April 2021 KACS(FM) Channel 213C2 Chehalis, Allocation Study

The attached spacing study shows the co-channel and adjacent channel spacing between stations and demonstrates that the proposed operation meets the IF channel spacing requirements as prescribed in §73.207 of the Commission's Rules.

The attached allocation study map exhibits demonstrate requisite contour protection for the following domestic stations close enough to warrant detailed study, with the exception of overlap received from KPLI, as discussed in a separate exhibit:

Cochannel: KGIO 213A Astoria, OR

First-Adjacent: KEXP-FM 212C3 , WA KLWO 212A Longview, WA KBOO 214C1 Portland, OR

Second-Adjacent: KVTI 215C1 Tacoma, WA KPLI 211A Olympia, WA KUPS 211A Tacoma, WA

Third-Adjacent: KGRG 210A Auburn, WA KGHP 210A Gig Harbor, WA

All contours depicted have been calculated using terrain HAAT data from the 3-second terrain database.

CBCV-FM Channel 213C Victoria, BC The proposed operation is short-spaced to Canadian station CBCV-FM on Channel 213C at Victoria, British Columbia. Under the terms of the Working Arrangement for the Allotment and Assignment of FM Broadcasting Channels Under the Agreement Between the Government of Canada and the Government of the United States of America Relating to the FM Broadcasting Service , as amended in 1997 (" Working Arrangement "), the required co-channel Class C to Class C3 spacing is 259 kilometers, whereas the distance between the proposed KACS site and the CBCV-FM transmitter site is 216 kilometers. The attached cochannel allocation study map

Hatfield & Dawson Consulting Engineers demonstrates that the proposed KACS 34 dBu F(50,10) contour will not overlap any Canadian land areas, nor does it cross the Canadian border. Therefore, the proposed operation is believed to be in full compliance with international allotment requirements.

TV Channel 6 Section 73.525 of the Commission’s Rules specifies a threshold distance of 193 kilometers for FM stations operating on Channel 213. There is no domestic TV Channel 6 station located within this threshold distance.

Hatfield & Dawson Consulting Engineers FMSTUDY.EXE Copyright 2020, Hatfield & Dawson, LLC Version 5.00 ======SEARCH PARAMETERS FM Database Date: 20210407 Channel: 213C2 90.5 MHz Page 1 Latitude: 46 43 50.7 (NAD83) Longitude: 123 1 33.7 Safety Zone: 50 km Job Title: KACS 213C2 COOK HILL

Call City Channel ERP(kW) Latitude Bearing Dist Req Status St FCC File No. Freq. HAAT(m) Longitude deg-True (km) (km) ======K210ES ABERDEEN 210D 0.115 46 56 0.3 293.0 58.33 0 LIC WA BLFT-20140520AJJ 89.9 0.0 123 43 52.5 0.00 TRANS

KGHP GIG HARBOR 210A 1.350 DA 47 14 26.3 18.7 59.88 55 LIC WA BLED-20061204AHL 89.9 61.0 122 46 20.4 4.88 CLOSE

KGRG-FM AUBURN 210A 0.230 DA 47 15 22.3 46.0 84.69 55 LIC WA BLED-20160929AJI 89.9 116.0 122 13 11.4 29.69 CLEAR

K211FH SHELTON 211D 0.050 DA 47 12 2.3 354.6 52.47 0 LIC WA BLFT-20141120ACZ 90.1 0.0 123 5 28.5 0.00 TRANS

KUPS TACOMA 211A 0.100 47 15 47.3 34.9 72.38 55 LIC WA BMLED-19950711KE 90.1 70.0 122 28 41.4 17.38 CLEAR

KPLI OLYMPIA 211A 0.100 DA 47 2 23.3 15.3 35.63 55 LIC WA BLED-20060913AAF 90.1 -10.0 122 54 7.5 -19.37 SHORT

K211AP CENTRALIA 211D 0.019 46 33 17.3 187.2 19.72 0 LIC WA BLFT-20001107AAZ 90.1 0.0 123 3 30.4 0.00 TRANS

K211ET ASTORIA 211D 0.013 46 17 11.3 233.8 83.14 0 LIC OR BLFT-20170911AAB 90.1 0.0 123 53 50.5 0.00 TRANS

KBSG RAYMOND 211A 0.440 46 41 43.4 266.3 57.23 55 LIC WA BLED-20180921ABP 90.1 279.0 123 46 21.6 2.23 CLOSE

KEXP-FM SEATTLE 212C3 4.700 DA 47 36 57.4 28.6 112.42 117 LIC WA BMLED-20071030AB 90.3 211.0 122 18 32.5 -4.58 SHORT

KLWO LONGVIEW 212A 0.400 46 9 46.4 168.2 64.47 106 LIC WA BLED-20070925AGO 90.3 272.0 122 51 18.4 -41.53 SHORT

KLON TILLAMOOK 212A 0.028 45 27 57.9 206.5 156.68 106 LIC OR 0000095303 90.3 399.0 123 55 15.4 50.68 CLEAR

K213DU GOLDENDALE/THE DALLE 213D 0.015 DA 45 42 24.4 126.7 187.66 0 LIC WA BLFT-20150312AAG 90.5 0.0 121 5 32.2 0.00 TRANS

VICTORIA 213C 0.000 48 35 40.3 349.6 210.85 274 ALC BC 90.5 0.0 123 32 41.7 -63.15 SHORT

Hatfield & Dawson Consulting Engineers FMSTUDY.EXE Copyright 2020, Hatfield & Dawson, LLC Version 5.00 ======SEARCH PARAMETERS FM Database Date: 20210407 Channel: 213C2 90.5 MHz Page 2 Latitude: 46 43 50.7 (NAD83) Longitude: 123 1 33.7 Safety Zone: 50 km Job Title: KACS 213C2 COOK HILL

Call City Channel ERP(kW) Latitude Bearing Dist Req Status St FCC File No. Freq. HAAT(m) Longitude deg-True (km) (km) ======KGIO ASTORIA 213A 0.220 46 17 11.3 233.8 83.14 166 LIC OR BLED-20170911AAA 90.5 381.0 123 53 50.5 -82.86 SHORT

KACS CHEHALIS 213A 6.000 DA 46 43 50.4 155.4 0.01 166 LIC WA BMLED-20150811AG 90.5 57.0 123 1 33.5 -165.99 SHORT

K214FI RAYMOND 214D 0.019 46 41 43.3 266.3 57.22 0 LIC WA BLFT-20181001AHN 90.7 0.0 123 46 21.5 0.00 TRANS

KBOO PORTLAND 214C1 26.500 45 29 19.4 169.4 140.40 158 LIC OR BLED-19910909KC 90.7 386.0 122 41 44.3 -17.60 SHORT

KNWR ELLENSBURG 214C1 5.000 47 15 47.4 72.5 208.83 158 LIC WA BLED-19920610KA 90.7 777.0 120 23 35.2 50.83 CLEAR

KCPB-FM WARRENTON 215A 0.240 DA 46 15 45.3 232.0 84.13 55 LIC OR BLED-20100715AAE 90.9 341.0 123 53 13.5 29.13 CLEAR

KVTI TACOMA 215C1 51.000 47 9 38.3 35.3 58.73 79 LIC WA BLED-19910510KA 90.9 111.0 122 34 39.4 -20.27 SHORT

KTJC KELSO 216C2 8.000 DA 46 19 45.3 174.0 44.88 58 LIC WA BLED-20040302AAC 91.1 189.0 122 57 54.4 -13.12 SHORT

KGHI WESTPORT 216A 1.900 46 55 10.3 286.9 73.94 55 LIC WA BLED-20150722ACR 91.1 18.0 123 57 18.6 18.94 CLEAR

K266BM OLYMPIA 266D 0.250 DA 46 58 23.3 342.6 28.26 0 LIC WA BLFT-20190904ABL 101.1 0.0 123 8 15.5 0.00 TRANS

K266BL RAYMOND 266D 0.009 46 41 43.4 266.3 57.23 0 LIC WA BLFT-20180925ACG 101.1 0.0 123 46 21.6 0.00 TRANS

K266BM OLYMPIA 266D 0.250 DA 46 58 23.3 342.6 28.26 0 CP WA BMPFT-20190618AB 101.1 0.0 123 8 15.5 0.00 TRANS

K266BM OLYMPIA 266D 0.250 DA 46 58 23.3 342.6 28.26 0 LICAPP WA 0000115909 101.1 0.0 123 8 15.5 0.00 TRANS

K267CX CENTRALIA 267D 0.135 46 33 19.3 187.2 19.65 0 CP WA BNPFT-20180430AA 101.3 0.0 123 3 29.4 0.00 TRANS

44444 END OF FM SPACING STUDY FOR CHANNEL 213 44444

Hatfield & Dawson Consulting Engineers JEFFERSON

KITSAP

KING

MASON

GRAYS HARBOR

PIERCE

THURSTON

KACS 213C2 Chehalis 60 dBu F(50,50) 40 dBu F(50,10)

LEWIS PACIFIC

KGIO 213A Astoria WAHKIAKUM 60 dBu F(50,50) 40 dBu F(50,10) COWLITZ

SKAMANIA CLATSOP COLUMBIA

KACS 213C2 Cochannel Study Map CLARK 0 204060 Kilometers Hatfield & Dawson 4/2021 KEXP 212C3 Seattle 60 dBuJEFFERSON F(50,50) 54 dBu F(50,10)

KITSAP

KING

MASON

GRAYS HARBOR K

PIERCE KACS 213C2 Chehalis 60 dBu F(50,50) THURSTON 54 dBu F(50,10)

LEWIS PACIFIC KLWO 212A Longview 60 dBu F(50,50) KBOO 214C1 Portland 54 dBu F(50,10) 60 dBu F(50,50) YAK 54 dBu F(50,10)

WAHKIAKUM

COWLITZ

SKAMANIA CLATSOP COLUMBIA

KACS 213C2 1st Adj Channel Study KLICKITMap 0 204060 Kilometers CLARK Hatfield & Dawson 4/2021 KGHP 210A Gig Harbor KING 60 dBu F(50,50) 100 dBu F(50,10) KUPS 211A Tacoma 60 dBu F(50,50) KGRG 210A Auburn 100 dBu F(50,10) 60 dBu F(50,50) 100 dBu F(50,10)

MASON

KVTI 215C1 Tacoma 60 dBu F(50,50) 100 dBu F(50,10) PIERCE

KPLI 211A Olympia 60 dBu F(50,50) 100 dBu F(50,10)

THURSTON

KACS 213C2 Chehalis 60 dBu F(50,50) 100 dBu F(50,10)

LEWIS

KACS 213C2 2nd/3rd Adj Channel Study Map 0 102030 Kilometers Hatfield & Dawson 4/2021 C A The proposed 34 dBu F(50,10) contour N does not overlap any Canadian territory. A SAN JUAN D A SKAGIT

ISLAND

CLALLAM SNOHOMISH

JEFFERSON

KITSAP KACS 213C2 Chehalis 34 dBu F(50,10)

KING

MASON

GRAYS HARBOR

PIERCE

THURSTON

KACS 213C2 Canada Study Map 0 153045 Kilometers Hatfield & Dawson 4/2021 April 2021 KACS(FM) Channel 213C2 Chehalis, Washington Waiver Requested for Received Second Adjacent Channel Overlap

Chehalis Valley Educational Foundation (“CVEF”) proposes to increase the power and service area of its station KACS (Facility ID #10685), which is presently licensed on Channel 213A under BMLED-20150811AGH. The proposed upgraded facility has been designed so as to not cause any prohibited contour overlap to any existing station, authorization, or pending application, as per §73.509 of the Commission’s Rules. However, the proposed increased 60 dBu service area would receive overlap from one licensed second-adjacent-channel full-power station, specifically KPLI on Channel 211A at Olympia.

This proposal will not cause overlap to KPLI as the proposed 100 dBu F(50,10) interfering contour of KACS will not overlap that station’s 60 dBu F(50,50) protected contour. However, the proposed KACS 60 dBu F(50,50) contour will receive overlap from the 100 dBu F(50,10) contour of KPLI.

The 60 dBu contour from the proposed KACS facility encompasses an area of 2,929 sq km and a population of 227,247 persons per the 2010 Census (using the block centroid method).

Area and Population in Percentage of Proposed KACS 60 dBu Area Received Overlap Area from KPLI and Population

1 sq km 0.03% area 238 persons 0.1% population

No overlap, and thus no interference, will occur within the boundaries of the KACS community of license.

In Educational Information Corporation , Memorandum Opinion and Order, 6 FCC Rcd 2207 (1991), the Commission noted that it would be inclined to grant waivers of second- or third-adjacent channel overlap in circumstances where the benefit of increased non-commercial service heavily outweighs the potential for interference in very small areas. “...the Commission has given the staff delegated authority to act on waivers of received overlap of up to 10 percent where sufficient justification is provided.” Educational Information Corporation at 7. “The Commission has long

Hatfield & Dawson Consulting Engineers recognized the unique characteristics of the noncommercial service and the need for flexibility to respond to the growing demand for such service. We are also more sensitive today to the increasing limitations within the reserved band which reflect the increased demand for service over the last 30 years. For these reasons, we are now inclined to grant waivers of second or third adjacent channel overlap in circumstances such as WCPE's, where the benefit of increased noncommercial educational service so heavily outweighs the potential for interference in very small areas.” Educational Information Corporation at 10.

CVEF hereby submits that the circumstances of the instant case are functionally equivalent to those in Educational Information Corporation , and respectfully requests a waiver of §73.509 of the Commission’s Rules to permit the grant of the proposed KACS facility. CVEF acknowledges that future modifications proposed by the licensee of KPLI will not be construed as a per se modification of the KACS license.

The licensed KACS 60 dBu contour encompasses an area of 1,455 sq km and a population of 74,200 persons. The grant of this waiver request will allow KACS to increase its 60 dBu service area by 101% and its 60 dBu service population by 206%. CVEF believes that this represents a significant increase in non-commercial service to the area, justifying grant of the requested waiver.

Hatfield & Dawson Consulting Engineers April 2021 KACS(FM) Channel 213C2 Chehalis, Washington RF Exposure Study

Facilities Proposed The proposed operation will be on Channel 213C2 (90.5 MHz) with a maximum lobe of 40 kilowatts. Operation is proposed with a 4-element circularly-polarized, half- wavelength-spaced directional antenna. The antenna will be side-mounted on the existing KACS tower located atop Cook Hill.

RF Exposure Calculations The power density calculations shown below were made using the techniques outlined in OET Bulletin No. 65. "Ground level" calculations in this report have been made at a reference height of 2 meters above ground to provide a worst-case estimate of exposure for persons standing on the ground in the vicinity of the tower. The equation shown below was used to calculate the ground level power density figures from each antenna.

2 3340981.()× AdjERP Watts S(/)µ W cm = D2 Where: AdjERP(Watts) is the maximum lobe effective radiated power times the element pattern factor times the array pattern factor.

D is the distance in meters from the center of radiation to the calculation point.

Ground level power densities have been calculated for locations extending from the base of the tower to a distance of 500 meters. Values past this point are increasingly negligible.

Calculations of the power density produced by the proposed antenna system assume a Type 2 element pattern, which is the element pattern for the “double V” antenna proposed for use. The highest calculated ground level power density occurs at a distance of 194 meters from the base of the antenna support structure. At this point the power density is calculated to be 26.9 µW/cm², which is 2.7% of 1000 µW/cm 2 (the FCC standard for controlled environments) and 13.5% of 200 µW/cm 2 (the FCC standard for uncontrolled environments).

Hatfield & Dawson Consulting Engineers Calculations of the power density produced by KACS and the other stations at this transmitter site are summarized in the following table:

Avg or Peak ERP Relative Height Calculated Max Gen Pub Call Antenna Model Field AGL Exposure FCC Limit % of Limit

KACS 40 kW H FMModel 54 m 26.9 µW/cm² 200 µW/cm² 13.5% 213C2 40 kW V (Type 2) 4-bay half-wave double V

K259BG 0.25 kW V FMModel 46 m 4.1 µW/cm² 200 µW/cm² 2.1% Dipole (Type 1)

K292HN 0.25 kW V FMModel 27 m 12.7 µW/cm² 200 µW/cm² 6.4% Scala FMV dipole (Type 1)

These calculations show that the maximum calculated power density produced at two meters above ground level by the proposed operation of KACS and the present operation of the other stations at this site (were their maxima to coincide, which they do not) is 44 µW/cm 2, which is 22% of 200 µW/cm 2 (the FCC standard for uncontrolled environments).

The permittee/licensee in coordination with other users of the site must reduce power or cease operation as necessary to protect persons having access to the site, tower or antenna from radiofrequency radiation in excess of FCC guidelines.

Hatfield & Dawson Consulting Engineers Ground-Level RF Exposure OET FMModel

KACS 213C2 Chehalis Antenna Type: double V (Type 2) No. of Elements: 4 Element Spacing: 0.5 wavelength

Distance: 500 meters Horizontal ERP: 40 kW Vertical ERP: 40 kW

Antenna Height: 54 meters AGL

Maximum Calculated Power Density is 26.9 µW/cm 2 at 194 meters from the antenna structure.

Hatfield & Dawson Consulting Engineers BROWNS POINT KEY CENTER ARTONDALE GIG HARBOR RUSTON

HOME WOLLOCHET 163 HERRON ISLAND 16 FOX ISLAND 509 LONGBRANCH FIF FIRCREST TACOMA SHELTON UNIVERSITY PLACE WALL 3

MASON 5 STEILACOOM MIDLAND ANDERSON ISLAND LAKEWOOD

PARKLAND MCCHORD AFB NORTH FORT LEWIS SPANAWAY 108 DUPONT FORT LEWIS FREDERIC 101

PIERCE ELK PLA MCCLEARY TANGLEWILDE OLYMPIA LACEY 8 NISQUALLY INDIAN COMMUNITY NTESANO SATSOP 510 BRADY ELMA ROY SOUTH CR TUMWATER MALONE GRAYS HARBOR NORTH YELM PORTER

MCKENNA 702 YELM 121 12 RAINIER 507

TENINO 5 OAKVILLE THURSTON ROCHESTER

GRAND MOUND BUCODA

FORDS PRAIRIE

CENTRALIA 60 dBu

CHEHALIS

6

508

NAPAVINE LEWIS ONALASKA PE ELL LEBAM PACIFIC 122

12 MOSSYROCK

WINLOCK

TOLEDO 505

506 5 VADER KACS 213C2 Contour Map RYDERWOOD 0 5 10 15 RAYS RIVER WAHKIAKUM COWLITZ Kilometers

SKAMOKAWA VALLEY ©2013 CALIPER Hatfield & Dawson 4/2021
