Using Sensor Data from Building Automation Systems in Digital Twins Nutzung Von Sensordaten Der Gebäudeautomation in Digitalen Zwillingen

Faculty of Civil Engineering, Institute of Construction Informatics

Using Sensor Data from Building Automation Systems in Digital Twins Nutzung von Sensordaten der Gebäudeautomation in Digitalen Zwillingen

Rehan Ahmad Khan

from

Noida, India

Master Thesis submitted to the Faculty of Civil Engineering, Institute of Construction Informatics, University of Technology Dresden in partial fulfilment of the requirements for the degree of

Master of Science

Responsible Professor: Prof. Dr.-Ing. habil. Karsten Menzel Second Examiner: Prof. Dr.-Ing. John Grunewald Scientific Supervisor: Dipl.-Ing. Adrian Schubert

Dresden, 16th November 2020

Declaration

I confirm that this assignment is my own work and that I have not sought or used the inadmissible help of third parties to produce this work. I have fully referenced and used inverted commas for all text directly quoted from a source. Any indirect quotations have been duly marked as such.

This work has not yet been submitted to another examination institution – neither in Germany nor outside Germany – neither in the same nor in a similar way and has not yet been published.

Dresden,

Place, Date

Signature

Acknowledgment

First and foremost, I feel a sense of obligation in conveying my sincere gratitude to Prof. Dr.-Ing habil. Karsten Menzel, Chair of the “Institute of Construction Informatics” and Prof. Dr.-Ing John Grunewald, Chair of the “Institute of Building Physics” for providing me the opportunity to work on my master thesis and having faith in my work.

Furthermore, I am honestly indebted to Dipl.-Ing. Adrian Schubert for his constant backing and supervision during the course of the work. Alongside this, I would also like to acknowledge the necessary help provided by all the staff at the “Institute of Construction Informatics” for their invaluable assistance.

Finally, I am thankful to my family- my parents and my siblings for their relentless support and continuous encouragement throughout my career. Without your endless support and love, I cannot comprehend reaching this stage.

Abstract

A Digital Twin, as a means to link digital models and simulations with real-world data, establishes new possibilities for improved creativity, competitive leverage, and human-centered design. Digital Twins can help deliver on the imposing challenges facing society, including achieving the United Nations Sustainable Development Goals and addressing rapid urbanization, population growth, and escalating infrastructure costs.

On the technological front, three major advancements have enabled the concept of Digital Twin; namely computing capability, sensors, and visualization. Recent computing advancements have enabled us to process, store, and communicate a massive amount of information used to operate modern buildings. The second technological improvement is through sensors, which have enabled the rise of smart buildings. Buildings can now be made to sense and communicate their precise status to permit us to know and manipulate exactly what is occurring within, simply by examining their Digital Twin. The third technology amelioration has been visualization, thus enabling us to render geometric designs virtually, in breath-taking constancy. With 3D visualization, we can merge the Digital Twin with its corresponding physical building, in order to see how the building is performing and rectify failures beforehand.

In the research study, sensed and metered data recorded from the building automation system installed at the Institute of Construction Informatics (NUR31) at TU Dresden, is used as a reference for the calibration of the Energy Simulation model in IESVE software. Subsequently, the output from the calibrated IES model is used to visualize the energy data in the Unity3D model, in order to establish a “proof of concept” for a Digital Twin of the Institute of Construction Informatics. Thus the creation of a Digital Twin bridges the gap between the physical and digital worlds through sensors that collect real-time data within the physical environment. Thus providing a real-time understanding of how a building is performing – enabling immediate adjustment to optimize efficiency and to provide data to improve the design of future buildings.
