Luc. 4 / 3rd class petrochemical industries

Petroleum Products

Petroleum products are materials derived from crude oil (petroleum) as it is processed in oil refineries. Unlike petrochemicals, which are a collection of well- defined usually pure chemical compounds, petroleum products are complex mixtures. The majority of petroleum is converted to petroleum products, which includes several classes of fuels.[1] According to the composition of the crude oil and depending on the demands of the market, refineries can produce different shares of petroleum products. The largest share of oil products is used as "energy carriers", i.e. various grades of fuel oil and gasoline. These fuels include or can be blended to give gasoline, jet fuel, diesel fuel, heating oil, and heavier fuel oils. Heavier (less volatile) fractions can also be used to produce asphalt, tar, paraffin wax, lubricating and other heavy oils. Refineries also produce other chemicals, some of which are used in chemical processes to produce plastics and other useful materials. Since petroleum often contains a few percent sulfur-containing molecules, elemental sulfur is also often produced as a petroleum product. Carbon, in the form of petroleum coke, and hydrogen may also be produced as petroleum products. The hydrogen produced is often used as an intermediate product for other oil refinery processes such as hydrocracking and hydrodesulfurization.

Gaseous fuels such as propane, stored and shipped in liquid form under pressure in specialized railcars to distributors.

Liquid fuels blending (producing automotive and aviation grades of gasoline, kerosene, various aviation turbine fuels, and diesel fuels, adding dyes, detergents, antiknock additives, oxygenates, and anti-fungal compounds as required). Shipped by barge, rail, and tanker ship. May be shipped regionally in dedicated pipelines to point consumers, particularly aviation jet fuel to major airports, or piped to distributors in multi-product pipelines using product separators called pipeline inspection gauges ("pigs").

Asphalt - used as a binder for gravel to form asphalt concrete, which is used for paving roads, lots, etc. An asphalt unit prepares bulk asphalt for shipment.

Asphalt, also known as bitumen (UK: /ˈbɪtjʊmɪn/, US: /bɪˈtjuːmən, baɪ-/),[1] is a sticky, black, and highly viscous liquid or semi-solid form of petroleum. It may be found in natural deposits or may be a refined product, and is classed as a pitch.

1

Luc. 4 / 3rd class petrochemical industries

Before the 20th century, the term asphaltum was also used.[2] The word is derived from the Ancient Greek ἄσφαλτος ásphaltos.

The primary use (70%) of asphalt is in road construction, where it is used as the glue or binder mixed with aggregate particles to create asphalt concrete. Its other main uses are for bituminous waterproofing products, including production of roofing felt and for sealing flat roofs.[3]

The terms "asphalt" and "bitumen" are often used interchangeably to mean both natural and manufactured forms of the substance. In American English, "asphalt" (or "asphalt cement") is commonly used for a refined residue from the distillation process of selected crude oils. Outside the United States, the product is often called "bitumen", and geologists worldwide often prefer the term for the naturally occurring variety. Common colloquial usage often refers to various forms of asphalt as "tar", as in the name of the La Brea Tar Pits.

Naturally occurring asphalt is sometimes specified by the term "crude bitumen". Its viscosity is similar to that of cold molasses[4][5] while the material obtained from the fractional distillation of crude oil boiling at 525 °C (977 °F) is sometimes referred to as "refined bitumen". The Canadian province of Alberta has most of the world's reserves of natural asphalt in the Athabasca oil sands, which cover 142,000 square kilometres (55,000 sq mi), an area larger than England.

Composition

Normal composition The components of asphalt include four main classes of compounds:

 Naphthene aromatics (naphthalene), consisting of partially hydrogenated polycyclic aromatic compounds  Polar aromatics, consisting of high molecular weight phenols and carboxylic acids produced by partial oxidation of the material

2

Luc. 4 / 3rd class petrochemical industries

 Saturated hydrocarbons; the percentage of saturated compounds in asphalt correlates with its softening point  Asphaltenes, consisting of high molecular weight phenols and heterocyclic compounds The naphthene aromatics and polar aromatics are typically the majority components. Most natural bitumens also contain organosulfur compounds, resulting in an overall sulfur content of up to 4%. Nickel and vanadium are found at <10 parts per million, as is typical of some petroleum.[3] The substance is soluble in carbon disulfide. It is commonly modelled as a colloid, with asphaltenes as the dispersed phase and maltenes as the continuous phase.[13] "It is almost impossible to separate and identify all the different molecules of asphalt, because the number of molecules with different chemical structure is extremely large".[14] Asphalt may be confused with coal tar, which is a visually similar black, thermoplastic material produced by the destructive distillation of coal. During the early and mid-20th century, when town gas was produced, coal tar was a readily available byproduct and extensively used as the binder for road aggregates. The addition of coal tar to macadam roads led to the word "tarmac", which is now used in common parlance to refer to road-making materials. However, since the 1970s, when natural gas succeeded town gas, asphalt has completely overtaken the use of coal tar in these applications. Other examples of this confusion include the La Brea Tar Pits and the Canadian oil sands, both of which actually contain natural bitumen rather than tar. "Pitch" is another term sometimes informally used at times to refer to asphalt, as in Pitch Lake. Occurrence

Bituminous outcrop of the Puy de la Poix, Clermont-Ferrand, France The majority of asphalt used commercially is obtained from petroleum.[16] Nonetheless, large amounts of asphalt occur in concentrated form in nature. Naturally occurring deposits of bitumen are formed from the remains of ancient, microscopic algae (diatoms) and other once-living things. These remains were deposited in the mud on the bottom of the ocean or lake where the organisms lived. Under the heat (above 50 °C) and pressure of burial deep in the earth, the remains were transformed into materials such as bitumen, kerogen, or petroleum.

Natural deposits of bitumen include lakes such as the Pitch Lake in Trinidad and Tobago and Lake Bermudez in Venezuela. Natural seeps occur in the La Brea Tar Pits and in the Dead Sea.

3

Luc. 4 / 3rd class petrochemical industries

Bitumen also occurs in unconsolidated sandstones known as "oil sands" in Alberta, Canada, and the similar "tar sands" in Utah.

Petroleum coke, used in specialty carbon products such as certain types of electrodes, or as solid fuel.

Petroleum coke, abbreviated coke or petcoke, is a final carbon-rich solid material that derives from oil refining, and is one type of the group of fuels referred to as cokes. Petcoke is the coke that, in particular, derives from a final cracking process—a thermo-based chemical engineering process that splits long chain hydrocarbons of petroleum into shorter chains—that takes place in units termed coker units.[1] (Other types of coke are derived from coal.) Stated succinctly, coke is the "carbonization product of high-boiling hydrocarbon fractions obtained in petroleum processing (heavy residues)."[2] Petcoke is also produced in the production of synthetic crude oil (syncrude) from bitumen extracted from Canada’s oil sands and from Venezuela's Orinoco oil sands.

In petroleum coker units, residual oils from other distillation processes used in petroleum refining are treated at a high temperature and pressure leaving the petcoke after driving off gases and volatiles, and separating off remaining light and heavy oils. These processes are termed "coking processes", and most typically employ chemical engineering plant operations for the specific process of delayed coking.

Petrochemicals or petrochemical feedstocks. Petrochemical are organic compounds that are the ingredients for the chemical industry, ranging from polymers and pharmaceuticals. Representative petrochemicals are ethylene and benzene-toluene-xylenes ("BTX").

Types of petroleum coke

There are at least four basic types of petroleum coke, namely, needle coke, honeycomb coke, sponge coke and shot coke. Different types of petroleum coke have different microstructures due to differences in operating variables and nature of feedstock. Significant differences are also to be observed in the properties of the different types of coke, particularly ash and volatile matter contents.[5]

4

Luc. 4 / 3rd class petrochemical industries

Needle coke, also called acicular coke, is a highly crystalline petroleum coke used in the production of electrodes for the steel and aluminium industries and is particularly valuable because the electrodes must be replaced regularly. Needle coke is produced exclusively from either FCC decant oil or coal tar pitch.

Honeycomb coke is an intermediate coke, with ellipsoidal pores that are uniformly distributed. Compared to needle coke, honeycomb coke has a lower coefficient of thermal expansion and a lower electrical conductivity.[5]

Fuel-grade coke

Fuel-grade coke is classified as either sponge coke or shot coke morphology. While oil refiners have been producing coke for over 100 years, the mechanisms that cause sponge coke or shot coke to form are not well understood and cannot be accurately predicted. In general, lower temperatures and higher pressures promote sponge coke formation. Additionally, the amount of heptane insolubles present and the fraction of light components in the coker feed contribute.

While its high heat and low ash content make it a decent fuel for power generation in coal-fired boilers, petroleum coke is high in sulfur and low in volatile content, and this poses environmental (and technical) problems with its combustion. Its gross calorific value (HHV) is nearly 8000 Kcal/kg which is twice the value of average coal used in electricity generation.[6]. A common choice of sulfur recovering unit for burning petroleum coke is the SNOX Flue gas desulfurisation technology,[7] which is based on the well-known WSA Process. Fluidized bed combustion is commonly used to burn petroleum coke. Gasification is increasingly used with this feedstock (often using gasifiers placed in the refineries themselves).

Calcined petroleum coke

Calcined petroleum coke (CPC) is the product from calcining petroleum coke. This coke is the product of the coker unit in a crude oil refinery. The calcined petroleum coke is used to make anodes for the aluminium, steel and titanium smelting industry. The green coke must have sufficiently low metal content to be used as anode material. Green coke with this low metal content is called anode- grade coke. When green coke has excessive metal content, it is not calcined and is used as fuel-grade coke in furnaces.

Desulfurization of petcoke

5

Luc. 4 / 3rd class petrochemical industries

A high sulfur content in petcoke reduces its market value, and may preclude its use as fuel due to restrictions on sulfur oxides emissions for environmental reasons. Methods have thus been proposed to reduce or eliminate the sulfur content of petcoke. Most of them involve the desorption of the inorganic sulfur present in the pores or surface of the coke, and the partition and removal of the organic sulfur attached to the aromatic carbon skeleton. Potential petroleum desulfurization techniques can be classified as follows:[8]

1. Solvent extraction 2. Chemical treatment 3. Thermal desulfurization 4. Desulfurization in an oxidizing atmosphere 5. Desulfurization in an atmosphere of sulfur-bearing gas 6. Desulfurization in an atmosphere of hydrocarbon gases 7. Hydrodesulfurization

Waxes

Waxes are a diverse class of organic compounds that are lipophilic, malleable solids near ambient temperatures. They include higher alkanes and lipids, typically with melting points above about 40 °C (104 °F), melting to give low viscosity liquids. Waxes are insoluble in water but soluble in organic, nonpolar solvents. Natural waxes of different types are produced by plants and animals and occur in petroleum.

Petroleum derived waxes

Although many natural waxes contain esters, paraffin waxes are hydrocarbons, mixtures of alkanes usually in a homologous series of chain lengths. These materials represent a significant fraction of petroleum. They are refined by vacuum distillation. Paraffin waxes are mixtures of saturated n- and iso- alkanes, naphthenes, and alkyl- and naphthene-substituted aromatic compounds. A typical alkane paraffin wax chemical composition comprises hydrocarbons with the general formula CnH2n+2, such as Hentriacontane, C31H64. The degree of branching has an important influence on the properties. Microcrystalline wax is a lesser produced petroleum based wax that contains higher percentage of isoparaffinic (branched) hydrocarbons and naphthenic hydrocarbons.

Millions of tons of paraffin waxes are produced annually. They are used in foods (such as chewing gum and cheese wrapping), in candles and cosmetics, as non- stick and waterproofing coatings and in polishes.

6

Luc. 4 / 3rd class petrochemical industries

Paraffin wax, used in the packaging of frozen foods, among others. May be shipped in bulk to a site to prepare as packaged blocks.

Paraffin wax is a soft colourless solid, derived from petroleum, coal or oil shale, that consists of a mixture of hydrocarbon molecules containing between twenty and forty carbon atoms. It is solid at room temperature and begins to melt above approximately 37 °C (99 °F);[1] its boiling point is >370 °C (698 °F). Common applications for paraffin wax include lubrication, electrical insulation, and candles; [3] dyed paraffin wax can be made into crayons. It is distinct from kerosene and other petroleum products that are sometimes called paraffin. Un-dyed, unscented paraffin candles are odorless and bluish-white. Paraffin wax was first created in 1830 in Germany, and marked a major advancement in candlemaking technology, as it burned more cleanly and reliably than tallow candles and was cheaper to produce.

Properties

Paraffin wax is mostly found as a white, odorless, tasteless, waxy solid, with a typical melting point between about 46 and 68 °C (115 and 154 °F),[7] and a density of around 900 kg/m3.[8] It is insoluble in water, but soluble in ether, benzene, and certain esters. Paraffin is unaffected by most common chemical reagents but burns readily.[9] Its heat of combustion is 42 MJ/kg.

The hydrocarbon C31H64 is a typical component of paraffin wax.

Paraffin wax is an excellent electrical insulator, with a resistivity of between 1013 and 1017 ohm metre.[10] This is better than nearly all other materials except some plastics (notably Teflon). It is an effective neutron moderator and was used in James Chadwick's 1932 experiments to identify the neutron.[11][12]

Paraffin wax is an excellent material for storing heat, with a specific heat capacity of 2.14–2.9 J g−1 K−1 (joules per gram kelvin) and a heat of fusion of 200–220 J g−1.[13] Paraffin wax phase-change cooling coupled with retractable radiators was used to cool the electronics of the Lunar Roving Vehicle during the manned

7

Luc. 4 / 3rd class petrochemical industries missions to the Moon in the early 1970s.[14] Wax expands considerably when it melts and this allows its use in wax element thermostats for industrial, domestic and, particularly, automobile purposes.

Manufacturing

The feedstock for paraffin is slack wax, which is a mixture of oil and wax, a byproduct from the refining of lubricating oil.

The first step in making paraffin wax is to remove the oil (de-oiling or de-waxing) from the slack wax. The oil is separated by crystallization. Most commonly, the slack wax is heated, mixed with one or more solvents such as a ketone and then cooled. As it cools, wax crystallizes out of the solution, leaving only oil. This mixture is filtered into two streams: solid (wax plus some solvent) and liquid (oil and solvent). After the solvent is recovered by distillation, the resulting products are called "product wax" (or "press wax") and "foots oil". The lower the percentage of oil in the wax, the more refined it is considered (semi-refined versus fully refined).[17] The product wax may be further processed to remove colors and odors. The wax may finally be blended together to give certain desired properties such as melt point and penetration. Paraffin wax is sold in either liquid or solid form.

Applications

In industrial applications, it is often useful to modify the crystal properties of the paraffin wax, typically by adding branching to the existing carbon backbone chain. The modification is usually done with additives, such as EVA copolymers, microcrystalline wax, or forms of polyethylene. The branched properties result in a modified paraffin with a higher viscosity, smaller crystalline structure, and modified functional properties. Pure paraffin wax is rarely used for carving original models for casting metal and other materials in the lost wax process, as it is relatively brittle at room temperature and presents the risks of chipping and breakage when worked. Soft and pliable waxes, like beeswax, may be preferred for such sculpture, but "investment casting waxes," often paraffin-based, are expressly formulated for the purpose.

In a pathology laboratory, paraffin wax is used to impregnate tissue prior to sectioning thin samples of tissue. Water is removed from the tissue through ascending strengths of alcohol (75% to absolute) and the tissue is cleared in an organic solvent such as xylene. The tissue is then placed in paraffin wax for a number of hours and then set in a mold with wax to cool and solidify; sections are then cut on a microtome.

8

Luc. 4 / 3rd class petrochemical industries

Slack wax, a raw refinery output comprising a mixture of oil and wax used as a precursor for scale wax and paraffin wax and as-is in non-food products such as wax emulsions, construction board, matches, candles, rust protection, and vapor barriers.

Chemistry

Ceroline brand wax for floors and furniture, first half of 20th century. From the Museo del Objeto del Objeto collection

Waxes are organic compounds that characteristically consist of long alkyl chains. They may also include various functional groups such as fatty acids, primary and secondary long chain alcohols, unsaturated bonds, aromatics, amides, ketones, and aldehydes. They frequently contain fatty acid esters as well. Synthetic waxes are often long-chain hydrocarbons (alkanes or paraffins) that lack functional groups.[1]

Plant and animal waxes

Waxes are synthesized by many plants and animals. Those of animal origin typically consist of wax esters derived from a variety of carboxylic acids and fatty alcohols. In waxes of plant origin, characteristic mixtures of unesterified hydrocarbons may predominate over esters.The composition depends not only on species, but also on geographic location of the organism.

Animal waxes

The most commonly known animal wax is beeswax, but other insects secrete (release) waxes. A major component of the beeswax used in constructing honeycombs is the ester myricyl palmitate which is an ester of triacontanol and palmitic acid. Its melting point is 62-65 °C. Spermaceti occurs in large amounts in the head oil of the sperm whale. One of its main constituents is cetyl palmitate, another ester of a fatty acid and a fatty alcohol. Lanolin is a wax obtained from wool, consisting of esters of sterols.[1]

9

Luc. 4 / 3rd class petrochemical industries

Plant waxes

Plants secrete waxes into and on the surface of their cuticles as a way to control evaporation, wettability and hydration.[3] The epicuticular waxes of plants are mixtures of substituted long-chain aliphatic hydrocarbons, containing alkanes, alkyl esters, fatty acids, primary and secondary alcohols, diols, ketones, aldehydes.[2] From the commercial perspective, the most important plant wax is carnauba wax, a hard wax obtained from the Brazilian palm Copernicia prunifera. Containing the ester myricyl cerotate, it has many applications, such as confectionery and other food coatings, car and furniture polish, floss coating, and surfboard wax. Other more specialized vegetable waxes include candelilla wax and ouricury wax.

Modified plant and animal waxes

Plant and animal based waxes or oils can undergo selective chemical modifications to produce waxes with more desirable properties than are available in the unmodified starting material.[4] This approach has relied on green chemistry approaches including olefin metathesis and enzymatic reactions and can be used to produce waxes from inexpensive starting materials like vegetable oils.[5][6]

Petroleum by-products

Over 6,000 items are made from petroleum waste by-products, including: fertilizer, flooring (floor covering), perfume, insecticide, petroleum jelly, soap, vitamins and some essential amino acids.
