1
The Compressibility of Liquids and Tait’s Equation-of-State
Peter Tait’s high pressure cell (source: Scientific report of the H.M.S. Challenger, narrative II, 1882)
From Deep Sea to Laboratory 3: From Tait's Work on the Compressibility of Seawater to Equations-of-State for Liquids, First Edition. Frédéric Aitken and Jean-Numa Foulc. © ISTE Ltd 2019. Published by ISTE Ltd and John Wiley & Sons, Inc. 2 From Deep Sea to Laboratory 3
1.1. Introduction
The temperature-measuring devices used by H.M.S. Challenger scientists have been presented in Volume 2. As pointed out, the high pressures in the seabed caused disruptions and led to errors in temperature measurements. After the return of the expedition, at the request of C.W. Thomson (scientific leader of the Challenger expedition), Peter Tait examined the conditions of use of the devices and carried out a detailed study to evaluate the temperature measurement errors due to the contraction of the solid and liquid components of the thermometers. It is on the basis of this particular study that we develop and present more general notions concerning the measurement of high pressures, the compressibility of liquids and the equations- of-state, with a particular focus on Tait’s equation-of-state in Volume 3. But first, let us look at a practical application using pressure measurement.
Challenger sailors found that ocean depth measurement using a sampling line was not always highly reliable, especially at great depths (see Volume 1, Section 4.4.3). The idea of using a pressure measurement to determine depth therefore appeared to be a relevant alternative. Indeed, a quasi-proportionality relationship exists between these two quantities:
P*()z z = [1.1] ρ × e ()P g
* zP )( P* = 0)0( where denotes the pressure gradient of the water, at depth z (with ), += * P is the absolute pressure ( a , PPPP a being the atmospheric pressure at the ρ () sea surface), g is the gravity field and e P is the density of the seawater.
ρ Knowing that the compressibility of seawater is relatively low (at 200 atm, e ρρ≅= decreases by less than 1%), we can consider that ee()P Const and that the relationship [1.1] becomes:
Pz*() zKPz≅=×*() [1.2] ρ × e g
The depth is therefore almost proportional to the pressure, with K ≅10 m atm-1 .
To measure pressure, an instrument capable of recording the contraction of a fluid or solid material subjected to pressure must be used. This, of course,
The Compressibility of Liquids and Tait’s Equation-of-State 3 presupposes that the response of the stressed material (dependence of its density or relative contraction as a function of the applied pressure) is known. A good knowledge of the compressibility of the materials used to manufacture pressure- (and temperature-) measuring instruments is therefore essential. In Volume 2, section 1.3, we have seen how the contraction of materials (glass, ebonite) affects temperature measurement errors. Peter Guthrie Tait’s work has thus made it possible to better understand the impact of pressure on the reading of Miller-Casella thermometers. In doing so, Tait also realized, on the one hand, that his predecessors’ results on low-pressure fresh water compressibility were very scattered and, on the other hand, that the study of salt solution compressibility was practically non-existent. The study of fresh water compressibility was therefore absolutely necessary because this liquid was widely used in piezometers and the study of the compressibility of salt solutions was also essential to be able to deduce with precision the depth of the sea from a pressure measurement.
Tait’s work after the Challenger’s return allowed him to further develop more general theoretical and experimental studies in the field of fresh water and saline compressibility, the effect of pressure on the maximum density of fresh water, and equations-of-state for liquids. In this chapter, we begin by describing Tait’s approach that led him to write his famous equation-of-state1. This relationship contains two parameters that change with temperature. In Chapter 2, we continue by comparing Tait’s equation with the equations-of-state of the same period by discussing parameter interpretations. This analysis is extended in Chapter 3 by applications to a few specific fluids that will provide us with the various parameter evolutions. Chapter 4 deals with the adiabatic compressibility module, which allows for modeling supercritical states up to very high pressures.
1.2. Concepts of compressibility
Compressibility is a general property of a material that causes anything to reduce its volume under the effect of pressure. This property is characterized by coefficients that can be different depending on the material concerned (gas, liquid or solid). In the case of a liquid (usually a state of matter that cannot withstand static shear stress without flow), the only modulus that can be defined is its modulus of elasticity in volume κ, also called the tangent modulus in volume.
1 If a phase of a system is transformed so that its intensive (density, temperature, etc.) and extensive (mass, volume, etc.) state parameters vary continuously, only some of them can be chosen arbitrarily. The others are functions of these arbitrary parameters. These relationships constitute the equations-of-state of the considered phase. 4 From Deep Sea to Laboratory 3
A specific volume V of liquid that is subjected to a hydrostatic pressure variation −=Δ PPP 0 (P is the applied pressure and P0 the reference pressure) undergoes a volume decrease equal to ΔV; its deformation in volume is: -ΔV/V. The modulus of elasticity in volume is then, by definition:
ΔP dP κ ≡−=−lim VV [1.3] Δ→P 0 ΔVdV
The reference pressure P0 is often taken as 1 atmosphere. In practice, since the pressures applied to measure the compressibility of liquids are much higher than 1 atm, the pressure variation is considered to be equal to the pressure applied (i.e. P =Δ P ).
The value of the module κ depends on the speed at which pressure variations occur. If the pressure is applied slowly, the liquid will remain at a constant κ temperature and, under these conditions, we will have an isothermal module T. If the pressure variations are so rapid that there can be practically no heat exchange κ between the liquid and its environment, then we will have an adiabatic module S.
The isothermal KT and adiabatic KS compressibilities are defined respectively as the inverse of the isothermal and adiabatic moduli of elasticity:
1 ∂V 1 ∂V K ≡− and K ≡− [1.4] T ∂ S ∂ VPT VPS
Thermodynamic relationships show that adiabatic compressibility is related to the celerity of sound c by the relationship:
= ρ 2 KcS 1 [1.5] and that the isothermal compressibility can be deduced from the adiabatic compressibility and other thermoelastic coefficients using the following equality:
β 2 =+T VT KKTS [1.6] CP
β where T is the coefficient of isobaric thermal expansion and CP is the heating capacity at constant pressure of the fluid. The Compressibility of Liquids and Tait’s Equation-of-State 5
The effect of liquid compressibility occurs in many processes such as the development of products under high pressure, the generation of shock waves, etc. In the electrical industry, the study of the behavior of insulating liquids subjected to very high voltages shows the appearance of streamers (channels of ionized vapor) leading to liquid breakdown (cover page illustration, Chapter 4). The propagation rate of these streamers is partly related to the compressibility properties of the medium (gas and liquid phases)2.
The first experimental studies of liquid compressibility encountered two major difficulties: the implementation of cells resistant to high pressures and the measurement of pressures within these same cells. As was done in Volume 2 on temperature measurement, we present below a brief history of the evolution of liquid compressibility measurement techniques3.
1.3. The first instruments to measure the compressibility of liquids
Until the 17th Century, it was accepted by physicists that gases and solids were compressible. For liquids, the answer was less clear-cut, but the most widespread opinion was that liquids were incompressible4. From then on, physicists were keen on carrying out experiments to determine with certainty whether or not liquids were compressible. – In his book Novum Organum, which was published in 1620 and which proposes a new approach to science, Francis Bacon5 addressed various subjects dealing with the laws of nature and, in particular, that of the contraction and
2 This type of study is carried out in particular at the Grenoble Electrical Engineering Laboratory (UMR 5269/INP Grenoble-UGA-CNRS), in the Dielectric and Electrostatic Materials team to which the authors of the book are attached. 3 Other contributions from researchers, not presented here, are referenced in the bibliography. 4 The reference to the particular structure of water, which at the time seemed different from that of gases and solids, argued in favor of its incompressibility, as suggested by Huygens C. (1666–1695), Œuvres complètes, vol. 19, Mécanique théorique et physique, Martinus Nijhoff, 1937 and The Hague, Perrault, Du ressort et de la dureté des corps. Essais de physique, vol. 1, pp. 51–57, Imprimeur Jean-Baptiste Coignard, Paris, 1680. 5 English philosopher, scientist and politician, born on January 22, 1561, in Strand near London, and died on April 9, 1626, in Highgate (London). Francis Bacon was a precocious child with a great vivacity of mind. At the age of 12, he began his studies at Cambridge University and at 16, he wrote a book to mark his opposition to Aristotle’s philosophy based on the supremacy of theory over experience. F. Bacon held eminent political responsibilities in England before becoming Grand Chancellor. He is also considered the father of “modern empiricism”, a philosophical theory based on the acquisition of knowledge from experience and the discovery of the laws of nature. Biographical note and account of the experience of crushed balls in Lorquet A., Novum Organum, new translation, Librairie de L. Hachette et Cie, Paris, 1857. 6 From Deep Sea to Laboratory 3 expansion of the bodies. On that occasion, he described an experiment, in which he participated, to assess the compressibility of water. He had a hollow lead globe prepared, with a thick wall and a volume of about 1 liter, which he filled with water before blocking the filling opening with molten lead. The globe was then heavily struck with a large hammer and placed under a press to reduce its volume and compress the water it contained. The water eventually escaped through the wall of the globe in the form of a fine dew. The calculation of the inner volume of the globe at the end of the experiment made it possible to estimate the water’s tensile strength, but not its compressibility because the pressure applied was not known. The conclusion drawn from this experiment was that water was extremely weak and difficult to compress. – Approximately 1660, members of the Accademia del Cimento6 embarked on the study of water compression. Three experiments were undertaken. The first two, only qualitative (expansion and compression of the water by thermal effect; experiment of balls filled with water and struck by a hammer, see representative illustration of the book), brought no new results. The third experiment, although it did not produce a convincing result either, nevertheless had the merit of presenting complete equipment capable of measuring compressibility. This device (see Figure 1.1a) consists of an AB glass container about 70 cm high and 8 cm in diameter, with a side outlet (CH nozzle) and an open EF crystal tube about 2 m high and 1.5 cm in diameter, welded to the top of the A container and whose lower part does not touch the bottom of the container.
In the experiment, water is poured into the container to CD height, then mercury is added to the tube until the water pushed by the mercury completely fills the container and the nozzle, and finally the hole H is closed with a flame. After determining the altitude A0 at which the mercury level was positioned, additional mercury is introduced into the tube up to the maximum altitude AM (point E). Under mercury pressure, the water contracts and rises to a value A E (dotted line in Figure 1.1b).
Finally, the observers failed to detect any contraction of the water and concluded that its compressibility could not be made sensitive by the experiment.
6 The Accademia del Cimento (Florentine Academy), Europe’s first scientific society, was founded in 1657, by Leopold and Ferdinand II de Médicis. This academy, which remained active for about 10 years, undertook a vast program of experimentation of physical and astronomical phenomena (thermometry, areometry, hydrostatics, etc.). It is in this context that work on compressibility and fluid density was carried out and published in Saggi di naturali esperienze fatte dall’ Academia del Cimento (Firenze): “Esperienze intorno alla compressione dell acqua”, pp. 197–205, Florence, 1667. The Compressibility of Liquids and Tait’s Equation-of-State 7
(a) (b)
hM
hE
Water Mercury F ΔhE
Figure 1.1. Compressibility measuring instrument of the Accademia del Cimento. (a) Original instrument; (b) schematic view of the instrument defining the quantities to be measured for the calculation of compressibility (source: from “Esperienze intorno alla compressione dell acqua”, 1667). For a color version of this figure, see www.iste.co.uk/aitken/deepsea3.zip
Let us analyze this experiment more closely, taking into account current knowledge. By denoting PM as the pressure exerted in the tube by mercury, PE the pressure exerted on the water in the container, h M the height of the mercury Δ column in the tube and hE the difference in water level in the container caused by PE , we get: = ρ ρ 1) PgMMM h; M , mercury density; g, acceleration of gravity, = = hAAMM0- ; PEMP ; 8 From Deep Sea to Laboratory 3
Δ= = 2) hAAhKPEE0EE– T ; K T , isothermal compressibility coefficient of water.
= = ρ =×33= 2 By taking: h.M 185 m; h.E 059 m; M 13. 5 10 kg/m ; g 10 m/s and =×−4-1 K.T 045 10 atm , we obtain:
≅ Δ ≅ P.M 25 atm; hE 70 μm
It can therefore be seen that, in this experiment, the contraction of water remains low. Nevertheless, for experimenters at the time, trained to detect very small variations in mercury levels, it can be assumed that an amplitude deviation of 70 µm could have been detected.
NOTE.– The device described above is most probably the first complete instrument for measuring the compressibility of a liquid, the principle of which was adopted a century and a half later by Œrsted.
Other experiments, using a metal container filled with water, clogged, and then compressed, were carried out during the 18th Century, but the only one that seems to prove that water is compressible is that of Robert Boyle who, having pierced the container with a needle after its compression, found that a jet of water was coming out with force7. – It was not until 1761 and John Canton’s8 experiments that the compressibility of liquids was proven [CAN 62, CAN 64]. In his first approaches, J. Canton appropriately used a thermometer to evaluate the contraction of water following a pressure increase.
7 Boyle R., Nova Experimenta Physico-Mechanica, Experiment XX, pp. 122–126, Pofttema ed. 1669. 8 John Canton was an English physicist born on July 13, 1718, in Stroud, and died on March 22, 1772, in London. At the age of 9, his father withdrew him from school believing that he knew enough to become an apprentice weaver. But not giving up his irresistible desire to learn, J. Canton educated himself and was favorably noticed by his entourage, in particular by Henry Miles, pastor, scientist and future member of the Royal Society. When Canton reached the age of 18, Miles finally convinced Canton’s father to let his son go to London so that he could study. Shortly afterwards, Canton became a school assistant teacher and Miles introduced J. Canton to the London scientific community. In 1744, J. Canton married Penelope Colebrooke, from a wealthy family of bankers who opened the doors of high society to him. During his career, J. Canton undertook scientific work in electrostatics, magnetism and chemistry, and studied the properties of liquids (water compressibility). In 1749, he was elected a member of the Royal Society of London, which twice awarded him the Copley Medal for his work on magnet making and water compressibility. Biographical note in Herbert K.B.H. John Canton FRS (1718–72), Physics Education, vol. 33, No. 2, pp. 126–131, 1998. The Compressibility of Liquids and Tait’s Equation-of-State 9
Portrait 1.1. John Canton (1718–1772). English physicist (© National Portrait Gallery, London)
The instrument (see Figure 1.2) consisted of a spherical tank at its base and a long vertical capillary tube of inner section S, graduated from bottom to top and open at its end. The principle of measuring the relative contraction of water Δ VV )/( at a given temperature T and pressure variation ΔP is as follows:
i) the instrument at temperature T is partially filled with water (total volume V ) under atmospheric pressure. The height of the water in the capillary indicates a value h0; ii) the tank is heated until the capillary is completely filled (the heated water has expanded) and then the end of the tube is welded; iii) the heating is switched off and we wait for the instrument to return to its initial temperature T. The height of the water in the capillary then indicates a value −=Δ h1 . Since the water is now subjected to zero pressure, we obtain: V 01 )( Shh for P =Δ 1 atm .
With this instrument, J. Canton measured the compressibility of different liquids (rainwater, seawater, mercury, liquors, etc.) at different temperatures and pressures limited to 3 atm. He measured a contraction / VV =Δ 1/10870 for water at t = 10°C and P =Δ 2 atm . These observations lead to an isothermal compressibility coefficient of about 0.46 × 10-4 atm-1, a value very close to that obtained by Kell and Whalley in 1965 (0.48 × 10-4 atm-1) [KEL 65]. 10 From Deep Sea to Laboratory 3
– About 60 years then passed between Canton’s initiating work and the appearance of the first operational compressibility measuring instruments proposed independently by Perkins and Œrsted.
Closed P = 1 atm tube P = 0
(a) (b) (c) h1
h0
T0 T1 > T0 T0
Figure 1.2. Compressibility measuring instrument by J. Canton. (a) The tank contains water at temperature T0 and subjected to atmospheric pressure; (b) water heated to temperature T1 fills the capillary, which is then welded at its end; (c) water brought to temperature T0 is subjected to zero pressure
In 1819, Jacob Perkins9 designed a new instrument to study liquids at very high pressure (P > 100 atm) [PER 20, PER 26]. Its experimental cell consists of a vertically positioned gun barrel (see Figure 1.3a) whose upper part is hermetically sealed with a screw cap. In the center of the cap, a valve transmits the pressure supplied by an external hydraulic pump and informs the operator when the preset
9 Jacob Perkins was an American mechanical inventor born on July 9, 1766, in Newburyport (USA), and died on July 30, 1849, in London. He started his professional life as an apprentice goldsmith and filed numerous patents during his career. In 1819, he emigrated to England and then ran a banknote and postage stamp production company. He brought real innovations in steam engines and refrigeration systems and invented a device to measure water compression. Biographical note in Encyclopedia Britannica, vol. 21, p. 173, 1911.
