EK-Supremacy Elite Edition Series Universal CPU Water Block

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
EK-Supremacy Elite Edition Series Universal CPU Water Block EK-Supremacy Elite Edition series universal CPU water block installation manual This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box. Before you start using this product please follow these basic guidelines: 1. Please carefully read the manual before through before beginning with the installation process! 2. Please remove your motherboard from the computer to assure safest mounting process in order to prevent any possible damages to your CPU and/or motherboard’s circuit board (PCB). 3. The EK High Flow and EK-PSC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber o-ring gaskets. 4. The use of corrosion inhibiting coolants is always recommended for any liquid cooling system. STEP 1: GENERAL INFORMATION ON PRODUCT COMPATIBILITY STEP 2: TABLE OF CONTENT Congratulations on your purchase of EK-Supremacy universal CPU water block. This The following items are enclosed with each EK-Supremacy water block: water block is pre-assembled* for use with modern AMD or Intel desktop socket type motherboards. By default this water block supports the following CPU sockets: - EK-Supremacy universal CPU water block - EK-TIM Indigo Extreme™ thermal interface material - Intel socket LGA-775, LGA-1155/1156, LGA-1366 and LGA-2011 - PreciseMount universal CPU mounting mechanism: - AMD socket S754/939/940, AMD AMx and FM1 o M4 threaded thumb screws (4 pcs) o Springs (4 pcs) o M4 threaded thumb nuts (4 pcs) Water block top o Washers (4 pcs) - LGA-2011 M4 threaded mounting studs (4 pcs) - Spare AMD / Intel mounting plate Gaskets - Backplate rubber gasket - Backplate for Intel LGA-1366 and AMD socket motherboards Mounting plate - Backplate for Intel LGA-115x socket motherboards - Allen (hex) key 2.5mm Jet plate - Additional jet plates: o Jet J2 (1.0mm thick) – optimized for LGA-1155/1156 CPUs o Jet J3 (0.7mm thick) – optimized for LGA-2011 CPUs Copper base Screws *: depending on the variant. EK-Supremacy Elite Edition – AMD AMx & FM1 is shipped factory pre-assembled with AMD mounting plate. Caution: Narrow server type LGA-2011 is not supported by default – a Mounting plate Supremacy LGA-2011 Narrow ILM (EAN: 3830046990600) is mandatory to install this water block on narrow server type LGA-2011 motherboards. STEP 3.1 (optional): INSTALLING AMD MOUNTING PLATE AND REPLACING JET PLATE PROCEDURE 1) Place water block on an even surface and remove the four M4x14 DIN7991 screws attaching the top to the copper base using the enclosed 2.5mm Allen key. 2) Replacing mounting plate: 2.1) Replace the Intel mounting plate with AMD one. You will feel the mounting plate locking into the position when placed correctly on to the top. 2.2) Reseat the larger o-ring gasket (57x2 mm) into the gap between the mounting plate and water block top. Skip to step #4 to complete installation. 3) Replacing jet plate: 3.1) Remove the default jet J1 (0.8mm thick) and replace it with jet J2 or jet J3, depending on your CPU platform. You will feel the jet plate locking into the position when placed correctly to the top. Reinstall smaller o-ring gasket if needed prior to replacing jet plate. 4) Carefully place copper base to waterblock top assembly, make sure gaskets stay in place! Beware of copper base orientation! 5) Repeat step #4 if necassery. Screw in all four (4) M4x14 DIN7991 screws using the enclosed 2.5mm Allen (hex) key. Step #3.1 Step #2.2 Step #4 Step #2.1 STEP 4: PREPARING BACKPLATE RUBBER GASKET The enclosed rubber gasket is essential part of the backplate and mounting system and must be used every time you install this water block. The rubber backplate has a partially cut inner part which needs to be removed when installed on Intel LGA-115x and LGA-2011 motherboard. The rubber is held on four places and can be peeled away with hand. These two pieces can be reassembled later if needed. Outer part Intel LGA-115x and LGA-1366 socket: Remove the inner core of the rubber and use the outer part only. Inner core AMD sockets: (removable) Use the whole rubber backplate including the inner core. All disclosures, notices and warranty conditions are being written on the back of the box. Revision 1.0. Released on 29th of August, 2012. STEP 5: INSTALLING THE WATER BLOCK: STEP 5a: Intel LGA-775, -1366 and AMD socket motherboard: STEP 5b: Intel LGA-115x socket motherboard: 1) Place motherboard on an even surface with front facing down. 1) Place motherboard on an even surface with front facing down. 2) Install backplate rubber gasket - depending on your CPU platform (see STEP 4) - 2) Install backplate rubber gasket - depending on your CPU platform (see STEP 4) - and place metal backplate for Intel LGA-1366 and AMD socket to the back of your and place metal backplate for Intel LGA-115x socket to the back of your motherboard. Align the holes on the motherboard with holes on rubber gasket motherboard. Align the holes on the motherboard with holes on rubber gasket and backplate. and backplate. Make sure to orientate the rubber gasket to fit past the 3) Carefully rotate motherboard assembly with front side facing up with one hand CPU socket ILM backplate. while holding the backplate and rubber in place with the other hand. 3) Carefully rotate motherboard assembly with front side facing up with one 4) Install the rest of mounting system as per installation manual (see STEP 6) hand while holding the backplate and rubber in place with the other hand. 4) Install the rest of mounting system as per installation manual (see STEP 6) Metal backplate Metal backplate Rubber gasket Rubber gasket Motherboard PCB Motherboard PCB figure 1: Isometric view of backplate assembly for LGA-1366 figure 2: Isometric view of backplate assembly for LGA-115x STEP 5c: Installing the mounting system: STEP 5d: Preparing your CPU and applying EK-TIM Indigo Extreme: Intel Socket LGA-115x/1366 and AMD sockets: Please consult the enclosed EK-TIM Indigo Extreme™ installation manual and Install the M4 thumb screws of the PreciseMount mounting system onto your install the thermal interface material as per installation manual. Improper motherboard. It is mandatory to put 0.7mm plastic washer underneath each of installation may will result in poor thermal properties of your EK-Supremacy Elite the M4 thumb screws. Tighten the M4 thumb screw to the metal backplate with Edition series water block! your hands until you reach the end of the thread. Using tools (such as pliers) is not recommended! Remember, EK-TIM Indigo Extreme™ is not re-usable once reflow process is started. Intel Socket LGA-2011: Install four (4) specific LGA-2011 M4 thumb screws into four M4 threaded stubs on the LGA-2011 socket integrated latch mechanism (ILM). The screws are to be installed using no tools (i.e. pliers). M4 thumb screw LGA 2011 M4 thumb screw PVC washer STEP 5e: Fastening the waterblock: STEP 6: CONNECTING WATER BLOCK TO THE COOLING CIRCUIT Install the waterblock on your CPU. Place an enclosed compression spring and Carefully identify the direction of the flow in your circuit. For the EK-Supremacy thumb nut over each M4 thumb screw. Start fastening two thumb nuts at a time, series water block to operate properly the G1/4 port nearest to the center of the preferably in cross pattern and do not tighten them fully until all of them are water block MUST BE USED AS THE INLET PORT. EK recommends the use of partially screwed in. Then - using your fingers only - screw in all four thumb nuts EK-PSC fittings. When using fittings other than EK-PSC series please use hose until you reach the end of the thread. clamps or appropriate substitute to secure the tubing to the barb. The use of biocide containing and corrosion inhibiting coolant is always recommended for any liquid cooling system. Thumb nut Coiled spring EK-PSC fitting Tubing REQUIRED TOOLS - allen key 2.5mm (enclosed) All disclosures, notices and warranty conditions are being written on the back of the box. Revision 1.0. Released on 29th of August, 2012. EK-TIM Indigo Extreme™ Installation Manual for use with EK -Supremacy™ Series CPU Water Block s This product is intended for installation only by expert users. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwaterblocks.com for updates. Before installation of this product please read important notice, disclosure, and warranty conditions printed on our home page. STEP 1: QUICK OVERVIEW STEP 1.1: EK -TIM Indigo Xtreme : STEP 1.2: Compatibility List: Engineered Thermal Interface for Socket 2011 (Intel Core™ i7 processors) Supported Hardware: Supported CPUs: Socket 2011 Indigo Xtreme™ is an Engineered Thermal Interface (ETI) • Core™ i7 that fits neatly between a CPU lid and heat sink or waterblock to keep CPUs cooler. Unlike greases, metallic thermal interface pads or liquid metal alloys, Indigo Xtreme is a self-contained and sealed structure, deploying Supported Water Blocks: a Phase Change Metallic Alloy (PCMA) which reflows and All EK-Supremacy series water blocks fills surface defects on the CPU lid and heat sink.
