GRAPHENE INDUCED FORMATION OF NANOSTRUCTURES IN COMPOSITES
by
CHEN SHEN B.S Zhejiang University, 2010 M.S University of Florida, 2012
A dissertation submitted in partial fulfillment of the requirements for the degree of Doctor of Philosophy in the Department of Materials Science and Engineering in the College of Engineering and Computer Science at the University of Central Florida Orlando, Florida
Spring Term 2018
Major Professor: Lei Zhai
© 2018 Chen Shen
ii ABSTRACT
Graphene induced nanostructures in graphene-based composites and the performance of these composites have been explored in this study. For the metallic nanoparticles decorated graphene aerogels composites, the fabrication of hierarchically structured, reduced graphene oxide (rGO) aerogels with heavily metallic nanoparticles was realized. Higher loading of palladium nanoparticles in graphene aerogels leads to improved hydrogen gas sensing performance. For polymer derived ceramics (PDCs) composites with anisotropic electrical properties, the fabrication of composites was realized by embedding anisotropic reduced graphene oxide aerogels (rGOAs) into the PDCs matrix. Raman spectroscopy and X-ray diffraction studies of
PDCs composites with and without graphene indicate that graphene facilitates the transition from amorphous carbon to graphitic carbon in the PDCs. For composites composed of PDCs and edge functionalized graphene oxide (EFGO), bulk PDCs based composites with embedded graphene networks show high electrical conductivity, high thermal stability, and low thermal conductivity.
For the study of poly(3-hexylthiophene) (P3HT) crystallization on graphitic substrates (i.e. carbon nanotubes, carbon fibers and graphene), different types of P3HT nanocrystals (i.e. nanowires, nanoribbons, and nanowalls) were observed. The type of nanocrystals grown from graphitic substrates depends on the curvature of graphitic substrates, the molecular weight of
P3HT molecules, and the concentration of P3HT marginal solutions. Besides, both specific surface area and curvature of graphitic substrates have major effects on P3HT crystallization processes.
iii
for my dreams since childhood
iv ACKNOWLEDGMENTS
First of all, I would like to appreciate my parents for pushing me go abroad for study. I was kidding privately that I would definitely have kids if I decided not to go abroad. But I have to say I definitely experienced many things that could not happen if I did not leave my home country.
Getting a PHD degree is not only about learning experimental skills, critical thinking, technical writing and professional presentation, but using these best years in my life to gain the wisdom for the future life. Now I can proudly say that I have become a quite different person who is mature, independent, and ready for the challenges in the future career. I hope my parents are satisfied with my performance now.
Secondly, I need to thank Dr. Zhai who offered me the chance to become a PHD. From strangers to now, we have experienced a lot. When I saw Acacia in the office, I realized that I have been here for so many years because she was even not born when I first came to UCF. Thank you for the guidance on analyzing problems, communication with people, and fully utilizing resources.
Let’s see how these trainings can affect my future professional career.
Thirdly, I have to be grateful to my lab-mates for both the help on experiments and troubles made in the lab, although I guess the second part should much more than the first part. Let me list their names here. Binh, Astha, Jean, Matt are group members joined the group before me. Joe, Xiaoyan,
Liz, David, Nilab, Zeyang are group members joined the group after me. Anyway, those troubles forced me to be a master in all experiments that can be performed in the lab and MCF. Besides, I had to manage the lab by myself to keep it in good conditions, and it made me to be able to remember the location of almost every tool in the lab.
v Then, I need to appreciate all professors and staffs in NSTC, MCF, MSE and the graduate school
for giving guidance and convenience to my life in the graduate school. I especially appreciate Kirk,
Matt, and Karen in MCF because I met them every week while doing characterizations, and they
answered my questions so nicely.
Also, I need to be thankful to my friends in United States and those friends I got when I was in
China. Moving furniture together, arranging dinners together, chatting irrelevant issues together,
the life at abroad is not that lonely with friends. On the other hand, for those friends who are not
in the US, it is so fortunate that some of us are still chatting online. Gratitude from the bottom of
my heart for a few sentences you said when I was experiencing several months of miserable life
during my PHD career. What can I say now? You are friends for life. We stayed quite calm at our
reunions when I came back to China, but we found that we can still talk in the way when we were
in middle schools after the first eye contact. For their privacy, I am not going to reveal their names
here.
Last but not the least, I need to say thanks to a person who even does not know me, Kobe Bryant.
I became a Kobe fan since I first saw he played basketball in 2001 NBA finals. After watching
about 200 matches he played, Kobe is like an old friend to me, and some of his personalities
infiltrated into my soul. When I was facing tricky experiments that I could not operate well, I asked
myself what Kobe would do after those failures. The answer was always “one more time”. As a
rookie picked at the 13th place, a skinny boy who could not shoot well, and a player with small
hands which could not grab the basketball, how many audiences can imagine him to be the point
guard only worse than Michael Jordan, the 3rd all-time leading scorer, and a slam dunk champion.
I guess the answer is hard working as he knew “how Los Angles looks like at 4 am everyday”.
vi However, Kobe’s success is not only because of hard working. Here, I need to share one Kobe movement that inspired me during my PHD career, and I believe it will influence my whole life.
It was April 11th, 2013, Kobe made a couple of free throws when his tender of the left ankle was broken, but no pain could be read from his face when he was making those two shots. For his loving team swaying in the midst of a raging storm, he played so many games with minimal rest only for wins and suddenly fell down. He devoted all his energy on the court because he promised
Dr. Buss, who left the world in that season, and himself to bring Lakers to the playoffs. Thank you,
Black Mamba.
vii TABLE OF CONTENTS
LIST OF FIGURES ...... xiii
LIST OF TABLES ...... xxiii
LIST OF ABBREVIATIONS ...... xxiv
CHAPTER 1: BACKGROUND ...... 1
Graphene ...... 1
Graphene Oxide ...... 2
Reduced Graphene Oxide ...... 3
Edge Functionalized Graphene Oxide ...... 4
Graphene Aerogel/metal Nanoparticles Composites ...... 4
Graphene/PDC Composites...... 5
Graphene Induced P3HT Crystallizations ...... 7
Techniques ...... 9
Chemical Vapor Deposition ...... 9
Schlenk Lines ...... 9
Ball Milling...... 10
Characterizations ...... 10
Scanning Electron Microscopy ...... 10
Energy-Dispersive X-Ray Spectroscopy ...... 11
Transmission Electron Microscopy ...... 11
Selected Area Electron Diffraction ...... 12
viii Atomic Force Microscopy ...... 12
Raman Spectroscopy ...... 13
Fourier-Transform Infrared Spectroscopy ...... 14
X-Ray Diffraction ...... 14
X-Ray Photoelectron Spectroscopy ...... 14
Ultraviolet–Visible Spectroscopy ...... 15
Dynamic Light Scattering ...... 15
Thermogravimetric Analysis ...... 15
Differential Scanning Calorimetry ...... 16
Gas Chromatography–Mass Spectrometry ...... 16
Nuclear Magnetic Resonance ...... 17
Gel Permeation Chromatography ...... 17
Quartz Crystal Microbalance ...... 17
Four-probes Measurement ...... 18
Thermal Conductivity Measurements ...... 18
References ...... 19
CHAPTER 2: FABRICATION OF GRAPHENE AEROGELS WITH HEAVILITY LOADED
MATALLIC NANOPARTICLES ...... 40
Introduction ...... 40
Materials and Methods ...... 42
Characterizations ...... 45
Results and Discussion ...... 45
Conclusions ...... 56
ix Supporting Materials ...... 56
References ...... 58
CHAPTER 3: ANISOTROPIC ELECTRICAL CONDUCTIVITY IN POLYMER DERIVED
CERAMICS INDUCED GRAPHENE AEROGELS ...... 67
Introduction ...... 67
Experimental Procedures ...... 70
Characterizations ...... 73
Results and Discussion ...... 74
Conclusions ...... 87
Supporting Materials ...... 88
References ...... 91
CHAPTER 4: BULK POLYMER DERIVED CERAMIC COMPOSITES WITH EDGE
FUNCTIONALIZED GRAPHENE ...... 102
Introduction ...... 102
Experimental Procedures ...... 104
Characterizations ...... 107
Results and Discussion ...... 108
Conclusions ...... 130
Supporting Materials ...... 131
References ...... 143
CHAPTER 5: CRYSTALLIZATION OF P3HT ON GRAPHIITC SUBSTRATES WITH
DIFFERENT CURVATURES ...... 158
x Introduction ...... 158
Materials ...... 160
Experimental Procedures ...... 161
Characterizations ...... 163
Results and Discussion ...... 164
Crystallization of LM-P3HT on Graphitic Substrates ...... 164
Crystallization of SM-P3HT on Graphitic Substrates by Using High Concentration Marginal
Solutions ...... 166
Crystallization of SM-P3HT on Graphitic Substrates by Using Low Concentration Marginal
Solutions ...... 177
Kinetic Study of LM-P3HT on Curved Graphitic Substrates ...... 179
Kinetic Study of SM-P3HT on Curved Graphitic Substrates ...... 184
Kinetic Study of LM-P3HT and SM-P3HT on Flat Graphene Substrates ...... 187
Conclusions ...... 188
Supporting Materials ...... 190
References ...... 199
CHAPTER 6: CONCLUSIONS AND FUTURE WORK ...... 212
Conclusions ...... 212
Future Work ...... 215
References ...... 216
APPENDIX A: LIST OF PUBLICATIONS ...... 218
APPENDIX B: PERMISSIONS FOR COPYRIGHTED MATERIALS ...... 220
xi Permission Request Policies from Multidisciplinary Digital Publishing Institute (MDPI) ...... 221
Permission Request Policies from Royal Society of Chemistry ...... 223
xii LIST OF FIGURES
Figure 2-1. Schematic illustration of the formation of metal nanoparticles decorated rGO aerogels...... 44
Figure 2-2. (a) SEM image of the cross-sectional area, (b) SEM image of the longitudinal section...... 47
Figure 2-3. SEM images of the (a,e) Pd, (b,f) Pt, (c,g) Ni, and (d,h) Sn nanoparticles loaded aerogels formed after hydrogen reduction...... 48
Figure 2-4. SEM images of (a)Pd, (b)Pt, (c)Ni, and (d)Sn loaded rGO aerogels and the corresponding EDS spatial mapping images of loaded (e)Pd, (f)Pt, (g)Ni, and (h)Sn on rGO sheets. The scale bar is 20 m...... 49
Figure 2-5. EDS spectra ofµ (a) palladium, (b) platinum, (c) nickel, and (d) tin loaded rGO aerogels after hydrogen reduction...... 50
Figure 2-6. Deconvoluted XPS spectra of the loaded metal in the aerogels. Pd in Pd loaded aerogels (a) as prepared and (b) after reduction, Pt in Pt loaded aerogels (c) as prepared and
(d) after reduction, Ni in Ni loaded aerogels (e) as prepared and (f) after reduction, Sn in Sn loaded aerogels (g) as prepared and (h) after reduction are shown...... 53
Figure 2-7. (a) The change of resistance of GA/Pd nanoparticle composites with different Pd loadings upon exposure to 1000 ppm hydrogen gas. (b) The change of resistance of GA/Pd nanoparticle composites upon hydrogen gas on/off cycles...... 55
Figure 2-8. SEM images of Pd nanoparticles on GA surfaces made from (a) 30 mM and (b)
70 mM Pd ion in GO suspensions...... 56
xiii Figure 2-9. Deconvoluted XPS spectra of the carbon in the aerogels. C in Pd loaded aerogels
(a) as prepared and (b) after reduction, C in Pt loaded aerogels (c) as prepared and (d) after reduction, C in Ni loaded aerogels (e) as prepared and (f) after reduction, C in Sn loaded aerogels (g) as prepared and (h) after reduction...... 57
Figure 2-10. The change of current of a hydrogen sensor when exposed to 1000 ppm hydrogen gas. The responding time and recovery time are highlight in green and brown, respectively.
...... 58
Figure 3-1. Optical images of GO suspension (a), GO aerogel (b), free standing rGOAs (c),
SEM images of rGOAs made from 20 mg/mL GO suspensions (d, e)...... 74
Figure 3-2. XPS spectra of the deconvoluted C 1s peaks of (a) GO aerogels and (b) rGOAs.
...... 74
Figure 3-3. Transversal section SEM images of SiCN/rGOA ceramic composites with (a,b)
10 mg/mL, (c,d) 20 mg/mL, (e,f) 30 mg/mL, and (g,h) 40 mg/mL rGOA...... 76
Figure 3-4. Longitudinal section SEM images of SiCN/rGOA ceramic composites with (a) 10 mg/mL, (b) 20 mg/mL, (c) 30 mg/mL, and (d) 40 mg/mL rGO...... 78
Figure 3-5. Anisotropic electrical conductivity of SiCN/rGOA ceramic composites...... 79
Figure 3-6. Electrical conductivity change of SiCN/rGOA ceramic composites from room temperature to higher temperatures...... 79
Figure 3-7. Raman spectra of (a) SiCN and (b) SiCN/rGOA pyrolyzed at different temperatures. The G band in each spectrum is label by an asterisk...... 82
Figure 3-8. XRD spectra of SiCN/rGOA composites pyrolyzed at different temperatures. . 84
Figure 3-9. Young’s Modulus of SiCN/rGOA composites of different RGOA concentration.
The inset is the picture of the cracked composite after the compression test...... 85
xiv Figure 3-10. SEM images of cracks formed during the compression test for SiCN/rGOA composites of (a,b) 10 mg/mL, (c,d) 20 mg/mL, (e,f) 30 mg/mL, and (g,h) 40 mg/mL rGOA.
...... 86
Figure 3-11. A picture of bulk SiCN/rGOA composite...... 88
Figure 3-12. Raman spectrum of single layer graphene transferred onto a quartz slide...... 88
Figure 3-13. SEM images of longitudinal (A) and transversal (B) section of 30mg/mL rGO aerogel...... 89
Figure 3-14. SEM images of SiCN ceramic surfaces at low (left) and high (right) magnification...... 89
Figure 3-15. The SEM image of a SiCN film on graphene embedded between PDC and quartz slide...... 89
Figure 3-16. Raman spectra of (a) PDC on graphene coated quartz slides after pyrolysis conducted at different temperatures (600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC) and (b)
PDC on quartz slides after pyrolysis conducted at different temperatures (600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC). All G band positons are labeled by asterisks...... 90
Figure 3-17. XRD spectra of GO...... 90
Figure 3-18. XRD spectra of GO pyrolyzed at different temperatures...... 91
Figure 3-19. Fitting the relationship between conductivity and temperature to the function of
(a) T-1/2, (b) T-1/3, (c) T-1/4, respectively...... 91
Figureσ ∝ 4-1. The schematicσ ∝ illustrationσ ∝ of the preparation of EFGO network embedded PDC composites...... 108
xv Figure 4-2. (a, b) TEM images of EFGO flakes. (c) The SAED pattern of EFGO flakes. Four sets of six-fold SAED pattern regarding the (1100) lattice fringe of graphitic structures are labeled in red, blue, green, and purple circles...... 110
Figure 4-3. The AFM image of a EFGO flake on mica substrate. The scanning area is 2.5
µm×2.5 µm. The height profile beneath the AFM image reveals the height at the white sectioning line in the AFM image...... 110
Figure 4-4. The Raman spectrum of EFGO flakes. The position of the G peak, the D peak and the 2D peak are at 1563.8 cm-1, and 1343.9 cm-1, and 2693.6 cm-1, respectively...... 111
Figure 4-5. SEM images of EFGO attached PVA foams after the immersion of PVA foams in the EFGO dispersion...... 111
Figure 4-6. SEM images of PDC composites green bodies...... 112
Figure 4-7. SEM images of PDC composites pyrolyzed at 1000 oC...... 113
Figure 4-8. TGA curves of the PDC composite and each component in the composite. .... 114
Figure 4-9. Raman spectra of PDC composites pyrolyzed at different temperatures...... 117
Figure 4-10. XPS spectra of PDC composites at (a) carbon region and (b) silicon region before pyrolysis (RT), at the transition state of pyrolysis (700 oC), and after pyrolysis (1000 oC).
...... 118
Figure 4-11. Room temperature electrical conductivity of PDC composites pyrolyzed at different temperatures and the corresponding linear shrinkage after pyrolysis...... 122
Figure 4-12. Raman spectra of (a) pure SILRES 62C and (b) EFGO/SILRES 62C composites with 2 wt% EFGO pyrolyzed at different temperatures...... 123
xvi Figure 4-13. Schematic illustration of graphitic domains evolution in (a) SILRES 62C, (b)
EFGO/SILRES 62C, and (c) EFGO/SILRES 62C/PVA composites (PDC composites) during pyrolysis processes...... 125
Figure 4-14. Electrical conductivity of PDC composites (EFGO/SILRES 62C/PVA composites) pyrolyzed at different temperatures. The testing temperature range is from 25 oC to 600 oC...... 126
Figure 4-15. The particle size distribution of EFGO flakes from the DLS test...... 131
Figure 4-16. FTIR spectrum of SILRES 62C precursor before (black line) and after (red line) curing process...... 131
Figure 4-17. 1H NMR spectrum of SILRES 62C preceramic polymer. The peak at 1.56 ppm is from water impurities...... 132
Figure 4-18. The SEM image of bare PVA foams...... 133
Figure 4-19. SEM images of the surface of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC, (d) 600 oC, (e) 700 oC, (f) 800 oC, (g) 900 oC, and (h) 1000 oC. Scale bars are
50 m...... 133
Figureµ 4-20. SEM images of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC, and (d) 600 oC without Au/Pd sputter coating...... 134
Figure 4-21. Linear shrinkage of PDC composites after pyrolysis at different temperatures.
...... 134
Figure 4-22. EDS spectra of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC,
(d) 600 oC, (e) 700 oC, (f) 800 oC, (g) 900 oC, and (h) 1000 oC...... 135
Figure 4-23. The SEM image of PDC composites treated in air at 500 oC...... 135
xvii Figure 4-24. Electrical conductivity comparison of different composites with same pyrolysis conditions at the testing temperature from 25 oC to 600 oC. Composites are pyrolyzed at (a)
700 oC, (b) 800 oC, (c) 900 oC, and (d) 1000 oC, respectively...... 136
Figure 4-25. Electrical conductivity of (a) EFGO/SILRES 62C/PVA, (b) EFGO/SILRES 62C, and (c) SILRES 62C pyrolyzed at different temperatures. The testing temperature range is from 25 oC to 600 oC...... 136
Figure 4-26. Specific heat capacity of (a) green bodies and (b) 1000 oC pyrolyzed PDC composites at different temperatures...... 137
Figure 4-27. Fabrication of ceramic composites, from starting materials to final products.142
Figure 4-28. Use a PDC composite pyrolyzed at 1000 oC to light up four white LED diodes with an output of 9 V. A propane gun is used to heat up the composite. The dimension of the composite is 5 mm×5 mm×40 mm...... 143
Figure 5-1. Schematic illustrations of (a) nanowire crystals formation from extended P3HT chains, (b) nanowire crystals formation from folded P3HT chains, and (c) nanoribbon crystals formation from extended P3HT chains...... 160
Figure 5-2. TEM images of LM-P3HT crystallized on (a) SWCNTs, (b) MWCNTs, (c) CFs, and (d) graphene from 0.05 mg/mL marginal solutions. Scale bars are 250 nm...... 164
Figure 5-3. Schematic illustrations of nanowires formation from LM-P3HT on graphitic substrates of (a) CNTs, (b) CFs, and (c) graphene...... 165
Figure 5-4. (a) The TEM image of SM-P3HT crystallized from SWCNTs by using a 0.30 mg/m LM-P3HT marginal solution. (b) The SAED pattern of nanowires in (a)...... 167
Figure 5-5. The schematic illustration of a SM-P3HT nanowire grown coaxially from
SWCNTs...... 167
xviii Figure 5-6. (a) The TEM image of SM-P3HT crystallized on MWCNTs to form nanoribbons from a 0.30 mg/mL marginal solution. (b) The SAED pattern of nanoribbons in (a)...... 169
Figure 5-7. The Schematic illustration of SM-P3HT nanoribbons grown from MWCNTs with a confined orientation...... 170
Figure 5-8. The AFM image of P3HT nanoribbons grown from MWCNTs. The scanning area is 2 µm×2 µm...... 170
Figure 5-9. (a) The TEM image of SM-P3HT crystallized on CFs from a 0.30 mg/mL marginal solution. (b) The SAED pattern of nanoribbons in (a)...... 171
Figure 5-10. (a) The SEM image of SM-P3HT crystallized on CFs, the scale bar is 1 m. (b)
The 3D image of SM-P3HT crystallized on CFs generated from AFM data (2 m×µ2 m).
...... µ µ 172
Figure 5-11. The schematic illustration of SM-P3HT nanoribbons grown from CFs with random radial and axial orientations...... 173
Figure 5-12. The Raman spectrum of crystallized SM-P3HT on CFs surface. The optical image of crystallized SM-P3HTT on CFs is in the inset, and the red circled area is investigated by Raman spectroscopy...... 174
Figure 5-13. (a) The TEM image of SM-P3HT crystallized on the surface graphene. Fell- down nanowalls are pointed out by arrows. (b) The SAED pattern of nanowalls in (a). Two sets of six-fold SAED patterns from the graphene substrate are circled in red and blue. ... 175
Figure 5-14. The illustration of SM-P3HT nanowalls grown vertically from graphene surface
(top view) with random orientations in the plane of graphene surface...... 176
Figure 5-15. The AFM image of SM-P3HT crystallized on graphene and height profiles of two lines labeled as 1 and 2. The scanning area is 1 m×1 m...... 176
µ µ xix Figure 5-16. TEM images of SM-P3HT crystallized on CFs from (a) 0.03 mg/mL, (b) 0.05 mg/m marginal solutions. The thin film in (a) and nanoribbons in (b) are pointed by arrows.
...... 178
Figure 5-17. The absorbance change at 600nm for P3HT crystallization on SWCNTs
(triangle), MWCNTs (square), and CFs (diamond) graphitic surfaces...... 181
Figure 5-18. Attached mass of LM-P3HT on unit area of SWCNTs (triangle), MWCNTs
(square), and CFs (diamond) graphitic substrates. Diameters of MWCNTs and CFs are considered as 15 nm and 170 nm in calculations...... 183
Figure 5-19. The absorbance change at 600nm for SM-P3HT crystallizations on SWCNTs
(black line), MWCNTs (red line), and CFs (blue line) graphitic surfaces...... 186
Figure 5-20. Attached mass of SM-P3HT on unit area of SWCNTs (black line), MWCNTs
(red line), and CFs (blue line) graphitic substrates. Diameters of SWCNTs, MWCNTs and
CFs are considered as 1.5 nm, 15 nm and 170 nm in calculations...... 186
Figure 5-21. Attached mass of LM-P3HT (black line) and SM-P3HT (red line) on unit area of graphene surface in crystallization processes...... 188
Figure 5-22. (a) The TEM image of dispersed SWCNTs. (b) The TEM image of dispersed
MWCNTs. (c) The TEM image of CVD graphene transferred on a TEM grid. (d) The SAED pattern of graphene on TEM grids...... 190
Figure 5-23. (a, b) TEM images of CFs. (c) The SEM image of CFs. (d) The AFM image of
CFs. (e) The height profile of the line is shown in (d)...... 190
Figure 5-24. SAED patterns of LM-P3HT nanowires crystallized on (a) SWCNTs, (b)
SWCNTs, (c) CFs, and (d) graphene. Two sets of six-fold SAED patterns from the graphene substrate are circled in red and blue in (d)...... 191
xx Figure 5-25. The AFM image of LM-P3HT crystallized on CFs and the height profiles of two lines labeled as 1-2. The scanning area of AFM imaging is 5 m×2.5 m...... 192
Figure 5-26. UV-Vis spectra during processes of P3HT crystallizationµ µ (a) SWCNTs, (b)
MWCNTs, and (c) CFs. Need to label 2 peaks about loss of free P3HT and gain of crystallized
P3HT...... 192
Figure 5-27. The TEM image of SM-P3HT crystallized in the dispersion contained MWCNT by rapid cooling. The concentration of MWCNTs and SM-P3HT are 0.005 mg/mL and 0.3 mg/mL, respectively...... 193
Figure 5-28. The top view AFM image (2 m×2 m) and the height profiles of 4 lines labeled as 1-4. Line 1 reveals a tilted nanoribbon fromµ CF.µ Line 2 reveals two nanoribbons parallel to the horizontal plane with the thickness of 105 nm and 10 nm. Line 3 reveals a nanoribbon with the length of 312 nm. Line 4 reveals a nanoribbon grown vertically respect to the horizontal plane with a width of 138 nm...... 193
Figure 5-29. The Raman spectrum of graphene surface...... 194
Figure 5-30. The Raman spectrum of SM-P3HT powders...... 194
Figure 5-31. The Raman spectrum of SM-P3HT crystallized on the graphene surface...... 194
Figure 5-32. TEM images of SM-P3HT crystallized on SWCNTs from (a) 0.05 mg/mL, and
(b) 0.10 mg/mL marginal solutions...... 195
Figure 5-33. The TEM image of SM-P3HT crystallized on MWCNTs to form nanowires from a 0.05 mg/mL marginal solution...... 195
Figure 5-34. The TEM image of SM-P3HT crystallized on graphene to form nanowalls composed on nanoribbons from a 0.05 mg/mL marginal solution...... 195
xxi Figure 5-35. (A) The figure of the optimized attachment of oligo(3-hexylthiophene) on
SWCNT (13,0). (B) The attachment of oligo(3-hexylthiophene) on a MWCNT (310,0) at angles of 90o, 0o, and 30o...... 197
xxii LIST OF TABLES
Table 4-1. Elemental Compositions of PDC composites after pyrolysis at different temperatures.
...... 116
Table 4-2. Summary of activation energy of different composites pyrolyzed at different
temperatures...... 128
Table 4-3. Summary of pyrolysis processes details...... 137
Table 4-4. Normalized Mass change of ceramic composites in preparation processes...... 138
Table 4-5. Density of Pyrolyzed SiCO PDCs...... 138
Table 4-6. Density of Composites pyrolyzed at different temperatures...... 139
Table 4-7. G peak positions of composites pyrolyzed composites...... 139
Table 4-8. Values of electrical conductivity increment from different pyrolyzed composites. . 140
Table 4-9. Young’s modulus of EFGO/SILRES 62C/PVA composites pyrolyzed at 1000 oC. . 140
Table 5-1. Curvature and specific surface area of different graphitic substrates. The diameter and
specific surface area are from specifications given by manufacturers...... 182
Table 5-2. Summary of nano-structures formation on different graphitic substrates from SM-P3HT and LM-P3HT molecules. Asterisks point out the formation of nanocrystals with a confined orientation...... 189
Table 5-3. The interaction energy of oligo(3-hexylthiophene) on different isomers of SWCNTs.
...... 197
Table 5-4. The interaction energy of oligo(3-hexylthiophene) on MWCNTs with different
orientations respect to the axis of MWCNTs...... 197
xxiii LIST OF ABBREVIATIONS
AFM Atomic Force Microscopy
CF Carbon Fiber
CNT Carbon Nanotube
CP Conjugated Polymer
CVD Chemical Vapor Deposition
DSC Differential Scanning Calorimetry
DLS Dynamic Light Scattering
EDS Energy-dispersive X-ray Spectroscopy
EFGO Edge Functionalized Graphene Oxide
FTIR Fourier-transform Infrared Spectroscopy
GA Graphene Aerogel
GC-MS Gas Chromatography-Mass Spectrometry
GIXRD Grazing Incidence X-ray Diffraction
GO Graphene Oxide
GPC Gel Permeation Chromatography
LED Light-emitting Diode
LM Low Molecular weight
MWCNT Multi-walled Carbon Nanotube
NMR Nuclear Magnetic Resonance
PDC Polymer Derived Ceramic
P3HT Poly (3-hexylthiophene)
xxiv PVA Poly (vinyl alcohol)
rGO Reduced Graphene Oxide
rGOA Reduced Graphene Oxide Aerogel
SAED Selected Area Electron Diffraction
SAXS Small Angle X-ray Scattering
SEM Scanning Electron Microscopy
SiCO Silicon Oxycarbide
SiCN Silicon Carbonitride
SM Small Molecular Weight
SiOC Silicon Oxycarbide
STM Scanning Tunneling Microscopy
SWCNT Single-walled Carbon Nanotube
QCM Quartz Crystal Micro-balance
TEM Transmission Electron Microscopy
TGA Thermogravimetric Analysis
UV-Vis Ultraviolet-Visible
XPS X-ray Photoelectron Spectroscopy
XRD X-ray Diffraction
xxv CHAPTER 1: BACKGROUND
Graphene
Graphene is a single layer of carbon atoms arranged in hexagonal lattices. Because of its unique structure, graphene has many unusual properties. For example, graphene has carrier mobility of about 20000 cm2/V⋅s at 25oC, its specific surface area is more than 2500 m2/g, and its Young’s modulus is 1.0 TPa. [1-7] Graphene was first got from a “scotch-tape” method. Graphite attached on silicon wafers was thinner into one-atom thick layer after many times of cleavages by using scotch tapes. Geim and Novoselov first performed the experiments to get single layer graphene, and their follow-up research on this new material led them to be the Nobel prize winners of physics in 2010. However, the “scotch-tape” method has several draw backs such as impossible to get large area graphene, limitation of substrates (unavailable to deposit onto hollow substrate such as
TEM grids), and difficult to handle without expertise. Chemical vaper deposition (CVD) method is a method which can overcome those drawbacks from the “scotch-tape” method. Gases of hydrogen and methane react at high temperature (~1000 oC) and then the deposited carbon on metal substrates such as copper and nickel to form graphene on substrates. After the etching of metal substrates, graphene can be transferred to required substrates for future experiments.
Because graphene with the size of metal substrates can be prepared by using the CVD method, the synthesis of large area graphene (larger than 1 cm×1 cm) is available. In the CVD method, when the gas flow and temperature are well controlled, synthesizing graphene is similar to baking bread in an oven, which is more convenient comparing to the “scotch-tape” method. To date, graphene has been utilized in applications such as OPVs, [8-10] FETs, [11-15] GQD-LEDs, [16] batteries,
1 [17] sensors. [18-33] It is confident to beliveve that graphene will be a compatitive candidate in
more applications in the future.
Graphene Oxide
Graphene oxide (GO) is a kind of material which consists of graphene framework along with
oxidized groups such as hydroxyl groups, carbonyl groups, and carboxylic acid groups. Hummer’s
method is the most widely used method to prepare GO. [34-36] There are many recipes derived
from Hummer’s method for GO preparation, and they are called modified Hummer’s methods.
The main mechanism of these recipes is the same, which is oxidizing graphite into GO by applying
strong oxidation agents. In our lab, we use concentrated sulfuric acid, potassium permanganate,
and hydrogen peroxide as oxidation agents to convert graphite to graphene oxide. Due to the
formation of functional groups on GO flakes, GO is dispersible in solvents such as water,
tetrahydrofuran, dimethylformamide, and ethylene glycol from the affinity between functional groups and solvents. [37] The excellent dispersity of GO facilitates the solution-based processing
of GO. Thus, GO can be applied in traditional processing methods such as drop casting, dip coating,
and spraying. Also, GO can be converted to aerogels by extracting out the solvent in dispersions,
and the process is called lyophilization. GO aqueous dispersions are first frozen, then the solvent
was sublimated in a high vacuum, low temperature environment. GO Aerogels are ultra-light
porous materials, and the density can be as low as 10 mg/mL. Also, the specific surface area of
GO aerogels can be up to 1000 m2/g. [38,39] By controlling the direction of freezing, GO aerogels
with anisotropic structures can be achieved after lyophilizations. [40] Due to their high specific
surface area and porous structures, GO aerogels have outstanding efficiencies in absorbing
2 substances, and they are excellent substrates for decorating active materials in applications of
catalysis and sensing.
Reduced Graphene Oxide
GO can be reduced to form reduced graphene oxide (rGO) by thermal reductions or chemical
reductions. In thermal reductions, oxidized functional groups are decomposed at high temperature
o (>300 C), and the reductions are performed in inert atmosphere (N2, Ar) to avoid oxidation of GO
during heating processes. In chemical reductions, reducing agents such as hydrazine, ascorbic acid,
and hydrogen are applied to chemical reduce oxidized functional groups on GO flakes. Also, it is
found that combining thermal reduction and chemical reduction can more effectively reduce
functional groups on GO flakes, reduction processes perform at elevated temperatures (>600 oC)
in hydrogen/argon mixed atmosphere is usually used in this scenario.
rGO has better electrical conductivity at the range of 1 to 100 S/cm, [41-43] and it is much higher than that of GO which can be considered as an insulator. In rGO flakes, the abundance of functional groups is greatly diminished comparing to GO. Accordingly, the aromatic structure is partially recovered, and it can facilitate the transport of electrons through π bonds. In consequence, the electrical conductivity of rGO is dramatically higher than that of GO. Due to the good electrical conductivity of rGO, it has been widely used in electric devices. Also, researchers usually form
GO composites with desired shapes then reduce them into rGO composites in these applications by taking advantages of both solution processable GO and electrical conductive rGO.
3 Edge Functionalized Graphene Oxide
Edge functionalized graphene oxide (EFGO) is a commercial product from Garmor Inc. EFGO
flakes have unaffected aromatic graphene structures in the basal area and functional groups such
as hydroxyl groups and carbonyl groups in the edge. The oxygen contents are between 5-10 wt%.
Briefly speaking, EFGO is produced by applying oxidations agent of hydrogen peroxide during
ball milling processes. The existence of functional groups only on edges of EFGO flakes leads to
good dispersity of EFGO flakes in solvents (methanol, ethanol and acetone) and excellent
electrical properties. Functional groups grant EFGO flakes with dispersity much better than that
of graphite and rGO. The remaining graphitic structures in the basal area of flakes guarantees the
availability of electron transport through intra-plane and inter-plane mechanisms. EFGO has been
used in composites to increase the electrical conductivity and mechanical strength of composites.
Graphene Aerogel/metal Nanoparticles Composites
Graphene aerogels are cooperated with metal nanoparticles to form composites with sensing
properties. Graphene aerogels (GAs) are attractive 3D graphene materials for sensing applications.
[18-33] They are produced through freeze-drying of graphene oxide (GO) dispersions followed by thermal reductions. This method produces physical crosslinks between the graphene sheets that are oriented in the freezing direction, creating long, continuous open pores throughout the GAs.
[33,44,45]
Graphene aerogels can be further functionalized with metal nanoparticles for sensing applications.
Metallic and metal oxide nanoparticles have been deposited on the graphene surfaces using three
general approaches. For the first approach, dispersed metallic nanoparticles are mixed with a GO
4 suspension and the aerogels are produced through the freeze-drying and reduction of the metal-
GO mixture. [46] In the second approach, the aerogels are immersed in a salt solution followed by reduction. [31,33] In the third approach, the GO is mixed with a metal salt solution and then subsequently freeze-dried and reduced. [47,48] The third approach offers the most versatile and
controllable method to load the metallic nanoparticles onto the GAs. However, the bridging effect
of the metal cations on the negatively charged GO significantly hinders the loading capacity of
metal ions onto the graphene surface. [47,49] To overcome this, chelating agents such as
ethylenediaminetetraacetic acid (EDTA) and acetates can be used to screen the electrostatic
interaction between the ions and GO and increase stability of dispersions. [50] In this dissertation,
we demonstrate the successful fabrication of palladium, platinum, nickel, and tin decorated
graphene aerogels. Also, a well-performed hydrogen gas sensor using palladium loaded GAs is
assembled.
Graphene/PDC Composites
Graphene is cooperated with polymer derived ceramics (PDCs) to make composites with supreme
properties from both graphene and PDCs. Composites with high electrical conductivity, excellent
thermal-mechanical stability, and chemical inertness can be realized. Silicon-based Polymer
Derived Ceramics (PDCs) have been synthesized from 1960s. [51] They keep the advantages of
mechanical strength, thermal stability, and chemical inertness from traditional ceramics. [52-56]
Unlike traditional ceramics obtained by sintering method, PDCs are synthesized by pyrolysis of
liquid polymeric precursors in inert atmosphere thus directly convert polymers into ceramics.
Liquid polymeric precursors provide the availability of various liquid-based processing techniques like casting, extrusion, spin-on coating, dip coating and spray coating. [57-61] These technologies
5 make PDCs capable to be processed into complex shapes such as fibers, [62,63] porous materials,
[64-66] and membrane coatings, [67,68] which are difficult or even impossible to be obtain by conventional routes. Also, synthesis of ceramics at temperatures lower than those for traditional ceramics leads to energy-saving ceramics preparations. [69] These superior properties of PDCs mentioned above make them as a kind of materials widely used in applications such as MEMS,
[70-72] energy storage, [61,73-75] and high temperature sensors. [76-79]
PDCs usually have low electrical conductivity 10-12-10-7 S/cm, [80,81] and the fabrication of PDCs based composites is the way to increase their electrical conductivity. Adding conductive components such as CNTs, [82-85] carbon fibers, [86] carbon black, [87,88] graphite flakes, [89] reduced graphene oxide (rGO), [90,91] and metal salts like aluminum oxide and Molybdenum disilicide [92,93] into insulating PDCs matrix can effectively increase the electrical conductivity of PDCs based composites. In addition, introducing percolated networks of conductive materials into PDC composites is found to be a better method of increasing the electrical conductivity.
[40,94,95] For example, additions of embedded graphene aerogels, which are conductive materials with inter-connected networks, were reported to be able to increase the electrical conductivity of composites to 1.57 S/cm. [96] In consequence, it is believed that adding graphene materials into
PDCs can also improve the electrical properties of PDC based materials.
During the investigation of the PDCs/graphene system, intriguing phenomena more than the improved electrical properties are observed.
In the anisotropic GO aerogels/PDC composites, the effect of carbon materials alignment on resulting composite properties is investigated. Graphene aerogels (GAs) prepared from directional freeze drying with anisotropic structures is used in this study. When such anisotropic structures
6 are embedded into a PDC matrix, the resulted composite is expected to offer anisotropic electrical
conductivity since the electron transport along the graphene basal plane is much more efficient
than the transport occurring through inter-plane hopping. [97-99] Bulk SiCN ceramics embedded with anisotropic reduced graphene oxide aerogels (rGOAs) were fabricated by filling anisotropic rGOAs with a preceramic polymer of SiCN ceramics, followed by crosslinking and pyrolysis. The morphology and electrical conductivity of SiCN/rGOA composites with different rGOA loadings were examined. The effect of rGOA on the transition of amorphous carbon to graphitic carbon in these composites was investigated by Raman spectroscopy and X-ray diffraction. In addition, the impact of rGOA on the mechanical properties of the composites was investigated.
In the EFGO/PDC composites, we report the introduction of conductive EFGO networks into bulk
PDCs composites with a facile method different from embedding aerogels, and SiOC PDCs which can be prepared from nontoxic polymeric precursors are used. SiOC polymeric precursors are infiltrated into the highly porous EFGO attached PVA foams to form green bodies for pyrolysis.
PVA foams are served as a sacrificial component and decomposes during pyrolysis, thus EFGO networks embedded SiOC PDC composites are prepared after pyrolysis. The electrical conductivity of such composites at a wide temperature (25 oC to 600 oC) is investigated. The role
of percolated EFGO networks on the preparation of bulk PDC composites, graphitic domains
formation in the nearby area, electrical conductivity improvement, and thermal conductivity is
explored.
Graphene Induced P3HT Crystallizations
Conjugated polymer (CP) have numerous potential applications in solution processed organic
electronics such as organic field-effect transistors (OFETs), [100-107] molecular electronics[108-
7 110] and bulk heterojunction organic photovoltaics (BHJ-OPVs). [111-126] Charge transport characteritics in these devices is one of the determining factors to these organic electronic devices.
The charge transport pathways in polycrystalline CP films include fast interchain and intrachain transport within crystals and slow inter-grain transport among CP crystals. [127] A recent study of the relationship between the disorder, aggregation and charge transport of CP films suggests that the inter-grain charge transport is the rate dertmining step for charge transport. The key to improve the charge transport is eliminating the grain boundary. [128] The understanding of charge transport mechanisms in CPs leads to much effort in producing CP crystals with controlled orientation and improving the active material/electrode interfacial properties. [129-135]
P3HT is one of the most extensively studied CP due to its high charge mobility and tendency to assemble into crystals (i.e. nanowires and nanoribbons). [130-133,136-143]
The investigatation of P3HT crystallization process in solutions by changing molecular weight
(Mn), crystallization temperature and polymer concentration suggested that P3HT polymer chains
transit from extending to folding in nanowhiskers when the Mn is above a critical value (10 kDa),
and extended P3HT chains can further grow into highly ordered two-dimensional (2D)
nanoribbons by the combination of π-π interaction among polymer backbones and alkyl side chain
Van der Waals interactions. [130]
The formation of P3HT nanocrystals on substrates include carbon nanotubes [104,133,136,144]
and graphene has also been reported. [145] However, the most reported P3HT superamolecular
assemblies are nanowires, which are formed by π-π interactions among polymer backbones. [140-
143,146-150] No formation of P3HT nanoribbons on graphitic substrates is reported in any publications.
8 Here in, we report the formation of P3HT nanocrystals on graphitic substrates with different curvatures (i.e. SWCNTs, MWCNTs, carbon fibers, and graphene). The trend of P3HT nanocrystals formation on graphitic surfaces is studied by applying P3HT with Mn below and above the folding threshold. Computational simulations of single P3HT molecule on carbon materials were used to justify the preferential orientation of P3HT nanocrystals on graphitic surfaces.
Techniques
The techniques used in samples preparations are briefly introduced in the following section.
Chemical Vapor Deposition
Chemical vapor deposition (CVD) is a chemical process used to prepare high quality solid materials with controllable thickness. In a typical CVD process, the substrate is exposed to gases or volatile precursors. Reactions or decompositions happen in the gas phase produce the desired substances on the substrate. In the meantime, by products in the gas phase are removed by gas flow through the reaction chamber.
Schlenk Lines
The Schlenk line is a commonly used chemistry apparatus developed by Wilhelm Schlenk. It consists of two separate gas supply lines with several ports. One gas supply line is connected to a source of inert gases such nitrogen and argon, while the other is connected to a vacuum pump.
Schlenk lines are useful for safely manipulating air-sensitive reactions. The vacuum line is also often used to remove the air from reaction flasks, and the inert gas is backfilled through another
9 line. Also, more than one port on those two lines to make it possible for several reactions to be run simultaneously.
Ball Milling
Ball milling is a method used to grind and blend materials. The size reduction of materials is primary from the impact of balls drops from near the top of the shell of a ball mill machine. A ball mill machine consists of a hollow cylindrical shell, and it is partially filled with balls made of stainless steel, ceramic, or rubber, which are used as grinding media. Ball milling have several advantages over other grinding systems. 1. the cost of installation and grinding medium is low. 2. it is suitable for continuous operation. 3. It is applicable for materials in all degrees of hardness.
[151-155]
Characterizations
All characterizations used to the investigations of samples and devices are briefly introduced in the following section.
Scanning Electron Microscopy
Scanning electron microscopy (SEM) produces images of a sample by scanning the surface with a focused beam of electrons. The electrons interact with atoms in the sample, producing various signals that contain information about the sample's surface morphologies. The most common SEM mode use the detection of secondary electrons emitted from the excitation of the electron beam.
The number of secondary electrons that can be detected depends on specimen topography. Samples for SEM imaging have to be conductive to withstand the vacuum conditions and high energy beam
10 of electrons. Non-conductive specimens collect charges when scanned by the electron beam, and this causes image artifacts. Sputter coating the surface of non-conductive samples with conductive materials, such as gold, gold/palladium alloy, platinum, iridium, tungsten, is one effective method to image non-conductive specimens by SEM.
Energy-Dispersive X-Ray Spectroscopy
Energy-dispersive X-ray spectroscopy (EDS) is an analytical technique used for the analysis a sample. It relies on an interaction of X-ray excitations and a sample. The characteristic X-rays emission is used to characterize atomic compositions in samples. To stimulate the emission of characteristic X-rays from a specimen, a high-energy beam of electrons is focused onto the surface of a sample. The incident electron beam can excite an electron in an inner shell, knocking out it from the shell while creating an electron hole where the electron once was. An electron from an outer, higher-energy shell then fills the hole, and the difference in energy between the higher- energy shell and the lower energy shell may be released in the form of an X-ray. The number and energy of the X-rays emitted from a specimen can be measured by detectors. As the energies of the X-rays are characteristic for each element, thus the elemental composition and the abundance of elements of the specimen can be measured.
Transmission Electron Microscopy
Transmission electron microscopy (TEM) is a kind of electron microscope technique which has a beam of electrons transmitted through a specimen to form an image. The specimen is most often an ultrathin section less than 200 nm thick or substances adhered on a grid. An image is formed from the interaction of the electrons with the sample. Transmission electron microscopes are
11 capable of imaging at a significantly high resolution (<0.1nm) owing to the small de Broglie wavelength of electrons used in the microscope. The high resolution of TEM makes it as a major analytical method in nanoscience. TEM specimens should be less than 200 nm in thickness for conventional TEM imaging.
Selected Area Electron Diffraction
Selected area electron diffraction (SAED) is a technique used to investigate the crystal structure of samples that can be performed inside a TEM. When a thin crystalline sample is subjected to a parallel beam of high energy electrons, some fractions of them will be scattered to particular angles, while others continue to pass through the sample without deflection. As a result, the image on the screen of the TEM will be a series of spots, and each spot corresponding to sample's crystal structure. During a SAED investigation, an aperture is used to block the image of the sample at the focal plane, and only diffractions of samples can be revealed.
Atomic Force Microscopy
Atomic force microscopy (AFM) is a very-high-resolution type of scanning probe microscopy with demonstrated resolution on the order of less than one nanometers. The AFM consists of a cantilever with a sharp tip at its end that is used to scan the specimen surface. The cantilever is typically silicon and silicon nitride, and the tip has a size of less than 10 nm. When the tip is brought into proximity of a sample surface, forces between the tip and the sample lead to a deflection of the cantilever, and it can be processed to get the morphological information of the sample. The AFM can be operated in a number of modes. In general, they can be classified into contact mode and tapping mode.
12 In the contact mode, the tip is literally dragged across the surface of the sample. The morphology of surface is measured either using the deflection of the cantilever directly or using the feedback signal required to keep the cantilever at a constant position which is commonly used in commercial
AFM systems.
In the tapping mode, the cantilever is driven to oscillate up and down at or near its resonance frequency. This oscillation is commonly achieved with a small piezo element in the cantilever holder. In tapping mode, the frequency and amplitude of the driving signal are kept constant, leading to a constant amplitude of the cantilever oscillation as long as there is no drift or interaction with the surface. When the distance of the tip and the sample is closer, the amplitude of the tip will decrease, and the feedback signal loop adjust the height to make the cantilever go back to its original amplitude. As a result, a tapping AFM image with morphological information is creased during scanning.
AFM samples do not have specific preparation processes. AFM tests have to be done in a quiet environment, and the machine should be placed on a stable floating table.
Raman Spectroscopy
Raman spectroscopy is a spectroscopic technique used to observe vibrational, rotational, and other low-frequency modes in a system. Raman spectroscopy is commonly used in chemistry to identify chemicals by observing structural fingerprints. Also, the interactions of molecules can be revealed by the shift of Raman peaks. Raman signals rely on inelastic scattering of monochromatic laser.
The laser light interacts with molecular vibrations, phonons or other excitations in the system, resulting in the energy of the laser photons being shifted up or down. The shift in energy gives
13 information about the vibrational modes in the system. There is no specific required sample
preparation procedure for Raman spectroscopy.
Fourier-Transform Infrared Spectroscopy
Fourier-transform infrared spectroscopy (FTIR) is a technique used to obtain an infrared spectrum
of a solid, liquid or gas. FTIR presents similar, but complementary, information comparing to
Raman spectroscopy. There is no specific required sample preparation procedure for Raman
spectroscopy.
X-Ray Diffraction
X-ray diffraction (XRD) is a technique used for determining the atomic and molecular structure of
a crystal. By measuring the angles and intensities of these diffracted beams, the crystal structure
of a sample can be obtained by comparing to databases. X-ray diffracts in crystals by
following Bragg’s law. No specific sample preparation is needed for XRD tests, but powders used in tests need to be flattened for better results.
X-Ray Photoelectron Spectroscopy
X-ray photoelectron spectroscopy (XPS) is a surface-sensitive quantitative technique that
measures the elemental composition of a material. XPS spectra are obtained by irradiating a
material with a beam of X-ray and measuring the kinetic energy and number of electrons that
escape from the top of the material simultaneously. About 10 nm of the top of materials can be
analyzed. Each element produces a characteristic set of XPS peaks at characteristic binding energy
values which can be used to identify the existence of elements in samples. These characteristic
14 spectral peaks correspond to the electron in different configuration, namely 1s, 2s, 2p, 3s, 3p, 3d,
and so on. The number of detected electrons in each of the characteristic peaks is directly related
to the amount of element in the sample. High vacuum of less than 10−8 mbar is required for XPS
investigations, in consequence, dry samples are required for XPS investigations.
Ultraviolet–Visible Spectroscopy
Ultraviolet–visible spectroscopy (UV-Vis) is used to measure the absorbance of samples at the UV
range of the visible range. The absorbance of light follows Beer-Lambert law in diluted solutions, or deviations may occur. Both solutions and thin films can be used in UV-Vis tests.
Dynamic Light Scattering
Dynamic light scattering (DLS) is a technique that can be used to determine the size distribution
profile of small particles in suspensions. DLS is used to characterize size of various particles
including proteins, polymers, micelles, nanoparticles, and cells. Dispersions are needed for DLS
tests.
Thermogravimetric Analysis
Thermogravimetric analysis (TGA) is a method of thermal analysis in which the mass of a sample
is measure as the temperature changes. This measurement provides information of thermal
stability of samples. TGA can be used to evaluate the thermal stability of a material. The mass loss
over temperature can tell when the decomposition happens and how much mass is lost at certain
temperature. The atmosphere and ramping procedure need to be the same for the comparison of
mass loss between different samples. Samples in powders are usually used in TGA tests.
15 Differential Scanning Calorimetry
Differential scanning calorimetry (DSC) is a thermal analytical technique in which the difference in the amount of heat required to increase the temperature of a sample and reference is measured as a function of temperature. Both the sample and reference are maintained at nearly the same temperature throughout the experiment. Generally, the temperature program for a DSC analysis is designed to be linearly increases as a function of time. The reference sample should have a well- defined heat capacity over the range of temperatures to be scanned. Differential scanning calorimetry can be used to measure a number of characteristic properties of a sample such as crystallization temperature and glass transition temperature. Also, specific heat can be calculated from the data of DSC tests. Powders are usually used in DSC tests.
Gas Chromatography–Mass Spectrometry
Gas chromatography–mass spectrometry (GC-MS) is an analytical method that combines gas- chromatography (GC) and mass-spectroscopy (MS) to identify different substances within a specimen. Gas chromatography utilizes a capillary column to separate molecules because of their different affinity to the column. Molecules are separated by different elution time. After that, the mass spectrometer detects the ionized fragments and their mass-to-charge ratio to identify molecules. By using these two components together, it is not possible to make an accurate identification of a particular molecule by gas chromatography or mass spectrometry alone.
Combining the two processes reduces the possibility of error, as it is extremely unlikely that two different molecules will behave in the same way in both GC and MS. Diluted solutions are needed for GC-MS investigations.
16 Nuclear Magnetic Resonance
Nuclear magnetic resonance (NMR) is a technique usually used to identify molecules. NMR spectra usually have peaks at different chemical shift. By studying the peaks of nuclear magnetic resonance spectra, the structure of compounds can be determined. NMR a very selective technique, thus it is used to unambiguously identify known and novel compounds, and as such, is usually required by scientific journals for identity confirmation of synthesized new compounds. Solutions in deuterated solvents are needed for NMR tests.
Gel Permeation Chromatography
Gel permeation chromatography (GPC) is often used to determine the relative molecular weight of polymer samples as well as the distribution of molecular weight. GPC separates polymer molecules with different molecular weight based on the size. Separation of molecules occurs by the use of porous beads packed in a column. Smaller molecules can enter the pores more easily and therefore spend more time in these pores, thus increase their retention time. In the contrary, larger molecules spend less time in the column because there are less pores they are able to enter.
Samples for GPC tests need to be diluted solutions.
Quartz Crystal Microbalance
The quartz crystal microbalance (QCM) measures a mass variation per unit area by measuring the change in frequency of a quartz crystal resonator. The resonance is disturbed by the addition or removal of a small mass. It is useful for monitoring the rate of deposition in thin film deposition systems under vacuum. In liquid, it is highly effective at determining the affinity of molecules to surfaces functionalized with recognition sites. Frequency measurements are easily leading to high
17 precision. It is easy to measure mass densities down to a level of below 1 μg/cm2. Substances need to have interactions with QCM probes. If materials with no interaction need to be detected, QCM probes coated with substances that are interactive with materials can be used as useful probes.
Four-probes Measurement
Four-probes measurement is a measuring technique that uses separate pairs of current -carrying and voltage -sensing electrodes to make more accurate measurements than the simpler and more usual two-probes measurement. Separation of current and voltage electrodes eliminates the lead and contact resistance from the measurement. This is an advantage for precise measurement of low resistance values. Flat samples are required for normal four probe measurement machines because all four probes are integrated onto one flat chip. For the characterization itself, no specific sample requirement is required.
Thermal Conductivity Measurements
The laser flash method is used to measure thermal diffusivity of a variety of different materials.
An energy pulse heats one side of a plane-parallel sample and the resulting time dependent temperature increment on another side due to the energy input is detected. The higher the thermal diffusivity of the sample, the faster the energy reaches the backside, and the higher increment of the temperature. Perfect conditions for the laser flash method are homogenous material, a homogenous energy input on the front side, and a short pulse. After the measurement of thermal diffusivity, the thermal conductivity of samples can be calculated by using the equation of k =
C , where is the thermal diffusivity, C is the specific heat capacity, and is the density. [156]α ∙
p ∙ ρ α p ρ
18 Disks coated with Pt and graphite aerosol are required for the measurement of thermal diffusivity when using the laser flash method.
References
1. Lee, C.; Wei, X.; Kysar, J.W.; Hone, J. Measurement of the elastic properties and
intrinsic strength of monolayer graphene. Science 2008, 321, 385-388.
2. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Katsnelson, M.I.; Grigorieva,
I.V.; Dubonos, S.V.; Firsov, A.A. Two-dimensional gas of massless dirac fermions in
graphene. Nature 2005, 438, 197-200.
3. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Zhang, Y.; Dubonos, S.V.;
Grigorieva, I.V.; Firsov, A.A. Electric field effect in atomically thin carbon films.
Science 2004, 306, 666-669.
4. Novoselov, K.S.; Jiang, Z.; Zhang, Y.; Morozov, S.V.; Stormer, H.L.; Zeitler, U.; Maan,
J.C.; Boebinger, G.S.; Kim, P.; Geim, A.K. Room-temperature quantum hall effect in
graphene. Science 2007, 315, 1379-1402.
5. Slonczewski, J.C.; Weiss, P.R. Band structure of graphite. Physical Review 1958, 109,
272-279.
6. Zhang, Y.; Tan, Y.-W.; Stormer, H.L.; Kim, P. Experimental observation of the quantum
hall effect and berry's phase in graphene. Nature 2005, 438, 201-204.
7. Balandin, A.A.; Ghosh, S.; Bao, W.; Calizo, I.; Teweldebrhan, D.; Miao, F.; Lau, C.N.
Superior thermal conductivity of single-layer graphene. Nano Letters 2008, 8, 902-907.
8. Hyesung, P.; Jill, A.R.; Ki Kang, K.; Vladimir, B.; Jing, K. Doped graphene electrodes
for organic solar cells. Nanotechnology 2010, 21, 505204-505232.
19 9. Gomez De Arco, L.; Zhang, Y.; Schlenker, C.W.; Ryu, K.; Thompson, M.E.; Zhou, C.
Continuous, highly flexible, and transparent graphene films by chemical vapor deposition
for organic photovoltaics. ACS Nano 2010, 4, 2865-2873.
10. Wu, J.; Becerril, H.A.; Bao, Z.; Liu, Z.; Chen, Y.; Peumans, P. Organic solar cells with
solution-processed graphene transparent electrodes. Applied Physics Letters 2008, 92,
263302-263315.
11. Dharmendar, R.; Leonard, F.R.; Gary, D.C.; Sanjay, K.B. Graphene field-effect
transistors. Journal of Physics D: Applied Physics 2011, 44, 313001-313034.
12. Lemme, M.C.; Echtermeyer, T.J.; Baus, M.; Kurz, H. A graphene field-effect device.
IEEE Electron Device Letters 2007, 28, 282-284.
13. Xia, F.; Farmer, D.B.; Lin, Y.-m.; Avouris, P. Graphene field-effect transistors with high
on/off current ratio and large transport band gap at room temperature. Nano Letters 2010,
10, 715-718.
14. Meric, I.; Han, M.Y.; Young, A.F.; Ozyilmaz, B.; Kim, P.; Shepard, K.L. Current
saturation in zero-bandgap, top-gated graphene field-effect transistors. Nature
Nanotechnology 2008, 3, 654-667.
15. Vicarelli, L.; Vitiello, M.S.; Coquillat, D.; Lombardo, A.; Ferrari, A.C.; Knap, W.; Polini,
M.; Pellegrini, V.; Tredicucci, A. Graphene field-effect transistors as room-temperature
terahertz detectors. Nature Materials 2012, 11, 865-873.
16. Song, S.H.; Jang, M.-H.; Chung, J.; Jin, S.H.; Kim, B.H.; Hur, S.-H.; Yoo, S.; Cho, Y.-
H.; Jeon, S. Highly efficient light-emitting diode of graphene quantum dots fabricated
from graphite intercalation compounds. Advanced Optical Materials 2014, 2, 1016-1023.
20 17. Kucinskis, G.; Bajars, G.; Kleperis, J. Graphene in lithium ion battery cathode materials:
A review. Journal of Power Sources 2013, 240, 66-79.
18. Chen, L.; Wang, X.; Zhang, X.; Zhang, H. 3d porous and redox-active prussian blue-in-
graphene aerogels for highly efficient electrochemical detection of h2o2. Journal of
Materials Chemistry 2012, 22, 22090-22096.
19. Liang, J.; Liu, Y.; Guo, L.; Li, L. Facile one-step synthesis of a 3d macroscopic sno2-
graphene aerogel and its application as a superior anode material for li-ion batteries. RSC
Advances 2013, 3, 11489-11492.
20. Wu, T.; Chen, M.; Zhang, L.; Xu, X.; Liu, Y.; Yan, J.; Wang, W.; Gao, J. Three-
dimensional graphene-based aerogels prepared by a self-assembly process and its
excellent catalytic and absorbing performance. Journal of Materials Chemistry A 2013, 1,
7612-7621.
21. Xiao, L.; Wu, D.; Han, S.; Huang, Y.; Li, S.; He, M.; Zhang, F.; Feng, X. Self-assembled
fe2o3/graphene aerogel with high lithium storage performance. ACS Applied Materials &
Interfaces 2013, 5, 3764-3769.
22. Chen, M.; Zhang, C.; Li, X.; Zhang, L.; Ma, Y.; Zhang, L.; Xu, X.; Xia, F.; Wang, W.;
Gao, J. A one-step method for reduction and self-assembling of graphene oxide into
reduced graphene oxide aerogels. Journal of Materials Chemistry A 2013, 1, 2869-2877.
23. Nardecchia, S.; Carriazo, D.; Ferrer, M.L.; Gutierrez, M.C.; del Monte, F. Three
dimensional macroporous architectures and aerogels built of carbon nanotubes and/or
graphene: Synthesis and applications. Chemical Society Reviews 2013, 42, 794-830.
21 24. Das, S.; Irin, F.; Ma, L.; Bhattacharia, S.K.; Hedden, R.C.; Green, M.J. Rheology and
morphology of pristine graphene/polyacrylamide gels. ACS Applied Materials &
Interfaces 2013, 5, 8633-8640.
25. Ji, C.-C.; Xu, M.-W.; Bao, S.-J.; Cai, C.-J.; Lu, Z.-J.; Chai, H.; Yang, F.; Wei, H. Self-
assembly of three-dimensional interconnected graphene-based aerogels and its
application in supercapacitors. Journal of Colloid and Interface Science 2013, 407, 416-
424.
26. Ye, S.; Feng, J.; Wu, P. Deposition of three-dimensional graphene aerogel on nickel foam
as a binder-free supercapacitor electrode. ACS Appl. Mater. Interfaces 2013, 5, 7122-
7129.
27. Yu, Z.; McInnis, M.; Calderon, J.; Seal, S.; Zhai, L.; Thomas, J. Functionalized graphene
aerogel composites for high-performance asymmetric supercapacitors. Nano Energy
2015, 11, 611-620.
28. Zhao, L.; Wang, Z.-B.; Li, J.-L.; Zhang, J.-J.; Sui, X.-L.; Zhang, L.-M. One-pot synthesis
of a three-dimensional graphene aerogel supported pt catalyst for methanol
electrooxidation. RSC Advances 2015, 5, 98160-98165.
29. Singh, S.; Tripathi, P.; Bhatnagar, A.; Prakash Patel, C.R.; Singh, A.P.; Dhawan, S.K.;
Gupta, B.K.; Srivastava, O.N. A highly porous, light weight 3d sponge like graphene
aerogel for electromagnetic interference shielding applications. RSC Advances 2015, 5,
107083-107087.
30. Liu, M.; Peng, C.; Yang, W.; Guo, J.; Zheng, Y.; Chen, P.; Huang, T.; Xu, J. Pd
nanoparticles supported on three-dimensional graphene aerogels as highly efficient
catalysts for methanol electrooxidation. Electrochimica Acta 2015, 178, 838-846.
22 31. Harley-Trochimczyk, A.; Chang, J.; Zhou, Q.; Dong, J.; Pham, T.; Worsley, M.A.;
Maboudian, R.; Zettl, A.; Mickelson, W. Catalytic hydrogen sensing using microheated
platinum nanoparticle-loaded graphene aerogel. Sensors and Actuators B: Chemical
2015, 206, 399-406.
32. Peng, L.; Zheng, Y.; Li, J.; Jin, Y.; Gao, C. Monolithic neat graphene oxide aerogel for
efficient catalysis of s → o acetyl migration. ACS Catalysis 2015, 5, 3387-3392.
33. Li, J.; Xie, J.; Gao, L.; Li, C.M. Au nanoparticles–3d graphene hydrogel nanocomposite
to boost synergistically in situ detection sensitivity toward cell-released nitric oxide. ACS
Appl. Mater. Interfaces 2015, 7, 2726-2734.
34. Dikin, D.A.; Stankovich, S.; Zimney, E.J.; Piner, R.D.; Dommett, G.H.B.; Evmenenko,
G.; Nguyen, S.T.; Ruoff, R.S. Preparation and characterization of graphene oxide paper.
Nature 2007, 448, 457-461.
35. Chen, J.; Yao, B.; Li, C.; Shi, G. An improved hummers method for eco-friendly
synthesis of graphene oxide. Carbon 2013, 64, 225-229.
36. Marcano, D.C.; Kosynkin, D.V.; Berlin, J.M.; Sinitskii, A.; Sun, Z.; Slesarev, A.;
Alemany, L.B.; Lu, W.; Tour, J.M. Improved synthesis of graphene oxide. ACS Nano
2010, 4, 4806-4814.
37. Paredes, J.I.; Villar-Rodil, S.; Martínez-Alonso, A.; Tascón, J.M.D. Graphene oxide
dispersions in organic solvents. Langmuir 2008, 24, 10560-10564.
38. Huang, H.; Chen, P.; Zhang, X.; Lu, Y.; Zhan, W. Edge-to-edge assembled graphene
oxide aerogels with outstanding mechanical performance and superhigh chemical
activity. Small 2013, 9, 1397-1404.
23 39. Qian, Y.; Ismail, I.M.; Stein, A. Ultralight, high-surface-area, multifunctional graphene-
based aerogels from self-assembly of graphene oxide and resol. Carbon 2014, 68, 221-
231.
40. Shen, C.; Calderon, J.E.; Barrios, E.; Soliman, M.; Khater, A.; Jeyaranjan, A.; Tetard, L.;
Gordon, A.; Seal, S.; Zhai, L. Anisotropic electrical conductivity in polymer derived
ceramics induced by graphene aerogels. Journal of Materials Chemistry C 2017, 5,
11708-11716.
41. Yin, S.; Niu, Z.; Chen, X. Assembly of graphene sheets into 3d macroscopic structures.
Small 2012, 8, 2458-2463.
42. Vuluga, D.; Thomassin, J.-M.; Molenberg, I.; Huynen, I.; Gilbert, B.; Jerome, C.;
Alexandre, M.; Detrembleur, C. Straightforward synthesis of conductive
graphene/polymer nanocomposites from graphite oxide. Chemical Communications
2011, 47, 2544-2546.
43. Wang, M.; Duong, L.D.; Oh, J.-S.; Mai, N.T.; Kim, S.; Hong, S.; Hwang, T.; Lee, Y.;
Nam, J.-D. Large-area, conductive and flexible reduced graphene oxide (rgo) membrane
fabricated by electrophoretic deposition (epd). ACS Applied Materials & Interfaces 2014,
6, 1747-1753.
44. Xu, Z.; Zhang, Y.; Li, P.; Gao, C. Strong, conductive, lightweight, neat graphene aerogel
fibers with aligned pores. ACS nano 2012, 6, 7103-7113.
45. Schiffres, S.N.; Harish, S.; Maruyama, S.; Shiomi, J.; Malen, J.A. Tunable electrical and
thermal transport in ice-templated multilayer graphene nanocomposites through freezing
rate control. ACS Nano 2013, 7, 11183-11189.
24 46. Ruiyi, L.; Juanjuan, Z.; Zhouping, W.; Zaijun, L.; Junkang, L.; Zhiguo, G.; Guangli, W.
Novel graphene-gold nanohybrid with excellent electrocatalytic performance for the
electrochemical detection of glucose. Sensors and Actuators B: Chemical 2015, 208, 421-
428.
47. Yin, P.T.; Kim, T.-H.; Choi, J.-W.; Lee, K.-B. Prospects for graphene-nanoparticle-based
hybrid sensors. PCCP 2013, 15, 12785-12799.
48. Yun, S.; Lee, S.; Shin, C.; Park, S.; Kwon, S.J.; Park, H.S. One-pot self-assembled,
reduced graphene oxide/palladium nanoparticle hybrid aerogels for electrocatalytic
applications. Electrochim. Acta 2015, 180, 902-908.
49. Cong, H.-P.; Ren, X.-C.; Wang, P.; Yu, S.-H. Macroscopic multifunctional graphene-
based hydrogels and aerogels by a metal ion induced self-assembly process. ACS Nano
2012, 6, 2693-2703.
50. Liu, C.; Zhang, H.; Tang, Y.; Luo, S. Controllable growth of graphene/cu composite and
its nanoarchitecture-dependent electrocatalytic activity to hydrazine oxidation. Journal of
Materials Chemistry A 2014, 2, 4580-4587.
51. Colombo, P.; Mera, G.; Riedel, R.; Sorarù, G.D. Polymer-derived ceramics: 40 years of
research and innovation in advanced ceramics. Journal of the American Ceramic Society
2010, 93, 1805-1837.
52. Ziegler, G.; Kleebe, H.J.; Motz, G.; Müller, H.; Traßl, S.; Weibelzahl, W. Synthesis,
microstructure and properties of sicn ceramics prepared from tailored polymers.
Materials Chemistry and Physics 1999, 61, 55-63.
53. Bill, J.; Aldinger, F. Precursor-derived covalent ceramics*. Advanced Materials 1995, 7,
775-787.
25 54. Riedel, R.; Kienzle, A.; Dressler, W.; Ruwisch, L.; Bill, J.; Aldinger, F. A silicoboron
carbonitride ceramic stable to 2,000°c. Nature 1996, 382, 796-806.
55. Wang, Z.-C.; Aldinger, F.; Riedel, R. Novel silicon-boron-carbon-nitrogen materials
thermally stable up to 2200°c. Journal of the American Ceramic Society 2001, 84, 2179-
2183.
56. Eckel, Z.C.; Zhou, C.; Martin, J.H.; Jacobsen, A.J.; Carter, W.B.; Schaedler, T.A.
Additive manufacturing of polymer-derived ceramics. Science 2016, 351, 58-62.
57. Hoy, C.V.; Barda, A.; Griffith, M.; Halloran, J.W. Microfabrication of ceramics by co-
extrusion. Journal of the American Ceramic Society 1998, 81, 152-158.
58. Wang, S.; Li, J.-F.; Watanabe, R.; Esashi, M. Fabrication of lead zirconate titanate
microrods for 1–3 piezocomposites using hot isostatic pressing with silicon molds.
Journal of the American Ceramic Society 1999, 82, 213-215.
59. Vorotilov, K.; Petrovsky, V.; Vasiljev, V. Spin coating process of sol-gel silicate films
deposition: Effect of spin speed and processing temperature. Journal of Sol-Gel Science
and Technology 1995, 5, 173-183.
60. Nguyen, M.D.; Bang, J.W.; Bin, A.S.; Kim, S.-R.; Kim, Y.; Hwang, K.H.; Pham, V.-H.;
Kwon, W.-T. Novel polymer-derived ceramic environmental barrier coating system for
carbon steel in oxidizing environments. Journal of the European Ceramic Society 2017,
37, 2001-2010.
61. David, L.; Shareef, K.M.; Abass, M.A.; Singh, G. Three-dimensional polymer-derived
ceramic/graphene paper as a li-ion battery and supercapacitor electrode. RSC Advances
2016, 6, 53894-53902.
26 62. Yajima, S.; Hayashi, J.; Omori, M.; Okamura, K. Development of a silicon carbide fibre
with high tensile strength. Nature 1976, 261, 683-801.
63. Yajima, S.; Okamura, K.; Hayashi, J.; Omori, M. Synthesis of continuous sic fibers with
high tensile strength. Journal of the American Ceramic Society 1976, 59, 324-327.
64. Majoulet, O.; Alauzun, J.G.; Gottardo, L.; Gervais, C.; Schuster, M.E.; Bernard, S.;
Miele, P. Ordered mesoporous silicoboron carbonitride ceramics from boron-modified
polysilazanes: Polymer synthesis, processing and properties. Microporous and
Mesoporous Materials 2011, 140, 40-50.
65. Shi, Y.; Wan, Y.; Zhao, D. Ordered mesoporous non-oxide materials. Chemical Society
Reviews 2011, 40, 3854-3878.
66. Borchardt, L.; Hoffmann, C.; Oschatz, M.; Mammitzsch, L.; Petasch, U.; Herrmann, M.;
Kaskel, S. Preparation and application of cellular and nanoporous carbides. Chemical
Society Reviews 2012, 41, 5053-5067.
67. Günthner, M.; Schütz, A.; Glatzel, U.; Wang, K.; Bordia, R.K.; Greißl, O.; Krenkel, W.;
Motz, G. High performance environmental barrier coatings, part i: Passive filler loaded
sicn system for steel. Journal of the European Ceramic Society 2011, 31, 3003-3010.
68. Prasad, R.M.; Iwamoto, Y.; Riedel, R.; Gurlo, A. Multilayer amorphous-si-b-c-n/γ-
al2o3/α-al2o3 membranes for hydrogen purification. Advanced Engineering Materials
2010, 12, 522-528.
69. Riedel, R.; Passing, G.; Schönfelder, H.; Brook, R.J. Synthesis of dense silicon-based
ceramics at low temperatures. Nature 1992, 355, 714-721.
70. Liew, L.-A.; Saravanan, R.A.; Bright, V.M.; Dunn, M.L.; Daily, J.W.; Raj, R. Processing
and characterization of silicon carbon-nitride ceramics: Application of electrical
27 properties towards mems thermal actuators. Sensors and Actuators A: Physical 2003,
103, 171-181.
71. Liew, L.-A.; Liu, Y.; Luo, R.; Cross, T.; An, L.; Bright, V.M.; Dunn, M.L.; Daily, J.W.;
Raj, R. Fabrication of sicn mems by photopolymerization of pre-ceramic polymer.
Sensors and Actuators A: Physical 2002, 95, 120-134.
72. Asthana, A.; Kim, K.-O.; Perumal, J.; Kim, D.-M.; Kim, D.-P. Facile single step
fabrication of microchannels with varying size. Lab on a Chip 2009, 9, 1138-1142.
73. David, L.; Bhandavat, R.; Barrera, U.; Singh, G. Silicon oxycarbide glass-graphene
composite paper electrode for long-cycle lithium-ion batteries. Nat Commun 2016, 7,
137-140.
74. David, L.; Bhandavat, R.; Barrera, U.; Singh, G. Polymer-derived ceramic functionalized
mos2 composite paper as a stable lithium-ion battery electrode. Scientific Reports 2015,
5, 9792.
75. Oschatz, M.; Kockrick, E.; Rose, M.; Borchardt, L.; Klein, N.; Senkovska, I.;
Freudenberg, T.; Korenblit, Y.; Yushin, G.; Kaskel, S. A cubic ordered, mesoporous
carbide-derived carbon for gas and energy storage applications. Carbon 2010, 48, 3987-
3992.
76. Zhao, R.; Shao, G.; Cao, Y.; An, L.; Xu, C. Temperature sensor made of polymer-derived
ceramics for high-temperature applications. Sensors and Actuators, A 2014, 219, 58-64.
77. Nagaiah, N.R.; Kapat, J.S.; An, L.; Chow, L. Novel polymer derived ceramic-high
temperature heat flux sensor for gas turbine environment. Journal of Physics: Conference
Series 2006, 34, 458-463.
28 78. Li, Y.; Yu, Y.; San, H.; Wang, Y.; An, L. Wireless passive polymer-derived sicn ceramic
sensor with integrated resonator/antenna. Applied Physics Letters 2013, 103, 163505.
79. Zhao, R.; Shao, G.; Cao, Y.; An, L.; Xu, C. Temperature sensor made of polymer-derived
ceramics for high-temperature applications. Sensors and Actuators A: Physical 2014,
219, 58-64.
80. Cordelair, J.; Greil, P. Electrical conductivity measurements as a microprobe for structure
transitions in polysiloxane derived si–o–c ceramics. Journal of the European Ceramic
Society 2000, 20, 1947-1957.
81. Shao, G.; Peng, W.; Ma, C.; Zhao, W.; Guo, J.; Feng, Y.; Wang, H.; Zhang, R.; An, L.
Enhanced electric conductivity of polymer-derived sicn ceramics by microwave post-
treatment. Journal of the American Ceramic Society 2017, 100, 842-847.
82. Mamunya, Y. Carbon nanotubes as conductive filler in segregated polymer composites -
electrical properties. In Carbon nanotubes - polymer nanocomposites, Yellampalli, S.,
Ed. InTech: Rijeka, 2011, 10, 42-47.
83. Sarkar, S.; Zou, J.; Liu, J.; Xu, C.; An, L.; Zhai, L. Polymer-derived ceramic composite
fibers with aligned pristine multiwalled carbon nanotubes. ACS Applied Materials &
Interfaces 2010, 2, 1150-1156.
84. Shopova-Gospodinova, D.; Burghard, Z.; Dufaux, T.; Burghard, M.; Bill, J. Mechanical
and electrical properties of polymer-derived si–c–n ceramics reinforced by
octadecylamine – modified single-wall carbon nanotubes. Composites Science and
Technology 2011, 71, 931-937.
29 85. Ionescu, E.; Francis, A.; Riedel, R. Dispersion assessment and studies on ac percolative
conductivity in polymer-derived si–c–n/cnt ceramic nanocomposites. Journal of
Materials Science 2009, 44, 2055-2062.
86. Shibuya, M.; Sakurai, M.; Takahashi, T. Preparation and characteristics of a vapor-grown
carbon fiber/ceramic composite using a methylsilicone precursor. Composites Science
and Technology 2007, 67, 3338-3344.
87. Xu, H.-P.; Dang, Z.-M.; Shi, D.-H.; Bai, J.-B. Remarkable selective localization of
modified nanoscaled carbon black and positive temperature coefficient effect in binary-
polymer matrix composites. Journal of Materials Chemistry 2008, 18, 2685-2690.
88. Ke, K.; Pötschke, P.; Wiegand, N.; Krause, B.; Voit, B. Tuning the network structure in
poly(vinylidene fluoride)/carbon nanotube nanocomposites using carbon black: Toward
improvements of conductivity and piezoresistive sensitivity. ACS Applied Materials &
Interfaces 2016, 8, 14190-14199.
89. Lin, Y.; Liu, S.; Liu, L. A new approach to construct three dimensional segregated
graphene structures in rubber composites for enhanced conductive, mechanical and
barrier properties. Journal of Materials Chemistry C 2016, 4, 2353-2358.
90. Wang, X.; Mera, G.; Morita, K.; Ionescu, E. Synthesis of polymer-derived
graphene/silicon nitride-based nanocomposites with tunable dielectric properties. Journal
of the Ceramic Society of Japan 2016, 124, 981-988.
91. Ji, F.; Li, Y.-L.; Feng, J.-M.; Su, D.; Wen, Y.-Y.; Feng, Y.; Hou, F. Electrochemical
performance of graphene nanosheets and ceramic composites as anodes for lithium
batteries. Journal of Materials Chemistry 2009, 19, 9063-9067.
30 92. Cordelair, J.; Greil, P. Electrical characterization of polymethylsiloxane/mosi2-derived
composite ceramics. Journal of the American Ceramic Society 2001, 84, 2256-2259.
93. Borrell, A.; Álvarez, I.; Torrecillas, R.; Rocha, V.G.; Fernández, A. Microstructural
design for mechanical and electrical properties of spark plasma sintered al2o3–sic
nanocomposites. Materials Science and Engineering: A 2012, 534, 693-698.
94. Wang, S.; Zhang, X.; Wu, X.; Lu, C. Tailoring percolating conductive networks of
natural rubber composites for flexible strain sensors via a cellulose nanocrystal templated
assembly. Soft Matter 2016, 12, 845-852.
95. Noh, Y.J.; Joh, H.-I.; Yu, J.; Hwang, S.H.; Lee, S.; Lee, C.H.; Kim, S.Y.; Youn, J.R.
Ultra-high dispersion of graphene in polymer composite via solvent free fabrication and
functionalization. Scientific Reports 2015, 5, 9141.
96. Shen, C.; Calderon, J.E.; Barrios, E.; Soliman, M.; Khater, A.; Jeyaranjan, A.; Tetard, L.;
Gordon, A.; Seal, S.; Zhai, L. Anisotropic electrical conductivity in polymer derived
ceramics induced by graphene aerogels. Journal of Materials Chemistry C 2017.
97. Shahil, K.M.F.; Balandin, A.A. Thermal properties of graphene and multilayer graphene:
Applications in thermal interface materials. Solid State Communications 2012, 152,
1331-1340.
98. Yang, M.; Hou, Y.; Kotov, N.A. Graphene-based multilayers: Critical evaluation of
materials assembly techniques. Nano Today 2012, 7, 430-447.
99. Sadeghi, M.M.; Jo, I.; Shi, L. Phonon-interface scattering in multilayer graphene on an
amorphous support. Proc. Natl. Acad. Sci. U. S. A. 2013, 110, 16321-16326.
31 100. Katz, H.E.; Bao, Z.N.; Gilat, S.L. Synthetic chemistry for ultrapure, processable, and
high-mobility organic transistor semiconductors. Accounts of Chemical Research 2001,
34, 359-369.
101. Bao, Z.; Dodabalapur, A.; Lovinger, A.J. Soluble and processable regioregular poly(3-
hexylthiophene) for thin film field-effect transistor applications with high mobility.
Applied Physics Letters 1996, 69, 4108-4110.
102. Salleo, A.; Chabinyc, M.L.; Yang, M.S.; Street, R.A. Polymer thin-film transistors with
chemically modified dielectric interfaces. Applied Physics Letters 2002, 81, 4383-4385.
103. Sirringhaus, H.; Wilson, R.J.; Friend, R.H.; Inbasekaran, M.; Wu, W.; Woo, E.P.; Grell,
M.; Bradley, D.D.C. Mobility enhancement in conjugated polymer field-effect transistors
through chain alignment in a liquid-crystalline phase. Applied Physics Letters 2000, 77,
406-408.
104. Sirringhaus, H.; Brown, P.J.; Friend, R.H.; Nielsen, M.M.; Bechgaard, K.; Langeveld-
Voss, B.M.W.; Spiering, A.J.H.; Janssen, R.A.J.; Meijer, E.W.; Herwig, P., et al. Two-
dimensional charge transport in self-organized, high-mobility conjugated polymers.
Nature 1999, 401, 685-688.
105. Fabiano, S.; Musumeci, C.; Chen, Z.; Scandurra, A.; Wang, H.; Loo, Y.-L.; Facchetti, A.;
Pignataro, B. From monolayer to multilayer n-channel polymeric field-effect transistors
with precise conformational order. Advanced Materials 2012, 24, 951-956.
106. Osaka, I.; Zhang, R.; Sauve, G.; Smilgies, D.-M.; Kowalewski, T.; McCullough, R.D.
High-lamellar ordering and amorphous-like pi-network in short-chain thiazolothiazole-
thiophene copolymers lead to high mobilities. Journal of the American Chemical Society
2009, 131, 2521-2529.
32 107. Tsao, H.N.; Mullen, K. Improving polymer transistor performance via morphology
control. Chemical Society Reviews 2010, 39, 2372-2386.
108. Zotti, G.; Vercelli, B.; Berlin, A. Monolayers and multilayers of conjugated polymers as
nanosized electronic components. Accounts of Chemical Research 2008, 41, 1098-1109.
109. Lafferentz, L.; Ample, F.; Yu, H.; Hecht, S.; Joachim, C.; Grill, L. Conductance of a
single conjugated polymer as a continuous function of its length. Science 2009, 323,
1193-1197.
110. Leroux, Y.R.; Lacroix, J.C.; Chane-Ching, K.I.; Fave, C.; Felidj, N.; Levi, G.; Aubard, J.;
Krenn, J.R.; Hohenau, A. Conducting polymer electrochemical switching as an easy
means for designing active plasmonic devices. J. Am. Chem. Soc. 2005, 127, 16022-
16023.
111. Thompson, B.C.; Frechet, J.M.J. Organic photovoltaics - polymer-fullerene composite
solar cells. Angewandte Chemie-International Edition 2008, 47, 58-77.
112. Chen, H.-Y.; Hou, J.; Zhang, S.; Liang, Y.; Yang, G.; Yang, Y.; Yu, L.; Wu, Y.; Li, G.
Polymer solar cells with enhanced open-circuit voltage and efficiency. Nature Photonics
2009, 3, 649-653.
113. Mondal, R.; Becerril, H.A.; Verploegen, E.; Kim, D.; Norton, J.E.; Ko, S.; Miyaki, N.;
Lee, S.; Toney, M.F.; Bredas, J.-L., et al. Thiophene-rich fused-aromatic thienopyrazine
acceptor for donor-acceptor low band-gap polymers for otft and polymer solar cell
applications. Journal of Materials Chemistry 2010, 20, 5823-5834.
114. Price, S.C.; Stuart, A.C.; You, W. Polycyclic aromatics with flanking thiophenes: Tuning
energy level and band gap of conjugated polymers for bulk heterojunction photovoltaics.
Macromolecules 2010, 43, 797-804.
33 115. Price, S.C.; Stuart, A.C.; You, W. Low band gap polymers based on benzo 1,2-b:4,5-b '
dithiophene: Rational design of polymers leads to high photovoltaic performance.
Macromolecules 2010, 43, 4609-4612.
116. Huo, L.; Hou, J.; Zhang, S.; Chen, H.-Y.; Yang, Y. A polybenzo 1,2-b:4,5-b ' dithiophene
derivative with deep homo level and its application in high-performance polymer solar
cells. Angewandte Chemie-International Edition 2010, 49, 1500-1503.
117. Bundgaard, E.; Hagemann, O.; Manceau, M.; Jorgensen, M.; Krebs, F.C. Low band gap
polymers for roll-to-roll coated polymer solar cells. Macromolecules 2010, 43, 8115-
8120.
118. Liang, Y.; Wu, Y.; Feng, D.; Tsai, S.-T.; Son, H.-J.; Li, G.; Yu, L. Development of new
semiconducting polymers for high performance solar cells. Journal of the American
Chemical Society 2009, 131, 56-57
119. Yao, Y.; Hou, J.; Xu, Z.; Li, G.; Yang, Y. Effect of solvent mixture on the nanoscale
phase separation in polymer solar cells. Advanced Functional Materials 2008, 18, 1783-
1789.
120. Lee, J.K.; Ma, W.L.; Brabec, C.J.; Yuen, J.; Moon, J.S.; Kim, J.Y.; Lee, K.; Bazan, G.C.;
Heeger, A.J. Processing additives for improved efficiency from bulk heterojunction solar
cells. Journal of the American Chemical Society 2008, 130, 3619-3623.
121. Sivula, K.; Ball, Z.T.; Watanabe, N.; Frechet, J.M.J. Amphiphilic diblock copolymer
compatibilizers and their effect on the morphology and performance of polythiophene:
Fullerene solar cells. Advanced Materials 2006, 18, 206-210.
122. Parnell, A.J.; Dunbar, A.D.F.; Pearson, A.J.; Staniec, P.A.; Dennison, A.J.C.;
Hamamatsu, H.; Skoda, M.W.A.; Lidzey, D.G.; Jones, R.A.L. Depletion of pcbm at the
34 cathode interface in p3ht/pcbm thin films as quantified via neutron reflectivity
measurements. Advanced Materials 2010, 22, 2444-2447.
123. Zhokhavets, U.; Erb, T.; Hoppe, H.; Gobsch, G.; Sariciftci, N.S. Effect of annealing of
poly(3-hexylthiophene)/fullerene bulk heterojunction composites on structural and
optical properties. Thin Solid Films 2006, 496, 679-682.
124. Ma, W.L.; Yang, C.Y.; Gong, X.; Lee, K.; Heeger, A.J. Thermally stable, efficient
polymer solar cells with nanoscale control of the interpenetrating network morphology.
Advanced Functional Materials 2005, 15, 1617-1622.
125. Padinger, F.; Rittberger, R.S.; Sariciftci, N.S. Effects of postproduction treatment on
plastic solar cells. Advanced Functional Materials 2003, 13, 85-88.
126. Yang, Y.; Mielczarek, K.; Aryal, M.; Zakhidov, A.; Hu, W. Nanoimprinted polymer solar
cell. ACS Nano 2012, 6, 2877-2892.
127. Zhang, R.; Li, B.; Iovu, M.C.; Jeffries-El, M.; Sauvé, G.; Cooper, J.; Jia, S.; Tristram-
Nagle, S.; Smilgies, D.M.; Lambeth, D.N., et al. Nanostructure dependence of field-
effect mobility in regioregular poly(3-hexylthiophene) thin film field effect transistors.
Journal of the American Chemical Society 2006, 128, 3480-3481.
128. Noriega, R.; Rivnay, J.; Vandewal, K.; Koch, F.P.V.; Stingelin, N.; Smith, P.; Toney,
M.F.; Salleo, A. A general relationship between disorder, aggregation and charge
transport in conjugated polymers. Nat Mater 2013, 12, 1037-1043.
129. Sarker, B.K.; Liu, J.; Zhai, L.; Khondaker, S.I. Fabrication of organic field effect transistor
by directly grown poly(3 hexylthiophene) crystalline nanowires on carbon nanotube
aligned array electrode. Acs Applied Materials & Interfaces 2011, 3, 1180-1185.
35 130. Liu, J.; Arif, M.; Zou, J.; Khondaker, S.I.; Zhai, L. Controlling poly(3-hexylthiophene)
crystal dimension: Nanowhiskers and nanoribbons. Macromolecules 2009, 42, 9390-
9393.
131. Chunder, A.; Liu, J.; Zhai, L. Reduced graphene oxide/poly(3-hexylthiophene)
supramolecular composites. Macromolecular Rapid Communications 2010, 31, 380-384.
132. Arif, M.; Liu, J.; Zhai, L.; Khondaker, S.I. Poly(3-hexylthiophene) crystalline nanoribbon
network for organic field effect transistors. Applied Physics Letters 2010, 96, 243304-
243316.
133. Sarker, B.K.; Liu, J.; Zhai, L.; Khondaker, S.I. Fabrication of organic field effect
transistor by directly grown poly(3 hexylthiophene) crystalline nanowires on carbon
nanotube aligned array electrode. Acs Applied Materials & Interfaces 2011, 3, 1180-
1185.
134. Liu, J.; Mikhaylov, I.A.; Zou, J.; Osaka, I.; Masunov, A.E.; McCullough, R.D.; Zhai, L.
Insight into how molecular structures of thiophene-based conjugated polymers affect
crystallization behaviors. Polymer 2011, 52, 2302-2309.
135. Zhai, L.; Khondaker, S.I.; Thomas, J.; Shen, C.; McInnis, M. Ordered conjugated
polymer nano- and microstructures: Structure control for improved performance of
organic electronics. Nano Today 2014, 9, 705-721.
136. Liu, J.; Zou, J.; Zhai, L. Bottom-up assembly of poly(3-hexylthiophene) on carbon
nanotubes: 2d building blocks for nanoscale circuits. Macromolecular Rapid
Communications 2009, 30, 1387-1391.
36 137. Oh, J.Y.; Shin, M.; Lee, T.I.; Jang, W.S.; Min, Y.; Myoung, J.-M.; Baik, H.K.; Jeong, U.
Self-seeded growth of poly(3-hexylthiophene) (p3ht) nanofibrils by a cycle of cooling
and heating in solutions. Macromolecules 2012, 45, 7504-7513.
138. Keum, J.K.; Xiao, K.; Ivanov, I.N.; Hong, K.; Browning, J.F.; Smith, G.S.; Shao, M.;
Littrell, K.C.; Rondinone, A.J.; Andrew Payzant, E., et al. Solvent quality-induced
nucleation and growth of parallelepiped nanorods in dilute poly(3-hexylthiophene) (p3ht)
solution and the impact on the crystalline morphology of solution-cast thin film.
CrystEngComm 2013, 15, 1114-1124.
139. Poelking, C.; Andrienko, D. Effect of polymorphism, regioregularity and paracrystallinity
on charge transport in poly(3-hexylthiophene) [p3ht] nanofibers. Macromolecules 2013,
46, 8941-8956.
140. Mazzio, K.A.; Rice, A.H.; Durban, M.M.; Luscombe, C.K. Effect of regioregularity on
charge transport and structural and excitonic coherence in poly(3-hexylthiophene)
nanowires. J. Phys. Chem. C 2015, 119, 14911-14918.
141. McFarland, F.M.; Ellis, C.M.; Guo, S. The aggregation of poly(3-hexylthiophene) into
nanowires: With and without chemical doping. J. Phys. Chem. C 2017, 121, 4740-4746.
142. Yagmurcukardes, M.; Kiymaz, D.; Zafer, C.; Senger, R.T.; Sahin, H. Atomic-scale
understanding of dichlorobenzene-assisted poly 3-hexylthiophene-2,5-diyl nanowire
formation mechanism. Journal of Molecular Structure 2017, 1134, 681-686.
143. Persson, N.E.; Chu, P.-H.; McBride, M.; Grover, M.; Reichmanis, E. Nucleation, growth,
and alignment of poly(3-hexylthiophene) nanofibers for high-performance ofets.
Accounts of Chemical Research 2017, 50, 932-942.
37 144. Giulianini, M.; Waclawik, E.R.; Bell, J.M.; Scarselli, M.; Castrucci, P.; Crescenzi, M.D.;
Motta, N. Microscopic and spectroscopic investigation of poly(3-hexylthiophene)
interaction with carbon nanotubes. Polymers 2011, 51, 33-42..
145. Acevedo-Cartagena, D.E.; Zhu, J.; Trabanino, E.; Pentzer, E.; Emrick, T.; Nonnenmann,
S.S.; Briseno, A.L.; Hayward, R.C. Selective nucleation of poly(3-hexyl thiophene)
nanofibers on multilayer graphene substrates. ACS Macro Letters 2015, 4, 483-487.
146. Liu, S.; Ma, X.; Wang, B.; Shang, X.; Wang, W.; Yu, X. Investigation the effect of
thermal annealing on p3ht nanofibers by scanning probe microscopy: From single chain
conformation, self-assembly to interfacial interactions with go. ChemPhysChem 2016, 5,
144-164.
147. Kim, F.S.; Ren, G.; Jenekhe, S.A. One-dimensional nanostructures of π-conjugated
molecular systems: Assembly, properties, and applications from photovoltaics, sensors,
and nanophotonics to nanoelectronics†. Chemistry of Materials 2011, 23, 682-732.
148. Yang, H.C.; Shin, T.J.; Yang, L.; Cho, K.; Ryu, C.Y.; Bao, Z.N. Effect of mesoscale
crystalline structure on the field-effect mobility of regioregular poly(3-hexyl thiophene)
in thin-film transistors. Advanced Functional Materials 2005, 15, 671-676.
149. Merlo, J.A.; Frisbie, C.D. Field effect transport and trapping in regioregular
polythiophene nanofibers. The Journal of Physical Chemistry B 2004, 108, 19169-19179.
150. Na, J.Y.; Kim, M.; Park, Y.D. Solution processing with a good solvent additive for highly
reliable organic thin-film transistors. The Journal of Physical Chemistry C 2017, 121,
13930-13937.
38 151. Calka, A.; Radlinski, A.P. Universal high performance ball-milling device and its
application for mechanical alloying. Materials Science and Engineering: A 1991, 134,
1350-1353.
152. Koch, C.C.; Cho, Y.S. Nanocrystals by high energy ball milling. Nanostructured
Materials 1992, 1, 207-212.
153. Weeber, A.W.; Bakker, H. Amorphization by ball milling. A review. Physica B:
Condensed Matter 1988, 153, 93-135.
154. Chen, Y.; Fitz Gerald, J.; Chadderton, L.T.; Chaffron, L. Nanoporous carbon produced
by ball milling. Applied Physics Letters 1999, 74, 2782-2784.
155. Stolle, A.; Szuppa, T.; Leonhardt, S.E.S.; Ondruschka, B. Ball milling in organic
synthesis: Solutions and challenges. Chemical Society Reviews 2011, 40, 2317-2329.
156. Rankin, D.W. Crc handbook of chemistry and physics (90th ed.). Taylor & Francis: Boca
Raton, Florida, 2009, 13, 193-215..
39 CHAPTER 2: FABRICATION OF GRAPHENE AEROGELS WITH HEAVILITY LOADED MATALLIC NANOPARTICLES
Chen Shen, Elizabeth Barrios, Matthew McInnis, Joseph Zuyus, Lei Zhai, “Fabrication of
Graphene Aerogels with Heavily Loaded Metallic Nanoparticles”, Micromachines 2017, 8(2), 47-
56. Copyright 2017 Multidisciplinary Digital Publishing Institute (MDPI).
Introduction
Nature has produced remarkable materials possessing unique characteristics and behaviors that
inspire scientists to replicate their structures synthetically. [1] Unlike synthetic materials, many
natural biomaterials possess a hierarchical structure on many different size scales that have a
complex interaction between each scale, leading to very unique behaviors. For example, the
biomolecules in pollens self-assemble to form a connective, highly porous network that enables
efficient mass transport. [2] Additionally, nanostructures on pollens possess a very large internal
surface area, endowing many possible sites for surface reactions to occur. [3] In pollen grains,
these two features enable a sensitive response of the pollen-stigma recognition and fertilization and the defense mechanism. [4-5] As such, the hierarchical porous network platform demonstrated in the pollen grain provides the possibility to manufacture a highly sensitive and efficient gas sensor. These possibilities have led to many researchers trying to fabricate biomimetic-sensing systems to advance today’s gas sensing technologies. [2-3, 6-10] For example, tin(IV) oxide
(SnO2) porous particles with large surface area have been produced using pollens as templates. [3]
In this work, we demonstrate a strategy to achieve a similar hierarchical porous network for hydrogen sensing capabilities through the loading of metallic nanoparticles onto a graphene aerogel motif.
40 Graphene is a planar monolayer of carbon atoms arranged in a honeycomb lattice and has
demonstrated very intriguing electrical properties, high strength, and a large in-plane electrical
conductivity. Additionally, they have a very large surface-to-weight ratio, making them highly
suitable sensor applications. For example, various metal nanoparticles have been attached on
graphene to detect chemicals such as hydrogen peroxide [11-13] and hydrogen. [14] The hierarchical porous structure demonstrated in the pollen grains can be achieved in graphene through the creation of a graphene aerogel (GA) decorated with nanostructures [15] where aerogels provide a network for charge transport and nanostructures grant large surface area to interact with hydrogen gas. Graphene aerogels (GAs) are promising materials for gas sensing and energy storage applications. [16-31] Historically, GA is produced through freeze-drying a graphene oxide
(GO) hydrogel, where the graphene oxide is synthesized via a modified Hummer’s method. The freeze-dried GO aerogel is then reduced to produce a reduced graphene oxide (rGO) aerogel. This method produces physical crosslinks between the graphene sheets that are oriented in the freezing direction, creating long, continuous open pores throughout the GA. [31-33] For use in gas sensing applications, GA is often functionalized with metallic nanoparticles like palladium, platinum, nickel, tin, and so on. [34]
Loading metallic nanoparticles onto a graphene surface requires mixing GO dispersion with a metal salt solution. The mixture was freeze-dried and then reduced to produce graphene/metallic nanoparticles composites. [35-36] However, the loading capacity of metallic nanoparticles on graphene sheets is limited by the bridging effect between GO and metal cations, and this effect diminishes the gas-sensing performance of the materials. [35, 37] To overcome this limitation, chelating agents such as ethylenediaminetetraacetic acid (EDTA) can be used to screen the
41 electrostatic interaction between metal cations and GO, thus increase the density of metallic
nanoparticles exposed on the surface of GO sheets. [38]
Herein, we report an effective approach for loading a large number of metallic nanoparticles onto
the surface of graphene aerogels using EDTA. These functionalized GO aerogels were fabricated
by creating a metal salt solution containing EDTA prior to the introduction of the aqueous GO
dispersion. The resulting GO aerogels loaded with metal ions were reduced to obtain the rGO (i.e.
graphene) aerogels with nanoparticle. In this work, we demonstrate the successful preparation of
palladium, platinum, nickel, and tin nanoparticle decorated graphene aerogels and the fabrication
of a hydrogen gas sensor using palladium nanoparticles loaded graphene aerogels.
Materials and Methods
Sulfuric acid, potassium permanganate, hydrogen peroxide and 0.5 M ethylenediaminetetraacetic
acid (EDTA) solution were purchased from Fisher Scientific. Tin chloride pentahydrate
(SnCl4∙5H2O), nickel chloride hexahydrate (NiCl2∙6H2O), palladium chloride (PdCl2) and
chloroplatinic acid (H2PtCl6) were purchased from Alfa Aesar. Graphite powders (microfyne grade)
were purchased from Dixon Inc. All chemicals were used as received without further purification.
Labconco freeze drying chamber (FreeZone 1) was used for the lyophilization of the graphene
oxide hydrogels. The Labcono lyophilizer was operated at a temperature of -52 oC under a pressure
of 0.02 mbar. VWR vacuum oven was used for the vacuum drying of GO powders. BRANSON
digital horn-sonifier was used to disperse GO in water. Thermo Scientific tube furnace (Lindberg
Blue M) was used for the hydrogen reduction of the freeze-dried graphene oxide aerogels.
42 Graphene Oxide (GO) was prepared by modified Hummers method using graphite powder.
Typically, 1 gram of graphite powder was added to a 500 mL beaker that was immersed in an ice
bath, followed by a slow addition of 50 mL concentrated sulfuric acid and 6 grams of potassium
permanganate while stirring. The mixture was stirred for an additional hour at 30oC. 80 mL of
deionized water (DI water) was added dropwise to the homogeneous mixture. After the addition
o of DI water, the beaker was then heated to 60 C and maintained for 1 hour. 6 mL of 30% H2O2
was then added into the beaker. The heat was turned off after 5 minutes. After the mixture was
cooled to room temperature, the crude products were washed with DI water followed by
centrifugation to obtain the product. The washing was finished when the supernatant had a pH
above 5. The wet GO was then dried in a vacuum oven at room temperature to avoid thermal
reduction during the drying process. [39,40]
In a typical preparation, 1 mmol of a metal salt (i.e. Pd, Pt, Ni, or Sn salts) was added to a 10 mL
0.1 M EDTA solution. Thus, the molar ratio between the metal salt and EDTA was 1:1. Most solutions were prepared at room temperature. However, the PdCl2/EDTA solution was heated at
90 oC for 15 minutes to fully dissolve the metal salt, and the solution was cooled to room
temperature prior to the next step. An aqueous GO dispersion was prepared by using a horn-
sonifier. A mixture of 200 mg of GO and 10 mL of DI water was sonicated for 30 minutes to form
an aqueous GO dispersion. As shown is Figure 2-1a, the completely dissolved metal salt/EDTA
solutions were mixed with 20 mg/mL GO dispersion with a volume ratio of 1:1 to form a metal
salt/GO dispersion. The dispersion was then transferred to several 2 mL plastic cuvettes after
vigorous mixing was applied. Dispersions in cuvettes were frozen by using dry ice for the following
43 lyophilization. After an overnight lyophilization, bulk metal salt loaded GO aerogels were formed as
shown in Figure 2-1b.
The metal salt loaded GO aerogels shown in Figure 2-1b went through vapor phase reduction, and
an atmosphere of hydrazine vapor mixed in nitrogen was used during this reaction. The reduction
was conducted at 90 oC for one hour. Epoxide functional groups on the basal plane of GO were
removed by hydrazine vapor to avoid potential structure destructions of aerogels in the next
hydrogen reduction step. [39,41] Once the aerogels were cooled down from hydrazine reduction,
they were further reduced by pure hydrogen gas in a pure hydrogen atmosphere at 400 oC for one
hour and at 900 oC for 10 minutes. The hydrogen flow rate was kept at 30 SCCM. Such two steps
reduction produced rGO aerogels decorated with metal nanoparticles as shown in Figure 2-1c, and
the color of aerogels was converted from brown to black during the reduction process. To form tin
decorated rGO aerogels, hydrogen reduction only needs to be conducted at 400 oC for one hour as
tin nanoparticles would flow away if higher temperatures were applied.
Figure 2-1. Schematic illustration of the formation of metal nanoparticles decorated rGO aerogels.
44 Characterizations
The morphologies of the aerogels were characterized by using a scanning electron microscope
operating at 10 keV (SEM, ZEISS ULTRA 55) and was coupled with Energy-Dispersive X-ray spectroscopy (EDS) to investigate the surface chemistry of the aerogels. The chemical states of elements were analyzed by X-ray photoelectron spectroscopy (XPS, PHI 5400).
In order to determine the influence of processing and experimental conditions of the aerogels on hydrogen sensing, rGO aerogels attached to electrical leads was inserted into a homemade flow chamber. The flow chamber was placed in a water bath with stable temperature, and a thermocouple was added to the interior of the flow chamber to diminish the affect from the exterior temperature. Conductometric response (i.e. resistance change of rGO aerogels) to hydrogen gas was carried out by monitoring the current through each aerogel under the condition of a steady flow of argon gas with periodic inclusion of 1000 ppm hydrogen gas into the stream. The relative change in resistivity [(Rg-R0)/R %] was calculated from the current and the voltage applied. These
values were plotted as a function of time after baseline correction.
Results and Discussion
The material fabrication started with a solution containing equal moles of a metal salt and a ligand,
specifically EDTA, in this study. EDTA was crucial in order to successfully form GO aerogels
during lyophilization. If a strong ligand like EDTA was not used, the strong electrostatic
interactions between positively charged metal ions and the negatively charged functional groups
on the edge of GO, usually the carboxylic acid groups caused the gelation of GO. [42] Such GO
hydrogel would shrink significantly during the lyophilization. As a result, GO aerogels with porous
45 microstructures were not formed, leading to the loss of the advantages of the aerogels originated
from this unique microstructure. On the other hand, if metal salts are mixed with EDTA before
being added to the GO suspension, the formation of metal-EDTA complexes eliminated the
electrostatic interactions between metal ions and GO. [43-45] Therefore, van der Waals interactions between the GO sheets became the major interactions in the mixtures, which is the same as when only GO was dispersed in water. As a result, nearly no shrinkage was observed after the lyophilization, and aerogels containing metal salts were successfully formed. After successfully creating the aerogels containing metal salts, the GO flakes and metal ions in the aerogels were converted to rGO sheets and metal nanoparticles during the high temperature hydrogen reduction.
The microstructure of a typical rGO aerogel decorated with metal nanoparticles was examined by
SEM as shown in Figure 2-2. The stacking of the rGO sheets can be clearly seen from the cross- sectional image in Figure 2-2a. This structure indicates that the van der Waals interactions among the rGO sheets remained even after the hydrogen reduction process. Also, it is shown that the pore sizes in the aerogels are in the sub-millimeter range. The interconnected porous graphene framework with a significant directionality in the longitudinal direction was realized (Figure 2-
2b). The well-defined 3D microstructure is due to the directional freezing resulted from placing dry ice beneath the cuvettes filled with metal salt/GO dispersions.
46
Figure 2-2. (a) SEM image of the cross-sectional area, (b) SEM image of the longitudinal section.
The loading of the metal nanoparticles was verified by the SEM under higher magnifications as
shown in Figure 2-3. The morphologies of the aerogels loaded with palladium, platinum, nickel, and tin nanoparticles are shown in Figure (2-3a, 2-3e), Figure (2-3b, 2-3f), Figure (2-3c, 2-3g), and Figure (2-3d, 2-3h), respectively. The presence of ripples and wrinkles on the sheets verified
the existence of rGO sheets. These features are typical in rGO sheets and are mainly resulted from
of the stress produced at elevated temperatures during hydrogen reduction process. After hydrogen
reduction, metal ions chelated with EDTA on the rGO sheets were reduced into their metallic state.
Thus, the nanoparticles located on rGO sheets can be seen on SEM images. The sizes of palladium,
platinum, and nickel metal nanoparticles are comparable, which ranged from 10 to 120 nm in
diameter. The tin nanoparticles loaded on rGO sheets have larger sizes when compared with other
three metal nanoparticles. Particles as large as 400 nm in diameter were observed. However, small
tin nanoparticles with diameters around 50 nm can still be observed.
47
Figure 2-3. SEM images of the (a,e) Pd, (b,f) Pt, (c,g) Ni, and (d,h) Sn nanoparticles loaded aerogels formed after hydrogen reduction.
To verify the distribution of metal nanoparticles on rGO sheets, the metal loaded aerogels were
characterized by using EDS elemental mapping. The SEM images of metal loaded aerogels and
the mapping of the loaded metal in the same area are shown Figure 2-4. The EDS mapping results
of rGO aerogels loaded with palladium, platinum, nickel, and tin are shown in Figure (2-4a, 2-4e),
Figure (2-4b, 2-4f), Figure (2-4c, 2-4g), and Figure (2-4d, 2-4h), respectively. Figure 2-4 (a-d) show SEM images of the area characterized for EDS elemental mapping. Uniform elemental
48 distribution of metals can be clearly seen on Figure 2-4 (e-h). Among them, Figure 2-4 (e-h) present the elemental mapping of palladium, platinum, nickel and tin on their corresponding rGO sheets in aerogels, respectively. These results confirm the successful loading of metal particles onto rGO aerogels with excellent uniformity.
Figure 2-4. SEM images of (a)Pd, (b)Pt, (c)Ni, and (d)Sn loaded rGO aerogels and the corresponding EDS spatial mapping images of loaded (e)Pd, (f)Pt, (g)Ni, and (h)Sn on rGO sheets. The scale bar is 20 m.
µ The amount of loaded of metal nanoparticles in rGO aerogels after hydrogen reductions was also characterized by EDS. Based on the EDS spectra in Figure 2-5, carbon and the loaded metals are the predominant components of the aerogels after hydrogen reduction, which is to be expected.
Oxygen in the palladium and platinum loaded aerogels are not detectable to give a reliable composition with the oxygen; however, small peaks at 0.525 eV can be seen for these two trials.
Oxygen in the nickel and tin loaded aerogels were detected in quantifiable quantities and is likely attributed to the oxides formed on the surfaces of the aerogels, which will be discussed further in the XPS studies. For the aerogels containing tin, the excess oxygen content compared with the other samples is also due to the incomplete reduction of the rGO that occurred during reduction conducted at the significantly lower temperature of 400 oC. The loading efficiency of the metal
49 nanoparticles was evaluated by analyzing the EDS spectra in Figure 2-5, and the mass percentage of metal nanoparticles in rGO aerogels after hydrogen reduction was calculated to be 59 %, 67 %,
39 % and 46 % for Pd, Pt, Ni, and Sn nanoparticles, respectively. Compared with existing approaches of loading metal nanoparticles to graphene (around 10 %), [46,47] our method grants much higher loading efficiencies.
Figure 2-5. EDS spectra of (a) palladium, (b) platinum, (c) nickel, and (d) tin loaded rGO aerogels after hydrogen reduction.
50 The chemical states of the metal nanoparticles loaded onto the aerogels, before and after hydrogen
reduction, were analyzed via XPS and the data is presented in Figure 2-6. The XPS spectra of palladium, platinum, nickel, and tin in aerogels before hydrogen reduction are presented in Figure
2-6a, 2-6c, 2-6e, and 2-6g, respectively. The XPS spectra of palladium, platinum, nickel, and tin in aerogels after hydrogen reduction are presented in Figure 2-6b, 2-6d, 2-6f, and 2-6h,
respectively. The deconvoluted XPS spectra in Figure 2-6a and 2-6b show 3d peaks of palladium
before and after hydrogen reduction. In Figure 2-6a, the deconvoluted XPS peaks are recognized
2+ 2+ as Pd 3d5/2 peak (338.55 eV) of palladium (II) chloride (PdCl2), Pd 3d3/2 peak (344.71 eV) of
2+ PdCl2, and Pd 3d5/2 peak (337.19 eV) of palladium (II) oxide (PdO). [48] The presence of a small
portion of PdO is most likely due to the hydrolysis of PdCl2. In Figure 2-6b, the major
0 0 deconvoluted XPS peaks are recognized as Pd 3d5/2 peak (335.20 eV) and Pd 3d3/2 peak (340.46
eV) of metallic palladium. These two major XPS peaks observed in palladium loaded aerogels
after hydrogen reduction verifies the effective formation of metallic palladium during reduction.
[49] Additionally, minimal deconvoluted XPS peaks correspond to PdO are observed in Figure 2-
2+ 2+ 6b, namely Pd 3d5/2 peak (337.20 eV) and Pd 3d3/2 peak (342.50 eV) of PdO. [50] The PdO in the aerogels after hydrogen reduction is likely from the surface oxides. The deconvoluted XPS
spectra in Figure 2-6c and 2-6d show 4f peaks of platinum before and after hydrogen reduction.
4+ 4+ The deconvoluted XPS peaks in Figure 2-6c are recognized as Pt 4f7/2 peak (74.56 eV), Pt 4f5/2
2+ 2+ peak (77.87 eV), Pt 4f7/2 peak (71.99 eV), and Pt 4f5/2 peak (75.50 eV), respectively. [51-53]
The existence of peaks for Pt2+ is likely due to the reduction of Pt4+ during the step of mixing Pt4+
salts with EDTA. [51] Two major deconvoluted XPS peaks in Figure 2-6d are recognized as Pt0
0 4f7/2 peak (70.81 eV) and Pt 4f5/2 peak (74.22 eV), respectively. [52-54] This result verifies the
effective reduction to form metallic platinum. Besides, minimal deconvoluted XPS peaks
51 2+ correspond to platinum (II) oxide (PtO) are observed in Figure 2-6d, namely Pt 4f7/2 peak (71.98
2+ eV) and Pt 4f5/2 peak (75.45 eV). Similar to the case of palladium loaded aerogels, the PtO in the aerogels after hydrogen reduction is also likely from the surface oxides. The deconvoluted XPS
spectra in Figure 2-6e and 2-6f show 2p peaks of nickel before and after hydrogen reduction. In
2+ Figure 2-6e, the single major peak is recognized as Ni 2p3/2 peak (860.20 eV). [55,56] In Figure
0 2+ 2-6f, the deconvoluted XPS peaks are recognized as Ni 2p3/2 peak (858.63 eV), Ni 2p3/2 peak
3+ 0 (860.21 eV), and Ni 2p3/2 peak (861.40 eV), respectively [57]. The Ni 2p3/2 peak (858.63 eV) is
the major deconvoluted XPS peak, and this result verifies the effective reduction to form metallic
nickel. Besides, the existence of Ni2+ and Ni3+ after hydrogen reduction is probably attributed to
the formation of nickel (II) oxide (NiO) and nickel (III) oxide (Ni2O3) on the surface of aerogels.
[51] The deconvoluted XPS spectra in Figure 2-6g and 2-6h show 3d peaks of tin before and after
4+ hydrogen reduction. In Figure 2-6g, the deconvoluted XPS peaks are recognized as Sn 3d5/2 peak
0 (487.09 eV) and Sn 3d5/2 peak (484.95 eV), respectively. [58-61] The presence of a small amount of metallic tin is likely due to the reduction by EDTA while mixing tin salts with EDTA. In Figure
0 2-6h, the single major peak is recognized as Sn 3d5/2 peak (484.96 eV), [61] and this result verifies
the effective reduction to form metallic tin.
Overall, the effective reduction of metal salts during a hydrogen reduction process was confirmed by the comparison of the deconvoluted XPS peaks before and after reduction. The appearance of dominant XPS peaks, which correspond to the metals at their metallic state, indicates the highly effective reduction of the metal salts in this study. Additionally, only a small amount of metal oxides exists in the aerogels loaded with palladium, platinum, and nickel after hydrogen reduction, and the residual metal oxides are probably attributed to oxides formed on surface after hydrogen
52 reduction. Furthermore, no XPS peaks regarding tin oxides were seen while applying curve fitting,
thus the reduction to form metallic tin nanoparticles is more effective than that of other three kinds
of metals.
Figure 2-6. Deconvoluted XPS spectra of the loaded metal in the aerogels. Pd in Pd loaded aerogels (a) as prepared and (b) after reduction, Pt in Pt loaded aerogels (c) as prepared and (d) after reduction, Ni in Ni loaded aerogels (e) as prepared and (f) after reduction, Sn in Sn loaded aerogels (g) as prepared and (h) after reduction are shown.
The reduction of carbon in aerogels during hydrogen reduction was also confirmed by the XPS
spectra of C 1s. The XPS images of carbon in aerogels loaded with four different kinds of metals
are shown in Figure 2-8. The obvious shift of XPS peaks to the lower binding area proves the
reduction of GO during the reduction. For aerogels loaded with palladium, platinum, and nickel,
the presence of major deconvoluted peaks at the binding energy of 284.6 eV, which is the signature
peak of graphitic C-C bonds, [25,37,62,63] indicates the effective reduction of carbon in hydrogen atmosphere at the temperature of 900oC. Besides, the dramatic decrease of the relative intensity
for the XPS peaks which correspond to the oxidized carbons, namely peaks of hydroxyl groups
53 with binding energy around 286.5 eV, peaks of carbonyl C=O double bond with binding energy
of around 288 eV, and peaks from O-C=O ester functional groups with binding energy around
289 eV, [25,37,62,63] further verifies the effective reduction of carbonyl and ester groups. For tin
loaded aerogels, the appearance of the deconvoluted XPS peak at the binding energy of 284.6 eV,
which is the characteristic peak of graphitic carbon, proves the effective reduction of carbon in
hydrogen atmosphere. Because a much lower reduction temperature of 400oC was used for tin
loaded aerogels, a much smaller fraction of graphitic carbon was formed. Additionally, the
decrease of the relative intensity of the ester groups verifies the reduction of this functional group
in aerogels. At last, deconvoluted peaks with the binding energies of 290.1 eV to 290.8 eV, which
exist in all aerogel samples as prepared and after hydrogen reduction, are the characteristic -
shakeup transition peaks in aromatic carbon compounds. [63,64] 𝜋𝜋 𝜋𝜋
Pd nanoparticles have been deposited on GO surfaces for hydrogen sensing because they have high affinity to hydrogen. Such affinity causes the electron density of the metal particle to be reduced, thereby increasing the work function of the graphene-metal-gas system, leading to a change of resistance. [47,65] The sensitivity of the sensors depends on the Pd nanoparticle/GO interfacial area and the response and recovery time is affected by the gas flow efficiency. The Pd nanoparticles on GAs offers large contact area between Pd nanoparticles and graphene and efficient gas flow due to the porous structures. In our study, different amount of Pd nanoparticles were loaded onto rGO aerogels (rGOAs) by adding different amount of PdCl2/EDTA solutions to
GO suspensions. In addition, PdCl2 without EDTA was added to GO suspensions as a control.
While the concentration of PdCl2 can be as high as 70 mM with EDTA before GO is precipitated,
more than 4mM pure PdCl2 would precipitate GO. The produced rGOA composites were put
54 between two electrodes and subject to hydrogen sensing test as shown in Figure 2-7a inset. The
resistance change of each rGOA/Pd nanoparticle composite upon the exposure to 1000 ppm
hydrogen gas is shown in Figure 2-7a. First, heavy loading of Pd nanoparticles on rGOA using
EDTA have much higher response to hydrogen gas than small loading of Pd nanoparticles using
pure PdCl2, suggesting that increased Pd nanoparticles on rGOA can increase sensitivity. Second,
the sensor response increases with Pd nanoparticle loading, reach a peak at 30 mM Pd precursor
concentration, and then decreases. With increasing Pd loading, the amount of nanoparticles
increases, the resulted increased Pd nanoparticle surface area leads to a increase in sensitivity.
However, the Pd nanoparticle size will increase with further increased Pd loading (Figure 2-9), which causes the reduction of Pd nanoparticle surface area. Figure 2-7 shows the change of resistance of rGOA/Pd nanoparticle composites versus time over four on-off cycles of 1000 ppm
hydrogen gas. It clearly shows a fast response of hydrogen gas (25 seconds) and recovery (175
seconds) (Figure 2-10) that are attributed to porous structures of rGOAs.
Figure 2-7. (a) The change of resistance of GA/Pd nanoparticle composites with different Pd loadings upon exposure to 1000 ppm hydrogen gas. (b) The change of resistance of GA/Pd nanoparticle composites upon hydrogen gas on/off cycles.
55 Conclusions
In this paper, rGO aerogels loaded with four kinds of metallic nanoparticles were successfully prepared with excellent directionality and decent hieratical structures. The loading of 59 wt%, 67 wt%, 39 wt% and 46 wt% of metallic palladium, platinum, nickel, and tin in rGO/metal aerogels were achieved after hydrogen reduction at elevated temperatures. It is believed that other kind of metallic nanoparticles can also be loaded onto rGO aerogels with similar procedures. A hydrogel gas sensor was produced using Pd nanoparticle loaded rGO aerogels. The large surface area and porous structure of rGO aerogel offer high sensitivity and fast response/recovery time of the sensor. The metal nanoparticles decorated aerogels which have open-pores structure and large surface area are promising platforms for numerous applications, including energy storage, gas sensing and catalysts of vapor phase reactions.
Supporting Materials
Figure 2-8. SEM images of Pd nanoparticles on GA surfaces made from (a) 30 mM and (b) 70 mM Pd ion in GO suspensions.
56
Figure 2-9. Deconvoluted XPS spectra of the carbon in the aerogels. C in Pd loaded aerogels (a) as prepared and (b) after reduction, C in Pt loaded aerogels (c) as prepared and (d) after reduction, C in Ni loaded aerogels (e) as prepared and (f) after reduction, C in Sn loaded aerogels (g) as prepared and (h) after reduction.
57
Figure 2-10. The change of current of a hydrogen sensor when exposed to 1000 ppm hydrogen gas. The responding time and recovery time are highlight in green and brown, respectively.
References
1. Wegst, U.G.K.; Bai, H.; Saiz, E.; Tomsia, A.P.; Ritchie, R.O. Bioinspired structural
materials. Nat Mater 2015, 14, 23-36.
2. Song, F.; Su, H.; Chen, J.; Moon, W-J.; Lau, W.M.; Zhang, D. Impatiens msisimwanensis
(Balsaminaceae): Description, pollen morphology and phylogenetic position of a new East
African species. South African Journal of Botany 2009, 75, 104-109.
3. Fazil, A.A.; Bhanu, J.U.; Amutha, A.; Joicy, S.; Ponpandian, N.; Amirthapandian, S.;
Panigrahi, B.K.; Thangadurai, P. A facile bio-replicated synthesis of SnO2 motifs with
porous surface by using pollen grains of Peltophorum pterocarpum as a template.
Microporous and Mesoporous Materials 2015, 212, 91-99.
4. Edlund, A.F.; Swanson, R.; Preuss, D. Pollen and stigma structure and function: The role
of diversity in pollination. The Plant Cell 2004, 16, 84-97.
58 5. Benton, R. Sensitivity and specificity in drosophila pheromone perception. Trends in
neurosciences 2007, 30, 512-519.
6. Zhao, N.; Wang, Z.; Cai, C.; Shen, H.; Liang, F.; Wang, D.; Wang, C.; Zhu, T.; Guo, J.;
Wang, Y.; Liu, X.; Duan, C.; Wang, H.; Mao, Y.; Jia, X.; Dong, H.; Zhang, X.; Xu, Jian.
Bioinspired materials: From low to high dimensional structure. Advanced Materials 2014,
26, 6994-7017.
7. Yang, X.; Zhu, J.; Qiu, L.; Li, D. Bioinspired effective prevention of restacking in
multilayered graphene films: Towards the next generation of high-performance
supercapacitors. Adv. Mater. 2011, 23, 2833-2838.
8. Coburn, J.M.; Gibson, M.; Monagle, S.; Patterson, Z.; Elisseeff, J.H. Bioinspired
nanofibers support chondrogenesis for articular cartilage repair. Proceedings of the
National Academy of Sciences of the United States of America 2012, 109, 10012-10017.
9. Song, F.; Su, H.; Han, J.; Lau, W.M.; Moon, W.; Zhang, D. Bioinspired hierarchical tin
oxide scaffolds for enhanced gas sensing properties. The Journal of Physical Chemistry C
2012, 116, 10274-10281.
10. Spitzer, D.; Cottineau, T.; Piazzon, N.; Josset, S.; Schnell, F.; Pronkin, S.N.; Savinova,
E.R.; Keller, V. Bio-inspired nanostructured sensor for the detection of ultralow
concentrations of explosives. Angew. Chem. Int. Ed. 2012, 51, 5334-5338.
11. Wang, H.; Wang, H.; Li, T.; Ma, J.; Li, K.; Zuo, X. Silver nanoparticles selectively
deposited on graphene-colloidal carbon sphere composites and their application for
hydrogen peroxide sensing. Sens. Actuators, B 2017, 239, 1205-1212.
12. Amanulla, B.; Palanisamy, S.; Chen, S.; Velusamy, V.; Chiu, T.; Chen, T.; Ramaraj, S.K.
A non-enzymatic amperometric hydrogen peroxide sensor based on iron nanoparticles
59 decorated reduced graphene oxide nanocomposite. J. Colloid Interface Sci. 2017, 487, 370-
377.
13. Thirumalraj, B.; Rajkumar, C.; Chen, S.; Barathi, P. Highly stable biomolecule supported
by gold nanoparticles/graphene nanocomposite as a sensing platform for H2O2 biosensor
application. J. Mater. Chem. B 2016, 4, 6335-6343.
14. Cadore, A.R.; Mania, E.; de Morais, E.A.; Watanabe, K.; Taniguchi, T.; Lacerda, R.G.;
Campos, L.C. Metal-graphene heterojunction modulation via H2 interaction. Appl. Phys.
Lett. 2016, 109, 033109-033114.
15. Wu, J.; Feng, S.; Wei, X.; Shen, J.; Lu, W.; Shi, H.; Tao, K.; Lu, S.; Sun, T.; Yu, L.; Du,
C.; Miao, J.; Norford, L.K. Facile synthesis of 3D graphene flowers for ultrasensitive and
highly reversible gas sensing. Adv. Funct. Mater. 2016, 26, 7462-7469.
16. Chen, L.; Wang, X.; Zhang, X.; Zhang, H. 3D porous and redox-active prussian blue-in-
graphene aerogels for highly efficient electrochemical detection of H2O2. Journal of
Materials Chemistry 2012, 22, 22090-22096.
17. Liang, J.; Liu, Y.; Guo, L.; Li, L. Facile one-step synthesis of a 3D macroscopic SnO2-
graphene aerogel and its application as a superior anode material for li-ion batteries. RSC
Advances 2013, 3, 11489-11492.
18. Wu, T.; Chen, M.; Zhang, L.; Xu, X.; Liu, Y.; Yan, J.; Wang, W.; Gao, J. Three-
dimensional graphene-based aerogels prepared by a self-assembly process and its excellent
catalytic and absorbing performance. Journal of Materials Chemistry A 2013, 1, 7612-7621.
19. Xiao, L.; Wu, D.; Han, S.; Huang, Y.; Li, S.; He, M.; Zhang, F.; Feng, X. Self-assembled
Fe2O3/graphene aerogel with high lithium storage performance. ACS Applied Materials &
Interfaces 2013, 5, 3764-3769.
60 20. Chen, M.; Zhang, C.; Li, X.; Zhang, L.; Ma, Y.; Zhang, L.; Xu, X.; Xia, F.; Wang, W.;
Gao, J. A one-step method for reduction and self-assembling of graphene oxide into
reduced graphene oxide aerogels. Journal of Materials Chemistry A 2013, 1, 2869-2877.
21. Nardecchia, S.; Carriazo, D.; Ferrer, M.L.; Gutierrez, M.C.; del Monte, F. Three
dimensional macroporous architectures and aerogels built of carbon nanotubes and/or
graphene: Synthesis and applications. Chemical Society Reviews 2013, 42, 794-830.
22. Das, S.; Irin, F.; Ma, L.; Bhattacharia, S.K.; Hedden, R.C.; Green, M.J. Rheology and
morphology of pristine graphene/polyacrylamide gels. ACS Applied Materials & Interfaces
2013, 5, 8633-8640.
23. Ji, C.; Xu, M.; Bao, S.; Cai, C.; Lu, Z.; Chai, H.; Yang, F.; Wei, H. Self-assembly of three-
dimensional interconnected graphene-based aerogels and its application in supercapacitors.
Journal of Colloid and Interface Science 2013, 407, 416-424.
24. Ye, S.; Feng, J.; Wu, P. Deposition of three-dimensional graphene aerogel on nickel foam
as a binder-free supercapacitor electrode. ACS Appl. Mater. Interfaces 2013, 5, 7122-7129.
25. Yu, Z.; McInnis, M.; Calderon, J.; Seal, S.; Zhai, L.; Thomas, J. Functionalized graphene
aerogel composites for high-performance asymmetric supercapacitors. Nano Energy 2015,
11, 611-620.
26. Zhao, L.; Wang, Z.; Li, J.; Zhang, J.; Sui, X.; Zhang, L. One-pot synthesis of a three-
dimensional graphene aerogel supported pt catalyst for methanol electrooxidation. RSC
Advances 2015, 5, 98160-98165.
27. Singh, S.; Tripathi, P.; Bhatnagar, A.; Prakash Patel, C.R.; Singh, A.P.; Dhawan, S.K.;
Gupta, B.K.; Srivastava, O.N. A highly porous, light weight 3D sponge like graphene
61 aerogel for electromagnetic interference shielding applications. RSC Advances 2015, 5,
107083-107087.
28. Liu, M.; Peng, C.; Yang, W.; Guo, J.; Zheng, Y.; Chen, P.; Huang, T.; Xu, J. Pd
nanoparticles supported on three-dimensional graphene aerogels as highly efficient
catalysts for methanol electrooxidation. Electrochimica Acta 2015, 178, 838-846.
29. Harley-Trochimczyk, A.; Chang, J.; Zhou, Q.; Dong, J.; Pham, T.; Worsley, M.A.;
Maboudian, R.; Zettl, A.; Mickelson, W. Catalytic hydrogen sensing using microheated
platinum nanoparticle-loaded graphene aerogel. Sensors and Actuators B: Chemical 2015,
206, 399-406.
30. Peng, L.; Zheng, Y.; Li, J.; Jin, Y.; Gao, C. Monolithic neat graphene oxide aerogel for
efficient catalysis of S → O acetyl migration. ACS Catalysis 2015, 5, 3387-3392.
31. Li, J.; Xie, J.; Gao, L.; Li, C.M. Au nanoparticles–3D graphene hydrogel nanocomposite
to boost synergistically in situ detection sensitivity toward cell-released nitric oxide. ACS
Appl. Mater. Interfaces 2015, 7, 2726-2734.
32. Xu, Z.; Zhang, Y.; Li, P.; Gao, C. Strong, conductive, lightweight, neat graphene aerogel
fibers with aligned pores. ACS nano 2012, 6, 7103-7113.
33. Schiffres, S.N.; Harish, S.; Maruyama, S.; Shiomi, J.; Malen, J.A. Tunable electrical and
thermal transport in ice-templated multilayer graphene nanocomposites through freezing
rate control. ACS Nano 2013, 7, 11183-11189.
34. Ruiyi, L.; Juanjuan, Z.; Zhouping, W.; Zaijun, L.; Junkang, L.; Zhiguo, G.; Guangli, W.
Novel graphene-gold nanohybrid with excellent electrocatalytic performance for the
electrochemical detection of glucose. Sensors and Actuators B: Chemical 2015, 208, 421-
428.
62 35. Yin, P.T.; Kim, T.H.; Choi, J.W.; Lee, K.B. Prospects for graphene-nanoparticle-based
hybrid sensors. Phys. Chem. Chem. Phys 2013, 15, 12785-12799.
36. Yun, S.; Lee, S.; Shin, C.; Park, S.; Kwon, S.J.; Park, H.S. One-pot self-assembled, reduced
graphene oxide/palladium nanoparticle hybrid aerogels for electrocatalytic applications.
Electrochim. Acta 2015, 180, 902-908.
37. Cong, H.; Ren, X.; Wang, P.; Yu, S. Macroscopic multifunctional graphene-based
hydrogels and aerogels by a metal ion induced self-assembly process. ACS Nano 2012, 6,
2693-2703.
38. Liu, C.; Zhang, H.; Tang, Y.; Luo, S. Controllable growth of graphene/cu composite and
its nanoarchitecture-dependent electrocatalytic activity to hydrazine oxidation. Journal of
Materials Chemistry A 2014, 2, 4580-4587.
39. Gao, X.; Jang, J.; Nagase, S. Hydrazine and thermal reduction of graphene oxide: Reaction
mechanisms, product structures, and reaction design. The Journal of Physical Chemistry C
2010, 114, 832-842.
40. Zhu, Y.; Stoller, M.D.; Cai, W.; Velamakanni, A.; Piner, R.D.; Chen, D.; Ruoff, R.S.
Exfoliation of graphite oxide in propylene carbonate and thermal reduction of the resulting
graphene oxide platelets. ACS Nano 2010, 4, 1227-1233.
41. Stankovich, S.; Dikin, D.A.; Piner, R.D.; Kohlhaas, K.A.; Kleinhammes, A.; Jia, Y.; Wu,
Y.; Nguyen, S.T.; Ruoff, R.S. Synthesis of graphene-based nanosheets via chemical
reduction of exfoliated graphite oxide. Carbon 2007, 45, 1558-1565.
42. Dreyer, D.R.; Park, S.; Bielawski, C.W.; Ruoff, R.S. The chemistry of graphene oxide.
Chemical Society Reviews 2010, 39, 228-240.
63 43. Anderegg, G. Critical survey of stability constants of edta complexes: Critical evaluation
of equilibrium constants in solution: Stability constants of metal complexes; Pergamon
Press: New York, USA, 1977, 19, 429-443..
44. Chisolm, J.J. The use of chelating agents in the treatment of acute and chronic lead
intoxication in childhood. The Journal of Pediatrics 1968, 73, 1-38.
45. Flora, S.J.S.; Pachauri, V. Chelation in metal intoxication. International Journal of
Environmental Research and Public Health 2010, 7, 2745-2773.
46. Liu, M.; Peng, C.; Yang, W.; Guo, J.; Zheng, Y.; Chen, P.; Huang, T.; Xu, J. Pd
nanoparticles supported on three-dimensional graphene aerogels as highly efficient
catalysts for methanol electrooxidation. Electrochim. Acta 2015, 178, 838-846.
47. Kumar, R.; Varandani, D.; Mehta, B.; Singh, V.; Wen, Z.; Feng, X.; Müllen, K. Fast
response and recovery of hydrogen sensing in Pd–Pt nanoparticle–graphene composite
layers. Nanotechnology 2011, 22, 275719-275735.
48. Militello, M.C.; Simko, S.J. Elemental palladium by XPS. Surface Science Spectra 1994,
3, 387-394.
49. Militello, M.C.; Simko, S.J. Palladium chloride (PdCl2) by XPS. Surface Science Spectra
1994, 3, 402-409.
50. Militello, M.C.; Simko, S.J. Palladium oxide (PdO) by XPS. Surface Science Spectra 1994,
3, 395-401.
51. Wojnicki, M.; PacŁAwski, K.; Socha, R.P.; Fitzner, K. Adsorption and reduction of
platinum(IV) chloride complex ions on activated carbon. Transactions of Nonferrous
Metals Society of China 2013, 23, 1147-1156.
64 52. Bancroft, G.M.; Adams, I.; Coatsworth, L.L.; Bennewitz, C.D.; Brown, J.D.; Westwood,
W.D. Esca study of sputtered platinum films. Analytical Chemistry 1975, 47, 586-588.
53. Luo, S.; Shen, P.K. Concave platinum–copper octopod nanoframes bounded with multiple
high-index facets for efficient electrooxidation catalysis. ACS Nano 2016, 47, 726-748.
54. Xiaohua, C.; Jingsi, X.; Jianqiang, H.; Xiumei, F.; Aiqing, L. Edta-directed self-assembly
and enhanced catalytic properties of sphere-constructed platinum nanochains. Journal of
Physics D: Applied Physics 2010, 43, 115403-115432.
55. Lian, K.; Thorpe, S.J.; Kirk, D.W. Electrochemical and surface characterization of
electrocatalytically active amorphous nico alloys. Electrochimica Acta 1992, 37, 2029-
2041.
56. Venezia, A.M.; Bertoncello, R.; Deganello, G. X-ray photoelectron spectroscopy
investigation of pumice-supported nickel catalysts. Surface and Interface Analysis 1995,
23, 239-247.
57. Mansour, A.N.; Melendres, C.A. Characterization of electrochemically prepared γ‐niooh
by xps. Surface Science Spectra 1994, 3, 271-278.
58. Cao, X.; Cao, L.; Yao, W.; Ye, X. Influences of dopants on the electronic structure of sno2
thin films. Thin Solid Films 1998, 317, 443-445.
59. Willemen, H.; Van De Vondel, D.F.; Van Der Kelen, G.P. An esca study of tin compounds.
Inorganica Chimica Acta 1979, 34, 175-180.
60. Shuttleworth, D. Preparation of metal-polymer dispersions by plasma techniques. An esca
investigation. The Journal of Physical Chemistry 1980, 84, 1629-1634.
65 61. Paparazzo, E.; Moretto, L.; D'Amato, C.; Palmieri, A. X-ray photoemission spectroscopy
and scanning auger microscopy studies of a roman lead pipe ‘fistula’. Surface and Interface
Analysis 1995, 23, 69-76.
62. Wu, X.; Wen, T.; Guo, H.; Yang, S.; Wang, X.; Xu, A. Biomass-derived sponge-like
carbonaceous hydrogels and aerogels for supercapacitors. ACS Nano 2013, 7, 3589-3597.
63. Tortello, M.; Colonna, S.; Bernal, M.; Gomez, J.; Pavese, M.; Novara, C.; Giorgis, F.;
Maggio, M.; Guerra, G.; Saracco, G.; Gonnelli, R. S.; Fina, A. Effect of thermal annealing
on the heat transfer properties of reduced graphite oxide flakes: A nanoscale
characterization via scanning thermal microscopy. Carbon 2016, 109, 390-401.
64. Gerenser, L.J. Photoemission investigation of silver/poly(ethylene terephthalate)
interfacial chemistry: The effect of oxygen‐plasma treatment. Journal of Vacuum Science
& Technology A 1990, 8, 3682-3691.
65. Lange, U.; Hirsch, T.; Mirsky, V.M.; Wolfbeis, O.S. Hydrogen sensor based on a graphene
– palladium nanocomposite. Electrochim. Acta 2011, 56, 3707-3712.
66 CHAPTER 3: ANISOTROPIC ELECTRICAL CONDUCTIVITY IN POLYMER DERIVED CERAMICS INDUCED GRAPHENE AEROGELS
Chen Shen, Jean Calderon, Elizabeth Barrios, Mikhael Soliman, Ali Khater, Aadithya Jeyaranjan,
Laurene Tetard, Ali Gordon, Sudipta Seal, Lei Zhai, “Anisotropic Electrical Conductivity in
Polymer Derived Ceramics Induced by Graphene Aerogels”, Journal of Materials Chemistry C
2017, 45(5), 11708-11716. Copyright 2017 Royal Society of Chemistry.
Introduction
Polymer derived ceramics (PDCs), a class of silicon-based ceramics synthesized by the thermal decomposition of polymeric precursors, have various attractive properties such as excellent high-
temperature thermo-mechanical properties, high piezoresistivity and chemical stability attributed
to their unique nanostructures. [1-8] For example, SiCN ceramics produced from various
preceramic polymers possess a unique nanostructure where Si3N4 domains of few nanometers are surrounded by carbon nanostructures, [8-10] This nanostructure grants SiCN interesting electrical properties as a semiconductor. [1,3,5,11,12] SiCN has a nitrogen content band gap ranging from
2.2 to 5.0 eV with charge carrier density of about 6.7x1017 /cm3 and a charge mobility around 0.6
cm2/V∙s. SiCN ceramics also have an electrical conductivity around 10-7 S/m which can be further improved by increasing carbon content. [3] Additionally, the polymer-to-ceramic process enables the integration of various functional materials into the ceramics and promotes the fabrication of complex shaped composites and devices due to the hybrid processing/shaping technologies that are available to preceramic polymer. [13] These aforementioned properties have made PDCs a promising material for applications in energy storage, [14] electromagnetic energy absorption,
[15,16] and high temperature sensors. [17,18]
67 On the other hand, the polymer-to-ceramic transformation involves the decomposition of organic molecules, the release of gases, and is usually accompanied with a shrinkage and possible breakage of the sample. [19] To mitigate the possible breakage, two types of fillers (i.e. inert or active filler) can be added to the preceramic polymers in order to reduce the amount of gas released. Inert fillers reduce the amount of gas released by diluting the polymers. [20-22] On the other hand, an active
filler will react with the gases generated during the pyrolysis, thus reducing the amount of gases
need to be released. [23] Nanoscale carbon materials such as carbon nanotubes (CNTs) are
common inert fillers that are often used to improve the electrical and mechanical properties of
PDCs, as well as their processability. [3,24,25] For example, multiwall carbon nanotubes
(MWCNTs) have been added to oligosilazanes to produce SiCN/MWCNT electro-spun fibres,
where the electrical conductivity is increased by 500 times with the addition of only 2 wt%
MWCNTs. [3] Xu and co-workers have produced flexible SiCN/MWCNT composites with
aligned carbon nanotube sheets through the infiltration and pyrolysis of liquid preceramic
polymers. [26] Graphene is another intriguing inert filler, especially for energy storage
applications [14,27] owing to its unique electrical properties (carrier mobility of about 20000
cm2/V⋅s at 25oC), large specific surface area (more than 2500 m2/g) and high mechanical strength
(Young’s modulus of E = 1.0 TPa). [28-34]
To date, efforts to produce PDC composites have focused primarily on composites in the forms of
fibers and thin films, and have yet to investigate the effect of carbon materials alignment on
resulting composite properties. Given the anisotropic charge transport requirements of electronic
materials, it is desirable to introduce anisotropic properties into bulk PDC composites. Embedding
anisotropic graphene networks into polymer matrice becomes a common method for introducing
68 anisoptopic properties into a composite. Graphene aerogels (GAs) prepared from directional freeze
drying have anisotropic structures. [35,36] When such anisotropic structures are embedded into a
PDC matrix, the resulted composite is expected to offer anisotropic electrical conductivity since
the electron transport along the graphene basal plane is much more efficient than the transport
occurring through inter-plane hopping. [37-39] Utilizing the unique open pore structure of GA along with the electrical and mechanical properties of graphene, GA has been used extensively in energy storage and polymer composite applications. [40-50] The question now becomes whether or not anisotropic GAs can introduce anisotropic electrical properties when embedded in PDCs and increase the electrical conductivity while simultaneously enabling the fabrication of crack-free bulk ceramic samples.
In the present study, bulk SiCN ceramics embedded with anisotropic reduced graphene oxide aerogels (rGOAs) were fabricated by filling anisotropic rGOAs with a preceramic polymer of
SiCN ceramics, followed by crosslinking and pyrolysis. Anisotropic rGOAs in an amorphous
SiCN matrix are expected to have multiple functions including: (1) a reinforcing frame to produce a bulk ceramic composite, (2) a conductive network to improve the charge transport efficiency, and (3) a filler to impart different electrical conductivity values in the highly aligned graphene sheets endowing different electrical conductivity in the longitudinal and transversal directions. The morphology and electrical conductivity of SiCN/rGOA composites with different rGOA loadings were examined. The effect of rGOA on the transition of amorphous carbon to graphitic carbon in these composites was investigated by Raman spectroscopy and X-ray diffraction. In addition, the impact of rGOA on the mechanical properties of the composites was investigated.
69 Experimental Procedures
Ceraset™ VL 20 (purchased from Kion Corporation, Charlotte, NC) was used as the preceramic
polymer to prepare polymer derived SiCN based ceramics. Potassium permanganate, sulfuric acid
(12M), hydrogen peroxide (30%), Azobisisobutyronitrile (AIBN), Iron Nitrate, and copper foil
were purchased from Fisher and used as received. Poly (methyl methacrylate) (PMMA) with
Mw=35000 was purchased from TCI and used as received. Quartz slides purchased from SPI were
cleaned by subsequent sonications in methanol, acetone, and isopropanol before use. Hydrogen,
methane, and argon were purchased from Air Liquide and used without further purifications.
Preparation of graphene oxide. GO was prepared by modified Hummers method starting from
graphite powder.1 Briefly, graphite was oxidized by concentrated sulfuric acid and potassium
permanganate. Deionized (DI) water was slowly added followed by 30% hydrogen peroxide.
Graphene oxide was purified by washing with de-ionized water and subsequent centrifugation for several times until pH above 5 was obtained. Highly oxidized GO sheets are more stable than less oxidized GO when suspended in water.
Fabrication of Graphene Aerogels. Aqueous suspensions of graphene oxide (GO) at different concentrations of GO (10-40 mg/mL) were put into 1 cm x 1 cm plastic cuvettes. Each solution was then placed onto a block of dry ice until fully frozen (~20 minutes) before being lyophilized.
Lyophilization was performed using a Labcono freeze drying chamber at 20 µbar with the collector temperature set at -52 °C. Subsequently, GO aerogels were reduced by hydrazine vapor at 90 oC
for 1 hour. These partially reduced aerogels were further reduced by pyrolysis in an Argon
atmosphere at 1000 oC for 2 hours to obtain reduced graphene oxide aerogels (rGOAs) which were
used as the graphene aerogels (GA) in this study.
70 Fabrication of SiCN/rGOA composites. The pre-ceramic polymer, oligosilazane, was mixed
with 0.25 wt% of AIBN and placed under vacuum for 2 hours. The degassed oligosilazane/AIBN
solution was used to backfill the rGOAs with the aid of vacuum. Then, the backfilled rGOAs were
heated to 60 oC for 48 hours in a nitrogen atmosphere to crosslink the preceramic polymer. The
crosslinked oligosilazane/aerogel composites were pyrolyzed in a tube furnace under Argon. The
ramping rate was 1oC/min in heat steps, and the temperature was halted at 400 oC, 600 oC and 1000
oC for 1 hour, 2 hours, and 2 hours, respectively. The slow ramping rate and the halting of
temperature at 400 oC and 600 oC were used to ensure the release of gases. The picture of a bulk
SiCN/rGOA composite is shown in Figure 3-11. The density of SiCN/rGOA composites was calculated to be 2.05 g/cm3. The filling of oligosilazane under vacuum and slow pyrolysis
temperature increase ramp grantee the production of high density composites. In addition, four
composite samples of 40 mg/mL rGOA filled with oligosilazane were pyrolyzed at 600 oC, 700
oC, 800 oC, 900 oC, and 1000 oC along with crosslinked oligosilazanes. The samples were
compared to evaluate the impact of rGO on the formation of crystalline carbon domains at different
temperatures.
Preparation and transfer of single layer graphene. Graphene flakes were synthesized by using
a chemical vapor deposition (CVD) method. At first, a quartz boat containing several copper foils
(1 cm×1 cm) was placed into a quartz tube and mounted in a furnace. The quartz tube was then
vacuumed by an oil pump until required vacuum level was reached. The pressure inside the quartz
tube was less than 50 mTorr to meet the vacuum requirement. After that, hydrogen at a flow rate
of 30 SCCM was introduced into the quartz tube. The furnace was then heated to 400 oC with a
ramping rate of 10 oC/min, and it was halted at this temperature for 1 hour to eliminate copper
71 oxides residuals on copper foils. The furnace was further heated to 1000 oC and halted at the
temperature for 30 minutes to anneal copper foils. After the annealing of copper foils, the furnace
was kept at 1000 oC, and methane with a flow rate of 250 SCCM was introduced into the furnace.
The reaction of mixed gases took 30 minutes. Then the quartz boat containing the copper foils was
rapidly cooled down to room temperature by sliding the furnace away. Graphene flakes on copper
foils were synthesized by the procedure mentioned above.
The as prepared graphene flakes on copper foils were transferred to quartz slides by a wet transfer
process. Typically, PMMA was spin-coated onto copper foils as the protective layer of graphene.
Copper foils were then etched by using iron nitrate aqueous solutions. After rinsed by deionized
water several times, PMMA covered graphene flakes floating on water were transferred onto
quartz slides for overnight drying. The PMMA covered graphene films on quartz slides were then
annealed at 100 oC for 15 minutes in ambient atmosphere to flatten the films. At last, PMMA was washed away by using boiling acetone. Consequently, only graphene films were left on quartz slides. The Raman spectrum of graphene is shown in Figure 3-12.
Preparation of PDC films on graphene coated quartz slides. The preceramic polymer was spin-
coated onto graphene coated quartz slides. Typically, 0.02 mL of preceramic polymer was dropped
onto the center of the graphene film coated area, and spin coated immediately at 4000 rpm for 1
minute. The spin coated graphene/preceramic polymer films were cured in an oven at 160 oC for
16 hours to crosslink the preceramic polymer. After curing, the samples were pyrolyzed in argon
at 600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC. A ramping rate of 1 oC/min and a halting time of
2 hours at the final pyrolysis temperatures were used for all trials. As a control group, the
72 preceramic polymer was coated on a clean, non-graphene coated quartz slide and was crosslinked and pyrolyzed in following the same step as for the above graphene/preceramic polymer films.
Characterizations
The microstructures and surface morphologies of the ceramic/graphene bulk composites and
ceramics on quartz slides were examined by Zeiss Ultra-55 field effect scanning electron
microscope (SEM). Raman spectroscopy was performed using a Witec Raman spectrometer. A
532 nm laser with power of 0.175 mW was used in all Raman characterizations. The chemical
compositions of aerogels were analyzed by X-ray photoelectron spectroscopy (XPS, PHI 5400).
X-Ray diffraction (XRD) spectra were obtained using a PANalytical Empyrean X-ray
diffractrometer. The DC conductivity of SiCN/rGOA composites were obtained by measuring the current-voltage (I-V) curves (Keithley 2400, Keithley instruments Inc., Cleveland, USA) at room temperature. The surfaces of SiCN/rGOA composites were brushed with silver paste to form
electrodes. The I-V curves of SiCN/rGOA composites were obtained using standard two-point
measurements. The electric resistance (R) of samples was calculated by R=1/k, where k is the
slope of I-V curve obtained from linear fitting. Then, the electric conductivity (σ) was calculated
using the formula of σ=k·d/S, where d and S represent the length and cross-section area of samples, respectively. The specific surface area of aerogels was measured by nitrogen adsorption/desorption experiments carried out on a Quantachrome Nova 4200e analyzer. To measure the temperature- dependent conductivity of the SiCN/rGOA composite, the surfaces of the obtained SiCN/rGOA composite was cut to a 0.7 mm3 dimension. Electrodes of silver paint are applied to the composite edges perpendicular to the rGO sheet orientation in the sample. The temperature-dependent
electrical conductivity of the samples was then measured in a tube furnace filled with high purity
73 nitrogen at temperatures range from 25 oC to 800 oC. The compression experiments were
performed using a High Load Universal Testing: Instron 50kN Electromechanical Load Frame.
All the compression experiments were performed at room temperature until sample breakage was
detected with a crosshead speed ranging from 40 - 86 μm·min-1. A constant starting height value
of 10000 μm was set for every experiment, due to variation in sample height. Young’s modulus
was calculated with the ratio of the stress or force applied per unit of area throughout an axis
against the strain or the ratio of deformation over initial length of the sample throughout the same
axis.
Results and Discussion
Figure 3-1. Optical images of GO suspension (a), GO aerogel (b), free standing rGOAs (c), SEM images of rGOAs made from 20 mg/mL GO suspensions (d, e).
Figure 3-2. XPS spectra of the deconvoluted C 1s peaks of (a) GO aerogels and (b) rGOAs.
74 Figure 3-1 (a-c) are the photographs of a GO suspension, a GO aerogel and an rGOA, respectively.
Aerogels with different rGO densities have specific surface area in the range of 159 to 407 m2/g,
which indicates the formation of highly porous structures from GO aerogels. Also, this value is
less than the theoretical specific surface area for single graphene sheet (>2600 m2/g) likely due to stacking of graphene sheets within the composites. [51] The colour change from brown to black
indicates the reduction of GO and restoration of the graphene network. [52] The scanning electron
microscopy (SEM) images in Figure 3-1d and 1e demonstrate the alignment of GO sheets along the freezing direction. When the GO suspension was placed on a piece of dry ice, pseudo-steady-
state growth of ice crystals took place and an array of micrometer-sized polygonal ice rods parallel
to the freezing direction was obtained. [53-55] The ice rods acted as the templates for the directional growth of graphene sheets to produce GO aerogels with anisotropic structures (Figure
3-13). The chemical composition of the GO aerogels and rGOAs was monitored using X-ray photoelectron spectroscopy (XPS) (Figure 3-2). The deconvolution of C 1s spectra shows five peaks which correspond to the sp2 C–C bonds of graphene at 284.6 eV, the alcohol, phenolic, and ether C–O bonds at 286.2 eV, the carbonyl C=O bonds at 287.2 eV; the carboxyl O=C–O bonds at 289.3 eV; and the carbonitride C–N bonds at 285.6 eV (Figure 3-2a). [56,57] The presence of
C–N bonds is attributed to the hydrazine reduction process. The effective reduction of GO is
confirmed by the XPS spectrum in Figure 3-2b. This spectrum indicates that the fraction of C-C
signal makes up the majority of the total C 1s signal. The morphologies of the SiCN/rGOA
composites with 10–40 mg/mL rGOAs were investigated using SEM. The weight percentage of
rGO in the composites was estimated to be 0.5, 1, 1.5 and 2 percent, respectively, according to the
mass reduction of GO upon reduction and the density of SiCN (~2.05g/cm3). [58] Figure 3-3 and
3-4 show SEM images of the transversal section (perpendicular to rGO aligned direction) and the
75 longitudinal section (parallel to rGO aligned direction) of SiCN/rGOA composites, respectively.
In Figure 3-3, rGO networks in the transversal section are clearly shown, and the density of rGO
increases with higher loading of rGOAs. Additionally, the SEM images of pure SiCN ceramic powder (Figure 3-14) only show smooth interfaces, indicating the network features depicted in
Figure 3-3 are indeed from the rGO. The longitudinal section SEM images of the SiCN/rGOA composites embedded with 10–30 mg/mL rGOAs (Figure 3-4 a–c) present decent SiCN/rGOA
interfaces; however, the longitudinal section SEM image of SiCN/rGOA composite with 40
mg/mL rGOAs (Figure 3-4d) reveals the restacking of graphene sheets through the presence of
multilayer rGO. The restacking of rGO is due to the inter-sheets van der Waals forces at high rGO
loading. [59] Compared with wrinkle-free rGO flakes in pure rGOAs (Figure 3-1), all rGO flakes
in the final ceramic composites are wrinkled due to the shrinkage of the samples (~17 %) during
the pyrolysis. [60,61]
Figure 3-3. Transversal section SEM images of SiCN/rGOA ceramic composites with (a,b) 10 mg/mL, (c,d) 20 mg/mL, (e,f) 30 mg/mL, and (g,h) 40 mg/mL rGOA.
76 The electrical conductivities of the SiCN/rGOA composites, measured in the longitudinal and
transversal directions are summarized in Figure 3-5. A small amount of rGOAs embedded in the
PDC matrices can dramatically increase the electrical conductivity of the SiCN/rGOA ceramic
composites. As shown in Figure 3-4, 20 mg/mL rGOAs, namely 1wt% of rGO, embedded in SiCN
creates a composite with a conductivity of 157 S/m, which is more than 108 higher than that of
pure SiCN ceramics (4.15x10-7 S/m). [62] The high electrical conductivity is attributed to the
embedded rGOAs which provide efficient charge transport paths in the ceramic matrices. The
aligned rGO in SiCN lead to obvious anisotropic electrical properties. SiCN/rGOA ceramic
composites with an rGO loading of 10, 20, 30 and 40 mg/mL have longitudinal electrical
conductivities of 5 S/m, 157 S/m, 95 S/m, and 65 S/m, respectively. On the other hand, the
transversal electrical conductivities of SiCN/rGOA composites are 0.8 S/m, 17 S/m, 28 S/m and
10 S/m, respectively. The longitudinal electrical conductivity of the SiCN/rGOA composite with
20 mg/mL rGOA is about 9 times higher than the transversal electrical conductivity. This huge
difference confirms that the SiCN/rGOA composites have anisotropic electrical properties, and is
attributed to the ease of electron transport along the graphene basal plane and the difficulty in
transport between graphene sheets. The electrical conductivities in both directions share the same
trend regardless of the degrees of rGO loading. Up to a critical loading value, the electrical
conductivity increases with rGO loading content. Past this critical value, restacking of the
graphene sheets occurs and disrupts the charge transport paths, thereby, lowering the observed
electrical conductivity (Figure 3-4 c-d).
77
Figure 3-4. Longitudinal section SEM images of SiCN/rGOA ceramic composites with (a) 10 mg/mL, (b) 20 mg/mL, (c) 30 mg/mL, and (d) 40 mg/mL rGO.
The electrical conductivity of SiCN is attributed to the main conducting phases (i.e. graphitic
carbon) developed during pyrolysis. SiCN/rGOA ceramic composites have higher electrical
conductivity than other polymer composites containing carbon nanotubes (CNTs) and rGO but
with lower degree of electrical conductivity of matrix material. For example, Duong and co-
workers have reported that a polydimthoxylsilane composite with 4.5 wt% CNT aerogel has an
electrical conductivity of 33 S/m (with 16 orders of magnitude increase of electrical conductivity)
[63] and a poly (methyl methacrylate) composite with 12 mg/mL rGO aerogels has an electrical
conductivity of 0.9 S/m. [64] We believe that the lower degree of electrical conductivity over
matrix materials is because SiCN has much higher electrical conductivity as a semiconductor than
polymers as insulators. The high electrical conductivity of SiCN/rGOA ceramic composites is
attributed to two facts, the alignment of rGO and the generation of graphitic (sp2) carbon domains
facilitated by embedded rGO.
78
Figure 3-5. Anisotropic electrical conductivity of SiCN/rGOA ceramic composites.
Figure 3-6. Electrical conductivity change of SiCN/rGOA ceramic composites from room temperature to higher temperatures.
In addition, electrical conductivity measurements of composites from 25 oC to 800 oC were performed. SiCN/rGOA ceramic composites with the highest electrical conductivity is used in this study. As shown in Figure 3-6, the electrical conductivity of the SiCN/rGOA ceramic composites increases 26.5% by increasing the testing temperature from 25 oC to 800oC. The positive temperature coefficient of the electrical conductivity indicates the SiCN/rGOA ceramic
79 composites to be a kind of semiconductor. [65] The SiCN/rGOA composites generated in this work exhibit electrical conductivity greater than those of similar ceramic materials, and the semiconducting properties of this ceramic composite are believed to be attributed to the rGO matrix. The electrical conductivity of interconnected graphene sheets can be explained by mechanisms of hopping and tunnelling conduction.[66,67] The relationship between electrical conductivity and temperature in Mott’s model can be expressed as ∝ T-[1/n] in different
mechanisms.[68] In this model, the excellent linearity of curves when n=2,σ n=3, and n=4 can be
used to indicate tunnelling conduction mechanism, 2D hopping mechanism, and 3D hopping
mechanism for charge transport mechanism in materials. As shown in supporting materials (Figure
3-19), the curves of ln versus T-[1/n] are nearly linear when n=2, n=3, and n=4 as the coefficients
of determination (R2) areσ calculated to be 0.99587, 0.99742, and 0.99745, respectively. Therefore,
the electron transport in the SiCN/rGOA ceramic composites follow hopping and tunnelling
conduction mechanisms. Additionally, the 2D graphene sheets arranged 3D aerogels in composites
could be the reason explains why both 2D and 3D hopping mechanisms are applicable to this
composite. Because this kind of composites combine high thermal stability with high electrical conductivity, they have the potential to be used as conductive materials for fuel cells, high-
temperature sensing, aerospace sciences, and other area where materials are required to be used in
harsh environment with high electrical conductivity.
For pyrolysis temperatures at or below 1000 oC, the increase of conductivity results from the loss
of residual hydrogen atoms that leads to the increase of the sp2/sp3 ratio of carbon atoms.
[61,62,69,70] It is very interesting to notice that rGO in oligosilazane matrices has significant
impact on the formation of sp2 carbon atoms (i.e. graphitic domains) during the pyrolysis. In our
80 study, four composite samples of 40 mg/mL rGOA filled with oligosilazane were pyrolyzed at
600oC, 700oC, 800oC, 900oC, and 1000oC along with crosslinked oligosilazanes. The obtained
SiCN/rGOA composites and SiCN were examined using Raman spectroscopy and X-ray
diffraction.
Raman spectra of SiCN/rGOA composites and SiCN pyrolyzed at different temperatures are
shown in Figure 3-7. D peak (~1340 cm-1) and G peak (~1580 cm-1), characteristic peaks of
graphitic materials, can be observed from SiCN/rGOA composites pyrolyzed at 700 oC and above
and SiCN pyrolyzed at 800 oC and above. The G band is related to graphite lattices, and its shift
toward higher frequency region (blue shift up to 1600 cm-1) corresponds to the transition from
amorphous carbon to graphitic domains. [71-74] The G band positions of SiCN/rGOA pyrolyzed
at 700 oC, 800 oC, 900 oC and 1000 oC are 1571.9 cm-1, 1574.2 cm-1, 1583.5 cm-1, and 1594.7 cm-
1, respectively. The blue shift of G band (22.8 cm-1) indicates an effective transition from
amorphous carbon to graphitic carbon in SiCN/rGOA composites. In contrast, the G band positions
of pyrolyzed pure SiCN at 800 oC, 900 oC and 1000 oC are 1570.9 cm-1, 1574.6 cm-1, and 1578.8
cm-1, respectively. The blue shift of G band (7.9 cm-1) indicates the transition from amorphous
carbon to graphitic carbon in SiCN, which agrees with previous reports. [9,75-77] Comparing the
results of pyrolyzed SiCN with or without rGO, the lowest temperature of the appearance of the G
band and the D band in SiCN with rGO is 100 oC lower than that of pyrolyzed SiCN without rGO.
The difference of Raman spectra suggests that rGO plays a role in lowering the transition
temperature of amorphous carbon to graphitic domains. In addition, rGO in SiCN leads to a much
larger blue shift of G band in the composite, suggesting that rGO in PDCs grants a more effective
81 transition of amorphous carbons to graphitic domains probably due to the graphene domains on
rGO.
Figure 3-7. Raman spectra of (a) SiCN and (b) SiCN/rGOA pyrolyzed at different temperatures. The G band in each spectrum is label by an asterisk.
Although a graphene-enhanced formation of crystalline carbon has not been reported before,
surface-induced crystallization of liquids and soft materials has been investigated. [78,79] During
the pyrolysis of preceramic polymers, carbon atoms are produced in bulk between Si3N4 domains
82 and crystalize into graphitic domains. If graphene is presented in the matrix, the transition of
carbon atoms generated in the area close to graphene may have different values of the
thermodynamic variables of state. The reduction of crystallization activation energy could need to
lower crystallization temperature. In order to verify if graphene can enhance the formation of
crystalline carbon during the pyrolysis, Raman spectroscopy was used to monitor the formation of
sp2 carbon atoms in the precursor samples with and without graphene at different pyrolysis
temperatures. Preceramic polymer samples were produced by depositing polymers on bare quartz
slides and graphene coated quartz slides followed by thermal crosslinking. The SEM image of the
cross-section of preceramic polymer on a graphene coated quartz slide substrate shows a uniform
polymer film with a thickness around 21 microns (Figure 3-15). After pyrolysis, brown or black
PDC films were formed on substrates, and Raman spectroscopy was used to characterize the
carbon contents in PDC films (Figure 3-16). The Raman spectra of SiCN with graphene are similar
to those of SiCN with rGOA. PDCs with and without graphene exhibit different Raman spectra at
different pyrolysis temperatures. The G band positions for the PDC films with graphene pyrolyzed
at 700 oC, 800 oC, 900 oC and 1000 oC are 1581.9 cm-1, 1582.2 cm-1, 1586.3 cm-1, and 1595.6 cm-
1, respectively. In contrast, the G band positions of the PDC films without graphene pyrolyzed at
800 oC, 900 oC and 1000 oC are at 1581.4 cm-1, 1582.4 cm-1, and 1583.8 cm-1, respectively. The G
band blue shift (13.7 cm-1) of SiCN films with graphene is larger than that of SiCN films (2.4 cm-
1). The comparison of Raman studies of SiCN, SiCN with rGOA and SiCN with graphene suggests
that graphene domains on rGO grant a more effective transition of amorphous carbons to graphene
nanocrystals.
83
Figure 3-8. XRD spectra of SiCN/rGOA composites pyrolyzed at different temperatures.
The structure evolution of SiCN/rGOA composites pyrolyzed at different temperatures was
monitored by XRD (Figure 3-8). Pure SiCN remains amorphous under these pyrolysis
temperatures. [8-10] XRD peaks at around 26.5 degree are observed from SiCN/rGOA composites
pyrolyzed at 700oC and above. The presence of characteristic (002) XRD peak of graphite at 26.5
degree suggests the formation of graphite nanocrystals in these samples. [65,80-82] To verify that the XRD peaks observed at 26.5 degree are from rGO induced crystallization of graphite nanocrystals but not from rGO itself, the evolution of XRD peaks of rGO was examined. The characteristic XRD peak of GO at around 11 degrees can be clearly seen from the GO [65,80,83]
synthesized through the modified Hummer’s method (Figure 3-17). The XRD spectra of GO after
heat treatments at different temperatures are shown in Figure 3-18. The appearance of
characteristic (002) XRD peaks of rGO around 25 degrees [80,83] in Figure 3-18 verifies the
formation of rGO. The shift of XRD peak position of from 24.9 degree to 25.9 degree with
increased heat treatment temperatures suggests the decrease of space between rGO sheets resulted
84 from the removal of functional groups (e.g. epoxide and hydroxyl) on rGO basal plane upon the reduction. We believe that the absence of rGO peaks at around 25 degrees in SiCN/rGOA samples is due to the low concentration of rGO. The occurrence of XRD peaks at 26.5 degree from pyrolyzed SiCN/rGOA composites is attributed to the rGO induced formation of graphite carbon domains.
Figure 3-9. Young’s Modulus of SiCN/rGOA composites of different RGOA concentration. The inset is the picture of the cracked composite after the compression test.
The impact of embedded rGOA on the mechanical properties of SiCN/rGOA composites was investigated through the compression testing of the composites made from 10 mg/mL, 20 mg/mL,
30 mg/mL, and 40 mg/mL rGOA. The correlation between the rGOA concentration and the
Young’s modulus of SiCN/rGOA material is shown in Figure 3-9. The Young's modulus was calculated in GPa to determine the rigidity of an elastic material.
Figure 3-9 shows that SiCN/rGOA composites have a Young’s modulus ranging from 0.38 to 0.25
GPa depending on the rGOA concentrations. The Young’s modulus of the composite with rGOA
85 concentration of 10 and 20 mg/mL remains nearly constant at approximately 0.38 GPa. However,
with increased rGOA concentrations, the Young’s modulus decreases to 0.25 GPa at 40 mg/mL.
This reduction in Young’s modulus is due to the restacking of the graphene sheets, which is clearly
demonstrated in the SEM studies.
Figure 3-10. SEM images of cracks formed during the compression test for SiCN/rGOA composites of (a,b) 10 mg/mL, (c,d) 20 mg/mL, (e,f) 30 mg/mL, and (g,h) 40 mg/mL rGOA.
The SEM images of the fractured samples (Figure 3-10) show breakage locations of SiCN/rGOA composites under compression. Figure 3-10 a-d shows that the cracks were formed in SiCN matrix for SiCN/rGOA composites with rGOA concentration of 10 and 20 mg/mL. Figure 3-10 a,b shows that the graphene sheets stop the crack propagation in SiCN matrix. In contrast, the breakage
86 occurs along the stacked graphene sheet interfaces when the rGOA concentration increases to 30
and 40 mg/mL (Figure 3-10 e-h). Combining the Young’s modulus of SiCN/rGOA composites, it
is clear that stacked rGOs lower the strength of the composite. Lehmann and co-workers produced
SiCN films with the thickness around several microns through ion-beam sputtering. The films have
Young’s modulus of 260 and 85 GPa with the carbon content of 0% and 68%, respectively. Their
results also show that the addition of carbon content decreases the Young’s modulus of the material.
[84] Jiang and co-workers have reported a method to make bulk SiCN ceramics using polyvinyl alcohol sponges as templates, the obtained bulk SiCN ceramics have a porosity of ~ 10% and a strength of about 80 MPa. [85] While our SiCN/rGOA composites have lower modulus than SiCN films, the strength is much higher than the porous SiCN samples.
Conclusions
Bulk SiCN ceramics embedded with anisotropic graphene aerogels have been fabricated through
filling anisotropic graphene aerogels with a polymer precursor of SiCN ceramics (oligosilazane),
followed by crosslinking and pyrolysis. The electrical conductivity of SiCN/rGOA composites
increases from 10-7 S/m to about 157 S/m by embedding 1 wt% of anisotropic rGOA in SiCN ceramics. The electrical conductivity in longitudinal direction is ten times higher than that in transversal direction due to the aligned graphene. It is interesting to discover that graphene also facilitates the formation of graphitic domains in ceramics. Graphene embedded in ceramic precursors lowers the transition temperature of amorphous carbons to graphene nanocrystals.
These results suggest that anisotropic graphene structures have great potential in creating
anisotropic properties in PDCs.
87 Supporting Materials
Figure 3-11. A picture of bulk SiCN/rGOA composite.
Figure 3-12. Raman spectrum of single layer graphene transferred onto a quartz slide.
The quality of CVD graphene transferred onto quartz slides was verified by using Raman
spectroscopy. The characteristic peaks of graphene, namely the G band (1587 cm-1), the 2D band
(2673 cm-1), and the D band (1343 cm-1) are labeled in Figure 3-15. The intensity ratio between
88 the 2D band and G band is 2.0. In addition, the D band which corresponds to defects in graphene
only shows a small intensity, verifying the high quality of the graphene.
Figure 3-13. SEM images of longitudinal (A) and transversal (B) section of 30 mg/mL rGO aerogel.
Figure 3-14. SEM images of SiCN ceramic surfaces at low (left) and high (right) magnification.
Figure 3-15. The SEM image of a SiCN film on graphene embedded between PDC and quartz slide.
89
Figure 3-16. Raman spectra of (a) PDC on graphene coated quartz slides after pyrolysis conducted at different temperatures (600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC) and (b) PDC on quartz slides after pyrolysis conducted at different temperatures (600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC). All G band positons are labeled by asterisks.
Figure 3-17. XRD spectra of GO.
90
Figure 3-18. XRD spectra of GO pyrolyzed at different temperatures.
Figure 3-19. Fitting the relationship between conductivity and temperature to the function of (a) T-1/2, (b) T-1/3, (c) T-1/4, respectively.
σ ∝ σ ∝ σ ∝ References
1. Colombo, P.; Mera, G.; Riedel, R.; Sorarù, G.D. Polymer-derived ceramics: 40 years of
research and innovation in advanced ceramics. Journal of the American Ceramic Society
2010, 93, 1805-1837.
91 2. Zhang, L.; Wang, Y.; Wei, Y.; Xu, W.; Fang, D.; Zhai, L.; Lin, K.-C.; An, L. A silicon
carbonitride ceramic with anomalously high piezoresistivity. Journal of the American
Ceramic Society 2008, 91, 1346-1349.
3. Sarkar, S.; Zou, J.; Liu, J.; Xu, C.; An, L.; Zhai, L. Polymer-derived ceramic composite
fibers with aligned pristine multiwalled carbon nanotubes. ACS Applied Materials &
Interfaces 2010, 2, 1150-1156.
4. Sarkar, S.; Chunder, A.; Fei, W.; An, L.; Zhai, L. Superhydrophobic mats of polymer-
derived ceramic fibers. Journal of the American Ceramic Society 2008, 91, 2751-2755.
5. Sarkar, S.; Gan, Z.; An, L.; Zhai, L. Structural evolution of polymer-derived amorphous
sibcn ceramics at high temperature. J. Phys. Chem. C 2011, 115, 24993-25000.
6. Kleebe, H.J.; Störmer, H.; Trassl, S.; Ziegler, G. Thermal stability of sicn ceramics studied
by spectroscopy and electron microscopy. Applied organometallic chemistry 2001, 15,
858-866.
7. Ryu, H.-Y.; Wang, Q.; Raj, R. Ultrahigh-temperature semiconductors made from polymer-
derived ceramics. Journal of the American Ceramic Society 2010, 93, 1668-1676.
8. Mera, G.; Tamayo, A.; Nguyen, H.; Sen, S.; Riedel, R. Nanodomain structure of carbon-
rich silicon carbonitride polymer-derived ceramics. Journal of the American Ceramic
Society 2010, 93, 1169-1175.
9. Widgeon, S.; Mera, G.; Gao, Y.; Stoyanov, E.; Sen, S.; Navrotsky, A.; Riedel, R.
Nanostructure and energetics of carbon-rich sicn ceramics derived from
polysilylcarbodiimides: Role of the nanodomain interfaces. Chemistry of Materials 2012,
24, 1181-1191.
92 10. Mera, G.; Riedel, R.; Poli, F.; Müller, K. Carbon-rich sicn ceramics derived from phenyl-
containing poly(silylcarbodiimides). Journal of the European Ceramic Society 2009, 29,
2873-2883.
11. Ramakrishnan, P.A.; Wang, Y.T.; Balzar, D.; An, L.; Haluschka, C.; Riedel, R.; Hermann,
A.M. Silicoboron-carbonitride ceramics: A class of high-temperature, dopable electronic
materials. Applied Physics Letters 2001, 78, 3076-3098.
12. Mera, G.; Navrotsky, A.; Sen, S.; Kleebe, H.-J.; Riedel, R. Polymer-derived sicn and sioc
ceramics - structure and energetics at the nanoscale. Journal of Materials Chemistry A 2013,
1, 3826-3836.
13. Eckel, Z.C.; Zhou, C.; Martin, J.H.; Jacobsen, A.J.; Carter, W.B.; Schaedler, T.A. Additive
manufacturing of polymer-derived ceramics. Science (Washington, DC, U. S.) 2016, 351,
58-62.
14. David, L.; Bhandavat, R.; Barrera, U.; Singh, G. Silicon oxycarbide glass-graphene
composite paper electrode for long-cycle lithium-ion batteries. Nat Commun 2016, 7.
15. Duan, W.; Yin, X.; Li, Q.; Schlier, L.; Greil, P.; Travitzky, N. A review of absorption
properties in silicon-based polymer derived ceramics. Journal of the European Ceramic
Society 2016, 36, 3681-3689.
16. Luo, C.; Duan, W.; Yin, X.; Kong, J. Microwave-absorbing polymer-derived ceramics
from cobalt-coordinated poly(dimethylsilylene)diacetylenes. J. Phys. Chem. C 2016, 120,
18721-18732.
17. Zhao, R.; Shao, G.; Cao, Y.; An, L.; Xu, C. Temperature sensor made of polymer-derived
ceramics for high-temperature applications. Sensors and Actuators, A 2014, 219, 58-64.
93 18. Nagaiah, N.R.; Kapat, J.S.; An, L.; Chow, L. Novel polymer derived ceramic-high
temperature heat flux sensor for gas turbine environment. Journal of Physics: Conference
Series 2006, 34, 458-472.
19. Bernardo, E.; Fiocco, L.; Parcianello, G.; Storti, E.; Colombo, P. Advanced ceramics from
preceramic polymers modified at the nano-scale: A review. Materials 2014, 7, 1927-1943.
20. Lee, S.-H.; Weinmann, M.; Aldinger, F. Particulate-reinforced precursor-derived si–c–n
ceramics: Optimization of pyrolysis atmosphere and schedules. Journal of the American
Ceramic Society 2005, 88, 3024-3031.
21. Konegger, T.; Liersch, A.; Gierl, C.; Scheffler, M. Bulk ceramic composites derived from
a preceramic polysilazane with alumina and zirconia fillers. Advanced Engineering
Materials 2013, 15, 394-406.
22. Günthner, M.; Schütz, A.; Glatzel, U.; Wang, K.; Bordia, R.K.; Greißl, O.; Krenkel, W.;
Motz, G. High performance environmental barrier coatings, part i: Passive filler loaded
sicn system for steel. Journal of the European Ceramic Society 2011, 31, 3003-3010.
23. Studart, A.R.; Gonzenbach, U.T.; Tervoort, E.; Gauckler, L.J. Processing routes to
macroporous ceramics: A review. Journal of the American Ceramic Society 2006, 89,
1771-1789.
24. Zhang, Y.; Yin, X.; Ye, F.; Kong, L. Effects of multi-walled carbon nanotubes on the
crystallization behavior of pdcs-sibcn and their improved dielectric and em absorbing
properties. Journal of the European Ceramic Society 2014, 34, 1053-1061.
25. An, L.; Xu, W.; Rajagopalan, S.; Wang, C.; Wang, H.; Fan, Y.; Zhang, L.; Jiang, D.; Kapat,
J.; Chow, L., et al. Carbon-nanotube-reinforced polymer-derived ceramic composites.
Advanced Materials 2004, 16, 2036-2040.
94 26. Yang, J.; Downes, R.; Yu, Z.; Park, J.G.; Liang, R.; Xu, C. Strong and ultra-flexible
polymer-derived silicon carbonitride nanocomposites by aligned carbon nanotubes.
Ceramics International 2016, 42, 13359-13367.
27. David, L.; Shareef, K.M.; Abass, M.A.; Singh, G. Three-dimensional polymer-derived
ceramic/graphene paper as a li-ion battery and supercapacitor electrode. RSC Advances
2016, 6, 53894-53902.
28. Lee, C.; Wei, X.; Kysar, J.W.; Hone, J. Measurement of the elastic properties and intrinsic
strength of monolayer graphene. Science 2008, 321, 385-388.
29. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Katsnelson, M.I.; Grigorieva, I.V.;
Dubonos, S.V.; Firsov, A.A. Two-dimensional gas of massless dirac fermions in graphene.
Nature 2005, 438, 197-200.
30. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Zhang, Y.; Dubonos, S.V.;
Grigorieva, I.V.; Firsov, A.A. Electric field effect in atomically thin carbon films. Science
2004, 306, 666-669.
31. Novoselov, K.S.; Jiang, Z.; Zhang, Y.; Morozov, S.V.; Stormer, H.L.; Zeitler, U.; Maan,
J.C.; Boebinger, G.S.; Kim, P.; Geim, A.K. Room-temperature quantum hall effect in
graphene. Science 2007, 315, 1379-1390.
32. Slonczewski, J.C.; Weiss, P.R. Band structure of graphite. Physical Review 1958, 109, 272-
279.
33. Zhang, Y.; Tan, Y.-W.; Stormer, H.L.; Kim, P. Experimental observation of the quantum
hall effect and berry's phase in graphene. Nature 2005, 438, 201-204.
34. Balandin, A.A.; Ghosh, S.; Bao, W.; Calizo, I.; Teweldebrhan, D.; Miao, F.; Lau, C.N.
Superior thermal conductivity of single-layer graphene. Nano Letters 2008, 8, 902-907.
95 35. Xu, Z.; Zhang, Y.; Li, P.; Gao, C. Strong, conductive, lightweight, neat graphene aerogel
fibers with aligned pores. ACS Nano 2012, 6, 7103-7113.
36. Schiffres, S.N.; Harish, S.; Maruyama, S.; Shiomi, J.; Malen, J.A. Tunable electrical and
thermal transport in ice-templated multilayer graphene nanocomposites through freezing
rate control. ACS Nano 2013, 7, 11183-11189.
37. Shahil, K.M.F.; Balandin, A.A. Thermal properties of graphene and multilayer graphene:
Applications in thermal interface materials. Solid State Communications 2012, 152, 1331-
1340.
38. Yang, M.; Hou, Y.; Kotov, N.A. Graphene-based multilayers: Critical evaluation of
materials assembly techniques. Nano Today 2012, 7, 430-447.
39. Sadeghi, M.M.; Jo, I.; Shi, L. Phonon-interface scattering in multilayer graphene on an
amorphous support. Proc. Natl. Acad. Sci. U. S. A. 2013, 110, 16321-16326.
40. Qian, Y.; Ismail, I.M.; Stein, A. Ultralight, high-surface-area, multifunctional graphene-
based aerogels from self-assembly of graphene oxide and resol. Carbon 2014, 68, 221-231.
41. Worsley, M.A.; Pauzauskie, P.J.; Olson, T.Y.; Biener, J.; Satcher, J.H.; Baumann, T.F.
Synthesis of graphene aerogel with high electrical conductivity. Journal of the American
Chemical Society 2010, 132, 14067-14069.
42. Chen, L.; Wang, X.; Zhang, X.; Zhang, H. 3d porous and redox-active prussian blue-in-
graphene aerogels for highly efficient electrochemical detection of h2o2. Journal of
Materials Chemistry 2012, 22, 22090-22096.
43. Liang, J.; Liu, Y.; Guo, L.; Li, L. Facile one-step synthesis of a 3d macroscopic sno2-
graphene aerogel and its application as a superior anode material for li-ion batteries. RSC
Adv. 2013, 3, 11489-11492.
96 44. Wu, T.; Chen, M.; Zhang, L.; Xu, X.; Liu, Y.; Yan, J.; Wang, W.; Gao, J. Three-
dimensional graphene-based aerogels prepared by a self-assembly process and its excellent
catalytic and absorbing performance. J. Mater. Chem. A 2013, 1, 7612-7621.
45. Xiao, L.; Wu, D.; Han, S.; Huang, Y.; Li, S.; He, M.; Zhang, F.; Feng, X. Self-assembled
fe2o3/graphene aerogel with high lithium storage performance. Acs Applied Materials &
Interfaces 2013, 5, 3764-3769.
46. Chen, M.; Zhang, C.; Li, X.; Zhang, L.; Ma, Y.; Zhang, L.; Xu, X.; Xia, F.; Wang, W.;
Gao, J. A one-step method for reduction and self-assembling of graphene oxide into
reduced graphene oxide aerogels. J. Mater. Chem. A 2013, 1, 2869-2877.
47. Nardecchia, S.; Carriazo, D.; Ferrer, M.L.; Gutierrez, M.C.; del, M.F. Three dimensional
macroporous architectures and aerogels built of carbon nanotubes and/or graphene:
Synthesis and applications. Chemical Society Reviews 2013, 42, 794-830.
48. Das, S.; Irin, F.; Ma, L.; Bhattacharia, S.; Hedden, R.C.; Green, M.J. Rheology and
morphology of pristine graphene/polyacrylamide gels. ACS Appl Mater Interfaces 2013,
12, 521-540.
49. Ji, C.-C.; Xu, M.-W.; Bao, S.-J.; Cai, C.-J.; Lu, Z.-J.; Chai, H.; Yang, F.; Wei, H. Self-
assembly of three-dimensional interconnected graphene-based aerogels and its application
in supercapacitors. Journal of Colloid and Interface Science 2013, 407, 416-424.
50. Ye, S.; Feng, J.; Wu, P. Deposition of three-dimensional graphene aerogel on nickel foam
as a binder-free supercapacitor electrode. ACS applied materials & interfaces 2013, 5,
7122-7129.
51. Peigney, A.; Laurent, C.; Flahaut, E.; Bacsa, R.R.; Rousset, A. Specific surface area of
carbon nanotubes and bundles of carbon nanotubes. Carbon 2001, 39, 507-514.
97 52. Pei, S.; Cheng, H.-M. The reduction of graphene oxide. Carbon 2012, 50, 3210-3228.
53. Deville, S.; Maire, E.; Lasalle, A.; Bogner, A.; Gauthier, C.; Leloup, J.; Guizard, C.
Influence of particle size on ice nucleation and growth during the ice-templating process.
Journal of the American Ceramic Society 2010, 93, 2507-2510.
54. Nishihara, H.; Mukai, S.R.; Yamashita, D.; Tamon, H. Ordered macroporous silica by ice
templating. Chemistry of Materials 2005, 17, 683-689.
55. Gutiérrez, M.C.; Ferrer, M.L.; del Monte, F. Ice-templated materials: Sophisticated
structures exhibiting enhanced functionalities obtained after unidirectional freezing and
ice-segregation-induced self-assembly. Chemistry of Materials 2008, 20, 634-648.
56. Cong, H.-P.; Ren, X.-C.; Wang, P.; Yu, S.-H. Macroscopic multifunctional graphene-based
hydrogels and aerogels by a metal ion induced self-assembly process. ACS Nano 2012, 6,
2693-2703.
57. Wu, X.-L.; Wen, T.; Guo, H.-L.; Yang, S.; Wang, X.; Xu, A.-W. Biomass-derived sponge-
like carbonaceous hydrogels and aerogels for supercapacitors. ACS nano 2013, 7, 3589-
3597.
58. Sun, Z.L.; Zhou, Y.; Jia, D.C.; Duan, X.M.; Yang, Z.H.; Ye, D.; Zhang, P.F.; Zhang, Q.
Mechanical and thermal physical properties of amorphous sicn(o) ceramic bulks prepared
by hot-press sintering. Materials Letters 2012, 72, 57-59.
59. Yang, X.; Zhu, J.; Qiu, L.; Li, D. Bioinspired effective prevention of restacking in
multilayered graphene films: Towards the next generation of high-performance
supercapacitors. Advanced Materials 2011, 23, 2833-2838.
60. Deng, S.; Berry, V. Wrinkled, rippled and crumpled graphene: An overview of formation
mechanism, electronic properties, and applications. Materials Today 2016, 19, 197-212.
98 61. Feng, C.; Yi, Z.; Dumée, L.F.; Garvey, C.J.; She, F.; Lin, B.; Lucas, S.; Schütz, J.; Gao,
W.; Peng, Z., et al. Shrinkage induced stretchable micro-wrinkled reduced graphene oxide
composite with recoverable conductivity. Carbon 2015, 93, 878-886.
62. Shao, G.; Peng, W.; Ma, C.; Zhao, W.; Guo, J.; Feng, Y.; Wang, H.; Zhang, R.; An, L.
Enhanced electric conductivity of polymer-derived sicn ceramics by microwave post-
treatment. Journal of the American Ceramic Society 2017, 100, 842-847.
63. Mikhalchan, A.; Fan, Z.; Tran, T.Q.; Liu, P.; Tan, V.B.C.; Tay, T.-E.; Duong, H.M.
Continuous and scalable fabrication and multifunctional properties of carbon nanotube
aerogels from the floating catalyst method. Carbon 2016, 102, 409-418.
64. Fan, Z.; Gong, F.; Nguyen, S.T.; Duong, H.M. Advanced multifunctional graphene aerogel
– poly (methyl methacrylate) composites: Experiments and modeling. Carbon 2015, 81,
396-404.
65. Wang, Y.; Jiang, T.; Zhang, L.; An, L. Electron transport in polymer-derived amorphous
silicon oxycarbonitride ceramics. Journal of the American Ceramic Society 2009, 92,
1603-1606.
66. Xu, Z.; Zhang, Y.; Li, P.; Gao, C. Strong, conductive, lightweight, neat graphene aerogel
fibers with aligned pores. ACS Nano 2012, 6, 7103-7113.
67. Peng, H. Aligned carbon nanotube/polymer composite films with robust flexibility, high
transparency, and excellent conductivity. Journal of the American Chemical Society 2008,
130, 42-43.
68. Mott, N.F. Conduction in glasses containing transition metal ions. Journal of Non-
Crystalline Solids 1968, 1, 1-17.
99 69. Trassl, S.; Puchinger, M.; Rössler, E.; Ziegler, G. Electrical properties of amorphous
sicxnyhz-ceramics derived from polyvinylsilazane. Journal of the European Ceramic
Society 2003, 23, 781-789.
70. Haluschka, C.; Engel, C.; Riedel, R. Silicon carbonitride ceramics derived from
polysilazanes part ii. Investigation of electrical properties. Journal of the European
Ceramic Society 2000, 20, 1365-1374.
71. Ferrari, A.C.; Robertson, J. Interpretation of raman spectra of disordered and amorphous
carbon. Physical Review B 2000, 61, 14095-14107.
72. Ferrari, A.C.; Robertson, J. Resonant raman spectroscopy of disordered, amorphous, and
diamondlike carbon. Physical Review B 2001, 64, 075414-075432.
73. Casiraghi, C.; Ferrari, A.C.; Robertson, J. Raman spectroscopy of hydrogenated
amorphous carbons. Physical Review B 2005, 72, 085401-085432.
74. Ferrari, A.C.; Robertson, J. Raman spectroscopy of amorphous, nanostructured, diamond–
like carbon, and nanodiamond. Philosophical Transactions of the Royal Society of London.
Series A: Mathematical, Physical and Engineering Sciences 2004, 362, 2477-2512.
75. Bouillon, E.; Langlais, F.; Pailler, R.; Naslain, R.; Cruege, F.; Huong, P.V.; Sarthou, J.C.;
Delpuech, A.; Laffon, C.; Lagarde, P., et al. Conversion mechanisms of a polycarbosilane
precursor into an sic-based ceramic material. Journal of Materials Science 1991, 26, 1333-
1345.
76. Saha, A.; Raj, R.; Williamson, D.L. A model for the nanodomains in polymer-derived sico.
Journal of the American Ceramic Society 2006, 89, 2188-2195.
77. Maniette, Y.; Oberlin, A. Interphase phenomena in silicon carbide single filament
composites. Journal of Materials Science 1990, 25, 3864-3874.
100 78. Li, T.; Donadio, D.; Ghiringhelli, L.M.; Galli, G. Surface-induced crystallization in
supercooled tetrahedral liquids. Nat Mater 2009, 8, 726-730.
79. Peter, L. Surface induced ordering effects in soft condensed matter systems. Journal of
Physics: Condensed Matter 2004, 16, 699-714.
80. Tai, F.C.; Wei, C.; Chang, S.H.; Chen, W.S. Raman and x-ray diffraction analysis on
unburned carbon powder refined from fly ash. Journal of Raman Spectroscopy 2010, 41,
933-937.
81. Zhang, K.; Zhang, Y.; Wang, S. Enhancing thermoelectric properties of organic composites
through hierarchical nanostructures. 2013, 3, 3448-3463.
82. Lin, M.-C.; Gong, M.; Lu, B.; Wu, Y.; Wang, D.-Y.; Guan, M.; Angell, M.; Chen, C.;
Yang, J.; Hwang, B.-J., et al. An ultrafast rechargeable aluminium-ion battery. Nature 2015,
520, 324-328.
83. Chu, X.; Zhu, Q.; Dai, W.-L.; Fan, K. Excellent catalytic performance of graphite oxide in
the selective oxidation of glutaraldehyde by aqueous hydrogen peroxide. RSC Advances
2012, 2, 7135-7139.
84. Lehmann, G.; Hess, P.; Wu, J.J.; Wu, C.T.; Wong, T.S.; Chen, K.H.; Chen, L.C.; Lee, H.Y.;
Amkreutz, M.; Frauenheim, T. Structure and elastic properties of amorphous silicon carbon
nitride films. Physical Review B 2001, 64, 165305-165332.
85. Jiang, T.; Hill, A.; Fei, W.; Wei, Y.; Tellam, M.; Xu, C.; An, L. Making bulk ceramics
from polymeric precursors. Journal of the American Ceramic Society 2010, 93, 3017-3019.
101 CHAPTER 4: BULK POLYMER DERIVED CERAMIC COMPOSITES WITH EDGE FUNCTIONALIZED GRAPHENE
Introduction
Silicon-based Polymer Derived Ceramics (PDCs) have been synthesized from 1960s. [1] They keep the advantages of mechanical strength, thermal stability, and chemical inertness from traditional ceramics. [2-6] Unlike traditional ceramics obtained by sintering method, PDCs are synthesized by pyrolysis of liquid polymeric precursors in inert atmosphere thus directly convert polymers into ceramics. Liquid polymeric precursors provide the availability of various liquid- based processing techniques like casting, extrusion, spin-on coating, dip coating and spray coating.
[7-11] These technologies make PDCs able to be used in fabrications of ceramics and related devices with complex shapes such as fibers, [12,13] porous materials, [14-16] and membrane coatings, [17,18] which are difficult or even impossible to be obtain by conventional routes. Also, synthesis of PDCs at temperatures lower than those for traditional ceramics leads to energy-saving ceramics preparations. [19] These superior properties of PDCs mentioned above make them as a kind of materials widely used in applications such as MEMS, [20-22] energy storage, [11,23-25] and high temperature sensors. [26-29]
PDCs usually have low electrical conductivity 10-12-10-7 S/cm, [30,31] and the fabrication of PDCs based composites is the way to increase their electrical conductivity. Adding conductive components such as CNTs, [32-35] carbon fibers, [36] carbon black, [37,38] graphite flakes, [39]
reduced graphene oxide (rGO), [40,41] and metal salts like aluminum oxide and Molybdenum
disilicide [42,43] into insulating PDCs matrix can effectively increase the electrical conductivity of PDCs based composites. Additionally, introducing percolated networks composed of
102 conductive materials into PDC composites is found to be a better method of increasing the electrical conductivity. [44-46] For example, the addition of embedded graphene aerogels composted of conductive materials with inter-connected networks was reported to increase the electrical conductivity of composites to 1.57 S/cm. [47]
Edge functionalized graphene oxide (EFGO) is a commercial conductive material from Garmor
Inc. Functional groups such as hydroxyl groups, carbonyl groups, and carboxylic acid groups only form on edges of graphene flakes. Those functional groups provide EFGO with a good dispersity in solvents such as ethanol, acetone. Meanwhile, the electrical conductivity of EFGO (~10 S/cm) is much higher that of graphene oxide synthesized from Hummer’s method. It is attributed to the remaining graphitic structures in the basal area of EFGO flakes which facilitate the charge transport by inter-plane hopping among EFGO flakes.
Here in, we report the introduction of conductive EFGO networks into bulk PDCs composites with a facile method different from introducing embedded graphene aerogels. Meanwhile, nontoxic polymeric precursors for the preparation of SiOC PDCs are used. [48] Polymeric precursors are infiltrated into the highly porous PVA foams with an excellent EFGO attachment to form green bodies for pyrolysis processes. PVA foams are served as a sacrificial component and decomposes during pyrolysis. As a result, EFGO networks embedded SiOC PDC composites are prepared after pyrolysis. The electrical conductivity of such composites at a wide temperature is investigated.
The role of percolated EFGO networks on the preparation of bulk PDC composites, graphitic domains formation in the nearby area, electrical conductivity improvement, and thermal conductivity is explored.
103 Experimental Procedures
Polysiloxsane precursor (SILRES 62C, Wecker), poly (vinyl alcohol) (PVA) foam (Sponge King),
Pyro-Duct 597-A conductive adhesive (Aremco), ethanol (Fisher) and copper wires (Fisher) were
used as received. Argon was purchased from Air Liquide and used without further purifications.
Edge functionalized graphene oxide (EFGO) with a few layers graphene was provided by Garmor
Inc.
Preparation of EFGO/SILRES 62C/PVA composites (PDC composites). A mixture containing
700 mg EFGO and 100 mL ethanol was sonicated (Branson digital sonifer equipped with stainless
steel tips) for 30 minutes, and a homogenous EFGO dispersion with a concentration of 7 mg/mL was obtained. Pre-shaped PVA foams were immersed into the EFGO dispersion for 2 hours, and the resulted EFGO attached PVA foams were placed into a vacuum oven set at 50 oC for 12 hours to completely evaporate the residual ethanol in PVA foams. Once the PVA foams were dried, they were immersed into the SILRES 62C precursor under vacuum for 12 hours to ensure that all voids were filled with SILRES 62C. The SILRES 62C filled samples were heated at 160 oC for 16 hours
to crosslink the polysiloxane for subsequent pyrolysis. In a typical pyrolysis process, green bodies
(i.e. crosslinked composites) were pyrolyzed at 300 oC, 400 oC, 600 oC, and 1000 oC for 2 hours,
respectively. The ramping rate in all heating steps was 1 oC/min, and composites were naturally
cooled down after pyrolysis. The whole pyrolysis process was conducted in argon atmosphere. To
study the composition evolution of ceramic composites during pyrolysis processes, composites
with different final pyrolysis temperatures (300 oC, 400 oC, 500 oC, 600 oC, 700 oC, 800 oC, and
900 oC) were obtained. The details of pyrolysis conditions are summarized in Table 4-3.
104 Preparation of EFGO/SILRES 62C ceramic composites. EFGO was first manually mixed with
SILRES 62C precursor with the mass ratio of EFGO: SILRES 62C=2:100, and the mixture was then sonicated by a horn sonifier for 30 minutes. After sonication, the mixture was filled into cylinder shape molds made by aluminum foils. Filled molds were placed into an oven set at 160
oC for 16 hours to cure the precursor. After peeling aluminum foils off, cured samples were ready
for pyrolysis. EFGO/SILRES 62C ceramic composites with different final pyrolysis temperatures
(300 oC, 400 oC, 500 oC, 600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC) were prepared by using the
same pyrolysis conditions as those for preparations of PVA/SILRES 62C/EFGO ceramic
composites.
Preparation of pure SILRES 62C ceramics. The liquid SILRES 62C precursor was put into
molds made by aluminum foils and placed into the oven at 160 oC for 16 hours to crosslink the
precursor. After removing aluminum foils, Pure crosslinked SILRES 62C samples were pyrolyzed
at different temperatures (300 oC, 400 oC, 500 oC, 600 oC, 700 oC, 800 oC, 900 oC, and 1000 oC)
by using the same pyrolysis conditions as those for preparations of EFGO/SILRES 62C/PVA
ceramic composites.
Heat treatment to reveal networks embedded in pyrolyzed composites. Green bodies used for
the preparation of EFGO/SILRES 62C/PVA composites were heated in air with the ramping rate
of 1 oC/min. The furnace temperature was halted at 300 oC and 500 oC for 2 hours, respectively.
Measurement of electrical conductivity. Resistance on two ends of cylinder shape samples
recorded using electrochemistry workstation (CH Instruments) was used to calculate the electrical
conductivity. The resistance was measured in a furnace filled with argon from room temperature
105 (25 oC) to 600 oC. Electrical conductivity of samples is calculated from the resistance. The
resistance of each sample was measured at least 3 times.
Measurement of thermal conductivity. Thermal conductivity of samples was calculated by using the equation of k = , where is the thermal diffusivity, is the specific heat capacity,
𝑝𝑝 𝑝𝑝 and is the density.𝛼𝛼 [49]∙ 𝐶𝐶 FlashLine∙ 𝜌𝜌 5000α thermal diffusivity system𝐶𝐶 (Anter Corporation, USA) was ρused to obtain heat diffusivities of composites. Round shape disks with 12.5 mm diameter and
1-2 mm thickness from PDC composites before and after pyrolysis at 1000 oC were used for the
measurement. Both sides of these disks were coated with ~15 nm platinum (Pt) by sputter coating
followed by a graphite aerosol spray. Standard pulse flash technique was used in measurement of
heat diffusivities. Specific heat capacity was measured by using differential scanning calorimetry
DSC (TA Instruments). About 10 mg PDC composites before and after pyrolysis at 1000 oC were
used in DSC tests. Ramping rate applied was 5 oC/min, and the scanning temperature was 10 oC to
170 oC for green bodies and 10 oC to 350 oC for pyrolyzed PDC composites. Acquired endothermal
curves were used to calculate heat capacities at specific temperatures (Figure 4-23).
Measurement of linear shrinkage. Linear shrinkage was obtained by measuring the change of
dimension from multiple cylinder shape samples after pyrolysis processes at different temperatures.
Measurement of Young’s modulus. Young’s modulus of composites was acquired by an Instron
50 kN Electromechanical Load Frame Universal Testing Machine at room temperature. 20 mm×20
mm×20 mm EFGO/SILRES 62C/PVA composites pyrolyzed at 1000 oC were used in this series
of tests. Every test was performed until sample breakage was observed with the starting height
106 value of 30 mm. Young’s modulus was calculated by the ratio between the force applied per unit
of area and the strain of the sample.
Characterizations
The tests on size distribution of EFGO flakes is performed on a dynamic light scattering instrument
(DLS, Malvern ns290). TEM images and selected area electron diffraction (SAED) patterns are obtained from a JEOL 1011 transmission electron microscope. Thickness of EFGO flakes is
revealed by a Veeco Dimension 3100 atomic force microscope system. The proton nuclear
magnetic resonance (1HNMR) spectrum of SiOC polymeric precursor was obtained from a Bruker
AvanceIII 400 (400 MHz). The Fourier-transform infrared (FTIR) spectrum of polysiloxane
precursor was investigated by a Perkin Elmer Spectrum 100 spectrometer. Morphologies and
elemental compositions of ceramic composites were examined by a scanning electron microscope
(SEM, ZEISS Ultra 55) coupled with Energy-Dispersive X-ray spectroscopy (EDS).
Decomposition and mass loss of ceramic composites and starting materials were acquired by
thermal gravimetric analysis (TGA) from TA Instruments. Raman spectra of ceramic composites
were obtained from a WiTec Raman system, and a 532 nm laser with power of 0.175 mW was
used in all Raman characterizations. Chemical states of elements in ceramic composites were
tested by X-ray photoelectron spectroscopy (XPS, PHI 5400). Electrical conductivities of ceramic
composites were measured by a chemical workstation from CH instruments with the aid of an
argon filled tube furnace. Thermal diffusivities of composites were measured by a FlashLine 5000
thermal diffusivity system (Anter Corporation, USA). Heat capacities of ceramic composites were
obtained from differential scanning calorimetry (DSC, TA Instruments).
107 Results and Discussion
Figure 4-1 illustrates the fabrication process of SiOC/EFGO composites. The graphene network
was obtained by immersing the pre-shaped PVA foam into a EFGO ethanol dispersion where
EFGO flakes were deposited onto PVA foam walls. The liquid SiOC precursor (SILRES 62C) was
filled into the voids of the PVA foam and crosslinked to produce EFGO/SILRES 62C/PVA green
bodies. The PVA foam was decomposed during the pyrolysis, which led to SiOC/EFGO
composites with a continuous EFGO network.
Figure 4-1. The schematic illustration of the preparation of EFGO network embedded PDC composites.
EFGO is a kind of commercialized multi-layers graphene oxide, and it is produced by ball-milling with simultaneous hydrogen peroxide oxidation. Edges of EFGO flakes are functionalized with hydroxyl, carbonyl and carboxylate groups, and the oxygen contents is reported to be about 5 wt%.
EFGO flakes have sizes of below 1 µm (Figure 4-2a), and the average size of them is 350 nm from
108 the DLS test (Figure 4-15). The multi-layer structure of EFGO can be clearly seen from Figure 4-
2b. Additionally, four sets of six-fold SAED patterns circled in Figure 4-2c indicate the existence of stacked multi-layer graphitic structure in EFGO. [50-52] Also, arcs in the SAED image
regarding the spacing of 2.10 nm and 1.23 nm is attributed to the (1100) and (1120) lattice fringes
of graphitic structures randomly oriented in EFGO flakes. [53-55] The typical thickness of EFGO
flakes is found to be around 8 nm from the AFM height profile (Figure 4-3), therefore EFGO flakes
have around 8 layers of stacked graphene.
The Raman spectrum in Figure 4-4 verifies the existence of graphitic domains in EFGO flakes
because characteristic G peak, D peak and 2D peak at 1563.8 cm-1, 1343.9 cm-1, and 2693.6 cm-1
are observed in the spectrum. The intensity ratio between the D peak and the G peak is 0.39, and
it is much smaller than that for GO synthesized from Hummer’s method (0.9-1.9). [56-59] The
intensity ratio of the D peak and the G peak relates to the ratio between sp3 carbon and sp2 carbon.
Smaller value of the intensity ratio reflects higher percentage of sp2 carbon in samples, namely
more ordered graphitic structure and fewer defects. Therefore, EFGO have more ordered
structure than GO synthesized by the Hummer’s method. The graphitic structure in the basal area of EFGO flakes endow EFGO with electrical conductivity (~10 S/cm) dramatically higher than that of GO synthesized from Hummer’s method. Meanwhile, functional groups on edges facilitate the dispersity of EFGO in solvents such as ethanol, acetone, and water, thus makes EFGO as an excellent candidate in solution-based processing. It needs to be noted that ethanol is the best medium to disperse EFGO among common solvents, and it is believed to be attributed to the abundant hydroxyl groups on edges of EFGO flakes. Therefore, ethanol is used as the dispersant for EFGO in the preparation of composites.
109
Figure 4-2. (a, b) TEM images of EFGO flakes. (c) The SAED pattern of EFGO flakes. Four sets of six-fold SAED pattern regarding the (1100) lattice fringe of graphitic structures are labeled in red, blue, green, and purple circles.
Figure 4-3. The AFM image of a EFGO flake on mica substrate. The scanning area is 2.5 µm×2.5 µm. The height profile beneath the AFM image reveals the height at the white sectioning line in the AFM image.
110
Figure 4-4. The Raman spectrum of EFGO flakes. The position of the G peak, the D peak and the 2D peak are at 1563.8 cm-1, and 1343.9 cm-1, and 2693.6 cm-1, respectively.
Figure 4-5. SEM images of EFGO attached PVA foams after the immersion of PVA foams in the EFGO dispersion.
111 EFGO flakes are attached on the surface of PVA networks after the immersion of PVA foams into
the EFGO ethanol dispersion. The excellent coverage of EFGO on PVA foams is shown in Figure
4-5. EFGO flakes attach onto PVA networks by the Van der Waals interaction, and the high
magnification SEM images (Figure 4-5 b-c) show no exposed PVA foams. Therefore, the immersion of PVA foams in the EFGO dispersion is an effective method to form EFGO flakes wrapped PVA networks.
Figure 4-6. SEM images of PDC composites green bodies.
The EFGO attached PVA foams were infiltrated by the SiOC polymeric precursor in a vacuum environment and cured at 160 oC to obtain green bodies for pyrolysis. The excellent infiltration of
SiOC precursor is verified by the SEM image (Figure 4-6a) which shows the formation of nearly
fully-dense green bodies. The vacuum assisted SiOC precursor infiltration nearly completely avoid
the formation of voids in green bodies by facilitating the exclusion of trapped air between the PVA
foam and the SiOC precursor. In addition, the thickness of EFGO wrapped PVA foam networks
in green bodies is 10-25 µm from Figure 4-6b.
112
Figure 4-7. SEM images of PDC composites pyrolyzed at 1000 oC.
PDC composites pyrolyzed at 1000 oC are shown in Figure 4-7. The cross-section area of PDC composites shows the interface between EFGO component and SiOC matrix. The breakage of
PDC composites happens at the interface because it is usually the weakest part in composites. Tiny gaps between these two components can be seen from the SEM images, and the aggregates of
EFGO flakes at the interface are observed. The nearly fully-dense morphology of PDC composites and the presence of EFGO component within composites verify the successful fabrication of
113 EFGO embedded PDC composites. Also, the surface of pyrolyzed PDC composites are
investigated, no cracks are seen from SEM images (Figure 4-19). For pyrolyzed PDCs from pure
SiOC polymeric precursors, cracks can be clearly seen from the surface by naked eyes. Thus, the embedded EFGO helps the formation of nearly crack-free PDC composites. Additionally, PDC composites which pyrolyzed at 300 oC to 600 oC without Au/Pd sputter coating show strong
charging during SEM imaging, and contents on the surface were burnt out in seconds (Figure 4-
20), thus the poor electrical conductivity of ceramic composites pyrolyzed at 300 oC to 600 oC is
revealed. No obvious charging is observed for PDC composites pyrolyzed above 600 oC without
Au/PD sputter coating. Therefore, it is an evidence of huge electrical conductivity difference
among composites pyrolyzed above or at and below 600 oC.
Figure 4-8. TGA curves of the PDC composite and each component in the composite.
114 The mass change of PDC composites and each component in PDC composites (PVA, SILRES
62C precursor, and EFGO) at elevated temperatures is monitored by TGA. TGA curves in Figure
4-8 show the mass loss of materials from room temperature to 1000 oC. PVA foam has a dramatic
mass loss from 300-350 oC which is result from the decomposition of PVA, and only 4% of the original mass remains at 1000 oC. The mass of EFGO nearly keeps constant through the heating process. Its minimal mass loss at 100 oC to 150 oC is from the evaporation of residual moisture,
and 96% of its original mass remains at 1000 oC. The major mass loss of SILRES 62C happens
from 300 oC to 800 oC and around 75% of its original mass remains at 1000 oC. Its mass loss is
primarily from the decomposition of organic components during the heat treatment. The breakage
of Si-H bonds and Si-C bonds in polymeric precursors leads to major emitted gases such as
methane and hydrogen. [60-64] The mass change of the PDC composites green body is also
monitored by TGA, and it can be considered as a mass change superimposition of all components
included. The major mass loss is at the temperature range from 200 oC to 800 oC, and about 63%
of its original mass remains at 1000 oC. Additionally, the loading percentage of EFGO in PDC
composites is calculated by the mass change of composites after each preparation step (Table 4-
4). The loading percentage EFGO is calculated to be 1.4-1.9 wt% in pyrolyzed PDC composites,
and consistent EFGO loading in composites is realized. The linear shrinkage of composites after
the pyrolysis at 1000 oC is 22-24% comparing to green bodies (Figure 4-21). The density of
composites pyrolyzed at different temperatures are logged in Table 4-5. The density of pyrolyzed
composites increases with the increasing of pyrolysis temperatures, and it is attributed to both the
mass loss from the organic component decomposition and the shrinkage of composites during
pyrolysis. The faster volumetric shrinkage of composites than that of mass loss leads to denser
composites pyrolyzed at higher temperatures. The density of composites pyrolyzed at 1000 oC is
115 ~1.76 g/cm3 (Table 4-5), and it is close to the SiOC polymeric precursor pyrolyzed at 1000 oC
(1.768 g/cm3, Table 4-6) thus verify the formation of nearly fully-dense ceramic composites. Also,
the density of EFGO is 1.8 g/cm3, so its spatial density is 1.4-1.9% in pyrolyzed composites.
Young’s modules of composites pyrolyzed at 1000 oC have the average value of 213.4 MPa (Table
4-9), which is comparable to previous reported PDC based composites. [47]
Table 4-1. Elemental Compositions of PDC composites after pyrolysis at different temperatures.
300℃ 400℃ 500℃ 600℃ 700℃ 800℃ 900℃ 1000℃
Carbon (%) 67.69 66.84 63.04 56.83 55.72 50.88 49.13 47.03
Oxygen (%) 21.11 21.23 22.86 28.60 29.12 32.67 33.41 35.54
Silicon (%) 11.09 11.93 14.10 14.56 15.16 16.45 17.45 17.43
The elemental composition of PDC composites after pyrolysis processes conducted at different
temperatures is investigated by EDS, and the results are summarized in Table 4-1. All samples for
EDS acquisitions were not sputter coated by Au/Pd to get authentic elemental compositions. The
atomic percentage of carbon decreases with the increasing of pyrolysis temperatures, and it results
from the decomposition of organic components in ceramics to form carbon containing gases such
as methane and ethane. [65] In the meantime, the atomic ratio between silicon and oxygen keeps
at nearly 0.5 after pyrolysis at different temperatures. It indicates the existence of SiO2 clusters in
SiOC ceramics, which is in accordance with the observation of structural evolution of PDCs in
previous reports. [30,66,67] Si-O bond has a dissociation energy of 452 kJ/mol which is considerably higher than those of C-C bond (346 kJ/mol), Si-C bond (318 kJ/mol), and Si-H bond
(319 kJ/mol) exist in composites, [68] and it is why Si-O bonds remain during pyrolysis processes.
116
Figure 4-9. Raman spectra of PDC composites pyrolyzed at different temperatures.
Raman study is performed to further study the chemical composition in PDC composites after
pyrolysis at different temperatures. It is interesting to see the presence of the G peaks and D peaks,
which are signature Raman peaks of graphitic domains, from PDC composites pyrolyzed at or
above 700 oC (Figure 4-9). Also, there is no discernible peaks of graphitic domains from PDC
composites pyrolyzed below 700 oC. However, EFGO itself has Raman signals from graphitic domains due to its graphitic structure in the basal area (Figure 4-4). Therefore, these signature
Raman signals from graphitic domains observed from PDC composites pyrolyzed at or above 700
oC is not from the EFGO component. As EFGO is not the source for graphitic Raman signals, these
Raman signals should be resulted from chemical change of other components during pyrolysis.
PVA foam is almost completely decomposed below 700 oC, so the Raman signals of graphitic
carbon domains should be from the chemical evolution of SILRES 62C precursor. Furthermore,
blue shift of G peaks is observed from ceramic composites with higher pyrolysis temperatures.
With increased pyrolysis temperature from 700 oC to 1000 oC, G peaks shift from 1586.4 cm-1 to
117 1614.7 cm-1. The blue shift (28.3 cm-1) of G peaks indicates the effective transition from amorphous carbon to graphitic domains in composites during pyrolysis. [69,70]
Figure 4-10. XPS spectra of PDC composites at (a) carbon region and (b) silicon region before pyrolysis (RT), at the transition state of pyrolysis (700 oC), and after pyrolysis (1000 oC).
118 XPS study is conducted to investigate the switch of elemental chemical state in PDC composites before pyrolysis, pyrolyzed at the transition temperature, and pyrolyzed at 1000 oC. Because obvious transition stage for ceramic composites pyrolyzed at 700 oC is observed both from SEM imaging (lowest pyrolysis temperature to observe no charging in SEM imaging without Au/Pd sputter coating) and Raman spectroscopy study (lowest pyrolysis temperature to observe the presence of the G peak and the D peak from graphitic domains), this pyrolysis temperature is considered to be the transition stage. XPS curves at carbon and silicon binding energy regions are presented in Figure 4-10. Small shift of XPS peaks at the carbon region is observed from PDC composites pyrolyzed at 700 oC, which indicate the start of graphitic “free carbon” domain formation in composites. [71-73] Deconvoluted XPS spectrum at the carbon region for PDC composites pyrolyzed at 1000 oC shows a peak with the binding energy of 284.6 eV, indicating the formation of abundant graphitic domains. On the other hand, the XPS peak in silicon region shifts to the lower energy region when PDC composites are pyrolyzed at 700 oC, and the peak shifts more to the lower energy region when PDC composites are pyrolyzed at 1000 oC. The breakage of Si-C bond and Si-H bond decreases the valance of silicon element in composites and leads to the shift of silicon XPS peak to the lower energy region. Therefore, the shift of XPS peak at the silicon region indicates the decomposition of organic component.
After the investigation of morphologies and chemical composition of PDC composites, the electrical conductivity of pyrolyzed samples at room temperature (25 oC) is studied (Figure 4-11).
Composites before pyrolysis shows electrical resistance beyond the measurement range, thus they can be considered as insulators at room temperature even with embedded conductive EFGO networks. After pyrolysis at 300 oC or higher, electrical conductivity is capable to be calculated
119 from the reading of electrical resistance, and composites pyrolyzed at higher temperature have
higher electrical conductivity at room temperature. As known from the Raman study, the formation
of conductive graphitic domains in the SILRES 62C precursor happens above 600 oC, thus the
observed electrical conductivity of composites pyrolyzed at or below 600 oC should not be from
the formation of graphitic domains in composites. In another aspect, composites shrink during
pyrolysis processes, and the more compacted composites after pyrolysis could be the reason for
the observable electrical conductivity of composites pyrolyzed at or below 600 oC. It can be
explained that the shrinkage of composites during pyrolysis processes enhances the interactions of
adjacent EFGO sheets, and the compact EFGO networks lead to improved electrical conductivity
by facilitating the charge transport of inter-plane hopping among EFGO flakes. The embedded
EFGO networks become more compact when higher pyrolysis temperature is applied, and the electrical conductivity of composites increases. Besides, the electrical conductivity of composites increases even after the increment of shrinkage is not obvious when the pyrolysis temperature is
at or above 800 oC. The increasing electrical conductivity of PDC composites pyrolyzed at or
above 800 oC is primarily due to the increasing abundance of graphitic domains in composites when higher pyrolysis temperatures are applied. The electrical conductivity of composites after
pyrolysis at 1000 oC and 1100 oC are almost identical, thus the threshold of electrical conductivity
is believed to be reached after the pyrolysis at 1000 oC.
To better understand the effect of each component to electrical conductivity properties, composites
of control groups were prepared. To investigate the function of EFGO, pyrolyzed PVA/SILRES
62C composites were fabricated to compare with PDC composites (PVA/SILRES 62C/EFGO
composites). However, only deformed composites with cracks from inside can be prepared at
120 pyrolysis temperatures at or above 400 oC. In contrary, intact PDC composites can be successfully prepared even when the pyrolysis temperature is much higher than 400 oC. Consequently, EFGO
must play an important role in avoiding cracks and deformation during the pyrolysis. The main
reason of cracks formation in PDCs based composites is the ineffective stress releasing from
emitted gases during pyrolysis processes. [74-76] PVA foams embedded in composites is the
major source of gas generation during pyrolysis, and it leads to severe problems of stress releasing
from composites. When bare PVA foams with no attached EFGO are in the composite, the force
from gas expansion directly acts onto cured SILRES 62C precursors, and cracks can be easily
formed because of the high stiffness of cured precursor as well as no effective pathways for gas
releasing in such binary system. However, when EFGO attached PVA foams are embedded in
SILRES 62C precursors, the force from gas expansion acts onto EFGO first, and the loosely
packed EFGO flakes act as cushions to partially absorb the stress applied onto cured SILRES 62C
precursor. Also, the network of EFGO attached PVA foams provides effective pathways for gas
releasing from composites. In consequence, EFGO flakes attached PVA foams help to release
stress from gas formation during pyrolysis, and it is vital to the formation of intact pyrolyzed PDC
composites.
Because no intact pyrolyzed SILRES 62C/PVA composites can be fabricated, the function of
EFGO on improving electrical conductivity of composites needs to be compared by pyrolyzed
EFGO/SILRES 62C composites and pyrolyzed SILRES 62C composites. It can be clearly seen
from Figure 4-24 that pyrolyzed EFGO/SILRES composites have electrical conductivity higher
than that of pyrolyzed SILRES both at room temperature and at elevated temperatures. The
121 improvement of electrical conductivity by having EFGO in composites is due to the introduction
of more conductive component. [36,42,77,78]
Figure 4-11. Room temperature electrical conductivity of PDC composites pyrolyzed at different temperatures and the corresponding linear shrinkage after pyrolysis.
The function of PVA foams to electrical conductivity can be revealed by comparing the electrical
conductivity of pyrolyzed PVA/SILRES 62C/EFGO composites (PDC composites) and pyrolyzed
SILRES 62C/EFGO composites. It can be clearly seen from Figure 4-24 that pyrolyzed
EFGO/SILRES/PVA composites have electrical conductivity several orders of magnitude higher
than that of SILRES/PVA pyrolyzed both at room temperature and at elevated temperatures. When
EFGO flakes attached PVA foams are embedded in composites, conductive EFGO networks after
pyrolysis can facilitate the electron transport within pyrolyzed composites by the percolated
122 networks. However, conductive EFGO flakes can only randomly distribute in composites without the presence of PVA frameworks, and no effective networks for electron transport can be realized within composites in this case. Accordingly, the introduction of percolated networks for electron transport is the main reason to the improvement of electrical conductivity when PVA foams are included in green bodies. [32,79-82].
The electrical conductivity data from PDC composites (EFGO/SILRES 62C/PVA composites) and pyrolyzed SILRES 62C composites is further analyzed to dig out more information about the mechanism of electrical conductivity improvement in ceramic composites. By extracting the electrical conductivity data of these two kinds of composites pyrolyzed at 1000 oC at room temperature, it is intriguing to notice that the value of PDC composites electrical conductivity is higher than that from classic models regarding the electrical conductivity of composites.[83-86]
Here in, SILRES 62C pyrolyzed at 1000 oC is considered as the less conductive continuous matrix, and EFGO is considered as the more conductive component. The detailed calculations are presented in the supplementary materials.
Figure 4-12. Raman spectra of (a) pure SILRES 62C and (b) EFGO/SILRES 62C composites with 2 wt% EFGO pyrolyzed at different temperatures.
123 Two possible reasons can be attributed to the exceeding electrical conductivity compared to classic
models. (1) excellent connectivity of the more conductive EFGO phase, and (2) the formation of
more conductive components during pyrolysis. To investigate the formation of EFGO networks
buried in the composites, green bodies for the preparation of PDC composites were heated in air
at 500 oC to completely decompose PVA foam, and 3D inter-connected channels can be observed within composites (Figure 4-23). Also, EFGO flakes are observed on edges of those void channels.
This morphology indicates that EFGO networks exist in pyrolyzed PDC composites. On the other hand, Raman spectroscopy is used to find out the effect of embedded EFGO on chemical change during pyrolysis processes. Raman spectra of pyrolyzed SILRES 62C in Figure 4-25a shows the presence of the G peak and the D peak from graphitic domains when the pyrolysis temperature is at or above 800 oC. By comparing the results to the Raman spectra of pyrolyzed PDC composites
(Figure 4-9), the temperature to the appearance of graphitic domain signals is 100 oC higher. Also,
the blue shift of G band (3.9 cm-1) is much smaller than that of PDC composites (28.3 cm-1) from
Table 4-7. Therefore, EFGO attached PVA foams facilitate the formation of graphitic domains in composites. To further verify the promoted formation of graphitic domains is from the addition of
EFGO, Raman spectra of pyrolyzed EFGO/SILRES 62C composites are acquired (Figure 4-12b).
By having well dispersed EFGO in composites, the temperature for the presence of D band and G band is lower than that of pure SILRES 62C ceramics, and it appears at 700 oC which is the same
as that of PDC composites. Also, the blue shift of G band and D band (23.1 cm-1) is larger than
that of pyrolyzed pure SILRES 62C (3.9 cm-1) from Table 4-7. Consequently, the embedded EFGO is the primary reason of accelerated formation of graphitic in composites. This result is in accordance with the phenomenon observed in the previous report that reduced graphene oxide and single layer graphene can induce the crystallization of graphitic domains from carbon nearby their
124 surfaces, [47] and it is believed due to the graphitic structures, which are resembled to reduced
graphene oxide and graphene, in the basal area of EFGO flakes.
Figure 4-13. Schematic illustration of graphitic domains evolution in (a) SILRES 62C, (b) EFGO/SILRES 62C, and (c) EFGO/SILRES 62C/PVA composites (PDC composites) during pyrolysis processes.
From the discussion above, schematic illustrations of graphitic domains formation in composites
during pyrolysis processes are summarized in Figure 4-13. The formation of graphitic domains in
composites have two kinds of mechanisms, namely self-crystallization and EFGO induced crystallization. In pyrolyzed SILRES 62C composites, only the self-crystallization is available to form graphitic domains in composites (Figure 4-13a). The abundance of graphitic domains increases with increasing pyrolysis temperatures, and it is proved by the analysis from Raman spectroscopy that characteristic peaks from graphitic domains have higher intensity when applying higher pyrolysis temperatures. In pyrolyzed EFGO/SILRES 62C composites, self-crystallization
125 and EFGO induced crystallization are both available to form graphitic domains (Figure 4-13b).
The abundance of graphitic domains in matrix increases with increasing pyrolysis temperatures.
Besides, EFGO induces the formation of graphitic domains from the surface of EFGO flakes. In pyrolyzed EFGO/SILRES 62C/PVA composites (PDC composites), self-crystallization and
EFGO induced crystallization are also both available to form graphitic domains (Figure 4-13c).
Other than the increment of graphitic domains abundance in matrix with increased pyrolysis temperatures, EFGO induces the formation of graphitic domains from the surface of embedded
EFGO networks.
Figure 4-14. Electrical conductivity of PDC composites (EFGO/SILRES 62C/PVA composites) pyrolyzed at different temperatures. The testing temperature range is from 25 oC to 600 oC.
126 The electrical conductivity of PDC (EFGO/SILRES 62C/PVA composites) composites at elevated
temperatures is further studied, and the results are presented in Figure 4-14. Composites pyrolyzed at higher temperatures have higher electrical conductivity through the whole measurement range.
Also, the increment of conductivity from room temperature to 600 oC decreases with increased
pyrolysis temperatures (Table 4-8). To better understand the mechanism of electrical conductivity
change from room temperature to elevated temperatures, electrical conductivity of pyrolyzed
EFGO/SILRES 62C composites and pyrolyzed SILRES 62C composites are also investigated
(Figure 4-7). Like pyrolyzed PDC composites, the increment of electrical conductivity from room
temperature to 600 oC decreases with increased pyrolysis temperature for these two kinds of
composites (Table 4-8). In addition, the times of electrical conductivity improvement from room
temperature to 600 oC have the trend of EFGO/SILRES 62C/PVA> EFGO/SILRES 62C> SILRES
among composites pyrolyzed at the same temperature.
The average activation energy of composites is the prominent parameter of electron transport.
[30,65,87-90] The classical equation of ~exp ( ) is used to calculate the average activation ∆𝐸𝐸 𝜎𝜎𝑇𝑇 𝑘𝑘𝐵𝐵𝑇𝑇 energy, where is electrical conductivity, is Boltzmann constant, and activation energy.
𝑇𝑇 𝐵𝐵 This equation 𝜎𝜎is considering the electrical𝑘𝑘 conductivity of semi-conductors∆𝐸𝐸 in the intrinsic
temperature range. Within this temperature range, the activation energy equals to one-half of the
band gap between the conduction band and the valence band. [87] The average activation energies of composites pyrolyzed at different temperatures are calculated by curve fittings and are summarized in Table 4-2.
For pyrolyzed EFGO/SILRES 62C composites and pyrolyzed SILRES 62C composites, the
electrical conductivity is primarily from the electron transport in matrix, the overall activation
127 energy of pyrolyzed EFGO/SILRES 62C and pyrolyzed SILRES 62C decreases with increasing pyrolysis temperature. Also, the overall activation energy of pyrolyzed EFGO/SILRES 62C is smaller than that of pyrolyzed SILRES 62C when same pyrolysis conditions are applied. Filled
EFGO in composites by sonication have band gap much smaller than that of SILRES 62C, thus the overall activation energy decreases. Besides, based on the observation in Raman spectra regarding pyrolyzed EFGO/SILRES 62C and SILRES 62C, the formation of graphitic domains is induced by EFGO particles in the nearby area. The formation of graphitic domains which are more conductive than the SiOC matrix further decreases the overall activation energy.
Table 4-2. Summary of activation energy of different composites pyrolyzed at different temperatures. Activation Energy (eV) Pyrolysis Temperature (oC) EFGO/SILRES 62C/PVA EFGO/SILRES 62C SILRES 62C
600 0.0287 N/A N/A
700 0.0265 0.074 N/A
800 0.0224 0.066 0.217
900 0.0192 0.048 0.112
1000 0.0107 0.031 0.106
Compare pyrolyzed EFGO/SILRES 62C/PVA composites (PDC composites) to pyrolyzed
EFGO/SILRES 62C composites, the calculated activation energy of pyrolyzed PDC composites is smaller than that of pyrolyzed EFGO/SILRES 62C when same pyrolysis conditions are applied
(Table 4-2). PDC composites and EFGO/SILRES 62C composites have almost identical mass percentage of conductive EFGO component in composites before pyrolysis, so the arrangement of
EFGO flakes in composites is crucial to the electrical properties of composites. Percolated EFGO
128 networks in pyrolyzed EFGO/SILRES 62C/PVA composites provide effective pathways for electrons, thus electrical conductivity of PDC composites is primarily from these networks.
[30,91,92] With the increasing of pyrolysis temperature, the number and size of graphitic domains in SILRES 62C matrix increases, the electrical conductivity from SILRES matrix component thus increases. Also, the formation of graphitic domains from the surfaces of EFGO networks helps to build better pathways for electron transport. Meanwhile, the distance from graphitic domains in
SILRES 62C matrix to EFGO networks decreases when applying higher pyrolysis temperatures, and it further facilitates the transport of electrons from matrix to effective pathways composed of
EFGO networks from hopping mechanism. It can be analogous to the case that closer distance from rural area (SILRES 62C matrix) to highway networks (EFGO networks) leads to more convenient travel from the rural area.
At last, the thermal conductivity of PDC composites is investigated. The thermal conductivity of
PDC composites pyrolyzed at 1000 oC is 0.7654±0.1091 W∙m-1∙K-1 and 0.8676±0.1289 W∙m-1∙K-
1 at room temperature (25 oC) and at 300 oC, respectively. Therefore, the thermal conductivity of pyrolyzed PDC composites at room temperature and at elevated temperature are quite close.
Besides, the thermal conductivity of PDC composites is much lower than the reported thermal conductivity of pure SiOC matrix (1.5-3 W∙m-1∙K-1). [93,94] It is probably due to the embedded
EFGO networks impede the phonon scattering through composites by the strong phonon-boundary scattering at interfaces between EFGO and matrix. [95] In addition, the thermal conductivity of
PDC composites before pyrolysis, namely green bodies, is 0.1459±0.0428 W∙m-1∙K-1 at 25 oC.
Therefore, the thermal conductivity increases from green bodies to pyrolyzed PDC composites. It is believed to be attributed to the formation of graphitic domains during pyrolysis processes.
129 Graphitic “free-carbon” domains have higher thermal conductivity than the SiOC matrix, based
on the common estimation method for the thermal conductivity of amorphous mixtures which is
the superimposition of different components, the overall thermal conductivity of composites
increases with the formation of components which are more thermal conductive than the matrix.
[96,97] In conclusion, the thermal conductivity of pyrolyzed composites keeps low and its
increment after pyrolysis is dramatically less than that of electrical conductivity.
Conclusions
EFGO embedded PDC composites are successfully fabricated. SiOC polymeric precursor is
infiltrated into EFGO attached PVA foams, and it is then cured and pyrolyzed to form composites.
This facile method is suitable to prepared composites with different shapes because only the
shaping of PVA foams into desired dimensions is needed. The introduction of EFGO networks
greatly increases the electrical conductivity of PDC based composites, and it is resulted from (1)
the effective pathways for the transport of electrons provided by embedded EFGO networks, and
(2) the induced formation of conductive graphitic domains in PDC matrix nearby embedded EFGO
networks. By only applying less than 2 wt% of EFGO, the electrical conductivity of composites is
0.95 S/cm at 25 oC and 1.8 S/cm at 600 oC. The times of electrical conductivity increment of PDC composites from room temperature to 600 oC is much lower than that of pyrolyzed SiOC polymeric
precursor due to the percolation of embedded EFGO networks. Also, the increment of electrical
conductivity from room temperature to 600 oC decreases when PDC composites are pyrolyzed at higher temperature. More abundant graphitic domains in SiOC matrix after pyrolysis performed at higher temperature lead to smaller energy needed for the transport of electrons from SiOC matrix to EFGO networks, and the increment of electrical conductivity thus decreases based on the classic
130 equation of semi-conductor electrical conductivity. Furthermore, the thermal conductivity of pyrolyzed PDC composites almost keeps the same at different testing temperatures and is quite low (<1 W∙m-1∙K-1). Such thermally stable materials with high electrical conductivity and low thermal conductivity have great potentials in applications such as thermal insulator, energy sources, and high temperature sensors. [98-100]
Supporting Materials
Figure 4-15. The particle size distribution of EFGO flakes from the DLS test.
Figure 4-16. FTIR spectrum of SILRES 62C precursor before (black line) and after (red line) curing process.
131
Figure 4-17. 1H NMR spectrum of SILRES 62C preceramic polymer. The peak at 1.56 ppm is from water impurities.
FTIR spectra of SILRES 62C precursor before and after curing in Figure 4-16 shows the chemical bond change during curing process. The FTIR spectrum of SILRES 62C precursor before curing
(black line) shows the stretching vibrations of Si-O bonds (1000-1150 cm-1), Si-H bonds (~2100
cm-1), C-O bonds (~1260 cm-1), C-H bonds in alkyanes (2900-3000 cm-1), C-H bonds in alkyenes
(3000-3100 cm-1), and aromatic C-H bonds (~1700 cm-1), as well as the bending vibrations of alkyl
C-H bonds (~1500 cm-1). For cured SILRES 62C precursor (red line), the absence of stretching
vibrations of Si-H bonds at around 2100 cm-1 is observed, and it is due to the hydrosilylation
reactions R Si H + H C = CH Si R R Si H C CH Si R happened heat ′ ′ 2 2 2 during cross-linking− − process. [101-103]− In −another�⎯� aspect,− the− 1HNMR− spe−ctrum− shown in Figure
4-17 reveals the chemical composition of the liquid SiCO precursor. The broad peak from -0.3
ppm to 0.5 ppm is the resonance of H in Si-CH3, Si-CH2, the peak at around 1.1ppm corresponds
to the resonance of H in Si-CH, the broad peaks at around 4.8 ppm and 3.8 ppm are attributed to the resonance of H in vinyl groups, the broad peak at around 5.9 ppm is from the resonance of H in aromatic Si-H, and the broad peak at 7-8 ppm is assigned to the resonance of H in aromatic C-
H. [104-108]
132
Figure 4-18. The SEM image of bare PVA foams.
Figure 4-19. SEM images of the surface of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC, (d) 600 oC, (e) 700 oC, (f) 800 oC, (g) 900 oC, and (h) 1000 oC. Scale bars are 50 m.
µ
133
Figure 4-20. SEM images of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC, and (d) 600 oC without Au/Pd sputter coating.
Figure 4-21. Linear shrinkage of PDC composites after pyrolysis at different temperatures.
134
Figure 4-22. EDS spectra of PDC composites pyrolyzed at (a) 300 oC, (b) 400 oC, (c) 500 oC, (d) 600 oC, (e) 700 oC, (f) 800 oC, (g) 900 oC, and (h) 1000 oC.
Figure 4-23. The SEM image of PDC composites treated in air at 500 oC.
135
Figure 4-24. Electrical conductivity comparison of different composites with same pyrolysis conditions at the testing temperature from 25 oC to 600 oC. Composites are pyrolyzed at (a) 700 oC, (b) 800 oC, (c) 900 oC, and (d) 1000 oC, respectively.
Figure 4-25. Electrical conductivity of (a) EFGO/SILRES 62C/PVA, (b) EFGO/SILRES 62C, and (c) SILRES 62C pyrolyzed at different temperatures. The testing temperature range is from 25 oC to 600 oC.
136
Figure 4-26. Specific heat capacity of (a) green bodies and (b) 1000 oC pyrolyzed PDC composites at different temperatures.
Table 4-3. Summary of pyrolysis processes details.
Final Pyrolysis Halting Halting Halting Halting
Temperature of Temperature 1 Temperature 2 Temperature 3 Temperature 4
Samples (oC) (oC) (oC) (oC) (oC)
300 300 N/A N/A N/A
400 300 400 N/A N/A
500 300 400 500 N/A
600 300 400 600 N/A
700 300 400 600 700
800 300 400 600 800
900 300 400 600 900
1000 300 400 600 1000
137 Table 4-4. Normalized Mass change of ceramic composites in preparation processes. After EFGO in After EFGO SILRES After Batch PVA PDC after infiltraion 62C pyrolysis at Number Foam (g) Pyrolysis at (g) infiltraion 1000oC (g) 1000oC (g) (g)
1 26.19 27.63 160.78 100 1.44
2 27.59 29.17 161.96 100 1.58
3 25.57 27.07 161.41 100 1.50
4 26.72 28.45 161.57 100 1.73
5 27.09 28.63 160.97 100 1.55
6 26.41 28.29 161.20 100 1.89
7 26.36 28.25 163.74 100 1.90
8 26.60 28.17 161.97 100 1.56
9 26.37 27.73 161.33 100 1.37
10 26.76 28.25 161.34 100 1.49
Average 26.57 28.17 161.63 100 1.60
Table 4-5. Density of Pyrolyzed SiCO PDCs. Pyrolysis Density of SiCO Average Density of Temperature PDCs (g/cm3) SiCO PDCs (g/cm3) (oC)
1.762
1000 1.775 1.768
1.769
138 Table 4-6. Density of Composites pyrolyzed at different temperatures. Density of Composites Pyrolysis Temperature (oC) (g/cm3)
300 1.22
400 1.24
500 1.28
600 1.32
700 1.52
800 1.65
900 1.73
1000 1.76
Table 4-7. G peak positions of composites pyrolyzed composites. G Peak Position of Pyrolyzed Composites (cm-1) Pyrolysis Temperature EFGO/SILRES SILRES EFGO/SILRES (oC) 62C/PVA 62C 62C
700 1586.4 n/a 1572.7
800 1593.7 1574.7 1576.3
900 1601.5 1576.6 1583.8
1000 1614.7 1578.6 1595.8
Blue Shift 28.3 3.9 23.1
139 Table 4-8. Values of electrical conductivity increment from different pyrolyzed composites. Pyrolysis Temperature (oC) Sample Name 600 700 800 900 1000
Pure SILRES N/A N/A 3824.2* 394.9 176.1
2%EFGO in N/A 51.1 38.9 18.0 7.4 SILRES
SILRES/EFGO/PVA 5.4 4.9 3.4 2.2 1.8
Table 4-9. Young’s modulus of EFGO/SILRES 62C/PVA composites pyrolyzed at 1000 oC. Sample Number Young's Modulus (Mpa)
1 205.2
2 234.8
3 198.6
4 224.9
5 203.5
Average 213.4
Standard Deviation 15.6
Calculations of PDC composites (EFGO/SILRES 62C/PVA composites) electrical conductivity at room temperature by applying different models for the electrical conductivity of composites.
Consider SILRES 62C pyrolyzed at 1000 oC and embedded EFGO networks as two phases in pyrolyzed composites. The volume fraction of EFGO is 1.4-1.9%, so the volume fraction of
SILRES 62C matrix is 98.1-98.6%. The electrical conductivity of EFGO and pyrolyzed SILRES
140 62C (SiOC matrix) at room temperature are ~10 S/cm and 1.8×10-5 S/cm, respectively. Effective electrical conductivity is denoted as , electrical conductivity of components in composites is
𝑒𝑒𝑒𝑒𝑒𝑒 denoted as , and volume fraction of𝜎𝜎 components in composites is denoted as .
𝜎𝜎𝑖𝑖 𝑋𝑋𝑖𝑖 Alternating parallel layers. [84]
EFGO networks arrange parallel to applied external current flow.
= = + (4-1) 𝑛𝑛 𝜎𝜎𝑒𝑒𝑒𝑒𝑒𝑒 ∑𝑖𝑖=0 𝑋𝑋𝑖𝑖𝜎𝜎𝑖𝑖 𝑋𝑋𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝜎𝜎𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝐸 𝑋𝑋𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝜎𝜎𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚 So, the effective electrical conductivity of composites is between 0.14S/cm to 0.19 S/cm by applying this model.
EFGO networks arrange axially to external current flow.
= = + (4-2) 𝑛𝑛 1 𝑋𝑋𝑖𝑖 𝑋𝑋𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝐸 𝑋𝑋𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚 𝑒𝑒𝑒𝑒𝑒𝑒 𝑖𝑖 𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝐸 𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚 𝜎𝜎 �𝑖𝑖=0 𝜎𝜎 𝜎𝜎 𝜎𝜎 So, the effective electrical conductivity of composites is between 1.81×10-5 S/cm to 1.83×10-5
S/cm by applying this model.
Effective conductivity of the random model. [83]
= = × (4-3) 𝑛𝑛 𝑋𝑋𝑖𝑖 𝑋𝑋𝐸𝐸𝐸𝐸𝐸𝐸𝐸𝐸 𝑋𝑋𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚 𝜎𝜎𝑒𝑒𝑒𝑒𝑒𝑒 ∏𝑖𝑖=1 𝜎𝜎𝑖𝑖 𝜎𝜎𝐸𝐸𝐸𝐸𝐸𝐸𝑂𝑂 𝜎𝜎𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚𝑚 So, the effective electrical conductivity of composites is between 2.17×10-5 S/cm to 2.31×10-5
S/cm by applying this model.
141 Effective conductivity of mixed media. [86] Because the equation is symmetric, consider EFGO
as phase 1 and SiOC matrix as phase 2.
= (3 1) + (3 1) + (3 1) + (3 1) + 8 (4-4) 1 2 𝜎𝜎𝑒𝑒𝑒𝑒𝑒𝑒 4 � 𝑋𝑋1 − 𝜎𝜎1 𝑋𝑋2 − 𝜎𝜎2 �� 𝑋𝑋1 − 𝜎𝜎1 𝑋𝑋2 − 𝜎𝜎2� 𝜎𝜎1𝜎𝜎2 � So, the effective electrical conductivity of composites is between 1.84×10-5 S/cm to 1.86×10-5
S/cm by applying this model.
Archies’s law. [85] m and p is connectivity exponents. Larger value of connectivity exponent
corresponds to less effective connectivity. In usual cases, the phase with more volume fraction phase has 0 = + (4-5) 𝑚𝑚 𝑝𝑝 𝜎𝜎𝑒𝑒𝑒𝑒𝑒𝑒 𝜎𝜎1𝑋𝑋1 𝜎𝜎2𝑋𝑋2 So, the effective electrical conductivity of composites is between 2.5×10-4 S/cm to 0.19 S/cm by applying this model. Figure 4-27. Fabrication of ceramic composites, from starting materials to final products. 142 Figure 4-28. Use a PDC composite pyrolyzed at 1000 oC to light up four white LED diodes with an output of 9 V. A propane gun is used to heat up the composite. The dimension of the composite is 5 mm×5 mm×40 mm. References 1. Colombo, P.; Mera, G.; Riedel, R.; Sorarù, G.D. Polymer-derived ceramics: 40 years of research and innovation in advanced ceramics. Journal of the American Ceramic Society 2010, 93, 1805-1837. 2. Ziegler, G.; Kleebe, H.J.; Motz, G.; Müller, H.; Traßl, S.; Weibelzahl, W. Synthesis, microstructure and properties of sicn ceramics prepared from tailored polymers. Materials Chemistry and Physics 1999, 61, 55-63. 143 3. Bill, J.; Aldinger, F. Precursor-derived covalent ceramics. Advanced Materials 1995, 7, 775-787. 4. Riedel, R.; Kienzle, A.; Dressler, W.; Ruwisch, L.; Bill, J.; Aldinger, F. A silicoboron carbonitride ceramic stable to 2,000°c. Nature 1996, 382, 796. 5. Wang, Z.-C.; Aldinger, F.; Riedel, R. Novel silicon-boron-carbon-nitrogen materials thermally stable up to 2200°c. Journal of the American Ceramic Society 2001, 84, 2179- 2183. 6. Eckel, Z.C.; Zhou, C.; Martin, J.H.; Jacobsen, A.J.; Carter, W.B.; Schaedler, T.A. Additive manufacturing of polymer-derived ceramics. Science 2016, 351, 58-62. 7. Hoy, C.V.; Barda, A.; Griffith, M.; Halloran, J.W. Microfabrication of ceramics by co- extrusion. Journal of the American Ceramic Society 1998, 81, 152-158. 8. Wang, S.; Li, J.-F.; Watanabe, R.; Esashi, M. Fabrication of lead zirconate titanate microrods for 1–3 piezocomposites using hot isostatic pressing with silicon molds. Journal of the American Ceramic Society 1999, 82, 213-215. 9. Vorotilov, K.; Petrovsky, V.; Vasiljev, V. Spin coating process of sol-gel silicate films deposition: Effect of spin speed and processing temperature. Journal of Sol-Gel Science and Technology 1995, 5, 173-183. 10. Nguyen, M.D.; Bang, J.W.; Bin, A.S.; Kim, S.-R.; Kim, Y.; Hwang, K.H.; Pham, V.-H.; Kwon, W.-T. Novel polymer-derived ceramic environmental barrier coating system for carbon steel in oxidizing environments. Journal of the European Ceramic Society 2017, 37, 2001-2010. 144 11. David, L.; Shareef, K.M.; Abass, M.A.; Singh, G. Three-dimensional polymer-derived ceramic/graphene paper as a li-ion battery and supercapacitor electrode. RSC Advances 2016, 6, 53894-53902. 12. Yajima, S.; Hayashi, J.; Omori, M.; Okamura, K. Development of a silicon carbide fibre with high tensile strength. Nature 1976, 261, 683-699. 13. Yajima, S.; Okamura, K.; Hayashi, J.; Omori, M. Synthesis of continuous sic fibers with high tensile strength. Journal of the American Ceramic Society 1976, 59, 324-327. 14. Majoulet, O.; Alauzun, J.G.; Gottardo, L.; Gervais, C.; Schuster, M.E.; Bernard, S.; Miele, P. Ordered mesoporous silicoboron carbonitride ceramics from boron-modified polysilazanes: Polymer synthesis, processing and properties. Microporous and Mesoporous Materials 2011, 140, 40-50. 15. Shi, Y.; Wan, Y.; Zhao, D. Ordered mesoporous non-oxide materials. Chemical Society Reviews 2011, 40, 3854-3878. 16. Borchardt, L.; Hoffmann, C.; Oschatz, M.; Mammitzsch, L.; Petasch, U.; Herrmann, M.; Kaskel, S. Preparation and application of cellular and nanoporous carbides. Chemical Society Reviews 2012, 41, 5053-5067. 17. Günthner, M.; Schütz, A.; Glatzel, U.; Wang, K.; Bordia, R.K.; Greißl, O.; Krenkel, W.; Motz, G. High performance environmental barrier coatings, part i: Passive filler loaded sicn system for steel. Journal of the European Ceramic Society 2011, 31, 3003-3010. 18. Prasad, R.M.; Iwamoto, Y.; Riedel, R.; Gurlo, A. Multilayer amorphous-si-b-c-n/γ- al2o3/α-al2o3 membranes for hydrogen purification. Advanced Engineering Materials 2010, 12, 522-528. 145 19. Riedel, R.; Passing, G.; Schönfelder, H.; Brook, R.J. Synthesis of dense silicon-based ceramics at low temperatures. Nature 1992, 355, 714-727. 20. Liew, L.-A.; Saravanan, R.A.; Bright, V.M.; Dunn, M.L.; Daily, J.W.; Raj, R. Processing and characterization of silicon carbon-nitride ceramics: Application of electrical properties towards mems thermal actuators. Sensors and Actuators A: Physical 2003, 103, 171-181. 21. Liew, L.-A.; Liu, Y.; Luo, R.; Cross, T.; An, L.; Bright, V.M.; Dunn, M.L.; Daily, J.W.; Raj, R. Fabrication of sicn mems by photopolymerization of pre-ceramic polymer. Sensors and Actuators A: Physical 2002, 95, 120-134. 22. Asthana, A.; Kim, K.-O.; Perumal, J.; Kim, D.-M.; Kim, D.-P. Facile single step fabrication of microchannels with varying size. Lab on a Chip 2009, 9, 1138-1142. 23. David, L.; Bhandavat, R.; Barrera, U.; Singh, G. Silicon oxycarbide glass-graphene composite paper electrode for long-cycle lithium-ion batteries. Nat Commun 2016, 7, 3792- 3801. 24. David, L.; Bhandavat, R.; Barrera, U.; Singh, G. Polymer-derived ceramic functionalized mos2 composite paper as a stable lithium-ion battery electrode. Scientific Reports 2015, 5, 9792-9803. 25. Oschatz, M.; Kockrick, E.; Rose, M.; Borchardt, L.; Klein, N.; Senkovska, I.; Freudenberg, T.; Korenblit, Y.; Yushin, G.; Kaskel, S. A cubic ordered, mesoporous carbide-derived carbon for gas and energy storage applications. Carbon 2010, 48, 3987-3992. 26. Zhao, R.; Shao, G.; Cao, Y.; An, L.; Xu, C. Temperature sensor made of polymer-derived ceramics for high-temperature applications. Sensors and Actuators, 2014, 219, 58-64. 146 27. Nagaiah, N.R.; Kapat, J.S.; An, L.; Chow, L. Novel polymer derived ceramic-high temperature heat flux sensor for gas turbine environment. Journal of Physics: Conference Series 2006, 34, 458-466. 28. Li, Y.; Yu, Y.; San, H.; Wang, Y.; An, L. Wireless passive polymer-derived sicn ceramic sensor with integrated resonator/antenna. Applied Physics Letters 2013, 103, 163505- 163513. 29. Zhao, R.; Shao, G.; Cao, Y.; An, L.; Xu, C. Temperature sensor made of polymer-derived ceramics for high-temperature applications. Sensors and Actuators A: Physical 2014, 219, 58-64. 30. Cordelair, J.; Greil, P. Electrical conductivity measurements as a microprobe for structure transitions in polysiloxane derived si–o–c ceramics. Journal of the European Ceramic Society 2000, 20, 1947-1957. 31. Shao, G.; Peng, W.; Ma, C.; Zhao, W.; Guo, J.; Feng, Y.; Wang, H.; Zhang, R.; An, L. Enhanced electric conductivity of polymer-derived sicn ceramics by microwave post- treatment. Journal of the American Ceramic Society 2017, 100, 842-847. 32. Mamunya, Y. Carbon nanotubes as conductive filler in segregated polymer composites - electrical properties. In Carbon nanotubes - polymer nanocomposites, Yellampalli, S., Ed. InTech: Rijeka, 2011; 20, 1947-1957. 33. Sarkar, S.; Zou, J.; Liu, J.; Xu, C.; An, L.; Zhai, L. Polymer-derived ceramic composite fibers with aligned pristine multiwalled carbon nanotubes. ACS Applied Materials & Interfaces 2010, 2, 1150-1156. 34. Shopova-Gospodinova, D.; Burghard, Z.; Dufaux, T.; Burghard, M.; Bill, J. Mechanical and electrical properties of polymer-derived si–c–n ceramics reinforced by octadecylamine 147 – modified single-wall carbon nanotubes. Composites Science and Technology 2011, 71, 931-937. 35. Ionescu, E.; Francis, A.; Riedel, R. Dispersion assessment and studies on ac percolative conductivity in polymer-derived si–c–n/cnt ceramic nanocomposites. Journal of Materials Science 2009, 44, 2055-2062. 36. Shibuya, M.; Sakurai, M.; Takahashi, T. Preparation and characteristics of a vapor-grown carbon fiber/ceramic composite using a methylsilicone precursor. Composites Science and Technology 2007, 67, 3338-3344. 37. Xu, H.-P.; Dang, Z.-M.; Shi, D.-H.; Bai, J.-B. Remarkable selective localization of modified nanoscaled carbon black and positive temperature coefficient effect in binary- polymer matrix composites. Journal of Materials Chemistry 2008, 18, 2685-2690. 38. Ke, K.; Pötschke, P.; Wiegand, N.; Krause, B.; Voit, B. Tuning the network structure in poly(vinylidene fluoride)/carbon nanotube nanocomposites using carbon black: Toward improvements of conductivity and piezoresistive sensitivity. ACS Applied Materials & Interfaces 2016, 8, 14190-14199. 39. Lin, Y.; Liu, S.; Liu, L. A new approach to construct three dimensional segregated graphene structures in rubber composites for enhanced conductive, mechanical and barrier properties. Journal of Materials Chemistry C 2016, 4, 2353-2358. 40. Wang, X.; Mera, G.; Morita, K.; Ionescu, E. Synthesis of polymer-derived graphene/silicon nitride-based nanocomposites with tunable dielectric properties. Journal of the Ceramic Society of Japan 2016, 124, 981-988. 148 41. Ji, F.; Li, Y.-L.; Feng, J.-M.; Su, D.; Wen, Y.-Y.; Feng, Y.; Hou, F. Electrochemical performance of graphene nanosheets and ceramic composites as anodes for lithium batteries. Journal of Materials Chemistry 2009, 19, 9063-9067. 42. Cordelair, J.; Greil, P. Electrical characterization of polymethylsiloxane/mosi2-derived composite ceramics. Journal of the American Ceramic Society 2001, 84, 2256-2259. 43. Borrell, A.; Álvarez, I.; Torrecillas, R.; Rocha, V.G.; Fernández, A. Microstructural design for mechanical and electrical properties of spark plasma sintered al2o3–sic nanocomposites. Materials Science and Engineering: A 2012, 534, 693-698. 44. Wang, S.; Zhang, X.; Wu, X.; Lu, C. Tailoring percolating conductive networks of natural rubber composites for flexible strain sensors via a cellulose nanocrystal templated assembly. Soft Matter 2016, 12, 845-852. 45. Shen, C.; Calderon, J.E.; Barrios, E.; Soliman, M.; Khater, A.; Jeyaranjan, A.; Tetard, L.; Gordon, A.; Seal, S.; Zhai, L. Anisotropic electrical conductivity in polymer derived ceramics induced by graphene aerogels. Journal of Materials Chemistry C 2017, 5, 11708- 11716. 46. Noh, Y.J.; Joh, H.-I.; Yu, J.; Hwang, S.H.; Lee, S.; Lee, C.H.; Kim, S.Y.; Youn, J.R. Ultra- high dispersion of graphene in polymer composite via solvent free fabrication and functionalization. Scientific Reports 2015, 5, 9141-9153. 47. Shen, C.; Calderon, J.E.; Barrios, E.; Soliman, M.; Khater, A.; Jeyaranjan, A.; Tetard, L.; Gordon, A.; Seal, S.; Zhai, L. Anisotropic electrical conductivity in polymer derived ceramics induced by graphene aerogels. Journal of Materials Chemistry C 2017, 32, 3033- 3038. 149 48. Cao, Y.; Yang, X.; An, L. Electric conductivity and microstructure evolution of polymer- derived sialco ceramics. Ceramics International 2016, 42, 4033-4038. 49. Rankin, D.W. Crc handbook of chemistry and physics (90th ed.). Taylor & Francis: Boca Raton, Florida, 2009; 52, 2-65. 50. Li, B.; Nan, Y.; Zhang, P.; Wang, Z.; Lu, Q.; Song, X. Synthesis and characterization of carbon nanostructures by evaporating pure graphite and carbon black in detonation-gas arc discharge. Diamond and Related Materials 2015, 55, 87-94. 51. Park, S.; An, J.; Piner, R.D.; Jung, I.; Yang, D.; Velamakanni, A.; Nguyen, S.T.; Ruoff, R.S. Aqueous suspension and characterization of chemically modified graphene sheets. Chemistry of Materials 2008, 20, 6592-6594. 52. Habiba, K.; Makarov, V.I.; Avalos, J.; Guinel, M.J.F.; Weiner, B.R.; Morell, G. Luminescent graphene quantum dots fabricated by pulsed laser synthesis. Carbon 2013, 64, 341-350. 53. Kim, Y.; Song, W.; Lee, S.Y.; Jeon, C.; Jung, W.; Kim, M.; Park, C.Y. Low-temperature synthesis of graphene on nickel foil by microwave plasma chemical vapor deposition. Applied Physics Letters 2011, 98, 263106-263113. 54. Ghosh, A.; Shukla, S.; Khosla, G.S.; Lochab, B.; Mitra, S. Sustainable sulfur-rich copolymer/graphene composite as lithium-sulfur battery cathode with excellent electrochemical performance. Scientific Reports 2016, 6, 25207. 55. Lee, J.; Kim, K.; Park, W.I.; Kim, B.-H.; Park, J.H.; Kim, T.-H.; Bong, S.; Kim, C.-H.; Chae, G.; Jun, M., et al. Uniform graphene quantum dots patterned from self-assembled silica nanodots. Nano Letters 2012, 12, 6078-6083. 150 56. King, A.A.K.; Davies, B.R.; Noorbehesht, N.; Newman, P.; Church, T.L.; Harris, A.T.; Razal, J.M.; Minett, A.I. A new raman metric for the characterisation of graphene oxide and its derivatives. Scientific Reports 2016, 6, 19491. 57. Mehta, J.S.; Faucett, A.C.; Sharma, A.; Mativetsky, J.M. How reliable are raman spectroscopy measurements of graphene oxide? The Journal of Physical Chemistry C 2017, 121, 16584-16591. 58. Kaniyoor, A.; Ramaprabhu, S. A raman spectroscopic investigation of graphite oxide derived graphene. AIP Advances 2012, 2, 032183. 59. Pankaj, C.; Malay, K.D.; Kamal, K.K. Green reduction of graphene oxide into graphene by cow urine. Current Nanomaterials 2016, 1, 110-116. 60. Kalfat, R.; Babonneau, F.; Gharbi, N.; Zarrouk, H. 29si mas nmr investigation of the pyrolysis process of cross-linked polysiloxanes prepared from polymethylhydrosiloxane. Journal of Materials Chemistry 1996, 6, 1673-1678. 61. Campostrini, R.; D'Andrea, G.; Carturan, G.; Ceccato, R.; Soraru, G.D. Pyrolysis study of methyl-substituted si-h containing gels as precursors for oxycarbide glasses, by combined thermogravimetry, gas chromatographic and mass spectrometric analysis. Journal of Materials Chemistry 1996, 6, 585-594. 62. Mera, G.; Gallei, M.; Bernard, S.; Ionescu, E. Ceramic nanocomposites from tailor-made preceramic polymers. Nanomaterials 2015, 5, 468. 63. Camino, G.; Lomakin, S.M.; Lageard, M. Thermal polydimethylsiloxane degradation. Part 2. The degradation mechanisms. Polymer 2002, 43, 2011-2015. 151 64. Chenoweth, K.; Cheung, S.; van Duin, A.C.T.; Goddard, W.A.; Kober, E.M. Simulations on the thermal decomposition of a poly(dimethylsiloxane) polymer using the reaxff reactive force field. Journal of the American Chemical Society 2005, 127, 7192-7202. 65. Bouillon, E.; Langlais, F.; Pailler, R.; Naslain, R.; Cruege, F.; Huong, P.V.; Sarthou, J.C.; Delpuech, A.; Laffon, C.; Lagarde, P., et al. Conversion mechanisms of a polycarbosilane precursor into an sic-based ceramic material. Journal of Materials Science 1991, 26, 1333- 1345. 66. Ionescu, E.; Kleebe, H.-J.; Riedel, R. Silicon-containing polymer-derived ceramic nanocomposites (pdc-ncs): Preparative approaches and properties. Chemical Society Reviews 2012, 41, 5032-5052. 67. Saha, A.; Raj, R.; Williamson, D.L. A model for the nanodomains in polymer-derived sico. Journal of the American Ceramic Society 2006, 89, 2188-2195. 68. Jones, R.G.; Ando, W.; Chojnowski, J. Silicon-containing polymers: The science and technology of their synthesis and applications. Springer Science & Business Media: 2013, 41, 1095-1107. 69. Ferrari, A.C.; Robertson, J. Interpretation of raman spectra of disordered and amorphous carbon. Physical Review B 2000, 61, 14095-14107. 70. Ferrari, A.C.; Robertson, J. Raman spectroscopy of amorphous, nanostructured, diamond– like carbon, and nanodiamond. Philosophical Transactions of the Royal Society of London. Series A: Mathematical, Physical and Engineering Sciences 2004, 362, 2477. 71. Jiang, T.; Wang, Y.; Wang, Y.; Orlovskaya, N.; An, L. Quantitative raman analysis of free carbon in polymer-derived ceramics. Journal of the American Ceramic Society 2009, 92, 2455-2458. 152 72. Raj, R.; Riedel, R.; Soraru, G.D. Introduction to the special topical issue on ultrahigh- temperature polymer-derived ceramics. Journal of the American Ceramic Society 2001, 84, 2158-2159. 73. Varga, T.; Navrotsky, A.; Moats, J.L.; Morcos, R.M.; Poli, F.; Müller, K.; Saha, A.; Raj, R. Thermodynamically stable sixoycz polymer-like amorphous ceramics. Journal of the American Ceramic Society 2007, 90, 3213-3219. 74. Bernardo, E.; Fiocco, L.; Parcianello, G.; Storti, E.; Colombo, P. Advanced ceramics from preceramic polymers modified at the nano-scale: A review. Materials 2014, 7, 1927. 75. Greil, P. Near net shape manufacturing of polymer derived ceramics. Journal of the European Ceramic Society 1998, 18, 1905-1914. 76. Greil, P. Active-filler-controlled pyrolysis of preceramic polymers. Journal of the American Ceramic Society 1995, 78, 835-848. 77. Katsuda, Y.; Gerstel, P.; Narayanan, J.; Bill, J.; Aldinger, F. Reinforcement of precursor- derived si–c–n ceramics with carbon nanotubes. Journal of the European Ceramic Society 2006, 26, 3399-3405. 78. Plachký, T.; Lenčéš, Z.; Hric, Ľ.; Šajgalík, P.; Baláž, P.; Riedel, R.; Kleebe, H.J. Processing and mechanical properties of si3n4 composites employing polymer-derived sialoc as sintering aid. Journal of the European Ceramic Society 2010, 30, 759-767. 79. Li, Y.; Samad, Y.A.; Polychronopoulou, K.; Alhassan, S.M.; Liao, K. Highly electrically conductive nanocomposites based on polymerinfused graphene sponges. Scientific Reports 2014, 4, 4652. 80. Shi, Y.; Peng, L.; Yu, G. Nanostructured conducting polymer hydrogels for energy storage applications. Nanoscale 2015, 7, 12796-12806. 153 81. Dalmas, F.; Dendievel, R.; Chazeau, L.; Cavaillé, J.-Y.; Gauthier, C. Carbon nanotube- filled polymer composites. Numerical simulation of electrical conductivity in three- dimensional entangled fibrous networks. Acta Materialia 2006, 54, 2923-2931. 82. Monthioux, M.; Delverdier, O. Thermal behavior of (organosilicon) polymer-derived ceramics. V: Main facts and trends. Journal of the European Ceramic Society 1996, 16, 721-737. 83. Yu, Y.; Wu, X. Study of the generalized mixture rule for determining effective conductivity of two-phase stochastic models. Applied Geophysics 2010, 7, 210-216. 84. Xu, Y.; Shankland, T.J.; Poe, B.T. Laboratory-based electrical conductivity in the earth's mantle. Journal of Geophysical Research: Solid Earth 2000, 105, 27865-27875. 85. Glover, P.W.J.; Hole, M.J.; Pous, J. A modified archie’s law for two conducting phases. Earth and Planetary Science Letters 2000, 180, 369-383. 86. Waff, H.S. Theoretical considerations of electrical conductivity in a partially molten mantle and implications for geothermometry. Journal of Geophysical Research 1974, 79, 4003-4010. 87. Ryu, H.-Y.; Wang, Q.; Raj, R. Ultrahigh-temperature semiconductors made from polymer- derived ceramics. Journal of the American Ceramic Society 2010, 93, 1668-1676. 88. Bouillon, E.; Mocaer, D.; Villeneuve, J.F.; Pailler, R.; Naslain, R.; Monthioux, M.; Oberlin, A.; Guimon, C.; Pfister, G. Composition-microstructure-property relationships in ceramic monofilaments resulting from the pyrolysis of a polycarbosilane precursor at 800 to 400 °c. Journal of Materials Science 1991, 26, 1517-1530. 154 89. Chollon, G.; Pailler, R.; Naslain, R.; Laanani, F.; Monthioux, M.; Olry, P. Thermal stability of a pcs-derived sic fibre with a low oxygen content (hi-nicalon). Journal of Materials Science 1997, 32, 327-347. 90. Haluschka, C.; Engel, C.; Riedel, R. Silicon carbonitride ceramics derived from polysilazanes part ii. Investigation of electrical properties. Journal of the European Ceramic Society 2000, 20, 1365-1374. 91. Wang, Y.; Zhang, L.; Xu, W.; Jiang, T.; Fan, Y.; Jiang, D.; An, L. Effect of thermal initiator concentration on the electrical behavior of polymer-derived amorphous silicon carbonitrides. Journal of the American Ceramic Society 2008, 91, 3971-3975. 92. Colombo, P.; Gambaryan-Roisman, T.; Scheffler, M.; Buhler, P.; Greil, P. Conductive ceramic foams from preceramic polymers. Journal of the American Ceramic Society 2001, 84, 2265-2268. 93. Gurlo, A.; Ionescu, E.; Riedel, R.; Clarke, D.R. The thermal conductivity of polymer- derived amorphous si–o–c compounds and nano-composites. Journal of the American Ceramic Society 2016, 99, 281-285. 94. Qiu, L.; Li, Y.M.; Zheng, X.H.; Zhu, J.; Tang, D.W.; Wu, J.Q.; Xu, C.H. Thermal- conductivity studies of macro-porous polymer-derived sioc ceramics. International Journal of Thermophysics 2014, 35, 76-89. 95. Fu, B.; Tang, G.; Li, Y. Electron-phonon scattering effect on the lattice thermal conductivity of silicon nanostructures. Physical Chemistry Chemical Physics 2017, 19, 28517-28526. 96. Liao, Q.; Liu, Z.; Liu, W.; Deng, C.; Yang, N. Extremely high thermal conductivity of aligned carbon nanotube-polyethylene composites. Scientific Reports 2015, 5, 16543. 155 97. Jopek, H.; Strek, T. Optimization of the effective thermal conductivity of a composite. In Convection and conduction heat transfer, InTech: 2011, 53, 371-379. 98. Sun, W.; Du, A.; Gao, G.; Shen, J.; Wu, G. Graphene-templated carbon aerogels combining with ultra-high electrical conductivity and ultra-low thermal conductivity. Microporous and Mesoporous Materials 2017, 253, 71-79. 99. Feng, J.; Feng, J.; Jiang, Y.; Zhang, C. Ultralow density carbon aerogels with low thermal conductivity up to 2000°c. Materials Letters 2011, 65, 3454-3456. 100. Lu, X.; Nilsson, O.; Fricke, J.; Pekala, R.W. Thermal and electrical conductivity of monolithic carbon aerogels. Journal of Applied Physics 1993, 73, 581-584. 101. Oulad Hammouch, S.; Beinert, G.J.; Herz, J.E. Contribution to a better knowledge of the crosslinking reaction of polydimethylsiloxane (pdms) by end-linking: The formation of star-branched pdms by the hydrosilylation reaction. Polymer 1996, 37, 3353-3360. 102. Esteves, A.C.C.; Brokken-Zijp, J.; Laven, J.; Huinink, H.P.; Reuvers, N.J.W.; Van, M.P.; de With, G. Influence of cross-linker concentration on the cross-linking of pdms and the network structures formed. Polymer 2009, 50, 3955-3966. 103. Radovanovic, E.; Gozzi, M.F.; Gonçalves, M.C.; Yoshida, I.V.P. Silicon oxycarbide glasses from silicone networks. Journal of Non-Crystalline Solids 1999, 248, 37-48. 104. Fang, Y.; Huang, M.; Yu, Z.; Xia, H.; Chen, L.; Zhang, Y.; Zhang, L. Synthesis, characterization, and pyrolytic conversion of a novel liquid polycarbosilane. Journal of the American Ceramic Society 2008, 91, 3298-3302. 105. Wang, M.; Yang, L.; Yu, C.; Xu, C. Liquid poly(silylacetylene)siloxane resin as a novel precursor of silicon carbide and silicon oxycarbide ceramics. Ceramics International 2012, 38, 2449-2454. 156 106. Aldridge, S. Main group chemistry: From molecules to materials. Dalton Transactions 2008, 3377-3387. 107. Sandford, S.A.; Bajt, S.; Clemett, S.J.; Cody, G.D.; Cooper, G.; Degregorio, B.T.; De Vera, V.; Dworkin, J.P.; Elsila, J.E.; Flynn, G.J., et al. Assessment and control of organic and other contaminants associated with the stardust sample return from comet 81p/wild 2. Meteoritics & Planetary Science 2010, 45, 406-433. 108. Cheng, X.; Xie, Z.; Song, Y.; Xiao, J.; Wang, Y. Structure and properties of polycarbosilane synthesized from polydimethylsilane under high pressure. Journal of Applied Polymer Science 2006, 99, 1188-1194. 157 CHAPTER 5: CRYSTALLIZATION OF P3HT ON GRAPHIITC SUBSTRATES WITH DIFFERENT CURVATURES Introduction Solution processed organic devices are of great interest for their potential applications in low cost electronics, optoelectronics and clean energy harvest because of their ease of processing, cost effective fabrication, light weight, flexibility, ability to cover large areas as well as their potential of constructing desired device using rationally designed molecules. [1-3] Conjugated polymers (CPs), containing conjugated chains with π-electrons delocalized along the polymer backbones, have numerous potential applications in solution processed organic electronics such as organic field-effect transistors (OFETs), [4-11] molecular electronics [12-14] and bulk heterojunction organic photovoltaics (BHJ-OPVs). [15-30] The performance of CP based organic electronic devices is determined by two factors: the morphology of CPs and the interface between CPs and electrodes due to the anisotropic charge transport characteritics in these devices. The charge transport pathways in polycrystalline CP films include fast interchain and intrachain transport within crystals and slow inter-grain transport among CP crystals. [31] A recent study of the relationship between the disorder, aggregation and charge transport of CP films suggests that the inter-grain charge transport is the rate dertmining step for charge transport. The key to improve the charge transport is eliminating the grain boundary. [32] The understanding of charge transport mechanisms in CPs leads to much effort in producing CP crystals with controlled orientation and improving the active material/electrode interfacial properties. [33-39] Regioregular poly(3-hexyl thiophene) (P3HT) is one of the most extensively studied CPs due to its high charge mobility and tendency to assemble into crystals (i.e. nanowires and nanoribbons). [34-37,40-47] The research 158 has been focused on the formation of P3HT crystals in solutions and on substrates include carbon nanotubes [8,37,40,48], graphene [49] and derivatives [50-54], and polymer assemblies. [55,56] The most reported P3HT superamolecular assemblies are nanowires, which are formed by π-π interaction among polymer backbones. [44-47,54,57-60] The investigatation of P3HT crystallization process in solutions by changing molecular weight (Mn), crystallization temperature and polymer concentration suggested that P3HT polymer chains transit from extending to folding in nanowhiskers when the Mn is above a critical value (10 kDa). The folding length can be controlled by crystallization temperature, and extended P3HT chains can further grow into highly ordered two-dimensional (2D) nanoribbons by the combination of π-π interaction among polymer backbones and alkyl side chain Van der Waals interactions. [34] CNTs and graphene have been used as electrodes in organic electronic devices in OFETs and for replacing indium tin oxide (ITO) transparent OFETs. [61] CNT electrodes are known to have superior charge injection than metal electrodes in OFETs.[62-66] Graphene has extraordinary room-temperature carrier mobility (20000 cm2/Vs), [67-72] conductivity, and high optical transmittance (97.7 % at 550 nm), making it a viable candidate for electrodes π-bonded surfaces CNTs and graphene are ideal for guiding the assembly of CPs to improve charge transport and providing optimum CP/electrode interfaces for efficient charge injection. The π-π intermolecular interactions between graphitic surfaces (i.e. CNT and graphene) and CPs such as poly(3- hexylthiophene) (P3HT) have been used to guide the growth of CP supramolecular assemblies (i.e. nanowires) on graphitic surfaces, [35,40,49] and fabricate efficient organicelectronics with optimized CP assembly orientation and CP assembly/electrode interfacial contact. 159 Here in, we report the formation of P3HT nanocrystals on graphitic substrates with different curvatures (i.e. SWCNTs, MWCNTs, carbon fibers, and graphene). P3HT with Mn below and above the folding threshold were used in this study to investigate the assembly of P3HT from graphitic surfaces. Computational simulations of single P3HT molecule on carbon materials were used to justify the preferential orientation of P3HT nanocrystals on graphitic surfaces. Figure 5-1. Schematic illustrations of (a) nanowire crystals formation from extended P3HT chains, (b) nanowire crystals formation from folded P3HT chains, and (c) nanoribbon crystals formation from extended P3HT chains. Materials Poly(3-hexylthiophene) (P3HT) molecules with vinyl end groups were synthesized in our lab using a procedure which has been previously reported. [73] P3HT molecules with different molecular weight were synthesized by using different polymerization time, and their molecular weight was determined by Gel permeation chromatography (GPC). P3HT with molecular weight larger than 160 the chain folding threshold was denoted as “LM-P3HT” (Mn=13.8 kDa, PDI=1.51), and P3HT with molecular weight smaller than the chain folding threshold was denoted as “SM-P3HT” (Mn= 4.8 kDa, PDI= 1.70). Graphene flakes were synthesized by a chemical vapor deposition (CVD) method similar to previous reports. [74-76] Mixed gases of hydrogen and methane were reacted at 1000 oC, and graphene flakes were formed on copper foils. After etching copper foils by the iron nitrate aqueous solution, graphene flakes were transferred onto desired substrates (TEM grids and QCM probes) by a wet transfer process. Single-walled carbon nanotubes (SWCNTs) with 1.5 nm diameters and Multi-walled carbon nanotubes (MWCNTs) with 10-20 nm diameters were purchased from NanoLab Inc. Carbon fibers (CFs) with 160-180 nm diameters were purchased from Sigma Aldrich. Highly Ordered Pyrolytic Graphic (HOPG) and silicon wafers were purchased from SPI. Anisole (HPLC grade) and dimethylformamide (DMF) (HPLC grade) were purchased from Fisher. Hydrogen and Methane were purchased from Air Liquide. All materials were used as received without further purifications. Experimental Procedures For crystallizations of P3HT on SWCNTs, MWCNTs and CFs, these graphitic carbon materials were added into 95 oC P3HT marginal solutions with required mass. After that, mixtures contained graphitic carbon materials and P3HT were sonicated for 30 minutes by a horn sonifier, and uniform bright yellow dispersions were formed after sonications. Dispersions were then heated back to 95 oC, and the crystallizations of P3HT on graphitic substrates were started by cooling down the P3HT/graphitic carbon materials dispersions. After several hours (usually 6 hours) of 161 crystallizations, dispersions were drop-casted onto carbon film supported TEM grids for TEM study and were drop-casted onto silicon wafers for characterizations of SEM and AFM. For crystallizations of P3HT on graphene, TEM grids coated with graphene and exfoliated HOPG flakes on silicon wafers were used as substrates. In crystallization processes, TEM grids or silicon wafers were vertically immersed into 95 oC P3HT marginal solutions. Marginal solutions were cooled down in ambient atmosphere to induce crystallizations of P3HT on graphene. After crystallizations, TEM grids and silicon wafers were directly dried for further characterizations. In all crystallization processes conducted in this paper, the marginal solvent for LM-P3HT crystallization is anisole, and the marginal solvent for SM-P3HT crystallization is the mixed solvent of anisole and DMF with a volume ratio of 2:1. In the study on crystallization kinetics, 0.05 mg/mL LM-P3HT solutions in anisole at 95 oC were mixed with SWCNTs, MWCNTs, and CFs, respectively. In these mixtures, a mass ratio of 10:1 between LM-P3HT and graphitic carbon materials was applied in all trials. Consequently, the concentration of P3HT and graphitic carbon materials in each dispersion were 0.05 mg/mL and 0.005 mg/mL, respectively. Mixtures were sonicated by a horn sonifier for 30 minutes to form uniform dispersions, and then they were heated back to 95 oC. Dispersions at 95 oC were transferred to quartz cuvettes for UV-Vis spectroscopy study. Quartz cuvettes were placed in the sample chamber at room temperature (20 oC), and UV-Vis spectra at different crystallization time were obtained from a UV-Vis spectrometer. In the study for SM-P3HT, Details of the crystallization study of SM-P3HT are the same as those of LM-P3HT except a marginal solvent of anisole: DMF= 2:1 (v: v) was applied in this series of 162 experiments. The concentration of graphitic substrates in dispersions is 0.005 mg/mL, and the concentration of SM-P3HT is 0.05 mg/mL. In the Quartz Crystal Microbalance (QCM) study, QCM probes coated with graphene were used. Graphene flakes on the QCM probes have a dimension of 1 cm×1 cm. The probe was vertically immersed into a 100 mL 0.05 mg/mL LM-P3HT or SM-P3HT marginal solution at 95 oC, and the point of immersion was considered as the time to start crystallization processes. The deposited mass of P3HT on graphene during crystallization processes was recorded by the built-in microbalance. Characterizations The number-average molecular weight (Mn) and polydispersity index (PDI) of P3HT were determined by gel permeation chromatography (GPC) using a JASCO LC2000 HPLC system. Polystyrene was used as standards, and tetrahydrofuran was used as the eluent. TEM images and the corresponding selected area electron diffraction (SAED) patterns were obtained on a JEOL 1011 electron microscopy operated at 100 kV. SEM images were got from a ZEISS ULTRA55 scanning electron microscope. AFM images were acquired from a Veeco Dimension 3100 scanning probe microscope in tapping mode. UV-Vis spectra were recorded on a Varian 300 Bio UV-Visible spectrophotometer. Raman Spectroscopy was conducted on a Raman confocal spectroscopy (Witec Alpha300RA) spectrometer system. The deposited mass of P3HT on graphene was monitored by a Matrex Quartz Crystal Microbalance (QCM) probe coated with a 1 cm×1 cm graphene film. 163 Results and Discussion Crystallization of LM-P3HT on Graphitic Substrates Figure 5-2. TEM images of LM-P3HT crystallized on (a) SWCNTs, (b) MWCNTs, (c) CFs, and (d) graphene from 0.05 mg/mL marginal solutions. Scale bars are 250 nm. For LM-P3HTs with Mn>10 kDa, their molecular chains are folded. [34] It has been reported that LM-P3HT form nanowires from the surface of graphitic substrates such as SWCNTs and MWCNTs. [40,77] P3HT nanowires with widths of 14 nm are found on surfaces of these graphitic 164 substrates, and the width is almost identical to that of nanowires crystallized from marginal solutions without graphitic substrates. Here in, it is not surprising to see P3HT nanowires with similar widths grown from the surface of CFs (Figure 5-2c) and graphene (Figure 5-2d). The assembly of LM-P3HT molecules can only be from – stacking among thiophene rings in their backbones, and it is the reason for the only formationπ ofπ nanowire crystals from LM-P3HT. The orientation of LM-P3HT nanowires grown from surfaces of graphitic substrates is also explored. It has been reported that P3HT molecules tend to interact coaxially with the surface of SWCNTs and MWCNTs to get a conformation with the lowest energy. [77] For the formation of P3HT nanowires on CFs, the overlapping of P3HT nanowires at different height positions is observed in the AFM image (Figure 5-25). Such results reveal the formation of P3HT nanowires on different area of CFs and thus indicates their random radial orientations on CFs. The crystallization of LM-P3HT on graphene leads to randomly oriented nanowires, and it is because of the minimal curvature of graphene that grants LM-P3HT molecules with the freedom in arrangement orientations on the nearly flat graphene surface. Schematic illustrations of LM-P3HT nanowires grown from different graphitic substrates are presented in Figure 5-3. Figure 5-3. Schematic illustrations of nanowires formation from LM-P3HT on graphitic substrates of (a) CNTs, (b) CFs, and (c) graphene. 165 Crystallization of SM-P3HT on Graphitic Substrates by Using High Concentration Marginal Solutions P3HT molecules with Mn<10 kDa have extended molecular chains. Previous report has addressed the formation of nanoribbon crystals from SM-P3HT in marginal solutions. [34] Here in, the crystallization behavior of it on graphitic substrates is explored. For the crystallization of SM-P3HT on SWCNTs, it is intriguing that no nanoribbons are observed from the surface of SWCNTs even by applying SM-P3HT marginal solution with the concentration (0.3mg/mL) higher than the threshold (0.2 mg/mL) for SM-P3HT nanoribbons formation. Only Nanowires with widths of around 7-8 nm are observed from Figure 5-4a, and the widths of nanowires are in agreement with the length of SM-P3HT backbones with Mn= 4.8 kDa. Besides, the SAED signal from P3HT nanowires is shown in Figure 5-4b. The spacing in the SAED image is the reciprocal of the spacing in the real world. The ring with the spacing of 2.56 in the SAED 1 𝑛𝑛𝑛𝑛 image is corresponding to the spacing of 3.9 Å (010) in P3HT nanowires crystals. The spacing of 3.9 Å verifies the formation of nanowire crystals because it reflects the distance between two adjacent P3HT molecules interacted by π-π stacking. Based on our previous studies using Molecular Dynamics (MD) simulations, P3HT chains are found attached along the axis of SWCNTs with alkyl chains wrapping around the carbon nanotube to achieve minimal interaction energy. [77] Here, additional simulations about P3HT oligomer arrangements on different types of SWCNTs, namely chiral (9, 0), armchair (8, 8) and zigzag (13, 0) are operated. Results in Table 5-3 suggest that the coaxial wrapping of P3HT is favored on surfaces of all types of SWCNTs because of the large negative interaction energy. With such coaxial arrangement on SWCNTs, the growth of P3HT nanocrystals from alkyl side chain interactions among extended P3HT chains is 166 inhibited. It is attributed to the huge curvature of SWCNTs surface which leads to the incapability of providing ground to support P3HT chains interacted by alkyl side chains. Therefore, the growth of P3HT nanocrystals can only be from the - stacking among thiophene rings in P3HT backbones. In consequence, only nanowires canπ beπ formed with a confined orientation coaxial to SWCNTs (Figure 5-5), and the formation of nanoribbons on SWCNTs is unavailable. Figure 5-4. (a) The TEM image of SM-P3HT crystallized from SWCNTs by using a 0.30 mg/m LM-P3HT marginal solution. (b) The SAED pattern of nanowires in (a). Figure 5-5. The schematic illustration of a SM-P3HT nanowire grown coaxially from SWCNTs. 167 Different from the crystallization of SM-P3HT on the surface of SWCNTs, the formation of nanoribbons is observed from the surface of MWCNTs. P3HT crystals grown from the surface of MWCNTs by using SM-P3HT molecules are shown in Figure 5-6. In this study, the concentration of SM-P3HT is 0.3 mg/mL. In Figure 5-6a, P3HT nanoribbons with widths of 70-120 nm and lengths of 50-150 nm are observed from the surface of MWCNTs. SAED rings regarding the spacing of 16.6 Å (100) and 3.9 Å (010) in crystals are seen from the SAED image (Figure 5-6b) by getting reciprocals of the spacing shown in the SAED image. 16.6 Å and 3.9 Å are in accordance with distances of two adjacent P3HT chains interacted by alkyl side chains and – stacking, respectively. Thus, the formation of nanoribbon crystals on MWCNTs is verified. πTheπ assembly of SM-P3HT nanoribbons on MWCNTs is schematically illustrated in Figure 5-7 based on results from TEM and SAED images. P3HT nanoribbons grown from the surface of MWCNTs have the orientation that backbones of SM-P3HT within nanoribbons arrange perpendicular to the axis of MWCNTs. To verify the availability of this arrangement of SM-P3HT on MWCNTs, Molecular Dynamics (MD) simulation regarding the interactions between P3HT chains and MWCNTs is performed. The length of P3HT chain used in this simulation is much smaller than the diameter of MWCNTs. According to the values of interaction energy shown in Table 5-4, P3HT molecules can take different orientations such as parallel (0o), perpendicular (90o) and have an angle of 30o to the axis of MWCNTs with minimal energy differences in this scenario. In consequence, not only the arrangement of SM-P3HT with backbones parallel to the axis of MWCNTs is available, but also arrangements with other orientations are eligible. When P3HT backbones arrange perpendicular to the axis of MWCNTs, the surface of MWCNTs can provide the ground to support follow-up P3HT chains interacted by Van de Waals alkyl side chain interactions, and the arrangement of P3HT chains by this interaction extends along the axis of MWCNTs. Besides, 168 P3HT molecules on MWCNTs can surely interact with follow-up P3HT molecules by π-π stacking to have the vertical growth from MWCNTs surface. Therefore, P3HT nanoribbons are formed by both - stacking and alkyl side chain interactions among SM-P3HT molecules. However, if P3HTπ chainsπ attach on the surface of MWCNTs with other orientations, no ground will be given by MWCNTs to support the extension from follow-up P3HT molecules interacted by their alkyl side chains due to the heavily curved surface of MWCNTs. As a result, SM-P3HT can only form nanoribbons on the surface of MWCNTs with a confined orientation. Furthermore, it needs to be mentioned that nanoribbons grown from MWCNTs are only able to be realized by using a slow cooling rate (15 oC/hour). P3HT nanoribbons prefer to be formed in the solution (Figure 5-27) instead of the surface of MWCNTs if rapid cooling processes are applied. Additionally, no nanowires on MWCNTs are observed in crystallizations using rapid cooling. It is probably attributed to the additional alkyl side chain interactions among P3HT molecules in P3HT nanoribbons which reduce the total entropy by assembling more ordered P3HT crystals. Thus, the formation of P3HT nanoribbons in the solution is more favored than the formation of P3HT nanowires on MWCNTs in crystallizations applying rapid cooling. Figure 5-6. (a) The TEM image of SM-P3HT crystallized on MWCNTs to form nanoribbons from a 0.30 mg/mL marginal solution. (b) The SAED pattern of nanoribbons in (a). 169 Figure 5-7. The Schematic illustration of SM-P3HT nanoribbons grown from MWCNTs with a confined orientation. Figure 5-8. The AFM image of P3HT nanoribbons grown from MWCNTs. The scanning area is 2 µm×2 µm. 170 The typical AFM image of nanoribbons composed of SM-P3HT on MWCNTs is shown in Figure 5-8. P3HT nanoribbons grown from the surface of MWCNTs can be clearly seen in this image. The height profile of the section line shows the thickness of nanoribbons to be 7.5 nm, and it is almost identical to the length of the unfolded SM-P3HT backbone. Therefore, nanoribbons composed of one layer of SM-P3HT are grown from the surface of MWCNTs. In addition, widths and lengths of P3HT nanoribbons observed from the AFM image are in accordance with the results from the TEM image. For the crystallization of SM-P3HT on CFs, nanoribbons with lengths of 150-300 nm are observed (Figure 5-9a) from the surface of CFs, and the SAED pattern of nanoribbons is shown Figure 5- 9b. SAED rings regarding the spacing of 16.8 Å (100) and 3.9 Å (010) in crystals are obtained by getting reciprocals of the spacing shown in the SAED image. 16.8 Å and 3.9 Å reflect the distance of two adjacent P3HT chains interacted by side alkyl chains and P3HT – stacking, respectively. Therefore, the crystallinity of P3HT nanoribbons formed on CFs is verified.π π Figure 5-9. (a) The TEM image of SM-P3HT crystallized on CFs from a 0.30 mg/mL marginal solution. (b) The SAED pattern of nanoribbons in (a). 171 To investigate the orientation of nanoribbons on CFs, P3HT nanocrystals grown from CFs are characterized by SEM and AFM. The SEM image of SM-P3HT nanoribbons grown from CFs is shown in Figure 5-10a. P3HT nanoribbons are vertically grown from the surface of CFs in different regions, so they have different radial orientations. Also, they have different orientations respect to the longitude axis of CFs, which can be clearly seen from the image. AFM imaging are further applied to reveal detailed information regarding the arrangement of P3HT nanoribbons on CFs. As shown in the 3D image generated from AFM imaging (Figure 5-10b), P3HT nanoribbons with different orientations to the longitude axis of CFs are clearly seen. their planes can be (I) perpendicular, (II) parallel or (III) non-parallel to the longitude axis of CFs as labeled in Figure 5- 10b. By analyzing the height profiles of several section lines, the thickness of about 100-150 nm and the lengths of about 300 nm are found (Figure 5-28). The thickness of P3HT nanoribbons formed on CFs (~100 nm) is much larger than the thickness of single layer SM-P3HT nanoribbons formed on MWCNTs (7.5 nm), thus it indicates multi-layers of P3HT are stacked in one P3HT nanoribbons crystal. The arrangement of SM-P3HT ribbons on CFs is schematically shown in Figure 5-11. P3HT nanoribbons are grown from CFs with random radial orientations as well as different angles respect to the longitude axis of CFs. Figure 5-10. (a) The SEM image of SM-P3HT crystallized on CFs, the scale bar is 1 m. (b) The 3D image of SM-P3HT crystallized on CFs generated from AFM data (2 m×2 m). µ 172 µ µ Figure 5-11. The schematic illustration of SM-P3HT nanoribbons grown from CFs with random radial and axial orientations. Localized Raman spectroscopy is used to verify nanocrystals on CFs are from P3HT. The optical image in the inset of Figure 5-12 is a CF wrapped by crystalized SM-P3HT, and the Raman spectrum of the red circled area on is shown in Figure 5-12. Signature Raman peaks of P3HT at 1369.6 cm-1 and 1451.2 cm-1 are seen from the spectrum, and they are characteristic peaks to the C=C (in thiophene rings) skeletal stretching vibration and the C–C (in thiophene rings) skeletal stretching vibration, [78] respectively. Thus, the existence of P3HT on CFs is verified. Also, the redshift (12 cm-1) of the peak regarding the stretching in thiophene rings from 1381.6 cm-1 (SM- P3HT powders) to 1369.6 cm-1 (SM-P3HT nanocrystals on CF) is obtained by the comparison between Figure 5-30 and Figure 5-12. It indicates the increase of conjugation length from the formation of ordered P3HT nanoribbon crystals on CFs. [79-82] 173 Figure 5-12. The Raman spectrum of crystallized SM-P3HT on CFs surface. The optical image of crystallized SM-P3HTT on CFs is in the inset, and the red circled area is investigated by Raman spectroscopy. At last, the crystallization of SM-P3HT on graphene is explored. TEM images of P3HT grown from graphene by using 0.30 mg/mL SM-P3HT in marginal solvents are shown in Figure 5-13a. P3HT nanoribbons are seen on the TEM image with widths of between 40-70 nm and lengths between 40-110 nm. In Figure 5-13b, strong SAED ring corresponding to the spacing of 16.7 Å (100) from alkyl side chain interactions and the weak SAED ring corresponding to the spacing of 3.9 Å (010) from - stacking can be obtained by getting reciprocals of spacing shown in the SAED image. The 𝜋𝜋results𝜋𝜋 from SAED images suggest P3HT “nanowalls” grow vertically from the surface of graphene, and they are composed of P3HT nanoribbons with random orientations in the graphene plane. When P3HT nanowalls grow vertically from the surface of graphene, the SAED pattern with spacing of 3.9 Å from - stacking cannot be seen from them. Therefore, the as seen SAED ring corresponding to the spacing𝜋𝜋 𝜋𝜋 of 3.9 Å from - stacking is attributed to be fell-down 174 𝜋𝜋 𝜋𝜋 P3HT nanoribbons in the TEM image. When the vertical growth of P3HT is too fast in some regions, nanowalls fall down because of their large aspect ratio. They inhibit the further vertical growth of nanowalls on graphene and become the top layer of P3HT crystallized from graphene surface. Besides, circled 6-fold patterns from graphene substrates in the SAED image (Figure 5- 13b) is consistent with a hexagonal lattice and indicates the high degree of crystallinity of graphene substrates. [83-86] The AFM image after the SM-P3HT crystallization on graphene surface is presented in Figure 5-15. The fell down nanowalls have the thickness of around 50-100 nm, and it indicates these nanowalls are composed of multi-layer nanoribbons from SM-P3HT molecules. From the discussion above, SM-P3HT nanowalls crystallized on graphitic substrates by using SM- P3HT are illustrated in Figure 5-14. Nanowalls grow vertically from the surface of graphene with random orientations in the plane of graphene surface. Figure 5-13. (a) The TEM image of SM-P3HT crystallized on the surface graphene. Fell-down nanowalls are pointed out by arrows. (b) The SAED pattern of nanowalls in (a). Two sets of six- fold SAED patterns from the graphene substrate are circled in red and blue. 175 Figure 5-14. The illustration of SM-P3HT nanowalls grown vertically from graphene surface (top view) with random orientations in the plane of graphene surface. Figure 5-15. The AFM image of SM-P3HT crystallized on graphene and height profiles of two lines labeled as 1 and 2. The scanning area is 1 m×1 m. 176µ µ The interactions between SM-P3HT and graphene was investigated by examining graphene surface, SM-P3HT, and SM-P3HT nanocrystals on graphene surface using Raman spectroscopy (Figure 5-29 to 5-31). The G peak from graphene redshifts 1 wavenumber from 1585.6cm-1 to 1584.6cm-1 after the growth of P3HT nanocrystals on its surface (Figure 5-31). The redshift of G peak is due to the interaction of electron donor with graphite. When graphene is contacting with an electron donor, the Fermi level of graphene increases, which leads to the decrease of the energy difference between the incident laser photons and the photons from Raman scattering, and G peak will have a redshift. [87,88] P3HT is a typical organic electron donor material, thus the interaction between P3HT and graphene surface is verified. In addition, the Raman shift regarding the peaks from P3HT is investigated. For the Raman peak around 1380cm-1 which is assigned to the stretching vibration of C–C on thiophene rings, it redshifts 4.9 wavenumber from 1381.6cm-1to 1376.7cm-1. The redshift indicates the increase of conjugation length which is believed to be attributed to the formation of P3HT nanowall crystals. Crystallization of SM-P3HT on Graphitic Substrates by Using Low Concentration Marginal Solutions Crystallization of SM-P3HT on graphitic surfaces by using solutions with concentration higher than the threshold of nanoribbons formatioon has been studied above. On the other hand, interesting phenomena are observed when solutions with concentration lower than the threshold of nanoribbons formation are applied. By using low concentration of SM-P3HT solutions, nanowires are formed from the surface of SWCNTs (Figure 5-32) and MWCNTs (Figure 5-33), and average length of nanowires increases with increasing concentration of SM-P3HT solutions used in crystallization processes. However, different kinds of nanocrystals are observed from the surface of CFs and graphene. 177 The resutls of SM-P3HT crystallization on CFs surface from low concentration marginal solutions are shown in Figure 5-16. Thin films are formed when the concentration of SM-P3HT is extremely low (0.03 mg/mL). sparsely distributed nanoribbons are observed when the concentration of SM- P3HT increases to (0.05 mg/mL). In addition, the TEM image of SM-P3HT crystallized on graphene surface by applying a marginal soluton with low concentration (0.05 mg/mL) is shown in Figure 5-34. Simiar results are observed compared to applying high concentraton of SM-P3HT marginal solutions (Figure 5-13). Figure 5-16. TEM images of SM-P3HT crystallized on CFs from (a) 0.03 mg/mL, (b) 0.05 mg/m marginal solutions. The thin film in (a) and nanoribbons in (b) are pointed by arrows. It has been previously reported that SM-P3HT solutions with low concentrations leads to the formation of nanowires during crystallization processes without graphitic carbon substrates, [34] then why nanowires are formed on the surface of CNTs and SM-P3HT nanocrystals in other types are observed from the surface of CFs and graphene when applying low concentration marginal solutions? For the crystallization of SM-P3HT on CNTs by using low concentration marginal 178 solutions, one of the reason of not forming large 2D nanocrystals is the lack of molecules. However, the large curvature of CNTs graphitic substrates is believed to be the primary reason. When SM- P3HT molecules wrap on the surface of SWCNTs and MWCNTs by the interaction of alkyl side chains, the follow-up stacking of SM-P3HT molecules are unable to keep both interations from π- π stacking and alkyl side chain integrations which are necessary to the formation of P3HT 2D structures. It is because large curvatures of CNTs will lead to significant distortions among follow- up stacked P3HT molecules arranged by alkyl side chain interactions. Such distortion increases with the stacking of more layers of P3HT molecules and will finally deassociates P3HT molecules interacted by alkyl side chains. As a result, no thin films composed of P3HT can be formed on surfaces of CNTs. For the crystallization of SM-P3HT on CFs, the much smaller curvature of CFs compared to CNTs leads to the capability of thin film formation due to much less distortion among P3HT interacted by alkyl side chains. However, when films become too thick, P3HT molecules interacted by alkyl side chains in the outer area will have the distortion large enough to dessociate these P3HT molecules and only the formation of nanoribbons in different regions can be realized. For the crystallization of SM-P3HT on graphene, the minimal curvature of the graphitic surface resulted in the formation of P3HT nanowalls by both π-π stackings and alkyl side chain interactions, and minimal distortion will exist within P3HT nanowalls ctystals. In some regions with faster vertical growth of SM-P3HT, nanowalls fall down and sparsely distributed on the top of P3HT crystals. Kinetic Study of LM-P3HT on Curved Graphitic Substrates In addition, in-situ UV-Vis spectroscopy studies are performed to investigate P3HT crystallizations on graphitic substrates with different curvatures. UV-Vis spectra during P3HT 179 crystallization processes are shown in Figure 5-26. The absorbance at around 455 nm decreases and the absorbance at around 600 nm increases during P3HT crystallization on SWCNTs, MWCNTs, and CFs. The absorbance with peak at 455 nm is assigned to individual P3HT molecules in the solution, and the absorption with peak at 600 nm is attributed to a combination of – electronic transitions and strong lattice vibrations in P3HT crystalline domains. [89] Thus, theπ formationπ of P3HT nanowire crystals from individual P3HT molecules in verified. Besides, obvious isosbestic points at around 482 nm in these UV–Vis spectra suggest a direct transformation from dissolved individual P3HT molecules to ordered nanowires crystals on graphitic substrates. [90,91] The increment of UV-Vis absorbance at 600 nm during crystallization processes is plotted in Figure 5-17. The increment is calculated as subtracting the absorbance at 600 nm during crystallization processes by the absorbance at 600 nm before crystallization processes. It can be clearly seen from Figure 5-17 that the absorbance increment for three P3HT crystallization processes is MWCNTs>SWCNTs>CFs through the whole range of crystallization time. Therefore, the crystallization rate on graphitic substrates has the trend of MWCNTs>SWCNTs>CFs. Besides, the absorbance at 600 nm does not increase after 3 hours, 4 hours, and 8 hours for P3HT crystallizations on MWCNTs, SWCNTs, and CFs, respectively. Therefore, the crystallization completion time of P3HT on graphitic substrates are shorter that needed in the marginal solution (40 hours), [40] and graphitic substrates greatly accelerate P3HT crystallizations. 180 Figure 5-17. The absorbance change at 600nm for P3HT crystallization on SWCNTs (triangle), MWCNTs (square), and CFs (diamond) graphitic surfaces. It is intriguing to find that the crystallization rate of P3HT on graphitic substrates have the trend of MWCNTs>SWCNTs>CFs. If the difference of total graphitic surface is the only parameter that affects the crystallization rate, the expected crystallization rate on graphitic substrates would be SWCNTs>MWCNTs>CFs. It is because the same concentration of graphitic substrates is applied in this series of experiments and their specific surface area has the trend of SWCNTs>MWCNTs>CFs from Table 5-1. However, this projected conclusion is different from the experimental results. Therefore, there must be other parameters that can affect P3HT crystallization rate on graphitic substrates. 181 Table 5-1. Curvature and specific surface area of different graphitic substrates. The diameter and specific surface area are from specifications given by manufacturers. Graphitic Diameter Curvature Specific Surface Substrates (nm) (nm-1) Area (m2/g) SWCNT 1.5 0.67 1000 MWCNT 10-20 0.05-0.1 200-400 CF 160-180 0.005-0.006 13-15 Because curvature is the major structural difference among those graphitic substrates, it is assumed as a vital parameter to P3HT crystallizations. The attached mass of P3HT on unit area graphitic substrates during crystallization processes is shown in Figure 5-18. The attached mass of P3HT on unit area of graphitic substrates is calculated as follows. The increment of absorbance at 600nm is divided by the absorbance at 455 nm before crystallization, then the value is multiplied by the concentration and the volume of marginal solution to get the total mass of attached P3HT. Attached mass of P3HT per unit area of graphitic substrates is obtained after dividing the total attached mass of P3HT by the total graphitic surface area from graphitic substrates. From Figure 5-18, the attached mass of P3HT on unit area of graphitic substrates has the trend of SWCNTs Table 5-4, so the attachment of P3HT on graphitic substrates with larger diameter (smaller curvature) is more stable. The more stable attachment of P3HT molecules on graphitic substrates will result in a higher possibility of P3HT nanowires formation from this area by interactions of follow-up P3HT molecules, thus higher utilization of graphitic surface for the formation of 182 nanowire crystals will be realized. Therefore, graphitic substrates with smaller curvatures will lead to higher utilization of graphitic surface for P3HT nanowires growth, and the attached mass of P3HT on unit area of graphitic substrates will be higher in the meantime. In conclusion, both total surface area and the curvature of graphitic surface can affect the rate of P3HT crystallization on graphitic substrates. Figure 5-18. Attached mass of LM-P3HT on unit area of SWCNTs (triangle), MWCNTs (square), and CFs (diamond) graphitic substrates. Diameters of MWCNTs and CFs are considered as 15 nm and 170 nm in calculations. Avrami Equation 5-1 is used to examine the dimensionality of P3HT nanocrystals from graphitic substrates aided crystallization. Because hot P3HT/graphitic substrates dispersions can rapidly cool down to room temperature in ambient atmosphere, P3HT crystallization processes are able 1 = ( ) (5-1) 𝑛𝑛 𝑐𝑐 to be considered as quasi-isothermal crystallization− 𝜑𝜑 𝑒𝑒𝑒𝑒𝑒𝑒 −processes.𝐾𝐾𝑡𝑡 is the degree of crystallinity, 𝑐𝑐 is the overall rate constant that generally depends on temperature,𝜑𝜑 is the crystallization time, and𝐾𝐾 𝑡𝑡 183 is the Avrami exponent. The value of for crystallization processes of P3HT on SWCNTs, MWCNTs,𝑛𝑛 and CFs are calculated to be𝑛𝑛 0.67, 0.68, and 0.57, respectively. Thus, the one- dimensional growth of P3HT crystals on graphitic carbon materials by using LM-P3HT is verified. Additionally, the order of crystallization reactions is also investigated. Typically, the reaction rate of a crystallization reaction is able to be expressed in Equation 5-2.[92,93] In the case of = = (5-2) 𝑑𝑑𝑑𝑑 𝑛𝑛 𝐺𝐺 − 𝑑𝑑𝑑𝑑 𝑘𝑘𝑐𝑐 P3HT crystallization, G is crystallization rate of P3HT, c is the concentration of isolated P3HT in solutions, t is the crystallization time, is the reaction coefficient, and n is the reaction order. First order reactions for these crystallization𝑘𝑘 processes after the curve fitting method mentioned in the supplementary materials. Kinetic Study of SM-P3HT on Curved Graphitic Substrates The kinetic study of SM-P3HT crystallization on SWCNTs, MWCNTs, and CFs is performed by using the in-situ UV-Vis spectroscopy. Same as the analysis regarding crystallizations of LM- P3HT on graphitic substrates, the increments of absorbance at 600 nm from the start of crystallization processes are used to determine the amount of crystallized SM-P3HT on graphitic substrates, and the results are presented in Figure 5-19. The increment of absorbance at 600 nm for the crystallization of SM-P3HT on CFs is larger than that on SWCNTs and MWCNTs. Also, the increments of absorbance at 600 nm for SM-P3HT crystallizations on SWCNTs and MWCNTs are close, and the increment regarding the SM-P3HT crystallization on MWCNTs is a little bit faster. Thus, the rate of SM-P3HT crystallizations on graphitic substrates has the trend of CFs>MWCNTs SWCNTs. The formation of 2D structures such as thin films and sparsely ≅ 184 dispersed nanoribbons is believed to be the reason of faster crystallization rate on CFs than that on SWCNTs and MWCNTs. Besides, the absorbance intensity at 600 nm keeps nearly unchanged in less than 2 hours of crystallization processes, which indicates no further formation of crystallized SM-P3HT molecules on graphitic substrates. As a result, the time takes to reach the plateau of absorbance intensity at 600 nm for SM-P3HT crystallizations on graphitic substrates is much shorter than that for LM-P3HT (4 hours, 3 hours, and 8 hours for crystallizations of LM-P3HT on SWCNTs, MWCNTs, and CFs, respectively), thus the SM-P3HT crystallizations on graphitic substrates completes much faster than that of LM-P3HT. An insight into their backbone structures can provide a plausible explanation on crystallization rate differences. The SM-P3HT molecule has an extended backbone (Figure 5-1a) instead of the folded backbone contains “turning points” and multiple segments of backbone separated by turning points (Figure 5-1b) from a LM-P3HT molecule. These “turning points” structures in LM-P3HT molecules can easily introduce defects into P3HT nanocrystals formed from LM-P3HT and thus weaken the stability of these P3HT nanocrystals. As a result, it will lead to a higher tendency of LM-P3HT molecules detachment in such dynamic crystallization processes and slow down the overall crystallization rate. Furthermore, the Avrami exponents regarding the crystallizations of SM-P3HT on SWCNTs, MWCNTs, and CFs are calculated by the same method as mentioned in the discussion of LM-P3HT crystallizations on graphitic substrates. The Avrami exponents of SM-P3HT crystallizations on SWCNTs, MWCNTs, and CFs are 0.65, 0.71, and 0.93, respectively. The larger Avramic exponent from the crystallization of SM-P3HT on CFs verifies the formation of 2D P3HT nanocrystals on CFs, and the smaller Avrami exponents from crystallizations of SM-P3HT on SWCNTs and MWCNTs verifies the formation of 1D P3HT nanowires on SWCNTs and MWCNTs. 185 Figure 5-19. The absorbance change at 600nm for SM-P3HT crystallizations on SWCNTs (black line), MWCNTs (red line), and CFs (blue line) graphitic surfaces. Figure 5-20. Attached mass of SM-P3HT on unit area of SWCNTs (black line), MWCNTs (red line), and CFs (blue line) graphitic substrates. Diameters of SWCNTs, MWCNTs and CFs are considered as 1.5 nm, 15 nm and 170 nm in calculations. Crystallized SM-P3HT per unit area through crystallizations process is plotted in Figure 5-20. The calculation method is the same as that for the analysis of crystallized LM-P3HT on graphitic 186 substrates. The mass of crystallized P3HT molecules on unit area of graphitic substrates still has the same trend of CFs>MWCNTs>SWCNTs. However, the difference between crystallized P3HT molecules on CFs and on other two kinds of graphitic substrates becomes more evident, and it is believed to be attributed to the formation of 2D SM-P3HT nanocrystals from the surface of CFs. At last, all crystallization processes are first order reactions after the curve fitting method mentioned in the supplementary materials. From the results of TEM imaging, SM-P3HT molecules form nanowires from the surface of SWCNTs and MWCNTs when its concentration in the marginal solution is 0.05 mg/mL, but they form thin films and nanoribbons, which are 2D structures, from the surface of CFs at such concentration. The availability of forming 2D structures on CFs leads to a higher crystallization rate. Also, the Avrami exponent regarding the crystallization of SM-P3HT on CFs is larger than that of crystallizations of SM-P3HT on SWCNTs and MWCNTs, it suggests the formation of 2D structures from the surface of CFs and the formation of 1D nanowires from the surface of SWCNTs and MWCNTs. Kinetic Study of LM-P3HT and SM-P3HT on Flat Graphene Substrates Kinetic studies regarding the comparison of SM-P3HT and LM-P3HT crystallizations on graphene is monitored by the QCM technique, and crystallization processes are performed by using graphene coated QCM probes. The attached mass of LM-P3HT and SM-P3HT onto unit area of vertically placed QCM probe is recorded by the built-in microbalance and is presented in Figure 5-21. The attached mass of SM-P3HT is higher than that of LM-P3HT throughout the whole range of crystallization time. 25 g/cm2 and 52 g/cm2 of attached P3HT are found after 19 hours of LM-P3HT and SM-P3HT crystallizations,µ respectively.µ In addition, the attached mass of LM- P3HT is almost constant after 6 hours, and the attached mass of SM-P3HT keeps increasing with 187 longer crystallization time. Avrami equation is applied to study the crystallization of P3HT on graphene. The Avrami exponent of P3HT crystallization on graphene is calculated to be 0.81 for LM-P3HT and 1.05 for SM-P3HT. The larger value of Avrami exponent from the crystallization of SM-P3HT on graphene indicates the formation of nanocrystals with higher dimensions, namely the vertically grown 2D nanowalls, from the graphene surface. Figure 5-21. Attached mass of LM-P3HT (black line) and SM-P3HT (red line) on unit area of graphene surface in crystallization processes. Conclusions The crystallization behavior of P3HT molecules on graphitic substrates with different curvatures is investigated. The type of P3HT nanocrystals grown from graphitic substrates is summarized in Table 5-2. LM-P3HT molecules are only able to form nanowires on graphitic substrates, while the formation of nanocrystals from SM-P3HT is relying on both the concentration of marginal solutions and the curvature of graphitic substrates. The crystallization of SM-P3HT on SWCNTs 188 only form nanowires on SWCNTs which have a huge surface curvature. SM-P3HT nanocrystals formed on MWCNTs switch from nanowires to nanoribbons by increasing the concentration of SM-P3HT in marginal solutions. The crystallization of SM-P3HT On CFs which have a small curvature only form nanoribbons. On the surface of graphene with a minimal curvature, vertically grown nanowalls are obtained. Besides, the orientation of nanocrystals differs on graphitic surfaces with different curvatures. Nanowires arrange coaxially on SWCNTs. Nanoribbons formed on MWCNTs have a confined orientation, and random oriented nanoribbons or nanowalls are formed on the surface of CFs and graphene. Studies of crystallization kinetics reveal that the rate of P3HT crystallization on graphitic substrates has a trend of MWCNTs>SWCNTs>CFs, and it results from both the specific surface area and curvature of graphitic substrates. Also, growth rate of SM-P3HT on graphene surface is much faster than that LM-P3HT which is believed from the capability of forming more ordered 2D P3HT nanowalls crystals. Table 5-2. Summary of nano-structures formation on different graphitic substrates from SM-P3HT and LM-P3HT molecules. Asterisks point out the formation of nanocrystals with a confined orientation. Small Mn P3HT Large Mn P3HT Low High Low High Concentration Concentration Concentration Concentration SWCNT Nanowires* Nanowires* Nanowires* MWCNT Nanowires* Nanoribbons* Nanowires* CF Nanoribbons Nanoribbons Nanowires Graphene Nanowalls Nanowalls Nanowires No Substrates Nanowires Nanoribbons Nanowires (In Solution) 189 Supporting Materials Figure 5-22. (a) The TEM image of dispersed SWCNTs. (b) The TEM image of dispersed MWCNTs. (c) The TEM image of CVD graphene transferred on a TEM grid. (d) The SAED pattern of graphene on TEM grids. Figure 5-23. (a, b) TEM images of CFs. (c) The SEM image of CFs. (d) The AFM image of CFs. (e) The height profile of the line is shown in (d). 190 Figure 5-24. SAED patterns of LM-P3HT nanowires crystallized on (a) SWCNTs, (b) SWCNTs, (c) CFs, and (d) graphene. Two sets of six-fold SAED patterns from the graphene substrate are circled in red and blue in (d). Calculation of spacing reflected in the crystal is as follows. The spacing reflected in the real world is the reciprocal of the value get from the SAED image. The spacing in the SAED image should be measured from the center electron beam spot to the desired position. If the center electron beam spot is blocked by the tip, find at least 3 points in diffraction signals from the same plane and generate a circle. The radius of the circle is the spacing in the SAED image, and its reciprocal is the spacing in the real world. For these SAED rings with spacing of 2.52-2.58 in SAED images 1 𝑛𝑛𝑛𝑛 above, their spacing in the real world is 3.88-3.97 Å. So, they reflect the distance between two adjacent P3HT molecules interacted by π-π stacking. In addition, the circled 6-fold SAED patterns from graphene substrates is consistent with a hexagonal lattice and indicates high degree of crystallinity of graphene substrates applied in this crystallization process. 191 Figure 5-25. The AFM image of LM-P3HT crystallized on CFs and the height profiles of two lines labeled as 1-2. The scanning area of AFM imaging is 5 m×2.5 m. µ µ Figure 5-26. UV-Vis spectra during processes of P3HT crystallization (a) SWCNTs, (b) MWCNTs, and (c) CFs. Need to label 2 peaks about loss of free P3HT and gain of crystallized P3HT. 192 Figure 5-27. The TEM image of SM-P3HT crystallized in the dispersion contained MWCNT by rapid cooling. The concentration of MWCNTs and SM-P3HT are 0.005 mg/mL and 0.3 mg/mL, respectively. Figure 5-28. The top view AFM image (2 m×2 m) and the height profiles of 4 lines labeled as 1-4. Line 1 reveals a tilted nanoribbon from CF. Line 2 reveals two nanoribbons parallel to the horizontal plane with the thickness of 105µ nm andµ 10 nm. Line 3 reveals a nanoribbon with the length of 312 nm. Line 4 reveals a nanoribbon grown vertically respect to the horizontal plane with a width of 138 nm. 193 Figure 5-29. The Raman spectrum of graphene surface. Figure 5-30. The Raman spectrum of SM-P3HT powders. Figure 5-31. The Raman spectrum of SM-P3HT crystallized on the graphene surface. 194 Figure 5-32. TEM images of SM-P3HT crystallized on SWCNTs from (a) 0.05 mg/mL, and (b) 0.10 mg/mL marginal solutions. Figure 5-33. The TEM image of SM-P3HT crystallized on MWCNTs to form nanowires from a 0.05 mg/mL marginal solution. Figure 5-34. The TEM image of SM-P3HT crystallized on graphene to form nanowalls composed on nanoribbons from a 0.05 mg/mL marginal solution. 195 Molecular Dynamics (MD) simulation was performed to investigate the interaction between the polymers and CNTs. [94] Three SWCNTs isomers: chiral (9, 0), armchair (8, 8) and zigzag (13, 0), and two types of MWCNTs: (150, 150) and (310, 0) were used to study the interaction between CNTs and the model oligomers. The steepest decent method and the NAMD Molecular Dynamic simulation are chosen to perform the optimization and the Amber Force Field was used in all the calculations. The model oligomers and the CNTs were constructed in VMD and optimized in NAMD. In the simulation, a model oligomer was put in the vicinity of a CNT, and the system energy will be optimized. The internal energy of nanotubes was not considered since it did not contribute to the interaction energy between the oligomer and the CNT. The interaction energy was obtained by subtracting the internal energy of the oligomer from the optimized energy of the oligomer/CNT system. Theoretical simulation was performed to study the orientation of 3- hexylthiophene oligomer with six repeating units on SWCNTs and MWCNTs by examining the interaction between oligomers and CNTs. In the studies, the oligomers were added to the optimized structures of CNTs in the vacuum system. The energy of the system was minimized, and the binding energy between the two parts was calculated. The interaction energy between the oligomers and three types of SWCNTs, and the interaction energy of the oligomers on MWCNTs (310, 0) at three angles were studied. As shown in Figure 5-35, the oligomer attaches along the SWCNTs axis with the alkyl chains wrapping around the tube after the energy minimization. The interaction energy values listed in Table 5-3 suggest that SWCNTs structures have trivial effect on the oligomer orientation on the SWCNTs surfaces. Also, the interaction energy values listed in Table 5-4 indicate the oligomer can take different orientation on the MWCNTs surfaces without causing much energy difference. Such theoretical simulation was in good agreement with our experimental observation of P3HT nanowires and nanoribbon formation on CNTs. 196 A B Figure 5-35. (A) The figure of the optimized attachment of oligo(3-hexylthiophene) on SWCNT (13,0). (B) The attachment of oligo(3-hexylthiophene) on a MWCNT (310,0) at angles of 90o, 0o, and 30o. Table 5-3. The interaction energy of oligo(3-hexylthiophene) on different isomers of SWCNTs. Isomer of SWCNTs Interaction Energy (kcal/mol) Chiral (9,0) -80.35 Armchair (8,8) -81.70 Zigzag (13,0) -80.15 Table 5-4. The interaction energy of oligo(3-hexylthiophene) on MWCNTs with different orientations respect to the axis of MWCNTs. Angle to the Axis of MWCNTs Interaction Energy (kcal/mol) 0o -112.65 30o -111.70 90o -111.51 197 Because hot P3HT/carbon materials dispersions can rapidly cool down to room temperature in ambient atmosphere, P3HT crystallization processes are able to be considered as quasi-isothermal crystallization processes. Derive Equation 5-1 to get Equation 5-3 and Equation 5-4. (1 ) = t (5-3) n 𝑙𝑙𝑙𝑙 − 𝜑𝜑𝑐𝑐 −𝐾𝐾 [ (1 )] = + (5-4) 𝑙𝑙𝑙𝑙 − 𝑙𝑙𝑙𝑙 − 𝜑𝜑𝑐𝑐 𝑙𝑙𝑙𝑙𝑙𝑙 𝑛𝑛𝑛𝑛𝑛𝑛𝑛𝑛 The value of in each trial was calculated by dividing the absorbance change at 600nm to the 𝑐𝑐 original absorbance𝜑𝜑 at 454nm. After that, data from UV-Vis spectra was substituted in Equation 5-4. [ (1 )] versus was plotted for each trial, and a linear correction was conducted. 𝑐𝑐 The value𝑙𝑙𝑙𝑙 − 𝑙𝑙of𝑙𝑙 n, −which𝜑𝜑 is the slope𝑙𝑙𝑙𝑙𝑙𝑙 of corrected line, was got after the linear correction. For the calculation of raction order, the presence of an obvious isosbestic point at around 488 nm in the UV-Vis spectra (Figure 5-26) suggests a direct transformation from dissolved individual polymer chains to ordered nanowires without any intermediate state, [90,91] so = , c is the concentration of isolated P3HT in solutions and x is the concentration of 𝑑𝑑crystallized𝑑𝑑⁄𝑑𝑑𝑑𝑑 − P3HT.𝑑𝑑𝑑𝑑⁄𝑑𝑑𝑑𝑑 As a result, Equation 5-2 can be derived to Equation 5-5 for this crystallization study. = = = (5-5) 𝑑𝑑𝑥𝑥 𝑑𝑑𝑑𝑑 𝑛𝑛 𝑑𝑑𝑑𝑑 𝑑𝑑𝑑𝑑 Besides, the effective area on graphitic𝐺𝐺 carbon materials− 𝑘𝑘 for𝑐𝑐 P3HT crystallizations is reasonable to be considered as a constant during crystallization processes. It is because the area stacked with P3HT by - interactions is still effective for further P3HT stackings. Therefore, the concentration of individuaLMπ π -P3HT molecules is the only variable in crystallization processes. Equation 5-5 was derived to Equation 5-6 by considering the starting condition as = , = 0. Equation 5-5 𝑐𝑐 𝑐𝑐0 𝑡𝑡 198 was integrated to get Equation 5-7 and Equation 5-8. Values of absorbance at 454nm were extracted to get curves of crystallinity ( ) versus crystallization time ( ). Then, values of , , and 0 were substituted into Equation 5-7 and𝑐𝑐 5-8 to find out integral with𝑡𝑡 the best fitting,𝑐𝑐 and𝑐𝑐 the value𝑡𝑡 of n turned out to be 1 for all three trials. First order reactions𝑛𝑛 for these crystallization processes are revealed after data processing mentioned above. = (5-6) 𝑐𝑐𝑡𝑡 1 𝑡𝑡 𝑛𝑛 ∫𝑐𝑐0 𝑐𝑐 𝑑𝑑𝑑𝑑 ∫0 −𝑘𝑘 𝑑𝑑𝑑𝑑 = + ( 1) ( 1) (5-7) 1 1 𝑛𝑛−1 𝑛𝑛−1 𝑐𝑐𝑡𝑡 𝑐𝑐0 𝑛𝑛 − 𝑘𝑘𝑘𝑘 𝑛𝑛 ≠ = ( = 1) (5-8) 𝑙𝑙𝑙𝑙 𝑐𝑐𝑡𝑡 𝑙𝑙𝑙𝑙 𝑐𝑐0 − 𝑘𝑘𝑘𝑘 𝑛𝑛 References 1. Forrest, S.R. The path to ubiquitous and low-cost organic electronic appliances on plastic. Nature 2004, 428, 911-918. 2. Arias, A.C.; MacKenzie, J.D.; McCulloch, I.; Rivnay, J.; Salleo, A. Materials and applications for large area electronics: Solution-based approaches. Chemical Reviews 2010, 110, 3-24. 3. Yan, H.; Chen, Z.; Zheng, Y.; Newman, C.; Quinn, J.R.; Dotz, F.; Kastler, M.; Facchetti, A. A high-mobility electron-transporting polymer for printed transistors. Nature 2009, 457, 679-686. 4. Katz, H.E.; Bao, Z.N.; Gilat, S.L. Synthetic chemistry for ultrapure, processable, and high- mobility organic transistor semiconductors. Accounts of Chemical Research 2001, 34, 359- 369. 199 5. Bao, Z.; Dodabalapur, A.; Lovinger, A.J. Soluble and processable regioregular poly(3- hexylthiophene) for thin film field-effect transistor applications with high mobility. Applied Physics Letters 1996, 69, 4108-4110. 6. Salleo, A.; Chabinyc, M.L.; Yang, M.S.; Street, R.A. Polymer thin-film transistors with chemically modified dielectric interfaces. Applied Physics Letters 2002, 81, 4383-4385. 7. Sirringhaus, H.; Wilson, R.J.; Friend, R.H.; Inbasekaran, M.; Wu, W.; Woo, E.P.; Grell, M.; Bradley, D.D.C. Mobility enhancement in conjugated polymer field-effect transistors through chain alignment in a liquid-crystalline phase. Applied Physics Letters 2000, 77, 406-408. 8. Sirringhaus, H.; Brown, P.J.; Friend, R.H.; Nielsen, M.M.; Bechgaard, K.; Langeveld-Voss, B.M.W.; Spiering, A.J.H.; Janssen, R.A.J.; Meijer, E.W.; Herwig, P., et al. Two- dimensional charge transport in self-organized, high-mobility conjugated polymers. Nature 1999, 401, 685-688. 9. Fabiano, S.; Musumeci, C.; Chen, Z.; Scandurra, A.; Wang, H.; Loo, Y.-L.; Facchetti, A.; Pignataro, B. From monolayer to multilayer n-channel polymeric field-effect transistors with precise conformational order. Advanced Materials 2012, 24, 951-956. 10. Osaka, I.; Zhang, R.; Sauve, G.; Smilgies, D.-M.; Kowalewski, T.; McCullough, R.D. High-lamellar ordering and amorphous-like pi-network in short-chain thiazolothiazole- thiophene copolymers lead to high mobilities. Journal of the American Chemical Society 2009, 131, 2521-2529. 11. Tsao, H.N.; Mullen, K. Improving polymer transistor performance via morphology control. Chemical Society Reviews 2010, 39, 2372-2386. 200 12. Zotti, G.; Vercelli, B.; Berlin, A. Monolayers and multilayers of conjugated polymers as nanosized electronic components. Accounts of Chemical Research 2008, 41, 1098-1109. 13. Lafferentz, L.; Ample, F.; Yu, H.; Hecht, S.; Joachim, C.; Grill, L. Conductance of a single conjugated polymer as a continuous function of its length. Science 2009, 323, 1193-1197. 14. Leroux, Y.R.; Lacroix, J.C.; Chane-Ching, K.I.; Fave, C.; Felidj, N.; Levi, G.; Aubard, J.; Krenn, J.R.; Hohenau, A. Conducting polymer electrochemical switching as an easy means for designing active plasmonic devices. J. Am. Chem. Soc. 2005, 127, 16022-16023. 15. Thompson, B.C.; Frechet, J.M.J. Organic photovoltaics - polymer-fullerene composite solar cells. Angewandte Chemie-International Edition 2008, 47, 58-77. 16. Chen, H.-Y.; Hou, J.; Zhang, S.; Liang, Y.; Yang, G.; Yang, Y.; Yu, L.; Wu, Y.; Li, G. Polymer solar cells with enhanced open-circuit voltage and efficiency. Nature Photonics 2009, 3, 649-653. 17. Mondal, R.; Becerril, H.A.; Verploegen, E.; Kim, D.; Norton, J.E.; Ko, S.; Miyaki, N.; Lee, S.; Toney, M.F.; Bredas, J.-L., et al. Thiophene-rich fused-aromatic thienopyrazine acceptor for donor-acceptor low band-gap polymers for otft and polymer solar cell applications. Journal of Materials Chemistry 2010, 20, 5823-5834. 18. Price, S.C.; Stuart, A.C.; You, W. Polycyclic aromatics with flanking thiophenes: Tuning energy level and band gap of conjugated polymers for bulk heterojunction photovoltaics. Macromolecules 2010, 43, 797-804. 19. Price, S.C.; Stuart, A.C.; You, W. Low band gap polymers based on benzo 1,2-b:4,5-b ' dithiophene: Rational design of polymers leads to high photovoltaic performance. Macromolecules 2010, 43, 4609-4612. 201 20. Huo, L.; Hou, J.; Zhang, S.; Chen, H.-Y.; Yang, Y. A polybenzo 1,2-b:4,5-b ' dithiophene derivative with deep homo level and its application in high-performance polymer solar cells. Angewandte Chemie-International Edition 2010, 49, 1500-1503. 21. Bundgaard, E.; Hagemann, O.; Manceau, M.; Jorgensen, M.; Krebs, F.C. Low band gap polymers for roll-to-roll coated polymer solar cells. Macromolecules 2010, 43, 8115-8120. 22. Liang, Y.; Wu, Y.; Feng, D.; Tsai, S.-T.; Son, H.-J.; Li, G.; Yu, L. Development of new semiconducting polymers for high performance solar cells. Journal of the American Chemical Society 2009, 131, 56-57 23. Yao, Y.; Hou, J.; Xu, Z.; Li, G.; Yang, Y. Effect of solvent mixture on the nanoscale phase separation in polymer solar cells. Advanced Functional Materials 2008, 18, 1783-1789. 24. Lee, J.K.; Ma, W.L.; Brabec, C.J.; Yuen, J.; Moon, J.S.; Kim, J.Y.; Lee, K.; Bazan, G.C.; Heeger, A.J. Processing additives for improved efficiency from bulk heterojunction solar cells. Journal of the American Chemical Society 2008, 130, 3619-3623. 25. Sivula, K.; Ball, Z.T.; Watanabe, N.; Frechet, J.M.J. Amphiphilic diblock copolymer compatibilizers and their effect on the morphology and performance of polythiophene: Fullerene solar cells. Advanced Materials 2006, 18, 206-210. 26. Parnell, A.J.; Dunbar, A.D.F.; Pearson, A.J.; Staniec, P.A.; Dennison, A.J.C.; Hamamatsu, H.; Skoda, M.W.A.; Lidzey, D.G.; Jones, R.A.L. Depletion of pcbm at the cathode interface in p3ht/pcbm thin films as quantified via neutron reflectivity measurements. Advanced Materials 2010, 22, 2444-2447. 27. Zhokhavets, U.; Erb, T.; Hoppe, H.; Gobsch, G.; Sariciftci, N.S. Effect of annealing of poly(3-hexylthiophene)/fullerene bulk heterojunction composites on structural and optical properties. Thin Solid Films 2006, 496, 679-682. 202 28. Ma, W.L.; Yang, C.Y.; Gong, X.; Lee, K.; Heeger, A.J. Thermally stable, efficient polymer solar cells with nanoscale control of the interpenetrating network morphology. Advanced Functional Materials 2005, 15, 1617-1622. 29. Padinger, F.; Rittberger, R.S.; Sariciftci, N.S. Effects of postproduction treatment on plastic solar cells. Advanced Functional Materials 2003, 13, 85-88. 30. Yang, Y.; Mielczarek, K.; Aryal, M.; Zakhidov, A.; Hu, W. Nanoimprinted polymer solar cell. ACS Nano 2012, 6, 2877-2892. 31. Zhang, R.; Li, B.; Iovu, M.C.; Jeffries-El, M.; Sauvé, G.; Cooper, J.; Jia, S.; Tristram-Nagle, S.; Smilgies, D.M.; Lambeth, D.N., et al. Nanostructure dependence of field-effect mobility in regioregular poly(3-hexylthiophene) thin film field effect transistors. Journal of the American Chemical Society 2006, 128, 3480-3481. 32. Noriega, R.; Rivnay, J.; Vandewal, K.; Koch, F.P.V.; Stingelin, N.; Smith, P.; Toney, M.F.; Salleo, A. A general relationship between disorder, aggregation and charge transport in conjugated polymers. Nat Mater 2013, 12, 1037-1043. 33. Sarker, B.K.; Liu, J.; Zhai, L.; Khondaker, S.I. Fabrication of organic field effect transistor by directly grown poly(3 hexylthiophene) crystalline nanowires on carbon nanotube aligned array electrode. Acs Applied Materials & Interfaces 2011, 3, 1180-1185. 34. Liu, J.; Arif, M.; Zou, J.; Khondaker, S.I.; Zhai, L. Controlling poly(3-hexylthiophene) crystal dimension: Nanowhiskers and nanoribbons. Macromolecules 2009, 42, 9390-9393. 35. Chunder, A.; Liu, J.; Zhai, L. Reduced graphene oxide/poly(3-hexylthiophene) supramolecular composites. Macromolecular Rapid Communications 2010, 31, 380-384. 36. Arif, M.; Liu, J.; Zhai, L.; Khondaker, S.I. Poly(3-hexylthiophene) crystalline nanoribbon network for organic field effect transistors. Applied Physics Letters 2010, 96, 243304. 203 37. Sarker, B.K.; Liu, J.; Zhai, L.; Khondaker, S.I. Fabrication of organic field effect transistor by directly grown poly(3 hexylthiophene) crystalline nanowires on carbon nanotube aligned array electrode. Acs Applied Materials & Interfaces 2011, 3, 1180-1185. 38. Liu, J.; Mikhaylov, I.A.; Zou, J.; Osaka, I.; Masunov, A.E.; McCullough, R.D.; Zhai, L. Insight into how molecular structures of thiophene-based conjugated polymers affect crystallization behaviors. Polymer 2011, 52, 2302-2309. 39. Zhai, L.; Khondaker, S.I.; Thomas, J.; Shen, C.; McInnis, M. Ordered conjugated polymer nano- and microstructures: Structure control for improved performance of organic electronics. Nano Today 2014, 9, 705-721. 40. Liu, J.; Zou, J.; Zhai, L. Bottom-up assembly of poly(3-hexylthiophene) on carbon nanotubes: 2d building blocks for nanoscale circuits. Macromolecular Rapid Communications 2009, 30, 1387-1391. 41. Oh, J.Y.; Shin, M.; Lee, T.I.; Jang, W.S.; Min, Y.; Myoung, J.-M.; Baik, H.K.; Jeong, U. Self-seeded growth of poly(3-hexylthiophene) (p3ht) nanofibrils by a cycle of cooling and heating in solutions. Macromolecules 2012, 45, 7504-7513. 42. Keum, J.K.; Xiao, K.; Ivanov, I.N.; Hong, K.; Browning, J.F.; Smith, G.S.; Shao, M.; Littrell, K.C.; Rondinone, A.J.; Andrew Payzant, E., et al. Solvent quality-induced nucleation and growth of parallelepiped nanorods in dilute poly(3-hexylthiophene) (p3ht) solution and the impact on the crystalline morphology of solution-cast thin film. CrystEngComm 2013, 15, 1114-1124. 43. Poelking, C.; Andrienko, D. Effect of polymorphism, regioregularity and paracrystallinity on charge transport in poly(3-hexylthiophene) [p3ht] nanofibers. Macromolecules 2013, 46, 8941-8956. 204 44. Mazzio, K.A.; Rice, A.H.; Durban, M.M.; Luscombe, C.K. Effect of regioregularity on charge transport and structural and excitonic coherence in poly(3-hexylthiophene) nanowires. J. Phys. Chem. C 2015, 119, 14911-14918. 45. McFarland, F.M.; Ellis, C.M.; Guo, S. The aggregation of poly(3-hexylthiophene) into nanowires: With and without chemical doping. J. Phys. Chem. C 2017, 121, 4740-4746. 46. Yagmurcukardes, M.; Kiymaz, D.; Zafer, C.; Senger, R.T.; Sahin, H. Atomic-scale understanding of dichlorobenzene-assisted poly 3-hexylthiophene-2,5-diyl nanowire formation mechanism. Journal of Molecular Structure 2017, 1134, 681-686. 47. Persson, N.E.; Chu, P.-H.; McBride, M.; Grover, M.; Reichmanis, E. Nucleation, growth, and alignment of poly(3-hexylthiophene) nanofibers for high-performance ofets. Accounts of Chemical Research 2017, 50, 932-942. 48. Giulianini, M.; Waclawik, E.R.; Bell, J.M.; Scarselli, M.; Castrucci, P.; Crescenzi, M.D.; Motta, N. Microscopic and spectroscopic investigation of poly(3-hexylthiophene) interaction with carbon nanotubes. Polymers 2011, 134, 3691-3696.. 49. Acevedo-Cartagena, D.E.; Zhu, J.; Trabanino, E.; Pentzer, E.; Emrick, T.; Nonnenmann, S.S.; Briseno, A.L.; Hayward, R.C. Selective nucleation of poly(3-hexyl thiophene) nanofibers on multilayer graphene substrates. ACS Macro Letters 2015, 4, 483-487. 50. Liscio, A.; Veronese, G.P.; Treossi, E.; Suriano, F.; Rossella, F.; Bellani, V.; Rizzoli, R.; Samori, P.; Palermo, V. Charge transport in graphene-polythiophene blends as studied by kelvin probe force microscopy and transistor characterization. Journal of Materials Chemistry 2011, 21, 2924-2931. 205 51. Meng, D.; Sun, J.; Jiang, S.; Zeng, Y.; Li, Y.; Yan, S.; Geng, J.; Huang, Y. Grafting p3ht brushes on go sheets: Distinctive properties of the go/p3ht composites due to different grafting approaches. Journal of Materials Chemistry 2012, 22, 21583-21591. 52. Liu, S.; Ma, X.; Wang, B.; Shang, X.; Wang, W.; Yu, X. Nanostructure-dependent interfacial interactions between poly(3-hexylthiophene) and graphene oxide. Macromolecules (Washington, DC, U. S.) 2015, 48, 5791-5798. 53. Skrypnychuk, V.; Boulanger, N.; Yu, V.; Hilke, M.; Mannsfeld, S.C.B.; Toney, M.F.; Barbero, D.R. Enhanced vertical charge transport in a semiconducting p3ht thin film on single layer graphene. Advanced Functional Materials 2015, 25, 664-670. 54. Liu, S.; Ma, X.; Wang, B.; Shang, X.; Wang, W.; Yu, X. Investigation the effect of thermal annealing on p3ht nanofibers by scanning probe microscopy: From single chain conformation, self-assembly to interfacial interactions with go. ChemPhysChem 2016, 32, 2183-2191. 55. Bu, L.; Dawson, T.J.; Hayward, R.C. Tailoring ultrasound-induced growth of perylene diimide nanowire crystals from solution by modification with poly(3-hexyl thiophene). ACS Nano 2015, 9, 1878-1885. 56. Rosu, C.; Chu, P.-H.; Tassone, C.J.; Park, K.; Balding, P.L.; Park, J.O.; Srinivasarao, M.; Reichmanis, E. Polypeptide composite particle-assisted organization of π-conjugated polymers into highly crystalline “coffee stains”. Acs Applied Materials & Interfaces 2017, 9, 34337-34348. 57. Kim, F.S.; Ren, G.; Jenekhe, S.A. One-dimensional nanostructures of π-conjugated molecular systems: Assembly, properties, and applications from photovoltaics, sensors, and nanophotonics to nanoelectronics†. Chemistry of Materials 2011, 23, 682-732. 206 58. Yang, H.C.; Shin, T.J.; Yang, L.; Cho, K.; Ryu, C.Y.; Bao, Z.N. Effect of mesoscale crystalline structure on the field-effect mobility of regioregular poly(3-hexyl thiophene) in thin-film transistors. Advanced Functional Materials 2005, 15, 671-676. 59. Merlo, J.A.; Frisbie, C.D. Field effect transport and trapping in regioregular polythiophene nanofibers. The Journal of Physical Chemistry B 2004, 108, 19169-19179. 60. Na, J.Y.; Kim, M.; Park, Y.D. Solution processing with a good solvent additive for highly reliable organic thin-film transistors. The Journal of Physical Chemistry C 2017, 121, 13930-13937. 61. Tang, H.; Hessel, C.M.; Wang, J.; Yang, N.; Yu, R.; Zhao, H.; Wang, D. Two-dimensional carbon leading to new photoconversion processes. Chemical Society Reviews 2014, 43, 4281-4299. 62. Aguirre, C.M.; Ternon, C.; Paillet, M.; Desjardins, P.; Martel, R. Carbon nanotubes as injection electrodes for organic thin film transistors. Nano Letters 2009, 9, 1457-1461. 63. Kang, N.; Sarker, B.K.; Khondaker, S.I. The effect of carbon nanotube/organic semiconductor interfacial area on the performance of organic transistors. Applied Physics Letters 2012, 101, 233302. 64. Sarker, B.K.; Khondaker, S.I. Thermionic emission and tunneling at carbon nanotube– organic semiconductor interface. ACS Nano 2012, 6, 4993-4999. 65. Sarker, B.K.; Khondaker, S.I. High-performance short channel organic transistors using densely aligned carbon nanotube array electrodes. Applied Physics Letters 2012, 100, 023301-023319. 207 66. Hellstrom, S.L.; Jin, R.Z.; Stoltenberg, R.M.; Bao, Z. Driving high-performance n- and p- type organic transistors with carbon nanotube/conjugated polymer composite electrodes patterned directly from solution. Adv. Mater. (Weinheim, Ger.) 2010, 22, 4204-4208. 67. Lee, C.; Wei, X.; Kysar, J.W.; Hone, J. Measurement of the elastic properties and intrinsic strength of monolayer graphene. Science 2008, 321, 385-388. 68. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Katsnelson, M.I.; Grigorieva, I.V.; Dubonos, S.V.; Firsov, A.A. Two-dimensional gas of massless dirac fermions in graphene. Nature 2005, 438, 197-200. 69. Novoselov, K.S.; Geim, A.K.; Morozov, S.V.; Jiang, D.; Zhang, Y.; Dubonos, S.V.; Grigorieva, I.V.; Firsov, A.A. Electric field effect in atomically thin carbon films. Science 2004, 306, 666-669. 70. Novoselov, K.S.; Jiang, Z.; Zhang, Y.; Morozov, S.V.; Stormer, H.L.; Zeitler, U.; Maan, J.C.; Boebinger, G.S.; Kim, P.; Geim, A.K. Room-temperature quantum hall effect in graphene. Science 2007, 315, 1379. 71. Slonczewski, J.C.; Weiss, P.R. Band structure of graphite. Physical Review 1958, 109, 272- 279. 72. Zhang, Y.; Tan, Y.-W.; Stormer, H.L.; Kim, P. Experimental observation of the quantum hall effect and berry's phase in graphene. Nature 2005, 438, 201-204. 73. Iovu, M.C.; Jeffries-El, M.; Sheina, E.E.; Cooper, J.R.; McCullough, R.D. Regioregular poly(3-alkylthiophene) conducting block copolymers. Polymer 2005, 46, 8582-8586. 74. Kim, K.S.; Zhao, Y.; Jang, H.; Lee, S.Y.; Kim, J.M.; Kim, K.S.; Ahn, J.-H.; Kim, P.; Choi, J.-Y.; Hong, B.H. Large-scale pattern growth of graphene films for stretchable transparent electrodes. Nature 2009, 457, 706-710. 208 75. Jiang, T.; Wang, Y.; Wang, Y.; Orlovskaya, N.; An, L. Quantitative raman analysis of free carbon in polymer-derived ceramics. Journal of the American Ceramic Society 2009, 92, 2455-2458. 76. Reina, A.; Jia, X.; Ho, J.; Nezich, D.; Son, H.; Bulovic, V.; Dresselhaus, M.S.; Kong, J. Large area, few-layer graphene films on arbitrary substrates by chemical vapor deposition. Nano Letters 2009, 9, 30-35. 77. Liu, J.; Moo-Young, J.; McInnis, M.; Pasquinelli, M.A.; Zhai, L. Conjugated polymer assemblies on carbon nanotubes. Macromolecules 2014, 47, 705-712. 78. Meng, D.; Sun, J.; Jiang, S.; Zeng, Y.; Li, Y.; Yan, S.; Geng, J.; Huang, Y. Grafting p3ht brushes on go sheets: Distinctive properties of the go/p3ht composites due to different grafting approaches. Journal of Materials Chemistry 2012, 22, 21583-21591. 79. Tsoi, W.C.; James, D.T.; Kim, J.S.; Nicholson, P.G.; Murphy, C.E.; Bradley, D.D.C.; Nelson, J.; Kim, J.-S. The nature of in-plane skeleton raman modes of p3ht and their correlation to the degree of molecular order in p3ht:Pcbm blend thin films. Journal of the American Chemical Society 2011, 133, 9834-9843. 80. Gao, Y.; Grey, J.K. Resonance chemical imaging of polythiophene/fullerene photovoltaic thin films: Mapping morphology-dependent aggregated and unaggregated c═c species. Journal of the American Chemical Society 2009, 131, 9654-9662. 81. Yacoby, Y.; Ehrenfreund, E. Resonant raman scattering in conjugated polymers. In Light scattering in solids vi: Recent results, including high- tc superconductivity, Cardona, M.; Güntherodt, G., Eds. Springer Berlin Heidelberg: Berlin, Heidelberg, 1991, 6, 73-135. 82. Khlaifia, D.; Ewels, C.P.; Massuyeau, F.; Chemek, M.; Faulques, E.; Duvail, J.-L.; Alimi, K. Unraveling the real structures of solution-based and surface-bound poly(3- 209 hexylthiophene) (p3ht) oligomers: A combined theoretical and experimental study. RSC Advances 2016, 6, 56174-56182. 83. Wilson, N.R.; Pandey, P.A.; Beanland, R.; Young, R.J.; Kinloch, I.A.; Gong, L.; Liu, Z.; Suenaga, K.; Rourke, J.P.; York, S.J., et al. Graphene oxide: Structural analysis and application as a highly transparent support for electron microscopy. ACS Nano 2009, 3, 2547-2556. 84. Liao, Z.; Medrano Sandonas, L.; Zhang, T.; Gall, M.; Dianat, A.; Gutierrez, R.; Mühle, U.; Gluch, J.; Jordan, R.; Cuniberti, G., et al. In-situ stretching patterned graphene nanoribbons in the transmission electron microscope. Scientific Reports 2017, 7, 211-224. 85. Li, J.; Wang, X.-Y.; Liu, X.-R.; Jin, Z.; Wang, D.; Wan, L.-J. Facile growth of centimeter- sized single-crystal graphene on copper foil at atmospheric pressure. Journal of Materials Chemistry C 2015, 3, 3530-3535. 86. Chen, K.; Song, S.; Xue, D. Beyond graphene: Materials chemistry toward high performance inorganic functional materials. Journal of Materials Chemistry A 2015, 3, 2441-2453. 87. Ferrari, A.C. Raman spectroscopy of graphene and graphite: Disorder, electron–phonon coupling, doping and nonadiabatic effects. Solid State Communications 2007, 143, 47-57. 88. Zheng, X.; Chen, W.; Wang, G.; Yu, Y.; Qin, S.; Fang, J.; Wang, F.; Zhang, X.-A. The raman redshift of graphene impacted by gold nanoparticles. AIP Advances 2015, 5, 057133-057146. 89. Yamamoto, T.; Komarudin, D.; Arai, M.; Lee, B.-L.; Suganuma, H.; Asakawa, N.; Inoue, Y.; Kubota, K.; Sasaki, S.; Fukuda, T., et al. Extensive studies on π-stacking of poly(3- alkylthiophene-2,5-diyl)s and poly(4-alkylthiazole-2,5-diyl)s by optical spectroscopy, nmr 210 analysis, light scattering analysis, and x-ray crystallography. Journal of the American Chemical Society 1998, 120, 2047-2058. 90. Mårdalen, J.; Samuelsen, E.J.; Pedersen, A.Ø. The nucleation process and the crystalline structure of poly(3-alkylthiophenes) precipitated from marginal solvents. Synthetic Metals 1993, 55, 378-383. 91. Berson, S.; De Bettignies, R.; Bailly, S.; Guillerez, S. Poly(3-hexylthiophene) fibers for photovoltaic applications. Advanced Functional Materials 2007, 17, 1377-1384. 92. Decker, C.; Jenkins, A.D. Kinetic approach of oxygen inhibition in ultraviolet- and laser- induced polymerizations. Macromolecules 1985, 18, 1241-1244. 93. Ding, N.; Amis, E.J. Kinetics of poly(ethylene oxide) crystallization from solution: Temperature and molecular weight dependence. Macromolecules 1991, 24, 3906-3914. 94. Liu, Y.; Chipot, C.; Shao, X.; Cai, W. Solubilizing carbon nanotubes through noncovalent functionalization. Insight from the reversible wrapping of alginic acid around a single- walled carbon nanotube. The Journal of Physical Chemistry B 2010, 114, 5783-5789. 211 CHAPTER 6: CONCLUSIONS AND FUTURE WORK This dissertation focuses on graphene induced nanostructures in composites. Graphene aerogels with large surface area are great substrates for the decoration of metallic nanoparticles. Embedded graphene aerogels and EFGO in PDC composites dramatically increase the electrical conductivity of composites and induce the crystallization of graphitic domains in the area nearby the embedded graphitic materials. Graphitic surfaces can guide the formation of highly ordered one dimensional (nanowires) or two dimensional (nanoribbons and nanowalls) P3HT nanocrystals on these substrates. Conclusions of each chapter and the prospective work of each project are summarized as below. Conclusions In chapter 2, rGO aerogels loaded with four kinds of metallic nanoparticles were successfully prepared with excellent directionality and decent hieratical structures. The loading of 59 wt%, 67 wt%, 39 wt% and 46 wt% of metallic palladium, platinum, nickel, and tin in rGO/metal aerogels were achieved after hydrogen reduction at elevated temperatures. It is believed that other kind of metallic nanoparticles can also be loaded onto rGO aerogels with similar procedures. A hydrogel gas sensor was produced using Pd nanoparticle loaded rGO aerogels. The large surface area and porous structure of rGO aerogel offer high sensitivity and fast response/recovery time of the sensor. The metal nanoparticles decorated aerogels which have open-pores structure and large surface area are promising platforms for numerous applications, including energy storage, gas sensing and catalysts of vapor phase reactions. 212 In chapter 3, Bulk SiCN ceramics embedded with anisotropic graphene aerogels have been fabricated through filling anisotropic graphene aerogels with a polymer precursor of SiCN ceramics (oligosilazane), followed by crosslinking and pyrolysis. The electrical conductivity of SiCN/rGOA composites increases from 10-7 S/m to about 157 S/m by embedding 1 wt% of anisotropic rGOA in SiCN ceramics. The electrical conductivity in longitudinal direction is ten times higher than that in transversal direction due to the aligned graphene. It is interesting to discover that graphene also facilitates the formation of graphitic domains in ceramics. Graphene embedded in ceramic precursors lowers the transition temperature of amorphous carbons to graphene nanocrystals. These results suggest that anisotropic graphene structures have great potential in creating anisotropic properties in PDCs. In chapter 4, EFGO embedded PDC composites are successfully fabricated. SiOC polymeric precursor is infiltrated into EFGO attached PVA foams, and it is then cured and pyrolyzed to form composites. This facile method is suitable to prepare composites with different shapes because only the shaping of PVA foams is desirable. The introduction of EFGO networks greatly increases the electrical conductivity of PDC based composites, and it results from (1) the effective pathways for the transport of electrons provided by embedded EFGO networks, and (2) the induced formation of conductive graphitic domains in PDC matrix nearby embedded EFGO networks. By only applying less than 2 wt% of EFGO, the electrical conductivity of composites is 0.95 S/cm at 25 oC and 1.8 S/cm at 600 oC. The times of electrical conductivity increment of PDC composites from room temperature to 600 oC is much lower than that of pyrolyzed SiOC polymeric precursor due to the percolation of embedded EFGO networks. Also, the increment of electrical conductivity from room temperature to 600 oC decreases when PDC composites are pyrolyzed at higher 213 temperatures. More abundant graphitic domains in SiOC matrix after pyrolysis performed at higher temperatures lead to smaller energy needed for the transport of electrons from SiOC matrix to EFGO networks, and the increment of electrical conductivity thus decreases based on the classic equation of semi-conductor electrical conductivity. Furthermore, the thermal conductivity of pyrolyzed PDC composites almost keeps the same at different testing temperatures and is quite low (<1 W∙m-1∙K-1). Such thermally stable materials with high electrical conductivity and low thermal conductivity have great potentials in applications such as thermal insulator, energy sources, and high temperature sensors. In chapter 5, The crystallization behavior of P3HT molecules on graphitic substrates with different curvatures is investigated. LM-P3HT molecules are only able to form nanowires on graphitic substrates, while the formation of nanocrystals from SM-P3HT is relying on both the concentration of marginal solutions and the curvature of graphitic substrates. The crystallization of SM-P3HT on SWCNTs only form nanowires because of the huge curvature of SWCNTs surface. SM-P3HT nanocrystals formed on MWCNTs switch from nanowires to nanoribbons by increasing the concentration of SM-P3HT in marginal solutions. The crystallization of SM-P3HT on CFs which have a small curvature only form nanoribbons. On the surface of graphene, which has a minimal curvature, vertically grown P3HT nanowalls are obtained. Besides, the orientation of nanocrystals differs on graphitic surfaces with different curvatures. Nanowires arrange coaxially on SWCNTs. Nanoribbons formed on MWCNTs have a confined orientation, and random oriented nanoribbons or nanowalls are formed on the surface of CFs and graphene. Studies of crystallization kinetics reveal that the rate of LM-P3HT crystallization on CNTs has a trend of MWCNTs>SWCNTs>CFs, and it results from both the specific surface area and curvature of graphitic substrates. Besides, the 214 growth rate of SM-P3HT on graphene surface is much faster than that of LM-P3HT which is believed due to the capability of forming more ordered 2D P3HT nanowalls crystals from SM- P3HT molecules. Future Work For graphene embedded PDC composites, the mechanism of graphene induced formation of graphitic domains needs more experiments to explore. In-situ TEM is a good candidate for this study. [1] The electrical conductivity of graphene embedded PDC composites at temperature higher than 600 oC and lower than room temperature needs to be systematically investigated to better understand the charge transport mechanism in PDCs in a wider temperature range. Also, the thermal conductivity of PDC composites needs to be systematically studied to find out its trend of change at a wide range of temperature to guide the designing for thermo-electrics. For graphitic surface guided crystallization of P3HT, more experiments such as small angel X-ray scattering (SAXS), [2-4] grazing incidence X-ray diffraction (GIXRD) [5,6] need to be done to further verify the vertical growth of P3HT on graphene. High resolution TEM or scanning tunneling microscopy (STM) needs to be done to reveal the arrangements of P3HT molecules in nanocrystals. Also, techniques like conductive AFM [7,8] and Kevin Probe force microscope (KPFM) [9] need to be performed to further study the electrical conductivity and work function of P3HT in nanocrystals. Thus, the electrical properties to the behavior of P3HT arrangements can be more closely related. 215 References 1. Boston, R.; Schnepp, Z.; Nemoto, Y.; Sakka, Y.; Hall, S.R. In situ tem observation of a microcrucible mechanism of nanowire growth. Science 2014, 344, 623. 2. Parnell, A.J.; Cadby, A.J.; Mykhaylyk, O.O.; Dunbar, A.D.F.; Hopkinson, P.E.; Donald, A.M.; Jones, R.A.L. Nanoscale phase separation of p3ht pcbm thick films as measured by small-angle x-ray scattering. Macromolecules 2011, 44, 6503-6508. 3. Huang, Y.-C.; Tsao, C.-S.; Chuang, C.-M.; Lee, C.-H.; Hsu, F.-H.; Cha, H.-C.; Chen, C.- Y.; Lin, T.-H.; Su, C.-J.; Jeng, U.S., et al. Small- and wide-angle x-ray scattering characterization of bulk heterojunction polymer solar cells with different fullerene derivatives. The Journal of Physical Chemistry C 2012, 116, 10238-10244. 4. Vegso, K.; Siffalovic, P.; Jergel, M.; Nadazdy, P.; Nadazdy, V.; Majkova, E. Kinetics of polymer–fullerene phase separation during solvent annealing studied by table-top x-ray scattering. ACS Applied Materials & Interfaces 2017, 9, 8241-8247. 5. Cataldi, P.; Bayer, I.S.; Cingolani, R.; Marras, S.; Chellali, R.; Athanassiou, A. A thermochromic superhydrophobic surface. Scientific Reports 2016, 6, 27984. 6. Heumueller, T.; Mateker, W.R.; Distler, A.; Fritze, U.F.; Cheacharoen, R.; Nguyen, W.H.; Biele, M.; Salvador, M.; von Delius, M.; Egelhaaf, H.-J., et al. Morphological and electrical control of fullerene dimerization determines organic photovoltaic stability. Energy & Environmental Science 2016, 9, 247-256. 7. Kamkar, D.A.; Wang, M.; Wudl, F.; Nguyen, T.-Q. Single nanowire opv properties of a fullerene-capped p3ht dyad investigated using conductive and photoconductive afm. ACS Nano 2012, 6, 1149-1157. 216 8. Reid, O.G.; Munechika, K.; Ginger, D.S. Space charge limited current measurements on conjugated polymer films using conductive atomic force microscopy. Nano Letters 2008, 8, 1602-1609. 9. Baghgar, M.; Barnes, M.D. Work function modification in p3ht h/j aggregate nanostructures revealed by kelvin probe force microscopy and photoluminescence imaging. ACS Nano 2015, 9, 7105-7112. 217 APPENDIX A: LIST OF PUBLICATIONS 218 1. Lei Zhai, Saiful I. Khondaker, Jayan Thomas, Chen Shen, Matthew McInnis, Ordered Conjugated Polymer Nano- and Microstructures: Structure Control for Improved Performance of Organic Electronics, Nano Today 2014, 9(6), 705-721. 2. Limin Guo, Kun liang, Kyle Marcus, Zhao Li, Prabhu Doss Mani, Hao Chen, Chen Shen, Yajie Dong, Lei Zhai, Kevin R. Coffey, Nina Orlovskaya, Yong-Ho Sohn, Yang Yang, Enhanced Photoelectrocatalytic Reduction of Oxygen Using Au@TiO2 Plasmonic Film, ACS Applied Materials & Interfaces 2016, 8(51), 34970–34977. 3. Chen Shen, Elizabeth Barrios, Matthew McInnis, Joseph Zuyus, Lei Zhai, Fabrication of Graphene Aerogels with Heavily Loaded Metallic Nanoparticles, Micromachines 2017, 8(2), 47-56. 4. Chen Shen, Jean Calderon, Elizabeth Barrios, Mikhael Soliman, Ali Khater, Aadithya Jeyaranjan, Laurene Tetard, Ali Gordon, Sudipta Seal, Lei Zhai, Anisotropic Electrical Conductivity in Polymer Derived Ceramics Induced by Graphene Aerogels, Journal of Materials Chemistry C 2017, 45(5), 11708-11716. 5. Xiaoyan Lu, Chen Shen, Zeyang Zhang, Elizabeth Barrios, Lei Zhai, Core-Shell Composite Fibers for High Performance Flexible Supercapacitor Electodes, ACS Applied Materials & Interfaces 2018, (published on January 3, 2018). 219 APPENDIX B: PERMISSIONS FOR COPYRIGHTED MATERIALS 220 Permission Request Policies from Multidisciplinary Digital Publishing Institute (MDPI) All articles published by MDPI are made immediately available worldwide under an open access license. This means: • everyone has free and unlimited access to the full-text of all articles published in MDPI journals, and • everyone is free to re-use the published material if proper accreditation/citation of the original publication is given. • open access publication is supported by the authors' institutes or research funding agencies by payment of a comparatively low Article Processing Charge (APC) for accepted articles. In accordance with major definitions of open access in scientific literature (namely the Budapest, Berlin, and Bethesda declarations), MDPI defines open access by the following conditions: • peer-reviewed literature is freely available without subscription or price barriers, • literature is immediately released in open access format (no embargo period), and • published material can be re-used without obtaining permission as long as a correct citation to the original publication is given. Until 2008, most articles published by MDPI contained the note: "© year by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes". During 2008, MDPI journals started to publish articles under the Creative Commons Attribution License and are now using the latest version of the CC BY license, which grants authors the most 221 extensive rights. All articles published by MDPI before and during 2008 should now be considered as having been released under the post-2008 Creative Commons Attribution License. This means that all articles published in MDPI journals, including data, graphics, and supplements, can be linked from external sources, scanned by search engines, re-used by text mining applications or websites, blogs, etc. free of charge under the sole condition of proper accreditation of the source and original publisher. MDPI believes that open access publishing fosters the exchange of research results amongst scientists from different disciplines, thus facilitating interdisciplinary research. Open access publishing also provides access to research results to researchers worldwide, including those from developing countries, and to an interested general public. Although MDPI publishes all of its journals under the open access model, we believe that open access is an enriching part of the scholarly communication process that can and should co- exist with other forms of communication and publication, such as society-based publishing and conferencing activities. Important Note: some articles (especially Reviews) may contain figures, tables or text taken from other publications, for which MDPI does not hold the copyright or the right to re-license the published material. Please note that you should inquire with the original copyright holder (usually the original publisher or authors), whether or not this material can be re-used. 222 Permission Request Policies from Royal Society of Chemistry Authors contributing to RSC publications (journal articles, books or book chapters) do not need to formally request permission to reproduce material contained in this article provided that the correct acknowledgement is given with the reproduced material. Reproduced material should be attributed as follows: • For reproduction of material from NJC: Reproduced from Ref. XX with permission from the Centre National de la Recherche Scientifique (CNRS) and The Royal Society of Chemistry. • For reproduction of material from PCCP: Reproduced from Ref. XX with permission from the PCCP Owner Societies. • For reproduction of material from PPS: Reproduced from Ref. XX with permission from the European Society for Photobiology, the European Photochemistry Association, and The Royal Society of Chemistry. • For reproduction of material from all other RSC journals and books: Reproduced from Ref. XX with permission from The Royal Society of Chemistry. If the material has been adapted instead of reproduced from the original RSC publication "Reproduced from" can be substituted with "Adapted from". In all cases the Ref. XX is the XXth reference in the list of references. 223 If you are the author of this article you do not need to formally request permission to reproduce figures, diagrams etc. contained in this article in third party publications or in a thesis or dissertation provided that the correct acknowledgement is given with the reproduced material. Reproduced material should be attributed as follows: • For reproduction of material from NJC: [Original citation] - Reproduced by permission of The Royal Society of Chemistry (RSC) on behalf of the Centre National de la Recherche Scientifique (CNRS) and the RSC • For reproduction of material from PCCP: [Original citation] - Reproduced by permission of the PCCP Owner Societies • For reproduction of material from PPS: [Original citation] - Reproduced by permission of The Royal Society of Chemistry (RSC) on behalf of the European Society for Photobiology, the European Photochemistry Association, and RSC • For reproduction of material from all other RSC journals: [Original citation] - Reproduced by permission of The Royal Society of Chemistry If you are the author of this article you still need to obtain permission to reproduce the whole article in a third-party publication with the exception of reproduction of the whole article in a thesis or dissertation. 224
