Contact Mechanics of Adhesive Beams. Part I: Moderate Indentation. Arxiv:1707.07543V1

Contact mechanics of adhesive beams. Part I: Moderate indentation.

V. S. Punati∗, I. Sharma and P. Wahi

Mechanics & Applied Mathematics Group, Department of Mechanical Engineering, Indian Institute of Technology Kanpur, Kanpur, Uttar Pradesh, India - 208016.

Abstract

We investigate the contact of a rigid cylindrical punch with an adhesive beam mounted on flexible end supports. Adhesion is modeled through an adhesive zone model. The resulting Fredholm integral equation of the first kind is solved by a Galerkin projection method in terms of Chebyshev polynomials. Results are reported for several combinations of adhesive strengths, beam thickness, and support flexibilities characterized through torsional and vertical translational spring stiffnesses. Special attention is paid to the important extreme cases of clamped and simply supported beams. The popular Johnson-Kendall-Roberts (JKR) model for adhesion is obtained as a limit of the adhesive zone model. Finally, we compare our predictions with preliminary experiments and also demonstrate the utility of our approach in modeling complex structural adhesives.

Keywords: contact mechanics; adhesive beams; integral transforms.

1 Introduction

Research in patterned adhesives is often motivated by the structures of natural adhesives, such as those present in the feet of gekkos; see e.g. Hiller (1976), and Arul and Ghatak (2008). In conventional adhesives, such as thin, sticky tapes, only the top and bottom surfaces are active. However, multiple surfaces may be activated with appropriate patterning. With more surfaces participating in the adhesion process the adhesives show increased hysteresis and, so, better performance. One example of a patterned adhesive is the structural adhesive shown in Fig. 1(a), which was developed by Arul and arXiv:1707.07543v1 [cond-mat.soft] 24 Jul 2017 Ghatak (2008). Figure 1(b) shows a possible mechanical model of the structural adhesive of Fig. 1(a) that utilizes several interacting adhesive beams. This motivates the goal of this paper, which is to investigate the adhesive contact of a beam; see Fig. 2(a). Contact with a half-space has been well studied over the past century, and we refer the reader to Alexandrov and Pozharskii (2001), and also the texts of Galin and Gladwell (2008), Gladwell (1980), Johnson (1985) and Hills et al. (1993). At the same time, the contact of thin layers is an active area of research in view of applications to electronics

∗Electronic address: [email protected]; [email protected]

1 P P

Layer Punch Punch

kt1 kt1

ks1 ks1

Micro-channels kt2 kt2

ks2 ks2

Rigid Platform Rigid Platform (a) (b) Figure 1: (a) Structural adhesive designed by Arul and Ghatak (2008). (b) Mechanical model of the structural adhesive in (a) employing an interconnected stack of adhesive beams. The rigidity of the vertical walls is modeled through torsional (stiﬀness kt) and vertical translational (stiﬀness ks) springs, as shown. The system is indented by a rigid punch, pressed down by the force P .

P x

kt h kt k k s a a s

y l l σ0 (a) a δc c P x ∞

h ∞ h kt kt k s a a ks

y l l (b)

Figure 2: (a) Indentation by a rigid cylindrical punch of an adhesive beam resting upon flexible supports. The flexible supports are modeled through torsional and vertical translational springs with stiffnesses kt and ks, respectively. (b) Mathematical model of the indentation process shown in (a). The inset shows details of the adhesive zone active near the contact edges; see text for details. The vertical deflection is exaggerated for ease of representation.

2 and computer industry; see, e.g. Barthel and Perriot ( 2007), and Dalmeya et al. (2012). In contrast, the indentation of beams is much less studied.

Seeking the solution to the indentation of a beam through a strength-of-materials approach overlooks the local contact mechanics. To probe the latter, it is necessary to formulate an elasticity problem with appropriate boundary conditions. This is typically a complex problem, and has prompted some alternate approaches to adhesionless contact, as discussed in the next paragraph. To the best of our knowledge there is no available work on the adhesive contact of beams.

Two-dimensional adhesionless indentation of a beam has been studied in the past by Keer and Silva (1970), Keer and Miller (1983), Keer and Schonberg (1986), Sankar and Sun (1983), Sun and Sankar (1985), and Kim et al. (2014). Keer and Miller (1983) modeled the beam as a linear elastic layer of inﬁnite extent with frictionless bottom and top surfaces. First, the elasticity problem was solved thorugh Fourier transforms, see e.g. Sneddon (1995, p. 395-414). Then, employing the Hankel transform (Gladwell 1980, p. 213) for the pressure distribution, and asymptotically matching the far-ﬁeld displacements with those obtained from Euler-Bernoulli beam theory, a Fredholm integral equation of the second kind was obtained. This equation was solved numerically.

Sankar and Sun (1983) employed Fourier series in their investigation of adhesionless contact with beams of ﬁnite length. Their results were in good agreement with those of Keer and Miller (1983). Recently, Kim et al. (2014) studied beam indentation through asymptotics. Finite element (FE) simulations were also carried out. The contact parameters, i.e. contact area and the total load acting on the punch, obtained through asymptotics, matched results of FE simulations well. In all these studies, the interaction of the beam with the punch is non-adhesive. However, extending these methods to adhesive beams is diﬃcult due to the presence of several iterated integral transforms. Here, we propose an alternative approach to the contact of a beam with a rigid punch, shown in Fig. 2(a), that models both non-adhesive and adhesive interactions in a straightforward manner.

Adhesion is modeled through the introduction of an adhesive zone that extends beyond the contact zone, as shown in the inset of Fig. 2(b). An adhesive zone model allows us to investigate the eﬀect of adhesion by admitting continuous variations in it’s strength. The popular JKR (Johnson et al., 1971) and DMT (Derjaguin et al., 1975) models for adhesion are obtained as special cases. The non-adhesive case (‘Hertzian contact’) is found by setting the adhesion strength to zero.

This paper is organized as follows. We start by formulating a mathematical model for the adhesive contact of the beam shown in Fig. 2(a). We will obtain a Fredholm integral equation of the first kind that relates the contact pressure distribution with the vertical displacement in the contact patch. Relevant conditions at the edge of the contact zone will also be derived. This integral equation is then solved numerically employing Galerkin projections in terms of Chebyshev polynomials. Theoretical results are compared with FE simulations whenever possible. We then explore the effect of various parameters in the problem, viz. flexibility of end supports, strength of adhesion, the beam’s geometry, etc. We close with a comparison with preliminary experimental results, and an application of our solution to complex structural adhesives, such as the one shown in Fig. 1(a).

3 2 Mathematical model

We begin by extending the beam of Fig. 2(a) beyond the supports to infinity, as shown in Fig. 2(b). The extension is done in a manner consistent with the kinematic and kinetic constraints imposed by the supports. Thus, the beam is extended linearly along its slope at the supports. The beam may now be thought of as a linear elastic layer of infinite length with thickness h. The beam is isotropic and homogeneous, with Young’s modulus E and Poisson’s ratio ν. The top and bottom surfaces of the beam are frictionless. 1 During indentation, a normal traction distribution Pc(x) acts on the top surface . − At this time, the vertical displacement of the bottom surface is vb(x), which is typically not known. When the contact area is less than the beam’s thickness, we assume that vb(x) may be approximated by the displacement obtained from Euler-Bernoulli beam theory when a point load of magnitude P acts at the center of the top surface, as depicted in Fig. 20. The details of how vb(x) is calculated for a beam on flexible supports are provided in App. A. The governing equations for the horizontal (u) and vertical (v) displacements in the extended beam (elastic layer) of Fig. 2(b), assuming plane strain, are given by

2 (1 ν) ∂2u ∂2u 1 ∂2v − + + = 0 (2.1a) 1 2ν ∂x2 ∂y2 1 2ν ∂x∂y − − ∂2v 2 (1 ν) ∂2v 1 ∂2u and + − + = 0, (2.1b) ∂x2 1 2ν ∂y2 1 2ν ∂x∂y − − which reﬂect horizontal and vertical linear momentum balance, respectively; see, e.g. Timoshenko and Goodier (1970, p. 241) or Sadd (2005, p. 125). The boundary conditions may be taken to be

σxy = 0, σyy = Pc(x) on the top surface, i.e. at y = 0, (2.2a) − and σxy = 0, v = vb(x) on the bottom surface, i.e. at y = h. (2.2b)

We now follow Sneddon (1995, p. 402) to map the above problem into Fourier space by transforming the x coordinate. Solving for the vertical displacement in Fourier space and, then, taking the inverse Fourier transform yields the following integral equation for the vertical displacement of the top surface:

∞ Z 2 2 ¯ sinh ξ h v (x, 0) = Pc (ξ) cos ξx dξ − πE∗ ξ (ξ h + sinh ξ h cosh ξ h) 0 ∞ 1 Z sinh ξ h + ξ h cosh ξ h + v¯ (ξ) cos ξx dξ, (2.3) π b ξ h + sinh ξ h cosh ξ h 0 where E∗ = E/ (1 ν2), − ∞ ∞ Z Z ¯ Pc (ξ) = Pc (t) cos ξt dt andv ¯b (ξ) = vb (t) cos ξt dt. (2.4) − −∞ −∞

1The negative sign is introduced in order to report compressive pressure during contact as positive.

4 Appendix B provides details of how (2.3) is obtained. For non-dimensionalizing it is more convenient to rewrite (2.3) as

∞ ∞ 2 Z Z sinh2 ξ h v (x, 0) = P (t) cos ξt dt cos ξx dξ πE∗ c ξ (ξ h + sinh ξ h cosh ξ h) 0 −∞ ∞ ∞ 1 Z Z sinh ξ h + ξ h cosh ξ h + v (t) cos ξt dt cos ξx dξ, (2.5) π b ξ h + sinh ξ h cosh ξ h 0 −∞ ¯ where we have invoked deﬁnitions (2.4) of Pc andv ¯b. In contact problems the vertical displacement within the contact region is constrained. For example, during indentation with a rigid punch, the surface in the contact region must conform to the shape of the punch. We now approximate the proﬁle of the cylindrical punch of radius R as a parabola in the contact region, as is appropriate if the indentation depth, and the dimensions of the contact region are much smaller than the radius of curvature of the punch. We set δ to be the vertical displacement of the punch. This allows us to write the vertical displacement of the beam’s top surface within the contact region as x2 v(x, 0) = δ , a x a, (2.6) − 2R − ≤ ≤ where the contact region lies between a and a. During contact, the pressure on the− beam’s top surface depends also on the adhesive interaction between the beam and the punch. This adhesive interaction is, in turn, introduced through the presence of an adhesive zone; see inset of Fig. 2(b). Within the adhesive zone the adhesive interaction is modeled through a Dugdale-Barenblatt model (Maugis, 1992), which assumes the adhesion to be of constant strength σ0. Thus, we may write the force distribution on the beam’s top surface as

 p (x) , x a  | | ≤ Pc (x) = σ0, a < x c (2.7)  0−, x >| c,| ≤ | | where c locates the outer edge of the adhesive zone; see inset in Fig. 2(b). Adhesive zones were introduced by Maugis (1992) in order to avoid the singularity in the pressure at the contact edge (x = a) found in JKR theory. For this, it is also necessary that there be no discontinuity in± the contact pressure at the contact edge, i.e.

lim p (x) = σ0. (2.8) x→±a− − To close our mathematical description we require an additional equation to compute the extent c of the adhesive zone. This is obtained by equating the energy release rate computed from the J integral (Rice, 1968) and the work of adhesion w, which leads to −

σ0δc = w, (2.9) where 2 δc = c /2R δ + vc (2.10) − is the air-gap at which the adhesive forces vanish and vc = v (c, 0); see inset in Fig. 2(b).

5 During non-adhesive indentation (2.10) is automatically satisﬁed as σ0 = 0 = w. The JKR approximation is obtained in the limits σ0 and c a, at which the energy balance (2.9) becomes → ∞ → K2 1 = w, (2.11) 2E∗ where p K1 = lim 2π (a x)p (x) (2.12) − x→a− − is the stress intensity factor that measures the strength of the square root singularity in the pressure at the contact edge; see Maugis (1992). This is equivalent to Griﬃth’s criterion in fracture mechanics; see e.g. Kanninen and Popelar (1985, p. 168). In this limit, we do not require the contact pressure end condition (2.8). Finally, the total load acting on the punch is found by integrating the normal traction over the top surface of the beam:

∞ a Z Z P = Pc (x) dx = p (x) dx 2 σ0 (c a) . (2.13) − − −∞ −a 3 Non-dimensionalization

We introduce the following non-dimensional parameters: a aRl P Rl k l k l3 A = ; ϕ (τ) = p (aτ¯); P¯ = ; kf = t ; kf = s ; l Kh3 Kh3 t EI s EI δR l R 1/3 πw 1/3 ∆ = ; L = ; λ = 2σ ; m = , l2 R 0 πwK2 RK where K = 4 E∗/3 and I = h3/12 is the beam’s area moment of inertia. We also deﬁne the scaled variables 1 1 ω ω x,¯ τ,¯ c,¯ γ¯ = x, t, c, h ; τ,ˆ γˆ = t, h ; ω, ω,¯ ωˆ = ξh, , ; { } a { } { } l { } { } γ¯ γˆ R ¯ I 1 aRl ϑ (¯x, 0) , ϑb (ˆτ) = v (¯x, 0) , vb (lτˆ) ; I = = ;Φ(τ) = Pc (aτ¯) . { } l2 { } h3 12 Kh3 In terms of these variables the non-dimensional vertical displacement of the top surface (2.5) becomes

∞ ∞ 8ˆγ3 Z Z ϑ (¯x, 0) = Φ (¯τ) cos (¯ωτ¯) dτ¯ K (¯ω, x¯) dω + 3π 1 0 −∞ ∞ ∞ 1 Z Z ϑ (ˆτ) cosω ˆτˆ dτˆ K (¯ω, x¯) dω, (3.1) πγˆ b 2 0 −∞ with the kernels sinh2 ω K (¯ω, x¯) = cos (¯ωx¯) 1 ω (ω + sinh ω cosh ω) sinh ω + ω cosh ω and K (¯ω, x¯) = cos (¯ωx¯) . 2 ω + sinh ω cosh ω

6 From (2.7), we obtain the non-dimensional pressure on the beam’s top surface:   ϕ (¯τ) , τ¯ 1 Φ (¯τ) = λAm/2ˆγ3L, 1| <| ≤τ¯ c¯ (3.2)  0−, τ¯ >| c.¯| ≤ | | Combining (3.1) and (3.2) yields

∞ ∞ 8ˆγ3 Z 8λAm Z ϑ (¯x, 0) = ϕ¯ (¯ω) K1 (¯ω, x¯) dω ϕ¯0 (¯ω) K1 (¯ω, x¯) dω − 3π − 3πL 0 0 ∞ 1 Z + ϑˆ (ˆω) K (¯ω, x¯) dω, (3.3) πγˆ b 2 0 with 1 c¯ ∞ Z Z Z ˆ ϕ¯ (¯ω) = ϕ (¯τ) cos (¯ω τ¯) dτ,¯ ϕ¯0 (¯ω) = cos (¯ω τ¯) dτ¯ and ϑb (ˆω) = ϑb (ˆτ) cos (ˆωτˆ) dτ.ˆ − −1 1 −∞ (3.4) Non-dimensionalizing the displacement in the contact region (2.6), the contact pressure end condition (2.8), and the energy equation (2.9) lead to, respectively, 1 ϑ(¯x, 0) = ∆ x¯2A2 for 1 x¯ 1, (3.5) − 2 − ≤ ≤ λ Am ϕ ( 1) = (3.6) ± −2γ ˆ3L πλL2 c¯2A2 and 1 = ∆ + ϑc , (3.7) 2m2 2 − where ϑc = ϑ (¯c, 0) and ∆ is the non-dimensional displacement of the punch. Combining (2.11) and (2.12), and non-dimensionalizing, we obtain

3 r m l 3Am lim p(1 x¯)ϕ (¯x) = , (3.8) x¯→1− − −2πL h L which replaces (3.6) and (3.7) whenever we invoke the JKR approximation. The total non-dimensional load acting on the punch is found from (2.13):

1 Z λAm P¯ = ϕ (¯τ) dτ¯ (¯c 1) . (3.9) − γˆ3L − −1 Finally, evaluating (3.3) in the contact region, i.e. for 1 x¯ 1, and employing (3.5) we obtain − ≤ ≤ ∞ ∞ 3 Z Z 1 2 2 8ˆγ 8λAm ∆ x¯ A = ϕ¯ (¯ω) K1 (¯ω, x¯) dω ϕ¯0 (¯ω) K1 (¯ω, x¯) dω − 2 − 3π − 3πL 0 0 ∞ 1 Z + ϑˆ (ˆω) K (¯ω, x¯) dω. (3.10) πγˆ b 2 0

7 This is a Fredholm integral equation of ﬁrst kind; see Polyanin and Manzhirov (2008, p. 573). We now solve the above equation, along with boundary conditions (3.6) and (3.7), for the contact pressure ϕ (¯x), displacement ∆ and the locationc ¯ of the adhesive zone’s edge, at a given contact area A.

4 Numerical solution

The integral equation (3.10) does not admit an analytical solution due to the complex kernels present. Thus, we solve it numerically. To this end, we approximate the unknown pressure distribution p (x) in the contact region through a series of Chebyshev polynomials. Chebyshev polynomials are chosen due to their spectral convergence; see Mason and Handscomb (2003, p. 63). The unknown non-dimensional pressure distribution is expressed as a series of Cheby- shev polynomials of the ﬁrst kind, viz.

N λAm 1 X ϕ (¯τ) = + b2nT2n (¯τ) , (4.1) −2ˆγ3L √1 τ¯2 − n=0 where b2n are unknown constants that are to be found. Only even Chebyshev polynomials are considered as the problem is symmetric about the origin. The constant term in the approximation is introduced to explicitly account for the continuity condition (3.6) that is imposed on the contact pressure at the edge of the contact zone.

Employing (4.1) to evaluate the integralsϕ ¯ (¯ω) andϕ ¯0 (¯ω) from (3.4), we obtain, respectively,

N λAm sinω ¯ X ϕ¯ (¯ω) = b α (¯ω) (4.2) γˆ3L ω¯ 2n 2n − n=0 1 andϕ ¯0 (¯ω) = ( sinω ¯ + sinω ¯c¯) , (4.3) ω¯ − where 1 Z 1 α2n (¯ω) = T2n (¯τ) cosω ¯τ¯ dτ.¯ (4.4) p(1 τ 2) −1 −

Appendix C provides details of how α2n (¯ω) are computed. Combining (3.9) and (4.1), we ﬁnd the total load acting on the punch to be

¯ λAm P = πb0 c.¯ (4.5) − γˆ3L ¯ The displacement of the beam’s bottom surface ϑb (ˆω) may, with (4.5), be written as 1 ˆ 4 λAmc¯ ˆ ϑb (ˆω) = b0 ϑp (ˆω) , (4.6) πγˆ 3ˆγI¯(1 ν2) − πγˆ3L − ¯ ¯ where I is the scaled area moment of inertia, and the exact form of ϑp depends upon how the beam is supported at its ends; see App. A.

8 The vertical displacement in the contact region may be expressed in terms of Cheby- shev polynomials as

N 1 X A2 A2 ∆ x¯2A2 = a T (¯x) = ∆ T (¯x) T (¯x) . (4.7) 2 2n 2n 4 0 4 2 − n=0 − −

Employing expansions (4.1)–(4.7) in the integral equation (3.10), we obtain

N 3 N X 8ˆγ X (1) 8λAm (1) 4 λAmc¯ (2) a2nT2n (¯x) = b2n (¯x) (¯x) + b0 (¯x) , 3π J2n − 3πL J 3ˆγI¯(1 ν2) − πγˆ3L J n=0 n=0 − (4.8) where

∞ Z (1) (¯x) = α2n (¯ω) K1 (¯ω, x¯) dω, J2n 0 ∞ Z (1) sinω ¯ c¯ (¯x) = K1 (¯ω, x¯) dω J ω¯ 0 ∞ Z (2) ˆ and (¯x) = ϑp (ˆω) K2 (¯ω, x¯) dω. J 0

We evaluate the above integrals at anyx ¯ through the Clenshaw-Curtis quadrature (Press et al. 1992, p. 196). We now follow Gladwell (1980, p. 267) and utilize Galerkin projections to solve (4.8) for the unknown coeﬃcients b2n. To this end, we multiply both sides of (4.8) 2 by T2m (¯x) /√1 x¯ , for m = 0, ,N, and integrate fromx ¯ = 1 tox ¯ = 1. This yields the following system− of N + 1 linear··· algebraic equations: −

N 3 N X 8ˆγ X (1) 8λAm (1) 4 λAmc¯ (2) a2n nm = b2n + b0 , (4.9) J 3π Jnm − 3πL Jm 3ˆγI¯(1 ν2) − πγˆ3L Jm n=0 n=0 − where

1 1 Z Z (1) T2n (¯x) T2m (¯x) (1) 2n (¯x) T2m (¯x) nm = dx,¯ = J dx,¯ J √1 x¯2 Jnm √1 x¯2 −1 − −1 − 1 1 Z (1) Z (2) (¯x) T2m (¯x) (¯x) T2m (¯x) (1) = J dx¯ and (2) = J dx.¯ Jm √1 x¯2 Jm √1 x¯2 −1 − −1 −

The foregoing integrals are evaluated through a Gauss-Chebyshev quadrature (Gladwell 1980, p. 260). Equations for b2n, ∆ andc ¯ are now obtained. Employing the expansion (4.1) in the contact pressure end condition (3.6) yields

b0 + b2 + + b2N = 0. (4.10) ··· 9 The energy balance (3.7) provides πλL2 c¯2A2 ∆ + ϑc = 1, (4.11) 2m2 2 − where the non-dimensional displacement of the punch

3 N 8ˆγ X (1) 8λAm (1) 4 λAmc¯ (2) ∆ = b2n (0) (0) + b0 (0) , (4.12) 3π J2n − 3πL J 3ˆγI¯(1 ν2) − πγˆ3L J n=0 − and the air gap at the end of the adhesive zone is

3 N 8ˆγ X (1) 8λAm (1) 4 λAmc¯ (2) ϑ (¯c) = b2n (¯c) (¯c) + b0 (¯c) . 3π J2n − 3πL J 3ˆγI¯(1 ν2) − πγˆ3L J n=0 − (4.13)

Finally, we have N + 1 equations from (4.9) and one each from (4.10) and (4.11), for a total of N + 3 equations. For a given contact area A, the total number of unknowns in this problem are also N + 3: the unknown coefficients b2n, with n = 0, ,N in the expansion (4.1) of the contact pressure ϕ (¯x), the displacement ∆ of the punch,··· and the locationc ¯ of the adhesive zone’s edge. The system of equations (4.9)–(4.11) are linear in b2n and ∆, but non-linear inc ¯; cf. (4.11). Thus, an iterative procedure is followed beginning with an initial guess forc ¯. At anyc ¯, (4.9) and (4.10) are solved for b2n and ∆. These b2n and ∆ must satisfy (4.11) at the current value ofc ¯. If (4.11) is not satisfied, then the value ofc ¯ is updated through a Newton-Raphson root finding algorithm; see, e.g. Chatterjee (2002). We continue to iterate until a consistent set of b2n, ∆ andc ¯ is found. Care should be taken while finding the adhesive zone sizec ¯, as it depends sensitively on the initial guess, and on the root finding algorithm that is employed. Once b2n, ∆ andc ¯ are found, the contact pressure ϕ (¯x) and the total load P¯ may be obtained from (4.1) and (4.5), respectively.

5 Finite element simulations

For comparison later, we will also solve the non-adhesive (‘Hertzian’) contact of a rigid punch with a beam through the ﬁnite element (FE) method. We employ the commercial FE package ABAQUS. While ABAQUS does provide some cohesive zone models that may be employed to simulate adhesive contact, they are not easily compared with the Dugdale-Barenblatt model that we employ. Thus, we restrict comparisons with FE results to non-adhesive contact. We also limit FE simulations to clamped and simply supported beams. In our FE simulations, the beam is modeled as a linear elastic layer with Young’s modulus E = 2000 MPa and Poisson’s ratio ν = 0.3. The beam’s thickness and half- span are taken as h = 4 mm and l = 40 mm, respectively. We note that these material properties are not typical of beams employed in structural adhesives, for example by Arul and Ghatak (2008). However, these properties are selected as their magnitudes allow us to easily distinguish the eﬀect of external inputs to the punch. 6 The cylindrical punch has radius R = 225 mm and Young’s modulus Ep = 2 10 × MPa - a thousand times the Young’s modulus of the beam. A high Ep is chosen in order to approximate a rigid punch.

10 In our FE analysis, plane-strain elements are considered for both the beam and the punch. The load is applied on the punch. The remaining contact parameters, i.e. contact pressure, contact area, and the displacement of the punch, are obtained after post- processing the computation’s output. These parameters are now compared with the semi-analytical results of Sec. 4.

6 Results: Non-adhesive (‘Hertzian’) contact

We ﬁrst investigate the adhesionless contact of a rigid punch with elastic beams. We will consider beams that are clamped, simply supported, or rest on ﬂexible supports. Some results will be compared with FE simulations of Sec. 5. Equations for the indentation of a non-adhesive beam are obtained by setting λ = 0 in (4.9):

N 3 N X 8ˆγ X (1) 4b0 (2) a2n nm = b2n + for m = 0, ,N. (6.1) J 3π Jnm 3ˆγI¯(1 ν2)Jm ··· n=0 n=0 − The contact pressure vanishes at the edgex ¯ = 1 of the contact zone, so that (4.10) holds. The energy condition (4.11) is now redundant.± The N + 2 equations that comprise (4.10) and (6.1) are to be solved for the N + 2 unknowns b2n (n = 0, ,N) and ∆ for a given choice of A. The contact pressure distribution and the total load··· are then found from (4.1) and (4.5), respectively, after setting λ = 0. Computations are carried out with N = 5, i.e. the expansion (4.1) is truncated at the Chebyshev polynomial T10.

6.1 Clamped beam f f ¯ A clamped beam is obtained in the limit of ks , kt . Thus, ϑp (ˆω) is given by (A.15), (2) → ∞ which then enters into the computation of m in (6.1). The unknown contact pressure distribution ϕ (¯x) is obtained by solving (6.1)J and (4.10). We compare the results of our semi-analytical procedure of Sec. 4 with FE simulations in Fig. 3 and with the results of Keer and Miller (1983) in Fig. 4. We observe from Figs. 3 and 4 that, when the ratio a/h of the contact area to the beam’s thickness is low, the maximum contact pressure is obtained at the center of the contact region. We also find from Fig. 4 that at low a/h ratios the pressure profiles are similar to the pressure distribution obtained for indentation into an elastic half-space. Increasing the a/h ratio – which, for a given beam (fixed h and l) corresponds to increasing the load, as the contact area increases – causes the pressure at the center of the contact region to decrease, but increase near its ends; thus, the pressure profiles acquire a double-humped character. Our semi-analytical results are in good agreement with those of FE simulations, and the theoretical results of Keer and Miller (1983) for a/h / 1; see Figs. 3 and 4, respectively. For a/h > 1, our assumption that the displacement of the beam’s bottom surface may be approximated through Euler-Bernoulli beam theory breaks down. This causes the semi-analytical results to deviate from those of FE computations in Fig. 3. We have followed Keer and Miller (1983) in plotting ap (¯x) /P along the vertical axis in Figs. 3(b) and 4. A match employing this scale may not guarantee a correspondence of the actual pressure profiles ϕ (¯x) or p (¯x). This is because the total load P in the denominator of ap (¯x) /P is calculated by integrating ϕ (¯x) in the numerator. Thus, even

11 ersn h ouinfra lsi afsae eut fKe n ilr(93,when (1983), Miller and Keer of circles. Results Open-circles ﬁlled by half-space. 4. shown Sec. elastic of are an available, procedure for semi-analytical solution the the from represent obtained results pressure are contact lines varying Solid Non-dimensional by beam. investigated clamped are a of contact ap Non-adhesive 4: Figure 4. Sec. of procedure semi-analytical 5. the Sec. of from simulations obtained FE results to correspond are lines lines Dashed Solid pressures contact curves. Non-dimensional areas beam. contact clamped a of contact (a) Non-adhesive 3: Figure (¯

x 3 ϕ ϕ (¯x)=aRlp (¯x) /Kh ) 0.04 0.08 0.12 0.16 (¯ 0.2 /P x 0 n (b) and ) 0 sson h emssedresratio slenderness beam’s The shown. is a 0.2 r netgtdb varying by investigated are ap (¯ (a) x 0.4 0. ) 25 x ¯ /P = ap (¯x) /P 0. 5 0.8 0.2 0.4 0.6 x/a r hw.Teba’ lnens ratio slenderness beam’s The shown. are 0 0.6 0 a/h 0. 0. 0. 1 75 5 25 1. 0. hc r oe ett hi orsodn curves. corresponding their to next noted are which , 1 1. 25 75 25 0.2 0.8 0.4 1 12 x ¯ a/h = x/a hc r oe ett hi associated their to next noted are which , ap (¯x) /P 0.6 0.2 0.4 0.6 0.8 0 0 0. l/h 0. 0. 1 75 25 5 0.8 1. 0 eea otc areas contact Several 10. = 0.2 25 1 0.4 x (b) ¯ = x/a l/h 0.6 1 = / 0.8 0 Several 10. 1 a if a constant factor is missed in p (¯x), the ratio ap (¯x) /P will remain unaffected. Given this, the comparison of pressure profiles shown in Fig. 3(a) is more illuminating. Finally, the pressure profiles in Figs. 3(b) and 4 do not vary much with the slenderness ration l/h. These plots may therefore be utilized to estimate pressures at other l/h as well. Next, the variation of the contact area A with the total load P¯ and with the displacement ∆ of the punch are shown in Fig. 5. Results of both clamped and simply supported beams (discussed in the next section) are shown. From Fig. 5(a) we find that to obtain the same contact area A, a clamped beam requires higher load compared to the simply supported beam. Similarly, Fig. 5(b) shows that, at a given A, a clamped beam displaces less than a simply supported beam. Both these outcomes are expected, as the bending stiffness of the clamped beam is higher than that of a simply supported beam. Thus, the contribution to vertical displacement ∆ from the beam’s bending is lowered in the case of a clamped beam. Similarly, a clamped beam wraps less about the punch, thereby lowering the contact area at given load. The clamped beam’s greater bending stiffness compared to that of a simply supported beam is clearly demonstrated by Fig. 6 that plots the deflection of the beam’s center point – which equals the punch’s displacement ∆ – against the total load P¯. The linear response of ∆ with P¯ is not unexpected as the displacement of the beam’s bottom surface is obtained from beam theory. From Figs. 5 and 6 it is evident that end supports have significant bearing on the beam’s indentation. Finally, in Figs. 5 and 6, we again find a good match both with FE simulations and with the results of Sankar and Sun (1983).

0.12 0.12

0.1 0.1 c 0.08 s 0.08

a/l c a/l = 0.06 = 0.06 s A A

0.04 0.04

0.02 0.02

0 0 0 0.1 0.2 0.3 0 0.1 0.2 0.3 0.4 P¯ = P Rl/Kh3 ∆ = δR/l2

(a) (b) Figure 5: Non-adhesive contact of clamped (‘c’) and simply supported (‘s’) beams. The contact area A is plotted as a function of (a) the total load P¯ acting on the punch and (b) the punch’s displacement ∆. The beam’s slenderness ratio l/h=10. Solid lines are results obtained from the semi-analytical procedure of Sec. 4. Filled circles correspond to FE simulations of Sec. 5. Predictions of Sankar and Sun (1983) are shown by open circles, when available.

13 0.3

0.25

2 s 0.2 R/l δ = 0.15 ∆

0.1 c

0.05

0 0 0.05 0.1 0.15 0.2 0.25 P¯ == P Rl/Kh3

Figure 6: Non-adhesive contact of clamped (‘c’) and simply supported (‘s’) beams. The displacement ∆ of the punch is shown as a function of the total load P¯. See also the caption of Fig. 5.

As mentioned in Sec. 5, the material parameters employed in FE simulations may not be relevant for typical applications. Thus, in Figs. 7 and 8 we report results with parameters more commonly encountered. Following Dalmeya et al. (2012), the Young’s modulus and Poisson’s ratio of the beam are taken corresponding to those observed in soft materials: E = 0.083 MPa and ν = 0.4, respectively. The beam’s geometry remains the same as before. The contact area A is plotted against the total load acting on the punch P¯ and the displacement ∆ of the punch in Fig. 7 for clamped beams of diﬀerent slenderness ratios l/h. A more slender beam is less resistant to bending. Thus, beams with higher l/h require less load compared to lower l/h beams to achieve the same contact area. Hence, the curves in Fig. 7(a) move downward with increasing slenderness ratio. Similarly, the punch’s displacement ∆ is high for more slender beams. Therefore, the curves in Fig. 7(b) also shift downward with growing l/h. Finally, in Fig. 8 we plot variation of the displacement ∆ of the punch with the total load P¯ for diﬀerent l/h ratios. We observe that, our choice of non-dimensionalization (cf. Sec. 3) for the punch’s displacement and the total load allows the curves in Fig. 8 to collapse onto a single line. This is not seen for other scalings, cf. Secs. 7 and 8, where we report results for adhesive contact.

6.2 Eﬀect of end conditions

f f We obtain results for a simply supported beam in the limit ks and kt 0. The vertical displacement of the bottom surface is given by (A.16).→ The ∞ contact→ pressure ϕ (¯x) is then found by solving (6.1) and (4.10), and invoking (4.1). The behavior of a simply supported beam is qualitatively similar to that of a clamped beam, but diﬀers quantitatively. Figure 9 repeats Figs. 3 and 4 for simply supported beams and compare our semi-

14 0.2 0.2

0.16 0.16

5 5 0.12 0.12 a/l a/l = = A 0.08 A 10 0.08 10

0.04 20 0.04 20 30 30 0 0 0 0.05 0.1 0.15 0.2 0.25 0 0.05 0.1 0.15 0.2 P¯ = P Rl/Kh3 ∆ = δR/l2

(a) (b) Figure 7: Non-adhesive contact of clamped beams. Variation of contact area A with (a) total load P¯ and (b) punch’s displacement ∆ is shown. Diﬀerent slenderness ratios l/h are considered and these are noted next to their associated curves.

0.2

0.16

2 0.12 R/l δ =

∆ 0.08 5 10

0.04 20 30

0 0 0.05 0.1 0.15 0.2 0.25 P¯ = P Rl/Kh3

Figure 8: Non-adhesive contact of clamped beams. Variation of punch’s displacement ∆ with total load P¯ is shown. Diﬀerent slenderness ratios l/h are considered as noted in the legend.

15 analytical results with those of FE simulations, and Keer and Miller (1983). As before, we ﬁnd good agreement between all three approaches for a/h / 1.

0.1 0.8 1.25 0.25 0.08

3 1 0.6 0.5 0.75 /Kh 0.75

x ) 0.06

(¯ 1

0.5 /P

x ) 0.4 (¯ aRlp 0.25

0.04 ap x )= (¯

ϕ 1.25 0.2 0.02

0 0 0 0.2 0.4 0.6 0.8 1 0 0.2 0.4 0.6 0.8 1 x¯ = x/a x¯ = x/a (a) (b) Figure 9: Non-adhesive contact of a simply supported beam. Non-dimensional contact pressure (a) ϕ (¯x) and (b) ap (¯x) /P are shown. Several contact areas are investigated by varying a/h as noted next to the associated curves, while keeping l/h = 10. Solid lines are results obtained from the semi-analytical procedure of Sec. 4. Dashed lines in (a) correspond to FE simulations of Sec. 5. Open circles in (b) represent the solution for an elastic half-space. Results of Keer and Miller (1983), when available, are shown in (b) by ﬁlled circles.

Contrasting Figs. 3(a) and 9(a) we find that, at the same a/h, pressures found in a simply supported beam are lower compared to those in a clamped beam. Thus, the total load P¯ required to achieve the same contact area, for clamped and simply supported beams of the same thickness, is very different. This reinforces the importance of correctly modeling end supports in beam indentation. Interestingly, because of the manner in which the contact pressure is scaled, Figs. 4 and 9(b) are nearly the same. Finally, we report results on the non-adhesive contact of beams resting on flexible supports with parameters utilized to generate Figs. 7 and 8. Again, for beams with slenderness ratio l/h = 10, the contact area A is plotted against the total load P¯ acting on the punch and the punch’s displacement ∆ in Figs. 10 and 11. Figure 10 shows results f for several torsional spring stiffnesses kt after setting the vertical translational spring’s f stiffness ks to infinity. Such a beam may be thought of as a simply supported beam with some resistance to rotation at the ends, or a beam whose clamped ends allow some rotational play. Results lie between those obtained for clamped and simply supported f beams. Expectedly, increasing kt shifts the results towards those of a clamped beam, and decreasing it yields results close to those of a simply supported beam. This is seen clearly in Fig. 10. f f Figure 11 repeats Fig. 10, but this time keeping kt as infinity and varying ks . We f ¯ find that increasing ks does not affect the variation of A with P , but the dependence

16 and respectively, become, (3.8) and (3.10) pressure, contact the along i.e. for (3.10) stiffness, (4.1) equation elastic integral dominating expansion strength the adhesive solve of to limit need the λ we in Thus, (3.8), previ- balance 3. approximation, energy and JKR with 2 the invoking Secs. approximation after in discussed beams JKR ously of contact - adhesive consider contact now We Adhesive Results: 7 in variation by unaffected also from are initiates now indentation that y so downwards, datum the ∆ displacement vertical the of respectively. beams, clamped a and supported simply for ratio area k slenderness contact load The beam’s total stiffness The supports. the spring’s flexible (a) on ∆. of beams function displacement of a contact as adhesive plotted Non 10: Figure t f .Oc ecretfr∆ for correct we Once 0. = ∞ → A r niae ett hi soitdcre.Oe n le ice ersn results represent circles filled and Open curves. associated their to next indicated are

n∆cags e h ne nFg 1b.Telte hnei,hwvr u to due however, is, change latter The 11(b). Fig. in inset the see changes; ∆ on A = a/l 0.02 0.04 0.06 0.08 hl h deiezn eoe nntsmlysal ota ¯ that so small, infinitesimally becomes zone adhesive the while , 0.1 0 0 X n N =0 a 2 0.05 n J k s f nm = P ¯ = 0.1 (a) = b 0 ∞ 0 Rl/Kh P 8ˆ 3 + aiu osoa pig r osdrdadterstiffnesses their and considered are springs torsional Various . γ π 3 b 1 0.15 l 2 X n N =0 l fteba’ pigspot.Tepeec f∆ of presence The supports. spring beam’s the of + efidta ipaeetposi h ne fFg 11(b) Fig. of inset the in plots displacement that find we 3 3 · · · b 2 n 0.2 k J + 500 s f nm ssoni i.11(b). Fig. in shown as , (1) b 2 N + 0.25 = 3ˆ 17 γ P − ¯ I ¯ 2 (1 cigo h uc n b h punch’s the (b) and punch the on acting 4 m πL A = a/l b 0.02 0.04 0.06 0.08 0.1 − 0 l/h 0 0 ν 2 h l ) 0 h etcltranslational vertical The 10. = J 3 m (2) r 0.1 6 Am for L 500 y (b) ∆ m ∆ = . = 0.2 δ 0 = R/l l 3 ahrta from than rather , c 2 , · · · → 1 0.3 .Employing 1. N , 0 l 0.4 shifts (7.2) (7.1) A is 0.1 0.1 f ks =1 1500 f 4 ks =2 2 0.08 0.08 1 f 0.08 ks =4 A kf = 1500 s 0.04 0.06 0.06 a/l a/l =

= 0

A 0 1 2 0.04 A 0.04 ∆ = δR/l2

kf =1 0.02 0.02 s f ks =4 f ks = 1500 0 0 0 0.05 0.1 0.15 0.2 0.25 0 0.05 0.1 0.15 0.2 P¯ = P Rl/Kh3 ∆ ∆ − l (a) (b) Figure 11: Non-adhesive contact of beams on flexible supports. The contact area A is plotted as a function of (a) the total load P¯ acting on the punch and (b) the adjusted punch displacement ∆ ∆l. The inset in (b) shows the variation of the contact area A with the punch’s displacement− ∆. The beam’s slenderness ratio l/h = 10. The torsional f spring stiffness kt = . Various vertical translational springs are considered and their f ∞ stiffnesses ks are indicated either in the legend or next to their associated curves. Filled circles in the inset in (b) represent results for a clamped beam.

18 From here on, we follow Maugis (1992) and employ

AL K 1/3 PH¯ 3 P ∆L2 K2 1/3 Aˆ = = a , Pˆ = = and ∆ˆ = = δ , m πwR2 Lm3 πw m2 π2w2R (7.3) where H = h/R, instead of, respectively, A, P , and ∆, to report our results. This is done in order to facilitate contact with other work on adhesion. We set the adhesion energy w = 0.02 10−3 J/mm2. Figure× 12 plots the variation of the contact area Aˆ with the total load Pˆ acting on the punch and with punch’s displacement ∆ˆ for clamped beams. While the slenderness ratio l/h = 10, two different combinations of l and h are considered. From Fig. 12 we observe that the variation of Aˆ with Pˆ and ∆ˆ is sensitive to the choice of l and h, notwithstanding the fact that l/h is kept constant. This is in contrast to the case of non-adhesive contact of Sec. 6, where results depended only on l/h. However, this behavior is expected for adhesive beams as the right hand side of (7.2) depends on L = l/R. This aspect is further exemplified in Fig. 13, which plots Aˆ against Pˆ and ∆ˆ for clamped beams for different choices of l and h.

4 4

3 3 AL/m 2 AL/m 2 = = ˆ ˆ A A

1 1

0 0 −40 −20 0 20 −400 −200 0 200 Pˆ = PH¯ 3/Lm3 ∆ˆ = ∆L2/m2

(a) (b) Figure 12: Adhesive contact of clamped beams with the JKR approximation. Variation of contact area Aˆ with the (a) total load Pˆ and (b) the punch’s displacement ∆.ˆ The beam’s slenderness ratio l/h = 10. Solid lines correspond to l = 40 mm and h = 4 mm, while the dashed line is for a beam with l = 80 mm and h = 8 mm.

In Figs. 12 and 13, negative values of Pˆ and ∆ˆ reﬂect tensile loads and upward displacement of the punch, respectively. We recall that ∆ˆ equals the deﬂection of the center point on the beam’s top surface, so that ∆ˆ < 0 indicates that the beam bends upwards. Negative values of Pˆ and ∆ˆ are due to the attractive adhesive forces. Due to adhesion, the beam bends upwards and jumps into contact. Equivalently, adhesive forces also act on the punch to pull it down, so that we require a tensile force to hold the punch in it’s place. This tensile force Pˆ is small for slender beams as they bend easily. For the same reason, this tensile force is smaller for a simply supported beam compared

19 to a clamped beam of the same thickness; cf. Fig. 14. Once contact is established, the tensile force is slowly released and replaced by a compressive (downwards) force in order to increase downward indentation. Again, for compressive loads, thin beams bend more easily to wrap around the punch. Thus, slender beams show greater contact area and displacement at the same compressive load Pˆ. This explains the intersection of the curves in Fig. 13. Therefore, with increasing slenderness ratio, the Aˆ–Pˆ curves in the left column of Fig. 13 move towards (inwards) the zero-load (Pˆ = 0) vertical line, and Aˆ–∆ˆ curves in the right column of Fig. 13 move away (outwards) from the ∆ˆ = 0 line.

8 8 (a) l=40 mm (b) l=40 mm 1

6 6 0.8

0.6 ˆ A AL/m 4 AL/m 4 0.4 = = ˆ ˆ A A 0.2 20 10 5 2 2 0 −1000 −500 0 l/h = 5 ∆ˆ 10 20 20 10 5 = l/h 0 0 −50 0 50 −1500 −1000 −500 0 500 Pˆ = PH¯ 3/Lm3 ∆ˆ = ∆L2/m2

4 4 (c) h=4 mm (d) h=4 mm 20

3 3 10 AL/m AL/m 2 5= l/h 2 = = ˆ ˆ A A

1 1

20 10 5 = l/h 0 0 −40 −30 −20 −10 0 10 −2000 −1500 −1000 −500 0 500 Pˆ = PH¯ 3/Lm3 ∆ˆ = ∆L2/m2

Figure 13: Adhesive contact of clamped beams with the JKR approximation. Left column reports the variation of contact area Aˆ with total load Pˆ, while the right column plots the change of Aˆ with the punch’s displacement ∆.ˆ Results in the top row are obtained by setting l = 40 mm and varying h as shown, while those in the bottom row have h = 4 mm but diﬀerent l, as indicated. The inset in (b) illustrates behavior at low Aˆ.

Finally, for adhesive beams on ﬂexible supports we plot the contact area Aˆ against the

20 ˆ ˆ f load P and displacement ∆ for various kt in Fig. 14. Convergence to the results obtained f for clamped and simply supported beams may be observed in Fig. 14 by varying kt . From f our discussion in Sec. 6.2, we know that the variation of ks does not aﬀect how the contact area Aˆ varies with the load Pˆ. At the same time, change in Aˆ with the displacement ∆ˆ f is aﬀected by variation in ks only through the vertical displacement of the translational ˆ springs supporting the beam at its ends. By removing this global displacement ∆l from ˆ ˆ ˆ ˆ f ∆ – as in Sec. 6.2 – the response of A to ∆-∆l is found to be invariant to ks .

4 4 4 4 0 500 3 1 1 3 0 3 500 3 3 3 ˆ ˆ A A

2 2 AL/m AL/m 2 2 = = ˆ ˆ A A 0 Pˆ 2 4 0 20 ∆ˆ 40 60

1 1 3 500 1 0 0 1 3 500 0 0 −30 −20 −10 0 10 −1000 −500 0 500 Pˆ = PH¯ 3/Lm3 ∆ˆ = ∆L2/m2 (a) (b) Figure 14: Adhesive contact of beam on flexible supports with the JKR approximation. The contact area Aˆ is plotted as a function of (a) the total load Pˆ acting on the punch and (b) the punch’s displacement ∆.ˆ The beam’s thickness h = 4 mm and l = 40 mm. The f vertical translational spring’s stiffness ks = . Various torsional springs are considered f ∞ and their stiffnesses kt are indicated next to their associated curves. The insets correspond to behavior at high Aˆ. Open and filled circles represent results for adhesive beams that are, respectively, simply supported and clamped.

8 Results: Adhesive contact with an adhesive zone model

We ﬁnally consider contact with an adhesive beam within the framework of adhesive zone models. As already mentioned, we will assume that an adhesive zone of length d = c a extends outside the contact zone; cf. Fig. 2(b). Within the adhesive zone the interaction− is modeled through the Dugdale-Barenblatt model of (2.7). To obtain the contact pressure ϕ (¯x), the displacement ∆ and the location c of the adhesive zone’s edge, we have to solve (4.9)–(4.11). For the clamped beam we plot in Fig. 15 the contact area Aˆ against the total load Pˆ and displacement ∆ˆ for various adhesive strengths λ. With increase in λ, the solutions

21 approach the JKR solution, and we see a close match at λ = 3. On the other hand, as λ 0, i.e. as adhesion reduces, solutions approach those obtained for non-adhesive contact→ in Sec. 6.

4 4

3 3 AL/m 2 AL/m 2 = = ˆ ˆ A A

1 1

3 0.2 3 0.005 0.2 0.005 0 0 −30 −20 −10 0 10 −300 −200 −100 0 100 Pˆ = PH¯ 3/Lm3 ∆ˆ = ∆L2/m2

(a) (b) Figure 15: Adhesive contact of clamped beams with an adhesive zone model. Variation of contact area Aˆ with (a) the total load Pˆ and (b) the punch’s displacement ∆.ˆ Diﬀerent adhesive strengths λ are considered and these are indicated next to their associated curves. The beam’s thickness h = 4 mm and l = 40 mm. Filled circles represent the JKR solution for the corresponding beam; cf. Sec. 7

From previous discussions, it is expected that results for beams with flexible supports will lie between those obtained for clamped and simply supported beams. Hence, we do not explore this parameter space in great detail. We only consider the variation of Pˆ ˆ ˆ f and ∆ with A for several values of torsional stiffness kt for a beam with h = 4 mm and l = 40 mm. Two different adhesive strengths λ are investigated. The results are shown f f in Fig. 16. The vertical translational spring’s stiffness ks is set to infinity. When kt = 0, the solutions match with those of a simply supported beam with the corresponding λ. f With increase in kt , the solution curves move towards those obtained for a clamped beam f and will coincide when kt becomes infinity. It is seen in Fig. 16 that curves for different f kt intersect with each other due to rotation permitted at the supports by the torsional springs – greater the rotation allowed, higher the displacements, and lower the loads for the same contact area. This intersection point moves up with increasing λ, as strong adhesive forces are able to bend the beam upwards more easily. Finally, in Fig. 17 we plot the variation of the non-dimensional adhesive zone size ¯ ˆ f d =c ¯ 1 with the contact area A for different adhesive strengths λ and various kt . We observe− that the adhesive zone size is large for smaller λ, and decreases with increasing λ, finally vanishing as λ . Moreover, we find that the adhesive zone’s size does not → ∞ f f vary much with the slenderness ratio l/h, and spring stiffnesses ks and kt .

22 pnadfildcrlsrpeetrslsfrasml upre n lme beam, clamped a and supported simply a for results corresponding represent the at circles respectively, filled and Open half-span and mm strengths adhesive different model. area zone of adhesive contact stiffnesses change an of the with variation plots supports the flexible row on reports beams row of Top contact Adhesive 16: Figure

Aˆ = AL/m ˆ

−150 A = AL/m 0 1 2 3 4 −5 0 1 2 3 4 (c) (a) k λ=0 t f −100 λ=0 r osdrd n hyaentdnx oterascae uvs Two curves. associated their to next noted are they and considered, are . 005 . 005 ∆ P ˆ −50 ˆ l = = 0m.Teist n()ad()dpc eaira high at behavior depict (d) and (b) in insets The mm. 40 = ∆ PH ¯ L A 0 ˆ 2 3 /m /Lm ihtepnhsdisplacement punch’s the with 0 λ 2 500 r osdrd sidctd h emsthickness beam’s The indicated. as considered, are 3 0 1 50 3 λ 1 3 . 0 500 100 5 23 A ˆ Aˆ = AL/m Aˆ = AL/m −1000 ihttlload total with −30 0 1 2 3 4 0 1 2 3 4 (d) (b) 2 Aˆ 3 4 λ=3 2 3 4 Aˆ λ=3 0 .Dffrn osoa spring torsional Different ∆. 0 ˆ −20 1 0 −500 20 500 P 500 ˆ ∆ 3 ˆ ∆ ˆ P = ˆ = 0 P 40 PH ˆ 3 ¯ ∆ 2 1 −10 1 3 hl h bottom the while , 3 0 L 0 500 3 500 2 /Lm /m 60 2 0 4 3 1 0 h 4 = 500 10 A ˆ . hnfudfloigCaduye l 19) h K xeiet ofimterange the confirm experiments JKR of The values (1996). noted al. is punch et for modulus the Chaudhury Young’s on following acting The found load the then balance. and inset semi-micro microscope, employing upper a the the punch through from in observed glass shown is the formed, 18(a), with thus Fig. patch contact of contact into rectangular brought The PDMS are micro-positoner. samples tests, the PDMS these The In 18(a). radius Fig. out. of carried punch glass are drical tests 1996) thickness al., of samples et (Chaudhury indentation JKR modulus Young’s ( mould. temperature rectangular the room a from into at extracted poured cured is then is sample is 10:1 This which in PDMS size. them mixture, taking desired this by from of mixture prepared desiccated mould uniform is is agent a Air curing samples, and PMDS ratio. base weight make elastomer To silicone punch. 184 glass Sylgard (poly-dimethyl- of cylindrical PDMS a clamped by a beam of siloxane) indentation the investigated experimentally have We 1(a). Fig. Experiments in shown type the as 9.1 of beam, adhesives clamped structural a model on to results methods experimental our preliminary apply present as we well section, final Applications this In and Experiments 9 k iue1:Ahsv otc fbaso eil uprswt nahsv oemodel. zone adhesive an with size supports zone’s flexible strengths adhesive on the beams of of Variation contact Adhesive 17: Figure t f at E is,mcotnietssaecridoto h DSsmlst esr their measure to samples PDMS the on out carried are tests micro-tensile First, d¯=¯c 1 on rmmcotnietss n n h oko adhesion of work the find and tests, micro-tensile from found λ − 0 1 2 3 4 5 0 = 0 E λ with , 3 . and 5. k t f 1 = ∞ 0.5 w 1 k E opr elwt hs eotderirb ontne l 21) and (2014), al. et Johnston by earlier reported those with well compare t f A hsi on ob nterneo P.Nx,standard Next, MPa. 2 – 1 of range the in be to found is This . ˆ (a) = h 0.2 = ≈ ∞ AL/m 2 5m r iil tahdt h ir-oiinr n cylin- a and micro-positioner, the to attached rigidly are mm 25 and R λ=0 ≈ k s f 3 . 27 005 = . mi lcdo o ftesm-ir aac;see balance; semi-micro the of top on placed is mm 5 ∞ d ¯ n b he ieettrinlsrn stiffnesses spring torsional different three (b) and , ihtecnatarea contact the with 4 24

d¯=¯c 1 − 0 1 2 3 4 5 0 E λ=0 n h oko adhesion of work the and . 5 ≈ 1 A 17 ˆ (b) o o a ieetadhesive diﬀerent (a) for A ˆ )frtody n the and days two for C) = w AL/m 2 ≈ 7mJ/mm 27 3 k k k t t t f f f 500 = =3 =0 2 w The . 4 are Arul and Ghatak (2008).

Microscope 2.5 h = 8 mm 2

Micro-positioner 1.5 stand Top view (mm)

Beam a 1 h = 25 mm 0.5

Punch 0 −1 0 1 2 3 4 5 6 7 8 Weighing P (g) Balance

(a) (b) Figure 18: (a) Indentation experiments for an adhesive clamped beam of thickness h = 8 mm and half-span l = 50 mm. Insets show a closeup of the side view of the indentation and a top view of the contact patch. (b) Variation of the contact area a (in mm) with the total load P (in g). Filled circles represent experimental data. Solid lines correspond to theoretical predictions. For h = 8 mm, we followed Sec. 7, while h = 25 mm, we employed the standard JKR solution for a half-space (Chaudhury et al., 1996).

Finally, contact mechanics experiments are carried out on a clamped PDMS beam. In these experiments, the beam’s half-span and thickness are maintained at l 50 mm and h 8 mm, respectively. The total load P and contact patch width 2a are measured.≈ The results≈ obtained are then compared with the predictions of our semi-analytical approach in Fig. 18(b). We ﬁnd good agreement. We observe that the results for a beam vary considerably from that of a half-space lending support for the necessity of the theoretical development presented in this paper. More thorough experiments, where we vary parameters like ﬂexibility of end supports, beam thickness h, the work of adhesion w, etc. are under progress.

9.2 Application We now demonstrate the application of our semi-analytical procedure to the indentation of structural adhesives with one micro-channel, as shown in Fig. 19(a). To this end, the parameters shown in Table 1 are employed to generate our theoretical results. The stiffnesses of the flexible end supports are estimated from a strength-of-materials approach f 0 3 3 f 0 3 3 to be ks 12b l /hch and kt lb /hch , where the various geometrical parameters are indicated≈ in Fig. 19(a). Here≈ we have assumed b0 > h, as b0 is not reported by Arul and Ghatak (2008). Our results are then compared with the experimental results of Arul and Ghatak (2008) in Fig. 19(b). We find good agreement upto an indentation depth δ 0.1 mm, i.e. until the point S23. At this point, the bottom surface S2 begins ≈ 25 Geometrical and material parameters Value Beam thickness h = 0.8 mm Micro-channel’s thickness hc = 0.1 mm Beam’s length 2l = 5 8 mm Punch radius R = 2.−24 mm Punch length lp = 2.7 mm Shear modulus G = 1 MPa Poission’s ratio ν = 0.49 Young’s modulus E = 2 (1 + ν) 3 MPa Work of adhesion w = 0.045 10≈−3 mJ/mm2 or N/mm ×

Table 1: Geometrical and material parameters considered for modeling adhesives with one micro-channel; see also Fig. 19(a). These values are taken from Arul and Ghatak (2008).

to interact with the surface S3 in experiments. This feature is not yet implemented in our mathematical model, so that it is expected that our predictions will deviate from experimental observations.

10 Conclusions

In this article we present a theoretical model for the indentation of adhesive beams mounted on flexible supports. Adhesion, when present, was incorporated through either the JKR approximation or an adhesive zone model. We approximate the displacement of the bottom surface of the beam through Euler-Benoulli beam theory. This is then utilized to formulate a boundary value problem, which is reduced to a single Fredholm integral equation of the first kind for the unknown contact pressure. The integral equation is then solved through a Galerkin projection employing Chebyshev polynomials. Finite element (FE) simulations were carried out for clamped and simply supported non-adhesive beams, and our results compared well with FE predictions, as well as with previously reported theoretical results. Results for adhesive contact were found for several combinations of adhesive strengths, beam geometries, and support flexibilities characterized through torsional and vertical translational springs. Theoretical results for adhesive clamped beam were compared with preliminary experiments and a satisfactory match was observed. Fi- nally, we demonstrated the application of our approach to model a complex structural adhesive. The semi-analytic technique presented here assumes that the displacement vb of the beam’s bottom surface is approximated well by Euler–Bernoulli beam theory. This assumption is seen to hold for contact areas less than or equal to the beam’s thickness, i.e. a/h . 1. For deeper indentations, we need to formulate the contact problem in terms of two unknowns, viz. the contact pressure p(x) and the displacement vb(x), and then solve the ensuing dual integral equations. This is done in the second part of this work. We will report extensive experiments on the adhesive contact of beams in the third part of this series. Looking further forward, we envisage extending our technique to modeling adhesive interaction of one beam with another, as is observed in multi-layered structural adhesives shown in Fig. 1. The present framework may also be adapted to three-dimensional axi-symmetric adhesive contact of punches with plates.

26 20

P 16

Punch N) 12 3 − S1 Air 10 × h ( 8 S23 P Structural S2 h S3 c adhesive 2l b 4

Rigid Platform 0 0 0.05 0.1 0.15 δ (mm) (a) (b) Figure 19: (a) A structural adhesive with one micro-channel. (b) Variation of the total load P with the punch’s displacement δ. The solid line represents the solution obtained from the procedure of Sec. 7. Asterisk (*) are the experiemtal results of Arul and Ghatak (2008).

11 Acknowledgements

We thank Dr. T. Bhuvana, Prof. P. Venkitanarayanan and Prof. S. L. Das of the Depart- ment of Mechanical Engineering, IIT Kanpur, for help with experiments. We acknowledge partial ﬁnancial support from the Department of Mechanical Engineering, IIT Kanpur. We are also grateful to Prof. Akash Anand from the Department of Mathematics and Statistics, IIT Kanpur for useful discussions.

A Calculations using beam theory

In this section, we ﬁnd the displacement of an Euler-Bernouli beam subjected to a point load at its center and resting on ﬂexible supports, as shown in Fig. 20.

x P kt h kt

ks ks

y l l

Figure 20: An Euler-Bernoulli beam on ﬂexible supports acted upon at its center by a concentrated force P .

27 From Euler-Bernoulli beam theory (Crandall et al., 2008, p. 165, 523, 543) we ﬁnd

d4v (x) EI n = P x −1, (A.1) dx4 h i where vn (x) is the displacement of the neutral axis (dash-dot line in Fig. 20) and

x, x > 0 x = h i 0, x 0. ≤ The appropriate boundary conditions are: P P vn x=−l = , vn x=l = , (A.2a) | 2ks | 2ks 2 2 dvn d vn dvb d vn kt = EI 2 and kt = EI 2 . (A.2b) dx x=−l dx x=−l − dx x=l dx x=l

Identifying the displacement vb of the beam’s bottom surface with vn, as is done in beam theory, and solving (A.1) and (A.2), provides

2 P 1 3 1 3 x l EI vb (x) = x x 1 + EI 6h i − 12 − 8 ktl + EI 1 EI EI + l3 + 3l3 + 12 . (A.3) 24 ktl + EI ks

As the displacement is symmetric in x, we henceforth employ vb (x) for x 0 in our calculations. ≥ Non-dimensionalizing (A.3) following Sec. 3, we obtain

¯ 3 3 2 4P τˆ τˆ τˆ −1 1 −1 −1 ϑb (ˆτ) = h i 1 + K + 1 + 3K + 12K , (A.4) 3I¯(1 ν2) 6 − 12 − 8 t 24 t s − −1 f −1 −1 3 f −1 where Kt = EI/(ktl + EI) = (1 + kt ) and Ks = EI/ksl = ks . When we extended the beam to inﬁnity – cf. Fig. 2(b) – the displacement of the overhang, i.e.τ ˆ > 1, is given by

dϑb (ˆτ) ϑb (ˆτ) = ϑb (ˆτ) τˆ=1 + (ˆτ 1) . (A.5) | dτˆ τˆ=1 − Calculating the displacement and slope atτ ˆ = 1 from (A.4) and substituting in (A.5) yields 4P¯ 1 1 ϑ (ˆτ) = (ˆτ 1) , τˆ > 1. (A.6) b 2 3I¯(1 ν ) 2Ks − 4Kt − − Finally, the displacement of the extended beam’s bottom surface over its entire length may be written as 4P¯ ϑ (ˆτ) = ϑ (ˆτ) , (A.7) b 3I¯(1 ν2) p − where τˆ3/12 τˆ2 1 + K−1 /8 + 1 + 3K−1 + 12K−1 /24 , 0 τˆ 1 ϑ (ˆτ) = t t s (A.8) p K−1/2− K−1 (ˆτ 1) /4 , τˆ > 1. ≤ ≤ s − t − 28 Finally, we evaluate the Fourier transform

∞ ∞ Z Z ˆ ϑb (ˆω) = ϑb (ˆτ) cos (ˆωτˆ) dτˆ = 2 ϑb (ˆτ) cos (ˆωτˆ) dτ,ˆ (A.9) −∞ 0 which is required in (3.10). The above integrals are typically undefined, as ϑ (ˆτ) is un- bounded once the beam is extended to infinity, unless the beam is clamped. To overcome this, we invoke St. Venant’s principle by which, displacement of the overhang, sufficiently far away from the supports, may be modified without exerting any significant influence on the displacement and stresses in the portion of the beam lying within the supports. To this end, we modify the displacement of the beam’s bottom surface by introducing

M ϑ (ˆτ) = ϑb (ˆτ) W (ˆτ) , (A.10) b · with  1, forτ ˆ ˆl ,  1 ˆ ≤ ˆ W (ˆτ) = w2 (ˆτ) , for l1 < τˆ < l2 , (A.11)  ˆ 0, forτ ˆ l2, ≥ where 2 ˆ exp 1/ l2 τˆ − − w (ˆτ) = , (A.12) 2 2 2 ˆ ˆ exp 1/ l2 τˆ + exp 1/ τˆ l1 − − − − ˆ ˆ ˆ and l1 and l2 locate points on the beam that are far away from its supports, i.e. l2 > ˆ l1 >> 1. The function W (ˆτ) is a mollifier, see Muthukumar (2016), and is infinitely differentiable everywhere. M The mollified displacement ϑb (ˆτ) in (A.10) is now utilized in (A.9) to compute the Fourier transforms. Thus,

∞ ∞ Z Z ˆ M ϑb (ˆω) 2 ϑ (ˆτ) cos (ˆωτˆ) dτˆ = 2 ϑb (ˆτ) W (ˆτ) cos (ˆωτˆ) dτ.ˆ (A.13) ≈ b 0 0

Evaluating the above integral and replacing the total load P¯ from (4.5) in the resulting equation provides ˆ 4πb0 4λAmc¯ ˆ ϑb (ˆω) = ϑp (ˆω) , (A.14) 3I¯(1 ν2) − 3ˆγ3IL¯ (1 ν2) − − where ∞ Z ˆ ϑp (ˆω) = 2 ϑp (ˆτ) W (ˆτ) cos (ˆωτˆ) dτ.ˆ (A.15) 0 f f Setting kt and ks , we obtain results for a clamped beam, while those for a → ∞ → ∞ f f simply supported beam are found by taking kt 0 and ks . Finally, we write → → ∞ 1 ˆ 4b0 4λAmc¯ ˆ ϑb (ˆω) = ϑp (ˆω) . (A.16) πγˆ 3I¯(1 ν2)γ ˆ − 3πγˆ4IL¯ (1 ν2) − − 29 B Vertical displacement of the beam’s top surface in Fourier space V (ξ, 0)

In Fourier space, the transformed horizontal and vertical displacements may be solved as, respectively,

ξy −ξy U (ξ, y) = κa1 + ξy (a1 + ia3) e + κb1 ξy (b1 ib3) e , (B.1) { } ξy { − − } −ξy and V (ξ, y) = κa3 + iξy (a1 + ia3) e + κb3 + iξy (b1 ib3) e , (B.2) { } { − } with ∞ ∞ Z Z U (ξ, y) = u (x, y) eiξxdx and V (ξ, y) = v (x, y) eiξxdx,

−∞ −∞ where a1, a3, b1 and b3 are unknown constants. These constants are obtained by satisfying boundary conditions (2.2), which in Fourier space are

¯ at y = 0 : Sξy= 0,Syy= Pc(ξ), (B.3a)

and at y = h : Sξy= 0,V =v ¯b(ξ), (B.3b) with

E d Sξy = U iξV , 2 (1 + ν) dy − E d ν d Syy = V + iξU + V , (1 + ν) dy 1 2ν − dy ∞ − ∞ Z Z ¯ iξx iξx Pc(ξ) = Pc (x) e dx andv ¯b(ξ) = vb (x) e dx. − −∞ −∞

Solving (B.1)–(B.3), we obtain the vertical displacement of the beam’s top surface in Fourier space as

¯ 2 2 Pc (ξ) sinh ξ h sinh ξ h + ξ h cosh ξ h V (ξ, 0) = +v ¯b (ξ) . − E∗ ξ (ξ h + sinh ξ h cosh ξ h) ξ h + sinh ξ h cosh ξ h

C Evaluation of the integrals αn (ω¯)

We recall from (4.4) in Sec. 4 that

1 Z 1 αn (¯ω) = Tn (¯τ) cos (¯ωτ) dτ.¯ (C.1) p(1 τ¯2) −1 −

We now compute these integrals explicitly. First, consider odd n. For this, the integrand is an odd function so that

α2n−1 (¯ω) = 0. (C.2)

30 Next, evaluating (C.1) for even n we obtain the ﬁrst few αn as

α0 (¯ω) = π J (0, ω¯), 2 π J (1, ω¯) α2 (¯ω) = π J (0, ω¯) , − ω¯ 8 π J (1, ω¯) 24 π J (0, ω¯) 48 π J (1, ω¯) α4 (¯ω) = π J (0, ω¯) + , − ω¯ − ω¯2 ω¯3 18 π J (1, ω¯) 144 π J (0, ω¯) 768 π J (1, ω¯) and α6 (¯ω) = π J (0, ω¯) + − ω¯ − ω¯2 ω¯3 1920 π J (0, ω¯) 3840 π J (1, ω¯) + , (C.3) ω¯4 − ω¯5 where J (n, ω¯) are the Bessel’s functions of the ﬁrst kind of order n. Employing the recurrence relation (Polyanin and Manzhirov 2008, p. 1016), 2n J(n + 1, ω¯) = J(n, ω¯) J(n 1, ω¯), ω¯ − − we rewrite (C.3) as

α2 (¯ω) = π J (2, ω¯), α4 (¯ω) = π J (4, ω¯) and α6 (¯ω) = π J (6, ω¯). − − In general, it is possible to show that

n α2n (¯ω) = ( 1) π J (2n, ω¯). (C.4) −

References

Alexandrov, A., Pozharskii, D. (2001). Three-dimensional contact problems. Kluwer Academic Publishers, Dordrecht, The Netherlands.

Arul, E. P., Ghatak, A. (2008). Bioinspired design of a hierarchically structured adhesive. Langmuir, 25: 611–617.

Barthel, E., Perriot, A. (2007). Adhesive contact to a coated elastic substrate. J. Phys. D: Appl. Phys., 40: 1059–1067.

Chatterjee, A. (2002). Lecture notes: An elementary continuation technique. http:// home.iitk.ac.in/~anindya/continuation.pdf. Chaudhury, M. K., Weaver, T., Hui, C., Kramer, E. (1996). Adhesive contact of cylindrical lens and a ﬂat sheet. J. Appl. Phys., 80: 30–37.

Crandall, S. H., Dahl, N. C., Lardne, T. J. (2008). Mechanics of Solids. Tata McGraw-Hill Education Pvt. Ltd., New Delhi, India.

Dalmeya, R., Sharma, I., Upadhyay, C., Anand, A. (2012). Contact of a rigid cylindrical punch with an adhesive elastic layer. J. Adhes., 88: 1–31.

Derjaguin, B. V., Muller, V. M., Toporov, Y. P. (1975). Eﬀect of contact deformations on the adhesion of particles. J. Colloid Interface Sci., 53: 314–326.

31 Galin, L. A., Gladwell, G. M. L. (2008). Contact Problems: The legacy of L.A. Galin. Solid Mechanics and Its Applications, Springer Netherlands.

Gladwell, G. M. L .(1980). Contact Problems in the Classical Theory of Elasticity. Sijthoﬀ & Noordhoﬀ Publishers, Alphen aan den Rijn, The Netherlands.

Hiller, U. J. (1976). Comparative studies on the functional morphology of two gekkonid lizards. Bombay Nat. Hist. Soc., 73: 278 – 282.

Hills, D. A., Nowell, D., Sackﬁeld, A. (1993). Mechanics of Elastic Contacts. Butterworth- Heinemann, Oxford, UK.

Johnson, K. L. (1985). Contact Mechanics. Cambridge U. Press, Cambridge, UK.

Johnson, K. L., Kendall, K., Roberts, A. D. (1971). Surface energy and the contact of elastic solids. Proc. R. Soc. Lond., A, 324: 301–313.

Johnston, I. D., McCluskey, D. K., Tan, C. K. L., Tracey, M. C. (2014). Mechanical char- acterization of bulk Sylgard 184 for microﬂuidics and microengineering. J. Micromech. Microeng., 24: 035017.

Kanninen, M. F., Popelar, C. L. (1985). Advanced Fracture Mechanics. Oxford U. Press, New York, USA.

Keer, L. M., Miller, G. R. (1983). Smooth indentation of ﬁnite layer. J. Eng. Mech., 109: 706–717.

Keer, L. M., Schonberg, W. P. (1986). Smooth indentation of an isotropic cantilever beam. Int. J. Solids Struct., 22: 87–106.

Keer, L. M., Silva, M. A. G. (1970). Bending of a cantilever brought gradually into contact with a cylindrical supporting surface. Int. J. Mech. Sci., 12: 751–760.

Kim, J. H., Ahn, Y. J., Jang, Y. H., Barber, J. R. (2014). Contact problems involving beams. Int. J. Solids Struct., 51: 4435–4439.

Mason, J.C., Handscomb, D.C. (2003). Chebyshev Polynomials. Chapman & Hall/CRC, Boca Raton, Florida, USA.

Maugis, D. (1992). Adhesion of spheres: the JKR-DMT transition using a Dugdale model. J. Colloid Interface Sci., 150: 243–269.

Muthukumar, T. (2016). Lecture notes: Sobolev spaces and applications. http://home. iitk.ac.in/~tmk/courses/mth656/main.pdf. Polyanin, A., Manzhirov, A. (2008). Handbook of Integral Equations: Second Edition. Chapman & Hall/CRC, Boca Raton, Florida, USA.

Press, W. H., Teukolsky, S. A., Vetterling, W. T., Flannery, B. P. (1992). Numerical Recipes in C: The Art of Scientiﬁc Computing. Cambridge U. Press India Pvt. Ltd., New Delhi, India.

Rice, J. R. (1968). A path independent integral and the approximate analysis of strain concentration by notches and cracks. J. Appl. Mech., 35: 379–386.

32 Sadd, M. H. (2005). Elasticity: Theory, Applications, and Numerics. Elsevier India, New Delhi, India.

Sankar, B. V., Sun, C. T. (1983). Indentation of a beam by a rigid cylinder. Int. J. Solids Struct., 19: 293–303.

Sneddon, I. N., (1995). Fourier Transforms. Dover Publications, New York, USA.

Sun, C. T., Sankar, B. V. ( 1985). Smooth indentation of an initially stressed orthotropic beam. Int. J. Solids Struct., 21: 161–176.

Timoshenko, S. P., Goodier, J. N. (1970). Theory of Elasticity. McGraw-Hill, Singapore.
