MOBILE GUN SYSTEM

STRYKER MGSVANGUARD FOR ARMY TRANSFORMATION STRYKER MGS MOBILE GUN SYSTEM MGS MISSION ROLE REQUIREMENTS FIRE SUPPRESSION Gunner (3) gunner’s periscopes • Exceptional tactical mobility for full 1 shot FM200 for troop compartment Compact modular sight spectrum operations 2 shot FE25 for engine compartment Day & thermal imager • Air transportable in combat ready Automatically activated 2-axis stabilization configuration Wide and narrow field of view • High baseline vehicle commonality with PERSONNEL other variants Auxiliary 3 total • 14.5 mm integral armor protection (optional (1) Direct optic feed to both 1 driver RPG-7 armor protection) commander and gunner 1 vehicle commander • Battlefield survivability and firepower to 1 gunner LAND NAVIGATION EQUIPMENT carry out combat missions • Supportability and affordability ARMAMENT GPS PLGR COMMUNICATION (C4ISR) SIZE/WEIGHT Primary (INCLUDING BASE ARMOR) • 105mm Low Profile Turret SINCGARS radios • M68A1E1 105mm cannon with muzzle EPLRS Length 275 inches brake Squad leaders video display terminal Width 107 inches • Fires all NATO ammunition FBCB2 Computer (Commander) Height 106 inches • 18 ready rounds Combat Weight GVW 41,300 lbs. • Auto loader achieves 6 second cycle rate PERFORMANCE @ GVW • All ammunition protected by spall liners Maximum speed 60 mph Maximum range (40mph) 330 miles Secondary Slope performance: Frontal: 60% • (2) 7.62mm machine guns Side: 30% (1) coaxial mounted Vertical climb 23 inches (1) commander’s weapon Gap 78 inches • (4400) rounds Ancillary POWER TRAIN & SUSPENSION • (2) M6 Smoke grenade launchers Engine 350 hp CLIMATE CONTROL SYSTEM Transmission 6 speeds forward 1 Reverse (2) roof vent fans Transfer case 2 speed (1) crew/engine heater Differentials 4 automotive • (1) driver heat exchanger Suspension 8 wheel hydropneumatic • (2) crew heat exchangers independent with Height Control ATGM WIRE CUTTER Driven wheels 4wd full time 8wd selectable 1 driver Tires Central Tire Inflation 1 turret crew System with runflats VISION Brakes Power brakes with ABS on rear three axles Driver (3) M-17 periscopes (1) DVE AIR TRANSPORTABILITY Vehicle Commander C-130 (6) commander’s periscopes C-5A Day & thermal imager C-17 360˚ viewing Wide and narrow field of view

General Motors Defense, 1660 L Street N.W., Suite 401, Washington, D.C., U.S.A. 20036 Phone: (202) 775-5020/5047 Fax: (202) 775-5046 www.gm-defense.com General Dynamics Land Systems website: www.gdls.com

130-680 2.5M 10/02
