Analysis of fires and firefighting operations on fully cellular container vessels over the period 2000 – 2015
Diploma dissertation
for the award of the academic degree
"Diplom-Wirtschaftsingenieur für Seeverkehr (FH)" (BSc equivalent in marine industrial engineering)
in the Summer semester of 2016
submitted to Bremen University of Applied Sciences – Faculty 5 "Nature and Engineering"
on the study course "Diplom-Wirtschaftsingenieur für Seeverkehr" (nautical science)
Examined by: Professor Captain Thomas Jung
Co-examiner: Captain Ute Hannemann
Submitted by: Helge Rath, Neustadtswall 14, 28199 Bremen, Germany
Phone: 0170-5582269 Email: [email protected]
Student registration no.: 355621
Date: Thursday, September 01, 2016 Foreword I
