Inferring Queueing Network Models from High-Precision Location Tracking Data

University of London Imperial College of Science, Technology and Medicine Department of Computing

Inferring Queueing Network Models from High-precision Location Tracking Data

Tzu-Ching Horng

Submitted in part fulﬁlment of the requirements for the degree of Doctor of Philosophy in Computing of the University of London and the Diploma of Imperial College, May 2013

Abstract

Stochastic performance models are widely used to analyse the performance and reliability of systems that involve the flow and processing of customers. However, traditional methods of constructing a performance model are typically manual, time-consuming, intrusive and labour- intensive. The limited amount and low quality of manually-collected data often lead to an inaccurate picture of customer flows and poor estimates of model parameters. Driven by advances in wireless sensor technologies, recent real-time location systems (RTLSs) enable the automatic, continuous and unintrusive collection of high-precision location tracking data, in both indoor and outdoor environment. This high-quality data provides an ideal basis for the construction of high-fidelity performance models.

This thesis presents a four-stage data processing pipeline which takes as input high-precision location tracking data and automatically constructs a queueing network performance model approximating the underlying system. The first two stages transform raw location traces into high-level “event logs” recording when and for how long a customer entity requests service from a server entity. The third stage infers the customer flow structure and extracts samples of time delays involved in the system; including service time, customer interarrival time and customer travelling time. The fourth stage parameterises the service process and customer arrival process of the final output queueing network model.

To collect large-enough location traces for the purpose of inference by conducting physical experiments is expensive, labour-intensive and time-consuming. We thus developed LocTrack- JINQS, an open-source simulation library for constructing simulations with location awareness and generating synthetic location tracking data.

Finally we examine the eﬀectiveness of the data processing pipeline through four case studies based on both synthetic and real location tracking data. The results show that the methodology performs with moderate success in inferring multi-class queueing networks composed of single- server queues with FIFO, LIFO and priority-based service disciplines; it is also capable of inferring diﬀerent routing policies, including simple probabilistic routing, class-based routing and shortest-queue routing.

i ii Acknowledgements

The completion of this research is largely owe to many of those I have worked with during my study at Imperial College London. I especially would like to express my gratitude to my supervisor Dr. William Knottenbelt, for his generosity, open-mindedness, enthusiasm as well as constant support and guidance during my PhD; and to my colleague Nikolas Anastasiou, for all the work we have done together and our personal friendship.

The PhD journey for me has been a long one with countless moments of self-questioning, doubts and confusion. Fortunately, there are many beloved ones always taking my side along the journey. Special thanks to my dearest friends – Pei-Chien Tsai, Tzu-Chun Chen, Cecilia Lopez, Olivier Blesbois – for always being there for me. Last, but most important of all, I owe my parents the deepest gratitude for everything they have given me throughout my life, with their unconditional love.

iii iv Dedication

This thesis is dedicated to Tzu-Ting Horng, who understands me the most and always has a place in my heart.
