Service Bulletin

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
Service Bulletin ATTENTION: IMPORTANT - All GENERAL MANAGER q Service Personnel PARTS MANAGER q Should Read and CLAIMS PERSONNEL q Initial in the boxes SERVICE MANAGER q provided, right. SERVICE BULLETIN APPLICABILITY: 2014MY Subaru Vehicles NUMBER: 13-96-13R SUBJECT: 2014 MY Paint Coding Information DATE: 05/20/13 REVISED: 07/09/13 INTRODUCTION Note: This is the most accurate information available at the time of printing. Various paint manufacturers designate their own stock numbers and coding information although many of the major suppliers are now using the SOA paint codes to help eliminate possible confusion. Their color formulations are updated on a continual basis. Some vendors may have different color names than those provided to them by SOA. Be sure to double-check the codes and formulas beforehand to help insure an accurate color match. Should discrepancies arise, please refer your Body Shop contact inquiries to the specific paint vendor or their jobber / supplier for the most updated formula information. The paint coding information can be found on the vehicle’s VIN plate. Subaru color codes are three characters in length. For the 2014 Model Year, Subaru of America is announcing seven new colors: • K6U Carbide Gray • JV9 Carbide Gray (Code for Tribeca only) • K7U Tungsten Metallic • J8U Quartz Blue Pearl • H5Q Jasmine Green • J9U Plasma Green • H4Q Burnished Bronze • H3Q Deep Sea Pearl Along with these new colors, an all-new XV Crosstrek Hybrid is being introduced to our line-up for 2014. The XV Crosstrek Hybrid is expected to arrive in Dealer showrooms in the near future. This color information covers all current and the new models. Continued... CAUTION: VEHICLE SERVICING PERFORMED BY UNTRAINED PERSONS COULD SUBARU OF AMERICA, INC. IS RESULT IN SERIOUS INJURY TO THOSE PERSONS OR TO OTHERS. “ISO 14001 COMPLIANT” Subaru Service Bulletins are intended for use by professional technicians ONLY. They The international standard for excellence are written to inform those technicians of conditions that may occur in some vehicles, or in Environmental Management Systems. to provide information that could assist in the proper servicing of the vehicle. Properly Please recycle or dispose of automotive trained technicians have the equipment, tools, safety instructions, and know-how products in a manner that is friendly to our to do the job correctly and safely. If a condition is described, DO NOT assume that this environment and in accordance with all Service Bulletin applies to your vehicle, or that your vehicle will have that condition. local, state and federal laws and regulations. Bulletin Number: 13-96-13R; Date: 07/09/13 Page 1 2014 FORESTER PAINT CODES EXTERIOR PAINT COLOR PAINT CODE Jasmine Green* H5Q Burnished Bronze* H4Q Marine Blue Pearl F9H Crystal Black Silica D4S Dark Gray Metallic 61K Satin White Pearl 37J Ice Silver Metallic G1U Venetian Red Pearl H2Q * Indicates new color 2014 IMPREZA, IMPREZA SPORT, WRX & STI PAINT CODES EXTERIOR PAINT COLOR PAINT CODE Quartz Blue Pearl* J8U Jasmine Green* H5Q Deep Sea Blue Pearl* H3Q Satin White Pearl 37J Dark Gray Metallic 61K WR Blue Pearl 02C Plasma Blue Silica F9T Crystal Black Silica D4S Ice Silver Metallic G1U Venetian Red Pearl H2Q * Indicates new color Bulletin Number: 13-96-13R; Date: 07/09/13 Page 2 2014 LEGACY & OUTBACK PAINT CODES EXTERIOR PAINT COLOR PAINT CODE Carbide Gray* K6U Tungsten Metallic* K7U Cypress Green Pearl F4T Crystal Black Silica D4S Satin White Pearl 37J Deep Indigo Pearl G5U Ice Silver Metallic G1U Twighlight Blue Metallic H1Q Venetian Red Pearl H2Q * Indicates new color 2014 TRIBECA PAINT CODES EXTERIOR PAINT COLOR PAINT CODE Carbide Gray* JV9 Crystal Black Silica EH3 Satin White Pearl EH6 Ice Silver Metallic GE2 Deep Indigo Pearl GE8 Venetian Red Pearl** H2Q * Indicates new color ** Note: For HZ9 refer to H2Q Paint Code. They are the same color (Tribeca only) *** Note: JV9 Carbide Gray (Code for Tribeca only). ****Note: On some Tribeca models there are unpainted “natural” lower body plastic cladding panels applied. Bulletin Number: 13-96-13R; Date: 07/09/13 Page 3 2014 XV CROSSTREK PAINT CODES EXTERIOR PAINT COLOR PAINT CODE Plasma Green* J9U Quartz Blue Pearl* J8U Crystal Black Silica D4S Dark Gray Metallic 61K Satin White Pearl 37J Ice Silver Metallic G1U Venetian Red Pearl H2Q Tangerine Orange Pearl G2U Desert Khaki H6Q * Indicates new color 2014 BRZ PAINT CODES EXTERIOR PAINT COLOR PAINT CODE WR Blue Pearl 02C Crystal Black Silica D4S Dark Gray Metallic 61K Lightning Red C7P Satin White Pearl 37J Sterling Silver Metallic D6S Bulletin Number: 13-96-13R; Date: 07/09/13 Page 4 Bulletin Number:13-96-13R; Date:07/09/13 2014 FORESTER PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR H5Q Jasmine Green* H5Q H5Q 932847 H5Q H5Q SUBH5Q H5Q H4Q Burnished Bronze* H4Q H4Q 932846 H4Q H4Q SUBH4Q H4Q F9H Marine Blue Pearl F9H F9H 927475 F9H F9H SUBF9H F9H D4S Crystal Black Silica D4S D4S 924868 D4S D4S SUB9407 D4S 61K Dark Gray Metallic 61K 61K 914602 61K 61K SUB9706 61K 37J Satin White Pearl 37J 37J 907371 37J 37J SUB9830 37J G1U Ice Silver Metallic G1U G1U 930642 G1U G1U SUBG1U G1U H2Q Venetian Red Pearl H2Q H2Q 932844 H2Q H2Q SUBH2Q H2Q * New Color Page 5 Bulletin Number:13-96-13R; Date:07/09/13 2014 IMPREZA, IMPREZA SPORT, WRX & STI PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR J8U Quartz Blue Pearl* J8U J8U 935050 J8U J8U SUBJ8U J8U H5Q Jasmine Green* H5Q H5Q 932847 H5Q H5Q SUBH5Q H5Q H3Q Deep Sea Blue Pearl* H3Q H3Q 932845 H3Q H3Q SUBH3Q H3Q 37J Satin White Pearl 37J 37J 907371 37J 37J SUB9830 37J 61K Dark Gray Metallic 61K 61K 914602 61K 61K SUB9706 61K 02C WR Blue Pearl 02C 02C 194512 02C 02C SUB9105 02C F9T Plasma Blue Silica F9T F9T 927474 F9T F9T SUBF9T F9T D4S Crystal Black Silica D4S D4S 924868 D4S D4S SUB9407 D4S G1U Ice Silver Metallic G1U G1U 930642 G1U G1U SUBG1U G1U H2Q Venetian Red Pearl H2Q H2Q 932844 H2Q H2Q SUBH2Q H2Q * New Color Page 6 Bulletin Number:13-96-13R; Date:07/09/13 2014 LEGACY & OUTBACK PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR K6U Carbide Gray* K6U K6U 936685 K6U K6U SUBK6U K6U K7U Tungsten Metallic* K7U K7U 935607 K7U K7U SUBK7U K7U F4T Cypress Green Pearl F4T F4T 924884 F4T F4T SUBF4T F4T D4S Crystal Black Silica D4S D4S 924868 D4S D4S SUB9407 D4S 37J Satin White Pearl 37J 37J 907371 37J 37J SUB9830 37J G5U Deep Indigo Pearl G5U G5U 931694 G5U G5U SUBG5U G5U G1U Ice Silver Metallic G1U G1U 930642 G1U G1U SUBG1U G1U H1Q Twighlight Blue Metallic H1Q H1Q 933752 H1Q H1Q SUBH1Q H1Q H2Q Venetian Red Pearl H2Q H2Q 932844 H2Q H2Q SUBH2Q H2Q *New Color Page 7 Bulletin Number:13-96-13R; Date:07/09/13 2014 TRIBECA PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR JV9 Carbide Gray* JV9 JV9 936685 JV9 JV9 SUBJV9 JV9 EH3 Crystal Black Silica EH3 EH3 924868 EH3 EH3 SUB9407 EH3 EH6 Satin White Pearl EH6 EH6 907371 EH6 EH6 SUB9830 EH6 GE2 Ice Silver Metallic GE2 GE2 930642 GE2 GE2 SUBG1U GE2 GE8 Deep Indigo Pearl GE8 GE8 931694 GE8 GE8 SUBG5U GE8 HZ9 Venetian Red Pearl** H2Q H2Q 932844 H2Q H2Q SUBH2Q H2Q *New Color ** Note: For HZ9 refer to H2Q Paint Code. They are the same color (Tribeca only) *** Note: Carbide Gray Paint Code is JV9 (Tribeca only) Page 8 Bulletin Number:13-96-13R; Date:07/09/13 2014 XV CROSSTREK PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR J9U Plasma Green* J9U J9U 935051 J9U J9U SUBJ9U J9U J8U Quartz Blue Pearl* J8U J8U 935050 J8U J8U SUBJ8U J8U D4S Crystal Black Silica D4S D4S 924868 D4S D4S SUB9407 D4S 61K Dark Gray Metallic 61K 61K 914602 61K 61K SUB9706 61K 37J Satin White Pearl 37J 37J 907371 37J 37J SUB9830 37J G1U Ice Silver Metallic G1U G1U 930642 G1U G1U SUBG1U G1U H2Q Venetian Red Pearl H2Q H2Q 932844 H2Q H2Q SUBH2Q H2Q G2U Tangerine Orange Pearl G2U G2U 931556 G2U G2U SUBG2U G2U H6Q Desert Khaki H6Q H6Q 932848 H6Q H6Q SUBH6Q H6Q *New Color Page 9 Bulletin Number:13-96-13R; Date:07/09/13 2014 BRZ PAINT CODES SHERWIN- WILLIAMS/ SPIES- BASF-R/M AKZO CODE COLOR NAME DUPONT PPG STANDOX MARTIN HECKER GLASURIT NOBEL SENOUR 02C WR Blue Pearl 02C 02C 194512 02C 02C SUB9105 02C D4S Crystal Black Silica D4S D4S 924868 D4S D4S SUB9407 D4S 61K Dark Gray Metallic 61K 61K 914602 61K 61K SUB9706 61K C7P Lightning Red C7P C7P 917270 C7P C7P SUB3011 C7P 37J Satin White Pearl 37J 37J 907371 37J 37J SUB9830 37J D6S Sterling Silver Metallic D6S D6S 922537 D6S D6S SUB9712 D6S *New Color Page 10.
