Asteroseismology & Exoplanets: A Kepler Success Story
Daniel Huber
SETI Institute / NASA Ames Research Center
U Chicago Astronomy Colloquium April 2014 Collaborators
Bill Chaplin, Andrea Miglio, Yvonne Elsworth, Tiago Campante & Rasmus Handberg (Birmingham) Jørgen Christensen-Dalsgaard, Hans Kjeldsen, Victor Silva Aguirre (Aarhus) Tim Bedding & Dennis Stello (Sydney) Ron Gilliland (PSU), Sarbani Basu (Yale), Steve Kawaler (Iowa State), Travis Metcalfe (SSI), Jaymie Matthews (UBC), Saskia Hekker (Amsterdam), Marc Pinsonneault & Jennifer Johnson (OSU), Eric Gaidos (Hawaii) Tom Barclay, Jason Rowe, Elisa Quintana & Jack Lissauer (NASA Ames / SETI) Josh Carter, Lars Buchhave, Dave Latham, Ben Montet & John Johnson (Harvard) Dan Fabrycky (Chicago) Josh Winn, Kat Deck & Roberto Sanchis-Ojeda (MIT) Andrew Howard, Howard Isaacson & Geoff Marcy (Hawaii, Berkeley) The Kepler Space Telescope • launched in March 2009 • 0.95 m aperture • 42 CCD’s , 105 sq deg FOV
Borucki et al. (2008), Koch et al. (2010) Kepler Field of View Kepler Orbit
Kepler obtained uninterrupted high-precision photometry of ~> 150,000 stars for 4 years to search for transiting exoplanets
Asteroseismology in a Nutshell AstEroseismology? AstEroseismology?
unnamed author, sometime in 1995 What causes stellar oscillations?
Oscillations in cool stars are driven by turbulent surface convection (opacity in hot stars) Radial Order n displacement
center surface number of nodes from the surface to the center of the star Spherical Degree l
l = 0 Spherical Degree l
l = 2
l = 0
Δν ~ 135 µHz for the Sun
sound speed cs -1 3 1/2 Δν = (2 ∫dr/cs) ∝ (M/R )
(ω = n π c / L!) Ulrich (1986) δν ∝ ∫dcs/dr (Age) δν
(individual frequencies)
sound speed cs -1 3 1/2 Δν = (2 ∫dr/cs) ∝ (M/R )
(ω = n π c / L!) Ulrich (1986) νmax
νmax ~ 3000 µHz for the Sun
0.5 -2 0.5 νmax ∝ νac ∝ g Teff ∝ M R Teff
Brown et al. (1991) Spectroscopy
Teff, log(g), [Fe/H] + fix log(g) Asteroseismology Δν α M1/2 R-3/2 -2 -1/2 log(g)seism νmax α M R Teff
R <~ 5% M <~ 10% Teff, R, M, [Fe/H], (Age) for single field stars! Does asteroseismology work?
Empirical tests: interferometry, parallaxes, astrometric & eclipsing binaries, transits, cluster members interferometric radii Huber et al. (2012) Generally validated to ~5% and ~10% in R & M; 4% better for dwarfs, worse for evolved giants
seismic radii The Kepler Revolution of Asteroseismology 1991: First confirmed detection of solar-like oscillations in a star other than the Sun
Procyon Sun
Brown et al. 1991 VIRGO/SOHO
challenging using ground-based observations! 2014: Kepler
?
? 2014: Kepler
16 Cyg A
Sun pre-2007
~10 unevolved stars ~10 evolved stars CoRoT ~10 unevolved stars ~2000 evolved stars Kepler
~ 600 unevolved stars ~ 15000 evolved stars Red Clump (He-core burning)
RGB (non He-core ? burning) Probing the cores of Giants: Mixed Modes Probing the cores of Giants: Mixed Modes l=1 l=1 l=1
Multiple l=1 peaks per order due to coupling of acoustic modes with gravity modes trapped in the stellar interior (“mixed modes”) He-core burning
non He- core burning Gravity mode period spacing Mean Density Bedding et al. 2011, Nature 481, 55 The Exoplanet - Asteroseismology Synergy Transits yield relative planet size Transits & Planet Radii M★ & R★ +
2 (RP/R★)
RP Kepler-37: A Special Host Star
νmax ~ 4300 µHz νmax,⦿ ~ 3000 µHz Δν ~ 179 µHz Δν⦿ ~ 135 µHz
R = 0.772+/- 0.026 R⦿ Smallest solar-type star with detected oscillations yet! Kepler-37: A Special Host Star
P = 13.4 days R = 0.30+/- 0.06 R♁
P = 21.3 days R = 0.74+/- 0.07 R♁
P = 39.8 days R = 2.0+/- 0.1 R♁ Barclay et al. 2013, Nature 494, 452 Asteroseismic Planet Host Stars
All Host Stars
Host stars with asteroseismic detections
Huber et al. (2013), ApJ 767, 127 An exotic host star: Kepler-56
red giant hosting 2 transiting planets
10.2d, 6.5R♁
21.4d, 9.8R♁ Kepler-56 Asteroseismology l=1 l=1 l=1 ~50 individual frequencies detected Kepler-56 Asteroseismology l=1 l=1 l=1 ~50 individual frequencies detected
mixed l=1 modes are split into triplets by rotation Andrea Miglio University of Birmingham, UK Kepler-56 Asteroseismology l=1 l=1 l=1 ~50 individual frequencies detected
mixed l=1 modes are split into triplets because the star is inclined towards line of sight
i ~ 45°! Kepler-56 Asteroseismology l=1 l=1 l=1 ~50 individual ? frequencies ↻ detected
mixed l=1 modes are split into triplets because the star is inclined towards line of sight
i ~ 45°! Keck/HIRES Radial Velocities
wide companion!
Planets b & c
Radial velocity drift due to third companion on a wide orbit torque by wide companion causes the orbital plane of the inner planets to precess (Mardling 2010, Kaib et al. 2011, Batygin 2012) Huber et al. 2013, Science 342, 331 The Big Picture: Stellar Properties of all Kepler Targets Petigura et al. (2013) Planet occurrence rates (in and outside the Kepler field!) depend on our understanding of the Kepler parent sample So far, this is still mostly based on the Kepler Input Catalog (KIC) Kepler Input Catalog
The purpose of the KIC was to select targets for observations Kepler Input Catalog
Isochrones for ~95% of metallicities in the solar neighborhood
“Problem Areas”
The purpose of the KIC was to select targets for observations Asteroseismology Spectroscopy ~15000 stars ~800 stars
Photometry KIC ~130000 stars ~30000 stars Old Catalog
New Catalog
Huber et al. (2014), ApJS 211, 2 Old Catalog (1) Identification of (1) new giant stars
(2) (2) Improved radii of (3) cool dwarfs
New Catalog (1) (3) Realistic metallicity (2) distribution for (3) solar-type dwarfs
Huber et al. (2014), ApJS 211, 2 Unclassified Stars (not the Sun anymore!)
Cool Dwarfs up to 90% smaller
Huber et al. (2014), ApJS 211, 2 What does this mean for planet occurrence?
Fressin et al. Howard et al. (2013) (2011) ? ?
Petigura et al. (2013a) Planet occurrence ? study in progress - stay tuned for new results! The Future: Kepler’s Ecliptic Plane Follow- Up Mission
Idea: Balance solar pressure around roll-angle (X-Y plane) of spacecraft, adjust with thruster firings
~80 day campaigns in each ecliptic field
Howell et al. (2014) Rich science fields: Young open clusters (Pleiades!) & moving groups (upper Sco), galactic fields ~20000-30000 targets per campaign (larger apertures mostly due to pointing precision); all targets are selected by the community
http://keplerscience.arc.nasa.gov/K2/ K2 photometric performance (in fine-point) within a factor of 2 of Kepler! Early Results: Transit and Eclipses
WASP-28 Eclipsing Binary Stars Early Results: Transit and Eclipses
WASP-28 Eclipsing Binary Stars
is back in Action! (Unexpected?) Early Results: Asteroids
Aviv Ofir, University of Göttingen Early Results: Oscillating Giants Oscillation Frequency Oscillation Evolution “Galactic Archeology”
K2 Asteroseismology will allow us to measure distances and ages for thousands of giants in the galaxy Conclusions
• Kepler has opened up a new era in Asteroseismology; Stellar oscillations are used to characterize the host stars the smallest planets and most exotic planetary systems known to date!
• A better understanding of planet occurrence from Kepler relies on accurate stellar properties for all target stars, making use of different observational techniques (including asteroseismology); still lots of work ahead!
• The K2 Mission will continue Kepler’s legacy in the ecliptic plane, both for exoplanet detections and asteroseismology; First results are very promising!
