SOFAMOR DANEK ® TrimLine Anterior Cervical Discectomy & Fusion Instrument Set A comprehensive color coded, streamlined cervical instrument set designed specifically for ACDF procedures. Anterior Cervical Discectomy and Graft Curettes Fusion Instrument Set Placement Instruments Color coded handles to differentiate sizes The TrimLine ACDF Instrument Set has been designed Can be used with autograft or allograft Hand polished cutting specifically for standard cervical anterior approaches, Holder/Introducer will not leave a hole in surfaces to help discectomies, and fusions. It includes instruments necessary the graft maintain sharp edges to perform the cervical exposure, decompression, graft harvest, Ergonomically designed handles Fully machined and placement. Instruments are color coded to simplify components to enhance identification and this feature allows the procedure to product run more smoothly. Instruments can be purchased consistency separately or as part of the TrimLine Set. Kerrisons Color coded handles to differentiate sizes Hand polished cutting surfaces to help maintain sharp edges Fully machined components to enhance product consistency Pin Distraction Set Universally acceptable Self-Retaining instruments Retractors Improved pin strength Right and left options Generic blade for use with either fixed or rotating Hand-Held modular blade handles Retractors Modular blade handles can be removed after retractor frame is added Aluminum blades for better imaging Improved side-loading connection mechanism Ergonomically designed handles Radiolucent blades to enhance imaging TRIMLINE® ACDF INSTRUMENT SET Cat. # Color Product Description Cat. # Color Product Description FORCEPS CURETTES/MICRO CURETTES (CONTINUED) 875-001 Bayonet Forceps, 8” 875-307 Curette Straight 2 875-002 Forceps, 7” 875-310 Curette Angled 6-0 875-003 Forceps with Teeth, 7” 875-312 Curette Angled 4-0 875-004 Tonsile Clamp, Curved, 71⁄4” 875-313 Curette Angled 3-0 875-005 Needle Holder, 8” 875-314 Curette Angled 2-0 DISSECTORS 875-315 Curette Angled 1-0 875-020 Metzenbaum Dissecting Scissors, Straight, 7” 875-370 Micro Curette Straight 6-0 875-021 Metzenbaum Dissecting Scissors, Curved, 7” 875-372 Micro Curette Straight 4-0 875-022 Penfield No. 4 875-373 Micro Curette Straight 3-0 HAND-HELD RETRACTORS 875-374 Micro Curette Straight 2-0 875-040 Gelpi, 51⁄4” 875-380 Micro Curette Angled 6-0 875-041 Weitlaner Retractor, Sharp, 43⁄8” 875-382 Micro Curette Angled 4-0 875-042 Army-Navy Retractor 875-383 Micro Curette Angled 3-0 875-050 Hand-Held Retractor, Straight, 18mm 875-384 Micro Curette Angled 2-0 875-051 Small Hand-Held Retractor, Straight, 18mm MICRO INSTRUMENTS 875-052 Hand-Held Retractor, Back Lip, 20mm 875-501 Micro Nerve Hook, Small Blunt 875-053 Hand-Held Retractor, Curved, 23mm 875-502 Micro Nerve Hook, Large Blunt SELF-RETAINING RETRACTORS 875-503 Micro Dental Dissector 875-110 Transverse Self-Retaining Retractor Frame MEASURING DEVICES 875-115 Longitudinal Self-Retaining Retractor Frame 875-530 Caliper 875-148 Retractor Blade Handle, Fixed 950-146 Ruler 875-149 Retractor Blade Handle OSTEOTOMES/ELEVATORS BLADES 875-601 Osteotome, Straight, 10mm 875-150 23 x 30mm Discectomy Blade 875-602 Osteotome, Curved, 10mm 875-152 23 x 40mm Discectomy Blade 875-030 1⁄4” Key Periosteal Elevator 875-154 23 x 50mm Discectomy Blade GRAFT PREPARATION/PLACEMENT INSTRUMENTS 875-156 23 x 60mm Discectomy Blade 875-650 Langenbeck Periosteal Elevator, 16mm 875-158 23 x 70mm Discectomy Blade 875-655 Kocher Forcep 875-160 20 x 30mm Longitudinal Blade 875-701 Graft Holder/Introducer 875-162 20 x 40mm Longitudinal Blade 875-708 8mm Tapper 875-164 20 x 50mm Longitudinal Blade 875-712 6mm x 12mm Tapper 875-166 20 x 60mm Longitudinal Blade 875-715 Mallet, 8” 875-168 20 x 70mm Longitudinal Blade PIN DISTRACTOR SET PIN DISTRACTOR SET 875-080 Vertebral Body Distractor (Right) 875-087 12mm Distractor Pins, (10/Pkg) Sterile 875-081 Vertebral Body Distractor (Left) 875-088 14mm Distractor Pins, (10/Pkg) Sterile 875-090 Distractor Screwdriver 875-089 16mm Distractor Pins, (10/Pkg) Sterile 875-084 Drill Guide (Right) KERRISONS 875-086 Twist Drill 875-251 1mm Kerrison CASES 875-252 2mm Kerrison 875-940 Exposure Case 875-253 3mm Kerrison 875-941 Decompression Case RONGEURS 875-942 Graft Harvest/Placement Case 875-260 Leksell Rongeur, 6mm 875-944 Hand-Held Retractor Case 875-265 Micro Pituitary With 1mm Tooth 875-945 Self-Retaining Retractor Case 875-266 2mm Micro Pituitary, 6” 875-946 Curette Case 875-267 3 x 10mm Pituitary, 7” 875-947 Micro Curette Case 875-268 3 x 10mm Up Bite Pituitary, 7” 875-948 Kerrison Case CURETTES/MICRO CURETTES 875-949 Graft Instrument Case 875-300 Curette Straight 6-0 875-950 Distractor Case 875-302 Curette Straight 4-0 875-303 Curette Straight 3-0 875-304 Curette Straight 2-0 875-305 Curette Straight 1-0 SOFAMOR DANEK See package insert for labeling limitations. MEDTRONIC SOFAMOR DANEK USA, INC. CUSTOMER SERVICE: 1800 PYRAMID PLACE 800-933-2635 For product availability or more information on this product, MEMPHIS, TN 38132 www.sofamordanek.com contact your MEDTRONIC SOFAMOR DANEK USA, INC. Sales Associate, (901) 396-3133 or call MEDTRONIC SOFAMOR DANEK USA, INC. (800) 876-3133 Customer Service toll free: (800) 933-2635. ©2002 Medtronic Sofamor Danek USA, Inc. All Rights Reserved. LIT-ACDF-BRO96 REV. C 4/02.
