72

Odonata from highlands in Niassa, , with two new country records

Merlijn Jocque1,2*, Lore Geeraert1,3 & Samuel E.I. Jones1,4

1 Biodiversity Inventory for Conservation NPO (BINCO), Walmersumstraat 44, 3380 Glab- beek, Belgium; [email protected] 2 Aquatic and Terrestrial Ecology (ATECO), Royal Belgian Institute of Natural Sciences (RBINS), Vautierstraat 29, 1000 Brussels, Belgium 3 Plant Conservation and Population Biology, University of Leuven, Kasteelpark Arenberg 31-2435, BE-3001 Leuven, Belgium 4 Royal Holloway, University of London, Egham Surrey TW20 OEX, United Kingdom * Corresponding author

Abstract. ‘Afromontane’ ecosystems in Eastern are biologically highly valuable, but many remain poorly studied. We list observations of a Biodiversity Express Survey to the highland areas in north-west Mozambique, exploring for the first time the Njesi Pla- teau (Serra Jecci/Lichinga plateau), Mt Chitagal and Mt Sanga, north of the provincial capital of Lichinga. A total of 13 species were collected. Allocnemis cf. abbotti and Gynacantha im­ maculifrons are new records for Mozambique. Further key words. Dragonfly, , Anisoptera, Zygoptera, biodiversity, survey

Introduction The mountains of the East African Rift, stretching south from to Mozam- bique, are known to harbour a rich biological diversity owing to their unique habi- tats and long periods of isolation. Typically comprised of evergreen montane interspersed with high altitude grassland/moorland , these montane archi- pelagos, often volcanic in origin, have been widely documented as supporting high levels of endemism across taxonomic groups and are of international conservation value (Myers et al. 2000). While certain mountain ranges within this region have been relatively well studied biologically e.g. the Eastern Arc Mountains of (Burgess et al. 2007), large gaps in our knowledge of the region remain. The moun- tains of northern Mozambique are one of the poorest studied regions of eastern Africa and until recently few biological records existed. Since the early 2000s, significant exploratory work addressing the knowledge- gaps in the biology of Mozambique’s mountains has been undertaken. A series of expeditions to the area, particularly Mt Mabu, Mt Namuli, Mt Inago and Chi­ perone, have begun to redress this (see Bayliss et al. 2010, 2014; Timberlake et al. 2007, 2009, 2012). However despite recent increased attention on Mozam- bique’s mountains, they still remain poorly known especially for several inverte- brate groups.

Notulae odonatologicae 9(2) 2018: 72-7737-82 – DOI:10.5281/zenodo.1481085 73

To further contribute to the study of the northernmost highlands and mountains of Mozambique, a Biodiversity Express Survey to the highland areas in the North- west of the country (Niassa province) was organised, covering the Njesi Plateau (Serra Jecci/Lichinga plateau), Mt Chitagal and Mt Sanga, north of the provincial capital of Lichinga. We present here observations on the from the ex- pedition.

Study region and methods We surveyed three peaks in the Serra Jecci Mountain range (Niassa, Mozambique), where camps were made at the summits of the peaks of Mt Chitagal and Mt Sanga as well as on the Njesi Plateau. Data were collected between 05–25-xi-2016. We timed our visit to span the beginning of the wet season, but except for one morning no rain fell during the survey period. Dragonflies were collected on an opportun- istic basis using hand nets. We sampled as wide a range of habitats as possible to obtain a good representation of the dragonflies that were active at the time of our surveys. Specimens were killed and preserved in 70 % ethanol and subsequently identified by Dr Rosser Garrison from the California Department of Food & Ag- riculture (Plant Pest Diagnostics Branch) in Sacramento, California, USA. After identification, part of the material was returned to the Museu de Historia Natural in Maputo, Mozambique, and part of the material was deposited in the personal collection of Dr Rosser Garrison.

List of localities with odonate records (1) Mt Chitagal (12°35’49.32’’S, 35°15’46.74’’E), 1 428 m a.s.l. (2) Mt Sanga (12°23’0.72’’S, 35°20’6.96’’E), 1 702 m a.s.l. (3) The Njesi Plateau (12°49’56.76’’S, 35°11’12.00’’E), 1 728 m a.s.l..

Results A total of 13 species were recorded. Allocnemis cf. abbotti (Fig. 1) and Gynacantha immaculifrons are newly recorded for Mozambique (see Dijkstra & Clausnitzer 2014).

List of species recorded

Family 1. Umma declivium Förster, 1906 (1) 1♂ 4♀.

Family 2. caligata (Selys, 1853) (1) 1♂.

Notulae odonatologicae 9(2) 2018: 37-82 74

Family 3. Allocnemis cf. abbotti (Calvert, 1896) (1) 1♂.

Family 4. Africallagma sinuatum (Ris, 1921) (1) 1♂ 2♀ (2) 1♀. 5. kersteni (Gerstäcker, 1869) (1) 1♂ (3) 9♂ 2♀. 6. Pseudagrion sublacteum (Karsch, 1893) (1) 1♂.

Family 7. Gynacantha immaculifrons Fraser, 1956 (1) 1♂.

Family 8. Atoconeura biordinata Karsch, 1899 (1) 2♂. 9. Crocothemis saxicolor Ris, 1919 (3) 2♂ 2♀. 10. Orthetrum chrysostigma (Burmeister, 1839) (1) 1♂. 11. Orthetrum julia Kirby, 1900 (1) 4♂ 1♀ (2) 2♂ (3) 2♂. 12. furva Karsch, 1899 (1) 1♂ (3) 6♂. 13. Trithemis pluvialis Förster, 1906 (1) 2♂ (3) 5♂.

Discussion The single male Allocnemis collected (Fig. 1) has a rounded tubercle on the paraproct, not a sharp tooth as stated and illustrated in the original description for A. maccleeryi (Pinhey 1969), and is closest to A. abbotti. The status of A. mac­ cleeryi is uncertain (K.-D.B. Dijkstra pers. comm.) and the specimen collected seems intermediate between A. abbotti and A. maccleeryi possibly pointing towards syno­nymy for these taxa. We recorded this dragonfly close to a small stream with fine sand in a forested valley surrounded by dry grasslands. This new record in Northern Mozambique is 170 km ‘as the crow flies’ crossing Lake from Mt Ntchi­si (Malawi), the only location from where A. maccleeryi is known (Claus- nitzer 2010a). It is about 220 km from the closest recorded location of A. abbotti in

Notulae odonatologicae 9(2) 2018: 37-82 75

South-west Tanzania (Clausnitzer 2010a). Allocnemis abbotti is classified as ‘Near Threatened’ Clausnitzer( 2010b). Gynacantha immaculifrons is a poorly known species documented with sparse- ly distributed records from Tanzania (two localities), the Democratic Republic of Congo (a single record), and a single record from Malawi (Dijkstra 2005). It is a difficult species to find. It is expected to be common in the known range, and is related to healthy (Clausnitzer 2017). Our record comprises the first for this species in Mozambique. Umma declivium is a species found along streams of the Eastern Arc Mts (Tanzania) but is also known to occur in Mozambique (Dijkstra & Clausnitzer 2014), including Mt Mabu (K.-D.B. Dijkstra pers. comm.). It is classified as ‘Vul- nerable’ (Clausnitzer 2010c) owing to rapid deforestation of its montane habi- tats which is fragmenting existing populations. Our record comprises an important new population of this threatened montane species. We recorded only 13 species during our fieldwork, most likely a reflection of the paucity of aquatic habitats available at the end of the dry season. There was no precipitation during the expedition and only small mountain streams were flowing. The occurrence of two new national records is indicative of the sparse knowledge of the dragonflies of Northern Mozambique and also the general fauna and flora of these habitats. Several species associated with healthy forested habitats were ob- served, confirming the observations in the field of little deforestation in the higher altitudes of the northernmost highlands. Further surveys in this region during dif- ferent seasons of the year will without any doubt reveal additional species.

Fig. 1. Male of Allocnemis cf. abbotti from Niassa province, Mozambique. Photo: Rosser Garrison

Notulae odonatologicae 9(2) 2018: 37-82 76

Acknowledgements. Thank you to Dr. Rosser Garrison for identifying the material and Klaas-Douwe B. Dijkstra for help with the identification of the Allocnemis. Fieldwork in the region was made possible by the help of James Egremont-Lee and colleagues at the Rift Val- ley Corporation. We also thank local guides and communities for permission to enter and guidance through the visited sites. Thank you to Lucillia Chuquela and Erica Tovela, Gabri- ela Bittencourt and Hermenegildo Matimele for help with the research permit application process, and Pedro Vicente, Simao Manuel and Basidio Buanar from Serviços Provinciais de Florestas e Fauna Bravia for help with obtaining the export permits. The BINCO expedition to Mozambique was supported by the Critical Ecosystem Partnership Fund (S16-367 Moz BINCO), Royal Geographical Society (with IBG) with a Neville Shulman Challenge Award, The Rift Valley Corporation and World Wildlife Fund Belgium.

References

Bayliss J., Monteiro J., Fishpool L., Clausnitzer V. 2010a. Allo­ Congdon C., Bampton I., Bruessow cnemis maccleeryi. The IUCN Red C., Matimele H., Banze A. & Tim- List of Threatened Species 2010: berlake J.R. 2010. Biodiversity and e.T180563A7648402. Online on the Conservation of Mount Inago, Mozam- inter­net, URL (25-i-2018): http:// bique. Report produced under Dar- dx.doi.org/10.2305/IUCN.UK.20103. win Initiative Award 15/036. Mulanje RLTS.T180563A7648402.en Mountain Conservation Trust, Malawi Clausnitzer V. 2010b. Allocnemis ab­ Bayliss J., Timberlake J., Branch W., botti. The IUCN Red List of Threatened Bruessow C., Collins S., Congdon Species 2010: e.T59836A12084445. On- C., Curran M., De Sousa C., Dowsett line on the inter­net, URL (25-i-2018): R., Dowsett-Lemaire F., Fishpool L., http://dx.doi.org/10.2305/IUCN. Harris T., Herrmann E., Georgiadis UK.2010-3.RLTS.T59836A12084445. S., Kopp M., Liggitt B., Monadjem A., en Patel H., Ribeiro D., Spottiswoode C., Taylor P., Willcock S. & Smith Clausnitzer V. 2010c. Umma declivi­ P. 2014. The discovery, biodiversity um. The IUCN Red List of Threatened and conservation of Mabu forest – the Species 2010: e.T60070A12294784. On- largest medium-altitude rainforest in line on the inter­net, URL (25-i-2018): southern Africa. Oryx 48: 177-185 http://dx.doi.org/10.2305/IUCN. UK.20103.RLTS.T60070A12294784.en Burgess N.D., Butynski T.M., Cor- deiro N.J., Doggart N.H., Fjeldså Clausnitzer V. 2017. Gynacan­ J., Howell K.M., Kilahama F.B., tha immaculifrons. The IUCN Red Loader S.P., Lovett J.C., Mbilinyi B. List of Threatened Species 2017: & Menegon M. 2007. The biological e.T59875A72360772. Online on the importance of the Eastern Arc Moun- inter­net, URL (25-i-2018): http:// tains of Tanzania and . Biological dx.doi.org/10.2305/IUCN.UK.20173. Conservation 134: 209-231 RLTS.T59875A72360772.en

Notulae odonatologicae 9(2) 2018: 37-82 77

Dijkstra K.-D.B. 2005. and Timberlake J., Dowsett-Lemaire F., identification of the continental African Bayliss J., Alves T., Baena S., Bento Gynacantha and Heliaeschna species C., Cook K., Francisco J., Harris T., (: Aeshnidae). International Smith P. & de Sous C. 2009. Mt Namu- Journal of Odonatology 8: 1-32 li, Mozambique: Biodiversity and Con- Dijkstra K.-D.B. & Clausnitzer V. servation. Report for Darwin Initiative 2014. The dragonflies and of Award 15/036: Monitoring and Manag- Eastern Africa. Handbook for all Odo- ing Biodiversity Loss in South-East Af- nata from to . Studies rica’s Montane Ecosystems. in Afrotropical Zoology 298. Royal Mu- Timberlake J., Bayliss J., Dowsett- seum for Central Africa, Tervuren Lemaire F., Congdon C., Branch W., Myers N., Mittermeier R.A., Mit- Collins S., Curran M., Dowsett R.J., termeier C.G., Da Fonseca G.A.B. Fishpool L., Francisco J., Harris & Kent J. 2000. Biodiversity hotspots T., Kopp M. & Sousa C. de. 2012. Mt for conservation priorities. Nature 403: Mabu, Mozambique; Biodiversity and 853-858 Conservation. Report for Darwin Ini- tiative Award 15/036: Monitoring and Timberlake J.R., Bayliss J., Alves T., Managing South-East Africa’s Montane Baena S., Francisco J., Harris T. & Ecosystems da Sousa C. 2007. The biodiversity and conservation of Mount Chiperone, Mo- zambique. Unpublished report of Dar- win Initiative project. Royal Botanic Gardens, Kew Received 6th July 2018

Notulae odonatologicae 9(2) 2018: 37-82
