Extension of Eigenvalue Problems on Gauss Map of Ruled Surfaces

Total Page：16

File Type：pdf, Size：1020Kb

Download full-text PDF Read full-text
Extension of Eigenvalue Problems on Gauss Map of Ruled Surfaces Preprints (www.preprints.org) | NOT PEER-REVIEWED | Posted: 20 September 2018 doi:10.20944/preprints201809.0407.v1 Peer-reviewed version available at Symmetry 2018, 10, 514; doi:10.3390/sym10100514 EXTENSION OF EIGENVALUE PROBLEMS ON GAUSS MAP OF RULED SURFACES MIEKYUNG CHOI AND YOUNG HO KIM* Abstract. A finite-type immersion or smooth map is a nice tool to classify subman- ifolds of Euclidean space, which comes from eigenvalue problem of immersion. The notion of generalized 1-type is a natural generalization of those of 1-type in the usual sense and pointwise 1-type. We classify ruled surfaces with generalized 1-type Gauss map as part of a plane, a circular cylinder, a cylinder over a base curve of an infinite type, a helicoid, a right cone and a conical surface of G-type. 1. Introduction Nash's embedding theorem enables us to study Riemannian manifolds extensively by regarding a Riemannian manifold as a submanifold of Euclidean space with sufficiently high codimension. By means of such a setting, we can have rich geometric information from the intrinsic and extrinsic properties of submanifolds of Euclidean space. Inspired by the degree of algebraic varieties, B.-Y. Chen introduced the notion of order and type of submanifolds of Euclidean space. Furthermore, he developed the theory of finite- type submanifolds and estimated the total mean curvature of compact submanifolds of Euclidean space in the late 1970s ([3]). In particular, the notion of finite-type immersion is a direct generalization of eigen- value problem relative to the immersion of a Riemannian manifold into a Euclidean space: Let x : M ! Em be an isometric immersion of a submanifold M into the Eu- clidean m-space Em and ∆ the Laplace operator of M in Em. The submanifold M is said to be of finite-type if x has a spectral decomposition by x = x0 + x1 + ::: + xk, where x0 is a constant vector and xi are the vector fields satisfying ∆xi = λixi for some λi 2 R (i = 1; 2; :::; k). If the eigenvalues λ1; λ2; :::; λk are different, it is called k-type. Since this notion was introduced, many works have been made in this area (see [3, 5]). This notion of finite-type immersion was naturally extended to that of pseudo-Riemannian manifolds in pseudo-Euclidean space and it was also applied to 2010 Mathematics Subject Classification. 53B25, 53B30. Key words and phrases. ruled surface, pointwise 1-type Gauss map, generalized 1-type Gauss map, conical surface of G-type. * supported by the National Research Foundation of Korea (NRF) Grant funded by the Korea government (MSIP) (2016R1A2B1006974). 1 © 2018 by the author(s). Distributed under a Creative Commons CC BY license. Preprints (www.preprints.org) | NOT PEER-REVIEWED | Posted: 20 September 2018 doi:10.20944/preprints201809.0407.v1 Peer-reviewed version available at Symmetry 2018, 10, 514; doi:10.3390/sym10100514 2 MIEKYUNG CHOI AND YOUNG HO KIM* smooth maps, particularly the Gauss map defined on submanifolds of Euclidean space or pseudo-Euclidean space ([1, 2, 3, 10, 11]). Regarding the Gauss map of finite-type, B.-Y. Chen and P. Piccini ([6]) initiated to study submanifolds of Euclidean space with finite-type Gauss map and classified compact surfaces with 1-type Gauss map, that is, ∆G = λ(G + C), where C is a constant vector and λ 2 R. Since then, quite a few works on ruled surfaces and ruled submanifolds with finite-type Gauss map in Euclidean space or pseudo-Euclidean space have been established ([1, 2, 3, 4, 7, 8, 9, 12, 13, 14, 15]). However, some surfaces including a helicoid and a right cone in Euclidean 3-space have an interesting property concerning the Gauss map: The helicoid in E3 parame- terized by x(u; v) = (u cos v; u sin v; av); a 6= 0 has the Gauss map and its Laplacian respectively given by 1 G = p (a sin v; −a cos v; u) a2 + u2 and 2a2 ∆G = G: (a2 + u2)2 The right (or circular) cone Ca with parametrization x(u; v) = (u cos v; u sin v; au); a ≥ 0 has the Gauss map 1 G = p (a cos v; a sin v; −1) 1 + a2 which satisfies 1 1 ∆G = (G + (0; 0; p ) u2 1 + a2 (cf. [4, 8]). The Gauss maps above are similar to 1-type, but it is not of 1-type Gauss map in the usual sense. Based upon such cases, B.-Y. Chen and the present authors defined the notion of pointwise 1-type Gauss map ([4]). Definition 1.1. A submanifold M in Em is said to have pointwise 1-type Gauss map if the Gauss map G of M satisfies ∆G = f(G + C) for some non-zero smooth function f and a constant vector C: In particular, if C is zero, then the Gauss map is said to be of pointwise 1-type of the first kind. Otherwise, it is said to be of pointewise 1-type of the second kind. Let p be a point of E3 and β = β(s) a unit speed curve such that p does not lie on β. A surface parametrized by x(s; t) = p + tβ(s) Preprints (www.preprints.org) | NOT PEER-REVIEWED | Posted: 20 September 2018 doi:10.20944/preprints201809.0407.v1 Peer-reviewed version available at Symmetry 2018, 10, 514; doi:10.3390/sym10100514 EXTENSION OF EIGENVALUE PROBLEMS 3 is called a conical surface. A typical conical surface is a right cone and a plane. Let us consider a following example of a conical surface. Example 1.2. ([15]) Let M be a surface in E3 parameterized by x(s; t) = (s cos2 t; s sin t cos t; s sin t): Then, the Gauss map G can be obtained by 1 G = p (− sin3 t; (2 − cos2 t) cos t; − cos2 t): 1 + cos2 t After a considerably long computation, its Laplacian turns out to be ∆G = fG + gC for some non-zero smooth functions f; g and a constant vector C: The surface M is a kind of conical surfaces generated by a spherical curve β(t) = (cos2 t; sin t cos t; sin t) on the unit sphere S2(1) centered at the origin. Inspired by such an example, we would like to generalize the notion of pointwise 1-type Gauss map as follows: Definition 1.3. ([15]) The Gauss map G of a submanifold M in Em is of generalized 1-type if the Gauss map G of M satisfies ∆G = fG + gC (1.1) for some non-zero smooth functions f; g and a constant vector C: Especially we define a conical surface with generalized 1-type Gauss map. Definition 1.4. A conical surface with generalized 1-type Gauss map is called a conical surface of G-type. Remark 1.5. ([15]) A conical surface of G-type is constructed by the functions f, g and the constant vector C by solving the differential equations generated by (1.1). In the present paper, we classify a ruled surface with generalized 1-type Gauss map in E3 as a plane, a circular cylinder, a cylinder over a base curve of an infinite type generated by the given function f; g and the constant vector C, a helicoid, a right cone and a conical surface of G-type. 2. Preliminaries Let M be a surface of the 3-dimensional Euclidean space E3. The map G : M ! 2 3 2 S (1) ⊂ E which maps each point p of M to a point Gp of S (1) by identifying the unit normal vector Np to M at the point with Gp is called the Gauss map of the surface M; where S2(1) is the unit sphere in E3 centered at the origin. Preprints (www.preprints.org) | NOT PEER-REVIEWED | Posted: 20 September 2018 doi:10.20944/preprints201809.0407.v1 Peer-reviewed version available at Symmetry 2018, 10, 514; doi:10.3390/sym10100514 4 MIEKYUNG CHOI AND YOUNG HO KIM* For the matrixg ~ = (~gij) consisting of the components of the metric on M, we denote byg ~−1 = (~gij) (resp. G ) the inverse matrix (resp. the determinant) of the matrix (~gij): Then the Laplacian ∆ on M is in turn given by 1 X @ p @ ∆ = −p G g~ij : (2.1) @xi @xj G i;j Now, we define a ruled surface M in the 3-dimensional Euclidean space E3: Let α = α(s) be a regular curve in E3 defined on an open interval I and β = β(s) a transversal vector field to α0(s) along α: Then the ruled surface M can be parameterized by x(s; t) = α(s) + tβ(s); s 2 I; t 2 R satisfying hα0; βi = 0 and hβ; βi = 1; where 0 denotes d=ds. The curve α is called the base curve and β the director vector field or ruling. In particular, M is said to be cylindrical if β is constant, or, non-cylindrical otherwise. Throughout this paper, we assume that all the geometric objects are smooth and all surfaces are connected unless otherwise stated. 3. Cylindrical ruled surfaces in E3 with generalized 1-type Gauss map In this section, we study the cylindrical ruled surfaces with generalized 1-type Gauss map in E3: Let M be a cylindrical ruled surface in E3. Without loss of generality, we assume that M is parameterized by x(s; t) = α(s) + tβ; where α(s) = (α1(s); α2(s); 0) is a plane curve parameterized by the arc-length s and β a constant vector, namely β = (0; 0; 1).
Load more

Recommended publications
  • Brief Information on the Surfaces Not Included in the Basic Content of the Encyclopedia
    Brief Information on the Surfaces Not Included in the Basic Content of the Encyclopedia Brief information on some classes of the surfaces which cylinders, cones and ortoid ruled surfaces with a constant were not picked out into the special section in the encyclo- distribution parameter possess this property. Other properties pedia is presented at the part “Surfaces”, where rather known of these surfaces are considered as well. groups of the surfaces are given. It is known, that the Plücker conoid carries two-para- At this section, the less known surfaces are noted. For metrical family of ellipses. The straight lines, perpendicular some reason or other, the authors could not look through to the planes of these ellipses and passing through their some primary sources and that is why these surfaces were centers, form the right congruence which is an algebraic not included in the basic contents of the encyclopedia. In the congruence of the4th order of the 2nd class. This congru- basis contents of the book, the authors did not include the ence attracted attention of D. Palman [8] who studied its surfaces that are very interesting with mathematical point of properties. Taking into account, that on the Plücker conoid, view but having pure cognitive interest and imagined with ∞2 of conic cross-sections are disposed, O. Bottema [9] difficultly in real engineering and architectural structures. examined the congruence of the normals to the planes of Non-orientable surfaces may be represented as kinematics these conic cross-sections passed through their centers and surfaces with ruled or curvilinear generatrixes and may be prescribed a number of the properties of a congruence of given on a picture.
    [Show full text]
  • Extension of Eigenvalue Problems on Gauss Map of Ruled Surfaces
    S S symmetry Article Extension of Eigenvalue Problems on Gauss Map of Ruled Surfaces Miekyung Choi 1 and Young Ho Kim 2,* 1 Department of Mathematics Education and RINS, Gyeongsang National University, Jinju 52828, Korea; [email protected] 2 Department of Mathematics, Kyungpook National University, Daegu 41566, Korea * Correspondence: [email protected]; Tel.: +82-53-950-5888 Received: 20 September 2018; Accepted: 12 October 2018; Published: 16 October 2018 Abstract: A finite-type immersion or smooth map is a nice tool to classify submanifolds of Euclidean space, which comes from the eigenvalue problem of immersion. The notion of generalized 1-type is a natural generalization of 1-type in the usual sense and pointwise 1-type. We classify ruled surfaces with a generalized 1-type Gauss map as part of a plane, a circular cylinder, a cylinder over a base curve of an infinite type, a helicoid, a right cone and a conical surface of G-type. Keywords: ruled surface; pointwise 1-type Gauss map; generalized 1-type Gauss map; conical surface of G-type 1. Introduction Nash’s embedding theorem enables us to study Riemannian manifolds extensively by regarding a Riemannian manifold as a submanifold of Euclidean space with sufficiently high codimension. By means of such a setting, we can have rich geometric information from the intrinsic and extrinsic properties of submanifolds of Euclidean space. Inspired by the degree of algebraic varieties, B.-Y. Chen introduced the notion of order and type of submanifolds of Euclidean space. Furthermore, he developed the theory of finite-type submanifolds and estimated the total mean curvature of compact submanifolds of Euclidean space in the late 1970s ([1]).
    [Show full text]
  • A Cochleoid Cone Udc 514.1=111
    FACTA UNIVERSITATIS Series: Architecture and Civil Engineering Vol. 9, No 3, 2011, pp. 501 - 509 DOI: 10.2298/FUACE1103501N CONE WHOSE DIRECTRIX IS A CYLINDRICAL HELIX AND THE VERTEX OF THE DIRECTRIX IS – A COCHLEOID CONE UDC 514.1=111 Vladan Nikolić*, Sonja Krasić, Olivera Nikolić University of Niš, The Faculty of Civil Engineering and Architecture, Serbia * [email protected] Abstract. The paper treated a cone with a cylindrical helix as a directrix and the vertex on it. Characteristic elements of a surface formed in such way and the basis are identified, and characteristic flat intersections of planes are classified. Also considered is the potential of practical application of such cone in architecture and design. Key words: cocleoid cones, vertex on directrix, cylindrical helix directrix. 1. INTRODUCTION Cone is a deriving singly curved rectilinear surface. A randomly chosen point A on the directrix d1 will, along with the directirx d2 determine totally defined conical surface k, figure 1. If directirx d3 penetrates through this conical surface in the point P, then the connection line AP, regarding that it intersects all three directrices (d1, d2 and d3), will be the generatrix of rectilinear surface. If the directrix d3 penetrates through the men- tioned conical surface in two, three or more points, then through point A will pass two, three or more generatrices of the rectilinear surface.[7] Directrix of a rectilinear surface can be any planar or spatial curve. By changing the form and mutual position of the directrices, various type of rectilinear surfaces can be obtained. If the directrices d1 and d2 intersect, and the intersection point is designated with A, then the top of the created surface will occur on the directrix d2, figure 2.
