THOR ZONE MJOLNIR
USER MANUAL (ENG) WHAT’S IN THE BOX?
MJOLNIR BASE MODEL
PANELS
OR OR
2X PERFORMANCE PANELS 2X TEMPERED GLASS PANELS 2X PANELS SETS
SCREWS
8X #6-32x1/4 COUNTERSUNK 8X #6-32x1/4 PAN HEAD 8X M3x4
MJOLNIR R — GODRAYS
2X RGB LED STRIPS
1X LED-TO-LED CABLE
1X LED-TO-MOTHERBOARD CABLE (3-PIN)
1X LED-TO-MOTHERBOARD CABLE (4-PIN)
4X M3x4
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 1 OPEN THE CASE
TOOLS SCREWS
INSTRUCTIONS 1. Unlock the case by turning the lock knob counterclockwise (located on the back) TIP: Use a credit card to easier turn the lock knob 2. Place the case on it’s back (hold the back panel so the Core doesn’t slide out) TIP: Put a soft cloth underneath to avoid scratches 3. Gently pull the Shell up and off the Core 4. Perform steps 1-3 in reverse when closing the case again
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 2 FLIP LAYOUT
TOOLS SCREWS
INSTRUCTIONS • The Core can be inserted normally or reversed 180° NOTE: Reversed orientation benefits thermals when using water coolers
NORMAL FLIPPED
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 3 CHANGE PANELS
TOOLS SCREWS
INSTRUCTIONS • Push on the panel (using one hand) from the inside until it releases TIP: Hold the panel with your other hand when it releases
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 4 MJOLNIR R — GODRAYS
TOOLS SCREWS
• Hex key (size: H2.0) 4x M3x4
INSTRUCTIONS 1 Attach the LED strips to the Core with four M3x4 screws 2. Connect the LED strips to each other, use the LED-to-LED cable NOTE: Connect the IN-port on one LED strip to the OUT-port on the other 3. Connect the LED strips to the Motherboard, use the LED-to-Motherboard cable NOTE: Connect the IN-port on the LED strips to a 5V dRGB header • There are 2 available LED-to-Motherboard cables (3-pin and 4-pin) TIP: Use one that best fits your motherboard’s 5V dRGB header • 5V DIGITAL ONLY - AVOID 12V/ANALOG HEADERS AT ALL COSTS! • CORRECTLY CONNECT POWER, DATA AND GROUND! • The GODRAYS are controlled by proprietary software on your motherboard TIP: For STRIX X570-I, GODRAYS are controlled by ARMOURY CRATE
LED-TO-MOTHERBOARD CABLE (3-PIN)
+5V D GND
IN OR
+5V D
GND
LED-TO-MOTHERBOARD CABLE (4-PIN)
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 5 HARDWARE — MOTHERBOARD
TOOLS SCREWS
• Phillips screw driver (size: PH1) 4x #6-32x1/4 Pan Head
INSTRUCTIONS 1. Install the I/O shield (usually included with your motherboard) 2. Align the motherboard with the I/O shield and secure it with four #6-32x1/4 Pan Head screws 3. Connect the PCIe riser 4. Connect the power button
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 6 HARDWARE — GRAPHICS CARD
TOOLS SCREWS
• Hex key (size: H2.0)
INSTRUCTIONS 1. Loosen the GPU bracket screw and slide the backet up 2. Insert the GPU into the PCIe riser 3. Slide the GPU bracket back down and tighten the screw again
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 7 HARDWARE — POWER SUPPLY (1/2)
TOOLS SCREWS
• Phillips screw driver (size: PH1) 4x #6-32x1/4 Pan Head
INSTRUCTIONS 1. Attach the PSU to the PSU bracket and secure it with four #6-32x1/4 Pan Head screws 2. Plug in the power cable into the PSU power socket
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 8 HARDWARE — POWER SUPPLY (2/2)
TOOLS SCREWS
• Phillips screw driver (size: PH1) 4x #6-32x1/4 Pan Head
INSTRUCTIONS 1. Remove the PSU frame and reattach in the bottom position 2. Attach the PSU to the PSU bracket and secure it with four #6-32x1/4 Pan Head screws 3. Plug in the power cable into the PSU power socket
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 9 HARDWARE — FANS AND RADIATORS
TOOLS SCREWS
• Phillips screw driver (size: PH1) 4-8x #6-32x1/4 Countersunk
INSTRUCTIONS • Fans, radiators and AIO water coolers can be mounted to the bottom rails using 4-8 #6-32x1/4 Countersunk screws
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 10 HARDWARE — SSDs AND STORAGE
TOOLS SCREWS
• Hex key (size: H2.0) 4-8x M3x4
INSTRUCTIONS • Attach 1-2x 2.5in SSDs to the storage frame and secure them with 4-8 M3x4 screws
THOR ZONE S:t Persgatan 23, 602 33 Norrköping Sweden [email protected] thor-zone.com MJOLNIR 11
