Introducing the 787 - Effect on Major Investigations - and Interesting Tidbits

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
Introducing the 787 - Effect on Major Investigations - and Interesting Tidbits Introducing the 787 - Effect on Major Investigations - And Interesting Tidbits Tom Dodt Chief Engineer – Air Safety Investigation ISASI September, 2011 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 1 787 Size Comparison 767-400 787-8 777-300 ~Pax 3-Class 245 250 368 ~Span 170 ft 197 ft 200 ft ~Length 201 ft 186 ft 242 ft ~MTGW 450,000 lbs 500,000 lbs 660,000 lbs ~Range 5,600 NM 7,650 NM 6,000 NM Cruise Mach 0.80 0.85 0.84 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 2 By weight 787 777 - Composites 50% 12% Composite Structure - Aluminum 20% 50% Other Carbon laminate Steel 5% Carbon sandwich 10% Fiberglass Titanium 15% Composites Aluminum 50% Aluminum/steel/titanium pylons Aluminum 20% COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 3 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 4 787 Wing Flex - On-Ground On-Ground 0 ft COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 5 787 Wing Flex - 1G Flight 1G Flight ~12 ft On-Ground 0 ft 1G Flight COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 6 787 Wing Flex Ultimate-Load ~26 ft 1G Flight ~12 ft On-Ground 0 ft Max-Load COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 7 787 Static Load Test @ Ultimate Load COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 8 Investigations with Composite Materials • Terms: Composites Aluminum disbond fatigue delaminate beach marks inter-laminar shear striation counts water absorbsion corrosion fiber architecture metallurgical prop. • Material Forensics Techniques will be different • On-Site with Exposed Composite Fibers Eyes - goggles or full face protection Nose - HEPA filter Hands - gloves Exposed Skin - coveralls COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 9 787 Cabin Experience COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 10 787 Windows 787 787 777 777 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 11 Cleaner Cabin Air COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 12 Ride Quality - Smoother Ride Vertical Gust Suppression 2 • Uses the flaperons and elevators 1 • Counters light to moderate 0 turbulence to improve ride quality -1 • Passengers have a more Change in altitude (m) in altitude Change comfortable flight -2 0 20 40 60 80 100 120 140 160 180 Time (sec) With Enhanced Gust Suppression Without Enhanced Gust Suppression COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 13 787 Cabin Experience Windows - Larger Pressure - Lower Humidity - Higher Air Quality - Improved Ride Quality - Improved Food Service - Unchanged (sorry) COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 14 787 Pax Oxygen 787 - Gaseous Oxy @ 3000 psi - Steel cylinder 777 - Chem Oxy Generators (2x) COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 15 787 Fuel Tank Inerting COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 16 Quiet for Airport Communities 85 dB Noise Contours at Heathrow London Heathrow 787 noise footprint stays in the airport property 767-300 787- 8 Feet 0 5000 • 85 dBA contours Meters Source MS Mappoint, (c) Microsoft, Inc. • 3,000 nmi mission 0 1500 4001041404 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 17 Engine Technology Advancements • No-engine-bleed-air systems architecture • Higher bypass ratio • Low-noise nacelles with chevrons COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 18 Airplane/Engine Architecture • No-engine-bleed-air systems 777 787 Wing LE Anti-Ice bleed air electric Air Conditioning bleed air electric Cabin Pressure bleed air electric Engine start bleed air electric • Engine Generators 777 787 240 kVA 1000 kVA (2 @ 120 kVA) (4 @ 250 kVA) Generators Starter/Gen’s COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 19 Variable Frequency Power Generation 777 115 VAC 400 Hz 787 230 VAC 360-800 Hz COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 20 EE vs Pneumatic Power Distribution COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 21 FLIGHT DECK NON-NORMAL CB BY STATE CB SEARCH Electronic SYS MENU CB CB CB RECENT CB CB BY ATA CB BY BUS Circuit Breakers BY LOCATION USED CB CUSTOM LIST CE2100713 CIRCUIT BREAKER NAME 1 TRIPPED DETAILS CONTROL • No physical CBs in Flight Deck CE2100714 CIRCUIT BREAKER NAME 2 DETAILS CONTROL CE2100715 CIRCUIT BREAKER NAME 3 DETAILS CONTROL CE2100701 CIRCUIT BREAKER NAME 4 DETAILS CONTROL • CB control and state indication CE2100702 CIRCUIT BREAKER NAME 5 DETAILS CONTROL are display based. 1 CK2100780 CONTACTOR NAME 6 TRIPPED DETAILS CONTROL CE2100716 CIRCUIT BREAKER NAME 7 ? UNK DETAILS CONTROL • Accessible on Multi-Function CE2100717 CIRCUIT BREAKER NAME 8 DETAILS CONTROL Display (MFD) and DO NOT CE2100718 CIRCUIT BREAKER NAME 9 CLOSE DETAILS CONTROL maintenance access devices CE2100719 CIRCUIT BREAKER NAME 10 DETAILS CONTROL CE2100703 CIRCUIT BREAKER NAME 11 DETAILS CONTROL 2 • A few Thermal CB are located CE2100721 CIRCUIT BREAKER NAME 12 DETAILS CONTROL DO NOT in the Fwd EE-Bay CE2100722 CIRCUIT BREAKER NAME 13 CLOSE DETAILS CONTROL CE2100723 CIRCUIT BREAKER NAME 14 ? UNK DETAILS CONTROL CK2100724 CONTACTOR NAME 15 DETAILS CONTROL CE2100725 CIRCUIT BREAKER NAME 16 DETAILS CONTROL COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 22 Overhead Panels - Circuit Breakers 787 777 COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 23 Avionics Integration 777777 787787 IntegratedIntegrated SurveillanceSurveillance WXRWXR EGPWSEGPWS TCASTCAS ATCATC SurveillanceSurveillance SystemSystem (ISS)(ISS) NavNav RadiosRadios VORVOR MBMB MMRMMR DMEDME RARA RARA DMEDME IntegratedIntegrated NavigationNavigation RadiosRadios (INR)(INR) CommComm RadiosRadios VHFVHF HFHF SATCOMSATCOM SATCOMSATCOM HFHF VHFVHF InertialInertial ADIRUADIRU SAARUSAARU EarthEarth ReferenceReference SystemSystem (ERS)(ERS) OtherOther LRUsLRUs WEUWEU OthersOthers CommonCommon CoreCore ResourceResource (CCR)(CCR) AirAir DataData AIMSAIMS CrewCrew AlertingAlerting DisplaysDisplays CommComm Management Management DFDACDFDAC DataData AcquisitionAcquisition FMFM // TMTM DisplaysDisplays CMFCMF // ACMFACMF // QARQAR FMFM // TMTM // ATAT FDCFFDCF HealthHealth ManagementManagement GatewaysGateways GatewaysGateways OthersOthers OthersOthers COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 24 IntegratedIntegrated FCEFCE Equivalent Channel of Flight Controls and High Lift 777 PSA ACE PFC 787 AFDC FSEU PCMPCM ACEACE FCMFCM COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 25 Common Core System CommonCommon ComputingComputing ResourceResource ••High High integrityintegrity computingcomputing resourcesresources forfor hostedhosted systemssystems applicationsapplications CommonCommon DataData NetworkNetwork ••High High IntegrityIntegrity NetworkNetwork • Open industry standard interfaces A664 • Open industry standard interfaces A664 RemoteRemote DataData ConcentratorsConcentrators ••21 21 RDCsRDCs ••Remote Remote I/OI/O capabilitycapability ••Reduces Reduces airplaneairplane wiringwiring COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 26 CCS Hosted Functions • Avionics Communication and Audio • Avionics Flight Management and Navigation • Avionics Thrust Management and Auto-throttle • Avionics Primary Display Function • Avionics Crew Alert/Warning and Surveillance • Avionics Crew Information Services • Avionics Maintenance and Data Loading • Cabin Management and Air Show • Environmental Control System Functions: Power Electronics and Other Equipment Liquid/forced air Cooling, Air Conditioning, Cabin Pressurization, Ice & Rain Protection, Air Distribution, Galley Refrigeration, Low Pressure Systems, Cargo Heat, Wheel Well Fire Detection and Cargo Fire Detection/Protection • Electrical Utility System Control Functions Remote Power Distribution System (RPDS), Power Distribution Panels (PDPs), Generator/Bus Power Control Units (GCU/BPCU), Proximity Sensors, Window Heat, Tail Strike, Emergency Passenger Assist System (EPAS), Exterior Lighting • Data Interface to Flight Controls Electronics (FCE) • Interface to Flight Deck Panels and Switches • Fuel Management and Fuel Quantity Indication • Hydraulics Control • Mechanical System Interface Functions in Brakes, Landing Gear, Nose Wheel Steering • Payloads Interface Functions in Galleys, Water & Waste, Emergency Lighting • Data Interface to Propulsion Controls in EEC, Engine Fire Detection/Protection, Thrust Reverser • Specific functionality supported by the CCS is described in the CCS SDD (Ref. 4) as well as in individual 787 CCS hosted function System Description • Documents (SDDs) identified in their respective certification plans listed in Ref. 4.). COPYRIGHT © 2010 THE BOEING COMPANY Smith, 7-April-2011, ESASI-Lisbon | 27 Hydraulic System Architecture 5000 psi systems Left Left System Center System Right Right System Engine Engine 25 gpm +/- 270V DC 27 gpm 27 gpm +/- 270V DC 25 gpm +/- 270V DC Engine Electric Driven Pump Electric Electric 13 gpm Driven Pump Electric (EDP) Electric Motor Pump Motor Pump (EDP) Motor Pump Motor Pump (EMP) (EMP) Ram Air (EMP) Turbine (EMP) 27 gpm (RAT) 27 gpm OB Aileron – L Wing: OB & IB L Wing: OB L Wing: IB IB Flaperon R Wing: IB R Wing: OB & IB R Wing: OB L Wing: 3 L Wing: 1, 7 L Wing:
