Passive Optical Lan Product Guide Not Just Products

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
Passive Optical Lan Product Guide Not Just Products PASSIVE OPTICAL LAN PRODUCT GUIDE NOT JUST PRODUCTS. ANSWERS. 3 DEPLOYMENT 4 ARCHITECTURES 1 Depending upon the facility layout, user needs, as well as other factors, POL may be deployed in various configurations: 1 Centralized Split Architecture 2 Zone Split Architecture 3 Remotely-Powered ONT Architecture 4 Hybrid Solution Architecture 2 THE OCC TEAM GETS IT. The more complex your network becomes, the TABLE OF CONTENTS more challenging it is to know which products to use, how to integrate them, PAGE 4 Centralized Split how to budget for them, and how to ensure your network runs with minimal PAGE 5 Zone Split PAGE 6 Remote Powered ONT downtime. In addition to providing an extensive Passive Optical LAN (POL) PAGE 7 Hybrid Solution product set, OCC experts can assist you in building the ideal solution for your PAGE 8 Product Highlights specific POL challenge. PAGE 10 Customer Support & Warranty Information PAGE 11 Glossary of Terms OCC's customers rely on us for more than just products. Our customers count on OCC's design-build expertise and broad portfolio of end-to-end solutions for the seamless integration and optimum reliability of the network. OCCFIBER.COM 2 WHAT IS PASSIVE OPTICAL LAN? Passive Optical LAN technology is a point-to-multi-point architecture that provides the capability to securely deliver voice, data, and IP video and/or broadband video over a single strand of optical fiber. This architecture is based upon carrier-grade passive optical network technology that has been reliably utilized in fiber-to-the-home deployments for many years, as well as hospitality, residential, and commerical applications. POL is comprised of two key network electronic components: 1) Optical Line Terminal (OLT) and 2) the Optical Network Terminal (ONT). The OLT is normally located in the equipment room. It aggregates optical traffic and provides the interface to edge IP network switches and routers. The ONT is normally located at the user's work station or zone enclosure and de-multiplexes the fiber optic signal into its component parts (i.e., voice/data/video) and outputs these signals on copper ports (i.e., RJ45). CORE ROUTER ONT VOICE 1X32 ONT DATA OLT ONT SWITCHED VIDEO The OCC POL Solution ensures network traffic is transported between these devices over a passive optical fiber infrastructure that generally consists of the following components: » Pre-terminated single-mode optical fiber cable » Passive optical splitters » Fiber adapter plates and cassette modules » Fiber enclosures (rack/wall/ceiling mount) » Faceplates/surface mount enclosures/pass-through couplers 3 OCCFIBER.COM CENTRALIZED SPLIT ARCHITECTURE In this architecture, the splitters are located near the OLT or other active hardware. Individual simplex fiber optic cables connect this centralized location to each ONT throughout ONT the building. The centralized split architecture works well in ONT retrofit installations, where a telecommunications room or rack ONT is already located near the users and is being re-used as a ONT telecommunications room. Desktop/Work Area Legend 1xN Passive Optical Splitter Zone Enclosure ONT Adapter Plate ONT SC-MTP Breakout Cassette ONT ONT ONT ONT SM Fiber Desktop/Work Area MTP Fiber Trunk Cable OLT Equipment Room ONT ONT ONT ONT Desktop/Work Area CENTRALIZED SPLIT DIAGRAM 1 1 » Stackable Cassette Bracket (PONSCB1U) 6 2 2 » Rack Mount Fiber Enclosure (RTC1U-3APB) 7 3 » 1x32 PON Splitter with 2mm Pigtails 3 (PONC1X32SCAPC2) » Faceplate Kit with SC insert, 1-Port, Angled, 4 Bright White (FPSK01ASCA12) » Fiber Optic Jumper, Single-Mode, SCAPC, 5 Simplex (S8SCAPC-SCAPC) 6 » MPO to 12-Port SC/APC Breakout Cassette 6 (PONCMTP12SCAPC2) » Fiber Cable Assembly, MT-MT, 12-Fiber, 4 7 5 SM, HD (MT12PRF8TK) OCCFIBER.COM 4 ZONE SPLIT ARCHITECTURE Legend 1xN Passive Optical Splitter ONT In this architecture, the Adapter Plate ONT SC-MTP Breakout Cassette splitters may be located ONT ONT ONT in the ceiling or in a rack ONT SM Fiber near the workspace that Zone Enclosure - Zone Split Desktop/Work Area MTP Fiber Trunk Cable contains the ONTs. In a multistory office building, each floor may have its ONT own zone or have multiple ONT zones, feeding back to ONT an OLT located in a single Mini-Zone ONT Enclosure telecommunications room. Desktop/Work Area On a campus installation, 12-Fiber Trunk Cable each zone may be as large as an entire building, with ONT the OLT being in another ONT building elsewhere on ONT campus. O LT ONT Equipment Room Desktop/Work Area Wall Mount Enclosure - Zone Split ZONE SPLIT DIAGRAM ZONE SPLIT DIAGRAM 1 » Ceiling Mount Enclosure (ZED12AP) 7 2 » Wall Mount Enclosure (WTC6APBD) 5 » Mini Zone Distribution Enclosure 3 (ZDMBC1AP) » 1x32 PON Splitter with 2mm Pigtails 4 (PONC1X32SCAPC2) » SC/APC 600-Series Adapter Plates 5 (6112SMDSCAPC) 1 4 4 6 » Fiber Service Outlet Box (SMEK2FSO12) 2 6 3 7 » Rack Mount Fiber Enclosure (RTC1U-3APB) 5 OCCFIBER.COM REMOTE POWERED ONT ARCHITECTURE This architecture is a method for providing remote DC power from a central power supply to the ONT utilizing a hybrid cable. ONT Remote power delivery eliminates the need ONT ONT ONT for local AC power outlets at each ONT. A ONT ONT centralized power supply with generator or Desktop/Work Area ONT Legend battery backup also eliminates the need for ONT 1xN Passive Optical Splitter Desktop/Work Area battery backup for each individual ONT. Adapter Plate Legend ONT ONT 1xN Passive Optical Splitter SM Fiber REMOTE POWER DISTANCE BY Adapter Plate Slimline-Plenum Hybrid Cable CONDUCTOR SIZE ONT ONT AWG MAX DISTANCE (FT) SM Fiber Slimline-Plenum Hybrid Cable 12 1606 14 1028 OLT 16 643 18 408 PDU ONT OLT ONT 20 254 Bulk Rectifier/Battery BU ONT PDU ONT 22 160 ONT ONT Equipment Room Desktop/Work Area Bulk Rectifier/Battery BU ONT *Values based on 1.75 Amps @48VDC nominal input ONT voltage to powered device from 57VDC power source. Equipment Room Desktop/Work Area REMOTE POWERED ONT DIAGRAM 1 » DC Pass-Thru Adapter Plate (6112DCPASS) 1 4 2 » KMJ Adapter 2-Conductor Pass-Thru (AKDCPT12) 3 » Slimline-Plenum Hybrid Cable (CE003SPDA9YP) 3 4 » SC/APC HD Adapter Plates (6112SMDSCAPCHD) » Faceplate Kit with SC Shuttered Insert, 1-Port, 5 Bright White (FPSK01ASCAS12) 5 2 OCCFIBER.COM 6 HYBRID SOLUTION ARCHITECTURE Cat6/6A The Hybrid Solution Voice Cat6/6A architecture is comprised Data ONT Cat6/6A of both optical fiber and Legend Local Power copper cabling. The ONT IPTV 1xN Passive Optical Splitter is typically located in an Resi/MDU Adapter Plate Enclosure active zone enclosure and ONT ONT may be either locally or SM Fiber remotely powered. The Slimline Plenum Hybrid Cable Cat6/6A Cable ONT utilizes Category 6/6A Cat6A/6A RJ45 Field Term Plug copper cabling to provide (Data +POE) Outlet data and optional Power Cat6A/6A (Data +POE) over Ethernet (PoE) to end OLT Cat6A/6A Multiport (Data +POE) ONT w/POE devices, such as Cat6A/6A PDU (Data +POE) Devices / IP CAM/ IoT Wireless Access Points Access Wireless Wireless Access Points (WAPs), IP cameras, or Active Zone Enclosure Bulk Rectier/Battery BU workstations. Equipment Room HYBRID SOLUTION DIAGRAM » Slimline Plenum Hybrid » Category 6A Field 1 4 Cable (CE003SPDA9YP) Terminable Plug (OCCUFP6A) » PON Splitter or 1x32 PON » Category 6A UTP Copper 2 5 Splitter with 2mm Pigtails Cable (OCC-U6A4R-05) (PONC1X32SCAPC2) 2 » Category 6A KMJ Outlet » Category 6A Patch Cord 3 6 Jack (K6A01) (PC6AU-0905) 4 5 1 3 6 7 OCCFIBER.COM PRODUCT HIGHLIGHTS CABLES & PRE-TERMINATED CABLE ASSEMBLIES SPLITTER MODULES & BREAKOUT CASSETTES » A complete system that integrates with other POL » Low-loss Planar Lightwave Circuit (PLC) and structured cabling components design » Flexible options based on application needs and » Dual input ports also available for infrastructure requirements redundancy » OCC’s POL Solution integrates seamlessly with all of » 2mm fiber pigtails (1-meter length) our structured cabling components for easy patching to adapter plates or cassettes DESCRIPTION OCC PART # DESCRIPTION OCC PART # Fiber Optic Jumper/Station Cable, SCAPC, Simplex # S8SCAPC-SCAPC 1X8 PON Splitter with 2mm Pigtails PONC1X8SCAPC2 Fiber Optic Jumper, Single-Mode, LCAPC, Simplex # S8LCAPC-LCAPC 1X16 PON Splitter with 2mm Pigtails PONC1X16SCAPC2 Fiber Cable Assembly, MT-MT, 12-Fiber, SM, HD Plenum# MT12PRF8TK-0010 1X32 PON Splitter with 2mm Pigtails PONC1X32SCAPC2 Slimline-Riser Indoor/Outdoor PLTC Hybrid CE004DPDA9YR 2X8 PON Splitter with 2mm Pigtails PONC2X8SCAPC2 Slimline Plenum Hybrid Cable * CE003SPDA9YP 2X16 PON Splitter with 2mm Pigtails PONC2X16SCAPC2 Simplex Bulk Cable, Single-Mode, Riser * AX001DSLA9YR 2X32 PON Splitter with 2mm Pigtails PONC2X32SCAPC2 Simplex Bulk Cable, Single-Mode, Plenum * AX001SSLA9YP MTP/MPO to 12-Port SC/APC Breakout Cassette * PONCMTP12SCAPC2 Category 6 Patch Cord # PCSIX04B02 *Other configurations available. Category 6A Patch Cord # PC6AU-0905 Category 6 Bulk Cable * OCC-UE64PLM-05 WORK AREA & EQUIPMENT OUTLETS/ADAPTERS » Faceplates accept KMJ-style fiber Category 6A Bulk Cable * OCC-U6A4R-05 or copper jacks/adapters » Angled faceplates minimize damage #Other configurations and varying lengths available. *Other configurations available. to connector and reduce space » Shuttered SC/APC fiber adapters protect fiber interface when not ADAPTER PLATES connected » Available in 6-, 12-, and 24-Port fiber configurations » Panel options available include DESCRIPTION OCC PART # SC, ST, FC, and LC Faceplate, 1-Port, Angled, Bright White FPSK01A12 Faceplate Adapter, SC/APC, Office White AKSCAPC01 Faceplate Adapter, SC/APC, Shuttered,
