Total Control Products, Inc

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
Total Control Products, Inc Allen-Bradley Allen-Bradley SLC 500 Setup for using an A-B SLC 500 Use the following procedure to ensure your target device is setup properly for the Allen-Bradley SLC 500. The procedure is in condensed format. Only the required settings are outlined. For additional details, see Creating a New Project beginning on page 3. Project Setup The drawing is a diagram of the Project Setup dialog box. Each button will display an additional dialog box. Many settings are options and are not required to establish communications. Verify the Project name and Display Device Model are correct. Leave the Initial Screen name blank. Project Setup Project Notes Project name: Project name appears in this field More Disable Beeper Display Device Model Model description appears in this field Default Panel Name Initial Screen Print (Inactive) Screen Saver Timeout Display Touch Print PLC Protocol setup PLC & Protocols Panel Trigger Tag Electrical Format CN1 PLC Type PLC Protocol name appears here Watchdog Tag Serial Parameters Watchdog timeout Port Protocol System OK Cancel Help PLC Type Select the PLC type from the list box. (AB SLC DH485). See PLC Type on page 5. QUICKDESIGNER Allen-Bradley • 11 Port Button Click the Port button to display the Serial Parameters dialog. The port values are automatically set to standard default values. See Serial Parameters on page 6. The following settings are recommended for AB SLC DH485. Elect. Format RS422 Half Duplex (When using the HMI-CAB-C83 Cable) or Elect. Format RS232 (When using the HMI-CAB-C84 Cable) Baud Rate 19200 Data Bits 8 Parity Even Stop Bits 1 Handshake None Protocol Button Click the Protocol button to display the dialog box associated with the selected PLC. The Source ID is the target display address on the DH485 network. The Destination ID is the PLC address where the target display will get variable data. The Maximum node ID is the highest available address on the DH485 network. The maximum ID should be set to the lowest possible number. Enter Timeout in seconds. Click OK to return to the Project Setup dialog box. Protected Files Processor files with Owner set cannot be written to by QUICKPANEL The Set and Clear Owner function allows a terminal to "own" one or more processor files on the network. Ownership means that as long as the owner is active on the network, other terminals can not access the on-line functions of the owned processor files. Note that only a programmer can own a node. In the following example, station 1 is owned by node 0. Notice station node 1 has a max. address 31 followed by a forward slash and then the ownership node. If you see this on the display, a QUICKPANEL cannot write to that station. You must clear the owner. 0 TCP (31) 1 5/02 (31/0) 2 Term (31) 3 Connecting to the SLC 500 A single point connection is simply one target display connected directly to the program port of a single SLC 500. This connection is made using the HMI-CAB-C83 cable. 12 • Allen-Bradley QUICKDESIGNER HMI-CAB-C83 Cable This cable connects the target display serial port to the Allen-Bradley SLC 500 Programming Port. TO TCP DEVICE 8-PIN MODULAR PHONE RJ-45 PROPRIETARY INFORMATION THIS INFORMATION IS PROVIDED AS A HMI-CAB-C83/A CONVENIENCE TO OUR CUSTOMERS. 25-PIN MALE TO SLC 500 YOU ARE NOT AUTHORIZED TO PROGRAM PORT CONSTRUCT THIS CABLE. 4 GND 7 UNAUTHORIZED CABLES ARE orange NOT SUPPORTED BY TOTAL CONTROL. 5 SHIELD 1 green RJ-45 shield 18 (--) 15 blue TOP white 19 16 brown black 21 (+) 10 red 22 11 SLC 500 Network Connection for Programming Equipment (DH485) This connection allows two devices to be connected to the PLC. In this case, a programming terminal can be connected to the PLC using a 1747-PIC Interface Converter connected to the HMI-CAB-C84 cable. The drawing shows the connections for adding a second device to the network connection. QUICKPANEL jr. SLC 500 Fixed I/O Controller TO SLC 500 PROGRAM PORT TO TCP DEVICE TO: Allen-Bradley 1747-PIC HMI-CAB-C84 Interface Converter QUICKDESIGNER Allen-Bradley • 13 HMI-CAB-C84 Cable This cable connects the target display serial port to the Allen-Bradley SLC 500 Programming Port. The cable is designed to allow connection to additional devices such as an Allen-Bradley 1747-PIC Interface Converter. Warning: The maximum length of this cable is 6 feet. Do not attempt to make it longer. 8-PIN MODULAR PHONE(MALE) 8-PIN MODULAR PHONE(FEMALE) 25-PIN MALE 25-PIN HMI-CAB-C84/A PROPRIETARY INFORMATION CABLE LENGTH = 6' orange -8 RJ-45 THIS INFORMATION IS PROVIDED AS A CONVENIENCE green -7 shield -6 TOP TO OUR CUSTOMERS. YOU ARE NOT AUTHORIZED TO blue -5 CONSTRUCT THIS CABLE. UNAUTHORIZED CABLES ARE white -4 NOT SUPPORTED BY TOTAL CONTROL. RS232 brown -3 8-PIN MODULAR TO black -2 PHONE PLUG red -1 THE RS232 CONVERTER CIRCUITS ARE CONTAINED ON RS422 orange -8 A CIRCUIT BOARD WITHIN THE 25-PIN D-SHELL. THE CIRCUIT green -7 (G) shield -6 ELECTRONIC CIRCUIT PROVIDES NETWORK CONTROL. 25-pin male D 25-pin male BOARD blue -5 (E) THE CIRCUIT DIAGRAM IS PROPRIETARY INFORMATION. white -4 THE CABLE IS LICENSED FROM ALLEN-BRADLEY. brown -3 black -2 ( - ) 8-PIN MODULAR red -1 (+) PHONE JACK CABLE LENGTH = 1' SLC 500 Network Connection using 1747 AIC Link Couplers (DH485) 14 • Allen-Bradley QUICKDESIGNER Connecting to a 1747 AIC Module (DH485) Connect the HMI-CAB-C84 cable to the 1747 AIC Module as shown below. QUICKPANEL jr. TO SLC 500 PROGRAM PORT DH485 Interface Peripheral - J2 CPU -J1 TO TCP DEVICE 1747-AIC MODULE TO: Allen-Bradley 1747-PIC HMI-CAB-C84 Interface Converter SLC 5/03 and SLC 5/04 Channel 0 Connection The SLC 5/03 and SLC 5/04 processors let you operate DF1 communication protocol by means of the RS-232 communication port, channel 0. In addition, the SLC 5/03 and SLC 5/04 processors support DH485 communication via channel 0. The 9-Pin connector on the SLC 5/03 and SLC 5/04 processors is programmable. The SLC 5/03 and SLC 5/04 processors can be configured for port-to-port connection using the HMI-CAB-C52 cable. Channel 0 must be set up as a DH485 master. This configuration can only read/write variables in the local PLC. Since it is not dependent on network loading, this configuration will provide quick display updates. QUICKDESIGNER Allen-Bradley • 15 HMI-CAB-C52 Cable This cable is used to connect the target display to a SLC 5/03 and SLC 5/04 RS232 Channel 0 Port. A label is placed on each end of the cable to indicate which device should be connected to that end. One of the labels will also indicate the cable part number so you can quickly verify you are using the right cable for your application. You can make your own cable using the following wiring diagram. 2 2 3 3 4 4 5 6 5 25 PIN MALE PIN 25 7 9 PIN FEMALE 9 PIN TO TCP DEVICE TO PLC PORT 1 SHIELD 7 TO TCP DEVICE 8 1 HMI-CAB-C52 TO PLC PORT SLC 5/03 and SLC 5/04 DH485 Connections You can connect channel 0 of the SLC 5/03 and SLC 5/04 modules to the 1747-PIC to make a connection to the DH485 network. SLC 500 5/02 Modular Controller SLC5/04 Modular Controller SLC 5/04 CPU RUN FORCE FLT DH+ BATT RS232 RUN REM PROG 1747-AIC Link Coupler 1747-PIC HMI-CAB-C84 QUICK PANEL Jr. 1747-PIC Programming Station Setup for using a SLC 5/03 and SLC 5/04 Channel 0 The procedure for setup of an AB SLC 5/03 Channel 0 is basically the same as for SLC500 DH485. The Electrical Format must be set to RS232. 16 • Allen-Bradley QUICKDESIGNER SLC 5/04 Data Highway Plus Data Highway Plus implements peer-to-peer communication with a token-passing scheme to rotate link mastership among a maximum of 64 nodes. Since this method does not require polling, it helps provide time-efficient reliable data transport. The SLC 5/04 processor lets you operate DH+ communication protocol by means of the DH+ communication channel 1. The SLC 5/04 also supports full-duplex DF1 protocol using the DF1 channel 0. The 3-pin connector is for actual DH+ communication and the 8-pin connector is for monitoring DH+ communication. The DH+ LED provides an indication of the condition of the network communication. The color can be green or red. A steady on condition indicates the processor is actively communicating on the network. Flashing green indicates there are no active nodes on the network. Flashing red indicates there are duplicate nodes on the link with the same node address. SLC 5/04 CPU RUN FORCE FLT DH+ BATT RS232 RUN REM PROG DH+ Channel 1 DF1 Channel 0 SLC 5/04 DH+ Connection The drawing shows a possible configuration for DH+. PLC 5/15 QUICKPANEL SLC5/04 Modular Controller SLC 5/04 CPU RUN FORCE FLT DH+ BATT RS232 RUN REM PROG CN1 DATA HIGHWAY PLUS MODULE LINE 2 BLUE SHIELD LINE 1 CLEAR QUICKDESIGNER Allen-Bradley • 17 SLC 500 Tag Variables for DH485 Protocol The following chart lists the legal tag variable names that can be used with the SLC 500 series. The target display talks to the SLC500 using the DH485 protocol. The DH485 protocol requires each device to have a node address.
