SRI ANGARA RAJESH SURVEY NO. 218 & 286, THOTAKURAPALEM VILLAGE, RAVIKAMATHAM MANDAL, DISTRICT,

FORM 1 (FULLY MECHANISED OPENCAST COLOUR GRANITE QUARRY-4.965 ha)

SUBMITTED BY STUDIES AND DOCUMENTATION BY Sri Angara Rajesh TEAM Labs and Consultants Flat No. 501, D. No. 7-18-5/16, (MoE&F O.M. - S. NO: 25, List A-1) Vinayghar Beach Apartment, B-115 to 117 & 509, Annapurna Block, , , Aditya Enclave, Ameerpet, Visakhapatnam – 530 017. Hyderabad-500 038 Mobile No. +91 98855 62539 Phone: 040-23748 555/616, Telefax: 040-23748666 Email: [email protected]

SUBMITTED TO STATE LEVEL ENVIRONMENTAL IMPACT ASSESSMENT AUTHORITY, ANDHRA PRADESH GOVERNMENT OF Sri Angara Rajesh Form-1 APPENDIX I (See paragraph – 6) FORM 1 (I) Basic Information S. No Item Details 1 Name of the Project/s Sri Angara Rajesh – Colour Granite Quarry 2 S. No in the Schedule 1(a) 3 Proposed capacity/area/length/tonnage to be Fully mechanized opencast method for handled/command area/lease area/number of Colour granite maximum production of wells to be drilled 38538 m3/annum. Quarry lease area is 4.965 ha. 4 New/Expansion/Modernization New Quarry Cost estimated for the project Rs. 52 Lakhs 5 Existing Capacity/Area etc. -- 6 Category of Project i. e 'A' or 'B' B (Quarry Lease area is <5Ha) 7 Does it attract the general condition? If yes, No please specify 8 Does it attract the Specific condition? If yes, No. please specify. 9 Location Plot/Survey/Khasra No. Survey No. 218 & 286, Thotakurapalem Village Village, Ravikamatham Mandal, Tehsil Visakhapatnam District, Andhra Pradesh District State 10 Nearest railway station/airport along with Railway Station: Narasingapalli - 11.8 km - distance in kms. SE 11 Nearest Town, City, District Headquarters along District head quarters: Visakhapatnam - with distance in kms. 42.0 km - E 12 Village Panchayats, ZillaParishad,Municipal Village Panchayat: Thotakurapalem Corporation, Local body (complete postal Zilla Parishad: Visakhapatnam address with telephone nos. to be given) 13 Name of the Applicant Sri Angara Rajesh 14 Registered Address Sri Angara Rajesh Flat No. 501, D. No. 7-18-5/16, Vinayghar Beach Apartment, Kirlampudi Layout, Chinna Waltair, Visakhapatnam – 530 017. Mobile No. +91 98855 62539 15 Address for Correspondence: Name Sri Angara Rajesh Designation(Owner/Partner/CEO) Owner Address D Flat No. 501, D. No. 7-18-5/16,

F-1 Sri Angara Rajesh Form-1

Vinayghar Beach Apartment, Kirlampudi Layout, Chinna Waltair, Visakhapatnam – 530 017. Pin Code 530 017 E-mail Telephone Number Mobile No. +91 98855 62539. Fax No. 16 Details of alternative Sites examined, if any. Village-District-State – Location of these sites should be shown on a -NA – topo sheet. Site specific project i.e. mining. 17 Interlinked Projects -NA- 18 Whether separate application of interlinked No project has been submitted? 19 If yes, date of submission -- 20 If no, reason -- 21 Whether the proposal involves No approval/clearance under: if yes, details of the same and their status to be given. (a) The Forest (Conservation) Act, 1980? (b) The Wildlife (Protection) Act, 1972? (c) The C.R.Z Notification, 1991? 22 Whether there is any Government Order/Policy Yes – In principle of Quarry lease relevant/relating to the site? application grant notice by the Director of Mines and Geology, Government of Andhra Pradesh vide notice no. 3866/R1-3/2017 dated 07.05.2018. Mining Plan was approved by Deputy Director of Mines and Geology, Vide letter No. 1347/MP- AKP/2018 dated 28.05.2018 23 Forest land involved (hectares) No 24 Whether there is any location pending against No the project and /or land in which the project is propose to be set up? (a) Name of the Court (b) Case No (c) Orders/directions of the Court, if any and its relevance with the proposed project.

F-2 Sri Angara Rajesh Form-1 (II) Activity 1. Construction, operation or decommissioning of the Project involving actions, which will cause physical changes in the locality (topography, land use, changes in water bodies, etc.) S. No. Information/Checklist Yes/No Details thereof (with approximate confirmation quantities /rates, wherever possible) with source of information data 1.1 Permanent or temporary NO The lease area is a hill raised 15m AGL change in land use, land cover within QL area with topo relief in SW or topography including direction. Present method of mining is increase in intensity of land fully mechanized opencast. use (with respect to local land use plan) 1.2 Clearance of existing land, NO The lease area is a hill raised 15m AGL vegetation and buildings? within QL area with topo relief in SW direction. 1.3 Creation of new land uses? NO 1.4 Pre-construction investigations YES Survey completed, based on the soil e.g. bore houses, soil testing? quality temporary office cum rest shelter, first aid room and toilets will be constructed. 1.5 Construction works? YES Construction activity involves infrastructure only. Office cum rest shelter, first aid room and toilets will be constructed. 1.6 Demolition works? NO 1.7 Temporary sites used for NO Local villagers shall be employed. construction works or housing of construction workers? 1.8 Above ground buildings, YES Above ground building for the mine office structures or earthworks only. No major excavation activity including linear structures, cut involved. and fill or excavations 1.9 Underground works including NO The present method of mining is fully mining or tunneling? mechanized opencast method for Colour granite. 1.10 Reclamation works? YES Reclamation will be done after completion of mine workings by backfilling with mine waste. Topsoil generated will be used for Afforestation of reclaimed land to gets rehabilitation. 1.11 Dredging? NO 1.12 Offshore structures? NO 1.13 Production and manufacturing YES Mining by using Fully mechanized processes? opencast method. (Annexure I)

F-3 Sri Angara Rajesh Form-1

1.14 Facilities for storage of goods NO or materials? 1.15 Facilities for treatment or YES The waste generated during plan period disposal of solid waste or will be dumped in SE side of the lease liquid effluents? area over an extent of about 0.5 ha to a height of 30 m. (Annexure IV) The waste will be further value addition of the mineral in the shapes of cobble stones, building stones, pavement stones. Liquid waste i.e. effluent from the domestic source shall be sent to septic tank followed by soak pit. 1.16 Facilities for long term housing NO Local Villagers will be employed. of operational workers? 1.17 New road, rail or sea traffic NO No major construction involves, local during construction or villagers will be employed for construction operation? and operational purpose. The number of trips required for transportation of mineral is seven in one day. 1.18 New road, rail, air waterborne NO or other transport infrastructure including new or altered routes and stations, ports, airports etc? 1.19 Closure or diversion of existing NO Very limited trucks are required. The transport routes or number of trips required for infrastructure leading to transportation of mineral is seven in one changes in traffic movements? day. 1.20 New or diverted transmission NO There is no transmission line or pipeline lines or pipelines? passing through the lease area. 1.21 Impoundment, damming, NO The quarrying operation will be Fully culverting, realignment or mechanized opencast method. No change other changes to the in hydrology due to proposed activity. hydrology of watercourses or aquifers? 1.22 Stream crossings? NO There is no stream crossing the lease area. 1.23 Abstraction or transfers of NO Water shall be drawn from local villages water form ground or surface for the purpose of domestic and water waters? sprinkling purpose. 1.24 Changes in water bodies or the NO There is no discharge from the quarrying land surface affecting drainage operations. or run-off? 1.25 Transport of personnel or NO Local villagers shall be employed. Granite

F-4 Sri Angara Rajesh Form-1

materials for construction, is sent away from the site, the numbers of operation or trips will be one in one day. decommissioning? 1.26 Long-term dismantling or NO Temporary structures will be constructed. decommissioning or restoration works? 1.27 Ongoing activity during NO There is no structure in the lease area, decommissioning which could mine office cum rest shelter will be have an impact on the constructed with temporary structures to environment? demolish after completion of workings. 1.28 Influx of people to an area in NO either temporarily or permanently? 1.29 Introduction of alien species? NO The lease area is a hill raised 15m AGL within QL area with topo relief in SW direction. 1.30 Loss of native species or NO genetic diversity? 1.31 Any other actions? NO

2. Use of Natural resources for construction or operation of the Project (such as land, water, materials or energy, especially any resources which are non-renewable or in short supply): S.No. Information/checklist Yes/No Details thereof (with approximate quantities /rates, wherever possible) Confirmation with source of information data

2.1 Land especially undeveloped YES The quarry lease area is 4.965 ha. The or agricultural land (ha) lease area is a hill raised 15m AGL within QL area with topo relief in SW direction. 2.2 Water (expected source & YES 14.7 KLD, through tankers and RWS competing users) unit: KLD from nearby village. Annexure-III. 2.3 Minerals (MT) YES The present proposal is for Colour granite mining and it is a mineral.

2.4 Construction material– stone, NA Quarry office and temporary rest aggregates, sand/soil(expected shelters will be constructed, no major source- construction involves. MT)

2.5 Forests and timber (source – MT) NO

2.6 Energy including electricity and YES Fully mechanized opencast mining; fuels (source, competing users) power shall be drawn from nearby

F-5 Sri Angara Rajesh Form-1

Unit: fuel (MT), energy (MW) villages.

2.7 Any other natural resources (use NO appropriate standard units)

3.Use, storage, transport handling or production of substances or materials, which could be harmful to human health or the environment or raise concerns about actual or perceived risks to human health. S.No. Information/Checklist. Yes/No Details thereof (with approximate confirmation quantities/rates, wherever possible) with source of information data 3.1 Use of substances or materials, NO There are no hazardous substances or which are hazardous (as per materials to human health or the MSIHC rules) to human health or environment. However drilling will be the environment (flora, fauna, carried out for mining.(Annexure-II) and water supplies) 3.2 Changes in occurrence of disease NO or affect disease vectors (e.g. insect or water borne diseases) 3.3 Affect the welfare of people e.g. YES The proposed project shall enhance the by changing living conditions? prospects of employment. Recruitment for the unskilled and semiskilled workers for the proposed project will be from the nearby villages 3.4 Vulnerable groups of people who NO The nearest village is Thotakurapalem could be affected by the project located at a distance of 0.9 km in N e.g. hospital patients, children, direction. The project shall not have any the elderly etc., significant impact on vulnerable groups of people. 3.5 Any other causes NO

F-6 Sri Angara Rajesh Form-1 4. Production of solid wastes during construction or operation or decommissioning (MT/month) S.No. Information/Checklist Yes/No Details thereof (with approximate confirmation quantities/rates, wherever possible) with source of information data 4.1 Spoil, overburden or mine YES Waste material generated during plan wastes period will be dumped at dump yard in an area of 0.5 ha. The waste material will be used in the shapes of cobble stones, building stones and pavement stones. The maximum waste will be utilization of available natural mineral and adopt value to increase the market for the colour granite products in various kinds and shapes 4.2 Municipal waste (domestic NO Domestic waste like paper will be disposed and or commercial off. wastes)

4.3 Hazardous wastes (as per NO Waste oil from equipment shall be sent to Hazardous Waste authorized recyclers. Management Rules)

4.4 Other industrial process NO wastes 4.5 Surplus product NO 4.6 Sewage sludge or other NO sludge from effluent treatment 4.7 Construction or demolition NO wastes 4.8 Redundant machinery or NO equipment 4.9 Contaminated soils or other NO materials 4.10 Agricultural wastes NO 4.11 Other solid wastes NO

F-7 Sri Angara Rajesh Form-1 5. Release of pollutants or any hazardous, toxic or noxious substances to air (Kg/hr) S. No. Information/Checklist Yes/No Details thereof (with approximate Confirmation quantities/rates, wherever possible) with source of information data 5.1 Emissions from combustion of NO fossil fuels from stationary or mobile sources

5.2 Emissions from production YES Dust emissions are anticipated from processes mining and transport activity. Water sprinkling and green belt development is proposed to reduce the dust. 5.3 Emissions from materials handling YES Dust may rise during mining, and including storage or transport transport. 5.4 Emissions from construction YES Dust may rise during transport of activities including plant and material and mining activity. The dust equipment emissions shall be mitigated by water spraying. 5.5 Dust or odours from handling of NO materials including construction materials, sewage and waste 5.6 Emissions from incineration of NO waste 5.7 Emissions from burning of waste NO in open air (e.g. slash materials, construction debris) 5.8 Emissions from any other sources NO

F-8 Sri Angara Rajesh Form-1 6. Generation of Noise and Vibration, and Emissions of Light and Heat: S. No. Information/Checklist Yes/No Details thereof (with approximate confirmation quantities/rates, wherever possible) with source of information data with source of information data 6.1 From operation of equipment YES Noise is anticipated during mining e.g. engines, ventilation plant, activity from drilling equipment, crushers transport vehicles. Wet drilling and water sprinkling system is provided to reduce the dust emissions. Personal protective equipments are provided to the workers to reduce the noise levels. 6.2 From industrial or similar NO processes 6.3 From construction or demolition YES Safety equipments shall be provided to the workers. 6.4 From blasting or piling YES Dust and noise may rise during drilling and transportation. Water sprinkling system is provided to control the dust emissions. PPE’s are provided to the workers. 6.5 From construction or operational YES The increased traffic shall not have any traffic significant impact. 6.6 From lighting or cooling systems NO 6.7 From any other sources NO

F-9 Sri Angara Rajesh Form-1 7. Risks of contamination of land or water from releases of pollutants into the ground or into sewers, surface waters, groundwater, coastal waters or the sea: S.No. Information/Checklist confirmation Yes/ No Details thereof (with approximate quantities/rates, wherever possible) with source of information data 7.1 From handling, storage, use or spillage of NO The material excavated is Colour hazardous materials Granite and is mineral. 7.2 From discharge of sewage or other NO Septic Tank followed by soak pit effluents to water or the land (expected shall be provided for temporary mode and place of discharge) toilets. 7.3 By deposition of pollutants emitted to air NO into the land or into water 7.4 From any other sources NO 7.5 Is there a risk of long term build up of NO pollutants in the environment from these sources?

8. Risk of accidents during construction or operation of the Project, which could affect human health or the environment S.No. Information/Checklist Yes/No Details thereof (with approximate confirmation quantities/rates, wherever possible) with source of information data 8.1 From explosions, spillages, fires etc NO from storage, handling, use or production of hazardous substances 8.2 From any other causes NO 8.3 Could the project be affected by NO natural disasters causing Environmental damage (e.g. floods, earthquakes, landslides, Cloudburst etc)?

F-10 Sri Angara Rajesh Form-1 9. Factors which should be considered (such as consequential development) which could lead to environmental effects or the potential for cumulative impacts with other existing or planned activities in the locality S. No. Information/Checklist confirmation Yes/No Details thereof (with approximate quantities/rates, wherever possible) with source of information data 9.1 Lead to development of supporting. YES The proposed project shall facilities, ancillary development or enhance the prospects of development stimulated by the project employment. Recruitment for which could have impact on the the unskilled and semiskilled environment e.g.: workers for the proposed •Supporting infrastructure (roads, project will be from the nearby power supply, waste or waste water villages. treatment, etc.)

•Housing development •Extractive industries • Supply industries • Other 9.2 Lead to after-use of the site, which NO could have an impact on the environment 9.3 Set a precedent for later developments NO 9.4 Have cumulative effects due to NO The baseline environmental proximity to other existing or planned status of the surrounding areas projects with similar effects is within the prescribed limits as observed from the secondary data.

F-11 Sri Angara Rajesh Form-1 (III) Environmental Sensitivity S.No. Areas Name/ Aerial distance (within 15 km.) Identity Proposed project location boundary 1 Areas protected under international NO conventions, national or local legislation for their ecological, landscape, cultural or other related value 2 Areas which are important or sensitive YES Tida RF is at a distance of 0.5 for ecological reasons - Wetlands, km in SW direction. Pangidi RF watercourses or other water bodies, is at a distance of 0.4 km in SE coastal zone, biospheres, mountains, direction. Guddepa RF is at a forests distance of 4.5 km in NW direction. Gollapalem RF is at a distance of 7.0 km in NW direction. Nallakonda RF is at a distance of 7.5 km in NW direction. Panduru RF is at a distance of 7.5 km in S direction. Gobburu RF is at a distance of 7.5 km in SE direction. Bayyavaram RF is at a distance of 8.0 km in SE direction. Erri Gedda seasonal vagu is fallowing at a distance of 5.0 km in West direction. Seasonal Jaji Gedda is flowing at a distance of 8.0km in West direction. Seasonal Vedurla Gedda is flowing at a distance of 7.0km in NE direction and also at a distance of 2.2km in South direction. Seasonal Mamidivaka Gedda is flowing at a distance of 8.2km in SE direction. Yeluru Canal is passing at a distance of 3.7km in South direction. 3 Areas used by protected, important or NO sensitive species of flora or fauna for breeding, nesting, foraging, resting, over wintering, migration 4 Inland, coastal, marine or underground NO waters

F-12 Sri Angara Rajesh Form-1

5 State, National boundaries NO 6 Routes or facilities used by the public for NO access to recreation or other tourist, pilgrim areas 7 Defence installations NO

8 Densely populated or built-up area NO The project impact area has no urban or semi-urban area. The PIA consists of rural area with low agricultural activity. 9 Areas occupied by sensitive man-made NO The PIA consists of community land uses (hospitals, schools, places of facilities in various villages, worship, community facilities) however no major impact is anticipated, as the mine is away from the residential area. 10 Areas containing important, high quality NO or scarce resources (ground water resources, surface resources, forestry, agriculture, fisheries, tourism, minerals) 11 Areas already subjected to pollution or NO The area is undeveloped and environmental damage. (those where consists of very few industries. existing legal environmental standards are exceeded) 12 Areas susceptible to natural hazard which NO could cause the project to present environmental problems (earthquakes, subsidence, landslides, erosion, flooding or extreme or adverse climatic conditions)

F-13 Sri Angara Rajesh Form-1 IV. Proposed Terms of Reference Environment Management Plan and Mitigation Plan: The proposed project is opencast method granite quarry lease area of 4.965 ha located in Survey No. 218 & 286, Thotakurapalem Village, Ravikamatham Mandal, Visakhapatnam District, Andhra Pradesh. The project authorities obtained quarry lease notice from Department of Mines and

Geology. Hence it is proposed to prepare an Environment Management Plan under B2 category. The Environment Management Plan shall identify typical impacts due to semi mechanized mining and a mining specialist shall work closely with the engineering team/technical consultants to suggest practicable measures to avoid or mitigate the impact. The mitigation of environmental impacts will be by three mechanisms. =>Introduction of mitigation features through the engineering practices. =>Implementation of environmental controls during construction and operation. =>Legislative control involving compliance with Indian environmental laws. The Environmental management plan shall include an estimate of capital and recurring costs of mitigation measures and will identify the institutional framework for implementation. Monitoring Plan: Having identified the significant environmental impacts that are likely to arise as a result of the project, the project team shall specify what monitoring is required during the various phases of the project cycle. The monitoring plan will identify parameters and frequency of monitoring and responsible organization. I hereby give the undertaking that data and information given in the application and enclosures are true to the best of my knowledge and belief and I am aware that if any part of the data and information submitted is found to be false or misleading at any stage, the project will be rejected and clearance give, if any to the project will be revoked at our risk and cost. Date: Place: Signature of the applicant With Name and Full Address (Project Proponent/Authorised Signatory)

Sri Angara Rajesh Flat No. 501, D. No. 7-18-5/16, Vinayghar Beach Apartment, Kirlampudi Layout, Chinna Waltair, Visakhapatnam – 530 017. Mobile No. +91 98855 62539.

F-14 ANNEXURES Sri Angara Rajesh Annexure of Form-1

ANNEXURE I Site Location map of Sri Angara Rajesh

A-1 Sri Angara Rajesh Annexure of Form-1

Quarry Lease boundary map of Sri Angara Rajesh

A-2 Sri Angara Rajesh Annexure of Form-1

1.0 Introduction Sri Angara Rajesh Proposes to conduct fully mechanized open cast method quarrying for Colour granite extraction in an area of 4.965 ha in Survey No. 218 & 286, Thotakurapalem Village, Ravikamatham Mandal, Visakhapatnam District, Andhra Pradesh. In principle of Quarry lease application grant notice by the Director of Mines and Geology, Government of Andhra Pradesh vide notice no. 3866/R1-3/2017 dated 07.05.2018. Mining Plan was approved by Deputy Director of Mines and Geology, Vide letter No. 1347/MP-AKP/2018 dated 28.05.2018. Proposed Colour granite production is 38538 m3/ annum. Capital cost proposed for quarrying is Rs. 52 Lakhs. We already submitted to DEAC, Visakhapatnam for Environmental Clearance and its meeting held on 25.06.2018. DEAC recommended address a letter to SEIAA for clarification on this issue. Now we are submitting to SEIAA, AP for Environmental Clearance. 2.0 Quarry Lease Area Location Sri Angara Rajesh proposes to conduct fully mechanized open cast quarry. The quarry lease area of 4.965 ha is located at Survey No. 218 & 286, Thotakurapalem Village, Ravikamatham Mandal, Visakhapatnam District, Andhra Pradesh. The quarry lease area falls in the Survey of India topo sheet no. 65K/14 of Latitude 17°40'50.2"N and Longitude 82°48'34.0"E with an elevation of 103 m. The nearest village is Thotakurapalem located at a distance of 0.9 km in N direction. Nearest Railway station is Narasingapalli at a distance of 11.8 km in SE direction. Kannurupalem to Tattabanda road is passing at a distance of 0.3 km in W direction from the lease area. Narsipatnam to Anakapalli road is passing at a distance of 5.0 km in S direction. Tida RF is at a distance of 0.5 km in SW direction. Pangidi RF is at a distance of 0.4 km in SE direction. Guddepa RF is at a distance of 4.5 km in NW direction. Gollapalem RF is at a distance of 7.0 km in NW direction. Nallakonda RF is at a distance of 7.5 km in NW direction. Panduru RF is at a distance of 7.5 km in S direction. Gobburu RF is at a distance of 7.5 km in SE direction. Bayyavaram RF is at a distance of 8.0 km in SE direction. Erri Gedda seasonal vagu is fallowing at a distance of 5.0 km in West direction. Seasonal Jaji Gedda is flowing at a distance of 8.0km in West direction. Seasonal Vedurla Gedda is flowing at a distance of 7.0km in NE direction and also at a distance of 2.2km in South direction. Seasonal Mamidivaka Gedda is flowing at a distance of 8.2km in SE direction. Yeluru Canal is passing at a distance of 3.7km in South direction. There is no national A-3 Sri Angara Rajesh Annexure of Form-1

boundary, national park, wildlife/bird sanctuary and critically polluted areas within 10km radius from the quarry lease area. Details of the mine lease area are presented in table A-1. Table A-1 Details of the Lease area

Sy. No./ Area in Ownership State & District Mandal Village Plot No. hectares of occupancy Andhra Pradesh & Ravikamatham Thotakurapalem 218 & 286 4.965 Govt. Land Visakhapatnam 3.0 Exploration This is a new quarry. 4.0 Geological Reserves The deposit is found to be irregular in shape. Hence cross sectional method adopted for estimation of Geological Reserves. 5 cross sections A-A1 to E-E1 were drawn at equal distance perpendicular to the strike direction of the formation to estimate. The cross sections were drawn perpendicular to the strike direction, the cross sectional area of the individual sectional influence of 36 m (average) to arrive of colour Granite. The exposed outcrops and the reserves upto 23 m below the surface are considered under proved category of reserves and 20m below the proved reserves are considered under probable resources. Section wise calculation of Colour granite reserves are given in the following table. Table A-2 Reserves Estimation Section Area Influence Volume Reserves Category Section m² Distance m m³ @ 20% m³ Proved 6809 36 245124 49025 A-A’ Probable 4644 36 167184 33437 Proved 7081 36 254916 50983 B-B’ Probable 4734 36 170424 34085 Proved 7333 36 263988 52798 C-C' Probable 4824 36 173664 34733 Proved 7665 36 275940 55188 D-D' Probable 4914 36 176904 35381 Proved 8184 57 466488 93298 E-E' Probable 5048 57 287736 57547 Grand Total 2482368 496474 Reserves blocked under 7.5m buffer zone Section Area Influence Volume Category Section m² Distance m m³ A-A’ Proved 445 36 16020 A-4 Sri Angara Rajesh Annexure of Form-1

Probable 312 36 11232 Proved 422 36 15192 B-B’ Probable 312 36 11232 Proved 445 36 16020 C-C' Probable 312 36 11232 Proved 469 36 16884 D-D' Probable 312 36 11232 Proved 517 57 29469 E-E' Probable 317 57 18069 Grand Total 156582 Reserves blocked under Safety slopes Section Area Influence Volume Category Section m² Distance m m³ Proved 338 36 12168 A-A’ Probable 707 36 25452 Proved 295 36 10620 B-B’ Probable 682 36 24552 Proved 330 36 11880 C-C' Probable 711 36 25596 Proved 369 36 13284 D-D' Probable 738 36 26568 Proved 438 57 24966 E-E' Probable 792 57 45144 Grand Total 220230

4.1 Mineable Reserves and Life of the Quarry Description Quantity m3 Total Colour Granite Reserves 2482368 Reserves blocked under 7.5m buffer zone 156582 Reserves blocked under safety slopes 220230 Total reserves blocked 376812 Reserves available 2105556 Annual Production 38538 Life of the quarry: Mineable Reserves/Annual Production=2105556/38538=54.6 years or say 55 years

5.0 Quarrying Method The mining operations are carried out by fully mechanized opencast mining by developing the bench height of 6m with the help of Hydraulic excavator and compressor operated jack hammers and wire saw machine will be used for cutting the rock. Close spaced drilling of 0.2m was adopted along a straight line and charged with expansive powder to avoid cracks. Transportation will be made by trucks to dispatching points. A-5 Sri Angara Rajesh Annexure of Form-1

6.0 List of Machinery S. No. Description No’s 1 Compressor 3 2 Drilling Machines 1 3 Jack Hammer 9 4 Excavator 2 5 Tippers 4 6 Tractor with Water Tanker 1 7 Jeep 1 8 Wire Saw Machine 1 7.0 Year wise Development and production for five years 1st Year: During the first year working will initiated from SW of the quarry lease area carried with an area of 4285 m2 with one bench of 6m height will be excavated and producing 25710 m3 of rock mass, 5142 m3 of granite blocks will be recovered and 20568 m3 of waste rock will be generated. 2nd Year: During the second year working will be continued due of 1st year workings of the quarry lease area carried with an area of 4252 m2 with one bench of 6m height will be excavated and producing 25512 m3 of rock mass, 5102.4 m3 of granite blocks will be recovered and 20409.6 m3 of waste rock will be generated. 3rd Year: During the third year working will be continued below 1st year workings of the quarry lease area carried with an area of 3734 m2 with one bench of 6m height will be excavated and producing 22404 m3 of rock mass, 4480.8 m3 of granite blocks will be recovered and 17923.2 m3 of waste rock will be generated. 4th Year: During the fourth year working will be continued below 2nd year workings of the quarry lease area carried with an area of 3708 m2 with one bench of 6m height will be excavated and producing 22248 m3 of rock mass, 4449.4 m3 of granite blocks will be recovered and 17798.4 m3 of waste rock will be generated. 5th Year: During the fifth year working will be continued below 3rd and 4th year workings of the quarry lease area carried with an area of 6423 m2 with one bench of 6m height will be excavated and producing 38538 m3 of rock mass, 7707.6 m3 of granite blocks will be recovered and 30830.4 m3 of waste rock will be generated. During the five years operations a total rock mass of 134412 m3 will be excavated and 26882.4 m3 of granite blocks will be recoverable from this rock mass and remaining material

A-6 Sri Angara Rajesh Annexure of Form-1 of about 107529.6 m3 will go as mineral waste. Year wise production and waste generation details are presented in table A-3 Table A-3 Year wise Granite Production and Waste generation Working Area Bench Height Production, m3 Year Volume m3 m2 (m) Granite @20% Waste @80% 1 Year 4285 6 25710 5142 20568 2 Year 4252 6 25512 5102.4 20409.6 3 Year 3734 6 22404 4480.8 17923.2 4 Year 3708 6 22248 4449.6 17798.4 5 Year 6423 6 38538 7707.6 30830.4 Grand - Total 134412 26882.4 107529.6

9.0 Employment

S. No. Description Quantity 1 Mine Manager/Supervisor 1 2 Compressor operator 3 3 Excavator operator 4 4 Drillers 2 5 Excavator Helpers 4 6 Tipper drivers 8 7 Helpers 6 8 Cutters 6 9 Watch and ward 4 10 Accountant, Store Keeper and Supervisors 4 Total 42

A-7 Sri Angara Rajesh Annexure of Form-1

ANNEXURE II

Drilling Drilling plays vital role in determining the size and shape of rough blocks ie., 2m x 2m cross section with a bench height of 6m. Drilling Pattern is important in developing a working face and also preparing the rough blocks suitable for their use in appropriate processing units. There are no important places in and around the area. Drill-Hole patterns for primary and secondary with Uniform single line equidistant holes (line drilling) will be deployed for separation of blocks from mother rock. In the case of sheet rock the primary drilling will be in the form of equidistant vertical holes to take out blocks of Gang Saw. Drilling Parameters i. Drill holes diameter: 32 mm up to 9 m Long ii. Depth and inclination of the holes: Generally drilled vertically in an alignment, however in primary cutting in the absence of sheet joints to develop bottom level horizontal holes also be drilled. iii. Spacing and Burden: 0.3 m X 1.6 m iv. Explosive type: Not Applicable. The applicant proposes to use Expansive powder will be used for splitting the rocks.

A-8 Sri Angara Rajesh Annexure of Form-1

ANNEXURE - III

Water Requirement Water requirement for the project is mainly for Domestic source, maintaining the green belt and also for sprinkling on the haulage roads to mitigate dust emissions. The water shall be drawn from nearby villages. The water requirement of the project is presented in Table A-4. Table A-4 Water Requirement S. No Water Usage Quantity KLD 1 Wet drilling operation 10.6 2 Water sprinkling on haul roads and for waste dump 1.6 3 Domestic Water 1.9 4 Green Belt 0.6 Total 14.7 The generation of wastewater from domestic sources is expected to be approximately 1.5 KLD, which will be sent to septic tank followed by soak pit. Site Services It is proposed to provide the site services like mine office and other statutory constructions like rest shelter, first aid, work shed and drinking water as required at the quarry lease area. Drinking water will be supplied to the workers from the borewell opened in the adjacent agricultural field or from nearby village.

A-9 Sri Angara Rajesh Annexure of Form-1

ANNEXURE – IV Solid Wastes Generation and Management Plan During the five years operations a total rock mass of 134412 m3 will be excavated and 26882.4 m3 of granite blocks will be recoverable from this rock mass and remaining material of about 107529.6 m3 will go as mineral waste. The waste material will be shapes of cobble stones, building stones and pavement stones. The maximum waste will be utilization of available natural mineral and adopt value to increase the market for the colour granite products in various kinds and shapes. Dump Area The waste generated during plan period will be dumped in SE side of the lease area over an extent of about 0.5 ha to a height of 30 m. The waste will be kept aside for further value addition of the mineral in the shapes of cobble stones, building stones, pavement stones and finally left over waste will be re-handled for backfilling during the Conceptual Plan period.

A-10 SRI ANGARA RAJESH SURVEY NO. 218 & 286, THOTAKURAPALEM VILLAGE, RAVIKAMATHAM MANDAL, VISAKHAPATNAM DISTRICT, ANDHRA PRADESH

Studies and Documentation by: Team Labs and Consultants (An ISO 9001:2008 Certified Company) (MoE&F O.M. - S. NO: 25, List A-1) B-115 to 117 & 509, Annapurna Block, Aditya Enclave, Ameerpet, Hyderabad-500 038 Tel: 91-040-23748555, 23748616 Fax: 91-040-23748666. Email: [email protected]
