Harris> David Wm., M.S., Spring, 1985 Geology
Crustal Structure of Northwestern Montana (63 pp.)
Director: Dr. Steven Sheriff S ^
Northwestern Montana is a structurally complex and diverse re gion of the northern Rocky Mountains. Hie regional Bouguer gravity map of the area demonstrates significant differences in the crustal structure between northwestern Montana and surrounding areas. Gravity modeling of the long-wavelength Bouguer anomaly, which is believed to be related to the configuration of the crust- mantle boundary, agrees well with previous seismic refraction surveys indicating a crustal root under the approximate position of the Rocky Mountain Trench. The Purcell anticlinorium and related geophysical anomalies north of the Lewis and Clark line and south of the Moyie fault appear to be the result of high- density low-susceptibility Purcell sills emplaced into the Lower Prichard approximately 870 m.y.b.p. Subsequent to their emplacement the sills were deformed concentrically with the encasing Belt strata by compressional forces related to the formation of the fold and thrust belt. Later modification by extensional tectonics and erosion led to the present day configuration of the Purcell anticlinorium and related features such as the Sylvanite anticline. A combination Purcell sill- basement ramp anticline model is also possible and, therefore, does not preclude the possibility of crystalline basement involvement in thrusting at depth. It appears unlikely that Phanerozoic rocks extend west of the Whitefish listric normal fault in the subsurface, therefore ex ploration for Paleozoic hydrocarbon reservoirs should be limited to the area immediately west of Glacier National Park. Addition ally, the probability of Paleozoic strata in the subsurface below the Hefty thrust decreases to the west toward the Rocky Mountain Trench. Two Tertiary basins of northwestern Montana, the Rocky Mountain Trench and the Kishenehn Basin, may be hydrocarbon productive if stratigraphie and structural development prove favorable.
13.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. ACKNOWLEDGEMENTS
In looking over the project I quickly realized that it would take
twenty pages to properly thank all the people who helped in this
endeavor. I thank the members of my committee. Dr. Steven Sheriff, Dr.
David Alt and Dr. Randy Jeppesen and former members Dr. David Fountain
and Dr. Anthony Qamar for their discussion and critical suggestions
about the problem and resultant manuscript. I wish to thank the people
at Marathon Oil Company for all their help and support and in
particular: Robert Whitman and Joe Kruger for discussion relevant to
potential field problems; Dave Ryan and Steve Adams for discussion about
the structure of northwestern Montana; Eric Potter for his help and
review of my work; Susan Daut for help with the gravity modeling program
modification; Barbara Daily for typing above and beyond the call of
duty; Kevin Lupton and the drafting department at Marathon for some
excellent (and time consuming) drafting and last but not least Robert
Shamlian, Bob Lantz, Steve Hollis and Dar Spearing for putting a foot
where it was needed.
I would like to thank David Campbell for allowing me to get a copy
of his gravity modeling programs before they were published and for en
during my subsequent ignorance, Viki Bankey for reduction of my data at
the U, S. G. S. and discussion of and about the data, Susan Bloomfield
Moore for help with computer work that wouldn't go away, Dolores Kulik
for discussion about gravity modeling and tectonic problems of the re
gion, and John Cady for discussion about crust-raantle structure and for
pointing out some relevant references I had overlooked.
i i i
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. A special thanks goes to Carol Piza-Harris who gave me unfailing
love and support throughout my field acquisition and our years together.
I would also like to give special thanks to Bill Boberg, who, through
long discussions helped me sort through the structural problems of
northwestern Montana and to Kurt Constenius who endured long discus
sions, in particular, on the structural problems of and near the
Kishenehn Basin and for a great time in the field.
I thank John Herrlin, John Garrigues, Elena and Mike Vigdorchik, and
Tom and Mary Hoar for their continued friendship and support. Thanks
must also go to my feline friends Nacho, Margarita, and Tequila plus the
late Taxco and Taco who created trouble and amusement for me on a daily
basis. I also wish to thank all those not mentioned who pulled strings
for and against me. To my parents Sam and Betty Harris, my sister Laura
Harris Lansing, and my grandmothers Pearl Harris and Grace Chatham there
is no way I can possibly express how much their love, support, patience
and understanding has meant to me on this project. Finally I wish to
dedicate this work to my grandfather William Henry Chatham who gave me a
sense of history and unparalleled joy in my early years.
1 V
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. TABLE OF CONTENTS
Page
ABSTRACT...... Ü
ACKNOWLEDGEMENTS...... iii
LIST OF FIGURES...... vi
LIST OF PLATES...... vii
LIST OF TABLES...... viii
CHAPTER
I. INTRODUCTION L
II. PURCELL ANTICLINORIUM: PROGRESS AND PROBLEMS...... 3
III. GRAVITY SURVEY OF NORTHWESTERN MONTANA AND NORTHERN IDAHO...... 6
Gravity Data Collection...... 6
Gravity Data Collection...... 7
IV. STRUCTURAL INTERPRETATION OF NORTHWESTERN MONTANA...... 9
Oil and Gas Possibilities in Northwestern Montana...... 35
V. CONCLUSIONS...... 43
APPENDIX...... 45
BIBLIOGRAPHY...... 59
V
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. LIST OF FIGURES
Page
Figure 1. Gravity anomaly map of the northwestern United States In Pocket
Figure 2. Bouguer gravity map of northwestern United States and southwestern Canada.. In Pocket
Figure 3. Correlation chart of Belt nomenclature according to selected references...... 12
Figure 4. Structure map on Précambrien crystalline basement...... 14
Figure 5. Structure map on the base of the Lewis thrust plate...... 15
Figure 6. Regional structural section - Pincher Creek - Waterton •* Flathead...... 16
Figure 7. Regional Bouguer gravity map of Montana and adjacent areas of wavelengths greater than 250 km. In Pocket
Figure 8A. Crustal root model A ...... 19
Figure 8B. Crustal root model B ...... 20
Figure 9. Synthetic seismogram - Shell MacDonald well...... In Pocket
Figure 10. Physical properties of rocks in and near the Purcell Trench In Pocket
Figure llA-F. Schematic cross section of Belt Basin, the Purcell anticlinorium and related features...... 31-34
vx
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. LIST OF PLATES
Plate 1. Complete Bouguer gravity map of theKalispell 1 X 2 degree sheet...... In Pocket
Plate 2. Complete Bouguer gravity map of the Cut Bank 1 X 2 degree sheet ...... In Pocket
Plate 3. Complete Bouguer gravity map of the Wallace 1 X 2 degree sheet In Pocket
Plate 4. Regional cross-section A-A'...... In Pocket
Plate 5. Regional base map...... In Pocket
Plate 6, Regional cross-section B-B'...... In Pocket
Plate 7. Alternate cross-section C-C’...... In Pocket
vxi
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. LIST OF TABLES
Page
Table 1. Purcell sill/Prichard Fm. rock density vs. Purcell sill/Prichard Fm. rock percentage...... 29
Vlll
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. CHAPTER I
INTRODUCTION
Northwestern Montana is a structurally complex and diverse region
in the western Cordillera of North America. The regional Bouguer
gravity map of northwestern Montana, southern British Columbia and
Alberta (Figs. 1 and 2; Plates 1-3) reveals significant differences in
this region in contrast to surrounding areas. The region is dominated
by the northwest trending gravity high of the Purcell anticlinorium
which, in turn, is bounded by parallel lows both to the northeast and
southwest (Plate 1). On the northeast the Purcell high is bounded by
the low of the Rocky Mountain Trench and farther to the northeast the
low of the Kishenehn Basin. To the west the bounding gravity low
corresponds to the Libby Trough. The gravity high of the Purcell
anticlinorium ends abruptly to the south at the Lewis and Clark line and
to the north at the Moyie fault (Fig. 2; Plate 3). To the east the
northwest striking gravity anomaly trends grade into the generally
northeast striking anomalies reflecting the Archean crystalline basement
structure of the Great Plains. West of the Purcell anticlinorium the
northeast trends give way to amoeboid anomalies of the Idaho Batholith
area and Eastern Metamorphic Belt (Fig. 1).
The obvious differences pointed out above in the gravity signature
of northwestern Montana, southern British Columbia and Alberta, as
opposed to surrounding areas, suggest a differing crustal structure.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 2 The primary purpose of this study is to combine existing geologic and
geophysical data with new gravity data generated as part of this study
to give a comprehensive picture of the crustal structure of northwestern
Montana with particular emphasis on the structure and evolution of the
Purcell anticlinorium. I focus on the area roughly defined by the
Kalispell and west half of the Cut Bank U.S.G.S. 1 by 2 degree
topographic sheets.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. CHAPTER II
PURCELL ANTICLINORIUM: PROGRESS AND PROBLEMS
Structural development of the Purcell anticlinorium has been dis
cussed in a number of investigations since 1977 (Wynn et al., 1977;
Harrison et al., 1980; Constenius, 1980; Price, 1981; Fountain and
McDonough, 1984), Any interpretation as to the structural development
of the Purcell anticlinorium (south of 49 degrees N) must take into
consideration the prominent gravity high as well as the lack of any
corresponding magnetic anomaly over the feature. Wynn et al. (1977),
utilizing audio-frequency magnetotellurics and gravity, modeled the
anticlinorium as a horst block rising 11 km. above a flat crystalline
basement at a depth of 17 km. The pre-Belt crystalline basement horst
complex suggested by Wynn et al. (1977) is 25 km. across and 6 km. below
the surface. Wynn et al. dismissed the aeromagnetic data because it
showed only local highs overmagnetite-rich Ravalli Group rocks. Thus
the magnetic anomalies do not correlate with deeper structure. Harrison
et al. (1980) concur and note that, "the deeply buried Precambrian
crystalline rocks show no recognizable magnetic expression". Harrison
et al. (1980) interpreted the Precambrian crystalline rocks of
northwestern Montana to be part of the magnetically quiet basement
observed to the south in the Great Basin.
Harrison et al. (1980) suggest stacked slices of crystalline base
ment involved in thrusting west of the Rocky Mountain Trench are the
cause of the gravity anomaly and, in their model, put the basement 6 km.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 4 below the surface to explain the lack of a magnetic expression. Gravity
modeling by Constenius (1981) essentially concurs with the efforts of
Harrison et al. (1980). Both studies require that faults such as the
Whitefish (Wigwam), Lewis, Pinkham, Hefty and Libby all be major thrusts
whereas geologic evidence (e.g. Johns, 1970; Harrison, 1983) suggest
that some of these may indeed have minor stratigraphie offset.
Price (1981), working in the southern Canadian Rockies, proposed
that northwest of the St. Mary and Moyie faults (Fig. 1) the Purcell
anticlinorium is, "a geometric consequence of the juxtaposition of the
thick northeasterly tapering prism of sediment that had accumulated above
the zone of abrupt crustal attenuation, outboard from the continental
margin, with relatively flat, planar basement surface on the continental
platform". Price (1981), in the same vein as Bally et al. (1966), does
not favor crystalline basement rock involvement in the development of
the Purcell anticlinorium northwest of the St. Mary and Moyie faults but
does recognize the possibility of a different style to the south as
postulated by Wynn et al. (1977). Price (1981) also points out that
suspected basement rocks occur above the Purcell thrust fault at about
52 degrees 30 minutes.
Fountain and McDonough (1984) favor a ramp anticline model for the
evolution of the Purcell anticlinorium and use dense crystalline
basement (2.87 gm/cc) at the core of the anticline 5-10 km. below the
surface to account for the observed gravity. Fountain and McDonough
theorize that the Lewis thrust transported the crystalline basement to
its current position. A problem arises, however, in trying to envision
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 5 dense 2.87 gm/cc material thrust up from their postulated 2.75 gm/cc
crystalline basement.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. CHAPTER III
GRAVITY SURVEY OF NORTHWESTERN MONTANA AND NORTHERN IDAHO
Gravity data collection
During the summer and fall of 1981 I measured the acceleration of
gravity, using a Worden gravimeter, at 389 stations in northwestern
Montana and northern Idaho. Readings were taken at road intersections,
bench marks, or any other place where an elevation could be found on a
U.S.G.S. 7 1/2 minute topographic map. The survey extends west from
Cut Bank, Montana to Sandpoint, Idaho and from Kalispell, Montana north
to the Canadian border.
The readings taken at the 389 stations included 15 base stations.
Loops were made by taking a reading at one of the 15 base stations and
within a three hour period (approximately) taking readings at as many
stations as possible and then returning to the base station in order to
"tie the loop". The vast area covered by the survey did not allow for
tieing all base stations in one loop, therefore, as the distance about
the loop became difficult to travel in three hours other base stations
were set up to allow for expansion of the survey. In this manner
traveling back and forth between base stations allowed for determination
of the differences in the acceleration of gravity at the base stations.
Readings taken at a base station every three hours allowed for
determination of drift of the gravity survey each day and subsequent
removal of such drift. Additionally, a reading taken at the Kalispell
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 7 Airport, a location of known absolute gravity (with a value of
980,567.39 mgals) , and tied into the rest of the survey in the manner
described above allowed for the determination of the absolute gravity at
all stations.
Gravity data reduction
United States Geological Survey computer programs were used to re
duce gravity meter readings to observed gravity values by calculating
and correcting for earth-tide and linear meter drift. The theoretical
gravity value was calculated using the 1967 formula of the Geodetic
Reference System (International Association of Geodesy, 1967) given
below.
G = 978031.85 (1 + 0.005278795 sin^ LAT + 0.000023462 sin^ LAT)
where LAT is the latitude of the station in degrees and G is the theoret
ical gravity in milligals.
Complete terrain corrections were also made by the U.S.G.S.
Terrain corrections were made for each station out to a radius of 166.7
km. using the method of Plouff (1977). The terrain corrections computed
by the U.S.G.S. are based on mean elevations digitized on a 15-seccnc
grid for 0 to 5 km., 1-minute terrain data for the corrections from 5 to
21 km., and 3-minute terrain data for the corrections from 21 to 166.7
km.. Terrain corrections were calculated in two parts from 0 to .89o
km. (through the F ring (Bible, 1962)) and from .893 to 166.7 km. The
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. p near correction (from 0 to .895 km.) is often calculated by hand but due
to the scope of this paper and the vast amount of time involved to make
the inner correction by hand the near correction computed by the U.S.G.S.
was used instead. Before using the U.S.G.S. near-terrain correction
values the validity of the computer calculated near-terrain corrections
were tested in several areas. Even in areas of high relief such as
Glacier National Park near terrain corrections varied less than 2 milli
gals (and much less in areas with lower relief) from the computer cor
rected values used in this study. The two terrain values calculated
were added together to obtain the total terrain correction. A density
value of 2.67 g/cc was assumed in calculation of all terrain correc
tions. The U.S.G.S. computer program also incorporates earth curvature
corrections into the complete (terrain corrected) Bouguer anomaly values.
Complete Bouguer values were calculated for each station using an aver
age rock density of 2.67 g/cc. Computed terrain corrections and Bouguer
anomaly values are given in Appendix.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. CHivPTER IV
STRUCTURAL INTERPRETATION OF NORTHWESTERN MONTANA
Many aspects of the crustal structure of northwestern Montana are
controversial and, indeed, poorly understood. It is my attempt here to
combine available gravity data, seismic reflection and refraction data
and previous geologic studies into a structural model of northwestern
Montana.
To arrive at a reasonablestructural model for the northwestern
Montana region surface geology from previous studies (principally Johns,
1970; Harrison, 1983; Ross, 1959), refraction seismic studies (Hales and
Nation, 1973; Asada and Aldrich, 1966; Bennett et al., 1975; Chandra and
Gumming, 1972; Gumming et al., 1978; Mereu et al., 1975; McCamy and
Meyer, 1964; Hill, 1972; Steinhart and Meyer, 1961), previous gravity
studies (Harrison et al., 1980; Wynn et al., 1977; Constenius, 1980,
1982; Kulik, 1982; Fountain and McDonough, 1984), a reflection seismic
line east of the Purcell anticlinorium were combined with two-
dimensional gravity modeling utilizing gravity data collected for
this study combined with a larger data base consisting of U.S.
Geological Survey sources (Wilson, 1978, 1979; McBride et al., 1980;
Brickey et al., 1982; Kulik, 1982), University of Montana data
(Stickney, 1980) and Defense Mapping Agency data. All gravity data
mentioned above were entered into the University of Montana computer
system and subsequently plotted at the same scale as the U.S.G.S. 1 by 2
degree topographic sheets. Gravity data for the Kalispell, Cut Bank,
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. oTid Vval^ace 1 b\ L degree sheets were then contoured by hand after
elimination of spurious points (Plates 1-3).
The gravity data were modeled utilizing a two-dimensional program
written in BASIC by Campbell (1983) of the U.S.G.S. and modified for an
APPLE 11+ utilizing Microsoft BASIC. The computer program used in
modeling is a "‘Talwani-type’* program (i.e. the program calculates
potential-field anomalies over horizontal prismatic bodies having planar
faces) . The "Talwani-type” programs were first introduced by Heirtzler
et al, (1962) and Talwani and Heirtzler (1964). The program used in the
gravity modeling is "two dimensional", that is, the source body is taken
to be infinitely long in the strike direction. Since the structures of
northwestern Montana generally strike consistently to the northwest
(Plate 1) the two-dimensional gravity modeling should work well. This
is, unfortunately, not true in all areas and must be taken into
consideration in gravity modeling. An example of this problem is the
Rocky Mountain Trench, Although the Rocky Mountain Trench is physically
continuous in the strike direction it does not everywhere have the same
amount of low density fill. This is particularly evident in the
vicinity of cross section A-A' where little fill is present relative to
its continuationto the northwest and southeast. Low density fill to
the northwest and to the southeast does influence the observed gravity
along A-A’. Therefore, I modeled the influence of the body trench by
including a schematic Rocky Mountain Trench body (see Plate 4) . The
density value assigned to the Rocky Mountain Trench body is not as
negative as that of the Kishenehn Basin to the east (i.e. -.25 gm/cc
contrast vs. -.35 gm/cc for the Kishenehn basin). The influence of the
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. trench fill is somewhat diminished because it does net directly underlie
the gravity profile. In order to account for edge effects (i.e. the
effect of bodies ending abruptly at the gravity model edge when in
reality the bodies are generally continuous past the end of the profile)
the gravity model was continued 60.97 km (200,000 feet) to the southwest
and 91.46 km. (350,000 feet) to the northeast past the zone of interest
shown on A -A’ (Plate A) . Topography used in modeling gravity profile
A-A’ was visually averaged in a predominately strike direction. The
topography shown on A-A* (Plate 4) is the actual topography.
After choosing a suitable line of cross-section roughly perpendicular
to regional strike (Plates 1 and 2) the next step in modeling the crustal
structure of northwestern Montana was to construct a regional structure
cross-section from surface geologic maps. Johns' (1970) geologic mapping in
Lincoln and Flathead counties in northwestern Montana still stands as the
only mapping that is complete from the North Fork of the Flathead. River
west to the Idaho border. I used Johns’ map as my primary source for the
cross-section west of the North Fork of the Flathead, integrating the more
recent structural interpretations of Harrison et al. (1983) where neces
sary. For consistency, I used the stratigraphie nomenclature of Johns'
(1970) for rocks west of Glacier National Park. In Glacier National Park
itself and to the east I used the geologic mapping and stratigraphie
nomenclature of Ross (1959). Since some of the Belt stratigraphie nomen
clature has evolved since the publication of Johns' and Ross' works I have
included a correlation chart (Fig. 3).
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. ■DCD O Q. C g Q. CORRELATION CHART OF BELT NOMENCLATURE ACCORDING TO SELECTED REFERENCES
■D ROSS, 1959 JOHNS, 1970 HARRISON, 1972 AAP6 COSUNA CHART, 1983 WINSTON el ol, 190'T CD IDAHO MISSOOLA G l.A C ItB , li.'f - 5T LINCOLN AND iJtiî jniji •VESIEfm '* a ADJACENT ALBKRTON6 wHirtnsi s »tvtn KW MOXfUW* DTlT I fASTtWN ID C H IH IlN D lt C/) FLATHEAD COS ST nCSIS M l BAHOt H* dtONtS'tA BASIN DtLT BAS'i C/) GLflClEH PARK MONTANA WESTERN NORTH EASTERN PILCHER PILCHER PHASE CENTRAL PHASE PHASE LIBBT EM GARNET RANGE ARNET BGE GARNET RANGE GRATISH - GREEN L i e e r ROOSVILLEMcNAMARA L IB 8 T FM McN a m a r a M fN AM AR A FM ARGILLITE FM. EM, FM EM
PINK PHILLIPS BONNER 8 BONNER BONNER OUARTZITE BONNER FM STRIPED OUARTZITE FM FM EM STRIPED PEAK (O' k in t l a s h ie l d s MT. FM, MT. s h i e l d s f m . PEAK MT SHIELDS FM FM. EM s h ie l d s FN LIM ESTO NE SHEPARD SHEPARD SHEPARD SHEPARD FM m i l l e r SHEPARD FM LE N SE S FM. FM /T ü r c ê l l A SHEPARD FM FURCEL SNONSLIP \ LAMA l a v a PURCELL LAVA l a v a FM. WESTERN SNOWSLIP SNOWSLir FM 3. G R E E N IS H - SNOWSLIP FM 3" EilASE PHASE CD CALCAREOUS a r g i l l i t e W ALLACE FM ■DCD O Q. HELENA HELENA WALLACE C SITEH WALLACE FM HELENA WALLACE SITEH DOLO. DOLO FM. a FM 3o "O o EMPIRE CMPIRF ST RfO tS F M I IPf ST REGIS FM. r ST. REGIS f m FM FM
RCVETT CD H E V E TT FM. SPOKANE R E VE TT FM SPO'ANE FM Q. FM FM GRINNELL GRINNELL BURKE FM BURKE RAVALLI FM UNDIVIDED APPC- ■D BURKE FM KUNNT CD APPEKUNNT APPEKUNNT APPEKUNNT FM. FM
C/) C/)
AI.TTN PRICHARD PRICHARD FM A L T V N LS FM
PRICHARD PRICHARD WATER- PRICHARD F m FM. FM TOM FM OF CANADA
BASE NOT EXPOSED r\j FIG. 3 13 The thickness of various formations was calculated directlv from
the geologic maps u s m g the dips and contacts grven combined with
information in the text (Johns, 1970) concerning various measured
sections their locality and thickness. The attitude of the crystalline
basement east of Glacier National Park was taken from Mudge’s (1982)
basement map of the northern disturbed belt of Montana (Fig. 4).
Structure or. the Lewis thrust of Glacier National Park was taken from
Gordy et al. (1977) (Fig. 5). Structure of the Paleozoic and Mesozoic
sections under the Lewis thrust plate was modified by myself using
gravity modeling after the work of Bally et al. (1966) and Kulik (1982)
(Fig. 6). The structure cross-section A-A' (Plate 4) in the vicinity of
the Kishenehn basin, on the west side of Glacier National Park (Plates 1
and 2), differs little on a broad scale from the detailed work of
Constenius (1981, 1982) with the exception of my interpretation of the
Hefty-Nyack fault relationship to be discussed later.
The gravity maps of the region are dominated by the gravity high of
the Purcell anticlinorium which in turn is surrounded by parallel gra
vity lows. In looking at this Bouguer gravity pattern (Fig. 1; Plates 1
and 2) one must decide what regional gravity profile must be removed to
isolate the more shallow, short-wavelength sources. The low-pass
filtered Bouguer anomaly map (cutoff wavelength of 250 km.) of
Hildenbrand et al. (1982) (Fig. 7) shows a particularly prominent
Bouguer gravity low over northwestern Montana. In the study area the
map shows a low of approximately -160 mgal. rising both east and west.
Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 14
f.-.y win.I
sv**aumsT **##***# I* «*»••! »##«## •« 3900 DOMC f k * f •«!»<■ #*# * f M ##« » $. Cw* TOOIÎ &alwMi f* mi#a* ■ FLATHEAD
PONDERA / / y
!, -'S»° , X :% .1 0 0 0 T ^ .A'\ T w i n C * e g * - \ , T E T O N eAQocn c*ee%x
emowN Sa»«o$TûN£ #(AA,6m*ov Tmewo .^*s
S A N M A T V N e T R tM O !
CASCADE JUDITH SAitN
tEW fS a n d CLARK t * S T t o u t o # p 9 10 4 0 M n .e s «0 o la ao 30 40 niuOMcTe^s F IG U R E 4 Stfuciure map on Pfecamofiart cr> sullino basement. F R O M M U D C E .1932 Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 15 >T«uCTü«5 WA# ON T**c fHC LEWtS THRUST PLATE •cr^Ftw «mowr* #QoM**T #*3: i^tc*Um *o ###n #N ( t u # # * % «MO kOOMN # » M . l^\ V Wi TilN FIGURE 5 FROM GORDY ET AL.. 1977 Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. ■aCD o cQ. g Û. ■D CD WATCRTOM PINCHER CREEK C/) (/) Ftolhtod I M S 3 I0-Î5 6-6 H'lliof'fig tl-IO 0.300' «.338' H.lOl' B.3t«' 13.133' 3" CD 8 1 0 0 0 m 0000 4000 m -"«.OCO 6000 m 3 CD r I TER1IARY" MISSISSIPPIAN AND DEVONIAN REGIONAL str u c tu r a l SECTION f— j UPPER CRETACEOUS CAMBRIAN PINCHER CREEK-WAFERTON'FLATHEAO CD LOWER CRETACEOUS PRECAMBRIAN BEITIAN ■o AND JURASSIC to O □ T/7T PLO CQ. I'"''"I PRECAMBRIAN SHIEUO a o3 ■o o FIGURE 6 FROM GORDY ET AL., 1977 CD Q. co (A(/) 3o' CT> To i-CSi, wnÊk^ineîT rlild6nbr3.ricî s msp insv incÎGsd r’spr’ssent th6 configuration of the crust—trantle boundary I decided to two-dinensionally model the gravityresponse using depths taken from various seismic refraction studies. Work by Bennett et al. (1975) between latitudes 50 and 53 north along the Rocky Mountain Trench, in the area of a -200 mgal. gravity low (Fig. 2), indicates that the thickness of the crust is in excess of 50 km. Mcreu et al. (1977) in a survey in the vicinity of Jasper, Alberta, in the high Canadian Rockies, also determined the thickness of the crust to be approximately 50 km. Cunning et al. (1978) at approximately 50 degrees north in southern Canada determined that the Moho dips east from approximately 30 km. near Highland Valley (at 50 degrees north latitude, -121 degrees east longitude) to greater than 40 km. under the Purcell anticlinorium. Chandra and Cumming (1972) determined that a crustal root of approximately 5 km. exists under the Rocky Mountains along latitude 50 degrees 30 minutes. Workers in the United States have apparently found a similar crustal root under the Montana portion of the northern Rocky Mountains. Depth or the crust-mantle boundary would not be expected to be as great as that under the Canadian Rockies as suggested by the differing Bouguer anomaly values (Fig. 2). Work by McCamy and Meyer (1964) indicates the crust between Glacier National Park and the Rocky Mountain Trench may be as thick as 43 km. Asada and Aldrich (1966) working with the data of Steinhart and Meyer (1961) and McCamy and Meyer (1964) inferred that the Moho boundary dips west from the continental divide. Hill (1972), from refraction data in eastern Washington, determined that the crust thins Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. to between 30 and 35 km. to the west and southwest. Work by Rales and Nation (1973), with refraction data, determined the crust to be about 37 km. thick in the vicinity of the British Columbia and Idaho-Montana borders. In modeling the crustal root I used two density contrasts between lower crust and upper mantle. Models A and B (Fig. 8) assumed the lower crust was less dense by 0.3 and 0.37 gm/cc respectively. The 0.3 gm/cc contrast was the density difference assumed by Fountain and McDonough (1984) in a study of northwestern Montana. Cady (1980) used a greater crust/mantle contrast of 0.37 gm/cc determined from velocity-density relationships (after Bateman and Eaton, 1967), to model crustal structure in the Omineca crystalline belt of northeastern Washington and southeastern British Columbia. Results of the models (Fig. 8 A and B) give a maximum depth to the Moho of 43.5 and 40 km. below sea level respectively with the crust-mantle interface rising both east and west. The good fit between observed and theoretical gravity (Fig. 8 A and B) lends credibility to the use of a bowl-shaped regional for northwestern Montana in subsequent gravity modeling. In the same fashion as Fountain and McDonough (1984), I view the long-wavelength Bouguer low (Hildenbrand et al., 1982) as representative of the regional Bouguer pattern which is hidden in the observed gravity profile. In order to model the shallow sources I have mathematically subtracted this bowl-shaped regional component (Plate 4). The result is the residual gravity profile used with structural cross-section A-A' (Plate 4). The use of a bowl-shaped regional differs from that of Harrison et al. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 19 D % - I 2 0 0 S -13 0 m< o -1 4 0 U i i=> O < 'ISO 1 wo "*• ——* 2 40 0 sw eo 120 160 200 240 28040 NE Km ■ M O D E L D A T U M >t.S Km 10 20 %E flu 30 Ou i LOWER CRUST 40 (-.3) UPPER MANTLE 50 CRUSTAL ROOT MODEL A Fig. 0 A LEGEND O 0 — &e««w«r t — icoi Ccn*ro»t« ü»«4 ** Mod#! OAW < 0 MAR#*) k— —,# — Shop* u##d f o t Mod#i Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 20 !20 o 0 130 > «J O z K. 140 W g 3 «O « ISO a wI SW 4 0 eo 120 160 200 2 4 0 K m ' MODEL DATUM'15 Km I 20 I X V' WCl 5 0 a LOWER CRUST 4 0 UPPER MANTLE 3 0 CRUSTAL ROOT MODEL B ng. S B LEGEND 0 —O —###*### Gael? I —TK«or«ttcai Grovity 3T I — C«<«'’oat» U m « M e # * Cwivi a «m. pUR<*iS — ft*4lT Shcp# U##d Gre*«t|f Uo4«l Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 21 (1980) who assumed a linear regional with a decrease in the field of 0.2 mgal/km to the west. Several features are obvious in the residual gravity profile along A-A' (Plates 1 and 4). Most outstanding is the prominent gravity high corresponding to the Purcell anticlinorium with gravity lows paralleling it both east and west. The low to the west corresponds to the Libby Trough while that to the east corresponds to the Kishenehn Basin. The Rocky Mountain Trench manifests itself along the profile as a slight flattening of the residual from approximately 114 to 130 km. A more developed part of the Rocky Mountain Trench (manifested as a more pronounced gravity low) can be seen both southeast and northwest of gravity profile A-A' (Plate 1). A subtle residual gravity high at the west end of the profile corresponds to an anticline cored by Prichard Formation on the Libby thrust plate. One of my primary considerations in gravity modeling was the deter mination of reasonable densities for the important geologic units: 1) Lower Prichard-Archean crystalline rocks, 2) Belt Supergroup (exclu sive of the Lower Prichard), 3) Paleozoic rocks, 4) Mesozoic rocks and 5) Quaternary-Tertiary rocks. Various publications use widely varying densities for each of the above rock units. Below is a summary of some recent publications and densities used in their gravity modeling. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. Harrison et al. (1980) 22 PhaneroEoic rocks - 2.64 to 2.68 g/cc. Belt rocks - 2.7 to 2.75 g/cc. Crystaline Basement - 2.8 g/cc. Kulik (1982) Tertiary undivided - 2.35 g/cc. Mesozoic undivided - 2.51 g/cc. Paleozoic undivided - 2.76 g/cc. Belt undivided - 2.55 g/cc. Precambrian basement - 2.67 g/cc, Constenius (1981) Quaternary - 1.8 to 2.0 g/cc. Tertiary - 2.1 to 2.63 g/cc. Proterozoic, Paleozoic and Mesozoic undivided - 2.7 g/cc. Archean crystalline basement - 2.S g/cc. Fountain and McDonough (1986) Deformed sedimentary rock above basement - 2.7 g/cc. Crystalline basement - 2.75 g/cc. Basement material in ramp anticline (causitive body for Purcell anticlinorium gravity high) - 2.87 g/cc. The densities I used for gravity modeling were derived from formation density logs from two wells (Plate 5): Shell Canada Resources Limited - b-30-H Shell MacDonald, in southeastern British Columbia and Husky Oil Co. - #1 Gulf Mercier in Glacier Co. Montana. Other wells in the area were examined but most proved to be of poor quality in the zones of interest. The program used in the modeling uses density contrasts rather than absolute densities. The densities used in modeling are all relative to the density of the Belt Supergroup undivided. The average densities assumed are given below with the relative densities used in modeling given in parentheses (also see Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 23 Tertiary and Quaternary undivided - 2.32 to 2.35 g/cc (-.35) Mesozoic undivided - 2.49 to 2.52 g/cc (-.18) Paleozoic undivided - 2.74 to 2.77 g/cc (.07) Belt undivided (excluding L. Prichard)- 2.67-2.7 g/cc (0) Lower Prichard and Archean Basement (causitive body for the Purcell anticlinorium gravity high ) - 2.8 to 2.83 ’ (.13) One of the main tools used in the interpretation of the Purcell anticlinorium gravity high and, indeed a constraint on the whole structure section A-A’, was a reflection seismic line across the Star Meadow anticline (Plates 1 and 4). Velocities obtained from the Shell MacDonald well, southeast British Columbia (Fig. 9) were used to determine depth and thickness of a prominent reflection package observed on the seismic line beginning at approximately 1.35 seconds (crest of the Star Meadow anticline). The reflection package is seen to dip both northeast and southwest to 1.8 and 1.9 seconds respectively. Thickness of the reflection package varies from roughly 1.25 to 1.5 seconds which corresponds to a thickness of from 3700 to 4600 meters. The seismic reflection package is shown schematically on cross-section A-A'. One notable feature of the reflection package is that it appears to be concentric with the surface geology (i.e. anticlines and synclines exposed at the surface can be seen in the reflection package directly below). This observation leads to two obvious possibilities as to the relationship between the Belt at the surface and the rocks of the reflection package: 1) the rocks of the reflection package were deformed concentrically with the overlying Belt units with no intervening major thrusts (i.e. both the Belt, which is seen to crop our at the surtace, and the reflection package are on the same thrust sheet); 2 ) the rocks above the reflection package were thrust over the underlying reflection Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 24 package and subsequently both hanging wall ana foot wall rocks were deformed concentrically (i.e. folding followed thrusting). The obvious implication of possibility number one is that the reflection nackage could not possibly be Paleozoic or younger sediments. As working constraints for my gravity modeling I made several as sumptions: 1) the top of the seismic reflection package corresponds to the top of the causitive body for the Purcell anticlinorium gravity high and related anomalies; 2) the top of the causitive body occurs at a roughly constant stratigraphie level below the top of the Prichard Formation across the profile and is, therefore, due to its stratigraphie level absent in the vicinity of Glacier Rational Park: 3) there is little lateral density variation in the density units designated above, i.e. Paleozoic undivided. Belt undivided etc.; 4) the rocks of the reflection package (hereafter designated Lower Prichard) in the vicinity of the reflection seismic line were deformed concentrically with the overlying Belt with no intervening major thrusts (i.e. possibility 1 mentioned in above paragraph). An interesting observation can be made upon casual inspection of the complete Bouguer maps of the Kalispell and Wallace quadrangles (Plates 1 and 3). Each of these Bouguer maps shows the outcrop pattern of the Prichard Formation (designated Yp). The pattern of Prichard out crop corresponds well with gravity highs (north of the Lewis and Clark line) as would be expected from assumptions 2 and 4 above. The Sylvanite anticline, in extreme northwestern Montana, is a particularly good example of this relationship (Plate 1). Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. Reasonable velocities obtained for Belt sediments are in the range o'^ A725 to 6000 meters/second (Constenius pers. comm., 1985; Bally et al., 1966) and a sonic log from the Shell MacDonald well which bottomed in the Ravalli Group (Fig. 9). The synthetic seismogram (Fig. 9) shows that, although the reflections in the Paleozoic sequence are more prominent than those in the Belt, reflections in the Belt do occur and would be expected on a normal reflection seismic section. Depths to the prominent reflection package discussed above, using the velocities cited above (relative to sea level), are: 1) southwest limb - -3950 to -4900 meters; 2) crest- -2530 to -3080 meters; 3) northeastern limb - -3720 to -4480 meters. The depths shown in the final gravity model fit well using the Belt velocities cited above. The velocity of the Belt rocks over the crest of the Star Meadow anticline are inferred to be higher than the velocity of the rocks over the southwest or northeast limb. An increase in velocity with depth can be seen on the sonic log of the Shell MacDonald well (Fig. 9) where the velocity of the Kintla Formation (Missoula Group) is notably lower than that of the deeper Grinnell Formation (Ravalli Group). An increase of velocity with depth is quite common and could easily explain the inferred higher velocity of the rocks over the crest of the Star Meadow anticline. A potential problem with the gravity modeling is the sparcity of gravity data along various parts of the profile (A-A'). This problem is particularly evident in the Whitefish Range (see Plate 1) where a cubic spline routine was used to interpolate values. Another potential problem with the gravity model is the inevitable error in the gravity measurements itself (terrain correction, station elevation etc.) and subsequent interpo lation of these gravity values. Despite these innate problems in the data Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 26 the final model A—A (Plate 4) works very well within the assumptions (1—4) outrined aoove. The model shows only slight variations in the thickness of the Prichard Formation above the causitive body (Lower Prichard) which is to be expected if the Prichard thickens to the west. As mentioned above the density contrast of the Lower Prichard unit (or causitive body of the Purcell anticlinorium gravity high) used in the gravity modeling is .13 (absolute density of 2.8 - 2.83 gm/cc) which in some respects seem high. It is, however, within the range of previous works mentioned above (2.8 to 2.87 gm/cc.). As dictated by my assumptions the density contrast must be rather large (i.e. .13 gm/cc), and the causitive body broad and close to the surface in order to account for the observed residual gravity field. Other workers have used lower contrasts which requires, in general, a narrower body with great relief (Harrison et al., 1980; Wynn et al., 1977; Constenius, 1981). Fountain and McDonough (1984) use a greater contrast (.17), with the causitive body narrower and at a greater depth. The evolution of the Purcell anticlinorium has been the subject of various papers and the cause of the gravity high (with a corresponding lack of a significant magnetic expression; see Plate 4) is still a matter for speculation. Within the bounds of the basic observations thus presented, in addition to evidence presented below, two principal models were deemed reasonable for the evolution of the Purcell anticlinorium and related anomalies: 1) emplacement of high—density, low susceptibility (probably altered) Purcell sills, the majority of whose intrusion is generally at a more or less consistent stratigraphie level in the Prichard Formation, with Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 27 subsequent deformation concentric with the encasing Belt (come of these sills crop out on the Sylvanite anticline); 2) a ramp anticline model (e.g. Fountain and McDonough (1984)) with the causitive body closer to the surface; and 3) a combination of 1 and 2. The following rock types potentially fit the high-density low suscep tibility criteria outlined above: 1) carbonates/evaporites; 2) metamorphics 3) intrusive igneous rocks. Given the right circumstances each of these categories could fulfill the requirements. The correct combination of events and, therefore, causitive rock bodies must be deduced from the available data which by no means leads to a unique solution. The use of a carbonate/evaporite sequence causes no conflict with the lack of a magnetic signature and further a thick sequence of dolomites/anhydrites could potentially give the proper density contrast required. In looking at the seismic (i.e. the strong reflection sequence) it is obvious qualitatively that strong velocity/density contrasts exist throughout the sequence. In order to create the observed reflection sequence high density/velocity rocks must alternate with relatively lower density/velocity rocks. Although the density of the pure mineral dolomite is approximately 2.87 gm/cc (Troger, 1952) in nature dolomite (dolostone) is generally impure and a density of 2.8 gm/cc or less is probably a more realistic figure. If dolomite is the high density/velocity rock observed it must alternate with rocks of a lower density/velocity which would lead to a lower average density than required to give the residual gravity anomaly observed (i.e. less than the 2.8 — 2,83 required by the modeling and related observations discussed above). If, however, anhydrite Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 28 (2.96 gm/cc; Troger, 195.i) is used as the high density/velocity rocks and dolomite plus other rocks are used as the lower density/velocity rocks this V ould potentially increase the average density enough to account for the residual gravity anomaly. However, it is unlikely that a thick sequence of carbonates and/or evaporites are present in the Lower Prichard. Smithson (1971) measured rock densities for seven different metamorphic terrains. Mean densities measured ranged from 2.7 to 2.86 gm/cc. Most mean rock densities of metamorphic terrains, however, fell between 2.7 and 2.79 gm/cc. Under the proper circumstances high density metamorphics could be contrasted with other metamorphics (say 2,76 gm/cc) to give the proper reflection sequence as well as the high average density needed to satisfy the residual gravity anomaly. Suscepti bilities of metamorhpic rocks are quite variable (Dobrin, 1976) and could potentially be of high density and yet of low susceptibility. Harrison et al. (1972) state that, "Sills of Precambrian gabbrc to quartz diorite are abundant in the lower part of the Prichard Formation." The study by Harrison et al. (1972) covers the region of the Purcell Trench of northern Idaho. Harrison et al. (1972) state that there is no time or genetic connotation implied, between the Purcell sills and the Purcell lava. The Purcell sills vary dramatically in thickness ranging up to 900 meters (3,000 feet) and also vary along their strike. The age of the sills is uncertain but a "fresh" sample gave an age of approximately 8/0 m.y.b.p. which Harrison et al. (1972) consider to be a minimum age. Density of the sills averaged approximately 2.92 gm/cc (Fig. 10) and were deemed to be of sufficient mass to produce well defined gravity anomalies. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 29 Density and susceptibility values of the Purcell sills fit veil within the requirements set forth above. It is not difficult to imagine that the Purcell sills could alternate with the normal Prichard Forma tion within the reflection sequence to give the high average density required (i.e. 2.8 to 2.83 gm/cc) over the 4573 meter interval observed ssismically as well as cause the reflection pattern observed. In the vicinity of the Fairview anticline (Plate 1 and 4) the top of the causi tive body (as modeled) starts at approximately 610 meters below sea level and continues down to 10,670 meters. In this area the causitive body is thus about 10,000 meters thick. Below 10,670 meters I have assumed that there are no lateral density variations, therefore, all density variations causing the residual Bouguer gravity anomaly lie above this depth. Table 1 shows Purcell sill and Prichard Fm. density versus Purcell sill and Prichard Fm. percentage over any interval which gives the 2.8 gm/cc average density required by gravity modeling. Sill Prichard Sill Prichard Density Density % % (gm/cc) (gm/cc) 2.92 2.67 52 48 2.92 2.70 46 54 2.92 2.72 40 60 2.92 2.75 30 70 3.00 2.67 40 60 3.00 2.70 33 67 3.00 2.72 29 71 3.00 2.75 20 80 Table 1 - Purcell sill/Prichard Fm. rock density vs. Purcell sill/Prichard Fm. rock percentage over a given interval to give average density of 2.8 gm/cc over that interval. It is a matter of conjecture which of these values for the densit} of the Purcell sills and the Prichard Fm. is correct. In my modeling I Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. use 2.67 to 2.7 gm/cc for the Belt Supergroup which leads to a roughly 50/50 ratio of Purcell sill to Prichard Formation rocks given the average density of 2.92 gm/cc (Harrison et al., 1972) for the sills. If a higher value for the average density of the sills and/or the Prichard Formation is used then the percentage of sills drops accordingly. A hypothetical model of the evolution of the Purcell anticlinorium is shown schematically in Fig. 11. Injection of the Purcell sills takes place during or just subsequent to deposition of the Upper Belt (based on the dates given by Harrison et al. (1972) (Fig. 11; a, b). The Purcell sills are subsequently deformed concentrically with the rest of the Belt leading to the development of the Purcell anticlinorium (Fig.11; c-e). Deformation in southern Canada within the fold and thrust belt spans the interval from late Jurassic to Paleocene time (Price and Mountjoy, 1970). Modification by extension and erosion leads to the present configuration(Fig.11 f) . This model uses the Purcell sills as the causitive body for the gravity anomaly, however, substitution of a carbonate/evaporite sequence or a metamorphic complex (possibly utilizing dense metamorphosed Lower Prichard Formation) for the Purcell sills could also fit the data as it stands. I believe, however, that the data best fits the Purcell sill scenario. The combination of a ramp anticline model (possibly in the form of basement involvement at depth) as in Fountain and McDonough (1984) and the Purcell sill model set forth above would not violate the data. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. "OCD O Q. C g Q. "O CD SCHEMATIC CROSS SECTION OF BELT BASIN C/) THE PURCELL ANTICLINORIUM C/) AND RELATED FEATURES CD SW NE 8 © U. BELT 3. 3 " CD ■DCD O Q. C a 3o "O o CD Q. BELT BASIN PRIOR TO EMPLACEMENT OF PURCELL SILLS ■D CD FIGURE II C/) C/) David Wm. Harris 11/84 CO 73 ■OCD O Q. C g Q. ■D CD NE (gC/) o"3 U BELT 2, CD 8 5 c q ' 2: LEGEND 3i CD /: | ZONE OF PURCELL "H C EMPLACEMENT OF PURCELL SILLS SILLS 3. 3 " CD RELATIVE DISPLACEMENT CD ■D SW NE O Q. PA PURCELL ANTICLINORIUM C PHANEROZOlCS a O 3 BELT ■D NO SCALE O COMPRESSION CD L.DELT Q. ■D CD C/) INCIPIENT THRUSTING DEFORMS PURCELL SILLS CONCENTRICALLY C/) WITH BELT AND PHANEROZOIC SEDIMFNTS ' FIGURE II David Wm. Harris 11/84 oo ro ■DCD O Q. C g Q. sw ■D PA PHANCnoZOlCS CD WC/) 3o" O COMPRESSION 8 ci' 3" ï 3 CD THRUSTING PROPAGATES 3. TO THE EAST 3 " CD CD SW ■D PA O Q. C a O 3 ■D O COMPRESSION -''I CD Q. ■D CD 3 CONTINUED PROPAGATION O F THRUS1ING C/) W TO THE EAST LEADS TO DEVELOPMENF OF o" PURCELL ANTICLINORIUM Ü OTHER STRUCTURAL FEAIURES FIGURE (I David Wm. Harris 11/84 w LO 34 LU rr CO O en t O 3 q: LU g c5 J 2 1 g O LU (— X LU V- >* Lü CQ W Q zr m LU LU OC Q 3 O O ÜJ CD en C. LU or z> LU H- _J W _J m < Z O co en LU tr CL 5 O U co en LU H- X LU Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 35 Two models of the structure in the vicinity cf the Purcell anticlinorium are presented in cross-sections A-A’ and C-C* (Plates 4 and 7), Both of these structure cross-sections are reasonable given the gravity modeling and the surface geologic data. The main difference in the cross-sections is the angle of the Pinkham thrust leading to a differing attitude of crystalline basement. In cross-section A-A* the attitude of the Pinkham is quite steep thus raising the possibility that the Lewis (basal thrust) drops off steeply (to avoid the Pinkham thrust cutting downsection in the direction of transport) suggesting the possibility of crystalline basement involvement below the Purcell anticlinorium in this area. An alternate interpretation in the same area (C-C’; Plate 7) shows the Pinkham thrust as much shallower (in places a bedding plane thrust) thus allowing the basement to remain at a relatively constant angle across the cross-section. This model suggests that any basement involvement would show up to the west where the Lewis thrust may potentially involve crystalline basement. Either of these models of structure in the vicinity of the Purcell anticlinorium is valid given the data used in this study. Oil and gas possibilities in northwestern Montana Another controversial subject involving the structure of northwestern Montana has been determining how far to the west Phanerocoic rocks extend in the subsurface. This question is critical to determining how far west potential oil bearing strata may exist. The data at my disposal on uHc Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 3 6 subject are nOv.> unfortunately, conclusive. In the determination of how much Paleozoic/Mesozoic strata could potentially be under Belt rocks west of Glacier National Park it is critical to take into consideration the following: 1) the thickness of the Belt west of the park; 2) the attitude of the crystalline basement west of the park; 3) the structural positions and configurations of various major thrusts in this vicinity (e.g. Hefty, Whitefish (Wigwam), Lewis etc.). In the construction of cross-sections A-A' and B-B' (Plates 4, 6) values for thickness of Belt and attitude of basement played a major role. Boberg (1984) notes that by combining the thickness of the Belt found in the Shell MacDonald well with drilled thicknesses from the Pacific-Atlantic Flathead well (Plate 5), in addition to a local measured section, a thickness approximately 4880 meters of Belt can be determined in the area just west of Waterton National Park, Canada. This thickness agrees well with the 5213 meters maximum Belt thickness determined by Whipple et al. (1984) for Glacier National Park, Dip of the basement west of Glacier National Park is difficult to determine. Bally et al. (1966) put the dip of the basement at approximately 2 degrees. It is not unreasonable to put a greater dip on the basement west of Glacier National Park. Kulik (1982) states that the Belt strata in Glacier National Park are preserved in a shallow structural depression in the crystalline basement suggesting the possibility that the attitude of the basement is not constant. It is not cleai how this basement depression would manifest itself west of the park and, therefore, does not preclude the possibility that the basement west of the park dips more steeply than to the east. The depth to the Lewis Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 37 thrust on cross-section A-A west of the park was determined by gravitv modeling constrained by surface geology in addition to the thickness of Belt cited above. The dip of the basement on cross-section A-A' is modeled at approximately 5 degrees. Bally et al. (1966) note that the "Cambrian event of the foothills can be traced to the east side of the Trench." This implies that, at least in the southern Canadian Rockies, the Lewis plate rides on a veneer of Cambrian strata until it ramps at the position of the Flathead fault where a duplex of Paleozoics is developed below the Lewis plate. By combining gravity modeling with the observation of Bally et al., 6400 meters of Belt strata may be present between the Lewis and the Hefty plates (Plate 4; see theoretical gravity values vs. residual gravity anomaly curve). By using the 4880 meter thickness of Boberg (1984) up to 1525 meters of Paleozoic strata may exist under the Hefty plate (Plate 4; see alternative model theoretical gravity vs. residual gravity anomaly curve). The curve fit without Paleozoics beneath the Hefty plate is obviously better than the fit with the Paleozoics. This observation does not preclude the existence of Paleozoic strata beneath the Hefty plate in this area for a variety of reasons, including: I) the density of data points in the Whitefish Range is rather low and may net reflect the true Bouguer gravity anomaly in the area; 2) density values may vary from those used in modeling; 3) the high density "Lower Prichard" unit utilized west of the Whitefish fault (see Plate 4) may be imbricates of Paleozoic rocks thereby requiring the Hefty thrust to cut up section faster than on A—A ’ and thus the Hefty would be shallower than shown. This would imply that Paleozoic strata may extend as .ar Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. west as the Rocky Mountain Trench.; 4) the dip of the basement may be greater than shown, thus allowing for but not requiring, more Paleozoic strata under the Hefty thrust. The nature of the Hefty thrust in the vicinity of A—A ’ is a matter of speculation, for its trace is not ex posed much farther south than the Cleft Rock Mountain area (see Plates 1, 5, and 6, NE Kalispell quadrangle). From its position on Cleft Rock Mountain, where Missoula Group rocks overlie Paleozoic carbonates (see B-B’, Plate 6), the Hefty ramps laterally more than 300 meters to a structurally lower position not far to the southeast. Constenius (1981, 1982) mapped a down-to-the-east fault, known as the Nyack, in approxi mately the same position as the Hefty fault would project. Constenius views the Nyack as a rotated antithetic normal fault related to the evolution cf the Flathead listric normal fault system. It is possible, however, that the Nyack is indeed the Hefty thrust whose leading edge is buried by Cenozoic sediments of the Kishenehn Basin. The latter hypo thesis is used in the construction of cross-section A-A'. Structure cross-section B-B' is close to where Boberg (1984) calcu lated 4880 meters of Belt strata. Consequently, this thickness of Belt is used between the Lewis thrust and the Hefty-Wedge Mountain thrust system and still allows for a substantial thickness of Paleozoic strata even with the shallow dip of the basement (3 degrees) used. Manipula tion of the angle of the Hefty and the dip of the basement could easrly allow for more Paleozoics under the Hefty and potentially extend them as far west as the Rocky Mountain Trench. Extension of Phanerozoic rocks in the subsurface west of the Whitefish Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 39 fault is also a matter for speculation, however, balancing a cross- section with Phanerozoics west of the Whitefish fault is problematic. Additionally, if the rocks of the Star Meadow anticline reflection package were deformed concentrically with the overlying Belt, and have no intervening major thrusts. Paleozoic rocks, if they exist west of the Whiterish fault, must be below the reflection sequence (i.e. greater than approximately 7620 meters subsea in this area) and a major thrust plate with a corresponding Belt package (although probably somewhat thinner) repeated below. This, I feel, is a highly unlikely occurrence. Moulton (1984) cited the presence of Cambrian rocks in the Libby Trough as evidence that Paleozoics extend in the subsurface west under the Libby thrust. In order to gain more Paleozoic strata in the subsurface to the west under the Libby thrust the Libby would cut downsection in the direction of transport. Cambrian rocks in the Libby Trough more likely represent the last remnants of Paleozoic strata in the area which were caught in thrust splays preserved by subsequent rotation of the strata by listric normal faults rotated into an underlying thrust, and therefore would not be expected to extend far into the subsurface to the west (see Plate 4). The potential for substantial amounts of Paleozoic strata in the subsurface is greatest in and near Glacier National Park. Potential for commercial hydrocarbon accumulations is good east of the Kishenehn Basin where imbricate stacks of Paleozoics are postulated to exist southeast along strike of the Pacific—Atlantic Flathead well (see A—A and B—B ; plus Plate 5) which encountered Paleozoic strata below the Lewis thrust at 1340 meters. West of the Kishenehn basin (A-A' and B-B') potential Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 40 for xinbricats stacks cf Paleozoic strata also exists under the Heftv plate. The strata in these imbricate stacks is presumably equivalent to that which produce prolific amounts cf hydrocarbons at Waterton Field in Canada. It seems reasonable to assume that if the same source and reservoir characteristics exist in the Paleozoic strata of the imbricate stacks east and west cf the Kishenehn Basin, then finding commercial hydrocarbon production is dependent on the determination of a favorable structural position with a seal and mature hydrocarbon source. West of Che Whitefish fault there appears little chance for the existence of Paleozoic strata in the subsurface, and therefore, little chance for commercial hydrocarbon accumulations. Aside from the Paleozoic potential cited above, potential also exists in two Tertiary basins of northwestern Montana: the Rocky Mountain Trench and the Kishenehn Basin (Plate 1) . The source and reservoir rock potential of the Rocky Mountain Trench of the United States is virtually unknown. In the United States the Rocky Mountain Trench is apparently the result of extension leading to development of a linear northwest—southeast striking system of listric normal faults which developed by rotation into reactivated thrust surfaces (A-A'; Plate 4). The differential movement of the normal faults has led to variable basinal development along the Rocky Mountain Trench and, therefore, differential valley fill along strike. Stickney (19SC) suggests approximately 825 meters of valley fill in the vicinity of Kalispell. Stickney's modeling was not, however, over the area wj.th the lowest gravity indicating that this is not a maximum value for thickness of fill. Additionally, if the density value of 2.2 gm/cc for Cenozoic Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. rocks used in Che study is too low then the Rocky Mountain Trench would be deeper. Even if source and reservoir rocks exist in the Trench it is Problematic whether the sediments have ever been buried deep enough to generate significant quantities of hydrocarbons. In the United States the Kishenehn Basin is a more developed version of the Rocky Mountain Trench. The sediments of the Kishenehn Basin are reportedly up to 3660 meters thick (Constenius pers. comm., 1985) and dip generally to the northeast into the Flathead fault which bounds the basin on the northeast, Constenius (1981) notes that rocks of the Kishenehn Basin are well suited as potential reservoir rocks. Mammal fossils and radiometric dating indicate the age of the Kishenehn sediments is early to middle Oligocene (33.2 4-/- 1.5 m.y.). Oil shales classified as kerogenous calcilutites and associated sapropelic coals are exposed in the basin and attain a thickness of approximately 85 meters (280’) (Constenius and Dyni, 1983). It is unknown, however, how much of this potential hydrocarbon source rock is buried in the subsurface. These oil shales and coals are at the pre-generation stage at the surface (Constenius and Dyni, 1983), however, it seems reasonable to speculate that these rocks could reach thermal maturity in the subsurface. Numerous oil and gas seeps have been discovered in the vicinity of the Kishenehn Basin (Boberg, 1984; and Constenius, 1981). It is not known whether the source of the hydrocarbons is the sediments of the Kishenehn Basin or Paleozoic/Mesozoic sediments under the Lewis plate (Constenius, 1981). A deterrent to hydrocarbon exploration in the basin is the fact that large portions of the Kishenehn lie in Glacier National Park. If, however, the continuity of reservoir rock, in addition to favorable juxtaposition of source, seal, and reservoir rock, allows for updip. mi- Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 42 gr^tlon over long distances some of the highest hydrocarbon potential could fortuitously lie outside the park. Although it seems reasonable to assume that both stratigraphie and structural traps may exist within the Kishenehn Basin, structural traps would initially be easier exploration targets since subsurface strati graphie information is sparce. Using geophysical techniques such as seismology and gravity analysis, structural traps could be defined. Structural traps may exist in the form of rollover structures bounded by listric and antithetic normal faults of the Flathead fault system. These postulated listric and antithetic normal fault-bounded rollover structures would presumably be best developed (as well as source rock more mature) in the deeper parts of the Kishenehn Basin and, therefore, potential for commercial hydrocarbon accumulation appears greatest inside Glacier National Park. Similar rollover structures along the Khitefish listric and antithetic normal fault system and related systems may exist in the Rocky Mountain Trench and could be potential targets for hydrocarbon accumulations. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. ai CHAPTER V CONCLUSIONS The synthesis of the data thus presented leads to many speculations regarding the nature of the crustal structure in the northwestern Montana region. From the data presented it is reasonable to conclude that the Purcell anticlinorium is cored by Prichard Formation strata that have been intruded by high-density low-susceptibility Purcell sills at a generally consistent stratigraphie level. Subsequent to their emplacement the sills were deformed concentrically with the encasing Belt sediments. Ultimately, these sills give rise to the observed gravity and magnetic signatures as well as to the present structural configuration of the Purcell anticlinorium and related features (e.g. Sylvanite anticline). A combination Purcell sill-basement ramp anticline model is not in violation of the data thus presented. This hypothesis will be tested by the Arco-Marathon #1 P. Gibbs well which has been drilled at the crest of the Fairview Anticline (Plates 1 and 4) to a depth of almost 5500 meters. Gravity modeling of the crust-mantle boundary tends to confirm re fraction seismic data indicating a crustal root under the approximate position of the Rocky Mountain Trench. The modeled amplitude of this root is dependent on the density contrast used between lower crust and upper mantle. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 44 The westward extend of Phanerozoic rocks in the subsurface west of Glacier National Park is problematic. It appears that Phanerozoic hydrocarbon potential west of the Nhitefish fault (Rocky Mountain Trench) is virtually non-existent. Hydrocarbon potential in Paleozoic rocks along the west side of Glacier National Park is good if substantial thicknesses have been preserved under the Hefty and Levis plates. The Tertiary sediments in the Kishenehn basin and Rocky Mountain Trench may contain commercial hydrocarbon reserves if stratigraphie and structural development prove favorable. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 45 Appendix: Principal Facts of Gravity Data Explanation of headings Identification sta id Gravity identification. Location latitude North latitude in degrees minutes and hundredths of minutes. longitude West longitude in degrees, minutes, and hundredths of minutes. ele Station elevation in feet. State where station is located. Gravity observed Observed gravity in milligals. theoretical Theoretical gravity. Corrections terrain Terrain correction out to 166.7 km in milligals. Bouguer Elevation correction in milligals. curv Curvature correction in milligals. special Not used, Anomalies free-air Free-air anomaly in milligals. complete-Bougue: Complete Bouguer anomaly in milligals for designated densities. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 46 a r #A c © # r A> pgA © © © 9 A A A 9 K 0 © © 0 © © O A . n ay IP fA PA •'te 0 P *A, A» 0 A *p 0 9 A a 0 A A rj 0 kO <8 0 O *- rc O z> 'C 1 * z Al ■n • • • • • « * » • • (3 © * v W| kP 00 0 5f 9 0 0 9 'P 9 pA 9 P S f n K * pA — ^ lA ^ r\j Aj ^ #m y 3 #A 9 9 9 i r © i r •« #A «8 < pA < r ir k© • < < « w d i/> tr <■£.£) «C tp a : T 5 1 < « « » t « 1 1 1 ( 1 t 1 # I 1 1 1 > • ## 1 $ 1 1 1 1 t • • » t t t I • t I K. 0 — kw © — Ai IP © #A pk». 9 9 c t r •M 9 or cr &r e? AT Ct' © 9 ^ C' tr c c f \ n 0 p 9 P 9 9 i/> A 9 0 9 9 A 0 0 p A C A p 0 0 • c 9 0 0 ■ ^ O C 9 0 D C) #« t ^ te. • ••»• «•«•* -# r g 0 «0 © © •A IP 0 © 0 c P t p 0 •> © 0 © 0 ■A © © *P i f \ ^ C /* t*' a . te 0 9 9 9 9 i r * r © <0 -0 « C f 0 «8 c r <8 - £ X 1 0 k8 ^ *C O «6 C T t 1 1 1 1 1 1 f 1 1 1 # t 1 t r 1 •« 1 1 1 1 « 1 t • te> * ■ I I I I I I I • » I 0 kO m fA © 0 9 0 A A « 0 4»# 0 mmi © 0 *A 0 0 «A -n Mk pA f' © »A P P 0 0 w or c #A IT tek © te. 4 9 A te «C K" «C «D 9 «0 © ©• 9 te 9 9 9 r- A P K» A A. 9 PP te' © te0 9 Cr 9 tr © © A 9- lA I-" © A © ir A K- AA A cc c A 9 9 te© © AAA AA •A A # — •A •A "T\ A P 9 9 A P A •A PP ify PPPPPPP P P p 0 P 9 « t # • t 1 i # • t 1 t « «1 1 » • 1 1 1 1 1 t 1 <* 9 0 0 0 0 9 0 0 0 0 OOOOO OOOOO OOOOO 09000 90000 00090 — © 0 0 9 0 OOOOO 00099 90000 9COOO ©OOOO O 9 9 O 9 COOOO tok •»••• ••••« •«••• *•««« «••*« •«•«• •*•«• «^U 0 9 0 9 9 OCC9C 00900 99900 OCOCC OOCOO 00090 00900 Z 05 > c te te A A 0 kC © fte A kf kf K" © te e C © te © k© te pkb te 9 C 9 A kC C © © © © © 9 X pO •A 9 •a 9 9 9 m A A A r*> AA •A fA A 0 0 0 0 • • •• ••••••• • *•••••• • • •*••• *••*• ♦•*•• s • V 1 r 1 1 1 t 1 1 1 1 111J1 1»11« 1• t » 1 > 1 • > 1 1 • 1 1 » • f 1 > 1 te. te PM kf c r«k 0 © A 9 9 © te P te © © 9 3. «W © P © © © © «»* p k© © 9 © P P 0 mr © mm te 0 fk. te 0 © 0 P te 9 *# A te 9 9 9 9 A 0 © © 9 9 © 0 © A •A A Z 0 2 •0 A © mn A «0 © te. c 0 m 0 0 P 9 0 © p A © © © 9 0 9 © k© a C © P A te © te te p p te © A k© P 0 A © «ik A A A «r P te A A 0 A te te kC e © o ^ 9 9 9«^000 K- O0 Oce "9 ^ kO 'O #- * c > A*Af«“©«. 9 9 C ir A AK K* te A cr p. A A 9 9 9 P cr #" 9 0 & #. 9 9 #f 9 ce. o o o o r - » n * ^ c o o © ot> o0 o 0 ^ o-0 —5 s aA aAf o0 «aoo-a-a0 0 PPP P 9 P ^ 3 T TZ T ? 'ZZ te» ir IT ©> © © © © © © %r a © W P P P ----.-p P P PPPP ._ P P If . P P PP 4r4Tirv‘i/’ .-. -- •-©ififtpir — ■- V3 OOOOO OOOOO 9 0 0 0 0 9 0 0 0 0 0 0 0 0 0 0 0 0 0 OOOOO 0 0 9 0 0 & F EEEES EEEEC ^ A O ^ "A -A "TS *A #A 0 te. 0 Al A p 9 p 0 9 0 0 0 V AJ te ■M- te te te 9 't tr © A. %C ^ A — 4P 9 9 t^C V» A f» t # * • 1 • t 1 1 1 1 # 1 1 1 * i 1 1 » © © te «£ cr «r P c r f A or tr y te © P p 9 ■C 0 "»© 9— 9 t>-^OîJ"r f 0 kO T © ro 9 © © © © c*»- ••••* «•«*• P r* 0 9 û 0 9 p 0 © © > •t^-P'AP© Al-A O é O 9 O 8 A A A A A f V A A A A pf r" ,f pf pr • ^ A A- A A A A^»*'**'A - —— AA AA A A — A g. a e v a s a t r c L c r ► C «rccao'tr m 9 t cC «f g. cr c ce Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 47 S:/::: s;;:;: s s s s : Ê i E E ! E E S E ï iE^E!^ EEEz^ EEEEE ^ÊËË:^ #-4 or 13 t I I I I %%i:.'L'i z^%%z.z %%'5.%'L ':!.^t%% *•••• **••• •••»• ••«•* «•**• »•••• »•*•• •••»• _ ^ zr ^ T IT — •^005» .., 3 g. -, » ^ ^ nj-^LnsrO' ^SflTTÆ a 9^ x a i i ^ ^ r^a«^r^r^ o «f ^ ^ 'WL •c^û 9 X AJ X AJ X 0 0 0 X Aj 9 tr» 9 0 X 9 rw 0 tn lA LP 9 rv A lA u. ft 9 X 0 0 0 0 0 0 0 0 0 0 0 0 0 a 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 c 0 0 O' 0 0 0 0 0 0 0 0 0 0 0 0 0 c 0 0 0 0 C c 0 0 0 0 0 0 0 0 0 0 0 0 0 *r L_ 0 0 c C 0 0 0 0 0 0 0 0 0 0 C 0 0 c 0 0 0 c CC 0 0 0 0 0 a. 0 0 0 0 0 0 Z en #— > rv 9 9 0 IM » X tr* IT Aj 0 0 0 0 0 0 A. 0 «C 0 A* X 9 %r IT 0 0 » IT f- » f- f- » » f- in XX Z nj A, t\t AJ Ai 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 %- %; ••*••••**• • ♦ * • • *** *•*♦* *♦•*• •••*• ••••• O U % f # t # 1 9 1 9 » 1 1 1 « 1 # 1 I 1 1 1 I»1•f ff111I 11 • 1 1 I t 1 1 1 U. U.' » 9 ff IT 0 g: ps. 9A 0 IT ir X 0 X IT 9 X t- fv tn » 0 0 9 tn M\ X «C X r- X in 0 0 o AAX r** » if 0 9 0 0 0 0 9 9 4P 0 9- cr p- 9 0 0 A.’ tr A 9 9 tn f- c 0 0 0 0 0 0 Aj » CD Ai 0 > O' AI X X X AJ CD <0 "A 0 X> AJ m 0 0 CD» CD in PA O' 0 X» 0 0 X Al 9 X to 0 AJ AJ X 9 9 X 9 «0 9 9 •A Ai PA 9 9 Ai PA » X 9 AJ AJ 9 9 9 9 9 »T IT IT 9 M". K ff. pf. ff K' PA A. A, K rv AJ fL A- ft A A. A A AJ A A ir , rp- p^’K K~ W » > » > » » 0* 0 0 0 » 0 > » 0 0 0 0 » 0 » 0 »» > » 0 0 0 0 O' o- > 0 0* > » 0 0* O' ^ cr 0 0 C 0 0 0 C 0 C 0 C- 0 0 0 C 0 0 0 0 0 0 0 0 0 C 0 0 c 0 0 c c C 0 c 0 C' c 0 O C ODX X GO %» T X X X X X G> CD X oD ID CO X CO X fO 3D X T «0 CDX X <0 X ao XX X ec X X CO to > u. e C O’ 0 0 0 0 c 0 0 0 0 0 0 0 0 0 0 0 0 0 0 » 0 0 0 0 0 0 0 0 O' 0 » 0 » 0 0 0 0 r 9 » 9 f*. 9 0 9 P-. 9 > AJ f-. PA 0 cc 0 9 AI rA r- Ai p-^ 0 •A Ai Ai 9 9 9 X«X AJ 9 0 & e cc » f f 0 X cc 9 ir X 0 0 X i r ft 0 X 0 0 0 r\> QL A 0 I f CC 9 0 » A 9 0 4/ > tt ç«- rvic tt q a X X (C €C OC »- X A. « C f ^ A ' C ' K CC X A. f- C « C X X X 9 — fO 3 IT 3 ^ ^ ^ ^ ^ fcO X X ^ f* r*"- p"» ^ f»» X X f» 0»»X®XX X A* ^ ^ XCOiCjXO ^ virtriAiT iriririrtf tfirififir &r v kr */ ir ifioififir irirtfiriT iririrvrx iririnirir Xr/> 0>3»000ac«.«cc OOOOO OOOOO «««.ttec a«r«r«Lec OOOOO ac Ç X e € e € E E e e E E E £ E EE e E E E e E E £ E EEGEE £ £ E E E E EEEE 0 0 0 0 0 a 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 e> 0 0 0 s> 0 0 0 0 0 0 0 0 9 0 0 0 AJ 0 Ji X XX jy X m uA 9 3 *A m 0 X» 0 9 in D m ■A X n 'M 0 X X A4 9 X 9 ff K r~ K a f- ff X C X e 9 ft 0 C c 0 c X ir ir 0 D •jy ~T 9 r— Ai M A# Ai •A Ai Al 0 0 9 AJ 0 9 0 9 ff K ff ff ff K* ff ff ff K ff- ff ff ff K ff ff ff K> ff ff K ff ff ff ff K fp' ff "A AJ 0 0 PA «A •A AJ 0 AJ fpp. nj O -n Aj "V n in Ai A A> ■A Ai PA 0 y AJ y e X 0 C c c q ff O. I f f - u. c X X X X #v » ir ir X X A r- X in 0 ff 0 C c. X c IT > f - 0 X c rt ff f 1 0 c a ft ff XA A ft A C 0 (- X -A ♦A PA m JA JA y .n y AJ AJ — -* y AJ AJ M y AJ «A 9 9 rA 9 9 7 9 9 9 9 9 0 9 9 < c 9 9 9 ? 9 9 y -A -f ■A A 9 9 9 9 9 y 9 ft 3 1 1 1 1 1 1 1 1 t 1 I • 1 1 4 4 I t t t • Il 1 1 1 1 4 1 • 1 1 4 I 1 1 ** ir o- c XT r- n 0 9 X C ff tr n fp- ir P- in LT C IT c* K K K“ U" •*• •- ff n- 0 f — AJ 0 0 X AJ — < D 0 0 0 0 C 9 > JU C c 9 0 9 9 9 9 "C -O ■0 ■0 0 c • X D y 0 9 A i AJ 0 y in A 9 7 9 A j > 0 3 6 r-. o y» 9 r- 9 9 —• — f^ 9 9 p* ff ft ft A f. prp^KAfA O y f A A fp K K' ft n f\ A ft A A ft ft ft ft A A ft A A 9 g p a. a g a z o U L O a Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 48 cr r» « tw cc A. fT> m. 4M> fw —. g lA LA 0 9 0 40 tr 7 A» O' A 7 er T 1 1 I• 1 I I 1 f • 1 1 t > 1 1 1 1 • 1 If11f t1•1• •1• • 1 1 « • « 1 fw fw A. — #«pr fw «. w i f If c q 0 fA I f 0 AJ 0 C o- ff' i f •- or €►f". 0 7 p*^. 7 •r •A ? lA » m fw « #A O' 0 7 l> £ Al 0 X> Al -*» 0 £ .0 0 « 45 C' 40 Lu Aj 0 AJ 0 7 m 0 wA •0 > £ sD*0 7 Xt X> 7 *U 0 7 40 -A £ « £ 7 %»0 £ 7 pO 0 * tO & a II lA lf> lf> I f 9 lA IT i r I f to 10 LAlA to If t r LAIf AJ AJ M' pA K-. p*^ 9 7 i f if. A K«i f i f A rv PA PA X 0 C X f 1 I f 1 1 t 1 1 1 I f 1 t t t «I 1 1 1 I 1 1 1 t t » 1 « I 1 1 1 1 # t t t L> 7 •A 7 LA «0 fw C^ lA 7- C* m #A AJ iO *A AJ O' 7 0 0 Al fw PH. *0 0 CD PA 7 0 OP 7 ct A; i f fw fA ' f H" fv. 7 A. f^. a: A- AJ rv C fV 7 A 7 ec f^ i r Al 0 40 A 0 to 9 I f w cr o- C. 7 t 0 i f ? LACFOTr 7 cr fw cr IC rv a 9 < ff. i f Al CD7 A if fw «C. A 7 P 4P u. 7 3 7 •A 7 7 7 7 iO lA 7 7 7 7 7 7 ru AJ AJ I 1 • A4 •A 7 AJ 7 Al Al -O 40 40 7 t % 1 1 t 1 1 J I 1 c I 1 f • f t 1 1 1 » 1 I 1 1 1 » • 1 1 # t 1 1 1 1 t —; < 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 C 0 0 0 0 0 e- C 0 0 0 C 0 0 c C 0 c CC 0 0 C 0 e* 0 0 0 0 0 0 0 0 0 0 w cr u. 0 0 0 c 0 0 0 C- 0 0 0 0 c 0 0 0 0 0 c ts 0 0 c e 0 0 0 0 0 c 0 C 0 0 0 C c 0 0 C- Z trCL > 10 to A j 0 AJ e 0 7 7 pH 0 7 7 I f 7 pA C to 7 < £ AJ 7 7 0 PA 10 pH or 0 0 0 0 0 6 0 0 0 0 0 A A j AJ A l 0 0 0 0 7 7 7 7 w a> 0 0 0 t_ • > 1 1 1 1 1 « * « • « 1 1 1 1 # 1 1 1 1 1 1 t 1 1 t I 1 1 1 1 • 1 • f i 1 1 4^ K C c IT en 0 mm 7 pm^ 0 i r pm P». «0 «» p*k fw A pH 7 i f A 0 pm £ fH e A j 7 PH A pH. 7 pm a D i f 0 Ph. 0 f 4» 0 7 04 4 f CD 7 0 CD 0 PA A l CD &f 7 pm 0 PA CD A l PA 0 f© 7 <0 PA PA Ct LS => PA -"A I f 4> A j 0 A l 0 CD 0 0 TV 90 i f •0 A 0 ■£ 7 CO 7 I f I f "A aO 7 7 e A l cr C 0 c - 0 C 0 0 c e 7 0 e p^ pm pm A e 0 c AJ c 0 e O' 7 CD • 1 1 1 c 1 1 1 » 1 f t 1 I I t f « 1 1 t 1 1 1 • $ • 1 1 1 1 1 * $ » 1 1 1 1 1 1_ A l t o 7 g K oO IT i f 7 0 7 pA f cr 4; pm c t r A < 7 *. pm < pm 'O 7 <• K cr #w 0 0 < Aj lO 7 CO pw pH 0 0 7 9 LO 0 £ 7 CD 7 7 41 30 n j 7 CD e 7 7 - f 4 f 7 I f 7 <0 7 7 «D S. % w . -* 0 0 0 #— A l •A i f m I f 7 K l 7 0 *"— f 7 i f 'O p f PA 7 7 •V A l — A l •0 #A —— PA AJ *A 7 0 i f pH 0 If 7 0 0 PA 7 e pA Aj 7 «■■ If 7 0 C 4^ CC K' A j CC CD pw 9 0 cr e •H 40 IT 7 cr pm 0 7 pH 9 CD PA•A#A 7 if pH PA *A •A 9 PA •© PA 7 9 PA 7 CD PAPA 0 9 •f if rA 9 £ 0 •A 0 9 pH lO Lf if pH «0 0 PA 7 PA 7 lA Al 0 CO pH -A 9 -7 tf 7 9 PAPAPA 0 7 lA •A m VI AJPA pm If pm IV A j AA A' 7 7 if if tf if If 9 rv tf If AA, AA.K 9 9 if tr rv if A. 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 •— e t 0 c C- e C 0 C» <5 0 C c- c C C C 7 0 0 C e C Ct 0 e 0 0 0 c- C c c 0 0 c c>- 0 o eo CD T> to 00 s « 40 «V CD (£> <0 $ 90 00 CD pD qD m CO Cv a m m a ao ao D x> CO 00 CO « 9> 03 > w e c e 0 9 9 9 O' e 7 7 0 0 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 X pA T> CO 9 CO 4) 0 9 *. *- 4. *. *. *. 4_ *, *- 4. E E e E e e G E % £ e E E e e E E e e Ç E E E E e E € G E e E E E e G € e E E S ooooo OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO rJN- rvo O ocO Oo f- A? — K O- - oAfwcc.1T m c to o ^ ?cc^OQ-ir ^ o ir fv Oirifoir ^ ar-K-c-c y Zk T^ :Crw ^ e C ^ 0»=.--, y y ^ y »ürK-'r^KK rr^:>';y r KK'Kf^ ^ ' K" f ; Ph A *H Ph. i f TO i f A4 ro 7 f AJ 0 7 0 I f PA «A f 7 •A 0 f f M If pm CC pm 0 c AJ A If if to If 7 C Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 49 Kf*“ LT ^ C O ^ 9 ^ 3 • f A •« <8 A 3 •£' c o _ #C — O (8 ;T C 7 « D C C ^ CP ps €^3* •♦•** **•«* **■«• O I f O ' O W 9 Of 4 - CP r y I f P f t f A O "V 4>^af®o 9*^*^N>K> lAA^orvr® o o A PS. t f L f A CD m H rv rv rv ^ A j • rv fv A, pm #A #r, # K\ e t f 9 A A #m. <1 #m f f \ 9 pn A AA #n pm pf • - « T itfii ifiii iriii • t 1 1 1 I • 1 1 1 1 • t 1 « 1 1 1 1 • • f t t jujA* f» o- If in e (P & M" *n <» ,e A, rv 3 A A - c K 43 #n IP r*i * n - AA c 9 A 9 u T e p f *- OCT lltti llili | | « « | 1 1 1 t » t i U 1 1 1 # 1 1 1 t * • 1 1 1 1 1 1 1 1 z — 9 #f 9 If o o o o — o 9 tf fs A •4 A ts o A If o ff o o tO m rs 43 9 iv c tf o to A A A O' A #n o tr Kt 9 A #f A 3 < OO O o O O O o o o o O O o o O O O o o O o o o o o o o o o o O o o o o O o o O o o o e e> o o o c o c o c e c c o c> o o o o c o o o o C' o c- o c © D 4k’ o o o o o o o o ooO O O o c o o c o o 0 3 0 o c o o o o c c e c O © © c Z e)a. O w > © •• 9 < 9 A O e © o r e 9 a 4T 9L. C 9 e C I f © © c c I f © O © o c •£ © O A 9 «0© tr 3 o O O © O O © CP CP ® o o ps 9 ® CO 9 CD to CP © O © © Z3 UO o o o OOO o e o o © O o O O © o u 1 • t f • t « 1 • 4 1 t 1 1 1 # 1 4 1 • 1 1 t » i 4 1 I 1 1 4 * 4 4 1 1 1 1 f X u I f • s O A © A 9 9 9 9 I f O © 9 A 9 fs K IT A 9 9 O y • f A c O mm o e 3 o If m Pf 9 ff o 9 t f O CG CP f s ® o ’O 9 CP TT - s © A X © a c 3 9 et> f s i n A 0» 9 9 9 A A ■c o O O A 9 #n 9 A A A A o 9 9 9 O I f o A -o o o « c o- O' e © c e O' «T CC O' e Ps < Ps f s fs «T f s O' ps fs >0 ps f s C ’ © o- C © c a 1 t 1 • • 1 • 1 1 1 4 1 4 1 1 1 « 1 1 1 1 1 4 4 4 1 1 1 c 1 I 1 I 1 1 1 1 1 1 t 1 Z V f s © K o © ® cc o C 9 o- 9 A C ff O ir O 9 A A P- o f s in ir © 9 ff o m tf A « >o f f ^ I f o 'O .o © ps « A CP f f A « a a « 9 9 A * n A A f f •o If ^ O Kt ^ 9 Kl A K | ® 0 * K i O ’ «0O K» ^ ff ff 9 *f 9 9 AA L.' IT © IT A' •X tr IT tr © ps pr » o o ps ps tr ps © If- O © A A #-© tr 9 IT o C 9 o tr < O A A 9 © f f © © o © O o 9 o o © 9 © © © 9 O A A 9 CDo 9 © © o 9 A 9 O t f © > C ’ f f 9 9 o f f fj fs A A A tn ps Ps CP o © © in « A ® A f © © CP © A A 9 9 tr © © t f t f t f ps f A rv A A A A A A A AAA Kl A f f A o O o O 9 0 o o w o O tP o O o O' o O o o o o o o O o O CP O O O O' O OO o o o O O O tf o tf tf tf t f tf t f 0 © c ©' c © c ©' c © o o c c e © c c e o o c c c c e c- © © © c o c © © c o x> © © ® © © « © © © 9 « CO © 90 o © GOtf tf> ® t f t f tf tf tf t f t f t f t f t f t f > k o O' O o O' O o o o o O o o o o oO'ooo CPO'ooo oooOo O 0 0 o o O O 0 o o X «C ^ © o A © © © © © o f f © tr A O* tf 9 © ® A © iT I f f f o © © tf© o A A © o 9 I f *. *, *, 4- 4* /> E E E e E e 6 g E E e e e E g £E E E E E £ £ E E E e E £ e EEE E £ g E £ EE ^ 000®0 OOOOO ©0»00 0O03O ooooe OOOOO OOOOO OOOOO Z u J ^ ® f (> O Aj mj in f%. n, N. 3 If LA "1 ® p. 3 m. ® p~ -n O' £> m o » f O O ^ « . O r - O i A O if 3 "A f fV f^n-irr^a c*--C'£?*C r e (p A if o w # %c ^ A ® ,r a ^ h - c o c c - * - — ^ g P* ® ® (ÿ» o o y 3 ? 3 O O o «m 3 — VI 3 —* «" —< O —' O 3 0 3 0 0 ^ Aj ^ 3 if if C A A A A K K A A ' A A A A A A #- A A A A A A A A A A A ^ A A A 3 A A K M" fs M f'. f O O O rs. o f "A "A © ff © s . © y» © ir © f ff © a y* fs © © y U C «- K 3 A ir " C A 3 3 3 3 0 X > A A fs 9 tr 3 © C e o O K K A fs A o A 0 3 CL O •«#«« #•»•• •••«• M- Z t C^-^A^ «OC*"C ps IT K A © a a © e K tf y © © A © y tr o f ff ff ———— AA A 9 tr 9 A — A _A 4 0 ? f _n 'f f 9 if f f If f f f If If If iT r ir ^r %r sA y» iT ■r iT yv r y» r r yi lT •y y» y r r yv *p U II### lllll I I I I # 1 1 1 1 1 1 1 1 4 1 4 1 1 1 1 1 C c K y H- Ps tf A ps n-0“p^vref c A c c o tr c tr A C A ff C Ps tr A A or ir © 0 © o © y © A Z j j c r 3 "V o w -p .0 -6 JO niff-^f s ir ir 0 © © © o 0 O C ••*•» *«#i* •*•*• r r r 3 E fsOCOnj -, 9 9 3 O X 9 8 f j> A 9 O D AA A ^ ^ A A r. ^ ^ ^«-•►AA A *- A — — AA A A A — a a er CC ff a tf ff tf C tf tf c ff ff tf cr tf tf ff p»C OrCCXOTBt P9ŒCÉC axxtc® 9 9 9 9 9 3 t 3 9 9 9 9 99999 99999 3 T 9 s 9 3 J| rn# Hi# Hfli HjH HHj j## I## ##: s:: 5 r :: r z : r? Z. Û « u D L C z o Ü, L a 3 Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 50 ^ = ^ztzt '^^zz'iz "'#% 5555E 555E5 ScccE ----- m ê . i ii-ùéi i i H i -®-e • . . . . • ...... 77777 77777 77777 77777 77777 ^.“. 7".^ = : : : 5 . ::::: =:t;s I # # f f i f ? ? i i i f If?f? # # i iffii i# # # # | " i - z : : t ^ z z ' ^ ^ tr " * " * J * * * * * ' * » • • * ...... , • • * u.F ^ ^ *C T f *T V ru f)w.XKM-C cr pn tntro-7»=ro ir ^ .t C e‘CB‘*ra3 m j"' tn ^in &r? ir3 %? ctr .0 ^ ^ r^ in 3 &r ir- tf r>^rxj^i-ire — ^ —— *•• *• ••••* lllll lllll lllll iriii lllll 111*1 < OC»000 OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO ^ ^ C- C" O O 0 0 0 0 C' OOOOO' OOOOO OOOOO OOOOO OOOOO OOOOO wo OOOOO••*•* OOOOO ••*•» OOOOO •«•*» «•»••OOOCO OOCOO •««•« COOOC •■»•• COOOO ■•••• OOOOO •*•«• »«4 > o #\i ft «C r»* ft pA ft f t ft O pp> pr ft ru «• 'ft ffv ff- IV 9 «— ft pp ft ft ft ft C iT ft K ft ft- ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft w *— ft c ft Is. fC ftt/ f t ft r^ rv !>» C pf p". ft ft P- IV t\} A* f.. ft p- A p- — p- pf ft 4 f f * f lA IT lA p'- *A f*- pA f t r v « f t A. CC IT f t r v i r cc c ft. f t rv CC K" or cc f t fs- P-* or 4A I f f t p- PA PA 'ft f t f t f t O 'D f t f t PA ft o QO e -A f t f t o f t mn lA f t f t f t o O lA A A f t O IV lA PA Pu -A rsj p'- f t #A •A V f t f t •A f t ■» A r v f t f t f t f t f t f t 'D f t D f t f t O f t f t o f t f t f t f t r v f t f t Cf C rv in f t f t f t > ft- f t f t f t EEE E E £ g E e EE EEE e E E EEEEEE (/) E E E E e E E E 6 Ê e e e £ e e e OOOOO OOOOO OOOOO OOOOO OOOOO O O O = 0=000 • • • • • # * • * PVOP'inC' C'O'C'C-^J|C 55l£i iîill ^ c 3 in 4) a ■«.i^oo-o "3 9^ > 52 — ^ r A | \ ^ A fl A.AIXrvA. rv f\ A rv A, rVAAAA w' pr *f M" C -•*— K rv,njpvf\.pv^ Ml A A M fi,i\.N'rwrv. M A Pk f\ f.-KK'fv9^ r* ^ fV •' .V «V O o o A *\r pp CO "A fS> rv •A x> rv y = r?= ;c;:r?z zrzz?* tr fv A ft u r ft ff- If p- rv c- c tr i\ A. ,f ^ A rv A «-rvcfC XX “e vr ■/.C.Cf't'X> ps a p c-O rvfv rvfV cC O K, — — — Âjri>M^'>J «1 If, "1 ^ a "V AJ AJ rv JA JA LA L,f V' IT m ^ in r 'y' J1 y, in ,n n T, y>nnn^ X ® lA A A A AA A AA lA LA lA I lllll lllll 3 ^ rrrrr rrrrz 77777« 7 7 ... c 1 1 * » 1 1 t •» t 1 t * n C c ff ff O •f e tr ft c er r\ tr =\f: .D • 7A^ ft ^ 7 =o 7ft r J3 00...... — OÉ f t Tf'nnao^?-*A •V ft ft <£>t>^nj—40 t> f AJ — —.rtp-x.uft ^ — .-rv *- g C f t ec ft ft CC flC ft c c u. V. H Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 50 fs. fv #A ft cc ir o o ft- o *-" œ T> t • a • # 1 a a a 1 t a a a » • a ( 1 a a a a a t 1 1 1 C a a a 1 1 a t c 1 a t pr- — u- r» — e c c ft fA c. ff « ft ft fA fA ft 9 9 fv p.. 9 ff. ft 9 ft O ft o- c fs. ft c ft ft ft ft c lA rv o 4P •o CD CDAJO ft) Ai rv ft ft to T* -A lA O AJ CO CD ft ft lA ft o ft eo ft o ft lA kv AJO O fA •A o AJ Or o AJ o (O o "A O' 9 fs. ft ft ft O ft ft X ft II fA 9 9 9 9 9 9 9 9 ft 9 ft 9 fA ff 9 9 9 ff pm 9 9 9 9 9 9 fA 9 9 9 9 rv rv f*“ OJ A X c O T 1 I # 1 1 t 1 1 a 1 1 1 1 1 1 a a 1 1 a a a a 1 1 a a a a a a 1 a 1 1 1 a a a a O z O rv CO 9 ft O o fO ftr MS fs. o ft "A rv o 9 9 AJ -A JD o ft* AJ ft ft •M ft a? Ai o «C u; ft rv ft o rv 4A 9 -£ IT 9 ft A j ft 9 A ft fA ft fs. lA O < o O o O o o O O O O O o O OO ft o o O ft ft* o o o O O O O O O o O o O O OO o O o c c- cr o o c- O O o ft- ft o ft ftr ft' ft ft ft ft ft ft c o o ft o ft o o o o O o o o c- o c c o w w o o O o o e o c ft ft o ft o ft ft ft ft ft ft ft O c C' ft ft ft ft ft ft ft c o o o c. o e ft c o Ou z cr- o fVi 9 f t ft ft fA 9 9 ft •ft ff> f f fA Aj — ft K*. ft- rv 9 — ft N “, fA ft 9 ft c e IT 9 sar 9 #S 01 ft- f t ft f t f t f t f t ft f t f t ft 9 o f t O O o 9 O f t f t f t OD f t O OO f t f t CD CD O 9 KJ o o f t f t f t f t 9 9 o O 9 9 o O O 9 9 a a a a a a a t a I 1 r 1 a a 1 a a t 1 a 1 a a a a a 1 1 • a a 1 I a 1 a a a a û r w && «r f t f t c «£ f t O A <£• ft ft ft ff, c fs. *. f t 9 c 9 f t f f tr* c •• r v f f rv — <- 9 c 9 %) CO 9 9 f t f t f t AJ 9 %> 9 f t f t 00 9 lA 00 ft ftftft «0 f t f t f t AJ V> "A f t m a- o 9 lA f t f t f t l/ \ 9 f t A j A i *A ft ft 9 f t CC f t 9 o f t g ff ft Ai lA « C 9- tf- A j « pr or tf CD f^ ps tf tr tr fS e- *A ir AJ CC CO A CC IT ar |s* fO PA ft ft "% #n AJ ft 9 O cO 9 •A sD o 9 fA lA 9 o •c ft ft LA LA ft 9 lA Ai rA 9 fA ■A nj ft 00 pA ft *y Z' Aj 9 *T ft 9 9 ft ft ft ft n ft O ft ft ft ft O ft ft ft ft 9 o C rv ft ft 9 C A. ft A j •ft •ft 9 •D IT ft .ft CO eo X) CD s> ft ft ft ft eo JO x> ft ft ft ft ft ft 9 9 ft ft ft ft 9 ft* ft ft ft ft > LU 9 ft ft ft O ft c ft- c- O o o o 9 9 9 O & C o- O O O C O ft ft O ft C *— cr CD 9 ft ft O CD 9 »CO 00 9 cC 9 so E F EE e 6 e e E E E £ E E EEE E E e E E E E € EEEE e CO E E e e E e e £ £ £ ft O ft -ft f t f t f t f t f t ft ft O ft ooooo OOOOO 9 o ft o O O o O f t ft f t f t f t ft ft f t • •••• ••♦*• tf f t o f t •A ft D ft CD 9 f t f t f t ft 9 jn f t f t f t D ft ps ^ ^ L/^ fO J*> o “w o o*" pf, r v o r - K ^ c - ft C t f A •tf K*. o Of t f tr tf tf tf pr 9 c tr A f f ff ff* A ft C* A lA ft f t ft ft 9 CO ft ft ps r» tf ft ft ft ft 9 9 ft ft ft 9 •A ? tn kA ^ a A A AAAAA A rv rv r. rv r. rv rv rv r K" K ff-* AA A A A pf A AA A A AA A K* P- pf * ^ » r u *^0 o 'V O #A ^ *n /» «"v ^ r~ <0 4P ^ r* r\* ^ 2 ^ !T Z S o — Otr — LT fv f\ o c ^ cr ^ i r c - c ^ e cccir— rv—vcu r-— r-cccr i& c OK-tT'C-r- *»••» •••»* •*•** ••••• ••■•« *•«•* ••««* ‘ m O rv rv C ^rvAfvir ^ à c c r a rv r. c — — rvrvrv — r e - C o »- Z C ^ ]L c. CL —^Aj'V'Xi ^ —•*-*— — — rjrorvi-M r>j ^ ^ A lA A J-' _r A riJ-' inir jy LA r»y* LAiT _r^ LT ir V& Vt jy iTtr lAir J ^ i iTA-A -tf-tftf»vA-A y*tf* lALtf LALtf tf tf» Jtf* ^ ’A tf*tf A A tf Atf Atf ^ y\ lA z) "? z T T T T T T T Ta Ta »1 « I #• # *1 a#i#ii a 1 a I ii«»i 1 * 1 1 1 1* a# #a 1# a# attiii a t 1 1 # # # » # g fs f.. ps ps ^ ^ ^ ^ g. Kc-irc rr ft ft 9 Aj ff uA fs ft -A tf ff M AJ O' AJ ft o ff 'V Z f c -y "V cr ?" « • ’O *— A •" —— — A A L/ a c Œ tfffo-cccrg e c«t««otf tf ff tf craffffec ff: er ff tf tf «crwcrei tf tf tf aecflcaatf tf tf tf aaercatf ef c a or ao*«-a 9 9 T 9 9 ff ff ■ff ■ff•ff ff ff ff ff ff ff ff ■ff < Si ^ = 7 = = Tr--rrf-r -T ff ff 9 ff _ T. ff A tr ff C A. =-C-rvK - U < A c A < c AA ir < A AA Nf-t r A O -V -V 'V *\J j ^ ^ Ai A! ff ff 9 y ft ff (. c *-* O "3 3 3 3 3 C 3 3 > 0 f > r ^ (0 y V V» «*. lA Zf f c tf ft r r *- ir «r c .2 o CD a a o a Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 51 ly © A- ps. pA Û: h- © f f f v fV © ■p' ec 9 P A er f f f f i r f - -J ® 9 <£) jn AJ•A AJ © rr ® O' ® 'J> 9 © nO f f fs. LA f f ® © AJ #A O AJ 9 A f f S' ar — H fs. MS 9 9 pp'» Pf~ K' f f. TV r v r v •V Arf A t 9 9 PA pA PA PA PA PA pA pA pf, 9 9 9 9 9 f f f f f f o c T 1 1 1 1 1 1 1 • 1 « • 1 t 1 t U » 1 « • f I r r 1 • • 1 1 1 • t 1 f % * 1 1 • t 1 2 O' 9 lA © «>« tr- ® AJ o O in O' A l f » f f o lA 9 ® © © PA O G f f <[ L. & o C O o fn A. f f IT t r o t r A CC P*' c f«. f f 9 ec o 9 f f O p f pf, G fs. © C *A f s G' X C ' #f. ir f f « «C i r Ct f f f f A- f f ® 9 © f f fs. A LT' C* pA f - 9 pA r v t r 9 r \r c f f f f U. ( 9 9 kA kA 9 •A •A AJ AJ JA .o -£> tAff ff ff ff ff f f f f f f f f f f f f f f f f • 1 t 1 t 1 I i 1 1 • » 1 1 1 1 • # t • t 1 1 > » 1 • 1 1 i f • « 1 1 * o o o O o o O OO © f f f f f f f f f f f f f f f f f f f f f f f f f f f f f f f f o f f o - O o O o o G O o O O o © © o c o o OO o f f ' f f f f f f f f f f f f f f f f f f f f f f f f c O f f c - f f o e O c o c G c o G e W o G cr, k. o o o o o f f o c f f f f f f f f f f f f f f f f f f f f f f f f f f f f c f f f f G c o o c G c C e C GO c 2 V5CL C »- > rv! ff- IT o r v 9 f f f f f f CC f f f f t r r v C f f f f -J* f f o t r r - P^ f f ps. f f fs e f f f f o G % AJ PA ©• ©* ® O ' O' o f f O o AJ PA f f ® ® «0 ® ® O" ® ® ® ® ® ® ® © © © ® ® ® ® ® © z o o o o o o f f o f f f f f f f f f f f f o f f o G o o o O o o o O o O u 1 • 1 1 I 1 f 1 I I» # I t 1 f 1 1 1 # 1 1 1 * • 1 1 f • • p 1 1 > i • c I • X » ü_ ü. f v e* 9 A j c r e G t r CC r v pf' p f o sC A f f f - C pr 9 0 “ t r <■ «-r f f to «C © i r f f c . © rv f f «■> f f O ® 9 O © ® c O f — o 9 O AJ sO O 9 PA PA 9 f f © •A tr f f PA f f ® f f tA © A cr u Z> ® m O AJ LA ® f f 9 ® f f •A M ® AJAJ OPO PA _ f*. C fV -* r- 4. *- *- *- f f e F E E e e £ e e £ e E E E € 5 £ E e c E £ £ S E e e g Ç e f £ s £ ë E cr Ç E r o o o G O O O G o O o 3 9 9 9 O O 9 9 9 9 o o o 9 9 9 O o 9 9 o 9 O o 9 9 9 9 ■ff f f AJ ® © AJ O f f JA oJ AJ lA f f © f f ff AJ 9 f f 9 © ® PA LA 9 ® A IT cr c G rv 9 © tr ps f f C rv r v fs pA, rv A* rv f f ff* O f f tr PA rA Ml ff ff 13 c "A f f ff lA lA ® © O o AJ 9 f f sA •A nj ff AJ f f f f f f f f PT- rv r v n. rv n . rv n pA pA f f f f K K rv. rv rv n r v r v rv A r v rv A A rv A A A A fs. fs PS •A •A lA O o ■n Ml Ps fs A fs 9 •A 9 Ml A n AJ -n n Aj *V fs O 9 -n yj f f LT rv © rv rv f f L. C fs i r o fs o o o fs tf> i r rv o tr f f i r C -tf •C tr .tf Z — c A' A f f t f tf- O e o f * rv C C c c C c O o c #- Z 6 PA A f f f f A A A pA MV pA sA -n -A Ml -A PA *A f f •A po AAA f f f f f f f f A A AAAA A AA A .n A < cr jA _n A AA AA AAAA AAA-A AAAAAA A A A *A ■A A AAAAAA AA r c.' 3 ? t 1 4 1 • 1 1 1 1 o _ • 1 t 1 1 1 t t 4 t t 4 1 1 » » ' • *• 1 1 1 1 * * f\ K r r \ r IT n t f C C -, C f f ' C fs fs t f t f M“ ff' \ r f\ tf CC fs tr rv tr H- SC c tf 9 ff AJ A 9 f f A 9 O 9 AJ t f 9 X' 0 *o A G A -c* M 9 9 © f f AJ f f A © O A f f D AJ f f O t f © AJ A © 9 \. A A tf" M' rv rv rv r rv f'' A A A A M" f f f t f f f f f rv *- "*■ •- — fV rv a t f C tf tf tf t f 9 er tf t f t f tf tf tf t f or t f p- tf % ff ff a tf tf a tf t f ff ff f f ff f f f f ff ff f f f f f f ff f f * ^ - tr ^ A»'‘ CrCC' - A K ^ h - L T ’^A . r * T O y\ lA J"' iT i^AAA-C J> O O O 3 P O T C mmrn I >> > > >>>>jÉ 0 0 - — C irz — jlZ- c ^ — ZZ P- »> V) (A c « e (t Z J3 ^ C z o &i_ t- C5 Q Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 52 ÛT ^ C If —- 9 ^ •€> r\j f\j V —r c fV ir o c. fr> IT C c e 9 fA fv K* C UJt*> «**^9.00 O^^-kTi — o CD 4ft o o o o O o o o o o o o o C p o 9 o o © o o 9 o O o © © f» o o f.% o o o o 9 o cr #—> 'C o t r #A *« ftf P- f v p^ i r CC t f t r a C fV o ftp' 9 t r t r A l 9 * f PA fp- f f IT 9 t r ft- X X tr o «-• ir I f oc te> CD o o o o o o AJ r v «A 9 PA 9 9 9 o O AJ AJ AJAJ o AJ AJ Aj o o o o o AJ w o O w ft ft ft 1 ft ft 1 ft ft ft ft ft ft ft ft ft ft ft ft 1 ft ft ft ft 1 ft ft ft ft ft * ft ft ft ft ft ft ft ft ft v_ a IT ft-. r v o o r. c pf* A ir p r O O t r ft- PT" t r O r - fT AA-K «• I f *. © o A; o pA 9 m 3 •A % o 9 t r 9 J) 9 •A r v O CD o a> •*v 9 o © X AJ O' i r to O o a C ^ D —f ft-- 9 e - o et t r 9 t r c o o fV 9 O' A j c lA t f t r t r 9 I f 9 A 1/ PA t f t f o f - P-. o c pf 9 f - 9 < ■A *A PA ao O' o «3eo#AO 9 OD PA #A r-» •A o t r AJ o O X o .6 i r PA X •ft X X Aj 9 X) >► L. •A PA »o « r v •A 9 9 t r OO •A O 9 9 -A 9 *A PA 9 *A -C 9 A4 PA 9 in -A O" XO' O O O’ ir tr tr < < -C -O r* r-. ft- r* f- ft"-ft-. tr o o o O O O o O o OO O o c © o o o 9 o UJ O' o O' O' O' O' O' o o o o o o o O O o O o CO CO eo x> 30 PC ay ec X X X X X o o O' X XX O* X a o c r o c c e e o CO 9 o o c 9 o o 9 c c . o c C' o c e o 9 c c o c c- c o c C' e c e o o s « T) 9 «C eo 9 X- CO «0 CO X m x> X ?r x> x> OD X «• X CD CO X CD X m X to XXXXX X XXX > u a o O' C o O O o o o o er o o o o o o o O O' O o O o o c o o o ooooo O'cooo X o X o PA AJ o rv o AJ 9 f - X o X PAo Al •A -A 9 PA O' — cc i r X CO PA X p—X pp- crc c trO' 9 9 •« P-I f rv p- tr o* f f -o o < pp* c o 9 X rv A r- t f I f C 9 9 O X- ft- X A 9 pf 9 ft- c > O' pf 9 rv P- «Lfv ec. K' A 9 r- o pf c 9 K* < o pp"» AK 9 .£ X C A o t r >c ft- AJ *c X O' o •o (f> •A X AJ o 9 AJ Al AJ AJ 9 9 -A r P- AJ A AJ ft— >0 t r u < < X <. -c X y£ trt/ trIftf tf tfIf9 < tr trtrIftftf I f If-I f trtr tftftfI f tf trtrtrtfIf CO o o o 9 X o O O o o o o X o o o O o X o o X X O o XX o X o o O o X o X o er ecOL'S c ACCD& X ct cc tr cc CLerCC ec cc QL ec E E E £ G G E E £ E G £ £ £ E e c G E £ E c £ G £ £ £ e £ E G £ E e EEEEE e 9 X X X o X O X o 9 o O O 9 O © O OO e X o 9 X X O o XXX O o o X o X XX _u AJ p - o 9 PA •A tr O' ? o AJ A j o iT r v X PA PA D O' tn o -A X A %r PA r j AJ o c X r n j X -A JA JA X P-» A JA AJ O *—■A l o ao ti.' c C f v c ft— r r v o o If o o A c - I f t f Aj Aj 9 f» æ X O' o o "A•A t r o » C \ft A j ^0 AJ AJ 9 '\ l AJ t> r JA o c JA p- 9 9 9 sr I f I f I f t f I f t f u t f *“ — g. g ec er CL o cc a «L CC' ex. or a cr «t a CC ec er cr cr a Q d er a ec QL CC cc «. a. < T 9 "TT 9 9 ? 3 9 9 9 9 9 ? 9 ■ar 9 9 9 9 9 9 9 9 9 C c fv pr c V r - a C c r L" "£ r C c «- P» C l I f -r P-. flC C C X. c *L o O O > > 7 > X f . X A A r A A A A A A A r . AAA A A A . D 3 3 3 3 *5 ■c 3 L5 3 3 T) c c Cf tn Cr c Zj <' ** — LT O Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 53 ::::: ::::: : ; = s : - f l T # # #TTT TT7TT # # ? # # # # # ? 7T7T? 77777 -J Ik' K cr cr- e- < cr ff XX rv C ffc er o o ff tr 9 #- C O ff 0»tr OJ Oj ffX ff PO V •r o A £ *f 9 O t~ rv 9 in «. Lk * XO A Ol O' •r»A > o A ■c r- t c «? X IT X' rv tf t'* A* o o r*. A ff h- A ff rv r*. O' A.» to rv O e ff cr Ojlru OJ Oj OJ ff m OJ ff #A #- z Oj Ol Ol ff 9 ff ff 9 9 ff 9 9 9 9 ■9 w ••***• •• ♦ •*♦*♦ •••• ••••• ••••* ••*•* •*•** L. 1 1 •« % 1 1 1 •• 1 » 1 f t t • • • 1 t t •# 1 t 1 t I i 1 1 1 1 1 1 1 « a « 1 w u. ir o Cr C: Cf tr cf fA ff ff mtmO' rv X ff X, rvf o cr A OJ *£ ff c ff to A ff ff «« r*. X A %> « OJ rv > m rv OJ f"-OJ OJ Oj £ £ ff Ol ff A ff ff •o OJ tSk ff O ff to ff ff Ol t:3 ru «0 o* *o ir -0 OJ O# t'- Oj flO A CO A Ol o £ o ff o *D OJ ff ff to e c fvi rv rv rv rv rvrv rv K rv. •ffff ff to tr£ rv O' ff£ X X o. £ tr t- t" ftO' ffff •ff o rv A c • 1 •• 1 • 1 1 f 1 1 t 1 f • 1 # 1 • • # t 1 > 1 r 1 • t 1 1 1 $ % t » 1 1 1 I 1 <_ •— C cr cr rv o tr rv #'• X *_ X A ff ff tf A ff X tr ff X r- X » c ff t*. ff ff A ff ff tN ff rv ru <%> 6 X o m Jp A OJ t"%ff t-w Oi sO O' o o •O »- £ A f**. r«* ff Ol OJ ff ff ffff OJ © CL X OJ 'ff O' O' £ fO £ to ff *o ff fO OJ OJ " - " "* " IT o- 'A «C t"- #f O’c O O ff trsX #o A ru ff rv rv o ff tr cf ff tr X X •fft*- X ff tr. tf A ff> LT rv o r- H> SJ“o o rv O A o O' o A t'%- o ru fi-O AA ff A ff ffA O' V- (T tc XX X X er X a ct X (T XX X XX X cr X X ff CC X T a cr X X cr O OL CT a A X 9 X ? T -T ? T ff ffff Tf ff 3 ff ff ff 7 ff ff 7 7 ff 7 7 ff 7 7 7 7 7 X r. A ■ff r- fT c o r c A •ff c* — if ft C V V ""v V •o "O Oj V *v V •n n n Ol -n 7 7 J A A A IV c c V/ rv rv r r. rv o o r f\ â ft :> U u U u V u o o u u u u u u V» V V 3 7 J 7 L> ft V X V ft X X X ff ff ff X ff XX ff X X ff t' «k ft •r (A ;a (A lA V) V) (A c un C It IT ft ft ft X e X 43 JO .c X a X X T O uC kÛ Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 54 o ^ TT c ^ .r, _ ^sTC.«a -c fvir a r- r v f v O' 9 eo »im tn A j A. K Aw at IT» AJ «* in A ' cy c - uJir* KSi/^fL(MO C C' T lllll lllll lllll lllll 1 1 I I 1 1 1 1 1 I I 1 1 I 1 1 1 1 1 I z o «■ un o 9 'O Aw o hw Aw #A m AJ X #A 9 X ■o O 9 fW. 9 cc 9 t n A l o « • 3> #A X o i n 9 o < o o o o CO o 0 o c> o o o 9 9 o O o o O 9 O O o 9 9 O 9 OO O o o O o o o o o o O c * o c c o o o o o e- o e* O o c - 9 c - o 9 O 9 O ' c O 9 O o o o o Ç o o o o o c e* c u fa. < r c c - C ' c c - o c . o O c t o O c e O OC c o o 9 C o 9 o o c C5 c - o o c o o c* o fL z cr cr I— > o Al o O' Aw 9 1^. o O' e: o ^W X rw fw X t r 9 Cr c o pr. pA A4 X X CT IT *1^ fw tn tn X pA PA rv o X o t r *A *n m •A PA*A m AJ Al AJ AJ AJ Al AJ AJ Al Al AJ PA CD fw f'w XX X to X X X o X to X X X <3 hwa o i f X ec «*■ c IT A t r I f tn t r CC pf X f f O' O' ec ec t r pp" c 9 t r X #n o €5 pf- or nr. CIT t r tn o O' o o Aj O 9 X O to AJ OC e X O' O C o A O t r i r « « 9 o 9 un o o o O #APA m to CD 9 jn un _A O' O' Aw XX Aj O o AJ X X o 9 o o fa; un O O o o O' o m o Al 9 9 m X X X X X X O O' o 9 X LA lA un un un •A AJ o o 9 AJ X O' O' pw A* A pfi *r, K- 9 pf% pf* 9 9 9 9 9 9 9 9 9 9 A A j pA pf I f i n t r t r I f t r i r t r 9 9 9 9 pf, A.' I f ‘jJ O O O o o O o o O' O O OOO O O' O' O' O' O O' O' O' O' o o o o O O' O' o O O o O' O' O o O' o r o o o o o o c c CC c 9 C- 9 o c o C O C o c 9 9 e o o o c er c.- O c C e o o c O O ao CO to CD CO r o ■o «0 CO «A X o X X If» PA O o AJXO' 9 PA O un X t f PA o •A pw Pw 40 CO Mi un X o A j o LA o o AJ «• a tf) AJ c 9 9 A . e- 9 9 9 pw pw pw t r t f pw pw O O' A. tf 9 t f pp^ tf c r t f o pA fL pw pw K CT tf o X t f er I f X t* j > #\ If tf A X 9 p^ pw X pw 9 p^ t f. A j XX A. p f t f 9 pf' X t r tf rv t r I f c I f p f 9 C- un jn Pw pw. X o o O un X X O' o O' to X X x> Pw »X » un tf) AJ JC O o PA 9 un X tf pw Lw t r 9 I f t f t f i r I f I f I f t r t r I f t r t r t f I f t r t f X t r X X X X XXXXXX X X XXX X X'X X t/> o O O o o T* O O o o o 9 o o O o o O o o o o o o 3 o o o o o o o 9 o o o O o o O CL X t f t f t f tf. t f t f t f t f t f t f t f t f tf t f t f t f tf. t f tf tf tf er CL t f t f t f t f tf t f t f 4L ec t f t f t f z> o o O' o o o o o o o o O o o o O' o o o O' O' O' O' O' o o O ' o o O' o o o o O' O o o o O' *_ 4- X T XT XT X X X X *- TX iO E e E E e E E £ E E e E E e E E E E E E e £ E E E c E E 0 0 0 9 0 OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO *. ••«•• ••••• ••••• ••••• **•*• ••**• ♦•**• ••**• g 0^»A09‘ 0^*^X»T ^ A j ' O r U t f ' 9 T" AJ ? ' 9 * k* ^ A J O O c K' r_ — OC99A a ^ ^ f', pA O'QOOC A O -- r~ —- A*>C99ir cr ct t<' — r^i.fr^*-0 jj c J3 o O r- 9 9 Aj ^ ^ O O O O '?' t> O r- X» <—i*COO»A •AAJ'V'A*^ Aj Aj "A Af Aj 'MO— *AO (2 *•> 9 l T 9 ’ C’ 9 BÏ9999 539999 t\ f\j f\ A fw AAA-AjA A — f\ A. A •w. r *A un o A> A j un O A j O 43 o « •A wA 9» O T'A •A x> ■A A3 Pw. AJ un OT) fw pw un A l Pw » "A un Ü, C X t r 9 rv t f O'tr tf-tf O X pw t r rv o pw C 9 t f O' O X c o O' C rv ay c •*- f- c e X rv t f 9 t f I f o pw 9 cr 9 t f t r pr. 9 X t f U pf 0 pw X ir p f A c f cc O • fl f l jn 9 9 9 ■A '.A A j AJ A j — un f f jn —— — un un i f jn un - Ï - r o •A *A A ■A AJ -V AJ Aj AJ n j AJ AJ A j Aj A j AJ AJ w-| JA JA jn jn X 6 D X o o D o X> o f •O X z < ——— •w — — — *- —— M. •- —— — M. — — *-— — *-•“ C 7 C 1 • I I e • • 1 1 « « 1 t 1 1*1»1 tr•1• 1»1 1 • 1 1 1 « # 1 • t > 1 cr pw pw C pw A A t r i r X X pw XX O g t f pw p^ CT t f o Pw a K c ftr A ec r r I f er t f t r c ^ c ro un o A j o ? A j > jn AJ 9 9 9 -T 9 X) 9 o O O O X) O -A wf -A .D -A jn •tn O' c ■'J AJ A j 'A "U A j 9 jn un O O o D o 9 *A -n wA *A •-A AJ O O' O O un AJ O *A O' % E rr f-r P^ r' p f pr pf P^ pf p f P-A rv rv f>. A. pf 9 =r pr p" rr rv tr * - r - 9 9 3 = M C CC tf t f a t f er t f t f er tf tf t f er t f CC. t f t f a Q t f t f o t f CT e t f tf t f O' t f t f tf tf t f t f t f t f t f CL 'S ft> 9 9 T -T T ? 9 9 9 9 ? 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 *7 9 9 ? 9 9 _ X K “ t/“xr‘ aOc*-A K9U V- A-r-occ •-Ar'ot/ s£r*crCC «-Ar^cK w, 5 tti/*'-T“ J^ .A A _n /" A _n y' o 3 r z c ù ù T‘ d o z ^ c r r” -i^ - r o Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 55 o © o 9 m i r © m r v 1 o A M h pA © 9 o Ml 9 n. o tr O O 9 O in tr tr UJ tA © o r v © O © © 9 1 9 o o r. tn A •o O © 9 o o © 4) •X o 9 o sO W sO o A j L5 © AJ 4? © 9 O' O tn A tn m 9 © A M% m fNj o 9 9 9 tn o o 9 hJ r j Ml r v f v rv #\j rv m A j A K\ n. pn m 9 3 IM tr m M M tn in tn tn Ml 9 9 m X) 1 1 I f f 1 < 4 1 fl t 1 1 1 4 t 1 1 t •I 1 1 « 4 1 t 1 » 1 1 fl fl fl 4 a w fk, O o r~ -1 © IT o 9 O o cr 9 9 O © 9 9 mtm 9 A © 9 9 A Ml 9 © © M> c © © A P». o o O o AJ o AJ m in O 9 A •o •O o O A o A OO 9 t i. O A in C p— AJ © im #n © 9 #A rv ■ »** « tn 9 h*. sC O' m O 9 O -# O M» in AOA X. a ro r v M> ro AJ MV cr in A A pn 9 If 9 tn in tn tn 9 9 in m o tr 9 9 9 9 9 £ © tr c c X • 1 1 I I • * 1 1 1 1 t I 1 1 1 1 t 1 « t 1 t 1 1 fl 4 • 4 • fl fl fl fl w fl fl 2 © tn tn c O O 4> «n rv © O © m O' © 9 9 o 9 m 9 9 in C © 9 X © © r- « u . o ir 9 c t- ir AJ o tr c ©■ © O in o M m O O 9 A M' O O tr M «C © in c wJ «r O #c IT r v M* « © «C. tr © A- o o O IT M © O C in tn ir M c 9 fl-. M' u. lA LO O t n cr 9 #n rv 9 © 9 1 r— m M| AI 9 M> tn in •o 1 M A A A fl » t i f I« 1 t 1 1 I « I I 1 t t 1 1 I t 1 • 1 c O O o © o 9 9 O O c OOOO o O o c o c o o o o O o O o O o o o OO O OOO o o c c c o c C © o o o coco o O o o o e o o o c O o c c C o O o c C c- c o c (_* 05 w c c C ' c c C O o c c OOOOOc c c Cj c c c c c o e> c o c c c c c c o c c o c 3» «O'C' o K> #n © © •c A A © 9 c A A' A 4%. ZJ tn m A c A c o 4T % OOOOO OOOOO CO O I f* O' © o © 9 in 9 9 9 Ml A 9 9 Ml 9 9 9 9 9 9 Ml 1^ % *•*•• ••••• # # W OOOOO 00«^00 OO' o O o o o W' e Ifitt llltl II 1 1 1 1 t 1 1 1 1 4 4 1 1 1 1 4 1 I 1 4 fl fl fl fl fl t ÜJ LL' O «- O fv O IT* cC ^ ' o tn 9 A pr *• © © © 4) C A 9 © © © A M © © ©> 3 O O O r«»0: AJ M> c © o o Ml 9 M» A m A M» tn A MM A ftcr «••»•.•••** ** o m o o o CO rv f- o m o =t> 9 o o © A 4>© © O •oO' A A © © 9 A © M © © 9 or c at O O fV fVl ITi cr IT’ *" 4D M' M» o tr lA tr AO IT Mv O o r- m 9 M» M 9 A. r- M © Ml r- 4) «0 Ml |J% O O M%#A o © r* O' 9 m m O 9 9 Ml M> m 9 © 9 O' «-# O l/^ rj O © if\ ij^ f\l 9 —# lA 4^ rv lA O ^ r w O tA O A i l A ^ r ^ © -O O O A Ml %r A ? ^ ^ #- f-m. ^ f>^ © t r i r ^ i / * ir ir lA ir lA Mvtrtririr ir tr m- m i a 4T it lt m< m m- m lt* ÜJ OOOC^O OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO ^Q; CO coo COOCO OOCOO ©OOOO COCOC CCOOO OOOOO OOOOO O © tD œ O D TD © C 0 © 0 © © © © O © O O O O © © © © © © © © © © © © © © © © © © o © © > Xtk OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO 9 © o 9 9 O © o A © © o hk © O' O' © CD © m © 9 9 A © © o Ml ©> o © © A m p—© O' c A © M c © M O o A in in 9 1—A Ml o If 9 © A © 9 p- o 9 9 o f- 9 in © A > o © M A' o 0L> in 9 © O fl- C c © 9 in M r- © M 9 If tf tr 9 in o in if © C ir o Œ o © * © © r— © © © © o © M> o CO o O M © O Ml m O' o © © A o o © o o A it. f— © © © © © © © © r- P— © © p- fl— © M 9 9 9 tr tf 9 in If IT in 9 9 9 9 5 tf 'I c o o o o 9 9 o o o o o S» o o o O o o o o CDO O O o o O o o o O o o O O c. © © CO c © © « c © t cr. cc or © a . © © « © © © © © © ff tL C. ff ff © cr tr © O o o o O' O O' O' o o O' O' o o o o o o o o o O' o O o o o O' o o O o o O o o o o o T T X T T XX X X X X X X X X X XXX X *- *- — *— £ EESE e GÇEE e £ E E e E e E € s o o 9 o o o o Oo o o o o o o o a o 9 o o o O 9 O o o o 9 o O O O o O o o o e o o A 40 o m %o fl— 9 _n A © O Lfl © A A Ml © Lf%o A O O'o 9 o “a o ^ o M M- A O 4P o c M 9 o © ©>If If IT 9 © M o 9 If If © c © A If o x> © A M» Ml yi M% O © A © A O r> -n 9 9 fl o > o «n jJ c 9 9 c — A A A A A AAA A — AM — A If © If If 9 M If tf MM If If If 9 Ja^ M l Ml O — A A © n m © © 9 X» O A m A M» m © O t n J > 9 40 00 m O A cc C O f f M< o Lf C u. c M I f o M o o «3 9 c O I f P - 9 9 9 e . ' © © fl— © c © I f c . C © r t M l Ml Ml M l Ml Ml Ml Ml M l M Ml ■Ml Ml M l © © © © c © © © © © © © £ D © © M l Ml M l ^ 3 O £> •£> o •- Z t —— - —- — — —— — — — •" - — — — *- -3 *T 1 fl 4 fl fl 1 • 1 fl fl fl fl 1 f l 1 fl 1 fl fl 1 fl t 1 1 1 f fl 1 fl I fl 1 f fl fl fl f f © i n c o r ac t r Ct f f M I f M f f pa. c © f l pa p*a AA f l - M © M A M A pf LT c r\ t o M l M, Ml 3 UJ c *A O A o o © CD X 9 D n X OC © Ml ff> x > %) 9 X ' © ff ■n n M» M» % Ê O' © O o © V M l O M l A •A 9 9 n» 9 A A M l o 9 A o O o => o 9 tr tr 1/ t n u I f I f IT 9 9 9 9 9 9 9 9 9 M 9 9 9 9 MM“. 9 9 9 9 A A A M A Q ff. ff ff o r ff a O c «k A K 9 C c tf © r O C c © V © © © c © A ff r o X) c o o O' O' 9 9 o r> 3 A A f . A A AA n. A n A 1 • c E p & k k £ k E E 9 c e= F ti) (A 1/) c « n c JJ Z) .3 £> © a Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 56 a r- 0 m I^cr99^ If e» o t f ' c o i r a> l t «5— « Uj *n ru 0 •0 o*«<4>9ru sy in o i\/ f\io4r^9 uu ^ m — ooru»^ tr n> •£> pf> K\ cc 9 0 tn r> e tn 0 9 ru c 'M 0 ni ••••• **••• * * * » » •«••» ••••• WL n in tr in o«c^=>-t -M»->iAoo Ointreo®» tnu*»?»o#v srooo*>p^ r*. 0 AJ 9 CP JA -n 0 0 #n ni cf «C 0 0 0 0 <0 0 0 0 0 0 -o 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 s> 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 e 9 0 9 0 C- 0 0 0 c c 0 c 0 0 0 c e* C5 0 e 0 c- c- c 0 0 C 0 0 ui tr» li. 0 0 c 0 c 0 c c 9 0 0 0 c c 0 0 0 0 c* e. C 0 c 0 c- C c c* C c c c 0 c 0 c c 0 0 0 z- Vi c > CP «* n. in tn 'D tr en 9 ID c tn 9 0 0 C 0 0 0 0 0 9 9 9 in 9 ..0 9 in pf in m < 9 -CD X «r 9 •n PO #n #n 9 9 9 9 tn 9 9 *n *n 9 9 9 WA #A *n •n pA -A pA fA #A #A *A -A 9 9 9 9 9 9 *A HA V- CD 0 0 w 1 1 t • t t 1 t 1 I 1 C 1 c • * t 1 ff t • 1 ff ff ff 1 ff 1 ff 1 ff 1 ff ff ff ff 1 ff t « X w L_ p- iD 9 OC .•<- •fi or 9 If cr in 9 0 'D «0 « 0 O' 0 C c <- 0 ru et' 0 CD d e P*“ 9 0 ff-. a ff-. 3 tn 9 «0 TO 9 D rw 0 0 0 pn pr> 9 tn ru ru CO 0 0 D 0 9 JA ru *n AC 3 CP 0 0 NA 9 pn 30 in tn 9 pn 0 UA 9 m 9 9 pfi _i IV 9 ru pr> h- cr pf K* in fu« in P-* <■ n- OC- Aj fC 9 P-* in A* pA 0 cr cc 0* in pf 9 C ru nj 0 9 #n D CP* 0 in 0 UA 0 9 0 0 p- 0 0 0 45 *0 •n 0 eo 9 0 0 0 pA >• w •n ru ru OO O' 0 .n P- ru AJ ru -n pn 9 9 9 0 D AJ 9 9 p.- JA D H> M- M- tr tf. in tn tn tn 9 9 tn tn in m tn < < U) 0 sT <£ .e sC >T -£• in ir 0 P- ff*-ff**^ff*- P» p*- ff**. r- 9 0 uJ 0 0 0 cr 0 0 0 9 *0 cn 0 0 D* o* 0 > 4. *. 4. 4_ 4. 4, 4_ 4, 4. CO Ê £ £ CE EB £ E £ E E E € £ £ e e £ E £ E E E e E g E g EEEE EE é ê e E ^ «-"» O S >000 *2 » 0 0 0 0 OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO ^ •••»* *•••• •••*• «•••• *•••• «••*• *»«•• •»••■ ^ ^ •m- 0 0 ^ 6 *— oootTo ^ «0 o e- "\j o o ? ç ^ o * ^ — — — o ..C O 'f fvacp^c •-^cn.a occ^c-rv ir «- n. c c cna-*-C crc*-C^ Tj c c ru o ^ Ln *n m o ^ ^ . n c r m "C cù ^ 90 ^ 30 :o »n ? jn y» ? o ^ ^n — «vi«n»n y» 6 o 'A C ^ triraj«o otrtrtfir ^irocro afsyooo 0000c* s?c^«rcr« ? tr tf tr tr irtro»n. 4W HA ■ha ■— p— HA AJAJ 0 AJ *— HA 3> "A m JA D H> X > 0 JA ffJ X) AO TO i n 0 X» 9 i n D t f u c f f 9 r v I f P- 9 0 C 0 fP** c r*- P-' c 0 A. C f f 1— c C t f er 0 rv. 0 V e p f f f f f 0 C K *ff f f f - c C c r f f ' I f r v I f f f f f t f I f cr 0 » t 9 1 1 • » 1 # 9 •• 91999 91911 «11 . 1 1 1 9 1 1 1 1 1 t » t f . tf. tf. a t f t f p - ff* f f I rv I f L'^ in p r r - tn r . pr f f r - p f r - e f f c t f cr. n p** p - d X p<- c ^ c 0 AJ JA %/ HA AJ 0 f f HA D A4 0 VJ D 9 0 > > f f c * AJ f f f f iA AJ V f f f f . C. -A D V 3 E 0 9 c 0 0 D D D> c * 7* 0 > n 0 X 0 0 0 — p r p r 9 9 9 9 f f IT Lf I f L f Lf I f If I f tr in I f -i p- = = I f 9 9 = i r p- c f f f f f f f f f f ec f f er f f f f f f f f f f a f f f f CD t f ff CT t f t f a ff t f (J a ff cr or a ec Of d f f CC f f < &) 9 9 9 9 9 *T 9 9 f f 9 9 9 9 9 9 9 9 9 9 9 9 f f f f T f f f f f f f f ff f f f f % p. J f f P- f f C c . r . i r f f C ec C C I f f f ff C t f D c t f s: L** c e X t) u “i •'NJ '.J V U V V A n ‘ U 1 ff c C •*“ K K Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 57 Œf*- a fv «T f- fs. —ff 0 fg rg fg fg 0 K, rv p/-, p*. w &A &r\ ff> "O f~-oc*C^fv &A o *M r,f a- a rv 0 c rg ^ 0000:=» ooooo OOOOO OOOOO o o o o o OOOOO ooooo OOOOO ^ ce- 00c OCOCC ccooc ooccc ooooo ooooo c o c o o 000 c-e w ••••• •••»• •••»• ••••• # » # # # ••••• •«••• ••«•• ooooo OOCOO ooooo ooooo ooooo OOCOO OOOCO. COCOC z ffa. c ^ > IT ff CT CTir 00 H> mm c 0 c CTIT C IT ru fs CT ff in in ir« c in 0* ru of H fs ff CT tr X 40 CTCT CTCT CT CTCTCTCT CTCT CTCT CT CT CT 0rg 0000 00fg HI ff Aj AJAJ ff 00 00 *- % o 00000 00000 00 00 00 w 1 1 ft ft ft ft 1 ft ft ft ft ft ft ft ft ft 1 ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft 1 t ft ft ft ft ft ft or Uj w in CT 0* fs. CT ff a- ftVrv O' H* fV CT CT CT _ fs #«# a ff CT CT fs mm, ts ff 0 CT fu CT « fs. *_ ff* A 3 in in H% 0rg ff CT ff HI CTCT ff Z AJ CT CT rg0 CT CTrg m 0CT ff m CT ff* HI 0ff* c. c a* rg 3 in CT 0ff* CD CT rgrg rg ■n m H> fg fgCTHI CT Hi CT ff HI AJ H| CTHI ff AJ ff* CT Af CTHJ HI c c fs fs fs a fts fs fs fs fs C A c C 00 c 0 rv c CTfs H* A ff* C e 0 e X 1 1 1 ft ft 1 1 ft ft ft ft ft ft t ft ft c ft ft 1 ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft ft z* • w #- 0fV 0fs ff e* a ft\If •— 0 H*. 0 CT IT CT fs fv 0 tf fs ff 00 1/ A a ff ff CT CT CTHI H> f g CT 0fs ff O' rgCT CT CT CT 0r g CT CTCT 0 ff* in 00 HI tf> 9 A CTff CT ff fg•n Aj rgHI AJ HI *n rg ff tn ff r g ff ff ff CTtn mJ ff 9 0 f f 0in »» ff f s 9 f f 0 0 CT 9 f g ff 9 CT 0 IT a CT 9IT 0 t f 9 ff 00or in < r g CT HI ff* r g H I r v 0 C O i n AJ 0 ff 9 9 CTCT HI H i H» 9 0 9 AJ C T ff 9 9 n ff CT CT >- w ff HI HI JA CT CTin 9 9 CT 9 AJ ff* CT %nJA JA JA J A 0 9 ff JA n HI JA 9AJ -A 9 in f s rgCT ff* e 0* ff ff* t n H*H H* H I n A fv i n C T fs f s fs f s fs CT CT CT> f s fs A fv w « C T Off CT CT f f f f ff f f ff ff ff f f ff f f f f f f ff ff f f ff f f f f f f f f ff ff f f ff f f ff f f ff ff ff ff ff ff f f ff D 0 O ' 0 C 0 0 C 0 ff 0 0 0 0 0 0 C 0 0 0 c 0 0 0 0 0 0 0 0 c 0 C O' 0 0 0 0 0 C* 0 0 CD CT 0 Off CT CTCTCTCT CT CT CT CT CT CT CT CT CT CT CT COCT COCTCT CT CT CT CTCT CO CT CT CT CT CT CT CT CT CT > it. ff* f f f f f f f f f f f f f f f f f f f f f f C ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff 0ff X f s J A HI 9 CT CT JA CT 0 9 HI CT ff 0 *** CT f f to 0 0 9 A j ff 0 ps. HI < 0 C D HI 0 Z> HI .w# f s 0 r g f f 9 e c H* tf f v m in 9 a A. r v CT' c c a tn ftf* i r f s A f s f s a 9 CT> r v A f v CT CT A 0 cr 0 CT UJ c > A . < a H* 0 0 0 H*. 9 0* 0 tf 9 9 in in ff 0 fs CT 0 CT H - f- C CT CT er HI AJCT f s f s C T f s CT CT CD JAA/ HI 9 n CT CT JA JA JA r g 9 HI 9 HI f f 0 A l ff CT tf) u X *c X CT •CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT CT in IT in CT CT in in in in g en 9 9 9 0 9 9 9 99 9 0 ff 9 9 0 0 0 0 0 0 0 0 9 0 9 0 0 0 0 0 9 ff- tf* tf t f a a a a a tf tf a tf a tf. tf a tf tf tf tf tf tf tf tf tf OL tf tf tf a tf 3 ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff *, 4P 4s 4P 4-*_ ■*. T XX XX T T T X T T *m e e e E *—■ ■*- € 6 E e E E e £ E F EE E g e f € € EE 6 E £ ^ OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO OOOOO o - « o o o ••••• ••*•• ••••• ••••• ••••• •••*• •••*• ***** z::z y z ;* » Ë J r r \j "vj *w «iM *0 r\J mm mm mm mm \J —* «-* —* mm <%) T~* "Sf *^1 v* O ff O O O P- O '%> TO O >«■»■ ï< r*. -6 0* ^ C *— rvfVfvrvfV n r^ A fv fv r\ n r\ rv f\ AfV k r-' k -. ^ rv »-r c i t o k k &r rv ff ff rr JA HI n 00■00JA 0 fs f s AJ HI so JA HI CT CT JA JA ""Vf o f f o agr tf A CT inin « fs fs in c CTCT ■C tf f f fs in f f 0 ff sC c o LT c* L'Z , C- f f If e CT CT tf or rv fV fv tf c A in CT a c 0 c c tr C 4A a lT rv a r* =• E HI H | H I HI JA %l -g AJ AJ A f H I HI HIHI — 9 •A H» 9 —• fg rg JA *i O 3 ffv JA -JA CT CT CT CT CT CT CT CT CT CT CT CT JA JA JA m JA JA JA JA JA jA m JA JA m ff ff ^ % Z ft — — *— — *- •s •' — ——— *~ 3 3 — ft ft ft ft ft 1 1 4 ft 9m I ft ft 1 ft ft ft ft ft ft ft ft 1 1 ft 1 _ «- H H fts fs H - c- p.. H rv C r- rv C •£ H' A tf in fs A 0 cr in 0 fv fs f \ H A in c 9 0 ■fl TO AJ CT> JA HI Aj f f J-* ^ T O *J C -J- TO fg f f 9 AJ ff AJ ff 9 c • A ■AJ f f rr AJ f f GO 9 CT 0 AJ r» Ù JA CT 0 .A 1 £ £? 3* X ff -• ff 3 g r 0 H H rv lA fv n 0in tr in If If in m U LT in m ir LT tn J J/ O'- r- ^ A rv. -- g cr tf 0 er a a er e «f o or «T #- c e a cr tf tf CC tf tf CC a tf CC <£ tf tf tf cr tf tf tf tf tf tf tf c ft) e o =r 9 9 9 ■O 9 9 a 9 9 9 9 9 9 9 9 9 -r 9 9 ■ ff ff ff ff ff ff ff _ X c r u CT fs ff c c. fs f If CT fs ff ff u tf JA JA JA .*A .*A JA JA -JA CT CT 0 CT CT K rv |H HH HHH ê E s ÇE 6 e £ e k! £ ?J Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 58 & - o LA LT «A o f o # A «? IV «C 9 VJ l A c r #A *\) f A o l A A J A j 9 o *A cr> t ? f y flO l a X > c r AJ O «DO 9 &A 9 u . i n LA t a LA LACT L f I f LALAC t r C ? A * «W Æ T t » •« • 1 1 1 t i 1 1 1 # Liw A j f V o* LA r ^ •£» I f o r - L f Lf «OD A J <£) e o L A C o « C L A LU _ f AJ A j c r A J #A "A•A o 3 0 « 0 2 a #* O #f' t r L A r-r &ALT LA LA LA « I f W 5 L A %. O c *D 1 • 1 1 # # fl I • 1 1 • 1 1 w r AJ c r • A r— AJ AJ ^ m J «OOOO o O o O O o o o o O O o c - o c o o O & o o o o O U l cr. w o o o c c e o o o c o c c e a . z tr. : > LA 9 >0 I f e o - 9 m t f t f ^ o O’ c t O O o O o o a * O ' O' O' O' o o : > u O e o o w fl 1 I 1 1 • 1 1 1 t c c U.' iU «TPA • c 9 9 r s . pA 9 O' « K- (h* T» lA O' ( y r n t f t f AJ O ^ # & c %> # n A J AJ tf> t f t f PA m m ^ «D a : c c C o C c - e t f OC' O' o cr ©- O' o 9 0 # 1 • 1 * t f -• c 1 t 1 f 1 fl • z LU I f 9 A - 6C I f fVi CP p r Kt o ec ÏJ fv < A l fA «T LAO' 9 O o o < r a oc o O o 9 o A l Lu i f O O c C o O' 4L J*L 80 OO 9 - pA t f t f lA O- > • w 9 *> fA LA ^ 1— C r L f r - N t f ' ^ ^ LA U J c r O ' o r O c r o O O O O O: c r o O c o C o c c o G o O => CO t f t f < 9 tf) t f t f t f t f CO 9 00 > l u c - c r C c O c e c c r a OOOO X h - AJ flO o t f #A 9 A l o kA «a C r c cy p f 9 c o « r t f t f i f & #" o o VLl e > p f t f 9 9 fVi fl~ «, r»■»-• o OC o t f t f m 9 pA Aj O w I f t f t r LfLf tf tf tf tf t f «0 ^ v> o o o o O O 9 o O O O O O a tf- t f t f t f t f t f t f , CL IT t f or «T t A, 3 o c r O' ( h O ' o r O' o o o o o (/> E E E E e e EEEE e e E e r * o o o o> o O o O o OOOO wU 4 - 9 - o OD s o AJ t f 9 lA 9 cr O fv fv ^ A. c 9 p - C c c r L A. cc o O* t - w c 40 o O 9 •A A t f ps. r>» eo *r— c fA pfK pf- pf. Ae PA A rw r v A. A. A A. K* O CL CD -A o jA t f y> y». O "A #A Li. C 9 e r o C c . 9 Lf c - 9 c A Ak C C3 CO 3 — r - t f r v I f t f K tJC A- •£ A w 6 LA lA lA lA fO — — A i AJ ~C> :? cr ? ? < ^ ? 9 9 - f 9 9 A LA X g ' c "O 1 « « I I • I fO U' 1 1 1 • •• * _Q fw. K « f <=■ K*r*r-ctr «roc- I.JC .jy J^ mm rt) ^ ^ , . * . • . % r ^ ? T Af JO - v ^ r y o — c jC T '-fv ^ ^^ — — —• O Lf ir LT Lf If C O C —i L. '«— Z. r a tt O- a er a o. Ol r er «r er a er (/, "3 ^ ? ? - ? 7 3 3 -? ? 3 3 3 3 3 ^ o r-c-rv..r - 3 3 If < r-cc— Q. -- -.tctr'w j’ r-ci.'P %,-•; , ,0333 wwr-'f''' we.e.<-c. trTKF'M- H-KK-Ct.e.>.w ^_ " n I -M : : : : 2 g u ...... " *■ ...... OJ — Q Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 59 BIBLIOGRAPHY AA.PG, 1983, Northern Rockies/Williston Basin Region stratigraphie chart, COSUNA project, Ballard, W. W. , Bluemle, J. P., and Gerhard, L. C., coordinators. Asada, T., and Aldrich, L. T., 1966, Seismic observations of explosions in Montana, in the Earth Beneath the Continents: Geoph. Mon. 10, AM. Geoph. Union, Washington D . C ., p. 382-390. Bally, A. W . , Gordy, P. L., and Stewart, B. A., 1966, Structure, seismic data, and erogenic evolution of southern Canadian Rocky Mountains: Bull. Canadian Petroleum Geology, V. 14, p. 337-381 Bateman, P. C ., and Eaton, J. P., 1967, Sierra Nevada batholith: Science, v. 158, p. 1407-1417. Bennett, G. T., Clowes, R. M., and Ellis, R. K. , 1975, A seismic refraction survey along the southern Rocky Mountain Trench, Canada: Bull. Seismological Soc. America, v. 65, p. 37-54. Bible, J. L, , 1962, Terrain correction tables for gravity: Geophysics, v. 27, no. 5, p. 715-718. Boberg, W. W. , 1984, Flathead region, Montana, Alberta and British Columbia, petroleum exploration an historical review: in Montana Geo. Soc. Field Conf. and Symposium Guidebook, northwestern Montana and adjacent Canada, p. 1-25. Brickey, M. R., Bankey, V., and Kleinkopf, M. D., 1981, Principal facts for gravity stations in part of the Wallace 1 by 2 degree quadrangle, Idaho and Montana: U. S. Geol. Survey Open-file Report 81-1782. Cady, J. W . , 1980, Gravity highs and crustal structure, Omineca crystalline belt, northeastern Washington and southeastern British Columbia: Geology, v. 8, p. 328-332. Campbell, D. L. , 1983, BASIC programs to calculate gravity and magnetic anomalies for 2 1/2 - dimensional prismatic bodies: Ü. S. Geol. Survey Open-File report 83-154, 40 p. Chandra, N . N. and Cumming, 1972, Seismic refraction studies in western Canada: Canadian Jour. Earth Sciences, v. 9, p. 1099-1109. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 60 Constenius, K. K., 1981, Stratigraphy, sedimentation, and tectonic history of the Kishenehn basin, northwestern Montana : M. S. thesis, Univ. of Wyoming. Constenius, K. N., 1982, Relationship between the Kishenehn basin, and the Flathead listric normal fault system and Lewis thrust salient: in Geologic Studies of the Cordilleran Thrust Belt, R. B. Powers, ed., v. 2, Rocky Mountain Association of Geologists, p. 817-830. Constenius, K. N., and Dyni, J. R., 1983, Lacustrine oil shales and stratigraphy of part of the Kishenehn basin. Northwestern Montana: in Mineral and Energy Resources (Colo. School of Mines), v. 26, no. 4, p. 1-16. Cumming, W. B ., Clowes, R. M., and Ellis, R. M., 1979, Crustal structure from a seismic profile across southern British Columbia: Canadian Jour. Earth Sciences, v. 16, p. 1024-1040. Dobrin, M. B ., 1960/1976, Introduction to geophysical prospecting (2nd/3rd ed.): New York, McGraw-Hill Book Co., Inc., 446 p./630 p. Fountain, D. K., and McDonough, D., 1984, Crustal structure of northwestern Montana and southern Alberta and British Columbia based on the interpretation of gravity data: Montana Geological So. Field Conference and Symposium Guidebook northwestern Montana and adjacent Canada, p. 253-258. Gordy, P. L., Frey, F. R., and Norris, D. K., 1977, Geological guide for the CSPG 1977 Waterton-Glacier Park Field Conf., 93 p. Hales, A. L., and Nation, J. B., 1973, A seismic refraction survey in the northern Rocky Mountains: more evidence for an intermediate crustal layer: Geoph. Jour, of the Royal Astronomical Soc., v. 35, p. 381-399. Harrison, J. E., Kleinkopf, M. D ., and Obradovich, J. D ., 1972, Tectonic events at the intersection between the Hope Fault and the Purcell Trench, northern Idaho: U. S. Geol. Survey Prof. Paper 719, 24 p. Harrison, J. E., Kleinkopf, M. D ., and Wells, J. D . , 1980, Phanerozoic thrusting in Proterozoic Belt rocks, northwestern United States: Geology, v. 8, p. 407-411. Harrison, J . E., Cressman, E. R ., and Whipple, J. W., 1983, Preliminary geologic and structure maps of part of the Kalispell 1 by 2 degree quadrangle, Montana: U. S. Ceci. Survey Open-File report 83-502. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. Hëirtzler, J. R., Peter, G./, Talwani, M., and Zurfeueh, E. G., 1962, Lamont Geol. Obs. (Columbia Univ.) Tech. Report #6, CU-6-62. Hildenbrand, T. G., Simpson, R. W., Godson, R. H., and Johns, M. F., 1982, Digital colored Bouguer gravity, conterminous U. S., U. S. Geol. Survey Map GP-953-A. Hill, D. P., 1972, Crustal and upper mantle structure of the Columbia Plateau from long-range seismic refraction measurements: Geol. Soc. American Bull., v. 83, p. 1639-1648. International Association of Geodesy, 1967, Geodetic Reference System, 1967, International Association of Geodesy Special Pub. 3, 74 p. Johns, W. K . , 1970, Geology and mineral deposits of Lincoln and Flathead counties, Montana: Montana Bureau of Mines and Geology Bull. 79. Kulik, D. M. , 1982, Preliminary gravity study of Glacier National Park, Montana, in Geologic Studies of the Cordilleran Thrust Belt, R. B. Powers, ed., v. i., Rocky Mountain Associations of Geologists, p. 459-462. McBride, T., Wilson, D., Bankey, V., and Kleinkopf, M. D . , 1980, Principal facts for gravity stations in the Cut Bank 1 by 2 degree quadrangle, Montana: U. S. Geol. Survey Open-file Report 80-1067. McCamy, K . , and Meyer, R. P., 1964, A correlation method of apparent velocity; Jour. Geophysical Res., V. 68, p. 691-699. Kereu, R. F., Majumdar, S. C., and White, R. E., 1977, The structure of the crust and upper mantle under the highest ranges of the Canadian Rockies from a seismic refraction survey; Canadian Jour. Earth Sciences, v. 14, p . 196— 208. Moulton, F ., 1984, Oil and Gas possibilities under the Precambrian Belt multiple thrust complex of northwestern Montana and northern Idaho: in Montana Geo. Soc. Field Conf. and Symposium Guidebook, northwestern Montana and adjacent Canada, p. 259-261. Kudge, M. P., 1982, a resume of the structural geology of the northern disturbed belt, northwestern Montana: in Geologic Studies of the Cordilleran Thrust Belt, R. B, powers, ed., v. 1, Rocky Mountain Association of Geologists , p. 91-122. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. Mudge, M. R.j a.nd EarViarü, R. L., 1983, Bedrock geology of part of the northern disturbed belt, Lewis and Clark, Teton, Pondera, Glacier, Flathead, Cascade, and Powell counties, Montana: U. S. Geol. Survey Map 1-1375. Plouff, D ., 1977, Preliminary documentation for a FORTRAN program to compute gravity terrain corrections based on topography digitized on a geographic grid: U. S. Geol. Survey Open-Fxle Report 77-535. Price, R. A., and Mountjoy, E. W., 1970, Geologic structure of the Canadian Rocky Mountains between Bow and Athabasca rivers - a progress report: in Structure of the Southern Canadian Cordillera, J. 0. Wheeler (ed.) Spec. Pap. Geol. Assoc. Can., v . 6, p. 7-25. Price, R. A., 1981, The Cordilleran thrust and fold belt in the southern Canadian Rocky Mountains: in Thrust and Nappe Tectonics, K. R. McClay and N. J. Price, (eds.), Geol. Soc. London Spec. Pub. No. 9, p. 427-448. Ross, C. P., 1960, Geology of Glacier National Park and the Flathead region northwestern Montana: U. S. Geol. Survey Prof. Paper 296, 125 p. Smithson, S. B ., 1971, Densities of metamorphic rocks: Geophysics, v. 36, no. 4, p. 690-694. Society of Exploration Geophysicists, 1982, Gravity anomaly map of the United States exclusive of Alaska and Hawaii. Spence, G. D., Clowes, R. M., and Ellis, R. M., 1977, Depth limits on the M-discontinuity in the southern Rocky Mountain Trench, Canada: Bull. Seis. Soc. Am., v. 67, p. 543-546. Steinhart, J. S., and Meyer, R. P., 1961, Montana, 1959: in Explosion studies of continental structure, Carnegie Inst. Wash. Publ. 622, p. 305-343. Stickney, M. C ., 1980, Seismicity and gravity studies of faulting in the Kalispell valley, northwest Montana: H. S. thesis. University of Montana, 82 p. Talwani, M . , and Heirtzler, J. R., 1964, Computation of magnetic anomalies caused by two-dimensional structures of arbitrary shape: in Computers in mineral industries, part I, Stanford Univ. Publ. Geol. Sci., v . 9, p. 464-480. Troger, W. E. , 1971, Optische bestimmung der gesteinbilden Minérale Teil 1, 188 p. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. 63 Whipple, J. W., Connor, J. J., Raup, 0. B., and McGimsey, R. G., 1984, Preliminary report on the stratigraphy of the Belt Supergroup, Glacier National Park and adjacent Whitefish Range, Montana: in Montana Geo. Soc. Field Conf, and Symposium Guidebook, northwestern Montana and adjacent Canada, p. 33-50. Wilson, D. M., 1978, Principal facts for gravity stations in Flathead, Glacier, Pondera, and Teton counties, Montana: U. S. Geol. Survey Open-file Report 78-104. Wilson, D. M . , 1979, Principal facts for gravity stations in the Wallace 1 by 2 degree quadrangle, Montana and Idaho; U. S. Geol. Survey Open-file Report 79-1039. Wynn, J. C., Kleinkopf, M. D ., and Harrison, J. E., 1977, Audio-frequency magnetotelluric and gravity traverse across the crest of the Purcell anticlinorium, northwestern Montana: Geology, v. 5, p. 309-312. Reproduced with permission of the copyright owner. Further reproduction prohibited without permission.
