BIOFLY BRICK'

ENGINEERING REUSE OF FLY ASH AND SEWAGE SLUDGE WASTES

by

Fady G. Sidrak

Thesis submitted to the Department of Civil and Mining Engineering of the University of Wollongong in partial fulfillment of the reguirements for the degree of

UNIVERSITY 09 WOLLONGONG LIBRARY

Master of Engineering Honours 1991 013171 The LORD has done great things for us, and we are filled with joy Psalm 126:3 To my wife, Mary

It was more work for you ACKNOWLFDnKMRNTS

The project was conducted under the guidance and supervision of Dr. M. Sivakumar, Senior Lecturer in Civil Engineering and who is also the "Biofly" project leader. The project is co-supervised by Associate Professor Robin N. Chowdhury.

I would like to express my gratitude, for their help and backing to:

Dr. M. Sivakumar Thank you for the many extra hours of help, mental refurbishing, constant friendships, understanding and guidance.

Associate Professor Robin N. Chowdhury For help with specific problems related to logistics and mechanics of research and technical help in engineering problems.

This study is being carried out by the University of Wollongong within the Water Engineering and Geomechanics Research program, Department of Civil & Mining Engineering and is financially supported by:

The Electricity Commission of New South Wales; The Water Board - Sydney, Illawarra and Blue Mountains, and Boral Limited

The author wishes to express sincere appreciation to Dr. A. Samarin, Director, Boral Research for his assistance, Mr. John Bacchus and Mr. Ian Finney of the Water Board and Mr. Peter Wood of the Electricity Commission for their input and contribution.

The author also wishes to thank all the employees at Boral Research Laboratory & Materials Laboratory for their help and co-operation.

Finally, the author wishes to express his indebtedness and sincere appreciation to his wife, Mary, daughter, Shery, and son, Kyrillos, for their patience and sacrifice throughout this investigation. ABSTRACT

Two of the greatest solid waste disposal problems are fly ash emitted from power plants and sewage sludge generated from municipal waste treatment plants. In an effort to introduce beneficial disposal alternatives, it was hypothesized that these waste products could be combined to produce a solidified material suitable for use in brick making. It is an innovative approach in solid waste reuse technology.

This research describes detailed laboratory investigation of small specimens with different proportions of fly ash, sewage sludge and clay/shale to determine the physical suitability of the mixtures and viability for use as a brick to be called "Biofly Brick".

Laboratory procedures for the manufacture of specimens are presented and the results of tests of compressive strength, absorptivity, efflorescence and examination for pitting due to lime particles are reported. Assessment of these structural properties were evaluated according to the Australian Standards which indicate that the small specimens of Biofly bricks are similar (if not better) in comparison to properties of ordinary bricks.

Other properties, such as shrinkage and density were evaluated. Waste leaching studies, exhaust gas analysis, and health issues have also been reported.

Statistical analysis were performed on the compressive strength data to establish confidence limits, standard deviation and coefficient of variation.

Laboratory experimental results indicated that, it is clearly possible and viable to use unattractive residues such as sewage sludge and fly ash together with clay/shale and transfer them to an attractive stable product such as "Biofly Brick". Bricks produced in the laboratory were shown to have less weight per unit volume, without the loss of strength and significant energy savings in comparison to ordinary bricks. -iv-
