Dissertation Performance Assessment of Simple Blast

DISSERTATION

PERFORMANCE ASSESSMENT OF SIMPLE BLAST WALL SYSTEMS

Submitted by

Assal Hussein

Department of Civil and Environmental Engineering

In partial fulfillment of the requirements

For the Degree of Doctor of Philosophy

Colorado State University

Fort Collins, Colorado

Spring 2019

Doctoral Committee:

Advisor: Hussam N. Mahmoud Co-Advisor: Paul R. Heyliger

John W. van de Lindt David I. McLean Jennifer L. Mueller

ABSTRACT

PERFORMANCE ASSESSMENT OF SIMPLE BLAST WALL SYSTEMS

Numerous planned suicide attacks have been recorded since the beginning of the current century in several regions of the world. These attacks have impacted huge number of victims and have resulted in economic and psychological consequences on communities and nations, with complex global influences at times. In recent years, terrorist organizations have adopted new strategies that have made it difficult for security and intelligence operations to stop attacks. The main objectives of this dissertation are 1) draw the attention to the benefit of considering simple blast wall systems to mitigate the hazard of the suicide attacks, 2) determining the efficiency of readily available materials in dissipating the blast of shock wave energy, and 3) to investigate the performance of simple blast wall systems. This study discusses the threat of suicide attacks that are executed by bombers wearing vests and provides a general view of this type of man- made hazard and its consequences on the existence of communities and their future. The study clarified the impacts of suicide attacks in the Republic of Iraq, and the U.S.

Muqdadiyah City was considered as a case study of these impacts in the Republic of Iraq.

The results of the literature review highlighted the necessity to adopt a new approach to designing simple blast wall systems. Designing such systems made of low-tech materials can mitigate and reduce losses from such type of threat, make their implementation easier and more cost-effective, and potentially result in a reduction in death, injury, and damage.

Different engineering methods have been investigated and considered for civilian

and military fields to mitigate blast shock wave effects. Standards and technical manuals have been published by federal agencies and research centers to set general safety precautions and/or structural design approaches, charts, and equations. However, many of these manuals are limited and not released to the public. In addition to a lack of funds, the technology of construction, and availability of high-tech materials, designing blast- resistant structures or high-tech blast wall systems are not an available option for designers in most developing countries. Design guidelines are sparse if not non-existent.

This research was focused on suggesting a new blast wall system using low-tech materials to mitigate the effect of a blast shock wave in free-air. The oriented stands board

(OSB) and wood-sand-wood (WSaW) blast walls were considered in the current study as examples of blast walls made of readily available materials that can be installed with minimal effort. The response of these structural systems was investigated experimentally, and results verified with numerical analysis results. Moreover, distribution of free-air blast pressure was measured and compared with the Kingery-Bulmash reference measurements for a wide variety of explosive charges. A good agreement was noticed between the measured blast pressure and Kingery-Bulmash model. The numerical analysis was implemented using 3-D-dynamic finite element method (3-D-FEM). The commercial software ABAQUS/Explicit version 6.14 combined with ConWep blast loading model as inbuilt blast load function was considered to represent the interactions between blast wave and the wall. The numerical analysis results of a WSaW blast wall showed a good agreement with test results.

iii

In addition to the focus on wall systems, initial efforts were made to measure damage to humans. Eardrum rupture is one of the main injuries due to blast shock wave and could lead to temporary and permanent hearing loss. In this study, the blast shock wave intensity on eardrum has been investigated experimentally. Due to the similarity

between the sheep ear structure and human ear, five Rambouillet-Columbia sheep heads

samples were subjected to blast shock wave. The measured blast pressure exceeded the

threshold of eardrum rupture. This means that the threshold for eardrum rupture was

already surpassed and a 50 percent probability of eardrum rupture is expected. The

micro-CT images showed the structure of the eardrum is totally ruptured. Three eardrum

samples on the right side were ruptured, while only two samples on the left side were

ruptured. The probability of temporary hearing loss injury could take place at level of

pressure less than the threshold which can be considered the starting point of eardrum

rupture (UFC 3-340-02). These experiments are described in this dissertation.

Finally, a probabilistic analysis of an equivalent single-degree of freedom (SDOF) system was completed for WSaW blast wall to estimate the fragility curves (FCs) of the

system under free-air blast load using direct Monte Carlo (MC) simulation method. The

suggested framework of the probabilistic analysis was developed to study the performance of the proposed blast wall according to the uncertainties in the structural properties and blast load parameters. The FCs were also estimated based on the variability in the equivalent

TNT weight of a suicide vest threat scenario.

This study recommends WSaW blast wall to reduce casualties and losses in properties in different scenarios. Furthermore, it is important to draw the attention of researchers and designer to start investigating the performance of simple blast walls

made of other low-tech materials since it is an urgent need in most areas threatened by terrorism.

ACKNOWLEDGMENTS

All praise be to Allah for helping and supporting me to reach this far and make it all possible. I want first to express my sincere gratitude to my advisors, Professor Hussam

Mahmoud and Professor Paul Heyliger for the advice, and support during my Ph.D. study at Colorado State University. Special thanks to Professor Hussam Mahmoud for funding the blast tests and to Professor Paul Heyliger to organize the blast tests. I would like to thank my doctoral committee, Professor David Mclean, Professor John van de Lindt, and

Professor Jennifer Mueller for their contribution in my Ph.D. research. I also thank Mr.

Karl Swenson and Mr. Christopher Giglio of the Environmental Health Services at

Colorado State University for their efforts in providing, handling, placing and detonating explosive charges in all implemented blast tests. I thank Dr. Kevin Troyer, Mechanical

Engineering Department, and Dr. Kirk McGilvray, Mechanical Engineering Assistant research of the Orthopaedic Bioengineering Research Laboratory (OBRL) for their help in providing, dissecting, and scanning the animal tissues. Thank you to Mr. Joel Vaad the manager of Maxwell Ranch site. I would like also to express my sincere gratitude to the

Iraqi Government-Prime Minister office-The Higher Committee for Education Development in

Iraq (HCED) for the financial support to finish my Ph.D. study at Colorado State University.

Also, not to forget to thank wife, Intisar for taking care of the family, supporting, and encouraging me throughout my academic career. Thank you to my children, Haneen, Ali, and Maria for encouraging me to continue my study successfully. Last, but not least, I thank my mother and brothers for their support, to keep me working actively to get my goals.

DEDICATION

This work is dedicated to the spirit of my father Tehseen Hussein and my younger

brother Ahmad. May God have mercy on them and place them in paradise.

vii

TABLE OF CONTENTS

CHAPTER 1. INTRODUCTION ...... 1

1.1 Research Hypothesis ...... 1 1.2 Research Approach ...... 2 1.3 Research Framework ...... 3 1.4 Dissertation Outline ...... 5

CHAPTER 2. SUICIDE BOMBING ATTACKS: AN OVERVIEW ...... 7

2.1 Terrorist Attacks Scenarios and Goals ...... 7 2.2 Suicide Attacks: The Challenge ...... 8 2.3 Bombing attacks: numbers and facts ...... 10 2.3.1 The United States of America ...... 11

2.3.2 Republic of Iraq ...... 15

2.3.3 Asia and the Middle East Countries ...... 17

2.4 Economical, Demographic, and psychological Impacts of attacks in Republic of Iraq- Muqdadiyah City ...... 19 2.4.1 The Impact of Suicide Attacks on Lifestyle in Muqdadiyah City, Iraq ...... 20

2.4.2 Recent Suicide Attacks in Muqdadiyah City ...... 22

2.5 The Suicide Attacks in the Republic of Iraq and United States-Comparative Study 24 2.5.1 Number of Victims by Suicide Bombings ...... 24

2.5.2 Number and Nature of Suicide Bombings ...... 26

2.5.3 Economic Impacts of Suicide Bombings ...... 27

2.5.4 Psychological Impact of Suicide bombings ...... 28

2.6 Blast Injuries Categories ...... 29

viii

2.7 Blast effects on Health ...... 30

CHAPTER 3. PRINCIPLES OF BLAST LOADING ...... 33

3.1 Introduction and Background ...... 33 3.2 Classification of Blast Loading ...... 35 3.3 Blast Shock Wave Pressure Generating in Air ...... 40 3.4 Typical Pressure-Time Curve in Free Field ...... 41 3.5 Scaling Law of Blast Loading ...... 43 3.6 TNT Equivalency ...... 44 3.7 Structural Response to Blast Loading ...... 46 3.8 Prediction of Peak Overpressure of Blast Loading ...... 46 3.9 Blast Shock Wave Versus Natural Hazards ...... 47 3.10 Behavior of Materials under Blast Loading ...... 50 3.11 Blast Loading Calculation Methods ...... 53 3.12 Kingery-Bulmash Equations-principles and limitations ...... 54 3.12.1 Introduction and Background ...... 54

3.12.2 Kingery and Bulmash Equations: Mathematical Format ...... 57

3.13 Conventional Weapons (ConWep) Blast loading Model ...... 58 3.14 Codes and Standards Blast Design Manuals ...... 60

CHAPTER 4. MITIGATION OF BLAST LOADING ...... 64

4.1 Security Precautions-Methods and Techniques ...... 64 4.1.1 Perimeter Protection Systems ...... 64

4.1.2 Façade Protection ...... 66

4.1.3 Curtain Wall Protection ...... 67

4.2 Layered Sand/Soil in Protective Systems-Historical Perspective ...... 68 4.3 Recent Attempts of using Sand in Protection ...... 69

4.4 The behavior of Composite Panels Subjected to Blast Loading-Review of Literature ...... 72 4.5 The efficiency of Blast Wall Systems in Mitigating Blast Loading ...... 78 4.6 Lessons from Invasion of Republic of Iraq ...... 79 4.7 Blast Wall Systems-Research Gap ...... 81

CHAPTER 5. NUMERICAL VERIFICATION AND TESTS VALIDATION OF SIMPLE

BLAST WALLS ...... 83

5.1 Introduction and Background ...... 83 5.2 Overview of the Finite Element Model ...... 84 5.3 Failure Prediction and Structural Response of OSB Wall ...... 85 5.4 Experimental Program ...... 90 5.4.1 Introduction and Summary ...... 90

5.4.2 Instrumentations ...... 90

5.4.3 Free-Air Blast Pressure-Trial Test ...... 93

5.5 Free-Air Blast Pressure Tests-I ...... 95 5.6 Free-Air Blast Pressure Tests-II ...... 100 5.7 Small-Scale Test of Oriented Strand Board (OSB) Wall ...... 102 5.7.1 Test Setup and Results ...... 102

5.7.2 Validation of OSB test results ...... 111

5.8 Large-Scale Test of Oriented Strand Board (OSB) Wall ...... 112 5.8.1 Free-Air Blast Pressure Measurements Test ...... 112

5.8.2 Response of OSB Wall under Blast Loading ...... 116

5.9 Blast Shock Wave Energy Distribution Test ...... 121 5.10 Blast Shock Wave Effect on Eardrum-Experimental Study ...... 124 5.10.1 Introduction and Background ...... 124

5.10.2 Experimental Test of Animal Tissue ...... 126

5.10.3 Dissecting procedure of the eardrum ...... 134

5.11 Large-Scale Test of WSaW Blast Wall ...... 139 5.11.1 WSaW Wall Construction and Test Setup ...... 139

5.11.2 Particles Distribution and Classification of Sand ...... 141

5.11.3 Free-Air Blast Pressure Measurements ...... 142

5.11.4 Measurement of the WSaW Blast Wall Response ...... 147

5.12 Summary and Conclusion ...... 150

CHAPTER 6. PROBABILISTIC ANALYSIS OF SINGLE-DEGREE OF FREEDOM

SYSTEM ...... 153

6.1 Introduction and Background ...... 153 6.2 Determination of Blast Loading Model ...... 154 6.3 Structural Response to Idealized Blast Forcing ...... 154 6.3.1 Introduction ...... 154

6.3.2 Failure Prediction and Structural Response of WSaW Blast Wall ...... 155

6.3.3 Response of SDOF System under Triangular Impulse Force ...... 160

6.4 Probabilistic Analysis of SDOF System ...... 162 6.4.1 Review of Literature ...... 162

6.4.2 Monte Carlo Simulation Method ...... 165

6.4.3 Equivalent SDOF System Response of WSaW Blast Wall ...... 165

6.4.4 Fragility Analysis ...... 168

6.5 Probability of Exceedance of SDOF System ...... 169 6.6 Summary ...... 175

CHAPTER 7. CONCLUSIONS AND FUTURE WORKS ...... 177

7.1 Summary and Outlines of Current Study ...... 177

7.2 Blast Wall Systems-Limitations and features ...... 178

7.2.1 High-Tech Blast-Resistant Wall Systems ...... 178

7.2.2 Simple Blast-Resistant Wall systems ...... 179

7.3 Experimental Test Results and Numerical Analysis Validation of Simple Wall Systems ...... 180

7.3.1 Free-Air Blast Test of OSB Blast Wall ...... 181

7.3.2 Free-Air Blast Test of WSaW Wall ...... 182

7.3.3 Blast Shock Wave Effect on the Eardrum-Experimental study ...... 183

7.4 Numerical Analysis Results and Validation of Test Results ...... 184

7.4.1 Failure Prediction Analysis of OSB Blast Wall ...... 184

7.4.2 Failure Prediction Analysis of WSaW Blast Wall ...... 184

7.5 Probabilistic Analysis of SDOF system ...... 185

7.6 Recommendation for Future Works ...... 186

REFERENCES ...... 188

xii
