MK-17 Patent Pending Operators Manual

*Rifle Shown with Additional Accessories

Issue 2 WARNING - This document contains technical data whose export is restricted by the Arms Export Control Act (Title 22, U.S.C., Sec 2751, et seq.) or the Export Administration Act of 1979, as amended (Title 50, U.S.C., App. 2401 et seq.). Violations of these export laws are subject to severe criminal penalties.

S.W.O.R.D International, Inc. 610 E. Glendale Avenue Sparks, NV 89431 775-343-1090

Specifications and models subject to change without notice. May 2020

Operator Manual : S.W.O.R.D International; MK 17 Issue 2 Multi-cal, Patent Pending SAFETY RULES The following safety rules are placed in this manual by S.W.O.R.D. International, Inc. as an important reminder that firearm safety is your responsibility. Please read this operator's manual before handling your firearm. Firearms can be dangerous and can potentially cause serious injury, damage to property, or death, if handled improperly.

• Treat every firearm as if it were loaded. • Never index your muzzle at anything you are not willing to destroy. • Keep your finger straight and off the until you are ready to fire. • Know your target, what is beyond it, and all surroundings. • Always wear hearing and eye protection when shooting. • Discharging firearms in poorly ventilated areas, cleaning firearms, or handling may result in exposure to lead, a substance known to be associated with birth defects, reproductive harm and other serious injury. • Be sure that your barrel is clear of obstructions before shooting. • Use only clean, high quality factory loaded ammunition in good condition.

WARNING

Before starting an inspection and/or moving down range, be sure to clear the firearm.

To be considered SAFE before disassembly, cleaning, inspecting, transporting, or storing, the firearm must be cleared.

With the carrier assembly locked to the rear or in its forward position, if the firearm is dropped or jarred with a loaded magazine in place, it could chamber a round.

When handling your firearm ALWAYS ensure it is pointed in a safe direction.

Do not load with a hot chamber.

If your firearm fails to fire with a live round in the chamber of a hot barrel, remove the round. If you cannot remove it within 10 seconds, remove magazine and wait 15 minutes with the firearm pointed in a safe direction. This way a round cooking off won’t harm you. ALWAYS keep your face away from the ejection port while clearing, especially with a hot chamber.

DO NOT OVERHEAT BARRELS. Sustained firing of the firearm will rapidly raise the temperature of the barrel to a critical point.

Firing 140 rounds, rapidly and continuously, will raise the temperature of the barrel to the COOKOFF point. At this temperature, any live round remaining in the chamber for any reason may cook off (detonate) in as short as 10 seconds.

Operator Manual : S.W.O.R.D International; MK 17 Issue 2 Multi-cal, Patent Pending WARNING

If the cook-off point/temperture is reached, the firearm should be immediately cleared and allowed to cool.

Sustained for the firearm is 12-15 rounds per minute. This is the rate of fire that the firearm can continue to deliver for an indefinite length of time without serious overheating.

Sustained rate of fire should never be exceeded except under circumstances of extreme urgency.

Exceeding the sustained rate of fire can result in a catastrophic failure of the barrel, resulting in injury or death to personnel.

When disassembling the magazine, turn the magazine away from your face, the spring is under compression.

Always make sure your firearm is clear and on SAFE before moving down range.

If an audible ‘POP’ or reduced RECOIL is experienced during firing, immediately CEASE FIRE. Either condition could indicate an incomplete powder burn and/or a stuck in the bore. If unsure how to correct this issue contact an experienced gunsmith.

DO NOT fire if water is present in barrel.

DO NOT interchange bolts between firearms.

Be sure the cam pin is installed in the bolt group. If it isn’t, your firearm can still fire and will damage the firearm.

INTERESTED IN FIREARMS TRAINING?

S.W.O.R.D International, Inc. offers firearms training courses ranging from novice to expert skill levels that are instructed by former US Military Special Operations Soldiers. For more information, please contact us on our website.

www.S.W.O.R.D-int.com/contact

Operator Manual : S.W.O.R.D International; MK 17 Issue 2 Multi-cal, Patent Pending TABLE OF CONTENTS

• Specifications 2

• Warranty 3

• Ammunition 4

• Lubrication 4

• Nomenclature

• Left Side 5

• Right Side 6

• Clearing & Unloading the Firearm 7

• Firing Procedure 7

• Disassembly Instructions 8

• Extractor Removal 8

• Stock Removal 8

• Detailed OPROD removal 9

• Detailed Bolt Carrier disassembly 10

• Troubleshooting 11

• Notes 13

MAGPUL M-LOK

The free-floating modular rail system on your new MK-17 rifle is equipped with Magpul M-LOK slots. You can find a complete range of M-LOK compatible accessories on their website.

www.magpul.com

Operator Manual : S.W.O.R.D International; MK 17 1 Issue 2 Multi-cal, Patent Pending SPECIFICATIONS

MK-17 Tyrant 22 13” Barrel

Calibers 7.62x51 NATO/ .308 WIN

Weight 8 lbs

Length (13” Barrel) Retracted 33”, Extended 37”

Rifling RH 1:8 twist

Muzzle Velocity 2750 fps (7.62mm)

Chamber Pressure 62,000 psi avg. (7.62mm)

Fire Selector SAFE / FIRE

Maximum Rate of Fire 40 rpm

Sustained Rate of Fire 12-15 rpm

Max Effective Range 800 m (individual/point targets)

Max Effective Range 1100 m (area targets)

MK-17 Tyrant 22 16” Barrel

Calibers 7.62x51 NATO/ .308 WIN

Weight 8.5 lbs

Length (16” Barrel) Retracted 36”, Extended 40”

Rifling RH 1:8 twist

Muzzle Velocity 2750 fps (7.62mm)

Chamber Pressure 62,000 psi avg. (7.62mm)

Fire Selector SAFE / FIRE

Maximum Rate of Fire 40 rpm

Sustained Rate of Fire 12-15 rpm

Max Effective Range 800 m (individual/point targets)

Max Effective Range 1100 m (area targets)

Operator Manual : S.W.O.R.D International; MK 17 2 Issue 2 Multi-cal, Patent Pending SPECIFICATIONS

MK-17 Gungnir 20” Barrel

Calibers 6.5 Creedmoor

Weight 9.5 lbs

Length (20” barrel) 35 3/8” / 39 1/4”

Rifling RH 1:8 twist

Muzzle Velocity 2725 fps approx.

Chamber Pressure 67,200 psi avg. approx.

Fire Selector SAFE / FIRE

Maximum Rate of Fire 40 rpm

Sustained Rate of Fire 12-15 rpm

Max Effective Range 1275 m (individual/point targets)

WARRANTY

S.W.O.R.D International, Inc. warranties the rifle to the original owner against manufacturing defects for the lifetime of the product. Aftermarket modifications, improper use and/or improper maintenance will void this warranty. Repairs, maintenance or replacement under this warranty is at S.W.O.R.D International’s discretion. A service or handling charge may be made. This warranty is nontransferable.

This warranty is void if the firearm has been abused, misused, or damaged; fired with hand loaded, reloaded, improper ammunition or with an obstruction in the barrel; or damaged by failure to perform proper maintenance. This warranty does not apply to normal wear of any parts, including their surface finish, or if unauthorized repair or alteration has been performed.

The terms of this warranty cannot be changed except in writing by S.W.O.R.D International. Wholesalers or Dealers, unless authorized by S.W.O.R.D International in advance are not authorized to make any warranty repair or adjustment on behalf of S.W.O.R.D International.

In the very unlikely event that S.W.O.R.D International should ever issue a recall of your firearm, S.W.O.R.D International will post a notice on our website.

www.sword-int.com

Operator Manual : S.W.O.R.D International; MK 17 3 Issue 2 Multi-cal, Patent Pending AMMUNITION

For the operator’s safety and for platform reliability, S.W.O.R.D International, Inc. strongly recommends using only ammunition manufactured by United States based reputable ammunition companies that are members of The Sporting Arms and Ammunition Manufacturers' Institute (SAAMI).

WARNING

Do Not Fire: • Seriously corroded ammunition • Dented cartridges • Cartridges with loose • Cartridges exposed to extreme heat (135°) until they have cooled • Cartridges with the bullet pushed in (short rounds) • Reloaded ammunition • Steel cased or lacquer coated cartridges

Failure to follow all of the above listed recommendations may result in reliability issues, operator injury, and Will Void Manufactures Warranty.

We have engineered this rifle to work with ammunition using 125-185 grain projectiles from a variety of manufacturers. Due to variances in manufacturers tolerances, you may experience inconsistency using ammunition with 140 grain and below bullets.

LUBRICATION

S.W.O.R.D. International, Inc. recommends using high quality firearms lubricants from well known manufacturers of such products. These are just a few examples.

Hoppes Double Tap Break Free

Lubricate the bolt, bolt carrier, disconnector, gas piston and charging handle slide and track sparingly prior to shooting and after cleaning.

Operator Manual : S.W.O.R.D International; MK 17 4 Issue 2 Multi-cal, Patent Pending NOMENCLATURE

Left Side View

A C D E F

L

B G I K H J

A – Compensator B – Barrel C – Free Float Modular Rail Assembly D – Charging Handle Assembly E – Upper Receiver F – Butt Stock G – Lower Receiver H – Magazine Release I – Bolt Catch/Release J – Trigger K – Pistol Grip L – Safety Selector

Operator Manual : S.W.O.R.D International; MK 17 5 Issue 2 Multi-cal, Patent Pending NOMENCLATURE

Right Side View

E L C A D

K F J I H G B

A – Compensator B – Barrel C – Free Float Modular Rail Assembly D – Gas Block E – Butt Stock F – Rail Clamp Screws G – Magazine Release H – Bolt Catch/Release I – Trigger J – Pistol Grip K – Safety Selector L – Forward Assist

Operator Manual : S.W.O.R.D International; MK 17 6 Issue 2 Multi-cal, Patent Pending CLEARING & UNLOADING THE FIREARM

WARNING Always assume firearms are loaded. Anytime you handle a firearm you should ensure that it is unloaded and safe. As well as always have your firearm pointed in a safe direction.

1. Place the selector lever on SAFE. If you are unable to move the selector to SAFE the hammer is likely down, proceed to step #2, insuring the firearm is pointed in a safe direction.

1. Remove the magazine by pressing the magazine release and pulling the magazine down.

1. Lock the bolt to the rear by pulling the charging handle back and pressing up on the bolt catch lever. Once the Bolt is locked open, return charging handle forward.

1. Visually inspect the chamber to ensure it is clear as well as the magazine well and bolt face. Never assume the chamber is clear without a thorough visual inspection.

FIRING PROCEDURES

NOTE Magazine may be inserted with bolt assembly open or closed.

1. Place selector lever on SAFE. If you are unable to move the selector to SAFE, pull the charging handle to the rear and release cocking the hammer, then put the selector on SAFE.

2. Insert cartridges into the magazine and then insert the magazine into the magazine well.

3. Chamber a round by pulling the charging handle rearward and releasing it. Do not ride the charging handle forward. If the bolt is already locked open you can release the bolt using the bolt release.

4. Face the target, place the firearm to your shoulder, move the selector lever from SAFE to FIRE.

5. Align the front and rear sight with the target and squeeze the trigger.

Operator Manual : S.W.O.R.D International; MK 17 7 Issue 2 Multi-cal, Patent Pending DISASSEMBLY INSTRUCTIONS

WARNING ALWAYS clear the firearm before disassembly, cleaning, inspecting, transporting or storing.

1. Clear your firearm. 2. Only use hand pressure to disengage the pivot and take-down pins. 3. Only push the pivot and take-down pins far enough to disengage the upper receiver from the lower receiver. 4. Separate the upper and lower receivers. 5. Pull back charging handle. 6. Remove bolt carrier from upper receiver.

EXTRACTOR REMOVAL

Disassemble using the following steps only when dirty or damaged. Also ensure, you have a clean work area where you can maintain positive control of components. 1. Using 1/16” punch and small hammer remove extractor pivot pin retaining pin. 2. Remove extractor pin. 3. Remove extractor and spring assembly.

NOTE Do not separate spring assembly from the extractor.

BUFFER/STOCK REMOVAL

1. Press in buffer, depress retainer, then release buffer.

2. Remove buffer and action spring.

3. Depress stock slide lock and fully extend.

4. Pull down firmly on protrusions forward of stock slide lock.

5. Remove stock from receiver extension.

To reinstall repeat the above steps only this time placing the butt stock back onto the receiver extension and reinstall the hardware with proper tools.

Operator Manual : S.W.O.R.D International; MK 17 8 Issue 2 Multi-cal, Patent Pending OPROD REMOVAL INSTRUCTIONS

WARNING ALWAYS clear the firearm before disassembly, cleaning, inspecting, transporting or storing.

1. Clear your firearm. 2. Remove the bolt carrier assembly. 3. Using a 3mm hex key remove the rail clamp bolts. (fig 1) 4. Remove the rail. 5. Hold the piston in place and slide the OPROD into the upper receiver. (fig 2) 6. Move the OPROD to the side (as seen from above) to clear the OPROD bushing retainer. 7. Remove piston from gas block. 8. Remove any build up found on piston, lightly oil. (fig 3) 9. Reassemble in reverse order.

Fig 1 Rail Clamp Screws

Slide rearward and to the side. Hold piston Fig 2

Clean and lightly oil

Fig 3

Operator Manual : S.W.O.R.D International; MK 17 9 Issue 2 Multi-cal, Patent Pending BOLT CARRIER DISASSEMBLY INSTRUCTIONS

WARNING ALWAYS clear the firearm before disassembly, cleaning, inspecting, transporting or storing.

1. Clear rifle 2. Remove bolt carrier assembly from upper receiver. 3. Remove retaining pin. (Figure 1) 4. Remove firing pin. 5. Remove cam pin. 6. Remove bolt. 7. Lightly clean and oil all parts. 8. Reassemble in reverse order.

Figure 1

Firing pin retaining pin

Figure 2

Firing pin retaining pin Bolt carrier

Firing pin

Bolt Cam pin

Operator Manual : S.W.O.R.D International; MK 17 10 Issue 2 Multi-cal, Patent Pending TROUBLESHOOTING

This section covers possible malfunctions and the corrective action(s) needed to correct that malfunction. In the unlikely event the malfunction is not corrected, or you feel it's above your knowledge or abilities, then please contact S.W.O.R.D. International, Inc. for service.

We do not recommend taking our rifles to an outside gunsmith as they will be unfamiliar with our operating system and procedures for conducting repairs.

MALFUNCTION POSSIBLE CAUSE REMEDIAL ACTION Dirty magazine catch Disassemble and clean

Magazine doesn't lock into Worn/broken parts Contract S.W.O.R.D. rifle Defective magazine catch Contact S.W.O.R.D. spring

Short stroke on recoil See Short Stroke section on next page Failure to feed Weak magazine spring Inspect and replace if needed.

Short stroke on recoil See Short Stroke section on next page Failure to chamber Dirty chamber Clean firearm Damaged buffer spring Contact S.W.O.R.D.

Improperly assembled bolt Assemble bolt correctly Bend OPROD (inside Contact S.W.O.R.D. upper receiver) Failure to lock into battery Broken buffer spring Contact S.W.O.R.D. Dirty firearm Contact S.W.O.R.D.

Dirty bolt assembly Disassemble and clean Broken firing pin Contact S.W.O.R.D. Broken/missing firing pin Contact S.W.O.R.D. retaining pin Failure to fire Improperly assembled Contact S.W.O.R.D. lower receiver Contact S.W.O.R.D. Broken trigger group

Operator Manual : S.W.O.R.D International; MK 17 11 Issue 2 Multi-cal, Patent Pending TROUBLESHOOTING

MALFUNCTION POSSIBLE CAUSE REMEDIAL ACTION

Bent OPROD (outside Contact S.W.O.R.D. upper receiver) Plugged barrel gas port Contact S.W.O.R.D. Failure to unlock Plugged gas block port Contact S.W.O.R.D. Improper ammunition Refer to the Ammunition section of this manual for recommended ammunition

Broken extractor, extractor Failure to extract pivot pin, or extractor Contact S.W.O.R.D. spring

Short stroke on recoil See Short Stroke section below Failure to eject Broken ejector or ejector Contact S.W.O.R.D. spring

Short stroke on recoil See Short Stroke section below Failure to cock Damaged trigger group Contact S.W.O.R.D.

Damaged OPROD Plugged barrel gas port Short Stroke Contact S.W.O.R.D. Plugged gas block port Damaged piston rings

Operator Manual : S.W.O.R.D International; MK 17 12 Issue 2 Multi-cal, Patent Pending NOTES

______Proudly Manufactured

In the U.S.A Operator Manual : S.W.O.R.D International; MK 17 13 Issue 2 Multi-cal, Patent Pending
