4. STUDIO TRANSMISSION AND SYNDICATION 4.1 STL – Studio Transmission Link 40 4.2 Redundix Solution 42

5.REMOTE CONTROL AND MONITORING 5.1 Barionet Device and Firmware 46

6. BARIX CONTOL LANGUAGE 6.1 ABCL – the key to your personalized audio solution 50 Solution finding with Barix Customer need

Barix provides with building blocs to address a variety of autio applications. By selecting the right Firmware and combining it with the appropriate hard- Firmware Selection Hardware Selection ware, Barix solutions solve audio applications in the most cost effective way. This document provides insight into the firmware and hardware components available from Barix. Barix gladly assists you in the solution finding by valida- ting your selection or supporting you in selecting the right components. Just The Perfect Solution contact [email protected]

Streaming Client FW Encoder Decorder

Serial I/O Amplifier Message Player Intercom FW USB Micro SD Talkstation Paging FW

Audio Recorder FW Audio Signage PoE STL Link

LIVE ENCODING 6 | Live Encoding

 Music streaming  Live music for events, festivals, open airs  Live speech streaming in schools, universities, churches  Background music for retail outlets  On hold music for VOIP telephone systems  Live surveillance

Instreamer Standard Firmware

The Instreamer Standard Firmware makes the streaming of audio over IP net- works smooth and easy. The software converts any audio signal into G.711, PCM or high-quality MP3 streams and can send the stream to up to 32 dif- ferent destinations across the LAN or over the . Supporting peer-to- peer connections with other Barix devices, the software can also be used for integration into wide audio infrastructures with Shoutcast or servers. Simple web and command interfaces makes the firmware configurable and the audio stream can be adjusted to the network bandwidth, set to send on CTS, on level or send always. Two physical ports are available (Ethernet/Se- rial), and with the BRTP protocol the application can communicate with other Barix devices on secured networks. Together with the Instreamer device, the firmware is an easy-to-install and cost-effective solution for professional audio streaming. Live Encoding | 7

FEATURES: Preloaded on: Instreamer

 Supported codecs: MP3 (VBR/CBR), PCM Works on:  Annuncicom PS1 Supported stream connections: HTTP, RTP, SIP, Annuncicom PS16 Raw UDP, Raw TCP, Icecast and Icecast ID3 Annuncicom 60 source, Shoutcast source Annuncicom 100 Annuncicom 155  Up to 32 BRTP streams at 128kbit/s Annuncicom 200  Supports Serial Port relaying (Serial gateway Annuncicom 1000 Exstreamer 500 over Network)  Streaming can be set to send always, send on CTS, send on Level, or manually via web interface  Supports SNMP protocol for monitoring device  The device can serve up to 6 concurrent HTTP radio streams or 8 UDP/RTP streams  Supports all General Purpose Inputs (GPIs) on the Exstreamer 1000, Exstreamer 500 and Annuncicom 1000. The Inputs are used either to trigger streaming or to send contact closures to a partner device with SW loaded capable of decoding the information 8 | Live Encoding

 Background music in shops, restaurants and bars  Live music broadcast for events  Speeches at schools, universities and churches  Live announcements  reception

Exstreamer / Streaming Client

The Streaming Client Firmware turns Barix Exstreamer devices into professi- onal network audio players, supporting MP3, G.711, PCM and other formats. The Streaming Client software enables a wide range of audio transport and background music applications. A three level priority setup ensures continous audio in case one source fails. Failover sources include other URL addresses or content on a locally connected USB storage. The firmware can easily be integrated into an existing infrastructure with a command or web interface. Several tools are built in, such as priority port setting for emergency calls and finetuning of the decoding speed to adapt to the encoded stream. Ba- rix realtime transport protocol (BRTP) enables the receiver device to open a pull session over secured networks, and maintain a continuous audio stream from a Barix Encoder to locations without a fixed IP address. Channel swit- ching can be done via command interface or IR remote control device, which makes the application easy to use for retail outlets, bars and restaurants. Live Encoding | 9

FEATURES:

 Plays MP3/AAC+ streams from network (HTTP, RTP, BRTP) and M3U (HTTP and local)  G.711 and PCM raw support in RTP/BRTP  Supports authentication (HTTP, Shoutcast, Icecast)  Shoutcast meta-data displayed on hardware featuring LCD  Autoplay functions plays all audio files inside USB/microSD without (standalone mode)  Relay control (if available on hardware) & Priority notification port  Allows centrally managed update of firmware, configuration and local contents (via HTTP)  Decoding correction allows fine tuning of the playback speed  Monitoring using SNMP and Barimon (HTTP, UDP)  Command interface via Serial, TCP, UDP, HTTP (CGI)  Supports proxy (HTTP proxy support)  Remote control support via API and IR (IR device dependent)  Serial gateway to transmit RS232 data to a remote location Preloaded on: Exstreamer 1xx  Shoutcast or commands can trigger the Exstreamer 2xx playback of local audio files Exstreamer 500  User Interface Development Kit for customization Exstreamer P5  Exstreamer 205 features a line input for passing audio from an external device (portable MP3 player)  VSC-Panel 10 | Live Encoding

 Live streaming to mobile phones  Museum guidance with mobile phone or other devices  Listening to music while working out in the gym  Audibility support for hearing impaired

Audio Signage Solution

Audio Signage is a smart solution by Barix to evolve the possibilities of Di- gital Signage. The audio stream of any TV channel can be sent over a WiFi connection to the customer’s smartphone to enable an intimate entertain- ment of the customer without disturbing the business environment with music or sound. The Barix Audio Signage App can be downloaded from the Apple and Google App store, and can be used together with earphones or loudspeakers to listen to the audio. When different audio channels are avai- lable, the Audio Signage Info Server Application can be loaded onto a Barix Exstreamer Store&Play device to show the channel information on the Audio Signage App. The network traffic and number of users must be kept in eye as a critical factor. Barix provides an application, with note and configuration file, for the Huawai AP5130DN Access Point, to configure the WiFi signal into a unicast stream and reach better audio quality. Live Encoding | 11

FEATURES:

 Low-latency streaming to cell phone app  Single channel or multi-channel support  Automatic recognition and dynamic listing of available channels  Audio Format: PCM / 24kHz 16bit mono  Option to integrate audio signage functionality within customer apps  Optional QR code to select the channel  IOS and Android compatible  Customizable logo on the App  Easy configuration

Works on: Instreamer Exstreamer Store&Play

MOVING AUDIO FROM A TO B 14 | Moving Music from A to B

 Retail in-store music  Music on hold  Looped messaging for kiosks and salespoints  Background music for hotels, restaurants, SPA’s

Store & Play

The Store&Play application supports a distributed audio management for companies with multiple sites. Playlists and audio files are stored on a cen- tralized FTP or HTTP server, where they are maintained offline, and where they can be downloaded by the remote playback devices at a scheduled time. This download mechanism enables an administrator to choose best time slot on network in case the network is overloaded or not reliable. The audio files are stored in the internal memory of a Barix Store&Play Exstrea- mer or on a connected USB device. Additionally to these sources an internet radio stream can be configured with a buffer time of one minute. Whenever the audio streamis interrupted, a priority list switches to the next configured source. Store&Play firmware supports Barimon subscription based service for centralized monitoring. Store&Play is the safe solution from Barix to ensu- re consistent audio playback!

Moving Music from A to B | 15

preconfigured on: Exstreamer Store&Play FEATURES:

 Local Storage and playback of Music, messages and ads (MP3, AAC+ and M3U files)  Content (audio files, playlists and config file) can be remotely updated via HTTP and FTP (periodically or during a restricted time slot)  Update playlists remotely and set them to play on a schedule  Playback of HTTP and RTP audio streams is supported  The device contains 8GB of internal memory and supports up to 32GB USB sticks  Supports a hundred playlists and 10’000 audio tracks  Schedule-based playback of messages  Fallback Configuration server settings in case of broken or missing configuration  Professional service monitoring via Logs from web UI, BariMon and SYSLOG 16 | Moving Music from A to B

 Emergency announcements in factories, public buildings, transportation  Announcement of shop openings or closings  Event voice announcements  Interactive application for museums, shops and shows in general

Digital Message Repeater

The Digital Message Repeater Application addresses the use of USB sticks in Barix devices with recorded audio files. Its main application is the local playback of prerecorded audio messages and emergency announcements in retail outlets and public buildings.

The playing can easily be triggered by any command interface or by assig- nment of keys on the Annuncicom PS16 or PS1 paging station. Messages can be stored on the USB flash stick and uploaded in the internal flash of the device. Moving Music from A to B | 17

FEATURES:

 MP3 audio files support  UDP, CGI, serial command interface (ASCII commands)  Local playback on analogue outputs  Relay activation on message playing (if available on hardware)  Playback triggered by contact closure (if available on hardware)  Message triggering and audio output volume can be configured from Web Interface or via command interface (UDP, CGI, serial)  Audio files upload on internal memory (instructions provided in the kit)  Barix X8 for additional 8 trigger inputs Works on:  Message mixed with audio from the line level Annuncicom PS1 Annuncicom PS16 input (if available on hardware) Annuncicom 60  Configurable options on buttons behavior Annuncicom 1xx Annuncicom 200  With command interface up to 100 messages Annuncicom 1000 are supported Exstreamer 1xx Exstreamer 2xx Exstreamer P5 18 | Moving Music from A to B

 Emergency announcements over IP connection to other sites  Streaming of emergency announcements for Barix ICpaging, Simple Paging, Streaming Client and SIP Client application using the priority/ notification port

Digital Message Streamer

The Digital Message Streamer application allows RTP streaming of locally on USB stored playlists in MP3 format with a synchronous analog playback for mo- nitoring purposes. The audio files and playlists can be downloaded at a precon- figured time from a remote FTP server.

The management of audio files can easily be done in the web interface, or by pressing an allocated key on the device. Moving Music from A to B | 19

Works on: Annuncicom 100 FEATURES: Annuncicom 200 Exstreamer 1xx Exstreamer 2xx  Unlimited amount of MP3 files (limited by Exstreamer 500 internal or USB memory – see device specs)  RTP streaming and local playback of up to 8 playlists  Broadcast and multicast support  Audio files and playlist updates via FTP at scheduled time  Up to three configurable times for FTP download from an external device (portable MP3 player)  NTP time with local zone and daylight saving settings  Possibility for forced download in case of NTP server failure  Playlist trigger from the Web Interface or from Barix X8 keys  Realtime volume control and local directory listing from the webUI 20 | Moving Music from A to B

 Feature rich cloud solution for background music, message on hold and announcement delivery  Multi-location background music delivery to retail outlets, hotel chains, fitness centers and others  Scheduled localized announcement insertion for entertainment, information and advertising  Turn-key solution for audio content providers

SoundScape Solution

SoundScape is a complete solution to manage and distribute audio over IP networks. With SoundScape, service providers now have a single, centralized solution for content delivery and network-wide monitoring and management, instead of requiring different platforms. The SoundScape solution brings together a central management software portal with corresponding audio playout devices.

Users with administrative access can create and schedule playlists featuring music, ads and promos from the head office, and can configure or update the firmware of the player devices across the network! At the playout loca- tions, Barix devices deliver high-quality audio content to speaker systems, with targeted advertisements seamlessly fading in and out of music streams. Moving Music from A to B | 21

FEATURES:

 Centralized management software (monthly subscription fee)  User friendly web interface  Reliable audio players with high-quality music reproduction  Dynamic ad insertions with seamless fade-in/out  Encrypted audio file distribution and storage  Seamless switching between live streams, stored playlists  Alarm generation, network reporting for monitoring and troubleshooting  Strong password protection  Advanced user management  Detailed time stamped logging of actual songs and adverts played Preloaded on:  Encryption of content for copyright security SoundScape Exstreamer

Works on: SoundScape Store & Play

INTERCOM & PAGING 24 | Intercom & Paging

 Door-intercom, talking over TCP/IP networks  Door-intercom/opening system  Emergency announcements and alarm light triggering in public infrastructures, for example airports  Emergency-intercom in public transport, elevators, tunnels

Annuncicom Standard Firmware

Peer-to-peer intercom application for fast and easy implementation in residential buildings and commercial infrastructures without a master-slave model. The Annuncicom Standard Firmware works fine with Barix Annuncicom devices in a peer-to-peer network, it supports the Barix ICGraph tool, to monitor the internal audio network. The firmware can be connected with other 3rd party control soft- ware on the computer (e.g. SureView-Immix). A wide range of console commands is available to perfectly customize Barix devices into the customer infrastructure.

Two input contacts and one output relay are available to trigger talking or perform machine executions like door opening. Up to eight devices can be addressed with unicast, multicast, broadcast or recognition of the last calling IP address. Annuncicom Standard Firmware is the perfect solution for a simultaneous audio transmission and machine control. Intercom & Paging | 25

Preloaded on: Annuncicom PS1 Annuncicom 100 FEATURES: Annuncicom 200

 Half duplex two-way communication using mono Works on: Annuncicom PS16 audio streams Annuncicom 60  Works over Internet connection Annuncicom 155 Annuncicom 1000  Choice of MPEG, G.711 and PCM audio formats  Easy integration into existing IT and intercom infrastructure  TCP and raw UDP streaming support  Controllable via standard web browser (PC, PDA, Web tablet) or via TCP/UDP and serial port  64 streaming targets table entries  SNMP traps sending on High and Low configurable audio levels  Line/Mic input support  Two button inputs plus relay output (see Annuncicom product sheet)  Supports supervision of microphone, speaker and temperature (on Annuncicom 155 and 1000)  Features priority notification port  Works with IC Graph application to monitor/ control the audio network 26 | Intercom & Paging

 Door intercom solutions  Emergency announcement systems  Large scale public announcement systems (e.g.ski-resort)

IC Paging Firmware

The Intercom & Paging Application firmware is the perfect solution for buil- ding intercom and paging systems over IP networks with a full-featured master-slave functionality. With this firmware, it’s easy to define groups and zones or multi-master architectures to switch to another control office when the first one is not reachable (f.e. during day/night shift). The same software can be set as ICMaster or ICClient after the installation.

The client version supports multichannel Background Music and interrupting voice announcements. On the master station, incoming calls can be showed on the display, set on hold or rejected. The additional ICgraph Java applicati- on allows to develop fully customized graphical interfaces for control, visuali- zation and management. ICGraph is running on various operating systems. Intercom & Paging | 27

FEATURES:

 full or half duplex mode of operation  8 configurable group target buttons, each group can address 128 devices with multicast or broadcast  With PS16 extension 104 devices can be addressed directly with unicast  Features priority notification ports  4 Master stations support (PS16/ICgraph)  no server needed  remote switching of client relay Works on: Annuncicom PS1  AIPHONE door panels support Annuncicom PS16 Annuncicom 60 Annuncicom 1xx Annuncicom 200 Annuncicom 1000 Exstreamer 1xx Exstreamer 2xx Exstreamer P5 28 | Intercom & Paging

 Add Barix devices to existing or 3rd party PA/ Intercom systems  Milestone® server integration for audio surveillance  Full-duplex communication  Adding new devices like loudspeakers or mics to an existing solution  Surveillance and workplace safeguarding

IP Intercom Application Works with:

IP Intercom Application firmware is a flexible and user-friendly tool to quickly -ex pand your audio infrastructure. It offers a full-duplex application for comfortable two-way communications in factories, office buildings or supermarkets. It inte- grates with Milestone AV server solutions to surveil and safeguard doors and workplaces. The firmware, which includes the Barix ABCL Programming kit, is highly adaptable and programmable to any customer’s need and allows an easy integration of Barix devices into 3rd party communication systems. Audio forwar- ding is achieved on the OS driver layer, which enhances sound quality and lowers latency at startup. RTP and raw-UDP packets are supported to speed up audio streaming and network handling time. All parameters can dynamically be set on a simple command inter-face, or can be configured from an existing platform. Also, the playback of files from a USB/FLASH file system can easily be managed with this application.

All product names, logos, and brands are property of their respective owners Intercom & Paging | 29

FEATURES:

 Destination IP can be unicast, multicast or broadcast  Full duplex communication  audio encoding is: uLaw / 24 kHz,uLaw / 8 kHz (G.711), aLaw / 24 kHz, aLaw / 8 kHz (G.711), PCM / 24 kHz (16bit), PCM / 8 kHz (16bit)  SNMP featured  Audio Echo Cancellation  two serial ports  Streaming destination can be changed dynamically via command interface  TCP/UDP command interface to control the device remotely  Streaming modes “send always”, “send on IO/ Works on: DI1, send level” and “respond” Annuncicom PS1 Annuncicom 60  DNS compatible for name resolution Annuncicom 1xx  Flow control can be set to Software or Annuncicom 2xx Annuncicom 1000 Hardware on RS-232 serial port Exstreamer 1xx  Sending syslog messages to remote host Exstreamer 200 Exstreamer 500 Exstreamer P5 30 | Intercom & Paging

 Security announcements for factories, boats, military buildings  Speech streaming in Schools, Universities, Churches  Intercom for kitchen and restaurant  Constant paging solution  Any to any intercom and announcement solutions

Any-to-All PA Application

The Any to All PA Application from Barix provides a fast and easy imple- mentation to stream audio to different locations. With this application, the audio stream starts to flow immediately upon pressing the talk button, without selecting any zones or addresses.

For every button on the device, the stream can be configured as unicast to a specific IP address, as multicast (to group of targets) or as broadcast (to all targets). Only speaking or listening is possible at one time. Any to All PA Application provides configuration parameters to set the stream to send always, or send on a specific input audio level. Intercom & Paging | 31

Works on: Annuncicom PS1 Annuncicom PS16 Annuncicom 60 Annuncicom 1xx Annuncicom 2xx Annuncicom 1000 FEATURES: Exstreamer 500

 The system supports a maximum of 16 individual targets, using Annuncicom Family hardware with an optional Barix X8 module attached or using a PS16 talk station with 16 buttons  One input can be defined as „stream to all destinations“  The application supports a web UI with configuration and status information  Application is supplied with source code (ABCL) and can be modified by user  Supports RTP streaming protocol  Uses MP3, G.711 audio format 32 | Intercom & Paging

 Adding PA functions to existing VOIP telephone systems  Adding single button call devices to a VoIP system  Cashier’s desk in retail outlets  SIP based door phone panels and talk stations  SIP addressable loudspeaker  SIP based alarm systems on highways, tunnels or railway lines

SIP Client Application

SIP Client Application is the right software to integrate Barix devices into an existing VOIP phone system. SIP Client works with most SIP based VoIP solu- tions including Cisco Unified Communications Manager or Asteriks and others. Using the Session Initiation Protocol (SIP), the client device receives a phone number in addition to its IP address, and can communicate either on a peer- to-peer connection or over a proxy-based connection (PBX).

Ringtone and busy tone guarantees that the call remains confidential and the recipient really receives the information. Featuring background music, audio rebroadcasting and special DTMF commands to quickly manage the device, the SIP Client is easy to integrate into an existing telephone system. Four different relay modes can be configured to open doors, windows, or to activate machines while simultaneously speaking. Intercom & Paging | 33

FEATURES:

 full-duplex phone communication  SIP (RFC 3261) compliant architecture  Supporting profiles for easy configuration  Configurable destination number to call for every input contact  Configurable call “pick up”/”hang off” timeout interval  Configurable “call/close on level” feature  Support for G.711 audio  Serial, UDP, TCP or CGI control interface  Priority-based notification audio messaging  Configurable relay to switch on at call answer/ Preloaded on: call ring Annuncicom 60  Transparent bidirectional Serial-To-TCP gateway Annuncicom 155  Friendly profile based WEB configuration UI Works on:  automatic network configuration (BOOTP, Annuncicom PS1 Annuncicom PS16 D H C P, I P z a to r ) Annuncicom 100  DTMF door open key sequence Annuncicom 200 Annuncicom 1000  Barix X8 product support to add 8 additional Exstreamer 1xx inputs for predefined calls Exstreamer 2xx Exstreamer 500  Features priority notification port Exstreamer P5 34 | Intercom & Paging

 Crestron Rava connection for door intercom  Peer-to-peer or group calling  Private house door intercom  Security check on public buildings

SIP Application

SIP Rava application has been developed to allow Barix Annuncicom devices to operate with Crestron RAVA Touch Panels for door intercom applications. It is perfectly tailored for the communication over SIP (Sessi- on Initiation Protocol) and CIP (Common Industrial Protocol), and supports Acoustic Echo Cancellation, DTMF commands and control interfaces for serial and CGI.

The software runs on half duplex mode in the common push-to-talk configuration, or in full duplex mode for synchronous talk and listening functionality. Featuring peer-to-peer connections, group calling or PBX integration, the application is the perfect client for your Crestron SIP Rava Intercom System.

All product names, logos, and brands are property of their respective owners Intercom & Paging | 35

Preloaded on: FEATURES: Annuncicom 100 Annuncicom 200

 Supports profiles for easy configuration Works on: Annuncicom 200  Configurable destination number to call for each input contact  Configurable call “pick up”/”hang up” timeout interval  Configurable “call/close on level” feature  Configurable “peer to peer” or “proxy based” connections  Configurable SIP and audio RTP ports  Support for G.711 and audio with Acoustic Echo Cancellation (AEC)  DTMF door open key sequence  Configurable relay activation at call answer/call ring  Configurable use of beep tone on call answer  Serial and CGI control interface  Profile based WEB configuration UI  10/100 Mbit Ethernet connection supports automatic network configuration (BOOTP, DHCP, IPzator, and as well as manual static IP configuration)  Several CIP messages are supported such as: IP_ID Tables of 8 entries, Receiving SIP Multicast paging  SIP Group call up to 8 peers  Works peer-to-peer or with SIP server (PBX)  Choose between “full-duplex” and “half-duplex” talk mode 36 | Intercom & Paging

 To reach staff wherever they are in the building: doctors, teachers, employees  To reach people from wherever you are on campus in response to live events: principals, security guards, janitors, or other personnel  To selectively announce information to specific zones

Simple Paging Solution

Simple Paging is a powerful Barix solution to implement a complete paging system into your enterprise. The Simple Paging Solution supports a master-slave model with a powerful interface to show and manage all connected devices, groups and zones. The installation can easily be done on the existing network and does not need a server. Barix offers its Annuncicom PS1 and PS16 as ideal master stations for Simple Paging.

A key-feature of the Barix Simple Paging Solution is the Simple Paging App to make public announcements from smartphones. The app is available for free from Apple App Store or Google Play. Access from mobile phone is protected through an optional password. Barix Simple Paging supports two announcement levels (normal paging and emergency notification) plus background music. To indicate voice announcements, an optional ‚pre-gong‘ chime is available. Intercom & Paging | 37

FEATURES:

 Make announcements from paging stations or smartphones!  Superior audio quality  Multi-zone system with busy/offline indication per zone  Make announcements selectively into one, some or all zones  Low power and no maintenance cost, no PC or server needed  Easily add zones and paging stations as you expand the system through a simple web UI  Mobile paging restricted to authorized users  Multiple Paging Stations  Paging Station indicate when Zones are busy  Supports simultaneous paging to independent targets  Dynamic status indication to make maintenance easy  Modular and easily expandable  Supports zoned Background Music playback via multicast for low network traffic Works on: Annuncicom PS1  Supports multiple mobile paging configurations: one set of Annuncicom PS16 groups for the principal, another for security! Annuncicom 60 Exstreamer 1xx  Works on a variety of Barix devices with and without amplifier Exstreamer 2xx  Independent volume setting for each Paging Zone Exstreamer P5

STUDIO TRANSMISSION AND SYNDICATION 40 | Studio Transmission and Syndication

 Studio Transmitter Link (STL  Studio to Studio link for live interviews  Syndicated radio distribution  Remote

Studio Transmitter Link

Studio Transmitter Link application is the fast and reliable STL solution from Barix to stream audio in full duplex PCM and half-duplex MP3 from a broadcast studio to a transmitter in a remote location. RTP over UDP protocol guarantees a low latency and good reliability of the audio stream at the same time. The application can stream to upto eight unicast or multicast destinations or can send in broadcast mode.

Several administration tools like keep alive handshake, contact closure tunneling, SNMP traps, serial gateway, multicast and DNS are supported. The optional Reflector service helps installing the connection over internet when no fix external IP address is available. STL application is a very powerful and flexible tool for professional radio distribution. Studio Transmission and Syndication | 41

Preloaded on: Exstreamer 500

FEATURES: Works on: Annuncicom PS1  WEB based, “easy to use” configuration Annuncicom PS16 Annuncicom 60  Audio formats include G.711 (µ/A-law) 8kHz/24kHz mono, Annuncicom 1xx over PCM 8kHz mono up to PCM 48kHz stereo and MP3 Annuncicom 200 Annuncicom 1000  Failover playback from USB on stream loss Exstreamer 1xx (decoder only)  Full duplex capable (encoding/decoding Exstreamer 2xx (decoder only) Exstreamer P5 (decoder only)  Configurable streaming mode: stream on level, stream on Instreamer (decoder only) contact, stream always  Configurable RTP delay on the decoder side  Configurable input source, input gain and output level  Configurable device relay‘s working mode  Configurable SNMP or/and SMTP (e-mail) messaging service  Configurable COM ports for TCP or UDP based serial gateways  Configurable security settings  Unidirectional studio-transmitter link can pass firewallS using BRTP protocol  (QoS) and (DSCP)  fading effect for new connections  customizable with BCL  Local and Remote stream and I/O status reporting 42 | Studio Transmission and Syndication

 Error resilience for studio to transmitter streaming  Studio to studio streaming (e.g. radio syndication or contribution)  Any kind of RTP streaming with delicate audio quality

Redundix Solution

Redundix by Barix is a solution that improves the quality of an RTP stream link using two mechanisms. The first is time-diverse routing, where the same audio stream is sent twice over the same link, immediately on encoding, and also time-delayed. The second is path divergent routing, where two streams are sent using separate networks.

At the receiving point, all streams are buffered and combined into one final „repaired“ stream. Redundix by Barix will cope with problems of the network infrastructure, including glitches, unreliable connections or even brief inter- ruptions. Studio Transmission and Syndication | 43

FEATURES:

 Automatic healing of RTP streams  Reduces audio glitches due to network issues  Encoder/Decoder independent: Can be used with existing infrastructure  Features time and/or path redundancy  2 Ethernet connectors for connections to independent IP infrastructures  Strong password protection  Web interface for configuration  Up to 10’000 miliseconds of user configurable time diversity Preconfigured on: Barix Redundix device

REMOTE CONTROL AND MONITORING 46 | Remote control and monitoring

 Industrial control and monitoring, machine control, serial, temperature, analogue and digital I/O  Home automation for control of thermostats and lighting  Access control and security systems driving horns or lights via relays or I/O  Environmental monitoring for power stations, industrial plants and buildings

Barionet device and firmware

Universal, programmable I/O device server for automation engineering in private houses, public buildings, in public transport and network infra- structures. The Barionet device covers a wide range of automation appli- cations for machine control, temperature/humidity monitoring, door-light steering, alarming and many more. With BCL programming language the Barionet is highly adaptable to all electronic control systems.

BCL programming allows the configuration of hardware interfaces like net- work, I/O, relay, temperature sensor, Wiegand, Serial and 1-wire. On the control side HTTP/CGI, UDP, TCP, SNMP and Modbus/TCP are suppor- ted, other protocols can be added over BCL programming. The Barionet products enable remote control and monitoring of infrastructure over the network in order to streamline operations. Remote control and monitoring | 47

FEATURES:

 Control and monitoring via Modbus, HTTP or SNMP  2 relay outputs, 4 digital outputs, 4 analog or digital inputs  Included webserver to store own applications/pages  Two serial ports for RS-232 and RS-422/RS-485 interfaces  Configurable SNMP traps, e.g. for input state change  DIN rail mounting capability  BCL programmable (Barix Control Language)  Up to 50 temperature sensors can be attached  analog inputs from zero to 5 volts DC and higher voltages with external resistor  Free programmable 1-wire interface on Barionet50, allows to add own 1-wire drivers  All input and output functions are addressed using a common I/O address map  Digital input with detection frequency up to 30 Hz  Barix X8 Expansion Module provides 8 independent inputs

or outputs Available:  Barix R6 expansion module provides 6 additional strong Barionet 50 (BCL) voltage relays (<250V / 10A) Barionet 100 (BCL)  Barix I/O 12 module provides 12 opto-isolated inputs and 12 outputs

BARIX CONTOL LANGUAGE 50 | ABCL Firmware

Make Barix devices do what you want:

 Customize the Barix SIPclient  Adapt Barix IP Intercom  Develop your own application

ABCL Firmware

The ABCL Firmware helps developers to customize BARIX devices to their special requirements. ABCL Firmware is fully programmable and comes with a range of development tools and programming examples to perfectly taylor Barix devices to a customers specific need. Easy to program with any kind of ASCII text editor, the software can be used to control Audio, network, serial, USB, LCD display, LED control, and IO control interfaces.

Upload the new code as an upgrade to the device or design your program from the outset in your text editor. BARIX Control Language is a simple in- terpreted high-level language to easily build up your electronic infrastructure. When the market is asking for new solutions, ABCL is the right instrument to implement new ideas. Find and share BCL-applications at: http://bcl-applications.info ABCL Firmware | 51

FEATURES:

 Interpreter firmware for free programmable customized application  contains complete development environment (Tokenizer and Web2cob)  The ABCL language can be compiled on Windows or  Internal webserver for own files/setup  Web Pages can include dynamic values  Full duplex audio in PCM or G.711 mono (for AnnunFDx application)  ABCL programming allows access to VSC Panel, PS16 display, LEDs, Network, audio, digital IOs, serial and USB  “Send on Level” mode with fast audio startup FreeBCL-source code available for: (for AnnunFDx application)  Any-to-All Firmware  RTP streaming with buffer management  Digital Message Repeater (for AnnunFDx application)  Digital Message Streamer  serial RS232 tunnel bi-directional  IC Paging Applications (for AnnunFDx application)  IP Intercom  SIP Client Application Find and share BCL-applications at:  STL Firmware http://bcl-applications.info 52 | Hardware

ANNUNCICOM FAMILY EXSTREAMER FAMILY IP Intercom and paging devices for bidirectional transmission of high quality Audio over IP devices for high quality audio streaming, Paging audio, contact closures and serial data over IP networks. and music distribution

Annuncicom 60 Exstreamer 100/105 Intercom / Paging device with contact closure inputs, mic/speaker IP Audio decoder with USB flash interface/ support, balanced audio output, PoE, 5W amplifier MicroSD slot and serial port

Annuncicom 100 Exstreamer 110/120 Intercom / Paging device with contact closure inputs IP Audio decoder with IR receiver and LCD display, and relay output, mic/speaker support, 2W amplifier relay output, serial port and USB/MicroSD

Annuncicom 200 Exstreamer P5 Intercom / Paging device with contact closure inputs and relay out- IP Speaker device, Power over Ethernet (PoE), put, mic/speaker support, PoE, 8W amplifier 5W audio output, RS-485 control port

Annuncicom 155 Exstreamer 200/205 Industrial, ruggedized device with dual Ethernet, IP Audio decoder with S/PDIF, IR receiver and supervised Mic/Speaker and control interface, balanced audio out- 2x25W amplified output, serial port, USB/MicroSD, put, rail certification EN50155, 5W amplifier stereo line-in for feed through (205 only)

Annuncicom 1000 Exstreamer 500 Professional Intercom / Paging device with supervised contact closu- Professional Mulitprotocol IP Audio de-/encoder res and relay outputs, 48V capable with I/O, balanced stereo audio, serial port, USB

Annuncicom PS1 Exstreamer 1000 Desktop/Wallmount IP Intercom and paging master Professional Mulitprotocol IP Audio de-/encoder with I/O, balanced station, headphone and gooseneck mic support, PoE stereo audio, serial port, AES/EBU and USB

Annuncicom PS16 Exstreamer SoundScape Desktop IP Intercom and paging master station, expandable key IP Audio decoder with internal 8 GB memory, keypad and display for field. PoE capable, redundant power supply use with the SoundScape cloud-based business music and advert delivery system

Exstreamer Store&Play INSTREAMER IP Audio decoder with internal 8 GB memory and external USB me- mory for downloading and playback of scheduled audio as well as Multiprotocol Audio over IP encoder with line level analog input (ste- live streaming applications. Configurable to work with SoundScape reo), serial port, low latency, PCM, G.711 and MP3 encoding platform Hardware | 53

BARIONET FAMILY OEM PRODUCTS Universal, Programmable I/O device server with web server, Modbus/TCP and Versatile embedded IP Audio module for OEM applications. SNMP support

IP Audio Module 102 Barionet 50 full I/O and codec/DSP capabilities, two serial ports, versatile digital Two serial ports (RS232 & RS485), 4 digital inputs, 4 relay outputs I/O, Encoding/Decoding, 5V supply and Dallas 1-wire support

IP Audio Module 300 Barionet 100 low cost version with limited feature set, one serial port, digital I/O, Two serial ports (RS232 & RS485), 2 relay and 4 digital outputs, 4 digi- Decoding only, 3.3V supply tal and 4 digital + analog inputs and Dallas 1-wire support, UL listed

IP Audio Module 302 Universal, standalone, IP Audio module, to encode and decode REDUNDIX BOX IP audio streams from/to analog sources. Features bidirectional Redundancy transmitter/receiver for any kind of point-to-point RTP Streaming full-duplex VOIP for Paging and Intercom Applications, 3.3V supply

IP Audio Module 400 Powerful and versatile codec (encoding/decoding), Linux based and Redundix Box programmable with a wide range of programming languages, including Barix Redundix makes your audio transmission error resilient by enab- C++, LUA, PHYTON. Featuring Quadcore Cortex™ A7 processor, USB, ling path and temporal link redundancy with automatic repair functio- serial, digital I/O, WiFi, Mic+Line I/O nality, LAN/WAN/WiFi interfaces

BARIONET 1000 For detailed hardware specifications OpenWrt/LEDE based universal, fully programmable I/O device server for OEM contact Barix support:

www.barix.com/downloads Barionet 1000 Two serial ports, 2 relay and 4 digital outputs, 4 digital and 4 digital + [email protected] analog inputs and Dallas 1-wire support, UL listed +41 434332211 Functionality Details

Detailed information on the HW and the firmware supported features can be found How to install the firmware on the Barix Wiki page at: http://wiki.barix.com/index.php5?title=Product_Matrix  Download the firmware from http://www.barix.com/downloads  Open your browser and connect to the devices web server Find detailed specifications, for example what type of microphone to connect to  Click on update and follow the instructions which device, availability of interfaces and detailed functionality of firmware.

Please refer to the Matrix on the web for the most current information: To comple- tely understand the capability of each firmware, download the user manual from the download section on the Barix web page. There you find all the details and program- ming interface description of the firmware: https://www.barix.com/downloads/

WNLOAD O OF D E E R F

WWW.BARIX.COM N O S E O FT WAR Barix Professional Services

While reliable hardware and flexible programming go a long way to serving an installation, sometimes you need that extra lift to bring the best out in each project. This is just one reason why Barix Professional Services was established.

The Barix Professional Service team brings more than 15 years of experience in audio, paging, VoIP and intercom application software and product development. Our strength is to help shorten your time to market by providing fast, cost-effective and robust development services, and to deliver solutions tailored to your needs.

Swiss Quality Products Best Worldwide Support

Barix is represented worldwide by a network of partners. Check our homepage for a list of distributors: www.barix.com Barix AG [email protected] www.barix.com +41 43 433 22 11
