M-545 XY Microscope Stage with Ultrasonic Linear Drives High Stability, Low Profile, High Speed, Direct Position Measurement

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
M-545 XY Microscope Stage with Ultrasonic Linear Drives High Stability, Low Profile, High Speed, Direct Position Measurement M-545 XY Microscope Stage with Ultrasonic Linear Drives High Stability, Low Profile, High Speed, Direct Position Measurement Limit and Reference Switches For the protection of your equip- ment, non-contact Hall-effect limit Ordering Information and reference switches are in- XY Microscope Stage System stalled. The direction-sensing with Closed-Loop PILine® reference switch supports ad- Piezomotor Drives, 25 x 25 mm, vanced automation applications 0.5 µm Linear Encoder, Includes with high precision. C-867.260 2 Axis Controller and Joystick. Advantages of PILine® Mi- cropositioning Systems MD5422LOU The ultrasonic piezoceramic for Olympus Microscopes drives used in PILine® microposi- MD5422LNU for Nikon Microscopes tioners have a number of ad- MD5422LZU vantages over classical drives: for Zeiss Microscopes The M-545.2P microscope stage with closed-loop ultrasonic piezo motors provides 25 x 25 mm travel range and very high stability Higher Acceleration, Speed The following PI stages can be used with the M-545: Smooth Motion, Integrated Closed-Loop Linear Piezomotor Drives Provide no Vibrations P-545 PInano™: all versions Smooth Motion and High Speed to 50 mm/s P-5x7 & P-528: all versions Travel Ranges 25 x 25 mm Small Form Factor P-561 & P-562: all versions Integrated Linear Encoders with 0.5 µm Resolution P-541 & P-542: all versions Self-Locking when P-736 PInano™-Z: Adapter Compact Design: 30 mm Profile Height, Powered Down, no Dither, P-736.AP1 required Mounts Directly to Microscopes no Energy Consumption Ask about custom designs Self-Locking at Rest, with no Servo Dither No Shafts, Gears or Other Compatible with PI Piezo Nanopositioning / Scanning Rotating Parts Application Examples Stages Non-Magnetic , Vacuum BiotechnologyPreliminary Specs Compatible Drive Principle Microscopy M-545.2P piezomotor stages are employed in traditional stages Scanning microscopy mainly designed for automated obsolete. In addition, the piezo- Confocal microscopy positioning applications in mi- motors are self-locking at rest Semiconductor testing croscopy. The form factor of the and hold the stage in a stable Handling M-545 is optimized for a low position without generating heat. profile height of 30 mm only; the mounting pattern is compatible Compatibility to PI Nanoposi- with many PI piezo nanoposition- tioning and Scanning Stages ing stages. A number of standard PI piezo flexure stages can be mounted Space Saving Piezomotors on the M-545 stage. Depending Compared to conventional mo- on the application, these highly torized translation stages, the specialized, ultra-precise na- M-545 provides a lower profile nopositioning systems are availa- and smaller footprint. The com- ble as fast XYZ scanners (for pact PILine® piezoelectric linear fluorescence microscopy), as motors and linear encoders make vertical Z positioners (3D imag- both, the lead screw duct and the ing), or with up to 6 degrees of flanged, bulky stepper motors freedom. PInano™ XYZ piezo scanner mounted on a M-545.2P Microscope stage. The XYZ piezo nanopositioning stage provides <1 nm resolution and 200x200x200µm scanning range. The high sta bility and autolocking feature of M-545 provides significant ad- vantages over other microscope stage designs when using fast piezo scan- ning stages. The two-channel C-867.260 controller video at: http://www.youtube.com/watch?v=eT617ackIOw Preliminary Specs Model M-545.2P Active axes XY Travel range 25 x 25 mm Integrated sensor Linear encoder Sensor resolution 0.5 µm (no dither at rest) Min. incremental motion 1 µm Unidirectional repeatability 1 µm Bidirectional repeatability 2 µm Max. velocity 50 mm/s Load Capacity 50*N Max. push/pull force 5 N Max. lateral force 4 N Motor type PILine® U-164 Operating voltage 67 V (RMS)*** Electrical power 10 W / Axis** Operating temperature range 10 to +30 °C Material Aluminum (black anodized) Mass 3.2 kg Cable length 1.7 m Connector 2 x MDR connector, 14-pin Controller/driver C-867.260 2-a xis Controller/Driver * 10 N for max. velocity. ** For drive electronics *** Piezomotor drive voltage; controller requires 12 VDC M-545 dimensions in mm, Olympus version shown, call for other versions MD5422LZU for Zeiss Microscopes 30 270 Cable, 1.7 m 1 each for X and Y axes 270 17.5 3.8 12.5 25 Travel 84 12.5 25 Travel 12.5 12.5 42 Focal Point 125 215 134 228 4x M6x1.0 16x M4x0.7 100 2 x M4 x0.7 3x C’Bore Hole for 149 M4 Pan Head Screw 166 + 184 + 201 Travel Direction M-545 Manual XY Microsope Stage w/ Motor Upgrade Option Long-Range Motion for Sample Positioning The M-545, 25 x 25 mm micro- Ordering Information scope stage, is designed to pro- vide a stable platform for piezo M-545.2MO XY Microscope Stage, 25 x 25 mm, scanning stages of the P-545 Micrometer Drive, High Stability, PInano™ series. These high- Compatible with PI Piezo Stages, speed, high-resolution XY / XYZ for Olympus Microscopes piezo stages allow nanometer- M-545.2MN precision adjustment of the spec- XY Microscope Stage, 25 x 25 mm, imen holder in up to three Micrometer Drive, High Stability, dimensions over 200 µm. The Compatible with PI Piezo Stages, M-545 is also compatible with for Nikon Microscopes the following capacitive-feed- M-545.2ML back type piezo stages: P-733, XY Microscope Stage, 25 x 25 mm, Micrometer Drive, High Stability, P-5x7, P-5x8, P-54x and P-56x Compatible with PI Piezo Stages, (s. p. 2-72). for Leica Microscopes M-545 manual XY microscopy stage with 25 x 25 mm The basic M-545 model is M-545.2MZ travel shown with optional PInano™ piezo nanopositioner equipped with manual microme- (200 µm motion in X, Y und Z) on top. The M-545 stage was XY Microscope Stage, 25 x 25 mm, designed to provide a stable basis for piezo stages, especially ters. Micrometer Drive, High Stability, when the highest step-and-settle performance is required Compatible with PI Piezo Stages, Motorizing for for Zeiss Microscope Automated Tasks Versions for other microscopes on ࡯ Stable Platform for P-545 PInano™ The M-545 XY-stage can be sup- request. plemented with motorized actu- Piezo Nanopositioning Systems Accessories ators M-229 (s. p. 1-44). The ࡯ Low Profile for Easy Integration: 30 mm M-545.USC product number M-545.USC ࡯ 25mmx25mmTravelRange Factory Installed Stepper-Mike comprises the complete package Upgrade for M-545 XY Microscope ࡯ Micrometer Screws, Motor Upgrade Available of two stepper linear actuators Stages: Includes Stepper-Mikes, ࡯ For Nikon, Zeiss, Leica and Olympus Mikroscopes with controller and joystick. Joystick and Controller M-545.USG includes two stepper M-545.USG linear actuators with mounting Factory Installed Stepper-Mike Upgrade for M-545 XY Microscope Stages: Includes Stepper-Mikes, Joystick M-545.SHP Adapter Plate for Sample Holders for M-545 XY Microscope Stages Accommodates the following PI nanopositioning stage series: P-517/ 518/ 527/ 528, P-541/ 542, P-560 PIMars and P-545 PInano™ Adapter available for P-733 nanopositioners: P-733.AP1 Adapter Plate for Mounting of P-733 Piezo Stages on M-545 XY Microscope Stage Additional accessories on request. M-545.2MO, M-545.2MN dimensions in mm. Mounting adapters for Olympus and Nikon microscopes respectively included in delivery M-545.2ML dimensions in mm © Physik Instrumente (PI) GmbHThe & newest Co. release KG for 2009. data Subject sheets to is change available without for notice. download All at data www.pi.ws. are R3 superseded 10/06/09.0 by any new release. M-545.2MZ dimensions in mm Technical Data Model M-545.2M Unit Tolerance Active axes XY Motion and positioning Displacement 25 x 25 mm Min. incremental motion 1 µm typ. Min. incremental motion with 1 µm typ. M-229 stepper linear actuators Velocity with M-229 stepper linear actuators 1.5 mm/s max. Mechanical properties Max. load 50 N Preload 10 N Miscellaneous Material Aluminum, stainless steel Mass 4 kg ±5% Find further specifications on M-229 stepper linear actuators in the datasheet (s. p. 1-44) 3. Accessories The following accessories are available for the M-545 Stage. Accessory kits can be ordered from PI and are supplied with fasteners P-736.AP1 P-736 Mounting Kit For mounting the high speed P-736 Z slide scanner to the M-545 Stage M3 x 10mm Screw P-736.ZR1 or P-736.ZR2 M6 x 8mm Pan Head Screw M-545 Top Plate M-545.SHP Sample Holder Adapter For mounting 1x3 microscope slides or 35mm Petri dishes directly to the M-545 M6 x 8mm Pan Head Screw M2 x 3mm Screw P-545.PD3 or P545.SH3 Sample Holder M-545 Top Plate 3. Accessories (continued) P-733.AP1 P-733 Mounting Kit Adaper kit for mounting a P-733 to the M-545. M4 x 25 mm Socket Head Screw M6 x 10mm Socket Head Screw P-733 Stage Body M545 Stage Top Plate M5 x 10mm Flat Head Screw M-545.USG Mounting Kit for M-229 Stepper Motor Actuators (requires controllers) Adapter kit for mounting motorized actuators to the M-545 Stage. Controllers are required and can be ordered separately. M-229.25S Stepper Motor Actuator Can be mounted in front or rear position Rear position requires factory installation M-229.25S Stepper Motor Actuator 1. Model Survey The M-545 Series of stages is designed for use with inverted microscopes from the leading manufacturers (Nikon, Olympus, Leica and Zeiss). The stages are designed to allow full rotation of the lense turret throughout the Z motion range of The turret. M-545. 2 MN | Manufacturer “N” Nikon “O” Olympus “L” Leica | “Z” Zeiss | “M” Manual Micrometer Drive “2” 2 active axes (XY) 2.
