Research Objectives: Psychophysical acceleration threshold is a tool for detecting

deficits in dynamic postural control. Our lab has shown differences in the acceleration

threshold among young adults, elderly adults, and elderly adults with diabetes.

Electromyography, Semmes-Weinstein monofilaments, and hearing tests investigate the

underlying physiological mechanisms for the detriments in postural control. Due to peri-

sway perturbations, the motion of a person’s sway affects the signal to noise ratio for

perturbed stance. Since increases in sway range accompany postural instabilities, sway

entrainment will allow us to investigate changes in acceleration threshold at different

points in sway. The center of pressure, observed for entrainment, only changes due to

rotations about joints, specifically the ankle. The current method to model rotation about

the ankle is a single orthogonal joint, and therefore inaccurate.

Methods: The SLIP-FALLS-STEPm Platform has lead to the ability to accurately

measure and observe interactions in the range of postural sway. The combination of the

platform with other testing modalities such as camera tracking systems, force mats, and

accelerometers will allow for a comprehensive testing scheme. The new scheme can be

combined with the induced sway produced by a sub-threshold sinusoidal entrainment

process. The nonorthogonal modelling is programmed in Matlab®.

Results: For constant displacements, anterior accelerations thresholds via two-

alternate forced choice (2AFC) showed differences in postural stability in mature,

iii

Reproduced with permission of the copyright owner. Further reproduction prohibited without permission. iv diabetic individuals with peripheral neuropathy (DPN) and those who are neurally intact

(DNI) compared to healthy mature adults (HMA), which corresponded with previous

results of lateral perturbations. Both DNI and DPN had significantly higher thresholds

for acceleration via 2AFC than HMA at 1 and 4 mm displacements (p < 0.01 and p<0.05)

and Semmes-Weinstein monofilaments. For psychophysical amplitude threshold

detection, we used our modified Single-Interval-Adjustment-Matrix to obtain amplitude

thresholds for subthreshold frequency entrainment.

Conclusion: The anterior acceleration thresholds show that peripheral neuropathy is

not the sole cause for postural instability with diabetes. The ability to control the motion

of sway will allow us to describe acceleration threshold throughout the range of sway.

With a realistic ankle model, we will be able to better simulate postural dynamics.
