pa 3 K (-7.93) (38.23) h 3 47km Twi 3 1 e 5 k n Moose 6 -1.79 r (0.92) r (79.89) . he 2.26 2 m 86.50 -19.10 2 ant Traction . P -10.40 -2.26 2 P 81 Km -87.39 Jharsuguda e 7

m - a Korba s 1 - -10.40 10.40 (-3.19) 222 km Twin Moose -12.24 n .4 0 1.00 k 0 .9 JHARSUGUDA o ZEBRA 9 81 k m (-0.92) (-0.73) t -2

m 0 90km (-3.18) o Panther h (11.83) 0 k

(-5.43) .2 Z Meramundali 85.14 0.1 6 8 0 -6 .6 .0 EB 5 Km (3.19) (15 e Jaleswar ) ) 1. M 7 0 R 83) Ze 1 Banspani (-1.96) r 4 6) -4 0 A br 9 9 1.00 a Panther 6 . Jharsuguda 7 -7.06 0.95 . 0. (-6.92) n 6 (- 0 0 n - 2 1 i (4.97) (- 0.0 .99 r 16 traction ( 0 1 e

r 63 SPS 289.00 4 BUDHIPADAR w 14.39 e . m h .

3 T

3 T MSP t

2 0.98

h 2 k 7

t -289.00 ) Jaleswar

( 0

6 n 5 . 9

8 an ( Km 0 9 7.01 -9.53 181 km 41.64

3 a

5 - 0.00 (-146.37) IPP . 8

. 6 7 12.80 2 4 X 600 MW .

Brajrajnagar 7 P 9 2 - MAYURBHANJ traction P

4 ) ) 2

7 . JHARSUGUDA (0.00) (-0.95) 7 9 Zebra ( 0.99 0. 4) (-0.00) 0.00 Karanjia (2 (8.46) (-42.33) -706.00 r Polasponga 2.34km m r the -4 0.98 k e CGP 4 Sterlite 8 an 0.95 h m 4 6 km P .2 (1.30) -47.17 3 t k ( . 3 . 872.89 .33 0.97 0 0 2 n -4 41 0 K 1.01 / 1.01 63 (-240.37) 53 Kuchinda (- 8 A 1 m ) 6 1 m 29.98 a (12.54) -1 3 . 0 .3 1 X 25 MW .1 Z 80 . k P R -221.02 9 . 6 .0 5 5 E . (270.00) 23 7 ) 8 5 r 2 B 2 e . e 7 ) 2 B ) R 3 9 X 135 MW 0.98 4 1 e . 1 9 A ( 1 ) 4 ) e s 2 5 , E SMC Vedanta CGP (3.60 - s -30.29 3 th (-16.57) 9 Z 3 3 s o K . 6 9 . 1 o n T 2 2 Bhushan 2 o o m ( 0.5 1.01 . 2) 9 9 m e o (-0.53) a w -17.00 K 7 1.6 - . K o 7 P 1.00 Z 6 .09(- ( P M M 6 i 0 E m 4 4 n B 1 -2 -7.32 6 oos M .8

a 3 (-2.02)

.5 ) A R 3 5 M n n 6 -13.00

A 1 X 60MW+ ( k 1 i i

M m 3 9 n n 1 1 ) 2 R

(-2.99) 6 4. .0 m in i k

9 o 06 6 . 3 t w w m 0

1 K

7 (-5.21) B 215.40 5 K 6 6 7 h w w

. m 1 X 40MW+ T . 1 o -18.71 T

2 1.01 Z 6 . T T

5 4 E Basta (-3.35)

k s MCL 0 E ) 9 e , Z B 2 R ( {

CGP 9 ( 2 8 e a r 4 m e 5 Z A 0 (56.48) 1 b 43.32 . 2 X 130MW+ ) m 0.99 ( Basundhra 9 3 r . m m ra

3 7 a 2 K K K 0.96 ( b T

2 X 8MW .9 ) r 0 (-3.13) w e

-215.40 9 0 3 5 -21.35 b 9 9 7 9

i 23.90 -76.74 Hindalco ) Z n 6 e ( ( 3 2 1 2 2 - -1 204.70 m (-1.28) (2.89) Angul 8 . 4 3 k r

M (-34.36) -5.02 . Z e 1.01 6 m . . .2 5

23.80 2 - 7 4 5 . h

o 355.50 ( Shyam DRI k 7 4 t

2 m

o Lapanga (-73.23) CGP 4X 150 MW 3 ) Balasore 2 n

5 (7.07) k ) a a

s 4X 100 MW 1.00 1 1 P

e (3.58) r CGP 2 (3.60) 2 alloys

2 k (59.09) Kuchinda 1 b -4.20 2 m km + 0 ) MERAMUNDALI

8 25.70 e 0.96 BALASORE

( r 3 1 6 r - 0 he m 0.99 t (-2.30) 18.56 1

1 . Pan Z (-2.73) . e 1 X 25 MW k

0 1 -24.09 1 X 67.5 MW Emami paper 6 (3 3 k h 0

. 6 -3.76 m 0.00 t (17.41) CGP 3 -0.00 Keonjhar Traction m

5 1.01 2

1x8 0 anther .8 1 P n CGP 8 ) km k (6.65) . .6 r (-0.00) . Joda

) 49 m -5.30 5 (0.00) 3 4 X 5 MW 5 (-1.62) a (-3.93) 7 e -15.00 7 -44.90 25.10 4 0.97 4

5 .8 280.50 k 0.00 k - h P m CGP 5 (-1.97) (-3.09) -2 8 Hindalco 3 t 1 X 30 MW 3 1 (0.00) 3 . n Balasore

- -0.20 Aryan ispat

( -131.20 (-0.07) (82.99) 1.00 23.41 7 a (3.56) - 5 P Sambalpur -73.39 IBTPS 0 (-9.31) 1.00 IPP CGP 8.83 0.99 -75.40 2 ) TSTPS

.0 2 Somnathpur 4 (-22.11) -2.50 85.14 (38.23) Barkote Keonjhar 0 )

0 0 Burla 1 2 . 1.01 Jharsuguda Tap 2 1 ( (18.83) (6.78) 15.00 T K -1.58 ( 0 (0.11)

0 . 93 . 5

0 . 4 (-18.39) m 0.99 3 3 7 r 0 w 1.01 .9 1.00 / . . ( 1.01 9.60 . 0 5 6 5 0 6 .

0 e 1 0.386km i (-0.64) 6 3 5 (55.94) ( 95.72 ) 8 0 (0.00) ) 6 - -22.91 -51.42(-0.24) 15km .09 . n . 6

0 0 1 X 350 MW h (4.46) (0 0 8 9 .

t 4 Rairakhol tap -2 9 m 5 4 r 0.00 M (

258.00 . ) (0.00) . 3 k 2 X 49.5 MW+ ) n k 0 Hirakud ) 338.55 (14.32)

e -14.57 (17.64) 44.42 16.60 -5.29 9 m Balasore traction

3 )

o a 0.00 ( a 4 0 ) 8 6

h 5 o r .3 3 (0.00) t 2 ) r P 3 X 37.5 MW+ 0 28.06

. 0.99 (4.94) 54 . 0.96 5

(-4.93) ) s ( . (-3.26) station b n 2 -9.60

e 130.57 KEONJHAR (-1.71) 6

9 .

5 ) 2 e e CGP 5 a 2

h 2 X 32 MW 6 -

1 1 DEOGARH 0 8

7 . STPS t m Z -9.10 1

P - r (

CGP 4 1 5 ( K )

7 (19.04)

k ( n .

Z . - e -2.50

m 5 Katapalli OPCL 0

6

6

a . (2.56) 7 h 34.8k 2

E 8 m

2 X 210 MW m

1 ( t

0

m -

. -39.19 0

6 4 P -37.20

2

B .

( 1.01

k

Ind_Bhartath 6 n (-0.06) .

k (-13.39)

5 Panther -

R 2 . a

1.00 2 1 1 X 30 MW 4 4

3

- SAMBALPUR 4 8 -16.54 m (

A . ) (-4.57) Soro P

m 3 3

5 X 50 MW 7

. 5 k 6 6 -39 . .

0.00 k ACC 1 ) Birla tyres 33

7 22.86 (-6.39)

2 5 Rathi 2 2 4 0.94 m 5 . (-11.29)

5 0

. k 3

0 0 8 0.96 k

9 CGP 25.70 0.97 4 r ( . ( 4 -3

Shyam DRI steels (-1.09) . -5.05 39.36 m e . 5 4 9 4 6) . ) m h 0 m 3 a (7.27) //

0 6 k 5 9 t . 0 -3.66 r r

4 7 ) k - 0 e n 0 1 e - . 8 - 1 X 20 MW s b

(10.07) 6 a 0 oo 223.88 (40.18) Baragarh 1 2 h e

7 . 6 M (-0.23) .4 t 9 1 . P 7 in 23

5 Z

. ( CGP w m .8 8 n

Katapalli 0 1 2 1 ) T Km

- 1 K

) ( m 9 a

0.97 (0.00) 4 m P 4 4

2 k 5. 3 an P t . 2 h 0 1 3 4 K e m (1 5 -16.61 ( Anandpur r 8 . 4

0 5 k -0.97 9 . ) 54.19 k 5

3 16.9 a 0 K

k 3 m r 1 m 4 . 0 0 1

Rengali_PH 0.97 b . m ) 7

5 e 0 0 8

. Burla (-1.09) P .

(14.33) anther -5 -15.47 Chiplima P Z 0.0

9 a Rengali_OS m 6

( Z

0.00 n 8 k Rengali_PH - 3

86.93 .5 e ( ) (-5.06) t -58.73 9 - 1.00 h 6 . (0.95) (0.00) -49.88 -35.98 1 b 9 e 1 7 -3 .7 r (14.11) (8.64) 3 5. r k ) -85.98

r -28.08 1 r 98 a (-21.05) ) m e

m e 11 m 6 h (14

k 5 3

k h ( 4 km a ) t . . a 1 7

t 9 5 r 6 r n 1 0 6 7

(-24.81) a 2 )

. r 5 .8 b k

n a .

2 b b (-20.81) - m e .

a 5 Z ( (-0 e P 0

e 4 9 Z Z

-53.05 - -19.00 TTPS

P (-6.30) e

2 1 Z m b 1 3 X 24 MW Rengali_PGCIL 0 m k ra - 22.54

0.00 2 5 ( 38. 2 6. k 0 1.02 /1.02 45km 76 (0.00) . 0 3 1.00 1.01 ( 7 2 7 . 3 Barpalli / 8 2 TSTPS 0 5.8 r 9 9 4 4 4 anthe (4 k -69.62 (-7.82) P .24) 0.98 . 6 m 6 X 500 MW (0.00) FCI (- a 4.6 r 5 8) Kamakhyanagar b ) 0.00 1.02 9 Bhadrak 432.00 TTPS BARGARH 2 ) e 7 . 8 Z ( . 1668.96 2 1 - 5 87.26 traction 0 (137.46) 3 . 1 8 2 X 600 MW Kaniha-NTPC ( .4 0 m .2 IPP -0.40 0 0 - (-13.24) a (1.56) . 6 k a 4 r -42.31 ( 5 (0.00) b 1 . - . r 7 ) 2 456.00 1.00 e 0.98 9 8 1 -32.18 1 1 Z 3 b m ) 6 1 m k -5.73 8.5km 0 1.01 e 3 k .6 K ( (-8.83) ( 0 -90.32 4 (-10.03) . 4 (223.47) .0 0 3 - 3 4 X 60 MW+2 X 110MW . 4 Z 03 4 7 (-0.19) m 4 7 25 -32.58 P 1 9 ) - . K 6 9 8. 2 5 ) - Bhadrak P a . 2 -2.60 m 9 . JITPL m ) k (-14.96) 1 81 -1.61 a n 0 K 8. m 4 5 (-11.02) n ( (-1 0.98 / 0.98 t ) 3 X 350 MW Rairakhol 1.02 ) 0 t h 4 h .0 7 e 8 Facor e 0 TTPS r 0.99 8 -1 r 0 ( 0.98 r -54.31 IPP 1 X 350 MW Km ra e (-15.40) Zeb th -2.94 -11.75 Pa 4 n Chainpal m a (10.09) nt .9 k P (2.50) 90.21 IPP h 4 23 (-4.10) 0 e 5 .8 -17.65 7 BHADRAK 1.02 r 4 km m -0.40 - (4.24) k 3 (-2.77) e 7 6 5 -49.23 4 .7 662.00 s 2 . k (0.18) SONEPUR - 7 n 335.00 34.20 (16.96) ) 4 -649.00 o 38.76 k . (26.26) m P 2 2 2 -24.70 a 1.01 ) 7 o n ( 2 3 (-2.82) P th

2 (-219.44) a (2.43) 3 ( Km (- o nt er Dhamara 4 (-15.13) r 4 3 0 4 he DUBURI P 2 . M 5 a . Boinda k r 0.00 (0.00) e 1 4 2 r JSPL m n 2 6 1 m .6 e 1 8 t 3 m 2 Q m h 0 Traction h CGP 2 ) d h - ) . k U e t 8 t 7 0 ( K A K r 1 0 1.00 a P .0 n r .3 6 2 3 D a 0 3 8 5 GMR n 3 1.01 n ) a 7 4 B u t e - 8 0.98 ( h 5 4 2 e P h 1 5 .6 a - - E K r t . ( 1 1 RS 2 6 Q MCL Kamakhyanagar n 77 .3 5 4 P 1 1 IM .6 a m 1 8. ) .4 1 5 3 1.01 7 8 m 4 -6 3 7 IR P 5 3 6 2 I Duburi new K 2 ) 2 8 S ( 2 P -24.76 0.99 a 3 6 0 0 ) 5 (-1.00) 6 m Z . - . . . 1 K 5 r 3 0 2 4 3 a 3 . 35 - Jajpur town e ) 0 Jabmaye 6 6 2 3 2 0 4 4 b 4 5 km ) .9 9 n .7 5 . 5 (-2.40) (9.04) 4 ) . b K 7 3 Q 4 e 4 se 4 K t ( ( P -18.40 .80 3 ( . m oo .0 1 r L 2 7 4 8 6 7 m m h L 9 . win (9 a m Z ferro Z Sonepur - - Twi 6 P 5 5 6 K T 0.95 -2.60 T ( n M k 42.04 Km 4 e ZZ oo a m.1 96 w se ) n 8 ( .0 r e ) Z+ 05 6 . 0 . t .6 2 i s alloy +0 0.99 55 h ) 0 8 4 0 0 (-4.16) (1 e ) n 0 r 1 0.00 NALCO o .9 09 10 X 120 MW o 4) 30.08 - MERAMUNDALI Dhamara M (2 9 2 9 50 ) M 5 3 CGP 2 3 o . .82.9 - .8 (-3 (8.73) 0.98 .7 1.02 5 29 4.9 7 .9 8 o n 4 (22 2 6 X 135 MW 2 ( 998.00 i -32.91 ..5 0 ) - 5 s (1.68) 36.05 0 52 .6 (1 2 7 . CGP e w 44 0 .01 7 ) 2 6 T Nuapara -3 4) ) 5 9 Angul 9 . 3 (350.28) r 0 1.05 Km . 2 ( 2 e . ANGUL ( 5 . m 5 -2.94 m th Pan 2 1-30.40 1 JAJPUR Angul 0 ther 1.01 3 K 9 0.93 an 1 7 6 . (-0.68) K

P ( 4.91 5 -1 . 0 5 m .9 (-10.15) ) ( 5 a 1 -113.93 .

0 K 9 rJoranda ) -884.00 8

.6 4 8 5 b (-52.18)

11.63 ( ) 5 9

1 5 1 e -47.97

1 .4 0

- 9) 8 (48.90) . 9 160.09 5 Z

(4.22) 1 .

) Bolangir_PGCIL . . traction

6 0 9 (-15.39) .6 Padampur Bolangir new 3 8 3 )

-3 Boudh 7 5 3 8 -4.71 (-296.70) 7

( 5

1.01 / 1.00 1 6 - 6 km JSPL 1 )

( 5 . 4 . .3 0 0.97 1.00 /0.99 0.98 7 Dhenkanal 19 ( 7 (-3.43) - 3 8 .9 4 45 3 . 39.8 Km -31.93 6 -4.90 9 ) 4 .7 3 7 46 Km -7.36 (0.97) 31.53 .1 ) 173.07 8 9 km0.97 -57.39 ( 6 2 (-4.97) 5 6 -4 .1 -4.72 (-2.52) 0.97 65 3 (- Panther 7 9 0 (33.03) (-1.32) Angul 9 -6.51 2 X 12MW .1 7.9 (6.00) -1 . .6 BOUDH (9 P 6 T K BRG steel

8 0 ) m 7.34 (1.13) 1 3 ) 71.34 a w )

r m - - 4 1.00/ 1.01 (22.62) (-20.70) n i k ( ) -9.02 (-2.16) 34.45 n 8

m e 0 t Meramundali

2 3 . M 0

7.3 Patnagarh K 8 km 0 h 5 1.01

- 12 h 0 -61.10 19 CGP e o .

24. t .8 (4.30) 3 1 8 - 3 1 0.00 1 o . ( 3 r 1 7

) n 4 92 Sterlite 2. s .4 1.01 / 1.01 / 1.01

. 2 e 7 4

.77 0.98 a 7 .32 28km Chandikhol 1 2 2 (17.48)

-0 e -174.18 K - -12.50 74.16

( Twin Moos ( k 1 m 7 m (

P (-17.54) 8 (0.00) k ( Z 7 T 0.91 1 2 2 6.80

(-5.93) . w (0.00) m e 0.00 i 0 22 b - 3 -74.95 (-8.38) (66.16) 2 -54.64 n Panther OCL 0 r (0.00) .55 Km Duburi 35 Mo Maheshwari P .40 Km a -12.50 (-5.63) (17.48)

- ose a T)w 113.81 (-8.38) 74.16

Bolangir (7.76) -74.95 0.98 2 n i (-5.46) ra

(9.11) -48.81 23 0.98 -7.78 -30.23 t -30.72 n M Panther 95.6 Km Zeb

1 X 50 MW . 3 7 h (54.86) 5 -34.30 . o

0.99 5 km 4 (-8.03) e os IPP 6 e

0 IPP (-16.62) k r e 4 Twin Moos P

r DHENKANAL (23.81) 5 7 Km 3 9

-60.57 (-6.65)

k (-2.54) m 9 0 Pattamundai .7 -414.35 412.82

e 7 5

m a .

28.00 -9.15 -103 1 0

h . - 5 (

n 163.70 0 - (51.55) 1 0.92 t 2 (40.66)

1 X 40 MW 1 2 0.00 Kharagprasad

-54.64 CGP t (25.11) . 2

n (2.42) . 5 5 Km h 2 X 54MW + 1 X 30MW )

ICCL P (88.84) (0 Kendrapara m 2) New Duburi k a CGP . 5k 9 0 BOLANGIR ) e 40.00 Aarti steels 0 . r (0.00)

a

03 (9.11) m 0.99 0 9 30.85 P 0.00

P 1 e 8 2 - an switching station 4 P r e th n (-5.28) ) 0.93 th . 1 er 7 14.34 -38.08 Mania ) n s 4 8 2 40. . a (8.18) 0.99 t 2.06 a .2 (0.00)

- 0 n Choudwar h -34.91 (- P o 9 4 15.66 0.94 m -31.06 - ( Navchrome

(6 t -12.82 km e 0.98 o ( 1 2 k km Km

h m 23 .72 r 38.08 (5.28) 51 (31.20) 50.94 -1.49 4km 1.49 8 M e k 2 .8 0.94 Bhuvi

(-4.08) .2 (4.08) (-3.91) 9 2 3 r -20.45 m Salepur KENDRAPARA (9.19) r 0 (-1.46)

. 0k 2 n e 1 ) ) -7 (-0.16) Panther (0.48)

e 2 1 i .

2 7.22 22.84 2k Marshgai s 2 0 -0.00 ( .4 6 0.94

(-2.81) -7.30 0.97 -21.07 -54.64 -54.64 a .

h m w - 7 1 0 7 m t ( o e 5 3 8

12.77 Kendrapara PH (-0.00) 3 T . m - (0.02) . 6 .1 3 0 81.76 m 7 )

k o K 6 0.93 br .

n r (-3.99) 4 - s 7 0 K e Bidanasi .2 ) 2 K 5 7 m

4 2 m (9.11) (9.11) ( 1 8 8 -3.96 h traction (3.76) a t . o 6 0 ) . 29.92 P 9 M -7.40 9

n -0.00 K - 4

a Rawmet 1) 1 o 3 . a

9 0.99 Ze ( . 9 . 0 Phulbani Hind metals 4 P P .9 1 ( (32.44) n 5 - n .

3 - ( 2 0 9 ( 9 3 3 Saintala 1.00 0.99 -29.80 3 .69 . (-1.44) ) i M CGP th 0 ) 4 7 3 e ) 1 - (0.00) . . 9 0 e (-1.82) 4 w - ( 0.99 8 ) n s 0.94 1.00 k 2 7 T i r m k m 6 . o 1 X 30 MW+

a -26.98 59.40 0.98 r K 0.00 (-8.93) m .8 .77 w Meramundali 2 e (-9.03) 7 7 o (-30.50) b .1 s 5 P ( m T (-8.90) -6.43 e 1 o 6 -40.00 4 4 M -15.66 1 X 65 MW 3 (3.01) Cuttack Z a .3 58 ( K traction o . 0 Z 5 e n ) 6 m n M 6 b t 3 -28.50 2 X 55 MW - 8 i -11.87 (-4.10) 0.01 4.48 1.00 1.00 (-10.17) h 1 6 K -0.01 (-6.82) 20.49 m n r . 7.4 (-0.29) i CUTTACKa e 5 w 7 KmPanther 0.94 k (-3.52) w km r km 8 T 4 T .6 1 - (0.30) (-0.30) 3 4 (-3.82) p 73 1 (-29.88) a . 1 n m ( 55

-52.97 - ML Rungta (9.30) 193.12 -65.03 th CGP K 89.40 8 -16.31 e ) .0 -74.70 r Bhushan 1 m (-8.46) 8 5 ) 1.99 5 K er (36.79) 6 2 4 1.01 se .9 h 25.60 . 7 ) 3.7 19 nt 7 1.02 8 9 o a (20.00) ( .9 9 (56.32) K 2 o (9.22) P 1 m .3 M (1.78) 9 9 . CGP 2

(-1.07) P k m 7 8 9 a m -11.75 n K 3 . .9 n i 3.5 -0.00 5 Goreknath -3.85 P 2 4 9 m th T w 2 -2.00 . k 9 - ( k e w T 1 a m 8 1 X 33 MW+ r in 5 n 3 ) 4 a - -38.07 Traction Paradeep th 7 r 6 2 M NAYAGARH -22.00 Phulnakara K -3 . 0 3 1 X 77 MW+ 8 o r (-8.09) b 6 m Pm 7 e 2 1 9. os 8 a -7.80 . r 8 e 4 k ( 6 NUAPARA e 6 e k Kesura n 0.91 0.96 /0.94 5 5 . m 0 3 6 0.99 (-6.10) Z 3 . h k IFFCO 3 4 2 X 150 MW 7 8 .5 t m . t h - 0 7 8 0.95 e Jagatsinghpur -41.19 7 1 P )10 n 0.94 ( 6 m (-2.53) r -12.01 6 (-8.76) Khariar 49 2 POWMEX r K the ( a . (-7.97) n K 95 a 3 r Pa - k m -14.22 .5 e 6 (-4.23) 8 n P 6 m m 0.91 h k 1 t .07 K m . t T 0.94 (-2 0.97 1.00 an 56 Pa Angul 1 h w 7 . P m n i 1 3 m (-4.21) P th e n 2) (-14.16) -7.81 (6.12) k er 5 .34 Bidanasi K 6 a r M a 22.05 40.16 ) IOCL r PPT o 0.691 n (-1.87) b (4 (0.22) 3 o .9 4 . e s t (1.59) PPL 8 e 5) . h Z .1 P 5 3 km Zebra 0.94 174 Dhenkanal 3 - 5 a K e (0.00) 8.86 0.96 m 8 n r MENDHASAL 3 K .5 m 0.94 21 16) -0.69 (-0.22) t 5 m . K -75.90 ra 0.00 6 m h 3) eb CHANDAKA2 .07 (6

8 (-23.39) K 3 e e . 0 Z 7 s Pa r 1 Moo 1 2 Essar n 0. in t -0.69 2 w h 5 -32.20 T er 1 (33.03) - Nayagarh 0.96 JAGATSINGHPUR -51.49 (0.47) ( 4 (-7.91) 1.00 ) 3 Bolangir (1.35) Kesinga km .22 .1 .28 19 -50.32 7 0 61 69 ( k .6 4. 04 a (6.03) m0.00

-25 0.97 0) 34. ebr ) 8 Z

) ) (-0. r (0.00)

.14 6 .33 he 7

9 7 t P

( . 18 n

m 7 ( a

5 . a Mendhasal

K r - P 6 n ( 7 2

3 e 8 K t

9 h 2 .7 m he .5 t - KANDHAMAL 71 k m 2 n 4 P

53.78 . 4 a (-1.67) 9 an r P (7.86) bra 1 th 48.80 -20.8 Ze (9.27) er 9 6 (7.86) km -0.60 (-6.65) Arati 5.2 (7 54.07 35 -68.91 KARADAGADIA -42.85 2 3) .13) 54.07 1 Atri (1.37) CHANDPUR Bhanja Nagar .8 ra 2 (-7 eb (-5.14) Nimapara (-5.55) .6 m Z / 8 69 k 0.99 0.99 -1 -23.76 68. -10.84 .85 0.96 (-5.34) 8 m 2) Baki 19.6 km Panther 6 k 0 r -5.81

m ) 1.6 (3.35) 0 5 0.0 e

9 (-1 .0 2 e r K 0 s h

8 1 0.99 ( (-0.67) e 3 . .3 0 t 0 (5 -72 .00 ) o 0)

o h 4 m ) 7 0 3 .0 n

. r ) (-2.42) 7 5 0 t 2 k 2 . m ( a 7 e .5 2 9 0 .

0 k . 0.00 3 h Bhanjanagar (9-1 2 m 3 n ) 6 n

t .2 2 .0 ( i 0 k P n 4 10.82 0 ) , Z w 0 m r a a -6.66 -3 0 -0 e 1 0 the

8 . b T . 0.00 n P P 1.01 /1.01 0 0 r 4 a m

.4 . 0// a 9. 0 P , P 0

8 ) 0 ( K .8 m 1 5 - ( (- 0 9 a (0.00) k 5 (-1.49)

4 (0.00) 0 . - Chandpur -

0 m

. n 0 1 (-2.54) 1 1 4 0.00 .0 0 2

- t k

( 0 ( 72.12 (-5.07) 3

-10.80 8 9

0 (1.61) 5 ) h .

.0 0.92 0 . 9 . r e 0 Bhawanipatna 0 3

7 ) e 5 r 2 .

4 - (-2.20) h 1 8 t 130 km, Twin Konark -18.44 Moose ( ) n Junagarh K 9 0 0.96 1 a 1 . Pandiabil .0 72.12 (-5.07) ) 45.63 0.96 m 8 MENDHASAL . 7 0 P 22 ) . ( 00. 4 2 (0.00) Pandiabil 0( 0 . .3 0.96 (-2.53) 8 ) 8 0.00 -0 r (6 7 9 (-10.98) P .0 a 0 e .42 Maheshwari ) r 1.00 h 3 ( r .0 t 9 a - 1 (-1.91) Dhenkanal b 0 n ( GANJAM e a PURI n . r a 0 e r h b P -9.40 e 6 t h ) 9 t e m -4.41 t Bidanasi Z h (0.00) n 8 ) 0.00 // Z K a 0.00 . 3 n , P - e ) m, 0 (-1.13) , 9 8 .6 Meramundali Arati steels 7 a m 0.00 m ) r 0 k 3 k 9.54 0.00 (0.00) . 1 0 4 m . 6 K 5 (0.00) 0 -37.93 0 0 1 P KHURDA r 1 (0.00) 2 . ) 8 Pandiabil 4 2 . ( - K e 0 03 4 3 , 7 m 2 ( CGP Solari r 2 - . 5 Cuttack 5 0 5 h 0.00 K e .0 3 9 ( . t ) . 3

0 m 6 6 0 3 . . n 4 . h - K 7 8 8 t 2 ( ( 0 k m 5 6 a 1 1 n ) (-13.31) 1 K 7 ) (-7.43) . traction

8 (0.77) 3 4 . P 5 a Puri P . )

m ) 0 - -289.63 6 0 1 ( 0.92 P 6 2 Smangra .0 .0 m -36.00 a 5 0 -30.15 46 2 n -1 8 ( 0 K 9. (1.13) Shamuka 0.99 8 t . 0.99 ( 5 - 4.41 (-10.12) P k h 3 77.10 P 0.99 (47.26) / 0 0.99 a m e (- a (-0.50)r CHILIKA n r BBSR splt .0 e t n m h m (0.00) 0 -4.41 h -9.52 -74.89 t 0 Balugaon t K e Chandaka K -55.49 0 m (0.50) h . r 0.99 r 0.00 0 0) n 5 5

e K e

-16.20 a .0 1 (-1.00) 9 (-25.68) r splt . h

(-4.85) 0 P 0.92 2 (0.00) (- 9 9 t 1 1 n -45.95 0.00 .1 . Chandaka a KALAHANDI 4 LAKE 7

Panther -1.99 P Vedanta 4 3 0.99 (10.97) Balugaon T 6 1.98 2 0.92 0km 1.99 . ) 1.00 2 -36.89 -91.00 6 53.31 38.25 0 Umerkote (-21.58) 1 r 7 9 the 5.5 Km 1 . . 1 an (3.65) 23.4 4 0.00 P ( 6 9 (0.00) 37.62 5 K 0.00 Panther (9.22) m Phulnakara 0.95 m 6 . (0.00) (-10.99) (-30.78) ) -115.51

6 a

5 k ( 3 P ) -2.00

0 6 r (-20.10) 65.00 an

2 2 (13.57) 0 the 9 . 7 . r a . b

1 r 3 ( 6 (9.80) 0.99 8

6 b 0 e (

. 4 Nuapatna (-8.09) 1 e

Z 2

) . m km 1 5 37.12

Z 3 K -37.62 37.04 0 -4.49 (-1.27) ( , r 3 0.95 . K 4 9 e m BPPL 1 0 (28.36) m h P ) . t (-13.57) Panther (13.95) a k 4 5 n 0.99 5 n L - t h 0.0 a A e NABARANGPUR 0 0 r P ( 2 Nuapatna Tap C -14.22 0 1 C .0 -65.42 (-10.28) (-4.21) 0 e 260.80 3 ) 0.98 C 0 4 T s 5 -2.33 (-2.19) A 3 w Aska . r o C . K - 8 5 12 2k e o a m .2 m i 1 m K 8 h n s 1.00 t 0 K P M m Rambha a 2 a 6 4 n n M -27.00 4 b K th a n P m e K 2 i a r o P 1 traction -250.00 a G m l o . w a 115.14 (-36.66)

n 0.00 P a 1 T

(0.00) 3 s t n a a n (-13.73) th 3 ) 3 r r h e . e c (19.78) r m 9 b b e 3 2 .1 e e a r 3 Mohana K 0.94 (2 Z Z -94.00

. 12.24 6

9 m m (-6.73) ) N 6 8 (6.25)

(-4.49) K K -96.60

m

7 r 0.94

P 5 6 6

9 K ) e

0 Purushottampur

K 2 2 (-27.97)

. 9 . .

3 a m h 5

.

. -16.55 5 t 7 7

4 n 4 .7 (1.78)

-45.36 7 -

6 0

7 1.00 9 n .

( k

t . . )

1 E 2

) h m 0 a 9

- 7

.1 2 0 Bhubaneswar P 1 - 0 P

5 e 2 (-0.12) 0

3 ( m 1 3 2 0

3 9 a 0 . r . k - ( 0 K 9 m .2 0 2 . . 5 (-7.13) n 2 ) 3 0 5 r 0.98 m Pa 1 6 . K 0 ( ) . a n t - 0 ) 8 6 K the 3 7 4 6 e 5 h . 0 . c ( 5 r r 3 m 0 7 B 7 3 h e e 16.49 - ) . t h e ( 7 6 s n t P .0 . 5 n o an r 1 2 a a ( 3 - a o l 0 - 287.98 P 0 ( - (40.26) 2 (0.86) n P M a 2. 16 . ( e 9 -4.60 0 Dabugaon (-0.30) 1 t 1 . b 491 K h 0 6 in s -2.33 m (0.00) o a 4 Indravati PGCIL P e ) Ganjam .9 w o ( a s (-0.89)

( (20.01) - T 5 0.7 2.9 n r F 0 . e 9 t -27.80 0.96 2 5 ) h M a 4 3 2 s 2 Digaphandi e m Mendhasal 6 ) Km 2 5 r 0.00 K 5 2 m n 0.99 . o 9 .47 - 2 .7 - i C ) .2 Indravati -21 1 0.00 1 7 0.94 K P 8 o 6 (0.00) (-8.56) 1 w ( 9 (-14.64) 0.94 a 1 1 -44.00 ) 0 n 6 4 . 1.00/ 0.99 T C th M 8 3. k (4 5 Narendrapur .9 Km .57 / 4 2 . 9 0.99 1.00 (-2.19) 3 3 e m / -12.00 3 1 - r - 2 6) -55.33 RAYAGADA (8.93) . ( 1 m 4 in 3 Tw - 105.40 O K -2 ( in 25 Theruvalli 8 11 Km ) 99.39 3 CC 3.1 w M 9.3 IMFA ) 61.49 her Chattrapur 2 7 5 t 2 A T oo 5 Pan 4 . 2 Kesura s 2 1.00 /1.00 9 -6.50 ( e (- m -33.73 0 1 -3 12 1.00 K ) . ( ) .7 m .33 44 m (6.25) (-1.62) K 6 (-0.70) Panther 2) k ) - (.10 39.81 Berhampur 8 5 .7 (-13.83) 4 ) 0 1 40 . 01 3 (-12.35) m 2 .6 ( 7 0 5 4 5 . .2 . 7 ) -83.73 K Tentulikhunti 5 0.94 6 (9 (4 . 9 Km 1 0 9 Y 6 ( 566.00 .3 5 (-4.70) 22.05 3. 5 154 (47.02) 6 4.8 1 . 0 r 2 9 (-0.85) 3 0 0.98 6 62) e Akhusingh -4 ) ) Narendrapur 8. (1.59) (-6.50) . 7 2 ) 27 h 3 6 0 (- m t .8 . 8 - -17.44 38.93 an 4 ) . a 39 K 1 9 ebr 4. P - 4 0 0 91 Km Z 15 ( . 0.96 / 0.95 A .3 0.95 -15.74 (8.57) 7 IREL 0 -15.00 -155.95 2) . 7 (1 27.6 (4.30) 9 ( (- Km 20 1

(0.55) 0.94 -6.05 6 INDRAVATI (43.06) 50.69 4. 86km 0) Panther -10.00 - 4 X 150 MW .0 2 ) (-1 B (-0.77) (-4.05) -40.91 . 0 (-1.24) 3 8 76 ( . Jagannathpur ) (2.80) 0.02 -72.00

JK paper -8.31 0 0 4 . 4

0.00 - .0 6

(-2.38) 7 traction 0 - k

(5.11) 196km 100.37 ( 1.00 -103.47 Zebra (13.72) m (-0.55) (-4.80) DUBURI a r (-11.64) 0.95 eb 94.47

-0.02 0.3km 0.00 (0.00) Z P

m a Rayagada -103.47(-4.80) (13.72) K n Panther 100.37 8

VVC ferro .2 t a h

a TISCO Bamanipal r 69 r Ranasinghpur 0.96 b e br Anandpur e e

e 0.00 Z th r Z an 0.96 ra 0.98 Km Atri P b km 5 , r e - Z 0 -6.45 (-2.22) 1 3 a m 22 e 2 1 r 7 .7 eb K .18 h m 9 Z 5 (- t k -0.00 . 0 4 km 6 .6 (-0.00) GAJAPATI 5 7 n 9.92 K 0 3 ) 5 3 m 9 26 a 1 16.58 .3 2 (-2.56) 6 K . ) P (0.49) P -68.99 m (-8.34)

Ch. Kusumi -9.92 (-0.49) Baripada 7 2 KORAPUT a n ) P 6 2 t 62 an . m h 7 K th traction 2 e BC Mohanty traction 8 m er 4 K r 7 (2.39) - -9.93 1 . Pa ( 6 0.98 . 3 n . 17.33 th a 7 er 4 r -0.00 1 (-0.49) -

-9.92 1 -0.00 5 eb (0.11) ( 6 ) Khurda ) Z . 0 1.01 3 5 7 4 8 9 8 a -51.64 6 . (-0.00) . 4 m a r -6.98 (0.58) -0 0.98 0.00 . k r 8 . ( 9 b b . 9 11 3 6 6 3 e e 6 (3.19) .8 2 K 6k -11.89 (0.00) 2 7 ) 1 Z Z 4 (-1.40) m P ) 8 Arugul Tap ( . m a 0.00 2 7 1 m m nth Tomaka Traction .5 . m (-0.00) 9 k k ( er -1 1 2 8 - ( K ) 0.00 0 3 1. 7 2 . 2 2 P ) 5 r K - 6 5 a 3 . .3 15k 0.00 Argul 7 e P . 47) r 1 0.00 m m a 3 2 (0.00) a - -5.00 3 (-0.00) 0.98 9 b 8. 1 (- n ( 5 n .2 1 e 1 r h Pa 4 ( t n (-1.65) t 0.00 th Maliguda traction t Kalarangi -3 .3 Z e he 0.99 h n r e Jayanagar 72 ) m Nayagarh th (0.00) 0.00 r e - 62 K n a 0.00 14km 1.01 Lakshmipur r . 9 a 0.96 1 6 P 1 . traction 1 -27.81 (- 8 P 0.01 1.01 Meramundali 6 11.87 (0.00) Jayanagar PGCIL -0.00 1.01 0.00 (0.00) 0.00 (0.00) m (0.00) Panther ) k

15.03 ( m 0. 19.85 (-0.20) -0.00 4 K 4 (-0.00) 2 12 0 1 r .8 7 8 (1.04) ) 7 e (-7.09) 2 0.60 -1.20 0.99 / 1.01 7 (1.17) P h Bhanjanagar ( 5 7 .2 ther .7 t . (-0.39) n a n m 0 . 2 a 8 Z 23 P n K a .0 P K 6 m -2.80 e k t m m Kaipadar (0.80) 0

h -414.35 (40.66)

b 0 m k k (0 r e 8 a 17.86 0 4 . 4 r 0 1 Panther 0.98 4

- (3.25) e 0 r (0.00) 5 0.00 8 5 (12.56) (0.00)

0.00 )

. s .

( 9 (-12.99) -50.91 ) e 8

- 0 0 ( 5 (0.00) 6 o -

4 3 0.00 0.00 h 6

t Nimapara

.9 .5 Jayanagar OPTCL 5 o .6

Aditya AL . 18km Panther

n -0.60 (1.37)

8 9 (0.00) Utkal AL (0.00) 5 .00 Balugaon T 5)

) / 4 0

m

1.01 1.01 0.00 -49.82 a 2

( 0.00 . Nilanchal Atri

P n 0.92 8 87.26 (2.22) i (-0.00) -5.00 Bhadrak .74 (-1.64) 0.00 2 X 19.25 MW + 1 X 24 MW ther 19 0.99 w (1.56) an m P 0.00 - T m 53.2k ) 1 Paralakhemundi m 0 5k

.0(50 Manbar traction .0 ) (0.00) r 0 K

) 6 716 m -0 2 8 (4.9 .7( .4 . 2 r 0.93 42.70 e e Z k 8 0 K . 3 X 4 MW+2 X 12.5 MW nth m 5 8 8 0 Pa ) e - )3 1.00 ( h 0 3 40 b -39.86 t CGP 9 .9 . r -44.58 -5.01 (16.72) 9 8 Damanjodi n a 1 1 (2 ) (1.25) -2.83 - ) - BRPL a .66 4 0 2 (30.08) 43.42 4 -0.00 30.95 Balasore 2 2 5 (-13.70) P

K (-0.00) 2 m e - 3 . 1.02 ( . 240.00 r (-2.98) 20.00 5 4 4 e (11.14) ( 4x80MW s Chandpur

IPP 0 . 1 (-30.50) -8.23 e 1 0.98 s 2 9 -3.56 m ( 2 Pan 10.91 3.56 o th h o -34.80 4 5 e ) k (-22.47) . (-1.28) r -43.41 5 t o 1 o . (-4.22) 1 0

1 m n

2 ) 5 (3.25) 4 MESCO m m 8 K Shamuka

0 a m . Upper Kolab Sunabeda (30.50) 3 (-0.85) (4.00) 1 m K 0.00 (1.16) K

3 . 2 1 P n 5 n a - i MSL 7 0.98 er 7 9 i th ( 35.6km n r - a 46.17 0.99 r (0.00) P (-0.16) e 2

nth b 9 w 1.01 m Pa e 0.98 w T T K Z (-0.82)

Meenakshi power m 3.23 -3.23 m 6

m (0.52)

40 K k K (0.00) 3 0.00 -23.60 (-3.07) 1.02 7 .5 Km

. -16.62 (5.31) r HAL 5 10 m Panthe 0 3.42 2.83 -10.92 (0.82) K m r -19.88 r (-4.91) 0.99 r K e (0.57) he 0.00 3 e 7 h (3.74) (-0.38) nt a

-3.56 m 4 h t a r .34 K 3 P (-1.16) 29 t 0 n eb 0.00 Narendrapur (0.00) n .0 a -3.23 Tata steel Z Jajpur road a 5 P3) 20 Km Panther (0.00) Panther P 6 (0.00) Km -47.01 . 0.98 50 Km (0 Machhkund road 67.64 -65.02 8 Km 0.99 7.9 0.00 -3.42 64.69 0.00 Machhkund 0 (-0.57) 13 0.0 (0.00) Kamakhyanagar (5.43) (-4.57) Panther (4.19) -54.78 -134.89 ra 1.03 (0.43) ) Panther traction -69.62 b 54.58 -37.84 (0.00 Panther bra Ze 23.55 1.00 TTPS (-7.82) 45km 6 km Ze er (-15.79) 95. (34.95) (-12.00) (-9.94) m 4 Km Panth (12.80) 148.33 K 12.5 -5.00 -9.92 0 0.00 (0.00) 7 (0.00) (-0.63) -149.89 9 P Duburi 3 X 17 MW+3 X 21.25 MW .8 ) a Meramundali B (-2.97) 4 4 0.00

9 (0.00) n 3 . 6 1 5 2 0.99 /0.98 9 0 t - . ( . h 0 (-16.77) ( 9 4 8 - 8 e 3 K ) K 8 - 55 Jindal steel r Jabmayee ferro alloys . . m . 5 m a 8 9 (3 r 1 0.99 b 0.00 (0.00) 0.99 ) Kolar Z 5 2 X 125 MW e 9 9 Z 4 e . .9 -16.04 (-7.32) 4 5 8 P 5 b 3 ) -5 174.60 + 5.00 m .1 K r -1 4 a (1.64) a 1 ) a K .1 45 m n m r -3 ) 3. 1X13 MW 0.00

9 (0.00) 4 b - 2 (3 (17.45) k a t ( .7 Km r h e (6 78 CGP 7 b e Z 4. 0 e r . ra Jajpur town LEGEND Z eb 2 Padwa traction ) 8.97 Z 9 -134.95 5 5 m .5 ) k 22 1.00 9 (-9.14) 1 . ) 5 2 ( 3 3 -115.00 (-38.66) 6 1 ( (- GENERATION 3 . 4 0 5 2 1 . 5 8 . 3 .3 7 9 5 12. 1 Visa steel - ) 4 ( 1 9 10.55 Km 0.99 HYDRO 1 .1 . 7 8) 0.00 0.00 8 ) - .4 - Zebra 0 5 62 (-5.28) 2 4 ( .75) 64.20 - . -14.40 (6 3 X 25 MW -8 HYDRO-IPP ( Rohit ferro tech ltd IPP 3 6 .5 Duburi new 4 0.99 (27.69) 3 -3 .75 k 3 (-1.94) 0.75 2 Km m 0 1.00 / 0.99 CGP 1 - (-1.36) 30.75 THERMAL 2 P 2 Ze -30.75 0.2km b a 5 ra -64.20 n k (-22.37) m -3 (1.99) (-1.99) Zebra 0 T .20 t Balimela .0 w (2 10 h . e (0 0 in 47 Km THERMAL-IPP . ) r 1.03 00 M Z IPP Balimela PH ) o e eb o s ra (49.44) Vizag s o 1.12 e Maithan ispat 1.03 o 326.02 3. 1 X 30 MW m 20 0.99 THERMAL-CGP (0.00) ( CGP n -1 12.80 i .80) w

T CGP MALKANGIRI , (7.28) SUB STATION

m

K 6 X 60+2 X 75 MW -1 0 96.7 Jakhapura traction 3 ) 2 765 kV 1 8 ) 6 0.98 7 . (- 0 7 2 . 5 3 .2 16.00 5 ( 7 9 400 kV - ) ( 2 (7.87) 2 . 7 13.2 Km .1 2 Panther m 2 r 220 kV k a anthe 7 P

1 -16.00 (-7.87) r 14 6 0.00 m b Km 7

- k

e 9 . Atri 9.4 1 Z 2 4 Z e (0.00) br 3 132 kV 2 0.00 a (3 Samangra (0.00) 9.77) (-46.14) 0.00 (0.00)

-1.20 Pandiabil To upper Sileru TRANSMISSION LINE 19 1.00 0.00 3.12 (36. HVDC 5 79) ( 8 1 6 0 . 0 ) 765 kV 5 0 .0 0 . 0 0 .0 Paradeep 7 Mendhasal 0 7 ( 400 kV ) Gazuwakka Kendrapara Chandikhole 220 kV 132 kV Power Research & Development Consultants Eastern Regional Power Committee Private Limited #5, 11th Cross, 2nd Stage, 14, Golf Club Road, Tollygunge, West of Chord Road, Orissa state existing network (May-17) geographical map Bangalore- 560086, INDIA Kolkata, West Bengal 700033 Ph : +91-080-2319 2209,2159 Fax: +91-080-2319 2210 R0 15.09.2017 E-mail : [email protected] TM APPROVED REVIEWED CHECKED DRAWN DESCRIPTION REVISION DATE REMARKS LOA details: ERPC/PR_DBASE/2016/3567 Dated 30 March 2016 DRAWN IN : MiP-PSCT DWG. NO. : Geographical Power Map\ER\May-2017\Odisha

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

ANNEXURE-III SHORT CIRCUIT STUDY RESULTS

174 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

Table H: State wise 3-Ph and SLG fault results of eastern region grid

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) Bihar 765 10959.80 8.27 8191.12 6.18 1 Sasarm 400 12579.11 18.16 9343.19 13.49 132 1495.93 6.54 1050.17 4.59 765 25201.64 19.02 17724.97 13.38 2 Gaya 400 25089.66 36.21 17925.31 25.87 220 7057.51 18.52 7346.56 19.28 400 15191.80 21.93 12417.52 17.92 3 Purnea_PG 220 7303.11 19.17 7681.78 20.16 220 7142.31 18.74 7204.22 18.91 4 Purnea old_PG 132 3215.38 14.06 3058.58 13.38 400 10972.97 15.84 6769.02 9.77 5 Lakhisarai 132 2207.70 9.66 1533.01 6.71 132 2880.79 12.60 2543.22 11.12 400 13279.94 19.17 10738.05 15.50 6 Muzzafarpur_PG 220 6117.31 16.05 6740.25 17.69 132 1245.01 5.45 1269.94 5.56 400 17000.04 24.54 11716.48 16.91 7 Patna 220 5795.92 15.21 5875.84 15.42 400 13046.79 18.83 12313.58 17.77 8 kishanganj 220 7409.09 19.44 4823.95 12.66 132 2500.60 10.94 2569.25 11.24 400 11142.30 16.08 7578.01 10.94 9 Banka_PG 132 2475.68 10.83 2242.01 9.81 400 17852.17 25.77 15737.71 22.72 10 Barh 132 911.83 3.99 500.78 2.19 400 13061.98 18.85 9381.89 13.54 11 Biharshariff_PG 400 17479.21 25.23 11597.39 16.74 220 7841.71 20.58 7933.47 20.82 220 7719.65 20.26 7612.04 19.98 12 Biharshariff_PG 132 2832.31 12.39 2716.28 11.88 400 15627.27 22.56 13635.32 19.68 13 Kahalgaon_NTPC 400 21048.67 30.38 19576.11 28.26 132 3204.59 14.02 3002.17 13.13 400 7216.40 10.42 5448.44 7.86 14 DMTCL 220 2515.14 6.60 2808.78 7.37 132 1569.72 6.87 1609.80 7.04

175 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 220 1242.92 3.26 761.20 2.00 15 Amnour(Chhapra) 132 622.57 2.72 467.23 2.04 220 1793.04 4.71 1861.84 4.89 16 Motipur 132 1590.11 6.96 1768.65 7.74 220 761.82 2.00 862.24 2.26 17 Mushahri 132 585.98 2.56 750.14 3.28 220 4991.41 13.10 4013.77 10.53 18 Bodhgaya 132 3060.01 13.38 2596.66 11.36 220 3352.58 8.80 2175.52 5.71 19 Dehri 132 2058.02 9.00 1530.39 6.69 220 4030.64 10.58 2782.48 7.30 20 Fatuha 132 2951.24 12.91 2179.83 9.53 220 3132.56 8.22 2301.34 6.04 21 Khagaul 132 1961.22 8.58 1594.23 6.97 220 1452.91 3.81 1059.62 2.78 22 Gopalganj 132 846.84 3.70 729.37 3.19 220 2515.14 6.60 2808.78 7.37 23 Darbhanga 132 1411.66 6.17 1157.12 5.06 220 4438.19 11.65 4373.12 11.48 24 MTPS 132 2293.59 10.03 2246.59 9.83 220 6440.41 16.90 6391.35 16.77 25 Pusauli 132 2326.61 10.18 2156.83 9.43 220 846.19 2.22 445.61 1.17 26 Arrah_PG 132 628.97 2.75 369.41 1.62 220 5903.05 15.49 5496.84 14.43 27 Pusauli New 132 2490.86 10.90 2299.83 10.06 220 5750.37 15.09 5774.68 15.16 28 Sipara 132 3427.44 14.99 3101.30 13.57 29 Madhepura 220 2312.27 6.07 1549.54 4.07 220 2698.07 7.08 1962.25 5.15 30 Hajipur 132 1195.05 5.23 995.63 4.36 220 2982.04 7.83 2428.32 6.37 31 Begusarai 132 2493.81 10.91 2228.28 9.75 220 2213.60 5.81 1937.54 5.09 32 Sonenagar New 132 1466.12 6.41 1610.84 7.05 220 7018.29 18.42 4652.10 12.21 33 Kishnganj New 132 2539.32 11.11 2692.71 11.78 34 Banka 132 1825.09 7.98 1350.02 5.91 35 Kahalgaon 132 2378.33 10.40 1753.55 7.67

176 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 36 Muzzafarpur 132 1731.21 7.57 1312.54 5.74 37 Purnea 132 3179.23 13.91 2972.71 13.00 38 Sugauli 132 508.35 2.22 303.92 1.33 39 Lauriya 132 299.22 1.31 160.64 0.70 40 Sone nagar 132 1454.82 6.36 1566.69 6.85 41 Karmansa 132 1098.85 4.81 690.99 3.02 42 Jehanabad 132 612.07 2.68 315.44 1.38 43 Rafiganj 132 702.80 3.07 372.03 1.63 44 Hathidah 132 1619.96 7.09 963.30 4.21 45 Jamui 132 1542.34 6.75 1278.59 5.59 46 Sheikhpura 132 548.12 2.40 318.88 1.40 47 Nawada 132 752.37 3.29 429.12 1.88 48 Jamalpur 132 653.35 2.86 355.54 1.56 49 Sultanganj 132 1058.05 4.63 647.49 2.83 50 Sabour 132 1133.97 4.96 706.03 3.09 51 Dumraon 132 302.67 1.32 136.18 0.60 52 Jakkanpur 132 2269.55 9.93 1596.18 6.98 53 Saharsa 132 2854.54 12.49 2398.69 10.49 54 Khagaria 132 530.76 2.32 291.51 1.28 55 Sitamarhi 132 311.24 1.36 344.90 1.51 220 1599.05 4.20 1470.20 3.86 56 Samastipur new 132 1410.07 6.17 1422.94 6.22 57 Pandauli 132 733.67 3.21 454.45 1.99 58 Hajipur New 132 1205.48 5.27 1022.63 4.47 59 Chhapra 132 527.64 2.31 282.40 1.24 60 Siwan 132 369.36 1.62 214.96 0.94 61 Motihari 132 578.98 2.53 355.77 1.56 62 Betiah 132 497.78 2.18 307.89 1.35 63 Ramnagar 132 322.36 1.41 174.07 0.76 64 Rajgir 132 277.98 1.22 127.95 0.56 65 Darbhanga New 132 1569.72 6.87 1609.80 7.04 66 Katihar 132 995.11 4.35 580.33 2.54 67 Belaganj 132 1101.64 4.82 616.33 2.70 68 Vaishali 132 1282.20 5.61 837.29 3.66 69 Sitalpur 132 1120.60 4.90 720.95 3.15 70 Dhaka 132 434.01 1.90 252.25 1.10 71 Jainagar 132 778.32 3.40 524.23 2.29 72 Madhubani 132 773.77 3.38 501.18 2.19 73 Phulparas 132 1500.15 6.56 936.75 4.10

177 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 74 Supaul 132 1577.81 6.90 994.59 4.35 75 Mohania 132 2115.58 9.25 1591.23 6.96 76 Bikramganj 132 641.42 2.81 355.84 1.56 77 Forbeshganj 132 1596.34 6.98 1001.78 4.38 78 Udakishanganj 132 409.05 1.79 217.32 0.95 79 Baripahari 132 2430.65 10.63 2052.86 8.98 132 1418.16 6.20 1412.33 6.18 80 Samastipur 132 1367.80 5.98 1315.22 5.75 81 Banjari 132 719.07 3.15 404.39 1.77 82 KCL 132 700.97 3.07 392.98 1.72 83 Kataiya 132 1368.03 5.98 807.28 3.53 84 Barauni TPS 132 2367.81 10.36 2372.29 10.38 85 Surajpur 132 187.42 0.82 91.19 0.40 86 Kudra 132 1458.75 6.38 894.93 3.91 87 Chandauti 132 2354.15 10.30 1563.34 6.84 88 Kochas 132 744.54 3.26 405.25 1.77 89 Balmikinagar 132 194.34 0.85 95.13 0.42 90 Masaurhi 132 1134.57 4.96 644.57 2.82 91 Bihta 132 1466.76 6.42 1017.99 4.45 92 Gaighat 132 1114.66 4.88 620.65 2.72 93 Mithapur 132 2177.56 9.52 1513.78 6.62 94 Rafiganj_R 132 676.52 2.96 357.37 1.56 95 Arrah 132 609.20 2.67 354.61 1.55 96 Lakhisarai_ 132 1680.56 7.35 1065.33 4.66 97 Raxaul 132 342.63 1.50 194.52 0.85 98 Runisaudpur 132 678.79 2.97 447.75 1.96 99 SKMCH 132 1591.16 6.96 1271.30 5.56 100 Buxar 132 267.83 1.17 118.52 0.52 101 Aurangabad 132 1068.99 4.68 877.99 3.84 102 Tekari 132 887.99 3.88 482.24 2.11 103 Goh 132 600.02 2.62 312.75 1.37 104 Arwal 132 429.32 1.88 215.14 0.94 105 Hulasganj 132 707.64 3.10 400.31 1.75 106 Wajirganj 132 960.81 4.20 549.56 2.40 107 Nalanda 132 255.35 1.12 123.98 0.54 108 Ekanagarsarai 132 938.51 4.11 554.61 2.43 109 Digha 132 1428.99 6.25 980.75 4.29 110 Katra 132 1340.45 5.86 777.35 3.40 111 Gangawara 132 1038.02 4.54 723.43 3.16

178 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 112 Madhepura 132 1925.25 8.42 1348.30 5.90 113 Sonbarsa 132 580.65 2.54 316.74 1.39 114 Mashrakh 132 370.59 1.62 214.61 0.94 115 Dalsingsarai 132 819.23 3.58 757.17 3.31 116 Kusheshwarnath 132 507.51 2.22 277.66 1.21 117 Jagdispur 132 450.18 1.97 248.35 1.09 118 harbauth 132 964.88 4.22 567.77 2.48 119 Jandaha 132 516.44 2.26 388.02 1.70 120 Imamganj 132 608.60 2.66 330.49 1.45 121 Tetha 132 1277.53 5.59 736.69 3.22 122 Benipati 132 714.90 3.13 536.30 2.35 123 Sheohar 132 265.71 1.16 348.68 1.53 124 Mahanar 132 258.82 1.13 293.61 1.28 125 Belsand 132 953.33 4.17 726.85 3.18 126 Sherghati 132 656.88 2.87 359.24 1.57 127 Paharpur 132 1348.07 5.90 818.65 3.58 128 Ekma 132 277.54 1.21 151.37 0.66 129 Rail Pahiya karkhana 132 770.03 3.37 454.20 1.99 130 Ekma Tap 132 278.71 1.22 152.13 0.67 131 Jhanjha_R 132 981.40 4.29 655.84 2.87 132 Hathidah_R 132 1167.04 5.10 658.85 2.88 133 Khagaul_R 132 1909.54 8.35 1525.49 6.67 134 Khusrupur 132 1965.45 8.60 1247.37 5.46 135 Arrah_R 132 576.33 2.52 332.15 1.45 136 Mokama_R 132 999.30 4.37 553.97 2.42 137 Dumraon_R 132 298.35 1.31 134.42 0.59 138 Hajipur_R 132 1131.68 4.95 909.64 3.98 139 Chhapra_R 132 517.81 2.27 276.78 1.21 140 Kudra_R 132 1497.69 6.55 1053.10 4.61 141 Harinagar sugar mill 132 303.58 1.33 163.17 0.71 142 Karbigahiya 132 2192.34 9.59 1520.30 6.65 143 JahanTrc 132 605.39 2.65 311.90 1.36 144 ShreeCem 132 1010.07 4.42 800.77 3.50 145 Naugachia 132 761.85 3.33 409.06 1.79 146 Beniapatti 132 753.73 3.30 554.08 2.42 147 Hathua 132 565.67 2.47 549.91 2.41 148 Pupri 132 702.83 3.07 522.88 2.29 149 Narkatiyaganj 132 349.74 1.53 201.66 0.88 150 Banmakhi 132 3006.06 13.15 2651.11 11.60

179 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 151 Tarapur 132 706.23 3.09 401.88 1.76 152 Triveniganj 132 1066.21 4.66 610.53 2.67 Jharkhand 765 19182.36 14.48 13913.94 10.50 153 Ranchi New_PG 400 25528.12 36.85 17053.52 24.62 400 21492.62 31.02 18124.77 26.16 154 Jamshedpur_PG 220 6253.98 16.41 6462.76 16.96 400 20514.75 29.61 15608.85 22.53 155 Maithon 400 16325.37 23.56 12197.49 17.61 220 11142.92 29.24 10717.30 28.13 156 MPL 400 16963.52 24.49 15579.03 22.49 400 17297.36 24.97 11455.21 16.53 157 Chaibasa_PG 220 3903.03 10.24 3500.94 9.19 400 17899.94 25.84 14568.26 21.03 158 Koderma_D 220 3921.62 10.29 4020.61 10.55 132 1978.45 8.65 1985.52 8.68 159 BTPS_DVC 400 9314.92 13.45 8809.60 12.72 400 23069.60 33.30 15537.20 22.43 160 Ranchi_PG 220 6458.91 16.95 6510.28 17.09 161 Chandawa 400 16657.96 24.04 9644.84 13.92 162 Adhunik 400 21401.73 30.89 18046.21 26.05 400 10835.36 15.64 8484.52 12.25 163 TISCO 132 4866.44 21.29 5519.23 24.14 220 6248.92 16.40 6444.26 16.91 164 Ramchandrapur 132 2627.35 11.49 2440.60 10.68 220 4603.10 12.08 3295.26 8.65 165 Chandil 132 2956.76 12.93 2360.93 10.33 220 4499.14 11.81 3613.34 9.48 166 Hatia New 132 2677.21 11.71 2323.89 10.16 220 3766.77 9.89 3222.04 8.46 167 PTPS 132 2054.91 8.99 1794.85 7.85 168 TTPS 220 3382.49 8.88 3861.81 10.14 220 1708.98 4.49 1200.56 3.15 169 Lalmatia 132 1974.06 8.63 1314.18 5.75 220 3859.32 10.13 3438.60 9.02 170 Chaibasa 132 1560.62 6.83 1487.09 6.50 220 3253.73 8.54 2058.83 5.40 171 Dumka 132 1772.59 7.75 1377.45 6.03 172 CTPS old 220 8517.27 22.35 8301.23 21.79

180 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 132 5765.89 25.22 6034.31 26.39 220 10919.55 28.66 9895.70 25.97 173 Kalyanaswari 132 4509.84 19.73 4887.79 21.38 220 2589.91 6.80 2138.07 5.61 174 Jamshedpur_D 132 2053.33 8.98 2110.24 9.23 220 8185.07 21.48 8592.76 22.55 175 BTPS_D 132 2295.92 10.04 2253.82 9.86 176 CTPS New 220 8863.15 23.26 8934.00 23.45 220 4302.60 11.29 3564.03 9.35 177 Giridih 132 2131.22 9.32 2277.54 9.96 220 6684.89 17.54 5646.07 14.82 178 Dhanbad_D 132 1015.46 4.44 988.04 4.32 220 3394.08 8.91 2987.61 7.84 179 Ramgarh 132 2301.25 10.07 2045.84 8.95 180 Garwah 132 880.19 3.85 810.14 3.54 181 Lahardaga 132 986.10 4.31 614.01 2.69 182 Gumla 132 700.72 3.07 397.12 1.74 183 Kamdara 132 721.75 3.16 399.64 1.75 184 Hatia old 132 2658.73 11.63 2290.30 10.02 185 Namkum 132 1344.29 5.88 882.21 3.86 186 Jmatara 132 1045.25 4.57 586.09 2.56 187 Deoghar 132 704.92 3.08 633.35 2.77 188 Dumka 132 1742.85 7.62 1344.04 5.88 189 Goelkhera 132 517.24 2.26 279.77 1.22 190 Kendposi 132 1069.61 4.68 987.77 4.32 191 Manique 132 1455.65 6.37 955.67 4.18 192 Adityapur 132 2568.16 11.23 2074.49 9.07 193 Golmuri 132 1429.48 6.25 857.23 3.75 194 Jaduguda 132 809.99 3.54 441.74 1.93 195 Rajkharsawa 132 1637.30 7.16 1085.71 4.75 196 Noamundi 132 8.45 0.04 8.45 0.04 197 Sikidiri 132 1527.32 6.68 1503.52 6.58 198 Chakradharpur 132 874.57 3.83 497.56 2.18 199 Bakaspur 132 572.96 2.51 310.39 1.36 200 Kanke 132 1486.89 6.50 1038.49 4.54 201 Chaibasa 132 1198.51 5.24 804.05 3.52 202 Latehar 132 590.29 2.58 346.01 1.51 203 Japla 132 802.51 3.51 536.30 2.35 204 Sahebganj 132 594.54 2.60 320.99 1.40

181 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 205 Pakur 132 375.96 1.64 195.09 0.85 206 Hazaribag 132 850.40 3.72 541.80 2.37 207 Daltonganj 132 404.65 1.77 229.92 1.01 208 Kendposi FD 132 1017.40 4.45 902.46 3.95 209 Tamar 132 652.06 2.85 354.30 1.55 210 Madhupur 132 621.34 2.72 331.69 1.45 211 Manoharpur 132 460.06 2.01 246.67 1.08 212 ECR-Gomia 132 1939.77 8.48 1648.86 7.21 213 Patratu 132 1265.41 5.54 1009.23 4.41 214 Mosabani 132 1168.35 5.11 965.50 4.22 215 Maithon 132 4375.29 19.14 4490.26 19.64 216 Kumardubi 132 3162.10 13.83 2679.39 11.72 217 Panchet 132 2720.39 11.90 2066.48 9.04 218 Patherdih 132 3152.53 13.79 2002.63 8.76 219 Putki 132 3993.24 17.47 2857.44 12.50 220 Nimiaghat 132 1968.47 8.61 1822.78 7.97 221 Barhi 132 1693.97 7.41 1440.38 6.30 222 Koderma 132 1388.62 6.07 1160.15 5.07 223 Konar 132 1321.36 5.78 994.55 4.35 224 North karanpur_D 132 846.81 3.70 561.06 2.45 220 2497.19 6.55 2174.02 9.51 225 Gola 132 2696.33 11.79 637.41 2.79 226 Hazaribag 132 975.34 4.27 1477.91 6.46 227 Ramkanali_D 132 2069.99 9.05 978.55 4.28 228 Manique_D_SW 132 1481.75 6.48 2204.24 9.64 229 Balihari_D 132 3841.82 16.80 1625.70 4.27 230 Electrosteel_D 220 2530.32 6.64 3934.14 10.32 231 BSL_D 220 5196.15 13.64 1225.04 5.36 232 HEC 132 1776.92 7.77 1668.89 7.30 233 APL 132 2108.86 9.22 985.01 4.31 234 JSPL 132 1246.31 5.45 3627.14 15.87 235 Mal-Impex 132 3893.67 17.03 1735.71 7.59 236 Sindri_SW 132 2812.78 12.30 947.35 4.14 237 Pkant_D 132 1679.62 7.35 2508.65 10.97 238 Rajbera_D 132 3465.73 15.16 843.20 3.69 239 Sermuri_D 132 1363.01 5.96 633.60 2.77 240 Gobindpur_D 132 792.70 3.47 869.07 3.80 241 Lodhma_R 132 1372.51 6.00 690.72 3.02 242 Chakradharpur_R 132 1145.43 5.01 764.61 3.34

182 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 243 Dalbhumgarh_R 132 1010.66 4.42 540.02 2.36 244 Titisoloi_R 132 907.53 3.97 474.98 2.08 245 Shankarpur_R 132 594.41 2.60 513.94 2.25 246 Jamtara_R 132 928.70 4.06 862.21 3.77 247 RKSNR_R 132 1370.65 6.00 618.79 2.71 248 Tolra_R 132 753.86 3.30 824.11 3.61 249 Manique_R 132 1297.48 5.68 737.61 3.23 250 Dalbhumgarh_R 986.73 4.32 132 251 ECR-Barkakhana_D 529.07 2.31 132 252 ECRRky_D 809.78 3.54 132 253 BSL_D 1769.18 7.74 132 254 Usha Martin 132 2323.03 10.16 728.51 3.19 255 Usha Martin 132 1158.87 5.07 6036.00 26.40 256 CTPS 132 5765.10 25.22 8062.57 221.66 257 ECRLY_DVC 132 1270.01 5.56 695.10 3.04 258 GoelkheraT 132 504.71 2.21 272.47 1.19 Odisha 765 33803.43 25.51 26820.85 20.24 259 Angul_PG 400 36101.97 52.11 29721.63 42.90 765 30205.11 22.80 20001.43 15.10 260 Jharsuguda_PG 400 22422.74 32.36 15064.27 21.74 400 8812.36 12.72 6697.34 9.67 261 Jaypore_PG 220 7087.97 18.60 7039.06 18.47 262 Indravati_PG 400 6656.51 9.61 5650.34 8.16 263 Indravati_Hdro 400 6535.76 9.43 5698.38 8.23 400 20176.11 29.12 16174.27 23.35 264 Rengali_PG 220 8679.31 22.78 8719.97 22.88 265 GMR_3rd 400 21635.12 31.23 16850.08 24.32 400 30263.38 43.68 31960.70 46.13 266 STPS 220 11725.40 30.77 11244.74 29.51 400 23858.88 34.44 15584.46 22.49 267 Bisra 220 7524.14 19.75 7387.18 19.39 400 12729.54 18.37 10217.98 14.75 268 Baripada 220 6271.78 16.46 6791.79 17.82 132 1929.16 8.44 2089.65 9.14 400 33085.21 47.75 28272.26 40.81 220 9076.20 23.82 8484.05 22.27 269 Meramundali 132 2572.91 11.25 2446.35 10.70 220 13069.98 34.30 13003.50 34.13

183 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 400 8366.67 12.08 7933.12 11.45 270 Sterlite 400 8366.65 12.08 7932.99 11.45 220 9023.09 23.68 8095.18 21.24 400 12880.69 18.59 9832.76 14.19 280 Dubri New 220 8337.45 21.88 8974.15 23.55 400 6138.97 8.86 4765.11 6.88 281 Keonjhar 220 2830.37 7.43 3054.97 8.02 400 4685.74 6.76 3895.69 5.62 282 Bolangir 220 3560.02 9.34 3759.53 9.87 283 IndBharat 400 50.63 0.07 42.86 0.06 284 JITPL 400 13847.97 19.99 14106.89 20.36 285 GMR_4 400 21257.37 30.68 17537.78 25.31 400 8633.13 12.46 6853.08 9.89 286 Mendhasal 220 5292.20 13.89 5830.55 15.30 132 1218.21 5.33 1375.18 6.02 287 JSPL 400 17268.04 24.92 15572.79 22.48 288 Pandibil 400 8360.49 12.07 6156.04 8.89 220 5746.17 15.08 4416.54 11.59 289 RSP 132 1023.43 4.48 1271.89 5.56 220 7024.32 18.43 7473.61 19.61 290 Balimela 220 7107.37 18.65 7628.53 20.02 291 Upper Kolab 220 6762.76 17.75 6768.21 17.76 292 Usileru 220 8143.45 21.37 6641.05 17.43 220 7584.97 19.91 7602.26 19.95 132 2297.67 10.05 2440.23 10.67 293 Jaynagar 132 2326.84 10.18 2415.64 10.57 220 6037.45 15.84 5102.17 13.39 220 5550.83 14.57 4445.84 11.67 294 Therunali 132 1530.15 6.69 1474.15 6.45 220 3672.19 9.64 3041.68 7.98 295 Bhanjanagar 132 1481.89 6.48 1657.89 7.25 296 Indravati 220 6570.12 17.24 7404.75 19.43 297 Nayagarh 220 2228.52 5.85 1927.55 5.06 220 5123.77 13.45 5489.59 14.41 298 Chandaka 132 4176.22 18.27 4666.20 20.41 132 3989.86 17.45 3950.25 17.28 220 9699.86 25.46 9034.21 23.71 299 TTPS 132 3956.91 17.31 4481.96 19.60

184 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 220 7557.69 19.83 6573.81 17.25 300 Tarkera 132 3702.02 16.19 3953.32 17.29 220 7653.99 20.09 7632.85 20.03 301 Duburi 132 2571.28 11.25 2671.95 11.69 220 3402.05 8.93 2733.01 7.17 302 Joda 132 2209.13 9.66 2139.16 9.36 303 Chandiposh 220 3467.35 9.10 2219.51 5.83 220 3321.40 8.72 2988.00 7.84 304 Balasore 132 1416.79 6.20 1680.63 7.35 220 3053.89 8.01 2785.94 7.31 305 Bidanasi 132 3899.39 17.06 3789.73 16.58 306 Barkote 220 3270.71 8.58 2590.12 6.80 220 14262.63 37.43 13967.80 36.66 307 Budhipadar 132 4808.35 21.03 4770.73 20.87 220 5010.10 13.15 3981.05 10.45 308 Katapali 132 4500.14 19.68 4078.95 17.84 220 998.07 2.62 1131.78 2.97 309 Narendrapur 132 781.46 3.42 997.74 4.36 220 3394.63 8.91 3468.56 9.10 310 Bolangir New 132 1569.71 6.87 1803.91 7.89 220 3893.91 10.22 3688.06 9.68 311 Atri 132 1538.84 6.73 1596.97 6.99 220 3080.82 8.09 2702.21 7.09 312 Samangara 132 1379.22 6.03 1416.46 6.20 220 2536.35 6.66 2351.54 6.17 313 Bhadrak 132 1432.23 6.26 1727.47 7.56 220 1951.94 5.12 1825.44 4.79 314 Paradip 132 1338.31 5.85 1546.02 6.76 315 Lakshmipur 220 4144.89 10.88 3028.23 7.95 220 7791.86 20.45 6044.03 15.86 316 Lapanga 132 5092.37 22.27 4419.96 19.33 317 MSL 220 6297.28 16.53 5591.18 14.67 220 3028.70 7.95 2753.77 7.23 318 Cuttack 132 1427.13 6.24 1498.52 6.55 319 Basundhara 132 2710.07 7.11 1654.83 4.34 320 Bangaripusi 132 850.56 3.72 649.39 2.84 321 BPPL 132 3536.87 15.47 3140.98 13.74 322 Damanjodi 132 664.47 2.91 389.94 1.71 323 Chatrapur 132 682.19 2.98 841.69 3.68

185 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 324 IRE 132 651.61 2.85 753.82 3.30 325 Aska 132 931.88 4.08 1077.01 4.71 326 Berhampur 132 727.05 3.18 911.27 3.99 327 Ganjam 132 568.67 2.49 615.83 2.69 328 Mohana 132 469.85 2.06 513.16 2.25 329 Phulbani 132 356.59 1.56 419.23 1.83 330 Balugaon 132 348.54 1.52 419.01 1.83 331 Khurda 132 994.66 4.35 1140.11 4.99 332 Puri 132 917.79 4.01 1076.30 4.71 333 Nimapada 132 562.47 2.46 675.16 2.95 334 Bhubaneswar 132 3280.88 14.35 3391.11 14.83 335 Chowdhwar 132 3403.15 14.89 3312.75 14.49 336 Dhenkanal 132 1302.63 5.70 1337.86 5.85 337 Chainpal 132 3515.99 15.38 3698.16 16.18 338 Angul 132 2389.75 10.45 2268.53 9.92 339 Nandira (MCL) 132 1477.95 6.46 1043.45 4.56 340 Nuapatna 132 493.22 2.16 557.42 2.44 341 BAMINPL 132 1128.48 4.94 726.95 3.18 342 Jajpur Road 132 1841.14 8.05 1886.50 8.25 343 Kendrapara 132 954.10 4.17 1128.71 4.94 344 Jaleswar 132 476.35 2.08 554.75 2.43 345 Baripada 132 1291.87 5.65 1382.34 6.05 346 Rairangpur 132 613.05 2.68 631.53 2.76 347 Palapanga 132 782.93 3.42 848.54 3.71 348 Nalda_R 132 562.81 2.46 449.19 1.97 349 Rourkela 132 3475.96 15.20 3602.05 15.76 350 Grid_Steel 132 3296.95 14.42 3245.29 14.19 351 Jharsuguda 132 2950.92 12.91 2790.54 12.21 352 Brajrajnagar 132 2052.06 8.98 1787.68 7.82 353 Rajgangpur 132 2439.71 10.67 2391.54 10.46 354 Sambalpur 132 2494.79 10.91 2181.43 9.54 355 Burla 132 5239.96 22.92 5204.50 22.76 356 Somnathpur 132 90.08 0.39 115.93 0.51 357 Bolangir 132 1569.71 6.87 1803.91 7.89 358 Saintala 132 889.13 3.89 743.80 3.25 359 Khariar 132 341.75 1.50 432.01 1.89 360 Tentulikhunti 132 571.87 2.50 598.89 2.62 361 Kalugaon 132 1899.76 8.31 1666.17 7.29 362 Dighapahari 132 514.55 2.25 594.18 2.60

186 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 363 Jagatsinghpur 132 473.09 2.07 507.65 2.22 364 Marshaghai 132 900.47 3.94 958.54 4.19 365 Rairakhol 132 776.52 3.40 621.33 2.72 366 FAP_Joda 132 2152.98 9.42 2035.62 8.90 367 Junagarh 132 291.10 1.27 358.39 1.57 368 Sundargarh 132 1771.14 7.75 1424.91 6.23 369 Boinda 132 962.47 4.21 850.60 3.72 370 Chend 132 2992.67 13.09 2954.42 12.92 371 Chandikhol 132 532.24 2.33 587.27 2.57 372 Umerkote 132 255.69 1.12 299.20 1.31 373 Soro 132 655.28 2.87 723.15 3.16 374 Pattamundai 132 657.89 2.88 703.71 3.08 375 Akhusingarh 132 424.50 1.86 456.19 2.00 376 HMSwitch(Kharagprasad) 132 391.80 1.71 453.48 1.98 377 Paralakhemundi 132 236.68 1.04 275.98 1.21 378 Sonepur 132 496.26 2.17 560.46 2.45 379 Ranasinghpur 132 1224.41 5.36 1339.50 5.86 380 Kalrangi 132 772.45 3.38 711.35 3.11 381 Kamakhyanagar 132 1122.25 4.91 952.84 4.17 382 Jajpur 132 620.51 2.71 720.74 3.15 383 Bolani 132 950.17 4.16 772.60 3.38 384 Sunabeda 132 722.16 3.16 700.53 3.06 385 Patnagarh 132 630.88 2.76 715.65 3.13 386 Padampur 132 376.23 1.65 365.88 1.60 387 Bolangir 132 1506.50 6.59 1707.56 7.47 388 EMAMI 132 90.35 0.40 116.44 0.51 389 Salepur 132 548.38 2.40 565.22 2.47 390 Balugaon_T 132 266.67 1.17 305.05 1.33 391 Bargarh 132 960.73 4.20 1091.37 4.77 392 Phulnakhara 132 1531.09 6.70 1311.39 5.74 393 Karanjia 132 504.81 2.21 528.83 2.31 394 Banki 132 899.62 3.94 827.77 3.62 132 716.01 3.13 832.97 3.64 395 Kesinga 132 716.77 3.14 816.97 3.57 396 Mania 132 1189.10 5.20 951.24 4.16 397 Anandpur 132 1114.31 4.87 1017.59 4.45 398 Barpali 132 469.14 2.05 517.31 2.26 399 Bansapanai 132 1910.54 8.36 1639.72 7.17 400 Barbil 132 631.45 2.76 543.14 2.38

187 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 401 Saliban 132 368.97 1.61 395.14 1.73 402 Purushottampur 132 603.46 2.64 578.31 2.53 403 Chandipur 132 275.50 1.21 329.10 1.44 404 konark 132 441.13 1.93 496.00 2.17 405 Samuka 132 649.35 2.84 716.95 3.14 406 Arugul 132 1143.23 5.00 1000.54 4.38 407 Nuapara 132 207.97 0.91 253.32 1.11 408 Dabugaon 132 357.09 1.56 371.21 1.62 409 Boudh 132 307.92 1.35 311.57 1.36 410 kuchinda 132 1048.83 4.59 861.71 3.77 411 Bhawanipatna 132 401.53 1.76 448.13 1.96 412 Kalarangi Tap 132 1017.21 4.45 833.66 3.65 413 Kesura 132 684.15 2.99 725.42 3.17 414 Rengali_PH_G 220 8949.40 23.49 8547.36 22.43 415 PPL 132 1122.38 4.91 1063.49 4.65 416 ITPS 220 9042.80 23.73 8496.04 22.30 417 NINL 220 5762.35 15.12 5124.74 13.45 418 Bhusan Steel 220 9320.36 24.46 9011.53 23.65 419 TSIL 220 2851.55 7.48 2215.87 5.82 420 Jindal Steel 220 7464.62 19.59 7606.52 19.96 421 VISA 220 5016.76 13.17 4267.12 11.20 422 Rohit ferro 220 6253.72 16.41 5474.62 14.37 423 SPS 220 7736.62 20.30 5648.63 14.82 424 Veda_G 220 11645.72 30.56 12652.20 33.20 425 NALCO 220 11547.26 30.30 12347.23 32.40 426 BSSL 220 11948.87 31.36 11580.09 30.39 427 JSPL 220 2820.42 7.40 2055.25 5.39 428 Tata Steel 220 7321.37 19.21 7087.26 18.60 429 ESSAR 220 1818.49 4.77 1626.68 4.27 430 IOCL 220 1772.85 4.65 1562.58 4.10 431 BPRL 132 2072.26 9.06 1772.65 7.75 432 MSL 132 1664.66 7.28 1245.96 5.45 433 IMFA 132 1429.05 6.25 1294.34 5.66 434 ICCL 132 3224.77 14.11 3398.12 14.86 435 FCI 132 2226.28 9.74 1656.36 7.25 436 FACOR 132 1370.40 5.99 1592.24 6.96 437 Balasore Alloy 132 1184.10 5.18 1138.45 4.98 438 Birla Tyr 132 1290.47 5.64 1358.14 5.94 439 Hindalco 132 4714.92 20.62 5180.41 22.66

188 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 440 Chiplima 132 3539.25 15.48 2955.38 12.93 441 ACC 132 911.90 3.99 992.43 4.34 442 CTC 132 3044.96 13.32 2919.70 12.77 443 SGEL 132 385.02 1.68 435.18 1.90 444 Action Ispath 132 2834.79 12.40 2706.81 11.84 445 L&T Cemco 132 1900.76 8.31 1363.13 5.96 446 PowerMax 132 572.91 2.51 527.17 2.31 447 OCL 132 2386.20 10.44 2313.72 10.12 448 ARATI 132 1526.78 6.68 1472.70 6.44 449 SamalMtl 132 388.28 1.70 443.87 1.94 450 NBVL 132 393.77 1.72 458.97 2.01 451 MCL 132 2076.37 9.08 1316.49 5.76 452 HindMetals 132 390.08 1.71 448.77 1.96 453 OPTCL 132 1592.51 6.97 1183.05 5.17 454 BC_Monty 132 1732.39 7.58 1324.05 5.79 455 Tomka_Tr 132 1163.31 5.09 756.18 3.31 456 JKPaper 132 1136.78 4.97 878.76 3.84 457 IFFCO 132 1230.68 5.38 1385.73 6.06 458 HAL 132 713.53 3.12 684.48 2.99 459 PPT 132 1081.27 4.73 990.83 4.33 460 Vedanta 132 1016.43 4.45 1074.61 4.70 461 Rungta 132 1770.81 7.75 1307.36 5.72 462 BRG 132 2120.50 9.28 1733.58 7.58 463 Machakunda 132 1170.09 5.12 1237.31 5.41 464 Machakunda Road_SW 132 489.01 2.14 273.95 1.20 465 Maheshwari 132 1612.16 7.05 1275.78 5.58 466 RAWMET 132 1591.60 6.96 1091.69 4.78 467 ShyamDRI 132 2485.35 10.87 1933.31 8.46 468 AryanISt 132 3583.40 15.67 2723.79 11.91 469 Rathi 132 2491.14 10.90 1732.72 7.58 470 Sriganesh 132 1302.95 5.70 979.58 4.29 471 Arya 132 745.03 3.26 612.87 2.68 472 BRP_St 132 641.71 2.81 484.80 2.12 473 Menaksh 132 665.95 2.91 584.19 2.56 474 MSP 132 459.15 2.01 440.89 1.93 475 OCL_TA 132 1038.48 4.54 828.60 3.62 476 B-Rtap 132 0.26 0.00 0.21 0.00 477 Basta 132 768.45 3.36 788.55 3.45 478 SMC 132 2413.96 10.56 1755.21 7.68

189 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 479 JambyFe 132 2114.72 9.25 1619.85 7.09 480 BEEKAY 132 472.93 2.07 344.84 1.51 481 Rajgangpur_R 132 2299.37 10.06 2135.43 9.34 482 Rambha_R 132 463.95 2.03 388.72 1.70 483 Solari_R 132 309.64 1.35 321.97 1.41 484 Kaipada_R 132 776.92 3.40 686.21 3.00 485 Jhakpur_R 132 1427.42 6.24 996.62 4.36 486 Bhadrak_R 132 1117.04 4.89 1019.40 4.46 487 Balasore-R 132 1267.75 5.55 1307.76 5.72 488 Jaleswar_R 132 465.74 2.04 526.78 2.30 489 Bhulta_R 132 395.24 1.73 268.18 1.17 490 Nuagaon_R 132 836.01 3.66 484.49 2.12 491 Jharsuguda_R 132 2920.25 12.77 2735.97 11.97 492 Kendrapara_R 132 2482.18 10.86 1918.09 8.39 493 Jornda_R 132 811.63 3.55 597.27 2.61 494 Meramundali_R 132 387.80 1.70 442.60 1.94 495 Jagannath_R 132 773.77 3.38 972.79 4.26 496 JayNagar_R 132 2233.69 9.77 2297.48 10.05 497 Padwa_R 132 395.89 1.73 216.84 0.95 498 Manbar_R 132 866.88 3.79 537.15 2.35 499 MalinG_R 132 1370.09 5.99 991.73 4.34 500 CHKSM-R 132 1088.45 4.76 720.18 3.15 501 Dhmraptr_R 132 445.39 1.95 270.24 1.18 502 Dhmra_R 132 646.35 2.83 435.27 1.90 503 Goreknath_R 132 399.52 1.75 363.97 1.59 504 Bamra_R 132 0.26 0.00 0.21 0.00 505 Keonjhor_R 132 573.39 2.51 473.97 2.07 West Bengal

400 9690.07 13.99 9215.96 13.30 506 Jeerat 220 7925.99 20.80 9025.67 23.69 132 4143.21 18.12 4796.39 20.98 400 15454.41 22.31 12923.45 18.65 507 Arambag 220 9648.25 25.32 10495.71 27.54 132 3304.49 14.45 4054.99 17.74 508 Durgapur 400 13201.12 19.05 11460.11 16.54 400 12146.99 17.53 10037.42 14.49 509 Kharagpur 220 6149.64 16.14 6827.84 17.92 132 1807.98 7.91 2144.34 9.38 510 Raghunathpur 400 14393.43 20.78 12833.76 18.52

190 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 511 Purullia pump storage 400 13386.38 19.32 12570.58 18.14 400 15229.95 21.98 12329.91 17.80 512 Bidhannagar 220 9596.50 25.18 10410.48 27.32 132 3399.15 14.87 4120.62 18.02 400 12707.42 18.34 12322.64 17.79 513 Kolaghat 220 5601.63 14.70 6360.31 16.69 132 3184.60 13.93 3858.33 16.88 8886.64 12.83 8756.59 12.64 514 Bakreswar 400 220 9925.43 26.05 10834.88 28.43 400 18390.99 26.55 17393.50 25.11 515 sagardighi 220 6623.50 17.38 6949.42 18.24 516 Haldia 400 6023.85 8.70 6236.07 9.00 400 13905.08 20.07 9744.27 14.07 400 15223.38 21.97 12077.35 17.43 517 Parulia 220 9025.47 23.69 9411.62 24.70 220 9025.51 23.69 9411.89 24.70 400 16869.33 24.35 12736.29 18.38 518 Malda 220 5271.88 13.84 5757.85 15.11 132 2060.14 9.01 2529.82 11.07 519 17609.12 25.42 14378.21 20.75 Binaguri 400 6601.39 17.32 6809.04 17.87 220 520 400 7612.53 10.99 8188.35 11.82 Subhasgarm_PG 6310.44 16.56 7845.37 20.59 220 521 Gokarna 400 9660.93 13.94 7615.30 10.99 522 Mejia 400 14711.91 21.24 13681.97 19.75 400 30659.76 44.25 30596.02 44.16 523 Farakka 220 4846.40 12.72 5436.12 14.27 400 14626.65 21.11 8959.07 12.93 524 Alipurduar PG 220 7084.48 18.59 6522.35 17.12 220 2139.68 5.62 1574.61 4.13 525 Vidyasagar Park 132 1738.85 7.61 1371.88 6.00 526 Sadaipur 220 8591.81 22.55 7965.11 20.90 220 5455.14 14.32 4920.50 12.91 527 Dharampur 132 4743.77 20.75 4575.64 20.01 220 4941.00 12.97 4786.77 12.56 528 Domjur 132 3640.13 15.92 4189.15 18.32 220 7909.06 20.76 8258.72 21.67 529 Gokarna 132 3255.12 14.24 4094.34 17.91

191 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 220 4234.98 11.11 4330.01 11.36 530 Howrah 132 2874.36 12.57 3565.98 15.60 220 5455.57 14.32 5834.77 15.31 531 Kasba 132 3778.64 16.53 4871.81 21.31 220 2797.38 7.34 2959.87 7.77 532 Laxmikantapur 132 1500.15 6.56 1967.21 8.60 220 4708.58 12.36 4435.30 11.64 533 Midnapur 132 2351.56 10.29 2873.87 12.57 220 5992.45 15.73 6030.73 15.83 534 New Jalpaigudi 132 3771.70 16.50 4462.15 19.52 220 3005.86 7.89 2745.14 7.20 535 New Haldia 132 2506.02 10.96 2728.17 11.93 220 4832.75 12.68 4533.91 11.90 536 Rishra 132 4103.50 17.95 4873.48 21.32 220 3474.25 9.12 3172.02 8.32 537 Satgachia 132 2318.18 10.14 2741.06 11.99 220 5022.45 13.18 5263.82 13.81 538 Santhaldih 132 1328.04 5.81 1444.20 6.32 220 2381.29 6.25 2227.61 5.85 539 Asansol 132 1368.33 5.99 1620.77 7.09 220 3496.48 9.18 3199.33 8.40 540 krishnagar 132 2051.95 8.98 2449.98 10.72 220 4225.97 11.09 3976.10 10.44 541 Bisnupur 132 2209.53 9.66 2723.96 11.91 220 4481.43 11.76 4385.71 11.51 542 Calcutta Leather Complex 132 3293.47 14.41 3834.49 16.77 6251.67 16.41 7694.33 20.19 543 Subhasgarm 220 132 1809.15 7.91 2224.80 9.73 5330.45 13.99 5457.77 14.32 544 New Town Action Area-3 220 132 2622.45 11.47 3030.64 13.26 2487.77 6.53 2347.90 6.16 545 Hura 220 132 1542.85 6.75 1863.69 8.15 220 4455.65 11.69 4360.41 11.44 546 Foundary Park 132 1628.00 7.12 1992.31 8.71 220 6336.21 16.63 5199.10 13.64 547 Dalkhola 132 2041.54 8.93 2380.06 10.41 220 7879.56 20.68 7569.86 19.87 548 DTPS (Waria) 132 3503.23 15.32 3913.96 17.12

192 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 220 8158.86 21.41 7755.54 20.35 549 Barjora 132 1046.25 4.58 1039.33 4.55 550 Parullia_D 220 9078.15 23.82 9386.16 24.63 551 J K Nagar 220 3153.32 8.28 2906.61 7.63 552 Durgapur(Muchipara) 220 7902.46 20.74 7337.89 19.26 553 Burnpur 220 4818.72 12.65 3539.49 9.29 554 Mejia 220 11468.89 30.10 12840.49 33.70 220 7831.15 20.55 8446.85 22.17 555 DPL 132 2334.56 10.21 2978.66 13.03 220 2683.84 7.04 2703.80 7.10 220 3229.14 8.47 3582.53 9.40 556 BBGS_C 132 3371.47 14.75 4163.20 18.21 132 2248.54 9.84 2869.97 12.55 220 2683.98 7.04 2707.07 7.10 220 3473.08 9.11 4156.66 10.91 557 EMSS_C 132 1733.66 7.58 2346.48 10.26 132 3769.73 16.49 4861.77 21.27 132 3769.72 16.49 4861.76 21.27 220 2987.44 7.84 3594.88 9.43 558 NCGS_C 132 1304.34 5.71 1713.80 7.50 132 2736.84 11.97 3486.17 15.25 220 6777.88 17.79 5832.84 15.31 559 Birpara 132 2171.09 9.50 2544.18 11.13 220 6176.08 16.21 5942.33 15.60 560 Siliguri 132 3528.18 15.43 3774.25 16.51 561 Dalkhola 220 6417.14 16.84 5263.19 13.81 562 Adisaptagram 132 3799.49 16.62 3668.00 16.04 563 Alipurduar 132 764.27 3.34 904.15 3.96 564 AshokNagar 132 2361.53 10.33 2480.59 10.85 565 mahispota 132 1764.59 7.72 1263.63 5.53 566 Balurghat 132 541.12 2.37 587.85 2.57 567 Bankura 132 1461.22 6.39 1495.65 6.54 568 Barasat 132 1229.80 5.38 1359.78 5.95 569 Basithpur 132 1102.01 4.82 1147.97 5.02 570 Joka 132 903.87 3.95 1113.10 4.87 571 Berhampore 132 1880.53 8.23 2052.80 8.98 572 Birpara 132 2153.97 9.42 2505.04 10.96 573 Bishnupur 132 2056.33 8.99 2396.74 10.48 574 Bolpur 132 1379.52 6.03 1510.86 6.61

193 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 575 Bongaon 132 1477.46 6.46 1410.93 6.17 576 C k Road 132 634.65 2.78 700.16 3.06 577 Lebong 132 1253.17 5.48 846.73 3.70 578 Debagram 132 964.51 4.22 910.29 3.98 579 Dhulian 132 649.68 2.84 703.77 3.08 220 2956.87 7.76 2766.02 7.26 580 Egra 132 1928.69 8.44 2304.58 10.08 132 577.47 2.53 382.15 1.67 581 Food Park 132 593.96 2.60 396.68 1.74 582 SaltLake GIS 132 1653.36 7.23 1344.17 5.88 583 Bajkul 132 1612.94 7.06 1195.37 5.23 584 Falta 132 1000.26 4.38 1189.82 5.20 585 Haldia 132 2467.47 10.79 2654.45 11.61 586 Hizlee 132 952.22 4.17 1071.53 4.69 587 Kalyani 132 2956.81 12.93 2480.24 10.85 588 Katwa 132 1012.04 4.43 1132.15 4.95 589 Khanyan 132 2110.02 9.23 1728.05 7.56 590 Kolaghat 132 2770.75 12.12 3093.71 13.53 591 Lilooah 132 2645.34 11.57 3092.80 13.53 592 Malda 132 1825.63 7.99 2192.18 9.59 593 Mankar 132 1501.64 6.57 1489.32 6.51 594 Myanaguri 132 1561.15 6.83 1545.07 6.76 595 North Bengal University 132 3108.05 13.59 3187.14 13.94 596 Pingla 132 1065.10 4.66 1208.86 5.29 597 Purulia 132 852.25 3.73 987.12 4.32 598 Raiganj 132 1224.83 5.36 1193.52 5.22 599 Raina 132 1468.03 6.42 1564.82 6.84 600 Rampurhat 132 975.38 4.27 1042.26 4.56 601 Ranaghat 132 1961.40 8.58 2058.65 9.00 602 Mathabang 132 403.72 1.77 482.42 2.11 603 SaltLake 132 2268.87 9.92 2291.14 10.02 604 Samsi 132 516.02 2.26 627.77 2.75 605 Siliguri 132 2532.02 11.08 2501.17 10.94 606 Sonarpur 132 1808.28 7.91 1817.59 7.95 607 Tamluk 132 2262.46 9.90 2171.74 9.50 608 Tarkeshwar 132 2299.61 10.06 2086.04 9.12 609 Titagarh 132 1760.68 7.70 1955.95 8.56 610 Ukhra 132 1779.76 7.78 1851.13 8.10 611 Uluberia 132 2635.50 11.53 2608.10 11.41

194 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 612 Sirakol 132 1000.39 4.38 1167.13 5.11 613 Cossipur 132 1187.99 5.20 901.80 3.94 614 Balichak 132 1166.21 5.10 997.91 4.37 615 TCF-1 132 2203.55 9.64 1944.39 8.50 616 Dankuni 132 1759.33 7.70 1417.06 6.20 617 Debagram 132 847.11 3.71 721.69 3.16 618 Balurghat 132 1461.71 6.39 1272.83 5.57 619 Modern 132 1724.81 7.54 1647.05 7.20 620 Jangipara 132 2092.68 9.15 1853.92 8.11 621 Chanditala 132 3696.06 16.17 3728.36 16.31 622 Gangarampur 132 550.86 2.41 608.05 2.66 623 Birsingha 132 1701.81 7.44 1656.08 7.24 624 Coochbehar 132 735.39 3.22 910.73 3.98 625 Belmuri 132 2357.81 10.31 2052.46 8.98 626 Barjora 132 1020.93 4.47 989.04 4.33 627 Chalsa 132 998.73 4.37 1027.59 4.50 628 Mechand 132 824.22 3.61 957.83 4.19 629 Raghunathpur 132 1296.21 5.67 1322.50 5.78 630 Amtala 132 873.47 3.82 1002.41 4.38 631 Contai 132 1202.82 5.26 1226.69 5.37 632 Haldia NIZ 132 1988.81 8.70 1799.42 7.87 633 Jhargram 132 998.83 4.37 1016.55 4.45 634 Lalgola 132 1466.21 6.41 1402.27 6.13 635 Najirpur 132 762.83 3.34 857.31 3.75 636 Bighati 132 3765.10 16.47 3523.19 15.41 637 RMBLK 132 1622.83 7.10 1173.58 5.13 638 TMBL 132 1627.46 7.12 1172.51 5.13 639 Farakka 132 997.05 4.36 1096.17 4.79 640 Khatri 132 781.33 3.42 863.96 3.78 641 Kalna 132 1518.96 6.64 1467.06 6.42 642 Kakdwip 132 751.19 3.29 785.12 3.43 643 Kurseong 132 1333.54 5.83 796.75 3.49 644 Bagnan 132 2380.23 10.41 2329.18 10.19 645 Sonarlal 132 1141.79 4.99 789.90 3.46 646 Saintia 132 1351.79 5.91 1434.14 6.27 647 New Town Action Area-1 132 2123.54 9.29 2111.93 9.24 648 Ujanu 132 2326.70 10.18 2272.97 9.94 649 BEL CCp 132 942.29 4.12 970.52 4.25 650 Belmuri 132 791.64 3.46 736.88 3.22

195 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 651 Burdwan 132 1065.29 4.66 961.51 4.21 652 Bagmundi 132 349.65 1.53 380.00 1.66 653 Kharagpur 132 714.86 3.13 456.20 2.00 654 Howrah 132 690.71 3.02 502.20 2.20 655 Kalapahari 132 2685.98 11.75 1824.18 7.98 656 Purulia 132 1640.73 7.18 979.70 4.29 657 Bandel 132 5675.26 24.82 6114.19 26.74 658 Jamuria 132 917.13 4.01 522.93 2.29 659 TCF 132 787.97 3.45 466.29 2.04 660 ASP 132 2906.56 12.71 2672.72 11.69 661 DPL A Zone 132 2178.67 9.53 2588.91 11.32 662 DPL B Zone 132 2257.80 9.88 2812.78 12.30 663 DPL AB Zone 132 2261.43 9.89 2747.34 12.02 664 DPL C Zone 132 2069.35 9.05 2331.40 10.20 665 DPL C1 Zone 132 2035.40 8.90 2236.78 9.78 666 Bamunara 132 1998.49 8.74 2122.87 9.29 667 NCGS_C 132 2736.84 11.97 3486.17 15.25 132 2287.02 10.00 2863.86 12.53 668 SRS_C 132 2206.68 9.65 2773.16 12.13 132 1744.39 7.63 1939.88 8.49 669 TRS_C 132 2542.01 11.12 3199.97 14.00 670 Majerhat_C 132 2491.97 10.90 3190.52 13.96 132 1271.42 5.56 1670.10 7.31 671 BT Road_C 132 2876.86 12.58 3669.14 16.05 132 1541.34 6.74 2077.66 9.09 672 Princep Street_C 132 2100.29 9.19 2618.40 11.45 132 2247.78 9.83 2869.04 12.55 132 3343.92 14.63 4313.24 18.87 673 East calcutta_C 132 2024.51 8.86 2559.05 11.19 674 Rishra_C 132 3736.48 16.34 4439.71 19.42 675 Taratala_C 132 2478.32 10.84 3171.54 13.87 676 Chakmir_C 132 2566.69 11.23 3263.01 14.27 132 2860.81 12.51 3577.11 15.65 677 Jadavpur_C 132 2258.74 9.88 2856.57 12.49 678 BBD Bag_C 132 2248.54 9.84 2869.96 12.55 679 Botanical garden_C 132 2830.72 12.38 3511.02 15.36 680 Belur_C 132 2523.95 11.04 2965.77 12.97 132 1590.74 6.96 2123.71 9.29 681 Park Lane_C 132 1590.74 6.96 2123.72 9.29

196 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 682 DumDum_C 132 3033.54 13.27 3883.94 16.99 683 Patuli_C 132 1590.74 6.96 2131.85 9.32 684 Park Circus_C 132 1642.57 7.18 2225.18 9.73 685 Majerhat_C 132 2491.97 10.90 3190.52 13.96 686 Kalingpong 66 410.45 3.59 313.21 2.74 687 Alipurduar 66 224.60 1.97 59.20 0.52 688 Birpara 337.50 2.95 66 66 286.13 2.50 318.61 2.79 689 Jali 66 291.63 2.55 301.13 2.63 690 Chalsa 66 383.73 3.36 207.79 1.82 691 Salakati NER 220 5789.30 15.19 6029.57 15.82 692 Chukha 220 4042.58 10.61 3929.16 10.31 693 Rammam 132 1714.07 7.50 1575.61 6.89 694 WBIDC 132 1672.98 7.32 1232.34 5.39 695 IPCL Haldia 220 2889.89 7.58 2576.97 6.76 696 Teesta Low Dam 220 1671.35 4.39 1601.32 4.20 697 Teesta Low Dam 220 1574.90 4.13 1380.65 3.62 698 RaghunathGanj 132 1188.67 5.20 1346.19 5.89 699 Madras Cement 132 2086.93 9.13 1780.34 7.79 700 HPCL 132 2370.55 10.37 2422.51 10.60 701 Bencon Street 132 1289.12 5.64 1173.31 5.13 702 Tata Power 132 2218.01 9.70 2202.81 9.64 703 Khejuria 132 1029.35 4.50 1157.80 5.06 704 Kuli 132 1498.81 6.56 1368.13 5.98 132 872.69 3.82 833.98 3.65 705 Ambuja 132 846.27 3.70 786.91 3.44 132 372.29 1.63 201.04 0.88 706 BRG Steel 132 346.20 1.51 185.94 0.81 707 Manaksia 132 1933.91 8.46 1711.19 7.48 708 Hizli TSS 132 941.98 4.12 1038.10 4.54 709 Jaysree 132 3408.95 14.91 3275.75 14.33 710 OCL Bishnupur 132 397.50 1.74 219.77 0.96 711 Emammi Cement 132 1449.72 6.34 1390.34 6.08 712 Bolpur TSS 132 1324.34 5.79 1384.68 6.06 713 Badri Narayan alloy 132 549.10 2.40 351.96 1.54 714 Sonic Thermal 132 1002.63 4.39 954.63 4.18 715 Cresent power 132 1121.68 4.91 1082.46 4.74 716 TGS 132 2542.01 11.12 3199.97 14.00 717 Chakaradharpur_R 132 589.73 2.58 599.63 2.62

197 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 718 Dhatrigram_R 132 1161.95 5.08 815.77 3.57 719 Katwa_R 132 956.35 4.18 1001.83 4.38 720 Bankura_R 132 1431.49 6.26 1434.30 6.27 721 Barasat_R 132 1130.09 4.94 1137.77 4.98 Sikkim 400 11244.84 16.23 11314.16 16.33 722 Rangpo_PG 220 6997.55 18.36 8081.32 21.21 132 2973.17 13.00 2905.25 12.71 723 Teesta-5 400 10251.12 14.80 10139.75 14.64 724 Teesta-3 400 8707.29 12.57 9651.70 13.93 725 Jorethang 220 4668.95 12.25 4281.59 11.24 726 New Melli 220 4834.48 12.69 4363.98 11.45 727 Chuzachen 132 1823.04 7.97 1806.49 7.90 132 2079.32 9.10 1667.70 7.29 728 Rongit 66 148.60 1.30 145.99 1.28 729 Sagbari 132 2065.66 9.04 1645.58 7.20 132 1200.54 5.25 777.79 3.40 730 Geyzing 66 259.57 2.27 218.87 1.92 132 1353.72 5.92 916.92 4.01 731 Gangtok 66 503.27 4.40 427.38 3.74 132 2068.04 9.05 1482.31 6.48 732 Melli 66 630.66 5.52 560.98 4.91 733 Melli 66 627.45 5.49 556.43 4.87 734 Tadong 66 383.08 3.35 295.70 2.59 735 Bulbuley 66 372.34 3.26 285.28 2.50 736 Sichey 66 365.37 3.20 278.58 2.44 737 Rongli 66 176.51 1.54 114.20 1.00 738 Mamring 66 271.44 2.37 192.30 1.68 739 Namchi 66 320.21 2.80 238.41 2.09 740 Rabangla 66 123.25 1.08 108.74 0.95 741 Rohtak 66 189.87 1.66 129.59 1.13 742 Soreng 66 151.22 1.32 101.59 0.89 743 Lower Lagyep 66 482.47 4.22 402.41 3.52 744 Phudong 66 210.81 1.84 146.47 1.28 745 Geyzing 66 259.67 2.27 218.55 1.91 746 Purano Namchi 66 239.76 2.10 167.29 1.46 747 Pakyong 66 313.10 2.74 210.09 1.84 748 Pelling 66 244.13 2.14 201.48 1.76 749 Rhenock 66 140.52 1.23 90.39 0.79

198 PRDC Bangalore September 2017

Web based Protection Database and Desktop based Protection setting calculation tool – ERPC

3-Ph to Ground fault SLG fault Rated 3-Phase Fault 1-Phase Fault Sl. no. Substation Name Voltage MVA Current MVA Current (kV) (MVA) (kA) (MVA) (kA) 750 Mangan 66 139.24 1.22 93.48 0.82 751 Rnipool 66 484.98 4.24 405.38 3.55 752 Topakhani 66 264.16 2.31 189.04 1.65 753 Meyong 66 115.58 1.01 76.81 0.67 754 Rongli 66 159.85 1.40 103.13 0.90

199 PRDC Bangalore September 2017
