Service Bulletin 89-020

Applies To: ALL June 24, 2008

Required Special Tools and Equipment (Supersedes 89-020, dated March 1, 2007, to update the information marked with black bars)

In accordance with the Automobile Sales and Service Agreement, Section 3.9, your service department is required to have, at a minimum, the tools and equipment listed in this bulletin. When a new model is introduced and requires special tools, those tools may be shipped to you automatically. If you receive a required special tool and believe you have an equivalent, refer to the Acura Dealer Operations Manual, Section 11, for the procedure to return items that have been distributed through the tool and equipment program.

REQUIRED SERVICE MANUALS Dealers are required to have a copy of each Service Manual, Electrical Troubleshooting Manual, and Body Repair Manual listed on the Helm web site, www.helminc.com.

REQUIRED SPECIAL TOOLS These tools are available from Acura. Use normal parts ordering procedures. Use the check (9) column to identify the tools you already have. NOTE: All tools are in single quantity units unless noted in italics under the Description heading.

Axle/Differential Tools Tool 9 Tool Number Drawer Description Location 07947-4630100 9 Fork Seal Driver 07947-SB0A100 9 Driver 07AAD-S3VA000 9 Driveshaft Remover 07AAD-S9VA000 6 Driveshaft Remover 07AAD-SJAA100 6 Front Driveshaft-Intermediate Shaft Remover 07JAD-PL9A100 9 Driver 07NAD-P20A100 9 Driver, 52 x 55 mm 07NAF-SR3A101 9 Half Shaft Base 07XAC-001010A 6 Threaded Adapter, 22 x 1.5 mm 07XAC-001020A 6 Threaded Adapter, 24 x 1.5 mm 07XAC-001030A 6 Threaded Adapter, 26 x 1.5 mm

Body Tools Tool 9 Tool Number Drawer Description Location 070AF-STX0100 15 A-Pillar Trim Tool 070AZ-SEAA200 16 Radio Test Harness 070AZ-SHJA190 18 ISOFIX Button Kit 070AZ-SNAA100 N/A SRS Test Lead J 070AZ-SNAA200 N/A SRS Test Lead K 070AZ-SNAA2300 N/A SRS Test Lead L 07AAC-000A1A0 15 Relay Puller, 10-Pack 07AAC-S3VA100 5 Vent Panel Puller 07AAC-SJAA100 15 Push Pin Puller 07AAE-000A100 15 Rivnut Tool, 6 mm 07AAF-SNAA100 16 Trunk Spring Removal/Installation Tool 07AAG-STXA101 N/A Audio Unit Software Update Disc 07AAG-TL2A120 N/A Spoiler Fixture

CLIENT INFORMATION: The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and training to correctly and safely maintain your vehicle. These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. Body Tools (cont’d) Tool 9 Tool Number Drawer Description Location 07AAJ-00A130 18 Includes: Radio Test Antenna 07AAJ-000A200, Radio Antenna Three-Pin Adapter Lead 07AAJ-000A300, Radio Antenna Five-Pin Adapter 07AAJ-000A300 07AAJ-S3MA100 N/A HID Headlight Checker 07AAJ-SJAA100 15 Body Panel Gap Gauge 07AAK-SNAA500 N/A Support Bolt 07AAK-SNAA600 N/A Support Eyelet 07AAK-STKA120 15 Mount Pads 07AAZ-SDAA100 18 15-Pin Breakout Box 07AAZ-SDBA100 16 Audio Diagnostics CD 07AAZ-SDBA200 16 ABEX Skip Test CD 07AAZ-SDBA300 16 ABEX Test CD TCD-721 07AAZ-SDBA400 16 ABEX Test CD SCD8700 07JAA-001000D 15 Antenna Nut Wrench 07JAZ-003000B 18 Terminal Pin Kit “A” 07MAZ-SL0000A N/A NSX Fender Cover 07MAZ-SP0020A 15 Seat Belt Service Connector (2 required) 07PAZ-001010A 5 SCS Service Connector 07QAZ-003020C 18 Terminal Pin Kit “C” 07SAZ-001000A 5 Backprobe Set (2 required) 07SAZ-TB4011A 15 SRS Inflator Simulator 07SAZ-TB4012A 15 SRS Simulator Lead “A” 07SAZ-TB4013A 15 SRS Simulator Lead “B” 07TAZ-001020A 5 Backprobe Adapter, 17 mm 07TAZ-SZ3010A 5 Immobilizer Jumper Connector (bag of five) 07TAZ-SZ3020A 5 Immobilizer Reminder Key Tag (bag of five) 07TAZ-SZ5011A 15 SRS Simulator Lead “C” 07TAZ-TB5011A 15 SRS Simulator Lead “D” 07WAZ-001010A 5 MPCS Service Connector 07XAZ-S1A0100 15 SRS Test Box 07XAZ-S1A0200 15 SRS Simulator Lead “E” 07XAZ-SZ30100 15 SRS Simulator Lead “F” 07XMJ-001000A 15 Terminal Inspection Feeler Tool Set 07YAZ-S3AA100 15 SRS Simulator Lead “H”

Common Bearing/Seal Drivers Tool 9 Tool Number Drawer Description Location 07746-0010100 17 Attachment, 32 x 35 mm 07746-0010200 17 Attachment, 37 x 40 mm 07746-0010300 17 Attachment, 42 x 47 mm 07746-0010400 17 Attachment, 52 x 55 mm 07746-0010500 17 Attachment, 62 x 68 mm 07746-0010600 17 Attachment, 72 x 75 mm 07746-0010700 17 Attachment, 24 x 26 mm 07746-0030100 17 Driver, 40 mm I.D. 07746-0030300 17 Attachment, 30 mm I.D. 07746-0030400 17 Attachment, 35 mm I.D. 07749-0010000 17 Driver

2 of 13 89-020 Common Bearing/Seal Drivers (cont’d) Tool 9 Tool Number Drawer Description Location 07947-6110501 17 Seal Driver Attachment, 68 mm 07947-6340201 17 Driver Attachment, 58 x 72 mm 07947-6340300 17 Driver Attachment 07947-6340500 17 Driver Attachment 07GAD-SD40101 17 Bearing Driver Attachment, 78 x 90 mm 07JAD-PH80400 17 Pilot, 28 x 30 mm 07LAD-SM4A100 17 Seal Driver Attachment 07MAD-PR90200 17 Pilot, 32 x 50 mm

Engine Tools Tool 9 Tool Number Drawer Description Location 07742-0010100 2 Valve Guide Driver, 5.5 mm 07757-PJ1010A 2 Valve Spring Compressor Attachment 07936-3710100 1 Remover Handle 07942-6570100 2 Valve Guide Driver, 6.6 mm 07973-6570500 1 Piston Base 07973-6570600 1 Piston Base Spring 07973-PE00310 1 Piston Pin Driver Shaft 07973-PE00320 1 Piston Pin Driver Head 07984-657010D 2 Valve Guide Reamer, 6.6 mm 07AAA-PAAA100 1 Oil Filter Wrench, 80 mm 07AAA-PLCA100 1 Oil Filter Wrench, 65 mm 07AAB-RJAA100 3 Tapered Holder, 65 mm Offset 07AAB-RWCA120 1 Camshaft Lock Pin Set 07AAJ-PNAA101 1 Air Regulator 07AAJ-RWCA100 1 Cam Chain Inspection Tool 07AAZ-P8AA100 2 Air Quick Connector 07GAF-PH60300 1 Piston Pin Base Insert 07GAF-PH70100 1 Pilot Collar 07HAH-PJ7A100 2 Valve Guide Reamer, 5.5 mm 07JAA-001010A 2 Socket, 17 mm 07JAA-001020A 2 Socket, 19 mm 07JAB-001010A 3 Pulley Holder Attachment, Pin Type 07JAB-001020A 3 Holder Handle 07LAB-PV00100 1 Ring Gear Holder 07LAD-PR4010A 1 Seal Driver 07LAD-PT3010A 1 Seal Driver 07LAJ-PR3020B 2 Air Stopper 07MAB-PY3010A 3 Holder Attachment, 50 mm Offset 07MAF-PR9010A 2 Valve Spring Compressor Attachment Extension 07NAB-001030A 3 Holder Attachment, 45 mm 07NAB-001040A 3 Holder Attachment, 50 mm 07NAF-PT0010A 2 Installer Cup 07NAF-PT0020A 2 Installer Shaft 07NAG-PT0010A 2 Seal Guide, 28 mm 07NAJ-P07010A 2 Pressure Gauge Adapter 07RAB-TB4010B 3 Flange Holder 07TGF-001000A 1 Piston Base Head

89-020 3 of 13 Engine Tools (cont’d) Tool 9 Tool Number Drawer Description Location 07TGG-001000A 3 Belt Tension Gauge Set 07VAD-P8A010A 1 Seal Driver Attachment, 80 mm I.D. 07VAJ-P8A010A 2 VTEC Air Adapter 07VAJ-P8A020A 2 VTEC Air Stopper 07WAF-S84010A 2 Installer Shaft, 10 mm 07XAF-PT00100 2 Seal Installer 07ZAD-P8AA000 2 EGR Port Tool Set 07ZAD-PNAA100 1 Driver, 96 mm 07ZAJ-PNAA101 2 VTEC Air Adapter 07ZAJ-PNAA200 2 VTEC Air Stopper 07ZAJ-PNAA300 2 Air Joint Adapter 07ZAJ-S5AA200 2 Oil Pressure Hose 14540-P8A-A01 1 Tension Stopper

Fuel/Emissions Tools Tool 9 Tool Number Drawer Description Location 07406-004000B 4 Fuel Pressure Gauge 07406-004030A 4 Fuel Pressure Adapter, 6 x 15 mm 07AAA-S0XA100 4 Fuel Pressure Wrench 07AAJ-PAAA100 4 90° Adapter 07AAJ-S6MA150 18 Fuel Pressure Test Adapters 07JAZ-001000B 4 Vacuum/Pressure Gauge, 0-4 in. Hg 07LAJ-PT3020A 5 Test Harness 07RAK-TB4080B 4 Fuel Pressure Gauge Adapter (V-6) 07VAJ-0040100 4 Fuel Pressure Gauge Adapter

Steering Tools Tool 9 Tool Number Drawer Description Location 07406-001A101 11 Power Steering Pressure Gauge 07725-0030000 11 Universal Holder 07916-SA50001 11 Locknut Wrench, 40 mm 07VAK-P8A011A 11 Power Steering Joint Adapter (Pump) 07VAK-P8A012B 11 Power Steering Joint Adapter Plate (Pump) 07ZAK-S7CA100 11 Power Steering Joint Adapter 07ZAK-S7CA200 11 Power Steering Joint Adapter

Suspension /Brake Tools Tool 9 Tool Number Drawer Description Location 070AB-SJA0100 14 Brake Booster Pushrod Holder 070AF-TA0A100 14 Bushing Driver 070AF-TA0A220 14 Bushing Receiver Set 071AD-S3VA000 14 Ball Joint Striker Tool 071AF-S3VA000 14 Threaded Cap, 14mm 07914-SA50001 14 Snap Ring Pliers 07965-6920201 14 Hub Assembly/Disassembly Base

4 of 13 89-020 Suspension /Brake Tools (cont’d) Tool 9 Tool Number Drawer Description Location 07965-SA00600 14 Bearing Driver Attachment 07965-SB00100 N/A Ball Joint Remover/Installer 07965-SB00200 13 Ball Joint Installer Base 07974-SA50700 13 Ball Joint Boot Clip Guide 07974-SA50800 13 Ball Joint Boot Clip Guide 07AAA-SVAA100 13 Strut Nut Adapter 07AAE-SEPA101 16 Brake Caliper Piston Compressor 07AAE-SJAA100 14 Rear Ball Joint Thread Protector 07AAF-SEAA100 9 Bushing Driver 07AAF-SEAA220 9 Bushing Receiver Set 07AAF-SEPA100 13 Ball Joint Puller 07AAG-SJAA000 13 Tapered Lug Adapter 07AAG-SJAA000 13 TPMS Test Gauge, 0-60 psi 07AAJ-000A100 13 Tire Pressure Gauge for TPMS 07AAJ-001A140 12 Steering Drift Set 07GAF-SD4031A 13 Ball Joint Base Remover Adapter © 07GAF-SD40330 13 Ball Joint Remover/Installer 07GAF-SD40700 14 Hub Assembly/Disassembly Base 07GAF-SD4A100 14 Assembly/Disassembly Tool 07GAF-SE00100 14 Hub Assembly/Disassembly Tool 07GAF-SE00200 14 Hub Assembly/Disassembly Guide Attachment 07GAG-SD40700 13 Ball Joint Boot Clip Guide 07HAD-SF10100 14 Driver Attachment 07HAF-SF10110 13 Ball Joint Remover/Installer 07HAF-SF10120 13 Ball Joint Installer Base 07HAF-SF1013A 13 Ball Joint Base Remover Adapter (F) 07JAG-SD40100 14 Pushrod Adjustment Gauge 07MAC-SL00100 13 Ball Joint Remover, 32 mm 07MAC-SL00200 13 Ball Joint Remover, 28 mm 07MAC-SL0A300 13 Tethers for Ball Joint Tools 07XAF-001010A 13 Ball Joint Remover/Installer Adapter (A) 07XAF-001020A 13 Ball Joint Remover/Installer Adapter (H) 07XAF-001030A 13 Ball Joint Remover/Installer Adapter (B) 07XAF-001040A 13 Ball Joint Remover/Installer Adapter (E) 07XAF-001050A 13 Ball Joint Pilot Adapter (G) 07XAF-001060A 13 Ball Joint Base Remover Adapter (D) OTC-7248 13 C-Frame Tool

Transmission/Clutch Tools Tool 9 Tool Number Drawer Description Location 070AD-PYZA100 6 Gear Driver, 57x62 mm 070AG-SJAA10S 13 Subframe Alignment Pin 070AJ-SJAA101 13 Torque Wrench Adapter 07406-0020401 7 A/T Oil Pressure Gauge Set with Panel (Hoses and adapters not included: requires 3) 07406-0070301 7 A/T Oil Pressure Gauge with Panel (Hoses and adapters not included: requires 1) 07736-A01000B 6 Adjustable Bearing Puller, 25-40 mm 07936-3710100 6 Remover Handle 07947-SD90101 9 Seal Driver Attachment

89-020 5 of 13 Transmission/Clutch Tools (cont’d) Tool 9 Tool Number Drawer Description Location 07947-SD90200 9 Attachment 07965-SD90100 9 Support Base 07965-SD90200 9 Support Collar 07AAB-PGHA100 N/A Camera Fixture/Tape 07AAB-PGHA110 N/A Bracket A75/A510 Canon Camera 07AAD-SJAA100 6 Driveshaft Remover 07AAD-STKA100 N/A Driver Handle 07AAD-STKA110 N/A Oil Seal Driver 07AAD-STKA120 N/A Dust Seal Driver 07AAE-P8EA000 10 Compressor 07AAE-P8EA220 N/A Clutch Adapter Set, 3.5 Engine 07AAF-P8EA000 10 Alignment Shaft 07AAF-S3VA101 9 VTM-4 Dust Seal Driver 07AAK-P8EA000 10 Clutch Plate Compressor Adapter (Intermediate piece) 07AAK-PGJA120 N/A Fluid Pump, Quarts 07AAK-PGJA220 N/A Fluid Pump, Gallons 07AAK-SNAA500 N/A Support Bolt 07AAK-SNAA600 N/A Support Eyelet 07AAK-STKA120 15 Mount Pads (2/Set) 07GAJ-PG20130 6 Mainshaft Base 07HAC-PK40102 6 Housing Puller 07HAJ-PK40201 6 Preload Inspection Tool 07JAD-PH80101 9 Driver Attachment 07JAD-SH3010A 9 Seal Driver Attachment 07JAF-PM7011A 6 Clutch Alignment Shaft 07LAB-PV00100 1 Ring Gear Holder 07LAC-PW50101 6 Extension Shaft Puller 07LAD-PW50500 9 Pinion Cover Driver Attachment 07LAD-PW50601 9 Attachment, 40 x 50 mm I.D. 07LAE-PX40100 6 Clutch Spring Compressor Attachment 07LAF-PT00110 6 Clutch Alignment Shaft 07LAF-SM40300 9 Support Base Attachment 07MAF-PR80100 6 Clutch Alignment Shaft 07MAF-PY40101 6 Extension Shaft Installer 07MAJ-PY4011A 7 A/T Pressure Hose, 2210 mm (four required) 07MAJ-PY40120 7 A/T Pressure Hose Adapter (four required) 07NAF-PR30100 6 Clutch Alignment Shaft 07RAK-TB4060A 7 A/T Pressure Adapter 07XAB-001A101 10 Flange Holder 07XAD-001000A 9 Seal Driver Attachment

6 of 13 89-020 REQUIRED SERVICE TOOLS AND EQUIPMENT In accordance with the Automobile Sales and Service Agreement, Section 3.9, your service department is required to have, at a minimum, the tools and equipment listed in this bulletin. When a new model is introduced and requires service tools, those tools may be shipped to you automatically. If you receive a required service tool and believe you have an equivalent, refer to the Acura Dealer Service Operations Manual, Section 11, for the procedure to return items. The tools and equipment in the following list can be purchased through the American Honda Tool and Equipment Program, or from outside sources. The recommended model listed for each item meets the minimum requirements for proper servicing of Acura vehicles. Refer to the American Honda Tool and Equipment Program catalog or the Interactive Network (iN) electronic catalog for equipment details and for information on other models that may be more suitable for your servicing needs. To obtain current information on pricing, product features and availability, or to order any listed tools or equipment, call the program’s client service representative at 1-888-424-6857. To order online, go to iN: Service/Service Bay/ Tool and Equipment Program/Online Catalog. Air Conditioning Service Equipment

Tool & Recommended Equipment 9 Item Minimum Specification and Note Program Model Web Site Section A/C (R-134a) Refrigerant Leak Capable of detecting a leak of 1/2 ounce or less TIFZX1 Detector* per year. A/C (R-134a) Refrigerant U.L. listed, complying to SAE J12210 (1991) ROB34788 Recovery/Recharging Station standards, 4 cfm or larger vacuum pump and measures the amount of refrigerant recovered by weight. A/C Clutch Holder ACT499A Digital Pyrometer Temperature range: -40 degrees F to 230 TEMP2A degrees F. Sensitivity: 0.1 degree. Accuracy: ±2%. Update rate: every 15 seconds. Thermistor Vacuum Gauge Capable of measuring 700 microns. ROB14777

Air, Lube, and Fuel Handling Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Oil Dispensing Unit * GRC246907 Oil Filter Drain Deflector For all 2.0 and 2.4 liter engines with steel oil pan. VSB02C000023 Deflects oil drained during filter removal into an oil catch basin. Oil Filter Drain Deflector For 2001 - 2006 MDX. Deflects oil drained VSB02C000034 during filter removal into an oil basin. Portable Gasoline Defueler/ 30 gallon: meets all local/federal government TEMFM3000GH or Refueler safety and gasoline handling requirements. TEMFM3200GA Portable Waste Oil Receptacle 16-gallon capacity AMLTM215A Portable Waste Oil Receptacle 25-gallon capacity GRC238-866 * Automatically shipped items

89-020 7 of 13 Engine Diagnostic/Electrical Test Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section AcuraLink Reprogamming Cable 2007 and later TL and MDX: Used to reprogam NUD420300HIP Adapter the AcuraLink control unit. Air/Fuel Ratio Sensor Socket S6154 Ammeter/Starting/Charging From 0 to 500 amps. OTC3131 System Tester Antifreeze Tester With temperature correction scale. OTC J23688 Battery Diagnostic Station with Will charge, test, and print out a battery warranty MTGR81100P Printer diagnostic code. Acura Battery Tester ED-18 Battery Tester. INBED18LLA, or INBED18LLAV2 Chassis Ear * JSPSM06600 Clamp Meter, Low Current Used to measure small amounts of current FLULH41A draw. Compression Gauge Adapter 12 x 1.25mm long reach EEPV306A Compression Gauge Set 0 to 300-psi with two adapters MT308M Cylinder Leak-Down Tester * EEPV309A Digital Multimeter Minimum ranges: FLU88 1 millivolt to 400 volts DC 1 millivolt to 400 volts AC 0.1 ohm to 400 megohms 0.1 milliamp to 10 amps Diode testing capability 0.5 Hz to 200 kHz frequency testing (optional) Engine Ear Electronic Listening Tool. JSPSM65001 Handheld Vacuum Pump Use to apply vacuum. YA400A Honda Diagnostic System HDS Tablet or equivalent (The package includes (HDS) a CF19 Panasonic Toughbook, a TDS35540402 GNA600H kit, and a 8-71237A computer lock cable.) Oil Pressure Adapter 1/8-inch BSPT adapter. AT77 Oil Pressure Adapter 1/8-inch BSPT adapter MT26E3 Oil Pressure Gauge From 0 to 5 kg/cm2 (0 to 71 psi). MT37A PC Interface Cable For Smart Cable and Honda Interface Module VET02002832 Portable Jump Starter Smart Starter Safety Booster Cart CAPCS-3 Propane Enrichment Device For fuel system troubleshooting. OTC7148 Radiator Cooling System Pump with gauge (0-1.2 kg/cm2, 0 to 19 psi). SVTS262B Pressure Tester Includes standard neck and cap adapters. Radiator Neck Adapters 32 mm I.D. by 10 mm depth. ASTFZ138 Stethoscope Equipped with sound-amplifying diaphragm and GA111D a 12 inch probe. Tachometer From 0 to 6,000 rpm, in increments of 20 rpm. MT2261A Timing Light Advance capacity 0 to 50 degrees. MT2261AP Vehicle Communictions Note: The Honda Interface Module (HIM) has TDS35540402 Interface GNA600 or Honda been discontinued. Interface Module (HIM) * Automatically shipped items

8 of 13 89-020 General Shop Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section A/T Cooler Cleaner * GTHTTCF6H Air Hammer (heavy duty) 2,500 blows per minute AT2050 Air Hose with Couplings 30-feet per stall ATF Leak Detection Kit Used to diagnose automatic transmission fluid UVUATFDYEKIT leaks. Bearing Separator Capacity 60 mm (0 - 2-3/8 in.) CJ950 Bearing Separator Capacity 117mm (0 - 4-5/8 in.) OTC1123 Bearing Separator Capacity, 0 to 5.75 in OTC1124 Bench Grinder 5/8 hp., 6 inch wheel diameter BADDW756 Bench Vise 5 inch jaws, 2 to 5 in. opening capacity WIL1765 Bore Gauge 35 to 80mm KD-3-1 Bore Gauge 10 to 18mm KD-3-5 Bore Gauge 18 to 35mm KD-3-6 Brake Disc Runout Joint Gauge One-inch dial indicator, 0 to 25mm range, GA3634 0.01mm graduations, includes 12-1/2-inch flex arm with special locking pliers. Bumper Saw Trailer Hitch Installation AKSK120 Cylinder Cleaning Brush 83mm diameter BCG83 Cylinder Cleaning Brush 89mm diameter BCG89 Cylinder Hone Rigid type, 100 mm (4 inch) capacity with 400 AMM500 and 600 grit honing stones. Dial Indicator From 0 to 10mm, in 0.001mm increments. KK-14-6 Dial Indicator Magnetic Stand With “on-off” switch, capable of gripping flat or KK-13-1 curved metal surfaces. Digital Camera Canon A75, Canon A510 or equivalent * Door Trim Remover Tools * ASGHONDA Drill Hand-held variable speed, air or electric, 3/8 MLW1107-6 inch. Drill Bit Selection, Fractional 1/16 to 1/2-inch DBTR129 Drill Bit Selection, Metric 1 to 13mm DBM125C Drill Bits, 8.5mm, Five-Pack Used to drill deck lid spoiler mounting holes, DBM8.5A 2009>TSX. Exhaust Overhead Drop, 3-inch diameter hose HRVTS-30 Telescopic Design Exhaust Overhead Drop, 4-inch diameter hose HRVTS-40 Telescopic Design Exhaust System “Y” Adapter One 4-ft. and one 2-ft. section, 3-inch diameter HRVH-30-3-47 Harness Exhuast System “Y” Adapter One 4-ft. and one 2-ft. section, 4-inch diameter HRVH-40-4-57 Harness Exhaust System (In-ground or One outlet per service bay, 200 cfm per outlet * overhead) Exhaust System Oval Tailpipe 3-inch by 6-1/2-inch oval (dual) tailpipe adapter HRVHF-477 Adapter Exhaust System Round Tailpipe 3-inch straight tailpipe adapter for each two HRVHF-250 Adapters service bays Exhaust System Round Tailpipe Straight tailpipe adapter, 3-inch O.D. tailpipe HRVHF-300 Adapters Exhaust System Round Tailpipe Straight tailpipe adapter, 3-1/2-inch O.D. tailpipe HRVHF-350 Adapters * Automatically shipped items

89-020 9 of 13 General Shop Equipment (cont’d)

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Exhaust System Round Tailpipe Straight tailpipe adapter, 4-inch O.D. tailpipe HRVHF-400 Adapters Extractors, 3/8 inch (Package of * BET712 five) Hole Saw Set 16mm, 19mm, 22mm, 24mm, and 26mm AKS052507 Hot Plate (Griddle) 12 by 21-inch Temp range 200x to 400x degree * F. Key Code Cutter * ILC029A Key Code Cutter Accessory Kit * INC029A-HD1 Key Code Duplicator for ILCO Silca RW2 ILCRW3A T5 Keys Key Cutter, Sidewinder End-mill type, BD Laser CUR9200011 Key Cutter, Sidewinder End-mill type, Silca Tri-Code ILCTRICODEAS Memory Saver Portable, connects to the vehicle’s data link EZRMS4000H connector (DLC). Maintains computer memory and presets while battery is removed. Micrometer 0 to 25 mm, 0.01 mm increments KK-1-1 Micrometer 25 to 50 mm, 0.01 mm increments KK-1-2 Micrometer 50 to 75 mm, 0.01 mm increments KK-1-3 Oil Filter Drain Deflector 2.0 and 2.4 engine with steel oil pan VSB02C000023 Parts Washer Recirculating type. NOTE: There is no EPA, OSHA, state, or locally approved aqueous parts cleaner at this time. Piston Ring Compressor, Capacity, 100mm (4-inch) RC40C Adjustable Pop Rivet Gun * * Puller, Harmonic Balancer * CJ119B Puller, Pilot Bearing 5/8 x 18-inch or 3/4 x16-inch CJ93B Puller, Pitman Arm 3/4 x16 x 16-7/8-inch SP2031 Puller, Steering Wheel * OTC1035 Puller, Steering Wheel 1 to 2-3/4-inch (26 to 70mm) OTC518 Puller, Steering Wheel * OTC7403 Puller, Two-Jaw 1-Ton KMTJ21834-4A Puller, Two-Jaw 2-Ton KMTJ22-88820A Ridge Reamer Minimum capacity, 100 mm (4 in.). WR30A Rivet Nut Tool 8-mm for Ridgeline running boards LEML722M8 Rubber Rollers Used to roll down and seat accessory mouldings MHLE54D Screw Extractor Selection 3 mm to 13 mm REX15B Shop Vacuum Wet/dry, heavy duty model. MNTC29085-05 Slide Hammer, 3/8 x 16-inch * KMTJ6125-1B Threaded Slide Hammer, 5/8 x 18-inch With 5-pound weight OTC1155 Threaded Slide Hammer, 5/8 x 18-inch With 2-1/2-pound weight OTC1156 Threaded Small Hole Gauge Set 6 to 8mm MROUND4 Socket 12 mm TORX FES120 Socket 34 mm IMM342 Socket 36 mm IMM362 Spring Scale 6 kg capacity, 50 g graduation SAMIN12MRP * Automatically shipped items

10 of 13 89-020 General Shop Equipment (cont’d)

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Spring Scale 2.5 kg capacity, 100 g graduation SAMIN25MRP Spring Scale 1000 g capacity, 20 g graduation SAMIN2MRP Tap and Die Selection 3 mm to 14mm TDM1117A Tap Set, Spark Plug Hole * TDM13A Thermometer 0° to 120−degrees C. (0° to 250−degrees F.) TEMP2A Torque Wrench 1/4 inch drive, 5 to 25 N-m (44 to 221 lb-in) QD1RN25 Torque Wrench 3/8 inch drive, 10 to 50 N-m (7 to 37 lb-ft) QD2RN50 Torque Wrench 1/2 inch drive, 70 to 350 N-m (52 to 258 lb-ft) QD3R350 TORX Socket 3/8 inch drive, tamper resistant, E16 FTX40E Trim Tool Set Used to remove trim without damage SILTRIMTL10 Trim Tool Set KTC tools remove trim without damage SOJATP2014 Utility Lights Fluorescent, reel-type, 25ft. cord. Alemite 7262-B Valve Guide Driver (Air Hammer 7.7 mm PHG83A Type) Valve Guide Driver (Air Hammer 9.3 mm PHG86A Type) Valve Guide Driver (Air Hammer 6.9 mm PHG96A Type) Valve Guide Driver (Air Hammer 5.2 mm PHG97A Type) Valve Seat Refacing Equipment * NWYKA1802 Valve Spring Compressor Cylinder head removed CF811B Valve Spring Compressor Cylinder head not removed. YA9140 V-Block 4-inch FFL52475015 V-Block 5-inch FFL52475020 Vernier Calipers From 0 to 150mm. CM6421

Lifting Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Automatic Transmission Case Honda-designed dolly. Created specifically for WCO210070 Dolly the transport and handling of Honda automatic transmission cases (containers). Auxiliary Under-hoist Utility Jack 1-1/2 ton capacity, minimum height 55-1/2 in., NRI81035A maximum height 81-1/2 in. Engine Balance Bar V6 engines VSB02C000019 Engine Hanger Universal, all models AART1256 Engine Hoist 3/4-ton capacity NRI81034A Engine Stand 750-lb. capacity OTC1726 Floor Jack 2-1/4-ton capacity NRI71230 Hydraulic Lift Truck 750 lb. capacity, 22 inch deep by 30-inch wide. WCOPL54-2230 Platform or fork lift capable of unloading and loading remanufactured automatic transmissions. Hydraulic Press 10-ton capacity OTC1884 Jack Stands (2) Each 3-tons capacity NRI81004C Subframe Adapter 2001 - 2006 MDX VSB02BX0 * Automatically shipped items

89-020 11 of 13 Lifting Equipment (cont’d)

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Subframe Adapter Universal, most models VSB02C000016 Transmission Adapter Bolts to the transmission and allows tipping with VSB02C000012 the transmission jack, when necessary. Transmission Jack 1/2-ton capacity, Two required NRI72500D Vehicle Lift, Above Ground Frame-contact hoist, 7,000-lb. capacity, arms ROTA10IRA must reach lift points of body, with rubber pads on the adapters to avoid underbody damage. Equipped with lift pad adapters for high ground clearance vehicles, minimum 4-inches high, maximum 5-inches high. Vehicle Lift, Above Ground Frame-contact hoist, 7,000-lb. capacity, arms ROTSPOA10RA must reach lift points of body, with rubber pads on the adapters to avoid underbody damage. Equipped with lift pad adapters for high ground clearance vehicles, minimum 4-inches high, maximum 5-inches high

Wheel, Brake, and Alignment Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Brake and Clutch Bleeder 72mm I.D. PRPBA09 Adapter Brake and Clutch Bleeder 55mm I.D. PRPBA08 Adapter Brake Bleeder, Diaphragm Type * BRNG300A Brake Disc Lathe (On-car) For resurfacing front brake rotors KWY108000501 Brake Disc Lathe Kwik Speed For most models KWY108006000 Mount Brake Disc Lathe Kwik Speed KWY108007500 Mount Brake Disc Lathe Power Drive Drives the rotor for on-car resurfacing KWY108000404 Unit Brake Drum Wear Gauge 6 in. to 15-inch range CNTCM6456A Brake Drum/Disc Lathe For rear brake discs KWY102000150 (Bench-type) Brake Pedal Holder * B240A Brake Rotor Micrometer From 0 to 25mm, in 0.001 mm increments FFL74815001 McPherson Strut Spring * BRN7400 Compressor * Automatically shipped items

12 of 13 89-020 Wheel, Brake, and Alignment Equipment (cont’d)

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Michelin PAX System PAX system certified Corghi PSR (PAX Support Ring Extractor System Support Ring) Portable Extractor (MCDH11100079) or PAX System Orbiter Workstation (HUN2017931) Michelin PAX System Wheel 2005 RL with Tech Package KWY590005000 Alignment Adapter Set Tire Changer Equipped with PAX System certified upgrade to Corghi Artigliomaster - service PAX System. Capable of servicing AM26 (MCDHAM26) high-performance and standard tires & wheels. with PAX System Upgrade Kit (MCDH260860A) or Hunter TC3600 with PAX System Upgrade Kit (HUNTC3510EPX) Tire Pressure Gauge 0 to 35 kg-cm2 (0 to 50 psi) YA206 Tire Tread Depth Indicator 0 to 5/16 in.: increments of 1/32 inch GA599 Wheel Alignment Rack Full four-wheel alignment capability, four HUNRX9 full-floating turning radius tables, or full-floating turning radius tables for the front and full-floating slip plates for the rear Wheel Alignment System Full four-wheel alignment capability (reading 0 +/ HUNWA141 - 1 degree). Wheel Alignment System * HUNHS401FC Sensor Wheel Balancer, Dynamic, Off- Reads in grams, 1-gram in-balance HUNDSP9602D, Car HUNDSP9602DW or HUNGSP971217

Work Stall Equipment

Tool & Recommended Equipment 9 Item Minimum Specification/Note Program Model Web Site Section Flammables Storage Cabinet 65 inch high by 43 inches wide by 18 inches HMNH25450 or deep, with self-closing doors. Complies with HMNH25452 local and federal government regulations. More than one cabinet may be needed, depending on the quantity of chemicals to be stored. Oil Rag Waste Cans * * Special Tool Storage and The Stanley Vidmar tool storage cabinet system STNACURA01, Inventory System is the only special tool storage system supported STNACURA02, by America Honda. STNACURA03, STNACURA04, STNACURA05 Workbench Minimum one per stall or one per technician SHU811001 * Automatically shipped items

89-020 13 of 13
