COMPACT HIGH PERFORMANCE ANALOG CMOS BASEBAND DESIGN SOLUTIONS FOR MULTISTANDARD WIRELESS TRANSCEIVERS
DISSERTATION
Presented in Partial Fulfillment of the Requirements for the Degree Doctor of Philosophy in the
Graduate School of The Ohio State University
By
Seok-Bae Park, B.S., M.S.
*****
The Ohio State University
2006
Dissertation Committee: Approved by
Mohammed Ismail El-Naggar, Adviser Patrick Roblin Adviser Steven B. Bibyk Graduate Program in Electrical and Computer Engineering c Copyright by
Seok-Bae Park
2006 ABSTRACT
In this dissertation, a novel compact wireless radio transceiver architecture reusing a baseband chain so as to significantly reduce the die area is proposed. The proposed architecture employs a direct conversion architecture with a shared base- band chain and is suitable for wireless standards based on time-division duplexing air interface. In direct conversion architectures, baseband channel selection filters and variable gain amplifiers are placed in the receive path as well as in the transmit path.
Here, it is proposed to use the same baseband filters and variable gain amplifiers in both the receive path and the transmit path to reduce the die area.
To realize a high performance direct conversion receiver for multistandard wireless communications, the limiting factors in the direct conversion receiver should be identified and removed. In this dissertation, among many problems in direct conversion receivers, the DC offset problem is addressed. The origins of the DC offset are summarized, and three self-mixing mechanisms generating the DC offset are modeled to understand how the static and dynamic DC offsets are produced from the mechanisms. A DC offset cancellation scheme consisting of a static DC offset canceller and a dynamic DC offset canceller is proposed. For the static DC offset canceller, a DC feedback loop is proposed to use and verified through simulation, fabrication, and measurement. A novel dynamic DC offset canceller utilizing an adaptive filtering technique is also proposed and verified through simulation.
ii An analog baseband chain for the proposed compact wireless transceiver is designed in this dissertation. A fully balanced differential difference amplifier is de- signed as a core amplifier to be used in both a baseband filter and a variable gain amplifier. A fully differential Sallen-Key channel selection filter and a fully differential variable gain amplifier using attenuators which can be shared for both the transmit path and the receive path are designed. A DC feedback loop is designed to cancel the static DC offset. This baseband chain is realized in a 0.5 μm standard CMOS process and verified through simulation, fabrication, and measurement.
iii This is dedicated to my parents and my wife . . .
iv ACKNOWLEDGMENTS
First of all, I deeply thank Prof. Mohammed Ismail, my advisor, for giving me a chance to join the Analog VLSI Lab., for his invaluable advice on my research and my future, for his constant guidance and numerous discussions on my dissertation research, and for all the support and opportunities.
I heartily thank Prof. Patrick Roblin and Prof. Steven Bibyk for being on my dissertation committee. I greatly appreciate their kindness and their precious time for me.
I thank Eisenhower National Clearinghouse (ENC) and Semiconductor Re- search Corporation (SRC) for their financial support throughout my graduate stud- ies. I express my special thanks to Karen Abhari and Roger Cunningham at ENC for their giving me opportunities.
I also thank many members of the Analog VLSI Lab. for numerous technical discussions, inspiration, and help.
From the bottom of my heart, I thank my parents, my sisters, and my wife,
Yonghee, for their love, encouragement, guidance, and support.
v VITA
May 1967 ...... Born- Pusan,Korea
February 1991 ...... B.S.ElectricalEngineering, Seoul National University, Seoul, Korea August 1994 ...... M.S.ElectricalEngineering, Seoul National University, Seoul, Korea December 2000 ...... M.S.ComputerEngineering, Ohio State University, Columbus, Ohio April 1998 - September 2005 ...... GraduateResearchAssociate, Ohio State University, Columbus, Ohio
PUBLICATIONS
Research Publications
Mohammed Ismail, Seok-Bae Park, Ayman A. Fayed, and R. F. Wassenaar, “Op- erational Transconductance Amplifiers”, Chapter 22, The VLSI Handbook,2ndEd., CRC Press, 2006.
Seok-Bae Park and Mohammed Ismail, “A Reconfigurable CMOS Analog Baseband for Compact TDD Wireless Radio Transceivers”, Proc. of IEEE International Mid- west Symposium on Circuits and Systems (MWSCAS ’05), pp. 1386–1389, August 2005.
Seok-Bae Park and Mohammed Ismail, “DC Offset Cancellation in Direct Conversion Multistandard Wireless Receivers”, Proc. of International Conference on Mixed Design of Integrated Circuits and Systems (MIXDES ’05), pp. 947–951, June 2005.
Seok-Bae Park, Hyang-Beom Lee, Il-Han Park, and Song-Yop Hahn, “Stator Slot Shape Design of Induction Motors for Iron Loss Reduction”, IEEE Transactions on Magnetics, Vol. 31, No. 3, pp. 2004–2007, May 1995.
vi FIELDS OF STUDY
Major Field: Electrical Engineering
Studies in: Analog VLSI Prof. Mohammed Ismail El-Naggar RF and Microwave Prof. Patrick Roblin
vii TABLE OF CONTENTS
Page
Abstract...... ii
Dedication...... iv
Acknowledgments...... v
Vita...... vi
ListofTables...... xi
ListofFigures...... xii
Chapters:
1. Introduction...... 1
1.1MotivationandObjectives...... 1 1.2OrganizationoftheDissertation...... 3
2. Wireless Receiver Architectures ...... 4
2.1Introduction...... 4 2.2 Heterodyne Receiver Architecture ...... 4 2.3 Direct Conversion Receiver Architecture ...... 5 2.4 Low-IF Receiver Architecture ...... 7 2.5 Digital-IF Receiver Architecture ...... 7 2.6Summary...... 8
viii 3. CompactTDDWirelessTransceiverArchitecture...... 9
3.1Introduction...... 9 3.2TransceiverArchitectureDescriptionandDesignIssues...... 12 3.3Summary...... 16
4. DC Offset Problem in Direct Conversion Receivers ...... 17
4.1Introduction...... 17 4.2DCOffsetModeling...... 19 4.2.1 DCOffsetGeneration...... 19 4.2.2 DCOffsetModel...... 21 4.3 DC Offset Cancellation for Multistandard Receivers ...... 27 4.3.1 StaticDCOffsetCancellation...... 29 4.3.2 DynamicDCOffsetCancellation...... 31 4.4DynamicDCOffsetCancellationUsingAdaptiveFiltering..... 32 4.4.1 AdaptiveFilteringTechniques...... 32 4.4.2 AdaptiveDynamicDCOffsetCancellation...... 35 4.4.3 SimulationStudies...... 37 4.5Summary...... 40
5. DesignofAnalogBasebandPrototype...... 46
5.1Introduction...... 46 5.2FullyBalancedDifferentialDifferenceAmplifier...... 46 5.2.1 CircuitImplementation...... 49 5.2.2 SimulationResults...... 53 5.3ChannelSelectionFilter...... 60 5.3.1 FullyDifferentialSallen-KeyLowPassFilter...... 60 5.3.2 SimulationResults...... 62 5.3.3 MeasurementResults...... 72 5.4StaticDCOffsetCancellationusingDCFeedbackLoop...... 78 5.4.1 DCFeedbackLoopDesign...... 78 5.4.2 SimulationResults...... 80 5.4.3 MeasurementResults...... 81 5.5VariableGainAmplifiers...... 88 5.5.1 Fully Differential Variable Gain Amplifier Using Attenuators 89 5.5.2 SimulationResults...... 91 5.5.3 MeasurementResults...... 93 5.6Summary...... 104
ix 6. Conclusion...... 105
6.1ContributionoftheDissertation...... 105 6.2FutureWork...... 107
Appendices:
A. WirelessCommunicationStandards...... 108
B. MatLabCodes...... 112
Bibliography...... 117
x LIST OF TABLES
Table Page
4.1MaximumDopplershift...... 25
5.1 Performance of the fully balanced differential difference amplifier . . . 60
5.2 Performance of the fully differential sixth-order Sallen-Key low pass filter 65
5.3Performanceofthefullydifferentialvariablegainamplifier...... 93
A.13GStandards...... 109
A.2WirelessLANStandards...... 110
xi LIST OF FIGURES
Figure Page
2.1Heterodynearchitecture...... 5
2.2Directconversionarchitecture...... 6
2.3Low-IFarchitecture...... 7
2.4Digital-IFarchitecture...... 8
3.1Diephotoexamplefrom[1]...... 10
3.2Diephotoexamplefrom[2]...... 11
3.3Directconversiontransceiverarchitecture...... 13
3.4CompactTDDwirelessradiotransceiverarchitecture...... 13
3.5 Reconfigurable compact TDD wireless radio transceiver architecture . 14
4.1Spectrumfordirectconversion...... 18
4.2GenerationofDCoffsetsduetoself-mixing...... 20
4.3 I-branch of direct conversion receivers ...... 22
4.4 Self-mixing models in direct conversion receivers ...... 24
4.5MultistandardDCRwithDCoffsetcancellation...... 28
4.6StaticDCoffsetcanceller...... 30
xii 4.7IdealfrequencyresponseofthestaticDCoffsetcanceller...... 31
4.8Adaptivefilteringproblemclassification...... 34
4.9DynamicDCoffsetcanceller...... 36
4.10Simulationsetupwithidealchannel...... 37
4.11SimulationsetupwithAWGNchannel...... 38
4.12 1000-symbol BPSK simulation results with ideal channel: part 1 . . . 41
4.13 1000-symbol BPSK simulation results with ideal channel: part 2 . . . 42
4.14 1000-symbol BPSK simulation results with AWGN channel (Eb/N0 = 3):part1 ...... 43
4.15 1000-symbol BPSK simulation results with AWGN channel (Eb/N0 = 3):part2 ...... 44
4.16BERperformanceofthedynamicDCoffsetcanceller...... 45
5.1Abufferconfiguration...... 47
5.2 Fully balanced differential difference amplifier (FBDDA) symbol . . . 48
5.3FullydifferentialbufferconfigurationusingFBDDA...... 49
5.4 Realization of FBDDA with common-mode feedback (CMFB) circuits 51
5.5LayoutviewoftheFBDDAinthebufferconfiguration...... 54
5.6 AC response of the fully balanced differential difference amplifier . . . 55
5.7ACresponseoftheFBDDAinthebufferconfiguration...... 56
5.8NoiseresponseoftheFBDDA...... 57
5.9StepresponseoftheFBDDAinthebufferconfiguration...... 58
5.10 Input 1dB compression point of the FBDDA in the buffer configuration 59
xiii 5.11Third-orderSallen-Keylowpassfilter...... 61
5.12 Fully differential third-order Sallen-Key low pass filter using FBDDA 63
5.13 Fully differential third-order Sallen-Key low pass filter for multistan- dardoperation...... 64
5.14 Fully differential sixth-order multistandard Sallen-Key low pass filter 64
5.15ACresponseofthesixth-orderSallen-Keylowpassfilter...... 66
5.16 Group delay response of the sixth-order Sallen-Key low pass filter . . 67
5.17Noiseresponseofthesixth-orderSallen-Keylowpassfilter...... 68
5.18 Input 1dB compression point of the sixth-order Sallen-Key low pass filter 69
5.19IIP3ofthesixth-orderSallen-Keylowpassfilter...... 70
5.20Stepresponseofthesixth-orderSallen-Keylowpassfilter...... 71
5.21 Fully differential third-order Sallen-Key low pass filter with a buffer formeasurement...... 73
5.22 Measured frequency response of the fully differential Sallen-Key low passfilter...... 74
5.23 Measured intermodulation test of the fully differential Sallen-Key low passfilter...... 75
5.24 Die photo of the fully differential Sallen-Key low pass filter with a measurementbuffer...... 76
5.25 Magnified die photo of the fully differential Sallen-Key low pass filter withameasurementbuffer...... 77
5.26StaticDCoffsetcanceller...... 78
5.27 Implementation of gm cellinthestaticDCoffsetcanceller...... 79
xiv 5.28Implementationofcapacitance...... 80
5.29FrequencyresponseoftheOTA...... 82
5.30FrequencyresponseofthestaticDCoffsetcanceller...... 83
5.31 Static DC offset canceller around the Sallen-Key low pass filter with measurementbuffer...... 84
5.32MeasuredfrequencyresponseofthestaticDCoffsetcanceller..... 85
5.33DiephotoofthestaticDCoffsetcanceller...... 86
5.34 Magnified die photo of the static DC offset canceller with a buffer for measurement...... 87
5.35 Fully differential variable gain amplifier using non-inverting amplifier 89
5.36FrequencyresponseoftheVGAusingnon-invertingamplifier..... 90
5.37 Fully differential variable gain amplifier (VGA) using attenuators and FBDDA...... 91
5.38 Fully differential variable gain amplifier (VGA) chain using attenuators andFBDDAs...... 92
5.39ACresponseoftheVGA...... 94
5.40NoiseresponseoftheVGA...... 95
5.41 Input 1dB compression point of the VGA ...... 96
5.42IIP3oftheVGA...... 97
5.43StepresponseoftheVGA...... 98
5.44 Fully differential VGA using attenuators and FBDDAs with a mea- surementbuffer...... 99
5.45 Measured frequency response of the fully differential variable gain am- plifier...... 100
xv 5.46 Measured intermodulation test of the fully differential variable gain amplifier...... 101
5.47Diephotoofthefullydifferentialvariablegainamplifier...... 102
5.48 Magnified die photo of the fully differential variable gain amplifier with abufferformeasurement...... 103
xvi CHAPTER 1
INTRODUCTION
1.1 Motivation and Objectives
A great deal of effort in academia and industry has been made to meet the ever-growing demands for low-cost, low-power, and single-chip transceivers for multi- standard wireless communications. The explosive growth in the mobile phone market has fueled the transition from the second generation (2G) to the third generation
(3G), and the growing demand for wireless access to the Internet in buildings has called for the development of wireless local area network (LAN) standards. Even short range wireless communication devices for connecting peripherals to a computer or speakers to an audio amplifier are in great demand recently. Therefore, to develop a single-chip wireless transceiver working for as many wireless standards as possible has been a challenging problem.
To reach the ultimate goal, the first step would be the choice of an appropriate transceiver architecture for effectively processing the signal received at the antenna.
The right selection of the transceiver architecture is the key to success in developing a multistandard single-chip wireless transceiver. The first objective of the dissertation is to propose a novel wireless transceiver architecture which occupies a smaller area
1 and can work for many wireless standards. The proposed transceiver architecture is
especially designed for time-division duplexing systems.
Among many transceiver architectures, the direct conversion,alsoknownasho- modyne or zero-IF, is the most attractive choice for multistandard wireless transceivers because of its simplicity and suitability for monolithic integration as well as multi- standard operation [3]. Though the direct conversion architecture possesses many preferable characteristics, it still has some critical drawbacks which should be miti- gated in order to be successfully implemented. The second objective of the disserta- tion is to address the DC offset problem, which is one of the inherent problems in the direct conversion architecture. In this dissertation, the DC offset generation mecha- nisms are modeled and the DC offset cancellation methods for multistandard wireless transceivers are discussed. A DC offset canceller which can track and cancel a fast varying DC offset is also proposed. Here, adaptive filtering techniques are utilized to cancel the fast varying DC offset.
The third objective of the dissertation is to design a prototype of an analog baseband chain for the proposed compact wireless transceiver. The idea is to design a single core amplifier and then use it to implement a channel selection filter as well as a variable gain amplifier. This reduces a design time and can contribute toward a smaller die area by choosing an appropriate filter structure and a variable gain amplifier topology. The design of a DC feedback loop is included to cancel the DC offset which varies very slowly or does not change over time. The design of this baseband chain is realized in a 0.5 μm standard CMOS process and verified through simulation, fabrication, and measurement.
2 1.2 Organization of the Dissertation
The dissertation is organized as follows. Chapter 2 briefly summarizes a variety of wireless communication receiver architectures. In Chapter 3, a compact wireless transceiver architecture suitable for time-division duplexing systems is proposed and its design issues are discussed. Chapter 4 addresses the DC offset problem in direct conversion receiver architecture. How the DC offset can be generated and how it can be modeled are presented. A DC offset cancellation scheme for multistandard direct conversion receivers is proposed and a novel fast varying DC offset cancellation scheme using an adaptive filtering technique is presented. In Chapter 5, the design of analog baseband circuits for the proposed compact wireless transceiver architecture is presented. To realize the baseband chain, a core amplifier is designed first and then we use the core amplifier for designing a channel selection filter and a variable gain amplifier. To cancel a very slowly or not varying DC offset, a DC feedback loop is designed and placed around the baseband filter. All the simulation results as well as measurement results are presented in this chapter. Chapter 6 concludes the dissertation and identifies future work.
3 CHAPTER 2
WIRELESS RECEIVER ARCHITECTURES
2.1 Introduction
In wireless communication receivers, the received radio frequency (RF) signal should be downconverted to baseband and sampled for further processing in digital domain. The received signal is processed first in the analog domain and passed on to the digital domain, and thus analog-to-digital and digital-to-analog conversions should occur somewhere in the receiver path. So, there are choices of receiver architectures according to where to put the analog-to-digital converter (ADC) and the digital-to- analog converter (DAC) and how to downconvert the received signal. It ranges from the traditional heterodyne architecture to digital-IF architectures. In this chapter, some of the important receiver architectures such as heterodyne, direct conversion, low-IF, and digital-IF receiver architectures are briefly summarized.
2.2 Heterodyne Receiver Architecture
In the heterodyne receiver architecture shown in Figure 2.1, an RF signal is downconverted to an intermediate frequency (IF) by the first mixer. Then the signal is I/Q separated and downconverted to baseband by the second mixers. The first band
4 Channel Select I LPF ADC
Band Select Image Reject Channel Select
BPF LNA BPF BPF IF Amp LO2
90 o
Q LPF ADC LO1 Channel Select
Figure 2.1: Heterodyne architecture
pass filter (BPF) located in front of the low noise amplifier (LNA) is for frequency band selection. The second BPF is for image rejection, and the third BPF and a low pass filer (LPF) are for channel selection. After low pass filtering for channel selection, the signal is sampled at baseband, which is called baseband sampling.As shown in Figure 2.1, the channel selection is done at IF as well as at baseband before
ADC, which relaxes the Q required of each channel selection filter. The heterodyne architecture has been the most popular receiver architecture for a long time due to its good selectivity and sensitivity and can be found in many commercial RF transceivers.
It relaxes the dynamic range of the baseband circuits. But, normally the IF band pass filter and the image reject (IR) filter are external components, which makes this architecture not suitable for monolithic integration.
2.3 Direct Conversion Receiver Architecture
Fig. 2.2 shows a direct conversion receiver (DCR) architecture which is also known as homodyne or zero-IF receiver architecture. In practice, an RF band selec- tion filter is placed between an antenna and an LNA, but it is not shown in the figure
5 I LPF VGA ADC
LNA DSP
90 o
Q LPF VGA ADC
Figure 2.2: Direct conversion architecture
for simplicity. The DCR downconverts the desired signal directly from RF to DC and utilizes the baseband sampling. Thus, the DCR eliminates the need for discrete image rejection (IR) as well as intermediate frequency (IF) filters, which makes it suitable for monolithic integration. In addition, as the desired signal band is down- converted to the baseband at the early stage in the receiver chain, it is relatively easy to design the baseband circuits for multistandard operation. That is, the channel selection and automatic gain control (AGC) in DCRs are done at baseband using on-chip low pass filters and variable gain amplifiers which can be made to work for multiple wireless communication standards with low cost and less current consump- tion. Since the information bearing signal and blockers are translated to baseband together and channel selection is done at baseband, the DCR usually requires high dynamic range baseband circuits. This architecture becomes the most popular archi- tecture in implementing an integrated single-chip receivers, but the main problems are DC offset problem and I/Q mismatch.
6 I VGA BP ADC
Band Select LO Poly− BPF LNA Phase Filter 90 o
Q VGA BP ADC
Figure 2.3: Low-IF architecture
2.4 Low-IF Receiver Architecture
As shown in Fig. 2.3, the low-IF architecture looks quite similar to the direct conversion architecture except that it downconverts the received signal not to DC but to a low intermediate frequency (IF). The low-IF architecture also does not need external IF and IR filters, which makes it suitable for monolithic implementation.
In addition, it does not suffer from DC offset problem which is the main problem in
DCRs. But it has an image problem, so it needs integrated poly-phase filter for image rejection.
2.5 Digital-IF Receiver Architecture
Fig. 2.4 shows the digital-IF architecture [4] where an RF signal is downcon- verted to IF by an analog mixer and directly sampled at IF. Low frequency operations such as the second mixing and filtering are performed in digital domain, which is called
IF sampling. Since the I and Q are not separated in the analog domain, only one ADC
7 Channel Select I LPF
Band SelectImage Reject Channel Select 0 o Digital BPF LNA BPF BPF IF Amp ADC Sinewave Generator 90 o
Q LPF LO Channel Select
Figure 2.4: Digital-IF architecture
is necessary instead of two ADCs and I/Q mismatch problem is avoided. At least one analog IF stages can be eliminated compared to heterodyne architecture. Since analog-to-digital conversion is done at IF, the baseband can be very easily made pro- grammable. So, this architecture is suitable for multistandard operation. The main difficulty in this architecture is to achieve very high ADC requirements such as very low quantization and thermal noise, very high clocking rate, high linearity, wide dy- namic range, wide input bandwidth. Heavy anti-aliasing filtering may be costly for mobile units.
2.6 Summary
In this chapter, some of the important receiver architectures such as hetero- dyne, direct conversion, low-IF, and digital-IF receiver architectures were briefly sum- marized and their advantages and drawback were discussed.
8 CHAPTER 3
COMPACT TDD WIRELESS TRANSCEIVER ARCHITECTURE
3.1 Introduction
To realize high performance wireless radio transceivers in a smaller die area has been a challenging problem. In particular, reducing the silicon area is extremely crucial in implementing a multistandard transceiver in a single chip because baseband circuitry processing both in-phase (I) and quadrature-phase (Q) signals in both the receive and transmit paths end up occupying a significant part of the transceiver die area that could reach up to 50 % of the total die in some applications. Fig. 3.1 and
Fig. 3.2 show die microphoto examples from [1] and [2], respectively. Both chips are for wireless LAN applications and the figures illustrate that the I and Q analog baseband circuits take up at least 35 or 40 % of the total die area. In this chapter, a novel compact wireless radio transceiver architecture reusing a baseband chain so as to reduce a considerable die area is proposed. This transceiver architecture is especially suitable for time-division duplexing (TDD) systems but can be used for frequency-division duplexing (FDD) systems too.
9 Figure 3.1: Die photo example from [1]
10 Figure 3.2: Die photo example from [2]
11 3.2 Transceiver Architecture Description and Design Issues
The proposed architecture employs a direct conversion architecture with a shared baseband chain. Due to its simplicity and suitability for single-chip implemen- tation as well as multistandard operation, the direct conversion architecture [4] [5] is chosen. Fig. 3.3 shows a generic direct conversion transceiver architecture with DC feedback loops for DC offset cancellation. A radio frequency (RF) transmit/receive
(T/R) switch is placed after an antenna to switch between the receive path and the transmit path for TDD systems. Before a low noise amplifier (LNA), an RF band selection filter may be also placed. The order of the baseband filter and the variable gain amplifiers (VGAs) may vary according to the wireless standards and correspond- ing system designs. In some applications, VGAs may not be necessary in the transmit path. However, in general, direct conversion architectures have baseband filters and
VGAs placed in the receive path as well as in the transmit path as shown in Fig. 3.3.
Here, it is proposed to use the same baseband filters and VGAs in both the receive path as well as the transmit path to reduce the die area.
Fig. 3.4 shows the proposed transceiver architecture employing a direct con- version architecture with a shared baseband chain. The same baseband filters and
VGAs are utilized in both the receive path and the transmit path to reduce the die area.
In order for the baseband filters and the VGAs to be shared, switches are deployed in front of and at the end of the baseband chain. So, in the receive mode, the switches are connected such that the signal from down-conversion mixers is fed to the baseband chain and its output goes to analog-to-digital converters (ADCs).
On the other hand, in the transmit mode, the switches are connected such that the
12 DC Offset Cancellation
I LPF VGA ADC
Q LPF VGA ADC LNA
Frequency DC Offset Cancellation Synthesizer
PA I VGA LPF DAC
Q VGA LPF DAC
Figure 3.3: Direct conversion transceiver architecture
I ADC
DC Offset Cancellation
LNA Q LPF VGA ADC
Frequency Synthesizer I LPF VGA DAC PA
DC Offset Cancellation Q DAC
Figure 3.4: Compact TDD wireless radio transceiver architecture
13 I ADC
DC Offset Cancellation
LNA Q LPF VGA ADC
Frequency Synthesizer
LPF VGA
DC Offset Cancellation
(a) Receiver configuration
DC Offset Cancellation
LPF VGA
Frequency Synthesizer I LPF VGA DAC PA
DC Offset Cancellation Q DAC
(b) Transmitter configuration
Figure 3.5: Reconfigurable compact TDD wireless radio transceiver architecture
14 signal from digital-to-analog converters (DACs) is fed to the baseband chain and
up-conversion mixers get its output.
As reported in [6], baseband filters and VGAs can be designed to be further
reconfigurable for multistandard operation. That is, the number of filters and VGAs as well as the order of filters and VGAs can be made reconfigurable for each wireless standard. For some applications that VGAs are not necessary in the transmit path, the proposed transceiver can be reconfigured such that the transmit path does not have VGAs. DC feedback loops for DC offset cancellation can be also reconfigurable for each of the receive and transmit mode as well as for each wireless standard.
The dynamic behavior of this technique should be carefully considered. When we switch from the receive mode to the transmit mode, we may be able to turn off the DC feedback loops to save power since DC offset compensation may not as critical in the transmit path in some applications. However, we should also make sure that the turn on time of the DC offset compensation loop is adequate for proper operation when we switch back to the receive mode. This has to be determined based on the application at hand. The same argument could be made for the automatic gain control (AGC) loop in which case one should consider the settling time of such a loop in the receive mode. Also, the switches at baseband must be tightly synchronized with the switch at the RF front end and their parasitics must be modeled carefully and incorporated into the design process.
The proposed compact wireless transceiver architecture can be used for any wireless applications to achieve small die area as long as the system is designed to meet the required specifications. Since this architecture employs switches operated by control signals from digital signal processing units, the baseband circuits should be
15 designed to be settled fast enough. As the proposed architecture shares a single analog
baseband chain for both the receive and transmit paths, it should be used with time-
division duplexing (TDD) systems. Applications using TDD systems include IEEE
802.11a/b/g [7][8][9], Bluetooth [10], and TD-CDMA (UTRA/TDD). However, it can
be also used in frequency-division duplexing (FDD) systems if continuous reception is
not necessary. As long as transmission and reception do not occur at the same time,
this compact wireless transceiver architecture can be utilized.
3.3 Summary
In this chapter, a novel compact wireless radio transceiver architecture reusing a baseband chain was presented. By sharing the baseband chain, the proposed archi- tecture can reduce a considerable die area. Since this transceiver architecture shares a single analog baseband chain which is configured for the receive mode or transmit mode, it is especially suitable for time-division duplexing systems.
16 CHAPTER 4
DC OFFSET PROBLEM IN DIRECT CONVERSION RECEIVERS
4.1 Introduction
Among many architectures, the direct conversion architecture is the most at- tractive choice of architecture for multistandard wireless transceivers due to its sim- plicity and suitability for monolithic integration as well as multistandard operation.
As mentioned in Section 2.3, in spite of many merits in using DCRs, a set of prob- lems inherent in DCRs such as DC offset, I/Q mismatch, flicker noise (1/f noise), and even-order distortion, have been difficulties in deploying DCRs [11][3][12]. Among the problems mentioned above, DC offset problem has been known as the most seri- ous problem [11]. In DCRs, since the desired signal band is downconverted directly to baseband as shown in Figure 4.1, any DC offset can corrupt the desired signal.
In addition, as most of amplification in DCRs takes place in the baseband chain, a small DC offset can be amplified by baseband amplifiers to a level that saturates the following stages and consequently prohibits the amplification of the desired signal [4].
Therefore, it is necessary to cancel the DC offset to successfully implement the DCR. Thus far, to use AC coupling, high pass filtering (HPF), or DC feedback
17 ω ω 0 ωc 0
Figure 4.1: Spectrum for direct conversion
loop is the most popular and common solution [13][14][15][16]. They can be effec-
tive in eliminating the DC offset which is not changing over time, but cannot cancel
a fast varying DC offset. Some digital cancellation methods have been also intro-
duced in [17][18][19]. However, the cancellation methods have been developed mostly
for a specific standard or a modulation scheme, and little work has been done for
multistandard wireless receivers.
In this chapter, we investigate the origin of the DC offset and then model
the DC offset. Based upon the modeling, we propose a novel digital DC offset can-
cellation method using an adaptive filtering technique and also consider issues for
multistandard operation.
Two types of DC offset have been identified. DC offset can be considered
constant over time (called static or time-invariant) or changing over time (called
dynamic or time-varying). As pointed out in [20], “time-varying DC offset” may not
be a precise expression in some sense because it is not DC any more. We use the
term static/dynamic DC offset throughout the dissertation as the term can be found more often in the literature.
18 4.2 DC Offset Modeling
In this section, we summarize the DC offset generation mechanisms in DCRs and present the modeling of the DC offset to better understand the DC offset problem.
4.2.1 DC Offset Generation
DC offsets in DCRs can be generated by the following mechanisms [3][11][12]:
1. transistor mismatches in the signal path,
2. self-mixing of local oscillator (LO) signals leaking into the RF port of the mixer
and the input port of the LNA as shown in Fig. 4.2(a),
3. self-mixing of LO signals leaking into, radiated from, and reflected back to the
antenna as shown in Fig. 4.2(b),
4. self-mixing of strong in-band interferers leaking into the LO port of the mixer
from the output of the LNA as shown in Fig. 4.2(c), and
5. second-order intermodulation (IM2) of the components such as LNAs, mixers,
and filters.
Though only the I-branch is shown in Fig. 4.2, the Q-branch undergoes the same phenomenon.
The main source of DC offset is self-mixing which is the signal multiplied by itself. Considering a simple sinusoidal local oscillator (LO) signal with frequency ω
and ignoring the delay in leakage signal, from the trigonometric identities, self-mixing
yields 1 1 cos(ωt) · cos(ωt)= + cos(2ωt) 2 2 19 LNA
LO Leakage
(a) Self-mixing due to LO leakage
LNA
LO Leakage
(b) Self-mixing due to LO leakage radiated
LNA
Interferer Leakage
(c) Self-mixing due to interferer leakage
Figure 4.2: Generation of DC offsets due to self-mixing
20 where we see that the DC term and the twice frequency term are generated. The
higher frequency term is removed from the following low pass filter, but the DC
term remains and may corrupt the desired signals and saturate the following stages
if no cancellation method is applied. LO leakage is defined as the finite amount of
feedthrough existing from the LO port to the RF port of the mixer, to the input port
of the LNA, and to the antenna, and it arises from capacitive coupling, substrate
coupling, and bond wire coupling if the LO signal is externally provided [4].
The DC offsets generated by the mechanism 1 and 2 can be considered as static
whereas those by the mechanism 3 and 4 as dynamic, which will be clearer from the
modeling presented in the next section.
4.2.2 DC Offset Model
In this section, we present mathematical formulation of DC offset problem.
We employ the similar approach used in [21]. As the main source of DC offset is self- mixing which is the signal multiplied by itself, we analyze the DC offset generated by self-mixing mechanisms here. Thus we assume that the components such as LNAs, mixers, and filters are ideal and do not exhibit nonlinearities. Particularly, we assume that the above circuits are well-balanced so that the DC offset produced by the even- order nonlinearity would not be an issue here. Usually, LNAs and mixers should be designed such that their even-order nonlinearity could be low enough. In this way, we can simplify the problem and separate the DC offset due to self-mixing from the DC offset due to IM2. The analysis for second-order intermodulation in mixers can be found in [22] and [23]. The DC offset produced by mechanism 1 is not significant and may be considered as a static DC offset so that it is not modeled in this dissertation.
21 u(t)s(t) y(t) x(t) LNA LPF
l(t)
Figure 4.3: I-branch of direct conversion receivers
It can be reduced by better matching in layout and can be cancelled out using the static DC offset canceller which will be discussed in Section 5.4.
Fig. 4.3 shows the I-branch of DCR. Using complex envelope representation
[24], the local oscillator (LO) signal l(t) in the figure can be expressed as
√ l(t)= 2Re{ej2πfct}
where Re{·} represents the real part of a complex variable and fc is a carrier frequency.
For simplicity, a unit amplitude of LO signal is assumed. Assuming that the channel is ideal, the received signal u(t) from the antenna is a real-valued passband signal given as √ u(t)= 2Re{b(t) ej2πfct} √ where b(t) is a complex-valued baseband signal. 2 is to ensure that the passband signal has the same energy as the baseband signal. Ideally, the mixer input signal s(t)is
s(t)=Au(t)
22 where A is the gain of the LNA and the mixer output signal y(t)issimply
y(t)=s(t) · l(t).
Therefore, in ideal case, the filtered output x(t) is written as
x(t)=A Re{b(t)}. (4.1)
Now, we analyze the DC offset generated by three self-mixing mechanisms.
The models corresponding to the three self-mixing mechanisms are shown in Fig. 4.4.
DC Offset Generated by Self-Mixing due to LO Leakage
In Fig. 4.4(a), the mixer input signal s(t) which is now corrupted by the LO leakage can be written as
s(t)=Au(t)+(K1 + AK2) l(t)
where A is the LNA gain and K1 and K2 represent the attenuation of the LO signal leaking into the mixer and the LNA. Then, y(t)issimplyequaltos(t) · l(t)andthe output of the low pass filter, x(t)is
x(t)=A Re{b(t)} +(K1 + AK2). (4.2)
From (4.2), we see that the DC terms K1 and AK2 have been generated by this self- mixing mechanism. As A, K1 and K2 are not expected to be changing over time, the
DC offset in (4.2) can be considered as static DC offset. Obviously, the LO leakage reached the LNA input port creates a larger DC offset due to the gain of the LNA.
DC Offset Generated by Self-Mixing due to LO Leakage Radiated
When the LO leakage is radiated from the antenna and reflected back from moving objects or buildings, we can model the problem as shown in Fig. 4.4(b). When
23 u(t) s(t)y(t) x(t) LNA LPF
l(t)
KK2 1
(a) Self-mixing model due to LO leakage
u(t) s(t) y(t) x(t) LNA LPF
l(t)
Doppler Shift K 3
(b) Self-mixing model due to LO leakage radiated
u(t)s(t) y(t) x(t) LNA LPF
K 4 l(t)
(c) Self-mixing model due to interferer leakage
Figure 4.4: Self-mixing models in direct conversion receivers
24 Carrier Frequency Maximum Doppler shift Maximum Doppler shift from a person from a vehicle 800 MHz 4.2 Hz 71.5 Hz 1.9 GHz 9.9 Hz 169.9 Hz 2.4 GHz 12.5 Hz 214.6 Hz 5.15 GHz 26.9 Hz 460.5 Hz
Table 4.1: Maximum Doppler shift
an electromagnetic wave reflected from a moving object, it undergoes the Doppler
effect [25], i.e. when the reflecting object is moving toward or away from the receiver,
the frequency of the signal reflected back to the receiver increases or decreases. The
Doppler shift (fDS) is a function of the relative speed (v) of the reflecting object and
the receiver, a carrier frequency (fc), and the angle of arrival (α) of the reflected signal such as vf f [Hz] = c cos(α) DS c where c is 3 × 108 [m/s]. When the average human walking speed is 3.5 [mph] and the average vehicle driving speed is 60 [mph], assuming the receiver is stationary, the maximum Doppler shifts (when α is equal to zero) for four carrier frequencies are computed in Table 4.1.
To simplify the analysis, we assume that the radiated LO leakage experiences an ideal channel ignoring multipath fading, noise, and time delay. As shown in
Fig. 4.4(c), we consider only Doppler effect in this analysis. Then, the received signal u(t) corrupted by the radiated LO leakage experiencing Doppler shift can be written as √ √ j2πfct j2π(fc+fDS)t u(t)= 2Re{b(t) e } + K3 2Re{e }
25 where K3 models the attenuation of the LO signal leaking into the antenna and fDS
represents the maximum Doppler effect experienced by the leakage. As s(t)isequal to Au(t), the filtered output x(t)is
j2πfDSt x(t)=A Re{b(t)} + AK3 Re{e }. (4.3)
We see from (4.3) that this mechanism does produce a time-varying DC offset term with the frequency of fDS, and we also know from Table 4.1 that the DC offset varies very slowly. Though we pick the largest maximum Doppler shift in the table which is 460.5 Hz, the duration of one period is 2.172 msec which is quite long compared to the preamble or symbol duration of wireless standards such as IEEE 802.11a [7] in
Appendix A.
DC Offset Generated by Self-Mixing due to Interferer Leakage
Self-mixing due to interferer leakage can be formulated in the same manner as in [21]. The received signal u(t) corrupted by the interferer can be written as √ √ u(t)= 2Re{b(t) ej2πfct} + 2Re{a(t) ej2πfit}
where a(t) is an interference signal centered at fi. The LO signal l(t) corrupted by the interferer leakage is expressed as √ j2πfct l(t)= 2Re{e } + AK4 u(t).
Since s(t)isequaltoAu(t), the output of the low pass filter x(t)is
x(t)=A Re{b(t)} + A Re{a(t) ej2πfot}
2 2 2 + A K4 [|a(t)| + |b(t)|
+2 Re{a(t) b∗(t) ej2πfot}] (4.4)
26 where fo = fi − fc and ∗ denotes complex conjugate. From (4.4), we identify the DC
2 2 2 2 j2πfot terms A K4 |a(t)| and A K4 |b(t)| , and time-varying terms A Re{a(t) e } and
2 ∗ j2πfot 2 A K4 Re{a(t) b (t) e } from interferer self-mixing mechanism. Here, fo should be less than the cut off frequency of the low pass filter (LPF) as x(t) has passed the
LPF. Therefore, the interferers producing dynamic DC offset are nearby user signals or any other strong signals in the same channel. Consequently, the range of fo is from
0 Hz to the LPF cut off frequency, and fo cannot be known in advance.
4.3 DC Offset Cancellation for Multistandard Receivers
From the DC offset modeling in the previous section, we learn that how much static as well as dynamic DC offsets in the DCR can be generated by self-mixing due to LO and interferer leakages. Based upon the models presented, we propose a multistandard DCR architecture with DC offset cancellation in Fig. 4.5. Since it is a multistandard DCR, the DCR is controlled by many control signals from the DSP as shown in the figure.
As shown in Fig. 4.5, the static and dynamic DC offsets are cancelled separately in the proposed architecture. To prevent the back-end in the receiver from saturation, the large DC offsets that are constant or varying very slowly have to be removed in the analog domain right after the mixer. In other words, the static DC offsets generated by the self-mixing mechanisms analyzed in Section 4.2.2 and Section 4.2.2 as well as theveryslowlyvaryingDCoffsetobservedin Section 4.2.2 should be cancelled before
LPF. The same DC feedback loop can also be deployed around VGAs to cancel the DC offset generated by the VGAs, but it must be placed around the LPF to effectively cancel the DC offset generated by the down-conversion mixers. In our proposed
27 Static DC Offset Canceller DC Feedback
I Dynamic LPF VGA ADC DC Offset Canceller
Control LNA DSP Signals
90 o
Q Dynamic LPF VGA ADC DC Offset Canceller
DC Feedback Static DC Offset Canceller
Figure 4.5: Multistandard DCR with DC offset cancellation
architecture, DC feedback loops are employed as our static DC offset cancellers as shown in Fig. 4.5. More detailed discussion on the static DC offset cancellation will follow in Section 4.3.1.
The residual dynamic DC offsets generated by the self-mixing mechanism ana- lyzed in Section 4.2.2 can be removed in the digital domain. The fast varying dynamic
DC offset generated by self-mixing due to interferer leakage cannot be easily measured and subtracted because it cannot be known when the dynamic DC offset is produced.
For some wireless communication standards receiving signals continuously, the long- term averaging method can be used for canceling the dynamic DC offset. That is, the received signals are stored during a certain time period and the mean value of them is subtracted from each data. But this is not capable of cancelling rapidly varying
28 DC offset. Therefore, we need a more sophisticated and refined technique in digital
domain to cancel the dynamic DC offset. For a multistandard DCR, the cancella-
tion scheme should work for both continuous reception and burst reception cases.
Section 4.3.2 and Section 4.4 will discuss on the dynamic DC offset cancellation.
4.3.1 Static DC Offset Cancellation
To cancel the static DC offset, we have to cut out some portion of the spectrum around DC using high pass filtering. Thus, the main issue here is whether or not we can do so without degrading the performance. Consequently, a modulation scheme is the most critical issue for the static DC offset cancellation in multistandard DCRs.
Modulation schemes such as FSK have little energy around DC, so we can use high pass filtering to cancel the static DC offset. Modulation schemes like PSK have considerable amount of energy near DC, but for wideband systems, the performance degradation due to high pass filtering may not be critical. It is reported in [12] that the cutoff frequency of the high pass filtering should be about 0.1 % of data rate to avoid significant degradation. For multistandard operation, we need to either adjust the high pass cutoff frequency according to each standard or set it to the lowest one which corresponds to the lowest data rate.
In this dissertation, we propose to use a DC feedback loop [13][26][27] shown in Fig. 4.6 as a static DC offset canceller.
A DC feedback loop creates a high pass pole at a frequency close to DC to remove a static DC offset. We could use an AC coupling capacitor or a high pass filter instead of a DC feedback loop to create a high pass pole. But, to use DC feedback loops is more apt for multistandard operation as well as monolithic implementation
29 g m C
Vin LPF Vout
Figure 4.6: Static DC offset canceller
because we can easily control the high pass cutoff frequency with smaller capacitance values.
The transfer function of the static DC offset canceller shown in Fig. 4.6 can be found as V (s) 1+s(r C) out = o 1 2 roC Vin(s) (1 + g r )+s r C + + s m o o SLP F SLP F
where ro is the output resistance of the transconductance (gm) cell and SLP F is the low pass pole created by the low pass filter (LPF). Assuming 1 S , the transfer roC LP F function can be approximated near DC as V (s) 1 1+s(r C) out ≈ o roC Vin(s) 1+gmro 1+s 1+gmro
which clearly shows that the DC feedback loop functions as a high pass filter. Fig. 4.7
shows the ideal frequency responses for the static DC offset canceller shown in Fig. 4.6.
By fixing the value of gm and ro and changing the value of C, we can easily change the high pass cutoff frequency of the static DC offset canceller according to each wireless standard. As we can see from Fig. 4.7, we need to have gm smaller to achieve a lower high pass cutoff frequency with a reasonable size of integrated
30 1
1 1+gmro s 1 gm SLPF roC C
Figure 4.7: Ideal frequency response of the static DC offset canceller
capacitors. In addition, we observe that we need to have ro larger to have enough attenuation around DC.
4.3.2 Dynamic DC Offset Cancellation
In order to effectively cancel the dynamic DC offset, we should estimate the
DC offset and subtract it from the original signal in real-time in the digital domain.
Also, to make the cancellation scheme work for multistandards, the technique should not be sensitive to the modulation schemes. Adaptive filtering would be the best technique to track and cancel the dynamic DC offset in multistandard environment.
In particular, the dynamic DC offset can be effectively cancelled by using the adaptive noise cancellation technique [28]. In the next section, a detailed description of the proposed dynamic DC offset cancellation mechanism will be presented.
31 4.4 Dynamic DC Offset Cancellation Using Adaptive Filter- ing
In this section, a dynamic DC offset cancellation scheme using adaptive fil- tering technique is presented. A brief summary on adaptive filtering techniques is introduced first, and then we explore the dynamic DC offset cancellation technique using adaptive noise cancellation techniques.
4.4.1 Adaptive Filtering Techniques
An adaptive filter has been a powerful tool in signal processing and control applications due to its ability to operate satisfactorily in an unknown environment and track time variations of input statistics [28]. The adaptive filtering problems can be classified into 4 classes.
Identification: In Fig. 4.8(a), the plant represents an unknown system. The plant
and the adaptive filter are fed by the same input u(n). By adjusting the filter
coefficients, the adaptive filter provides a linear model of the unknown plant.
Channel estimation in communication systems falls into this class.
Inverse modeling: In Fig. 4.8(b), the plant is an unknown system and the adaptive
filter provides an inverse model of the unknown plant. In the case of a linear
system, the inverse model has an inverse transfer function of the unknown plant.
Channel equalization in communication systems is classified into this class.
Prediction: As shown in Fig. 4.8(c), the filter provides the prediction of the present
value of the random input based on the past values of the input u(n). Source
32 coding, channel prediction, and de-noising are some of the applications of this
class.
Interference cancellation: As shown in Fig. 4.8(d), the filter has two inputs, d(n)
and u(n). d(n) is called a primary signal containing an information bearing
signal and an unknown interference or noise signal. u(n) is called a reference
signal which is derived from the interference or noise source. The adaptive
filter can cancel the unknown interference or noise in the primary signal using
the reference signal. Applications of this class include noise cancellation, echo
cancellation, and beamforming.
Thus, adaptive filters in all four classes have the same elements: desired re-
sponse d(n), adaptive filter output y(n), adaptive filter input u(n), and the estimation
error e(n) which is calculated as
e(n)=d(n) − y(n).
The adaptive filter adjusts the filter coefficients so that the estimation error is mini-
mized in some sense. In other words, a recursive algorithm is employed to update the
filter coefficients. Basically, there are two kinds of popular recursive algorithms: the
Least-mean-square (LMS) algorithm and the Recursive least-square (RLS) algorithm.
The RLS algorithm is based on the least-square (LS) algorithm which is determin-
istic. The RLS converges faster than the LMS, but it is more complex and could
have a stability issue. On the other hand, the LMS is the stochastic gradient decent
algorithm. In the LMS, the filter coefficients are updated according to
w(n +1)=w(n)+μ · u(n) · e∗(n)
33 u(n) d(n) e(n) Plant
Adaptive y(n) Filter
(a) Identification
d(n+ Δ ) Delay d(n) e(n) (Δ)
u(n) Adaptive y(n) Plant Filter
(b) Inverse modeling
u(n+ Δ ) d(n) e(n)
y(n)
Delay u(n) Adaptive (Δ) Filter
(c) Prediction
d(n) e(n)
u(n) Adaptive y(n) Filter
(d) Interference cancellation
Figure 4.8: Adaptive filtering problem classification
34 where w(n) represents the adaptive filter coefficient at time index n, μ the step size, and * complex conjugate. The LMS is simpler and more stable than the RLS, and it has a good tracking performance. But it takes longer to converge than the RLS. By far, the LMS is the most popular adaptive filtering algorithm and will be used in our case too.
4.4.2 Adaptive Dynamic DC Offset Cancellation
The main target DC offset to be cancelled in the digital domain is the dynamic
DC offset generated by self-mixing due to interferer leakage. From the DC offset models, we know that the dynamic DC offset is a sinusoid with the frequency fo.
Thus, our dynamic DC offset cancellation problem is reduced to an adaptive noise cancellation problem with the primary input (d(n)) consisting of the desired signal
(s(n)) and a dynamic DC offset (o(n)).
As shown in the Fig. 4.8(d), the original adaptive noise canceller needs a primary input d(n) as well as a reference input u(n) which is correlated to the offset
signal o(n). When we denote the primary input d(n)as
d(n)=s(n)+o(n),
the reference signal as
u(n)=o1(n), and the adaptive filter output as y(n), the error signal e(n) will be equal to d(n)−y(n).
Here, we know that the desired signal s(n) is uncorrelated to o(n)andtoo1(n), but the offset signals o(n)ando1(n) are correlated to each other. So, by adapting the adaptive filter using some algorithm, we can get the filter output
y(n) ≈ o(n),
35 s(n) + o(n) d(n) e(n) Primary Input y(n)
Delay u(n) Adaptive (Δ) Reference Filter Input
Adaptive Noise Canceller
Figure 4.9: Dynamic DC offset canceller
which means
e(n) ≈ s(n).
But the reference input is not available in our problem. Thus, we should
employ the adaptive noise canceller without an external reference source [29] shown
in Fig. 4.9. As shown in Fig. 4.9, the reference signal u(n) in our problem is the
delayed version of the input signal d(n) consisting of the desired signal s(n)andthe
dynamic DC offset o(n) which is a sinusoid, that is,
u(n)=d(n − Δ) = s(n − Δ) + o(n − Δ).
As a whole, this is also called an adaptive linear forward predictor [29][30] which
can cancel a sinusoid from a broadband signal. In modern digital communication
systems, the modulated signal can be considered as broadband signal, so that this
dynamic DC offset canceller can work for wireless multistandard. Since the desired
signal s(n) is a broadband signal and the dynamic DC offset o(n) is a sinusoid, s(n)
and s(n − Δ)) are uncorrelated and o(n)ando(n − Δ)) are correlated. Therefore, the
delayed version of the input signal can be an effective reference signal for the adaptive
36 (1 or 0) (1 or −1)
Data BPSK TX Upsampling Generation Modulation Filter
RX Adaptive BPSK Downsampling Filter Offset Canceller Demodulation
Figure 4.10: Simulation setup with ideal channel
noise canceller. By adapting the adaptive filter using some algorithm, we can make the signal e(n) equal to our desired signal s(n) which is free from the dynamic DC
offset.
4.4.3 Simulation Studies
Simulations were performed with 1 Mbps binary phase shift keying (BPSK) signals and 1 MHz of a dynamic DC offset. The magnitude of the offset is bigger than that of the desired signal by 30 dB. An ideal channel is assumed first and later the additive white Gaussian noise (AWGN) channel is considered. Fig. 4.10 shows the
Matlab simulation setup which models a digital communication transmitter (TX) and a receiver (RX) [31] in an ideal channel environment. To make the simulation setup more realistic, the BPSK modulated signal is upsampled at the TX and downsampled at the RX. The number of oversamples used here is 10. The TX and RX filters are
Nyquist filters with roll-off factor 0.5 and 21 taps. The adaptive dynamic DC offset canceller is located between the RX filter and the downsampler. The dynamic DC offset signal is added to the receiver signal, which is not shown in the figure. In
37 AWGN (1 or 0) (1 or −1)
Data BPSK TX Upsampling Generation Modulation Filter
RX Adaptive BPSK Downsampling Filter Offset Canceller Demodulation
Figure 4.11: Simulation setup with AWGN channel
Fig. 4.11, the Matlab simulation setup in an additive white Gaussian noise (AWGN)
channel environment. The white Gaussian noise is added to the channel in the model.
Among many algorithms to update the adaptive filter, we used the normalized
least mean square (NLMS) algorithm [28] in which the adaptive filter coefficient w(n)
is updated using
∗ w(n +1)=w(n)+μNLMS · u(n) · e (n)
−1 2 where μNLMS =1/(μ + ||u(n)|| ) and * denotes complex conjugate. μ was chosen to be 0.001.
Two important parameters in designing the adaptive dynamic DC offset can- celler are the adaptive filter length and the value of the delay, Δ. The choice of the optimal filter length in an adaptive linear forward predictor has been studied in
[30] and it is shown that the optimal filter length is dependent on input SNR and ∼ signal bandwidth α. Under low SNR conditions, Lopt = 1/α, and under high SNR conditions, Lopt < 1/α.Thus,
Lopt ≤ 1/α
38 where α is the signal bandwidth [30]. This gives an idea on the upper bound of L.
Attempting to over-resolve narrowband signal by increasing L eventually degrades the performance because of larger misadjustment noise. The value of the delay, Δ, which is known as the prediction distance of the filter or decorrelation parameter, should be chosen in such a way that the broadband signal can be effectively decorrelated and disappeared at the filtered output, y(n). In adaptive linear forward predictor, the optimum Δ, Δopt, which minimizes the prediction error (e(n)) power is derived and
given by
ω(2Δopt + L − 1) = nπ where n is integer. Thus, the optimum value of Δ is a function of the filter length (L) and the frequency (ω) of the input sinusoid which are not known apriori[32]. So, it is difficult to use this in our problem. It is also reported that the optimum value of Δ for noise suppression lies in an interval between the correlation distance of the noise and the correlation distance of the signal [30]. A series of simulations were performed to get an optimum length with Δ = ceil(L/2) and then to find an optimum delay. In our case, the adaptive filter length (L) is chosen to be 9 and the delay (Δ) is set to
5, which gives the best performance from the simulation studies.
Fig. 4.12(a) shows the offset corrupted signal which is input to the DC offset canceller and Fig. 4.12(b) shows its output. Fig. 4.13(a) and Fig. 4.13(b) show the squared data error with offset canceller and without offset canceller, respectively.
Right at the moment that the DC offset was applied, the error occurred, but soon it cancelled all the dynamic DC offset. Fig. 4.14(a), Fig. 4.14(b), Fig. 4.15(a), and
Fig. 4.15(b) show the simulation results with AWGN channel. In this case, the DC offset was applied from the beginning. Since the channel is no longer ideal, there are
39 some errors even with the DC offset canceller. However, compared to the case without
the offset canceller, we still see that the offset canceller can effectively cancel the offset.
Fig. 4.16 shows the BER performance in AWGN channel. The simulation results
show that the BER performance was much improved with this dynamic DC offset
cancellation scheme compared to the case without the dynamic DC offset cancellation.
The MatLab codes developed for simulations appear in Appendix B.
4.5 Summary
In this chapter, three self-mixing mechanisms generating the DC offset in di- rect conversion receivers were modeled. A DC offset cancellation technique suitable for multistandard wireless direct conversion receivers was proposed. The proposed cancellation scheme suggests to separate the dynamic DC offset cancellation from the static DC offset cancellation. A dynamic DC offset canceller utilizing an adaptive
filtering technique was proposed and verified through simulation. The simulation results demonstrate that the proposed dynamic DC offset technique can effectively cancel a very fast varying DC offset.
40 AFP input signal d(n) corrupted by offset 40
30
20
10
0
−10
−20
−30
−40 0 2000 4000 6000 8000 10000 12000 (a) offset corrupted input d(n)
corrected signal and desired signal 20 e s 15
10
5
0
−5
−10
−15
−20
−25 0 2000 4000 6000 8000 10000 12000 (b) offset canceller output e(n)
Figure 4.12: 1000-symbol BPSK simulation results with ideal channel: part 1
41 (raw data − demodulated data)2 2
1.5
1
0.5
0
−0.5
−1 100 200 300 400 500 600 700 800 900 1000 (a) squared data error with offset cancellation
(raw data − demodulated data)2 2
1.5
1
0.5
0
−0.5
−1 100 200 300 400 500 600 700 800 900 1000 (b) squared data error without offset cancellation
Figure 4.13: 1000-symbol BPSK simulation results with ideal channel: part 2
42 AFP input signal d(n) corrupted by offset 40
30
20
10
0
−10
−20
−30
−40 0 2000 4000 6000 8000 10000 12000 (a) offset corrupted input d(n)
corrected signal and desired signal 20 e s
15
10
5
0
−5
−10 0 2000 4000 6000 8000 10000 12000 (b) offset canceller output e(n)
Figure 4.14: 1000-symbol BPSK simulation results with AWGN channel (Eb/N0 =3): part 1
43 (raw data − demodulated data)2 2
1.5
1
0.5
0
−0.5
−1 100 200 300 400 500 600 700 800 900 1000 (a) squared data error with offset cancellation
(raw data − demodulated data)2 2
1.5
1
0.5
0
−0.5
−1 100 200 300 400 500 600 700 800 900 1000 (b) squared data error without offset cancellation
Figure 4.15: 1000-symbol BPSK simulation results with AWGN channel (Eb/N0 =3): part 2
44 BER − BPSK 0 10
−1 10
−2 10
−3 10 BER
−4 10
−5 10 theory w/o offset offset with cancellation offset w/o cancellation
−6 10 0 1 2 3 4 5 6 7 8 9 10 Eb/N0 [dB]
Figure 4.16: BER performance of the dynamic DC offset canceller
45 CHAPTER 5
DESIGN OF ANALOG BASEBAND PROTOTYPE
5.1 Introduction
In this chapter, the design of a fully differential analog baseband chain is presented. A fully differential architecture has been chosen for improving the perfor- mance in terms of supply noise rejection, dynamic range, and harmonic distortion [6].
First, the chapter starts with a core amplifier design for use in both the baseband channel selection filter and the variable gain amplifier (VGA). A fully balanced dif- ferential difference amplifier (FBDDA) is employed as a core amplifier in this design.
And the design of the channel selection filter and the VGA using the FBDDA follow.
5.2 Fully Balanced Differential Difference Amplifier
A differential difference amplifier (DDA) [33][34][35] has been adopted as the core amplifier in the design of the analog baseband chain including a channel selection
filter and a variable gain amplifier (VGA). The DDA is a versatile building block for analog signal processing and has been utilized in many applications [33][34][35]. In particular, a fully balanced version of the DDA [36][37] has been employed in this design to implement a fully differential analog baseband chain.
46 V i Vo
Figure 5.1: A buffer configuration
The fully balanced differential difference amplifier (FBDDA) is an attractive choice in implementing fully differential op-amp circuits where both the op-amp inputs are floating [37]. Especially, the FBDDA is quite useful in realization of a fully differential buffer. Fig. 5.1 shows a common buffer configuration using a single-ended op-amp. This buffer configuration cannot be converted to a fully differential buffer configuration by the steps described in [38] because none of the op-amp inputs are grounded. Normally, one can use two single-ended op-amps to build a fully differential buffer, that is, one for the positive input and the other for the negative input, in which case the number of elements are doubled and the matching between the two paths is difficult to achieve. However, as shown in Fig. 5.2, a FBDDA has four inputs so that a fully differential buffer can be readily constructed using a single FBDDA, which results in a smaller area and a better matching. This is the reason why the
FBDDA was chosen in this implementation of an analog baseband chain. As it will be discussed in Section 5.3 and Section 5.5, the FBDDA is very suitable for implementing fully differential Sallen-Key filters as well as fully differential variable gain amplifiers.
Once a FBDDA is designed, we can extensively use it in implementing a baseband
filter and a variable gain amplifier.
47 Vpp
Vpn Vop
Vnp Von
Vnn
Figure 5.2: Fully balanced differential difference amplifier (FBDDA) symbol
As shown in Fig. 5.2, the FBDDA has four inputs. The outputs of the FBDDA can be written as
Vop − Von = Ao [(Vpp − Vpn) − (Vnp − Vnn)] (5.1)
where Ao is the open-loop gain of the FBDDA and it is ideally infinite. From (5.1),
when a negative feedback is applied, the two differential inputs have the following
relation:
(Vpp − Vpn)=(Vnp − Vnn) (5.2) as Ao →∞[36][37], that is, the differential voltages of the two inputs become equal as the open-loop gain Ao approaches infinity. Therefore, the open-loop gain Ao should be made as large as possible to achieve a good performance, which is also the case in the op-amp design.
Now that a FBDDA has four inputs and two outputs, two outputs can be fed back to construct a fully differential buffer as shown in Fig. 5.3. In the figure, in order
+ to make negative feedbacks, the positive output Vo is connected to the negative input
− Vpn and the negative output Vo is connected to the positive input Vnn.Inthiscase,
48 Vi
Vo
Vi Vo
Figure 5.3: Fully differential buffer configuration using FBDDA
Vnn should be considered as a positive input because it is a double negative in the
notation. This fully differential buffer configuration will be utilized in the design of
a Sallen-Key low pass filter in Section 5.3.
5.2.1 Circuit Implementation
Fig. 5.4 shows a circuit implementation of the FBDDA with two common-mode feedback (CMFB) circuits. As shown in the figure, the core of the FBDDA is a two- stage amplifier. The first input stage of the amplifier has two differential pairs instead of one to accommodate four inputs. The PMOS input stages (M1 through M4) are employed with NMOS current source loads (M5 and M6). The PMOS input stage has been chosen for a better noise performance against the NMOS counter part [39].
The second output stages consist of NMOS common-source stages (M9 and M10) and
PMOS current source loads (M11 and M12). To ensure the stability, compensating capacitors (Cc) and resistors (Rc) [40][41] are included. The small-signal voltage gain
49 of the FBDDA is given as
Ao = gm1(ro1||ro5) · gm9(ro9||ro11) (5.3)
where gm and ro denote the transconductance and the output resistance of MOS transistors, respectively. So, in order to increase the gain, the transconductance of the input and output common-source stages should increase. The input-referred thermal noise can be obtained as 2 16 2 gm5 Vn = kT + 2 (5.4) 3 gm1 gm1 where k is the Boltzmann’s constant (1.38 × 10−23 J/K) and T is the temperature in
Kelvin [42] [37]. This suggests that large input PMOS devices and small NMOS load devices are preferable to achieve low noise.
Two CMFB circuits are used to keep the common-mode output voltages from drifting [43]. Normally, one CMFB circuit is employed for setting the output voltage of the second stage, but it was found out through corner simulations that the output voltage of the first stage also needs a CMFB circuit. Two different types of CMFB circuits are utilized. The circuit in Fig. 5.4(b) is used to set the second-stage common- mode output voltages (Vop and Von) and the circuit in Fig. 5.4(c) is used to set the first- stage common-mode output voltage (Vop1 and Von1) [44]. The CMFB1 in Fig. 5.4(b) senses the second stage output common-mode voltage which is the average voltage of Vop and Von through two equal size resistors (Rcm). The voltage between the two resistors, Voc,is V + V V = op on (5.5) oc 2 and the desired common-mode voltage Vcm is subtracted from the detected common- mode voltage Voc. Then, the output voltage of the differential amplifier consisting
50 Vb1 M11 Vb3 M7 M8 Vb3 M12
Von VpnM1 M2 Vpp Vnp M3 M4 Vnn Vop
Cc Rc Rc Cc
Vop1 Von1
Vb2 M9 M5 M6 M10
(a) FBDDA core
M3c M4c Rcm Vop Ccm Vb3
Vcm M1c M2c Voc
Ccm Von Vbcm1 M5c Rcm
(b) CMFB1
Vb1 M6cc M7cc
Vcm2 Von1 M1cc M2cc M3cc M4cc Vop1
Vb2 M5cc
(c) CMFB2
Figure 5.4: Realization of FBDDA with common-mode feedback (CMFB) circuits
51 of M1c through M5c controls the gate voltages of the second stage PMOS current
sources, M11 and M12, in Fig. 5.4(a). The CMFB1 circuit can control the common-
mode voltage quite well so that the output common-mode voltage is very close to
the Vcm provided. But due to the resistors (Rcm) and capacitors (Ccm), it suffers from loading effect. On the other hand, the CMFB2 in Fig. 5.4(c) [43] uses only transistors and it does not have as much loading effect as the CMFB1 does. In
CMFB2, the differential pairs M1cc through M4cc are matched and the first stage output common-mode voltage in Fig. 5.4(a) is detected through M1cc through M4cc.
Here, the drain current in M2cc and the drain current in M3cc are proportional to the voltage differences Vop1 − Vcm2 and Von1 − Vcm2, respectively. These currents are summed in diode-connected NMOS M5cc and mirrored by M5 and M6 in Fig. 5.4(a) to consequently control the first stage output common-mode voltage. The CMFB2 circuit is still capacitively loaded by the PMOS M1cc and M4cc but it is suitable to control the first stage output common-mode voltage. The CMFB1 cannot be used in place because its resistive load can severely affect the performance.
The FBDDA circuit has been designed using the AMI 0.5 μm standard digital process available through MOSIS [45]. It is a twin-well CMOS technology on P- substrate. The process has two poly and three metal layers. The Poly-Insulator-Ploy
(PiP) capacitors consisting of the two poly layers has capacitance of 950 aF/μm2.
The resistors can be made using a high resistance poly (HRP) layer, one of the two poly layers. The threshold voltage is about 0.71V for NMOS and about 0.99V for
2 PMOS. The value of μnCox for NMOS is about 100 μA/V and that of μpCox for
PMOS is about 40 μA/V2. The nominal supply voltage of the process is 5V but
the FBDDA was designed with 3V supply voltage. Fig. 5.5 shows the layout view of
52 the FBDDA in the buffer configuration shown in Fig. 5.3. This FBDDA is used in
both the baseband filter and the variable gain amplifier implementation which will
be described in the later sections.
5.2.2 Simulation Results
The FBDDA was simulated using the BSIM3v3 models in Cadence environ- ment. Table 5.1 summarizes the open-loop performance of the FBDDA in the typical corner. The amplifier was loaded with 2pF capacitance. The DC gain was traded off for the bandwidth. In the buffer configuration, the gain-bandwidth product is
126.7MHz. The spot noise was measured at 20MHz where the minimum occurs. The √ spot noise at 1MHz was 15.2nV/ Hz. The 1dB input compression point in the buffer configuration is 15dBm.
The AC response of the open-loop configuration is shown in Fig. 5.6 and that of the buffer configuration in Fig. 5.7. Fig. 5.8 illustrates the noise performance. For stability test, the step input was applied into the amplifier in the buffer configuration and its step response is shown in Fig. 5.9. The plot of the 1dB input compression point in the buffer configuration is illustrated in Fig. 5.10.
53 Figure 5.5: Layout view of the FBDDA in the buffer configuration
54 Figure 5.6: AC response of the fully balanced differential difference amplifier
55 Figure 5.7: AC response of the FBDDA in the buffer configuration
56 Figure 5.8: Noise response of the FBDDA
57 Figure 5.9: Step response of the FBDDA in the buffer configuration
58 Figure 5.10: Input 1dB compression point of the FBDDA in the buffer configuration
59 Parameter Result Unit Technology 0.5 μm Supply voltage 3 V Open loop gain 60.4 dB Phase margin 67 ◦ -3dB bandwidth 73.6 KHz Gain-bandwidth product 77.3 MHz√ Noise at 20MHz 9.4 nV/ Hz Input compression point 15 dBm Current consumption 2.77 mA Power consumption 8.3 mW Area 580 × 230 μm × μm
Table 5.1: Performance of the fully balanced differential difference amplifier
5.3 Channel Selection Filter
The main purpose of the channel selection filters in wireless receivers is to
filter out the blockers and relax the linearity requirement of the receiver. Active RC and gm-C filters are popular choices of channel selection filters. The gm-C filters are more suitable for high frequency applications but it is difficult to achieve high linearity with gm-C filters. On the other hand, active RC filters have better linearity.
In this baseband design, an active RC filter topology is employed. Among various kinds of active RC filters, the Sallen-Key filter has been chosen because it has a simple topology and thus occupies less area.
5.3.1 Fully Differential Sallen-Key Low Pass Filter
Fig. 5.11 shows a third-order Sallen-Key low pass filter topology [46][47][48].
It has only one amplifier in the buffer configuration. The unity-gain buffer can be just
60 C 2
R 3 R 1 R 2 V i Vo C 3 C 1
Figure 5.11: Third-order Sallen-Key low pass filter
a source follower in the simplest form of implementation [49]. Fig. 5.11, without R3
and C3, it is a second-order Sallen-Key low pass filter. Thus, using the second-order and the third-order Sallen-Key sections, a higher order filter can be most efficiently built with a smaller number of amplifiers. The transfer function of the third-order
Sallen-Key low pass filter shown in Fig. 5.11 can be found as
Vo(s) 1 = 3 3 2 2 (5.6) Vi(s) R C1C2C3s +2R (C1C3 + C1C2)s + R(3C1 + C3)s +1 where R = R1 = R2 = R3. The Sallen-Key filter can be designed with an amplifier
whose gain is more than unity [38][48]. However, it is reported that the damping ratio
in this case is dependent on the values of resistors that set the closed-loop amplifier
gain, thus poles may be less reliably located [48]. Consequently, it is more popular to
use a buffer in the Sallen-Key filter implementations so that the filter section has 0dB
gain. In the analog baseband systems for wireless communication receivers, usually
the gain is obtained by variable gain amplifiers and the channel selection filter has 0
dB gain.
Now that the single-ended filter structure in Fig. 5.11 cannot be straightfor-
wardly extended to a differential version using a differential op-amp as we discussed
61 in Section 5.2, a fully balanced differential difference amplifier (FBDDA) presented
in Section 5.2 is employed here to build a fully differential Sallen-Key low pass filter.
As shown in Fig. 5.12(a), a third-order fully differential Sallen-Key low pass filter
can be readily implemented with a FBDDA in the buffer configuration. To tune the
filter, MOS transistors operating in the triode region can be placed in parallel with
resistors as shown in Fig. 5.12(b) [6]. That is, the filter tuning can be achieved by
varying the gate voltages of the MOS resistors operating in triode region. In addition,
the filter can be designed to be programmable for multistandard operation by having
another set of resistor chains connected in parallel and reconfigured using switches as
shown in Fig. 5.13. So, by varying resistors, we can obtain both the filter tuning and
the multistandard operation. Now, by cascading the two fully differential third-order
Sallen-Key low-pass filters, a fully differential sixth-order Sallen-Key low-pass filter
suitable for multistandard operation is realized in Fig. 5.14. The filter was designed
to work with three wireless standards such as Bluetooth, IEEE 802.11a, and IEEE
802.11b/g. So, R was set to 3.1KΩ for 802.11a/b/g and to 48KΩ for Bluetooth.
Capacitance values don’t change with the standard. C1 was set to 0.3pF, C2 to 7pF, and C3 to 2.77pF.
5.3.2 Simulation Results
The fully differential sixth-order Sallen-Key low-pass filter was designed using the AMI 0.5 μm standard digital process available through MOSIS [45], and simulated using the BSIM3v3 models in Cadence environment. The filter was loaded with 2pF capacitance at each output node. The filter performance in the typical corner is √ summarized in Table 5.2. The spot noise was 34.5nV/ Hz at 1MHz. The 1dB input
62 C 2
R 3 R 1 R 2 V i
C 3 C 1 Vo Vcm C Vo C 3 1
V i R 3 RR1 2
C 2 (a)
C 2
R 3 RR1 2 V i
C 3 C 1 Vo
Vcm C Vo C 3 1
V i R 3 R 1 R 2
C 2 (b)
Figure 5.12: Fully differential third-order Sallen-Key low pass filter using FBDDA
63 C 2
R 3 R 1 R 2
R 3 R 1 R 2 V i
C 3 C 1 Vo Vcm C Vo C 3 1
V i R 3 R 1 R 2
R 3 R 1 R 2
C 2
Figure 5.13: Fully differential third-order Sallen-Key low pass filter for multistandard operation
C 2 C 2
R 3 R 1 R 2 R 3 R 1 R 2
R 3 R 1 R 2 R 3 R 1 R 2 V i
C 3 C 1 C 3 C 1 Vo Vcm Vcm C C Vo C 3 1 C 3 1
V i R 3 R 1 R 2 R 3 R 1 R 2
R 3 R 1 R 2 R 31R R 2
C 2 C 2
Figure 5.14: Fully differential sixth-order multistandard Sallen-Key low pass filter
64 compression point in the buffer configuration was 15dBm and the third order input intercept point was 19dBm.
The AC response of the fully differential sixth-order Sallen-Key low-pass filter is shown in Fig. 5.15. The frequency response of the filter shows the cut-off frequencies for three wireless standards: 500 KHz for Bluetooth, 10 MHz for IEEE 802.11a, and
11 MHz for IEEE 802.11b/g. Fig. 5.16 shows a group delay response. Group delay has minimum of 48nsec and 59nsec maximum, so the group delay ripple is 11 nsec.
Fig. 5.17 illustrates the noise performance. To test the linearity of the filter, the input
1dB compression point and the third input intercept point (IIP3) were simulated and illustrated in Fig. 5.18 and in Fig. 5.19, respectively. For stability test, the step input was applied into the filter and its step response is shown in Fig. 5.20. One 3rd order
filter occupies 617 μm × 475 μm and consumes 2.77mA of current.
Parameter Result Unit Technology 0.5 μm Supply voltage 3 V Passband gain -0.016 dB -3dB bandwidth 0.5,10,11 MHz Group delay minimum 48 nsec Group delay maximum 59 nsec√ Noise at 1MHz 34.5 nV/ Hz Input compression point 15 dBm IIP3 19 dBm Current consumption 5.55 mA Area 617 × 950 μm × μm
Table 5.2: Performance of the fully differential sixth-order Sallen-Key low pass filter
65 Figure 5.15: AC response of the sixth-order Sallen-Key low pass filter
66 Figure 5.16: Group delay response of the sixth-order Sallen-Key low pass filter
67 Figure 5.17: Noise response of the sixth-order Sallen-Key low pass filter
68 Figure 5.18: Input 1dB compression point of the sixth-order Sallen-Key low pass filter
69 Figure 5.19: IIP3 of the sixth-order Sallen-Key low pass filter
70 Figure 5.20: Step response of the sixth-order Sallen-Key low pass filter
71 5.3.3 Measurement Results
A test chip containing the fully differential third-order Sallen-Key low-pass fil- ter with a buffer for measurement was fabricated and measured. Fig. 5.21 shows the schematic view of the submitted chip. The FBDDA was used here for the measure- ment buffer. Die size was 1.5 mm × 1.5 mm, and packaging was done with DIP40 (40 lead dual-inline package), a standard ceramic package by Kyocera available through
MOSIS [45]. The chip photo taken from the 0.310” cavity at the top of the package is shown in Fig. 5.24 and its magnified die photo is shown in Fig. 5.25. The chip was mea- sured on a standard breadboard. The measured frequency responses for 802.11a/b/g are shown in Fig. 5.22. The cut-off frequencies were 8MHZ for IEEE802.11a and
8.3MHz for 802.11b/g which was reduced by about 20 % due to process variations.
Fig. 5.23 shows the third order intermodulation distortion test. Two tones, 1MHz and 2MHz sinusoidal inputs, were applied to the filter and the third order harmonic was measured at 3MHz. The measured IM3 was about -42dBc.
72 C 2
R 3 R 1 R 2
R 3 R 1 R 2 V i
C 3 C 1 Vo
Vcm C Vo C 3 1
V i R 3 R 1 R 2
R 3 R 1 R 2
C 2
Figure 5.21: Fully differential third-order Sallen-Key low pass filter with a buffer for measurement
73 5
0
−5
−10
−15 [dB]
−20
−25
−30
−35 5 6 7 10 10 10 frequency [Hz]
Figure 5.22: Measured frequency response of the fully differential Sallen-Key low pass filter
74 0
−10
−20
−30
−40 [dB]
−50
−60
−70
−80 0.5 1 1.5 2 2.5 3 3.5 6 frequency [Hz] x 10
Figure 5.23: Measured intermodulation test of the fully differential Sallen-Key low pass filter
75 Figure 5.24: Die photo of the fully differential Sallen-Key low pass filter with a measurement buffer
76 Figure 5.25: Magnified die photo of the fully differential Sallen-Key low pass filter with a measurement buffer
77 g m g m C
g Vin m i LPF Vout
Figure 5.26: Static DC offset canceller
5.4 Static DC Offset Cancellation using DC Feedback Loop
In Chapter 4, two kinds of DC offsets were studied and cancellation methods for each kind were discussed. In this section, the design of a DC feedback loop as a static DC offset cancellation is presented. DC feedback loops [13][26][27] are capable of canceling static DC offset as well as slowly varying dynamic DC offset. A DC feedback loop is designed to have the output of the Sallen-Key low pass filter fed back into the input of the filter through a very narrow band feedback element, so the overall transfer function with the DC feedback loop has a high pass pole close to DC.
A Gm-C filter provides the narrow band feedback. By varying the value of C,wecan
control the high pass cut-off frequency.
5.4.1 DC Feedback Loop Design
Fig. 5.26 is the detailed block diagram of the DC feedback loop which is the static DC offset canceller implemented in this dissertation. The LPF represents the channel selection filter. Often, the output of the mixer is current-mode, so the
transconductance cell gmi is to produce the input current for the static DC offset
78 M12 VcmfbVb1 M5 Vcmfb M13
M10 Vb3 Vn M1 M2 Vp Vb3 M11
Von Vop
M8 Vb2 Vb2 M9
M6 M3 M4 M7
(a) Operational transconductance amplifier
M5c M6c
Vcmfb
VCMM1c M2c Von VCM M3c M4c Vop
Vbc1 M7c M8c
(b) Common-mode feedback circuit
Figure 5.27: Implementation of gm cell in the static DC offset canceller
79 Figure 5.28: Implementation of capacitance
canceller. Another transconductance cell gm included in the feedback path is also to convert the gm-C integrator output into the current so that the feedback current is subtracted from the input current. It is also possible to subtract the signal in the voltage mode if the mixer output is voltage, in which case the additional gm cells are not used. We implemented this DC feedback loop around a fully differential
3rd-order Sallen-Key low pass filter [50]. A fully differential transconductance cell gm used in the static DC offset canceller is shown in Fig. 5.27(a). To increase the
output resistance ro, a cascode configuration is employed to achieve the DC gain of
85dB and the -3dB frequency of 11Hz with 10pF. The common-mode feedback circuit
shown in Fig. 5.27(b) is used to control the common-mode output voltage. To reduce
the parasitic capacitance, the capacitors in the static DC offset canceller have been
implemented the way shown in Fig. 5.28.
5.4.2 Simulation Results
The static DC offset canceller was designed in a standard 0.5 μmCMOSpro- cess. The frequency response of the gm cell designed is illustrated in Fig. 5.30 which shows the DC gain of 85dB and the -3dB frequency of 11Hz with 10pF. The frequency response of the static DC offset canceller is illustrated in Fig. 5.30. The cut-off fre- quency of the Sallen-Key low pass filter was set to 10MHz, and the location of the high pass pole was made programmable. By varying the value of capacitance, we can
80 change the high pass cut-off frequency easily from 1KHz (with 14pF) to 10KHz (with
1pF) with the reasonable value of capacitance for monolithic integration.
5.4.3 Measurement Results
A test chip containing the static DC offset canceller with a fully differential third-order Sallen-Key low-pass filter and a buffer for measurement was fabricated and measured. Fig. 5.31 shows the schematic view of the submitted chip. The capacitor chain has the capacitance such as Cd1 =1pF,Cd1 = 3pF, and Cd1 = 10pF. The
FBDDA was used here for the measurement buffer. Die size was 1.5 mm × 1.5 mm, and packaging was done with DIP40 (40 lead dual-inline package), a standard ceramic package by Kyocera available through MOSIS [45]. The static DC offset canceller occupies 330 μm × 280 μm and gm cell occupies 112 μm × 80 μm. The chip photo taken from the 0.310” cavity at the top of the package is shown in Fig. 5.33 and its magnified die photo is shown in Fig. 5.34. The chip was measured on a standard breadboard. The measured frequency responses are shown in Fig. 5.32. The high pass cut-off frequencies were 6KHz and 8KHz.
81 Figure 5.29: Frequency response of the OTA
82 Figure 5.30: Frequency response of the static DC offset canceller
83 g g m C d1 C d2 C d3 m
C 2
R 3 R 1 R 2
R 3 R 1 R 2 gm V i i
C 3 C 1 Vo Vcm C Vo C 3 1
gm V i i R 3 R 1 R 2
R 3 R 1 R 2
C 2
Figure 5.31: Static DC offset canceller around the Sallen-Key low pass filter with measurement buffer
84 10
0
−10
−20 [dB]
−30
−40
−50 4 5 10 10 frequency [Hz]
Figure 5.32: Measured frequency response of the static DC offset canceller
85 Figure 5.33: Die photo of the static DC offset canceller
86 Figure 5.34: Magnified die photo of the static DC offset canceller with a buffer for measurement
87 5.5 Variable Gain Amplifiers
Variable gain amplifiers (VGA) or programmable gain amplifiers (PGA) are one of key blocks in analog baseband systems. The variation of the amplifier gain is necessary in wireless communication receivers because the received signal strength is changing according to the distance between a receiver and a transceiver as well as the wireless channel environment including interferences. The most common and simplest way of implementing a variable gain amplifier using a single amplifier is to employ an inverting amplifier configuration or non-inverting amplifier configuration [37]. As pointed out in Section 5.2, a non-inverting amplifier configuration cannot be converted into a fully differential version easily by the steps described in [38] because none of the op-amp inputs are grounded. One can still use two single-ended op-amps to build a fully differential non-inverting amplifier, which increases area, mismatch, and power consumption. A fully balanced differential difference amplifier (FBDDA) presented in Section 5.2 can ease the design of a fully differential non-inverting amplifier. Thus, a variable gain amplification can be readily designed using the FBDDA as shown in
Fig. 5.35. By varying the values of resistors, either R1 or R2, we can control the gain of the non-inverting amplifier. For the gain control to be programmable, the resistors need to be controlled by switches. It is easy to develop but the drawback is that the -3 dB bandwidth of the VGA is also varying, which is not desirable especially in broadband applications. Fig. 5.36 illustrates the problem of bandwidth reduction in high gain modes. Therefore, it is proposed in this dissertation to use attenuators, in which case the bandwidth is fixed in all gain control modes.
88 RR1 2 Vcm
V i
Vo
V i Vo
Vcm R 1 R 2
Figure 5.35: Fully differential variable gain amplifier using non-inverting amplifier
5.5.1 Fully Differential Variable Gain Amplifier Using At- tenuators
To have the bandwidth of the VGA unchanged according to the gain variation, we use attenuators in this implementation. The current-mode approach can also give us the constant bandwidth in higher gain modes, we explore the attenuators in this dissertation because it is also easy to realize gain steps below 0 dB. As described in
Chapter 3, the VGA should be designed to have both amplification and attenuation of the signals to be used for both the receive path and the transmit path, respectively.
Fig. 5.37 shows the fully differential VGA designed using attenuators and the FBDDA.
To have gains, a fully differential non-inverting amplifier consisting of FBDDA, R1
and R2 has been designed. In this design, attenuators consisting of MOS switches and poly resistors have been employed and differential inputs are applied through the attenuators as shown in Fig. 5.37. As we can see in the figure, the attenuator
89 Figure 5.36: Frequency response of the VGA using non-inverting amplifier
90 R 1 R 2 Vcm
V i Vcm
Vo
Vo
V i Vcm
Vcm R 1 R 2
Figure 5.37: Fully differential variable gain amplifier (VGA) using attenuators and FBDDA
is just a voltage divider consisting of resistors. To control the gain, we control the
MOS switches so that the input signals to the FBDDA could be attenuated according
to the gain setting from the digital signal processing block. At the maximum gain
setting, the input signals just go to the amplifier without any attenuation, in which
case the signal is amplified by the non-inverting amplifier gain determined by the
ratio of R1 and R2. Therefore, in this scheme, the -3 dB frequency does not change when the gain is varying. By cascading the VGA shown in Fig. 5.37, we can achieve the baseband chain with large gain range.
5.5.2 Simulation Results
The single stage of the fully differential VGA using attenuators as shown in
Fig. 5.37 was designed using the AMI 0.5 μm standard digital process and then the
91 R R 1 2 R 1 R 2 V cm Vcm V V i cm Vcm
V V i cm Vcm V cm Vcm R R 1 2 R 1 R 2
R 1 R 2 R 1 R 2 R 1 R 2 Vcm Vcm Vcm
Vcm Vcm Vcm
Vo
Vo
Vcm Vcm Vcm
Vcm Vcm Vcm R 1 R 2 R 1 R 2 R 1 R 2
Figure 5.38: Fully differential variable gain amplifier (VGA) chain using attenuators and FBDDAs
single stage is cascaded to implement a fully differential VGA having -16 dB to 38 dB
gain range with 6 dB gain step. Fig. 5.38 is the schematic view of the fully differential
VGA chain. The first three stages are the fully differential VGAs using attenuators and the following two non-inverting FBDDAs are to increase the gain for achieving the necessary gain range.
The single VGA stage was loaded with 2 pF capacitance at each output node and simulated using the BSIM3v3 models in Cadence environment. It was designed to have 7.8 dB of gain and 33.7 MHz of -3 dB bandwidth. The small gain was chosen for the single stage to have enough bandwidth. The resistance values used are such that R1 =1.7KΩandR2 = 2.5 KΩ. The single VGA stage consumes 2.77 mA of current and occupies 580 μm × 290 μm. The simulation results of the cascaded VGA chain shown in Fig. 5.38 in the typical corner are summarized in Table 5.3.
92 Parameters Result Unit Technology 0.5 μm Supply voltage 3 V Gain range (6dB step) -16 ∼ 38 dB -3dB bandwidth 10 MHz√ Noise at 10MHz 13 nV/ Hz Input compression point 12 dBm IIP3 23 dBm Current consumption 13.9 mA
Table 5.3: Performance of the fully differential variable gain amplifier
Fig. 5.39 is the frequency response showing the gain range of -16 dB to 38 dB with 6 dB gain step. We can see that the -3 dB frequency set to 10 MHz for the
IEEE 802.11a wireless LAN is the same for all gain settings. The spot noise in the √ highest gain mode (38 dB) at 6 MHz is 13 nV/ Hz and the noise plot is shown in √ Fig. 5.40. The spot noise at 6 MHz is 386 nV/ Hz with 2 dB gain setting. The 1 dB input compression point was 12 dBm as shown in Fig. 5.41 and the third order input intercept point was 23 dBm in Fig. 5.42. The step input was applied into the VGA chain at 2 dB gain setting and its step response is shown in Fig. 5.43.
5.5.3 Measurement Results
For a test chip, a fully differential VGA consisting of two single stage fully differential VGAs using attenuators and one non-inverting FBDDA was fabricated and measured. The FBDDA buffer was included for measurement at the end of the
VGA chain as shown in Fig. 5.44. The gain range of this VGA chain is -13 dB to
23 dB with 6dB gain step. The fully differential VGA occupies μm 850 × 580 μmand
the measurement buffer does μm 580 × 230 μm. Die size was 1.5 mm × 1.5 mm, and
93 Figure 5.39: AC response of the VGA
94 Figure 5.40: Noise response of the VGA
95 Figure 5.41: Input 1dB compression point of the VGA
96 Figure 5.42: IIP3 of the VGA
97 Figure 5.43: Step response of the VGA
98 R R 1 2 R 1 R 2 V cm Vcm V V i cm Vcm
V V i cm Vcm V cm Vcm R R 1 2 R 1 R 2
R 1 R 2 Vcm
Vo
Vo
Vcm R 1 R 2
Figure 5.44: Fully differential VGA using attenuators and FBDDAs with a measure- ment buffer
packaging was done with DIP40 (40 lead dual-inline package), a standard ceramic
package by Kyocera available through MOSIS [45]. The chip photo taken from the
0.310” cavity at the top of the package is shown in Fig. 5.24 and its magnified die
photo is shown in Fig. 5.25. The chip was simulated with 40 pF of capacitive load
before submission. The fabricated chip was measured on a standard breadboard.
Fig. 5.22 shows the measured frequency responses. Fig. 5.23 shows the third order intermodulation distortion test. Two tones, 1MHz and 2MHz sinusoidal inputs, were applied to the VGA and the third order harmonic was measured at 3MHz. The measured IM3 was about -43.2dBc.
99 30
20
10
0 gain [dB]
−10
−20
−30 5 6 7 10 10 10 frequency [Hz]
Figure 5.45: Measured frequency response of the fully differential variable gain am- plifier
100 0
−10
−20
−30
−40 [dB] −50
−60
−70
−80
−90 0.5 1 1.5 2 2.5 3 3.5 6 frequency [Hz] x 10
Figure 5.46: Measured intermodulation test of the fully differential variable gain amplifier
101 Figure 5.47: Die photo of the fully differential variable gain amplifier
102 Figure 5.48: Magnified die photo of the fully differential variable gain amplifier with a buffer for measurement
103 5.6 Summary
In this chapter, the design of a fully differential analog baseband chain was presented. A fully balanced differential difference amplifier (FBDDA) was designed as a core amplifier and used in the design of a fully differential Sallen Key channel selection low pass filter and a fully differential variable gain amplifier using the FB-
DDA and attenuators. For static DC offset cancellation, a DC feedback loop has been designed. The design was verified through simulation, fabrication, and measurement.
104 CHAPTER 6
CONCLUSION
6.1 Contribution of the Dissertation
In this dissertation, a novel compact wireless radio transceiver architecture for time-division duplexing (TDD) systems was proposed. The transceiver architecture shares a baseband chain for both the receive path and the transmit path to reduce a significant portion of the die area. The proposed compact wireless transceiver architecture can be used for any TDD wireless systems to achieve small die area as long as the system is designed to meet the required specifications.
The DC offset problem in direct conversion multistandard wireless receivers was studied. Three self-mixing mechanisms generating the DC offset in direct con- version receivers were modeled, and a DC offset cancellation architecture suitable for multistandard wireless direct conversion receivers was proposed. The proposed technique separates the dynamic DC offset cancellation from the static DC offset can- cellation to effectively cancel both the static and dynamic DC offsets. The static DC offset canceller was implemented in analog domain using a DC feedback loop and the dynamic DC offset canceller was designed in digital domain using an adaptive noise
105 canceller. Both the static and the dynamic DC offset cancellers have been verified through simulations which exhibit the promising results.
A fully differential Sallen-Key low-pass filter using FBDDA with DC offset compensation loop has been implemented. Fully differential VGAs using attenuators and FBDDA are also designed to have the gain range of -16 dB to 38 dB. The circuits have been designed using a standard 0.5 μm CMOS process, verified through simulations, fabrication, and measurement.
In conclusion, the contribution of the dissertation is summarized in the follow- ing.
1. A compact transceiver architecture which is suitable for time-division duplexing
systems is proposed and its design issues are studied.
2. The DC offset problem in the direct conversion receiver architecture has been
modeled, the static and dynamic DC offsets are identified, and their generation
mechanisms are illustrated through modeling.
3. The static and dynamic DC offset cancellation method for multistandard direct
conversion receivers is proposed.
4. The adaptive filtering technique has been applied for the dynamic DC offset
cancellation.
5. A DC feedback loop for static DC offset cancellation has been designed and
verified through fabrication on silicon and measurement.
6. A fully differential channel selection low pass filter and a fully differential vari-
able gain amplifier for a multistandard direct conversion receiver have been
106 designed by using a fully balanced differential difference amplifier and verified
through fabrication on silicon and measurement.
6.2 Future Work
Several avenues for future research have been identified. First, a specific wire- less communication standard will be applied for the proposed compact TDD wireless transceiver architecture in order for us to do a full link budget and system analysis, which will give us more insight and detailed specification on designing a single-chip transceiver. Second, the performance of the proposed dynamic DC offset cancellation scheme will be investigated with more complex modulations such as QPSK or OFDM.
Finally, a different operational transconductance amplifier may be explored for a DC feedback loop to improve settling behavior.
107 APPENDIX A
WIRELESS COMMUNICATION STANDARDS
In this appendix, we summarize a variety of wireless communication standards.
The standards for the third generation (3G) are in Table A.1 and those for IEEE
802.11a/b/g, Bluetooth, and Zigbee are shown in Table A.2 .
According to IEEE 802.11a standard [7], an OFDM modulated signal consists of 52 subcarriers (48 data + 4 pilots) and the subcarrier falling at DC is not used to avoid difficulties in analog-to-digital/digital-to-analog converters offsets and carrier feedthrough in the RF system. Since the subcarrier spacing is 312.5 KHz, the fre- quency range from 0 Hz through 156.25 KHz is not used. Each frame has a preamble composed of 10 repetitions of a short training sequence and two repetitions of a long training sequence [7]. A short training sequence is used for AGC convergence, di- versity selection, timing acquisition, and coarse frequency acquisition in the receiver while a long training sequence is used for channel estimation and fine frequency acqui- sition. The preamble duration is 16 μsec (8 μsec of short training sequence duration and 8 μsec of the long training sequence duration). An OFDM symbol duration is 4
μsec which is 0.8 μsec of the guard interval duration plus 3.2 μsec of the IFFT/FFT period.
108 Standard W-CDMA TD-CDMA CDMA2000 CDMA2000 (UTRA FDD) (UTRA TDD) 1XRTT 3XRTT (1X EV-DO/DV) Frequency UL:1.92–1.98 GHz 1.90–1.92 GHz 800, 900 MHz 800, 900 MHz Band DL:2.11–2.17 GHz 2.010–2.025 GHz 1.8, 1.9 GHz 1.8, 1.9 GHz Channel 5MHz 5MHz 5MHz 5MHz Spacing
109 Data Rate 2 Mbps 2 Mbps DO:2.4 Mbps 2 Mbps DV:4.8 Mbps Chip Rate 3.84 Mcps 3.84 Mcps 1.2288 Mcps 3.6864 Mcps Duplexing FDD TDD FDD FDD Spreading DSSS DSSS MC MC Modulation DL:QPSK QPSK DL:QPSK DL:QPSK UL:HPSK UL:HPSK UL:HPSK
Table A.1: 3G Standards Standard IEEE 802.11a [7] IEEE 802.11b [8][51] IEEE 802.11g [9] Bluetooth [10] IEEE 802.15.4 [52] (Zigbee) Frequency 5.15–5.25GHz 2.4–2.4835GHz 2.4–2.4835GHz 2.4–2.4835GHz 868–868.6MHz(EU) Band 5.25–5.35GHz 902–928MHz(USA) 5.725–5.825GHz 2400–2483.5MHz Channel 20MHz 25MHz 25MHz 1MHz 868–868.6:300KHz Bandwidth 902–928:600KHz 400–2483.5:2MHz Data Rate 6, 9, 12, 18, 24, 1, 2, 5.5, 11Mbps 1, 2, 5.5, 11, 1Mbps 868–868.6:20Kbps 36, 48, 54Mbps 6, 9, 12, 18, 24, 902–928:40Kbps 110 36, 48, 54Mbps 2400–2483.5:250Kbps Duplexing TDD TDD TDD TDD FDD Spreading OFDM DSSS DSSS, OFDM FHSS DSSS Modulation BPSK(6,9) DBPSK(1) DBPSK(1) GFSK BPSK(20,40) (Data Rate) QPSK(12,18) DQPSK(2) DQPSK(2) OQPSK(250) 16-QAM(24,36) CCK:DQPSK(5.5) CCK:DQPSK(5.5) 64-QAM(48,54) CCK:DQPSK,QPSK(11) CCK:DQPSK,QPSK(11) OFDM (6,9,12,18, 24,36,48,54)
Table A.2: Wireless LAN Standards In IEEE 802.11b [8][51] standard, two different preambles are defined: the mandatory supported long preamble and an optional short preamble. The long pream- ble duration is 144 μsec and the short preamble duration is 72 μsec.
111 APPENDIX B
MATLAB CODES
clear all; % to make clean close all;
%******************** Preparation part ********************** sr=1e6; % Symbol rate ml=1; % Number of modulation levels br=sr.*ml; % Bit rate (=symbol rate in BPSK) nd = 1000; % Number of symbols that simulates in each loop IPOINT=10; % Number of oversamples
%******************* Filter initialization ******************** irfn=21; % Number of filter taps alfs=0.5; % Rolloff factor [xh] = hrollfcoef(irfn,IPOINT,sr,alfs,1);%Transmitter filter coefficients [xh2] = hrollfcoef(irfn,IPOINT,sr,alfs,0);%Receiver filter coefficients
N_it = 10418;
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %%%%%%%%%%%%%% applying offset %%%%%%%%%%%%%%%%%% tu = 1/(sr*IPOINT); % min. time unit freq_s = sr*IPOINT; % sampling freq freq_in = 1e6; % input freq of applied sine
% for transient offset application %%%%%%%%%%%%%%%%%%% N_it1 = ceil(N_it/200); N_it2 = N_it - N_it1 - 1; ott = N_it2*tu; % total time for the sine ot = [0:1/freq_s:ott]; % Time vector of tt second o2 = 32*sin(2*pi*freq_in*ot);%Create a sine wave of freq_in for t seconds.
112 o1 = zeros(1, N_it1); % the period of no offset applied o = [o1,o2]; %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%******************** START CALCULATION ********************* nloop=200; % Number of simulation loops
N_f = 9 % adaptive filter length Delta = ceil(N_f/2); % delay for ebn0 = 0:2:10 noe = 0; % Number of error data nod = 0; % Number of transmitted data clear f; clear d; clear y; clear e; noe_afp = 0; % Number of error data nod_afp = 0; % Number of transmitted data noe_cor = 0; % Number of error data nod_cor = 0; % Number of transmitted data for iii=1:nloop
%******************** Data generation ********************************
data=rand(1,nd)>0.5; % rand: built in function
%******************** BPSK Modulation ***********************
data1=data.*2-1; [data2] = oversamp( data1, nd , IPOINT) ; data3 = conv(data2,xh); % conv: built in function
%****************** Attenuation Calculation *****************
spow=sum(data3.*data3)/nd; attn=0.5*spow*sr/br*10.^(-ebn0/10); attn=sqrt(attn);
%************ Add White Gaussian Noise (AWGN) ***************
113 inoise=randn(1,length(data3)).*attn; % randn: built in function data4=data3+inoise;
data5=conv(data4,xh2); % conv: built in function
sampl=irfn*IPOINT+1; data6 = data5(sampl:IPOINT:IPOINT*nd+sampl-1);
%******************** BPSK Demodulation *********************
demodata=data6 > 0;
%******************** Bit Error Rate (BER) ******************
noe2=sum(abs(data-demodata)); % sum: built in function nod2=length(data); % length: built in function noe=noe+noe2; nod=nod+nod2;
%======%******************** AFP ********************** %======s = data5; % after Rx filter e_D = zeros(N_f, 1); e_D(Delta + 1) = 1; E_D = toeplitz(zeros(N_f, 1), e_D); f(:, 1) = zeros(N_f, 1); % adap. filter initialization
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %%%%%%%%%%% AFP %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% mu = 0.001; for n = 1:N_it-(N_f-1), s_ = s(n:n+(N_f-1)).’; o_ = o(n:n+(N_f-1)).’; d_ = s_ + o_; d(n) = s(n) + o(n);
u_ = E_D*d_; y(n) = f(:, n)’*u_; e(n) = d(n) - y(n); mu_nlms = 1/(1/mu + u_’*u_); f(:, n+1) = f(:, n) + mu_nlms*u_*e(n)’; % NLMS end
114 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %************* BER for fixed signal ************** data5_afp=e; sampl = irfn*IPOINT+1; data6_afp = data5_afp(sampl:IPOINT:IPOINT*nd+sampl-1);
%******************** BPSK Demodulation ********************* demodata_afp = data6_afp > 0;
%******************** Bit Error Rate (BER) ****************** der_afp = data-demodata_afp; noe2_afp = sum(abs(der_afp)); % sum: built in function nod2_afp = length(data); % length: built in function noe_afp = noe_afp + noe2_afp; nod_afp = nod_afp + nod2_afp;
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %************* BER for corrupted signal ************** data5_cor = d; sampl = irfn*IPOINT+1; data6_cor = data5_cor(sampl:IPOINT:IPOINT*nd+sampl-1);
%******************** BPSK Demodulation ********************* demodata_cor = data6_cor > 0;
%******************** Bit Error Rate (BER) ****************** der_cor = data-demodata_cor; noe2_cor = sum(abs(der_cor)); % sum: built in function nod2_cor = length(data); % length: built in function noe_cor = noe_cor + noe2_cor; nod_cor = nod_cor + nod2_cor; end % for iii=1:nloop
%********************** Output result *************************** ber = noe/nod; fid = fopen(’BERbpsk.dat’,’a’); fprintf(fid,’%d\t%e\t%f\t%f\t\n’, ebn0, ber, noe, nod); fclose(fid);
%********************** Output result ***************************
115 ber_afp = noe_afp/nod_afp; fid = fopen(’BERafp_bpsk.dat’,’a’); fprintf(fid,’%d\t%d\t%d\t%e\t%f\t%f\t\n’, ebn0, N_f, Delta, ... ber_afp, noe_afp, nod_afp); fclose(fid);
%********************** Output result *************************** ber_cor = noe_cor/nod_cor; fid = fopen(’BERcor_bpsk.dat’,’a’); fprintf(fid,’%d\t%d\t%d\t%e\t%f\t%f\t\n’, ebn0, N_f, Delta, ... ber_cor, noe_cor, nod_cor); fclose(fid); end % for ebn0 %******************** end of file ***************************
116 BIBLIOGRAPHY
[1] R. Ahola, A. Aktas, J. Wilson, K. R. Rao, F. Jonsson, I. Hyyrylainen, A. Brolin, T.Hakala,A.Friman,T.Makiniemi,J.Hanze, M. Sanden, D. Wallner, Y. Guo, T. Lagerstam, L. Noguer, T. Knuuttila, P. Olofsson, and M. Ismail, “A single- chip CMOS transceiver for 802.11a/b/g wireless LANs,” IEEE Journal of Solid- State Circuits, vol. 39, no. 12, pp. 2250–2258, Dec. 2004. [2] I. Vassiliou, K. Vavelidis, T. Georgantas, S. Plevridis, N. Haralabidis, G. Kamoulakos, C. Kapnistis, S. Kavadias, Y. Kokolakis, P. Merakos, J. C. Rudell, A. Yamanaka, S. Bouras, and I. Bouras, “A single-chip digitally cali- brated 5.15-5.825-GHz 0.18-μm CMOS transceiver for 802.11a wireless LAN,” IEEE Journal of Solid-State Circuits, vol. 38, no. 12, pp. 2221–2231, Dec. 2003.
[3] A. Mashhour, W. Domino, and N. Beamish, “On the direct conversion receiver - a tutorial,” Microwave Journal, pp. 114–128, June 2001.
[4] B. Razavi, RF Microelectronics. Upper Saddle River, NJ: Prentice Hall PTR, 1998.
[5] A. Loke and F. Ali, “Direct conversion radio for digital mobile phones–design issues, status, and trends,” IEEE Transactions on Microwave Theory and Tech- niques, vol. 50, no. 11, pp. 2422–2435, Nov. 2002. [6] H. Elwan, H. Alzaher, and M. Ismail, “A new generation of global wireless com- patibility,” IEEE Circuits and Devices Magazine, pp. 7–19, Jan. 2001. [7] Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications: High-speed Physical Layer in the 5 GHz Band, IEEE Std. 802.11a, 2000. [8] Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications - Higher-Speed Physical Layer Extension in the 2.4 GHz Band, IEEE Std. 802.11b, 2000. [9] Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications Amendment 4: Further Higher Data Rate Extension in the 2.4 GHz Band, IEEE Std. 802.11g, 2003.
117 [10] Bluetooth Specification Version 1.2, Std., 2003. [Online]. Available: http://www.bluetooth.com
[11] A. A. Abidi, “Direct-conversion radio transceivers for digital communications,” IEEE Journal of Solid-State Circuits, vol. 30, no. 12, pp. 1399–1410, Dec. 1995.
[12] B. Razavi, “Design considerations for direct-conversion receivers,” IEEE Trans- actions on Circuits and Systems—Part II: Analog and Digital Signal Processing, vol. 44, no. 6, pp. 428–435, June 1997.
[13] C. D. Hull, J. L. Tham, and R. R. Chu, “A direct-conversion receiver for 900 MHz (ISM band) spread-spectrum digital cordless telephone,” IEEE Journal of Solid-State Circuits, vol. 31, no. 12, pp. 1955–1963, Dec. 1996.
[14] P. Stroet, R. Mohindra, S. Hahn, A. Schuur, and E. Riou, “A zero-IF single-chip transceiver for up to 22 Mb/s QPSK 802.11b wireless LAN,” in IEEE Inter- national Solid-State Circuits Conference Digest of Technical Papers, 2001, pp. 152–154.
[15] R. Magoon, A. Molnar, J. Zachan, G. Hatcher, and W. Rhee, “A single- chip quad-band (850/900/1800/1900 MHz) direct conversion GSM/GPRS RF transceiver with integrated VCOs and fractional-N synthesizer,” IEEE Journal of Solid-State Circuits, vol. 37, no. 12, pp. 1710–1720, Dec. 2002.
[16] A. Behzad, Z. Shi, S. Anand, L. Lin, K. Carter, M. Kappes, T. Lin, T. Nguyen, D. Yuan, S. Wu, Y. Wong, V. Fong, and A. Rofougaran, “A 5-GHz direct- conversion CMOS transceiver utilizing automatic frequency control for the IEEE 802.11a wireless LAN standard,” IEEE Journal of Solid-State Circuits, vol. 38, no. 12, pp. 2209–2220, Dec. 2003.
[17] B. Lindquist, M. Isberg, and P. Dent, “A new approach to eliminate the DC offset in a TDMA direct conversion receiver,” in Proc. IEEE Vehicular Technology Conference, May 1993, pp. 754–757.
[18] S. Sampei and K. Feher, “Adaptive DC-offset compensation algorithm for burst mode operated direct conversion receivers,” in Proc. IEEE Vehicular Technology Conference, May 1992, pp. 93–96.
[19] H. Yoshida, H. Tsurumi, and Y. Suzuki, “DC offset canceller in a direct- conversion receiver for QPSK signal reception,” in Proc. IEEE International Symposium on Personal, Indoor and Mobile Radio Communications, Sept. 1998, pp. 1314–1318.
[20] A. Parssinen, Direct Conversion Receivers in Wide-Band Systems.Boston,MA: Kluwer Academic Publishers, 2001.
118 [21] M. Faulkner, “DC offset and IM2 removal in direct conversion receivers,” IEE Proceedings - Communications, vol. 149, no. 3, pp. 179–184, June 2002.
[22] K. Kivekas, A. Parssinen, and K. Halonen, ““Characterization of IIP2 and DC- offsets in transconductance mixers”,” IEEE Transactions on Circuits and Sys- tems II: Analog and Digital Signal Processing, vol. 48, no. 11, pp. 1028–1038, November 2001.
[23] D. Manstretta, M. Massino, and F. Svelto, ““Second-order intermodulation mechanisms in CMOS downconverters”,” IEEE Journal of Solid-State Circuits, vol. 38, no. 3, pp. 394–406, March 2003.
[24] E. A. Lee and D. G. Messerschmitt, Digital Communication, 2nd ed. Boston, MA: Kluwer Academic Publishers, 1994.
[25] W. C. Jakes, Microwave Mobile Communications. New York: Wiley, 1974.
[26] R. Harjani, J. Kim, and J. Harvey, “DC-coupled IF stage design for a 900-MHz ISM receiver,” IEEE Journal of Solid-State Circuits, vol. 38, no. 1, pp. 126–134, Jan. 2003.
[27] Y.-J. Jung, H. Jeong, E. Song, J. Lee, S.-W. Lee, D. Seo, I. Song, S. Jung, J. Park, D.-K. Jeong, S.-I. Chae, and W. Kim, “A 2.4-GHz 0.25-μm CMOS dual- mode direct-conversion transceiver for Bluetooth and 802.11b,” IEEE Journal of Solid-State Circuits, vol. 39, no. 7, pp. 1185–1190, July 2004.
[28] S. Haykin, Adaptive Filter Theory, 4th ed. Upper Saddle River, NJ: Prentice Hall, 2002.
[29] B. Widrow, J. Glover, J. McCool, J. Kaunitz, C. Williams, R. Hearn, J. Zeidler, E. Dong, and R. Goodlin, “Adaptive noise cancelling: principles and applica- tions,” Proceedings of the IEEE, vol. 63, no. 12, pp. 1692–1716, Dec. 1975.
[30] J. Zeidler, “Performance analysis of LMS adaptive prediction filters,” Proceedings of the IEEE, vol. 78, no. 12, pp. 1781–1806, Dec. 1990.
[31] H. Harada and R. Prasad, Simulation and Software Radio for Mobile Commu- nications. Boston, MA: Artech House, 2002.
[32] Y. Yoganandam, V. U. Reddy, and T. Kailath, “Performance analysis of the adaptive line enhancer for sinusoidal signals in broad-band noise,” IEEE Electron Device Letters, vol. 36, no. 11, pp. 1749–1757, Nov. 1988.
[33] E. Sackinger and W. Guggenbuhl, “A versatile building block: the CMOS differ- ential difference amplifier,” IEEE Journal of Solid-State Circuits, vol. 22, no. 2, pp. 287–294, Apr. 1987.
119 [34] S. R. Zarabadi, F. Larsen, and M. Ismail, “A reconfigurable Op-Amp/DDA CMOS amplifier architecture,” IEEE Transactions on Circuits and Systems— Part I: Fundamental Theory and Applications, vol. 39, no. 6, pp. 484–487, June 1992.
[35] S.-C. Huang, M. Ismail, and S. R. Zarabadi, “A wide range differential differ- ence amplifier: a basic block for analog signal processing in MOS technology,” IEEE Transactions on Circuits and Systems—Part II: Analog and Digital Signal Processing, vol. 40, no. 5, pp. 289–301, May 1993.
[36] J. F. Duque-Canillo, G. Torelli, R. Perez-Aloe, J. M. Valverde, and F. Maloberti, “Fully differential basic building blocks based on fully differential difference am- plifiers with unity-gain difference feedback,” IEEE Transactions on Circuits and Systems—Part I: Fundamental Theory and Applications, vol. 42, no. 3, pp. 190– 192, Mar. 1995.
[37] H. Alzaher and M. Ismail, “A CMOS fully balanced differential difference am- plifier and its applications,” IEEE Transactions on Circuits and Systems—Part II: Analog and Digital Signal Processing, vol. 48, no. 6, pp. 614–620, June 2001.
[38] R. Schaumann and M. E. V. Valkenburg, Design of Analog Filters.NewYork: Oxford University Press, 2001.
[39] D. A. Johns and K. Martin, Analog Integrated Circuit Desgin.NewYork:John Wiley & Suns, 1997.
[40] P. E. Allen and D. R. Holberg, CMOS Analog Circuit Design, 2nd ed. New York: Oxford University Press, 2002.
[41] R. Gregorian, Introduction to CMOS OP-AMPs and Comparators.NewYork: John Wiley & Sons, Inc., 1999.
[42] B. Razavi, Design of Analog CMOS Integrated Circuits. New York: McGraw Hill, 2001.
[43]P.R.Gray,P.J.Hurst,S.H.Lewis,andR.G.Meyer,Analysis and Design of Analog Integrated Circuits, 4th ed. New York: John Wiley & Sons, Inc., 2001.
[44] S.-J. Yoo and M. Ismail, “A highly linear CMOS baseband chain for wideband wireless applications,” ETRI Journal, vol. 26, no. 5, pp. 486–492, Oct. 2004.
[45] The MOSIS service. [Online]. Available: http://www.mosis.org/
[46] R. P. Sallen and E. L. Key, “A practical method of designing RC active filters,” IRE Transactions on Circuit Theory, pp. 74–85, Mar. 1955.
120 [47] P. Horowitz and W. Hill, The Art of Electronics, 2nd ed. Cambridge, United Kingdom: Cambridge University Press, 1989.
[48] J. K. Roberge, Operational Amplifiers: Theory and Practice.NewYork:John Wiley & Sons, 1975.
[49] B. Razavi, “A 2.4-GHz CMOS receiver for IEEE 802.11 wireless LAN’s,” IEEE Journal of Solid-State Circuits, vol. 34, no. 10, pp. 1382–1385, Oct. 1999.
[50] S.-B. Park and M. Ismail, “A reconfigurable CMOS analog baseband for compact TDD wireless radio transceivers,” in Proc. IEEE International Midwest Sympo- sium on Circuits and Systems, Aug. 2005, pp. 1386–1389.
[51] Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications - Amendment 2: Higher-speed Physical Layer (PHY) ex- tension in the 2.4 GHz band - Corrigendum 1, IEEE Std. 802.11b, Rev. Cor 1-2001, 2001.
[52] Part 15.4: Wireless Medium Access Control (MAC) and Physical Layer (PHY) Specifications for Low-Rate Wireless Personal Area Networks (LR-WPANs), IEEE Std. 802.15.4, 2003.
121
