ENIGMA X Aka SPARKLE Enclosure Manual Ver 7 012017

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
ENIGMA X Aka SPARKLE Enclosure Manual Ver 7 012017 ENIGMA-X / SPARKLE* ENCLOSURE SHOWER ENCLOSURE INSTALLATION INSTRUCTIONS IMPORTANT DreamLine® reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals, warranty information or additional details please refer to your model’s web page on DreamLine.com MODEL #s MODEL #s SHEN-6134480-## SHEN-6134720-## SHEN-6134600-## ##=finish *The SPARKLE model name designates an option with MirrorMax patterned glass. 07- Brushed Stainless Steel The installation is identical to the Enigma-X. 08- Polished Stainless Steel Right Hand Return panel installation shown 18- Tuxedo For more information about DreamLine® Shower Doors & Tub Doors please visit DreamLine.com ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 This model is treated with DreamLine’s exclusive ClearMaxTM Glass technology. This is a specially formulated coating that prevents the build up of soap and water spots. Install the surface with the ClearMaxTM label towards the inside of the shower. Please note that depending on the model, the glass may be coated on either one or both surfaces. For best results, squeegee the glass after each use and dry with a soft cloth. ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 2 B B A A C ! E IMPORTANT INFORMATION REGARDING THE INSTALLATION OF THIS SHOWER DOOR D PANEL DOOR F Right hand door installation shown as an example A Guide Rail Brackets must be firmly D Roller Guards must be postioned and attached to the wall. Installation into a secured within 1/16” of Upper Guide Rail. stud is strongly recommended. Apply thread lock. All of the guide rail bracket set screws must be tightened. E Bumper Vinyl Seal must be installed on the closing edge of the door glass B Thread Lock must be applied to both stopper set screws. F The Guide Block must be screwed to the Panel-side stopper must be installed threshold and installed square to the panel into the pre-drilled stopper hole in glass and door glass. Installing the guide the upper guide rail. block crooked may damage the bottom edge Door-side stopper must be installed of the door glass and lead to breakage. at the proper position to stop the door from contacting the wall. PLEASE READ THE ENCLOSED INSTALLATION MANUAL FOR DETAILS REGARDING PROPER INSTALLATION. C Roller Wheel Safety Set Screws must be re-tightened after installation. THE LATEST VERSION OF THE INSTALLATION Apply Thread lock. MANUAL IS AVAILABLE TO VIEW OR PRINT ON DREAMLINE.COM ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 3 Reinforcement for Enigma Series Heavy Glass frameless sliding shower door Install studs OR install 2”x 6” wood blocking between the studs where the Guide Rail Brackets will attach to the wall 2” X 6” Stud or 2” X 6” measured from threshold* (see list below) threshold or tub deck *Blocking height requirement (to center) as measured from threshold or tub deck: threshold Enigma Air = 73” for shower ht / 59” for tub ht or tub deck Enigma X = 72-1/2“ for shower ht / 58-1/2” for tub ht Enigma Z = 73-1/2” for shower ht / 59-1/2“ for tub ht Enigma = 75-1/2” for shower ht only ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 4 Preparation 1. After opening all boxes and packages, read this introduction carefully. Check that all of the needed parts are included in the package by marking all the components on the “Detailed Diagram of Shower Door Components”. Examine boxes and packages for shipping damage. If the unit has been damaged, has a finishing defect, or has missing parts, please contact our customer support department within 3 business days of the delivery date. Please note that DreamLine® will not replace any damaged products or missing parts free of charge after 3 business days or if the product has been installed. Please contact DreamLine® if you have any questions. 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine® is not responsible for code compliance standards for your project and will not accept any returns. 3. If this unit is going to be installed in a new construction, install all of the required plumbing and drainage before installing the shower. Use a competent and licensed (if required by local code) plumber for all plumbing installation. 4. Please make sure that prior to beginning the installation, the surfaces are leveled and solid and will be able to support the total weight of the unit. Also make sure the walls are at right angles. Irregular installation surface level, radius corners or improper angle of side walls will result in serious problems for your installation. Please note that some adjustments and drilling might be necessary during the installation process. 5. Please protect all primary surfaces of the product during installation. Never set your glass down directly onto a tile floor. Leave corner protectors in place until necessary to remove them. Always use a piece of wood or cardboard to protect the bottom edge and corners of the glass prior to and during installation. 6. This unit must be installed upon a finished threshold and against finished walls. 7. NOTE! This door does not have out-of-plumb adjustment. Make sure your walls are at right angles. 8. This door requires a minimum 2-3/4”of flat threshold space for installation. 9. Note: The installation of this unit requires that you drill down into the threshold. 10. Please note that Step #16 has an option for installing the guide rail brackets to the wall using anchors. However, the manufacturer strongly recommends installing these heavy doors to the studs or to pre-installed 2”x 6” wood reinforcements behind the wall in the area where the guide rail brackets will be attached to the wall. Attention: This door is extremely heavy and requires professional installation. ! Two installers recommended. Do Not hang or drape a towel or wash cloth over the Enigma series guide rail as this ! may cause the roller wheels to get stuck and possibly cause serious damage or injury. NOTE: The Enigma Series doors and enclosures are reversible for left or right hand installation. This manual will show the right hand door installation. For a left hand installation, simply begin on the opposite wall and reverse the orientation of the parts as necessary. ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 5 Tools Level Tape Phillips Measure Pencil Power Screwdriver Silicone Drill Drill bit Drill bit Drill bit Drill bit (Ø=1/8") (Ø=1/4") (Ø=5/16") (Ø=3/8") (3mm) (6mm) (8mm) (10mm) Hammer Chop saw and Hacksaw Painter’s Tape Razor Knife Tip: Measure the finished opening before proceeding with the installation to be sure that the correct model size has been ordered. Be sure to cover the shower drain to prevent losing small parts. NOTE: Unpack your unit carefully and inspect it. Lay it out and identify all parts using the detailed diagram and packing list in this manual as a reference. Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine® for replacement. The shipping boxes may contain extra parts not used in your model configuration. NOTE: Retain these installation instructions for future reference. ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 6 Detailed Diagram of shower door components 7 MODEL #s SHEN-6134480-## 8 SHEN-6134600-## 1 9 ##=finish 07- Brushed Stainless Steel 10 2 4 08- Polished Stainless Steel 3 11 28 12 13 5 14 27 6 15 16 The glass surface with the ClearMax™ 17 label must be installed facing the 18 inside of the shower 19 20 26 Parts List ITEM # DESCRIPTION QTY ITEM # DESCRIPTION QTY 01 Door stopper 2PCS 12 Guide block(with caps) 1PC 02 Stationary glass 1PC 13 Bumper strip** 1PC 03 Upper guide rail 1PC 14 Anti-water strip 2PCS 04 Roller 2PCS 15 Anti-splash Guard 1PC 05 Door glass 1PC 16 Anti-splash Guard cap** 1PCS 06 Handle 1PC 17 ST4.2×40 Countersunk screw 2PCS 07 Glass bracket 2PCS 18 ST4.2×55 Truss Head screw 3PC 08 Guide rail bracket 2PCS 19 Wall bracket 4PCS 09a Wall anchoØr 3/8"(10mm) 1PCS 20 Roller guard 2PCS 09b Wall anchor Ø5/16"(8mm) 3PCS 26 Thread Lock adhesive 1PC 10 Large Truss Head Screw ST6×65 1PCS 27 Return panel glass 1PC 11 Allen Wrench 3, 4, 5mm 1set 28 Glass connector 1PC ** not used with the 72” configuration ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 7 Detailed Diagram of shower door components 7 MODEL #s SHEN-6134720-## 8 1 ##=finish 9 2 07- Brushed Stainless Steel 08- Polished Stainless Steel 4 10 3 11 5 21 28 12 13* 14 6 27 15 17 The glass surface with the ClearMax™ 18 label must be installed facing the 19 inside of the shower 20 26 22 23 Parts List ITEM # DESCRIPTION QTY ITEM # DESCRIPTION QTY 01 Door stopper 2PCS 14 Anti-water strip 3PC 02 Stationary glass 1PC 15 Anti-splash guard 1PC 03 Upper guide rail 1PC 16 Anti-splash guard cap** 1PCS 04 Roller 2PCS 17 ST4.2×40 Countersunk screw 4PCS 05 Glass door 1PC 18 ST4.2×55 Truss Head screw 3PC 06 Handle 1PC 19 Wall bracket 5PC 07 Glass bracket 2PCS 20 Roller guard 2PCS 08 Guide rail bracket 2PCS 21 Small stationary glass bracket 1PC 09a Wall anchor Ø 3/8"(10mm) 1PCS 22 Small stationary glass bottom bracket 1PC 09b Wall anchor Ø 5/16"(8mm) 3PCS 23 Small stationary glass 1PC 10 Large Truss Head Screw ST6×65 1PCS 26 Thread Lock Adhesive 1PC 11 Allen Wrench 3, 4, 5mm 1set 27 Return panel glass 1PC 12 Guide block(with caps) 1PC 28 Glass Connector 1PC 13 Bumper strip* (not used with 72” model) 1PC ** not used with the 72” configuration ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 8 SHOWER ENCLOSURE PLAN 34 1/2" 2-3/4” minimum threshold required 44-3/8 “ min to 48-3/8” max 34 1/2" 2-3/4” minimum threshold required 56-3/8” min to 60-3/8” max ENIGMA-X / SPARKLE Enclosure manual Ver 7 01/2017 9 SHOWER ENCLOSURE PLAN 34 1/2" 2-3/4” minimum threshold required 68-3/8” min - 72-3/8" max This shower enclosure requires a minimum 2-3/4” wide threshold for installation.
