System Requirements
IBM PC or compatibles Available PS/2 keyboard port and mouse port. CD-ROM drive or DVD drive Microsoft Windows 95, Windows 98, Windows NT 4.0, Windows ME Windows 2000 or Windows XP operating system. Microsoft Internet Explorer 5.0 or later version (for the Internet keys)
Please refer to below table for the other system requirements for the various features.
Function Description Operating System
Windows 95 / Windows 2000 / Windows 98 / Windows ME Windows NT 4.0 Windows XP
Wireless Available immediately Available immediately functionality after hardware installation after hardware installation
Keyboard extra 7 Requires KeyMaestro Available immediately Internet buttons keyboard driver installation after hardware installation (see driver CD for details)
Keyboard extra Requires enabling of system Available immediately Sleep button APM (sleep mode) function after hardware installation
Mouse driver Requires installation of Requires installation of shortcut function mouse driver (see driver mouse driver (see driver CD for details) CD for details)
Besides providing unprecedented freedom of movement when operating your keyboard or mouse, it also offers even more extra functions by introducing 7 dedicated buttons for often used Internet browser functions as well as a Sleep button (Please note: The Internet keys work only under Microsoft Internet Explorer 5.0 or later version!). And last but not least, this package also provides a special driver which provides unique shortcut functions.
Radio frequency - 2 metres for keyboard, 1 metre for mouse. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 3
Installing the batteries
Remove the battery compartment cover by pressing the catch. Insert 2 x AAA batteries into the mouse as shown then replace the battery compartment cover.
Remove the battery compartment cover and insert 2 x AA batteries into the keyboard as shown. Replace the battery compartment cover.
Connecting the receiver Make sure your computer is switched off.
Connect the green connector to the mouse port on the back of your computer. Connect the purple connector to the keyboard port on the back of your computer. Make sure the receiver is placed in a location which is relatively free from strong electromagnetic or transmission sources for example a monitor in order to ensure the best reception of the keyboard and mouse signal.
Now, switch on your PC PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 4
Connecting the mouse and keyboard Push the “CONNECT” button on the receiver. Then push the button on the back of the mouse the upper left corner.) Please note that this step must completed within 8 seconds after pushing the “CONNECT” button on the reciever.When the mouse and reciever are connected, move the pointer. The LED should blink.This indicates the setting has been completed. If the setting has not been completed,repeat the process again.
To connect the keyboard, push the “CONNECT” button on the receiver. Then push the button on the right side of the keyboard, at the top corner. Please note that this step must be completed within 8 seconds after pushing the “CONNECT” button on the receiver. Push the “SPACE” key on the keyboard, the LED will blink, the setting has been completed. If the setting has not been completed, repeat the process again.
Installing the software
Keyboard If you are using Windows 2000, ME or XP then you should be able to use the 7 extra browser function buttons and the sleep button. If you are using Windows 95, 98 or NT 4.0 you will have to install the keyboard drivers.
Insert the Drivers CD into your CD drive.
Click on START then click RUN. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 5
Type D:\keyboard-driver\setup.exe Where ‘D’ is the letter for the CD drive this letter may vary.
Click OK
Follow the on screen instructions to complete the installation.
Installing the software
Mouse Switch your computer on if it is not already on. To be able to use the shortcut feature of your mouse you will have to install the mouse drivers.
Insert the Drivers CD into your CD drive.
Click on START then click RUN.
For Win NT4.0,95,98 and ME: Type D:\mouse-driver\Win9xNT\setup.exe For Win 2000: Type D:\mouse-driver\Win2000\setup.exe For Win XP: Type D:\mouse-driver\WinXP\setup.exe Where ‘D’ is the letter for the CD drive this letter may vary.
Click OK
Follow the on screen instructions to complete the installation. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 6
Using the keyboard Apart from the usual keys your keyboard has an extra 8 which are used with a web browser apart from the Sleep key. They have the following functions:
Back key: Pressing this key will let you return to the last viewed page.
Forward key: Pressing this key will let you go forward to the next page (when available)
Stop key: Pressing this key will let your browser stop the current loading of a page.
Search key: Pressing this key will start a search engine for the internet. 4 Web/Home key:4 Pressing this key will start up your browser and/or startup your selected home page (please refer to internet explorer4 for4 more information on how to set/modify this home page address).
Refresh key: Pressing this button will Refresh your current web page. 4 Mail key: Pressing4 this key will automatically startup your favourite e-mail application (e.g Microsoft Outlook). You can select Tools-> Internet Options-> Programs-> Email to change the default settings4 of internet Explorer.4 Favourites key: Pressing this button will let you choose from * your list of favourite web addresses.
Calculator key: Pressing this button willactivate the calculator.
My Computer key: Pressing this button will bring up the My Computer window.
4 PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 7 4
Power key: Pressing this key will turn the PC mode off.
Wake Up key: Pressing this button will turn your PC on from sleep4 4mode. 44 4 Sleep key: Pressing this key will switch the PC into sleep mode.
Mute key: Pressing this key will mute the sounds
Increase Volume key: Pressing this key will increase the volume
Decrease Volume Key: Pressing this key will decrease the 4 volume.
Sound key: Pressing this key will start a search engine for the internet.
Play/Pause key: Pressing this key once will playback the music. 4 Press it again and the music will pause.
Stop key: Pressing this button will stop the playback
9 Previous key: Pressing this key will skip back to the previous
4 position. 9 Next key: Pressing this button will skip forward to the next position.
44 PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 8
Using the mouse
After installing the mouse drivers you will be able to startup the Mouse Control Panel by right clicking on the mouse icon which should be on the icon bar at the bottom right of your screen. You can also get to the mouse control panel by clicking on Start-> Programs-> KeyMaestro-> KeyMaestro Mouse. For Windows XP, please click on Start-> Programs-> Scroll Mouse-> Scroll Mouse Panel.
Magic tab allows you to change the browsing speed and direction of the browsing button.
Pointers tab allows you to choose your favourite pointer shape.
Cursor tab allows the selection of special cursor functions such as trails for your cursor or loop function.
Action tab allows you to redefine the mouse keys function and speed.
Settings tab allows you to reassign mouse button shortcuts and/or switch Office 97 mouse mode on/off.
About tab shows you the current Packard Bell version information.
Orientation tab allows you to setup the angle of the mouse when moving upwards. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 9
Using the mouse Also, after installing the mouse driver and starting the KeyMaestro mouse driver program you will have access to 12 special function icons by pressing the scroll wheel once. The 12 functions are:
1. Close the Application: 12 1 2 allows you to close the current application. 11 2. Internet Explorer: starts up the default browser (Internet Explorer) 10 3
3. Calculator: 9 4 will open the calculator. 4. MS DOS: 8 5 will take you into MS DOS windows. 7 6 5. Outlook Express: starts up Outlook Express 6. File Manager: brings up the File Manager window 7. Shut down: will give you the option to Shut Down your PC. 8. Auto Scroll: allows to scroll the page in any direction. 9. Media Player: will start up the default Media Player. 10. CD Player: will start up the default CD player. 11. Zoom: allows you to zoom into the page. 12. Control Panel: allows you to quickly change the settings.
For more detailed information please read the online help by clicking on Start-> Programs-> KeyMaestro Mouse -> KeyMaestro Mouse Online Help. For Windows XP, please click on Start-> Programs-> Scroll Mouse-> Scroll Mouse Help File. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 10
Troubleshooting
If the keyboard or the mouse do not work correctly, then please check the following:
1. Take out the receivers connector and check both the receivers mouse and keyboard plug for possible broken pins. If the plugs appear normal then re-insert the plugs into their respective connectors on your PC.
2. Make sure the mouse plug is inserted in the mouse connector on your PC and the keyboard plug is inserted into the keyboard connector on your PC. Compare the icons on both the cable and rear of your PC if necessary.
3. Check if the batteries in keyboard and mouse are installed correctly. Make sure the polarity of the batteries corresponds with the polarity signs in the battery compartment.
4. Replace the batteries to make sure the batteries that are used are not low on power.
5. Check if the channel switch for receiver, keyboard and mouse is set to the same channel. Try the alternate channel for both the receiver, keyboard and mouse in case the initially selected channel appears to work improperly, possibly because of interference from other devices in the vicinity of the receiver.
6. It is strongly recommended to locate the receiver in front of the monitor in order to prevent signal disturbance from the monitor.
7. If your PC system's BIOS setup has options for the keyboard or mouse then make sure they are set to default settings. If you are not familiar with the BIOS, then please refer to your PC's manual for more information. PC Line KB200 Keyboard and Mouse.qxd 03/04/2003 10:57 Page 11
Troubleshooting
8. If you have problems using the sleep button in your system then make sure that the power management in your PC has been enabled both in the BIOS and in Windows. For more information on your PC's BIOS settings please refer to your PC's manual. For more information on how to enable the power management features of your Windows version please refer to your Windows manual.
9. If you have problems using the extra browser buttons and/or the special mouse functions then make sure you have installed the keyboard and mouse driver correctly as described in this manuals ‘Installing the Software’ section. Also check if the hardware requirements that are described in the ‘System Requirement’ section are met by your system.
10. Use the mouse only on a clean, flat, non-slippery surface in order to ensure smooth and sure cursor action.
11. Keep all kit items away from direct sunlight, moisture, dirt, extreme heat and abrasive chemical (cleaning) solutions.
12. Should the receiver, keyboard or mouse become accidentally immersed or splashed on by any liquid, then switch off your PC immediately, then unplug all items and refer to your dealer for further assistance. In these cases please refrain from using any of the items before consulting with your dealer !
If you have any problems installing your cordless keyboard and mouse please call the PC Helpline on 0906 7525600
The helpline is open 24 hours a day 7 days a week and calls cost 75p per minute
