Through a window, brightly: A review of selected nanofabricated thin film platforms for spectroscopy, imaging, and detection Jason R. Dwyer and Maher Harb Corresponding authors: Jason R. Dwyer, ORCID 0000-0002- 2938-2888, 140 Flagg Road, Department of Chemistry, University of Rhode Island, Kingston, RI, 02881; Maher Harb, ORCID 0000-0002- 6853-9454, Departments of Physics and Materials Science & Engineering, Drexel University, Philadelphia, PA, 19104. Abstract We present a review of the use of selected nanofabricated thin films to deliver a host of capabilities and insights spanning bioanalytical and biophysical chemistry, materials science, and fundamental molecular-level research. We discuss approaches where thin films have been vital, enabling experimental studies using a variety of optical spectroscopies across the visible and infrared spectral range; electron microscopies and related techniques such as electron energy loss spectroscopy; x-ray photoelectron spectroscopy; and single-molecule sensing. We will anchor this broad discussion by highlighting two particularly exciting exemplars: a thin-walled nanofluidic sample cell concept that has advanced the discovery horizons of ultrafast spectroscopy, and of electron microscopy investigations of in-liquid samples; and a unique class of thin-film-based nanofluidic devices, designed around a nanopore, with expansive prospects for single-molecule sensing. Free-standing, low-stress silicon nitride membranes are a canonical structural element for these applications, and we will elucidate the fabrication and resulting features—including mechanical stability, optical properties, x-ray and electron scattering properties, and chemical nature—of this material in this format. We also outline design and performance principles, and include a discussion of underlying material preparations and properties suitable for understanding the use of alternative thin-film materials such as graphene. Keywords: thin film, silicon nitride, graphene, in situ, silicon nitride windows, liquid electron microscopy, liquid cell transmission electron microscopy, nanopore, carbon nanomembrane, nanofluidics, environmental cell. Introduction

A sample support or window should contribute to a measurement only in the desired manner. An ideal cuvette, for example, would define the path length but not affect the optical transmission. In spectroscopic applications, the usual approach is to minimize material absorption by choice of window material.1 In a charged-particle technique such as transmission electron microscopy (TEM), however, the strong interaction between the interrogating beam and matter places stringent limits on the material composition and thickness of any sample support through which the beam must pass. Sample-dependent solutions for TEM have included supports with open-areas to leave samples unobscured (but unsupported over that opening), and thin carbon and polymer films that minimize signal loss by reducing support thicknesses. There is considerable “art” in the fabrication of many support films:2, 3 the adoption of nanofabricated thin films has expanded the library of materials and structures to include thin film silicon nitride, graphene, and nanostructured variants such as porous silicon, among others.4-15 Both composition and thickness can be tuned in concert to obtain optimal performance. More broadly, new performance capabilities can be engineered (or discovered) when the thin-film sample support or window itself becomes a focus of investigation. Silicon nitride thin-films offer superb mechanical properties—a <100 nm-thick window can withstand over an atmosphere of cross-film pressure differential, for example16—and this can be exploited to create sample supports and containers that overcome severe challenges such as nonlinear window responses on short timescales in ultrafast spectroscopy.17-19 Thin films with suitable properties and structures can also be used in a more active role in experimental studies: a ~10 nm-diameter channel through a <100 nm-thick thin film—a so-called nanopore—is the basis for a wide range of single-molecule sensing and manipulation methods that emerge from the passage of a molecule into, or through, the nanofluidic channel.20-29 Figure 1 offers two illustrations to illuminate the rich scope of experimental configurations and possibilities using just these two platforms. We will frame our discussion of the interplay between thin film design—composition and structure—and application by using these two quite different implementations: a sample cell with thin-film windows bracketing a nanofluidic channel, and a nanopore single-molecule sensor platform where the robust thin film supports a nanofluidic through-channel. Figure 2a shows the common structural foundation of the two nanofluidic devices: a free-standing thin silicon nitride film supported by a silicon frame.16 We will use this canonical construct and material to discuss key design and operating considerations, highlight experimental accomplishments, challenges and opportunities, and touch on alternative materials and architectures.

Figure 1: (a) A <100 nm-thick layer of liquid between two thin windows can be interrogated with a range of optical and particle probes, in isolation and combination, yielding molecular-level insights over a range of time and length scales. (b) A ~10 nm- diameter central nanochannel can be used to (electrophoretically) detect and entrain single molecules for interrogation by a variety of methods such as electron tunneling (e.g. using transverse electrodes proximal to the pore), and single-molecule fluorescence. Molecular coatings (wavy lines at upper right) can tune the performance of nanopores (and other nanofluidic devices) through judiciously chosen terminal functional groups (red curve). Bacteriochlorophyll molecule from reference 30; scaling is not intended to be rigorously representative.

Figure 2: (a) The basic <100 nm-thick silicon nitride membrane, free-standing over an open aperture in silicon can serve as (b) the windows of a nanofluidic cell with additional features such as a wetting layer (green) added through conventional nanofabrication approaches, or (c) be used as a single-molecule sensor element after formation of a nanochannel through the membrane.

Perhaps the most captivating feature of silicon nitride is its ability to withstand being suspended unsupported, with a film thickness of <100 nm, over millimeter-wide open apertures. A robust, free-standing thin film such as this is a compelling structural component—one that can be further patterned—for use in a host of applications. The freedom from supports is in marked contrast to the usual need for thin carbon film substrates for TEM, for example, to be supported. The success of this unusual configuration hinges on carefully controlling the film stress through the film stoichiometry during fabrication (see below).16, 31 Early examples of applications include their use as vacuum chamber windows, to create a wet cell for x-ray microscopy, to protect the source for scanning transmission ion microscopy studies (STIM) in air, to create a sample cell for scanning electron microscopy (SEM) at atmospheric pressure, and to serve as sample substrates for studies using ultrafast spectroscopy, optical microscopy, TEM, and atomic force microscopy (AFM)—and for studies using such techniques in tandem.6-8, 16, 31-35 The films have the demonstrated ability to withstand even atmospheric pressure differentials.16 The impressive mechanical properties of these films have resulted in their increasing use in an ever-wider range of applications that can be further enhanced by additional beneficial properties of the films, such as their transparency to a host of probes across a wide range of wavelength regions–and encompassing electrons. The use of silicon nitride windows in creating sample cells and chambers has become increasingly prevalent, as has their use as sample supports; their use as a platform to host structural elements such as nanofluidic channels is a relatively new area of application and investigation.16-29, 36-58 Two particularly compelling uses of thin-film windows are shown in Figures 1 and 2. The windowed nanofluidic sample cell concept has been used for femtosecond mid-infrared studies of water and for transmission electron microscopy studies on liquid samples.17 Alternative configurations exist, including fully-sealed sample chambers cut off from liquid control (see also Figure 9).38, 40 Such a nanofluidic cell has, for reasons outlined in the article below, been able to deliver molecular-level insights on the fastest timescales and nanometer-length scales relevant for creating molecular movies. The nanopore platform has found principal use in genomics,59 but with increasing use to profile proteins and intermolecular interactions.21-29 Extension of this single-pore design to many pores allows the same thin-film platform to function as a high-throughput filter, with implications also for nanoplasmonics.60, 61 There are excellent reviews focusing on these two particular implementations, alone,21-29, 38, 40 and a recent book chapter reviewing both in a unifying context of nanofluidics:20 we hope the present review will encourage an appreciation of the breadth of application of even an ostensibly prosaic free-standing thin-film structure across a host of spectroscopy, microscopy, and sensing techniques. Thin-Film Silicon Nitride Membranes

Our references to “silicon nitride” in the context of free-standing silicon nitride thin films are to silicon-rich silicon nitride, SiNx (or, more restrictively SixN4 with x>3; Si3N4 is stoichiometric 20 silicon nitride), prepared by low-pressure chemical vapor deposition (LPCVD). LPCVD SiNx is an excellent micro- and nanofabrication material, used widely for surface passivation including as a barrier to electrons, ions, water, and oxygen in microelectronic and microsystem devices, and as 62-65 an etch stop in some fabrication processes. The basic fabrication processes for SiNx thin films are well-established, and can be easily found in standard texts of micro- and nanofabrication, 62 underscoring the prevalent use of this material. Dichlorosilane (SiH2Cl2) and ammonia (NH3) source gases are mixed in reduced-pressure furnaces at <1000°C and deposited, in our applications, onto polished Si (100) wafers.62, 66 The film stoichiometry—and consequently its residual stress— is controlled by tuning the two source gas feeds.62 Enriching the relative amount of silicon in fabricating the non-stoichiometric (silicon-rich), amorphous films controls the residual stress and is responsible for what is, to us, the most dramatic property of SiNx films: their ability to withstand large cross-membrane pressure differences.16, 67 Indeed, vendors may use and report only the film’s residual stress, rather than its stoichiometry.16, 67 The silicon-rich nature of the surface has additional consequences for surface chemical modification (see below).20 The creation of a free-standing membrane of thin SiNx follows a conventional route combining photolithography and etching.16, 20 The detailed fabrication process is depicted in Figure 3. LPCVD SiNx films are formed on both sides of a doubly polished Si (100) wafer. Standard photolithography and reactive ion etching (RIE) are used to create the window feature in one of the SiNx layers (thereby exposing the Si). The exposed Si is anisotropically etched with ~40% by ° weight aqueous potassium hydroxide (KOH) at 80 C, for which the intact SiNx on the other face serves as an etch stop.65 The unsupported area of the film is smaller than the opening in the patterned side of the wafer owing to the 54.7o etch profile arising from preferential etching of the Si planes. Openings from micrometers to millimeters can be made,16, 17 and the remaining Si frame can be used for support and manipulation. It is standard to design patterns that accommodate multiple frames on a single Si wafer, and to fabricate snap lines that extend ~1/3 of the depth of the wafer for easy separation of the individual frames. Though KOH etching of Si (100) with a SiNx mask is by far the most standard approach used to fabricate freestanding structures, unconventional geometrical etch profiles can be created by employing Si wafers with alternative crystallographic orientations and surface miscuts, and by use of different etch stops and etching 68 solutions. Moreover, SiNx thin films can be completely removed from their underlying substrates by following a modified fabrication procedure, although that requires the films to be porous.69

Figure 3. (Top panel) Fabrication steps for freestanding SiNx windows: (a) SiNx is deposited on both sides of a double-side polished (100)-oriented Si wafer by LPCVD (b) Photoresist is sequentially coated onto both sides of the wafer. While photoresist is only needed on one side for photolithography, the photoresist on the back (membrane) side serves as a protective layer against etching of the SiNx in step d. (c) The window feature is created in the photoresist layer via standard photolithography (UV exposure and development). (d) Reactive ion etching (RIE) is used to transfer the window feature into the SiNx layer. Note that RIE is isotropic; the vertical profile of the exposed area as shown in the figure does not accurately depict the actual isotropic etch profile, but because the depth of the etched region is much smaller than the lateral dimension of the exposed area, this effect can be ignored. (e) Photoresist is stripped from both sides using a suitable chemical bath. (f) KOH is used to etch through the wafer and create the free-standing SiNx structure. KOH stops at the SiNx layer. KOH is anisotropic, with etch rates of the (100) and (110) planes much larger than the (111) planes. Thus, the etch front progresses along the (111) planes of the crystal, resulting in the narrowing of the window dimension relative to the dimension of the mask feature by a factor of the thickness of the wafer multiplied by √2. To speed up the onset of the KOH process, it is recommended to dip the patterned wafer into a buffered oxide etch solution (BOE) prior to the KOH etch step. BOE removes the native oxide layer that forms naturally on the exposed Si. (Bottom panel) Top-down views of the fabricated membrane and supporting frame. The view from the membrane side shows only the window. The view from the patterned side shows the etch pit whose angles are determined by the silicon crystal planes. There are various subtleties and practical know-hows to the fabrication process that are beyond the scope of this article. We mention, however, a couple of important ones–both related to the KOH etching process. The fabrication procedure described above assumes that SiNx is a perfect KOH etch stop. Yet, the selectivity of KOH etching for LPCVD SiNx versus Si, though extremely high, is not infinite. While the KOH etch rate of SiNx is not well studied, some sources report selectivity values that range from 1:10,000 to 1:50,000.70, 71 The upper limit on the corresponding KOH etch rate of SiNx is 0.1 nm/min. Such an etch rate is not negligible when fabricating ultrathin windows (<10 nm) and should be taken into account when deciding on the thickness of the LPCVD deposited SiNx layers. The other point relates to the use of doped Si wafers. For certain applications, it is desired to use highly doped Si in order to electrically ground the supporting frame. For instance, this is useful when employing the window as support structure in electron microscopy, in which the structure is continuously exposed to a high flux beam of electrons. However, using boron doped silicon can significantly retard the KOH etch rate, and, above a certain doping threshold, boron-doped Si can serve as an effective KOH etch stop.72 Therefore, it is recommend to use n-type doped Si (e.g. phosphorus-doped) for applications where high electrical conductivity is desired, without severely impacting the KOH etch rate.

Mechanical Properties of Free-Standing SiNx LPCVD SiNx deposited on Si possesses an amount of residual stress from two sources: intrinsic stress due to the deposition conditions and thermal stress due to the mismatch in the coefficients of thermal expansion between film and substrate.73 Even though stoichiometric silicon nitride has a slightly lower coefficient of thermal expansion than silicon, resulting in compressive residual stress, the residual stress in LPCVD SiNx tends to be tensile in nature (i.e. the deposited film is elongated relative to a stress-free film).74 The deposition parameters (temperature, pressure, and gas flow rate) offer a certain degree of control over the amount of residual stress. Moreover, nonstandard deposition techniques can be employed to control the residual stress within a wide range of values. For example, Shi et al. demonstrated using ion implantation to tailor the residual 75 stress of SiNx over a range of values extending from 1.2 GPa (tensile) to -0.1 GPa (compressive). In Micro-Electro-Mechanical Systems (MEMS)-type devices, however, low residual stress films are highly desirable. While there are reports in literature on fabricating stress-free films,76 the standard processes that are commonly accessible in nanofabrication facilities produce films with tensile stress as low as ~200 MPa. For SiNx windows used as support structures, a mechanical property of interest is the amount of bulging (also referred to as buckling or bowing) due to differential pressure (e.g. pressure applied from one side of the membrane normal to the membrane surface). For example, in nanofluidic devices such as the one shown in Figure2b, two SiNx windows and a spacer are used to define a sample path length.77 In such an application, the effective increase in the path length due to bulging of the membranes could severely compromise the functionality of the device. Thus, it is essential both to characterize bulging and to understand which design features can be used to keep bulging to a minimal acceptable level. A schematic of the bulging geometry for a square membrane is shown in Figure 4. Characterization of the bulging profile is typically done with load-deflection measurements.74, 78- 84 In these measurements, pressure is applied to one side of the membrane and deflection is measured optically under a microscope—calibrated to measure depth through changes in the focal plane. For a square membrane, the load-deflection behavior is found to follow the relationship 4 3 2 (퐸푡⁄푎 )푑 + (1.66푡σo⁄푎 )푑 = 0.547푝, (1) where d is the maximum membrane deflection, t is the membrane thickness, 2a is the side of the square membrane, E is Young’s modulus, σo is the residual stress, and p is the external differential pressure.85 The equation above can be also used to model deflection of a rectangular membrane, with 2a representing the smaller lateral dimension of the rectangle. Figure 4 also shows the results of calculations of the maximum membrane deflection, d, as function of differential pressure. The calculation assumes a SiNx membrane with residual tensile stress of 200 MPa and a Young’s modulus of 300 GPa.86, 87 In these calculations of the maximum deflection under differential pressure, it was assumed that the membrane is able to withstand the pressure up to the maximum amount displayed in the plots. In reality, the membrane may fracture at some point as the pressure is increased. The fracture toughness of a membrane is an important materials property that defines the resistance of a membrane to fracture. It is directly related to the lateral stress at which a membrane that contains a crack fails. This property of the membrane is measured using the same load-deflection experiments used to characterize the bulging profile. Previous measurements found the fracture toughness to be in the 6-7 MPa m1/2 range independent of the membrane thickness.81, 88 The fracture toughness (퐾Ic) and failure differential pressure (푝failure) are related by 2 퐾Ic = (푎 푝failure⁄2푑푡)√π푐, (2) where 2c is the length of the pre-existing crack line.81 Thus, to calculate the failure pressure, an assumption must be made about the length of the crack. Figure 4 shows the fracture points for a crack of 10 μm length. As Eq. 2 shows, the failure pressure has an inverse square dependence on membrane dimension and linear dependence on membrane thickness. Thus, it is advantageous from the standpoint of avoiding fracture to use thicker membranes with smaller lateral dimensions. Nevertheless, the calculations above also demonstrate the extraordinary toughness of the SiNx free- standing structure: a 100×100 μm2 membrane that is 10 nm thick is able to withstand differential pressures up to an impressive ~0.5 atmospheres.

Figure 4. (Top panel) Cross-sectional view depicting bulging of a square-shaped silicon nitride membrane of side 2a and thickness t, due to net differential pressure p. The parameter of interest is the maximum deflection d at the center of the membrane. Maximum deflection of a 100 μm square membrane (center panel) and a 1 mm square membrane (bottom panel) as function of differential pressure up to ~1 atmosphere and for different membrane thicknesses (10, 100, and 1000 nm). The cross marks represent fracture points calculated according to the model in Eq. 2. The fracture model assumes that the membrane has a pre-existing crack line that is 10 μm in length. Absence of a fracture point indicates that the membrane is able to withstand the pressure at least up to the top end of the calculated range.

The calculations above give an impression of the sensitivity of the expected amount of deflection and fracture point to window thickness, window dimension, and applied pressure. For devices that use irregular window shapes or where it is desired to map out the exact profile of the membrane deformation, elaborate models of the deformation were developed and tested by Yang and co-workers.82 Lastly, measurements specific to bulging of nanofluidic cells under liquid flow conditions were carried out in situ using a scanning transmission electron microscope (STEM).89 Beyond the design and handling considerations imposed by these calculations and measurements, one should be cautious in using ultrasonication as part of a cleaning process, since it can easily rupture the membranes.46, 90

Optical Properties of Free-Standing SiNx Together with the mechanical stability and ease of fabrication, transparency of SiNx windows is one of the key features that makes them appealing for use as sample support structures in various spectroscopic applications. In applications where light (in the IR, visible, and UV range of the spectrum) interacts with SiNx windows, it is important from the viewpoint of experimental design to understand losses due to reflection at interfaces and due to absorption within the window material. In addition to informing design of the experiment, knowledge of the optical properties of the window is key to performing proper data analysis (e.g. in terms of determining the deposited energy within the sample volume in pump-probe experiments). Measurements of the frequency dependent dielectric function of silicon nitride in the 1-24 eV range were previously performed by 91 H. R. Philipp. The dielectric function ϵ = ϵ1 + 푖ϵ2 is related to the complex index of refraction according to 2 (푛 + 푖κ) = ϵ1 + 푖ϵ2, (3) where n is the real part of the refractive index and κ is the extinction coefficient. A summary of the measurements of the dielectric function is shown in Figure 5. The left panel suggests that there is no significant absorption below a photon energy of ~5 eV (corresponding to a wavelength of ~250 nm). The observed absorption threshold is consistent with silicon nitride being an insulator with a bandgap of around 5.3 eV.92 The right panel shows the refractive index for a range of wavelengths spanning the spectrum of interest in optical spectroscopy. Notice that there is little change in the refractive index from ~2 in the 750-2500 nm wavelength region.

Figure 5. (Left panel) Experimentally determined complex dielectric function of silicon nitride in the 1-25 eV range (reproduced from measurements by H. R. Philipp).91 (Right panel) The real part of the refractive index as extracted from the dielectric constant. The y- axis scale on the right side shows the reflectance of SiNx at normal incidence.

Reflectance of p- and s-polarized light at an air-material interface are calculated from the refractive index according to Fresnel’s equations: 2 2 −푛2 cos θ+√푛2−sin2θ cos θ−√푛2−sin2θ 푅 = | | and 푅 = | | . (4) p 푛2 cos θ+√푛2−sin2θ s cos θ+√푛2−sin2θ In the above, n is the index of refraction and θ is the angle of incidence. At normal incidence, both expressions collapse to

푛−1 2 푅 = 푅 = ( ) . (5) p s 푛+1 Figure 5 shows that the reflectance at normal incidence can be up to 20% for frequency ranges below the absorption threshold. There are several strategies for reducing the reflectance to near zero. If the experiment does not constrain the angle of incidence and light polarization, reflections can be mitigated by tuning these parameters: the most straightforward approach would be to use p-polarized light at Brewster’s angle (~63° for SiNx) to totally suppress reflection. Other strategies take advantage of multiple beam interference effects—as in a Fabry-Perot etalon—to suppress reflection for a narrow range of frequencies and angles of incidence. Under this scheme, the thickness of the window itself could be a key parameter to control in suppressing reflections, thereby improving signal quality. The theory of multiple beam interference is well developed and can be found in introductory optics text books.93 To demonstrate the benefits of tailoring the window thickness according to the application of interest, consider an air-SiNx-water interface. At normal incidence, the reflectivity of the structure varies between

2 2 2 1−푛2 푛2−푛1 푅min = ( ) and 푅max = ( 2) , (6) 1+푛2 푛2+푛1 93 where n1 and n2 are the respective indices of refraction of SiNx and water. In the visible range of the spectrum, the variation in reflectivity is between 2% and 25%. The former can be obtained if the film thickness is made to be an integer multiple of half the wavelength of light. This example, while rudimentary, demonstrates the importance of both considering and taking advantage of interference effects in the structure. A study by Poenar et al. measured the index of refraction and extinction coefficient of LPCVD SiNx in the 400-800 nm wavelength range using spectroscopic ellipsometry and direct reflectivity measurements.94 Because of the narrower measurement range compared to the earlier work of Philipp,91 this study provides better estimates of the extinction coefficient in the visible range of the spectrum. As shown in Figure 6, the extinction coefficient, κ, is ~10-3 across the 600- 800 nm range and increases up to ~10-1 towards the lower end of the spectrum (i.e. at 400 nm). The corresponding attenuation depth, given by 푙 = λ/4πκ, is ~50 μm, and decreases to ~0.3 μm at 400 nm. Therefore, thin SiNx windows can usually be treated as transparent in the visible range. Optical absorption can be significant in the UV range of the spectrum, though, and should be taken into account: a study of the transmission properties of 100 nm SiNx windows in the UV range demonstrates that, owing to absorption, window transmission is reduced from 90% at 400 nm to 10% at 200 nm.16

Figure 6. Extinction coefficients of several thin film materials including low stress silicon nitride (solid lines). Data based on ellipsometry and reflectivity measurements by Poenar et al.94 BSG and PSG refer respectively to borosilicate glass and phosphosilicate glass. Reproduced with permission from the Optical Society. Lastly, a recent theoretical study calculated the dielectric function of silicon nitride using density functional theory.95 The results were consistent with the measurements of Philipp for β- SiN—a crystalline phase of silicon nitride. The same study also examined both the effect of defects due to excess silicon and the effect of hydrogen termination on the optical properties. In both cases, changes in the energy loss spectrum below 10 eV were found, suggesting the possibility of tuning optical properties by controlling the composition and surface chemistry of the silicon nitride films.

X-Ray and Electron Scattering Properties of Free-Standing SiNx In applications where SiNx windows are used as x-ray or electron transparent support structures, the main concern is reducing scattering of the probe from the window material. The objective here is twofold: to reduce background signal resulting from scattering off the window, and to avoid severely attenuating the probe beam (be it an x-ray or an electron beam). Obviously, using as thin a membrane as possible would be the ideal strategy. However, there are often other constraints that come into play when designing a suitable support structure. The most important limitation to reducing window thickness is the reduced mechanical stability and, subsequently, the susceptibility of the window to bowing and fracture. Other constraints may include thermal and charge transport properties in applications where large amounts of energy or charge are deposited into the window-sample structure. Figure 7 shows the x-ray transmission of SiNx windows of various thicknesses as a function of photon energy. In the higher energy range (e.g. above ~5 keV), transmission is close to unity even when using 1 μm thick windows. In the low energy range (below ~2 keV), windows with thicknesses above 100 nm have severely reduced transmission. It is therefore recommended for soft x-ray applications to keep the window thickness on the order of a few tens of nanometers.

Figure 7. X-ray transmission of 10 nm (red line), 100 nm (green line), and 1000 nm (blue line) thick SiNx windows. Data obtained from the CXRO database, based on the work of Henke et al.96 The calculation assumes a density of silicon nitride of 3.44 g/cm3. The left panel highlights transmission at energies below 2 keV, whereas the right panel is for energies in the 2-10 keV range.

At even lower photon energies, working with thicker windows is not an option and the trade-off between mechanical stability and x-ray transmission becomes more restrictive. To circumvent this problem, certain designs employ a porous membrane structure. For instance, several commercial suppliers of SiNx windows offer what is referred to as “holey membranes”. These membranes are thick enough (~200 nm) to allow for sufficient mechanical stability, have a large enough window area (~1 mm2), but contain a number of holes for x-rays or electrons to pass through. The downside of this approach is the limited transmission as defined by the porosity of the membrane (typically below 25%). Alternative approaches implement grid-like support structures to enhance the stability of the film. For example, Törmä et al. fabricated ultrathin SiNx x-ray windows (40 nm thick) with an area as large as 30 mm2.97 Mechanical stability was achieved by embedding in the window design a grid structure made of polycrystalline-Si for additional support. The open free-standing area of the window was 77%.

Figure 8. (Left panel) Electron transmission of 5 nm (blue filled circles), 10 nm (red filled circles), 20 nm (green filled circles), and 40 nm (purple filled circles) thick SiNx windows, 5 nm a-C (green open circles), 40 nm a-C (red open circles), and bilayer graphene (purple open circles). Data obtained from theoretical electron scattering cross-sections.98 The 3 calculation assumes a density of SiNx of 3.44 g/cm and a 1:1.1 Si:N stoichiometry. This composition is used to calculate the average scattering cross-section weighted by the number densities of the composite atoms. a-C and bilayer graphene were assumed to have a density of 2.0 g/cm3. The solid lines are trend lines (the original work modeled energies satisfying 2m keV, with m being an integer between 0 and 8). (Right panel) Selected area electron diffraction (SAED) images of an α-Si3N4 nano-rod. The image on the bottom left is for a single-crystalline section taken from the body of the rod. The image on the top right is for an amorphous structure corresponding to the tip of the nano-rod. Image reproduced from reference 99 with permission from Elsevier.

Electrons interact more strongly with matter than x-rays. Therefore, scattering effects are more severe when employing SiNx windows as support structures in a Transmission Electron Microscope (TEM). There is little data in the literature on the electron transmission of silicon nitride, but this property can be calculated from the theoretical elastic scattering cross-sections developed by Riley, MacCallum, and Biggs for the 1-256 keV energy range.98 In order to calculate the electron transmission of the windows, the inelastic contribution to scattering has to be also considered. The inelastic contribution to scattering is derived from the empirical law 휎푖푛푒푙 = 18휎푒푙/푍, where 휎 is the scattering cross-section (integrated over the unit sphere; subscripts el and inel respectively refer to elastic and inelastic scattering), and Z is the atomic number.100 The total electron mean free path is then given by 1 1 Λtot = ≈ , (6) 푁σtot 푁σel(1+18/푍) with N the number density of atoms. For a molecule, the total electron mean free path is obtained by averaging the scattering cross-sections of the composite atoms–weighted by the number densities, as follows 1 Λtot = . (7) ∑ 푁jσtot,j In the above, the summation j is over the type of atom. Finally, electron transmission, T, of the SiNx window is calculated from the mean free path by

푇 = exp(− 푡⁄Λtot), (8) where t is the window thickness. Figure 8 shows the electron transmission of SiNx windows of select thicknesses in the 1-256 keV range as calculated from Eq. 8. Note that these calculations are inherently conservative as they assume that any electron that undergoes a scattering event is “lost”. The derivation above can be readily modified to accommodate a more realistic scenario by excluding from the scattering cross-section the angular range within which scattered electrons remain useful to the experimental measurement. This is done by replacing the elastic scattering cross-section, σ푒푙, by the partial elastic scattering cross-section integrated over the unit sphere minus some defined “useful” solid angle—as dictated by the experiment geometry. To this end, parametrized electron scattering cross-sections as a function of scattering angle can be found in the literature.98 Nevertheless, if we just consider the conservative results of Figure 8, it is then apparent that at the standard TEM energy of ~100 keV the windows should be <10 nm thick. This conclusion is supported by the fact that vendors of SiN windows marketed as TEM support structures offer thickness starting at below 10 nm. Another important aspect to the use of SiNx windows as support structures for TEM samples is the background signal resulting from the scattering of the electrons and the window material. Even in the single scattering regime, where the window transmission is sufficiently high, part of the electron beam will undergo forward scattering at angles other than 0o (relative to the unscattered beam direction). Because SiNx is amorphous, the pattern originating from the window has a diffuse character rather than the well-defined diffraction patterns generated by scattering from single-crystalline structures. Figure 8 is an example contrasting the electron diffraction patterns of single-crystalline α-Si3N4 and amorphous α-Si3N4. The amorphous pattern is diffuse and contains broad ring-like patterns that correspond to the nearest neighboring distances in the amorphous material. In order to account for the contribution from the window, measurements are typically done on a blank window (i.e. without sample) and the background pattern is subtracted from the diffraction obtained for a sample-on-window structure. Scattering, however, is not strictly additive in this sense, but the approach does not require complex beam propagation calculations. Accounting for background signal is especially important when the sample of interest is not crystalline and will therefore not have the benefit of spatially well-defined diffraction peaks. When operating the TEM in imaging mode, another concern is the reduced spatial resolution due to inelastic scattering of the electron beam from its interaction with the window material. de Jonge and Ross modeled this effect in nanofluidic cells.101 The main conclusion was that for ~1 µm liquid thickness, the window material itself does not contribute significantly to inelastic scattering. Instead, the resolution-limiting factor comes from inelastic scattering of the electrons with the liquid constrained between the cell windows. Further reduction of electron scattering from the support structure can be achieved with use of lighter membrane material. The most commonly available option for TEM applications are amorphous carbon (a-C) films that are mounted on standard TEM grids. The thicknesses of these films can be <10 nm. Figure 8 shows that the transmission of a 5 nm a-C membrane is slightly higher than that of a SiNx membrane of the same thickness. Even higher transmission can be achieved using graphene, few layer graphene (FLG), and graphene oxide support membranes—all of which are commercially available. In Figure 8, the transmission of bilayer graphene at 100 keV is ~98%. Yet, even with the higher electron transmission, whether it is advantageous to use SiNx vs. a carbon-based support structure depends on the specific application. The SiNx fabrication process is scalable; whereas with graphene and a-C, the support film needs to be prepared separately then transferred onto a suitable TEM grid. Consequently, the transferred film tends to have folds and wrinkles that limit its usable area. More importantly, when it comes to building of devices, SiNx is still more attractive because its deposition and processing are part of the highly standardized nanofabrication processes developed by the semiconductor and MEMS industries. On the other hand, an important distinguishing feature of graphene and a-C films is their high electrical conductivity—in contrast with SiNx, which is an insulator. It is expected that as progress continues in the fabrication technology of graphene and carbon-based materials, such films will be considered more seriously as viable alternatives for SiNx.

Chemical Properties of SiNx Surfaces The surface of silicon-rich silicon nitride exhibits a rich blend of silicon-, oxygen-, and nitrogen- bearing surface species, whose particular mixture depends strongly on sample preparation and history (including “aging” and, in the case of commercial sources, vendor).20, 64, 66, 102-106 This history dependence can perhaps be appreciated most easily through a survey of the silicon oxynitride (SiOxNy) literature, or through the variability of experimental outcomes when proper care is not taken.66, 107, 108 A surface oxide coating readily forms in air (and can lead to an oxide 102, 108, 109 gradient into the film), and the susceptibility of stoichiometric silicon nitride (Si3N4) to evolve ammonia by hydrolysis in the presence of liquid- and vapor-phase water should also be considered.102, 103 In spite of this, silicon nitride shows very strong chemical resistance to a wide range of etchants and conditions, and indeed, etch resistance is the mechanism by which the film is made free-standing.16, 17, 65 These films will, however, yield to etching in hot phosphoric acid (which requires quartz or other suitable vessel material).110 The consequences of this rich tangle of surface chemistry are both fearsome and tantalizing. In aqueous solution, multiple surface acid- base equilibria exist, and one must be attentive to unintended effects arising from the surface charge (and surface charge screening) that can change as a function of solution pH and ionic strength.20, 104, 109, 111-113 Under most conditions, the total surface charge density will reduce to

σ = |푒|(Γ + + Γ + − Γ −). (9) 푆푖2−푁퐻2 푆푖−푁퐻3 푆푖−푂

Here, e is the electron charge, and Γ푋 is the surface concentration of the specified species X, and the surface will have an isoelectric point determined by solution conditions (especially pH), and of course by the detailed fabrication and processing history that determine the particular surface chemical composition. The use of literature values to calculate the isoelectric point is complicated by process history differences and by variability even in the reported values.20 The challenges are underscored by the range of values reported for the isoelectric point (IEP) and point of zero charge 104, 109 111 (pHpzc) of silicon nitride, such as 4.2-7.6, and ~5. The surface can be generally conditioned using standard approaches such as exposure to a suitable oxidizing or reducing environment, or wet etching including hydrofluoric acid (and analogues) or piranha solution (and analogues).20, 47, 64, 102, 106, 108, 114-123 Specialized extensions of these methods can bring additional chemical flexibility.20, 64, 104 Silane chemistry is a common route to surface chemical functionalization, but one that can be undermined by insufficient attention to either the silicon nitride process history, or to the demands of the silane reaction, itself.64, 106, 124, 125 While the silica surface chemistry literature thus offers strategies by which to modify silicon nitride,126, 127 the fact that the films of interest to us are silicon-rich opens up the extensive, and well-established silicon surface chemistry literature for consideration.128 Hydrosilylation reactions are of particular interest: terminal alkenes and alkynes can be covalently linked with excess silicon in the SiNx films, either thermally or photochemically.105, 106, 117, 120, 121, 129 The first step in these hydrosilylation reactions is to etch the SiNx surface with dilute hydrofluoric acid; while the use of this processing step to remove the surface oxide coating (here, to permit subsequent covalent surface functionalization) is long- established, the exact chemical species left on the treated surface remains an area of active investigation.130 What remains undisputed, however, is that hydrosilylation is a potent and flexible method to install a wide range of different chemical moieties—from small molecules with passivating or reactive surface terminal functional groups, to biomacromolecules—on silicon-rich silicon nitride surfaces.105, 106, 117, 120, 121, 129 The approach offers straightforward and robust chemical tuning to prepare the silicon nitride surface for compatibility with a diversity of applications, as well as to install additional functional elements. Nanofluidic Sample Cells

Experimental efforts to gain ever-greater insight into the molecular world—on ever-faster timescales, with ever-greater spatial resolution, with ever-greater departure from tractable model systems, and with ever-greater diversity of sample—can encounter extraordinary barriers.17, 38, 39, 131-133 In some cases, the challenges arise from the properties of the sample, itself—high optical absorption or scattering cross-sections that require extremely short path lengths, for example.17, 38, 39 In others, experimental conditions can present challenges as simple, but unyielding, as the necessity for vacuum conditions, or as pernicious as probe-induced sample damage.38, 39, 134, 135 Challenges can be additive and mutually amplifying in severity. The use of a sample container can play a similarly complex role. On the one hand, it may be used to ensure the requisite conditions are satisfied, but on the other hand, it introduces additional matter into the experiment’s path of interrogation. As a concrete example, attempts to use femtosecond multidimensional infrared spectroscopy to study energy redistribution of the hydrogen bonding network in pure water, rather than in isotopically-substituted model systems, had to deal with the high optical absorption at the energies of interest that restricted the water layer thickness to ~500 nm. Attempts to compress the water to the desired thickness between thin diamond windows could easily place at least one of the “sample” challenges in stark relief: expensive cracked windows without successful spectroscopic measurements (personal communication, ~2004). An additional challenge of using windows to physically constrain the water path length to submicron dimensions was that even optically transparent windows could generate a nonresonant contribution to the measured signal at short times, thereby potentially obscuring the short-time dynamics of the water. The joint consideration—the need for a well-defined submicron path length in a configuration that did not add on an (appreciable) nonresonant contribution—prompted the design of a sample cell constructed from thin-film silicon nitride windows around a 500 nm-high fluid channel.17 The 800 nm-thick windows did not themselves contribute to the signal, which was vital to reveal the ~50 fs timescale for the decay of the memory of persistent correlations in the hydrogen-bonded network of pure water. The utility of this silicon nitride material—or its thin-film brethren—for sample cell windows extends across the spectrum and into charged-particle techniques.17-20, 35-45, 53-58 We note, of course, that there is a tradition of alternative nanoscale sample chambers for spectroscopic studies, including vesicles, micelles, zeolites, and supramolecular entities.136-140 Vesicles, for example, have been used in both ultrafast and single-molecule studies and use well- established formation protocols to use thin, but fragile, lipid bilayers to provide nanoscale confinement and low window signal (Figure 9a).136, 138, 139 Pores can be formed through the bilayer to permit limited access to the vesicle interior.136-138 More recently, ~1 µm thick, window-free liquid samples in vacuum have been achieved and used for transmission soft x-ray studies using a sophisticated arrangement of liquid jets.141. The performance of this elegant solution is determined by sample properties such as the surface tension, viscosity, temperature, and vapor pressure, where solvent-optimization may lend generality to the study of solution samples using this approach. Nanofabricated equivalents of conventional sample cells and cuvettes,17-20, 35-45, 53-58 have a number of advantages relating, primarily, to their generality of application. Their construction provides for straightforward manipulation, even by hand, and one has access to materials that can offer a greater range of sample compatibilities—either directly or through modifications—than the materials in specialized implementations such as phospholipid-based vesicles. The basic structure (Figure 9d,e) can be modified by a host of conventional and unconventional nanofabrication approaches, allowing the integration of functional and structural elements such as electrodes to allow for more in-depth or flexible investigations.42, 142-144 Two additional key advantages emerge. First, the design provides for a convenient macroscopic-to-microscopic interface (Figure 9f-i). This is seen, on the one hand, by the natural integration of the thin-walled channel with a convenient silicon frame. By opening the nanochannel to the edge of the silicon frames to create a through-channel, sample could be loaded into the preassembled cell by capillary action or, through appropriate design of a sample chamber holder, through forced flow.17, 36, 41, 42, 145-147 Second, the dimensions of structural and functional elements can be readily tuned within the existing fabrication infrastructure in order to adapt to different experimental needs. An exceptionally stringent test for thin-walled nanofluidic cells comes in the context of transmission electron microscopy (Figure 9j).

Figure 9: (a) Vesicles offer nanoscale liquid confinement in soft phospholipid envelopes, with well-established formation protocols. (b) Robust graphene membranes can form nanoscale containers around liquid droplets. (c) Micrometer-diameter openings in otherwise intact vacuum windows provide access to underlying liquid-phase samples (see discussion of SALVI in text). Silicon nitride thin films spanning openings in silicon frames can be used to form a range of nanoscale liquid containers. Cell formats include those (d) with integral spacers that require sample addition before sealing; those (e) with, e.g. nanoparticle spacers that can be loaded with liquid before or after closing; those (f) with integral spacers allowing (g) liquid loading after closing; and those (h) with an integral spacer but (i) more sophisticated fluidic connections allowing (j) structured flow channels for control over fluid flow useful for, e.g. TEM. Object sizes are not intended to convey scaling information. Figures in (d)-(j) from reference 20 – Reproduced by permission of The Royal Society of Chemistry.

Liquid (or “wet”) samples have long held allure for practitioners of (transmission) electron microscopy, but the vacuum environment needed for electron microscopy and the need for <100 nm-thick samples left the field with only a handful of painstakingly executed early investigations.38, 40, 143, 148-159 Both challenges similarly afflict a broader class of samples than liquids. Sophisticated and elegant solutions have involved reconfiguring the sample-containing region of the electron microscope, itself, and using low-vapor-pressure ionic liquids to cope with the vacuum conditions.149, 156, 160-165 Cryomicroscopy rather enviably protects the sample against the vacuum, but suffers from a number of severe limitations: the possibility to observe structural dynamics—such as aggregation, nucleation, electrodeposition, and self-assembly-driven processes37, 38, 40, 143, 166-169—is essentially eliminated, as is the ability to rapidly exchange samples on-the-fly.20 A liquid cell for TEM thus holds much appeal. The minimal requirement for such a cell is that it adequately preserve the integrity of a sample, with a thickness suitable for the desired spatial resolution (≤100 nm for higher resolution).36, 40, 170 This thickness limit includes sample and window thicknesses, weighted by the scattering properties determined by their structure and composition. The channel height (but not window thickness) restrictions are less stringent on gas cells for TEM.171 Sample cells for scanning electron microscopy (SEM) on liquid samples face similar challenges in terms of the effective window thickness (as measured by its contribution to signal attenuation), but without the accompanying requirement to also control the sample thickness which will, instead, by determined by the electron beam penetration depth.101, 172-175 To fully maximize the potential of in-liquid TEM for exploring nanoscale structure, it is necessary that the nanofluidic cell support through-flow.17, 36, 41, 42, 145-147, 176 Once such a sample cell is loaded into the electron microscope, with connecting fluid lines external to the microscope, sample can be easily introduced for examination without the delays of waiting for vacuum to reestablish during conventional sample loading. Sample damaged by the electron beam—either directly, or through solvent-mediated damage—can be quickly purged and replaced. Surface chemical treatment (or use of alternative window materials) may be required to suppress unwanted interactions between the sample and window—or to encourage favorable interactions.20, 36, 177-180 Perhaps the most exciting research frontier is the pursuit of structural dynamics.36, 37, 41, 132, 143, 167-169, 179, 181-185 Sample structural evolution can be triggered by changing the liquid composition (e.g. the solution pH, or the solvent polarity, or injecting different constituents such as cross-linkers and denaturants), and then observed with the spatial resolution of the electron microscope. The promise of this new generation of conventional nanofabricated fluid cells for TEM was first demonstrated in 2003.37 In brief, the cell was hand-assembled by using vacuum- compatible epoxy to seal two 100 nm-thick silicon nitride windows around a 0.5-1 휇m-high ring of SiO2. A particularly exciting element of this particular cell was the inclusion of electrodes, a configuration that allowed for directly triggering the structural dynamics: electrodeposition of copper within the cell. The two key structural advances of this cell were the use of thin silicon nitride windows, and the incorporation of a hard spacer to define the liquid channel height. More streamlined fabrication approaches have tackled the limitations of using hand-applied epoxy to seal the cell: thin-film indium can serve to seal the sample cell and define the liquid reservoir height; direct wafer bonding has also been used for cell sealing and is compatible with the use of well-defined hard spacers to define the liquid channel height.42, 167 There is considerable variability and flexibility—depending on acceptable performance specifications—in the construction of 4, 6-10, 186, 187 devices using thin-film windows in a silicon frame (e.g. SiNx, SiO2 ), including using hand-applied epoxy as spacer and for bonding (for a ~5µm gap), hand-applied nanoparticles as spacers, and patternable photoresist spacers.20, 36-38, 40, 42, 43, 179, 188 Recent advances in materials science have broadened the choice of window materials beyond traditional nanofabrication materials and, in a sense, have resurrected the use of thin, carbon-based films. The principal advantage of such a material choice is of course that the low (average) atomic number and low atomic density have salutary effects on image contrast and resolution.101 Of course the materials—true for all such windows—must offer sufficient mechanical robustness, electron-beam resistance (including conductivity when charging is a concern), and chemical compatibility with the sample. The limitations of using conventional carbon-based polymer thin films as windows for TEM fluid cells were seen quite clearly in early developments in building cells for using SEM to examine wet samples.101, 175 Of a number of carbon-based films tested by Moses and co-workers, only polyimide was found to be suitable, and then with a window thickness of 145 nm (50 nm could be achieved if a small leak was introduced into the microscope chamber), and without being used to constrain a thin liquid layer.101, 175 Carbon nanomembranes, a recent, ~1.5 nm-thick, addition to the TEM support film toolkit, may hold promise for designing fluidic cells.5, 11, 189, 190 Large-area carbon nanomembrane films can be readily manufactured, but their more compelling characteristics stem from their synthesis by electron-beam-induced cross-linking of molecular precursors. One can choose from a variety of molecular precursors that will all generate ultrathin carbon-based films that can subsequently be chemically functionalized with relative ease.190 Thus, the film properties of these ultrathin, carbon- containing films can be determined with molecular-level control.190 In contrast, graphene offers a set of prospects determined by its unique composition and structure. Graphene, though, has received considerable attention in the field of TEM of liquid samples.38, 179, 183, 191, 192 Liquid- containing “nanobubbles” (Figure 9b) can be formed between two graphene sheets laid together, reminiscent of earlier work using ~30 nm-thick “hard” carbon films.150 The formation and size of these nanochambers is not directed, and so sample-containing regions suitable for study must be found. In a sense, the use of this cutting-edge material has brought the “sample question” of TEM—and of TEM on liquids—full-circle: the nanocontainers are closed (aside from leaks; the contents are not added or exchanged after container formation), and the assembly is essentially by- hand. As the fabrication footprint for graphene matures, however, assembly should become more deterministic and more sophisticated graphene-windowed fluid cells for TEM will undoubtedly emerge. Nevertheless, these graphene-bounded liquid cells have set the standard for imaging resolution, through the use of windows a single atom thick, where that atom is of low atomic number, and with achievable liquid path lengths of tens of nanometers.38, 179, 183, 191 Nanofluidic through-flow grants incredible capabilities and for both breadth of study and depth of discovery, must remain a focus of effort, regardless of the particular window material or assembly process.17, 36, 41, 42, 145-147, 176 Many of the most impressive advances in thin-walled nanofluidics are driven by the demands of TEM, but have tremendous cross-over potential for other investigations. The stringent requirements of the sample cells for TEM may lead to designs that have base capabilities greater than those required by a different technique—SEM, for example, needs not have the thin sample path lengths of TEM—but the additional capabilities may nevertheless be beneficial. For example, when a particular sample cell limits the sample to, e.g. a 100 nm-thickness, and a particular technique’s penetration depth exceeds that depth, the sample (cell), itself, will provide ~100 nm vertical resolution without the need for additional mechanisms. Thin-film silicon nitride windows find use also in XPS studies under ambient, or reactive, environments.193-196 If one is willing to accept (and in fact, design for) the otherwise ostensibly nightmarish prospect—aside from the nanopore sensing paradigm discussed below—of a hole in a liquid cell window chosen for its impermeability, then one may gain even greater experimental access to the chemical processes occurring in liquids (Figure 9c).197 A custom-designed vacuum compatible microfluidic electrochemical device was created with a thin film SiNx cover. By forming a ~2 µm hole in that cover, the authors were able to then use in situ liquid secondary ion mass spectrometry (SIMS) to probe the electrochemistry, including the electrode-solution interface.198 A similar fluid cell—one with protected thin-film SiNx window with a single micrometer-scale breach to allow unfettered access—had earlier allowed the characterization of a single cell by both super-resolution optical microscopy and time-of-flight secondary ion mass spectrometry (ToF-SIMS), and the combination of SEM and ToF-SIMS.173, 199 The compatibility of this platform of a micrometer aperture in a thin silicon nitride membrane with a range of characterization tools has led to the coining of the term System for Analysis at the Liquid Vacuum Interface (SALVI).198, 199 The performance of this platform has been well-established and was recently anchored in a mini-review of in situ monitoring of catalytic processes in aqueous environments.200 The available fabrication tools for Si-based cells, coupled with favorable material properties, allow for other functional architectures such as integrated microwells instead of a single sample volume.201 Beyond structural modifications of the basic nanofluidic platform, advanced detection schemes can be used to compensate for some material and fabrication limitations, and implementation of different experimental techniques can broaden the achievable insights (Figure 1a). For example, an annular dark field detector can be used to yield atomic number contrast. Thus, when samples, themselves, offer low contrast—a prime example being biological material in a surrounding aqueous medium101—spatial resolution can be enhanced by using an annular dark field detector in conjunction with heavy-atom-containing labels such as gold nanoparticles.34, 202- 204 This approach was used to enhance the spatial resolution in a fluidic cell for TEM where the liquid path length was micrometers-thick, instead of the desired nanometer-thickness.34, 202-204 Electron energy is also an important consideration when developing optimized sensing schemes— whether it be the incident electron energy or the transmitted electron energy. For example, energy- filtering of the electrons just before detection can improve the spatial resolution of the image, albeit it at the cost of detected electron intensity.11, 40, 205, 206 Energy-discrimination of the sample- transmitted electrons leads naturally to a dramatically broadened scope of sensing capabilities, including electron energy loss spectroscopy (EELS),89, 207, 208 and to perhaps its ultimate extension, vibrational spectroscopy by EELS, with extremely high spatial resolution and different selection rules than optical approaches.209 By opening up the interior of the TEM to liquid-compatible samples, other investigation tools become available, including X-ray energy-dispersive spectroscopy (XEDS),210 and time-resolved studies including and extending well beyond dynamic TEM (DTEM).131, 132, 169 Nanopore Single-Molecule Sensing

Typical nanopore devices are constructed from the basic structure outlined in Figure 2c: a nanofluidic channel through a thin, free-standing silicon nitride membrane. Nanopore holders are constructed so that this nanopore provides the sole fluid path connecting electrolyte solutions on both sides of the membrane. The insulating, impermeable silicon nitride thus acts as a physical barrier and as a support for the channel through which ions and molecules can pass under the influence of an electric field or other suitable driving force.21-29, 211-216 The most common sensing configuration is the so-called resistive-pulse sensing mode (Figure 10). In brief, ions pass through the nanopore in response to the applied cross-membrane electric field, giving a typically pico- to nanoampere current. The nanopore conductance magnitude is determined by the solution conductivity (and solution pH, through its effect on surface charges), nanopore size and shape, and also by the nanopore’s surface charge.24, 113, 217-221 Passage of an analyte through the nanopore can generate a perturbation in the measured current that arises from physical displacement of solution ions by the analyte, and from more complex interactions between charges in solution and on the surface of the analyte and nanopore.24, 28, 52, 221-223 It is convenient to generically refer to the current perturbations as “blockages”, although analyte properties and sensing conditions may lead even to current enhancements.221 With suitable nanopore and experimental design, the measured current perturbation generates a signal from a single molecule at a time that can be used for chemical identification, or profiling. Nanopores can also be used in alternative sensing schemes, including for force spectroscopy and single-molecule optical sensing, that will be outlined after a brief discussion of their fabrication.

Figure 10. (a) Schematic of a typical nanopore experimental setup showing the nanopore-containing membrane separating two reservoirs, with electrolyte filling the wells and the pore. The measured current is generated by a voltage applied across the nanopore that drives electrolyte ions (light blue) through the nanopore. Passage of a molecule or particle of interest (orange) through the nanopore can perturb that current. (b) Molecular recognition can augment the sensing selectivity. The complex between analyte and aptamer—the molecular recognition agent—prevents the aptamer from travelling through the pore before it dissociates from the target—a process indicated here by the increased current perturbation duration in the presence of target. Figure (a) from reference 20 – Reproduced by permission of The Royal Society of Chemistry.

Thin film silicon nitride is a standard material for nanofabrication, but small-diameter (<10 nm), solid-state nanopores formed in thin-film membranes historically represented extreme fabrication challenges. Laborious efforts requiring significant operator expertise saw charged- particle milling—in transmission and scanning electron microscopes, by focused ion beams, or in helium ion microscopes, for example—deliver the desired structures, albeit with fabrication yields that dramatically diminished with sizes <50 nm.21, 23, 25, 27, 144, 224-231 Chemical etching of damage tracks left in thin Si-based thin films by relativistic ion bombardment can produce single nanopores and (irregularly spaced) nanopore arrays, but the approach does require the use of large-scale facilities.232 More specialized approaches exist alongside efforts to draw on conventional techniques such as atomic-layer deposition (ALD).21, 23, 25, 27, 144, 224-227, 230, 233, 234 Dielectric breakdown has emerged as a simple, yet extremely flexible and powerful, technique to fabricate nanopores: it requires little more than the usual apparatus used for nanopore sensing, and instantly wets the nanopore (contrary to TEM-based methods, for example, where surface contamination poses wetting, and other, challenges).235-237 In overview, nanopores as small as 1 nm in diameter, and ~10 nm long can be fabricated with some flexibility in fabrication method. Characterization of nanopores can be done using charged-particle microscopes and related techniques such as electron tomography and EELS,219, 220, 238-241 or by much less instrumentally-intensive (ionic) conductance-based approaches.113, 217-220 A conductance-based characterization is gentler than charged-particle-based approaches, and is also more naturally connected to the nanopore surface chemistry—especially to any organic monolayers that may be damaged in the TEM, for example— and to the usual measurable of nanopore single-molecule measurements (that is, to the ionic current as a function of time). The advantages of using a conventional nanofabrication material are seen naturally in applications, some of which are outlined below, in which additional functional elements are added to the base nanopore nanofluidic platform. Nevertheless, efforts to continue to develop nanopores using other thin-film materials such as molybdenum disulfide, but with graphene seemingly foremost among them, continue; approaches often see the use of an underlying thin-film silicon nitride support.242-248 While lacking the electronic properties of graphene, carbon nanomembranes (see discussion above) present an appealing potential ultrathin carbon-based alternative.249 Nanopores, fabricated using a suitable selection of means and materials of construction, and employed in a variety of configurations and approaches, are an exciting and promising motif for single-molecule sensing, confinement, and manipulation.20, 21, 23, 27, 28, 59, 222, 250-270 Non-Optical Single-Molecular Sensing

The conventional approach to nanopore sensing, so-called resistive-pulse sensing,222 treats the nanopore as a nanofluidic channel through which dissolved ions and analytes pass, and with the presence of the transiting analyte registered as an electronically registered current perturbation. Analyte properties are revealed, or at least suggested, by the current perturbation properties such as depth, duration, and fluctuation statistics. In other words, a large number of signal determinants—driving force (usually electrophoretic), solution properties (especially pH and ionic strength), nanopore size and surface chemistry, and, critically, analyte characteristics including size and charge distribution—are collapsed onto a single signal channel. The operational simplicity of this basic sensing paradigm places limits on the analytical selectivity that can be overcome without using additional measures compatible with nanopore sensing (below), but the single- molecule sensitivity—without the need for sample labelling or amplification—comes with an ease of operation that exceeds that of most other single-molecule methods. Moreover, there are vitally important application areas where sample complexity is not an issue. In the case of DNA sequencing, for example, the challenge is to distinguish between only four unmodified DNA bases, and to detect a small number of epigenetic modifications, but to do so rapidly and ideally without significant sample processing that might introduce artefacts.59, 271, 272 Alternatively, nanopores can be an exquisitely useful quality assurance tool even in complex, many-component samples: the departure of measured current perturbation statistics from those measured on a certified standard sample will indicate the presence of an impurity. In applications requiring greater selectivity, molecular recognition agents such as aptamers can be used as an adjunct to conventional nanopore sensing. In one possible configuration, the interior of the nanopore is functionalized with the molecular recognition agent, making the nanopore responsive to the given analyte (one can envision some implementations functioning as a <100 nm-long affinity column for a single molecule at a time).211, 273 In another, aptamers are released into the sample and the current perturbation characteristics accompanying the partitioning of the aptamer-analyte complex into, or through, the nanopore provides the selectivity.274-277 Binding of an aptamer to its target can drive and stabilize an aptamer conformation change (or stabilize an existing conformation). If, as illustrated in Figure 10b, the complex is too large to enter into the nanpore, the current perturbation could last until, for example, the complex was ruptured allowing unfolded aptamer passage again.275, 276, 278-281. The use of the nanopore as a fixed aperture (or as a region of high electric field) to rupture intermolecular complexes, or to disrupt intramolecular interactions, are particular applications of the general approach of nanopore force spectroscopy (NFS), which can be used for bioanalytical applications such as genotyping, and for more fundamental investigations such as exploring receptor-ligand interactions, protein folding, and biologically important interactions between macromolecules.252, 253, 260, 261, 282-287 The details of the interactions are mapped onto the ionic current signature. While NFS offers a compelling alternative to other force microscopes288 for a number of investigations, there are also a number of interesting uses of nanopores in conjunction with atomic force microscopes (AFM) and laser optical tweezers.258, 284, 289-294 Nanopore sensing selectivity can also be improved without molecular recognition agent adjuncts by incorporating different sensing mechanisms that may rely on adding sensing elements to the conventional platform (Figure 1b). Here, the mechanical robustness and nanofabrication compatibility of the traditional silicon nitride platform allows for structural and functional elements to be integrated into the nanopore platform, in as straightforward a manner as is allowed by the extreme length scales of nanopores. The installation of electrodes proximal to the nanopore opening and orthogonal to the translocation path, for example, holds prospects for electron tunneling (or, e.g. capacitive) measurements on passing molecules.23, 59, 295-303 Of course the installation of nanoelectrodes in nanopores for conventional electrochemical investigations has its own exciting prospects.244, 295, 304 Such extensions beyond resistive pulse-sensing highlight the importance and breadth of application of nanopores for single-molecule science, with an implementation free of the instrumentation, and free from sample processing steps, that may be needed for single-molecule optical studies. The nanopore platform, though, is powerfully suited to also enhance single-molecule optical studies. Nanopore as Nanofluidic Cuvette and Optofluidic Device

Nanopores possess a number of structural and functional aspects that can be used to enrich single- molecule optical studies. At the same time, optical methods can allow for greater insight into nanopore-enabled single-molecule studies, and the complementary operating paradigms allow for multimodal measurements. During optical interrogation of a nanopore-constrained single molecule, simultaneous electrical measurements (e.g. resistive-pulse sensing, or tunneling measurements) can also be performed, or the applied electric field (or chemical gradients, for example), can be used to perturb the system under investigation (Figure 1b). Key examples of such non-optical sensing and manipulation approaches were outlined earlier. In a largely passive sense, solid-state nanopores offer lateral molecular localization and confinement on ~10 nm length scales. Much as vesicle-based nanocontainers have allowed molecular passage through lipid- bilayer-incorporated protein nanopores,136, 138 the solid-state channel here, itself, provides confinement but also molecular passage. Indeed, the nanopore can be thought of as a sort of sample chamber of zeptoliter volume where nanopore surface functionalization (Figure 1b) and solution conditions can define a unique chemical environment, and where an entrained molecule can be subjected to a number of perturbations and interrogation methods. Vertical confinement— provided physically by the nanopore membrane, and optically by reflective coatings on the silicon nitride film—yields a number of benefits, with a common effect being detection of a moiety only once it has passed through the nanopore. Fluorescence is the most likely optical technique to be used in conjunction with a nanopore, but one could imagine that a suitably structured gold film, separated by a well-defined nanopore gap containing an analyte, might also be used for surface- enhanced Raman spectroscopy.20, 27, 46, 61, 90, 267-269, 305-315 Extensions to Nanopore Arrays We conclude our discussion of the merging of physical- and optical-based nanopore sensing and manipulation approaches, with the consideration of nanopore arrays. While much fundamental nanopore work uses single-nanopore devices, application throughput can be significantly increased by crafting and adopting devices housing arrays of nanopores.21-29, 38, 40 We conclude not with a discussion of the general benefits of multimodal nanopore array-based measurement, which can be understood as array-based extensions of earlier discussions, but rather by focusing more specifically on two final porous thin-film platforms. Track-etched polymer membranes, with <100 nm diameter pores with number densities as high as ~109 cm-2, find widespread use as filters.316-319 The ~100 µm membrane thicknesses, coupled with often tortuous paths, can degrade filtering speed. In contrast, suitable thin membrane filters—such as those 13, 47-50, 52, 69, 232, 249, 307, 320, 321 fabricated from thin-film SiNx—allow for much higher flow rates. When formed using nanofabrication-compatible materials, these porous thin-film platforms can be readily integrated into devices and moreover modified to generate functions beyond filtering. Nanopore filters coated with suitable coinage metal films can combine filtering with surface- enhanced Raman spectroscopy (SERS).46, 305, 322, 323 One particularly interesting application area depends on the ability to control the size and position of the nanopores, so that after metallizing them, they form a plasmonic array.60, 61 Concluding Thoughts and Prospects

Free-standing thin film structures feature both prominently and unobtrusively in a wide range of tools and methods for molecular-level research. Suitable thin films can provide transparency through composition and path length, and that transparency can extend across a wide range of spectroscopically and crystallographically important wavelengths to include charged-particle transparency. Highly localized micro- and nanoscale apertures can be opened in sufficiently robust films when transparency cannot be otherwise achieved. Such transparent, or locally transparent, thin film window constructs thus enable studies ranging from linear and ultrafast spectroscopies across the visible, infrared, and x-ray; to x-ray photoelectron spectroscopy, mass spectrometry, and transmission electron microscopy; and many others. A less inconspicuous role uses the mechanical properties of particular thin film windows to not merely contain samples within well- defined environments, but to provide protection from severe challenges to sample integrity such as vacuum conditions necessary for some experimental methods. The use of thin-walled nanofluidic cells to allow transmission electron microscopy on liquid samples is but the most dramatic of such a role. Thin film elements can be more forcefully engaged, as seen in nanopore single-molecule sensing applications. Nanochannels formed through thin films and having tailored size, shape, and surface chemistry, can be used as a powerful class of tool for single-molecule sensing and manipulation. The capabilities of this basic element, alone, have dramatically expanded the toolkit of single molecule science, but it can be even further expanded when additional functional elements and techniques can be integrated with the core nanopore structure. Thin film silicon nitride membranes, by virtue of their composition, properties, structure, and fabrication compatibility and infrastructure, figure prominently in all of the structures, devices, and approaches featured in this review article. We therefore used this canonical structural and functional element to demonstrate key performance criteria and principles that will govern the development and application of new materials and structures. Free-standing thin films are truly an enabling element for molecular science.

Acknowledgements.

The authors are grateful to Y.M. Nuwan D.Y. Bandara for assistance with some figures. Funding.

JRD acknowledges the support of funding from NSF CAREER award CBET-1150085 for nanopore sensing research.

1. D.C. Harris. Quantitative Chemical Analysis. W.H. Freeman and Company, 2016. 9 ed. 2. D.A. Handley, B.R. Olsen. "Butvar B-98 as a Thin Support Film". Ultramicroscopy. 1979. 4(4): 479-480. 3. E. Davison, W. Colquhoun. "Ultrathin Formvar Support Films for Transmission Electron Microscopy". Journal of Electron Microscopy Technique. 1985. 2(1): 35-43. 4. F. Enquist, A. Spetz. "The Fabrication of Amorphous SiO2 Substrates Suitable for Transmission Electron Microscopy Studies of Ultrathin Polycrystalline Films". Thin Solid Films. 1986. 145(1): 99-104. 5. C.T. Nottbohm, A. Beyer, A.S. Sologubenko, I. Ennen, et al. "Novel Carbon Nanosheets as Support for Ultrahigh-Resolution Structural Analysis of Nanoparticles". Ultramicroscopy. 2008. 108(9): 885-892. 6. J.W.M. Jacobs, J.F.C.M. Verhoeven. "Specimen Preparation Technique for High Resolution Transmission Electron Microscopy Studies on Model Supported Metal Catalysts". Journal of Microscopy. 1986. 143(1): 103-116. 7. T.L. Morkved, W.A. Lopes, J. Hahm, S.J. Sibener, et al. "Silicon Nitride Membrane Substrates for the Investigation of Local Structure in Polymer Thin Films". Polymer. 1998. 39(16): 3871-3875. 8. A.W. Grant, Q.H. Hu, B. Kasemo. "Transmission Electron Microscopy 'Windows' for Nanofabricated Structures". Nanotechnology. 2004. 15(9): 1175. 9. G.J. Kearns, E.W. Foster, J.E. Hutchison. "Substrates for Direct Imaging of Chemically Functionalized SiO2 Surfaces by Transmission Electron Microscopy". Anal. Chem. 2006. 78(1): 298-303. 10. R.D. Glover, J.M. Miller, J.E. Hutchison. "Generation of Metal Nanoparticles from Silver and Copper Objects: Nanoparticle Dynamics on Surfaces and Potential Sources of Nanoparticles in the Environment". ACS Nano. 2011. 5(11): 8950-8957. 11. D. Rhinow, M. Büenfeld, N.-E. Weber, A. Beyer, et al. "Energy-Filtered Transmission Electron Microscopy of Biological Samples on Highly Transparent Carbon Nanomembranes". Ultramicroscopy. 2011. 111(5): 342-349. 12. R.S. Pantelic, J.C. Meyer, U. Kaiser, H. Stahlberg. "The Application of Graphene as a Sample Support in Transmission Electron Microscopy". Solid State Commun. 2012. 152(15): 1375-1382. 13. C.C. Striemer, T.R. Gaborski, J.L. McGrath, P.M. Fauchet. "Charge- and Size-Based Separation of Macromolecules Using Ultrathin Silicon Membranes". Nature. 2007. 445(7129): 749-753. 14. M. Harb, R. Ernstorfer, T. Dartigalongue, C.T. Hebeisen, et al. "Carrier Relaxation and Lattice Heating Dynamics in Silicon Revealed by Femtosecond Electron Diffraction". J. Phys. Chem. B. 2006. 110(50): 25308-25313. 15. M. Harb, R. Ernstorfer, C.T. Hebeisen, G. Sciaini, et al. "Electronically Driven Structure Changes of Si Captured by Femtosecond Electron Diffraction". Phys. Rev. Lett. 2008. 100(15): 155504. 16. D.R. Ciarlo. "Silicon Nitride Thin Windows for Biomedical Microdevices". Biomed. Microdevices. 2002. 4(1): 63-68. 17. M.L. Cowan, B.D. Bruner, N. Huse, J.R. Dwyer, et al. "Ultrafast Memory Loss and Energy Redistribution in the Hydrogen Bond Network of Liquid H2o". Nature. 2005. 434(7030): 199-202. 18. J.R. Dwyer, Ł. Szyc, E.T.J. Nibbering, T. Elsaesser. "Note: An Environmental Cell for Transient Spectroscopy on Solid Samples in Controlled Atmospheres". Rev. Sci. Instrum. 2013. 84(3): 036101-036101-036101-036102. 19. J.R. Dwyer, Ł. Szyc, E.T.J. Nibbering, T. Elsaesser. "Ultrafast Vibrational Dynamics of Adenine-Thymine Base Pairs in DNA Oligomers". J. Phys. Chem. B. 2008. 112(36): 11194- 11197. 20. J.R. Dwyer, Y.M.N.D.Y. Bandara, J.C. Whelan, B.I. Karawdeniya, et al. "Silicon Nitride Thin Films for Nanofluidic Device Fabrication". In: J. Edel, A. Ivanov and M. Kim, editors. Nanofluidics, 2nd Edition. Royal Society for Chemistry, 2016. 2 ed. 21. D.G. Haywood, A. Saha-Shah, L.A. Baker, S.C. Jacobson. "Fundamental Studies of Nanofluidics: Nanopores, Nanochannels, and Nanopipets". Anal. Chem. 2015. 87(1): 172-187. 22. K. Mathwig, T. Albrecht, E.D. Goluch, L. Rassaei. "Challenges of Biomolecular Detection at the Nanoscale: Nanopores and Microelectrodes". Anal. Chem. 2015. 87(11): 5470- 5475. 23. J. Kudr, S. Skalickova, L. Nejdl, A. Moulick, et al. "Fabrication of Solid-State Nanopores and Its Perspectives". ELECTROPHORESIS. 2015. 36(19): 2367-2379. 24. Z.D. Harms, D.G. Haywood, A.R. Kneller, S.C. Jacobson. "Conductivity-Based Detection Techniques in Nanofluidic Devices". Analyst. 2015. 140(14): 4779-4791. 25. M. Taniguchi. "Selective Multidetection Using Nanopores". Anal. Chem. 2015. 87(1): 188-199. 26. J.E. Reiner, A. Balijepalli, J.W.F. Robertson, J. Campbell, et al. "Disease Detection and Management Via Single Nanopore-Based Sensors". Chem. Rev. 2012. 112(12): 6431-6451. 27. B.N. Miles, A.P. Ivanov, K.A. Wilson, F. Dogan, et al. "Single Molecule Sensing with Solid-State Nanopores: Novel Materials, Methods, and Applications". Chem. Soc. Rev. 2013. 42(1): 15-28. 28. S. Howorka, Z. Siwy. "Nanopore Analytics: Sensing of Single Molecules". Chem. Soc. Rev. 2009. 38(8): 2360-2384. 29. T. Albrecht, J.B. Edel, M. Winterhalter. "New Developments in Nanopore Research— from Fundamentals to Applications". J. Phys.: Condens. Matter. 2010. 22(45): 450301. 30. Chem3d Ultra. 16.01.4. PerkinElmer, 2017. (commercial) 31. H.W. Lefevre, R.M.S. Schofield, D.R. Ciarlo. "Thin Si3N4 Windows for Energy Loss Stim in Air". Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms. 1991. 54(1): 47-51. 32. K.K. Goncz, P. Batson, D. Ciarlo, B.W. Loo, et al. "An Environmental Sample Chamber for X-Ray Microscopy". Journal of Microscopy. 1992. 168(1): 101-110. 33. E.D. Green, G.S. Kino. "Atmospheric Scanning Electron Microscopy Using Silicon Nitride Thin Film Windows". Journal of Vacuum Science & Technology B. 1991. 9(3): 1557- 1558. 34. M.J. Dukes, D.B. Peckys, N. de Jonge. "Correlative Fluorescence Microscopy and Scanning Transmission Electron Microscopy of Quantum-Dot-Labeled Proteins in Whole Cells in Liquid". ACS Nano. 2010. 4(7): 4110-4116. 35. S.-K. Eah, H.M. Jaeger, N.F. Scherer, X.-M. Lin, et al. "Femtosecond Transient Absorption Dynamics of Close-Packed Gold Nanocrystal Monolayer Arrays". Chem. Phys. Lett. 2004. 386(4–6): 390-395. 36. C. Mueller, M. Harb, J.R. Dwyer, R.J.D. Miller. "Nanofluidic Cells with Controlled Pathlength and Liquid Flow for Rapid, High-Resolution in Situ Imaging with Electrons". J. Phys. Chem. Lett. 2013. 4(14): 2339-2347. 37. M.J. Williamson, R.M. Tromp, P.M. Vereecken, R. Hull, et al. "Dynamic Microscopy of Nanoscale Cluster Growth at the Solid-Liquid Interface". Nature Materials. 2003. 2(8): 532-536. 38. F.M. Ross. "Opportunities and Challenges in Liquid Cell Electron Microscopy". Science. 2015. 350(6267) 39. J.R. Dwyer, R.E. Jordan, C.T. Hebeisen, M. Harb, et al. "Experimental Basics for Femtosecond Electron Diffraction Studies". Journal of Modern Optics. 2007. 54(7): 923-942. 40. N. de Jonge, F.M. Ross. "Electron Microscopy of Specimens in Liquid". Nature Nanotechnology. 2011. 6(11): 695-704. 41. J.M. Grogan, L. Rotkina, H.H. Bau. "In Situ Liquid-Cell Electron Microscopy of Colloid Aggregation and Growth Dynamics". Physical Review E. 2011. 83(6): 061405. 42. J.M. Grogan, H.H. Bau. "The Nanoaquarium: A Platform for in Situ Transmission Electron Microscopy in Liquid Media". J. Microelectromech. Syst. 2010. 19(4): 885-894. 43. D.B. Peckys, G.M. Veith, D.C. Joy, N. de Jonge. "Nanoscale Imaging of Whole Cells Using a Liquid Enclosure and a Scanning Transmission Electron Microscope". PLoS ONE. 2009. 4(12): e8214. 44. S. Schreck, G. Gavrila, C. Weniger, P. Wernet. "A Sample Holder for Soft X-Ray Absorption Spectroscopy of Liquids in Transmission Mode". Rev. Sci. Instrum. 2011. 82(10): 103101. 45. G. Gavrila, K. Godehusen, C. Weniger, E.T.J. Nibbering, et al. "Time-Resolved X-Ray Absorption Spectroscopy Of infrared-Laser-Induced Temperature Jumps in Liquid Water". Appl. Phys. A. 2009. 96(1): 11-18. 46. J.C. Whelan, B.I. Karawdeniya, Y.M.N.D.Y. Bandara, B.D. Velleco, et al. "Electroless Plating of Thin Gold Films Directly onto Silicon Nitride Thin Films and into Micropores". ACS Appl. Mater. Interfaces. 2014. 6(14): 10952-10957. 47. M. Gironès, Z. Borneman, R.G.H. Lammertink, M. Wessling. "The Role of Wetting on the Water Flux Performance of Microsieve Membranes". Journal of Membrane Science. 2005. 259(1–2): 55-64. 48. H. Huang, Z. Song, N. Wei, L. Shi, et al. "Ultrafast Viscous Water Flow through Nanostrand-Channelled Graphene Oxide Membranes". Nat Commun. 2013. 4: 2979. 49. G. Liu, W. Jin, N. Xu. "Graphene-Based Membranes". Chem. Soc. Rev. 2015. 44(15): 5016-5030. 50. D. Fine, A. Grattoni, R. Goodall, S.S. Bansal, et al. "Silicon Micro- and Nanofabrication for Medicine". Adv. Healthcare Mater. 2013. 2(5): 632-666. 51. M. Wirtz, S. Yu, C.R. Martin. "Template Synthesized Gold Nanotube Membranes for Chemical Separations and Sensing". Analyst. 2002. 127(7): 871-879. 52. R.B. Schoch, J. Han, P. Renaud. "Transport Phenomena in Nanofluidics". Reviews of Modern Physics. 2008. 80(3): 839-883. 53. N. Huse, H. Cho, K. Hong, L. Jamula, et al. "Femtosecond Soft X-Ray Spectroscopy of Solvated Transition-Metal Complexes: Deciphering the Interplay of Electronic and Structural Dynamics". J. Phys. Chem. Lett. 2011. 2(8): 880-884. 54. L.Å. Näslund, J. Lüning, Y. Ufuktepe, H. Ogasawara, et al. "X-Ray Absorption Spectroscopy Measurements of Liquid Water". J. Phys. Chem. B. 2005. 109(28): 13835-13839. 55. J. Meibohm, S. Schreck, P. Wernet. "Temperature Dependent Soft X-Ray Absorption Spectroscopy of Liquids". Rev. Sci. Instrum. 2014. 85(10): 1-7. 56. T. Tokushima, Y. Harada, Y. Horikawa, O. Takahashi, et al. "High Resolution X-Ray Emission Spectroscopy of Water and Its Assignment Based on Two Structural Motifs". J. Electron. Spectrosc. Relat. Phenom. 2010. 177(2–3): 192-205. 57. P. Wernet, G. Gavrila, K. Godehusen, C. Weniger, et al. "Ultrafast Temperature Jump in Liquid Water Studied by a Novel Infrared Pump-X-Ray Probe Technique". Appl. Phys. A. 2008. 92(3): 511-516. 58. N. Huse, H. Wen, D. Nordlund, E. Szilagyi, et al. "Probing the Hydrogen-Bond Network of Water Via Time-Resolved Soft X-Ray Spectroscopy". PCCP. 2009. 11(20): 3951-3957. 59. D. Branton, D.W. Deamer, A. Marziali, H. Bayley, et al. "The Potential and Challenges of Nanopore Sequencing". Nat. Biotechnol. 2008. 26(10): 1146-1153. 60. A.B. Dahlin. "Sensing Applications Based on Plasmonic Nanopores: The Hole Story". Analyst. 2015. 140(14): 4748-4759. 61. H. Im, N.J. Wittenberg, A. Lesuffleur, N.C. Lindquist, et al. "Membrane Protein Biosensing with Plasmonic Nanopore Arrays and Pore-Spanning Lipid Membranes". Chemical Science. 2010. 1(6): 688-696. 62. MEMS Materials and Processes Handbook. New York: Springer US, 2011. 63. V.M. Bermudez, F.K. Perkins. "Preparation and Properties of Clean Si3N4 Surfaces". Appl. Surf. Sci. 2004. 235(4): 406-419. 64. R. Stine, C.L. Cole, K.M. Ainslie, S.P. Mulvaney, et al. "Formation of Primary Amines on Silicon Nitride Surfaces: A Direct, Plasma-Based Pathway to Functionalization". Langmuir. 2007. 23(8): 4400-4404. 65. K.R. Williams, R.S. Muller. "Etch Rates for Micromachining Processing". J. Microelectromech. Syst. 1996. 5(4): 256-269. 66. F.H.P.M. Habraken, A.E.T. Kuiper. "Silicon Nitride and Oxynitride Films". Mater. Sci. Eng., R. 1994. 12(3): 123-175. 67. Rogue Valley Microdevices. "Low Stress LPCVD Nitride". 2015. https://roguevalleymicrodevices.com/wafer-services/lpcvd-nitride/low-stress-lpcvd-nitride/ [accessed September 10 2015]. 68. H. Seidel, L. Csepregi, A. Heuberger, H. Baumgartel. "Anisotropic Etching of Crystalline Silicon in Alkaline-Solutions .1. Orientation Dependence and Behavior of Passivation Layers". J. Electrochem. Soc. 1990. 137(11): 3612-3626. 69. J.M. Joshua, N.C. Robert, B.M. Kelly, S.D. Jon-Paul, et al. "Lift-Off of Large-Scale Ultrathin Nanomembranes". Journal of Micromechanics and Microengineering. 2015. 25(1): 015011. 70. M.J. Madou. Fundamentals of Microfabrication: The Science of Miniaturization. March 13, 2002 ed.: CRC Press, p. 752. 71. T. NanoFAB. "Koh Etching of Bulk Silicon". https://www.nanofab.ualberta.ca/wp- content/uploads/downloads/2016/07/KOH-Etching-Info-2013_V2.pdf [accessed March 15 2017]. 72. H. Seidel, L. Csepregi, A. Heuberger, H. Baumgartel. "Anisotropic Etching of Crystalline Silicon in Alkaline-Solutions .2. Influence of Dopants". J. Electrochem. Soc. 1990. 137(11): 3626-3632. 73. P. Temple-Boyer, C. Rossi, E. Saint-Etienne, E. Scheid. "Residual Stress in Low Pressure Chemical Vapor Deposition SiNx Films Deposited from Silane and Ammonia". J. Vac. Sci. Technol., A. 1998. 16(4): 2003-2007. 74. A. Kaushik, H. Kahn, A.H. Heuer. "Wafer-Level Mechanical Characterization of Silicon Nitride MEMS". J. Microelectromech. Syst. 2005. 14(2): 359-367. 75. W.D. Shi, H.X. Zhang, G.B. Zhang, Z.H. Li. "Modifying Residual Stress and Stress Gradient in LPCVD Si3N4 Film with Ion Implantation". Sens. Actuators, A. 2006. 130: 352-357. 76. J.G.E. Gardeniers, H.A.C. Tilmans, C.C.G. Visser. "LPCVD Silicon-Rich Silicon Nitride Films for Applications in Micromechanics, Studied with Statistical Experimental Design". J. Vac. Sci. Technol., A. 1996. 14(5): 2879-2892. 77. C. Mueller, M. Harb, J.R. Dwyer, R.J.D. Miller. "Nanofluidic Cells with Controlled Path Length and Liquid Flow for Rapid, High-Resolution in Situ Imaging with Electrons". J. Phys. Chem. Lett. 2013. 4(14): 2339-2347. 78. J. Gaspar, P. Ruther, O. Paul. "Mechanical Characterization of Thin-Film Composites Using the Load-Deflection Response of Multilayer Membranes - Elastic and Fracture Properties". Mater. Res. Soc. Symp. Proc. 2006. 977 79. J. Gaspar, M. Schmidt, J. Held, O. Paul. "Reliability of MEMS Materials: Mechanical Characterization of Thin-Films Using the Wafer Scale Bulge Test and Improved Microtensile Techniques". Mater. Res. Soc. Symp. Proc. 2007. 1052 80. A. Karimi, O.R. Shojaei, T. Kruml, J.L. Martin. "Characterisation of Tin Thin Films Using the Bulge Test and the Nanoindentation Technique". Thin Solid Films. 1997. 308: 334- 339. 81. B. Merle, M. Goken. "Fracture Toughness of Silicon Nitride Thin Films of Different Thicknesses as Measured by Bulge Tests". Acta Mater. 2011. 59(4): 1772-1779. 82. J.L. Yang, J. Gaspar, O. Paul. "Fracture Properties of LPCVD Silicon Nitride and Thermally Grown Silicon Oxide Thin Films from the Load-Deflection of Long Si3N4 and SiO2/Si3N4 Diaphragms". J. Microelectromech. Syst. 2008. 17(5): 1120-1134. 83. J.L. Yang, O. Paul. "Fracture Properties of LPCVD Silicon Nitride Thin Films from the Load-Deflection of Long Membranes". Sens. Actuators, A. 2002. 97-8: 520-526. 84. M.H. Zhao, Y. Xiang, J. Xu, N. Ogasawara, et al. "Determining Mechanical Properties of Thin Films from the Loading Curve of Nanoindentation Testing". Thin Solid Films. 2008. 516(21): 7571-7580. 85. M.G. Allen, M. Mehregany, R.T. Howe, S.D. Senturia. "Microfabricated Structures for the Insitu Measurement of Residual-Stress, Youngs Modulus, and Ultimate Strain of Thin- Films". Appl. Phys. Lett. 1987. 51(4): 241-243. 86. A. Khan, J. Philip, P. Hess. "Young's Modulus of Silicon Nitride Used in Scanning Force Microscope Cantilevers". J. Appl. Phys. 2004. 95(4): 1667-1672. 87. W.H. Chuang, T. Luger, R.K. Fettig, R. Ghodssi. "Mechanical Property Characterization of LPCVD Silicon Nitride Thin Films at Cryogenic Temperatures". J. Microelectromech. Syst. 2004. 13(5): 870-879. 88. J.A. Liddle, Huggins, H.A., Mulgrew, P., Harriott, L.R., Wade, H.H. and Bolan, K. "Fracture Strength of Thin Ceramic Membranes". Mater. Res. Soc. Symp. Proc. 1994. 338: 501. 89. M.E. Holtz, Y. Yu, J. Gao, H.D. Abruña, et al. "In Situ Electron Energy-Loss Spectroscopy in Liquids". Microsc. Microanal. 2013. 19(4): 1027-1035. 90. J.C. Whelan, B.I. Karawdeniya, Y.M.N.D.Y. Bandara, B.D. Velleco, et al. "Correction to Electroless Plating of Thin Gold Films Directly onto Silicon Nitride Thin Films and into Micropores". ACS Appl. Mater. Interfaces. 2015. 7(46): 26004-26004. 91. H.R. Philipp. "Optical Properties of Silicon Nitride". J. Electrochem. Soc. 1972. 120: 295-300. 92. J.P. Xanthakis, S. Papadopoulos, P.R. Mason. "The Electronic-Structure of Sinx - the Valence Band Dos and Band-Gaps". J. Phys. C: Solid State Phys. 1988. 21(16): L555-L560. 93. G.R. Fowles. Introduction to Modern Optics. New York: Dover Publication, 1989. 2nd ed. 94. D.P. Poenar, R.F. Wolffenbuttel. "Optical Properties of Thin-Film Silicon-Compatible Materials". Appl. Optics. 1997. 36(21): 5122-5128. 95. S.X. Tao, A.M.M.G. Theulings, V. Prodanovic, J. Smedley, et al. "Optical Properties of Silicon-Rich Silicon Nitride (Sixnyhz) from First Principles". Computation. 2015. 3(4): 657-669. 96. B.L. Henke, E.M. Gullikson, J.C. Davis. "X-Ray Interactions - Photoabsorption, Scattering, Transmission and Reflection at E=50-30,000 Ev, Z=1-92". At. Data Nucl. Data Tables. 1993. 55(2): 349-349. 97. P.T. Torma, H.J. Sipila, M. Mattila, P. Kostamo, et al. "Ultra-Thin Silicon Nitride X-Ray Windows". IEEE Trans. Nucl. Sci. 2013. 60(2): 1311-1314. 98. M.E. Riley, C.J. MacCallum, F. Biggs. "Theoretical Electron-Atom Elastic Scattering Cross Sections: Selected Elements, 1 Kev to 256 Kev". At. Data Nucl. Data Tables. 1975. 15(5): 443-476. 99. J.T. Huang, S.W. Zhang, Z.H. Huang, M.H. Fang, et al. "Co-Catalyzed Nitridation of Silicon and in-Situ Growth of Alpha-Si3N4 Nanorods". Ceram. Int. 2014. 40(7): 11063-11070. 100. M.M. Mkrtchyan, J.A. Liddle, A.E. Novembre, W.K. Waskiewicz, et al. "Electron Scattering and Transmission through Scalpel Masks". J. Vac. Sci. Technol., B. 1998. 16(6): 3385-3391. 101. S. Thiberge, O. Zik, E. Moses. "An Apparatus for Imaging Liquids, Cells, and Other Wet Samples in the Scanning Electron Microscopy". Rev. Sci. Instrum. 2004. 75(7): 2280-2289. 102. S.I. Raider, R. Flitsch, J.A. Aboaf, W.A. Pliskin. "Surface Oxidation of Silicon Nitride Films". J. Electrochem. Soc. 1976. 123(4): 560-565. 103. L. Bergström, R.J. Pugh. "Interfacial Characterization of Silicon Nitride Powders". J. Am. Ceram. Soc. 1989. 72(1): 103-109. 104. T.J. Senden, C.J. Drummond. "Surface Chemistry and Tip-Sample Interactions in Atomic Force Microscopy". Colloids and Surfaces A: Physicochemical and Engineering Aspects. 1995. 94(1): 29-51. 105. A. Arafat, K. Schroën, L.C.P.M. de Smet, E.J.R. Sudhölter, et al. "Tailor-Made Functionalization of Silicon Nitride Surfaces". J. Am. Chem. Soc. 2004. 126(28): 8600-8601. 106. A. Arafat, M. Giesbers, M. Rosso, E.J.R. Sudhölter, et al. "Covalent Biofunctionalization of Silicon Nitride Surfaces". Langmuir. 2007. 23(11): 6233-6244. 107. R.P. Vasquez, M.H. Hecht, F.J. Grunthaner, M.L. Naiman. "X‐Ray Photoelectron Spectroscopy Study of the Chemical Structure of Thermally Nitrided SiO2". Appl. Phys. Lett. 1984. 44(10): 969-971. 108. H. Du, R.E. Tressler, K.E. Spear, C.G. Pantano. "Oxidation Studies of Crystalline Cvd Silicon Nitride". J. Electrochem. Soc. 1989. 136(5): 1527-1536. 109. L. Bergström, E. Bostedt. "Surface Chemistry of Silicon Nitride Powders: Electrokinetic Behaviour and Esca Studies". Colloids and Surfaces. 1990. 49: 183-197. 110. W. van Gelder, V.E. Hauser. "The Etching of Silicon Nitride in Phosphoric Acid with Silicon Dioxide as a Mask". J. Electrochem. Soc. 1967. 114(8): 869-872. 111. M. Firnkes, D. Pedone, J. Knezevic, M. Döblinger, et al. "Electrically Facilitated Translocations of Proteins through Silicon Nitride Nanopores: Conjoint and Competitive Action of Diffusion, Electrophoresis, and Electroosmosis". Nano Lett. 2010. 6(8): 895-909. 112. S.H. Behrens, D.G. Grier. "The Charge of Glass and Silica Surfaces". J. Chem. Phys. 2001. 115(14): 6716-6721. 113. C.M. Frament, J.R. Dwyer. "Conductance-Based Determination of Solid-State Nanopore Size and Shape: An Exploration of Performance Limits". J. Phys. Chem. C. 2012. 116(44): 23315-23321. 114. D. Gilmore, W.Z. Cai, D. Iyer, R. Burgin, et al. "Reoxidation of Silicon Nitride Studied Using X-Ray Photoelectron Spectroscopy and Transmission Electron Microscopy". J. Appl. Phys. 2004. 95(1): 367-372. 115. K. Okada, K. Fukuyama, Y. Kameshima. "Characterization of Surface-Oxidized Phase in Silicon Nitride and Silicon Oxynitride Powders by X-Ray Photoelectron Spectroscopy". J. Am. Ceram. Soc. 1995. 78(8): 2021-2026. 116. V.A. Hackley, W. Pu Sen, S.G. Malghan. "Effects of Soxhlet Extraction on the Surface Oxide Layer of Silicon Nitride Powders". Mater. Chem. Phys. 1993. 36(1): 112-118. 117. M. Rosso, A.T. Nguyen, E. de Jong, J. Baggerman, et al. "Protein-Repellent Silicon Nitride Surfaces: UV-Induced Formation of Oligoethylene Oxide Monolayers". ACS Appl. Mater. Interfaces. 2011. 3(3): 697-704. 118. D. Martin Knotter, T.J.J. Denteneer "Etching Mechanism of Silicon Nitride in Hf-Based Solutions". J. Electrochem. Soc. 2001. 148(3): F43-F46. 119. V.M. Bermudez. "Wet-Chemical Treatment of Si3N4 Surfaces Studied Using Infrared Attenuated Total Reflection Spectroscopy". J. Electrochem. Soc. 2005. 152(2): F31-F36. 120. M. Rosso, M. Giesbers, A. Arafat, K. Schroën, et al. "Covalently Attached Organic Monolayers on SiC and SixN4 Surfaces: Formation Using UV Light at Room Temperature". Langmuir. 2009. 25(4): 2172-2180. 121. A.T. Nguyen, J. Baggerman, J.M.J. Paulusse, C.J.M. van Rijn, et al. "Stable Protein- Repellent Zwitterionic Polymer Brushes Grafted from Silicon Nitride". Langmuir. 2011. 27(6): 2587-2594. 122. G.P. Kennedy, O. Buiu, S. Taylor. "Oxidation of Silicon Nitride Films in an Oxygen Plasma". J. Appl. Phys. 1999. 85(6): 3319-3326. 123. M. Cerruti, S. Fissolo, C. Carraro, C. Ricciardi, et al. "Poly(Ethylene Glycol) Monolayer Formation and Stability on Gold and Silicon Nitride Substrates". Langmuir. 2008. 24(19): 10646-10653. 124. A. Ebner, L. Wildling, R. Zhu, C. Rankl, et al. "Functionalization of Probe Tips and Supports for Single-Molecule Recognition Force Microscopy". In: P. Samorì, editors. Stm and AFM Studies on (Bio)Molecular Systems: Unravelling the Nanoworld. Springer Berlin Heidelberg, 2008. pp.29-76. 125. A. Holtzman, S. Richter. "Electroless Plating of Silicon Nitride Using (3-Aminopropyl) Triethoxysilane". J. Electrochem. Soc. 2008. 155(3): D196-D202. 126. R.L. Alley, K. Komvopoulos, R.T. Howe. "Self‐Assembled Monolayer Film for Enhanced Imaging of Rough Surfaces with Atomic Force Microscopy". J. Appl. Phys. 1994. 76(10): 5731-5737. 127. S. Diegoli, P.M. Mendes, E.R. Baguley, S.J. Leigh, et al. "Ph-Dependent Gold Nanoparticle Self-Organization on Functionalized Si/SiO2 Surfaces". Journal of Experimental Nanoscience. 2006. 1(3): 333-353. 128. J.M. Buriak. "Organometallic Chemistry on Silicon and Germanium Surfaces". Chem. Rev. 2002. 102(5): 1271-1308. 129. Y.M.N.D.Y. Bandara, B.I. Karawdeniya, J.C. Whelan, L.D.S. Ginsberg, et al. "Solution- Based Photo-Patterned Gold Film Formation on Silicon Nitride". ACS Appl. Mater. Interfaces. 2016. 8(51): 34964-34969. 130. L. Li-Hong, J.M. David, P.C. Tatiana, P.P. Sidharam, et al. "Surface Etching, Chemical Modification and Characterization of Silicon Nitride and Silicon Oxide—Selective Functionalization of Si3N4 and SiO2". J. Phys.: Condens. Matter. 2016. 28(9): 094014. 131. E.A. Stach. "Real-Time Observations with Electron Microscopy". Mater. Today. 2008. 11, Supplement: 50-58. 132. P. Baum. "Laser-Driven Nanoparticle Motion in Liquids". Science. 2017. 355(6324): 458-459. 133. M.L. Taheri, E.A. Stach, I. Arslan, P.A. Crozier, et al. "Current Status and Future Directions for in Situ Transmission Electron Microscopy". Ultramicroscopy. 2016. 170: 86-95. 134. R. Henderson. "The Potential and Limitations of Neutrons, Electrons and X-Rays for Atomic Resolution Microscopy of Unstained Biological Molecules". Quarterly Reviews of Biophysics. 1995. 28(02): 171-193. 135. B.J. Siwick, J.R. Dwyer, R.E. Jordan, R.J.D. Miller. "An Atomic-Level View of Melting Using Femtosecond Electron Diffraction". Science. 2003. 302(5649): 1382-1385. 136. J.J. Benítez, A.M. Keller, P. Chen. "Chapter 4 - Nanovesicle Trapping for Studying Weak Protein Interactions by Single-Molecule Fret". In: G.W. Nils, editors. Methods Enzymol.: Academic Press, 2010. pp.41-60. 137. A. Dudia, A. Koçer, V. Subramaniam, J.S. Kanger. "Biofunctionalized Lipid−Polymer Hybrid Nanocontainers with Controlled Permeability". Nano Lett. 2008. 8(4): 1105-1110. 138. B. Okumus, S. Arslan, S.M. Fengler, S. Myong, et al. "Single Molecule Nanocontainers Made Porous Using a Bacterial Toxin". J. Am. Chem. Soc. 2009. 131(41): 14844-14849. 139. O. Kel, A. Tamimi, M.D. Fayer. "Size-Dependent Ultrafast Structural Dynamics inside Phospholipid Vesicle Bilayers Measured with 2d Ir Vibrational Echoes". Proceedings of the National Academy of Sciences. 2014. 111(3): 918-923. 140. J.C. Scaiano, H. García. "Intrazeolite Photochemistry: Toward Supramolecular Control of Molecular Photochemistry". Acc. Chem. Res. 1999. 32(9): 783-793. 141. M. Ekimova, W. Quevedo, M. Faubel, P. Wernet, et al. "A Liquid Flatjet System for Solution Phase Soft-X-Ray Spectroscopy". Structural Dynamics. 2015. 2(5): 054301. 142. Y. Chen, A. Pépin. "Nanofabrication: Conventional and Nonconventional Methods". ELECTROPHORESIS. 2001. 22(2): 187-207. 143. G.-Z. Zhu, S. Prabhudev, J. Yang, C.M. Gabardo, et al. "In Situ Liquid Cell TEM Study of Morphological Evolution and Degradation of Pt–Fe Nanocatalysts During Potential Cycling". J. Phys. Chem. C. 2014. 118(38): 22111-22119. 144. C. Duan, W. Wang, Q. Xie. "Review Article: Fabrication of Nanofluidic Devices". Biomicrofluidics. 2013. 7(2): 026501-026541. 145. D. Kraemer, M.L. Cowan, A. Paarmann, N. Huse, et al. "Temperature Dependence of the Two-Dimensional Infrared Spectrum of Liquid H2o". Proceedings of the National Academy of Sciences. 2008. 105(2): 437-442. 146. K.L. Klein, I.M. Anderson, N. De Jonge. "Transmission Electron Microscopy with a Liquid Flow Cell". Journal of Microscopy. 2011. 242(2): 117-123. 147. E.A. Ring, N. de Jonge. "Microfluidic System for Transmission Electron Microscopy". Microsc. Microanal. 2010. 16(05): 622-629. 148. I.M. Abrams, J.W. McBain. "A Closed Cell for Electron Microscopy". J. Appl. Phys. 1944. 15(8): 607-609. 149. P. Gai. "Developments in in Situ Environmental Cell High-Resolution Electron Microscopy and Applications to Catalysis". Top. Catal. 2002. 21(4): 161-173. 150. K. Nishijima, J. Yamasaki, H. Orihara, N. Tanaka. "Development of Microcapsules for Electron Microscopy and Their Application to Dynamical Observation of Liquid Crystals in Transmission Electron Microscopy". Nanotechnology. 2004. 15(6): S329. 151. K. Fukushima, A. Ishikawa, A. Fukami. "Injection of Liquid into Environmental Cell for in Situ Observations". J. Electron Microsc. 1985. 34(1): 47-51. 152. F. Nagata, I. Ishikawa. "Observation of Wet Biological Materials in a High Voltage Electron Microscope". Japanese Journal of Applied Physics. 1972. 11(9): 1239-1244. 153. D.D. Double, A. Hellawell, S.J. Perry. "The Hydration of Portland Cement". Proceedings of the Royal Society of London. A. Mathematical and Physical Sciences. 1978. 359(1699): 435- 451. 154. D.F. Parsons. "Structure of Wet Specimens in Electron Microscopy". Science. 1974. 186(4162): 407-414. 155. D.J. Stokes. "Recent Advances in Electron Imaging, Image Interpretation and Applications: Environmental Scanning Electron Microscopy". Philosophical Transactions of the Royal Society of London. Series A: Mathematical, Physical and Engineering Sciences. 2003. 361(1813): 2771-2787. 156. V.R. Matricardi, R.C. Moretz, D.F. Parsons. "Electron Diffraction of Wet Proteins: Catalase". Science. 1972. 177(4045): 268-270. 157. I.M. ABRAMS, J.W. MCBAIN. "A Closed Cell for Electron Microscopy". Science. 1944. 100(2595): 273-274. 158. N. de Jonge. "Introduction to Special Issue on Electron Microscopy of Specimens in Liquid". Microsc. Microanal. 2014. 20(2): 315-316. 159. H.-G. Liao, H. Zheng. "Liquid Cell Transmission Electron Microscopy". Annu. Rev. Phys. Chem. 2016. 67(1): 719-747. 160. N. Luo, Y. Lv, D. Wang, J. Zhang, et al. "Direct Visualization of Solution Morphology of Cellulose in Ionic Liquids by Conventional TEM at Room Temperature". Chem. Commun. 2012. 48(50): 6283-6285. 161. J.Y. Huang, L. Zhong, C.M. Wang, J.P. Sullivan, et al. "In Situ Observation of the Electrochemical Lithiation of a Single Sno2 Nanowire Electrode". Science. 2010. 330(6010): 1515-1520. 162. C.M. Wang, W. Xu, J. Liu, D.W. Choi, et al. "In Situ Transmission Electron Microscopy and Spectroscopy Studies of Interfaces in Li Ion Batteries: Challenges and Opportunities". J. Mater. Res. 2010. 25(08): 1541-1547. 163. P. Roy, R. Lynch, P. Schmuki. "Electron Beam Induced in-Vacuo Ag Deposition on Tio2 from Ionic Liquids". Electrochem. Commun. 2009. 11(8): 1567-1570. 164. S. Kuwabata, A. Kongkanand, D. Oyamatsu, T. Torimoto. "Observation of Ionic Liquid by Scanning Electron Microscope". Chem. Lett. 2006. 35(6): 600-601. 165. P.L. Gai. "Development of Wet Environmental TEM (Wet-Etem) for in Situ Studies of Liquid-Catalyst Reactions on the Nanoscale". Microsc. Microanal. 2002. 8(1): 21-28. 166. H. Zheng, S.A. Claridge, A.M. Minor, A.P. Alivisatos, et al. "Nanocrystal Diffusion in a Liquid Thin Film Observed by in Situ Transmission Electron Microscopy". Nano Lett. 2009. 9(6): 2460-2465. 167. H. Zheng, R.K. Smith, Y.-w. Jun, C. Kisielowski, et al. "Observation of Single Colloidal Platinum Nanocrystal Growth Trajectories". Science. 2009. 324(5932): 1309-1312. 168. K.L. Jungjohann, S. Bliznakov, P.W. Sutter, E.A. Stach, et al. "In Situ Liquid Cell Electron Microscopy of the Solution Growth of Au–Pd Core–Shell Nanostructures". Nano Lett. 2013. 13(6): 2964-2970. 169. J.E. Evans, K.L. Jungjohann, N.D. Browning, I. Arslan. "Controlled Growth of Nanoparticles from Solution with in Situ Liquid Transmission Electron Microscopy". Nano Lett. 2011. 11(7): 2809-2813. 170. R. Ramachandra, H. Demers, N. de Jonge. "Atomic-Resolution Scanning Transmission Electron Microscopy through 50-nm-Thick Silicon Nitride Membranes". Appl. Phys. Lett. 2011. 98(9): -. 171. N. de Jonge, W.C. Bigelow, G.M. Veith. "Atmospheric Pressure Scanning Transmission Electron Microscopy". Nano Lett. 2010. 10(3): 1028-1031. 172. H. Nishiyama, M. Suga, T. Ogura, Y. Maruyama, et al. "Atmospheric Scanning Electron Microscope Observes Cells and Tissues in Open Medium through Silicon Nitride Film". Journal of Structural Biology. 2010. 169(3): 438-449. 173. L. Yang, Z. Zhu, X.-Y. Yu, E. Rodek, et al. "In Situ SEM and Tof-Sims Analysis of Igg Conjugated Gold Nanoparticles at Aqueous Surfaces". Surf. Interface Anal. 2014. 46(4): 224- 228. 174. I. Barshack, J. Kopolovic, Y. Chowers, O. Gileadi, et al. "A Novel Method for "Wet" SEM". Ultrastructural Pathology. 2004. 28(1): 29-31. 175. S. Thiberge, A. Nechushtan, D. Sprinzak, O. Gileadi, et al. "Scanning Electron Microscopy of Cells and Tissues under Fully Hydrated Conditions". Proceedings of the National Academy of Sciences of the United States of America. 2004. 101(10): 3346-3351. 176. C. Mueller, M. Harb, J.R. Dwyer, R.J.D. Miller. "Acs Liveslides: Nanofluidic Cells with Controlled Pathlength and Liquid Flow for Rapid, High-Resolution in Situ Imaging with Electrons". 2013. http://pubs.acs.org/iapps/liveslides/pages/index.htm?mscNo=jz401067k. 177. J.M. Miller, D. Hein Alsem, N. Salmon, N.E. Johnson, et al. "Functionalized Surfaces to Improve Imaging Conditions in Liquid Cell Transmission Electron Microscopy". Microsc. Microanal. 2014. 20(S3): 1140-1141. 178. M.W.P. van de Put, C.C.M.C. Carcouët, P.H.H. Bomans, H. Friedrich, et al. "Writing Silica Structures in Liquid with Scanning Transmission Electron Microscopy". Small. 2014. n/a- n/a. 179. J.M. Yuk, J. Park, P. Ercius, K. Kim, et al. "High-Resolution Em of Colloidal Nanocrystal Growth Using Graphene Liquid Cells". Science. 2012. 336(6077): 61-64. 180. K. Degen, M. Dukes, J.R. Tanner, D.F. Kelly. "The Development of Affinity Capture Devices-a Nanoscale Purification Platform for Biological in Situ Transmission Electron Microscopy". RSC Advances. 2012. 2(6): 2408-2412. 181. S. Keskin, S. Besztejan, G. Kassier, S. Manz, et al. "Visualization of Multimerization and Self-Assembly of DNA-Functionalized Gold Nanoparticles Using in-Liquid Transmission Electron Microscopy". J. Phys. Chem. Lett. 2015. 6(22): 4487-4492. 182. H.-G. Liao, L. Cui, S. Whitelam, H. Zheng. "Real-Time Imaging of Pt3fe Nanorod Growth in Solution". Science. 2012. 336(6084): 1011-1014. 183. X. Ye, M.R. Jones, L.B. Frechette, Q. Chen, et al. "Single-Particle Mapping of Nonequilibrium Nanocrystal Transformations". Science. 2016. 354(6314): 874-877. 184. M.J. Dukes, B.W. Jacobs, D.G. Morgan, H. Hegde, et al. "Visualizing Nanoparticle Mobility in Liquid at Atomic Resolution". Chem. Commun. 2013. 49(29): 3007-3009. 185. J.P. Patterson, P. Abellan, M.S. Denny, C. Park, et al. "Observing the Growth of Metal– Organic Frameworks by in Situ Liquid Cell Transmission Electron Microscopy". J. Am. Chem. Soc. 2015. 137(23): 7322-7328. 186. W.W. Molzen, A.N. Broers, J.J. Cuomo, J.M.E. Harper, et al. "Materials and Techniques Used in Nanostructure Fabrication". J. Vac.Sci. Technol. 1979. 16(2): 269-272. 187. Dune Sciences. "Biogrids™ for Life Science". 2014. http://www.dunesciences.com/ [accessed October 9 2014]. 188. K.-L. Liu, C.-C. Wu, Y.-J. Huang, H.-L. Peng, et al. "Novel Microchip for in Situ TEM Imaging of Living Organisms and Bio-Reactions in Aqueous Conditions". Lab on a Chip. 2008. 8(11): 1915-1921. 189. D. Rhinow, J. Vonck, M. Schranz, A. Beyer, et al. "Ultrathin Conductive Carbon Nanomembranes as Support Films for Structural Analysis of Biological Specimens". PCCP. 2010. 12(17): 4345-4350. 190. A. Turchanin, A. Gölzhäuser. "Carbon Nanomembranes". Adv. Mater. 2016. 28(29): 6075-6103. 191. C. Wang, Q. Qiao, T. Shokuhfar, R.F. Klie. "High-Resolution Electron Microscopy and Spectroscopy of Ferritin in Biocompatible Graphene Liquid Cells and Graphene Sandwiches". Adv. Mater. 2014. 26(21): 3410-3414. 192. N. Mohanty, M. Fahrenholtz, A. Nagaraja, D. Boyle, et al. "Impermeable Graphenic Encasement of Bacteria". Nano Lett. 2011. 11(3): 1270-1275. 193. F. Tao, M. Salmeron. "In Situ Studies of Chemistry and Structure of Materials in Reactive Environments". Science. 2011. 331(6014): 171-174. 194. M.E. Grass, P.G. Karlsson, F. Aksoy, M. Lundqvist, et al. "New Ambient Pressure Photoemission Endstation at Advanced Light Source Beamline 9.3.2". Rev. Sci. Instrum. 2010. 81(5): 053106. 195. F. Tao. "Design of an in-House Ambient Pressure Ap-XPS Using a Bench-Top X-Ray Source and the Surface Chemistry of Ceria under Reaction Conditions". Chem. Commun. 2012. 48(32): 3812-3814. 196. M. Salmeron, R. Schlögl. "Ambient Pressure Photoelectron Spectroscopy: A New Tool for Surface Science and Nanotechnology". Surf. Sci. Rep. 2008. 63(4): 169-199. 197. L. Yang, X.-Y. Yu, Z. Zhu, T. Thevuthasan, et al. "Making a Hybrid Microfluidic Platform Compatible for in Situ Imaging by Vacuum-Based Techniques". Journal of Vacuum Science & Technology A: Vacuum, Surfaces, and Films. 2011. 29(6): 061101. 198. Z. Wang, Y. Zhang, B. Liu, K. Wu, et al. "In Situ Mass Spectrometric Monitoring of the Dynamic Electrochemical Process at the Electrode–Electrolyte Interface: A Sims Approach". Anal. Chem. 2017. 89(1): 960-965. 199. X. Hua, C. Szymanski, Z. Wang, Y. Zhou, et al. "Chemical Imaging of Molecular Changes in a Hydrated Single Cell by Dynamic Secondary Ion Mass Spectrometry and Super- Resolution Microscopy". Integrative Biology. 2016. 8(5): 635-644. 200. H. Shi, J.A. Lercher, X.-Y. Yu. "Sailing into Uncharted Waters: Recent Advances in the in Situ Monitoring of Catalytic Processes in Aqueous Environments". Catalysis Science & Technology. 2015. 5(6): 3035-3060. 201. M.J. Dukes, R. Thomas, J. Damiano, K.L. Klein, et al. "Improved Microchip Design and Application for in Situ Transmission Electron Microscopy of Macromolecules". Microsc. Microanal. 2014. 20(2): 338-345. 202. N. de Jonge, N. Poirier-Demers, H. Demers, D.B. Peckys, et al. "Nanometer-Resolution Electron Microscopy through Micrometers-Thick Water Layers". Ultramicroscopy. 2010. 110(9): 1114-1119. 203. H. Demers, N. Poirier-Demers, D. Drouin, N. de Jonge. "Simulating Stem Imaging of Nanoparticles in Micrometers-Thick Substrates". Microsc. Microanal. 2010. 16(06): 795-804. 204. N.d. Jonge, D.B. Peckys, G.J. Kremers, D.W. Piston. "Electron Microscopy of Whole Cells in Liquid with Nanometer Resolution". Proceedings of the National Academy of Sciences. 2009. 106(7): 2159-2164. 205. F.M. Ross. "Electrochemical Nucleation, Growth and Dendrite Formation in Liquid Cell TEM". Microsc. Microanal. 2010. 16(S2): 326-327. 206. J.P. Langmore, M.F. Smith. "Quantitative Energy-Filtered Electron Microscopy of Biological Molecules in Ice". Ultramicroscopy. 1992. 46(1–4): 349-373. 207. T.L. Daulton, B.J. Little, K. Lowe, J. Jones-Meehan. "In Situ Environmental Cell– Transmission Electron Microscopy Study of Microbial Reduction of Chromium(Vi) Using Electron Energy Loss Spectroscopy". Microsc. Microanal. 2001. 7(06): 470-485. 208. T.L. Daulton, B.J. Little, K. Lowe, J. Jones-Meehan. "Electron Energy Loss Spectroscopy Techniques for the Study of Microbial Chromium(Vi) Reduction". J. Microbiol. Methods. 2002. 50(1): 39-54. 209. O.L. Krivanek, T.C. Lovejoy, N. Dellby, T. Aoki, et al. "Vibrational Spectroscopy in the Electron Microscope". Nature. 2014. 514(7521): 209-212. 210. N.J. Zaluzec, M.G. Burke, S.J. Haigh, M.A. Kulzick. "X-Ray Energy-Dispersive Spectrometry During in Situ Liquid Cell Studies Using an Analytical Electron Microscope". Microsc. Microanal. 2014. 20(2): 323-329. 211. A.E.P. Schibel, E.N. Ervin. "Decreasing the Limits of Detection and Analysis Time of Ion Current Rectification Biosensing Measurements Via a Mechanically Applied Pressure Differential". Anal. Chem. 2015. 87(13): 6646-6653. 212. W.-J. Lan, H.S. White. "Diffusional Motion of a Particle Translocating through a Nanopore". ACS Nano. 2012. 6(2): 1757-1765. 213. B. Lu, D.P. Hoogerheide, Q. Zhao, H. Zhang, et al. "Pressure-Controlled Motion of Single Polymers through Solid-State Nanopores". Nano Lett. 2013. 13(7): 3048-3052. 214. D.P. Hoogerheide, B. Lu, J.A. Golovchenko. "Pressure–Voltage Trap for DNA near a Solid-State Nanopore". ACS Nano. 2014. 8(7): 7384-7391. 215. Y. He, M. Tsutsui, Ralph H. Scheicher, C. Fan, et al. "Mechanism of How Salt-Gradient- Induced Charges Affect the Translocation of DNA Molecules through a Nanopore". Biophys. J. 2013. 105(3): 776-782. 216. M. Wanunu, W. Morrison, Y. Rabin, A.Y. Grosberg, et al. "Electrostatic Focusing of Unlabelled DNA into Nanoscale Pores Using a Salt Gradient". Nat Nano. 2010. 5(2): 160-165. 217. Y.M.N.D.Y. Bandara, B.I. Karawdeniya, J.R. Dwyer. "Real-Time Profiling of Solid-State Nanopores During Solution-Phase Nanofabrication". ACS Appl. Mater. Interfaces. 2016. 8(44): 30583-30589. 218. C.M. Frament, N. Bandara, J.R. Dwyer. "Nanopore Surface Coating Delivers Nanopore Size and Shape through Conductance-Based Sizing". ACS Appl. Mater. Interfaces. 2013. 5(19): 9330-9337. 219. Y. Liebes, M. Drozdov, Y.Y. Avital, Y. Kauffmann, et al. "Reconstructing Solid State Nanopore Shape from Electrical Measurements". Appl. Phys. Lett. 2010. 97(22): 223105. 220. S.W. Kowalczyk, A.Y. Grosberg, Y. Rabin, C. Dekker. "Modeling the Conductance and DNA Blockade of Solid-State Nanopores". Nanotechnology. 2011. 22(31): 315101. 221. R.M.M. Smeets, U.F. Keyser, D. Krapf, M.-Y. Wu, et al. "Salt Dependence of Ion Transport and DNA Translocation through Solid-State Nanopores". Nano Lett. 2006. 6(1): 89- 95. 222. H. Bayley, C.R. Martin. "Resistive-Pulse Sensing-from Microbes to Molecules". Chem. Rev. 2000. 100(7): 2575-2594. 223. A. Aksimentiev. "Deciphering Ionic Current Signatures of DNA Transport through a Nanopore". Nanoscale. 2010. 2(4): 468-483. 224. P.S. Spinney, D.G. Howitt, R.L. Smith, S.D. Collins. "Nanopore Formation by Low- Energy Focused Electron Beam Machining". Nanotechnology. 2010. 21(37): 375301. 225. D.G. Howitt, S.J. Chen, B.C. Gierhart, R.L. Smith, et al. "The Electron Beam Hole Drilling of Silicon Nitride Thin Films". J. Appl. Phys. 2008. 103(2): 024310. 226. K. Healy, B. Schiedt, A.P. Morrison. "Solid-State Nanopore Technologies for Nanopore- Based DNA Analysis". Nanomedicine. 2007. 2(6): 875-897. 227. A. Kocer, L. Tauk, P. Déjardin. "Nanopore Sensors: From Hybrid to Abiotic Systems". Biosens. Bioelectron. 2012. 38(1): 1-10. 228. J. Yang, D.C. Ferranti, L.A. Stern, C.A. Sanford, et al. "Rapid and Precise Scanning Helium Ion Microscope Milling of Solid-State Nanopores for Biomolecule Detection". Nanotechnology. 2011. 22(28): 285310. 229. A.J. Storm, J.H. Chen, X.S. Ling, H.W. Zandbergen, et al. "Fabrication of Solid-State Nanopores with Single-Nanometre Precision". Nature Materials. 2003. 2(8): 537-540. 230. T. Ruby dela, L. Joseph, S. Alon, M. Amit. "Fabrication and Characterization of Solid- State Nanopore Arrays for High-Throughput DNA Sequencing". Nanotechnology. 2012. 23(38): 385308. 231. J. Li, D. Stein, C. McMullan, D. Branton, et al. "Ion-Beam Sculpting at Nanometre Length Scales". Nature. 2001. 412(6843): 166-169. 232. I. Vlassiouk, P.Y. Apel, S.N. Dmitriev, K. Healy, et al. "Versatile Ultrathin Nanoporous Silicon Nitride Membranes". Proceedings of the National Academy of Sciences of the United States of America. 2009. 106(50): 21039-21044. 233. S.-W. Nam, M.J. Rooks, K.-B. Kim, S.M. Rossnagel. "Ionic Field Effect Transistors with Sub-10 nm Multiple Nanopores". Nano Lett. 2009. 9(5): 2044-2048. 234. P. Chen, T. Mitsui, D.B. Farmer, J. Golovchenko, et al. "Atomic Layer Deposition to Fine-Tune the Surface Properties and Diameters of Fabricated Nanopores". Nano Lett. 2004. 4(7): 1333-1337. 235. H. Kwok, K. Briggs, V. Tabard-Cossa. "Nanopore Fabrication by Controlled Dielectric Breakdown". PLoS ONE. 2014. 9(3): e92880. 236. K. Briggs, H. Kwok, V. Tabard-Cossa. "Automated Fabrication of 2-nm Solid-State Nanopores for Nucleic Acid Analysis". Small. 2014. 10(10): 2077-2086. 237. I. Yanagi, R. Akahori, T. Hatano, K.-i. Takeda. "Fabricating Nanopores with Diameters of Sub-1 nm to 3 nm Using Multilevel Pulse-Voltage Injection". Sci. Rep. 2014. 4 238. M.-Y. Wu, R.M.M. Smeets, M. Zandbergen, U. Ziese, et al. "Control of Shape and Material Composition of Solid-State Nanopores". Nano Lett. 2009. 9(1): 479-484. 239. B.M. Venkatesan, B. Dorvel, S. Yemenicioglu, N. Watkins, et al. "Highly Sensitive, Mechanically Stable Nanopore Sensors for DNA Analysis". Adv. Mater. 2009. 21(27): 2771- 2776. 240. M.J. Kim, B. McNally, K. Murata, A. Meller. "Characteristics of Solid-State Nanometre Pores Fabricated Using a Transmission Electron Microscope". Nanotechnology. 2007. 18(20) 241. M. van den Hout, A.R. Hall, M.Y. Wu, H.W. Zandbergen, et al. "Controlling Nanopore Size, Shape and Stability". Nanotechnology. 2010. 21(11): 115304. 242. K. Liu, J. Feng, A. Kis, A. Radenovic. "Atomically Thin Molybdenum Disulfide Nanopores with High Sensitivity for DNA Translocation". ACS Nano. 2014. 8(3): 2504-2511. 243. A.T. Kuan, B. Lu, P. Xie, T. Szalay, et al. "Electrical Pulse Fabrication of Graphene Nanopores in Electrolyte Solution". Appl. Phys. Lett. 2015. 106(20): 203109. 244. S. Banerjee, J. Shim, J. Rivera, X. Jin, et al. "Electrochemistry at the Edge of a Single Graphene Layer in a Nanopore". ACS Nano. 2013. 7(1): 834-843. 245. A. Morin, D. Lucot, A. Ouerghi, G. Patriarche, et al. "Fib Carving of Nanopores into Suspended Graphene Films". Microelectron. Eng. 2012. 97(0): 311-316. 246. C.A. Merchant, K. Healy, M. Wanunu, V. Ray, et al. "DNA Translocation through Graphene Nanopores". Nano Lett. 2010. 10(8): 2915-2921. 247. G.g.F. Schneider, S.W. Kowalczyk, V.E. Calado, G.g. Pandraud, et al. "DNA Translocation through Graphene Nanopores". Nano Lett. 2010. 10(8): 3163-3167. 248. S.J. Heerema, C. Dekker. "Graphene Nanodevices for DNA Sequencing". Nat Nano. 2016. 11(2): 127-136. 249. R. Ritter, R.A. Wilhelm, M. Stoger-Pollach, R. Heller, et al. "Fabrication of Nanopores in 1 nm Thick Carbon Nanomembranes with Slow Highly Charged Ions". Appl. Phys. Lett. 2013. 102(6): 063112-063115. 250. L. Ma, S.L. Cockroft. "Biological Nanopores for Single-Molecule Biophysics". ChemBioChem. 2010. 11(1): 25-34. 251. J.J. Kasianowicz, S.E. Henrickson, H.H. Weetall, B. Robertson. "Simultaneous Multianalyte Detection with a Nanometer-Scale Pore". Anal. Chem. 2001. 73(10): 2268-2272. 252. V. Tabard-Cossa, M. Wiggin, D. Trivedi, N.N. Jetha, et al. "Single-Molecule Bonds Characterized by Solid-State Nanopore Force Spectroscopy". ACS Nano. 2009. 3(10): 3009- 3014. 253. B. Hornblower, A. Coombs, R.D. Whitaker, A. Kolomeisky, et al. "Single-Molecule Analysis of DNA-Protein Complexes Using Nanopores". Nature Methods. 2007. 4(4): 315-317. 254. L.-Q. Gu, S. Cheley, H. Bayley. "Capture of a Single Molecule in a Nanocavity". Science. 2001. 291(5504): 636-640. 255. Y. Liu, S.M. Iqbal. "A Mesoscale Model of DNA Interaction with Functionalized Nanopore". Appl. Phys. Lett. 2009. 95(22): 223701-223703. 256. M. Wiggin, C. Tropini, V. Tabard-Cossa, N.N. Jetha, et al. "Nonexponential Kinetics of DNA Escape from Alpha-Hemolysin Nanopores". Biophys. J. 2008. 95(11): 5317-5323. 257. C. Ma, E.S. Yeung. "Single Molecule Imaging of Protein Molecules in Nanopores". Anal. Chem. 2010. 82(2): 478-482. 258. U.F. Keyser, S. van Dorp, S.G. Lemay. "Tether Forces in DNA Electrophoresis". Chem. Soc. Rev. 2010. 39(3): 939-947. 259. Z.S. Siwy, S. Howorka. "Engineered Voltage-Responsive Nanopores". Chem. Soc. Rev. 2010. 39(3): 1115-1132. 260. J. Nakane, M. Wiggin, A. Marziali. "A Nanosensor for Transmembrane Capture and Identification of Single Nucleic Acid Molecules". Biophys. J. 2004. 87(1): 615-621. 261. C. Tropini, A. Marziali. "Multi-Nanopore Force Spectroscopy for DNA Analysis". Biophys. J. 2007. 92(5): 1632-1637. 262. B. McNally, M. Wanunu, A. Meller. "Electromechanical Unzipping of Individual DNA Molecules Using Synthetic Sub-2 nm Pores". Nano Lett. 2008. 8(10): 3418-3422. 263. W. Guo, H.W. Xia, F. Xia, X. Hou, et al. "Current Rectification in Temperature- Responsive Single Nanopores". Chemphyschem. 2010. 11(4): 859-864. 264. A.J. Wolfe, Mohammad, S. Cheley, H. Bayley, et al. "Catalyzing the Translocation of Polypeptides through Attractive Interactions". J. Am. Chem. Soc. 2007. 129(45): 14034-14041. 265. N.A. Wilson, R. Abu-Shumays, B. Gyarfas, H. Wang, et al. "Electronic Control of DNA Polymerase Binding and Unbinding to Single DNA Molecules". Acs Nano. 2009. 3(4): 995- 1003. 266. J.W.F. Robertson, C.G. Rodrigues, V.M. Stanford, K.A. Rubinson, et al. "Single- Molecule Mass Spectrometry in Solution Using a Solitary Nanopore". Proceedings of the National Academy of Sciences. 2007. 104(20): 8207-8211. 267. B. McNally, A. Singer, Z. Yu, Y. Sun, et al. "Optical Recognition of Converted DNA Nucleotides for Single-Molecule DNA Sequencing Using Nanopore Arrays". Nano Lett. 2010. 10(6): 2237-2244. 268. G.A.T. Chansin, R. Mulero, J. Hong, M.J. Kim, et al. "Single-Molecule Spectroscopy Using Nanoporous Membranes". Nano Lett. 2007. 7(9): 2901-2906. 269. A. Kleefen, D. Pedone, C. Grunwald, R. Wei, et al. "Multiplexed Parallel Single Transport Recordings on Nanopore Arrays". Nano Lett. 2010. 10(12): 5080-5087. 270. A. Oukhaled, L. Bacri, M. Pastoriza-Gallego, J.-M. Betton, et al. "Sensing Proteins through Nanopores: Fundamental to Applications". ACS Chemical Biology. 2012. 7(12): 1935- 1949. 271. T.P. Niedringhaus, D. Milanova, M.B. Kerby, M.P. Snyder, et al. "Landscape of Next- Generation Sequencing Technologies". Anal. Chem. 2011. 83(12): 4327-4341. 272. J. Korlach, S.W. Turner. "Going Beyond Five Bases in DNA Sequencing". Current Opinion in Structural Biology. 2012. 22(3): 251-261. 273. M.A.I. Mahmood, W. Ali, A. Adnan, S.M. Iqbal. "3d Structural Integrity and Interactions of Single-Stranded Protein-Binding DNA in a Functionalized Nanopore". J. Phys. Chem. B. 2014. 118(22): 5799-5806. 274. D.J. Niedzwiecki, R. Iyer, P.N. Borer, L. Movileanu. "Sampling a Biomarker of the Human Immunodeficiency Virus across a Synthetic Nanopore". ACS Nano. 2013. 7(4): 3341- 3350. 275. Y.-L. Ying, H.-Y. Wang, T.C. Sutherland, Y.-T. Long. "Monitoring of an Atp-Binding Aptamer and Its Conformational Changes Using an Α-Hemolysin Nanopore". Small. 2011. 7(1): 87-94. 276. R. Kawano, T. Osaki, H. Sasaki, M. Takinoue, et al. "Rapid Detection of a Cocaine- Binding Aptamer Using Biological Nanopores on a Chip". J. Am. Chem. Soc. 2011. 133(22): 8474-8477. 277. V. Van Meervelt, M. Soskine, G. Maglia. "Detection of Two Isomeric Binding Configurations in a Protein–Aptamer Complex with a Biological Nanopore". ACS Nano. 2014. 8(12): 12826-12835. 278. W.J. Greenleaf, K.L. Frieda, D.A.N. Foster, M.T. Woodside, et al. "Direct Observation of Hierarchical Folding in Single Riboswitch Aptamers". Science. 2008. 319(5863): 630-633. 279. L. Lin, H. Wang, Y. Liu, H. Yan, et al. "Recognition Imaging with a DNA Aptamer". Biophys. J. 2006. 90(11): 4236-4238. 280. Y.H. Tennico, D. Hutanu, M.T. Koesdjojo, C.M. Bartel, et al. "On-Chip Aptamer-Based Sandwich Assay for Thrombin Detection Employing Magnetic Beads and Quantum Dots". Anal. Chem. 2010. 82(13): 5591-5597. 281. A.A. Lubin, K.W. Plaxco. "Folding-Based Electrochemical Biosensors: The Case for Responsive Nucleic Acid Architectures". Acc. Chem. Res. 2010. 43(4): 496-505. 282. K.J. Freedman, S.R. Haq, J.B. Edel, P. Jemth, et al. "Single Molecule Unfolding and Stretching of Protein Domains inside a Solid-State Nanopore by Electric Field". Sci. Rep. 2013. 3 283. J. Mathe, H. Visram, V. Viasnoff, Y. Rabin, et al. "Nanopore Unzipping of Individual DNA Hairpin Molecules". Biophys. J. 2004. 87(5): 3205-3212. 284. A.R. Hall, S. van Dorp, S.G. Lemay, C. Dekker. "Electrophoretic Force on a Protein- Coated DNA Molecule in a Solid-State Nanopore". Nano Lett. 2009. 9(12): 4441-4445. 285. S.W. Kowalczyk, M.W. Tuijtel, S.P. Donkers, C. Dekker. "Unraveling Single-Stranded DNA in a Solid-State Nanopore". Nano Lett. 2010. 10(4): 1414-1420. 286. S. Renner, S. Geltinger, F.C. Simmel. "Nanopore Translocation and Force Spectroscopy Experiments in Microemulsion Droplets". Small. 2010. 6(2): 190-194. 287. J. Comer, A. Ho, A. Aksimentiev. "Toward Detection of DNA-Bound Proteins Using Solid-State Nanopores: Insights from Computer Simulations". ELECTROPHORESIS. 2012. 33(23): 3466-3479. 288. K.C. Neuman, A. Nagy. "Single-Molecule Force Spectroscopy: Optical Tweezers, Magnetic Tweezers and Atomic Force Microscopy". Nat Meth. 2008. 5(6): 491-505. 289. G.V. Soni, M.P. Jonsson, C. Dekker. "Periodic Modulations of Optical Tweezers near Solid-State Membranes". Small. 2013. 9(5): 679-684. 290. M. van den Hout, I.D. Vilfan, S. Hage, N.H. Dekker. "Direct Force Measurements on Double-Stranded Rna in Solid-State Nanopores". Nano Lett. 2010. 10(2): 701-707. 291. S. Andy, S. Andre, K. Maryam, L. Miriam, et al. "Dynamic Translocation of Ligand- Complexed DNA through Solid-State Nanopores with Optical Tweezers". J. Phys.: Condens. Matter. 2010. 22(45): 454121. 292. E.M. Nelson, H. Li, G. Timp. "Direct, Concurrent Measurements of the Forces and Currents Affecting DNA in a Nanopore with Comparable Topography". ACS Nano. 2014. 8(6): 5484-5493. 293. L.S. Connelly, B. Meckes, J. Larkin, A.L. Gillman, et al. "Graphene Nanopore Support System for Simultaneous High-Resolution AFM Imaging and Conductance Measurements". ACS Appl. Mater. Interfaces. 2014. 6(7): 5290-5296. 294. C. Hyun, H. Kaur, R. Rollings, M. Xiao, et al. "Threading Immobilized DNA Molecules through a Solid-State Nanopore at >100 Μs Per Base Rate". ACS Nano. 2013. 7(7): 5892-5900. 295. A.P. Ivanov, K.J. Freedman, M.J. Kim, T. Albrecht, et al. "High Precision Fabrication and Positioning of Nanoelectrodes in a Nanopore". ACS Nano. 2014. 8(2): 1940-1948. 296. K. Yokota, M. Tsutsui, M. Taniguchi. "Electrode-Embedded Nanopores for Label-Free Single-Molecule Sequencing by Electric Currents". RSC Advances. 2014. 4(31): 15886-15899. 297. K. Healy, V. Ray, L.J. Willis, N. Peterman, et al. "Fabrication and Characterization of Nanopores with Insulated Transverse Nanoelectrodes for DNA Sensing in Salt Solution". ELECTROPHORESIS. 2012. 33(23): 3488-3496. 298. P.S. Spinney, S.D. Collins, D.G. Howitt, R.L. Smith. "Fabrication and Characterization of a Solid-State Nanopore with Self-Aligned Carbon Nanoelectrodes for Molecular Detection". Nanotechnology. 2012. 23(13): 135501. 299. K. Chihiro, N. Tetsuya, T. Makusu, T. Masateru, et al. "Electrical Detection of Single Pollen Allergen Particles Using Electrode-Embedded Microchannels". J. Phys.: Condens. Matter. 2012. 24(16): 164202. 300. M. Tsutsui, M. Taniguchi, K. Yokota, T. Kawai. "Identifying Single Nucleotides by Tunnelling Current". Nat Nano. 2010. 5(4): 286-290. 301. M. Di Ventra, M. Taniguchi. "Decoding DNA, Rna and Peptides with Quantum Tunnelling". Nat Nano. 2016. 11(2): 117-126. 302. S. Lindsay. "The Promises and Challenges of Solid-State Sequencing". Nat Nano. 2016. 11(2): 109-111. 303. A.P. Ivanov, E. Instuli, C.M. McGilvery, G. Baldwin, et al. "DNA Tunneling Detector Embedded in a Nanopore". Nano Lett. 2011. 11(1): 279-285. 304. J. Zhijun, M. Mirna, C. Jason, S. Derek. "Fabrication of Nanopores with Embedded Annular Electrodes and Transverse Carbon Nanotube Electrodes". J. Phys.: Condens. Matter. 2010. 22(45): 454114. 305. M.P. Cecchini, A. Wiener, V.A. Turek, H. Chon, et al. "Rapid Ultrasensitive Single Particle Surface-Enhanced Raman Spectroscopy Using Metallic Nanopores". Nano Lett. 2013. 13(10): 4602-4609. 306. W.H. Pitchford, H.-J. Kim, A.P. Ivanov, H.-M. Kim, et al. "Synchronized Optical and Electronic Detection of Biomolecules Using a Low Noise Nanopore Platform". ACS Nano. 2015. 9(2): 1740-1748. 307. F. Sawafta, B. Clancy, A.T. Carlsen, M. Huber, et al. "Solid-State Nanopores and Nanopore Arrays Optimized for Optical Detection". Nanoscale. 2014. 6(12): 6991-6996. 308. A. Ivankin, R.Y. Henley, J. Larkin, S. Carson, et al. "Label-Free Optical Detection of Biomolecular Translocation through Nanopore Arrays". ACS Nano. 2014. 8(10): 10774-10781. 309. B.N. Anderson, O.N. Assad, T. Gilboa, A.H. Squires, et al. "Probing Solid-State Nanopores with Light for the Detection of Unlabeled Analytes". ACS Nano. 2014. 8(11): 11836- 11845. 310. S. Liu, Y. Zhao, J.W. Parks, D.W. Deamer, et al. "Correlated Electrical and Optical Analysis of Single Nanoparticles and Biomolecules on a Nanopore-Gated Optofluidic Chip". Nano Lett. 2014. 14(8): 4816-4820. 311. M.P. Jonsson, C. Dekker. "Plasmonic Nanopore for Electrical Profiling of Optical Intensity Landscapes". Nano Lett. 2013. 13(3): 1029-1033. 312. Y.-Q. Li, Y.-B. Zheng, R.N. Zare. "Electrical, Optical, and Docking Properties of Conical Nanopores". ACS Nano. 2012. 6(2): 993-997. 313. G.V. Soni, A. Singer, Z. Yu, Y. Sun, et al. "Synchronous Optical and Electrical Detection of Biomolecules Traversing through Solid-State Nanopores". Rev. Sci. Instrum. 2010. 81(1): 014301. 314. S. Kumar, N.J. Wittenberg, S.-H. Oh. "Nanopore-Induced Spontaneous Concentration for Optofluidic Sensing and Particle Assembly". Anal. Chem. 2013. 85(2): 971-977. 315. V. Kurz, E.M. Nelson, J. Shim, G. Timp. "Direct Visualization of Single-Molecule Translocations through Synthetic Nanopores Comparable in Size to a Molecule". ACS Nano. 2013. 7(5): 4057-4069. 316. C.R. Martin, M. Nishizawa, K. Jirage, M. Kang. "Investigations of the Transport Properties of Gold Nanotubule Membranes". J. Phys. Chem. B. 2001. 105(10): 1925-1934. 317. K.B. Jirage, J.C. Hulteen, C.R. Martin. "Nanotubule-Based Molecular-Filtration Membranes". Science. 1997. 278(5338): 655-658. 318. C.J. Brumlik, V.P. Menon, C.R. Martin. "Template Synthesis of Metal Microtubule Ensembles Utilizing Chemical, Electrochemical, and Vacuum Deposition Techniques". J. Mater. Res. 1994. 9(05): 1174-1183. 319. G. Guillot, F. Rondelez. "Characteristics of Submicron Pores Obtained by Chemical Etching of Nuclear Tracks in Polycarbonate Films". J. Appl. Phys. 1981. 52(12): 7155-7164. 320. J.P.S. DesOrmeaux, J.D. Winans, S.E. Wayson, T.R. Gaborski, et al. "Nanoporous Silicon Nitride Membranes Fabricated from Porous Nanocrystalline Silicon Templates". Nanoscale. 2014. 6(18): 10798-10805. 321. D.Z. Fang, C.C. Striemer, T.R. Gaborski, J.L. McGrath, et al. "Methods for Controlling the Pore Properties of Ultra-Thin Nanocrystalline Silicon Membranes". J. Phys.: Condens. Matter. 2010. 22(45): 454134. 322. M.A. Penn, D.M. Drake, J.D. Driskell. "Accelerated Surface-Enhanced Raman Spectroscopy (Sers)-Based Immunoassay on a Gold-Plated Membrane". Anal. Chem. 2013. 85(18): 8609-8617. 323. K.R. Wigginton, P.J. Vikesland. "Gold-Coated Polycarbonate Membrane Filter for Pathogen Concentration and Sers-Based Detection". Analyst. 2010. 135(6): 1320-1326.

Figure Captions

Figure 1: (a) A <100 nm-thick layer of liquid between two thin windows can be interrogated with a range of optical and particle probes, in isolation and combination, yielding molecular- level insights over a range of time and length scales. (b) A ~10 nm-diameter central nanochannel can be used to (electrophoretically) detect and entrain single molecules for interrogation by a variety of methods such as electron tunneling (e.g. using transverse electrodes proximal to the pore), and single-molecule fluorescence. Molecular coatings (wavy lines at upper right) can tune the performance of nanopores (and other nanofluidic devices) through judiciously chosen terminal functional groups (red curve). Bacteriochlorophyll molecule from reference 30; scaling is not intended to be rigorously representative.

Figure 2: (a) The basic <100 nm-thick silicon nitride membrane, free-standing over an open aperture in silicon can serve as (b) the windows of a nanofluidic cell with additional features such as a wetting layer (green) added through conventional nanofabrication approaches, or (c) be used as a single-molecule sensor element after formation of a nanochannel through the membrane.

Figure 3. (Top panel) Fabrication steps for freestanding SiNx windows: (a) SiNx is deposited on both sides of a double-side polished (100)-oriented Si wafer by LPCVD (b) Photoresist is sequentially coated onto both sides of the wafer. While photoresist is only needed on one side for photolithography, the photoresist on the back (membrane) side serves as a protective layer against etching of the SiNx in step d. (c) The window feature is created in the photoresist layer via standard photolithography (UV exposure and development). (d) Reactive ion etching (RIE) is used to transfer the window feature into the SiNx layer. Note that RIE is isotropic; the vertical profile of the exposed area as shown in the figure does not accurately depict the actual isotropic etch profile, but because the depth of the etched region is much smaller than the lateral dimension of the exposed area, this effect can be ignored. (e) Photoresist is stripped from both sides using a suitable chemical bath. (f) KOH is used to etch through the wafer and create the free-standing SiNx structure. KOH stops at the SiNx layer. KOH is anisotropic, with etch rates of the (100) and (110) planes much larger than the (111) planes. Thus, the etch front progresses along the (111) planes of the crystal, resulting in the narrowing of the window dimension relative to the dimension of the mask feature by a factor of the thickness of the wafer multiplied by √2. To speed up the onset of the KOH process, it is recommended to dip the patterned wafer into a buffered oxide etch solution (BOE) prior to the KOH etch step. BOE removes the native oxide layer that forms naturally on the exposed Si. (Bottom panel) Top-down views of the fabricated membrane and supporting frame. The view from the membrane side shows only the window. The view from the patterned side shows the etch pit whose angles are determined by the silicon crystal planes.

Figure 4. (Top panel) Cross-sectional view depicting bulging of a square-shaped silicon nitride membrane of side 2a and thickness t, due to net differential pressure p. The parameter of interest is the maximum deflection d at the center of the membrane. Maximum deflection of a 100 μm square membrane (center panel) and a 1 mm square membrane (bottom panel) as function of differential pressure up to ~1 atmosphere and for different membrane thicknesses (10, 100, and 1000 nm). The cross marks represent fracture points calculated according to the model in Eq. 2. The fracture model assumes that the membrane has a pre-existing crack line that is 10 μm in length. Absence of a fracture point indicates that the membrane is able to withstand the pressure at least up to the top end of the calculated range.

Figure 5. (Left panel) Experimentally determined complex dielectric function of silicon nitride in the 1-25 eV range (reproduced from measurements by H. R. Philipp).91 (Right panel) The real part of the refractive index as extracted from the dielectric constant. The y-axis scale on the right side shows the reflectance of SiNx at normal incidence.

Figure 6. Extinction coefficients of several thin film materials including low stress silicon nitride (solid lines). Data based on ellipsometry and reflectivity measurements by Poenar et al.94 BSG and PSG refer respectively to borosilicate glass and phosphosilicate glass. Reproduced with permission from the Optical Society.

Figure 7. X-ray transmission of 10 nm (red line), 100 nm (green line), and 1000 nm (blue line) thick SiNx windows. Data obtained from the CXRO database, based on the work of Henke et al.96 The calculation assumes a density of silicon nitride of 3.44 g/cm3. The left panel highlights transmission at energies below 2 keV, whereas the right panel is for energies in the 2-10 keV range.

Figure 8. (Left panel) Electron transmission of 5 nm (blue filled circles), 10 nm (red filled circles), 20 nm (green filled circles), and 40 nm (purple filled circles) thick SiNx windows, 5 nm a-C (green open circles), 40 nm a-C (red open circles), and bilayer graphene (purple open circles). Data obtained from theoretical electron scattering cross-sections.98 The calculation 3 assumes a density of SiNx of 3.44 g/cm and a 1:1.1 Si:N stoichiometry. This composition is used to calculate the average scattering cross-section weighted by the number densities of the composite atoms. a-C and bilayer graphene were assumed to have a density of 2.0 g/cm3. The solid lines are trend lines (the original work modeled energies satisfying 2m keV, with m being an integer between 0 and 8). (Right panel) Selected area electron diffraction (SAED) images of an α-Si3N4 nano-rod. The image on the bottom left is for a single-crystalline section taken from the body of the rod. The image on the top right is for an amorphous structure corresponding to the tip of the nano-rod. Image reproduced from reference 99 with permission from Elsevier.

Figure 9: (a) Vesicles offer nanoscale liquid confinement in soft phospholipid envelopes, with well-established formation protocols. (b) Robust graphene membranes can form nanoscale containers around liquid droplets. (c) Micrometer-diameter openings in otherwise intact vacuum windows provide access to underlying liquid-phase samples (see discussion of SALVI in text). Silicon nitride thin films spanning openings in silicon frames can be used to form a range of nanoscale liquid containers. Cell formats include those (d) with integral spacers that require sample addition before sealing; those (e) with, e.g. nanoparticle spacers that can be loaded with liquid before or after closing; those (f) with integral spacers allowing (g) liquid loading after closing; and those (h) with an integral spacer but (i) more sophisticated fluidic connections allowing (j) structured flow channels for control over fluid flow useful for, e.g. TEM. Object sizes are not intended to convey scaling information. Figures in (d)-(j) from reference 20 – Reproduced by permission of The Royal Society of Chemistry.

Figure 10. (a) Schematic of a typical nanopore experimental setup showing the nanopore- containing membrane separating two reservoirs, with electrolyte filling the wells and the pore. The measured current is generated by a voltage applied across the nanopore that drives electrolyte ions (light blue) through the nanopore. Passage of a molecule or particle of interest (orange) through the nanopore can perturb that current. (b) Molecular recognition can augment the sensing selectivity. The complex between analyte and aptamer—the molecular recognition agent—prevents the aptamer from travelling through the pore before it dissociates from the target—a process indicated here by the increased current perturbation duration in the presence of target. Figure (a) from reference 20 – Reproduced by permission of The Royal Society of Chemistry.
