IN THE NAME OF GOD CONTENTS
MAHSHAHR 7 Introduction 4 Khuzestan Province 8 Tourist Attractions 9 Mahshahr Port 10 Imam Khomeini Port 11 Petrochemical Special Economic Zone (MAHSHAHR) 13 Bandar Imam petrochemical Co. 14 Kharazmi Bandar Imam Co. 15 Faravaresh Bandar Imam Co. 16 Kimia Bandar Imam Co. 18 Basparan Bandar Imam Co. 20 Ab Niroo Bandar Imam Co. 22 Arvand Petrochemical Co. 24 Amirkabir Petrochemical Co. 26 Buali Sina Petrochemical Co. 30 ASSALUYEH 59 Tondguyan Petrochemical Co. 32 Bushehr Province 60 Khuzestan Petrochemical Co. 36 Assaluyeh Port 63 Fajr Petrochemical Co. 38 Pars Special Economic / Energy Zone (Assaluyeh) 64 Karoon Petrochemical Co. 40 Pardis Petrochemical Co. 66 Fanavaran Petrochemical Co. 42 Nouri (Borzuyeh) Petrochemical Co. 68 Razi Petrochemical Co. 44 Pars Petrochemical Co. 70 Marun Petrochemical Co. 46 Arya Sasol Polymer Co. 72 Laleh Petrochemical Co. 48 Mobin Petrochemical Co. 74 Farabi Petrochemical Co. 49 Zagros Petrochemical Co. 76 Ghadir Petrochemical Co. 51 Mehr Petrochemical Co. 77 Shimi Baft Co. 52 Jam Petrochemical Co. 78 Navid Zar Shimi Co. 53 Morvarid Petrochemical Co. 80 Shahid Rasouli Petrochemical Co. 54 Kavian Petrochemical Co. 81 Shimi Tex Arya Co. 55 Farsa Shimi Petrochemical Co. 82 Arya Phosphoric Jonoub Co. 56 Jam Poly Propylene Co. 83 Rejal Petrochemical Co. 57 Jam Ehtemam Co. 84 OTHER REGIONS 85 Shazand (Arak) Petrochemical Co. 87
Esfahan Petrochemical Co. 91 Kharg Petrochemical Co. 94 Tabriz Petrochemical Co. 97 Shiraz Petrochemical Co. 101 Khorasan Petrochemical Co. 106 Kermanshah Petrochemical Co. 108 Bisotoon Petrochemical Co. 110 Kermanshah Polymer Co. 112 Orumiyeh Petrochemical Co. 114 Ilam Petrochemical Co. 116 Poly Nar Co. 117 Abadan Petrochemical Co. 118 Iran Carbon Co. 120 Ghaed Basir Petrochemical Co. 121 Gameron Petro Sanat Co. 122
PETROCHEMICAL TERMINALS & TANKS 124 Pars Petrochemical Port 125 Mahshahr Petrochemical Port 126 Mahshahr Tank Yard 127 INTRODUCTION Petrochemical is a major industry in Iran. Being an important source of non-oil revenues, it plays a significant role in the expansion of local industries, the development and localization of technologies and the growth of its downstream industries. It is also important for the industry’s research and development activities. Diversity of feedstocks, access to international waters and specialist workforce are among the major advantages of the industry. The genesis of Iran’s petrochemical industry goes to 1963 when a fertilizer plant was built in the city of Shiraz. One year later, the state-owned National Petrochemical Company was established to spearhead the development and policy-making for the industry. During 1964- 1977, Razi (ex-Shahpour), Abadan, Pazargad, Ahwaz Carbon Black (ex-Iran Carbon), Kharg, Farabi (ex-Iran-Nippon) and Shiraz expansion projects were built. During this period, a large portion of Bandar Imam Petrochemical Co. (ex-Iran and Japan Petrochemical Co.) was completed. This growth trend was, however, disrupted after Iraq invaded Iran in early 1980s. When the war came to an end, Iran implemented its first five-year development plan (1989- 1994) after the victory of its Islamic Revolution. Under the plan, NPC reconstructed its war-damaged facilities and built two new plants in Esfahan and Shazand (Arak).In 1997, NPC’s output reached 5.2 million tons and in 2013 it rose to 60 million tons. By implementing more than 67 approved projects, the output capacity continued to surge and reach more than 120 million tons.
PETROCHEMICAL COMPLEXES 9 th Edition 4 Iran’s Petrochemical Complexes (Based on 2014 approval)
Total number: 53
Location
Region No. Capacity (million/tons per year) Mahshahr 21 25.6 Assaluyeh 13 24.3 Other regions 19 9.1 Total output capacity 59 million/tons per year
Including Bandar Imam 3rd NF 61.6 million/tons per year Total NO. of Mahshahr & Assaluyeh Complexes include Fajr & Mobin Petrochemical Companies.
PETROCHEMICAL COMPLEXES 5 9 th Edition PETROCHEMICAL COMPLEXES 9 th Edition 6 Petrochemical Special Economic Zone MAHSHAHR
PETROCHEMICAL COMPLEXES 7 9 th Edition Khuzestan Province
The southwestern Khuzestan Province spreads over an area of 64,057km2. It is bordered by Lurestan, Chaharmahal-va-Bakhtiari, Kohkiloyeh-va-Boyerahmad and Ilam provinces. On its south is located the Persian Gulf and it has Iraq on its west. According to a 2011 census, it had a population of over 4.5 million of which about 67 percent of the population lives in urban areas. In summer time, Khuzestan and its coasts are extremely hot. According to the census, the annual average temperature was 26.3º C and annual precipitation in the center of province was around 184.3 millimeters. The census also showed that the majority of people in the province speak Farsi. Other ethnic languages including Arabic, Lori Bakhtiari, Dezfooli and Shooshtari are also spoken. Khuzestan is home to one of the man’s most ancient civilizations.
About six thousand years ago, a civilization emerged in the city of Shoosh or Susa. Which, two thousand years later, led to the formation of the powerful kingdom of Elam. The kingdom was vastly developed under the Achaemenian, Arsacides and Sassanids dynasties. Khuzestan is very important to the Iranian Economy. The province contains enormous oil and gas resources. Due to the availability of well-developed marine, air and land connections as well as access to the international waterways, Khuzestan offers lucrative investment opportunities. The province consists of 53 cities, 61 towns, 55 districts and 130 villages. The provincial capital is Ahwaz.
PETROCHEMICAL COMPLEXES 9 th Edition 8 Tourist attractions: The most attractive historical and natural places of interest in Khuzestan are: Abadan: Museum, Minoo Island, Arvand Rood (River). Andimeshk: Dehloran mineral water springs, Ein-e-Khosh Fountain and Karkhe protected zone. Ahwaz: Suspension Bridge (also known as White Bridge), Karoon River and its riverside parks. Izeh and Bagh-e-Malek: Eshkaft-e-Salman (Salman Chasm), Bard Nebeshteh (Stone Inscription), Kol Fareh Carvings and Hani Inscription. Behbahan: Zohre River, Jarahi (Maroon) River, Arjan Castel, Tang-e-Tak Ab Inscription. Khoramshahr: Arvand Rood (River) and its riversides, Grand Mosque and Yaghoob-e-Leis Tomb. Dezful: Dez Dam lake, Dezful Caravansary, The city’s ancient bridge, Vazir (vizier) bath, Jondi Shahpour ancient city, Grand Mosque and Yaghoob-e-Leis Mausoleum. Ramhormoz: Jarahi (Maroon) River, Ghal-e-Dokhtar (The Girl’s Castle). Soosangerd: Hoor-al-Azim marshland. Shadegan: Shadegan Lagoon. Shoosh: Choghazanbil Ziggurat, Apadana Palace, Acropol Castle, Karkh-e- Porch, Ardeshir Palace, Prophet Daniel’s Shrine and Shoosh Museum. Shooshtar: Waterfalls, ancient water mills, Gorab mineral waters, Grand Mosque, Shooshtar Caravansary, and Seyed Mohammad Mahroo Mausoleum. Mahshahr: Osk ancient city, Salak ancient village, Basif ancient castle. Masjed-Soleiman: Karoon Dam Lake, Ghal-e-Bardi (Stone Castle) and Bard Neshandeh (stone inscription) Temple.
PETROCHEMICAL COMPLEXES 9 9 th Edition Mahshahr port Mahshahr port is located at the extreme northeast of Khuzestan province near the Mousa Estuary. It is bounded in the north by Ahwaz and Ramhormoz cities; in the east by the city of Behbahan; in the west by the city of Khoramshahr and in the south by the Persian Gulf. Mahshahr covers an area of over 7304km and its altitude is 3m above the sea level. It consists of 3 districts: Central, Bandar Imam and Hendijan. Its distance from Tehran is 1032km, from Ahwaz is 151km, from Abadan is 95km, from Aghajari is 72km and from the nearby Bandar Imam Khomeini is 18km. It has humid weather and maximum summer temperature is as high as 50ºC. The average annual temperature is about 25ºC. Average humidity is 65% at 06:30am and 40% at 06:30pm. Average annual precipitation in Mahshahr is about 196mm.
PETROCHEMICAL COMPLEXES 9 th Edition 10 Zohreh and Jarahi (Maroon) Rivers run is home to the majority of the population, through the city outskirts. Mahshahr, is 3km from the new one. Most of the literally meaning ‘the moon city’, is one government organizations and institutions of the most ancient ports on the Persian are located in this section. Gulf. Formerly called Mashoor, the city In 1991, NPC unfolded a new development consists of two districts; the old and the plan for the petrochemical industry in the new Mahshahr. region, which has boosted its economy. The new Mahshahr came into existence In addition to its oil and gas export when an oil-exporting port was constructed. installations, Mahshahr is notably important It was the country’s largest oil-exporting port for its petrochemical industry. Bandar Imam before the Kharg Island oil export terminal Khomeini, one of Iran’s major ports, is was built. The old section of the city, which located 20km from Mahshahr.
Imam Khomeini Port The port lies at the extreme northwest part of the Persian Gulf. It is bordered in the east by the cities of Abadan and Khoramshahr and in the southeast by the provincial capital Ahwaz. Imam Khomeini Port is connected to the Persian Gulf via Mousa Estuary. It is one of the world’s most important natural canals. Vessels of up to 100,000 tonne capacity ought to pass through this canal en route to Bandar Imam Khomeini and Mahshahr.In 1973, the residents of Bandar Imam Khomeini were relocated to the nearby Sar Bandar. Imam Khomeini Port is currently Iran’s largest marine terminal. It has an annual loading/ unloading capacity of over 50 million tonnes. The development of the petrochemical industry in the region in the past recent years has spelled considerable growth of the port. Currently, the port annually operates about 35 million tons of various goods.
PETROCHEMICAL COMPLEXES 11 9 th Edition PETROCHEMICAL COMPLEXES 9 th Edition 12 Petrochemical Special Economic Zone (MAHSHAHR) The Petrochemical Special Economic Zone is located in the southwest of Mahshahr city, in Khuzestan province, southern Iran, near the northern coast of the Persian Gulf. The Zone now covers an area of 2,600 hectares. When it was first established, it only encompassed an area of 1,700 hectares.The expansion came after Bandar Imam, Razi and Farabi Petrochemical Complexes were annexed to the Zone, which is linked to international waterways via Bandar Imam Port and has access to Turkey, Europe and Central Asian countries via Iran’s national railroad. The main reason behind establishing the Zone was to bring about industrial development especially in the petrochemical sector and its downstream industries. The zone offers a wide range of economic and social benefits at local and national levels including the attracting state-of-the-art technologies and generating job opportunities.The Organization of Petrochemical Special Economic Zone, which is a subsidiary of NPC, is responsible for promoting and developing the Zone. It began its activities in 1997 after receiving the respective sanction from the nation’s High Council for Free Trade and Industrial Zones. Among its major activities are developing the infrastructural facilities with the aim of attracting domestic and foreign investors. It is the gateway to Iran’s abundant oil and gas resources.
PETROCHEMICAL COMPLEXES 13 9 th Edition BANDAR IMAM Petrochemical Complex (BIPC)
BIPC located at a 270-hectares area in the southern province of Khuzestan. It is 160km away from Ahwaz and 84km from Abadan.
Management Structure In 2002, in line with non-centralized directorate, BIPC restructured its management organization by establishing five independent subsidiaries each responsible for a number of plants to boost its productivity and to have a better improvement potentiality. Area: 270 hectares Founded in: 1971 (two years later a joint venture with five Japanese companies was signed) Ownership: Persian Gulf Petrochemical Co. (69.27%), Justice Shares Broker Co. (0.37%), Preferred Stock (0.73%).
BIPC’s subsidiaries include: Kharazmi Kimiya Faravaresh Basparan Abniroo
Process Block Diagram
PETROCHEMICAL COMPLEXES 9 th Edition 14 Kharazmi Bandar Imam Co.
Kharazmi Company is responsible for projects, maintenance and services management. Projects management: scopecovers supervising, planning and progress control of projects. Maintenance management: includes maintenance services, main workshop, instrument, electricity, telecommunication and critical machine services. Services management: includes social welfare services, transportation, general and specialized services and housing and maintenance services.
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000 QCC EFQM
PETROCHEMICAL COMPLEXES 15 9 th Edition Faravaresh Bandar Imam Co.
Location: Petrochemical Special Economic Zone Area: 120 hectares Founded in: 1999 Ownership: BIPC
Product Final ( ‘000 t/y) Feed Licensor Production date
Ethane 565 NGL Parsons Propane 1,090 NF2 (1990) Butane 908 NF1 (1995) C5+ 768 Ethane, Ethylene 411 C5+ Lummus 1993 Propylene (chemical grade) 117 C4 Cut 80 Pyrolysis gasoline 113.5
Fuel oil 21.6 Parsons NF2 (1990) NF1 (1995) Engel Hard, Benzene 230 Naphtha 1996 UOP, HRI Mixed xylenes 140 Raffinate 241 Paraxylene 180 Mixed Xylenes IFP 2000
* The 3rd NF plant of BIPC with annual production capacity 443,000 tons of Ethane, 870,000 tone of Propane, 688,000 tone of Butane, 649,000 tons of C5+ and 35,000 tons of gas fuel is on stream.
PETROCHEMICAL COMPLEXES 9 th Edition 16 Products application
NF plant products such as C2, Butane and C5 provide the feedstock for olefins & fuels. Output from the olefin plant provides the main feedstock for the BIPC’s polymer plants. Output from Aromatic plants like Benzene, mixed xylenes & paraxylenes are used in the production of paints and plastic industries as well as the production of PTA and chemical industries solvents.
Input feed Amount (‘000 t/y) Source NGL 3,200 NIOC Naphtha 1,000 Abadan refinery Mixed xylenes 74 import
Standard certificates
ISO-9001 ISO 18001 ISO-14001 QCC EFQM
PETROCHEMICAL COMPLEXES 17 9 th Edition Kimiya Bandar Imam Co.
Location: Petrochemical Special Economic Zone Area: 31 hectares (process plants), 1550 hectares salt lake Founded in: 1999 Ownership: BIPC
Product Final ( ‘000 t/y) Feed Licensor Production date
Sodium chloride (Salt) 520 Sea water Technocell 1994 Caustic Soda 250 Salt Denora
63.3 Chlorine / hydrogen Lorrian, HCL (33%) Carbon+SGL Sodium 6.6 Chlorine, Caustic Denora hypochlorite Soda EDC (DC) 300 Chlorine, Ethylene Tosoh EDC (OXY) 140 HCL, ethylene VCM 180 EDC MTBE 500 Methanol, Butane UOP 2002
PETROCHEMICAL COMPLEXES 9 th Edition 18 Products application
Detergents, industrial solvents, PVC, sugar industry, paper industry, unleaded gasoline, water and sewage treatment
Input feed Amount (M3/y) Source Sea water 21,000,000 Persian Gulf DM water 159,135 Abniroo Co.
Input feed Amount (‘000 t/y) Source Butane 382 Faravaresh Co. Ethylene 126 Faravaresh Co. Methanol 176 Fanavaran petrochemical Co.
Standard certificates
OHSAS-18001:1999 ISO-14001:2004 ISO-9001:2000 QCC EFQM
PETROCHEMICAL COMPLEXES 19 9 th Edition Basparan Bandar Imam Co.
Location: Petrochemical Special Economic Zone Founded in: 1999 Ownership: BIPC
Product Final ( ‘000 t/y) Feed Licensor Production date
HPDE 150 Ethylene Mitsui 1994 LDPE 2*50 Tosoh Corp. LD-1(1995), LD-2(1994) Polypropylene 50 (polymer grade) Mitsui, Toatsu 1994
Propylene (polymer grade) 64 Propylene (Chemical grade) PVC 175 VCM HULS (Germany) 1995 C4 raffinate 62.6 C4 cut BASF (Germany) 1994 1,3 Butadiene 26 C4 cut Synthetic rubber 40 1,3 Butadiene & JSR (Japan) Styrene According to National Petrochemical Company board of directors approval, production of this unit has been stopped from early 2006 and produced propylene are sending to Rejal Petrochemical Company.
PETROCHEMICAL COMPLEXES 9 th Edition 20 Products application
HDPE: pipes, cables, various plastic bags, food & chemical containers LDPE: Cable covering, various nylon films, plastic bags, household appliances, pipes, sport goods and laboratory equipment PP: kitchen ware, stationary, toys, food packing, auto parts, cereal bags, bottles PVC: cable coverings, transparent films, pipes and joints door & window panes, shoe industry, electronic industry SBR: auto parts tires, floor covering, shoe soles, floor covering, toys
Input feed Amount (‘000 t/y) Source Ethylene (HD plant) 155 Faravaresh Bandar Imam Co. Ethylene (LD plant) 115 Propylene (PP plant) 117 VCM (PVC plant) 180 Kimiya Bandar Imam Co. C4Cut (SBR plant) 80 Faravaresh Bandar Imam Co. Styrene (SBR plant) 8 Pars Petrochemical Co.
Standard certificates
HSE OHSAS 18001:99 ISO 9001:2000 ISO 14001:2004 QCC EFQM
PETROCHEMICAL COMPLEXES 21 9 th Edition Ab Niroo Bandar Imam Co.
Location: Petrochemical Special Economic Zone Area: 22 hectares Founded in: 1999 Ownership: BIPC
Product Final Feed Licensor Production date
DM water 2,500 m3/h Raw water Kurita 1990 DM water, Return Steam 1,500 t/h condensate Kawazaki Power 260 mw Fuel Toshiba/ABB
Industrial Air 92,000 m3/h Air Mitsui
Nitrogen 18,000 Nm3/h Compressed air Kobe, Airproduct
Liquid Nitrogen 1,500 kg/h
PETROCHEMICAL COMPLEXES 9 th Edition 22 Products application
Utilities for BIPC plants
Input feed Amount (m m3/y) Source Fuel Gas 1,100 NIGC Raw water (Karoon River) 36,5 Water Organization
Standard certificates
ISO 9000 ISO 14000 OHSAS 9001 QCC EFQM
PETROCHEMICAL COMPLEXES 23 9 th Edition Arvand Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 108 hectares Founded in: 2000 Ownership: Persian Gulf Petrochemical company (80%), Petroleum Ministry Retirement & Welfare Fund (20%)
Product Final (‘000 t/y) Feed Licensor Production date
PVC (Suspension) 300 VCM VENOLIT 2011 (GERMANY) PVC (Emulsion) 40 VCM EDC 890 Chlorine, ethylene 2010 VCM 343 EDC 2011 Chlorine 585 DM Water,Salt Udeh 2010 Caustic Soda 660 Sodium Hypochlorite 16.2 Chlorine, Caustic Soda
Products application
Production of detergents, industrial solvents, paper & sugar industries, sew- age and water treatment, antiseptic . . .
PETROCHEMICAL COMPLEXES 9 th Edition 24 Input feed Amount (‘000 t/y) Source Ethylene 252 West Ethylene Pipeline Salt 1,300 Local Sources Chloridric acid 50 Karoon Petrochemical Co. DM water 1400 Fajr Petrochemical Co.
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000
Process Block Diagram
Salt Hydrogen
DM water Chlor Alkali Unit Chlor
Caustic Soda DC Reactor Purification Caustic Soda EDC EDC Unit EDC EDC Oxygen Reactor VCM VCM Chlor Purification Unit S-PVC Unit S-PVC Sodium Hypochlorite Chloridric Ethylene acid
Sodium E-PV E-PVC Hypochlorite Ethylene Oxygen Chloridric acid
PETROCHEMICAL COMPLEXES 25 9 th Edition Amir Kabir Petrochemical Co.
Location: Petrochemical Special Economic Zone (Mahshahr) Area: 55 hectares Founded in: 1998 Ownership: Private sector
Product Final (‘000 t/y) Feed Licensor Production date
Ethylene 520 Linde 2005 Ethane/LPG Propylene 154 Raffinate/ C4 Cut 104 light ends Pyrolysis gasoline 134.2 Butane/ pentane Fuel oil 23.5 Butene-1 20 Ethylene IFP 2002 HDPE 140 Hoechst LLDPE 260 B.P. (Innovene) 2005 LDPE 300 Basell 2010 Butadiene 51 C4Cut Lurgi 2005 C4 Raffinate 52 Lurgi
PETROCHEMICAL COMPLEXES 9 th Edition 26 Products application
HDPE: pipes, cables, plastic bags, containers, barrels for holding chemicals and foodstuffs LLDPE: packing, films, foodstuff container, water and sewage canals, oil, milk & juice packages, containers for holding chemicals LDPE: Cable Covering, packing, films, general applications for different kinds of films Butadiene: production of synthetic rubber and other resistant polymers
PETROCHEMICAL COMPLEXES 27 9 th Edition Input feed Amount (‘000 t/y) Source Ethane 233 BIPC Raffinate 210 Butane 117 Raffinate 199 Buali Sina Petrochemical Co. Light ends 350 C5 21 Liquid gas 39 Ethylene 200 Local Sources
Standard certificates
ISO 9001:2000 ISO 14001:2004 ISO 29001:2003 OHSAS 18001:1999 EFQM
PETROCHEMICAL COMPLEXES 9 th Edition 28 Process Block Diagram
Ethylene
Butene-1
Propylene
PETROCHEMICAL COMPLEXES 29 9 th Edition Buali Sina Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 36 hectares Founded in: 1998 Ownership: Persian Gulf Petrochemical company (70%), Justice Shares Broker Co.(30%)
Product Final ( ‘000 t/y) Licensor Licensor Production date
Condensates, Axens, Benzene 180 2004 Pyrolysis Gasoline Uhde,Sinopec Paraxylene 400 Orthoxylene 30 Light cuts naphta 350 2003 Raffinate 199 LPG 39 C5 cuts 21 Heavy cuts naphtha 488 Heavy cuts pyrolysis 11 gasoline Heavy aromatics 23 2004
Products application
Paraxylene: production of terephthalic acid or dimethyl terephthalic as well as intermediate material for polyesters and fibers. Benzene: production of styrene, 2-decylbenzene for producing detergents, cyclohexene for producing nylons, phenol and nitrobenzene for producing aniline and solvents. Orthoxylene: production of softeners, pharmaceuticals, pesticides, paints and phthalic anhydride (PA).
Input feed Amount (‘000 t/y) Source Condensate 1,718 South Oil fields (Pazanan) Pyrolysis gasoline 139 Amir Kabir Petrochemical Co.
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000
PETROCHEMICAL COMPLEXES 9 th Edition 30 Process Block Diagram
cuts
PETROCHEMICAL COMPLEXES 31 9 th Edition Shahid Tondguyan Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 34 hectares Founded in: 1998 Ownership: Persian Gulf Petrochemical company (75%), Petroleum Ministry Retirement & Welfare Fund (15%), Justice Shares Broker Co. (10%)
Phase - 1
Product Final( ‘000 t/y) Feed Licensor Production date
Paraxylen , PTA 350 Tecnimont (Italy) 2005 Acetic Acid PET-A (bottle grade) 60 MEG , PTA Lurgi Zimmer (Germany) 2004 PET-B (fiber grade) 117.5 2005 PET-C (fiber grade) 117.5 2005 PET-D (bottle grade) 117.5 2005
PETROCHEMICAL COMPLEXES 9 th Edition 32 Phase - 2
Product Final ( ‘000 t/y) Feed Licensor Productio date
PTA 350 Paraxylen,Acetic Acid MHI 2006 PET-F (bottle grade) 132 MEG , PTA Noyvallesina 2007 PET-G (fiber grade) 132 Under Commissioning PET (stapel grade) 66 2011 PET (POY grade) 66 2011
Products application
PET (bottle grade): Production of various bottles (for mineral water and other beverages), cans, packing for food and pharmaceutical products, photography and radiology films, solid food packing. PET (fiber grade): Production of various fibers for textile, cotton and artificial thread.
PETROCHEMICAL COMPLEXES 33 9 th Edition Input feed Amount (‘000 t/y) Source BIPC & Buali Sina Paraxylene 468 Petrochemical Co. Acetic acid 37 Fanavaran Petrochemical Co. MEG 273 Marun Petrochemical Co.
Standard certificates
ISO 9001 ISO 14001 OHSAS 18000 EFQM
Process Block Diagram-Phase 1
MEG PET Bottle Grade PET(POLY-A) SSP-A
MEG PET Fiber Grade PET(POLY-B)
P-Xylene MEG CTA PTA PET Fiber Grade Acetic Acid PET(POLY-C)
MEG PET Bottle Grade PET(POLY-D) SSP-D H2
PETROCHEMICAL COMPLEXES 9 th Edition 34 Process Block Diagram-Phase 2
MEG P-Xylene Solid State PET Bottle Grade PET(POLY-F) Polycondensation-F CTA PTA Acetic Acid MEG PET Fiber Chip PET(POLY-G)
MEG H2 PET(POLY-H) Staple PST Unit
POY Spinning POY Unit
PETROCHEMICAL COMPLEXES 35 9 th Edition Khuzestan Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 10 hectares Founded in: 1997 Ownership: Persian Gulf Petrochemical company (70%),Justice Shares Broker Co.(30%)
Product Final (‘000t/y) Feed Licensor Production date
Liquid epoxy Epichlorohydrin, 5 Salzgitter 2003 resin Bisphenol A Solid epoxy resin 5 2003 Phosgene, Polycarbonates 25 2007 Bisphenol A Bisplenol A 30 Phenol, Aceton 2003
Products application
Epoxy resin: Interior protective coatings of oil and gas pipes to prevent corrosion, in production of paints, adhesive, floor covering, reinforced containers and polymer cements used for buildings & bridges construction. Polycarbonate: In auto industry, hygienic & pharmaceutical industry, medical & Industrial eye glasses, contact lens, dialysis equipments..., and electricity & computer industries.
PETROCHEMICAL COMPLEXES 9 th Edition 36 Input feed Amount (‘000 t/y) Source Caustic soda (100%) 40 BIPC Acetone 8.3 Imported Phenol 26.1 Epichlorohydrin 5.2 Chlorine 10 BIPC
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000 EFQM
Process Block Diagram
PETROCHEMICAL COMPLEXES 37 9 th Edition Fajr Petrochemical Co.
Location: 2nd & 4th Site of Petrochemical Special Economic Zone Area: 54 hectares Founded in: 1999 Ownership: Persian Gulf Petrochemical Co. (70%), Justice Shares Broker Co.(30%)
Product Final Feed Licensor Production date
Electricity 1483 MW-H Natural gas, gas oil Steam 1688 T/h DM water Alstom 2003 Nitrogen (gas) 51,000 nm3/h Air Air Product Nitrogen (liquid) 3 T/h (1st & 2nd train); 2002 (Train 1&2) Oxygen (gas) 40,500 nm3/h Air Liquid 2006 (Train 3) Oxygen (liquid) 2.4 t/h (3rd train) Instrument air 42,500 nm3/h Air Product 2002 Service air 31,500 nm3/h Argon (liquid) 375 kg/h Air Liquid 2006 RO water 10,530 m3/h Service water DM water 34,30 m3/h RO water Service water 800 m3/h Clarified water Vatech 2006 Clarified water 16,800 m3/h Karoon River Potable water 375 m3/h Mixed RO+DM Water Boilers water 2784 m3/h DM water Firefighting Water 14,630 m3/h DM water Sewage treatment capacity is 980 m3/h
PETROCHEMICAL COMPLEXES 9 th Edition 38 Products application
Supply of utilities required by the process plants in Petrochemical Special Economic Zone.
Input feed Amount Source Raw water (Karoon River) 7,000 m3/h Water Organization Natural gas 12 mm3/d NIGC
Standard certificates
IMS ISO 9001-2000 EFQM ISO 14001-1996 OHSAS 18001-1999
Process Block Diagram Fajr - Phase 1 RO Water Raw Water DM Water DM Water Service Water Firefighting Water
Fuel Gas Steam Power Plant Electricity B.F.W
Air (Atmosphere) Oxygen & Nitrogen Air Seperation Unit Instrument & Service Air Argon
Service Water Sewages 1st & 2nd Sewage Treatment Purified Sewages
Fajr - Phase 2 RO Water DM Water Raw Water Water Treatment Service Water Firefighting Water
Steam Fuel Gas Power Plant Electricity B.F.W
Oxygen & Nitrogen Air (Atmosphere) Air Seperation Unit Instrument & Service Air
PETROCHEMICAL COMPLEXES 39 9 th Edition Karoon Petrochemical Co. - Phase 1
Location: Petrochemical Special Economic Zone Area: 34 hectares Founded in: 2001 Ownership: BIPC (40.82%), Chematur of Sweden (30.61%), Petrochemical Industries Investment Co.(20.41%), PCC (8.16%)
Product Final ( ‘000 t/y) Feed Licensor Production date
TDI 40 Chlorine, CO, Hydrogen, Chloridric Acid (33%) 116/4 Toluene Nitric Acid Chematur 2008 Sodiom Hypochlorite 4 Caustic Soda, Chlorine Nitric Acid 88 Ammonia 2011
Products application
Raw material for production of various kinds of polyurethanes, construction industry, auto industry, insulations, false ceilings, sponges, adhesives, refrigerator parts.
PETROCHEMICAL COMPLEXES 9 th Edition 40 Input feed Amount (‘000 t/y) Source Toluene 25.3 Esfahan Petrochemical Co. Chlorine 36.6 BIPC Hydrogen 4.3 Fanavaran Petrochemical Co. CO 15.3 Fanavaran Petrochemical Co. Ammonia 17.1 Razi & Kermanshah Petrochemical Co. Caustic Soda (48.5%) 14.1 Arvand Petrochemical Co.
Process Block Diagram Phase -1
Ammonia Nitric Acid Unit Nitric Acid
Toluene DNT Unit MTD Unit
Hydrogen
Co TDI CDC Unit TDI Unit Chloridric Acid
Chlorine Chlorine Purification & Sodiom Hypochlorite Caustic Soda Production Unit Sodiom Hypochlorite
PETROCHEMICAL COMPLEXES 41 9 th Edition Fanavaran Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 25 hectares Founded in: 1998 Ownership: Private Sector
Product Final (‘000 t/y) Feed Licensor Production date
Methanol 1,000 Natural gas, CO2 Haldor Topsoe 2004 (Denmark) CO 140 Natural gas 2006 Acetic acid 150 Methanol, CO Khimteknologia 2006 (Ukraine)
Products application
Methanol: Acetic acid, formaldehyde, MTBE, solvent for organic materials CO: Acetic acid, phosgene Acetic acid: VAM, purification of terephthalic acid, cellulose acetate, solvents, pharmaceutical products, paints
PETROCHEMICAL COMPLEXES 9 th Edition 42 Input feed Amount (mn m3/y) Source Natural Gas 824 NIGC CO2 90 Razi Petrochemical Co. CO2 46 Marun Petrochemical Co. Includes feedstock & fuel
Standard certificates
ISO 9001 ISO 14000 OHSAS 18000
Process Block Diagram
PETROCHEMICAL COMPLEXES 43 9 th Edition Razi Petrochemical Co. (RPC)
Location: Petrochemical Special Economic Zone Area: 100 hectares Founded in: 1965 Ownership: Gubre Fabrikalari Anonim (47.81%), Energy Asia (23.91%), others (28.28%)
Product Final (‘000 t/y) Feed Licensor Production date
Sulfuric acid 2×313 Liquid sulfur Sim-Chem 1977 (plant 1&2) Phosphoric acid 255 Sulfuric acid & phosphate rock Prayon 1970 DAP (plant 1) 210 Phosphoric acid & ammonia T.V.A DAP (plant 2) 240 Stamicarbon 1990
Urea 594 Ammonia & CO2 H.F.T & Stamicarbon Ammonia 1 330 Natural gas Keliogg 1970 (plant 1) Ammonia 2 330 1977 (plant 2) Ammonia 3 676 Natural Gas & Hydrogen Ammonia Casale 2007 (plant 3) Sulfur 620 Sour gas Ralph Parsons 1970
Products application
Ammonia: Production of fertilizers & refrigrant fluid Urea: Production of fertilizers, resins, formaldehyde urea and melamines Sulphur: Production of sulphuric acid and raw material for sulphuric producitons Sulphuric Acid: Chemical industries & phosphoric acid production Di Ammonium Phosphate: fertilizers Phosphoric Acid: production of di-ammonium phosphate fertilizer and industrial usage
Input feed Amount (mn m3/y) Source Sour gas 1,419 Masjid-Soleiman sour gas wells Natural gas 800 NIGC Includes feedstock & fuel
PETROCHEMICAL COMPLEXES 9 th Edition 44 Input feed Amount (‘000 m3/y) Source Phosphate rock 816 Import Phosphoric acid If required Arya Phosphoric Co. & Import Hydrogen (for 3rd Ammonia) 132 Petrochemical Special Economic Zone
Standard certificates
ISO 9001-2000 ISO 14001-2004 OHSAS 18001-1999 ISO 29001 QCC EFQM
Process Block Diagram
acid
acid
PETROCHEMICAL COMPLEXES 45 9 th Edition Marun Petrochemical Co.
Location: Ahwaz & Petrochemical Special Economic Zone Area: 102.5 hectares (93 hectares in Petrochemical Special Economic Zone located in Site 2 and 9.5 hectares in Ahwaz located in Kritcamp area, 15km from Ahwaz) Founded in: 1998 Ownership: Private Sector
Product Final ( ‘000 t/y) Feed Licensor Production date
C2+ 1,900 Natural gas Linde (Germany) 2005 Ethylene 1,100 C2+ 2006 Propylene 200 C3+ 168 Pyrolysis gasoline 83 Ethylene glycols 443 Ethylene & oxygen Shell (Netherlands) HDPE 300 Ethylene Basell (Germany) 2005 Polypropylene 300 Propylene 2006
Products application
Production of plastics including; cable cover, films and tapes, bottle box, auto battery coverage, liquid containers, pharmaceutical equipments, pipes, as well as feedstock for downstream industries, production of anti-oxide, anti-freeze, textile and synthetic fibers, adhesives, wire insulation, print ink & cosmetics.
PETROCHEMICAL COMPLEXES 9 th Edition 46 , Input feed ( 000 t/y) Source Butene-1 5 Jam Petrochemical Co., import Oxygen 275 Fajr Petrochemical Co. Propylene 100 Local sources, import Rich gas 25 mn m3/d Khuzestan oil & gas grids
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000 EFQM
Process Block Diagram
Rich gas NG
Oxide Oxygen
PETROCHEMICAL COMPLEXES 47 9 th Edition Laleh Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 12 hectares Founded in: 2002 Ownership: Marun Petrochemical Co.(64%), Pushineh Polymer Industrial Group (36%)
Product Final ( ‘000 t/y) Feed Licensor Production date
LDPE 300 Ethylene Sabtec 2007
Products application
Various nylon films, plastic bags & packaging industries
Input feed Amount (‘000 t/y) Source Ethylene 303 Marun Petrochemical Co. Propylene 5 Local Sources
Process Block Diagram
PETROCHEMICAL COMPLEXES 9 th Edition 48 Farabi Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 15 hectares Founded in: 1973 Ownership: Private Sector
Product Final (‘000 t/y) Feed Licensor Production date
dioctyl phethalat (DEP) 55 Liquid PA, 2EH Von-Heyden 1977 Phethalic anhydride (PA) 34.5 Liquid PA Lurgi
Products application
Production of plastics, resin & paints industry
PETROCHEMICAL COMPLEXES 49 9 th Edition Input feed Amount (‘000 t/y) Source 2EH 28 Shazand (Arak) Petrochemical Co./Import OX 29.8 Esfahan & Buali Sina Petrochemical Companies
Standard certificates
ISO 9001-ISO 14001 TS29001 OHSAS 18001
Process Block Diagram
Orthaxylene PA Oxygen PA Unit
DOP 2EH DOP Unit
PETROCHEMICAL COMPLEXES 9 th Edition 50 Ghadir Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 15.2 hectares Founded in: 2002 Ownership: Social Security Investment Co. (90%), Bandar Imam Khomeini Investment Co. (10%).
Phase - 1
Product Capacity ( ‘000 t/y) Feed Licensor Production date
PVC 120 Ethylene BF-Goodrich 2009 VCM 150 Chlorine Mitsui
Products application
Raw material for hoses, pipes, auto industry.
Input feed Amount (‘000 t/y) Source Ethylene 70 Marun, West Ethylene Pipeline Chlorine 90 Arvand Petrochemical Co.
Standard certificates
ISO 9001:2008 OHSAS 18001 ISO 14001 ISO/TS 2900 ISO 9001 EFQM
Process Block Diagram
VCM
Oxygen VC PVC PVC Ethylene Unit Unit
EDC Color Gas DC Unit
PETROCHEMICAL COMPLEXES 51 9 th Edition Shimi Baft Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 5 hectares Founded in: 1994 Ownership: Private sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
MTBE 90 C4 raffinate, Hulse 2002 methanol C4 raffinate - 2 62
Products application
MTBE is used as additive in gasoline production (octane booster) C4 raffinate 2 is used as feed for MEK production.
Input feed Amount (‘000 t/y) Source Methanol 33 Fanavaran Petrochemical Co. Raffinate 1 122 Bandar Imam, Amirkabir, Tabriz & Shazand Petrochemical Cos, Abadan Refinery
Standard certificates
ISO 9001 OHSAS 18001 ISO14001 ISO/TS 29001 HSE - MS
Process Block Diagram
Methanol
Separation methanol from Methanol Butane Extraction
Raffinate II
Methanol Reaction Butane MTBE MTBE Raffinate I Section Separation Separation
Azeotrope Methanol & MTBE
PETROCHEMICAL COMPLEXES 9 th Edition 52 Navid Zar Shimi Co.
Location: Petrochemical Special Economic Zone Area: 5.7 hectares Founded in: 1999 Ownership: Private sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
Polypropylene 160 Ethylene, propylene, Basell 2004 butane-1, hydrogen
Products application
Raw material for plastic industry, textile, manufacture of parts, packing films, water pipes.
Input feed Amount (‘000 t/y) Source Propylene 160 Amirkabir Petrochemical Co. Ethylene 2 Hydrogen 0.05 Butane 1
Standard certificates
ISO 9001:2008 OHSAS 18001: 2007 ISO14000:2004 ISO/TS 29001: 2007
Process Block Diagram
Propylene Polypropylene Unit Polypropylene Ethylene
PETROCHEMICAL COMPLEXES 53 9 th Edition Shahid Rasouli Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 8.6 hectares Founded in: 2001 Ownership: Private sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
Formaldehyde 66 Methanol Wonjin 2006
Input feed Amount (‘000 t/y) Source Methanol 30 Fanavaran Petrochemical Co.
Products application
Medical Industry, adhesives & production of Formaldehyele resins.
Process Block Diagram Methanol Formaldehyele Formaldehyele Production Unit
PETROCHEMICAL COMPLEXES 9 th Edition 54 Shimi Tex Arya Co.
Location: Petrochemical Special Economic Zone Area: 5 hectares Founded in: 2006 Ownership: Private sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
Methyl ethyl 50 Raffinate-2 & Sulphu- Edeleanu 2013 Ketone (MEK) ric Acid (98%) (Germany) Raffinate-3 2.5
Products application
Commercial - Industrial Solvent with widespread use in base oil production refineries, resin industry, print & imitation leather.
Input feed Amount (‘000 t/y) Source Raffinate-2 8 Shimi Baft Co. Sulphuric Acid (98%) 7 Razi Petrochemical Co.
Process Block Diagram Sulphuric Acid MEK Production MEK Raffinate Unit
PETROCHEMICAL COMPLEXES 55 9 th Edition Arya Phosphoric Jonoub Co.
Location: Razi Petrochemical Area: 7844 m2 Founded in: 2004 Ownership: Private Sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
Phosphoric Acid 125 Phosphate soil-Sulphuric Parayon 2009 Acid
Products application
Phosphate fertilizer, Livestock and Poultry feed supplementaries, domestic and industrial detergents, Paper, Plating, Loom and Photography industries.
Input feed Amount (‘000 t/y) Source Sulphuric Acid 375 Razi Petrochemical Co. Phosphate Soil 450 Internal and external sources
Phosphate Soil Process Block Diagram Phosphoric Phosphoric Acid Sulphuric Acid Acid Unit
PETROCHEMICAL COMPLEXES 9 th Edition 56 Rejal Petrochemical Co.
Location: Petrochemical Special Economic Zone Area: 12.3 hectares Founded in: 2002 Ownership: Private Sector (100%)
Product Capacity ( ‘000 t/y) Feed Licensor Production date
Polypropylene 160 Propylene A.B.B 2006 & 2012
Products application
Tubing Industry, Sacks, disposable Containers & Film industry.
Input feed Amount (‘000 t/y) Source Propylene 160 BIPC & other resources
Standard certificates
OHSAS 18001: 2007 ISO 10002: 2005 ISO 9001:2008 ISO 14001: 2004 Calibration Laboratory Accreditation
Process Block Diagram
Propylene Propylene Unit Polypropylene
PETROCHEMICAL COMPLEXES 57 9 th Edition PETROCHEMICAL COMPLEXES 9 th Edition 58 ASSALUYEH Pars Special Economic / Energy Zone
PETROCHEMICAL COMPLEXES 59 9 th Edition Bushehr Province
The Province of Bushehr is located at 27°16’-30°18’ North, 50°06’-52°56’ East. Situated on the southern coast of Iran, the Province stretches over an area of 22,743sq km. It is bordered in the north by Khuzestan and Kohkiloyeh- va-Boyerahmad Provinces; in the east by Fars Province; in the northeast by Hormozgan Province and in the south and the west by the Persian Gulf. The population of the province is about 886,267 of whom 468,062 are male and 418,205 are female. About 65% of the population is urban. Close to 25.7% of the population are less than 15-year old, 70.25% are between 15-65 and the remaining 4.06% are over 65 years old. Farsi is the dominant language in the region. Some residents speak Arabic while the nomads speak Turkish. Average temperature is 23.1° C and average humidity stands at 67%-75% during 6:30 - 12:30 am. The history of Bushehr goes back to the ancient Elam when the Elamite kings used it as a naval base and a port city. Having a 600km border with the Persian Gulf, Bushehr enjoys a strategic location. Resisting foreign intervention is a major part of the contemporary history of Bushehr. With a host of different huge industrial project underway in the province, including Bushehr Nuclear Power Plant and Pars Special Economic/Energy Zone, it has attracted a large workforce from other provinces.
PETROCHEMICAL COMPLEXES 9 th Edition 60 Major industries and economic sectors in the region Oil, gas, petrochemical, fishing and agriculture (date palm groves) are the staple industries in the province. The geographical advantages of Bushehr including its vicinity to the Persian Gulf plus its fishing and date industry play an important role in its economy. But, its huge hydrocarbon reserves have considerably boosted its economy. Bushehr consists of 9 cities, 29 towns, 22 districts and 43 villages. The major natural, archeological and historical places of interest in the province are as follows: Bushehr: (in central region) the ancient Siraf region, Qavam ancient underground water reservoir , Malek Building, Shaqab Cemetery, Sheikh Sadoon Mosque, Holy Christ Church, (in Kharg Island) the Dutch Castle, Pozeidon Temple, Mir Mohammad Hanifeh mausoleum, Kharg ancient church
Tangestan: Ahrom, Mir Ahmad and Khanik hot springs, Zar Khezerkhan Castle, Kalat Castle and Rais Ali Delvari’s house. Borazjan: Dalaki, Borazjan and Khanik hot springs, Bardak Siah Castle, Kooroush Castle, Derakht underground water reservoir, Tooz ancient area, Telesmi and Khandaq hills, Forty-Houses Cave Bandar Dayyer (Dayyer Port): Bardestan Mosque, Bardestan Castle, islands and seashore, riverside park, Emamzadeh SeyyedJamaludin shrine Khormooj: Mand Fortress, Dukhtaar Castle, Shirineh Building, Shahzadeh Mohammad, Ganoyeh hot spring, Seyyed Mohammad Amin Bandar Genaveh (Genaveh Port): Gonbad hills, Toodeev, Bi Mareh Mausoleum, Khan Hosseiniyeh, Holleh lagoon, seaside Bandar Deilam (Deilam Port): Emamzadeh Soleiman, Seeniz Port, Ememzadeh Hassan, seaside
Kangan Kangan port is the center of the Town of Kangan. It lies on the southwest of the province on the Persian Gulf coast nearby Bandar Dayer. It covers an area of 3,083 sq km and has a population of over 95,000 people. It has an ancient history which goes back to 350 BC. During the Safavid period, it was named Kunaga. After the Safavid, the name was changed to Kangan. At the early Islamic period it was named Bandar (port) Siraf. In the sixteenth century, Kangan was divided in two regions. The division is still valid ever since despite some minor changes.
PETROCHEMICAL COMPLEXES 61 9 th Edition Poshtkooh region: Jam district is located in this region which consists of Jam and Riz villages with 129 small hamlets.
Sheibkooh region: The central section of the Town of Kangan is situated in this region. The region covers the coast of Kangan and its suburbs. It consists of 70 villages and 3 hamlets namely Assaluyeh, Nai Band and Taheri.Taheri Castle in Bandar Taheri, Mianloo hot spring and Seyyed Gharib Mausoleum in Kangan, Jam palm trees and the beautiful Bandar Kangan and Bandar Taheri seashores are the most captivating places of interest in the area.The exploration of huge gas reserves in Kangan has given a boost to the region’s role in Iran’s economy. Explorations of Kangan, Nar, South and North Pars fields have led to enormous investment in Kangan. Fajr Refinery in Kangan and South Pars refinery, which is already under construction, are among the world’s largest refineries. Pars region has attracted Iran’s largest domestic investment.
PETROCHEMICAL COMPLEXES 9 th Edition 62 Assaluyeh Port It is located on the northern coast of the Persian Gulf, 70 km southeast of Kangan Port. There is no consensus about the origin and the meaning of the word Assaluyeh. Some say that the fresh water that flew down from Bid Khoon to a nearby valley was very tasty and refreshing. As a result, the locals called it ‘Asal’, meaning honey in Farsi. Some others say the word has originated from the Elamite language and was written ‘aslaviyeh’ meaning port. And another interpretation is that the word has its roots in the word ‘asl’ which means ‘pond’. In 1998, Pars Special Economic /Energy Zone was established based on a cabinet authorization to utilize the gas from the South Pars field in a bid to develop the oil, gas, petrochemical and their related downstream industries. Covering an area of 30,000 hectares, the Zone lies on east of Bushehr province. It is 105km away from the offshore South Pars Gas field. The Zone is bounded in the west by Shirino village, in the south by the Persian Gulf, in the north by the Zagros Range and in the east by Chah Mobarak village. Its temperature ranges between 5-50 degrees centigrade in the course of the year. The average humidity ranges between 59-88 percent. Average annual precipitation is about 180 millimeters.
PETROCHEMICAL COMPLEXES 63 9 th Edition Pars Special Economic/Energy Zone (Assaluyeh) The Pars Special Economic / Energy Zone Organization on behalf of Iran’s Petroleum Ministry and National Iranian Oil Company (NIOC) manages and develops the South and North oil and gas fields in the region. The Zone consists of three regions; Pars 1 (South Pars) with an area of 14.000 hectares, Pars 2 (Pars Kangan) with an area of 16.000 hectares and Pars 3 (North Pars) with an area of 16.000 hectares. The Organization was established in 1999 to support the development of South Pars Gas Field, the world’s largest gas field, through establishing, approving, planning, implementing, utilizing and maintaining of public infrastructures like roads, rail ways, ports, airports, power plants and drinking water facilities. The availibility of proper infrastructures in the up, middle and down streams of oil and gas industry, Pars Complex Port, the International Persian Gulf Airport, water and power facilities, communication, roads and available natural tourist attractions have made the region an ideal place for local and foreign investors. Lying on the coast of the Persian Gulf, the Zone has access to the rich hydrocarbon resources in the region providing suitable conditions for foreign investment. It is the hub of development activities underway at South Pars gas field. With its reserves estimated at 14 trillion cubic meters of gas and 18 billion barrels of condensates, the field is the world’s largest gas field. It represents 6.8% of the global gas reserves. Given the field’s capacity, 28 development phases and 3 giant LNG projects have so far been planned to be built in Assaluyeh and Kangan in an area of 30,000 hectares. Currently, the first ten phases are onstream. On average, $1.5bn has been invested for each phase. The implementation work of phases 11 - 24 have been started and are underway. Several word-scale petrochemical plants are being constructed in assaluyeh Zone as part of the country`s 3rd, 4th & 5th development plants.
PETROCHEMICAL COMPLEXES 9 th Edition 64 Investment advantages and incentives Availability of abundant gas reservoir Access to international waters and markets in south of the Persian Gulf and the Far East Availability of airport Deep navigable waterways Well-developed ports for export of petrochemicals and LPG with a loading capacity of 30 million tonnes per year, service port with an annual loading capacity of 10 million tonnes which is equipped with warehouses & other required services including customs clearance Availability of an independent power plant and a desalination unit Availability of both skilled and unskilled workforce Vicinity to tourist attractions and commercial and industrial facilities in Kish, Qeshm, Shiraz and Esfahan Availability of independent communication networks facilitating communications and data transmission Access to the mainland and central Asian markets via local transport networks Tax exemption for any industrial investment 100 percent repatriation of capital Exemption from customs duties & commercial interests for imports of raw material, machinery, equipment and spare parts Possibility of using Foreign Reserves Fund Up to 100% foreign joint investment and ownership (with the exception of land)
Industrial Projects Access to international waters and mainland and central Asian markets, the South Pars (Assaluyeh) with enjoying 6.8% of worldwide reserved gas became pivotal Energy hub for the country. In the first stage, 24 phases of gas refineries and 17 worldwide petrochemical complexes as well as many downstream industrial plants implemented.
PETROCHEMICAL COMPLEXES 65 9 th Edition Pardis Petrochemical Co.
Location: Pars Special Economic/Energy Zone Area: 64.6 hectares Founded: 2001 Ownership: Private Sector
Phase - 1
Product Final ( ‘000 t/y) Feed Licensor Production date
Ammonia 680 Natural gas M. W. Kellogg 2009 CO2, Stami Carbon, Granular urea 1,075 ammonia H.F.T
Phase - 2 Product Final ( ‘000 t/y) Feed Licensor Production date
Ammonia 680 Natural gas M. W. Kellogg 2009 CO2, Stami Carbon, Granular urea 1.075 2010 ammonia H.F.T
PETROCHEMICAL COMPLEXES 9 th Edition 66 Products application
Urea: Production of chemical fertilizers for agricultural purposes; raw material of melamine Ammonia: Raw material for industrial and agricultural purposes
Input feed Amount (mn m3/y) Source South Pars Gas Field Natural gas 2×670 (Through Mobin Petrochemical Co.) Includes feedstock & fuel
Process Block Diagram
PETROCHEMICAL COMPLEXES 67 9 th Edition Nouri (Borzuyeh) Petrochemical Co.
Location: Pars Special Economic/Energy Zone Area: 61 hectares Founded: 2001 Ownership: Persian Gulf Petrochemical Co. (76.55%); Tamin Chemical & Petrochemical Industry Co. (17%), National Pension Investment Co. (6.45%)
Product Final ( ‘000 t/y) Feed Licensor Production date
Paraxylene 750 Benzene 430
Orthoxylene 100 IFP(France) Condensates, Heavy ends 2,000 Toray (Japan) Pyrolysis July 2007 Heavy aromatics 16 Uhde gasoline Raffinate 380 (Germany) Light ends 680 LPG 76 C5 cut 47
Input feed Amount (‘000 t/y) Source Condensates 4,500 South pars phases Pyrolysis gasoline 270 Jam Petrochemical Co.
Products application
Paraxylene is used in the production of PTA, DME as well as intermediate feedstock for polyester & fiber Benzene is used in the production of Styrene, Dodecyl Benzen for detergents, Cyclohexene (for Nylon), Phenol and Nitrobenzene (for Anylene production) and solvents Orthoxylene is used for the production of softeners & pharmaceuticals, pesticides, paints and anhydrid phethalic
Standard certificates
ISO 9000 ISO 14000 OHSAS 18000 EFQM
PETROCHEMICAL COMPLEXES 9 th Edition 68 Process Block Diagram
cuts
Unit 950
Purified
PETROCHEMICAL COMPLEXES 69 9 th Edition Pars Petrochemical Co.
Location: Pars Special Economic/Energy Zone Area: 23 hectares + 14 hectares for EB/SM Founded: 1998 Ownership: Persian Gulf Petrochemical Co. (60%), SATA (40%)
Product Final (‘000t/y) Feed Licensor Production date
Ethane 1,600 Riched gas Linde 2006 Propane 980 Butane 570 C5+ 86 Ethyl benzene 645 Ethylene / Benzene snamprogetti 2009 Styrene Monomer 600 Ethyl Benzene 2009
Products application
Ethane: olefins & fuel Propane: olefin units, raw material for industrial applications as well as refrigrant fluid Butane: olefin units, main material for industrial usage & fuels Pentane: olefin plants, main material for industrial usage & fuel Styrene Monomer: styrene, rubber, resins, adhesives, solvents, textiles, ABS, SBR, SAN
PETROCHEMICAL COMPLEXES 9 th Edition 70 Input feed Amount Source Riched gas 75 mm3/d South Pars phases (1,2,3 phases) Ethylene 175.000 t/y Arya Sasol Polymer Co. Benzene 470.000 t/y Nouri & Buali Sina Petrochemical Companies
Standard certificates
EFQM ISO-9001 ISO-14001 OHSAS 18001 ISO-9001 ISO-14001 OHSAS 18001 EFQM
Process Block Diagram
Ethylene Ethyl Styrene Styrene Ethyl Benzene Benzene Benzene Monomer Toluene Unit Unit
PETROCHEMICAL COMPLEXES 71 9 th Edition Arya Sasol Polymer Co.
Location: Pars Special Economic/Energy Zone Area: 72 hectares Founded: 2003 Ownership: Pars Petrochemical Co.(50%), Sasol Polymer Co. of Germany (50%)
Product Final ( ‘000 t/y) Feed Licensor Production date
Ethylene 1,000 Ethane Technip 2007 C3+ 90 2007 LDPE 300 Ethylene Sabtec 2008 HDPE/MD 300 Basell 2008
Products application
LDPE: films, bags, containers, cable coverage and industrial parts HDPE & MD: home appliances, films, industrial parts, containers, pipes, plastic bottles Ethylene: feedstock for polymer plants
PETROCHEMICAL COMPLEXES 9 th Edition 72 Input feed Amount (,000t/y) Source Ethane 1,267.5 Pars Petrochemical Co. Propane 56 Pars Petrochemical Co. Hexene-1 7.2 Import Propylene 4.2 Jam Petrochemical Co. Hexane 87 Import
Standard certificates ISO 9000 ISO 14001 OHSAS 18001 EFQM
Process Block Diagram
PETROCHEMICAL COMPLEXES 73 9 th Edition Mobin Centralized Utility
Location: Pars Special Economic/Energy Zone Area: 110 hectares Founded: 2000 Ownership: Persian Gulf Petrochemical Co. (100%)
Product Final Feed Licensor Production date
Electricity 990 MW Natural gas GE 2004 & 2009 Steam 2865 t/h DM water Foster Wheeler 2005 Fresh water 1,560 m3/h Sea water Sidem 2004
DM & condense 2,700 m3/h Fresh water; Sidem/Comar water Returned condense Potable water 100 m3/h Fresh water Ready for start-up Oxygen 160,000 nm3/h Atmosphere Linde 2005 & 2009 (44 bar) Oxygen 50,400 nm3/h (29 bar) Nitrogen 96,000 nm3/h Service air 17,000 nm3/h Instrument air 44,000 nm3/h Service water 330 m3/h Water Bamag 2007 Cooling water 386,000 m3/h Sea water Sadra 2006
Products application
Supply of utilities for petrochemical plants at Pars Special Economic/ Energy Zone
PETROCHEMICAL COMPLEXES 9 th Edition 74 Input feed Amount (m m3/d) Source Natural Gas 22.5 South Pars Oil & Gas Co. Sea Water - Persian Gulf
Standard certificates ISO 9000 ISO 14000 OHSAS 18000 EFQM
Process Block Diagram
Hot Water Closed tube Sea Water pages Converters Cold Water Sea Water Sea Water Pool Open loop converters Sea Water
MED Unit Fresh Water Fresh Water Returned Condense DM Treatment DM Water DM Water Steam Fuel Gas Power Plant Electricity B.F.W Oxygen Nitrogen Air (Atmosphere) Air Seperation Instrument Air Service Air
Industrial Sewages Water Service Water Treatment
PETROCHEMICAL COMPLEXES 75 9 th Edition Zagros Petrochemical Co.
Location: Pars Special Economic/Energy Zone Area: 31 hectares Founded: 2000 Ownership: Private Sector (100%) Phase - 1
Product Final (‘000 t/y) Feed Licensor Production date
Natural gas Methanol 1,650 Lurgi 2006 & Oxygen
Phase - 2
Product Final (‘000 t/y) Feed Licensor Production date
Natural gas Methanol 1,650 Lurgi 2006 & Oxygen
Input feed Amount (mn m3/y) Source Natural gas 2×1500 South Pars Oil & Gas Co. Oxygen 2×670 Mobin Petrochemical Co. Includes feedstock & fuel
Products application
Production of MTBE, acetic acid, formaldehyde and as solvent in chemical industries Standard certificates
ISO 9000 ISO 14000 OHSAS 18000
Process Block Diagram
PETROCHEMICAL COMPLEXES 9 th Edition 76 Mehr Petrochemical Co.
Location: Pars Special Economic/ Energy Zone (Site No. 2) Area: 13 hectares Founded: 2005 Ownership: NPC International (40%), Singapore Petrochemical Investment Ettehad Co. (59.99%)
، Product Final( 000t/y) Feed License Production Date
HDPE 300 Ethylene Mitsui(MCI) 2009
Products application
Production of plastics like pipes, cable coverage, film, ...
Input Feed Amunt(،000t/y) Source Ethylene 310 Jam and other petrochemical complexes Butene-1 2.4 import / Jam Petrochemical Co.
Process Block Diagram Ethylene HDPE Unit HDPE Butene-1
PETROCHEMICAL COMPLEXES 77 9 th Edition Jam Petrochemical Co.
Location: Pars Special Economic/ Energy Zone Area: 77 hectares + 22 hectares in phase 2 Founded in: 2000 Ownership: Tamin oil, gas & Petrocheamical investment Co. (22.70%), National Retirement Investment Fund (23.19%), National Pension Fund (22.85%), Justice Shares Broker Co. (15%), Others (16.26%)
Product Final ( ‘000 t/y) Feed Licensor Production date
Ethylene 1321 Propylene 305 Ethane, Light cuts, C3+, C5+, Raw Pyrolysis Gasoline 216 Condensates, Technip 2007 CFO 40 Heavy Aromatics C4+ 245 LLDPE/HDPF 300 Ethylene Basell 2008 HDPE 300 Ethylene 2007 Butadiene 1&3 115 C4 cut BASF 2009 C4 Raffinates 130
Butene-1 100 Ethylene Axens 2012
Products application
Feedstock for Acrylic rugs, fibers, acrylic, solvents, paints, lubricants, anti- freeze, textiles & adhesives as well as various plastic products such as cable coats, films, containers and pipes. Industrial parts like: audio visual appliances, inner auto parts,...
Input feed Amount (‘000 t/y) Source Light cuts 687 Nouri (Borzuyeh) Petrochemical Co. Raffinates 384 C5 cut 55 Condensates 84 Heavy Aromatics 16 Ethane 707 South Pars Gas Field Ethane 267 Pars Petrochemical Co. C3+ 88 C5 cut 91
PETROCHEMICAL COMPLEXES 9 th Edition 78 Standard certificates ISO 9000 ISO 14000 OHSAS 18000 EFQM
Process Block Diagram
ABS Acrylonitryl Styrene
PETROCHEMICAL COMPLEXES 79 9 th Edition Morvarid Petrochemical Co.
Location: Pars Special Economic/ Energy Zone (Site No.2) Area: 7.8 hectares Founded: 2005
Ownership: Teachers Reserve Fund (46.55%), Petrochemical Industries Investment Co. (17%) Petroleum Ministry Retiremet Welfare Fund (17%), Petroleum ministry Retirement investment Fund (17%).
، Product Final( 000t/y) Feed License Production Date
Ehylene 500 Ethane Technip 2010 C3+ 44 Ethane Technip 2010
Products application
Raw material for production of polyethylene and ethylene glycols
Input Feed Amount (،000t/y) Source Ethane 650 Pars Oil & Gas Co.
Standard certificates EFQM IMS
Process Block Diagram Ethylene Ethane Olefin Unit C3+
PETROCHEMICAL COMPLEXES 9 th Edition 80 Kavian Petrochemical Co. (Phase 1)
Location: Pars Special Economic/ Energy Zone (Site No. 2) Area: 43 hectares Founded in: 2006 Ownership: Petroleum Ministry Pension & Welfare Fund (17.5%), Bakhtar Petrochemical Co. (56.5%) ,Lorestan Petrochemical Co. (6.5%), Kermanshah Polymer Co. (6.5%), Kordestan Petrochemical Co. (6.5%), Mahabad Petrochemical Co. (6.5%)
Phase - 1 ، Product Final( 000t/y) Feed License Production Date
Ehylene 1000 Ethane Technip 2012 C3+ 90 Ethane Technip 2012
Phase - 2 ، Product Final( 000t/y) Feed License Production Date
Ehylene 1000 Ethane Technip 2012 C3+ 90 Ethane Technip 2012
Phase 2 of Kavian is projected to be operationl in second half of 2014
Products application
Raw material for production of polyethylene and ethylene glycols
Input Feed Amount (،000t/y) Source Ethane 2×1300 South Pars Oil & Gas Co.
Ethylene Process Block Diagram Ethane Olefin Unit C3+
PETROCHEMICAL COMPLEXES 81 9 th Edition Farsa Shimi Co.
Location: Pars Special Economic/ Energy Zone Area: 7 hectares Founded: 2002 Ownership: Private sector (100%)
، Product Capacity ( 000t/y) Feed License Production Date
MEG 400 Ethylene & Oxygen Shell 2007 DEG 40 TEG 3
Input Feed Amount (،000t/y) Source Ethylene 260 Jam Petrochemical Co. Oxygen 300 Mobin Petrochemical Co.
Standard certificates
ISO 2001: 2007 OHSAS 18001: 2007 ISO 14001: 2004
Products application
Production of polyester fibers, anti-freeze, solvents
Process Block Diagram
Ethylene MEG Ethylene Glycol OEG Oxygen Oxcid Ethylene Unit Unit TEG
PETROCHEMICAL COMPLEXES 9 th Edition 82 Jam Poly Propylene Co.
Location: Pars Special Economic/ Energy Zone Area: 8 hectares Founded: 2004 Ownership: Private sector (100%)
، Product Final( 000t/y) Feed License Production Date
Polypropylene 300 Propylene Basell 2008
Products application
Production of rugs, fibers, acrylic, films, audio visual appliances, auto parts, ...
Input Feed Amount (،000t/y) Source Propylene 300 Jam Petrochemical Co.
Standard certificates
ISO 14001: 2004 ISO9001: 2008 BSOHSAS 18001: 2007
Process Block Diagram Propylene Poly Propylene Poly Propylene Unit
PETROCHEMICAL COMPLEXES 83 9 th Edition Jam Ehtemam Co.
Location: Pars Special Economic/ Energy Zone Area: 2 hectares Founded: 2004 Ownership: Private sector (100%)
، Product Capacity ( 000t/y) Feed License Production Date
Formaldehyde 40 Methanol Alder (Italy) 2011 UFC 25 Formaldehyde, urea & Soda
Products application
Formaldehyele: In production of adhesives, auto and textile industry, Sanitary & Medical products, urea Formaldehyde resins & ... UFC: Consists of 60% Formaldehyde & 25% urea and is used in production of melamine resins & urea Formaldehyde & ...
Input Feed Amount (،000t/y) Source Methanol 19.1 Zagros Petrochemical Co. Urea 6 Pardis Petrochemical Co. Caustic Soda 0.1 Arvand Petrochemical Co.
Standard certificates
ABiCert
Process Block Diagram
Caustic Soda
Formaldehyde Methanol Formaldehyde UFC Unit Formaldehyde Urea Unit
Urea
PETROCHEMICAL COMPLEXES 9 th Edition 84 OTHER REGIONS
PETROCHEMICAL COMPLEXES 85 9 th Edition Arak city The city of Arak is bordered by Tafresh in the north, Hamadan and Malayer in the west, Mahalat in the east and Khomein and Sarband in the south. It has an average altitude of 1700 m. Arak has relatively moderate summers and cold winters. Carpet weaving is the major handicraft in the city and its Saroogh carpets are well-known throughout Iran.
PETROCHEMICAL COMPLEXES 9 th Edition 86 Shazand (Arak) Petrochemical Co.
Location: Arak, 22km of Arak-Boroojerd Road Area: 523 hectares Founded in: 1984 Ownership: Private Sector (100%)
Product Final (‘000 t/y) Feed Licensor Production date
Ethylene 306 Naphtha TPL, KTI 1993 Propylene 128 C4Cut 79 Fuel oil 65 Pyrolysis gasoline 169 PGH IFP, UOP PP 75 Propylene Himont Butene-1 7 Ethylene IFP HDPE 85 HOSCHT 1994 LLDPE 60 BP Butadiene 27.3 C4Cut NIPPON, ZEON Polybutadiene 26 Butadiene Rubber Ethylene oxide 113 Ethylene Scientific Design EG 119 Ethyleneoxide AA 30 Ethylene Hochst 1995 VA 30 Ethylene Bayer 2EH & Butanols 55.7 Propylene Davy Mckey Ethanolamines 30 Ethyleneoxide, Ammonia Oxiteno 1999 Ethoxylates 30 Fatialcohol, nonylphenol, ethyleneoxid Balestra 2003
Products application
Production of plastic pipes, paints, adhesives, packing films, fibers, surgical threads, serum, polyester industries, solvents, detergents, antifreeze, electrical insulation, shampoos, gas absorbents, pharmaceuticals, cosmetics, oil, gas & petrochemical industries, cement industry, antiseptics, plastic containers, toys, household appliances, bags, plastic sheets, water pipes, antifoams.
PETROCHEMICAL COMPLEXES 87 9 th Edition ، Input feed Amount ( 000t/y) Source Light and heavy naphtha 925 Arak & Esfahan Refineries Ammonia 6 Local sources Propylene 6 Local Sources/Import Fuel gas 350 mnm3/y NIGC
Standard certificates
ISO -9001 ISO -14001 OHSAS -18001 EFQM
PETROCHEMICAL COMPLEXES 9 th Edition 88 Process Block Diagram
oxygene
PETROCHEMICAL COMPLEXES 89 9 th Edition Esfahan city The city of Esfahan is located in central Iran at an altitude of 1570 from the sea level on the coast of Zayande Rood River.
Historical sites Esfahan is well-known for its historical sites including the widely acclaimed Naghsh-e-Jahan Square, Si-o-Sepol Bridge, Khajoo Bridge, the Shaking Minarets, Hasht Behesht, Esfahan Bazaar, Chehelsotoon, Shah Mosque, Sabz-e-Meidan, Mount Atashgah, Shahrestan Bridge, Alighapoo, Vank and Beit-ol-lahm churches.The ancient city of Esfahan has been praised as a symbol of magnificence. The French writer & art historian Andre Malraux says only Florence and Beijing are comparable to Esfahan. The ancient and historical sites in the city represent the best examples of various Iranian architectural schools. Some experts believe these sites are the masterpieces of post-Islam era in Iran.
PETROCHEMICAL COMPLEXES 9 th Edition 90 Esfahan Petrochemical Co. (Public Joint Stock)
Location: 5th km Azadegan Highway, Esfahan Area: 165 hectares Founded in: 1989 Ownership: Private Sector (100%)
Esfahan Petrochemical Co. It is Iran’s first aromatics plant. It was brought onstream in 1992. The plant enjoys one of the world’s state-of-the-art technologies and was the first plant in Iran which employed fully computerized DCS technology. It was privatized in 1997 and was subsequently listed on Tehran’s Stock Exchange in 1990
Product Final (‘000 t/y) Feed Licensor Production date
Benzene 55.6 Platformate UOP 1992 Toluene 71.6 Orthoxylene 22 Mixed xylenes Paraxylene 44 Mixed xylenes 75 Platformate Phathalic Anhydride 40 orthaxylene Rolechim 2008
PETROCHEMICAL COMPLEXES 91 9 th Edition Products application
Benzene: raw material for softeners, detergents, insecticides and paints. Toluene: raw material for softeners and solvents. Orthoxylene: raw material for softeners, plastics and resins. Paraxylene: production of resins, fibers, polyesters and polyacrylics. Mixed xylenes: pesticides, paints, resins.
Input feed Amount (‘000 t/y) Source
Platformate 363 Esfahan oil Refinery Co. Hydrogen 1
PETROCHEMICAL COMPLEXES 9 th Edition 92 Standard certificates
ISO 9002 ISO 14001 OHSAS 18001 QCC EFQM
Process Block Diagram
Hydrogen
PETROCHEMICAL COMPLEXES 93 9 th Edition Kharg Petrochemical Co.
Location: Kharg Island Area: 155 hectares Founded in: 1966 Ownership: Private Sector (100%) Kharg Island Kharg coral island spreads over an area of 35 kilometers in northeast of the Persian Gulf. It is one the world’s major oil terminals. Apart from its industrial texture, the Island’s sand hills, roaming deer cattle and Mir Mohammad Tomb are among its distinctive attractions.
Product Final (‘000 t/y) Feed Licensor Production date
Methanol 660 Sweet gas Lurgi 1999 Sulfur 170 Sour gas Pritchard 1967 Propane 115 Butane 120 Gasoline 70
Products application
Methanol: raw material for producing MTBE, acetic acid, formaldehyde and industrial solvents. Sulfur: raw material for producing sulfuric compounds, sulfuric acid, fertilizers, electrical insulators, chemical and paper industries, rubber vulcanization, and medicine. Propane: raw material in production of olefins and fuel. Butane: raw material in production of olefins and fuel. Gasoline: raw material in production of olefins and fuel.
Input feed Amount (mn m3/y) Source Sour gas 1,400 Offshore oil wells
Standard certificates
QCC OHSAS -18001:1999 ISO -14001:2004 ISO -9001:2000
PETROCHEMICAL COMPLEXES 9 th Edition 94 Process Block Diagram
PETROCHEMICAL COMPLEXES 95 9 th Edition Tabriz Tabriz is the provincial capital of Eastern Azerbaijan. It has an area of 1200 square kilometers and has a population of 1,460,000. It has been an in- fluential city in Iran’s political and economic developments. It was Iran’s first capital city during the Safavid Dynasty and later during the rule of the Qajar Dynasty; it was the city where the crown prince used to live. Tabriz was a populous city during 3-5 centuries B.C. Because of its geographical characteristic, it has been prone by natural disasters including earthquakes. Meanwhile, it was frequently invaded by the Byzantine Empire and Armenian armies. As a result, most of its historical monuments have been destroyed.
Places of interest Arg-e-Tabriz (Tabriz citadel) Elgoli Tabriz mosques Tabriz Bazaar Constitution Museum Oan-ibn-Ali Tomb Azerbaijan Museum Firefighting Tower (Borj-e-Atashneshani)
Tabriz Petrochemical Co. In 1988, NPC approved the implementation of Tabriz Petrochemical Co. (TPC). Design and engineering work on TPC started in late 1989 and erection activities began in 2002. It is situated in the west of Tabriz Refinery. The complex located in an area of 391 hectares, 1,362 meters above sea level. Tabriz Petrochemical complex produces raw plastic materials such as polyethyene, polystyrene and ABS.
PETROCHEMICAL COMPLEXES 9 th Edition 96 Tabriz Petrochemical Co.
Location: Southwest of Tabriz, west of Tabriz Refinery Area: 391 hectares Founded in: 1988 Ownership: Tabriz Oil Refinery (37.75%), Social Welfare Org. (11.57%), Justice Shares Broker Co. (10%), Omid Shares management & Investment Co. (17.89%), others (22.80%)
Product Final (‘000 t/y) Feed Licensor Production date
Ethylene 136 Naphtha, LPG, ethane Propylene 56 TPL (Italy) KTI (Netherlands) 1997 C4Cut 34 Butane-1 7 Ethylene IFP (France) HD/LLDPE 100 BP (England) IFP (France), Krupp Benzene 56 PGH Koppers (Germany) UOP, UNOCAL, Lummus Ethyl benzene 100 Ethylene, benzene UOP, Lumms Monsanto 1999
Styrene 95 UOP, Lumms Toluene 2 Monsanto Expandable Styrene, 15 Sunpor (Austria) polystyrene pentane General-purpose 25 Styrene, Elfatochem (France) polystyrene mineral oil High-impact 40 Styrene, polystyrene mineral oil, PBR High - Impact 54 Styrene Mineral oil, SULZER 2010 polystyrene2 PBR Butadiene 16.5 C4Cut BASF (Germany) 2003 Raffinate C4 15 Styrene, BD, AMS, ACN Samsung (South Korea), Chell ABS 35
Products application
LDPE/HDPE: Liquid containers, bags, plastic films, toys, home appliances Expandable polystyrene: Ice containers, insulation, packing General-purpose polystyrene: Pens, tooth brush, light bulb industry, refrigerators, automobiles, disposable containers High-impact polystyrene: TV, radio and cassette player cases, refrigerator, washing machine and auto parts, home appliances, disposable containers ABS: Monitor and typing machine cases, electronic parts, refrigerators, telephone handset, auto parts Propylene: Feed for polymer plants 1-3 Butadiene: Production of PBR, ABS PETROCHEMICAL COMPLEXES Toluene: Various chemical solvents 97 9 th Edition Input feed Amount (‘000 t/y) Source LSRG 245 Tabriz & Tehran Refineries HSRG 42.5 LPG 54 BIPC / Tabriz Refinery Ethane 8 Tabriz Refinery ACN 8 Import Mineral Oil 4.7 PBR 8.7 Import, Shazand Petrochemical Co. AMS 1.1 Import C6 cuts pyrolysis gasoline 37.5 Shazand Petrochemical Co. Benzene 23 BIPC/Buali Sina Petrochemical Co. Styrene Monomer 48 Pars Petchemical Co.
Standard certificates
QCC OHSAS-18001:1999 ISO-14001:2004 ISO-9001:2000
PETROCHEMICAL COMPLEXES 9 th Edition 98 Process BlockDiagram 99 PETROCHEMICAL COMPLEXES High-impact PS High-impact PS Unit 2 (Vavious grates) 9 th Edition Shiraz The city of Shiraz is in southwest of Iran. It is the capital of Fars province. Covering an area of 340 km, it is Iran’s third largest city. Shiraz has a population of 1,727,331 and is Iran’s fourth most populous city. It is situated at an altitude of 1486 at the foot of Zagros mountain range. It is 919km from Tehran. Shiraz is one of Iran’s most beautiful and historical cities.
Places of interest:
Ghavam Citrus Garden Eram Garden Bagh-e-Delgosha (Delgosha Garden) Karim Khan-e-Zand citadel Hafeziyeh Afif Abad Garden Quran Gate Kohpaye Shahe Cheragh Siboyeh Tomb Masjid-e-Vakil Vakil Bazaar Haft Tanan Mausoleum Khajuye Kermani Tomb Vakil Bath Chehel Tanan Mausoleum Pars Museum Flower Clock Shiraz twin cities: Nicosia (Cyprus) Chongqing (China) Dushanbe (Tajikistan)
PETROCHEMICAL COMPLEXES 9 th Edition 100 Shiraz Petrochemical Co.
Location: 45km north of Shiraz Area: 300 hectares Founded in: 1959 Ownership: Private Sector
Shiraz Petrochemical Co. Shiraz Petrochemical Co. was Iran’s first petrochemical complex which was brought onstream in 1963. It is located near Kor River. The complex lies in an area of 300 hectares of which 72 hectares are allocated to industrial sites. At the outset, the complex consists of 4 production plants including ammonia, urea, nitric acid and ammonium nitrate plus utility unit. Later, the complex underwent several expansion projects which included soda ash which was commissioned in 1973 and the complex’s largest expansion project was launched in 1985.
Product Final (‘000 t/y) Feed Licensor Production date
Ammonia 432.6 NG, air ICI (England) 1985 Urea (unit-1) 48 Ammonia, Co2 Monteh Cartini 1963
Urea (unit-2) 495 Ammonia, Co2 Stami Carbon (Netherlands) Methanol 84 NG Lurgi (Germany) 1990
Nitric acid 341.2 Ammonia, air Grand Paroise (France)
Ammonium nitrate 214.5 Ammonia, Kalten Bach 1965 nitric acid (France Light Soda ash 80 Lime, salt Industrial Dense soda ash 66 Soda ash Export/Import 1973 Sodium bicarbonate 20 (Romania)
Argon 5 Purge gas Air Liquid (France) 1994 Chlorine 20 Caustic 22.4 Salt Denora (Italy) 1988 HCL 20 Sodium Hypochloride 13.2 Perchlorine 5 CL2, NAOH, lime Denora (Italy) 1993
Chloralkali and perchlorine plants have been put out of service since 2009.
PETROCHEMICAL COMPLEXES 101 9 th Edition Products application
Soda ash: Production of glass and crystal, food and pharmaceuticals, paper industry, leather industry Ammonia: feed for Production of various chemicals and fertilizers Urea: Production of fertilizers, resins, formaldehydes & melamines Nitric Acid: Explosives and dairy products Ammonium nitrate: fertilizer to improve soil; also used in medical, mineral and military industries Argon: welding , steel industry and electric light bulbs Chloralkali: food ,Sanitarian, paper, aluminum, plastic industries as well as treatment of potable water, production of disinfectants Methanol: production of acetic acid, MTBE, formaldehydes and organic solvents melamine Perchlorine: Production of disinfectants and antiseptics
Input feed Amount (mn m3/y) Source NG 900 NIGC Water 15,5 Fars Water Org Includes Feedstock & Fuel
PETROCHEMICAL COMPLEXES 9 th Edition 102 Input feed Amount (‘000 t/y) Source Salt 220 Maharlo River Lime 120 Nearby limestone mine
Standard certificates
ISO-9001:2000 ISO-14001:2004 HSE MS OHSAS -18001: 1999 QCC EFQM
Process Block Diagram
Javel water
PETROCHEMICAL COMPLEXES 103 9 th Edition BOJNURD Bojnurd is the capital city of the northeastern Province of Northern Khorasan which lies on the border with the Turkmenistan Republic. Bojnurd has common borders with Shirvan City in the east, Esfarayen and Jajarm in the South and Golestan Province in the west.
Places of interest: Masomzadeh Hill Sardar Mofakham Building Mirror House Mahak Khan Tomb Baba Aman Tourist site Ampakhu Fire Temple
PETROCHEMICAL COMPLEXES 9 th Edition 104 Khorasan Petrochemical Co. Khorasan Petrochemical Co. is located on the 17th kilometer of Bojnurd- Mashhad Road. It has an altitude of 105 meters. The complex lies on an area of 204 hectares. Its construction was approved in 1989. Its proximity to the gas-rich Khangiran region in northern Iran and a growing demand for fertilizers in the northern parts of Iran were among the major reasons for its construction.
PETROCHEMICAL COMPLEXES 105 9 th Edition Khorasan Petrochemical Co.
Location: Bojnurd-Mashhad Road,17km Area: 204 hectares Founded in: 1992 Ownership: Tamin oil, gas & petrochemical Investment Co. (41.7%), Parsian Oil & Gas Expansion (18%), Petro Farhang (19%), Atieh Saba (12.4%), others (8.9%).
Product Final (‘000 t/y) Feed Licensor Production date
Ammonia 330 NG MW Kellogg 1996 Prilled urea 495 Ammonia, Co2 Stami Carbon Ammonia & Melamine 20 Eurotechnica 2003 Urea solution
Products application
Ammonia: Production of fertilizers, refrigerant fluid in refrigeration systems Urea: Production of fertilizers, urea-formaldehyde resins and melamine Melamine: Production of resins
PETROCHEMICAL COMPLEXES 9 th Edition 106 Input feed Amount (mm3/y) Source NG 478 Khangiran-Sarakhs Refinery Includes Feedstock & Fuel.
Standard certificates
OHSAS -18001 ISO-14001:2004 ISO -9001: 2000 EFQM
Process Block Diagram
PETROCHEMICAL COMPLEXES 107 9 th Edition Kermanshah Petrochemical Industry Co.
Location: Harsin Road, Kermanshah Area: 295.5 hectares Founded in: 1986 Ownership: Private Sector (100%)
Product Final (‘000 t/y) Fee Licensor Production date
Ammonia 396 Natural Gas M.W. Kellogg 2007 Granular Urea 660 Ammonia + CO2 Stamicarbon
Products application
Ammonia: Production of fertilizers and material fluid Urea: Production of fertilizers, resins, formaldehyde urea & melamines
Input feed Amount (mn m3/y) Source Natural Gas 533 Gas Pipeline Includes Feedstock & Fuel.
Standard certificates
ISO 14000 OHSAS 18000 HSE-MS ISO 9001 ISO/IEC 17025 ISO/TS 29001
Process Block Diagram
Natural gas
PETROCHEMICAL COMPLEXES 9 th Edition 108 Bisootun Bisootun is a city located in the northwestern province of Kermanshah. It lies at the foot of a mountain from which it takes its name. It consists of the villages of Chehr and Markazi.
Bisootun has numerous ancient and historical monuments including Bisootun Inscription or Darius Inscription Balash Inscription Farhad Tarash (Farhad Carving) Maraftab Cave Martarik Cave Shekarchi Cave Hercules Statue Khosravi Bridge Sheikh Alikhan Inscription Bisootun Stone Lion (Shire Sangi) to name afew.
PETROCHEMICAL COMPLEXES 109 9 th Edition Bisootun Petrochemical Co.
Location: 8th KM Kermanshah-Bisootun Road Area: 63 hectares Founded in: 1999 Ownership: Private Sector
Product Final (‘000 t/y) Feed Licensor Production date
LAB 50 Benzene & Kerosene IFP (Axens) 1996 HAB 6.5
Input feed Amount (‘000 t/y) Source Kerosene 386 Kermanshah, Abadan Refineries Benzene 19 Buali Sina, BIPC Natural Gas 15(mnm3/y) NIGC
Standard certificates
ISO-9001:2000 OHSAS 18001:1999 ISO-14001:2004 QCC EFQM
PETROCHEMICAL COMPLEXES 9 th Edition 110 Products application
LAB: Raw material for detergents HAB: Production of industrial oils
Process Block Diagram
PETROCHEMICAL COMPLEXES 111 9 th Edition Kermanshah Polymer Co.
Location: Harsin Road, Kermanshah Area: 55 hectares Founded in: 1995 Ownership: Bakhtar Petrochemical Co. (100%)
، Product Final( 000t/y) Feed License Production Date
HDPE 300 Ethylen Basell 2012
Products application
Production of plastics, pipes, cable coverage, film ...
Input Feed Amount (،000t/y) Source Ethane 305 West Ethylene Pipeline Butane-1 3.3 Local Sources
Ethylene Process Block Diagram HDPE Butene-1 HDPE
PETROCHEMICAL COMPLEXES 9 th Edition 112 Orumiyeh Orumiyeh is the provincial capital of Western Azerbaijan Province. Its history goes back to 2000 BC. Orumiyeh is situated in a wide and lavish green plateau, skirted with grapevines, apple orchards and farmlands. Orumiyeh Lake and Marmishlo Lake are located on east and west part of the city respectively.The city’s moderate temperature and scenic views attract many visitors.
Other places of interest in the city include:
Sardar Masjid Azam Masjid Jame Masjid Sargonbad monument Nane Maryam church the city museum
PETROCHEMICAL COMPLEXES 113 9 th Edition Orumiyeh Petrochemical Co
Location: 30 Km of Orumiyeh - Mahabad Road, Orumiyeh Area: 110 hectares Founded in: 1991 Ownership: PCC (49%), Justice Shares Broker Co.(30%), Iranian Petrochemical Investment Co. (21%).
Product Final (‘000 t/y) Feed Licensor Production date
Crystal melamine 4.4 Ammonia, urea CNCCC 1996 Sulfuric acid, Ammonia Sulfate 13.2 Ammonium carbonate Sulfuric Acid 50 Sulfur KSJ 2013
Input feed Amount (‘000 t/y) Source Urea 15.2 Urea plants Ammonia 4 Ammonia plants Sulfur 6.6 Kabudan Phosphate Co.
PETROCHEMICAL COMPLEXES 9 th Edition 114 Products application
Crystal melamine: Production of resins Ammonia sulfate: Production of leather, batteries, paint and agricultural industries
Standard certificates
ISO 9001:2000 ISO 14001:2004 OHSAS 18001:1999
Process Block Diagram
PETROCHEMICAL COMPLEXES 115 9 th Edition Ilam Petrochemical Co
Location: Ilam Area: 108 hectares Founded in: 2004 Ownership: Private Sector (100%)
، Product Final( 000t/y) Feed License Production Date
HDPE 300 Ethylene Mitsui(MCI) 2013
Products application
Plastic production such as pipe, cable coverage, film & ...
Input Feed Amount (،000t/y) Source Ethylene 305 West Ethylene Pipeline (Before Ilam olefine unit is on stream) Butane-1 3.3 Local Sources
Process Block Diagram
Ethylene HDPE HDPE Butene-1 Unit
PETROCHEMICAL COMPLEXES 9 th Edition 116 Poly Nar Co
Location: Tabriz Area: 19.5 hectares Founded in: 1992 Ownership: Private Sector (100%)
، Product Final( 000t/y) Feed License Production Date
Polypropylene 60 Propylene Himont 2000
Products application
Production of Carpet Fibers, auto & home appliances, Carpet, Packing films & ...
Input Feed Amount (،000t/y) Source Propylene 62.5 Tabriz Petrochemical Co.
Standard certificates
ISO 9001: 2008 ISO 14001:2004 OHSAS 18001: 2007
Process Block Diagram Propylene Propylene Polypropylene Unit
PETROCHEMICAL COMPLEXES 117 9 th Edition Abadan Petrochemical Co.
Location: Motahari District, Abadan Area: 50 hectares Founded in: 1966 Ownership: Private Sector (100%)
Product Final (‘000 t/y) Feed Licensor Production date
PVC 110 Ethane, BF Goodrich 1969 propane, butane DDB 10 Chevron Research Caustic soda 29 Salt Denora 1993
Products application
Downstream plastic industries, detergents, hygenic industries, chemicals, refineries
Input feed Amount Source Gas 150-200 t/d Abadan Refinery Propane 50-100 t/d Petrochemical complexes
Standard certificates
ISO - 9000 ISO -14001
PETROCHEMICAL COMPLEXES 9 th Edition 118 Process Block Diagram
Caustic Soda
Sodium Hypochlorite
Chlor Alkali EDC/VCM PVC PVC Unit Unit Unit
EDC
HCL HCL (33%) Ethylene Gas Stock Olefin Propane Unit Propane + Propylene
Propane Tetramer Unit Dodecyl benzene Dodecyl benzene Benzene Unit
PETROCHEMICAL COMPLEXES 119 9 th Edition Iran Carbon Co.
Location: Karoon Industrial Zone, Ahwaz Area: 13 hectares Founded in: 1974 Ownership: Private Sector (100%)
Product Final (‘000 t/y) Feed Licensor Production date
Industrial coke 36 Aromatic oils Cabot 1974
Products application
Production of tires, plastic parts, paints
Input feed Amount (000t/y) Source Aromatic oils 120 Tar and oil refineries, petrochemical plants
Standard certificates
ISO 9001-2000 ISO 14001-2004
PETROCHEMICAL COMPLEXES 9 th Edition 120 Ghaed Basir Petrochemical Co.
Location: 10 km Golpayegan - Khomein road, Esfahan Area: 30 hectares Founded in: 1997 Ownership: Private sector (100%)
، Product Final( 000t/y) Feed License Production Date
ABS 35 Styrenemonomer- Kumho 2003 Butadiene Acrylonitrile (South Korea)
Products application
Auto Parts, Appliances, Electronic device, ...
Input Feed Amount (،000t/y) Source Styrene monomer 18.2 Pars Petrochemical Co. Acrylonitrile 6.8 Import (Taiwan-Turkey) Butadiene 4.9 Tabriz-Amirkabir Petrochemical Cos.
Standard certificates
ISO 9001:2008 OHSAS 18001: 2007 ISO-14001:2004 ISO/TS 29001: 2010 ISO 10015: 1999
Process Block Diagram
Monomer Styrene
Acrylonitrile ABS Unit ABS Butadiene
PETROCHEMICAL COMPLEXES 121 9 th Edition Gameron Petro Sanat Co.
Location: Next to industrial park-No1, Bandar Abbas Area: 6 hectares Founded in: 2012 Ownership: Private Sector (100%)
Product Final (‘000 t/y) Feed Licensor Production date
Formalin 56 Methanol Indo Chem (UK) 2012 Hexamin 5 Methanol & Ammonia Formaldehyde Urea 10 Urea-Formalin
Products application
Adhesive, resin & detergent industry.
Input feed Amount (000t/y) Source Shiraz, Zagros, Fannavaran Methanol 27 Petrochemical Cos. Shiraz, Kermanshah, Ammonia 3 Khozestan Petrochemical Cos. Urea 2.7 Shiraz Petrochemical Co.
Standard certificates
ISO 9001-2000 ISO 14001-2004
Process Block Diagram
Methanol Formalin Formalin Ammonia Hexamin Unit Urea Formaldehyde Urea
PETROCHEMICAL COMPLEXES 9 th Edition 122 Petrochemical Terminals & Tanks
PETROCHEMICAL COMPLEXES 123 9 th Edition Petrochemical Terminals & Tanks Co.
Location: Petrochemical Special Economic Zone(Mahshahr) & Pars Special Economic/ Energy Zone(Assaluyeh) Founded: 1998 Ownership: NPC(100%)
Petrochemical Terminals & Tanks Co. Is in charge of operating NPC’s two massive and specialized ports in Mahshahr (Bandar Imam) and Assaluyeh as well as the petrochemical tank farm that is located in Bandar Imam. This company handles the export of petrochemical products, import of raw materials and the storage of these products and raw materials.
PETROCHEMICAL COMPLEXES 9 th Edition 124 Pars Petrochemical Port Total jetties: 15 jetties consisting 6 for liquid products, 7 for solid products and 2 for LPG Commissioning Date: The first phase was brought onstream in 2005; the port became operational in its entirely in 2009. Total capacity: 35 million tons (29 million tons of liquids & LPG and 6 million tons of solid products) Breakwater length: 15 to 32 meters Berthing capacity: 70,000 tons Total loading/ unloading capacity: 170- 2,250 tons per hour Anchorage traffic: 800- 1200 vessels per annum Major exports: Butane, propane, methanol, ammonia, ethylene, benzene, light ends, heavy ends, styrene, orthoxylene, paraxylene, polyethylene, urea, polypropylene, ...
PETROCHEMICAL COMPLEXES 125 9 th Edition Mahshahr Petrochemical port Total no. of jetties: 7 jetties consisting 5 for liquid products & LPG and 1 for solid products - another jetty for liquid products is under pre-commissioning. Commissioning Date: 1969 (3 jetties), 1990(2 jetties) and one in 2004 Total capacity: 15 million tons Breakwater length: 11- 13 meters Berthing capacity: 50,000 tons Loading/ Unloading capacity: 150- 1600 tons/ hour Anchorage Traffic: About 1000 vessels per annum Major exports / imports: propane, butane, heavy ends, methanol, ethylene, ammonia, C5+, benzene, paraxylene, light cuts, naphtha, pyrolysis gasoline, sulfuric acid, sulfur, orthoxylene, phenol, aceton, phosphate rock, phosphoric acid, caustic soda, MC, VCM, EDC,..
PETROCHEMICAL COMPLEXES 9 th Edition 126 Mahshahr Tank Yard (Bandar Imam) No. of storage tanks: 19 Total storage capacity: 157,200 m3 Commissioning date: 2004 Storage capacity: 2,000m3- 20,000 m3 Tanks material:carbon steel and stainless steel Mounted equipment: Some tanks have cooling/ heating systems Major Exports / Imports: Heavy cuts, Naphtha, Acetic Acid, Raffinate, phenol, Acetone, VAM, DEG,...
PETROCHEMICAL COMPLEXES 127 9 th Edition Published by: NPC PR Dep. Project Manager: Hadi Zonouzi Asl Experts: Azimeh Zilaie, Homa Mehraie, Nayereh Mohammadi, Samira Karimi Pour, Soudeh Maleki, Farzaneh Shahbazi, Marzieh Salehi, Razieh Hemmati, Hossein Naseri, Seyed Jalaledin Mir Hashemi, Ghodratollah Faraj Pour, Ali Soleimani Roozbehani, Seyed Hossein Nouri, Mohsen Gheibi, Seyed Mehdi Rasti Translators: Mahshid Haji Anzehaie, Reihaneh Rabbani Language Editor: Mahshid Haji Anzehaie Photography Manager: Abolghasem Rahmani Implemented by: Simiahonar Design & Publication Office Art Director: Mahdi Haji mohammadi Graphic Designer: Zeynab Shariati
