NECESSITY FOR A PROPOSED TRANSMISSION LINE
DOCKET NO. 51737
Submit seven (7) copies of the application and aU attachments supporting the application. If the application is being Jiled pursuant to 16 Tex. Admin. Code §25.101(b)(3)(D) (TAC) or 16 TAC §25.174, include in the application aH direct testimony. The application and other necessary documents shall be submitted to:
Public Utility Commission of Texas Attn: Filing Clerk 1701 N. Congress Ave. Austin, Texas 78711-3326 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Note: As used herein, the term "joint application" refers to an application for proposed transmission facilities for which ownership will be divided. All applications for such facilities should be filed jointly by the proposed owners ofthe facilities. 1. Applicant (Utility) Name:
For joint applications, provide all information for each applicant.
Applicant (Utility) Name: Oncor Electric Delivery Company LLC ("Oncor" or "Company")
Certificate Number: 30043
Street Address: 1616 Woodall Rodgers Freeway Dallas, Texas 75202
Mailing Address: 1616 Woodall Rodgers Freeway Dallas, Texas 75202-1234
2. Please identify all entities that will hold an ownership interest or an investment interest in the proposed project but which are not subject to the Commission's jurisdiction.
Oncor will hold the sole ownership interest in the Kyle Ranch Substation - Quarry Field Switch 138 kV Transmission Line Project.
3. Person to Contact: Ife Adetoro Title/Position: Regulatory Project Manager Phone Number: (214) 486-4918
Mailing Address: 1616 Woodall Rodgers Fwy, Suite 6A-014 Dallas, Texas 75202-1234 Email Address: [email protected]
3a. Legal Counsel: Jaren A. Taylor Winston P. Skinner Phone Number: (214) 220-7754 Mailing Address: Vinson & Elkins LLP Trammell Crow Center 2001 Ross Avenue, Suite 3700 Dallas, Texas 75201 Email Address: [email protected]
2 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
[email protected] Please contact Jaren Taylor with any inquiries regarding the project.
4. Project Description:
Provide a general description of the project, including the design voltage rating (kV), the operating voltage (kV), the CREZ Zone(s) (if any) where the project is located (all or in part), any substations and/or substation reactive compensation constructed as part of the project, and any series elements such as sectionalizing switching devices, series line compensation, etc. For HVDC transmission lines, the converter stations should be considered to be project components and should be addressed in the project description.
If the project will be owned by more than one party, briefly explain the ownership arrangements between the parties and provide a description of the portion(s) that will be owned by each party. Provide a description of the responsibilities of each party for implementing the project (design, Right-Of-Way acquisition, material procurement, construction, etc.).
If applicable, identify and explain any deviation in transmission project components from the original transmission specifications as previously approved by the Commission or recommended by a PURA §39.151 organization. Name or Designation of Project: Kyle Ranch - Quarry Field 138 kV Transmission Line Project Design Voltage Rating (kV): 138 kV Operating Voltage Rating (kV): 138 kV Normal Peak Operating Current (A): 2569 A
The Kyle Ranch Substation - Quarry Field Switch 138 kV Transmission Line Project ("Proposed Transmission Line Project") is a new single-circuit 138 kilovolt ("kV") transmission line to be built on double-circuit capable structures between the newly- constructed Kyle Ranch Substation and the newly-constructed Quarry Field Switch station, both of which are located in Loving County, Texas. This project was previously approved in Commission Docket No. 49302, including the re-location of the Kyle Ranch Substation approximately 3 miles east of its originally proposed location. However, the single route for the Proposed Transmission Line Project presented herein results from numerous conversations with directly affected landowners, all of whom have consented to a series of route modifications from the settlement route approved in Docket No. 49302. The Kyle Ranch Substation is located in Loving County approximately 6 miles southeast of the intersection of County Road ("CR") 300 and Farm-to-Market ("FM") 652. Quarry Field Switch is located approximately six miles north of the community of Mentone, Texas, also in Loving County.
Construction ofthe Kyle Ranch Substation, and halfof its estimated cost, was included with the Riverton - Kyle Ranch 138 kV Line approved in Commission Docket No. 49304, while the other half ofthe Kyle Ranch Substation's construction cost, as well the construction and
3 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
cost of Quarry Field Switch, were included in Docket No. 49302. Those stations have now been constructed. The Kyle Ranch Substation and Quarry Field Switch station costs, as well as the three miles of new transmission line construction from the re-located Kyle Ranch Substation site west to the terminus of the Riverton - Kyle Ranch transmission line approved in Docket No. 49304, will continue to be reported in Oncor's monthly construction progress reports under Docket No. 49302. Neither of these two stations nor that 3-mile portion of the previously-approved transmission line are at issue in this proceeding. As addressed in the cover pleading submitted concurrently with this Application, the portion of the transmission line from re-located Kyle Ranch Substation to Quarry Field Switch is being re-submitted for Commission approval.
Please see Attachment No. 1 for a map regarding project approvals that illustrates: (1) the Riverton - Kyle Ranch 138 kV transmission line route, as approved in Docket No. 49304, (2) the re-located Kyle Ranch Substation, the Quarry Field Switch station, and the 3 miles of transmission line west from the re-located Kyle Ranch Substation to the terminus of the Riverton-Kyle Ranch transmission line's terminus, all of which were previously approved in Docket No. 49302 and are not at issue in this proceeding, and (3) the proposed transmission line route from the re-located Kyle Ranch Substation to Quarry Field Switch, which is at issue in this proceeding.
The length of the Proposed Transmission Line Project is approximately 11.3 miles based on the route proposed herein.
5. Conductor and Structures: Conductor Size and Type: 1926.9 kcmil ACSS/TW Number of conductors per phase: 1 Continuous Summer Static Current Rating (A): 2569 A Continuous Summer Static Line Capacity at Operating Voltage (MVA): 614 MVA Continuous Summer Static Line Capacity at Design Voltage (MVA): 614 MVA Type and composition of Structures: Double-Circuit Steel or Concrete Pole Height of Typical Structures: 85 - 105 feet* *This number reflects the approximate visible height ofthe structure from ground to structure top. Please see the drawing of a typical tangent structure in Figure 1 - 2 , page 1 - 7 , of the Environmental Assessment and Alternative Route Analysis for Oncor Electric Delivery Company LLC's Proposed Kyle Ranch - Quarry Field 138 kV Transmission Line Project in Loving County , Texas (" Environmental Assessment and Routing Study "), prepared by HalffAssociates, Inc. in connection with Docket No. 49302, and included as Attachment No. 2.
4 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Explain why these structures were selected; include such factors as landowner preference, engineering considerations, and costs comparisons to alternate structures that were considered. For joint applications, provide and separately identify the above-required information regarding structures for the portion(s) of the project owned by each applicant.
Oncor selected the double-circuit 138 kV steel and concrete monopoles for numerous reasons including costs, technical specifications, structure footprint right-of-way ("ROW") requirements, the specific characteristics of the study area and other items. This structure type is also Oncor's current standard for new single- and double-circuit 138 kV construction. This structure selection was approved by the Commission in Docket No. 49302.
Provide dimensional drawings of the typical structures to be used in the project. A drawing of the typical tangent structure is shown in Figure 1-2, page 1-7, of the Environmental Assessment and Routing Study included as Attachment No. 2.
6. Right-of-way: For joint applications, provide and separately identify the above-required information for each route for the portion(s) of the project owned by each applicant. Miles of Right-of-Way Approximately 11.3 miles Miles of Circuit Approximately 11.3 miles Width of Right-of-Way 70 feet Percent of Right-of-Way Acquired 2%* *This represents the portion of ROW relating to the Proposed Transmission Line Project that was donated to Oncor by Z&T Cattle Company, LLC pursuant to Ordering Paragraph 15 of the Commission's final order in Docket No. 49302. Provide a brief description of the area traversed by the transmission line. Include a description of the general land uses in the area and the type of terrain crossed by the line. The project area is situated in a relatively remote portion of Loving County. No incorporated cities, unincorporated towns, or communities are located within the project area. Almost the entirety of the study area consists of rural, undeveloped land used primarily for livestock grazing or oil and gas production. Residential development and commercial development are scarce as CR 300 and CR 22 represent the few public roads within the study area. Much of the county road network has been incorporated into private oil and gas operations. The topography ofthe study area is sloping from the northeastern corner to the southwestern corner of the study area towards the Pecos River located over a mile outside of the study area. A variety of grasses, forbs, and woody species pervade unimproved rangeland pastures.
5 February 4, 2021 Crl Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Specific discussion regarding natural, human and cultural resources in the project area is set forth in the Environmental Assessment and Routing Study, Sections 3.2 through 3.8, pages 3-1 through 3-57, included as Attachment No. 2. Substations or Switching Stations: List the name of all existing HVDC converter stations, substations or switching stations that will be associated with the new transmission line. Provide documentation showing that the owner(s) of the existing HVDC converter stations, substations and/or switching stations have agreed to the installation of the required project facilities. Oncor's Kyle Ranch Substation Oncor's Quarry Field Switch station List the name of all new HVDC converter stations, substations or switching stations that will be associated with the new transmission line. Provide documentation showing that the owner(s) of the new HVDC converter stations, substations and/or switching stations have agreed to the installation of the required project facilities. None Estimated Schedule:
Estimated Dates of: Start* Completion*
Right-of-way and Land Acquisition 5/2021 10/2021
Engineering and Design 1/2021 4/2021
Material and Equipment Procurement 4/2021 10/2021
Construction of Facilities 10/2021 3/2022
Energize Facilities 3/2022 3/2022 *Estimated schedule assumes administrative approval of CCN and numerous other factors. If a hearing is required to process this CCN, the anticipated energization date would be November 2022. The estimated construction schedule should not in any way be considered a representation, promise, or guarantee. Counties: For each route, list all counties in which the route is to be constructed.
The proposed route is located wholly within Loving County.
10. Municipalities:
For each route, list all municipalities in which the route is to be constructed. The proposed route will not traverse any municipality.
For each applicant, attach a copy of the franchise, permit or other evidence of the city's consent held by the utility, if necessary or applicable. If franchise, permit, or other evidence
6 February 4,2021 J) Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
of the city's consent has been previously filed, provide only the docket number of the application in which the consent was filed. Each applicant should provide this information only for the portion(s) of the project which will be owned by the applicant. Not applicable
11. Affected Utilities:
Identify any other electric utility served by or connected to facilities in this application.
No other electric utility will initially be served by or connected to the Proposed Transmission Line Project. Describe how any other electric utility will be affected and the extent of the other utilities' involvement in the construction of this project. Include any other electric utilities whose existing facilities will be utilized for the project (vacant circuit positions, ROW, substation sites and/or equipment, etc.) and provide documentation showing that the owner(s) of the existing facilities have agreed to the installation of the required project facilities. No other electric utility will be involved in the construction of the Proposed Transmission Line Project. No other utilities' existing facilities will be utilized. 12. Financing:
Describe the method of financing this project. For each applicant that is to be reimbursed for all or a portion of this project, identify the source and amount of the reimbursement (actual amount if known, estimated amount otherwise) and the portion(s) of the project for which the reimbursement will be made. Oncor proposes to finance the facilities included in the Proposed Transmission Line Project with a combination of debt and equity in compliance with its authorized capital structure, which is similar to the means used for previous construction projects. Oncor plans to utilize internally generated funds (equity) and proceeds received from the issuance of securities. Oncor will typically obtain short-term borrowings as needed for interim financing of its construction expenditures in excess of funds generated internally. These borrowings are then repaid through the issuance of long-term debt securities, the type and amount of which are as ofyet undetermined. Oncor is the sole applicant, and therefore no other party will be reimbursed for any portion ofthe project. 13. Estimated Costs: Provide cost estimates for each route of the proposed project using the following table. Provide a breakdown of "Other" costs by major cost category and amount. Provide the information for each route in an attachment to this application.
7 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Transmission Substation Facilities* Facilities **
Right-of-way and Land $1,260,000 Acquisition
Engineering and Design (Utility) $386,000
Engineering and Design $827,000 (Contract)
Procurement of Material and $4,077,000 Equipment (including stores)
Construction of Facilities $0 (Utility)
Construction of Facilities $10,611,000 (Contract) Other (all costs not included in the above categories)
Estimated Total Cost $17,161,000 * This estimate includes the costs to construct the transmission line from the re-located Kyle Ranch Substation to Quarry Field. As discussed above, the 3 miles of transmission line construction west of Kyle Ranch Substation, to the terminus of the transmission line approved in Docket No. 49304, is fully constructed and thus not included in this filing. The cost estimate difference between the route approved in Docket No 49302 and the single route proposed herein is attributed to two partially off- setting sets ofchanges: removing the already-constructed 3 mile section mentioned above, while adding new structures to accommodate the proposed route. ** The Kyle Ranch Substation's construction costs were included in Docket Nos. 49302 and 49304. respectively, and Quarry Field Switch's construction costs were also included in Docket No. 49302. Therefore no station costs are included in this Application. For joint applications, provide and separately identify the above-required information for the portion(s) of the project owned by each applicant. Not applicable.
14. Need for the Proposed Project:
For a standard application, describe the need for the construction and state how the proposed project will address the need. Describe the existing transmission system and conditions addressed by this application. For projects that are planned to accommodate load growth, provide historical load data and load projections for at least five years. For projects to accommodate load growth or to address reliability issues, provide a description of the steady state load flow analysis that justifies the project. For interconnection projects, provide any documentation from a transmission service customer, generator, transmission service provider, or other entity to establish that the proposed facilities are needed. For projects
8 February 4, 2021 00 00 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
related to a Competitive Renewable Energy Zone, the foregoing requirements are not necessary; the applicant need only provide a specific reference to the pertinent portion(s) of an appropriate commission order specifying that the facilities are needed. For all projects, provide any documentation of the review and recommendation of a PURA §39.151 organization. The need for the Proposed Transmission Line Project was previously reviewed and approved in Docket No. 49302, and the same justifications still apply. The need for the Proposed Transmission Line Project, as discussed in Oncor's application in Docket No. 49302, is substantially re-produced below, with appropriate updates for historical and projected load numbers and recent construction projects. ERCOT's Regional Planning Group ("RPG"), Technical Advisory Committee, and Board of Directors have recommended approval of the "Far West Texas Project 2" as a Tier 1 transmission project. ERCOT performed power flow studies as part of the ERCOT RPG process and found voltage violations under NERC Standard TPL-001-4 reliability criteria. In its Independent Review of the Far West Texas Project 2 (included as Attachment No. 3 to the Application), ERCOT recommended construction of the Quarry Field Switch station on the Wink - Riverton 138 kV line, and it also recommended construction of a new Kyle Ranch - Riverton 138 kV line. In its Independent Review, ERCOT also analyzed the Kyle Ranch - Quarry Field 138 kV Line proposed in this Application as a project already in- place in order to serve new loads, since it is considered a Tier 4 neutral project under ERCOT Protocols. Thus, ERCOT's recommended solution contemplated creation ofa 138 kV loop between Quarry Field Switch, Kyle Ranch Substation, and Riverton Switch, as shown on pages 5 and 16 of its Independent Review. See ERCOT Endorsement Letter dated June 12,2018, and Independent Review dated May 2018, included as Attachment No. 3. Oncor continues to experience load growth in West Texas due to oil and natural gas production, mid-stream processing, and associated economic expansion in the area referred to as the Delaware Basin. In order to meet this need, a new transmission line in Loving County is being proposed to connect Oncor's Quarry Field Switch Station, located in Loving County, to Oncor's Kyle Ranch Substation, located in Loving County. This new transmission line, in conjunction with the Riverton - Kyle Ranch 138 kV Line (recently approved in Commission Docket No. 49304), will create a new 138 kV transmission circuit between the Quarry Field Switch station and the Riverton Switch station, located in Reeves County, as envisioned in ERCOT's approval of the Far West Texas Project 2. Loving County lies within the West Texas region of the Delaware Basin where deep underground shale deposits referred to as "plays " are providing opportunities for oil and natural gas exploration and production. Improvements in oil and natural gas exploration technologies have increased activity in the area and resulted in electric load growth at substations within the Delaware Basin. This growth has resulted in increased load served on the existing Oncor Wink - Culberson Switch 138 kV Line and the Oncor Yucca Drive Switch - Culberson Switch 138 kV Line (together, "Culberson Loop"). Table 1 below shows the sum of historical and projected summer peak loads (MW) for the substations on the Culberson Loop transmission lines. The loads from 2015 to 2019 are actual non-coincident summer peaks and the loads for 2020 to 2024 are projected non-
9 February 4,2021 (D Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
coincident summer peaks. These projections only include confirmed load increases for Oncor substations and customer requests that have signed agreements for service.
Historical Load Projected Load 2015 2016 2017 2018 2019 2020* 2021 2022 2023 2024 Total 93.7 205.4 246.4 406.2 640.2 1,237.2 1,522.1 1,726.7 1,857.9 1,910.0 (MW) Table 1 - Historical and Projected Load on the Wink - Culberson and Yucca Drive - Culberson 138 kV Transmission Lines *Load information for 2020 is currently being compiled and actuahzed. finalized numbers are expected by March 2021 in accordance with the Annual Load Data Request (ALDR) Instructions referenced in ERCOT Planning Guide Section 6 5 This rapid load growth causes concerns for transmission reliability in the area. ERCOT's steady state load flow analysis identified single-contingency outages which would cause the Culberson Loop 138 kV Lines to be unable to maintain adequate system operating conditions, resulting in an unsolved contingency during load flow analysis. The unsolved contingencies show an inability of the power system to maintain acceptable voltages following a disturbance, resulting in potential voltage collapse along these lines which could potentially cause all load on these lines to be dropped. The Proposed Transmission Line Project will address these reliability concerns by being one of the elements that creates a new 13 8 kV pathway from the Quarry Field Switch station to the Riverton Switch station. The Quarry Field Switch station is the site for a dynamic reactive device (DRD)-including one 250 MVAR STATCOM and 150 MVAR static capacitors-and the Riverton Switch station is the site for a 345 kV injection, both of which are referenced in the ERCOT approved Far West Texas Project 2. See Attachment No. 3. Creating a new electrical connection between these two points will result in a 138 kV system that will become more networked and allow bi-directional flow in the area, ultimately allowing the voltage support from the DRD and the 345 kV injection to address the reliability concerns during outage conditions. In addition, this would improve operational flexibility during emergency conditions, obtaining clearances for maintenance of equipment, and connecting new loads to the system. ERCOT found on page 10 of its Independent Review that "the new 138 kV lines proposed in the [Far West Texas Project 2] are necessary to strengthen the Culberson Loop and provide operational flexibility under normal and outage conditions." Load Additions In addition to addressing transmission reliability concerns, the Proposed Transmission Line Project is needed to serve load growth in the area by establishing transmission service for new substations. Oncor needs to serve customers in the geographic area north of the existing Wink - Riverton 138 kV Line. This area is extremely active with oil and natural gas customers, yet there are no transmission or substation facilities in the vicinity. Oncor continues to receive multiple customer inquiries for electric service in this area, notably north toward the Texas-New Mexico border. With these growing load additions in remote locations, distribution feeder performance is a major concern. Customers in the area rely on long-distance distribution feeders from the El Mar and Mason substations, which have limited reach to customers in
10 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
these portions of Loving County . See Attachment No . 4 showing the area transmission infrastructure. These long feeders have a higher probability of forced outages due to increased exposure to storm events. They are also prone to low voltage problems due to the length of the feeder and have strict motor start limitations imposed on them to limit voltage fluctuations. These performance issues can currently be seen on distribution feeders in the area since many of them are several miles long. The existing distribution facilities in the area and the El Mar and Mason substations do not have capability to serve allload requests. As a result ofthese limitations, more than 20MW of load requests were put on hold until the new Kyle Ranch Substation was established. Oncor proposes to construct a new 138 kV transmission line from the Quarry Field 138 kV Switch station. The Quarry Field 138 kV Switch station will provide a connection to the existing Wink - Riverton 138 kV Line, the closest 138 kV interconnection point available. In conjunction with the Riverton - Kyle Ranch 138 kV Line (which, as approved in Docket No. 49304, would remain a radial line without interconnection to the Proposed Transmission Line Project), the Proposed Transmission Line Project will also allow for bi- directional, looped service which would allow the ability to segment this line via remote switches at the substations. This will provide operational flexibility to sectionalize the entire transmission line and maintain service to these customers during construction, maintenance, or outages. 15. Alternatives to Project:
For a standard application, describe alternatives to the construction of this project (not routing options). Include an analysis of distribution alternatives, upgrading voltage or bundling of conductors of existing facilities, adding transformers, and for utilities that have not unbundled, distributed generation as alternatives to the project. Explain how the project overcomes the insufficiencies of the other options that were considered. Potential alternatives to the Proposed Transmission Line Project were considered and rejected in Docket No. 49302. Discussion of those potential alternatives, as contained in Oncor's application in Docket No. 49302, is re-produced below.
Due to the existing system configuration and remote location of the surrounding transmission lines, alternatives to the Proposed Transmission Line Project that address all load growth and reliability concerns are limited. Alternatives to the Proposed Transmission Line Project were studied as part of the ERCOT RPG process for the Far West Texas 2 Project. ERCOT's independent review considered three project options, all of which included the Quarry Field - Kyle Ranch 138 kV Line as a project already in-place in order to serve new loads. Distribution alternatives would not improve the reliability and operational capability of the transmission system, and thus would not address the reliability criteria violations previously discussed. Additionally, distribution alternatives are not practical in serving new large load additions with the distribution system in the area already strained. Without a new transmission line in the area and the subsequent new substation, numerous customer sites
11 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
would still have difficulty being served from the distribution system due to long feeders that will be prone to low voltage problems and suffer from insufficient motor start capability. Upgrading voltage of existing facilities is not practical. A new 345 kV source in the area would be needed to upgrade voltage because all existing facilities in the area are constructed and operated at 138 kV. Additionally, all loads in the area are served from the 138 kV transmission system. Bundling of conductors would not address the reliability and operational issues under the contingencies of concern since any bundled circuits would be located on the same structures as the existing 138 kV lines in the area. The existing Oncor Wink - Riverton 138 kV Line is already a double-circuit. Additionally, bundling conductors does not provide new transmission service closer to the customers who have signed new service agreements. Adding transformers to existing substations would not address the distribution feeder or transmission reliability issues noted above. Oncor has constructed the Quarry Field Switch station where a Dynamic Reactive Device ("DRD") has been installed as approved by ERCOT in connection with the Far West Texas Project 2. Additionally, Oncor has constructed new 345 kV facilities at the Riverton Switch station. While these projects will provide voltage support to serve area load growth, they do not provide transmission service in an area near where customers' load can be served. 16. Schematic or Diagram: For a standard application, provide a schematic or diagram of the applicant's transmission system in the proximate area of the project. Show the location and voltage of existing transmission lines and substations, and the location of the construction. Locate any taps, ties, meter points, or other facilities involving other utilities on the system schematic. A schematic ofthe transmission system in the proximate area ofthe Proposed Transmission Line Project is shown in Attachment No. 5. The location and voltage of existing transmission lines, substations, taps, ties, meter points or other facilities involving other utilities in relation to the Proposed Transmission Line Project are included. A map outlining the project area can be found in Figure 3-1 of the Environmental Assessment and Routing Study, included as Attachment No. 2. 17. Routing Study: Provide a brief summary of the routing study that includes a description of the process of selecting the study area, identifying routing constraints, selecting potential line segments, and the selection of the routes. Provide a copy of the complete routing study conducted by the utility or consultant. State which route the applicant believes best addresses the requirements of PURA and P.U.C. Substantive Rules. In Docket No. 49302, Oncor retained Halff Associates, Inc. ("Halff') to prepare the Environmental Assessment and Routing Study. Given the single route proposed in this Application and its similarity to the settlement route approved in Docket No. 49302, Oncor is relying on the Environmental Assessment and Routing Study produced in Docket No. 49302 for this Application, which is included as Attachment No. 2. Discussion of that Environmental Assessment and Routing Study, as contained in Oncor's application in
12 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Docket No. 49302, is largely re-produced below, except that the route proposed herein best meets the requirements of PURA and Commission rules for the reasons discussed throughout this Application.
The objective of the Environmental Assessment and Routing Study was to provide information in support of this Application in addressing the requirements of Section 37.056(c)(4)(A)-(D) of the Texas Utilities Code, the PUCT CCN Application form, and 16 Tex. Admin. Code ("TAC") § 25.101 as these apply to the Proposed Transmission Line Project. By means of examination of existing environmental conditions, including the human and natural resources that are located in the project area, the Environmental Assessment and Routing Study appraises the environmental effects that could result from the construction, operation, and maintenance of the Proposed Transmission Line Project between the proposed Kyle Ranch Substation and the proposed Quarry Field Switch in Loving County. The Environmental Assessment and Routing Study may also be used in support of any additional local, state, or federal permitting activities that may be required for the Proposed Transmission Line Project. To assist Halff in its evaluation, Oncor provided information regarding the project endpoints, the need for the project, engineering and design requirements, construction practices, and ROW requirements for the Proposed Transmission Line Project. After considering environmental and geographical data, Halff defined a study area that encompassed the provided endpoints with a sufficient area to identify routing. See Section 3.0 of the Environmental Assessment and Routing Study, included as Attachment No. 2, for a discussion of the study area. Routing constraints were identified after collection of area data from many sources (e.g., governmental agencies, evaluation of aerial photography), consideration of criteria established in Section 37.056(c)(4)(A)-(D) of the Texas Utilities Code, the PUCT's CCN Application form, and 16 TAC § 25.101. Potential links were identified by evaluating the constraints mapped for the study area and then developing potential opportunity areas such as existing corridors and other linear features. Corridors were identified and developed into potentially viable routes. These preliminary routes were further evaluated based on information received from government agencies and the public participation meeting. Impacts were evaluated by Halff for each identified alternative route. Specific discussion regarding the study area, identification of constraints, selection of potential line segments, and alternative route analysis is set forth in the Environmental Assessment and Routing Study.
Given the consent obtained from all directly affected landowners, Oncor is filing the single route proposed herein. A series of maps showing this route and the relevant portion of the route approved in Docket No. 49302 are also attached hereto as Attachment No. 6. Halff has also re-calculated the relevant environmental and land use data for the proposed route, and compared it to the route previously approved in Docket No. 49302, based on recent investigations of publicly-available information and the Environmental Assessment and
13 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Routing Study conducted in Docket No. 49302. That environmental and land use data table and comparison for the proposed route is included as Attachment No. 7. 18. Public Meeting or Public Open House:
Provide the date and location for each public meeting or public open house that was held in accordance with 16 TAC §22.52. Provide a summary of each public meeting or public open house including the approximate number of attendants, and a copy of any survey provided to attendants and a summary of the responses received. For each public meeting or public open house provide a description of the method of notice, a copy of any notices, and the number of notices that were mailed and/or published. With respect to the single route proposed in this Application, no public meeting was necessary prior to this filing under 16 TAC § 25.52, as less than 25 landowners would be directly affected by the proposed route. With respect to the version of this project as proposed in Docket No. 49302, the relevant information from that Application is re-produced below. One public participation meeting was hosted by Oncor and attended by Oncor and Halff personnel, as well as personnel from TRC Solutions, Inc., a contractor who assists Oncor in abstracting. The public participation meeting was held January 15,2019, from 4:00 p.m. to 7:00 p.m., at the Kermit Community Center in Kermit, Texas. Oncor mailed a total of approximately 25 individual written notices of the meeting to all owners of property within 300 feet of the centerline of the preliminary alternative route links for the Proposed Transmission Line Project. Also, a public notice was placed in the local newspaper listed below announcing the location, time, and purpose of the meeting. Oncor also emailed notice of the public meeting to the Department of Defense Siting Clearinghouse. January 2019 Meeting Newspaper County The Winkler County News Loving The meeting was designed to solicit comments and input from residents, landowners, public officials, and other interested parties concerning the Proposed Transmission Line Project. The objectives included promoting an understanding of the Proposed Transmission Line Project including the purpose, need, and potential benefits and impacts; informing and educating the public with regard to the routing process and schedule; and gathering information about the values and concerns of the public and community leaders. The meeting was configured in an informal information station format rather than a formal speaker/audience format with each station assigned to a particular aspect of the project, or routing process, and staffed with Oncor representatives and/or Halff staff. Each station had exhibits, maps, illustrations, aerial photography, or other information describing certain project aspects and subject matter information. It was Oncor's intent to encourage attendees to visit each station in order, so the entire process could be explained in the general sequence of project development. Oncor has found this meeting format valuable due to its informality and because it allows attendees the opportunity to gather information most important to
14 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
them and to spend as much time as necessary with those particular project aspects. Additionally, individual discussions allow for and encourage more interaction from attendees who otherwise might be hesitant to participate in a more formal setting. Neither notified property owners nor other members of the public attended the public participation meeting. No comments or letters were received via mail or phone at a later date by either Oncor or Halff. Additional discussion concerning the public involvement program and specific information regarding the public participation meeting may be found in the Environmental Assessment and Routing Study, Sections 2.5 and 5.0, included as Attachment No. 2. A representative copy of the notice that was provided to property owners and a copy of the questionnaire provided to meeting attendees is included in Appendix B of Attachment No. 2. 19. Routing Maps: Base maps should be a full scale (one inch = not more than one mile ) highway map of the county or counties involved, or other maps of comparable scale denoting sufficient cultural and natural features to permit location of all routes in the field. Provide a map (or maps) showing the study area, routing constraints, and all routes or line segments that were considered prior to the selection of the routes. Identify the routes and any existing facilities to be interconnected or coordinated with the project. Identify any taps, ties, meter points, or other facilities involving other utilities on the routing map. Show all existing transmission facilities located in the study area. Include the locations of radio transmitters and other electronic installations, airstrips, irrigated pasture or cropland, parks and recreational areas, historical and archeological sites (subject to the instructions in Question 27), and any environmentally sensitive areas (subject to the instructions in Question 29). With respect to the single route proposed in this Application, a map containing the information required in this Question, which also shows this proposed route and the route approved in Docket No. 49302, is included as Attachment No. 6 to this Application. With respect to the maps originally included in the Docket No. 49302 Environmental Assessment and Routing Study, the relevant information from that Application is re- produced below. A one inch = 3,000 feet map (Environmental Assessment and Routing Study Figure 3-1) is included in the map pocket of Attachment No. 2. This base map includes sufficient cultural and natural features to permit the location of all routes in the field. This figure delineates the study area, routing constraints, and route links considered in the selection of routes. The map also depicts the approximate locations of radio transmitters and other electronic installations, airstrips, irrigated pasture or cropland, parks and recreational areas, historical and archeological sites, and any environmentally sensitive areas. Figure 3-1 depicts existing facilities in the area of the Proposed Transmission Line Project, including taps, ties, meter points, or other utility facilities, as applicable. Provide aerial photographs of the study area displaying the date that the photographs were taken or maps that show (1) the location of each route with each route segment identified, (2) the locations ofall major public roads including, as a minimum, all federal and state roadways, (3) the locations of all known habitable structures or groups of habitable structures (see Question 19 below) on properties directly affected by any route, and (4) the boundaries 15 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
(approximate or estimated according to best available information if required) of all properties directly affected by any route. Figure 3-1 of the Environmental Assessment and Routing Study included as Attachment No. 2 depicts on an aerial photograph: (1) the location of each route with each route segment identified, (2) the locations of all major public roads including all federal and state roadways, (3) the locations ofall known habitable structures on properties directly affected by any route, and (4) the boundaries (approximate or estimated according to available county tax information) of all properties directly affected by any route. In addition, the locations of radio transmitters and other electronic installations, airstrips, irrigated pasture or cropland, parks and recreational areas, historical and archeological sites, and any environmentally sensitive areas are depicted, if any. Similarly, Attachment No. 6 provides this information with respect to the proposed route and the route approved in Docket No. 49302. For each route, cross-reference each habitable structure (or group of habitable structures) and directly affected property identified on the maps or photographs with a list of corresponding landowner names and addresses and indicate which route segment affects each structure/group or property. Attachment No. 8 is a table that cross references each property directly affected by the proposed route and includes corresponding landowner names and addresses. No known habitable structures were identified within 300 feet of any route at the time they were proposed in Docket No. 49302; however, as shown in Attachment No. 6, the route approved in Docket No. 49302 would directly affect at least one set of habitable structures.
No known habitable structure was identified within 300 feet of the route proposed herein.
20. Permits: List any and all permits and/or approvals required by other governmental agencies for the construction of the proposed project. Indicate whether each permit has been obtained. The following permits/approvals will be obtained after PUC approval of the CCN and prior to beginning construction, if necessary: 1. Texas Department of Transportation permit(s) for crossing a state-maintained roadway. 2. A Storm Water Pollution Prevention Plan will be prepared and a Notice of Intent will be submitted to the Texas Commission on Environmental Quality under the Texas Pollutant Discharge Elimination System program. 3. A cultural resources survey plan will be developed with the Texas Historical Commission for the proposed project. 4. Consultation with the U.S. Army Corps of Engineers will occur following the Commission's approval ofthis Application to determine appropriate requirements under Section 404/Section 10 Permit criteria.
16 February 4, 2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
5. Consultation with the U.S. Fish and Wildlife Service will occur following the Commission's approval ofthis Application to determine appropriate requirements under the Endangered Species Act. 21. Habitable structures:
For each route list all single-family and multi-family dwellings and related structures, mobile homes, apartment buildings, commercial structures, industrial structures, business structures, churches, hospitals, nursing homes, schools, or other structures normally inhabited by humans or intended to be inhabited by humans on a daily or regular basis within 300 feet of the centerline if the proposed project will be constructed for operation at 230 kV or less, or within 500 feet of the centerline if the proposed project will be constructed for operation at greater than 230 kV. Provide a general description of each habitable structure and its distance from the centerline of the route. In cities, towns or rural subdivisions, houses can be identified in groups. Provide the number of habitable structures in each group and list the distance from the centerline of the route to the closest and the farthest habitable structure in the group. Locate alllisted habitable structures or groups of structures on the routing map. The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halffs investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. As depicted on Attachment No. 6 and listed on Attachment No. 7, no known habitable structures were identified within 300 feet of the centerline of the proposed route. 22. Electronic Installations: For each route, list all commercial AM radio transmitters located within 10,000 feet of the center line of the route, and all FM radio transmitters, microwave relay stations, or other similar electronic installations located within 2,000 of the center line of the route. Provide a general description of each installation and its distance from the center line of the route. Locate all listed installations on a routing map. The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halffs investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. There are no known AM radio transmitters that are located within 10,000 feet of the centerline ofthe proposed route and no known FM radio transmitters that are located within 2,000 feet of the centerline of the proposed route. There are two known communication towers (microwave relay stations or other similar electronic installations)-one existing and one planned-that are within 2,000 feet of the proposed route. The approximate distances from each ofthe alternative route links and corresponding routes to the communication towers are summarized in the table below. Facility ID Installation Type Distance to Route (feet) Direction
*** THERE ARE NO AM RADIO TRANSMITTERS WITHIN 10,000 FEET OF A ROUTE ***
17 February 4, 2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
Facility ID Installation Type Distance to Route (feet) Direction
*** THERE ARE NO FM RADIO TRANSMITTERS WITHIN 2,000 FEET OF A ROUTE ***
OTHER ELECTRONIC INSTALLATIONS WITHIN 2,000 FEET OF ROUTE
Tower 1 (proposed) Unknown 960 West Tower 2 Unknown 670 West See also Sections 3 . 7 . 7 and 7 . 7 . 6 of the Environmental Assessment and Routing Study , included as Attachment No. 2. Communications towers located within the relevant distances from the proposed route are shown in Attachment No. 6 and listed in Attachment No. 7.
23. Airstrips: For each route, list all known private airstrips within 10,000 feet of the center line of the project. List all airports registered with the Federal Aviation Administration (FAA) with at least one runway more than 3,200 feet in length that are located within 20,000 feet of the center line of any route. For each such airport, indicate whether any transmission structures will exceed a 100:1 horizontal slope (one foot in height for each 100 feet in distance) from the closest point of the closest runway. List all listed airports registered with the FAA having no runway more than 3,200 feet in length that are located within 10,000 feet of the center line of any route. For each such airport, indicate whether any transmission structures will exceed a 50:1 horizontal slope from the closest point of the closest runway. List all heliports located within 5,000 feet of the center line of any route. For each such heliport, indicate whether any transmission structures will exceed a 25:1 horizontal slope from the closest point of the closest landing and takeoff area of the heliport. Provide a general description of each listed private airstrip, registered airport, and heliport; and state the distance of each from the center line of each route. Locate and identify all listed airstrips, airports, and heliports on a routing map. The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halffs investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. Halff's review of federal and state aviation/airport maps and directories, aerial photography, and reconnaissance surveys identified the following: no FAA-registered airports with a runway greater than 3,200 feet in length within 20,000 feet ofthe proposed route; no private airstrip or FAA-registered airport with a runway no more than 3,200 feet in length within 10,000 feet of the proposed route; and no heliport within 5,000 feet of the proposed route.
See also Sections 3 . 7 . 6 and 7 . 7 . 5 of the Environmental Assessment and Routing Study , included as Attachment No. 2, and Attachment Nos. 6 and 7. 24. Irrigation Systems: For each route identify any pasture or cropland irrigated by traveling irrigation systems (rolling or pivot type) that will be traversed by the route. Provide a description of the irrigated land and state how it will be affected by each route (number and type of structures etc.). Locate any such irrigated pasture or cropland on a routing map.
18 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halff's investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. Results of aerial photography interpretation and field reconnaissance surveys did not identify any pasture or cropland irrigated by traveling irrigation systems (rolling or pivot type) that will be traversed by any of the proposed routes of the Proposed Transmission Line Project. See Table 7-2 in Appendix E ofthe Environmental Assessment and Routing Study, included as Attachment No. 2, and Attachment Nos. 6 and 7. 25. Notice: Notice is to be provided in accordance with 16 TAC §22.52.
A. Provide a copy of the written direct notice to owners of directly affected land. Attach a list of the names and addresses of the owners of directly affected land receiving notice. A copy of the written direct notice, with attached map, that will be provided to owners ofdirectly affected land and all parties that intervened in DocketNo. 49302 is included as AttachmentNo. 9. A list ofthe names and addresses ofthose owners of directly affected land and Docket No. 49302 parties to whom notice will be mailed by first-class mail is included as Attachment No. 8. B. Provide a copy of the written notice to utilities that are located within five miles of the routes. Not Applicable - no other utilities are located within five miles of the Proposed Transmission Line Project. C. Provide a copy of the written notice to county and municipal authorities, and the Department of Defense Siting Clearinghouse. Notice to the DoD Siting Clearinghouse should be provided at the email address found at http://www.acq.osd.mil/dodsc/. osd.dod-sitinq-clearinghouse(Ei.mail.mil A representative copy of the written notice, with attached map, that will be provided to county and municipal authorities is included as Attachment No. 10. The following county agencies will be provided the requisite notice on or before the filing date: Loving County, County Judge The following municipalities will be provided the requisite notice on or before the filing date:
Not Applicable - no municipalities are located within the project area.
19 February 4, 2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
A representative copy of the written notice, with attached map, that will be provided to the Department of Defense Siting Clearinghouse at the specified email address is included as Attachment No. 10. D. Provide a copy of the notice that is to be published in newspapers of general circulation in the counties in which the facilities are to be constructed. Attach a list of the newspapers that will publish the notice for this application. After the notice is published, provide the publisher's affidavits and tear sheets. Notice for this Application will be published in The Pecos Enterprise , a newspaper of general circulation in Loving County. A copy of the newspaper notice to be published is included as Attachment No. 11. Proof of publication will be provided in the form of publisher's affidavits and tear sheets following publication ofthese notices. For a CREZ application, in addition to the requirements of 16 TAC § 22.52 the applicant shall, not less than twenty-one (21) days before the filing of the application, submit to the Commission sta ff a "generic" copy of each type of alternative published and written notice for review. Staffs comments, if any, regarding the alternative notices will be provided to the applicant not later than seven days after receipt by Staff of the alternative notices, Applicant may take into consideration any comments made by Commission staff before the notices are published or sent by mail. Not applicable. A copy of the Application, in addition to written notice and maps, will be provided to the Texas Office of Public Utility Counsel ("OPUC"). A copy of the notice and maps that will be provided to OPUC is included as Attachment No. 10. 26. Parks and Recreation Areas: For each route, list all parks and recreational areas owned by a governmental body or an organized group, club, or church and located within 1,000 feet of the center line of the route. Provide a general description of each area and its distance from the center line. Identify the owner of the park or recreational area (public agency, church, club, etc.). List the sources used to identify the parks and recreational areas. Locate the listed sites on a routing map. The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halff's investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. After review of federal, state, and local websites and maps, as well as field reconnaissance surveys, no parks or recreational areas owned by a government body or an organized group, club or church were identified within the study area or located within 1,000 feet of the proposed route centerline. See also Sections 3 . 7 . 2 and 7 . 7 . 2 of the Environmental Assessment and Routing Study , included as Attachment No. 2, and Attachment Nos. 6 and 7. 27. Historical and Archeological Sites: For each route, list all historical and archeological sites known to be within 1,000 feet of the center line of the route. Include a description of each site and its distance from the center line.
20 February 4, 2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
List the sources (national, state or local commission or societies) used to identify the sites. Locate all historical sites on a routing map. For the protection of the sites, archeological sites need not be shown on maps. The following information is based on the Environmental Assessment and Routing Study conducted in Docket No. 49302 and Halff's investigation of publicly-available databases regarding this information conducted in December 2020, as it relates to the proposed route. A review of the maps at the Texas Archeological Research Laboratory and the Texas Historical Commission's Archeological Sites Atlas, along with field reconnaissance, were conducted to locate known cultural resources within 1,000 feet of the route for the Proposed Transmission Line Project. THC records indicated no historical or archeological sites known to be within 1,000 feet of the proposed route centerline. THC records indicated no National Register of Historic Places ("NRHP"), State Antiquities Landmarks ("SALs 5,\),or cemeteries recorded within 1,000 feet of the proposed route centerline. See also Sections 3 . 8 and 7 . 8 ofthe Environmental Assessment and Routing Study , included as Attachment No. 2, and Attachment Nos. 6 and 7. 28. Coastal Management Program: For each route, indicate whether the route is located, either in whole or in part, within the coastal management program boundary as defined in 31 T.A.C. §503.1. If any route is, either in whole or in part, within the coastal management program boundary, indicate whether any part of the route is seaward of the Coastal Facilities Designation Line as defined in 31 T.A.C. §19.2(a)(21). Using the designations in 31 T.A.C. §501.3(b), identify the type(s) of Coastal Natural Resource Area(s) impacted by any part of the route and/or facilities. The Proposed Transmission Line Project is not located, either in whole or in part, within the coastal management program boundary as defined in 31 T.A.C. §503.1. 29. Environmental Impact: Provide copies of any and all environmental impact studies and/or assessments of the project. If no formal study was conducted for this project, explain how the routing and construction of this project will impact the environment. List the sources used to identify the existence or absence of sensitive environmental areas. Locate any environmentally sensitive areas on a routing map. In some instances, the location of the environmentally sensitive areas or the location of protected or endangered species should not be included on maps to ensure preservation of the areas or species. The Environmental Assessment and Routing Study prepared by Halff in Docket No. 49302 is included as Attachment No. 2. The relevant tabulation of environmental and land use data relating to the proposed route herein is included as Attachment No. 7. Within seven days after filing the application for the project, provide a copy of each environmental impact study and/or assessment to the Texas Parks and Wildlife Department (TPWD) for its review at the address below. Include with this application a copy of the letter of transmittal with which the studies/assessments were or will be sent to the TPWD. Texas Parks and Wildlife Department Director of Wildlife Mr. Clayton Wolf
21 February 4,2021 Standard Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line and Application for a Certificate of Convenience and Necessity for a Proposed Transmission Line Pursuant To 16 TAC §25.174
4200 Smith School Road Austin, Texas 78744 The applicant shall file an affidavit confirming that the letter of transmittal and studies/assessments were sent to TPWD. A copy of the Environmental Assessment and Routing Study from Docket No. 49302, as well as the maps of the project approvals and the proposed route along with the environmental and land use data table for the proposed route, which are included as Attachment Nos. 1, 2, 6 and 7, will be provided to the Texas Parks and Wildlife Department ("TPWD") for review within seven days following the filing of the Application for the Proposed Transmission Line Project. See Attachment No. 13 for a copy of the transmittal letter which will be sent to the TPWD. 30. Affidavit Attach a sworn affidavitfrom a qualified individual authorized by the applicant to verify and affirm that, to the best of their knowledge, a!1 information provided, statements made, and matters set forth in this application and attachments are true and correct.
31. List of Attachments to the CCN Application Attachment No. 1: Map Regarding Project Approvals Attachment No. 2: Environmental Assessment and Routing Study from Docket 49302 Attachment No. 3: ERCOT Endorsement Letter, Independent Review Report dated June 12,2018 Attachment No. 4: Existing Transmission Area Map Attachment No. 5: Schematics of Transmission System in Proximate Area of Project Attachment No. 6: Project Map of Proposed Route (Overview and Figures 1-11) Attachment No. 7: Environmental and Land Use Data for Proposed Route (with Comparison to Route Approved in Docket No. 49302) Attachment No. 8: Notice Mail Out List for Directly Affected Land Owners and Docket No. 49302 Parties Attachment No. 9: Copy of Direct Notice to Directly Affected Land Owners and Docket No. 49302 Parties Attachment No. 10: Copy of Direct Notice to Utilities5 Counties, Municipalities, OPUC, and Department of Defense Siting Clearinghouse Attachment No. 11: Copy of Newspaper Notice Attachment No. 12: Copy of Direct Notice to Pipeline Owners/Operators and Permian Basin Petroleum Association Attachment No. 13: Transmittal Letter to TPWD Attachment No. 14: Affidavit
22 February 4,2021 Kyle Ranch-Quarry Field 138kV ~ RIVERTON-KYLE RANCH Transmission Line Project: /.-.-.-.-.-.-.-.. TERMINUS Map Regarding Project Approval ,
1 KYLE RANCH/ SUBSTATION
1 0 4,000 8,000 16,000
Scale in Feet 0 1 2 4 (*=t RIVERTON U <+Ph-l SWITCH Scale in Miles Legend Approved in Dkt. 49302 (Not Subiect to this Filing) Approved in Dkt. 49304 ATTACHMENT ~ Kyle Ranch-Quarry Field Project Endpoint ® Riverton-Kyle Ranch Project Endpoint td Kyle Ranch - Quarry Field PUC Approved Route .4.'Riverton-Kyle Ranch PUC Approved Route -Wansmission Line Route Sublect to this Filing /~Proposed Modified Route QUARRY FIELD
NO. SWITCH
1 r ENVIRONMENTAL ASSESSMENT AND ALTERNATIVE ROUTE ANALYSIS
for the proposed
Kyle Ranch-Quarry Field 138 kV Transmission Line Project in Loving County, Texas
Oncor Electric Delivery Company LLC P.O. Box 970 Fort Worth, Texas 76101
By ...... HALFF 1201 North Bowser Road Richardson, Texas 75081
MARCH 2019
ATTACHMENT NO 2 25 Printed on 100% post-consumerrecycled fiberand Sustainable Forestry lnitiative certified fiber. Made in the USA...... TABLE OF CONTENTS
List of Tables...... iv List of Figures...... iv Acronyms and Abbreviations ...... v
1.0 PROJECT DESCRIPTION 1-1 1.1 Scope of the Project...... 1-1 1.2 Need for the Project...... 1-2 1.3 Description of Proposed Construction...... _...... 1-2 1.3.1 Transmission Line Design...... 1-2 1.3.2 Right-of-Way Requirements...... 1-2 1.3.3 Clearing Requirements...... 1-2 1.3.4 Monopole Structure Assembly and Erection...... 1-3 1.3.5 Conductor Stringing...... 1-3 2.0 ROUTE SELECTION METHODOLOGY 9-1 2.1 Study Area Delineation...... 2-1 2.2 Data Collection...... 2-2 2.2.1 Solicitation of Information from Local, State, and Federal Officials and Agencipg 2-2 2.2.2 Reconnaissance Surveys...... 2-8 2.3 Constraints Mapping...... 2-8 2.4 Identification of Preliminary Alternative Route Links...... 2-9 2.5 Public Involvement Program...... 2-10 2.6 Adjustments of Alternative Route Links Following the Public Participation Meeting. 2-11 2.7 Evaluation of the Alternative Routes 9-11 3.0 ENVIRONMENTAL SETTING OF THE STUDY AREA 3.1 Constraints Mapping...... 3-1 3.2 Physiography and Geology...... „...... 3-1 3.3 Soils...... 3-2 3.3.1 Soil Associations ...... 3-2 3.3.2 Prime Farmland...... 3-9 3.4 Water Resources...... 3-9 3.4.1 Surface Waterand Floodplains...... 3-9 3.4.2 Groundwater/Aquifer...... 3-10 3.5 Ecology...... 3-11 3.5.1 Vegetation...... 3-11 3.5.1.1 Terrestrial Vegetation...... 3-16 3.5.1.2 Aquatic/Hydric Vegetation...... 3-25 3.5.1.3 Commercially or Recreationally Important Vegetation 3-26 3.5.1.4 Endangered and Threatened Plant Species...... 3-26 3.5.2 Fish and Wildlife .3-28 3.5.2.1 Terrestrial Wildlife...... 3-28 3.5.2.2 Fish and Aquatic Wildlife...... 3-38 3.5.2.3 Commercially or Recreationally Important Fish and Wildlife Species .3-38 3.5.2.4 Endangered and Threatened Fish and Wildlife Species...... 3-39
Halff Associates Page i ...... 3.6 Community Values and Community Resources...... 3-47 3.7 Land Use...... 3-48 3.7.1 Urban/Residential Areas . 3-48 3.7.2 Recreation Areas...... 3-49 3.7.3 Agriculture...... 3-50 3.7.4 Industry...... 3-50 3.7.5 Aesthetics...... 3-50 3.7.6 Transportation/Aviation...... 3-51 3.7.7 Communication Towers...... 3-52 3.8 Cultural Resources...... 3-52 3.8.1 Cultural History 3.8.1.1 Paleoindian...... 3-53 3.8.1.2 Archaic...... 3-54 3.8.1.3 Late Prehistoric...... 3-54 3.8.1.4 Protohistoric...... 3-55 3.8.1.5 Historic...... 3-55 3.8.2 Records Review...... 3-55 3.8.2.1 Previous Archaeological Investigations ...... 3-55 3.8.2.2 Previously Recorded Archaeological Sites ...... 3-56 3.8.2.3 Historic Sites ...... 3-56 4.0 IDENTIFICATION OF PRELIMINARY ALTERNATIVE ROUTE LINKS 5.0 PUBLIC INVOLVEMENT PROGRAM.., 5-1 6.0 MODIFICATION OF ALTERNATIVE ROUTE LINKS 6-1 7.0 EVALUATION OF THE ALTERNATIVE ROUTFR 7-1 7.1 Impacts on Physiographyand Geology...... 7-1 7.2 Impacts on Soils...... 7-1 7.2.1 Soil Associations ...... 7-1 7.2.2 Prime Farmland...... 7-2 7.3 Impacts on Water Resources...... 7-2 7.3.1 Surface Water and Floodplains...... 7-2 7.3.2 Groundwater/Aquifer...... 7-4 7 . 4 Impact on Ecosystems ...... 7 - 5 7.4.1 Vegetation...... 7-5 7.4.1.1 Terrestrial Vegetation ...... 7-5 7.4.1.2 Aquatic/Hydric Vegetation ...... 7-6 7.4.1.3 Commercially or Recreationally Important Vegetation...7-6 7.4.1.4 Endangered and Threatened Plant Species...... 7-6 7.4.2 Fish and Wildlife...... 7-7 7.4.2.1 Terrestrial Wildlife...... 7-7 7.4.2.2 Fish and Aquatic Wildlife...... 7-9 7.4.2.3 Commercially or Recreationally Important Fish and Wildlife Species...... 7-10 7.4.2.4 Endangered and Threatened Fish and Wildlife Species...... 7-10 7.5 Summary of Natural Resources Impacts...... 7-12 7.6 Impacts on Community Values and Community Resources...... 7-12 77 Land Use Impacts ...... 7 - 13 7.7.1 Urban/Residential...... 7-13 7.7.2 Recreation Areas...... 7-14
Page ii Halff Associates ...... 7.7.3 Agriculture...... 7-14 7.7.4 Aesthetics...... 7-14 7.7.5 Transportation/Aviation...... 7-15 7.7.6 Communication Towers...... 7-17 7.8 Cultural Resources Impacts...... 7-17 7.8.1 Historical Summary...... 7-19 7.8.2 Archaeological Summary...... 7-19 8.0 LIST OF PREPARERS 8-1 9.0 REFERENCFR 9-1
APPENDICES A Agency Correspondence B Public Involvement C Preliminary Route Modifications D Link Composition of Alternative Routes E Environmental Data for Evaluation of Alternative Routes F Environmental and Land Use Constraints Map
Halff Associates Page iii ...... TABLES 2-1 Newspaper and Publication Date for Notice of Public Participation Meeting... 2-10 3-1 Soil Association within the Study Area...... 3-5 3-2 Upland Plant Species inthe Study Area ...... 3-24 3-3 Endangered, Threatened, or Rare Plants...... 3-28 3-4 Amphibian Species within the Study AreA 3-30 3-5 Reptile Species within the Study Area...... 3-30 3-6 Bird Species which May Permanently Reside within the Study Area...... 3-31 3-7 Bird Species which May Breed within the Study Area...... 3-32 3-8 Bird Species which May Winter within the Study Area...... 3-33 3-9 Bird Species which May Migrate through the Study Area...... 3-35 3-10 Mammal Species within the Study Area...... 3-36 3-11 Game Species within the Study Area...... 3-39 3-12 Endangered, Threatened, or Rare Wildlife Potentially in the Study Area...... 3-40 7-1 Link Composition of Alternative Routes...... Appendix D 7-2 Environmental Data for Alternative Route Evaluation ...... Appendix E 7-3 Alternative Link Proximity to High Probability Areas for Archaeological Sites.. 7-20 8-1 List of Preparers...... 8-1
FIGURES 1-1 Project Location Map...... 1-5 1-2 Typical 138 kV Tangent Double-Circuit Monopole with One Circuit in Place..... 1-7 2-1 Project Area Map...... 2-3 2-2 Study Area Boundary Map...... 2-5 3-1 Environmental and Land Use Constraints Map...... Appendix F 3-2 Geologic Atlas of Texas Map...... 3-3 3-3 Soil Association Map...... 3-7 3-4 Major Land Resources Area Map...... 3-13 3-5 Land Cover Map .3-17 6-1 Revisions of Links B2, D3, and D4...... C-1 6-2 Revisions of Links C3 and G4...... C-3 6-3 Revisions of Link D2...... C-5 6-4 Revisions of Links G2 and 12...... C-7 6-5 Revision of Link Il ...... C-9 6-6 Revision of Link I3...... C-11 6-7 Revision of Link Jl ...... C-13 6-8 Revision of Link J2...... C-15 6-9 Revision of Link Kl...... C-17
Page iv Halff Associates ...... ACRONYMS AND ABBREVIATIONS A . D . anno Domini ( after Christ ) APLIC Avian Power Line Interaction Committee ARC AR Consultants, Inc. B.C. Before Christ BEG Bureau of Economic Geology BMP Best Management Practice C Candidate Species CCN Certificate of Convenience and Necessity CFR Code of Federal Regulations Centerline CNAH Center for North American Herpetology CR County Road DM Recovered, delisted, or being monitored species DoD Department of Defense E State Listed Endangered Species e.g. exemp# gratia (for example) EMST Ecological Mapping Systems Cover Type EOID Element Occurrence Identification number EPA Environmental Protection Agency EPRI Electric Power Research Institute ESA Endangered Species Act ESI Environmental Science Institute et al . et alia ( and others ) FAA Federal Aviation Administration FEMA Federal Emergency Management Agency FM Farm-to-Market Road (e.g. FM 866) FPPA Farmland Protection Policy Act GIS Geographic Information System GHMs General Highway Map GLO Texas General Land Office Halff Halff Associates, Inc. HPA High Probability Area . e . id est ( that is ) ISD Independent School District kV kilovolt (1,000 Volts) LRR Land Resource Region LE Federally Listed Endangered Species LT Federally Listed Threatened Species MBTA Migratory Bird Treaty Act MLRA Major Land Resource Area msI Mean Sea Level
Halff Associates Page v ...... ACRONYMS AND ABBREVIATIONS NDD Natural Diversity Database NGS National Geographic Society NHD National Hydrology Data Set NRCS Natural Resources Conservation Service (an agency of the USDA) NRHP National Register of Historic Places NWI National Wetlands Inventory NWP Nationwide Permit Oncor Oncor Electric Delivery Company LLC OTHM Official Texas Historical Markers PCN Pre-construction Notification PUCT Public Utility Commission of Texas ROW Right-of-Way RRC Railroad Commission of Texas SAL State Antiquities Landmark SCS Soil Conservation Service (agency was renamed NRCS, see above) SGCN Species of Greatest Conservation Need SH State Highway (e.g. 302) sp. Species spp. Species (plural) SWPPP Storm Water Pollution Prevention Plan T State Listed Threatened Species TARL Texas Archeological Research Laboratory TASA Texas Archaeological State Atlas TDA Texas Department of Agriculture TCEQ Texas Commission on Environmental Quality THC Texas Historical Commission TNRIS Texas Natural Resource Information System TPWD Texas Parks and Wildlife Department TWDB Texas Water Development Board TxDOT Texas Department of Transportation U.S. United States US United States Highway USACE United States Army Corps of Engineers USDA United States Department of Agriculture USFWS United States Fish and Wildlife Service USGS United States Geological Survey USNPS United States National Park Service var. Variation
Page vi Halff Associates ...... 1.0 PROJECT DESCRIPTION
1.1 Scope of the Project Oncor Electric Delivery Company LLC (Oncor) proposes to construct a 138 kilovolt (kV) transmission line from the proposed Kyle Ranch Substation to the proposed Quarry Field Switch, both located in Loving County, Texas, United States (U.S.). The proposed Kyle Ranch Substation will be located west of County Road (CR) 300 (referred to as CR 2 in Appendix A), approximately 5 miles southeast from the intersection of Farm-to-Market (FM) 652 and CR 300. The proposed Quarry Field Switch will be located west of CR 300, approximately 5 miles north of the intersection of CR 300 and CR 22. The proposed transmission line project will be approximately 15 to 21 miles long. Each of these project endpoints is shown relative to the location of the nearby towns and communities and the state and county boundaries on Figure 1-1.
Oncor retained Halff Associates, Inc. (Halff) to identify and evaluate alternative routes, and to prepare an Environmental Assessment and Alternative Route Analysis report to support its application for a Certificate of Convenience and Necessity (CCN). The routing study conducted is incorporated into this document. This report has been prepared to provide information and address the requirements of Section 37.056(c)(4)(A)-(D) of the Texas Utilities Code, Public Utility Commission of Texas (PUCT) Procedural Rules Section 22.52(a)(4), PUCT Substantive Rules Section 25.101, and the PUCT CCN application form for a proposed transmission line. This report may also be used in support of local, state, or federal permitting activities that may be required for the proposed project.
To assist Halff in the evaluation of the proposed project, Oncor provided Halff with information regarding the need, construction practices, and right-of-way (ROW) requirements for the proposed project. Oncor also provided information regarding the engineering and design requirements for the routing study.
The following sections include a description of the proposed project (Section 1.0), an explanation of the methodology used to select alternative routes (Section 2.0), a description of the existing environmental and social conditions in the study area (Section 3.0), and a description of the preliminary alternative routes that were developed by this process (Section 4.0). The public involvement program is described in
Halff Associates Page 1-1 ...... Section 5.0, and a discussion of changes to preliminary alternative route links following the receipt of public input and other information is described in Section 6.0. An evaluation of expected environmental impacts is presented in Section 7.0, followed by a list of report preparers (Section 8.0), and bibliographical references used in preparing this report (Section 9.0). The appendices include copies of agency correspondence (Appendix A), public participation meeting information (Appendix B), preliminary route modifications (Appendix C), route definitions (Appendix D), alternative route environmental data (Appendix E), and environmental and land use constraints maps (Appendix F).
1.2 Need for the Project Oncor will provide support for the purpose and need for the proposed project as a part of the CCN application.
1.3 Description of Proposed Construction
1.3.1 Transmission Line Design For the proposed project, Oncor anticipates the use of a self-supporting, double-circuit steel or concrete pole (Figure 1 -2). Design criteria will comply with applicable statutes, the appropriate edition of the National Electrical Safety Code, and Oncor's standard design practices. The typical structure height is anticipated to be 85 to 105 feet, but pole height will vary depending on terrain. The results of site-specific geotechnical and engineering studies will be used to determine the appropriate design and placement of the structures.
1.3.2 Right-of-Way Requirements The proposed ROW width for the proposed project will be approximately 70 feet. The ROW normally extends an equal distance on both sides of the transmission line centerline. Additional ROW may be required at line angles, dead ends, or for terrain-related constraints.
1.3.3 Clearing Requirements All brush and undergrowth within the ROW will be removed and maintained. For areas requiring hand-clearing, vegetation will be cut level with the ground. No stump exceeding 2 inches above the ground will remain. Any tree located in a fence line having a diameter greater than 4 inches will be cut even with the top of the fence. Stumps located on hillsides
Page 1-2 Halff Associates ...... or uneven ground will be cut where a mowing machine can pass over the ROW without striking any stumps, roots, or snags.
1.3.4 Monopole Structure Assembly and Erection Foundations for the monopole structures will be completed before erecting the structures. If the monopole is to be directly embedded, then a single hole will be augured into the ground at each structure location. Once the structure has been placed, the foundation will be filled with concrete, native material, or other approved material to hold the structure securely in place.
If the pole is to have an anchor bolted foundation, a hole will be augured into the ground at each structure location, an anchor bolt cage will be placed in addition to steel rebar to reinforce the foundation, and the hole will be filled with concrete. Depth and diameter of the foundation will vary depending on the design of the structure specific to that location.
1.3.5 Conductor Stringing Once a series of structures has been erected along the transmission line centerline, the conductor stringing phase can begin. Specialized equipment will be attached to properly support and protect the conductor during the pulling, tensioning, and sagging operations. Once conductors and shield wire are in place and tension and sag have been verified, conductor and shield wire hardware are installed at each suspension point to maintain conductor position. Conductor stringing continues until the transmission line construction is complete. All construction equipment will be removed. All temporary culverts and environmental controls previously installed will be removed.
Halff Associates Page 1-3 ......
