2999.99 $3399.99 $1599.99 ONLY ONLY STARTING AT $1,599.99 $2,999.99 $3,399.99 PM2800B PM2200 CYCLONE PM2000B DRILL PRESS DUST COLLECTOR 10" TABLE SAW PAGE 8 PAGE 10 PAGE 20 VISIT POWERMATIC.COM FOR MORE DETAILS PRICES EFFECTIVE JANUARY 1 TO JUNE 30, 2020 4224B LATHE • Sliding headstock with electronic $ .99 variable speed and digital RPM readout for accurate speed adjustments 7,899STOCK NO. 1794224K • Spindle lock and built-in spindle indexing on the headstock for drilling hole patterns, routing flutes, and other equally spaced features • Vacuum system provides quick method of chucking bowl blanks • 15-amp quad receptacle for easy reach or powered accessories • Set of dead centers which hold a spindle for visual comparison • Quad system provides 115-volt electrical supply • Magnetic-backed moveable control box for customizable versatility and safety • Lamp kit and guard included STOCK NO. DESCRIPTION PRICE 1794224K 4224B Lathe, 3HP 3PH 230V, with Lamp Kit $7,899.99 PM2020 SHORT BED LATHE $ .99 • Sliding headstock with electronic variable speed • Digital RPM readout for accurate speed adjustments 3,699STOCK NO. 1792020 • Tailstock has internal storage for additional accessories and attached tool caddy allows convenient access to centers and wrenches • Spindle lock and built-in spindle indexing on the headstock for drilling hole patterns, routing flutes and other equally spaced features • Two-position mount for the optional bed extension • Chrome-trimmed handwheels are ergonomic for a comfortable feel • Guard included STOCK NO. DESCRIPTION PRICE 1792020 PM2020 Short Bed Lathe, 2HP 1/3PH 220V $3,699.99 2 POWERMATIC | WOODWORKING 3520C LATHE • Digital indexing readout simplifies the indexing process for added precision $ .99 • Magnetic-backed moveable control box for 4,499STOCK NO. 1353001 customizable versatility and safety • Adjustable riser blocks for 4 inches of height adjustment, allowing maximum comfort when turning • Upgraded banjo features a non-marring, pinch-style clamp for solid toolrest placement • Extended spindle note increases access to the workpiece • Able to maintain speed as low as 15 RPM STOCK NO. DESCRIPTION PRICE 1353001 3520C Lathe, 2HP, 220V $4,499.99 LATHE ACCESSORIES STOCK NO. DESCRIPTION PRICE 6294905 20" Bed Extension for 4224B $699.99 6294904 63" Bed Extension with Stand for 4224B $2,499.99 1353002 20" Bed Extension for 3520C $479.99 6294706 Tailstock Swing Away for 4224B $349.99 6294721 Tailstock Swing Away for 3520, 3520A, 3520B, PM2020 $299.99 6294903 Tailstock Riser Block for 4224B $729.99 6294732 Heavy-Duty Outboard Turning Stand for Models 3520B, 3520B and 4224B $499.99 6294751 Bowl Turning Toolrest (Left) for 3520A, 3520B, 3520C, 4224 $129.99 6294740 Bowl Turning Toolrest (Right) for 3520A, 3520B, 3520C, 4224 $129.99 6294739 6" Toolrest for 3520A, 3520B, 3520C, 4224 $89.99 6294901K Lamp Kit 4224B, 3520B, 3520C $479.99 6294733 On/Off Remote Switch for 3520A, 3520B, 4224 $99.99 JANUARY 1 TO JUNE 30, 2020 | POWERMATIC.COM 3 18", 20" & 24" BANDSAWS • Spacious, heavy-duty cast iron table with more room in front of the blade $ .99 • Solid cast iron upper and lower wheels create the momentum needed for heavy resaw 5,199STOCK NO. 1791800B • Foot brake with magnetic switch interrupt provides user with hands-free stopping option • Exclusive Powermatic® T-square style Accu-Fence® maximizes accuracy and safety • Blade tension release with electrical interlock prevents the bandsaw from starting when the blade is de-tensioned • Heavy-duty 5HP motor provides power needed for all projects STOCK NO. DESCRIPTION PRICE 1791800B PM1800B, 18" Bandsaw, 5HP 1PH 230V $5,199.99 1791801B PM1800B-3, 18" Bandsaw, 5HP 3PH 230/460V $5,199.99 1791257B PM2013B, 20" Bandsaw, 5HP 1PH 230V $5,699.99 1791258B PM2013B-3, 20" Bandsaw, 5HP 3PH 230/460V $5,699.99 1791259B PM2415B, 24" Bandsaw, 5HP 1PH 230V $6,299.99 1791260B PM2415B-3, 24" Bandsaw, 5HP 3PH 230/460V $6,299.99 4 POWERMATIC | WOODWORKING PM1500 BANDSAW • Blade tension release with electrical interlock prevents the $ .99 bandsaw from starting when the blade is de-tensioned or released 2,999STOCK NO. 1791500 • Solid cast iron upper and lower wheels create the momentum needed for heavy resaw • Oversized fence side plate can be used in the horizontal or vertical position • Sturdy cast iron table and trunnion assembly offers maximum rigidity for heavy workpieces • Exclusive Powermatic® T-square style Accu-Fence® maximizes accuracy and safety • High-end blade guide with tool-less adjustment provide stability, increasing cut accuracy STOCK NO. DESCRIPTION PRICE 1791500 PM1500, 14" Bandsaw, 3HP 1PH 230V $2,999.99 PWBS 14" BANDSAW • Precision-balanced, nine-spoke cast iron wheel makes for $ .99 smooth blade travel 1,299STOCK NO. 1791216K • Upper and lower dual ball bearing guides for accurate cuts • CARTER® quick tension lever speeds blade changes and the de-tensions setting extends blade life during non-use • Chip blower ensures a clean,visible cut line • Exclusively designed, quick-release precision T-square style rip fence with 4" resaw attachment STOCK NO. DESCRIPTION PRICE 1791216K PWBS-14CS, Bandsaw, 1.5HP 1PH 115/230V $1,299.99 JANUARY 1 TO JUNE 30, 2020 | POWERMATIC.COM 5 PM-2X4SPK CNC KIT WITH ELECTRO SPINDLE • Heavy-duty welded steel frame provides rigidity and maintains accuracy • Enclosed cabinet is heavy welded steel and includes a handy toolbox and casters for mobility • The extruded aluminum table delivers a large, sturdy surface while the integrated T-slots allow the hold-down clamps to be positioned in any location • An MDF spoil board protects the table from damage and can be quickly resurfaced using the pre-loaded program $ .99 • Exclusive, heavy-duty gantry supports 8,749STOCK NO. 1797024K are made of gravity cast aluminum • Precision ball screws with recirculating ball bearings allow for rapid movement on each axis while maintaining precise spindle placement • The electro spindle is liquid-cooled by a system that pushes coolant through the spindle while a radiator and fan assembly dissipate the heat • Linear guideways with recirculating ball bearings ensure precise and accurate positioning of the tool bit • The handheld controller attaches to the DSP control box via a 8-ft. cable that makes it easy to oversee any project from a variety of positions • Flexible nylon track chains protect all cables, preventing rubbing and stress • High-torque stepper motors control each axis, providing fast, quiet and precise movement STOCK NO. DESCRIPTION PRICE 1797024K PM-2X4SPK CNC Kit With Electro Spindle $8,749.99 6 POWERMATIC | WOODWORKING PM-2X2RK CNC KIT WITH ROUTER MOUNT • Heavy-duty welded steel frame provides rigidity and maintains accuracy • Enclosed cabinet is heavy welded steel and includes a handy toolbox and casters for mobility • The extruded aluminum table delivers a large, sturdy $ .99 surface while the integrated T-slots allow the hold-down 5,949STOCK NO. 1797022K clamps to be positioned in any location • An MDF spoil board protects the table from damage and can be quickly resurfaced using the pre-loaded program • Exclusive, heavy-duty gantry supports are made of gravity cast aluminum • Precision ball screws with recirculating ball bearings allow for rapid movement on each axis while maintaining precise spindle placement • Linear guideways with recirculating ball bearings ensure precise and accurate positioning of the tool bit • The handheld controller attaches to the DSP control box via an 8-ft. cable that makes it easy to oversee any project from a variety of positions • Flexible nylon track chains protect all cables preventing rubbing and stress • High-torque stepper motors control each axis, providing fast, quiet and precise movement • The included puck allows you to quickly and easily re-zero your Z-axis with the push of a button on your controller • Enclosed steel stand features drawers for storage, casters for mobility and independent leveling feet • Hold-down clamps have a 5/16" T-bolt with a 1-1/8" wide by 5-1/4" tall aluminum arm - 4 hold-down clamps included with CNC kit *ROUTER NOT INCLUDED STOCK NO. DESCRIPTION PRICE 1797022K PM-2X2RK CNC Kit With Router Mount $5,949.99 CNC ACCESSORIES STOCK NO. DESCRIPTION PRICE 1797000 PM-HD CNC Hold-Downs (Set of 2) $24.99 1797001 PM-DS CNC Dust Shoe $59.99 1797003 PM-RBS CNC Router Bit Set $299.99 JANUARY 1 TO JUNE 30, 2020 | POWERMATIC.COM 7 PM2800B 18" VARIABLE $ .99 SPEED DRILL PRESS • Mechanical variable speed allows for full range of 1,599STOCK NO. 1792800B speed with no belt changes • 6" of quill travel with one revolution of the handle • Fence system adjustable for a perfect 90° relationship to the table, for rapid alignment of stock • Adjustable material stop makes repetitive actions accurate and quick • A digital readout with a range of 250-3,000RPM, allows the user to optimize the spindle speed to the application • Laser guides provide an accurate indication for tool point entry • Reversible handles can be mounted on either side of the machine for more comfortable working of the quill • Redesigned high output LED lighting eliminate shadows • Work table can be rotated to a full 90° position • Replaceable square table insert with leveling screws make it flush with the top of the table • Oversize cast iron base for added stability • Safety key prevents accidental starting STOCK NO. DESCRIPTION PRICE 1792800B PM2800B, 18" Drill Press, 1HP 1PH 115/230V $1,599.99 MECHANICAL VARIABLE QUILL SPEED SYSTEM 6" of quill travel with one revolution of Full range of speed with no belt change the handle 8 POWERMATIC | WOODWORKING PM701 BENCHTOP $ .99 DELUXE MORTISER • In-line depth stop allows stopping at pre-set 599STOCK NO. 1791310 depths without racking the bit to the base • Heavy-duty reversible handle can be installed to either side of the head without tools • Stock hold-down with a double-lock system, top and side, to eliminate slippage of workpiece • Quick-action cam lock will quickly lock fence in position with one 90° movement • Two integrated bit and chisel spacers for quick set up STOCK NO.
