!! Call Before You Dig !! Dial 811 If You Are a Homeowner

Total Page:16

File Type:pdf, Size:1020Kb

!! Call Before You Dig !! Dial 811 If You Are a Homeowner IF YOU ARE A HOMEOWNER !! CALL BEFORE YOU DIG !! DIAL 811 (Can also dial 1-800-282-7411) It’s the Law: Anyone in the State of Georgia who is planning to dig must call the Georgia Utilities Protection Center (UPC) for a dig ticket and wait two full business days to allow owners of underground utilities to locate their lines. What is a dig ticket? During your call, the UPC of Georgia will give you a ticket number. This ticket is the official notification of you request and is called the “dig ticket” or “locate request”. The “dig ticket” is immediately sent to all utility owners in your area. Click on the link below for more information about the ticket process. Georgia UPC | Homeowners What type of work requires a dig ticket? The dig ticket (locate request) in which you call in is intended to prevent any harm to your life and property. Among the work types that we suggest you call in a ticket for include: planting, repairing or replacing underground utilities (specifying which utility) , fences, mailbox, retaining walls, aerating, grading, tilling, using an auger, any mechanized/motorized piece of machinery, etc.. What information do I need before I call? • Name, area code, phone number, address, city, county and nearest cross streets. • Type of work to be done and how long it will take. • Date and start time digging is scheduled to begin. • If any work will be done within 10 ft. of overhead high voltage power lines. • Contractor/contact person and phone number. • Where on the property you want marking done. • Specific directions to your property – landmarks, etc. How will the underground lines be marked? Color coded markings and/or flags will be used to mark the approximate locations of any underground lines. You should not do any digging within two (2) feet on either side of the markings. The color coding for utilities is shown in the chart below. APGA Proposed Excavation UNIFORM COLOR Temporary Survey Markings CODE Electric power lines and conduits Natural gas, oil or petroleum Call Before You Dig! Telephone or Cable Utilities Protection Potable Water Center DIAL 811 Reclaimed water or irrigation Or call 1.800.282.7411 Sewers and drain lines For more information about digging near underground lines, please click on the following link: Georgia UPC | Homeowners Pipeline Safety Considerations When planning landscaping projects, avoid planting large trees or shrubs near you gas meter. As the tree grows, it can interfere with your gas meter or underground gas service line. Be WATCHFUL If you notice someone digging in your yard, be sure that they have contacted the Georgia UPC before they started digging. You can help enforce safety laws by shutting down anyone who is not using the One-Call system. For example, if your sprinkler system or pool installer starts digging before you see any paint or flags in your yard, he is probably not complying with the law. By shutting down the excavation work your will be protecting your own property by preventing damage to gas, electric, water, telephone and cable lines. .
Recommended publications
  • Sloping and Benching Systems
    Trenching and Excavation Operations SLOPING AND BENCHING SYSTEMS OBJECTIVES Upon the completion of this section, the participant should be able to: 1. Describe the difference between maximum allowable slope and actual slope. 2. Observe how the angle of various sloped systems varies with soil type. 3. Evaluate layered systems to determine the proper trench slope. 4. Illustrate how shield systems and sloping systems interface in combination systems. ©HMTRI 2000 Page 42 Trenching REV­1 Trenching and Excavation Operations SLOPING SYSTEMS If enough surface room is available, sloping or benching the trench walls will offer excellent protection without any additional equipment. Cutting the slope of the excavation back to its prescribed angle will allow the forces of cohesion (if present) and internal friction to hold the soil together and keep it from flowing downs the face of the trench. The soil type primarily determines the excavation angle. Sloping a method of protecting employees from cave­ins by excavating to form sides of an excavation that are inclined away from the excavations so as to prevent cave­ins. In practice, it may be difficult to accurately determine these sloping angles. Most of the time, the depth of the trench is known or can easily be determined. Based on the vertical depth, the amount of cutback on each side of the trench can be calculated. A formula to calculate these cutback distances will be included with each slope diagram. NOTE: Remember, the beginning of the cutback distance begins at the toe of the slope, not the center of the trench. Accordingly, the cutback distance will be the same regardless of how wide the trench is at the bottom.
    [Show full text]
  • Earthwork Design and Construction
    Technical Fundamentals for Design and Construction April 6, 2020 Earthwork Design and Construction Key Points • The primary objectives of earthwork operations are: (1) to increase soil bearing capacity; (2) control shrinkage and swelling; and (3) reduce permeability. • Particle shape is a critical physical soil property influencing engineering modification of a soil. • Proper water content is essential to economically achieve specified soil density. Purpose and Scope of Earthwork The purpose and scope of earth construction differ for various types of constructed facilities. The major types of earthwork projects include: • Transportation projects, which require embankments, roadways, and bridge approaches. • Water control, which usually involves dams, levies, and canals. • Landfill closures, which need impervious caps. • Building foundations, which must support loads and limit soil movement by shrinkage and swelling. Properly modified soils are the most economical solution for many constructed facilities. To meet structural support requirements, soils at some project sites may require treatment such as the addition of water, lime, or cement. 1 Technical Fundamentals for Earthwork Design, Materials, and Resources The physical chemical properties of project site soils have a major influence on the design of earthen structures and on the resources and operations needed to properly modify a soil. The fundamental properties of a soil include: granularity, course to fine; water content; specific gravity; and particle size distribution. Other properties include permeability, shear strength, and bearing capacity. The engineering design of a soil seeks to provide sufficient bearing capacity, settlement control, and either limit, in the case of dams and landfill caps, the movement of water or facilitate the movement of water in the case of drains, such as behind retaining walls.
    [Show full text]
  • Failure of Slopes and Embankments Under Static and Seismic Loading
    American Scientific Research Journal for Engineering, Technology, and Sciences (ASRJETS) ISSN (Print) 2313-4410, ISSN (Online) 2313-4402 © Global Society of Scientific Research and Researchers http://asrjetsjournal.org/ Failure of Slopes and Embankments Under Static and Seismic Loading Nicolaos Alamanis* Lecturer, Dept. of Civil Engineering, Technological Educational Institute of Thessaly, Larissa, Greece, Civil engineer (National Technical University of Athens, D.E.A Ecole Centrale Paris) Email: [email protected] Summary The stability of slopes and embankments under the influence of static and seismic loads has been the subject of study for many researchers. This paper presents the mechanisms and causes of landslides as well as the forms of failure of slopes and embankments under static and seismic loading, with examples of failures from both Greek and international space. There is also mention to measures to protect and stabilize landslides, categories of slope stability analysis, and methods of seismic impact analysis. What follows is the determination of tolerable movements based on the caused damage on natural slopes, dams and embankments and an attempt is made to connect them with the vulnerability curves that are one of the key elements of stochastic seismic hazard. Particular importance is given to the statistical parameters of the mechanical characteristics of the sloping soil mass and to the simulation of random fields necessary for solving complex geotechnical works. Finally, we compare the simulation and description of random fields and the L.A.S. method is observed to be the most accurate of all simulation methods. The L.A.S. algorithm in conjunction with finite difference models can demonstrate the large fluctuations in the factor of safety values and the permanent seismic displacements of the slopes under the effect of seismic charges whose time histories are known.
    [Show full text]
